minipack Modular 70 Digit Restyling Parts List

Minipack-torre S.p.A.
Via Provinciale, 54 - 24044 Dalmine (BG) - Italy
Tel. (035) 563525 – Fax (035) 564945
E-mail:info@ minipack-torre.it
http://www.minipack-torre.it
Catalogo ricambi
( Valido dalla matricola nr. 498 del 05.2011 )
Spare parts catalogue
( Valid from serial number 498 dated 05.2011 )
REV.02: modificato colore da grigio RAL7032 a grigio RAL7035. REV.02: modified colour from grey RAL7032 to grey RAL7035.
CONSULTARE ATTENTAMENTE QUESTO CATALOGO PRIMA DI ORDINARE PEZZI DI RICAMBIO
CAREFULLY READ THIS CATALOGUE BEFORE ORDERING ANY SPARE PART
DOC. N. FM112020 REV. 02 Ed: 05.2013
LEGENDA PARTICOLARI / ITEMS DESCRIPTION
Pos. Pos.
1.02 S0K00303 Kit morsetto anteriore / Front clamp kit
1.03 S0K00304 Kit morsetto posteriore / Rear clamp kit
1.04 S03A0306 Kit morsetto centrale portalama / Blade holder central clamp kit
1.06 S03A0310 Kit isolatori / Infill blocks kit
1.07 S03A0319 Kit profilati porta isolatori / Infill holder channel kit
1.08 S03A0901 Kit protezione antinfortunistica anteriore / Front guard kit
1.09 S03A0903 Kit protezione antinfortunistica laterale / Side guard kit
1.10 KR030001 Lama saldante teflonata / Teflon-coated sealing blade
Codice Code
Descrizione Description
TAVOLA 1 / SCHEME 1
1
ESPLOSO MACCHINA / MACHINE DETAIL DRAWING
TAVOLA 1 / SCHEME 1
2
LEGENDA PARTICOLARI / ITEMS DESCRIPTION
Pos. Pos.
2.00 FM090666 Copertura di fondo centrale / Central lower cover
2.01 FM090665 Copertura di fondo destra / Right lower cover
2.02 FM090671 Copertura di fondo sinistra / Left lower cover
2.03 FM095789 Supporto macchina sinistro RAL7035B. / RAL7035B. machine left support
2.04 FM095896 Supporto macchina destro RAL7035B. / RAL7035B. machine right support
2.05
2.05.01
2.05.02
2.06 FM095895 Carenatura RAL7035B. / RAL7035B. fairing
2.07 FM770509
2.08 FM770510
2.09 FM280270 Protezione anteriore lama / Front guard blade
2.10 FM280239 Protezione laterale lama / Side guard blade
2.11 S0095580 Pulsantiera RAL7035B. / RAL7035B. push button panel
2.12
2.12.01
2.12.02
2.12.03
2.13 FE080001 Interruttore 20A / Switch 20A
2.14 FM090039 Quadro comandi RAL9005B. / RAL9005B. command panel
2.15 FM095195 Carter / Carter
2.16 FM140001 Profilato “ROLLGE 150” / “ROLLGE 150” channel
2.17 FM220501 Angolare per guida / Guide corner
2.18 FE340501 Porta contatti / Contacts holder
2.19 FE340005 Pulsante di emergenza / Emergency pushbutton
2.20 FE340001 Pulsante di marcia / Start button
2.21 FE085004 Selettore MAN-AUT / MAN-AUT selector
Codice Code
PC03G001 PC03I000 FM090357 FM090162 FM300003
S0190012
SM190016
FM110134
FE120339
Descrizione Description
Kit piatto di confezionamento RAL7035B. / RAL7035B. packaging plate kit Kit piatto di confezionamento inox (optional) / Inox packaging plate kit (optional) Piatto di confezionamento RAL7035B. / RAL7035B. packaging plate Piatto di confezionamento inox (optional) / Inox packaging plate (optional) Telaio piatto di confezionamento / Packaging plate frame
Ruota
100 / Wheel 100
Ruota
100 con freno / Wheel 100 with brake
Pannello + scheda elettronica / Panel + electronic board Pannello / Panel Membrana adesiva per scheda / Adhesive membrane x electronic board Scheda elettronica / Electronic board
TAVOLA 2 / SCHEME 2
3
ESPLOSO MACCHINA / MACHINE DETAIL DRAWING
TAVOLA 2 / SCHEME 2
4
5
LEGENDA PARTICOLARI / ITEMS DESCRIPTION
Pos. Pos.
3.01 PB13B004 Kit supporto bobina RAL7035B. / RAL7035B. film roll support kit
3.02 S03A0602 Kit tubo porta bobina / Film roll tube kit
3.03 S03A0607 Kit astine microforatore / Microperforator rods kit
3.04 FM660002 Carrello con ruota / Wheeled trolley
3.05 FM220501 Angolare per guida / Guide corner
3.06 FM090364 Supporto bobina RAL7035B. / RAL7035B. film roll support
3.07 S03A0605 Kit rotellina con aghi / Microperforator with needles kit
3.08
3.08.
3.09 FM710318 Rullo di rinvio / Film drive roller
Codice Code
S03A0606
01
S0K00610
Descrizione Description
Kit rotellina con cava / Slotted microperforator kit Kit anelli in gomma per rotellina (10 pezzi) / Rubber rings kit for wheel (10 pcs)
TAVOLA 3 / SCHEME 3
6
ESPLOSO MACCHINA / MACHINE DETAIL DRAWING
TAVOLA 3 / SCHEME 3
7
LEGENDA PARTICOLARI / ITEMS DESCRIPTION
Pos. Pos.
4.01 S0K01001 Kit flangia bloccaggio barra torsione / Torsion bar blocking flange kit
4.02 FM540007 Bussola / Bush
4.03 FE220133 Microinterruttore / Microswitch
4.04 FM060024 Leva sicurezza / Security lever
4.05 S0K01002 Kit perno dx rotazione campana / Hood rotation right pin kit
4.06 FM200051 Perno / Pin
4.07 FM640002 Testa a snodo / Rod end
4.08 FM170135 Molla / Spring
4.09 FM160055 Fermo per leva / Lever blocking device
4.10 FM290101 Supporto campana / Hood support
4.11 KR030002 Kit teflon / Teflon kit
4.12 S0130405 Kit profilati porta gomma superiore / Upper rubber holder channels kit
4.13 FM350024 Gomma silicone bianco Lg.1550 / White silicone rubber Lg.1550
4.14 FM300034 Telaio / Frame
4.15 FM200093 Distanziale / Spacer
4.16 FM170117 Molla / Spring
4.17 FM290238 Supporto / Support
4.18 S0K00412 Kit tastatore microinterruttore / Microswitch screw kit
4.20 S03A1003 Kit alloggiamento barra di torsione / Torsion bar housing kit
4.21 FM340100 Bussola per barra torsione / Torsion bar bush
4.22 FM170003 Barra di torsione / Torsion bar
4.23 FM250103 Tubo x barra di torsione / Tube x torsion bar
4.24 FE220136 Microinterruttore / Microswitch
Codice Code
Descrizione Description
TAVOLA 4 / SCHEME 4
8
ESPLOSO MACCHINA / MACHINE DETAIL DRAWING
TAVOLA 4 / SCHEME 4
LEGENDA PARTICOLARI / ITEMS DESCRIPTION
Pos. Pos.
5.01 AV130003 Gruppo avvolgitore / Rewinder group
5.02 FM300141 Traversa / Crosspiece
5.03 FE190032 Interruttore / Switch
5.04 FM010041 Albero avvolgitore film / Film rewinder shaft
5.05 FM160111 Rondella / Washer
5.06 FE220105 Microinterruttore / Microswitch
5.07 FM290175 Supporto avvolgitore / Rewinder support
5.08 FM160104 Ghiera / Ring nut
5.09 FM170161 Molla / Spring
5.10 FM120040 Flangia mobile / Movable flange
5.11 FM250128 Mozzo / Hub
5.12 FM120041 Flangia fissa / Fixed flange
5.13 FM280326 Piastrina / Plate
5.14 FM250074 Rullo / Roller
5.15 FM030063 Asta / Rod
5.16 FM060027 Leva / Lever
5.17 FM290172 Supporto leva / Lever support
5.18 FE220101 Protezione microinterruttore / Microswitch guard
5.19 FM290107 Supporto motoriduttore / Gearmotor support
5.20 FE250016 Motoriduttore / Gearmotor
5.21 FM095138 Carter / Case
5.22 FM290258 Supporto rinvio film / Film transmission support
5.23 FM200069 Perno per rullo di rinvio / Transmission roller pin
5.24 FM250049 Rullo rinvio / Transmission roller
5.25 S0K00407 Kit guida a piolo per film / Film guide kit
5.26 FE310122 Cavo 3X0,75X1500 / Cable 3X0,75X1500
5.27 FM160231 Anello guida film / Film guiding ring
Codice Code
Descrizione Description
TAVOLA 5 / SCHEME 5
9
0
ESPLOSO MACCHINA / MACHINE DETAIL DRAWING
TAVOLA 5 / SCHEME 5
1
LEGENDA PARTICOLARI / ITEMS DESCRIPTION
Pos. Pos.
6.01
6.01.
6.01.
6.01.03
6.01.04
6.01.
6.01.06
6.01.07
6.01.08
6.01.09
6.01.11
6.01.12
6.01.13
6.01.14
6.01.15
6.01.
6.01.17
6.01.
6.01.21
6.01.22
6.01.23
6.01.24
6.01.25
6.01.26
6.01.27
6.01.28
Codice Code
NT130002
01
S0130023
02
S0130022 FM710112 FM200025
05
FM200026 FM095116 FM710304 FM090403 FM280313 FM040008 FM300172 FE250043 FM260022 SM100001+ FM550006
16
FM040005 FM160056
20
FM290130 FM610022 FM520058 FM290239 FM140019 FM040009 FM140020 FM290131 FM510049
Descrizione Description
Kit nastro trasportatore / Transport belt kit Kit rullo traino / Transmission roller kit Kit rullo rinvio / Transmission roller kit Nastro / Conveyor belt Vite di regolazione / Adjusting screw Vite di regolazione / Adjusting screw Carter / Case Rullo rinvio / Transmission roller Piano scorrimento / Sliding plane Piastra supporto motoriduttore / Gearmotor support plate Blocchetto di tensionamento / Tensioning brake Telaio nastro / Belt frame Motoriduttore / Gearmotor Pignone / Pinion Catena / Chain Giunto / Joint Blocchetto di regolazione / Adjusting brake Distanziale / Specer Supporto anteriore / Front support Cuscinetto radiale / Radial bearing Seeger per fori / Seeger ring Supporto / Support Guida femmina supporto / Female guide support Blocchetto di regolazione / Adjusting brake Guida maschio supporto / Male guide support Supporto / Support Volantino / Handwheel
TAVOLA 6 / SCHEME 6
11
ESPLOSO MACCHINA / MACHINE DETAIL DRAWING
TAVOLA 6 / SCHEME 6
12
LEGENDA PARTICOLARI / ITEMS DESCRIPTION
Pos. Pos.
7.01 FE260020 Ventilatore / Fan
7.02 FM290171 Supporto / Support
7.03 FM400001 Batteria di raffreddamento / Cooling system battery
7.04 S0K02005
7.05 FM092001 Piano di base / Base plane
7.06 FM250506 Tubo serbatoio Lg.660mm / Tank tube Lg.660mm
7.07 FM250554 Tubo impianto raffreddamento Lg.660mm / Cooling plant tube Lg.660mm
7.08 FM250512 Tubo impianto raffreddamento Lg.1300mm / Cooling plant tube Lg.1300mm
7.09 FM250554 Tubo impianto raffreddamento Lg.660mm / Cooling plant tube Lg.660mm
7.10 FM250508 Tubo impianto raffreddamento Lg.330mm / Cooling plant tube Lg.330mm
7.11 FM160102 Bocchettone impianto raffreddamento / Cooling plant filler
7.12 FM160103 Controdado / Lock nut
7.13 FM510302 Tappo / Cap
Codice Code
S0K02004 S0K02006
Descrizione Description
Kit elettropompa (per 230-380-415V) / Electropump kit (for 230-380-415V) Kit elettropompa (per 200V) / Electropump kit (for 200V) Kit elettropompa (per 208V) / Electropump kit (for 208V)
TAVOLA 7 / SCHEME 7
13
ESPLOSO MACCHINA / MACHINE DETAIL DRAWING
TAVOLA 7 / SCHEME 7
14
5
LEGENDA PARTICOLARI / ITEMS DESCRIPTION
Pos. Pos.
8.01 FM300021 Telaio / Frame
8.02 FM290138 Supporto microinterruttore / Microswitch support
8.03 FE220135 Microinterruttore / Microswitch
8.04 FM610708 Supporto NSK / NSK support
8.05 FM060015 Manovella / Handle
8.06 FM160031 Distanziale / Spacer
8.07 FM640002 Testa a snodo / Rod end
8.08 FM060016 Biella / Connecting rod
8.09 FM760005 Riduttore / Reduction gear
8.10 FE245004
8.11 FM290223 Supporto cammes / Cams support
8.12 FM070024 Camme / Cam
8.13 FM010012 Albero / Shaft
Codice Code
FE245008 FE245006
Descrizione Description
Motore 220/380/415V / 220/380/415V Motor Motore 200V / 200V Motor Motore 208V / 208V Motor
TAVOLA 8 / SCHEME 8
1
6
ESPLOSO MACCHINA / MACHINE DETAIL DRAWING
TAVOLA 8 / SCHEME 8
1
7
ESPLOSO MACCHINA / MACHINE DETAIL DRAWING
TAVOLA 9/ SCHEME 9
POS
CODICI PARTICOLARI
POS.
1 FE120349 Modulo potenza / Power board 1 2 FE290405
3 FE290401 Fusibile 2A / Fuse 2A 3 4 FE290401
5 FE370006 Relè 24V / Rele 24V 1 6 FE110602 Contattore LC1-D09B7/ Contactor LC1-D09B7 3 7 FE110615 Contattore LC1-D18B7 / Contactor LC1-D18B7 1 8 FE290121 Fusibile T2A / Fuse T2A 1 9 FE440026
10 FE440622
ITEMS CODE
FE290407
FE290402
FE440025 FE440621
DENOMINAZIONI PARTICOLARI ITEMS DESCRIPTION
Fusibile 10A (380-415V) / Fuse 10A (380-415V) Fusibile 16A (200-208-220V) / Fuse 16A (200-208-220V)
Fusibile 2A (380-415V) / Fuse 2A (380-415V) Fusibile 4A (200-208-220V) / Fuse 4A (200-208-220V)
Trasformatore 400VA (380-415V) / Transformer 400VA (380-415V) Trasformatore 400VA (200-208-220V) / Transformer 400VA (200-208-220V) Trasformatore 2500VA (380-415V) / Transformer 2500VA (380-415V) Trasformatore 2500VA (200-208-220V) / Transformer 2500VA (200-208-220V)
1
Q.tà
Q.ty
2
2
1 1
SCHEMA ELETTRICO
WIRING DIAGRAM
18
SCHEMA ELETTRICO
WIRING DIAGRAM
19
B1 B2 B3 B4 B5 E1/2 ER1 F1 F2 F3 F4 FU1 K1 M1 M2 M3 M4 Q1 Q2 QM1 QM2 QM3 QM4 QM5 S0 S1 S2 SK1 T1 T2 X1 X2
LEGENDA SCHEMA ELETTRICO
WIRING DIAGRAM DESCRIPTION
Finecorsa discesa telaio Frame descent limit switch Finecorsa salita telaio Frame rise limit switch Finecorsa esclusione sicurezza Safety device cutting out limit switch Finecorsa di sicurezza Safety limit switch Finecorsa avvolgitore Rewinder limit switch Ventilatore di raffreddamento Cooling fans Resistenza lama saldante Sealing blade heater Fusibili lama saldante 10.3X38 Sealing blade fuse 10.3X38 Fusibili motori 10.3X38 Motor fuse 10.3X38 Fusibili trasformatore ausiliario 10.3X38 Auxiliary transformer fuse 10.3X38 Fusibile motori ventilatore / pompa 5X20 Ventilator / pump motor fuse 5X20 Fusibile scheda 5X20 Board fuse 5X20 Modulo di potenza Electronic control board Motore nastro Belt motor Motore automazione telaio Frame drive motor Motore pompa di raffreddamento Pump motor Motore avvolgitore Rewinder motor Interruttore generale Main switch Interruttore avvolgitore Rewinder switch Contattore lama saldante Sealing blade contactor Contattore salita telaio Frame rise contactor Contattore discesa telaio Frame descent contactor Contattore nastro Belt contactor Contattore accessori Accessories contactor Pulsante di emergenza Emergency pushbutton Pulsante di marcia Start button Selettore manuale Manual selector Scheda di comando Control board Trasformatore di taglio Cutting transformer Trasformatore ausiliario Auxiliary transformer Presa alimentazione avvolgitore Rewinder power supply socket Spina alimentazione avvolgitore Rewinder power supply plug
20
