Operating and installation instructions
for condenser tumble dryer
PT 5135 C OS
To avoid the risk of accidents or
damage to the machine it is
essential to read these instructions
before it is installed, commissioned and
used for the first time.
en - EXP
M.-Nr. 09 869 880
Caring for the environment
Disposal of the packing
material
The transport and protective packing
has been selected from materials which
are environmentally friendly for disposal
and should be recycled.
Ensure that any plastic wrappings,
bags, etc are disposed of safely and
kept out of the reach of babies and
young children. Danger of suffocation.
Disposal of your old machine
Electrical and electronic machines
often contain materials which, if
handled or disposed of incorrectly
could be potentially hazardous to
human health and to the environment.
They are, however, essential for the
correct functioning of your machine.
Please do not therefore dispose it with
your household waste.
Energy saving tips
To avoid unnecessarily long drying
times and high consumption of energy:
Make sure that your laundry is
–
thoroughly spun before drying.
The higher the spin, the greater the
savings that can be made in energy
and time during drying.
Load according to the optimum
–
amount of laundry recommended for
the programme being used.
Underloading is uneconomical.
Overloading gives a poorer quality of
drying and may cause unnecessary
creasing.
– Make sure the room in which the
dryer is located is well ventilated.
– After every cycle remove the fluff
from the fluff filter in the door and in
the door opening (see "Cleaning and
Care").
– Check the condenser unit from time
to time and clean it when necessary.
Please dispose of it at your local
community waste recycling centre or
contact your dealer for advice. Ensure
that it presents no danger to children
while being stored for disposal.
2
Contents
Caring for the environment..........................................2
Warning and Safety instructions .....................................6
Operating the tumble dryer.........................................17
Control panel .....................................................17
Before using for the first time.........................................17
Display ..........................................................18
Before using for the first time.......................................19
Notes and tips on laundry care .....................................20
1. Sort the laundry .................................................20
2. Load the tumble dryer ............................................21
3. Select a programme .............................................21
Short instructions ................................................22
Delay start.......................................................26
Programme chart .................................................27
Basic programmes ................................................27
Special programmes ...............................................29
Changing the programme sequence .................................33
Payment system...................................................33
Changing a programme once it has started .............................33
Cancelling the current programme ....................................33
Adding or removing laundry after a programme has started ................33
Power cuts .......................................................33
Time remaining ...................................................33
Cleaning and care ................................................34
Cleaning the fluff filters .............................................34
Cleaning them whilst dry .........................................34
Cleaning them with water .........................................35
Replacing the filters .............................................35
3
Contents
Cleaning the tumble dryer ...........................................36
Cleaning the heat exchanger ........................................37
Removing the heat exchanger .....................................37
Checking the condenser unit (heat exchanger unit) ....................38
To clean the condenser unit .......................................38
Replacing the condenser unit......................................39
Problem solving guide ............................................40
Problem solving guide ..............................................40
Fault messages in the display ........................................40
An unsatisfactory drying result .......................................42
Other problems ...................................................43
Changing the lamp ................................................46
After sales service ................................................47
Repairs..........................................................47
PC / Optical interface...............................................47
Optional accessories ...............................................47
Installation and connection ........................................48
Front view .....................................................48
Side view......................................................49
Rear view .....................................................49
View from above ................................................49
Washer-dryer stack..............................................49
Installing the tumble dryer ...........................................50
Transporting the dryer to its installation site ...........................50
Levelling the machine............................................50
Room in which the dryer is located .................................51
Securing the tumble dryer against slippage ..........................51
Payment system ................................................51
External drainage of the condensed water ..............................52
Electrical connection ...............................................53
4
Contents
Technical data ...................................................54
Settings menu ...................................................56
Opening the Settings menu via the Supervisor level.......................56
Language J ......................................................57
Supervisor level ...................................................57
Anti-crease.......................................................58
Buzzer ..........................................................58
Time of day ......................................................58
Display contrast ...................................................58
Display brightness .................................................58
Standby .........................................................59
Extended cool down ...............................................59
Drying levels .....................................................59
Cottons .......................................................59
Minimum iron ..................................................59
Machine iron ...................................................59
Clean out airways .................................................60
Clean condenser unit...............................................60
Delay start .......................................................61
5
Warning and Safety instructions
It is essential to read these instructions.
~
This tumble dryer complies with current safety requirements.
Inappropriate use can, however, lead to personal injury and
damage to property.
To avoid the risk of accidents and damage to the tumble dryer,
please read these instructions carefully before using it for the first
time. They contain important information on its safety, installation,
use and maintenance.
Keep these instructions in a safe place and ensure that they are
made available to new users. They must be made aware of these
Warning and Safety instructions.
Pass these instructions on to any future users/owners.
Correct application
This tumble dryer is only intended for drying fabrics which have
~
been washed in a water solution, and marked on the manufacturer's
care label as being suitable for tumble drying.
If using dry cleaning kits, do so at your own risk, and follow the
instructions provided on the packaging.
Any other applications may be dangerous. Miele cannot be held
liable for damage resulting from incorrect or improper use or
operation.
The tumble dryer is not intended for outdoor use.
~
6
Warning and Safety instructions
The tumble dryer can only be used by people with reduced
~
physical, sensory or mental capabilities, or lack of experience or
knowledge, if they are are supervised whilst using it or have been
shown how to use it in a safe way and recognise and understand the
consequences of incorrect use.
Children under 8 years of age must be kept away from the tumble
~
dryer unless they are constantly supervised.
Children 8 years and older may only use the tumble dryer
~
unsupervised if they have been shown how to use it in a safe way
and recognise and understand the consequences of incorrect
operation.
Children must not be allowed to clean or maintain the tumble
~
dryer unsupervised.
Please supervise children in the vicinity of the tumble dryer and
~
do not let them play with it.
Technical safety
Before setting up the tumble dryer, check it for any externally
~
visible damage.
Do not install or use a damaged tumble dryer.
Do not make any alterations to the tumble dryer, unless
~
authorised to do so by Miele.
Do not connect the tumble dryer to the mains electricity supply by
~
an extension lead. Extension leads are a fire hazard and do not
guarantee the required safety of the tumble dryer.
7
Warning and Safety instructions
The tumble dryer may only be operated when the following
~
conditions are met:
the ship’s hull is longer than 28 metres.
–
the list of the vessel is not more than 2°.
–
any external vibration is no more than 150 Hz at an amplitude of
–
0.35 mm.
The safe operation and correct functioning of the tumble dryer can
only be guaranteed if the above conditions are met.
The tumble dryer may not be operated on an open deck.
~
Appliances not marked with the CSA C/US Safety Label comply with
~
European safety regulations. These tumble dryers must not be
operated in the USA.
A risk assessment of the installation must be carried out by a
~
suitably qualified engineer before this appliance is installed or used.
Installation must only be carried out by a suitably qualified engineer.
The tumble dryer must be fixed in position when it is installed.
~
Failure to do this could result in personal injury and damage to
property.
8
Warning and Safety instructions
The electrical safety of this tumble dryer can only be guaranteed
~
when correctly earthed. It is essential that this standard safety
requirement is met. If in any doubt, please have the electrical
installation tested by a qualified electrician. Miele cannot be held
liable for the consequences of an inadequate earthing system (e.g.
electric shock).
Unauthorised repairs could result in unforeseen dangers for the
~
user, for which Miele cannot accept liability. Repairs should only be
undertaken by a Miele authorised service technician, otherwise any
subsequent damage will not be covered by the guarantee. Ensure
current is not supplied to the tumble dryer until after maintenance or
repair work has been carried out.
Faulty components must only be replaced by genuine Miele
~
original spare parts. Only when these parts are fitted can the safety
standards of the tumble dryer be guaranteed.
To ensure the correct performance of the tumble dryer and to
~
prevent the risk of faults and fire, it is important to check it and carry
out maintenance on a regular basis.
The tumble dryer must be isolated from the electricity supply in
~
the event of a fault and during cleaning and maintenance.
Please also read the "Installation and connection" and the "Electrical
connection" sections.
9
Warning and Safety instructions
Please observe the instructions in "Installation and connection"
~
and "Technical data".
The socket must be easily accessible after installation in order to
~
disconnect the tumble dryer from the electricity supply.
For hard-wired machines, the all-pole isolator provided on-site
~
must be easily accessible after installation in order to disconnect the
tumble dryer from the electricity supply.
Do not block the gap between the base of the dryer and the floor
~
with plinth facings, deep pile carpet etc. as this would hinder a
sufficient intake of air.
Make sure the dryer door can be opened without hindrance after
~
installation.
In areas which may be subject to infestation by cockroaches or
~
other vermin, pay particular attention to keeping the tumble dryer
and its surroundings in a clean condition at all times. Any damage
which may be caused by cockroaches or other vermin will not be
covered by the appliance guarantee.
10
Warning and Safety instructions
Correct use
The maximum load of dry laundry for this tumble dryer is 6,5 kg.
~
See the Programme chart for the maximum recommended loads in
individual programmes.
Do not let anyone sit or lean on the door, as this can cause the
~
tumble dryer to tip up. Danger of injury.
Always close the door after use. This way you will avoid the
~
danger of:
children climbing into the dryer or hiding things in it.
–
– pets or other small animals climbing into it.
Do not use a pressure washer or hose to clean the tumble dryer.
~
Always keep the area around the tumble dryer free of dust and
~
fluff. Dust and dirt drawn into the tumble dryer can cause blockages.
Faults can then occur as well as the risk of fire.
11
Warning and Safety instructions
The dryer must not be used without the fluff filters in place or if
~
the fluff filters are damaged in any way. Damaged filters can cause
operational faults and blockages in the airways, condenser unit and
heating elements. Fire hazard.
In the event of a damaged filter, switch the dryer off and replace the
filter with a new one.
The fluff filters must be cleaned regularly.
~
The dryer must not be used without the condenser unit in place.
~
The fluff filters must be thoroughly dried after cleaning. Damp or
~
wet filters could cause operational faults.
Do not install the tumble dryer in a room where there is a risk of
~
frost occurring. At temperatures around freezing point the tumble
dryer may not be able to operate properly.
There is a risk of damage if the condensed water is allowed to
freeze in the pump and hoses.
The ambient room temperature should be between +2°C and
+35°C.
If the water is drained externally instead of being collected in the
~
condensed water container, make sure the drain hose is securely
attached if you hang it in a sink or basin to avoid the hose slipping
and the water causing damage.
Condensed water is not drinking water.
~
It can cause health problems in both people and animals.
12
Warning and Safety instructions
To prevent the risk of fire, the following textiles must not be dried
~
in this tumble dryer:
items which have not been washed.
–
items, such as workwear, which have not been thoroughly
–
cleaned and which are still soiled with grease, oil or other
deposits (such as cosmetics, lotions etc).
If items have not been thoroughly cleaned there is a danger that
these might self-ignite when heated, even after they have been
removed from the dryer at the end of the programme.
items (e.g. mops and floor cloths) which have been treated with
–
inflammable cleaning agents or which contain residues of
acetone, alcohol, benzine, petrol, kerosene, stain remover,
turpentine, wax, wax remover or other chemicals.
– items which have been splashed with hair lacquer, hair spray, nail
varnish remover or similar substances.
When washing such heavily soiled items ensure that you use
sufficient detergent and select a high temperature. If in doubt,
wash the items several times.
Remove all items such as lighters and matches from pockets.
~
Warning: Do not switch the tumble dryer off before the drying
~
programme has finished. If this is done, the laundry must be hung
up or spread out to cool it down.
13
Warning and Safety instructions
Danger.
~
This tumble dryer must not be connected to a controllable socket
(e.g. a timer switch or a peak load shut-off device).
If the dryer programme were to be interrupted before the end of the
cooling down phase, the laundry could self-combust.
To prevent the risk of fire, the following must not be tumble dried:
~
items which have been cleaned using chemicals (e.g.
–
professional dry-cleaning agents).
fabrics which contain a large proportion of rubber, foam rubber or
–
rubber-like materials. For example, products made from latex
foam rubber, shower caps, waterproof textiles, rubberised articles
and items of clothing and pillows with foam rubber filling.
– damaged items which contain padding or fillings (e.g. pillows,
jackets). When damaged, the filling can get out with the risk of
igniting in the dryer.
In many programmes, the heating phase is followed by a cooling
~
down phase to ensure that the items are not too hot to handle when
you remove them (this also avoids the danger of the laundry
self-igniting). The programme is not finished until the cooling down
phase has been completed.
As soon as the programme has finished, remove all laundry from the
drum.
Fabric conditioner and similar products must be used according
~
to the instructions on the manufacturer's packaging.
14
Warning and Safety instructions
Benzine, petrol, paraffin or any easily flammable liquid must not
~
be stored or used near the tumble dryer. Danger of fire and
explosion.
Do not allow air contaminated with chlorine, fluorine or other
~
vapours containing solvents to get into the tumble dryer. Fire
hazard.
For tumble dryers with stainless steel surfaces:
~
The stainless steel surfaces must not come into contact with liquid
cleaning and disinfecting agents which contain chlorine or sodium
hypochlorite. These agents can have a corrosive effect on stainless
steel.
Aggressive vapours containing chlorine can also be corrosive.
Do not, therefore, store containers of these agents near the tumble
dryer.
15
Warning and Safety instructions
Accessories
Only use genuine Miele original spare parts and accessories with
~
this tumble dryer.
If non-Miele parts are used, guarantee, performance and product
liability claims may be invalidated.
A Miele tumble dryer can be stacked on top of a Miele washing
~
machine using the appropriate stacking kit (available as an optional
accessory). Please make sure you order the correct one for the
Miele tumble dryer and Miele washing machine.
If installing the machine on a Miele plinth, (available as an
~
optional accessory), please make sure you order the correct one for
this tumble dryer.
Miele cannot be held liable for damage caused by
non-compliance with these Warning and Safety instructions.
16
Control panel
Operating the tumble dryer
a Display
The display lights up when the
machine is switched on.
As soon as the dryer is ready to use,
the Entry menu appears in the
display.
b Start button
The indicator light flashes while a
programme is being selected, and
lights up when the programme starts.
c –, OK, + buttons
See the following pages for more
information.
d + button
For selecting Delay start; Time of day
display
e PC/Optical interface
This is used by Miele service
technicians during servicing work for
testing purposes.
f Low temperature button
For drying delicate fabrics
(Care label symbol r).
g Programme selector
The programme selector can be
turned clockwise or anti-clockwise.
h On/Off button s
For switching the dryer on and off.
To save energy the dryer will switch
off automatically 15 minutes after the
end of the programme/anti-crease
phase or 15 minutes after the dryer is
switched on if it is not operated.
i Door button
Opens the machine door
independently of the electricity
supply.
Before using for the first time
Before using the machine for the first
time, ensure that it is correctly
installed and connected. See
"Installation and connection".
17
Operating the tumble dryer
Display
The following are shown in the display:
Programme selection
–
Programme duration and the
–
programme start and end time
The following are selected via the
display
Special programmes
–
Denim
Shirts
Outerwear
Proofing
Automatic (if activated)
Smoothing
Pillows
Delicates
Basket - Std. temp.
Basket - Low temp.
Silks handcare
Reactivate
– Delay start
–
The Settings menu
–/+ buttons
For altering the values shown in the
display:
– decreases the value or moves the
highlighting upwards.
+ increases the value or moves the
highlighting downwards.
OK button
For confirming the value selected and
choosing the next element.
Default settings can be altered to
adapt the dryer to different
requirements. See the end of this
booklet for further information.
18
+ button
For selecting Delay start.
You can also press this button during a
drying programme to check the
estimated programme end time or the
current time of day.
Before using for the first time
Press the On/Off button s briefly to
^
switch on.
As soon as the dryer is ready to use,
the Entry menu appears.
When the tumble dryer is switched on
for the first time, the Miele Professional
welcome screen will appear.
The Miele Professional welcome
screen will not appear again after you
have entered the language and the
time of day, and run an initial
programme through to the end.
The display for setting the language will
then appear.
Setting the language
C dansk -
deutschB
F
english H
^ Use the + and – buttons to select the
language you want, and confirm your
choice by pressing the OK button.
A tick
L will appear beside the
language to show that it has been set.
Setting the time (of day) (if necessary)
It is possible to alter the time at any
stage via the Settings menu.
10 :00
Set the time of day
Set the hour with the - and + buttons,
^
and confirm your setting by pressing
the OK button.
Now set the minutes and confirm
^
your selection.
Entry menu
The Entry menu will always appear after
the machine has been switched on,
until you select an option.
10:00
Select a programme
Settings F...
See "Settings menu" at the end of this
booklet for more information.
^
You can now load the laundry into the
dryer and select a programme as
described in "Short instructions".
19
Notes and tips on laundry care
1. Sort the laundry
Garment care label symbols
Drying
q Normal/higher temperature
r Reduced temperature:
Select Low temperature
(for delicate textiles)
s Do not tumble dry
Ironing
I Very hot
H Hot
G Warm
J Do not iron
Before drying
– Wash heavily soiled items very
thoroughly, ensuring that you use
sufficient detergent and select a high
temperature. If in doubt, wash the
items several times.
–
Do not put soaking wet items into the
tumble dryer Make sure that your
laundry is thoroughly spun before
drying.
The higher the spin, the greater the
savings that can be made in energy
and time during drying.
New dark-coloured garments should
–
be washed and dried separately
from light-coloured garments the first
few times they are washed, to avoid
the risk of colours running and
discolouring other garments or even
the plastic components in the tumble
dryer.
Dark-coloured fibres can also settle
on light-coloured garments and vice
versa.
Starched laundry can be dried in the
–
tumble dryer. To achieve the usual
finish, double the amount of starch
should be used.
– Check the seams of padded or
down-filled items to prevent the risk
of fillings coming out. These could
catch fire in the tumble dryer.
– Tie together textile belts and apron
ties to stop them getting tangled.
– Fasten duvet covers etc. to prevent
small items from being trapped
inside them. Fasten hooks and eyes
etc.
–
Stitch in or remove loose underwiring
from bras.
–
Leave jackets open and undo any
long zips so that textiles dry evenly.
20
–
For an even drying result, it is
important to...
. . . spin,
. . . shake out,
. . . and sort items according to
fabric type, size, care label and the
drying level required.
Notes and tips on laundry care
2. Load the tumble dryer
Using the tumble dryer
,
incorrectly could cause a fire. Read
the "Warning and Safety instructions"
before using the machine.
Make sure that objects, e.g.
,
detergent dispensing balls, have
been removed from the laundry.
They could melt and cause damage
to the dryer or the laundry.
Do not overload the drum.
–
Overloading can cause unnecessary
wear and tear to the laundry, give a
disappointing drying result and
cause more creasing.
– To save energy, always observe the
maximum load for each programme
(see "Programme chart").
– Minimum iron fabrics tend to crease
more the greater the load. This is
also the case for garments made
from very fine weave fabrics, such as
shirts or blouses.
If necessary, reduce the size of the
load for these types of fabrics.
3. Select a programme
On many programmes, different
–
drying levels can be selected
depending on individual
requirements
. . . e.g. Normal+ for laundry that you
want to fold and put away immedi
ately after drying.
. . . e.g. Machine iron or Hand iron if
the laundry needs further processing
after drying, e.g. machine ironing.
See "Programme chart".
For delicate fabrics with the r care
–
label, select Low temperature as
well.
– Down-filled garments have linings
which have a tendency to shrink,
depending on the quality of the item.
They can be partially dried using the
Smoothing programme.
– Pure linen should only be machine
dried if specified as suitable by the
manufacturer on the care label, as
the surface of the fabric may
otherwise become rough. They can
be partially dried using the
Smoothing programme.
–
Woollens and wool blends tend to
become matted and shrink if dried in
a tumble dryer. Only dry these
fabrics in a Woollens programme.
-
–
Loopknit garments (e.g. T-shirts and
underwear) tend to shrink depending
on their quality. Therefore: Do not
over-dry these textiles. When
purchasing these garments it is
advisable to take their shrinkage
properties into account.
21
Short instructions
A Sort the laundry
It is very important to read the
,
"Notes and tips on laundry care"
section before proceeding.
B Load the tumble dryer
^ Open the door.
^ Load the drum.
To avoid damaging your laundry,
,
when shutting the door check that
no items of laundry have become
trapped in the door opening.
^ Shut the door either with a gentle
swing, or lean against it and push it
shut.
22
Short instructions
C Select a programme
Press the On/Off button s briefly to
^
switch on.
Please note:
If no further selection is made within
–
15 minutes, the dryer will switch off
automatically.
This does not apply to machines with
–
a payment system.
^
Turn the selector to the programme
you require.
The display will vary according to which
programme has been selected.
With the Cottons and Minimum iron
programmes, the drying level is
selected with the programme selector.
To select a Special programme
A selection of programmes will appear
in the display when you select Special
programmes.
Denim
E
Shirts
Outerwear
Use the + or - button to highlight the
^
H
programme you want. The arrow H
in the display indicates that there are
further options.
^ Confirm your selection by pressing
the OK button.
On some Special programmes, the
drying level can be altered as follows:
Shirts
Normal
Duration: 0:36h
^ Use the + or - button to change the
drying level.
For the drying level options, see
"Programme chart".
Warm air, Cool air and Basket
programmes
1:00 h Warm air
Duration: 1:00h
^
The programme duration can be
increased or reduced using the + or
– buttons.
23
Short instructions
Low temperature button
For drying particularly sensitive
^
fabrics (care symbol r), e.g.
acrylics, press the Low temperature
button.
Because the heater rating is reduced
for the Low temperature setting, clothes
dry more slowly thus lengthening drying
times.
+ button
See "Delay start".
^
Coin operation
If your machine has a payment system,
the amount of credit required will
appear in the display.
Opening the door or cancelling the
programme after it has started may
cause loss of credit (depending on
how the machine was set up).
D Start the programme
The indicator for the Start button will
flash as soon as a programme can be
started.
^
Press the Start button.
–
Prog. running will appear in the
display, followed by Drying and the
programme duration.
Changing the programme sequence
Further information about the following
can be found under "Changing the
programme sequence":
Coin box
–
Changing a programme once it has
–
started
Cancelling the current programme
–
Adding or removing laundry after a
–
programme has started
Power cuts
–
– Time left
Programme duration/Estimated time
left
When a programme is selected, the
estimated duration will appear in the
display. Please be aware that it is only
an estimate!
The following factors all affect the
estimated time remaining: residual
moisture content after spinning; type of
fabric; size of load; room temperature;
fluctuations in power supply.
The electronics assess conditions in the
dryer and adjust the estimated time
remaining for a more accurate reading.
Because of this, the time displayed can
alter during the course of a programme.
–
With programmes with drying levels,
e.g. Machine iron, Hand iron etc.,
the drying level reached will be
shown in the display later on.
24
Before the end of a programme
There is a cooling down phase at the
end of the drying sequence: Cooling
down will appear in the display. The
programme will not finish until the
cooling down phase has been
completed.
There is no cooling down phase at the
end of the following programmes:
Woollens handcare, Smoothing.
Do not switch the tumble dryer off
before the end of the drying
programme.
E Remove the laundry when the
programme has finished
Anti-crease (if activated) and Finish will
appear in the display to indicate that
the programme has finished.
Please note:
– To avoid creasing, during the
anti-crease phase the drum will
continue to turn at intervals until the
laundry is removed.
The anti-crease phase is not
activated in the following
programmes; Woollens handcare,
Basket programmes.
–
The dryer will switch off automatically
15 minutes after the end of a
programme/the end of the
anti-crease phase.
It is advisable to remove laundry as
soon as the programme has
finished.
Short instructions
Open the door.
^
^ Remove everything from the drum.
Check that all items have been
removed from the drum. Anything
left in the dryer could be damaged
by overdrying when it is next used.
The drum lighting will come on when
the door is opened. It will go out a few
minutes later to save energy.
^
Press the On/Off button s briefly to
switch off the machine.
The display will go out.
^
Close the door.
Maintenance after each drying
programme
^
Please see "Cleaning and care" for
details.
25
Delay start
Depending on the Delay start setting,
you can set the time you wish a
programme to finish or start at, or you
can delay the start of the programme.
Factory default: Delay start not
activated.
To begin delay start
Press the Start button.
^
Normal
Start in: 1:14h
To select Delay start
Select the programme you want and
^
then press the + button.
10:00
Start:
Finish:
10:00
11:16
Example: The display will show the
current time of day at the top, the time
the programme will start in the middle
and the time the programme will finish
at the bottom.
10:00
Start:
Finish:
^
Use the + controls to select the
11:14
12:30
desired time.
The Start and Finish times will now be
postponed by 30 minutes. The
maximum time that an automatic
programme start can be delayed by is
24 hours.
Use the – button to reduce the time.
^
Confirm your selection by pressing
the OK button.
The delay start time will now count
down in minutes until the start of the
programme.
The drum will turn briefly every hour to
help prevent creasing.
Changing the programme sequence
While the Delay start time is counting
down, you can still...
. . . select the Low temperature option
or another drying level.
. . . press the Door button and add or
remove laundry. After closing the door,
press the Start button.
To alter delay start
^ Press the + button.
^
Use the - or + button to alter the time.
^
Confirm your selection by pressing
the OK button.
To delete Delay start
^
Press the + button.
^
Press and hold the – button until the
time stops reducing.
^
Confirm your selection by pressing
the OK button.
The programme will now start immedi
ately.
-
26
To cancel Delay start
^
Turn the programme selector to
Finish.
Programme chart
Basic programmes
Cottons t ** Max. load 6.5 kg*
Use for Normal wet cotton laundry, as described in Cottons Normal .
Notes
Cottons max. 6.5 kg
Normal+, Normal
Use for
Note – Do not overdry loopknit fabrics (e.g. T-shirts, underwear,
Low temperature Select for fabrics with the r symbol.
Hand iron, Machine iron
Use for – Cotton or linen fabrics
Note – To prevent laundry from drying out, it should be rolled up
Low temperature Select for fabrics with the r symbol.
Minimum iron max. 3.5 kg
Normal+, Normal, Hand iron
Use for
Low temperature Select for fabrics with the r symbol.
Items are dried to a "Normal" level only.
–
Cottons t is the most energy-efficient programme for
–
drying normal wet cotton laundry.
Single and multi-layered cotton fabrics such as:
–
Towelling, T-shirts, underwear, flannelette bed linen and
–
baby clothes.
Workwear, jackets, cotton blankets, aprons, face flannels,
–
tea towels, bed linen, towels, table linen that can be
washed hot, overalls.
baby clothes), as they have a tendency to shrink.
– Table linen, bed linen, starched laundry.
until you are ready for ironing.
–
Minimum iron cotton, synthetic and mixed fibre fabric
–
Workwear, overalls, pullovers, dresses, trousers, table linen
*
*
*
Weight of dry items
** Note for test institutes:
Test programme in accordance with regulation 392/2012/EU measured according to EN 61121
27
Programme chart
Towelling max. 6.5 kg
Normal+
Use for
Large quantities of single-layer and multi-layer towelling items.
–
Towels, dressing gowns, face flannels, towelling bedding.
–
Woollens handcare max. 2.5 kg
Use for Woollen garments.
Note
Items are dried and aired briefly.
–
Remove garments as soon as the programme has finished
–
and leave to finish drying at room temperature.
Timed drying, warm air (15-60 minutes**) max. 6.5 kg
Use for
Multi-layered fabrics whose layers have different drying
–
characteristics,
– Voluminous items, e.g. jackets, pillows.
– For drying individual items.
– Bath towels, swimwear, tea-towels.
Note – Do not select the longest drying time to start with. Check the
items as you are drying them to find the optimum time.
Low
Select for fabrics with the r symbol.
temperature
Timed drying, cool air (10-120 minutes**) max. 6.5 kg
Use for – Any item which only needs airing.
*
*
*
*
*
Weight of dry items
** The upper and lower limits of the programme duration can be changed by a Service technician.
28
Programme chart
Special programmes
Denim max. 3.5 kg
Normal, Hand iron r
Use for
Shirts max. 2.5 kg
Normal, Hand iron r
Use for
Outerwear max. 3.5 kg
Normal, Hand iron r
Use for
Proofing max. 2.5 kg
Normal
Use for – Microfibre fabrics, skiwear, fine, closeweave cotton garments
Note – This programme includes a proofing fixing phase.
Denim garments, e.g. jeans, jackets, skirts, shirts.
–
Shirts and blouses.
–
Outerwear which is suitable for drying in a tumble dryer.
–
(poplin) or tablecloths which are suitable for drying in a tumble
dryer and have been treated to provide a water and dirt resistant
finish.
– Only use proofing agents containing fluorochemical compounds
which which are stated by the manufacturer as being "suitable
for use on membrane textiles". Do not dry items which have
been treated with proofing agents containing paraffin. Fire
hazard!
*
*
*
*
* Weight of dry laundry
29
Programme chart
The following programme must be activated by a Service technician:
Automatic Max. load 3.5 kg*
Normal+, Normal, Hand iron r
Use for
Smoothing max. 3 kg
Use for
Note
*
Weight of dry items
Mixed loads of garments suitable for the Cottons and Minimum
–
iron programmes. Sort according to colour.
Cotton and linen fabrics.
–
Minimum iron mixed fibre, cotton or synthetic fabrics, e.g.:
–
trousers, anoraks, shirts.
Smooths out creasing caused during the spin cycle in the
–
washing machine.
Remove garments as soon as the programme has finished and
–
leave to finish drying at room temperature.
*
30
Programme chart
Standard pillows max. 2.5 kg
Normal
Use for
Feather or down pillows.
–
Quantity: 2 pillows 80x80 cm
–
Delicates max. 4 kg
Normal+, Normal, Hand iron r
Use for
Delicate cotton, synthetic and mixed fibre fabrics
–
Thin pullovers, dresses, trousers, overalls, table cloths, shirts,
–
blouses.
Lingerie and appliquéd fabrics.
–
Important
*
Weight of dry items
Low creasing.
–
*
*
31
Programme chart
Basket programmes (20-90 min)
Note
Use for – See the operating instructions supplied with the drying basket.
Basket Std. temp. (20-90 min) max. load in the basket 3 kg
– For thermally stable textiles / items
Basket - Low temp. (20-90 min) max. load in the basket 3 kg
– For thermally sensitive textiles / items
Silks handcare max. 1.5 kg
Use for
Important
Reactivate max. 2.5 kg
Normal
Use for
Note
The drying basket (optional
–
accessory) must be in place when
items are dried or aired using this
programme.
To prevent the risk of damage when
–
the drum rotates, do not place large
items which could come into contact
with the drum or drum ribs in the
drying basket (e.g. knee length boots, large bags or
rucksacks).
Sleeves, belts and ties should be folded in or secured so that
–
they are fully contained within the drying basket.
Use this programme to dry items which are suitable for drying
–
in a tumble dryer but which are not suitable for drying using
mechanical action.
– It is essential to observe the operating instructions for the
drying basket.
–
Silks, e.g. blouses and shirts.
–
Smooths out creasing.
–
Remove garments as soon as the programme has finished and
leave to finish drying at room temperature.
–
Outerwear which is suitable for drying in a tumble dryer.
–
Makes the fibres more water-repellant.
*
*
*
Weight of dry items
32
Changing the programme sequence
Payment system
Opening the door or cancelling the
programme after it has started may
cause loss of credit (depending on
how the machine was set up*).
* A Miele service technician can re-set
the payment system so that
programming changes can be made
within a specified time period.
Changing a programme once it
has started
You cannot change to another
programme once a programme has
started (this prevents unintentional
alterations). If the programme selector
is altered, the words Programme
cannot be changed appear if the
selector is not turned back to the
original programme.
You will need to cancel the current
programme before you can select a
new one.
Cancelling the current
programme
^
Turn the programme selector to
Finish.
When Finish appears in the display,
this shows that the programme has
been cancelled.
Adding or removing laundry
after a programme has started
The laundry, the drum and the
,
back of the machine all become
very hot during operation. Take care
when in the vicinity of the machine,
when opening the door and
handling freshly dried laundry.
Danger of burning.
Press the Door button.
^
Open the door.
^
^ Add or remove items as required.
^ Close the door.
^ Press the Start button.
Power cuts
– If the dryer is switched off during a
drying programme or there has been
a power cut:
^ When the power is restored and/or
the machine is switched on again,
confirm with OK and start the
programme again.
Time remaining
The time left shown in the display may
now vary from the actual drying time.
^
Open the door.
^
Close the door.
^
Select a new programme.
^
Press the Start button.
33
Cleaning and care
Cleaning the fluff filters
Fluff from items being dried is collected
by the fluff filters in the door and the
door opening. Clean the filters after
each drying programme*.
Cleaning them whilst dry
^ Open the door and pull the fluff filter
(1) out as illustrated.
Remove any fluff from the hollow part
^
of the door opening. You could also
use a cleaning brush which is
available as an optional extra from
your Miele dealer or the Miele Spare
Parts Department or use a vacuum
cleaner.
Once clean, push the filter back into
^
the door holder until it clicks into
position. Ensure it is facing the
correct way.
Also clean the door seal (2) with a
^
damp cloth.
^
Use your fingers or a vacuum cleaner
to remove the fluff from the surface of
the filter.
34
^
Use your fingers or a vacuum cleaner
to remove the fluff from the two fluff
filters in the door opening.
^
Close the door.
,
* The fluff filters should be
checked and cleaned regularly but
always clean immediately the Clean
out airways message appears.
Cleaning and care
Cleaning them with water
If there is a great deal of compacted
fluff on any of the filters, they can be
removed and cleaned under hot
running water.
Open the door and pull the fluff filter
^
out of the door as described
previously.
The two filters in the door opening can
also be removed if you need to clean
them with water.
Replacing the filters
Do not replace the filters if they
,
are damp or wet. Damp or wet filters
could cause operational faults.
Push the large filter back into the
^
door holder until it clicks into position.
Ensure it is facing the correct way.
Replace the filters in the door
^
opening by first inserting them at the
bottom and then pressing them into
place at the top.
Lock both catches (you will hear
^
them click).
^
Turn catch a until you hear it click.
^
Pull the filter by the dial out of the
door opening as shown b.Dothe
same on the other side.
^
Rinse all the filters under hot, running
water.
^
Also clean the airways underneath
each one with a vacuum cleaner, for
example.
^
Dry the filters thoroughly with care.
35
Cleaning and care
Cleaning the tumble dryer
Disconnect the tumble dryer
,
from the mains electricity supply.
Do not use solvents, abrasive
,
cleaners, glass cleaners or
all-purpose cleaners. These could
damage plastic surfaces and other
parts.
The tumble dryer must never be
,
hosed down.
^ Clean the housing and the control
panel with a slightly damp cloth and
a mild detergent or soapy water.
^ The drum and other stainless steel
parts can be cleaned with a suitable
proprietary stainless steel cleaner
following the manufacturer's
instructions.
^
Dry all parts with a soft cloth.
36
Cleaning the heat exchanger
Check the heat exchanger unit
,
regularly. It should always be
cleaned immediately the Clean
condenser unit or Clean out airways
message appears.
Removing the heat exchanger
Cleaning and care
Turn the lever on the inner cover
^
downwards to the vertical position.
^ Pull the cover forwards.
^ Remove it by pulling it diagonally
upwards.
^ Open the access panel.
The hooks at the side will prevent the
panel from falling off.
^
Now remove the panel by pulling it
diagonally upwards.
^
Then place it to one side.
^
Turn the lever on the heat exchanger
to the vertical position.
37
Cleaning and care
Pull the condenser (heat exchanger)
^
unit out of its housing by the handle
Checking the condenser unit (heat
exchanger unit)
If you can see some fluff:
Clean the condenser unit as
^
described below.
To clean the condenser unit
Use a shower head or similar to rinse
^
the unit out as shown.
.
^
Hold the condenser unit up to the
light as shown.
^
Check to see if there is any fluff
inside it. The arrows in the illustration
above indicate where to look.
If you cannot see any fluff:
^
Replace the condenser unit (see
following page).
38
– From the sides.
–
From the front.
Fluff is washed out by the water.
Cleaning and care
Check the condenser unit again for
^
any visible fluff, and if necessary
flush it through again until it has all
gone.
Also make sure the rubber seals are
^
clean.
The rubber seals must not be
removed and must be free of kinks.
To check and clean the condenser unit
housing
Remove any soiling still visible inside
^
the housing by hand using a damp
cloth. Do not try and access areas
you cannot reach by hand.
Replacing the condenser unit
Push the condenser unit all the way
^
back into the housing, until it clicks
into place.
The handle
must be at the top, and the lever at
the bottom.
Turn the lever down to the horizontal
^
position, making sure that the hook
on the lever clicks into the groove at
the bottom.
When replacing the inner cover,
ensure that the rubber seal fits
correctly into the groove.
^ Replace the cover making sure the
hooks locate correctly. To do this,
hold it at an angle and push it gently
downwards.
^ Then turn the lever upwards into the
horizontal position to lock the cover.
^ Replace the service panel and press
the upper edge until it clicks into
position.
for the condenser unit
It is important to ensure that both the
condenser unit and the cover are
correctly positioned and locked
otherwise water may leak from the
machine.
39
Problem solving guide
Problem solving guide
With the help of the following notes minor faults in the performance of this dryer,
some of which may result from incorrect operation, can be put right without
contacting the Service Department.
Repair work to electrical appliances should only be carried out by a suitably
qualified person in accordance with current local and national safety
regulations. Repairs and other work by unqualified persons could be
dangerous. The manufacturer cannot be held liable for unauthorised work.
Fault messages in the display
Problem Possible cause Remedy
l
Adjust
the load
,
Technical
Fault
A fault code eg F47
may also appear in
the display
This is not a fault.
The electronic unit has
recognised that there is no
laundry in the drum and
cancelled the programme.
Drying individual garments or
items which are already dry
can also cause the programme
to be cancelled.
No obvious cause.
In some circumstances, Clean
out airways will have appeared
in the display already.
You cannot start another
programme whilst this
message shows in the display.
Use the Warm air
programme (timed
drying) to dry individual
items.
To delete the fault
message:
– Open the door.
– See next page: Clean
out airways.
–
Follow the instructions
in the display.
–
Try to start the
programme again.
40
Problem solving guide
Problem Possible cause Remedy
Power failure
Programme
stopped
If the dryer is switched off
during a drying programme
or there has been a power
cut:
After switching the dryer on /
–
power has been restored,
confirm with OK and start the
programme again.
The following
appears at the
end of the
programme:
Service info
Clean the
condenser
unit
Clean out
airways
or
Clean the filters
appears at the
end of the
programme or
after a
programme
has been
cancelled.
Drain fault
Check drainage
The dryer is reminding you
that the condenser unit
(heat exchanger unit)
needs to be cleaned.
You can adjust the setting
which controls when or if
the message Clean the
condenser unit appears.
The dryer is not working
efficiently or economically.
Possible cause: A build-up
of fluff or detergent
residues.
The drain hose is kinked.
Clean the condenser unit.
–
To delete the fault message:
Confirm with OK.
–
See "Settings menu J, Cleaning
the condenser unit".
– Cleaning the filters is usually all
that is required.
However, if the message does
not go out after you have
cleaned the filters, then also
check all the possible causes
described under "The drying
process goes on too long or
even switches off".
To delete the fault message:
–
Open and close the door, or
confirm with OK.
You can adjust the setting which
controls when or if the message to
clean out the airways appears.
–
See "Settings menu J, Clean
the airways".
–
Remove the kink.
To delete the fault message:
–
Confirm with OK.
Programme
cannot
be changed
An attempt has been made
to alter a programme while
it is in progress.
–
You will need to cancel the
current programme before you
can select a new one.
41
Problem solving guide
An unsatisfactory drying result
Problem Possible cause Remedy
The laundry is not
sufficiently dry.
Feather filled pillows
smell after drying.
Items made of synthetic
fibres are charged with
static electricity after
drying.
There is a build-up of
fluff.
The load consisted of
different fabrics.
Feathers are a natural
product and this is quite
normal.
Synthetic fibres tend to
attract static charge.
Fluff is principally the
result of friction when
garments are being worn
and to some extent when
they are being washed.
Machine drying causes
hardly any fluff to form
and has no appreciable
effect on the lifetime of
the fabric.
Finish drying using the
–
Warm air programme.
Select a different
–
programme next time
(see "Programme
chart").
The smell will dissipate
after sufficient airing.
Static charge can be
reduced by adding a
fabric conditioner to the
final rinse in the washing
programme or a fabric
conditioner sheet to the
load when drying.
Fluff is collected by the
fluff filter and can be
easily removed (see
"Cleaning and care").
42
Problem solving guide
Other problems
Problem Possible cause Remedy
The drying
process goes on
too long or even
switches off.
You might be asked to
clean the ducting
system/filters again.
Ventilation to and from the
dryer may be insufficient,
e.g. because it is installed
in a room which is too
small. This can cause the
temperature in the room to
rise sharply.
The vents below the door
are blocked.
The fluff filters are
clogged up with fluff or
were still wet when they
were replaced.
Detergent residues, hair
and fine fibres can block
the condenser unit.
The laundry has not been
spun sufficiently.
The tumble dryer has
been overloaded.
Metallic components, e.g.
zips have prevented the
dryer from registering the
correct moisture level in
the laundry.
Please check all possible
causes, described below.
Open a door or window while
the dryer is in operation for
increased air flow.
– Remove any objects that are
blocking the vents.
– Remove any fluff.
– The fluff filters must be
completely dry.
Check the condenser unit from
time to time and clean it if
necessary.
Make sure that your laundry is
thoroughly spun at the
appropriate spin speed in the
washing machine.
Do not exceed the maximum
load for the programme
selected.
–
Open zips next time.
If the problem occurs again,
dry garments with long zips
using the Warm air programme
(timed drying).
43
Problem solving guide
Problem Possible cause Remedy
Water leaks from
the dryer after the
condenser unit has
been cleaned.
The interior drum
lighting does not
come on.
Power cuts. – After the power supply has been restored, switch the
The inner cover of the
–
condenser unit has not
been locked properly
and/or the condenser unit
has not been positioned
correctly.
Fluff has collected in the
–
condenser unit housing.
The lighting switches off
automatically (to save
energy).
dryer on using the s button.
– Confirm with OK.
Ensure that the
–
condenser unit is
positioned correctly and
lock the inner cover.
Check the rubber seals.
–
Use a cloth to remove
–
any visible fluff from the
inside of the condenser
unit housing.
It will switch on again
–
after the door has been
closed and then opened.
If the lamp needs to be
–
replaced, follow the
instructions in "Changing
the lamp" at the end of
this section.
44
Problem solving guide
Problem Possible cause Remedy
The programme does
not start and the display
is dark.
The display is in a
different language.
The indicator lamp for
the Start button flashes
when a programme is
being selected.
The display is dark and
the light ring around the
multi-function selector
is not lit up.
The Start button light
flashes slowly.
No obvious cause.
The dryer switches off
automatically after 15
minutes if no further
selection is made.
A different language has
been selected in "Settings
J" "Language J".
This is not a fault.
The flashing indicates
that a programme can be
started.
The display has switched
off automatically to save
energy (Standby mode).
The same applies to the
programme selector.
The programme selector
light goes out when the
Settings menu has been
selected.
If the problem persists,
there is a fault.
Is the dryer switched
–
on?
Is the door closed
–
properly?
Has the fuse or circuit
–
breaker tripped?
When the power comes
back on after a power
cut, confirm with OK and
start the programme
again.
Switch the dryer on.
Set the language you
want. The flag symbol
will guide you.
Once the programme has
been started, the Start
button stops flashing and
lights up constantly.
The display and
programme selector are
lit up after pressing a
button or turning the
programme selector.
The programme selector
light comes on when a
programme is selected.
Contact the Miele Service
Department.
45
Problem solving guide
Changing the lamp
Disconnect the tumble dryer from
the mains electricity supply.
The lamp specification and
maximum wattage is stated on the
data plate and on the lamp cover.
Open the door.
^
You will find the interior lamp cover at
the top of the drum aperture.
^ Insert a suitable tool, such as a wide
bladed screwdriver, under the side
edge of the lamp cover as illustrated.
^
Apply a little pressure and whilst
doing so turn your wrist in the
direction of the arrow to open the
cover.
Replace the lamp.
^
To close the cover push it upwards
^
and press it on the left and right until
you hear it click into position.
Ensure that it is fitted into
,
position securely, as any moisture
could cause a short circuit.
The cover will open downwards.
The temperature resistant lamp should
only be ordered from your Miele dealer
or the Miele Spare Parts Department.
46
After sales service
Repairs
In the event of any faults which you
cannot remedy yourself, or if the tumble
dryer is under guarantee, please
contact
your Miele Dealer
–
or
the Miele Service Department (see
–
back cover for contact details).
When contacting the your Dealer or the
Service Department, please quote the
model and serial number of your dryer
both of which are shown on the data
plate.
PC / Optical interface
The indicator or check light marked PC
on the fascia panel is the interface used
by Miele service technicians during
servicing work for testing purposes and
for updating the machine´s programme
data.
Optional accessories
Optional accessories for this dryer are
available from your Miele Dealer or from
the Miele Spare Parts Department.
47
Installation and connection
Front view
a Mains connection cable
b Control panel
c Door
d Service panel for condenser unit
e Four height adjustable screw feet
48
f External drainage options (e.g. via
wash basin, wash basin drain outlet
or gully)
Optional accessory: Extension hose
g Intake and exhaust vents for cooling
the condenser unit
Installation and connection
Side view
Rear view
View from above
Washer-dryer stack
a Protruding lid edge (see arrows) for
holding when moving the tumble
dryer.
b Air exhaust vent for cooling the
condenser unit
c Stainless steel plith (open or closed,
optional Miele accessory)
The tumble dryer can be combined with
a Miele washing machine in a
washer-dryer stack. A stacking kit is
required which can be purchased from
Miele. The stacking kit must be fitted by
a Miele authorised service technician.
49
Installation and connection
Installing the tumble dryer
Make sure the dryer door can be
,
opened without hindrance after
installation.
Transporting the dryer to its
installation site
When moving the dryer, hold it by the
lid where it protrudes to the rear. To
manoeuvre the dryer out of its packing
case to its installation site you will also
need to hold it by the front feet.
Levelling the machine
The machine must be perfectly level to
ensure safe and proper operation.
,
Ensure the tumble dryer is stable
during transportion.
50
^
The screw feet can be adjusted to
compensate for any unevenness in
the floor.
Never block the vents on the
,
dryer.
In order to ensure sufficient
ventilation to the dryer, do not
reduce the vent gap between the
underside of the dryer and the floor
with a plinth, deep-pile carpet, etc.
This tumble dryer is not suitable for
building under.
Installation and connection
Payment system
The dryer can be fitted with a payment
system (optional accessory).
This must be connected and
programmed by a Miele Service
technician.
Coins/tokens must be removed from
the payment system regularly,
otherwise it will become blocked.
Note for service technician:
–
Room in which the dryer is located
Air taken in for use in the drying
process will be warm when it is
expelled from the underside and back
of the dryer. This expelled air heats up
the air in the room. It is therefore very
important to ensure that the room is
adequately ventilated, particularly if the
dryer is located in a small room.
Otherwise running times and energy
consumption could be increased.
Securing the tumble dryer against
slippage
,
Secure both front feet on the
dryer using the fixing brackets
supplied.
When connecting to a payment
,
system, the plug connector on the
push button switch (see wiring
diagram) must be disconnected
from its position ex-works and
reconnected to the position for
payment system operation.
Failure to do this can cause the
payment system to malfunction.
51
Installation and connection
External drainage of the
condensed water
The condensed water is pumped
away through the drain hose which is
located at the back of the dryer at the
bottom.
Drain hose length: ..............2m
Delivery head: .................1m
Do not pull on the drain hose
,
and do not allow it to become
kinked as this could damage it.
Drain hose connection:
1. Direct into a sink or basin.
– Hook the hose over the edge and
secure.
– Use the bow-shaped guide (see
illustration on the right).
Remove adapter 1 and hose clip 3
^
behind it.
^ Fit adapter 1 to the sink drain outlet
using nut 2.
2. Connected securely to a floor gully.
3. Connected directly to a sink drain
outlet.
Connection to a sink drain outlet
To connect the drain hose to a sink
drain outlet you will need to use the
adapter and hose clip located at the
back of the dryer at the bottom.
52
^
Secure the drain hose with hose clip
3 to the nut.
Electrical connection
All electrical work must be
,
carried out by a suitably qualified
and competent person in
accordance with current local and
national safety regulations (BS 7671
in the UK).
Installation and connection
If the machine is disconnected
,
from the electricity supply adequate
measures must be taken to ensure
that the machine cannot be
reconnected to the electricity supply
until all work has been carried out.
This machine is supplied with a
connection cable and moulded plug
(BS 1363) for connection to a 230 V
mains supply.
The machine must only be operated
with the voltage, frequency and fuse
rating shown on the data plate supplied
with the machine. Please ensure these
match the site mains supply.
We recommend connecting the
machine to the power supply via an
IP44 plug and socket which must be
easily accessible for servicing and
maintenance work after the machine
has been installed.
Do not connect the machine via an
extension lead. Extension leads do not
guarantee the required safety of the
machine (e.g. danger of overheating).
For extra safety and protection we
recommend connecting the machine by
a 30 mA residual current device (RCD).
The machine must be
,
permanently connected to the
electricity supply to enable the
programme to complete and to
enable the load to cool down after
drying. For this reason it must not be
connected to devices such as timers
which would switch it off
automatically.
WARNING
THIS MACHINE
MUST BE EARTHED
An electrical safety test must be carried
out after installation and after any ser
vice work.
The mains connection cable may only
be replaced by an original Miele spare
part.
-
53
Technical data
Height 850 mm
Width 595 mm
Depth 710 mm
Depth with door open 1188 mm
Weight 58 kg
Drum volume 130 litres
Maximum capacity 6.5 kg dry weight
Length of connection cable 1600 mm
Voltage
Connected load
Fuse rating See data plate
Lamp wattage
Test certificates awarded
Max. load bearing
in operation
Product safety standard According to EN 10472, EN 60335
Sound emission level
in accordance with
EN ISO 11204/11203
approx. 710 Newton
<70dBre20µPa
54
Changing default settings
Default settings can be altered to
adapt the tumble dryer to different
requirements.
Depending on the programmable
status, the Settings/Supervisor level
menu can be locked with a code to
prevent it being accessed by
unauthorised personnel (the Language
J setting can still be altered).
– Code not required
Some of the settings may be
changed.
–
Code required
All of the settings may be changed.
Please contact Miele for details.
Note:
The tumble dryer must be
commissioned as described at the
beginning of this booklet.
55
Settings menu
Opening the Settings menu
If the Settings menu is not locked,
some of the settings may be
changed.
A The entry menu showing the current
time of day will appear after the dryer
has been switched on, until you
select a programme.
10:00
Select a programme
Settings F...
B Press the OK button.
C This will take you into the Settings
menu.
Selecting a setting
C Back A
Language F
Supervisor level H
D Use the + and – buttons to select the
setting you want, and confirm your
selection by pressing the OK button.
–
The arrow H in the display indicates
that there are further options.
–
If you do not make a selection in the
Settings menu and in its sub-menus
within approx. 15 seconds, the
display will revert to the previous
menu.
Closing the Settings menu
Back A
C
Language F
Supervisor level
Select Back and confirm your
^
H
selection with the OK button.
Opening the Settings menu via
the Supervisor level
The Settings menu can be locked
against unauthorised use (except for
the Language option J). It will then
only be able to be accessed at
Supervisor level by entering a code.
C Back A
Language F
Supervisor level
^ Open the Supervisor level sub-menu
To enter the code
C Back A
Access via code
Change code
^
Confirm Access via code.
Enter the code 000(factory default
setting). If you enter the code wrongly
three times, you will be locked out of
the Supervisor level for an hour.
56
000
Enter code
Use the + button to enter the first
^
number.
Confirm your selection of this number
^
by pressing the OK button.
Now enter the second number.
^
Repeat the process until all three
^
numbers have been entered.
To confirm the code
Yes 000 No
Confirm code
^ Confirm the code with OK (Yes is
highlighted).
Settings menu
Language J
You can select the language
displayed via the Languages J
sub-menu.
The flag after the word Language acts
as a guide to prevent a language which
will not be understood from being set.
Supervisor level
You can alter the access code to the
supervisor level.
^ Enter the old code.
^ Enter a new code.
After you have confirmed the new code,
the display will change to the beginning
of the Settings menu.
To correct the code
^
Press the + button so that No is
highlighted.
^
Confirm by pressing the OK button.
^
Enter the correct code.
To change the code
^
See the "Supervisor level" setting.
57
Settings menu
Anti-crease
At the end of the programme the
drum can be set to rotate at intervals
for one or two hours to prevent
laundry creasing, if you do not wish
to remove it immediately.
Factory default: Off.
–
1h
–
2h
–
Buzzer
When the buzzer function has been
activated, an audible tone sounds at
the end of a programme.
– Off
(factory default)
The buzzer will still sound if there is a
fault even if it has been deactivated.
– Normal
The buzzer sounds at the end of a
programme.
–
Loud
The buzzer sounds at maximum
volume at the end of a programme.
Time of day
First select whether you want the
clock displayed as a 24 hour or 12
hour clock, or to not display it at all.
Then set the current time of day.
24 h clock or 12 h clock
–
Once the clock display has been
selected, the time of day can be set.
To set the time of day:
Set the hour with the – and + buttons,
^
and confirm your selection by
pressing the OK button.
^ Now set the minutes and confirm
your selection.
– Time not displayed
If Delay start is activated (see
Settings Delay start), then the timer
will only show the option Start in or
Finish in in hours/minutes.
Display contrast
Display brightness
There are ten different display
contrast and display brightness
settings.
58
The bars show you the setting.
–
Factory default: level 5
Settings menu
Standby
To save energy, the display goes out
after 10 minutes and the indicator
light for the Start button flashes
slowly.
The display is switched on again by
moving the programme selector or
touching one of the buttons, without any
effect on any programme that is
running.
On
–
Standby comes on:
...ifaprogramme is not selected.
. . . after the Start button has been
pressed in a programme that is
running.
. . . after the end of a programme.
– Not in current prog.
(default setting)
Standby is activated if no
programme selection is made after
the end of a programme - but not
during a programme that is running.
You cannot extend the cooling down
time for the Warm air, Cool air,
Woollens handcare or Smoothing
programmes.
Drying levels
Cottons
Please note: Changing the settings for
drying levels in the Settings menu will
also affect the Cottons t
programme.
Minimum iron
You can alter the drying levels for the
Cottons and Minimum iron
programmes.
The bars show you the setting.
– from drier to
– damper
– Factory default: level 4
Machine iron
Extended cool down
The cooling down phase which takes
place before the end of a programme
can be lengthened if required. This
makes the garments easier to handle.
The bars show you the setting.
–
from 0-18 mins.
–
Factory default: 0 mins (normal
cooling down period)
The programme duration will increase
accordingly.
The drying level Machine iron can be
altered separately in the Cottons
programme.
The bars show you the setting.
–
from drier to
–
damper
–
Factory default: medium.
59
Settings menu
Clean out airways
The electronic unit in the dryer
detects the degree of a blockage
caused by fluff or detergent residues
in the fluff filter or ducting, and the
following prompt comes up in the
display: Clean out airways. You can
decide at what level of fluff this
message should appear.
You will have an idea of how often this
should be done after a few drying
programmes.
Off
–
Clean out airways does not appear.
In cases of a very severe blockage in
the ducting, the programme is
cancelled and the message Clean
out airways comes up regardless of
this option.
– Heavy
Clean out airways only appears
when there is a heavy build-up of
fluff
Clean condenser unit
Check the condenser unit from time
to time, and clean it if necessary.
The Clean the condenser unit
maintenance message will remind
you to do this. You can decide after
how many hours you want the
message to appear.
The number of hours will depend on
how much fluff collects in the
condenser unit.
If the condenser unit gets choked with
fluff, or conversely there is hardly any
build-up of fluff in it, the number of
hours can be adjusted accordingly.
– Factory default: after 400 h.
– Off
– Time interval of 100 to 1600 hours
–
Normal
(Factory default setting)
–
Light
Clean out airways appears when
there is only a small build-up of fluff.
60
Delay start
You can set a later start time using
Delay start (see "Delay start").
You can decide how this time is
displayed.
Programme end
–
The finish time for the programme is
selected.
Programme start
–
The start time for the programme is
selected.
– Time until start
The time to the start of the
programme is selected in
minutes/hours.
– Off
(factory default)
Settings menu
By pressing the + button, the time
remaining and the finish time for the
programme is displayed.
616263
A
A
International Service Contacts
merica: +1 609 419 4376
ustralia, Asia, Oceania: +61 3 9764 7880
Europe, Africa, Middle East: +49 5241 89 66 877
E-mail: service@miele-marine.com
www.miele.com/marine-service
Manufacturer: Miele & Cie. KG, Carl-Miele-Straße 29, 33332 Gütersloh, Germany
Alteration rights reserved/3715
M.-Nr. 09 869 880 / 04
Loading...
