Miele KMDA 7774 Operating instructions

Operating and installation instructions
Ceramic hobs with induction

To avoid the risk of accidents or damage to the appliance it is essential
to read these instructions before it is installed and used for the first time.

en-AE, SA M.-Nr. 10 797 991

Contents

Warning and Safety instructions.......................................................................... 5

Caring for the environment ................................................................................ 17

Guide to the appliance........................................................................................ 18

Hob........................................................................................................................ 18

Controls / Indicators.............................................................................................. 19

Cooking zones....................................................................................................... 21

Before using for the first time ............................................................................ 22

Cleaning the hob for the first time......................................................................... 22

Switching on the hob for the first time .................................................................. 22

Induction .............................................................................................................. 23

How it works.......................................................................................................... 23

Noises.................................................................................................................... 24

Cookware .............................................................................................................. 25

How the cooker hood works .............................................................................. 26

Tips on saving energy ........................................................................................ 27

Cooking zone power levels ................................................................................28

Operation.............................................................................................................. 29

Using the appliance............................................................................................... 29

Switching on the hob ............................................................................................ 30

Setting the power level.......................................................................................... 30

Switching off a cooking zone ................................................................................ 30

Residual heat indicator.......................................................................................... 30

Power level setting - Extended setting range........................................................ 31

PowerFlex area ...................................................................................................... 31

Auto heat-up ......................................................................................................... 32

Booster.................................................................................................................. 33

Keeping warm ....................................................................................................... 35

Cooker hood.......................................................................................................... 36

Timer..................................................................................................................... 37

Minute minder ....................................................................................................... 37

Switching off a cooking zone automatically.......................................................... 38

Additional functions ............................................................................................ 39

Stop & Go.............................................................................................................. 39

Recall..................................................................................................................... 39

Wipe protection..................................................................................................... 40

Demonstration mode............................................................................................. 40

2

Contents

Displaying hob data............................................................................................... 40

Safety features..................................................................................................... 41

System lock / Safety lock...................................................................................... 41

Safety switch-off ................................................................................................... 43

Overheating protection.......................................................................................... 44

Programming ....................................................................................................... 45

Cleaning and care ............................................................................................... 48

Cooker hood drip tray ........................................................................................... 50

Grease filter / extraction grille................................................................................ 50

Resetting the grease filter operating hours counter ............................................. 51

Reactivating charcoal filter.................................................................................... 51

Resetting the charcoal filter operating hours counter........................................... 51

Problem solving guide ........................................................................................52

Optional accessories ..........................................................................................57

Miele@home / Con@ctivity ................................................................................ 58

Hob - Logging-on.................................................................................................. 58

Signing off the hob ................................................................................................ 58

Safety instructions for installation..................................................................... 59

Safety distances .................................................................................................. 60

Installation notes ................................................................................................. 63

Onset installation................................................................................................... 63

Flush-fit installation ............................................................................................... 64

Minimum plinth height........................................................................................... 64

Drip tray................................................................................................................. 64

Installation examples............................................................................................. 65

Changing the exhaust direction/fan position ...................................................66

Building-in dimensions - Onset hobs ................................................................ 68

KMDA 7774 FR...................................................................................................... 68

Worktop depth 600mm ........................................................................................ 70

Worktop depth greater than 600mm.................................................................... 72

Building-in dimensions - Flush-fit hobs ............................................................ 74

KMDA 7774 FL ...................................................................................................... 74

Worktop depth 600mm ........................................................................................ 75

Worktop depth greater than 600mm.................................................................... 77

3

Contents

Installation............................................................................................................ 79

Connection to a window contact switch if required.............................................. 79

Onset installation................................................................................................... 81

Flush-fit installation ............................................................................................... 82

Exhaust ducting................................................................................................... 83

Electrical connection ..........................................................................................84

Wiring diagram ..................................................................................................... 86

After sales service............................................................................................... 87

Contact in case of malfunction ............................................................................. 87

Data plate .............................................................................................................. 87

Guarantee.............................................................................................................. 87

Conformity declaration ....................................................................................... 88

4

Warning and Safety instructions

This hob complies with all relevant safety requirements.
Inappropriate use can, however, lead to personal injury and
damage to property.

To avoid the risk of accidents and damage to the hob, please read
these instructions carefully before installation and before using it
for the first time. They contain important notes on installation,
safety, use and maintenance.
Miele cannot be held liable for damage caused by non-compliance
with these instructions.

Keep these instructions in a safe place and ensure that new users
are familiar with the content. Pass them on to any future owner.

5

Warning and Safety instructions

Correct application

 This hob is intended for domestic use and use in other similar

environments.

 This hob is not intended for outdoor use.
 It is intended for domestic use only to cook food and keep it

warm. Any other use is not supported by the manufacturer and could
be dangerous.

 People with reduced physical, sensory or mental capabilities, or

lack of experience and knowledge who are not able to use the hob
safely on their own must be supervised whilst using it. They may
only use it unsupervised if they have been shown how to use it safely
and recognise and understand the consequences of incorrect
operation.

6

Warning and Safety instructions

Safety with children

 Children under 8 years of age must be kept away from the hob

unless they are constantly supervised.

 Children 8 years and older may only use the hob unsupervised if

they have been shown how to use it in a safe way and can recognise
and understand the consequences of incorrect operation.

 Children must not be allowed to clean the hob unsupervised.
 Please supervise children in the vicinity of the hob and do not let

them play with it.

 The hob gets hot when in use and remains hot for a while after

being switched off. Keep children well away from the hob until it has
cooled down and there is no danger of burning.

 Danger of burning.

Do not store anything which might arouse a child's interest in
storage areas above or next to the hob. Otherwise they could be
tempted into climbing onto the appliance.

 Danger of burning or scalding.

Place pots and pans on the cooking zone in such a way that children
cannot pull them down and burn themselves.

 Danger of suffocation. Packaging, e.g. plastic wrappings, must be

kept out of the reach of babies and children. Whilst playing, children
could become entangled in packaging or pull it over their head and
suffocate.

 Activate the system lock to ensure that children cannot switch on

the hob inadvertently. Use the safety lock when the hob is in use to
prevent children from altering the settings selected.

7

Warning and Safety instructions

Technical safety

 Unauthorised installation, maintenance and repairs can cause

considerable danger for the user. Installation, maintenance and
repairs must only be carried out by a Miele authorised technician.

 Do not use a damaged appliance. It could be dangerous. Check

the hob for visible signs of damage.

 Reliable and safe operation of this hob can only be assured if it

has been connected to the mains electricity supply.

 The hob must not be connected to the inverter of an autonomous

power supply such as e.g. a solar power system. When the
appliance is switched on, power surges could result in a safety
switch-off. This could damage the electronic unit.

 The electrical safety of this hob can only be guaranteed when

correctly earthed. It is essential that this standard safety requirement
is met. If in any doubt please have the electrical installation tested by
a qualified electrician.

 To avoid the risk of damage to the hob, make sure that the

connection data on the data plate (voltage and frequency) match the
mains electricity supply before connecting it to the mains.
Consult a qualified electrician if in doubt.

 Do not connect the hob to the mains electrical supply by a multi-

socket adapter or extension lead. These are a fire hazard and do not
guarantee the required safety of the appliance.

 For safety reasons, this hob may only be used after it has been

built in.

 This hob must not be used in a non-stationary location (e.g. on a

ship).

8

Warning and Safety instructions

 Never open the casing of the hob.

Touching or tampering with electrical connections or components
and mechanical parts is highly dangerous to the user and can cause
operational faults.

 While the hob is under warranty, repairs should only be

undertaken by a Miele authorised service technician. Otherwise the
warranty is invalidated.

 Miele can only guarantee the safety of the appliance when

genuine original Miele replacement parts are used. Faulty
components must only be replaced by Miele spare parts.

 The hob is not intended for use with an external timer switch or a

remote control system.

 The hob must be connected to the electricity supply by a qualified

electrician (see "Electrical connection").

 If the connection cable is damaged, it must be replaced by a

suitably qualified electrician with a special connection cable of type
H 05 VV-F (pvc insulated). See "Electrical connection".

 The hob must be disconnected from the mains electricity supply

during installation, maintenance and repair work. Ensure that power
is not supplied to the appliance until after it has been installed or
until any maintenance or repair work has been carried out.

 Danger of electric shock.

Do not use the hob if it is faulty, or if the ceramic surface is cracked,
chipped or damaged in any way. Switch it off immediately,
disconnect it from the mains electricity supply and contact your
Miele dealer.

 If the hob is installed behind a furniture panel (e.g. a door), ensure

that the door is never closed whilst the hob is in use. Heat and
moisture can build up behind a closed furniture panel and cause
subsequent damage to the hob, the housing unit and the floor. Do
not close the door until the residual heat indicators have gone out.

9

Warning and Safety instructions

Using at the same time as other heating appliances that depend on the air from the room

 Danger of toxic fumes!
Great care should be taken when using the cooker hood in the
same room or the same area of the house as another heating
appliance that depends on the air from the room.
Such heating appliances draw in air from the room and duct
exhaust gases out through a chimney or extraction ducting. They
include gas, oil, wood and coal-fired boilers and heaters,
continuous flow or other water heaters, gas hobs and ovens.

The cooker hood draws in air from the kitchen and from
neighbouring rooms. This applies to the following modes of
operation:

- extraction mode,

- recirculation mode with a recirculation box installed outside the
room.
If there is insufficient air, an underpressure will occur. The heating
appliance may be starved of oxygen. This impairs combustion.
Harmful gases could be drawn from the chimney or extraction
ducting back into the room, with potentially fatal consequences.
Risk of death!

10

Warning and Safety instructions

In order to ensure safe operation and to prevent gases given off by
the heating appliance from being drawn back into the room, when
the cooker hood and the heater are both operated simultaneously,
an underpressure in the room of 0.04mbar (4Pa) is the maximum
permissible.

Sufficient ventilation can be maintained by air inlets which cannot
be blocked, e.g. in windows, doors and outside wall vents. The
diameter of the inlet openings must enable sufficient ventilation. A
ventilation brick alone is not generally sufficient to ensure safe
ventilation.

The overall ventilation condition of the dwelling must be taken into
account. If in any doubt, the advice of a competent builder, or for
gas, a qualified gas fitter should be sought.

If the cooker hood is being operated in recirculation mode, where
the air is passed back into the room in which the extractor is
installed, the above restrictions do not apply.

11

Warning and Safety instructions

Correct use

 The hob gets hot when in use and remains hot for a while after

being switched off. There is a danger of burning until the residual
heat indicators go out.

 Oil and fat can overheat and catch fire. Do not leave the hob

unattended when cooking with oil and fat. If it does ignite do not
attempt to put the flames out with water.
Disconnect the hob from the mains and use a suitable fire blanket,
saucepan lid, damp towel or similar to smother the flames.

 Open flames are a fire hazard!

Do not flambé food. When switched on, the cooker hood could draw
flames into the filter. Kitchen grease deposits could ignite.

 Spray canisters, aerosols and other inflammable substances can

ignite when heated. Therefore do not store such items or substances
in a drawer under the hob. Cutlery inserts must be heat-resistant.

 Do not heat an empty pan.
 Do not heat up food in closed containers e.g. tins or sealed jars

on the hob, as pressure can build up in the container, causing it to
explode.

 Do not cover the hob, e.g. with a hob cover, a cloth or protective

foil. The material could catch fire, shatter or melt if the hob is
switched on by mistake or if residual heat is still present.

 When the appliance is switched on either deliberately or by

mistake, or when there is residual heat present, there is the risk of
any metal items left on the hob heating up, with the danger of
burning. Depending on the material, other items left on the hob could
also melt or catch fire. Damp pan lids might adhere to the ceramic
surface and be difficult to dislodge. Do not use the appliance as a
resting place. Switch the cooking zones off after use.

12

Warning and Safety instructions

 You could burn yourself on the hot hob. Protect your hands with

heat-resistant pot holders or gloves when handling hot pots and
pans. Do not let them get wet or damp, as this causes heat to
transfer through the material more quickly with the risk of scalding or
burning yourself.

 Hot cooking vapours during cooking can cause the cooker hood

to get hot.
Do not touch the casing or the grease filters until the cooker hood
has cooled down.

 When using an electrical appliance, e.g. a hand-held food blender,

near the hob, ensure that the cable of the electrical appliance cannot
come into contact with the hot hob. The insulation on the cable
could become damaged.

 Grains of salt, sugar and sand (e.g. from cleaning vegetables) can

cause scratches if they get under pan bases. Make sure that the
ceramic surface is clean before placing pans on it.

 Even a light object can cause damage in certain circumstances.

Do not drop anything on the ceramic surface.

 Placing hot pans on the sensors and indicators could damage the

electronics underneath. Do not place hot pans on the sensors or
indicators.

 Do not allow solid or liquid sugar, or pieces of plastic or aluminium

foil to get onto the cooking zones when they are hot, as they can
damage the ceramic surface when it cools down. If this should
occur, switch off the appliance and scrape off all the sugar, plastic or
aluminium residues whilst still hot, using a shielded scraper blade.
Wear oven gloves. Allow the cooking zones to cool down and clean
them with a suitable ceramic hob cleaning agent.

 Pans which boil dry can cause damage to the ceramic glass. Do

not leave the hob unattended whilst it is being used.

13

Warning and Safety instructions

 Only use pots and pans with smooth bases. Rough bases will

scratch the ceramic glass.

 Lift pans into position on the hob. Sliding them into place can

cause scuffs and scratches.

 Induction heating works extremely quickly and so the base of the

pan could heat up to the temperature at which oil or fat self-ignites
within a very short time. Do not leave the hob unattended whilst it is
being used.

 Heat oil or fat for a maximum of one minute. Do not use the

Booster function to heat oil or fat.

 For people fitted with a heart pacemaker: Please note that the

area immediately surrounding the hob is electromagnetically
charged. It is very unlikely to affect a pacemaker. However, if in any
doubt, consult the manufacturer of the pacemaker or your doctor.

 To prevent damage to items which are susceptible to

electromagnetic fields, e.g. credit cards, digital storage devices,
pocket calculators, etc, do not leave them in the immediate vicinity
of the hob.

 Metal utensils stored in a drawer under the hob can become hot if

the appliance is used intensively for a long time. Do not store any
metal items or utensils in a drawer under the hob.

 This hob is fitted with a cooling fan. If a drawer is fitted directly

underneath the hob, ensure that there is sufficient space between
the drawer and its contents and the underside of the appliance in
order to ensure sufficient ventilation of the hob. Do not store pointed
or small items or paper in the drawer. They could get in through the
ventilation slots or be sucked into the housing by the fan and
damage the fan or impair cooling.

 Do not use two pans on a cooking zone, extended zone or

PowerFlex zone at the same time.

14

Warning and Safety instructions

 If the pan only partially covers the cooking zone, the handle could

become very hot.
Ensure that you always place the pan in the middle of the cooking
zone.

 Deposits of grease and dirt will prevent the cooker hood from

working properly.
Do not use the cooker hood without the grease filters in place.
Otherwise cooking vapours will not be cleaned.

 There is a risk of fire if cleaning is not carried out as described in

these operating instructions.

 Do not cover the intake grille on the cooker hood when in use.
 Liquids can damage the cooker hood if they get into it. Keep

liquids away from the cooker hood.

 Light objects can be drawn into the cooker hood and impair its

operation. Do not place any light objects (e.g. paper towels) within
close proximity of the cooker hood.

15

Warning and Safety instructions

Cleaning and care

 Do not use a steam cleaning appliance to clean this hob.

The steam could reach electrical components and cause a short
circuit.

 If the hob is built in over a pyrolytic oven, the hob should not be

used whilst the pyrolytic process is being carried out, as this could
trigger the overheating protection mechanism on the hob (see
relevant section).

Accessories

 Only use genuine original Miele accessories and spare parts with

this appliance. Using accessories or spare parts from other
manufacturers will invalidate the guarantee, and Miele cannot accept
liability.

16

Caring for the environment

Disposal of the packing material

The packaging is designed to protect
the appliance from damage during
transportation. The packaging materials
used are selected from materials which
are environmentally friendly for disposal
and should be recycled.

Recycling the packaging reduces the
use of raw materials in the
manufacturing process and also
reduces the amount of waste in landfill
sites.

Disposal of your old appliance

Electrical and electronic appliances
often contain valuable materials. They
also contain materials which, if handled
or disposed of incorrectly, could be
potentially hazardous to human health
and to the environment. They are,
however, essential for the correct
functioning of your appliance. Please
do not therefore dispose of it with your
household waste.

Please dispose of it at your local
community waste collection / recycling
centre or contact your Miele dealer for
advice.

Ensure that it presents no danger to
children while being stored for disposal.

17

Guide to the appliance

Hob

a

PowerFlex cooking zone

b

PowerFlex cooking zone

c

PowerFlex cooking zone

d

PowerFlex cooking zone

18

e

Controls / Indicators

f

Grille

g

Grease filter

h

Removable drip tray

Guide to the appliance

Controls / Indicators

Sensor controls

a

For switching the hob on and off

b

Stop & Go

c

Wipe protection

d

For switching PowerFlex cooking zones on together/separately.

e

For activating/deactivating the keeping warm function

f

Numerical keybank
For setting power levels/minute minder and switch-off times

g

Automatic switch-off selector for cooking zones

h

Minute minder

Indicator lights

i

Automatic switch-off allocation of cooking zones

j

Residual heat

k

Booster

l

Timer display

: to
:

 System lock/safety lock activated
 Demonstration mode activated

Duration

19

Guide to the appliance

Cooker hood

a

Numerical keybank for setting the power level

b

Touch control for the 5minute run-on option

c

Touch control for the 15minute run-on option

d

Clean grease filter indicator

e

Reactivate charcoal filter indicator

20

Guide to the appliance

Cooking zones

Cooking zone Øin cm* Rating in watts for 230 V**

 15–23 Normal

TwinBooster, level 1
TwinBooster, level 2

 15–23 Normal

TwinBooster, level 1
TwinBooster, level 2

+ 22–23 /

15x23–23x39

 15–23 Normal

 15–23 Normal

+ 22–23 /

15x23–23x39

* Pans with a base diameter within the given range may be used.
** The wattage quoted may vary depending on the size and material of pans used.

Normal
TwinBooster, level 1
TwinBooster, level 2

TwinBooster, level 1
TwinBooster, level 2

TwinBooster, level 1
TwinBooster, level 2

Normal
TwinBooster, level 1
TwinBooster, level 2

Total 7300

2100
3000
3650

2100
3000
3650

3400
4800
7300

2100
3000
3650

2100
3000
3650

3400
4800
7300

21

Before using for the first time

 Please stick the extra data plate for

the appliance, supplied with this
documentation, in the space provided
in the "After sales service, data plate,
warranty" section of this booklet.

 Remove any protective wrapping and

stickers.

Cleaning the hob for the first time

 Before using for the first time, clean

the hob with a damp cloth only and
then wipe dry.

Switching on the hob for the first time

The metal components have a
protective coating which may give off a
slight smell when heated up for the first
time. The induction coils may also give
off a slight smell for the first few hours
of operation. This smell will be less
noticeable with each subsequent use
before dissipating completely.

The smell and any vapours given off do
not indicate a faulty connection or
appliance and they are not hazardous
to health.

Please note that the heating up time
on induction hobs is very much
shorter than on conventional hobs.

22

Induction

How it works

An induction coil is located under each
cooking zone. When a cooking zone is
switched on, this coil creates a
magnetic field which impacts directly
on the base of the pan and heats it up.
The cooking zone itself is heated up
indirectly by the heat given off by the
pan.

An induction cooking zone only works
when a pan with a magnetic base is
placed on it (see "Pans"). Induction
automatically recognises the size of the
pan.

The set power level flashes in the
numerical keybank for the cooking zone

– if the zone has been switched on

without a pan in place, or if the pan is
unsuitable (non-magnetic base),

– if the diameter of the base of the pan

is too small,

– if the pan is taken off the cooking

zone when it is switched on.

 When the appliance is switched

on either deliberately or by mistake,
or when there is residual heat
present, there is the risk of any metal
items placed on the hob (e.g. cutlery)
heating up.

Danger of burning.
Do not use the appliance as a resting

place for anything else. Switch the
cooking zones off after use with the
appropriate sensor controls.

If a suitable pan is placed on the
cooking zone within 3 minutes, the
flashing power level will go out and you
can continue as normal.

If no pan or an unsuitable pan is placed
on the cooking zone, the cooking zone
will switch off automatically after
3minutes.

23

Induction

Noises

When using an induction cooking zone,
the following noises can occur in the
pan, depending on what it is made of
and how it has been constructed.

On the higher power settings, it might
buzz. This will decrease or cease
altogether when the power setting is
reduced.

If the pan base is made of layers of
different materials (e.g. in a sandwiched
base), it might emit a cracking sound.

Whistling might occur if linked zones
(see "Booster") are being used at the
same time, and the pans also have
bases made of layers of different
materials.

You might hear a clicking sound from
the electronic switches, especially on
lower power settings.

You might hear a whirring sound when
the cooling fan switches on. It switches
on to protect the electronics when the
hob is being used intensively. The fan
may continue to run after the appliance
has been switched off.

24

Induction

Cookware

Suitable pans include:

– stainless steel pans with a magnetic

base

– enamelled steel pans

– cast iron pans

Unsuitable pans include:

– stainless steel pans without a

magnetic base

– aluminium or copper pans

– glass, ceramic or earthenware pots

and pans

To test whether a pot or pan is
induction-compatible, hold a magnet to
the base of the pan. If the magnet
sticks, the pan is generally suitable.
If the pan is unsuitable the set power
level will flash in the numerical keybank
for the cooking zone.

Please be aware that the properties of
the pan base can affect the evenness
with which the food heats up (e.g. when
making pancakes).

– To make optimum use of the cooking

zones, choose pans with a suitable
base diameter (see chapter "Cooking
zones"). If the pan is too small it will
not be recognised and the set power
level will flash in the numerical
keybank for the cooking zone.

– Use only pots and pans with smooth

bases. Rough bases can scratch the
ceramic glass.

– Always lift the pans to move them.

This will help prevent scratching.

– Please note that the maximum

diameter quoted by manufacturers
often refers to the diameter of the top
rim of the pot or pan. The diameter of
the base (generally smaller) is more
important.

25

How the cooker hood works

The cooker hood can be operated in
one of the following ways:

Extraction mode

The air is drawn in and cleaned by the
grease filter and directed outside.

Recirculation mode

(DUU 1000(-1) conversion kit required)

The air is drawn in and cleaned by the
grease filter. The air is then directed into
the recirculation box where it is also
cleaned by the charcoal filters. The
cleaned air is then recirculated back
into the kitchen.

Operating hours counter

The number of hours that the cooker
hood has been used for is stored in
memory.

When the grease filter symbol  or the
charcoal filter symbol , lights up, the
operating hours counters are signalling
that the filters need to be cleaned or
changed. Further information about
cleaning and changing the filters and
resetting the operating hours counter
can be found under "Cleaning and
care".

The instruction manual supplied with
the recirculation box states that the
operating hours counter for the
charcoal filter needs to be activated.
This is not necessary here.

The charcoal filter system  also
appears when the appliance is
operated using extraction mode.

26

Tips on saving energy

– Use a lid whenever possible to

minimise heat loss.

– Select a smaller pan when cooking

small quantities. A smaller pan uses
less energy than a larger pan with
very little in it.

– Cook with as little water as possible.

– Once food has come to the boil or

the oil in the pan is hot enough for
frying, reduce the heat to a lower
setting.

– Use a pressure cooker to reduce

cooking times.

– It is important to ensure that the

kitchen is well ventilated during
operation. In extraction mode if there
is insufficient air flow, the cooker
hood cannot operate efficiently and
this causes increased operating noise
levels.

– Always cook with the lowest possible

setting. This produces fewer cooking
vapours, so you can use a lower
power level and therefore benefit
from reduced energy consumption.

– Clean or replace the filters at regular

intervals. Heavily soiled filters reduce
performance, increase the risk of fire
and are unhygienic.

– Check the power level on the cooker

hood. A low power level is usually
sufficient. Only use the Booster
setting when necessary.

– When a large volume of cooking

vapours are being produced, switch
to a high power level in good time.
This is more efficient than operating
the cooker hood for longer to try to
capture cooking vapours which have
already been distributed throughout
the kitchen.

– Switch the cooker hood off after

cooking.

27

Cooking zone power levels

The cooking zones are set as standard with 9 power levels. If you wish to fine-tune
a setting, you can extend the power level range to 17power levels (see
"Programming").

Setting range

Default
setting

(9 power

levels)

Melting butter
Dissolving gelatine
Melting chocolate

Making milk puddings 2 2–2.
Heating small quantities of liquid

Cooking rice
Defrosting frozen vegetables 3 2.–3
Making porridge 3 2.–3.
Heating liquid and semi-solid food

Making omelettes and lightly frying eggs
Steaming fruit

Cooking dumplings 4 4–5.
Steaming vegetables, fish 5 5
Defrosting and reheating frozen food 5 5–5.
Gently frying eggs (without overheating the fat) 6 5.–6.
Bringing large quantities of food to the boil, e.g. casseroles

Thickening custard and sauces, e.g. Hollandaise
Gently frying meat, fish and veal sausages (without

overheating the fat)
Frying potato cakes, pancakes, etc 7 6.–7
Braising meat 8 8–8.
Boiling large quantities of water

Bringing to the boil

1–2 1–2.

3 3–3.

4 4–4.

6–7 6.–7

6–7 6.–7.

9 9

Extended

settings

(17 power

levels)

These settings should only be taken as a guide. The power of the induction coils will vary
depending on the size and material of the pan. For this reason it is possible that the settings
will need to be adjusted slightly to suit your pans. As you use the hob, you will get to know
which settings suit your pans best. When using new pans that you are not familiar with, set
the power level below the one specified.

28

Operation

Using the appliance

This ceramic hob is equipped with
electronic sensor controls which react
to finger contact. For safety reasons, in
order to switch the hob on, the On/
Off sensor needs to be touched for a
little longer than the other sensors.
Each time you touch a sensor, an
audible tone sounds.

Only the printed On/Off symbol is
visible when the hob is switched off.
More sensors light up when the hob is
switched on.

Malfunction due to dirty and/or
covered sensors

If the sensors are dirty or covered
this could cause them to fail to react,
to activate a function or even to
switch the hob off automatically (see
"Safety switch-off"). Placing hot
pans on the sensors/indicators can
damage the electronic unit
underneath.

Keep the sensors and indicators
clean and do not place anything on
top of them. Do not place hot pans
on them.

29

Operation

 Fire hazard.

Do not leave the hob unattended
whilst it is being used.
Please note that the heating up time
on induction hobs is very much
shorter than on conventional hobs.

Switching on the hob

 Touch the sensor.

Other sensors will light up.

If no further entry is made, the hob will
switch itself off after a few seconds for
safety reasons.

Setting the power level

Permanent pan recognition is
activated as standard (see
"Programming"). When the hob is
switched on and you place a pan on
one of the cooking zones, all the
sensors for that cooking zone's
numerical keybank will light up.

Switching off a cooking zone

 To switch off a cooking zone, touch

the 0 sensor for that cooking zone.

 To switch off the hob and all the

cooking zones, touch the sensor.

Residual heat indicator

If the cooking zone is still hot, the
residual heat indicator will light up after
the zone has been switched off.
Depending on the temperature, a dot
will appear above power levels 1, 2 and

3.

The dots of the residual heat indicator
will go out one after another as the
cooking zone cools down. The last dot
only goes out when the cooking zone is
safe to touch.

 Danger of burning. Do not touch

the cooking zones whilst the residual
heat indicators are lit up.

 Place a pan on the cooking zone you

want to use.

 Touch the appropriate number sensor

for the power level you want.

30

Operation

Power level setting - Extended setting range

 Touch the numerical keybank in

between two number sensors.

The numbers to the left and right of the
interim level light up brighter than the
others.

Example:
If you have set power level 7. the
numbers 7 and 8 will be brighter than
the other numbers.

PowerFlex area

The PowerFlex cooking zones combine
automatically to form a PowerFlex
cooking area when you place a
sufficiently large pot or pan on them
(see "Guide to the appliance - Hob").
Settings for the linked cooking area are
controlled by the front or left PowerFlex
zone (depending on model). The
PowerFlex cooking area can also be
switched on and off manually.

Position the pan centrally on the
PowerFlex cooking area.

Manually switching PowerFlex cooking zones on together/ separately.

 Touch the or sensor.

31

Operation

Auto heat-up

When Auto heat-up has been activated,
the cooking zone switches on
automatically at the highest setting and
then switches to the continued cooking
setting which you have previously
selected. The heat-up time depends on
which continued cooking setting has
been chosen (see chart).

Activating Auto heat-up

 Touch the sensor for the continued

cooking setting you want until a tone
sounds and the sensor starts to
pulsate.

During the heat-up time (see chart), the
continued cooking level set will pulsate.
With extended power levels (see
"Programming"), the sensors for the
power levels in front of and after the
interim power level will pulsate if an
extended power level setting has been
selected.

Altering the continued cooking setting
will deactivate Auto heat-up.

Deactivating Auto heat-up

 Touch the sensor for the continued

cooking setting, or

 Set another power level.

Continued

cooking setting

1 approx. 0:15

1. approx. 0:15

2 approx. 0:15

2. approx. 0:15

3 approx. 0:25

3. approx. 0:25

4 approx. 0:50

4. approx. 0:50

5 approx. 2:00

5. approx. 5:50

6 approx. 5:50

6. approx. 2:50

7 approx. 2:50

7. approx. 2:50

8 approx. 2:50

8. approx. 2:50

9 –

The continued cooking settings with a dot
after the number are only available if the
power level range has been extended (see
"Programming").

Heat-up time

[min : sec]

32

Operation

Booster

The cooking zones are equipped with a
TwinBooster.

When activated, the power is boosted
so that large quantities can be heated
up quickly, e.g. when boiling water for
cooking pasta. The boost in power is
active for a maximum of 15 minutes

The Booster function can only be used
on two cooking zones at the same time.

If the Booster function is switched on
when

– no power level has been selected,

the cooking zone will revert
automatically to level 9 at the end of
the booster time or if the booster
function is switched off before this.

– a power level has been selected, the

cooking zone will revert automatically
to the power level selected at the end
of the booster time or if the booster
function is switched off before this.

In each case two cooking zones are
linked together in order to provide
sufficient power for the Booster. While
the Booster is in operation some of the
power is taken away from the linked
cooking zone. This has one of the
following effects:

– Auto heat-up is deactivated

– The power level will be reduced.

– The linked cooking zone is switched

off.

33

Operation

Activating TwinBooster, level 1

 Place a pan on the cooking zone you

want to use.

 Select a power level if necessary.
 Touch theB sensor.

The indicator  for TwinBooster level 1
lights up.

Activating TwinBooster, level 2

 Place a pan on the cooking zone you

want to use.

 Select a power level if necessary.
 Touch theB sensor twice.

The indicator  for TwinBooster level 2
lights up.

Deactivating TwinBooster

 Touch theB repeatedly until the the

indicators go out, or

 Set another power level.

34

Operation

Keeping warm

This function is for keeping food warm
which has just been cooked and is still
hot. It is not for reheating food that
has gone cold.

The maximum duration for keeping food
warm is 2 hours.

– Keep food warm in the pan it was

cooked in and cover with a lid.

– You do not have to stir food while it is

being kept warm.

– Nutrients are lost when food is

cooked, and continue to diminish
when food is kept warm. The longer
food is kept warm for, the greater the
loss of nutrients. Try to ensure that
food is kept warm for as short a time
as possible.

Activating/deactivating the keeping warm function

 Touch the sensor for the cooking

zone you wish to use.

35

Operation

Cooker hood

The cooker hood will switch itself on
automatically if a there is a pan on the
cooking zone and a power level has
been set for that zone. The power level
on the cooker hood is set to suit to the
power level on the hob.

The power level of the cooker hood can
be manually altered at any time. For
light to heavy cooking vapours, select
from power levels 1 to 3. For short
periods of strong vapours and cooking
odours, e.g. whilst searing meat, select
the B Booster setting.

Switching the fan on and off

 To switch the fan on touch the

appropriate sensor for the power
level you want.

 To switch the fan off touch the 0

sensor.

If the fan is not switched off, it will
switch itself off automatically 12 hours
after the last time a control was
operated.

Fan run-on

It is advisable to run the fan for a few
minutes after cooking has finished This
helps to neutralise any lingering
vapours and odours in the air. The
following two options are available:
(5minutes) and  (15minutes).
The run-on duration will be carried out
using the power level set during
activation. You can change the power
level during the run-on period.

 Touch the or  sensor to activate

the run-on period.

 Touch the,  or 0 sensor to

deactivate the run-on period.

If you switch the hob off with the
sensor, the run-on period will continue
through to the end.

Booster

The maximum duration for the Booster
is 10minutes.

 To switch it off early, set a different

power level.

36

Tip: To help release vapours effectively
with pans over 15cm high, place a
wooden spoon between the lid and the
pan.

Timer

The hob has to be switched on if you
wish to use the timer.
You can set a duration between
1minute (:) and 9hours 59 minutes
(:).

Durations of up to 59 minutes are
shown in minutes (0:59), durations of
more than 60 minutes are shown in
hours and minutes. The duration is
shown in the order of hours, followed
by minutes in the tens and units
positions.

Example:

59 minutes = 0:59, Enter as: 5-9
80 minutes = 1:20, Enter as: 1-2-0

After the first number has been entered
the timer display will light up constantly.
After the second number has been
entered, the first number will move to
the left. After the third number has been
entered, the first and second numbers
will move to the left.

The timer can be used for two different
functions:

– to set the minute minder

– to set a cooking zone to switch off

automatically.

The functions can be used at the same
time. The shortest time is always
displayed and the sensor (minute
minder) or the indicator light for the
cooking zone (automatic switch-off)
pulsates.

If you want to show times remaining
which are counting down in the
background, touch the or  sensor.
If a switch-off time has been
programmed for several cooking zones,
touch the sensor repeatedly until the
indicator light for the cooking zone you
want pulsates.

Minute minder

The minute minder is set using the
numerical keybank for the (front) left
cooking zone.

To set the minute minder

 Touch the sensor.

The timer display will start to flash.
 Select the time you require.

To change the minute minder duration

 Touch the sensor.
 Select the time you require.

To delete the minute minder duration

 Touch the sensor until:

appears in the timer display.

37

Timer

Switching off a cooking zone automatically

You can set a time after which the
cooking zone will switch off
automatically. This function can be
used on all cooking zones at the same
time.

The switch-off time is set with the
numerical keybank for each cooking
zone you want to switch off
automatically.

If the time programmed is longer than
the maximum operational time
allowed, the cooking zone will switch
off after the maximum time allowed
(see "Safety switch-off").

 Select a power setting for the zone

you require.

 Touch the sensor.

The indicator light will start to flash.

touch the  sensor repeatedly until
the indicator light for the zone you
require flashes.

To change a switch-off time

 Touch the  sensor repeatedly until

the indicator light for the zone you
require flashes.

 Select the time you require.

To delete a switch-off time

 Touch the  sensor repeatedly until

the indicator light for the zone you
require flashes.

 Touch 0 on the numerical keybank.

 Select the time you require.
 If you want to set another cooking

zone to switch off automatically,
follow the same steps as described
above.

If more than one switch-off time is
programmed, the shortest time
remaining will be displayed, and the
corresponding indicator light will flash.
The other indicator lights will light up
constantly.

 If you want to show the time

remaining for another zone which is
counting down in the background,

38

Additional functions

Stop & Go

When Stop & Go is activated, the power
of all cooking zones in use is reduced to
power level1. The power level of the
cooker hood is not reduced. Depending
on the power level set for the hob it
may even increase.
The settings for the cooking zones and
the timer settings cannot be changed,
the hob can only be switched off. The
minute minder, Booster times and times
for Auto heat-up continue.
When deactivated, the cooking zones
will run on the setting that was
previously selected.

If the function is not deactivated within
1 h, the hob will switch off.

Activating / Deactivating

 Touch the sensor.

Use this function if there is a danger of
food boiling over.

Recall

If the hob is switched off in error during
operation, this function can be used to
reset all settings. For this to work, the
hob must be switched on again within
10seconds of being switched off.

 Switch the hob on again.

The previously set power level flashes.
 Touch one of the flashing power

levels immediately.

All the cooking zones and the timer will
continue to operate using the settings
selected previously.

39

Additional functions

Wipe protection

The hob sensors can be locked for
20s in order, for example, to remove
soiling. The is not locked.

Activating

 Touch the sensor.

The time will count down in the timer
display.

Deactivating

 Touch the sensor until the timer

display goes out.

Demonstration mode

This function enables the hob to be
demonstrated in showrooms without
heating up.

Activating / Deactivating

 Switch the hob on.
 Touch the 0 and 2 sensors on one of

the numerical keybanks for 6
seconds.

 will alternate with  (Demonstration
mode active) or  (Demonstration
mode deactivated) in the timer display
for a few seconds.

Displaying hob data

The model designation and software
version can be displayed. There must
not be any pots or pans on the hob.

Model designation

 Switch the hob on.
 Touch the 0 sensor on a numerical

keybank.

 Touch the0 and 4 sensors at the

same time.

The timer display shows 2 numbers
flashing alternately.

Example:  flashing alternately with 
= KM1234

Software version

 Switch the hob on.
 Touch the 0 sensor on a numerical

keybank.

 Touch the0 and 3 sensors at the

same time.

Numbers will appear in the timer
display:

Example: : = Software version 2.00

40

Safety features

System lock / Safety lock

The system lock and safety lock are
deactivated if there is an interruption
to the power supply.

Your hob is equipped with a system
lock and a safety lock to prevent the
hob and the cooking zones being
switched on or any settings being
altered.

The system lock is activated when the
hob is switched off. If the system lock is
activated, the hob cannot be switched
on and the timer cannot be used. A set
minute minder time continues to count
down. The hob is programmed so that
the system lock must be activated
manually. It can be programmed to be
activated automatically 5minutes after
the hob has been switched off if the
system lock is not manually activated
first (see "Programming").

The safety lock is activated when the
hob is switched on. When activated, the
hob can be operated only under certain
conditions:

– The cooking zones, the cooker hood

and the hob can only be switched off.

– A set minute minder can be changed.

If an unavailable sensor is touched
whilst the system lock or safety lock is
activated  will appear in the timer
display for a few seconds and a tone
will sound.

Activating the system lock

 Touch the sensor for 6seconds.

The time will count down in the timer
display.  will appear once the time
has elapsed. The system lock has been
activated.

Deactivating the system lock

 Touch the sensor for 6seconds.
 will appear briefly in the timer

display and then the time will count
down. The lock function is deactivated
once the time has elapsed.

41

Safety features

Activating the safety lock

 Touch and hold the and 

sensors at the same time for
6seconds.

The time will count down in the timer
display.  will appear once the time
has elapsed. The safety lock is
activated.

Deactivating the safety lock

 Touch and hold the and 

sensors at the same time for
6seconds.

 will appear briefly in the timer
display and then the time will count
down. Once the time has elapsed the
lock function is deactivated.

42

Safety features

Safety switch-off

Safety switch-off if the sensors are covered

Your hob will turn off automatically if
one or several of the sensors remain
covered for longer than 10 seconds, for
example, by finger contact, food boiling
over or by an object such as an oven
glove or tea towel. will flash briefly
above the sensor and a tone will
sound.

will go out once you have removed



the object or cleaned the hob and the
hob will be ready to use again.

Safety switch-off with an overlong cooking time

The safety switch-off mechanism is
triggered automatically if one of the
cooking zones is heated for an
unusually long period of time. This
period of time depends on the power
level selected. Once exceeded, the
cooking zone switches off and the
residual heat indicators appear. The
cooking zone can be operated again
after it has been switched off and back
on.



Power level* Maximum operating time

[h:min]

Safety setting

0** 1 2

1 10:00 8:00 5:00

1. 10:00 7:00 4:00

2/2. 5:00 4:00 3:00

3/3. 5:00 3:30 2:00

4/4. 4:00 2:00 1:30

5/5. 4:00 1:30 1:00

6/6. 4:00 1:00 0:30

7/7. 4:00 0:42 0:24

8 4:00 0:30 0:20

8. 4:00 0:30 0:18

9 1:00 0:24 0:10

* The power levels with a dot after the
number are only available if the power level
range has been extended (see "Setting
range").

** Factory default setting

The hob is programmed to safety
setting 0 at the factory. If necessary, a
higher safety setting with a shorter
maximum operating time can be set
(see chart).

43

Safety features

Overheating protection

All the induction coils and cooling
elements for the electronics are fitted
with an overheating protection
mechanism. Before the induction coils
or cooling elements get too hot, the
overheating protection mechanism cuts
in in one of the following ways:

Induction coils

– Any Booster function in operation will

be switched off.

– The set power level will be reduced.

– The cooking zone switches off

automatically.  flashes in the timer
display alternating with .

You can use the cooking zones again as
usual when the fault code has gone out.

Cooling elements

– Any booster function in operation will

be switched off.

– The set power level will be reduced.

The overheating protection mechanism
can be triggered by:

– Heating up an empty pan.

– Fat or oil being heated on a high

power level.

– Insufficient ventilation to the

underside of the hob.

– A hot cooking zone being switched

on after an interruption to the power
supply.

If, despite removing the cause, the
overheating protection mechanism
triggers again, contact your Miele
dealer.

– The cooking zones switch off

automatically.

The affected cooking zones can only be
used again as usual once the cooling
element has cooled down to a safe
level.

44

Programming

You can adapt the programming of the
hob to your personal needs. Several
settings can be altered in succession.

After accessing programming mode,
the symbol and  will appear in the
timer display. After a few seconds :
(programme 01) will flash alternately
with : (code) in the timer display.

Change programming

Accessing programming mode

The sensor is located approx.
1cm (index finger width) to the left of
the sensor.

 With the hob switched off, touch

the and  sensors at the same
time until the symbol and 
appear in the timer display.

Setting a programme

For a two digit programme number
you need to first set the tens position.

To save the settings

 While the programme is showing in

the display (e.g. :) touch the 
sensor until the indicators go out.

To avoid saving the settings

 While the programme is showing in

the display (e.g. :) touch the 
sensor until the indicators go out.

 Whilst the programme is visible in the

display (e.g. :), touch
thesensor repeatedly until the
number for the programme you want
appears in the display or touch the
appropriate number on the numerical
keybank.

Setting the code

 Whilst the code is visible in the

display (e.g. :), touch
thesensor repeatedly until the
number for the code you want
appears in the display or touch the
appropriate number on the numerical
keybank.

45

Programming

Programme

1)

Code

2)

Settings

P:01 Demonstration mode C:00 Demonstration mode off

C:01

Demonstration mode on

3)

P:03 Factory setting C:00 Do not restore standard settings

C:01 Restore standard settings

P:04 Number of power levels C:00 9 power levels

4)

P:06 Keypad tone when a sensor is

touched

C:01

C:00

17 power levels

5)

Off

C:01 Quiet

C:02 Medium

C:03 Loud

P:07 Audible tone for the timer C:00

Off

5)

C:01 Quiet

C:02 Medium

C:03 Loud

P:08 System lock C:00 System lock can only be activated

manually

C:01 System lock activated

automatically

P:09 Maximum operating time C:00 Safety setting 0

C:01 Safety setting 1

C:02 Safety setting 2

P:10 Miele@home/Con@ctivity C:00 Not available

C:01 Signed off

C:02 Signed on

P:12 Sensor controls reaction

speed

C:00 Slow

C:01 Normal

C:02 Rapid

46

Programming

Programme

1)

Code

2)

Settings

P:15 Permanent pan recognition C:00 Not active

C:01 Active

1)

Unlisted programmes are not assigned.

2)

The factory setting is shown in bold.

3)

After the hob has been switched on  appears in the timer display for a few seconds.

4)

In the text and charts, the extended power levels are shown with a dot after the number

for better understanding.

5)

The tone which sounds when the On/Off sensor is touched cannot be switched off.

47

Cleaning and care

 Danger of burning.

The cooking zones must be switched
off. The hob must have cooled down.

 Danger of injury.

The steam from a steam cleaning
appliance could reach electrical
components and cause a short
circuit.

Do not use a steam cleaner to clean
the hob.

The use of unsuitable cleaning
agents can cause the surfaces to
discolour or alter.

All surfaces are susceptible to
scratching.

Remove any cleaning agent residues
immediately.

Allow the hob to cool down before
cleaning.

 Clean the hob after every use.
 Dry the hob thoroughly after every

cleaning to avoid limescale residue.

Unsuitable cleaning agents

To avoid damaging the surfaces of your
appliance, do not use:

– washing-up liquid,

– cleaning agents containing soda,

alkalines, ammonia, acids or
chlorides,

– cleaning agents containing descaling

agents,

– stain or rust removers,

– abrasive cleaning agents, e.g.

powder cleaners and cream cleaners,

– solvent-based cleaning agents,

– dishwasher cleaner,

48

– grill and oven cleaners,

– glass cleaning agents,

– hard, abrasive brushes or sponges,

e.g. pot scourers, or sponges which
have been previously used with
abrasive cleaning agents,

– melamine eraser blocks.

Cleaning and care

Cleaning the glass ceramic surface

Risk of damage from pointed
objects!

Do not clean the area between the
glass ceramic surface and the frame
or the frame and the worktop with
sharp, pointed objects.

Not all soiling and residues can be
removed using a solution of
washing-up liquid.

An invisible film can develop that can
lead to discolouration of the ceramic
glass. This discolouration cannot be
removed.

Clean the glass ceramic surface
regularly with a suitable ceramic hob
cleaning agent.

 Remove any coarse soiling with a

damp cloth and more stubborn
soiling with a glass scraper.

 Spots caused by limescale, water

and aluminium residues (spots with a
metallic appearance) can be removed
using Miele's ceramic and stainless
steel hob cleaner.

 Danger of burning.

Wear oven gloves when removing
residues of sugar, plastic or
aluminium foil from a hot hob with a
glass scraper.

 Should any sugar, plastic or

aluminium foil spill or fall onto a hot

cooking zone while it is in use, first
switch off the appliance.

 Then carefully scrape off these

residues immediately whilst they are
still hot, using a shielded scraper
blade.

 Afterwards, clean the glass ceramic

surface in its cooled state, as
described above.

 Then clean the ceramic glass surface

with the Miele ceramic and stainless
steel hob cleaner (see "Optional
accessories") or with a proprietary
ceramic glass cleaner applied with a
paper towel or a clean cloth. Do not
apply the cleaner while the hob is still
hot, as this can result in marking.
Please follow the cleaning agent
manufacturer's instructions.

 Finally wipe the hob with a damp

cloth and polish with a soft, dry cloth.

Residues can burn onto the hob the
next time it is used and cause damage
to the ceramic surface. Ensure that all
cleaning agent residues are removed.

49

Cleaning and care

Cooker hood drip tray

Clean the drip tray if liquid from food
being spilled or boiling over has got into
the cooker hood.

 Remove the grease filter and clean as

described in "Grease filters".

 Hold the drip tray securely and open

the 4 catches (2 on the right and 2 on
the left). Hold the drip tray
horizontally and carefully take it out of
the housing.

 Pour the liquid away.
 Clean and dry the drip tray.

Grease filter / extraction grille

The extraction grille and the reusable
metal grease filter collect solid matter
from kitchen vapours (grease, dust etc.)
and therefore prevent soiling of the
cooker hood. The grease filter must be
cleaned after 30 hours of use. The 
sensor will light up.

An oversaturated filter is a fire
hazard.

Clean the grease filter regularly.

Removing the grease filter

 Lift up the extraction grille.
 Remove the grease filter carefully. Do

not let the grease filter tip over.

 Pour out any liquid which has

collected at the bottom of the grease
filter.

 Also clean and dry accessible arease

inside of the cooker hood.

 Secure the drip tray back in the

housing.

 Replace the grease filter and replace

the extraction grille.

50

Cleaning and care

Cleaning the extraction grille and the grease filter by hand.

 Clean the extraction grille and the

grease filter with a soft nylon brush in
a mild solution of hot water and a
little washing-up liquid. Do not use
concentrated washing-up liquid.

Cleaning the extraction grille and the grease filter in the dishwasher

 Place the extraction grille upright in

the lower basket.

 Place the grease filter with the filter

base at the top in lower basket.
Ensure the spray arm is not
obstructed.

 Use a proprietary household

dishwasher detergent.

 Select a dishwasher programme with

a wash temperature between 50°C
and 65°C.

Depending on the dishwasher
detergent used, cleaning the filter in a
dishwasher can cause permanent
discolouration to internal surfaces of
the filter. However, this will not affect
the functioning of the filter in any way.

Resetting the grease filter operating hours counter

After cleaning the grease filter, the
operating hours counter needs to be
reset.

 Touch the sensor for 3seconds.

The sensor will go out.

Reactivating charcoal filter

The charcoal filter needs to be
reactivated after 120operating hours.
The  sensor will light up.

 Reactivate the charcoal filter as

described in the operating
instructions supplied with the
recirculation box.

Resetting the charcoal filter operating hours counter

 Touch the sensor for 3seconds.

The sensor will go out.

Internal surfaces of the cooker hood

 Whilst the grease filter is removed

remove any grease deposits from all
accessible areas of the housing
Doing so will prevent a fire hazard.

51

Problem solving guide

Many malfunctions and faults that can occur in daily operation can be easily
remedied. Time and money will be saved because a service call will not be
needed.

The following guide may help you to find the reason for a malfunction or a fault,
and to correct it.

Issue Cause and remedy

The hob or cooking
zones cannot be
switched on.

A smell and vapours are
given off when the new
appliance is being used.

The power level
selected is flashing.

After the hob has been
switched on or a sensor
has been touched 
appears in the timer
display for a few
seconds.

There is no power to the hob.
 Check if the mains fuse has tripped. If it has,

contact a qualified electrician or your Miele dealer
(minimum fuse rating - see data plate).

There may be a technical fault.
 Disconnect the appliance from the electricity

supply for approx. 1 minute. To do this:
– switch off at the isolator, or
– disconnect the mains fuse.

 If, after resetting the trip switch in the mains fuse

box and switching the appliance back on, the
appliance will still not heat up, contact a qualified
electrician or your Miele dealer.

The metal components have a protective coating.
When the appliance is used for the first time, this
causes a smell and possibly also vapour. The material
from which the induction coils are made also gives off
a smell in the first few hours of operation. This smell
will be less noticeable with each subsequent use
before dissipating completely. The smell and any
vapour given off do not indicate a faulty connection or
appliance and they are not hazardous to health.

There is no pan on the cooking zone, or the pan is
unsuitable.

 Use a suitable pan (see "Pans").

The system lock or safety lock is activated.
 Deactivate the system lock or safety lock (see

"System lock / Safety lock").

52

Issue Cause and remedy

The hob has switched
off automatically. When
the hob is switched
back on, an appears
above the On/Off
sensor.

After the hob has been
switched on  appears
in the timer display for a
few seconds. The
cooking zones do not
heat up.

A cooking zone
switches off
automatically.

A cooking zone or the
whole hob switches off
automatically.

The Booster has
deactivated early
automatically.

The cooking zone is not
working in the usual
way on the power
setting selected.

Power level 9 is
automatically reduced if
you select power level 9
on two linked cooking
zones at the same time.

The food in the pan
does not heat up when
the Auto heat-up
function is switched on.



One or more of the sensors are covered, e.g. by finger
contact, food boiling over or an object.

 Clean off any dirt or remove the object (see

"Safety switch-off").

The hob is in demonstration mode.

 Touch the and  sensors at the same time until

 flashes alternately with  in the timer display.

It has been operated for too long.
 You can use the cooking zone again by switching

it back on (see "Safety switch-off").

The overheating protection mechanism has been
activated.

 See "Overheating protection".

The overheating protection mechanism has been
activated.

 See "Overheating protection".

The overheating protection mechanism has been
activated.

 See "Overheating protection".

Operating both zones at power level 9 would exceed
the permitted maximum power for the two zones.

 Use a different cooking zone.

A large amount of food is being heated up.
 Start cooking at the highest power level and then

turn down to a lower one manually later on.

The pan is not conducting heat properly.
 Use a different pot or pan which conducts heat

properly.

Problem solving guide

53

Problem solving guide

Issue Cause and remedy

An operating noise can
be heard after the
appliance has been
switched off.

The sensors show
increased sensitivity or
fail to react.

 alternating with 
flashes in the timer
display.

1 and a number, e.g. 1-0
flashes alternately with
a 3 digit number in the
timer display.

The fan will continue running until the appliance has
cooled down. It will then switch itself off
automatically.

The sensitivity level of the sensors has changed.
 Make sure that there is no direct light (from the sun

or from an artificial source) falling onto the hob.
The area surrounding the hob must not be too
dark.

 Make sure that there is nothing covering the

sensors or the hob.
Take any pans off the hob and wipe away any food
deposits.

 Interrupt the power supply to the hob for approx. 1

minute.

 If the problem persists after power has been

restored, please contact your Miele dealer.

The hob is incorrectly connected.
 Contact your Miele dealer. The hob must be

connected to the mains according to the wiring
diagram.

Cooking zone fault
 Interrupt the power supply to the hob for approx. 1

minute.

 If the problem persists after power has been

restored, please contact your Miele dealer.

54

Issue Cause and remedy

 alternating with a
number flashes in the
timer display.

Liquid has got into the
cooker hood.



The overheating protection mechanism has been
activated.

 See "Overheating protection".
,  or 

The fan is blocked or defective.
 Make sure it has not been blocked by something

like a fork. Remove the cause of the blockage.

 If this fault code continues to appear in the

display, contact your Miele dealer.

 and other numbers
There is a fault in the electronic module.

 Interrupt the power supply to the hob for approx. 1

minute.

 If the problem persists after power has been

restored, please contact your Miele dealer.

Due to boiling over or spillage, liquid has made its
way through the extraction grille into the cooker hood.
The base of the grease filter can hold approx. 250ml
of liquid. The drip tray underneath the housing can
hold a further 250ml of liquid.

Problem solving guide

 Switch the cooker hood off.
 Clean the grease filter, the drip tray and the inside

of the housing (see "Cleaning and care").

Extraction performance
has decreased.
Extraction noise has
increased.

The  sensor is lit up. The charcoal filter needs to be reactivated.

Objects (e.g. a cloth) have been drawn into the cooker
hood.

 Switch the cooker hood off.
 Remove the grease filter (see "Cleaning and care").
 Remove any objects from the grease filter.

 If the cooker hood is being operated in

Recirculation mode, proceed as described in the
operating instructions supplied with the
recirculation box. Reset the operating hours
counter (see "Cleaning and Care" in this manual).

 If the cooker hood is being operated in Extraction

mode, reset the operating hours counter (see

"Cleaning and Care" in this manual).

55

Problem solving guide

Issue Cause and remedy

The  sensor is lit up. The grease filter must be cleaned.

 Clean the grease filter as described in "Cleaning

and Care – Grease filter / Extraction grille".

56

Optional accessories

Miele offer a comprehensive range of
useful accessories as well as cleaning
and conditioning products for your
Miele appliances.

These can be ordered from your Miele
dealer (see end of this booklet for
contact details).

Pans

Miele offer a wide range of pans which
are perfect for Miele hobs. Please
contact your Miele dealer for more
details on individual products.

– Pans in various sizes

– Frying pan with lid

– Anti-stick pans

– Wok

– Gourmet oven dishes

Cleaning and care products

Ceramic and stainless steel hob cleaner 250 ml

Removes heavy soiling, limescale
deposits and aluminium residues

Microfibre cloth

Removes finger marks and light soiling

57

Miele@home / Con@ctivity

Hob - Logging-on

To sign the hob onto Miele@home,
prepare the logging-on process on the
master appliance.

 With the hob switched off, touch

the and  sensors at the same
time until the symbol and 
appear in the timer display.

After a few seconds :
(programme01) will flash alternately
with : (code) in the timer display.

 While : is shown in the display,

press the  sensor as often as
necessary until : (programme
P:10) is displayed.

 While : is shown in the display,

press the  sensor as often as
necessary until : appears in the
display.

The signing on process will begin and a
scrolling bar will appear in the display.
The signing on process takes a few
minutes. As soon as it is completed
successfully,: will light up in the
display.

Signing off the hob

If you want to sign the hob off from
Miele@home, first carry out the signing
off procedure on the master appliance.

 With the hob switched off, touch

the and  sensors at the same
time until the symbol and 
appear in the timer display.

After a few seconds :
(programme01) will flash alternately
with : (code) in the timer display.

 While : is shown in the display,

press the  sensor as often as
necessary until : (programme
P:10) is displayed.

 While : is shown in the display,

press the  sensor as often as
necessary until : appears in the
display.

The signing off process will begin and a
scrolling bar will appear in the display.
The signing-off process will take a few
minutes. As soon as it is completed
successfully,: will light up in the
display.

 If the signing on process is not

completed successfully, repeat the
process.

 While : is visible in the display,

touch the sensor until the
indicators go out to save the setting.

 Finish signing on the cooker hood/

master appliance (see the relevant
instructions).

58

 If the signing off process is not

completed successfully, repeat the
process.

 While : is visible in the display,

touch the sensor until the
indicators go out to save the setting.

Safety instructions for installation

 The appliance must only be installed and connected to the electricity supply

by a suitably qualified and competent person in strict accordance with current
national and local safety regulations.

Fit the wall units and cooker hood before fitting the hob to avoid damaging the
hob.

 The veneer or laminate coatings of worktops (or adjacent kitchen

units) must be treated with 100°C heat-resistant adhesive which will
not dissolve or distort. Any backmoulds must be of heat-resistant
material.

 The hob must not be installed over a fridge, fridge-freezer, freezer,

dishwasher, washing machine, washer-dryer or tumble dryer.

 This hob must not be installed above ovens or cookers unless

these have a built-in cooling down fan.

 After installation, ensure that nothing can come into contact with

the connection cable and that it is without hindrance.

 The electrical cable may not come into contact with any moving

kitchen component (e.g. a drawer) or be subject to mechanical
obstruction which could damage it.

 Observe carefully the safety clearances listed on the following

pages.

 Exhaust ducting must be of non-inflammable material. Suitable

material is available from your Miele dealer.

 The appliance must not be connected to a chimney or flue which

is in use. Neither should it be connected to ducting which ventilates
rooms with fireplaces.

 If exhaust air is to be extracted into a chimney or ventilation duct

no longer used for other purposes, seek professional advice.

All dimensions are given in mm.

59

Safety distances

Safety distance above the hob

The safety distance specified by the
manufacturer of the cooker hood must
be maintained between the hob and the
cooker hood above it.

If combustible objects are installed
above the hob (e.g., cabinets, utensil
rail, etc.), a minimum safety distance of
600mm must be maintained.

When two or more appliances which
have different safety distances are
installed together below a cooker
hood, you should observe the
greatest safety distance.

60

Safety distances to the sides and back of the hob

It is advisable to install the hob with
plenty of space either side of it.

The minimum distance  shown below
must be maintained between the back
of the hob and a tall unit or wall.

Safety distances

The minimum distance ,  shown
below must be maintained between a
tall unit or a wall to the left or right of
the hob with a minimum distance of
300mm on the opposite side.

Minimum distance between the back
of the worktop cut-out and the rear
edge of the worktop:
50mm

Minimum distance between the
worktop cut-out and a wall or tall unit to
the right of it:
50mm.

Minimum distance between the
worktop cut-out and a wall or tall unit to
the left of it:
50mm.

Not allowed

Recommended

Not recommended

Not recommended

61

Safety distances

Safety distance when installing the appliance near a wall with additional niche cladding

A minimum safety distance must be maintained between the worktop cut-out and
any niche cladding to protect it from heat damage.

If the niche cladding is made from a combustible material (e.g. wood) a minimum
safety distance  of 50 mm must be maintained between the cut-out and the
cladding.

If the niche cladding is made from a non-combustible material (e.g. metal, natural
stone, ceramic tiles) the minimum safety distance  between the cut-out and the
cladding will be 50 mm less the thickness of the cladding.
Example: 15 mm niche cladding
50mm - 15mm = minimum safety distance of 35mm

Flush-fitted hobs Hob with frame or bevelled edge

a

Masonry

b

Niche cladding dimension x = thickness of the niche cladding material

c

Worktop

d

Worktop cut-out

e

Minimum distance to

combustible materials 50mm
non-combustible materials 50mm - dimension x

62

Installation notes

Onset installation

Seal between the hob and the worktop

Using sealant under the hob could
result in damage to the hob and the
worktop if the hob ever needs to be
removed for servicing. Do not use
sealant between the hob and the
worktop.
The sealing strip under the edge of
the top part of the hob provides a
sufficient seal for the worktop.

Tiled worktops

Grout lines and the hatched area
underneath the hob frame must be
smooth and even. If they are not the
hob will not sit flush with the worktop
and the sealing strip underneath the
hob will not provide a good seal
between the hob and the worktop.

63

Installation notes

Flush-fit installation

Flush-fit installation is only possible in
natural stone (granite, marble), solid
wood and tiled worktops. Certain
models are suitable for building into
glass worktops - please see advice
under "Building-in dimensions". When
using a worktop made from any other
material, please check first with the
worktop manufacturer that it is
suitable for installing a flush fit hob.

The internal width of the base unit
underneath the appliance must be at
least as wide as the inner worktop cut­out (see chapter "Building-in
dimensions"), so that the hob is easily
accessible from underneath after
installation and the bottom half of the
casing can be removed for
maintenance. If the underside of the
hob is not freely accessible after
installation, any sealant used to plug
the gaps around the appliance must
be removed to enable the hob to be
lifted out of the cut-out should this be
necessary.

The hob can be installed

– in a suitable cut-out in a natural stone

worktop,

– in a suitable cut-out in a solid wood,

tiled or glass worktop with a wooden
support frame. The frame must be
provided on site, and is not supplied
with the appliance.

Minimum plinth height

The minimum plinth height is 100 mm.

Housing unit back panel

The extraction ducting is laid behind the
housing unit back panel. The back
panel must be removable for
maintenance purposes.

Drip tray

The hob must be installed such that the
drip tray is easily accessible as it needs
to be removed for cleaning.

64

Installation examples

Recirculation mode

Extraction mode

Installation notes

65

Changing the exhaust direction/fan position

By modifying the cooker hood, it is
possible to change the position of the
fan and the exhaust connection.

Rotating the fan

 Place the hob on its ceramic surface

on a soft underlay.

 Rotate the fan by 90°.
 Secure the fan by the 4screws. Make

sure that the plastic edge is on the
left.

Extraction to the right

 Release the 4 catches and remove

the drip tray.

 Undo the 4 screws on the fan.

 Undo the fixing bracket.

66

 Secure the fan to the fixing brackets.
 Place the cooker hood onto the drip

tray again and secure the tray using
the 4 catches.

Changing the exhaust direction/fan position

Extraction to the left

 Undo the 4 screws on the frame.

 Lift the frame and the fan and turn it

180°.

 Refit the 4 screws in the frame.

 Secure the fan to the fixing brackets.
 Place the cooker hood onto the drip

tray again and secure the tray using
the 4 catches.

67

Building-in dimensions - Onset hobs

a

KMDA 7774 FR

Front

b

Removable drip tray

c

Mains connection box with mains
connection cable, L = 1440 mm

d

Air duct connection – at the back
(ex-works)

e

Air duct connection - on the right
(conversion required)

f

Air duct connection - on the left
(conversion required)

68

KMDA 7774 FL

Building-in dimensions - Onset hobs

a

Front

b

Removable drip tray

c

Mains connection box with mains
connection cable, L = 1440 mm

d

Air duct connection – at the back
(ex-works)

e

Air duct connection - on the right
(conversion required)

f

Air duct connection - on the left
(conversion required)

69

Building-in dimensions - Onset hobs

Worktop depth 600mm

KMDA 7774 FR

a

Housing unit back panel
The housing unit back panel must be
removable for service work. The
housing unit wall and an adjoining
room wall or a piece of furniture
must be at least 110 mm apart to
ensure sufficient room for the
ducting.

b

Drip tray
After installation the removable drip
tray must be accessible from below.

KMDA 7774 FL

a

Housing unit back panel
The housing unit back panel must be
removable for service work. The
housing unit wall and an adjoining
room wall or a piece of furniture
must be at least 110 mm apart to
ensure sufficient room for the
ducting.

b

Drip tray
After installation the removable drip
tray must be accessible from below.

70

Extraction to the rear

Extraction to the right

Building-in dimensions - Onset hobs

Extraction to the left

71

Building-in dimensions - Onset hobs

Worktop depth greater than
600mm

KMDA 7774 FR

a

Housing unit back panel
The housing unit back panel must be
removable for service work. The
housing unit wall and an adjoining
room wall or a piece of furniture
must be at least 110 mm apart to
ensure sufficient room for the
ducting.

b

Variable length of interim piece

c

Drip tray
After installation the removable drip
tray must be accessible from below.

x= Dimension by which the worktop is
deeper than 600 mm.

KMDA 7774 FL

a

Housing unit back panel
The housing unit back panel must be
removable for service work. The
housing unit wall and an adjoining
room wall or a piece of furniture
must be at least 110 mm apart to
ensure sufficient room for the
ducting.

b

Variable length of interim piece

c

Drip tray
After installation the removable drip
tray must be accessible from below.

x= Dimension by which the worktop is
deeper than 600 mm.

72

Extraction to the rear

Extraction to the right

Building-in dimensions - Onset hobs

Extraction to the left

73

Building-in dimensions - Flush-fit hobs

a

KMDA 7774 FL

Front

b

Removable drip tray

c

Mains connection box with mains
connection cable, L = 1440 mm

d

Stepped cut-out

e

Wooden frame (to be provided on
site)

f

Air duct connection – at the back
(ex-works)

g

Air duct connection - on the right
(conversion required)

h

Air duct connection - on the left
(conversion required)

74

Building-in dimensions - Flush-fit hobs

Worktop depth 600mm

KMDA 7774 FL

a

Housing unit back panel
The housing unit back panel must be
removable for service work. The
housing unit wall and an adjoining
room wall or a piece of furniture
must be at least 110 mm apart to
ensure sufficient room for the
ducting.

b

Drip tray
After installation the removable drip
tray must be accessible from below.

75

Building-in dimensions - Flush-fit hobs

Extraction to the rear

Extraction to the right

Extraction to the left

76

Building-in dimensions - Flush-fit hobs

Worktop depth greater than
600mm

KMDA 7774 FL

a

Housing unit back panel
The housing unit back panel must be
removable for service work. The
housing unit wall and an adjoining
room wall or a piece of furniture
must be at least 110 mm apart to
ensure sufficient room for the
ducting.

b

Variable length of interim piece

c

Drip tray
After installation the removable drip
tray must be accessible from below.

x= Dimension by which the worktop is
deeper than 600 mm.

77

Building-in dimensions - Flush-fit hobs

Extraction to the rear

Extraction to the right

Extraction to the left

78

Connection to a window contact switch if required

 The window contact switch is

live!
Danger of electrical shock!
Disconnect the hob from the mains

electricity supply before connecting
the switching mechanism.

The switching mechanism must only
be connected by a suitably qualified
person.

Installation

The switching mechanism
connection cable must be type

H03VV-F 2x0.75mm2 and must not
exceed 2.0 m in length.
The switching mechanism must be
equipped with a potential free shut­off contact suitable for 230V, 1A.
When open the cooker hood is off.
Only use DIBt permitted and tested
wireless switching mechanisms (e.g.
window contact switches,
underpressure monitors) which have
been approved for use by an
authorised person.
You will need the relevant documents
supplied with the external switching
mechanism to ensure its safe
connection and operation.

 Release the catch and pull the plug

out.

 Undo the screw  on the cable strain

relief and undo the casing on both
sides.

 Open the casing.
 Remove the stopper.

79

Installation

 Exchange bridge  with the

switching mechanism connection
cable.

 Close the casing.
 Retighten the screw for the cable

strain relief.

 Reconnect the plug.

80

Onset installation

 Prepare the worktop cut-out

Remember to maintain the minimum
safety distances (see "Safety
distances").

 Seal the cut surfaces on wooden

worktops with a suitable heat-

resistant sealant to avoid swelling
caused by moisture. The sealant
must be temperature-resistant.

Make sure that the sealant does not
come into contact with the top of the
worktop.

 Attach the seal provided underneath

the edge of the hob.

 Feed the mains connection cable

down through the cut-out.

 Place the hob centrally in the cut-out.

When doing this make sure that the
seal of the appliance sits flush with
the worktop on all sides. This is
important to ensure an effective seal
all round.

Installation

Do not use any additional sealant
(e.g. silicone) on the hob.

If the seal does not meet the worktop
correctly on the corners, the corner
radius (≤ R4) can be carefully scribed
to suit.

 Connect the hob to the mains.
 Check that the hob works.

81

Installation

Flush-fit installation

 Prepare the worktop cut-out

Remember to maintain the minimum
safety distances (see "Safety
distances").

 Solid wood, tiled and glass worktops:

Fix a wooden frame5,5 mm below
the top edge of the worktop (see
diagram in "Building-in dimensions ­flush-fit hobs).

 Attach the seal provided underneath

the edge of the hob.

 Feed the mains connection cable

down through the cut-out.

 Centre the hob in the cut-out.

The gap between the ceramic surface
and the worktop must be at least
2mm wide. This is so that the hob can
be sealed.

 Connect the hob to the mains.
 Check that the hob works.
 Seal the gap between the hob and

the worktop with a silicone sealant
that is heat-resistant to at least
160°C.

Unsuitable sealant can damage
natural stone.

For natural stone worktops and
natural stone tiles, only use silicone
sealant that is specially formulated
for natural stone. Please follow the
manufacturer's instructions.

82

 If the cooker hood is used at the

same time as a heating appliance
that relies on oxygen from the same
room, there is a risk of toxic fumes.

It is essential that the "Warning and
Safety" instructions are observed.

The cooker hood should be installed
according to local and national
building regulations. Seek approval
from the building inspector where
necessary.

The cooker hood has an exhaust
connection of 222x89mm.

 Use smooth pipes or flexible ducting

made from approved non-flammable
materials for exhaust ducting.

 To achieve the most efficient air

extraction with the lowest noise
levels, please note the following:

– The cross-section of the exhaust

ducting must not be smaller than the
cross-section of the exhaust
connection (see "Appliance
dimensions").

Exhaust ducting

 If the exhaust air is to be ducted into

a flue, the ducting must be directed in
the flow direction of the flue.

 Where ducting is horizontal, it must

be laid to slope away at at least 1 cm
per metre. This is to ensure that
condensate cannot drain back into
the cooker hood.

 If the exhaust ducting is to run

through rooms, ceiling space etc.
where there may be great variations
in temperature between the different
areas. The problem of condensation
will need to be addressed. The
exhaust ducting will need to be
suitably insulated.

– The exhaust ducting should be as

short and straight as possible.

– Only use wide radius bends.

– The exhaust ducting must not be

kinked or compressed.

– Ensure that all connections are

strong and airtight.

Remember that any constriction of
the air flow will reduce extraction
performance and increase operating
noise.

83

Electrical connection

 Danger of injury.

Miele cannot be held liable for
unauthorised installation,
maintenance and repair work as this
can be dangerous to users.
Miele cannot be held liable for
damage or injury caused by incorrect
installation, maintenance or repair
work, or by an inadequate or faulty
earthing system (e.g. electric shock).

This hob must be connected to the
mains electrical supply by a suitably
qualified and competent person, in
accordance with current local and
national safety regulations.

After installation ensure that all
electrical components are shielded
and cannot be accessed by users.

Total power rating

See data plate

Connection data

The connection data is quoted on the
data plate. Please ensure these match
the household mains supply.

Please see wiring diagrams for
connection.

Separators

The appliance must be able to be
disconnected from the mains on all
poles by disconnecting devices. When
switched off there must be an all-pole
contact gap of at least 3 mm in the
isolator switch. Disconnecting devices
include overcurrent protection and
circuit breakers.

84

Electrical connection

Disconnecting from the mains

 Danger of electric shock.

After disconnection, ensure the
appliance cannot be switched back
on by mistake.

To disconnect the appliance from the
mains power supply, do one of the
following depending on installation:

Safety fuses

 Completely remove fuses

Automatic circuit breakers

 Press the (red) button until the middle

(black) button springs out.

Built-in circuit breakers

 Circuit breakers, type B or C: switch

the on-off switch from 1 (on) to 0 (off).

Residual current device (RCD)

 Switch the main switch from 1 (on) to

0 (off) or press the test button.

Mains connection cable

The hob must be connected to the
electrical supply with a special
connection cable, type H 05 VV-F (PVC
insulated) with a suitable diameter.

Please see wiring diagram for
connection.

See the data plate on the hob for the
correct voltage and frequency.

Replacing the mains cable

 Danger of electrical shock.

The mains connection cable must be
fitted by a suitably qualified and
competent person in accordance
with current local and national safety
regulations.

The wires in the mains cable are
coloured in accordance with the
following code:
Green/yellow = earth
Blue = neutral
Brown = live

The earth lead must be connected to
the point marked.

If the mains cable needs to be replaced
it must be replaced with a special
connection cable, type H05VV-F (PVC­insulated), available from your Miele
dealer.

The connection data is quoted on the
data plate.

85

Electrical connection

L1

200-240 V~

200-240 V~

200-240 V~

ab

cde

-

L2 L3 N

-

L2

b

L1

a cdNe

(L3)

200-240 V~

200-240 V~

aL1bcdNe

-

(L2)

200-240 V~

Wiring diagram

86

After sales service

Contact in case of malfunction

In the event of any faults which you cannot remedy yourself, please contact your
Miele Dealer.

Contact details for Miele are given at the end of this document.

Please note that telephone calls may be monitored and recorded for training
purposes and that a call-out charge will be applied to service visits where the
problem could have been resolved as described in this booklet.

Please quote the model and serial number of your appliance when contacting
Miele. This information can be found on the data plate.

Data plate

Stick the extra data plate supplied with the appliance here. Make sure that the
model number matches the one specified on the back cover of this document.

Guarantee

For information on the appliance guarantee specific to your country please contact
your Miele dealer. See end of this booklet for contact details.

87

Conformity declaration

Miele hereby declares that the hobs
listed at the end of this booklet comply
with the basic requirements and other
relevant regulations of
Guideline1999/5/EC.

A copy of the full Declaration of
Conformity can be obtained from the
address on the back page.

88

Manufacturer:

Miele & Cie. KG, Carl-Miele-Straße 29, 33332 Gütersloh, Germany

Miele Saudi Arabia
AWAD BADI NAHAS TRADING CO. LTD
Head Office:
Jeddah

Miele United Arab Emirates

Miele Appliances Ltd.
Gold & Diamond Park
Office No. 6-217
Sheikh Zayed Road
P.O. Box 114782 - Dubai
United Arab Emirates

Tel. [phone]
Fax. [phone]
800-MIELE (64353)
E-Mail: [e-mail]
Website: www.miele.ae
Webshop: www.shop.miele.ae

Sama Tower (Ground Floor)
Dubai World Trade Center
Roundabout
Dubai

Shed No. 9, Block B,
Jamal Al Ghurair Warehouses
Al Quoz Industrial III
Dubai

Miele Gallery Dubai

Miele Service Centre

Taif

Riyadh

Branches:

Khobar

Jeddah

Jeddah

Jeddah

P.O. Box 11529 Jeddah 21463
Tel. [phone], Fax. [phone]
Hotline for customer care: 920003240
Website: www.awadnahas.com

Madina Road
Tel. [phone], Fax. [phone]

Sitteen Street
Tel. [phone], Fax. [phone]

Miele Gallery
Al Thanyyan Group Building, Al-Madina Road,
Near, Al Rowdah District, Jeddah
Tel. [phone] Ext. 100
Fax. [phone] Ext. 200

Olaya Street
Tel. [phone], Fax. [phone]

Hadiya Street
Tel. [phone], Fax. [phone]

Al Zahran Road
Tel. [phone], Fax. [phone]

KMDA7774



M.-Nr. 10 797 991 / 00en-AE, SA
