Operating instructions
Gas cooktops
To avoid the risk of accidents or damage to the appliance, it is essential
to read these operating instructions before it is installed or used for the
first time.
M.-Nr. 05 827 461en - AUS
Contents
Description of the appliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Appliance models ..................................................3
Burner ...........................................................5
Warning and Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Caring for the environment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Before using for the first time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
General notes ....................................................13
Cleaning and heating up for the first time ...............................13
Using the gas cooktop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Switching on, controlling, switching off .................................14
Settings .........................................................16
Suitable pans for gas burners ........................................17
Safety cut-out.....................................................18
Use during a power cut .............................................18
Cleaning and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
General .........................................................19
Pan support, Control knobs ..........................................19
Cooktop surface ..................................................20
Burners .........................................................21
Problem solving guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Gas connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Electrical connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
After Sales Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
2
Appliance models
KM 390
Description of the appliance
a Wok ring
b Wok burner
c Auxiliary burner
d Fast burner
e Normal burner
f Pan support (separate for each
burner)
g Cooking zone symbols
h Mains connection cable
Depending on country of destination,
the appliance may be supplied with
or without a plug. The plug shown is
for illustration only
Control knob for cooking zone:
i Front right
j Rear right
k Rear middle
l Rear left
m Front left
3
Description of the appliance
KM 391
a Wok burner
b Wok ring
c Auxiliary burner
d Fast burner
e Normal burner
f Mains connection cable
Depending on country of destination,
the appliance may be supplied with
or without a plug. The plug shown is
for illustration only.
g Pan support (separate for each
burner)
h Cooking zone symbols
4
Control knob for cooking zone:
i Front right
j Rear right
k Rear middle
l Rear left
m Front left
Description of the appliance
Burner
Wok burner Auxiliary, normal and fast burner
n Burner cap
o Burner ring
p Burner head
q Burner base
r Ignitor
s Ignition safety device
5
Warning and Safety instructions
The electrical safety of this
This appliance complies with all
relevant legal safety requirements.
Improper use of the appliance can,
however, present a risk of both
personal injury and material
damage.
To avoid the risk of accidents and
damage to the appliance, read
these instructions carefully before
using it for the first time. They
contain important notes on the
installation, safety, operation and
care of the appliance.
Supervise elderly or infirm when
using the appliance.
Keep these instructions in a safe
place for reference and pass them
on to any future user.
Building in and connection
The connection to the gas supply
~
must be carried out by a suitably
qualified and competent person in
accordance with local and national
safety regulations, e.g. a registered gas
fitter. If the appliance is supplied
without a plug, or if the plug is removed
the appliance must additionally be
installed and connected by a suitably
qualified and competent electrician in
strict accordance with national and
local regulations. The manufacturer
cannot be held responsible for damage
caused by incorrect installation or
connection.
~
appliance can only be guaranteed
when continuity is complete between it
and an effective earthing system which
complies with local and national safety
regulations. It is most important that this
basic safety requirement is present and
tested regularly, and where there is any
doubt, the household wiring system
should be inspected by a qualified
electrician. The manufacturer cannot be
held liable for the consequences of an
inadequate earthing system (e.g.
electric shock).
Ensure that the gas pipe and
~
electrical cable are installed in such a
way that they do not touch any parts of
the appliance which become hot. This
could cause damage.
Do not connect the appliance to the
~
mains electricity supply by an extension
lead. Extension leads do not guarantee
the required safety of the appliance.
This appliance must not be installed
~
and used in mobile installations (e.g.
ships, caravans etc.).
Do not modify this appliance.
~
6
Warning and Safety instructions
Correct usage
For safety reasons the appliance
~
must only be operated after it has been
built in. This is necessary to ensure that
all electric components are shielded.
This appliance is for domestic use
~
only, and is not intended for
commercial use.
Use this appliance for the
~
preparation of food only. Any other
usage is at the owner's risk and could
be dangerous. The manufacturer
cannot be held liable for damage
caused by incorrect or improper use of
the appliance.
Do not use the appliance to heat up
~
the room. The high temperature could
cause inflammable objects nearby to
catch fire.
Using the gas cooktop can cause
~
heat and moisture to build up in the
kitchen. Ensure that the room is well
ventilated; open a door or window or
provide a mechanical means of
ventilation, by installing a rangehood,
for example.
Make sure all the components of the
~
gas burners have been correctly
assembled before switching on.
When using a rangehood over the
~
gas cooktop, ensure that any burners in
use are always covered with a pan.
Otherwise flames could be drawn up by
the suction of the rangehood, parts of
which could then be damaged or even
set on fire.
Pans must be the correct size for the
~
burner they are used on (see "Suitable
pans"). A pan which is too small will be
unstable on the pan support. If the pan
diameter is too large flames can spread
out to the sides and damage or burn
the worktop, wall claddings or
surrounding units and also parts of the
cooktop. The manufacturer cannot be
held liable for this type of damage.
Do not use or store flammable
~
materials in the appliance storage
drawer or near this appliance.
If the cooktop is used for very long
~
periods of time additional ventilation of
the room may be necessary, e.g. by
opening windows or doors, or running
the rangehood on the highest setting.
This appliance must not be set up or
~
operated in the open air.
7
Warning and Safety instructions
Safety with children
The appliance is only intended for
~
use by adults who have read these
operating instructions.
This appliance is not a toy! To avoid
~
the risk of injury keep children well
away and do not let them play with it or
use the controls. They will not
understand the potential dangers
posed by it. They should be supervised
whenever you are working in the
kitchen.
Older children may use the
~
appliance only when its operation has
been clearly explained to them, and
they are able to use it safely,
recognising the dangers of misuse.
The appliance gets hot when in use
~
and remains hot for quite a while after
being switched off. To safeguard
against burning, keep children well
away from the appliance at all times.
Keep all pans out of reach of
~
children. Turn pan handles inwards
away from the edge of the cooktop.
Danger of burning or scalding.
Packaging (e.g. cling film,
~
polystyrene) and plastic wrappings
must be kept out of the reach of babies
and young children. Danger of
suffocation. Dispose of all packaging
safely as soon as possible.
Before disposing of an old
~
appliance, ensure that disconnection
from the gas supply is made by a
suitably qualified and competent
person. Switch off at the mains
electricity supply. Cut off and render
any plug useless. Cut off the cable
directly behind the appliance to prevent
misuse. This should be done by a
competent person. Ensure that the
appliance presents no danger to
children while being stored for
disposal.
Do not store anything which might
~
arouse a child's interest in storage
areas above or next to the appliance.
Otherwise they could be tempted into
climbing onto the appliance with the
risk of burning themselves.
8
Warning and Safety instructions
Protecting the appliance from
damage
Do not use a steam cleaner to clean
~
this appliance. The steam could reach
electrical components and cause a
short circuit. Pressurised steam could
also cause permanent damage to the
surface and to other components, for
which the manufacturer cannot accept
liability.
Unless the pan manufacturer states
~
that you can do so, you should never
use pans with thin bases on this
cooktop and you should never heat up
an empty pan. Otherwise the cooktop
could get damaged.
In countries where there are areas
~
which may be subject to infestation by
cockroaches or other vermin, pay
particular attention to keeping the
appliance and its surroundings in a
clean condition at all times. Any
damage which may be caused by
cockroaches or other vermin will not be
covered by the appliance guarantee.
Stainless steel surfaces:
Avoid allowing liquids or foods
~
containing salt to spill onto a stainless
steel cooktop or trim. If salty foods or
liquids do get on the cooktop, they
should be removed as soon as possible
to avoid the risk of corrosion.
Replace the pan supports carefully
~
to avoid scratching the surface.
Appliances with a ceramic surface:
Do not drop anything on the ceramic
~
surface. Even a light object could
cause damage in certain
circumstances.
9
Warning and Safety instructions
Protection from burning and
scalding
The surface of the appliance gets
~
hot when in use, and remains hot for
quite a while after being switched off.
Do not touch it whilst it is still hot.
Use heat-resistant pot holders or
~
gloves when handling hot pots and
pans. Ensure that they do not come into
contact with the flames. Do not use
large cloths, tea towels or similar as the
ends could touch the flames and catch
fire. Take care not to let pot holders or
gloves get damp or wet, as this causes
heat to transfer through the material
quicker with the risk of burning yourself.
Do not heat up unopened tins of
~
food on the cooktop as pressure will
build up in the tin and it can explode.
This could result in injury or damage.
Do not use the cooktop as a resting
~
place for anything else. If the cooktop
was switched on inadvertently, or if it
was still hot the article could begin to
melt or catch fire.
Remove splashes of fat and other
~
food debris from the surface as soon as
possible. These are a fire hazard.
Never leave the appliance
~
unattended when cooking with oil or fat
as these are fire hazards if overheated.
Very hot oil can catch fire and could
even set a rangehood above on fire.
Always heat fat slowly, watching as it
heats.
If, despite this, oil or fat does catch
~
fire, do not attempt to put out the flames
with water. Use a suitable fire blanket,
saucepan lid, damp towel or similar to
smother the flames.
Do not flambé under a rangehood.
~
The flames could set the rangehood on
fire.
Ensure that the flames from the
~
burner do not spread out beyond the
base and up the sides of the pan.
Do not spray aerosols in the vicinity
~
of this appliance while it is in operation.
Do not cover the cooktop with a
~
cloth, household foils or other similar
objects. This could lead to danger of
the article catching fire, if the cooktop
were to be switched on inadvertently.
10
Warning and Safety instructions
With a damaged appliance
In the event of damage or a defect,
~
switch off the appliance immediately.
Turn off the gas supply tap, and
disconnect completely from the
electricity supply. Contact Miele.
Ensure that the appliance is
disconnected from the electricity
supply before any servicing or repair
work.
Ceramic cooktops:
~
Any breakages or cracks in the ceramic
surface of the cooktop are defects and
must be treated as such.
Repairs to the gas and electrical
~
components of this appliance must only
be carried out by a suitably qualified
person. Repairs by unauthorised
personnel could be dangerous. On no
account open the outer casing of the
appliance.
While the appliance is under
~
guarantee repairs should only be
undertaken by a service engineer
authorised by the manufacturer.
Otherwise the guarantee is invalidated.
Further safety notes
When using an electrical appliance,
~
e.g. a hand-held mixer, near the gas
cooktop, ensure that the connection
cable doesn't come into contact with
the hot cooktop. The insulation on the
cable could become damaged, giving
rise to an electric shock hazard.
Always ensure that food is
~
sufficiently cooked or reheated. Many
factors will affect the overall cooking
time, including the size and amount of
food and its temperature. Some foods
may contain micro-organisms which are
only destroyed by thorough cooking;
therefore when cooking or reheating
foods such as poultry, it is particularly
important that the food is completely
cooked through. If in doubt, select a
longer cooking or reheating time.
Do not use plastic or aluminium foil
~
containers. These melt at high
temperatures and could damage the
ceramic surface. Fire hazard.
If the appliance has not been used
~
for a longer period of time it should be
thoroughly cleaned before it is used
again. It is also advisable to have the
appliance tested for safety. This should
be done at regular intervals.
The manufacturer cannot be held
liable for damage caused by
non-compliance with these safety
instructions.
11
Caring for the environment
Disposal of the packaging
material
The transport and protective packing
has been selected from materials which
are environmentally friendly for disposal
and can normally be recycled.
Packaging (e.g. cling film, polystyrene)
and plastic wrappings must be kept out
of the reach of babies and young
children. Danger of suffocation.
Dispose of or recycle all packaging
materials as soon as possible.
Disposal of your old appliance
or machine
Electrical and electronic appliances /
machines often contain materials
which, if handled or disposed of
incorrectly, could be potentially
hazardous to human health and to the
environment. They are, however,
essential for the correct functioning of
your appliance or machine. Please do
not therefore dispose of your old
machine or appliance with your
household waste.
Please dispose of it at your local
community waste collection / recycling
centre and ensure that it presents no
danger to children while being stored
for disposal.
12
It should be unplugged or
disconnected from the mains electricity
supply by a competent person. The
plug must be rendered useless and the
cable cut off directly behind it to
prevent misuse.
Before using for the first time
General notes
A data plate for your appliance is
supplied with this documentation. It
should be stuck into the space
provided at the end of the instruction
book. The address of your nearest
Miele office is given on the back page.
Cleaning and heating up for
the first time
Before using for the first time clean the
cooktop and all removable parts as
follows:
The removable parts of the gas
^
burner assembly can be washed in a
mild solution of water and
washing-up liquid. Wipe dry and
reassemble in the correct order (see
"Cleaning and care").
Clean the cooktop with a damp cloth
^
only, and then wipe dry.
Do not use washing up liquid to
clean the ceramic surface as it can
leave a blue sheen which may be
difficult to remove.
Metal components have a protective
coating which may give off a slight
smell when the cooktop is heated up for
the first time. The smell and any
vapours will dissipate after a short time
and do not indicate a faulty connection
or appliance.
13
Using the gas cooktop
Switching on, controlling,
switching off
The control knobs are used to switch on
the burner and regulate the strength of
the flame.
Small, medium and large burners
Wok burner
The burners can only be switched
on by pressing in the appropriate
control and turning it anti-clockwise,
and switched off by turning the
control clockwise. The outer flame
ring on the wok burner can only be
switched on and off by pressing the
control in and turning it the
appropriate way.
The following can damage
components in the appliance:
- Trying to switch on a burner
without pressing in the control.
- Switching off a burner by
turning it anti-clockwise.
- Switching the outer flame ring
on the wok burner on or off
without pressing in the control.
- Switching on a burner by
turning it clockwise.
The manufacturer cannot be held
liable for this type of damage.
14
To switch on:
^
The control for the burner required
must be pressed in and turned
anti-clockwise to the large flame
symbol to switch on.
^
When the flame ignites, keep the
control pressed in for 8-10 seconds,
and then let it go.
If the flame goes out, repeat the
procedure, keeping the control pressed
in for a few extra seconds.
Using the gas cooktop
Controlling:
When the flame burns steady after
^
releasing the knob, select a setting
between the large and the small
flame symbol. The flame gets
smaller, when you turn the control
knob anti-clockwise and bigger when
turning clockwise. You don’t need to
press the knob.
Wok burner:
^
On reaching the resistance briefly
press the knob to turn past. Then
without pressing it in turn the control
to the required setting.
^ Control the flame so that it does not
spread out beyond the sides of the
pan. As the outer part of the flame is
much hotter than the centre, the tips
of the flames should stay beneath the
pan base. Flame tips which extend
beyond the sides of the pan merely
warm up the air in the room and can
also damage pan handles and
increase the danger of burning.
Switching off:
Turn the knob clockwise until the "ß"
^
position is reached.
This stops the flow of gas and the flame
goes out.
15
Using the gas cooktop
Settings
Setting Auxiliary-, nromal-
and fast burner
ß gas supply is turned off
* strong flame outer ring: strong
inner ring: strong
&
(2x)
+ - outer ring: off
/ weak flame outer ring: off
- outer ring: weak
inner ring: strong
inner ring: strong
inner ring: weak
Wok burner
16
Using the gas cooktop
Suitable pans for gas burners
Burners Min. pan base
diameter in cm
Small burner 10
Medium burner 12
Large burner 14
Wok burner 14*
Max. diameter at
top of pans in cm
Small burner 22
Medium burner 22
Large burner 24
Wok burner 24*
* This diameter doesn't apply when
using a wok.
– You should select pans which are
suitable for the burner they are to be
used on. In general: use larger
diameter pans on the large burner
and smaller diameter pans on the
small burner.
–
Wide, shallow pans are preferable to
tall, narrow ones. They will heat up
faster.
Pans with thick bases are preferable
–
as these distribute heat more evenly,
and therefore lessen the risk of heat
spots occurring which can cause
food to stick or burn. With thin bases
heat is conducted quickly to the
food, however there is a danger of
food heating up unevenly and too
quickly increasing the risk of burning.
Stir the food frequently.
Any heat-resistant pans can be used
–
on a gas burner.
Remember when purchasing new
–
pans that manufacturers usually refer
to the diameter at the top of the pan
in their documentation.
– Refer to the chart above and ensure
that the pan diameter falls within the
minimum and maximum diameters
given for the burner you are using. A
pan which is too small will be
unstable on the pan support. If the
pan diameter is too large flames can
spread out to the sides and damage
or burn the worktop, wall claddings
or surrounding units and also parts of
the cooktop. The manufacturer
cannot be held liable for this type of
damage.
–
Use a pan lid whenever possible to
minimise heat loss.
17
Using the gas cooktop
Safety cut-out
This appliance is fitted with an electric
ignition safety device which cuts off the
supply of gas to a burner if the flame
goes out, for example if food has boiled
over, or if there was a sudden draught.
To use the cooktop again, turn the
^
knob clockwise until the "ß" position
is reached and switch on as normal.
The safety cut-out operates
independently from the electricity
supply. This means that it is still active
when the cooktop is used during a
power cut (see "Use during a power
cut").
Use during a power cut
If there is an interruption to the
electricity supply the gas can be
ignited with a match:
Press in the relevant control knob
^
and turn it anti-clockwise to the large
gas symbol.
Hold the control pressed in and light
^
the gas at the burner with a match.
Keep the control knob pressed in for
^
a further 8-10 seconds and then
release it.
18
Cleaning and care
General
Clean the appliance regularly,
preferably after each use. Allow it to
cool sufficiently.
Do not use a steam cleaner to clean
this appliance. The steam could
reach electrical components and
cause a short circuit. Pressurised
steam could also cause permanent
damage to the surface and to other
components, for which the
manufacturer cannot accept liability.
Do not use any sharp objects which
could damage the seal between the
ceramic surface and the
surrounding frame and between the
frame and the worktop.
Do not use any of the following on
your cooktop as they can damage
the surface material:
cleaning agents containing sand,
soda, alkalines, acids or chlorides,
grill and ovensprays, dishwasher
detergent, stain or rust removers,
scouring agents or cream cleaners,
abrasive sponges and brushes
Pan support, Control knobs
Take off the pan supports.
Clean these and the control knobs with
a damp cloth, washing up liquid and
warm water. Stubborn soiling is best
soaked before.
Finally dry everything with a clean soft
cloth.
On stainless steel models:
Replace the pan supports carefully
to avoid scratching the surface.
Do not let the ignitor in the burner
get wet. It it gets wet it will not spark.
After cleaning the cooktop it must
be thoroughly dried with a soft cloth
to prevent a build up of limescale
deposits.
19
Cleaning and care
Cooktop surface
Stainless steel
Clean the cooktop surface with a
sponge and a mild solution of warm
water and washing up liquid. Soak
baked or hardened spills.
Dry the cooktop surface thoroughly
after cleaning.
The stainless steel surface of the
cooktop can be cleaned using a
proprietary non-abrasive cleaning
agent designed for use on stainless
steel surfaces. Apply with an even
pressure following the direction of the
"grain".
Please contact Miele for information on
the appropriate cleaning product.
Thoroughly remove salty foods or
liquids from the cooktop as soon as
possible to avoid the risk of
corrosion.
Ceramic surface
Wipe soiling off using a damp cloth.
Stubborn soiling is best removed with a
shielded scraper blade.
Then apply a proprietary cleaning
agent for ceramic surfaces using a soft
cloth or kitchen paper towel. This way
any limescale deposits, caused for
example by water boiling over, are
removed.
Finally wipe the cooktop surface with a
damp cloth and then dry it with a clean
soft cloth.
Note that some cleaning agents contain
a protective additive designed to
prevent water marks and smears
adhering to the surface.
Do not use washing up liquid on the
ceramic surface as it can leave a
blue sheen which may be difficult to
remove.
20
When using a cleaner for ceramic
surfaces follow the manufacturer’s
instructions on the packaging.
Cleaning and care
Burners
The burners can be dismantled for
cleaning.
Proceed as follows:
Take off all the removable parts of the
^
burner and wash in a solution of hot
water and washing-up liquid. Then
dry them all thoroughly. Make sure
that the flame holes are clean and
completely dry.
The surface of the burner cover will
gradually become more matt with time.
This is quite normal and will not affect
the operation of the cooktop.
Wipe the fixed parts of the burner
^
base with a damp cloth and dry
afterwards.
Gently wipe the ignitor and the
^
ignition safety device with a well
wrung-out cloth and wipe dry with a
clean cloth.
21
Cleaning and care
Re-assemble the auxiliary, normal
and fast burners as follows:
Please ensure that all locating tabs and
notches are aligned correctly to enable
correct positioning of components.
Position the burner head p to the
^
burner base q so that the ignitor r
and the ignition safety device s
extend through the respective burner
head holes.
Finally, position the burner cap n
^
over the burner head p. Ensure that
the locating tabs fit into the notches
in the burner head.
Important: Please ensure that the
components are placed in the correct
order after cleaning is complete.
1. Do not mix up the top and bottom.
2. The locating lugs must fit exactly
into the notches.
22
Cleaning and care
Re-assemble the wok-burner as
follows:
Please ensure that all locating tabs and
notches are aligned correctly to enable
correct positioning of components.
Position the burner head p to the
^
burner base q, so that the ignitor r
and the ignition safety device s fit
through the holes of the burner head.
If the burner head is correctly
positioned, it does not move about.
Position the burner ring o.
^
Position the outer burner cap n.
^
Important: Please ensure that the
components are placed in the correct
order after cleaning is complete.
1. Do not mix up the top and bottom.
2. The locating lugs must fit exactly
into the notches.
23
Problem solving guide
Repairs to the gas and electrical
components of this appliance must
only be carried out by a suitably
qualified and competent person to
ensure safety. Unauthorised repairs
could be dangerous.
However, some minor problems can be
resolved as follows:
What to do if ...
... the gas flame goes out after being
lit?
Check whether the burner cover is
correctly assembled.
... the ignitor on the burner does not
spark?
Check whether food deposits have
lodged themselves between the ignitor
and the burner cover.
Carefully remove any soiling. Do not let
the ignitor get wet.
... the burner does not ignite after
several attempts?
Check whether
– the burner is correctly assembled.
– the gas supply tap is turned on.
– the burner is dry and clean.
– the flame slits are clean and
unblocked.
–
The mains fuse has blown. If this is
the case, call a qualified electrician
or Miele. (The gas can be lit with a
match). (See "Use during a power
cut").
... the flame suddenly looks
different?
Check whether the burner is correctly
assembled.
24
Connection to the gas supply, or
conversion from use of one type of
gas to another should only be
undertaken by an approved fitter,
who is responsible for the correct
functioning of the appliance when
installed. Every appliance should
have its own isolating valve.
Check with your local gas supplier
about the type of gas and its
calorific value and compare this
information with the type of gas
quoted on the data plate.
The gas installation must be made in
such a way that the isolating valve is
visible and easily accessible.
Gas connection
Depending on country of destination
this appliance is set up for connection
to natural or liquid gas (see adhesive
label on the appliance).
Depending on country of destination
jets are supplied for conversion to a
different type of gas.
If the appropriate jets have not been
supplied with the appliance you will
need to contact your Chartered Agent
or Miele.
Conversion to another type of gas is
described in the separate Installation
Instructions supplied with this cooktop.
25
Electrical connection
All electrical work should be carried out
by a competent person, in strict
accordance with national and local
safety regulations.
For extra safety it is advisable to install
a residual current device (RCD), with a
trip current of 30 mA.
Connection for each appliance should
be made via a suitable isolator.
The data plate gives the necessary
data for connection.
Voltage: 230 - 240 V, 50 Hz
Rated load: see data plate
Plug rating: 10 A
Test marks Gas safety
Electrical safety,
C-Tick Mark.
WARNING
THIS APPLIANCE MUST BE
EARTHED
Important:
The wires in the mains lead are
coloured in accordance with the
following code:
Green/yellow = earth
Blue = neutral
Brown = live
As the colours of the wires in the mains
lead of this appliance may not
correspond with the coloured markings
identifying the terminals in your plug
proceed as follows:
The wire which is coloured green and
yellow must be connected to the
terminal in the plug which is marked
with the letter E or by the earth symbol
z or coloured green or green and
yellow.
The wire which is coloured blue must
be connected to the terminal which is
marked with the letter N or coloured
black.
The wire which is coloured brown must
be connected to the terminal which is
marked with the letter A or coloured
red.
26
After Sales Service
In the event of any faults which you cannot remedy yourself, please contact:
Miele (see back of manual for contact details).
–
When contacting Miele, please quote the model and serial number of your
appliance. These are given on the data plate.
Space in which to stick the extra data plate supplied with the appliance. Ensure
that the model number is the same as the one on the front of these instructions.
Warranty
The manufacturer's warranty for this appliance is two years.
2728293031
KM 390 / KM 391
M.-Nr. 05 827 461 / 04en - AUS
Loading...
