Miele KFN 7764 D Operating instructions

0 (0)

Operating instructions

Fridge-freezer

To avoid the risk of accidents or damage to the appliance it is essential to read these instructions before it is installed and used for the first time.

en-GB

M.-Nr. 11 746 390

Contents
Warning and Safety instructions......................................................................	5
Caring for the environment ..............................................................................	14
Installation..........................................................................................................	15
Installation site.....................................................................................................	15
Side-by-side combinations ............................................................................	15
Climate range .................................................................................................	16
Ventilation.......................................................................................................	17
Furniture door panel ............................................................................................	17
Horizontal and vertical gaps...........................................................................	17
Weight of the furniture door ...........................................................................	18
Building-in dimensions .......................................................................................	19
Installation in a tall unit/side view...................................................................	19
Connections and ventilation...........................................................................	20
Limiting the opening angle of the appliance doors .............................................	21
Electrical connection ...........................................................................................	22
Saving energy ....................................................................................................	23
Guide to the appliance......................................................................................	24
Start display ........................................................................................................	26
Using the appliance........................................................................................	26
Settings mode ...........................................................................................	27
Adjusting the interior fittings................................................................................	29
Using the door shelf fine adjustment .............................................................	29
Moving the door shelf/bottle shelf..................................................................	29
Clipping the egg trays on ...............................................................................	29
Adjusting or removing the bottle holder .........................................................	29
Moving the adjustable shelf/adjustable shelf with lighting.............................	30
Space for a baking tray ..................................................................................	30
Moving the charcoal filters .............................................................................	30
Optional accessories...........................................................................................	31
Switching on and off .........................................................................................	33
Before using for the first time ..............................................................................	33
Connecting the refrigeration appliance ..........................................................	33
Switching the refrigeration appliance on.............................................................	33
Switching off the refrigeration appliance.............................................................	34
Switching off the refrigerator section separately............................................	34
Switching off for longer periods of time .........................................................	34
The correct temperature...................................................................................	35
Temperature display ............................................................................................	36

	Contents
Setting the temperature in the refrigerator/freezer sections................................	36
Possible temperature settings ........................................................................	36
Using Super cool, Super freeze and Dynamic cooling ..................................	37
Selecting further settings .................................................................................	40
Explanation of the different settings....................................................................	40
Party mode .................................................................................................	40
Holiday mode ............................................................................................	40
Switching the lock function / on.............................................................	40
Sabbath mode ............................................................................................	41
Information on Sabbath mode ....................................................................	42
Changing the time before the door alarm is triggered ...............................	42
Miele@home ...................................................................................................	43
Changing the volume of the alarms and buzzers / ................................	45
Adjusting the display brightness ...............................................................	45
Switching off Demo mode ...........................................................................	45
Resetting the settings to their default settings .........................................	46
Information ..................................................................................................	46
Charcoal filter change indicator .................................................................	46
Cleaning mode .........................................................................................	46
Temperature and door alarm............................................................................	47
Storing food in the refrigerator section...........................................................	49
Different storage zones .......................................................................................	49
Food which is not suitable for storage in the refrigerator section .......................	50
Notes on buying food..........................................................................................	50
Storing food correctly..........................................................................................	51
Storing food in the DailyFresh drawer.............................................................	52
Freezing and storing food.................................................................................	54
Freezing fresh food..............................................................................................	54
Maximum freezing capacity ...........................................................................	54
Storing frozen food..............................................................................................	54
Home freezing .....................................................................................................	55
Storage time for frozen food................................................................................	56
Cooling drinks quickly .........................................................................................	57
Using accessories ...............................................................................................	57
Making ice cubes ...........................................................................................	57
Defrosting...........................................................................................................	58

Contents
Cleaning and care .............................................................................................	59
Cleaning agents...................................................................................................	59
Preparing the refrigeration appliance for cleaning ..............................................	60
Cleaning the inside of the appliance ...................................................................	61
Cleaning accessories by hand or in the dishwasher...........................................	61
Removing, dismantling and cleaning accessories ..............................................	62
Cleaning the door seal ........................................................................................	67
Cleaning the ventilation gaps ..............................................................................	67
After cleaning ......................................................................................................	67
Problem solving guide ......................................................................................	68
The interior lighting is not working ......................................................................	77
Noises.................................................................................................................	79
Service................................................................................................................	80
Contact in the event of a fault .............................................................................	80
EPREL database .................................................................................................	80
Warranty ..............................................................................................................	80

Warning and Safety instructions

This refrigeration appliance complies with current safety requirements. Inappropriate use can, however, lead to personal injury and material damage.

Please read the operating and installation instructions carefully before using the refrigeration appliance for the first time. They contain important information on safety, installation, use and maintenance. This is to protect yourself from injury, and from damaging your refrigeration appliance.

In accordance with standard IEC 60335-1, Miele expressly and strongly advises that you read and follow all information provided on installing the refrigeration appliance, as well as the safety notes and warnings.

Miele cannot be held liable for injury or damage caused by noncompliance with these instructions.

Keep these operating and installation instructions in a safe place and pass them on to any future owner.

Warning and Safety instructions

Correct application

This refrigeration appliance is intended for use in the home and in similar environments, for example

– in shops, offices and similar work settings

– by the guests in hotels, motels, bed & breakfasts and other typical home settings.

This refrigeration appliance is not intended for outdoor use.

This appliance is intended for domestic use only for cooling and storing food and drink as well as for storing deep frozen food, freezing fresh food and for making ice.

Any other usage is not supported by the manufacturer and could be dangerous.

This refrigeration appliance is not suitable for storing and keeping cool medicines, blood plasma, laboratory preparations or similar substances or products that are subject to the Medical Device Directive. Incorrect use of the refrigeration appliance for such purposes may cause deterioration of the items stored. The refrigeration appliance is also not suitable for use in areas where there is a risk of explosion.

Miele cannot be held liable for damage caused by improper or incorrect use or operation of the appliance.

The appliance can only be used by people with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, if they are supervised whilst using it, or have been shown how to use it in a safe way and recognise and understand the consequences of incorrect operation.

Safety with children

Children under 8 years of age must be kept away from the refrigeration appliance unless they are constantly supervised.

Children 8 years and older may only use the appliance unsupervised if they have been shown how to use it in a safe way and recognise and understand the consequences of incorrect operation.

Warning and Safety instructions

Children must not be allowed to clean or maintain the appliance unsupervised.

Please supervise children in the vicinity of the appliance and do not let them play with it.

Danger of suffocation! Whilst playing, children could become entangled in packaging (such as plastic wrapping) or pull it over their head and suffocate. Keep packaging material away from children.

Technical safety

The coolant circuit has been checked for leaks. The refrigeration appliance complies with statutory safety requirements and the appropriate EU directives.

This refrigeration appliance contains the refrigerant isobutane (R600a), a natural gas which is environmentally friendly but flammable. The refrigerant does not damage the ozone layer and does not contribute to the greenhouse effect.

The use of this refrigerant has, however, led to a slight increase in the noise level of the appliance. In addition to the noise of the compressor, you might be able to hear the refrigerant flowing around the cooling circuit. Unfortunately, this cannot be avoided, but it does not affect the performance of the refrigeration appliance.

When transporting and installing the refrigeration appliance, ensure that no parts of the cooling circuit are damaged. Splashes of refrigerant can damage the eyes.

In the event of damage:

-Avoid naked flames or anything which creates a spark.

-Disconnect the refrigeration appliance from the mains electricity supply.

Warning and Safety instructions

-Ventilate the room where the refrigeration appliance is located for several minutes.

-Contact the Miele Customer Service Department.

The more coolant there is in a refrigeration appliance, the larger the room it should be installed in. In the event of a leakage, if the appliance is in a small room, there is the danger of a combustible gas/ air mixture building up. For every 11 g of coolant at least 1 m3 of room space is required. The amount of coolant in the refrigeration appliance is stated on the data plate inside the appliance.

To avoid the risk of damage to the appliance, make sure that the connection data (fuse rating, frequency and voltage) on the data plate corresponds to the household supply.

Check that this is the case before connecting the appliance. Consult a qualified electrician if in any doubt.

The electrical safety of this appliance can only be guaranteed when correctly earthed. It is essential that this standard safety requirement is met. If in any doubt please have the electrical installation tested by a qualified electrician.

Reliable and safe operation of this appliance can only be assured if it has been connected to the mains electricity supply.

If the electrical connection cable supplied is damaged, it must only be replaced by an original spare part to prevent a hazard for the user. Miele can only guarantee the safety of the appliance when original Miele spare parts are used.

Do not connect the appliance to the mains electrical supply by a multi-socket adapter or extension lead. These are a fire hazard and do not guarantee the required safety of the appliance.

If moisture gets into electrical components or into the mains connection cable, it could cause a short circuit. Therefore, do not operate this refrigeration appliance in areas which are exposed to moisture (e.g in a garage or utility room).

Warning and Safety instructions

This appliance must not be used in a non-stationary location (e.g. on a ship).

Do not use a damaged appliance. It could be dangerous. Check the appliance for visible signs of damage.

For safety reasons, this appliance may only be used after it has been built in.

The appliance must be isolated from the electricity supply during installation, maintenance and repair work.

Unauthorised installation, maintenance and repairs can cause considerable danger for the user.

Installation, maintenance and repairs must only be carried out by a Miele authorised technician.

While the appliance is under warranty, repairs should only be undertaken by a Miele authorised service technician. Otherwise the warranty is invalidated.

Faulty components must only be replaced with genuine Miele original spare parts. Miele can only guarantee the safety standards of the appliance when Miele replacement parts are used.

This refrigeration appliance is supplied with a special lamp to cope with particular conditions (e.g. temperature, moisture, chemical resistance, abrasion resistance and vibration). This lamp must only be used for the purpose for which it is intended. The lamp is not suitable for room lighting. Replacement lamps may only be fitted by a Miele authorised technician or by the Miele Customer Service Department. This refrigeration appliance contains several light sources with at least energy efficiency class F.

Proper installation

When installing the refrigeration appliance, it is a mandatory requirement to follow the installation instructions supplied with it.

Two people are required to install the refrigeration appliance.

Warning and Safety instructions

Change the door hinging (if necessary) as described in the installation instructions supplied with the appliance.

Only install the refrigeration appliance in a solid, rectangular and level housing unit, positioned on an even and level floor.

Correct use

This refrigeration appliance is designed for use within specific ambient temperatures (climate range). Do not use in ambient temperatures for which it is not designed. The climate range is stated on the data plate in the interior cabinet of the refrigeration appliance. A lower ambient temperature will cause the compressor to switch off for longer periods, meaning that the refrigeration appliance is unable to maintain the required temperature.

Do not cover or block the air vents as this could impair the efficiency of the appliance, increase the electricity consumption and could cause damage to the components.

If storing food which contains a lot of fat or oil in the appliance or the door, make sure that it does not come into contact with plastic components as this could cause stress cracks or break the plastic.

Risk of fire and explosion. Do not store explosive materials in the refrigeration appliance or any products containing propellants (e.g. spray cans). Electrical components can cause flammable mixes of gases to ignite.

Danger of explosion. Do not operate any electrical equipment (e.g. an electric ice-cream maker) inside the refrigeration appliance. Danger of sparking and explosion.

Danger of injury and damage to the appliance. Do not store cans or bottles containing carbonated drinks or liquids which could freeze in the freezer zone. Otherwise they could burst.

Danger of injury and damage to the appliance. When cooling drinks quickly in the freezer zone, make sure bottles are not left in for more than one hour. Otherwise they could burst.

Warning and Safety instructions

Danger of injury. Never handle frozen food or the metal parts of the appliance with wet hands. Your hands may freeze to the frozen food or to the metal.

Danger of injury. Do not take ice cubes out with your bare hands and never place ice cubes or ice lollies in your mouth straight from the freezer zone. The very low temperature of the frozen food can cause frost burn to the lips and tongue.

Do not refreeze partially or fully defrosted food. Consume defrosted food as soon as possible, as it will lose its nutritional value and spoil if left for too long. Defrosted food may only be re-frozen after it has been cooked.

Observe the manufacturer's “use-by” dates and storage instructions given on food to avoid the risk of food poisoning. Storage times will depend on several factors, including the freshness and quality of the food, as well as the temperature at which it is stored.

Accessories and spare parts

Only use genuine original Miele accessories and spare parts with this appliance. Using accessories or spare parts from other manufacturers will invalidate the warranty, and Miele cannot accept liability.

Miele will guarantee to supply functional spare parts for a minimum of 10 years and up to 15 years following the discontinuation of your refrigeration appliance.

Warning and Safety instructions

Cleaning and care

Do not use any oils or grease on the door seals, as these will cause the seals to deteriorate and become porous with time.

Do not use a steam cleaning appliance to clean or defrost this appliance.

Steam could reach electrical components and cause a short circuit.

Sharp edged or pointed objects will damage the evaporator, causing irreversible damage to the appliance. Do not use sharp edged or pointed objects to

-remove frost and ice,

-separate frozen food or remove ice trays.

Do not place electric heaters or candles in the appliance to defrost it. These can damage the plastic parts.

Do not use defrosting sprays or de-icers, as they could contain substances which could damage the plastic parts or which might cause the build-up of gases and pose a danger to health.

Warning and Safety instructions

Transport

Always transport the appliance in an upright position and in its original transport packaging to avoid damage in transit.

Danger of injury and damage to the appliance. The refrigeration appliance is very heavy and must be transported by two people.

Disposal of your old appliance

If your old refrigeration appliance has a door lock, destroy it. This will prevent the risk of children playing accidentally locking themselves in and endangering their lives.

Splashes of coolant can damage the eyes. Be careful not to damage any part of the pipework whilst awaiting disposal, e.g. by

-puncturing the coolant channels in the condenser,

-bending any pipework, or

-scratching the surface coating.

Symbol on the compressor (depending on model)

This information is only relevant for recycling. There is no risk during normal operation.

The oil in the compressor can be fatal if swallowed or if it penet-

rates the airways.

Caring for the environment

Disposal of the packing mater-

ial

The packaging is designed to protect the appliance from damage during transportation. The packaging materials used are selected from materials which are environmentally friendly for disposal and should be recycled.

Recycling the packaging reduces the use of raw materials in the manufacturing process and also reduces the amount of waste in landfill sites.

Disposing of your old appli-

ance

Electrical and electronic appliances contain many valuable materials. They also contain certain materials, compounds and components which were essential for their correct functioning and safety. These could be hazardous to human health and to the environment if disposed of with household waste or if handled incorrectly. Please do not, therefore, dispose of your old appliance with household waste.

Instead, please make use of officially designated collection and disposal points to dispose of and recycle electrical and electronic appliances in your local community, with your dealer or with Miele. By law, you are solely responsible for deleting any personal data from the old appliance prior to disposal.

Take care not to damage your refrigeration appliance’s pipework before or during transportation to an authorised collection depot.

This is to ensure that refrigerant in the cooling circuit and oil in the compressor is contained, and will not leak into the environment.

Ensure that your old appliance presents no danger to children while being stored for disposal. For further information, see “Warning and safety instructions” in these operating instructions.

Installation

Installation site

Risk of damage and danger of injury due to the refrigeration appliance tipping over.

This refrigeration appliance is very heavy and can tip forwards when the appliance door is open.

Keep the appliance door(s) closed until the refrigeration appliance has been built in. The refrigeration appliance must be secured in its buildingin niche in accordance with the operating and installation instructions.

Fire risk and risk of damage from appliances which give off heat. Appliances which give off heat can catch fire and set fire to the refrigeration appliance.

This refrigeration appliance must not be installed underneath a hob.

Fire risk and danger of damage from open flames.

Open flames can set fire to the refrigeration appliance.

Keep open flames (e.g. a candle) away from the refrigeration appliance.

This appliance should be installed in a dry, well-ventilated room.

When deciding on the installation site, please bear in mind that your refrigeration appliance will use more energy if installed near to a heater, a cooker or other appliance that gives off heat. Avoid direct sunlight.

The higher the ambient temperature, the longer the compressor runs and the higher the energy consumption is.

Risk of damage due to high humidity.

In environments with high humidity, condensation can build up on external refrigeration appliance panels. This condensate can cause corrosion on external appliance panels.

Install the refrigeration appliance in a dry and/or air-conditioned room with sufficient ventilation.

After installation please make sure that the appliance door(s) closes (close) properly and the refrigeration appliance is installed in accordance with these installation instructions. It is essential to comply with the specified ventilation cutout requirements.

Side-by-side combinations

Risk of damage due to condensation on external appliance panels. In environments with high humidity, condensation can build up on external appliance panels, which can cause corrosion.

Do not place different refrigeration appliance models directly next to or on top of one other.

Installation

Exception: your refrigeration appliance can be installed next to another refrigeration appliance with an integrated heating unit if each appliance is built into a separate niche. Please contact your dealer for specific information about which combinations will work with your refrigeration appliance.

Climate range

Climate range	Ambient temper-
	ature

SN	+10 to +32 °C

N	+16 to +32 °C

ST	+16 to +38 °C

T	+16 to +43 °C

A lower ambient temperature leads to the compressor switching off for longer periods. This can cause the internal temperature in the refrigeration appliance to rise with the risk of food deteriorating and going off.

Installation

Ventilation

Risk of fire and damage due to insufficient ventilation.

If the refrigeration appliance is not ventilated sufficiently, the compressor will run more frequently and for longer periods. This will result in increased energy consumption and a higher operating temperature for the compressor. This may, in turn, cause damage to the compressor.

Please ensure that there is adequate ventilation around the refrigeration appliance.

It is essential to observe the required ventilation gaps.

The ventilation gaps must not be covered or blocked in any way. They must also be regularly dusted.

Air at the back of the refrigeration appliance gets warm. The appliance housing unit must therefore be constructed to allow sufficient space for ventilation (see “Installation dimensions” and the installation instructions provided).

Furniture door panel

Horizontal and vertical gaps

Depending on the style of kitchen furniture, the thickness and edge radius of the furniture door panel and the gap that runs around the door, vertically and horizontally, are specified.

It is essential to pay attention to the following:

- Horizontal gap

The gap between the furniture door panel and the housing unit door above or below it must be at least 3 mm.

- Vertical gap

If the gap between the refrigeration appliance furniture door panel and the adjoining housing unit door or wall on the hinged side is too small, the appliance door could collide with the adjoining housing unit door or wall when opened.

It may be necessary to adjust the size of this gap to suit the thickness and edge radius of the appliance furniture door.

This must be taken into consideration when planning your kitchen and when replacing an old refrigeration appliance with a new one to ensure the installation conditions required are met.

Installation

Appliance		Gap X [mm]
furniture			for different
door			edge radiiB
thickness
A [mm]
	R0		R1.2			R2	R3
≥16–19				min. 3
20	5	4			4		3.5
21	5.5	5			4.5		4
22	6.5	6			5.5		5

Weight of the furniture door

If the furniture door panel is too heavy, this can cause damage. Fitting a furniture door panel which is heavier than the maximum permitted weight could damage the hinges. This can cause subsequent functional problems.

The maximum permissible weights of the furniture doors in kg are:

Refrigeration	Upper	Lower
appliance	furniture	furniture
	door	door
	panel	panel

KFN 7764 D	18	12

Adjoining kitchen furniture front

A = Furniture front thickness

B = Edge radius

X = Gap

Adjoining side wall

A = Furniture front thickness

B = Edge radius

X = Gap

Tip: Fit a spacer between the housing unit carcase and the side wall. This way you will get a sufficiently wide gap.

Installation

Building-in dimensions

Installation in a tall unit/side view

All dimensions are given in mm.

* The declared energy consumption was calculated in a 560 mm deep niche. The refrigeration appliance is fully functional in a 550 mm niche but the energy consumption will be slightly higher.

Before installation, ensure the housing unit dimensions are the correct size.

Installation

Connections and ventilation

All dimensions are given in mm.

The specified ventilation cross-sections must be adhered to in order to ensure the correct functioning of the refrigeration appliance.

a View from the front

b Mains connection cable, length 2200 mm

cVentilation cross-section min. 200 cm2

dVentilation

eNo connection sockets in this area

Installation

Limiting the opening angle of

the appliance doors

The door hinges are set to enable the appliance doors to be opened wide.

If the opening angle of the doors needs to be limited to approx. 90°, the hinge can be adjusted to accommodate this.

The locking pins for limiting the door opening must be fitted before the refrigeration appliance is installed.

The refrigerator section door must be taken off in order to insert the pins into the upper hinge of the freezer section door (see the installation instructions provided).

Insert the locking pins supplied for limiting the door opening into the hinges from above.

This will limit the opening angles of the appliance doors to approx. 90°.

Installation

Electrical connection

The refrigeration appliance must only be connected to an earthed socket using the connection cable supplied. A longer connection cable is available to order from the Miele Customer Service Department.

The socket must be easily accessible after the refrigeration appliance has been installed. If the socket is not easily accessible, ensure that a suitable means of disconnection is provided on the installation side for each pole.

Risk of fire from overheating. Connecting the refrigeration appliance to a multi-socket plug adapter or to an extension lead can overload the cable.

For safety reasons, do not use an extension lead or multi-socket adapter.

The electrical system must comply with local and national safety regulations (BS 7671 in the UK).

For safety reasons, we recommend using a type residual current device (RCD) in the assigned electrical installation for connecting the refrigeration appliance.

If the mains connection cable is damaged, it must only be replaced with a specific mains connection cable of the same type (available from the Miele Customer Service Department). For safety reasons, such replacement may only be carried out by a qualified specialist or the Miele Customer Service Department.

These operating instructions and the data plate indicate the nominal power consumption and the appropriate fuse rating. Compare this information with the data of the on-site electrical connection.

If in any doubt, consult a qualified electrician.

Do not connect the refrigeration appliance to a stand-alone inverter such as those used with an autonomous energy source, e.g. solar power. When the refrigeration appliance is switched on, power surges could result in an auto switch-off. This could damage the electronic module.

Connecting the refrigeration appliance

Insert the plug connector into the socket at the back of the refrigeration appliance.

Make sure that the plug connector has clicked into position correctly.

Insert the plug of the refrigeration appliance into the socket.

The refrigeration appliance is now connected to the electricity supply.

Saving energy

How to save energy:

Installation The refrigeration appliance has to cool more often at higher amsite bient temperatures and consumes more energy in the process.

Therefore, you should:

-Install the refrigeration appliance in a well-ventilated room.

-Do not install the refrigeration appliance near to a heat source (heater element, cooker).

-Protect the refrigeration appliance from direct sunlight.

-Ensure an ideal ambient temperature of 20 °C.

-Clean the ventilation gaps on a regular basis to remove any dust.

Temperature	The colder the temperature, the higher the energy consumption.
setting	The following settings are recommended:
	-	4 to 5 °C in the refrigerator section.
	-	-18 °C in the freezer section.
Use	Energy consumption is increased by heat input and impeded air
	circulation. Therefore, you should:
	-	Only open the appliance door(s) when necessary and for as
		short a time as possible. Arrange the food in such a way that
		makes it easy to find in the appliance.
	-	Always close the appliance door(s) properly after opening
		them.
	-	Allow hot food and drinks to cool down before placing them in
		the refrigeration appliance.
	-	Store food well packaged or covered.
	-	Do not overfill the compartments to allow air to circulate.
	-	Place frozen food in the fridge zone to defrost.
	-	Keep drawers and shelves arranged as they were when the
		appliance was delivered.

Guide to the appliance

aDisplay

bFan with lighting

cAdjustable shelf with lighting (FlexiLight 2.0)

dEgg tray

eDoor shelf with fine adjustment

fDry back wall

gBottle shelf with bottle holder

hSpace for a baking tray (ComfortSize)

iCompartment lid for setting the humidity level in the DailyFresh drawer

jDailyFresh drawer for fruit and vegetables (humidity-controlled)

kCondensate channel and drain hole

lFreezer section interior lighting

mFreezer drawers

Guide to the appliance

Start display

The touch display can be scratched by pointed or sharp objects, e.g. pens. Only touch the display with your fingers.

If your fingers are cold, the touch display may not react.

1	5°C

2 -18°C

a Temperature display for fridge zone

b Temperature display for freezer section

c Settings mode

sensor control for adjusting various settings in Settings mode

d Display for Miele@home connection status

(only visible when the Miele@home function has been set up)

e Demo mode display

(only visible when the Demo mode function has been switched on)

Using the appliance

Touch the area/symbol you want on the start display.

Swipe left or right across the display until the value/symbol you want is shown in the middle.

Tap on the option you want on the display to confirm.

The selected value/symbol will light up orange (except for a few exceptions).

To leave the Settings level, tap on or OK.

+ 58 hidden pages
