Built-In
30” Refrigerator
K 1813 SF / K 1803 SF
Specification Sheets TRS 09082015
8mieleusa.com
Built-In 30” Refrigerator
K 1813 SF / K 1803 SF
SPECIFICATIONS
K 1803 SF — Item 36180311USA - Right Hinged
K 1813 SF — Item 36181311USA - Left Hinged
Overall Unit Width - Excluding Fascia Dimension 29
Overall Unit Height - Excluding Fascia Dimension 83
Overall Unit Depth - Excluding Fascia Dimension 24” (610 mm)
Overall Fascia Dimensions
Niche
Minimum Cabinet Opening Width
Minimum Cabinet Opening Height 83
Minimum Cabinet Opening Depth 24” (610 mm)
Electrical
Electrical Requirements - Volts/Amps
Power Cord - Plug and length Yes - NEMA 5-15 plug, 5 ft (1.52 m)
Shipping
Shipping Weight 467 lbs (212 kg)
Shipping Dimensions 33
Support
Call Miele 800.843.7231
Miele Website
20/20 Link
3
/4” (756 mm)
1
/2” - 853/16” (2121 mm - 2165 mm)
301/2” (775 mm) W x 84” - 8511/16”
(2134 mm - 2176.5 mm) H x
30” (762 mm)
5
/8” (2124 mm)
110V / 120V, 60Hz, 15 Amps
In the case of side-by-side installations,
a separate outlet must be used for each
appliance.
5
/8” W x 893/4” H x 291/4” D
8www.mieleusa.com
82020technologies.com
3
/4” (19 mm) D
Features:
• MasterCool controls
• ClearView lighting system
• Drop and Lock Shelves
• SmartFresh storage drawers
• FullView storage drawers
• RemoteVision capable
• Acoustic door and temperature
alarm
• Optical door and temperature
alarm
• Energy Star
K 1813 SF / K 1803 SF
Specification Sheets TRS 09082015
Page 2 of 5
Built-In 30” Refrigerator
K 1813 SF / K 1803 SF
FOR PROUD INSTALLATION
Outer Trim Details*
* Outer Trim runs completely across the top and down
the sides of the unit. The Side Trim stops at the bottom
edge of the door panel.
Fascia dimensions
K 1813 SF / K 1803 SF
Page 3 of 5
Specification Sheets TRS 09082015
Built-In 30” Refrigerator
K 1813 SF / K 1803 SF
POWER SUPPLY CONNECTION
BACK VIEW
Electrical - 5 foot (1.52 m) - 120 Volt - 15 Amp - NEMA 5-15 molded plug
DOOR PANEL DIMENSIONS
WITHOUT OUTER TRIM
/8” (2029 mm)
7
79
353/4” (908 mm)
293/4” (756 mm)
/16”
3
4” - 5
(102 - 132 mm)
K 1813 SF / K 1803 SF
Page 4 of 5
Specification Sheets TRS 09082015
Built-In 30” Refrigerator
rooD °511rooD °09
K 1813 SF / K 1803 SF
HINGING DETAILS
Door Swing
3 9/16”
3 9/16"
(90 mm)
33 3/16”
(843 mm)
33 3/16"
Door Swing
15 1/2”
(394 mm)
15 1/2"
MAX
K 1813 SF / K 1803 SF
Specification Sheets TRS 09082015
Page 5 of 5
