Miele HR1124GRLP Installation
Installation Instructions
30" Electric, 30" Induction Range
30", 36" All Gas Range
30", 36"
, 48" Dual Fuel Range
To prevent accidents and damage to the range, you must r
instructions supplied before installing or using the appliance.
en–US, CA M.-Nr. 09 898 160
ead all
IMPORTANT SAFETY INSTRUCTIONS
WARNING
Children and adults can tip over the range if has not been
sec
ured. This may lead to fatal injuries.
This r
device according to the installation instructions.
If
tip device until you feel it lock into place.
Do not use the r
installed and engaged.
F
instructions can lead to serious or fatal injuries for children and
adults.
ange must be secured and connected using the anti-tip
you have moved the range, slide the locking latch onto the anti-
ange if the anti-tip device has not been properly
ailure to observe the information contained in the installation
2
IMPORTANT SAFETY INSTRUCTIONS
®
®
W
ARNING: If the information in this manual is not followed exactly, a fire or
explosion may result causing property damage, personal injury, or death.
– Do not use or store gasoline or other flammable liquids or vapors in the vicinity
of this or any other appliance.
– WHAT TO DO IF YOU SMELL GAS
– Do not try to light any appliance.
– Do not touch any electric switches.
– Do not use any phones inside your building.
– Immediately call your gas supplier from a neighbor's phone. Follow the gas
supplier's instructions.
– If you are unable to reach your gas provider, call the fire department.
– Installation and service must be performed by a qualified installer, qualified
ser
vice agency or your gas provider.
(In Massachusetts, installation must be performed by a licensed installer / gas
fitter.)
– Note to the installer:
se give these installation instructions to the consumer for the local
Plea
electrical/gas inspector.
3
Contents
IMPORTANT SAFETY INSTRUCTIONS................................................................. 2
IMPORTANT SAFETY INSTRUCTIONS.................................................................
Notes on installation............................................................................................
6
13
Model numbers ..................................................................................................... 13
Data plate .............................................................................................................. 13
Distance to the range hood.................................................................................... 13
Items included with this range............................................................................... 13
Toe-kick and drop guard................................................................................... 14
Installation of the toe-kick................................................................................. 14
Installation of the drop guard............................................................................ 14
Optional accessories ............................................................................................. 15
RBGAG All Gas Backguard/RBGDF Dual Fuel Backguard............................... 15
RBS Backsplash ............................................................................................... 17
XKM 3000 W Remote Vision............................................................................. 17
Required connections............................................................................................ 19
Electric Range dimensions .................................................................................
20
HR 1421; HR 1622................................................................................................. 20
Detailed views of HR 1421..................................................................................... 22
Detailed views of HR 1622..................................................................................... 25
All Gas Range dimensions ..................................................................................
28
HR 1124, HR 1134, HR 1135, HR 1136................................................................. 28
Detailed views of HR 1124..................................................................................... 30
Detailed views of HR 1134..................................................................................... 33
Detailed views of HR 1135..................................................................................... 36
Detailed views of HR 1136..................................................................................... 39
Dual Fuel Range dimensions ..............................................................................
42
HR 1924, HR 1934, HR 1935, HR 1936, HR 1954, HR 1955, HR 1956................. 42
Detailed views of HR 1924..................................................................................... 45
Detailed views of HR 1934..................................................................................... 48
Detailed views of HR 1935..................................................................................... 51
Detailed views of HR 1936..................................................................................... 54
Detailed views of HR 1954..................................................................................... 57
Detailed views of HR 1955..................................................................................... 60
Detailed views of HR 1956..................................................................................... 63
Anti-tip device ......................................................................................................
66
Before installation .................................................................................................. 66
Checking the installation space............................................................................. 67
Included accessories ............................................................................................. 67
4
Contents
Installation dimensions of locking bolt................................................................... 68
Installing the range with the anti-tip device ........................................................... 68
Disconnecting the range from the anti-tip device.................................................. 71
Electrical connection...........................................................................................
Data plate.......................................................................................................... 73
Plumbing...............................................................................................................
Notes on connecting to the water supply.............................................................. 75
Attach the stainless steel hose to the range.......................................................... 76
Connecting to the water supply............................................................................. 76
Gas connection ....................................................................................................
Converting to another gas type..........................................................................
Burner ratings.......................................................................................................
Burner rating gas cooktops ................................................................................... 80
Burner rating gas ovens......................................................................................... 86
Caring for the environment.................................................................................
72
75
77
79
80
87
5
IMPORTANT SAFETY INSTRUCTIONS
When using the appliance, follow basic safety precautions, including the
following:
Read all instructions before installation and use of the range to prevent
accidents and machine damage.
This range complies with current safety requirements. However,
impr
oper use of the appliance can result in personal injury or
damage to property.
Please read the installation instructions carefully before installing
and connecting the appliance.
Read the operating instructions before using the range for the first
time. To prevent accidents and damage to the appliance, always
observe both the installation instructions and operating
instructions. Both documents contain important information about
installation, safety, use and maintenance.
Miele cannot be held liable for damage occurring as a result of
non-compliance with the instructions.
Keep these installation instructions and operating instructions in a
safe place and pass them on to any future owner.
6
Use
IMPORTANT SAFETY INSTRUCTIONS
This r
environments.
This applianc
ange is intended for domestic use and use in other similar
e is not intended for outdoor use.
Use the range exclusively under normal domestic conditions:
– Use the oven for baking, roasting, broiling, defrosting, canning
and dr
– Use the stovetop to prepare food and keep it warm.
Any other use is not permitted.
ying food.
Risk of Fire! Do not use this oven to store or dry flammable
materials.
P
ersons who lack physical, sensory or mental abilities, or
experience with the appliance should not use it without supervision
or instruction by a responsible person.
Children
As w
by children.
ith any appliance, close supervision is necessary when used
Chil
unless constantly supervised.
Chil
without supervision.
Please super
not let them play with the appliance.
Burn hazar
the oven.
Dange
etc. are disposed of safely and kept out of the reach of children.
dren under the age of eight must be kept away from the range
dren must not be allowed to clean or maintain the range
vise any children in the vicinity of the range and do
d from improper use! Do not allow children to operate
r of suffocation! Ensure that any plastic wrappings, bags,
7
IMPORTANT SAFETY INSTRUCTIONS
Burn hazar
Keep the spaces above and behind the range clear of any items that
could draw the attention of children. Otherwise, they can be tempted
into climbing onto the appliance.
Dange
of the appliance.
d!
r of injury. Never allow children to hang or lean on any part
Technical safety
Installatio
a Miele authorized service technician in accordance with national
and local safety regulations and the provided installation
instructions. Contact Miele’s Technical Service Department for
examination, repair or adjustment. Repairs and other work by
unauthorized persons could be dangerous and may void the
warranty.
Do not carr
control panel!
Check whethe
into place (see "Anti-tip device"):
n, repair and maintenance work should be performed by
y or lift the range by the oven door handle or the
r the anti-tip device is properly installed and locked
– The anti-tip device must be fastened to the floor or wall with
sui
table screws.
– You must be able to feel that the locking latch is engaged in the
bolt of the anti-tip device.
Slide the r
The locking latch must be noticeably engaged with the bolt of the
anti-tip bracket.
W
moved more easily.
Do not move the range if it is still hot. To avoid injuries from
tipping
tip device after moving, and be sure to lock the wheels.
8
ange's locking latch into place on the anti-tip device.
ARNING! This range sits on wheels, which allow it to be
, make sure that the range is locked into place on the anti-
IMPORTANT SAFETY INSTRUCTIONS
A d
signs of damage. Never use a damaged appliance.
Reliable
it is connected to the public power supply.
amaged range can be dangerous. Always check for visible
and safe operation of the range can only be guaranteed if
The electrical safety of the range can only be guaranteed when it
is properly grounded. Compliance with this essential safety
requirement is absolutely mandatory. If in any doubt, please have
the building's wiring system inspected by a qualified electrician.
T
o avoid damaging the range, make sure that the connection data
(voltage and frequency) on the data plate correspond to the
building's power supply before connecting the appliance.
When in doubt, consult a qualified electrician.
During
lighting is broken (see "Frequently asked questions"), the range must
be completely disconnected from the household electricity supply.
The gas supply must be shut off. Ensure that this is the case by:
– removing the fuse,
– "tripping" the circuit breaker, or
installation, maintenance and repair work, e.g. if the oven
– unplugging the unit. Pull the plug not the cord.
– Shut off the gas supply and, if necessary, disconnect the range
om the gas line. Installation and maintenance of the gas
fr
connection must be performed by qualified installers, service
agencies or gas providers.
Do not use a power strip or e
to electricity. These are a fire hazard and do not guarantee the
required level of appliance safety.
xtension cord to connect the range
Any contact with live connections or tampering with the electrical
or mecha
and may lead to appliance malfunctions.
Do not open the appliance housing under any circumstances.
nical components of the range will endanger your safety
9
IMPORTANT SAFETY INSTRUCTIONS
This applianc
installations (e.g. on a ship).
Any r
technician will void the warranty.
epairs not performed by a Miele authorized service
e must not be installed and operated in mobile
Defective components should be replaced by Miele original parts
only. Only with these parts can the manufacturer guarantee the
safety of the appliance.
Risk of electri
defective or chipped, cracked or broken in any way, immediately
switch the stovetop off and do not continue to use it. Disconnect the
range from the power supply and contact Miele Technical Service.
In or
supply of cool air. Ensure that the air flow is not impaired. Also be
sure that the cool air supply is not excessively heated by other heat
sources (e.g. solid fuel stoves).
If
door while the appliance is in operation. Heat and moisture can build
up behind the closed door and cause damage to the range and to
the surrounding cabinets and flooring. Do not close the door until
the appliance has completely cooled down.
der for the range to function properly, it requires an adequate
the range is installed behind a cabinet door, do not close the
c shock! If the ceramic surface of the stovetop is
Do not insta
over a hot stovetop to access the cabinets can result in burns. If it is
necessary to install cabinets, you can reduce the risk of burns by
installing a range hood that extends at least 4 3/4" (12 cm) past the
bottom of the cabinets.
The wat
been installed.
The int
damage if the following conditions are met:
– The range is properly installed (connected to electric and water
supply).
10
ll kitchen cabinets above the range, since reaching
er shutoff valve must be accessible after the range has
egrated Waterproof System offers protection against water
IMPORTANT SAFETY INSTRUCTIONS
– The range is repaired immediately whenever damage is detected.
– The water supply is shut off during extended periods of non-use
(e.g. vacation).
Har
osmosis filtering systems can damage the range. Only use filtered,
softened and demineralized water from the building's plumbing to
supply the range.
Preparing your appliance for an extended vacation
If
period of time, please note that this may not be enough to reduce
the risk of a leak. To be completely safe, you must turn off the water
supply to each individual appliance.
d water, water containing minerals and water from reverse
you elect to turn off the water to your home for an extended
Cleaning and care
Do not use a st
The steam may reach electrical components and cause a short
circuit.
Only clean par
Instructions.
Scr
Do not use abrasive cleaners, hard sponges, brushes or sharp metal
tools to clean the door glass.
atches on the door glass can cause the glass to break.
eam cleaner to clean the range.
ts listed in these Operating and Installation
The shel
"Cleaning and care"). Ensure they are correctly fitted after cleaning
and never operate the oven without the shelf runners inserted.
Ther
the door. Take care not to rub, damage or move the gasket.
Do not use ove
liners of any kind should not be used in or around any part of the
oven.
f runners can be removed for cleaning purposes (see
e is a seal around the oven interior which seals the inside of
n cleaners. Commercial oven cleaners or oven
11
IMPORTANT SAFETY INSTRUCTIONS
Debris shoul
d be removed before running the Self Clean program.
If not removed this debris can smoke causing the self-cleaning
program to turn itself off.
SAVE THESE INSTRUCTIONS AND REVIEW THEM PERIODICALLY
12
Notes on installation
Model numbers
A list of the ovens described in these
ating instructions can be found on
oper
the back page.
Data plate
The data plate is behind the toe-kick.
oe-kick cover is attached to the
The t
base of the range by magnets so it can
be removed and put back again easily.
There you can find the model number,
the serial number and the connection
data (voltage/fr
load) for your range.
Have this information available when
cting Miele Technical Service.
conta
equency/maximum rated
Distance to the range hood
The minimum clearance between the
appliance an
be listed by the hood manufacturer.
If the hood manufacturer's instructions
ar
e not available or if flammable objects
are installed over the appliance (e.g.,
cabinets, utensil rail, etc.), a minimum
safety distance of 30" (760 mm) must
be maintained.
d a range hood above will
Items included with this range
The range is supplied with:
– Installation Instructions,
– Multiple operating instructions
(depending on model) for:
– Electric Range
– Induction Range
– Convection Oven
– Gas Cooktop
– Gas Convection Oven
– Speed Oven
– Warming Drawer
– an anti-tip device including screws
for fast
– various accessories.
ening the range,
If there is more than one appliance
led below the range hood, each
instal
with a different safety clearance, the
largest clearance must be used.
13
Notes on installation
Toe-kick and drop guard
30" and 36" range
The co
packaging of the range.
48" range
The co
mounted.
Installation of the toe-kick
The toe-kick has sheet metal lugs and
magnets by means of which it can be
position
of the range.
Position the toe-kick in such a way
P
mponents are located in the
mponents are already
ed and attached to the base
that the sheet metal lugs are facing
the provided holes in the base.
ush the toe-kick onto the base of
the range until it audibly locks into
place.
Installation of the drop guard
The drop guard covers the gap
between the oven cavi
Open the oven door
Lay the dr
between the oven cavity and the
door.
Clo
op guard over the gap
se the oven door.
ty and the door.
.
14
Notes on installation
1
22
Optional accessories
All accessories and cleaning products
isted in these instructions are designed
l
to be used with the Miele range.
These can be ordered from the Miele
e (see end of this booklet for
websit
contact details).
When ordering, please have your model
number available.
RBGAG All Gas Backguard/RBGDF
Dual F
Depending on the model, you can
e
your appliance for a larger range
backguard. The backguard is available
in the following heights: 12" (305 mm)
and 20" (508 mm).
Mounting the RBGDF Dual Fuel
Bac
uel Backguard
xchange the existing island trim of
kguard
The rear of the range must be
accessible.
Mounting the RBGAG All Gas
kguard
Bac
The rear of the range must be
accessible.
Mount the backguard before installing
the anti-tip device and connecting of
the r
ange.
oosen the screws of the island trim.
L
P
ull back the island trim slightly until
it can be removed.
Mount the backguard before installing
the anti-tip device and connecting of
the r
ange.
L
oosen the screws of the island trim.
ull back the island trim slightly until
P
it can be removed.
The backguard can be installed in
r
everse order.
a
Extender
b
Air ducts
Inser
Scr
The backguard can be installed in
r
t one extender onto each of the
left and right air ducts.
ew the extenders into place with 2
screws each.
everse order.
15
Notes on installation
1
2
a
Backguard
b
Range
Slide the Backg
extenders.
uard over the air duct
12" Backguard
Once the backgu
Range push the Backguard
backwards.
Secur
16
e the Backguard using the
existing screws.
ard is placed on the
20" Backguard
RBS Backsplash
The backsplash is intended for
mounting t
o a Miele range hood.
Observe the installation instructions of
the Miele range hood.
XKM 3000 W Remote Vision
Depending on the model, the range
maybe compatible with
R
emoteVisionTM.
In order to use the RemoteVision
TM
monitoring service, you will require a
XKM 3000 W Communication Module.
Refer to the Operating and Installation
Instructions of the Miele XKM 3000 W
Communication Module.
Notes on installation
17
Notes on installation
Do not carry or lift the range by the oven door handle or the control panel!
The range is heavy.
Due to the size and weight of the appliance, installation should be performed
by two people.
The net weight of the range with accessories is as follows:
Model Width Net weight incl.
accessories:
HR 1421
HR 1622
HR 112x
HR 192x
HR 113x
HR 193x
HR 195x 48" (1219 mm) approx. 573 lbs (260 kg)
30" (762 mm) approx. 307 lbs (140 kg)
36" (914 mm) approx. 405 lbs (180 kg)
18
Notes on installation
Installation location
This appliance is not intended for outdoor use.
Ranges with a connection to the water supply should not be installed in rooms
wher
e there is a risk of freezing temperatures.
The floor of the space where the appliance is to be installed must be flat, level and
made of a str
Because the range is heavy and requires attachment of the anti-tip device
suppli
ed, the surface must be able to fully bear the load of the appliance. If
necessary, seek the advice of an architect or construction expert.
Ventilation
The air intake and outlet openings must not be covered or blocked in any way.
They sh
Required connections
ong, rigid material.
ould be dusted on a regular basis.
Model Electrical
connection
HR 1421 X – –
HR 1622 X – X
HR 112x
HR 113x
HR 192x
HR 193x
HR 195x
X Connection required
– Connection not provided
X X –
X X X
Gas connection Plumbing
19
Electric Range dimensions
1
HR 1421; HR 1622
20
HR 1421; HR 1622
Position Dimension Description
Electric Range dimensions
13" (330 mm) Maximum depth of top cabinet
6" (152 mm) Minimum distance (left and right) to flammable
sur
faces
18" (547 mm) Minimum distance to bottom edge of top cabinet
30" (762 mm) Minimum distance between the top of the cooking
ea and the bottom of an unprotected wooden or
ar
metal cabinet
or 24" (609 mm) Minimum distance if the bottom of the wooden or
35 1/2"–37"
(901 - 940 mm)
30 1/16“ + 1/16"
(763.6 mm +
1.58 mm)
approx.
10 13/16"
(274 mm)
metal cabinet is not pr
inch-thick, flame-retardant cardboard, which is
covered and protected by no less than No. 28
MSG sheet steel, 0.015-inch-thick stainless sheet
steel, or covered with 0.024-inch-thick aluminum
or 0.020-inch-thick sheet copper.
Distance from floor to cooktop surface
Width of cabinet opening
Maximum connection width right and left
otected by less than 1/4-
The gray areas represent the minimum distance from flammable surfaces.
The hatched areas represent the installation areas for the connections.
For island installations, 12" (305 mm) minimum distance from back of range to flammable
ear wall above countertop.
r
approx. 4 1/2"
(115 mm)
approx. 2 13/16"
(72 mm)
Maximum connection height
Maximum connection depth
21
Electric Range dimensions
47 5/8" (1210mm)
5 9/16" (141mm)
(x)
22 1/16" (561mm)
8 1/8" (207mm)
35 1/2 - 37" (901.7 - 939.8mm)
27 1/4" (692mm)
28 15/16" (734.4mm)
1
24 15/16" (633mm)
1 9/16" (40mm)
Detailed views of HR 1421
Side view of HR 1421
(x) = Depending on the appliance height adjustment: 4" - 5 1/2 " (101.6 mm -
139.7 mm)
22
Detailed front side view of HR 1421
1 9/16" (40mm)
2 3/8" (60mm)
1 1/4" (32mm)
8 1/8" (207mm)
9 1/4" (235mm)
10 15/16" (278mm)
1 3/4" (45mm)
2 9/16" (65.2mm)
1 9/16" (40mm)
1/8" (3mm)
Electric Range dimensions
23
Electric Range dimensions
30 5/8"
(778.5mm)
24 3/8"
(619.9mm)
E
Rear view of HR 1421
E = Electrical connection
24
Detailed views of HR 1622
47 5/8" (1210mm)
5 9/16" (141mm)
(x)
22 1/16" (561mm)
8 1/8" (207mm)
35 1/2 - 37" (901.7 - 939.8mm)
27 1/4" (692mm)
28 15/16" (734.4mm)
1
24 15/16" (633mm)
1 9/16" (40mm)
Side view of HR 1622
Electric Range dimensions
(x) = Depending on the appliance height adjustment: 4" - 5 1/2 " (101.6 mm -
139.7 mm)
25
Electric Range dimensions
1 9/16" (40mm)
2 3/8" (60mm)
1 1/4" (32mm)
8 1/8" (207mm)
9 1/4" (235mm)
10 15/16" (278mm)
1 3/4" (45mm)
2 9/16" (65.2mm)
1 9/16" (40mm)
1/8" (3mm)
Detailed front side view of HR 1622
26
Rear view of HR 1622
30 5/8"
(778.5mm)
24 3/8"
(619.9mm)
E
5 7/8"
(149mm)
W
3 1/4"
(81.8mm)
Electric Range dimensions
E = Electrical connection
W = Water connection
27
All Gas Range dimensions
1
HR 1124, HR 1134, HR 1135, HR 1136
Position Dimension Description
28
13" (330 mm) Maximum depth of top cabinet
6" (152 mm) Minimum distance (left and right) to flammable
sur
faces
18" (457 mm) Minimum distance to bottom edge of top cabinet
30" (762 mm) Minimum distance between the top of the cooking
ar
ea and the bottom of an unprotected wooden or
metal cabinet
35 1/2"–37"
(901 - 940 mm)
Distance from floor to cooktop surface
Loading...
