Miele G 1182, G2182 User Manual

Operating Instructions

Dishwasher G 1182 G 2182

To prevent accidents and appliance damage read these instructions

before

installation or use. M.-Nr. 07 724 140

en - US, CA

Contents

IMPORTANT SAFETY INSTRUCTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Guide to the dishwasher . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Control panel ......................................................8

Caring for the environment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Before using for the first time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

To open the door ..................................................10

To close the door ..................................................10

Rinse aid ........................................................11

Adding rinse aid ..................................................11

Rinse aid indicator .................................................11

Adjusting the dosage...............................................12

Loading the dishwasher . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Items not recommended for dishwashing ...............................14

Cutlery tray.......................................................15

Upper basket .....................................................16

Adjusting the upper basket ..........................................17

Lower basket .....................................................18

Basket accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Adding detergent..................................................23

Turning on .......................................................24

Selecting and starting a program .....................................24

Program guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

At the end of a program.............................................26

Preparing your appliance for an extended vacaion .......................26

Interrupting a program..............................................26

Changing a program ...............................................26

Additional options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Buzzer ..........................................................27

Default settings ...................................................28

Contents

Frequently asked questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Technical faults ...................................................29

Problems with water Intake / Drain ....................................30

General problems with the dishwasher .................................31

Sounds..........................................................32

Poor cleaning results ...............................................33

Comparison Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

After sales service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Transport . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

User Maintenance Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Cleaning and Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Triple filter system .................................................43

Cleaning the spray arms ............................................45

Cleaning the water inlet filter .........................................46

Cleaning the drain pump and non-return valve...........................47

Installation instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Electrical connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Plumbing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Waterproof system.................................................51

Connection to the water supply .......................................51

Drainage ........................................................52

IMPORTANT SAFETY INSTRUCTIONS

WARNING -

When using your dishwasher, follow basic precautions, including the following:

Read all instructions before installation or use of the dishwasher to prevent injury and machine damage.

Use the dishwasher only for its intended purpose. This appliance is intended for residential use only.

Keep these operating instructions in a safe place and pass them on to any future user.

Electrical Safety

Before installation, make sure that

the voltage and frequency listed on the data plate correspond with the household electrical supply. This data must correspond to prevent injury and machine damage. Consult a qualified electrician if in doubt.

Before installation or service,

disconnect the power supply to the work area by unplugging the unit, "tripping" the circuit breaker or removing the fuse.

Do not use an extension cord to

connect this appliance to electricity. Extension cords do not guarantee the required safety of the appliance (e.g. danger of overheating).

Be certain your appliance is

properly installed and grounded by a qualified technician. To guarantee the electrical safety of this appliance continuity must exist between the appliance and an effective grounding system. It is imperative that this basic safety requirement be met. If there is any doubt, have the electrical system of the house checked by a qualified electrician.

IMPORTANT SAFETY INSTRUCTIONS

Installation

The dishwasher must be installed

and connected in compliance with the installation instructions.

Installation and repair work should

be performed by a Miele authorized service technician. Work by unqualified persons could be dangerous and may void the warranty.

Do not install or use a damaged

dishwasher. A damaged appliance is dangerous. Unplug the machine and call your Miele dealer or the Miele Technical Service Department.

Ensure that any plastic wrappings,

bags, etc. are disposed of safely and kept out of the reach of children. Danger of suffocation!

This equipment is not designed for

maritime use or for use in mobile installations such as recreational vehicles or aircraft. However, under certain conditions it may be possible for an installation in these applications. Please contact the nearest Miele dealer or the Miele Technical Service Department with specific requirements.

It is recommended that the

dishwasher only be connected to the mains with the plug (no hard-wiring). The outlet must be accessible at all times after installation to disconnect the dishwasher.

, WARNING - Fire hazard

Do not cover or crush the plug of the appliance. Ensure that the cabinet opening for the dishwasher provides ample space for the plug. Installing the dishwasher in a tight space may crimp the power cord or put pressure on the plug which could cause overheating.

This dishwasher should only be

installed under a continuous counter top secured to adjacent cabinetry.

Do not install this dishwasher

beneath a cooking surface, oven or any appliance that radiates heat. High temperatures from these units may damage the dishwasher.

When installing the dishwasher

under a counter top and removing the toekick, a build-under toekick must be installed. Use the respective installation kit. Danger of injuries.

Do not cut the intake hose or

submerge it in liquid. This hose contains electrical components that could cause injury or property damage if cut or submerged.

Only connect the dishwasher to the

mains when all installation and plumbing work is complete.

IMPORTANT SAFETY INSTRUCTIONS

Use

To reduce the risk of injury, do not

allow children to play in, on or near the dishwasher.

Only use the dishwasher if all panels

are properly in place.

Do not tamper with the controls.

Do not damage, sit or stand on the

door or baskets of the dishwasher. Close the door when not in use.

Under certain conditions, hydrogen

gas may be produced in a hot water system that has not been used for two weeks or more. HYDROGEN GAS IS EXPLOSIVE. If the hot water system has not been used for such a period, turn on all hot water faucets and let water flow from each for several minutes before using the dishwasher. This will release any accumulated hydrogen gas. Do not smoke or use an open flame during this time.

Be sure that all items placed in the

dishwasher are "dishwasher safe". For items not labeled, check the manufacturer’s recommendations.

When loading tableware, place

sharp items away from the door to prevent damage to the seal. Load sharp items pointing downwards to prevent injuries.

Only use detergents and rinse aids

recommended for residential dishwashers. Keep all detergents and rinse aids out of the reach of children.

Do not inhale or swallow detergents.

Dishwasher detergents contain irritant and corrosive ingredients. They can cause burning in the mouth and throat if swallowed, or inhibit breathing. Consult a doctor immediately if detergent has been swallowed or inhaled.

Do not drink water from the

dishwasher! Harmful residues could be present.

Do not fill the rinse aid reservoir with

detergent. It will damage the rinse aid compartment.

The door will close automatically

once pushed against the door catch. Do not put your hand inside of the door as it is closing. Danger of injury.

If the power cord is damaged it

must only be replaced by a Miele Service technician with a genuine Miele power cord.

Disposal of an appliance

If the appliance is removed from its

installation site and will not be used, remove the doorlock to the wash cabinet to prevent children from locking themselves in the machine.

SAVE THESE

INSTRUCTIONS

Guide to the dishwasher

a Upper spray arm (not visible)

b Cutlery tray

c Upper basket

d Middle spray arm

e Air inlet for drying

(depending on model)

f Lower spray arm

g Triple filter system

h Data plate

i Rinse aid reservoir

j Dual compartment detergent

dispenser

Guide to the dishwasher

Control panel

a Check / Refill indicators

b Program selection

c Program button

d On button g with Indicator

e Off button o

Energy saving washing

This dishwasher is exceptionally economical in the use of water and electricity. For best results follow these tips:

^ For lowest energy consumption you

may connect the dishwasher to a cold water source.

^ For fastest possible wash times, with

slightly higher energy consumption, connect the dishwasher to a hot water source.

^ Make full use of the baskets without

overloading for the most economical washing.

^ Use the correct amount of detergent

and rinse aid. Detergent dosage is dependent upon the amount of soiling and type of dishware being washed. See the "Program Guide" for more information.

Caring for the environment

^ When using powder or gel detergent,

reduce the amount to normal amount when washing a small load.

^ Choose a program that best suits the

degree of soiling and the type of dishes being washed.

^ For small loads select "Express".

/3of the

Before using for the first time

To open the door

^ Pull the handle to open the door.

If the door is opened during operation, the dishwasher will stop running. Once the door is closed the program will continue.

To close the door

^ Push the baskets in.

^ Lift the door and push until it clicks

into position.

Rinse aid

Rinse aid helps to prevent spotting on dishes and glassware. The rinse aid is filled in the reservoir and the set amount will be automatically dosed.

Filling the rinse aid reservoir with

detergent will damage the reservoir. Only pour rinse aid formulated for residential dishwashers into the reservoir.

When using "Tab" detergents rinse aid is not needed.

Before using for the first time

^ Pour liquid rinse aid into the reservoir

until it is visible on the surface of the screen.

Adding rinse aid

^ Press the button in the direction of

the arrow until the flap springs open.

The rinse aid reservoir holds approx.

3.7 oz (110 ml).

^ Press on the flap until you hear it

click shut. Failure to close it all the way allows water to enter the reservoir during the wash program.

^ Clean any spilled rinse aid. The flap

will remain closed during normal operation.

Rinse aid indicator

When the rinse aid indicator first comes on, there will be enough rinse aid left for2-3washes.

^ The rinse aid indicator on the control

panel will light when the rinse aid reservoir needs refilling.

Before using for the first time

Adjusting the dosage

The dosage selector is preset to 3. This dispenses approximately 3 ml of rinse aid per program. It can be adjusted from 0 to 6.

– Use a higher setting if spots appear

on dry glassware.

^ Use a lower setting if streaking

appears on dishes or glasses.

^ Turn the dishwasher off "V".

^ Press and hold the "Program" button

and at the same time turn the dishwasher on g. Hold the "Program" button until the "Rinse & Hold" indicator comes on.

If it does not come on start over.

^ Press the "Program" button three

times.

The "Intake / Drain" indicator flashes three times in intervals.

The "SaniWash" indicator flashes 3 times in intervals. The rinse aid dosage is adjusted to 3 ml by default.

The amount set can be recognized by the flashing rhythm of the "SaniWash" indicator (see table):

Dosage in ml Flashing rhythm

1 Once

2 Twice

3 3 times

4 4 times

5 5 times

6 6 times

^ Press and hold the "Program" button

until the "Intake / Drain" indicator lights up.

^ Select the desired setting with the

"Program" button. Every touch of the button increases the level.

The programmed dosage is saved.

^ Turn the dishwasher off "V".

Do not wash items soiled with

ash, sand, wax, grease or paint in the dishwasher. Ash and sand do not dissolve and will be distributed throughout the inside of the dishwasher. Wax, grease and paint will cause permanent discoloration and damage to the dishwasher.

^ Scrape food from dishes before

placing them in the dishwasher, rinsing is not necessary.

^ Some foods contain natural dyes,

e.g. carrots or tomatoes. Plastic items may discolor permanently if they come in contact with food dyes.

^ All items can be placed anywhere in

the baskets.

^ Load dishes so that water can reach

all surfaces. Do not place dishes or cutlery inside other pieces.

Loading the dishwasher

^ The spray arms must not be blocked

by items that are too tall or hang through the baskets. Check clearance by manually rotating the spray arms.

^ Place very small items in the cutlery

tray or basket so they do not fall to the bottom of the wash cabinet.

^ Food residue and spilled liquids

should be cleaned from the sides of the dishwasher door. These are outside of the wash cabinet and are not cleaned by water from the spray arms.

^ Make sure that all items are securely

positioned.

^ Hollow items such as cups and

glasses should be placed upside down in the baskets.

^ To ensure good water coverage,

tall, narrow and hollow items, i.e. vases or champagne glasses, should be placed in the center of the basket rather than in the corners.

^ Concave based items such as mugs

or bowls, should be placed at an angle so that water does not pool.

Loading the dishwasher

Items not recommended for dishwashing

– Cutlery with wooden handles

– Wooden cutting boards

– Glued items such as old knives with

handles glued together around the shank of the blade

– Handmade craft items, antique,

metal trimmed or decorative glassware

– Plastic items that are not heat

resistant

– Copper, brass, tin or aluminum

– Dishes with color painted over the

glaze. These dishes may fade over time

– Cast iron pots and pans

* depending on model

If unsure whether your china and crystal are dishwasher safe, please check with the manufacturer. The China & Crystal program, although extremely gentle and thorough can cause the china and crystal to "wear" if they are not dishwasher safe.

Glassware:

– There are no standard guidelines for

washing glassware, when in doubt wash by hand.

– When purchasing new dishes,

glasses and cutlery, make sure they are dishwasher safe. Only wash items marked "dishwasher safe" in the dishwasher.

Silver and aluminum:

– Silver or aluminum items may tarnish.

– Silverware previously cleaned with a

silver polish may be damp or spotted at the end of a program where water has adhered to the polish. This can be rubbed off with a soft, dry cloth. Silver that has been cleaned in an immersion dip is usually dry at the end of a program, but may tarnish.

– If left to dry, foods containing sulfur

can discolor silver. These include egg yolk, onions, mayonnaise, mustard, fish and marinades.

– Silverware may tarnish or pit if

washed next to stainless steel. Leave space between these metals.

– Clean aluminum items, e.g. grease

filters, with domestic dishwasher detergent only.

Cutlery tray

^ Arrange the cutlery as shown in the

cutlery tray.

For easier unloading cutlery should be grouped in zones, one for knives, one for forks, one for spoons, etc.

Place knives with the cutting edge down and forks with the prongs between the holders. Spoons should be placed in the opposite direction with the handles between the holders so that water can run off more easily.

Loading the dishwasher

Spoons with thick handles may have to be placed as knives and forks with their heads in the holders.

The upper spray arm must not be blocked by tall cutlery items.

The cutlery tray insert is removable.

Loading the dishwasher

Upper basket

Always use the dishwasher with

the upper and lower basket inserted.

^ Load the upper basket with small,

lightweight, or delicate items such as cups, saucers, glasses, dessert bowls and flat pans.

^ Long items such as soup ladles,

mixing spoons and long knives should be placed lying down across the front of the upper basket.

Coffee bar

(depending on model)

Glasses can be leaned against the coffee bar for a secure stand.

^ The bar can also be used to separate

two rows of glasses.

To stack wide items, flip the bar to the right.

Cup racks

Raise the rack to make room for tall glasses. Lower it to double stack smaller pieces.

Loading the dishwasher

Adjusting the upper basket

The upper basket can be raised or lowered to accommodate tall items.

The basket can also be angled to fit tall items in both, the upper and lower baskets. The angles should not be set to opposite extremes. This will block the middle spray arm. Take care when sliding the basket in and out in this position.

^ Slide out the upper basket.

Depending on the setting of the upper basket, a variety of plate dimensions can be accommodated.

For example: If the upper basket is in its highest position a plate with a diameter of 12 the lower basket.

/16" (31 cm) can be fit in

^ Pull up the levers at the sides of the

upper basket and adjust the basket height.

^ Release the levers and the basket will

lock in place.

+ 39 hidden pages
