Operating and Installation Instructions

Freezer with Ice Maker F 1801 Vi, F 1811 Vi F 1901 Vi, F 1911 Vi

To prevent accidents and appliance damage read these instructions

before

installation or use.

en - US, CA

M.-Nr. 09 168 930

Contents

IMPORTANT SAFETY INSTRUCTIONS.................................4

Guide to the freezer ................................................8

Before use ......................................................10

Turning the appliance On/Off ........................................10

Settings.........................................................11

Using the settings .................................................11

Additional settings .................................................11

Turning the button sound On/Off ......................................12

Turning off for longer periods of time ..................................13

Temperature and door alarm .......................................14

Temperature alarm ................................................14

Door alarm .......................................................14

Setting the temperature............................................15

Using the freezer efficiently ........................................17

Freezing food.....................................................17

Defrosting .......................................................18

Cooling drinks quickly ..............................................18

SuperCool.......................................................20

Ice cube maker ...................................................21

Automatic defrost ................................................22

Adjusting the interior fittings .......................................23

Moving the shelves ................................................23

Freezer baskets ...................................................23

Ice cube container.................................................24

Cleaning and care ................................................25

Cleaning the interior and accessories ..................................26

Ventilation slits ....................................................27

Door seals .......................................................27

Changing the light bulb .............................................28

Water filter ......................................................30

Water filter change indicator .........................................30

Exchanging the water filter ..........................................31

Confirming the filter change .........................................32

Using an external water filter .........................................32

Lead free certificate ...............................................35

Frequently asked questions ........................................36

After sales service ...............................................43#

Contents

Caring for the environment.........................................46

Installation ......................................................47

Installation site ....................................................47

Stainless steel panels ..............................................49

Custom door panels ...............................................49

Installation options .................................................49

Dimensions......................................................52

Niche dimensions .................................................53

Installing the appliance ............................................55

Before you begin ..................................................55

RemoteVision module installation .....................................57

Preparing the installation niche .......................................58

Sliding the appliance into the installation niche ..........................62

Aligning the appliance..............................................63

Attaching the appliance to the installation niche..........................64

Preparing the custom door ..........................................66

Attaching and aligning the custom door front ............................68

Plumbing........................................................72

Electrical connection..............................................75

RemoteVision (optional accessory) ..................................76

IMPORTANT SAFETY INSTRUCTIONS

When using the appliance, follow basic safety precautions, including the following:

Read all instructions before installation and use to prevent accidents and machine damage.

This appliance is intended for residential use only. Use only as described in this Operating manual.

Only use the appliance for its intended purpose.

This appliance complies with current safety requirements. Improper use of the appliance can lead to personal injury and material damage.

Keep these operating instructions in a safe place and pass them on to any future user.

Electrical Safety

Before installation, make sure that

the voltage and frequency listed on the data plate correspond with the household electrical supply. This data must correspond to prevent injury and machine damage. Consult a qualified electrician if in doubt.

Before installation or service,

disconnect the power supply to the work area by unplugging the unit, "tripping" the circuit breaker or removing the fuse.

Do not use an extension cord to

connect this appliance to electricity. Extension cords do not guarantee the required safety of the appliance (e.g., danger of overheating).

Be certain your appliance is

properly installed and grounded by a qualified technician. To guarantee the electrical safety of this appliance continuity must exist between the appliance and an effective grounding system. It is imperative that this basic safety requirement be met. If there is any doubt, have the electrical system of the house checked by a qualified electrician.

Only connect power to the

appliance when all installation and plumbing work is complete.

IMPORTANT SAFETY INSTRUCTIONS

Installation

This appliance is top-heavy and must be secured to prevent the possibility of tipping forward. Keep the door closed until the appliance is completely installed and secured per installation instructions.

This appliance must be installed

and connected in compliance with the installation instructions.

Installation and repair work should

be performed by a Miele authorized service technician. Work by unqualified persons could be dangerous and may void the warranty.

Installation must comply with local

plumbing regulations and state laws.

Do not operate any appliance with a

damaged cord or plug, or if the appliance has been damaged in any manner. Contact Miele’s Technical Service Department.

This appliance must not be used in

a non-stationary location (e.g. on a ship).

Do not install the freezer in a room

with too low an ambient temperature, e.g., a garage, as this may lead to the appliance switching off for longer periods so that it cannot maintain the required temperature.

In appliances with an automatic ice

maker, avoid contact with the moving parts of the ejector mechanism, or with the heating element located on the bottom of the ice maker. Do not place fingers or hands on the automatic ice making mechanism while the freezer is plugged in.

The ice cube maker is not suitable

for connection to a hot water supply.

Do not use water that is

microbiologically or chemically unsafe or of unknown quality without adequate disinfection or other treatment before or after the filter is used; the filter alone is not an adequate safeguard.

Use

This appliance is not designed for

commercial use. It is intended for use in domestic households and in similar working and residential environments such as:

–

shops, offices and similar work environments

–

by customers in hotels, motels, Bed & Breakfasts or similar residential environments.

This appliance is not intended for

outdoor use.

The appliance is only intended for

residential use to store frozen foods, freeze fresh foods and prepare ice. All other uses are prohibited and may be dangerous.

IMPORTANT SAFETY INSTRUCTIONS

Persons who lack physical, sensory

or mental abilities, or experience with the machine should not use it without supervision or instruction by a responsible person.

To reduce the risk of injury, do not

allow children to play in, on or near the appliance, especially in the door hinge area.

After your freezer is in operation, do

not touch the cold surfaces in the freezer compartment, particularly when hands are damp or wet. Skin may adhere to these extremely cold surfaces.

Do not refreeze frozen foods which

have thawed completely.

Do not store or use gasoline or other

flammable vapors and liquids in the vicinity of this or any other appliance.

Do not deactivate the water filter

display.

Do not use defrosting sprays or

de-icers, as they might contain substances which could damage the plastic parts or which could cause a build-up of gases and pose a danger to health.

Do not use any oils or grease on the

door seal, as these will cause the seal to deteriorate and become porous with time.

Do not block the ventilation gaps in

the plinth or the top of the appliance housing unit, as this can impair the efficiency of the appliance, increase the electricity consumption and cause damage to the appliance.

Never use a steam cleaner to clean

the appliance. Pressurized steam could damage electrical components and cause a short circuit.

Do not use sharp-edged objects to

remove frost and ice, or separate frozen foods and remove ice trays. They will damage the evaporator, causing irreversible damage to the appliance.

IMPORTANT SAFETY INSTRUCTIONS

Disposal of your old appliance

Before disposing of an old

appliance, first make the door latch or lock unusable.

Take off the door.

Leave the shelves in place so that

children may not easily climb inside.

Consult with your municipal policy

on recycling.

Be careful not to damage any part of

the pipework while awaiting disposal by:

- puncturing the refrigerant channels in the evaporator.

- bending any pipework.

- scratching the surface coating.

Splashes of refrigerant can damage the eyes.

Your old freezer may have a cooling

system that used CFCs (chlorofluorocarbons). CFCs are believed to harm stratospheric ozone. If you intentionally release this CFC refrigerant, you can be subject to fines and imprisonment under provisions of environmental legislation. Make sure the CFC refrigerant is removed and disposed of by a qualified technician.

SAVE THESE INSTRUCTIONS

Guide to the freezer

a Door shelves (height adjustable)

b Shelves (height adjustable)

c Ice cube maker

d Ice cube container

e Control panel

f Main switch to turn the appliance

On/Off

g Freezer baskets

h Water filter

Control panel

Guide to the freezer

a Access button "p"

b Temperature display

X colder; Y warmer Allows you to set the desired temperature in the freezer

c On/Off sensor button for the

SuperCool function

d On/Off sensor button for the ice cube

maker

e Sensor button for the temperature

and door alarm*

f Water filter change indicator*

* Only visible when the relevant

function is activated

Before use

Before using for the first time

Clean the inside of the appliance and

the accessories with a mild solution of warm water and liquid dish soap. Dry with a soft cloth.

If the appliance was transported to the installation site horizontally, leave the appliance standing upright for approx. 8 hours before connecting it to the electrical supply. This is very important to ensure correct functioning.

Turning the appliance On/Off

Open the appliance door.

Turn the appliance On/Off with the

main switch.

The main switch is located on the right-side underneath the control panel.

Once on, the appliance begins cooling. When the door is open, the interior lights come on.

The access button will light in the control panel.

The preset temperatures (factory default settings) are reached after a few hours. Do not put any food in the appliance until the preset temperatures are reached.

Turning off the appliance with the main switch does not safely isolate it from the power supply.

Settings

Using the settings

This appliance is operated with the use of touch keys activated by a finger.

An available button will appear white.

–

A selected button will appear yellow.

–

Touch the access button "p"soit

turns yellow.

On the control panel you will see additional sensor buttons to operate the appliance.

These buttons allow you to:

– adjust the temperature,

– select the SuperCool function, or

– turn the ice maker On/Off.

For additional information, see the corresponding sections in this manual.

To leave the settings menu, touch the access button "p" so it turns white. The last settings entered are stored. If the access button is not pressed the display will go out after approx. 30 secs.

Additional settings

In the settings mode you can select and change functions.

In settings mode, certain settings can be changed. The function possibilities are described in the respective chapters of this manual.

Overview of the selectable function settings:

Function Display text

To enter and exit the Settings mode

Temperature unit °C-°F (see "Setting the temperature")

RemoteVision Module settings (optional accessory)

Button sound on/off (see "Settings")

No function ^

†

;

The other sensor buttons now disappear from the control panel.

Settings

Turning the button sound On/Off

If you prefer the buttons to be silent when touched the button sound can be turned off.

Touch the access button "p"soit

turns yellow.

Note the position of the X button, but

do not touch.

^ Touch the access button "p" again so

it turns white.

Only the access button "p" is visible.

^ Place one finger on the position of

the X button and hold (the X button will not be visible).

While holding down the X button,

press the access button "p" once. Keep holding the X button down until the following appears in the display (approx. 5 seconds).

Tap the X button until = appears in

the display.

Touch the access button "p"to

confirm.

^ By touching the X button, you can

choose between:

= 0 : Button sound is off = 1 : Button sound is on = – : Return to menu.

^ Touch the access button "p"to

confirm the setting.

^ Tap the X button until you see ; in

the display.

Touch the access button "p".

You have now left the Custom settings mode.

When you are in the Custom settings mode the door alarm is turned off automatically. Once the door is closed it is reactivated.

Turning off for longer periods of time

If the appliance is not going to be used for an extended time (for example, during a vacation) some precautions need to be taken:

Shut off the water supply line,

(several hours before switching off the appliance)

Take all food out of the appliance

Turn the appliance off

Unplug the appliance

^ Empty the ice cube container

^ Clean the interior

^ Remove and discard the water filter

(secure the filter cap)

^ Leave the door open to prevent

odors

Settings

Temperature and door alarm

The appliance is equipped with an alarm system, to ensure that the temperature does not rise unnoticed because of energy loss or an open door.

The alarm system is always operational, it does not need to be switched on.

Temperature alarm

If the temperature becomes too warm, an alarm sounds and the "alarm" indicator turns red and flashes and the temperature flashes in the control panel.

The temperature display shows the highest temperature reached during the alarm.

The alarm will sound and the display will flash if:

– too much warm air flows into the

appliance, for example when food is being loaded, re-arranged, or taken out.

–

large amounts of food are being frozen at once.

Turning the temperature alarm Off

As soon as the alarm condition is corrected, the alarm signal turns off and the affected zone stops flashing in the display. The "alarm" indicator goes out.

To turn the alarm off early, press

the "alarm" sensor button. The alarm signal turns off. The "alarm" indicator remains on until the alarm condition is corrected.

If the temperature in the freezer zone reaches 0°F (-18°C) or higher, check that food has not defrosted.

Door alarm

If the appliance door is left open, an alarm signal will sound and the "alarm" indicator will turn red after five minutes.

Once the door is closed the alarm will turn off and the "alarm" indicator will go out.

–

the power fails.

As soon as the alarm condition is corrected the alarm with turn off and the sensor button for alarm will go out.

Turning the door alarm Off

To turn the alarm off early:

The "alarm" indicator and signal will turn off. The alarm will turn off and the "alarm" indicator will go out.

Setting the temperature

Touch the access button "p"soit

turns yellow.

Use the X and Y buttons next to the

temperature display to set the temperature warmer or colder.

Tap the X and Y sensor buttons to raise/lower the temperature 1°, or hold it down to move through the temperature range more quickly.

The temperature display on the control panel always shows the

desired temperature.

Temperature range

The temperature can be set within the following range: 7°F to -11°F (-14°C to -24°C).

To freeze fresh food and store frozen food for an extended period of time, a temperature of 0°F (-18°C) is suggested.

The room temperature and the installation location can affect the time it takes for the appliance to drop to the coldest temperature. If the room temperature is too high, it may not be possible for the appliance to reach the lowest temperature.

Setting the temperature

Temperature unit (Fahrenheit/Celsius)

The temperature can be displayed in degrees Fahrenheit (°F) or Celsius (°C).

Touch the access button "p"soit

turns yellow.

Note the position of the X button, but

do not touch.

Touch the access button "p" again so

it turns white.

Only the access button "p" is visible.

^ Place one finger on the position of

the X button and hold (the X button will not be visible).

While holding down the X button,

press the access button "p" once. Keep holding the X button down until the following appears in the display (approx. 5 seconds).

Tap the X button until † appears in

the display.

Touch the access button "p"to

confirm.

^ By touching the X button you can

select either Fahrenheit or Celsius for the temperature display.

†0: Fahrenheit †1: Celsius † –: return to menu.

^ Touch the access button "p"to

confirm the setting.

^ Tap the X button until a ; appears in

the display.

Touch the access button "p".

You have left the Custom settings mode.

When you are in the Custom settings mode the door alarm is turned off automatically. Once the door is closed it is reactivated.

Using the freezer efficiently

Freezing food

Fresh food should be frozen as quickly as possible. This helps maintain the nutritional value, vitamin content, appearance and taste of the food.

Never refreeze partially or fully defrosted food. Consume defrosted food as soon as possible, it will lose its nutritional value and spoil if left for too long. Do not refreeze defrosted food unless it has been cooked.

Before placing food in the freezer

^ When you are planning to freeze

large amounts of food (more than 4 ½ lbs [2 kg]), switch on the SuperCool function ahead of time (see "SuperCool"). This will provide the food already in the freezer with a protective boost of cold air.

Placing food in the freezer

Food to be frozen can be placed anywhere in the freezer.

Load bearing capacity of the baskets:

Small

basket

F 18X1Vi/SF 72 lbs

(33 kg)

F 19X1Vi/SF 94 lbs

(43 kg)

^ Spread the food to be frozen across

the bottom of the freezer basket or across the shelves, so that it will freeze through to the core as quickly as possible.

^ When placing items in the freezer,

make sure the packaging and containers are dry, to keep them from sticking together when frozen.

Large

basket

72 lbs

(33 kg)

94 lbs

(43 kg)

When freezing, try not to let frozen food come into contact with unfrozen food, this could cause the frozen food to defrost.

Using the freezer efficiently

Defrosting

Frozen food can be defrosted in different ways:

in a microwave oven,

–

at room temperature,

–

in the refrigerator (the cold given off

–

by the frozen food helps to keep the other food cold),

in a steam oven.

–

Poultry It is especially important to observe proper hygiene when defrosting poultry. Never save the liquid from defrosted poultry. Drain it away and promptly wash the container, the sink and your hands. Danger of salmonella poisoning.

Fruit should be defrosted at room temperature in its packaging, or in a covered bowl.

Most vegetables can be cooked while still frozen. Simply place directly into boiling water or hot oil.

Cooling drinks quickly

To cool drinks quickly, switch on the SuperCool function, see "SuperCool" for more information.

Do not leave bottles in the freezer for more than 1 hour, closed containers could burst.

Using the freezer efficiently

Freezing tips

The following are examples of foods

–

suitable for freezing: Fresh meat, poultry, game, fish, vegetables, herbs, fresh fruit, pastry/dough, leftovers, and a range of pre-cooked meals.

The following examples of foods not

–

suitable for freezing: Lettuce, radishes, sour cream, mayonnaise, eggs in their shells, onions, whole raw apples and pears.

To retain color, taste and vitamin C,

–

vegetables should be trimmed, washed, and blanched. To blanch: bring a large saucepan of water to a boil, then submerge the vegetables in rapidly boiling water for 2-3 minutes, depending on type. Remove, and plunge into ice-cold water to cool quickly. Drain and pack for freezing.

– Lean meat freezes better than fatty

meat, and can be stored for considerably longer.

–

To prevent chops, steaks, cutlets or rolled meats from freezing together in solid blocks when packed, separate with a sheet of plastic freezer wrap.

Do not place hot foods or drinks in

–

the freezer. This causes already frozen food to thaw, and increases the energy consumption considerably. Allow hot foods and drinks to cool down before placing them in the freezer.

Packing tips

Unsuitable packing material

- wrapping paper

- greaseproof paper

- cellophane

- garbage bags

- plastic shopping bags

Suitable packing material

- plastic freezer bags/wrap

- aluminum foil

- freezer containers

^ To help prevent freezer burn, expel

as much air as possible from bags, etc., before sealing them.

^ Close the packaging tightly with

- plastic clips

- twist ties

- rubber bands

Mark the package to indicate the contents and the date of freezing.

–

Do not season fresh foods or blanched vegetables before freezing. Cooked food can be lightly seasoned before freezing, but care should be taken as the taste of some spices alters when frozen.

SuperCool

When the SuperCool function is activated, the appliance is cooled as cold as possible (to a factory-preset temperature).

SuperCool

The SuperCool function is ideal for freezing large quantities of unfrozen food. Ideally the function should be switched on4-6hours before the food is placed in the freezer. If the max. freezing capacity is used, 24 hours are recommended. This helps food to freeze quickly and retain its nutrients, vitamins, flavor and appearance.

Switching on SuperCool

^ Touch the SuperCool sensor so that

it turns yellow.

Switching off SuperCool

The SuperCool function automatically switches off after approx. 52 hours. The sensor button turns white, and the appliance continues running at normal power.

To save energy, you can switch off the SuperCool function once the food is sufficiently chilled.

^ Touch the SuperCool sensor so that it

turns white.

The temperature display returns to the original temperature setting.

The appliance now continues running at normal power.

The temperature now begins to fall, with maximum cooling performance.

The new temperature setting appears in the display -22°F (-30°C).

For the automatic ice cube maker to operate, it must be connected to the household water supply. See "Plumbing".

Ice cube maker

ice cube maker and collect in the container.

Once the ice cube container is full, the ice cube maker switches off automatically.

Turning on the ice cube maker

Make sure that the ice cube

container is under the ice cube maker, as far as possible.

Ice cubes will not be produced unless the container is completely closed.

^ Touch the sensor button for the ice

cube maker so that it turns yellow.

As soon as the freezer has cooled to a freezing temperature, the ice cube container fills with water. Cold air is blown directly over the container.

As soon as the ice cubes are frozen, they fall into the ice cube container.

The ice cube maker can produce approx. 120 ice cubes within 24 hours. Note: Ice production will vary due to your water supply temperature, pressure and hardness.

The production volume of the ice depends on the temperature in the freezer. The lower the temperature the more ice cubes produced.

Do not use the ice cube container for rapid cooling of food or drinks. The ice cube maker may become blocked and be damaged.

Do not use the first three containers of ice cubes from the ice cube maker. Discard the ice produced in the first 24 hours after switching on the ice cube maker. This applies for the very first use, and whenever the appliance has been out of service for an extended period of time.

The amount of ice cubes produced depends on the temperature in the freezer section. The lower the temperature, the more ice cubes will be produced in a given period of time.

Turning off the ice cube maker

The water supply line must be shut off several hours before the appliance or ice cube maker is switched off.

After the appliance is turned on for the very first time, it can take up to 10 hours for the first ice cubes to drop out of the

Touch the sensor button for the ice cube maker so that it turns white.

Automatic defrost

The freezer defrosts automatically.

The moisture generated in the appliance collects in the evaporator. It is automatically defrosted and dissipated by the condenser periodically.

This automatic defrosting system enables the freezer to remain permanently ice-free, while ensuring that the food stored in the freezer stays frozen.

Adjusting the interior fittings

Moving the shelves

The shelves can be adjusted according to the height of the food.

Using both hands, grasp the shelf

from underneath and lift slightly so that the rear of the shelf is slightly above the mountings.

Pull the shelf forward.

Move the shelf to the desired height,

then insert the (rear) hooks into place.

Make sure the shelf is level.

Top shelf

^ Lift the shelf up and out.

^ When replacing the shelf, make sure

that the latches on the corners at the back are correctly engaged.

Adjusting the door shelves

For easier loading, unloading, and cleaning, the door shelves can be shifted or completely removed.

Using both hands, grasp the door shelf by the frame and tip it slightly forward.

Slide the tipped shelf up or down along the slide-rails, and click it into place with the lower hooks.

Make sure the shelf is level.

Replacing a door shelf

Start at the top of the slide-rails and

slide the shelf down into the desired position.

Freezer baskets

For easier loading, unloading, and cleaning, the freezer baskets can be shifted or completely removed.

Pull the basket forward until

resistance is felt.

On the hinged-side of the door is a safety lock, which must be turned to a horizontal position before the drawer can be removed.

Using a suitable object, e.g., coin, turn the safety lock to a horizontal position a.

On both sides of the basket, pull the latches b upward and lift the basket out of the freezer.

Replacing the freezer basket

Fully extend the telescopic tracks.

Removing a door shelf

Slide it upward all the way to the top of the slide-rails, until it can be removed.

Lay the basket onto the tracks so that it connects in the front and back.

Turn the safety lock back to the vertical position.

Slide the freezer basket in.

Adjusting the interior fittings

Ice cube container

The ice cube container is set on telescopic tracks, and can be removed for loading, unloading and cleaning.

Slide the container forward until

resistance is felt.

^ On both sides of the container, pull

the latches (see arrow) upward and lift the container out of the freezer.

Push the tracks back into the freezer to avoid injury.

Replacing the ice cube container

Completely extend the telescopic tracks.

Lay the container onto the tracks so that it connects in the front and back.

Slide the ice cube container completely in.

To reduce the risk of electrical shock, disconnect the appliance from the power supply by shutting off the power main, tripping the circuit breaker or unplugging the power cord before maintenance.

Cleaning and care

To better maintain your appliance avoid the following:

cleaners containing soda, ammonia,

–

thinners, or chlorides

cleaners containing descaling

–

agents or lime removers,

abrasive cleaners,

–

Never use cleaning agents containing abrasive substances such as sand, soda, acids, chlorides or chemical solvents. Non-abrasive cleaning agents are also unsuitable, as they can cause matte areas to appear.

Only use a mild solution of warm water and liquid dish soap to clean this appliance.

Do not use a steam cleaner to clean this appliance. Pressurized steam could penetrate electrical components and cause a short circuit.

Do not allow water to get into the electronic unit or lights.

The data plate located inside the appliance must not be removed. It contains information which is required in the event of a service call.

stainless steel cleaners,

–

dishwasher soap (powder),

–

caustic (oven) cleaners,

–

scouring pads, steel wool, hard

–

brushes,

– metal scrapers,

– eraser sponges,

– steam cleaning products.

Glass cleaners may be used to clean the exterior. However do not allow them to sit or "puddle", this can cause damage to the surface.

Remove the cleaner promptly.

Cleaning and care

Before cleaning

Use the main switch to turn the

appliance off completely.

The main switch is located on the right side underneath the control panel.

Unplug the power cord.

Remove any food from the appliance

and store it in a cool place.

^ Take out any removable parts,

e.g., shelves.

Cleaning the interior and accessories

Use a mild solution of warm water and liquid dish soap. Wash all accessories and drawers by hand. Do not wash in a dishwasher.

Aluminum frames

The shelf frames and the door baskets are made of aluminum.

Clean the frames with a mild solution

of warm water and liquid dish soap.

Aluminum is susceptible to scratches and nicks, treat with care.

The aluminum frames may become discolored or otherwise altered if soiling is not cleaned away promptly.

Do not use stainless steel cleaners; lime removers; scouring pads, such as pot scrubbers; or used sponges that still contain abrasive cleanser residue to clean the frames.

Clean the appliance as needed.

After washing, wipe down the interior and accessories with a clean wet cloth, then dry with a soft cloth. Leave the appliance door open for a short time, so the moisture can evaporate.

Cleaning and care

Ventilation slits

Check the ventilation slits in the base

panel regularly. Remove any dirt/dust with a vacuum cleaner or brush. Clean as needed.

Door seals

Do not use any oils or grease on the door seals. This may cause the seals to deteriorate and become porous over time.

Clean the door seals with warm water

and dry with a soft cloth.

After cleaning

Return all shelves and accessories.

Shut the appliance door, plug in the

appliance and turn it on with the main switch.

Turn on the SuperCool function. The

freezer section will cool down quickly.

Once the temperature is cold

enough, place the freezer baskets containing the frozen food into the freezer.

^ Turn off the SuperCool function on a

temperature of 0 °F (-18 °C) is reached.

Cleaning and care

Changing the light bulb

The lighting automatically switches off after the door has been open for approx. 5 minutes. This is not a fault.

After the bulb has cooled for a short time it will turn on again.

If the light does not come on when the door is opened briefly, the light bulb should be changed.

Use the main switch to turn the

appliance off.

To reduce the risk of electric shock, disconnect the appliance from the power supply by unplugging or tripping the circuit breaker.

Upper lighting

Remove the defective light bulb.

Place the new bulb in the socket.

Halogen bulb type: 20 W/12 V/socket GY 6.35.

^ Slip the rear of the light cover back

into position, then pull it forward and into place.

Grasp the front of the light cover with both hands, and slide it back.

Carefully pull the cover forward and out.

Never touch a halogen bulb with bare fingers. When inserting a glass halogen bulb always hold with a soft cloth.

Side lighting

Turn the light cover counterclockwise

and pull out.

Never touch a halogen bulb with bare fingers. When inserting a glass halogen bulb always hold with a soft cloth.

Cleaning and care

Pull the defective light bulb from the socket.

Place the new bulb in the socket. Halogen bulb type: 5 W/12 V/socket G 4.

Put the light cover back on and turn clockwise into place.

Restore power to the appliance.

Water filter

The Appliance is supplied with an active charcoal filter which improves the taste and smell of ice cubes by removing chlorine and other substances from the incoming tap water.

Additional water filters are available from Miele.

It is important to change the water filter regularly.

To avoid serious illness or death, do not use water that is microbiologically or chemically unsafe or of unknown quality without adequate disinfection or other treatment before or after use of a filter.

Note:

After installing a new water filter and

–

switching on the ice maker, discard the first 24 hours' worth of ice production.

If the ice maker has not been used

–

for a prolonged time discard any ice cubes in the freezer, empty the container and discard the ice production of the next 24 hours.

If the appliance or ice maker have

–

not been routinely used for several weeks or months, or if the ice cubes have an unpleasant odor, change the water filter.

Water filter change indicator

The change indicator will appear approx. every 6 months depending on the quantity of ice produced.

–

When the filter indicator lights red, this is an indication that a filter change will soon be necessary.

New water filters (Bypass and Active charcoal filters) are available from Miele.

When the filter indicator flashes red in the display the filter must be changed.

Exchanging the water filter

Note: Air trapped in the system may cause water and the filter cartridge to eject forcefully. Use caution when removing.

^ Push in and rotate the filter cap on

the base panel of your appliance counterclockwise 180°, 1.

Water filter

Remove the cap from the used filter,

Take a new filter cartridge out of the

packaging and remove the protective cap.

^ Push the cap onto the new filter

cartridge, 4.

^ Pull the used filter cartridge out of the

appliance, 2.

Push the filter cartridge with cap, in a horizontal position, all the way into the opening in the base panel, 5.

Rotate the filter cartridge clockwise 180° until the cap is in a horizontal position, 6.

Water filter

After the filter change the filter

indicator in the display still flashes. The change must be be confirmed in the electronic.

Confirming the filter change

^ Press and hold the filter change

sensor button.

^ At the same time place a finger on

the access button. Press and hold both sensor buttons for approx. 5 seconds until a beep is heard.

Using an external water filter

If your household water supply already has an external water filter installed, leave the standard water filter (bypass cartridge) installed in the appliance.

The water filter change has been confirmed and the filter change indicator had been reset.

The filter change indicator goes out.

Close the door.

After installing a new water filter discard the first 24 hours of ice production.

State of California

Department of Public Health

Water Treatment Device

Certificate Number

177506 -

Date Issued: March 10, 2006

Date Revised: April 3, 2008

rademark/ModelDesignation

9000 077095 9000 077104

Miele 07134220 07134220

Manufactur

hewatertreatment devic

T 11

6830

of th

crobiological

Cysts

Turbidity

gani

c Contaminants

None

r: Cuno, Incorporated

(s)

liste

eHeal

th and Safety Codefor thefollowinghealth relate

Contam

donthiscertificatehavemetthetestingrequirements pursuant to Section

nants and Turbidity Inorganic/Radiological

eplaceme

nt Eleme

d contaminants:

None

nts

Water filter

Contam

nants

ated Servic

Capac

Do not use where water is microbiologically unsafe or with water of unknown quality, except that systems certified for cyst reduction may be used on disinfected waters that may contain filterable cysts.

740 galsR

ty: 0.75 gpm

Cond

iti

ons of Certification:

ated Servic

eFl

ow:

Water filter

Performance Data Sheet For Filter Model 07134220

Using Replacement Cartridge 07134220

This system has been tested according to NSF/ANSI Standards 42 and 53 for the reduction of the substances listed below. The concentration of the indicated substances in water entering the system was reduced to a concentration less than or equal to the permissible limit for water leaving the system, as specified in NSF/ANSI 42 and 53.

System tested and certified by NSF International in Model 07134220 against NSF/ANSI Standard 53 for the reduction of Cysts and Turbidity and against Standard 42 for the reduction of Chlorine Taste and Odor; Nominal Particulate Class I.

To a capacity of 739.68 gallons (2800 liters).

Substance Average Inﬂuent Challenge Product Average Maximum Permissible Max. Min. % NSF Inﬂuent Concentration Water % Product Water Efﬂuent Reduction Test Concentration mg/L Concentration Reduction Concentration

Cysts* 166500 Minimum 50,000/L 1 99.99 99.95 1 99.99 516458-05

Turbidity 10.7 11 + 1 NTU 0.31 97.09 0.5 NTU 0.49 95.42 516456-05

Particulate Class I Particle size: At least 10,000 > 0.5 to < 1 um 5700000 particles/ml 30583 99.52 > 85% 69000 98.9 511079-03 Chlorine taste and odor 1.9 2.0 mg/L ± 10% 0.05 97.3 > 5 0% 0.06 96.84 511081-03

* Based on the use of Cryptosporium parvum oocysts

Application Guidelines/Water Supply Parameters

Water pressure 30- 120 psi (207 - 827 kPa)

Water temperature* 33°F - 100°F (0.6°C - 38°C)

Service ﬂow 0.75 gpm (2.83 lpm)

CAUTION: To avoid property damage due to water leakage, you MUST read and follow these operating instructions before installation and use of this

IMPORTANT: Must be installed and operated in accordance with application guidelines.

Failure to do so may void warranty. Change filter at least every 6 months.

Flush new cartridge for 3 minutes.

For estimated costs of replacement elements please visit your local appliance dealer or parts distributor.

product.

WARNING: Do not use with water that is microbiologically unsafe or of unknown quality without adequate disinfection before or after the system. Systems certified for cyst reduction may be

used on disinfected waters that may contain filterable cysts.

Note that while the testing was performed under standard laboratory conditions, actual performance may vary.

Lead free certificate

This product F 1801 Vi, F 1811 Vi (KIMSDF30US) / F 1901 Vi, F 1911 Vi (KIMSDF36US) is tested and certified by WQA against ORD0902 for California "lead free" compliance.

Miele & Cie. KG Carl-Miele-Straße 29 D-33332 Gütersloh

Frequently asked questions

With the aid of the following guide minor problems can be corrected without a ser vice call.

Repairs should only be carried out by a qualified and trained person in strict accordance with local and national safety regulations. Unauthorized repairs could cause personal injury or machine damage and may void the warranty.

Problems with temperature

Issue Possible fault Solution

The freezer does not get cold.

The machine is not turned on.

The machine is not plugged in.

Check that the fuse has not tripped.

The temperature is set incorrectly.

Check whether the appliance is turned on at the main switch. The temperature display must be lit up.

Check that the plug is correctly inserted in the power outlet.

Reset the circuit breaker.

If the breaker trips again the appliance or the outlet may be defective. Contact Miele or a qualified electrician.

Check the display.

The temperature in the freezer is too low.

The freezer is too warm.

Select a warmer temperature.

The SuperCool function is still on.

The door is not closed. Check that the door has been

A large amount of food is being frozen at the same time.

The room temperature is lower than the ambient temperature for which the appliance is designed.

See "Selecting the correct temperature".

SuperCool automatically shuts off after 52 hours.

closed properly.

This makes the compressor run longer, causing the temperature to fall automatically.

Raise the temperature of the room. Operating the appliance in a room that is too cold will cause the cooling system to switch off for too long, causing the freezer section to become too warm.

Frequently asked questions

General problems

Issue Possible fault Solution

Water is flowing out of the appliance.

The door to the freezer section will not open.

The compressor kicks on very frequently and for too long.

Close the shut-off valve immediately.

Check whether the water pipe in the appliance is defective.

Check whether the water pressure is too low.

Check whether the correct water valve has been installed.

This is not a fault. The suction caused by opening and closing the door too many times in succession prevents it from opening.

The ventilation slits are covered or dusty.

The door has been opened too frequently, or a large amount of unfrozen food has been put in at once for freezing.

Contact Miele Technical Service.

Contact a plumber.

Self-tapping valves and 3/16" (4.76 mm) saddle valves reduce the water pressure and can block the pipe.

Wait a few minutes, then try again. It should now open without force.

Clean with a vacuum or brush.

Once the freezer gets down to the set temperature the compressor will turn off.

The freezer runs continuously.

The temperature reading in the freezer shows -18°C, although a higher temperature is set.

The door is not closed. Check that the door has

been closed properly.

To save energy the compressor runs at a lower speed, but for longer when less cooling is required.

This is not abnormal. When the ice maker is in use and the temperature of the room is above freezing the temperature automatically stays at -18°C to ensure proper functioning.

Frequently asked questions

Alarm / Indicator warnings

Issue Possible fault Solution

The alarm is going off. The appliance door(s)

have been open for longer than 5 minutes.

The alarm is ringing and the "alarm" indicator is flashing.

The filter display is red. This is a warning that the

The filter display is flashing red.

The door is not closed. Once the alarm condition

A large amount of food is being frozen at the same time.

There has been a power failure.

water filter needs to be changed soon.

The water filter needs to be changed.

Close the door.

has been corrected, the alarm will turn off and the "alarm" indicator will stop flashing.

Order replacement filters from Miele.

See "Exchanging the water filter".

Frequently asked questions

Problems with the ice maker

Issue Possible fault Solution

The ice cube maker will not switch on.

The ice cube maker is not producing any ice cubes.

The appliance is not plugged in.

Check that the appliance is connected to the power supply.

When the appliance is turned on for the very first time, it can take up to 10 hours for the first ice cubes to drop out of the ice cube maker and collect in the container.

The appliance is not turned on.

The water supply line was

Check that the appliance is switched on.

Contact Miele. not primed (purged of air) before the appliance was used for the first time.

Check if: – the ice cube maker is

switched on.

See "Ice Cube Maker"

and/or "Plumbing" for more

information.

– the water supply line is

open.

– there are ice cubes

stuck together and blocking the exit.

–

the ice cube container is in the right position.

–

the freezer compartment temperature is too high.

–

the water pressure is too low. The water pressure must be between 25 and 120 psi (1.72-8.25 bar).

Check whether the correct water valve has been installed.

Self-tapping valves and

/16" (4.76 mm) saddle valves reduce the water pressure and can block the pipe.

Frequently asked questions

Problems with the ice maker

Issue Possible fault Solution

The ice cubes are small.

The ice cubes have an unpleasant odor/flavor.

Other domestic appliances that use water are in operation.

Check whether the water filter needs changing.

Check the water pressure. The water pressure must be between 25 and 120 psi (1.72-8.25 bar).

Check whether the correct water valve has been installed.

When ice is stored for an extended period it may absorb odors, which affects the taste.

Check if the ice cube container is dirty.

Unsealed packages in the freezer will transfer odor/flavor particles to the ice cubes.

Avoid using such items as a dishwasher, washing machine or shower at the same time.

See "Water filter" for more information.

Consult a plumber.

Self-tapping valves and

/16" (4.76 mm) saddle valves reduce the water pressure and can block the pipe.

Use the ice maker more frequently.

Clean the container.

Check that food has been packed in airtight containers.

Frequently asked questions

Problems with the ice maker

Issue Possible fault Solution

The ice maker is not producing enough ice or the ice cubes are misshapen.

Ice is forming in the supply hose to the ice maker.

Check the water pressure. The water pressure must be between 25 and 120 psi (1.72-8.25 bar).

Check that the freezer temperature is too high.

Change the water filter. See "Water filter".

Check the water pressure. The water pressure must be between 25 and 120 psi (1.72-8.25 bar).

Check whether the freezer compartment temperature is too high.

Contact a plumber.

See "Selecting the correct temperature".

Contact a plumber.

See "Selecting the correct temperature".

Frequently asked questions

The appliance is making noises.

Issue Possible fault Solution

Brrrrr... Humming noise made by the

compressor. This noise can get louder for brief periods when the motor is switching on.

Blubb, blubb... A gurgling noise can be heard

when coolant is circulating through the pipes.

Click... Clicking sounds are made when

the thermostat switches the compressor on and off.

Sssrrrrr... On multi-zone and frost-free

appliances you can sometimes just hear the movement of air circulating inside the appliance.

Creaking Creaking sounds can be heard

when material inside the appliance expands.

Rattling, vibrating The appliance is uneven. Realign the appliance

These noises are not a fault.

The noise of the compressor and the coolant circulating in the system is unavoidable.

using a level, by raising or lowering the screw feet underneath the appliance.

The appliance is touching another appliance or piece of furniture.

Drawers, baskets or shelves are unstable or sticking.

Bottles or containers are unstable or knocking against each other.

The transport cable clips are hanging loose at the back of the appliance.

Move it away.

Check all removable items and refit them correctly.

Separate them.

Remove the clips.

After sales service

In the event of a fault which you cannot easily fix yourself, please contact the Miele Technical Service Department at the address on the back of this booklet.

When contacting the Technical Service department, please quote the model and serial number of your appliance given on the data plate inside the appliance.

MieleCare

(USA only)

MieleCare, our Extended Service Contract program; gives you the assurance of knowing that your appliance investment is covered by 5 years of worry-free ownership. MieleCare is the only Extended Service Contract in the industry that guarantees repairs by a Miele Authorized Service Provider using genuine Miele parts. Only genuine Miele parts installed by factory-trained professionals can guarantee the safety, reliability and longevity of your Miele appliance.

Please note that unless expressly approved in writing by the Miele Service department, Extended Service Contracts offered by other providers for Miele products will not be recognized by Miele. Our goal is to prevent unauthorized (and untrained) service personnel from working on your Miele products, possibly doing further damage to them, you and/or your home.

To learn more about MieleCare Extended Service Contracts, please contact your appliance dealer or visit us online at:

http://mieleusa.com/mielecare

Installation instructions

Information is subject to change. Please refer to our website to obtain the most current product specification, technical & warranty information.

To prevent accidents and machine damage read these instructions

before

installation or use.

Caring for the environment

Disposal of packing materials

The cardboard box and packing materials are biodegradable and recyclable. Please recycle.

Ensure that any plastic wrappings, bags, etc., are disposed of safely and kept out of the reach of babies and young children. Danger of suffocation!

Disposal of an old appliance

Old appliances contain materials that can be recycled. Please contact your local recycling center about the possibility of recycling these materials.

Before discarding an old appliance, disconnect it from the electrical supply and cut off the power cord to prevent it from becoming a hazard.

Have the appliance installed by a qualified technician, according to the enclosed installation instructions.

WARNING This appliance is top-heavy and must be secured to prevent it from tipping forward. Keep the door closed until the appliance is completely installed and secured as per the installation instructions.

Installation

Installation site

The appliance should be installed in a dry, well-ventilated room.

Do not install the appliance:

- outdoors

- in an environment with dripping water

- in rooms that are at risk of frost.

The installation location should not be exposed to direct sunlight, nor near a heat source, such as an oven, radiator, etc.

Empty weight of your machine:

F 18X1 Vi ..........421lbs(191 kg)

F 19X1 Vi ..........459lbs(208 kg)

The ambient temperature should not drop below 55°F (13°C) or rise above 110°F (43°C), otherwise malfunctions may occur.

If installation next to a heat source is unavoidable observe the following minimum distances from the heat source:

–1

/4" (3 cm) from an electric cooktop

or electric oven.

–

12" (30 cm) from a gas or oil cooktop, range or oven.

Installation

Base

A fully loaded appliance is very heavy. The load-bearing capacity of your floor must meet the following requirements. The approx. weight of a fully loaded machine is:

F 18X1 Vi ..........950lbs(430 kg)

F 19X1 Vi .........1,125 lbs (510 kg)

To ensure that the appliance is installed securely and functions properly, the base must be flat, level and made of a hard, rigid material.

If in doubt, contact Miele.

Furniture/fixtures

The new appliance will be mounted securely to adjacent and overhead furniture/fixtures. For this reason, it is essential that all attachable furniture/fixtures be connected securely to the floor or wall by a suitable means.

Ventilation

The air intake and outlet must not be blocked or covered in any way. They also need to be dusted/cleaned on a regular basis.

Installation niche

To ensure safe, trouble-free installation and the best possible cosmetic result, check to be sure that the installation space complies with the installation dimensions. See "Niche dimensions".

The side walls of the installation cavity must be plumb.

The minimum thickness of the side walls and the top wall must be (16 mm).

The minimum thickness of the toe-kick panel must be ½" (13 mm). A thickness

/4" (19 mm) is recommended.

/8"

Installation

Stainless steel panels

Stainless steel door panels and toe-kick covers are available from Miele.

Custom door panels

This appliance is compatible with all styles and designs of kitchen cabinetry.

The total weight of the decorative panel(s) must not exceed the following:

F 18X1 Vi ...........106lbs(48kg)

F 19X1 Vi ............79lbs(36kg)

Fitting a door panel which is heavier than the max. permitted could damage the hinges.

Installation options

There are many different installation options. You are limited only by the design of the kitchen.

The door hinge cannot be exchanged.

Side-by-side

This appliance can be installed "side-by-side" with another fridge/freezer using a "Merging Kit".

The "Merging Kit" is available from Miele.

Contact Miele or your dealer for specific information about which combinations will work with your appliance.

For instructions on how to attach the appliances and install the heating mat, please refer to the instructions included with the "Merging Kit", available from Miele.

Installation without a partition using the "Merging Kit"

Single column

The appliance can be installed at any preferred location in the kitchen.

However, be sure the door will open and close properly in the chosen location.

If the appliances are installed directly next to each other (without a partition), they need to be attached together using the "Merging Kit".

Installation

Installation with partition using the "Merging Kit"

The minimum thickness of the partition

/8" (16 mm).

If there is a partition with a thickness

from

/8" (16 mm) to 65/16" (160 mm)

between the adjacent appliances, then each appliance should be individually installed within its own niche using the mounting accessories included. The "Merging Kit" will also be needed.

Side panels

If one side of the appliance is visible, a side panel must be used.

The side panel must be firmly secured to the wall, the floor and the overhead furniture/fixtures before the appliance is placed in the cavity.

The dimensions of the side panel are taken from the opposite wall of the installation space. During installation, ensure that the cavity is square and the measurements are correct.

The "Merging Kit" is available from Miele.

Installation with partition without using the "Merging Kit"

If there is a partition with a thickness of

more than 6

/16" (160 mm) between

the adjacent appliances, then each appliance should be individually installed within its own niche using the mounting accessories included (the "Merging Kit" is not necessary).

Front panel gap kit (optional accessory)

Two adjacent doors can be attached instead of one large door.

To connect these doors on the rear, a metal strip can be purchased as an optional accessory. Contact Miele.

Installation

When attaching the metal strip to the furniture doors, observe the maximum length of the screws and the position of the drill holes. Always screw into the best possible load-bearing material of the custom doors.

Dimensions

Door dimensions (open 115°)

ABCD

F 18X1 Vi 32

F 19X1 Vi 38

/8"

(829 mm)

/16"

(982 mm)

Door front max.

1 1/2" (38 mm)

Door front max.

1 1/2" (38 mm)

Door handle*

145/16" (363 mm)

167/8" (428 mm)

*The dimensions of the door fronts and handles will vary according to each individual kitchen.

Miele recommends using the full door opening angle of 115° for this freezer.

Niche dimensions

Dimensions

Niche width (A)

F 18X1 Vi 30" (762 mm)

F 19X1 Vi 36" (915 mm)

Dimensions

Power supply and water connection

F 18X1 Vi 15" (381 mm)

F 19X1 Vi 18" (458 mm)

Door front dimensions

1. Power supply

2. Water connecti

F 18X1 Vi 79

F 19X1 Vi 79

4" - 5 3/16" (102 - 132 mm)

/8"

2029 mm

/8"

2029 mm

293/4" 756 mm

353/4" 908 mm

Before you begin

Read these instructions completely and carefully. Have the appliance installed by a qualified technician, according to the enclosed installation instructions.

To reduce the risk of injury or damage to the product, two people should be used for installation.

Installing the appliance

Level

–

Tape measure

–

Square

–

When fastening the cabinet to the wall behind it (see "Installing the appliance") use:

suitable plugs/screws depending on

–

the type of wall.

several mounting brackets, if

–

required.

These installation instructions are intended for use by qualified installers. In addition to these instructions, the appliance must be installed in accordance with all local codes. In the absence of a local code, the following should be used:

– In the USA, the National Electric

Code, ANSI/NFPA 70 - latest edition/State and Municipal codes and/or local codes.

–

In Canada, the Canadian Electric code C22.1 - latest edition/Provincial and Municipal codes and/or local codes.

Tools needed for installation

–

Cordless screwdriver

–

Torx screwdriver

–

Hammer drill

–

Wood drills in different sizes

Other

– Stepladder

– Dolly, hand truck

– Wooden beam

(cross section min. 3" x 4" [75 mm x 100 mm] as an alternative tilt protection, length depends on the width of the installation cavity)

– Wood screws in different sizes

Optional accessories

–

"Merging Kit" for side-by-side installation

–

Front panel gap kit

–

RemoteVision module for wireless monitoring

–

Hammer

–

rachet 5/16" (8 mm)

–

Adhesive tape

–

Multi-grip pliers

Installing the appliance

Aligning the housing unit

The housing unit must be carefully aligned using a spirit level before installing the appliance. The unit corners must be at right angles, as otherwise the furniture door will not align correctly with the 4 corners of the appliance.

Check the installation niche

To ensure a safe, trouble-free installation and the best possible cosmetic result, check to be sure that the installation space complies with the installation requirements.

Check the base (see "Installation").

Check the dimensions of the cavity.

Check that the cavity is square.

Check the location of the power

outlet.

^ Check the location of the water

connection (see "Plumbing").

^ Check that all furniture parts in the

vicinity of the appliance are securely connected to the wall.

^ Check that the adjacent

furniture/fixtures do not collide with the open door.

–

The side panels of the housing must be even.

–

The housing unit panels must be at least 16 mm thick.

–

The plinth facing must be at least 13 mm thick (or preferably 19 mm).

Before installation

Caution - the appliance is very heavy. Use caution when unpacking and opening the door, danger of tipping.

To protect the base from damage during installation, attach a hard board, linoleum, etc., to the floor in front of the intended installation location.

Take the supplied accessories out of the protective packaging.

Installing the appliance

From the rear of the appliance

carefully lift it from the pallet.

Once the appliance is on the ground it can be wheeled around.

RemoteVision module installation

Do not remove the installation

supports from the appliance door. They will be used later in the installation niche.

There are transportation safety devices inside the appliance to protect the shelves and storage compartments until installation is complete. Do not remove them,or parts may be damaged.

^ Check the appliance for damage in

transit.

Do not install the appliance if it is visibly damaged. If in doubt, contact your dealer.

(optional accessory)

Always disconnect the appliance from the power supply when performing installation, maintenance or service work. Install the RemoteVision module before placing the appliance in its installation niche. Once connected the RemoteVision module will increase the energy consumption of the appliance.

The slot for the RemoteVision module is located in the lower area of the back of your appliance.

Loosen the bracket that holds the appliance to the pallet.

Caution! The appliance is no

longer secured and may be unstable.

Unscrew the screws a on the cover b and pull off the sticker c.

Remove the cover b.

Installing the appliance

Push the module into the slot until it

locks into place.

Connect the appliance to the power

supply and turn it on. After several seconds the indicator light e will come on.

The indicator light will display different colors one after the other; any control light at the end indicates that the module was correctly installed.

Pull the antenna d straight out.

Guide the cover b over the antenna

d and screw on the cover.

^ Angle the antenna d so that it faces

to the right or left.

If necessary, disconnect the power supply and continue installing the appliance.

If the indicator light does not come on, installation of the module was unsuccessful. In that case, repeat the process. If that does not correct the problem, contact Miele.

Preparing the installation niche

Keep the appliance door closed until it is securely fastened in the niche. Tipping hazard.

Because of the size and weight of the appliance, it is essential to ensure that the appliance cannot tip over once it has been mounted in the niche.

Mounting Accessories

The mounting accessories needed for installing the appliance into the niche are included in the packaging. Several plastic bags are included which are marked alphabetically.

The bag needed for each step will be marked with its respective letter.

Use the included Torx screwdriver to

tighten the screws.

Anti-tip brackets

The anti-tip brackets help keep the appliance safely secured to the installation niche to prevent tipping.

Two anti-tip brackets are recommended for each appliance or appliance combination (side-by-side).

Installing the appliance

The distance "D" between the anti-tip brackets b is the width of the appliance.

Position the anti-tip brackets b on

the left and right walls of the appliance niche.

^ Mark the holes through the anti-tip

brackets b on the floor of the installation niche.

^ Set the brackets aside - they will be

needed later.

If the installation niche is deeper than the appliance, a solid wooden beam a can be placed behind the anti-tip brackets b so the appliance can be securely attached to the base or wall.

The length of the wooden beam a should be the width of the installation space.

Screws are supplied with the appliance for various applications/materials.

If the anti-tip brackets cannot be attached securely with the screws supplied, an alternative anti-tip device can be used.

Assure that there are no electrical wires or plumbing in the area which the screws could penetrate - risk of injury and damage.

Installing the appliance

Drill pilot holes:

/8"(3mm)for5x60mmwood

–

screws

/16"(2mm)for4x15mmwood

–

screws

^ Tightly secure the anti-tip brackets in

the niche.

Be certain that the screws penetrate through the flooring and into the wall plate a minimum of

/4" (19 mm).

In a cabinet with a back wall

^ screw the back wall of the cabinet in

several places directly to the wall behind it. For this, use suitable plugs/screws depending on the type of wall.

In a cabinet without a back wall

If the included anti-tip brackets cannot be secured in the niche, the built-in

cabinet must be secured to the wall behind it with several screws. Only in this way can the appliance later secured in the built-in cabinet be prevented from tipping.

screw the cabinet to the wall behind it in several places using suitable mounting brackets. For this, use suitable plugs/screws depending on the type of wall.

Installing the appliance

Securing an alternative anti-tip device

If the anti-tip brackets cannot be attached securely, an alternative anti-tip device can be used. Ensure that there is no "give" between the appliance and the anti-tip device.

If possible, always screw the wooden beam to existing studs.

The beam must cover the appliance

–

by at least 2" (50.8 mm).

Mark the installation height (lower

edge of the beam) on the rear wall of the niche.

Select screws according to the

thickness of the wooden beam. Example: 3 ½" screw for 2x4 beam.

Determine the number of screws based on the niche width, to ensure that the beam will be attached securely.

^ Locate wall studs near the rear wall

of the cavity and mark drill holes in the beam.

^ Pre-drill the wooden beam.

^ Attach the wooden beam to the rear

wall of the niche.

Now prepare the water connection from the appliance to the main supply line (see "Plumbing").

–

Cut a wooden beam (cross section min. 3" x 4" [75 mm x 100 mm]) to the required length.

–

The length is equal to the width of the installation niche.

–

If the installation niche is deeper than the appliance, select a beam with a larger cross section, or attach two beams.

Installing the appliance

Sliding the appliance into the installation niche

If a side-by-side installation is desired, connect the two appliances together. See the Installation Manual included with the "Merging Kit".

^ Unscrew the plinth.

Plug the appliance into the power

outlet b.

The plug of the appliance should be easily accessible after installation. If the plug is not accessible after the appliance has been installed, disconnection from the power supply should be completed via the circuit breaker.

In the case of side-by-side installations, a separate outlet must be used for each appliance.

^ To prevent the power cord from

becoming caught: Tie a piece of string to the middle of the power cord and feed it forward under the appliance. When sliding the appliance in, pull the cable forward c.

^ Carefully slide the appliance into the

space until the height-adjustable wheels interlock with the anti-tip brackets d.

To protect the corners of the installation space, attach the supplied edge protector a on both sides with adhesive tape.

If resistance is felt when attempting to slide the appliance into the installation niche - for example, because the floor is uneven,

Turn the rear adjustable wheels slightly outward (see "Aligning the appliance"), then push the appliance in.

Be careful not to damage the water pipe or power cord attached to the floor.

Remove the edge protector a.

Aligning the appliance

Align the appliance with the custom

front.

The installation aids e on the appliance door have been designed for custom door thicknesses of 3/4" (19 mm) and 1 1/2" (38 mm).

Installing the appliance

Important! When unscrewing the height-adjustable feet, proceed gradually, alternating between left and right.

Unscrew the height-adjustable feet

–

until the mark on the base has reached the indicated guide dimension 1 1/4" (32 mm). The guide dimension of 1 1/4" (32 mm) is related to a niche height of 84" (2134 mm).

The height-adjustable feet at the front and rear can all be adjusted from the front:

–

Front feet: Adjust with a rachet 5/16" (8 mm) f.

–

Rear feet: Adjust with a (cordless) screwdriver and/or a rachet 5/16" (8 mm) for fine adjustment g

Use a level to align the installation aids e on the door.

Align the appliance again using a level.

Note:

–

When unscrewing the height-adjustable feet, proceed gradually, alternating between left and right.

–

If using a wooden beam as an alternative anti-tip device, rotate the appliance all the way toward the wooden beam.

Installing the appliance

Attaching the appliance to the installation niche

Secure the attachment plate side

lugs.

^ Screw the attachment plate lugs h to

the overhead furniture/fixtures.

If there is no way to attach the top of the appliance, it can be attached to the sides of the installation niche.

Pull out the plate side lugs i.

If there is a fairly large gap above the appliance, cut a wooden beam to fit exactly and place it in the gap.

^ If necessary, shorten the filler strip j

to the required height.

Place the 2 strips on top of each other k.

Insert the filler strip until you hear it click into place l.

Installing the appliance

For a side-by-side combination the filler strips from both appliances are put together to form one long filler strip:

Take the peg from the "Side-by-side

Merging Kit" and insert it halfway into the filler strip rail on the left-side appliance.

^ Place the second filler strip on the

peg and press both filler strips together.

^ Insert both filler strips into the

installation space above the appliance, until they click into place.

Open the appliance door.

^ Screw the attachment plate lugs m to

the adjacent furniture/fixtures.

With side-by-side combinations, only the external side of the appliances can be secured to the niche.

Now connect the water supply to the appliance (see "Plumbing").

Installing the appliance

Preparing the custom door

Open the appliance door.

Unscrew the installation supports n

from the appliance door.

^ Loosen the remaining screws from

the strips o on each side of the door, then remove.

^ Set aside the screws and side strips

o - you will need them again later.

^ Remove the light switch cover (see

arrow).

Close the appliance door.

^ Measure the distance X between the

bracket from the door and the overhead furniture/fixtures.

^ Loosen the two nuts.

Set aside the nuts - you will need them again later.

^ With the inside facing up, lay the

custom door on a stable surface (to avoid scratch marks, place some plastic or a cloth on the surface).

Installing the appliance

^ Mark the distance X on the back-side

of the custom door.

^ Also calculate and mark the center of

the custom door Y.

^ Remove the mounting frame from the

appliance door and position it according to the markings on the custom door.

Pre-drill the holes.

Tightly screw on the bracket using the pre-drilled holes: Attach the bracket to each attachment point with at least one screw.

Attach the bracket at the top with at least 10 screws.

Please note: When attaching the mounting frame onto two adjacent doors (see "Front panel gap kit") screw into the thicker outer frames of the doors only.

The bracket includes a variety of holes for the various design options of custom doors.

When performing work on the custom door, always observe the following:

–

Always select the best load-bearing surface of the custom door as the location for screws.

–

Always select a screw length that is shorter than the thickness of the door front.

Secure the door handle to the front of the appliance from the inside.

Installing the appliance

Attaching and aligning the custom door front

^ Open the door and hang the custom

door with the mounting frame over the threaded bolts p.

Align the custom door height with the

threaded bolts p.

Now tighten the nuts q on top. This

secures the appliance door.

^ Put the side strips o back into place

and screw them completely down on both sides of the appliance door. Bag E contains spare screws for this purpose.

Screw the nuts q a few turns onto the threaded bolts p. Do not tighten the nuts completely.

Close the appliance door and check the distance to doors of adjacent furniture/fixtures.

Installing the appliance

Attaching the fixing brackets

(Only for appliances using the "Front panel gap kit".)

The fixing brackets are used to secure the custom door front to the bottom of the appliance door.

^ Open the appliance door all the way.

Attaching the covers

^ To mount the cover strips on both

sides of the door, click them into place from bottom to top, into the gap between the appliance door and the custom door.

^ Slightly loosen the screw (1.).

Position the fixing bracket on the appliance door (2.) and pre-drill a hole in the custom door front.

Screw the fixing bracket securely to the custom door front (3.).

Tighten the screw (4.).

Put the cover on the bracket (5.).

The number of lower brackets will depend on the width and the design of the custom door.

Screw the brackets onto both sides of the appliance, to hold the cover strip.

Installing the appliance

^ Insert the cover strip into the space

between the appliance and the side panel. For side-by-side combinations, the cover strips (on both sides of the appliance) are applied to the outermost spaces only.

Attaching the toe-kick cover

The maximum height of the toe-kick cover is 4" from the top of the floor. Do not cover the ventilation slits in the plinth. Risk of damage to the appliance.

If required, cut the toe-kick cover to

the required length and height.

Attach the light switch cover.

Attach the plinth to the appliance, and put the included cover plates in place.

Attach the toe-kick cover to the plinth.

Mounting the air separator

The air separator keeps the supply and exhaust air separate. This prevents warm exhaust air from flowing into the machine, optimizing the energy performance of the unit.

Installing the appliance

^ Position the air separator in the

center of the appliance door.

^ From below, screw the air separator

firmly onto the door with the 2 screws.

^ If necessary, shorten the three parts

of the air separator.

Insert the foam pieces back into the sides.

Plumbing

All plumbing work should be carried out by a suitably qualified and competent person, in accordance with all applicable local and national regulations.

The water quality must conform to country requirements for drinking water.

The appliance is only suitable for

–

connection to the cold water supply.

– The water pressure must be between

25 and 120 psi (1.72-8.25 bar).

– A separate shut-off valve must be

installed, so that the water supply can be interrupted as needed.

– The maximum outer diameter of the

water pipe (without fittings):

/8" (10 mm).

The shut-off valve for the water connection must not be located behind the appliance. It is recommended to place the shut-off valve directly next to the appliance (base unit) or in another easily accessible location.

Plumbing

Preparing the water connection

The connection to the household water supply must be installed before the appliance is installed.

Turn off the main water valve to prevent

damage caused by leaking water.

Attach the connecting pipe to the

shut-off valve, according to the instructions supplied by the manufacturer of the ice cube maker installation kit.

Install the connecting pipe. Always

observe the indicated clearance dimensions to prevent damage to the connecting pipe when pushing in the appliance.

For appliances with a hose guide

position the device in front of the

niche and push the stainless steel tube through the hose guide at the back of the unit.

At this point the niche should be ready for the appliance to be pushed back into it (see "Installing the appliance").

^ You can now continue with the

installation.

Secure the connecting pipe to the floor with adhesive tape.

You may now proceed to install the appliance. See "Installing the appliance".

Plumbing

Connecting the water supply

When connecting the water pipe to the solenoid valve of the appliance, follow the instructions supplied by the manufacturer of the ice cube maker installation kit.

When bending the water pipe, be sure not to kink it, otherwise there is a risk of leaks and water damage. Use bending aids.

Push the union nut and seal onto the

water pipe.

Push the end of the water pipe into

the appliance connection and screw on the union nut, 3. First tighten by hand.

Then use an open-ended wrench to

tighten the union nut. Do not over tighten.

Open the shut-off valve and the main

water connection. Check for leaks at the connection for the shut-off valve and to the appliance.

^ Switch the appliance on.

After a maximum of 10 hours the first ice cubes will drop out of the ice cube maker and collect in the ice cube container.

Remove the cap from the appliance connection, 1.

Bend the water pipe to suit the location of the connection on the appliance, 2.

Avoid the risk of electrical

shock

- Plug into a grounded 3-prong outlet.

- Do not move the ground plug.

- Do not use an adapter.

- Do not use an extension cord.

Failure to follow these instructions can result in death, fire, or electrical shock.

Improper connection of the equipment grounding conductor may result in electric shock. If you are in any doubt as to whether the appliance has been properly grounded, have the appliance checked by a qualified electrician or service technician.

Installation, repairs and other work by unqualified persons could be dangerous.

Electrical connection

The appliance is supplied with a UL-listed, 3-wire power cord and NEMA 5-15 P plug ready for connection to a 120 V, 60 Hz supply. The fuse rating is 15 amps.

The appliance requires a 3-wire receptacle. The receptacle must be installed by a licensed electrician only.

In the case of side-by-side installations, a separate outlet must be used for each appliance. Ideally, the power outlet should be next to the appliance and easily accessible. Do not connect the appliance to the power supply by an extension cord. Extension cords do not guarantee the required safety of the appliance (danger of overheating).

If any changes are needed to the household wiring or power supply, this work must be performed by a qualified electrician.

Before installing the appliance, verify that the voltage, load and circuit rating information found on the data plate match the household electrical supply.

If there are any questions regarding the electrical connection of this appliance to the power supply, please consult a licensed electrician or call the Miele Technical Service.

U1-800-999-1360

V1-800-565-6435

RemoteVision (optional accessory)

Miele's RemoteVision Wi-Fi technology creates a 'virtual link' between your appliance and our monitoring center. If a fault occurs, Miele's client service center will be notified and contact you, or another trusted individual identified on your call roster, in order to gain access to your appliance to fix the problem.

For information on set-up and installation of the RemoteVision module see the "Installation" section of this manual.

Be sure your wireless system meets the following requirements

A wireless router that supports an

–

IEEE 802.11b protocol

Windows XP

–

system, Mac

Cable or DSL modem

–

Microsoft

–

or newer operating

OS X 10.3 or higher

Internet Explorer 6 or

higher, Safari 2.0 or higher, Firefox

1.5 or higher

* Please note that each wireless router manufacturer supplies their own device drivers and setup programs. Due to the differences in manufacturers, exact router setup instructions are not included in this manual. Wording and instructions may vary.

RemoteVision (optional accessory)

Accessing the RemoteVision control panel

Touch the access button "p"soit

turns yellow.

Note the position of the X button, but

do not touch.

Touch the access button "p" again so

it turns white.

Only the access button "p" is visible.

^ Place one finger on the position of

the X button and hold (the X button will not be visible).

^ While holding down the X button,

press the access button "p" once. Keep holding the X button down until the following appears in the display (approx. 5 seconds).

Tap the X button until ; appears in

the display.

Touch the access button "p"to

confirm.

See the table on the following page for a description of each setting in the display.

Use the Y or X buttons to select the

RemoteVision options.

The module has been connected to the network when ; # appears in the display. If ; # does not appear, refer to the "Network options" section of the XKM 2000 Installation Instruction manual.

^ Press and hold the access button "p"

for 2 seconds to confirm the change.

^ To return to the main menu, tap the X

button until a solid ; - appears in the display.

Access to the Custom settings mode is now active for approximately 10 seconds.

Press the access button "p"to confirm.

Tap the X button until a ; appears in the display.

Touch the access button "p".

You have left the Custom settings mode.

When you are in the Custom settings mode the door alarm is turned off automatically. Once the door is closed it is reactivated.

RemoteVision (optional accessory)

MasterCool control panel options for RemoteVision

Status indicators Description of function

Flashing ; ~ Module booting phase

Flashing ; ‡ Not connected to network

Flashing ; | Connection to network established, no IP address

assigned

Solid ; # Connected to network

Flashing ;< In Ad-Hoc Mode, not connected

Flashing ;= In Ad-Hoc Mode, connected

Selectable

options

; - Back

; 2 Reboot the module

; 3 Reset to factory settings

; 4 Enter Ad-Hoc Mode

Note: If you cannot select any option (other than ; - "Back", the module has not been installed correctly.

Description of function

Alteration rights reserved / 3712

INFORMATION IS SUBJECT TO CHANGE. PLEASE REFER TO OUR WEBSITE TO OBTAIN THE MOST CURRENT PRODUCT SPECIFICATIONS, TECHNICAL & WARRANTY INFORMATION.

M.-Nr. 09 168 930 / 03

Miele F 1801 Vi, F 1811 Vi, F 1911 Vi, F 1901 Vi User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
