Operating and installation instructions
Freezer
F 1313 S
To avoid the risk of accidents or
damage to the appliance, it is
essential to read these operating instructions
before it is installed or used for the
first time.
G
M.-Nr. 06 154 980
Description of the appliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Optional accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Thermometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Caring for the environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Warning and Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
How to save energy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Switching on and off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Switching off for longer periods of time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
The correct temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Temperature selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Temperature alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Switching on the alarm system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Super freeze . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Freezing fresh food . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Super freeze. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Freezing and storing food. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Maximum freezing capacity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Storing frozen food. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Home freezing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Hints on home freezing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Packing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Before placing food in the freezer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Placing food in the freezer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Defrosting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Cooling drinks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Defrosting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Cleaning the outer casing, the interior and accessories . . . . . . . . . . . . . . . . . . . . 22
Ventilation gaps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Door seal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Metal grille at the back of the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Problem solving guide . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Noises . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Service Department . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Electrical connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Contents
Electrical connection U.K. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Climate range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Ventilation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Aligning the appliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Changing the door hinging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Contents
a In-operation indicator light
b Alarm indicator light
e Freezer drawers
c Super freeze button and indicator
light
d On/Off and temperature selector dial
Description of the appliance
4
Optional accessories
Thermometer
The thermometer can be used for
checking the temperature inside the
freezer.
It is available from the Miele Spare
Parts Department or from your dealer.
Description of the appliance
5
Disposal of the packing
material
The transport and protective packing
has been selected from materials which
are environmentally friendly for
disposal, and can normally be
recycled.
Ensure that any plastic wrappings,
bags etc. are disposed of safely and
kept out of the reach of babies and
young children. Danger of suffocation!
Rather than just throwing these
materials away, please ensure that they
are recycled.
Disposal of your old appliance
Please ensure that the appliance
presents no danger to children while
being stored for disposal.
It should be unplugged or
disconnected from the mains electricity
supply by a competent person. The
plug must be rendered useless and the
cable cut off directly behind the
appliance to prevent misuse. See the
"Warning and Safety" section of this
booklet for further details.
Electrical and electronic appliances
often contain materials which, if
handled or disposed of incorrectly,
could be potentially hazardous to
human health and to the environment.
They are, however, essential for the
correct functioning of your appliance.
Please dispose of your old appliance at
your local community waste collection /
recycling centre and not with your
household waste.
Take care not to damage the pipework
at the back of it before or during
transportation to an authorised
collection depot.
In this way, refrigerant in the pipework
and oil in the compressor will be
contained, and will not leak out into the
environment.
Caring for the environment
6
This appliance complies with all
relevant legal safety requirements.
Improper use can, however, present
a risk of both personal injury and
material damage.
To avoid the risk of accidents and
damage to the appliance, read the
operating instructions carefully
before installation and before using
for the first time. They contain
important notes on the installation,
safety, operation and care of the
appliance.
Keep these operating instructions in
a safe place and pass them on to
any future user.
Correct use
This appliance is intended for
domestic use only, to store deep
frozen food, freeze fresh food, and to
make ice.
Any other usage is not supported by
the manufacturer and could be
dangerous. The manufacturer cannot
be held liable for damage caused by
incorrect or improper use of the
appliance.
This appliance is not a toy! To avoid
the risk of injury, do not allow
children to play on or near it, or to
play with the controls. Supervise its
use by the elderly or infirm.
Technical safety
This appliance contains the coolant
Isobutane (R600a), a natural gas
which is environmentally friendly.
Although it is flammable, it does not
damage the ozone layer and does not
increase the greenhouse effect. The
use of this coolant has, however, led to
a slight increase in the noise level of the
appliance. In addition to the noise of
the compressor, you might be able to
hear the coolant flowing around the
system. This is unavoidable, but does
not have any adverse effect on the
performance of the appliance.
Care must be taken during the
transportation and installation of the
appliance that no parts of the cooling
system are damaged. Leaking coolant
can damage the eyes.
In the event of any damage:
- avoid open fires and anything which
creates a spark,
- disconnect from the mains,
- air the room in which the appliance is
located for several minutes and
- contact the Service Department for
advice.
The more coolant there is in an
appliance, the larger the room it
should be installed in. In the event of a
leakage, if the appliance is in a small
room, there is the danger of
combustible gases building up.
For every 8 g of coolant at least 1 m
3
of
room space is required. The amount of
coolant in the appliance is stated on the
data plate inside the appliance.
Warning and Safety instructions
7
Before connecting the appliance to
the mains supply, make sure that
the rating on the data plate
corresponds to the voltage and
frequency of the household supply.
This data must correspond in order to
avoid the risk of damage to the
appliance. Consult a qualified
electrician if in any doubt.
The electrical safety of this
appliance can only be guaranteed
when continuity is complete between
the appliance and an effective earthing
system, which complies with local and
national safety regulations. It is most
important that this basic safety
requirement is present and regularly
tested. Where there is any doubt, the
household wiring system should be
inspected by a qualified electrician.
The manufacturer cannot be held liable
for the consequences of an inadequate
earthing system (e.g. electric shock).
Safe operation of the appliance is
only assured if it has been installed
and connected in accordance with
these operating and installation
instructions.
This equipment may only be used
in mobile installations such as
ships, caravans, aircraft etc. if a risk
assessment of the installation has been
carried out by a suitably qualified
engineer.
Installation work, maintenance and
repairs may only be carried out by
suitably qualified and competent
persons in accordance with national
and local safety regulations.
Repairs and other work by unqualified
persons could be dangerous and the
manufacturer will not be held liable.
Ensure current is not supplied to the
appliance while maintenance or repair
work is being carried out.
The appliance is only completely
isolated from the electricity supply
when:
– it has been switched off at the socket
and the plug has been withdrawn.
– the mains fuse is withdrawn, or
– the screw-out fuse is removed (in
countries where this is applicable).
Do not connect the appliance to
the mains electricity supply by an
extension lead.
Extension leads do not guarantee the
required safety of the appliance (e.g.
danger of overheating).
Warning and Safety instructions
8
Use
Never handle frozen food with wet
hands. Your hands may freeze to
the frozen food. Danger of frost burn.
Do not take ice cubes out with your
bare hands and never place ice
cubes or ice lollies in your mouth
straight from the freezer.
The very low temperature of the frozen
ice or lollies can cause frost burn to the
lips and tongue.
Do not allow children to play with
the appliance, for example to climb
inside the drawers or to swing on the
door.
Do not refreeze thawed or partially
thawed food.
Defrosted food should be used up as
quickly as possible, as food soon loses
it nutritional value and goes off.
Defrosted food may only be re-frozen
after it has been cooked.
Storage times will depend on
several factors, including the
freshness and quality of the food as
well as the temperature at which it is
stored. To avoid the risk of food
poisoning, follow the instructions given
on the food manufacturer's packaging
on the storage conditions required, as
well as the "use by" date.
Do not store explosive materials in
the appliance or any products
containing propellants (e.g. spray
cans). Thermostats switching on may
produce sparks which could present a
fire hazard. Flammable compounds
could explode.
Do not store cans or bottles
containing carbonated drinks or
liquids which could freeze in the
freezer. The cans or bottles could
explode.
Danger of injury and damage to the
appliance.
When cooling drinks quickly in the
freezer, make sure bottles are not
left in for more than one hour, otherwise
they could burst. This could result in
injury or damage.
Do not use sharp edged objects to
– remove frost and ice,
– separate frozen foods or remove ice
trays. They will damage the
evaporator, causing irreversible
damage to the appliance.
Do not use any oils or grease on
the door seals, as these will cause
the seals to deteriorate and become
porous with time.
Do not block the ventilation gaps in
the appliance as this would impair
the efficiency of the appliance, increase
the electricity consumption and could
cause damage to the appliance.
Warning and Safety instructions
9
The appliance is designed for use
within certain climate ranges
(ambient temperatures), and should not
be used outside this range. The climate
range for your appliance is stated on
the data plate inside the appliance.
Installing it in a room with too low an
ambient temperature, e.g. a garage,
will lead to the appliance switching off
for longer periods so that it cannot
maintain the required temperature.
Never place electric heaters or
candles in the appliance to defrost
it. These can damage the plastic parts.
Do not use defrosting sprays or
de-icers, as they might contain
substances which could damage the
plastic parts or which could cause a
build-up of gases and pose a danger to
health.
Never use a steam-cleaning
appliance to defrost or clean this
appliance. Pressurised steam could
reach the electrical components and
cause a short circuit.
In countries where there are areas
which may be subject to infestation
by cockroaches or other vermin, pay
particular attention to keeping the
appliance and its surroundings in a
clean condition at all times. Any
damage which may be caused by
cockroaches or other vermin will not be
covered by the guarantee.
Disposal of your old appliance
Before disposing of an old
appliance, first make the door latch
or lock unusable. This way you will
prevent children from accidentally
locking themselves in and endangering
their lives.
Disconnect it from the mains. Cut
off the cable and render any plug
unusable.
Be careful not to damage any part
of the pipework whilst awaiting
disposal, e.g. by
– puncturing the refrigerant channels
in the evaporator.
– bending any pipework.
– scratching the surface coating.
Splashes of refrigerant can damage the
eyes.
The manufacturer cannot be held
liable for damage caused by
non-compliance with these Warning
and Safety instructions.
Warning and Safety instructions
10
normal energy
consumption
increased energy
consumption
Installation In a ventilated room. In an enclosed, unventilated room.
Protected from direct sunlight. In direct sunlight.
Not situated near to a heat source
(radiator, oven).
Situated near to a heat source
(radiator, oven).
Where the ambient room
temperature is ideal at approx.
20 °C.
Where there is a high ambient room
temperature.
Temperature setting with
a thermostat which is
approximate
(set in stages).
With a medium setting of 2 to 3. With a high setting: The lower the
compartment temperature, the
higher the energy consumption.
Temperature setting with
a thermostat which is
exact to the degree
(digital display).
Cellar section 8 to 12 °C
On appliances with winter setting,
please make sure that the winter
setting is switched off when the
ambient temperature is warmer
than 16 °C.
Refrigerator section 4 to 5 °C
StayFresh zone approx. 0 °C
Freezer section -18 °C
Use Only open the door when
necessary and for as short a time
as possible.
Frequent opening of the door for
long periods will cause a loss of
coldness.
Store food in an organised way. If food is not stored in an organised
way, searching for an item will
mean the door is open for longer.
Allow hot food and drinks to cool
down before placing them in the
appliance.
Placing hot food in the appliance
will cause the compressor to run for
a long time, as the appliance will
have to work harder to lower the
temperature.
Store food covered or packaged. The evaporation or condensation of
liquids will cause a loss of coldness
in the refrigerator.
Place frozen food in the refrigerator
to defrost.
Do not over-fill the sections to allow
air to circulate.
Defrosting Defrost the freezer section when a
layer of ice one centimetre thick
has built up.
A layer of ice hinders the cold from
reaching the frozen food, and
causes an increase in energy
consumption.
How to save energy
11
Before using for the first time
^
Clean the inside of the appliance and
the accessories with warm water and
a little washing up liquid, and then
dry with a soft cloth.
Important:
To ensure the correct functioning of
the appliance, let it stand for
between ½ and 1 hour after
transporting it to its final location
before connecting it to the mains.
Switching on
^ Using a coin, turn the On-Off /
Temperature dial in a clockwise
direction away from the "0" position.
The higher the setting, the lower the
temperature in the appliance.
Forcing it beyond its range will
damage it. Turn it only as far as it will
go, then turn it back again.
The "in operation" and the alarm
indicator lights come on, and the
appliance starts cooling.
Allow the appliance to run for a few
hours before placing food in it. This will
ensure that the temperature is
sufficiently low.
Switching off
^
Using a coin, turn the On-Off /
Temperature dial in an anti-clockwise
direction back to the "0" position.
All indicator lights go out and the
cooling process is switched off.
Switching off for longer
periods of time
If the appliance is not going to be used
for a longer period of time, e.g. whilst
on holiday,
^ switch the appliance off at the mains,
^ withdraw the plug (pull on the plug
and not the cable),
^ defrost and clean the appliance out
and
^ leave the door ajar to air the
appliance.
If, during a long absence, the
appliance is switched off but not
cleaned out and the door is left shut,
mould and odours are likely to build
up inside the appliance.
Switching on and off
12
It is very important to set the correct
temperature for storing food in the
appliance. Micro-organisms will cause
food which is not stored at the correct
temperature to deteriorate rapidly.
Temperature influences the growth rate
of these micro-organisms. Reducing
the temperature reduces their growth
rate.
To freeze fresh food and to store frozen
food for a long time, a temperature of at
least -18 °C is required. At this
temperature the growth of
micro-organisms is generally halted. As
soon as the temperature rises to above
-10 °C, the micro-organisms become
active in the food again so that it cannot
be kept as long. For this reason,
partially defrosted or defrosted food
must not be re-frozen. Food may be
re-frozen once it has been cooked as
the high temperatures achieved when
cooking destroy most micro-organisms.
The temperature in the appliance will
rise:
–
the more often the door is opened
and the longer it is kept open,
–
if too much food is stored in it at
once,
–
the warmer the food is which is being
put into it,
–
the higher the ambient temperature
surrounding the appliance.
The appliance is designed for use in
specific ambient temperatures
(climate ranges). Do not use in
ambient temperatures for which it is
not designed.
Temperature selection
The temperature is set with the
temperature dial.
^ Use a coin to turn the temperature
dial clockwise to the required setting.
Forcing it beyond its range will
damage it. Turn it only as far as it will
go, then turn it back again.
The higher the setting, the lower the
temperature in the appliance.
In normal use, a midway setting is
generally sufficient. You should also
check the temperature inside the
appliance from time to time.
The correct temperature
13
Your appliance has been fitted with a
warning system which ensures that the
temperature in the freezer cannot rise
unnoticed. The alarm indicator light will
come on if the temperature becomes
too warm. The temperature dial
determines the range of temperatures
the appliance recognises as too warm.
The alarm indicator light will come on
–
when the freezer is switched on.
–
if the door has been left open for a
while, e.g. in order to load, to
re-arrange or to take food out.
– when freezing large amounts of food
at once.
– when there has been a lengthy
interruption to the power supply.
The alarm indicator light goes out as
soon as the freezer has reached the
programmed-in temperature range.
Switching on the alarm system
The warning system is always active.
It does not have to be switched on
manually.
Temperature alarm
14
Freezing fresh food
Fresh food should be frozen as quickly
as possible. This way the nutritional
value of the food, its vitamin content,
appearance and taste are not impaired.
Food which takes a long time to freeze
will lose more water from its cells,
which then shrink.
During the defrosting process only
some of this water is reabsorbed by the
cells. The rest collects around the food.
In practice this means that the food
loses a large degree of its moisture.
If food is frozen quickly, the cells have
less time to lose moisture, so they
shrink less. As there is not so much
moisture, it is easier for the food to
reabsorb it during the defrosting
process, and there will be very little water around the defrosted food.
Super freeze
Switch the Super freeze function on
before putting fresh food into the
freezer.
Exceptions:
–
when putting in frozen food.
–
when freezing less than 2 kg fresh
food daily.
Switching on Super freeze
When freezing small quantities of food
in the freezer, the Super freeze function
should be switched on 6 hours
beforehand. When freezing the
maximum load of food the Super
freeze function should be switched on
24 hours beforehand.
^
Press the Super freeze button; the
Super freeze indicator light will come
on.
The appliance works at full power to
lower the temperature in the freezer.
It can take up to 8 minutes for the
compressor to switch on after the
Super freeze button has been
pressed. This is due to a built-in
delay switch, which helps prolong
the life of the appliance.
Super freeze
15
Switching Super freeze off
The Super freeze function will switch off
automatically after approx. 60 hours.
The Super freeze indicator light will go
out and the appliance will continue to
operate at normal power.
To save energy the Super freeze
function can be switched off once a
constant temperature of -18 °C or
colder has been reached in the freezer.
^
Press the Super freeze button.
The Super freeze indicator light will go
out and the appliance will continue to
operate at normal power.
Super freeze
16
Maximum freezing capacity
To ensure that fresh food placed in the
freezer freezes through to the core as
quickly as possible, the maximum
freezing capacity must not be
exceeded. The maximum freezing
capacity for freezing within a 24-hour
period is given on the data plate
“Freezing capacity ....kg/24 hrs”.
Storing frozen food
When buying frozen food to store in
your freezer, check
– that the packaging is not damaged,
– the use-by date,
– the temperature at which the frozen
food is being stored in the shop. The
length of time it can be kept is
reduced if it has been stored at a
temperature warmer than -18 °C.
^ Buy frozen food once you have
finished the rest of your shopping,
and wrap it in newspaper or use a
cool bag or box to transport it.
^
Store it in the freezer as soon as
possible.
Never re-freeze partially or fully
defrosted food. Consume defrosted
food as soon as possible as it will
lose its nutritional value and spoil if
left for too long. Defrosted food may
only be re-frozen after it has been
cooked.
Home freezing
Only freeze fresh food which is in good
condition.
Hints on home freezing
–
The following types of food are
suitable for freezing:
Fresh meat, poultry, game, fish,
vegetables, herbs, fresh fruit, dairy
products, pastry, leftovers, egg
yolks, egg whites and a range of
pre-cooked meals.
–
The following types of food are not
suitable for freezing:
Grapes, lettuce, radishes, sour
cream, mayonnaise, eggs in their
shells, onions, whole raw apples and
pears.
– To retain colour, taste and vitamin C,
vegetables should be blanched after
they have been trimmed and
washed. To blanch: bring a large
saucepan of water to the boil and
immerse the vegetables in the fast
boiling water for 2-3 minutes,
depending on variety. Remove and
plunge into cold water to cool
quickly. Drain and pack ready for
freezing.
–
Lean meat freezes better than fatty
meat, and can be stored for
considerably longer.
–
To prevent chops, steaks, cutlets or
rolled meat from freezing together in
solid blocks when packed, separate
with a sheet of plastic freezer film.
Freezing and storing food
17
–
Do not season fresh foods or
blanched vegetables before
freezing. Only season cooked
dishes sparingly. but care should be
taken as the taste of some spices
alters when frozen.
–
Do not place hot food or drinks in the
freezer. This causes already frozen
food to thaw and increases the
energy consumption considerably.
Allow hot food and drinks to cool
down before placing them in the
freezer.
Packing
^ Freeze food in portions.
Unsuitable packing material
- wrapping paper
- grease-proof paper
- cellophane
- bin bags
- plastic carrier bags
Suitable packing material
- plastic freezer film
- freezer bags
- aluminium foil
- freezer containers
Freezer bags may also be sealed using
home heat-sealing kits.
^
Expel as much air as possible from
bags etc. before sealing them to
prevent freezer-burn on food.
^
Close the packaging tightly with
- rubber bands
- plastic clips
- string or bag ties
- freezer tape.
^
Make a note of the contents and the
date of freezing on the packaging.
Before placing food in the freezer
When freezing more than 2 kg of fresh
food, switch on the Super freeze
function for some time before placing
the food in the freezer (see "Super
freeze").
Placing food in the freezer
Fresh food can be placed in any
drawer for freezing, however it is
preferable to use the upper drawers.
Large quantities can be placed directly
on the evaporator plates to freeze the
food quickly. To do this first take out
one or several freezer drawers. The
lowest freezer drawer must always
remain in the appliance.
Each drawer and evaporator plate
can be loaded with a maximum of
25 kg.
^
Place the food flat in the bottom of
the drawers or on the evaporator
plates so that it freezes through to the
core as quickly as possible.
^
Make sure that the packaging and
containers are dry to prevent them
sticking together when frozen.
When freezing, make sure that food
already frozen does not come into
contact with fresh food being frozen
as this could cause the frozen food
to begin to defrost.
Freezing and storing food
18
Defrosting
Frozen food can be defrosted in
different ways:
–
in the microwave oven,
–
in the oven using the “Fan” or
“Defrost” setting,
–
at room temperature,
–
in the fridge,
–
in a steam oven.
Fruit should be defrosted at room
temperature in its packing or in a
covered bowl.
Most vegetables can be cooked while
still frozen. Just put straight into boiling
water or hot fat. The cooking time is
slightly less than that of fresh
vegetables.
Poultry
It is particularly important to observe
food hygiene rules when defrosting
poultry. Do not use the liquid from
defrosted poultry. Pour it away, wash
the container it was in, the sink and
your hands.
Never re-freeze partially or fully
defrosted food. Consume defrosted
food as soon as possible as it will
lose its nutritional value and spoil if
left for too long. Defrosted food may
only be re-frozen after it has been
cooked.
Cooling drinks
When cooling drinks quickly, make sure
bottles are not left in the freezer for
more than one hour, as they could
burst.
Freezing and storing food
19
In normal use, ice and frost will form on
the evaporator plates. If allowed to
accumulate, this will impair the
efficiency of the freezer and increase
the consumption of electricity.
Do not scrape ice and frost off the
evaporator plates as this can
damage them and render the freezer
unusable.
The freezer should be defrosted from
time to time. It must be defrosted if a
layer of ice approx. 5 mm thick has
accumulated. It is best to defrost when
only very little food or no food at all is
left in the freezer.
Before defrosting
^ Switch on the Super freeze function
at least 4 hours before defrosting to
ensure frozen food retains its cold
reserve for longer when taken out of
the freezer.
^
Remove the frozen food from the
freezer and place it in another freezer
or cool box, or wrap it in several
layers of newspaper or cloths and
store in a cool place until the freezer
is ready for use again.
^
Remove all the freezer drawers from
the freezer.
To defrost
Carry out the defrosting procedure
as quickly as possible if food has
not been placed in another freezer.
The longer the food is left out at
room temperature, the faster it
defrosts.
^
Switch the appliance off with the
temperature dial, switch off at the
socket and remove the plug.
^
Open the freezer door.
To speed up defrosting, a bowl
containing hot water (not boiling) can
be placed in the appliance. Closing the
door in this instance will help retain the
warmth and speed up the defrosting
process.
We do not recommend the use of
hot air blowers such as hairdryers
for defrosting your appliance.
Never place electric heaters or
candles in the appliance to defrost
it. These can damage the plastic
parts.
Do not use defrosting sprays or
de-icers, as they could contain
substances which could damage
the plastic parts and which may
cause a build-up of gases and pose
a danger to health.
Defrosting
20
After defrosting
^
Use a sponge or towel to soak up
any water from defrosting still in the
appliance.
^
Clean the appliance, and then dry it
thoroughly.
^
Close the appliance door, insert the
plug in the socket and switch the
appliance back on.
^
Switch on the Super freeze function
so that the freezer can cool down
quickly. The indicator light will come
on.
^ Once the temperature in the freezer
is sufficiently low, place the food
back in the freezer drawers and put
them back in the freezer.
^ The Super freeze function can now
be switched off.
The indicator light will go out.
Defrosting
21
Never use cleaning agents
containing abrasive substances
such as sand, soda, acids or
chemical solvents.
"Non-abrasive" cleaning agents are
also unsuitable as they can cause
matt areas to appear.
Make sure that water cannot get into
the electronic unit or into the
ventilation gaps.
Never use steam cleaning
apparatus to clean the appliance.
Pressurised steam could reach the
electrical components and cause a
short circuit.
The data plate located inside the
appliance must not be removed. It
contains information which is
required in the event of a service
call.
^
Clean the appliance immediately
after defrosting it.
^
Switch the appliance off, take any
food out of the appliance and store it
in a suitable cool place (e.g. cool-box
or another freezer). Remove all the
freezer drawers from the appliance.
Cleaning the outer casing, the
interior and accessories
Use warm water with a little washing up
liquid. Accessories and drawers should
be hand washed only. Do not wash in a
dishwasher.
^
After cleaning, wipe the outer casing,
the interior and accessories with a
damp cloth and dry with a soft cloth.
Leave the door open to air the
appliance for a short while.
E-Cloth
^ A microfibre "E-Cloth" is available
from the Miele UK Spare Parts
Department, which is suitable for
cleaning surfaces such as stainless
steel, glass, plastic and chrome
without the use of chemicals. It can
be washed 300 times.
Ventilation gaps
^ The ventilation gaps should be
cleaned regularly with a brush or
vacuum cleaner. A build-up of dust
will increase the energy consumption
of the appliance.
Door seal
Do not use any grease or oil on the
door seal. These will cause the seal
to deteriorate and become porous
over time.
The door seal should be cleaned
regularly with clean water and then
wiped dry with a soft cloth.
Cleaning
22
Metal grille at the back of the
appliance
The metal grille at the back of the
appliance (heat exchanger) should be
dusted at least once a year. A build-up
of dust will increase the energy
consumption of the appliance.
When cleaning the grille, make sure
that the pipework and other
components do not get broken or
damaged in any way.
After cleaning
^ Close the door and switch the
appliance on.
^ Switch on the Super freeze function
so that the freezer can cool down
quickly.
The indicator light will come on.
^ Once the temperature in the freezer
is sufficiently low, place the food
back in the freezer drawers and put
them back in the freezer.
^
You can switch the Super freeze
function off once the temperature in
the freezer has reached a constant
temperature of at least -18°C.
The indicator light will then go out.
Cleaning
23
Repairs to electrical appliances
should only be carried out by a
suitably qualified and competent
person in accordance with local and
national safety regulations. Repairs
and other work by unqualified
persons could be dangerous. The
manufacturer cannot be held liable
for unauthorised work.
Some minor problems can be corrected
without contacting the Service
Department.
. . . the appliance does not get cool.
^ Make sure that the temperature dial is
not pointing to the "0" position.
^ Check that the plug is correctly
inserted in the socket and switched
on.
^ Check that the fuse is not defective
and that the mains fuse has not
blown. If it has, contact the Miele Service Department.
. . . the door will not open because it
has been opened and closed too
many times in succession.
This is not a fault. The suction caused
by opening and closing the door is
preventing the door from opening. Wait
a few minutes and then try again. It
should now open without force.
. . . the temperature is too low.
^
Turn the temperature selector to a
setting closer to "0".
^
The Super freeze function has not
been switched off. The indicator light
is still on.
. . . the appliance is switching in too
frequently and for too long.
^
Check whether the ventilation gaps
have been covered over or become
too dusty.
^
Check whether the metal grille (heat
exchanger) at the rear of the
appliance has become too dusty.
^
The door has been opened too
frequently, or a large amount of fresh
food has been put in at once for
freezing.
^ Check that the door has been
properly closed.
^ Check whether a thick layer of ice
has built up. If it has, then the freezer
will need defrosting.
. . . the alarm indicator light is on.
The temperature has risen above the
setting on the temperature dial because
^
the door has been opened too
frequently, or large amounts of fresh
food have been put in at once for
freezing.
^
there has been a lengthy interruption
to the power supply.
^
the ventilation gaps are blocked.
Once the problem has been resolved
the alarm indicator light will go out.
Problem solving guide . . .
24
. . . the Super freeze indicator light
does not light up although the
appliance is working.
^
The indicator light is defective. Call
the Service Department.
. . . food has frozen together.
Use a blunt instrument, e.g. a spoon
handle or plastic scraper, to prise it
apart carefully.
. . . there is a thick layer of ice in the
freezer.
^ Check whether the door closes
properly.
^ Defrost and then clean the freezer.
Too thick a layer of ice reduces
efficiency and increases energy
consumption.
If you still cannot remedy the fault
having followed these suggestions,
please contact the Miele Service
Department.
To prevent unecessary loss of
temperature it is advisable not to
open the door while waiting for the
appliance to be serviced.
Problem solving guide . . .
25
Normal noises What causes them
Brrrrr... Humming noise made by the motor (compressor). This noise can
get louder for brief periods when the motor is switching on.
Blubb, blubb.... A gurgling noise can be heard when coolant is circulating
through the pipes.
Click.... Clicking sounds are made when the thermostat switches the
motor on and off.
Sssrrrrr.... On multi-zone and frost free appliances you can sometimes just
hear the movement of air circulating inside the appliance.
Remember that the noise of the compressor and the coolant circulating in the
system is unavoidable.
Noises that you can
easily rectify
What causes them, and what can you do about
them?
Rattling, vibrating The appliance is uneven: Realign the appliance using a spirit
level, by raising or lowering the screw feet underneath the
appliance.
The appliance is touching another appliance or piece of
furniture: Move it away.
Drawers, baskets or shelves are unstable or sticking: Check
all removable items and refit them correctly.
Are any bottles or containers unstable or knocking against
each other? Separate them.
The transport cable clips are hanging loose at the back of the
appliance: Remove the clips.
Noises
26
In the event of a fault which you cannot
correct yourself, or if the appliance is
under guarantee, please contact:
–
Your Miele Dealer
or
–
The Miele Service Department (see
back cover for address).
When contacting your Dealer or the
Service Department, please quote the
model and serial number of your
appliance. This information is given on
the data plate.
Please note that telephone calls may
be monitored and recorded to
improve our service.
Service Department
27
Electrical connection U.K.
All electrical work should be carried out
by a suitably qualified and competent
person in accordance with local and
national safety regulations.
The appliance is supplied with a mains
cable and moulded plug ready for
connection to an a.c. single phase
220-240 V 50 Hz supply.
The voltage and connected load are
given on the data plate. Please ensure
that these match the household mains
supply. The fuse rating is quoted on the
plug.
Connection should be made via a
suitable switched socket which is easily
accessible. For extra safety it is
advisable to install a residual current
device (RCD) with a trip current of 30
mA (in accordance with DIN VDE 0664,
VDE 0100, Section 739).
Do not connect the appliance to the
mains electricity supply by an extension
lead. Extension leads do not guarantee
the required safety of the appliance
(e.g. danger of overheating).
The appliance must not be connected
to an inverter and must not be used
with a plug adapter as these can cause
damage to the appliance's electronic
unit.
Non-rewireable plugs (BS 1363)
The fuse cover must be re-fitted when
changing the fuse, and if the fuse cover
is lost, the plug must not be used until a
suitable replacement is obtained. The
colour of the correct replacement cover
is that of the coloured insert in the base
of the plug, or the colour that is
embossed in words in the base of the
plug (as applicable to the design of the
plug fitted).
Replacement fuses should be ASTA
approved to BS 1362 and have the
correct rating. Replacement fuses and
fuse covers may be purchased from
your local electrical supplier.
WARNING
THIS APPLIANCE MUST BE
EARTHED
Electrical connection
28
Appliances without side wall heating
must not be installed "side-by-side"
next to another refrigerator or
freezer.
Do not place any appliance which
gives off heat, such as a toaster or
microwave oven, on top of this
appliance, as this would increase
the appliance's energy
consumption.
Location
It should not be installed where it is
exposed to direct sunlight or directly
adjacent to a heat-producing appliance
such as an oven or a radiator. The
appliance should be installed in a dry
well-ventilated room.
The higher the ambient temperature of
the room the more energy the
appliance requires to operate.
Climate range
The appliance is designed for use
within certain climate ranges (ambient
temperatures), and should not be used
outside this range. The climate range of
this appliance is stated on the data
plate inside the appliance.
Climate range Ambient room
temperature
SN
N
ST
T
SN-ST
SN-T
+10 °C to +32 °C
+16 °C to +32 °C
+18 °C to +38 °C
+18 °C to +43 °C
+10 °C to +38 °C
+10 °C to +43 °C
The appliance will function perfectly
down to a temperature of +5 °C.
Ventilation
Air at the back of the appliance gets
warm. To ensure sufficient ventilation,
the ventilation grilles must not be
covered over. The air inlet and outlet
must not be covered or blocked in any
way. They should be dusted on a
regular basis.
Installation
^ Remove any cable clips from the
back of the appliance.
^ Check that all parts at the back of the
appliance are unhindered. Remove
any hindrance.
^ Carefully push the appliance into
position.
Aligning the appliance
^
To align the appliance, adjust the feet
using the spanner supplied.
Installation
29
The appliance is supplied right-hand
hinged. If left-hand door hinging is
required follow these instructions.
^ Close the appliance door, unscrew
hinge bracket b, and take the door
off.
^
Take hinge pin c out of the hinge
bracket, then refit it in the second
hole in the hinge bracket. (Use the
spanner supplied to unscrew and
refit the hinge pin).
^
Remove cover a and use it to cover
the now empty holes on the opposite
side.
^
Use the spanner supplied to unscrew
upper hinge pin d and refit it on the
other side.
^
Remove stoppers f, and unscrew
handle e. Refit the handle on the
other side of the door.
^
Then refit stoppers g on the opposite
side of the door.
^
Hang the door on the upper hinge
pin and close the door.
^
Fit hinge bracket b in the lower door
bearing. Then screw it securely to the
appliance plinth.
Use the long slots in the hinge
bracket to align the door. Make sure
you have tightened all screws
properly.
Changing the door hinging
30
31
Alteration rights reserved / 4604
F 1313 S
M.-Nr. 06 154 980 / 02
Loading...
