Operating and installation instructions Induction wok
To avoid the risk of accidents or damage to the appliance it is essential to read these instructions before it is installed and used for the first time.
en-GB M.-Nr. 09 551 700
Contents
Warning and Safety instructions.......................................................................... 4
Wok ....................................................................................................................... 14
Indicators............................................................................................................... 14
Control symbols .................................................................................................... 15
Display................................................................................................................... 15
Cooking zone controls .......................................................................................... 20
Residual heat indicator.......................................................................................... 20
Auto heat-up ......................................................................................................... 21
Safety features..................................................................................................... 23
Overheating protection.......................................................................................... 24
Ceramic surface .................................................................................................... 26
Operating controls................................................................................................. 27
Optional accessories ..........................................................................................30
Safety instructions for installation..................................................................... 31
Installation notes ................................................................................................. 36
2
Contents
Building-in dimensions ......................................................................................37
Building-in several CombiSets........................................................................... 38
Installation............................................................................................................ 40
Electrical connection ..........................................................................................44
3

Warning and Safety instructions

This wok complies with all relevant safety requirements. Inappro­priate use can, however, lead to personal injury and damage to property.
To avoid the risk of accidents and damage to the wok, please read these instructions carefully before installation and before using it for the first time. They contain important notes on installation, safety, use and maintenance. Miele cannot be held liable for damage caused by non-compliance with these instructions.
Keep these instructions in a safe place and ensure that new users are familiar with the content. Pass them on to any future owner.
4
Warning and Safety instructions

Correct application

This wok is designed for domestic use and for use in similar envir-
onments.
This wok is not intended for outdoor use.This wok is intended for domestic use only to cook food and keep
it warm. Any other use is not supported by the manufacturer and could be dangerous.
This wok can only be used by people with reduced physical, sens-
ory or mental capabilities or lack of experience and knowledge if they are supervised whilst using it. They may only use it unsuper­vised if they have been shown how to use it in a safe way and under­stand the hazards involved.
5
Warning and Safety instructions

Safety with children

Children under 8 years of age must be kept away from the wok
unless they are constantly supervised.
Children 8 years and older may only use the wok unsupervised if
they have been shown how to use it safely and recognise and under­stand the consequences of incorrect operation.
Children must not be allowed to clean the wok unsupervised.Please supervise children in the vicinity of the wok and do not let
them play with it.
The wok gets hot when in use and remains hot for a while after
being switched off. Keep children well away from the appliance until it has cooled down and there is no danger of burning.
Danger of burning.
Do not store anything which might arouse a child's interest in stor­age areas above or next to the wok. Otherwise they could be temp­ted into climbing onto the appliance.
Danger of burning or scalding.
Place pots and pans on the cooking zone in such a way that children cannot pull them down and burn themselves.
Danger of suffocation. Packaging, e.g. plastic wrappings, must be
kept out of the reach of babies and children. Whilst playing, children could become entangled in packaging or pull it over their head and suffocate.
Activate the system lock to ensure that children cannot switch the
wok on by mistake.
6
Warning and Safety instructions

Technical safety

Unauthorised installation, maintenance and repairs can cause
considerable danger for the user. Installation, maintenance and re­pairs must only be carried out by a Miele authorised technician.
A damaged wok can be dangerous. Check it for visible signs of
damage. Do not use a damaged appliance.
Reliable and safe operation of the wok can only be assured if it
has been connected to the mains electrical supply.
The electrical safety of this wok can only be guaranteed when cor-
rectly earthed. It is essential that this standard safety requirement is met. If in any doubt please have the electrical installation tested by a qualified electrician.
Before connecting the wok to the mains supply, ensure that the
connection data on the data plate (voltage and frequency) match the mains electricity supply. This data must be checked before connecting the appliance. Consult a qualified electrician if in any doubt.
Do not connect the wok to the mains electricity supply by a multi-
socket unit or an extension lead. These do not guarantee the re­quired safety of the appliance (fire hazard).
For safety reasons, this wok may only be used after it has been
built in.
This wok must not be used in a non-stationary location (e.g. on a
ship).
Never open the casing of the wok.
Touching or tampering with electrical connections or components and mechanical parts is highly dangerous to the user and can cause operational faults.
7
Warning and Safety instructions
While the wok is under guarantee, repairs should only be under-
taken by a Miele authorised service technician. Otherwise the guar­antee is invalidated.
Miele can only guarantee the safety of the appliance when genu-
ine original Miele replacement parts are used. Faulty components must only be replaced by Miele spare parts.
The wok is not intended for use with an external timer switch or a
remote control system.
If the plug is removed from the connection cable or if the cable is
supplied without a plug, the wok must be connected to the electrical supply by a suitably qualified electrician.
If the connection cable is damaged, it must be replaced by a suit-
ably qualified electrician with a special connection cable of type H 05 VV-F (pvc insulated). See "Electrical connection".
During installation, maintenance and repair work, the wok must be
completely disconnected from the mains electricity supply. Depend­ing on country this is done in one of several different ways:
– disconnect the mains fuse, or
– completely unscrew the screw-out fuse (in countries where this is
applicable), or
– switch off at the wall socket and withdraw the plug from the
socket. Pull by the plug and not by the mains connection cable to disconnect from the mains electricity supply.
Danger of electric shock.
Do not use the wok if it is faulty. Switch it off immediately, discon­nect it from the mains electricity supply and contact Miele.
If the wok is installed behind a furniture panel (e.g. a door), ensure
that the door is never closed whilst the wok is in use. Heat and mois­ture can build up behind a closed furniture panel and cause sub­sequent damage to the wok, the housing unit and the floor. Do not close the door until the residual heat indicators have gone out.
8
Warning and Safety instructions

Correct use

The wok gets hot when in use and remains hot for some time after
being switched off. The risk of burning is present until the residual heat indicators have gone out.
Overheated fat and oil can ignite and catch fire. Never leave the
wok unattended. Do not attempt to extinguish burning oil or fat with water. Switch the wok off and carefully smother the flames with a fire blanket or a damp tea towel
Flames could set the grease filters of a cooker hood on fire. Do
not flambé under a cooker hood.
Spray canisters, aerosols and other inflammable substances can
ignite when heated. Therefore do not store such items or substances in a drawer under the wok. Cutlery inserts must be heat-resistant.
Do not heat an empty pan.Do not heat up food in closed containers e.g. tins or sealed jars
on the wok, as pressure will build up in the container which could cause it to explode.
Do not cover the wok, e.g. with a cover, a cloth or protective foil.
The material could catch fire, shatter or melt if the appliance is switched on by mistake or if residual heat is still present.
When the wok is switched on either deliberately or by mistake, or
when there is residual heat present, there is the risk of any metal items left on the wok heating up, with the danger of burning. De­pending on the material, other items left on the appliance could also melt or catch fire. Do not use the wok as a resting place. Switch the wok off after use.
9
Warning and Safety instructions
You could burn yourself on the hot wok. Protect your hands with
heat-resistant pot holders or gloves when handling hot pots and pans. Do not let them get wet or damp, as this causes heat to trans­fer through the material more quickly with the risk of scalding or burning yourself.
When using an electrical appliance, e.g. a hand-held food blender,
near the wok, ensure that the cable of the electrical appliance cannot come into contact with the hot wok. The insulation on the cable could become damaged.
Grains of salt, sugar and sand (e.g. from cleaning vegetables) can
cause scratches if they get under pan bases. Make sure that the ceramic surface is clean before placing pans on it.
Even a light object can cause damage in certain circumstances.
Do not drop anything on the ceramic surface.
Do not place hot pans on the display as this could cause damage
to the electronics underneath. Do not place hot pans on the area around the display.
Do not allow solid or liquid sugar, or pieces of plastic or aluminium
foil to get onto the wok when it is hot, as they can damage the ceramic surface when it cools down. If this should occur, switch off the appliance and scrape off all the sugar, plastic or aluminium residues whilst still hot, using a shielded scraper blade. Wear oven gloves. Allow the cooking zones to cool down and clean them with a suitable ceramic hob cleaning agent.
Wok pans which boil dry can cause damage to the ceramic glass.
Do not leave the wok unattended whilst it is being used.
Induction heating works extremely quickly and so the base of the
pan could heat up to the temperature at which oil or fat self-ignites within a very short time. Do not leave the wok unattended whilst it is being used.
10
Warning and Safety instructions
Heat oil or fat for a maximum of one minute. Do not use the
Booster function to heat oil or fat.
For people fitted with a heart pacemaker: please note that the
area immediately surrounding the wok is electromagnetically charged. It is very unlikely to affect a pacemaker. However, if in any doubt, consult the manufacturer of the pacemaker or your doctor.
To prevent damage to items which are susceptible to electromag-
netic fields, e.g. credit cards, digital storage devices, pocket calcu­lators, etc, do not leave them in the immediate vicinity of the wok.
Metal utensils stored in a drawer under the wok can become hot if
the appliance is used intensively for a long time. Do not store any metal items or utensils in a drawer under the wok.
This wok is fitted with a cooling fan. If a drawer is fitted directly
underneath the wok, ensure that there is sufficient space between the drawer and its contents and the underside of the appliance in or­der to ensure sufficient ventilation of the wok. Do not store pointed or small items or paper in the drawer. They could get in through the ventilation slots or be sucked into the housing by the fan and dam­age the fan or impair cooling.
Only use the wok pan supplied with the appliance. For safety
reasons, other wok pans must not be used. Danger of burning. See "Induction - Pans".
Where several CombiSets are installed side by side:
Hot objects can damage the seal of the cover strip between the ap­pliances. Do not place hot pans near or on the cover strip.
11
Warning and Safety instructions

Cleaning and care

Do not use a steam cleaning appliance to clean this wok.
The steam could reach electrical components and cause a short cir­cuit.
If the wok is built in over a pyrolitic oven, the wok should not be
used whilst the pyrolitic process is being carried out, as this could trigger the overheating protection mechanism on the wok (see relev­ant section).
12

Caring for the environment

Disposal of the packing mater­ial
The packaging is designed to protect the appliance from damage during transportation. The packaging materials used are selected from materials which are environmentally friendly for disposal and should be recycled.
Recycling the packaging reduces the use of raw materials in the manufactur­ing process and also reduces the amount of waste in landfill sites.
Disposing of your old appli­ance
Electrical and electronic appliances of­ten contain valuable materials. They also contain specific materials, com­pounds and components, which were essential for their correct function and safety. These could be hazardous to hu­man health and to the environment if disposed of with your domestic waste or if handled incorrectly. Please do not, therefore, dispose of your old appliance with your household waste.
Please dispose of it at your local com­munity waste collection / recycling centre for electrical and electronic ap­pliances, or contact your dealer or Miele for advice. You are also respons­ible by law for deleting any personal data that may be stored on the appli­ance being disposed of. Please ensure that your old appliance poses no risk to children while being stored prior to dis­posal.
13

Guide to the appliance

Wok
a
b
c

Indicators

f
g
h
14
Wok basin
Wok pan
Control knob
In-operation indicator
Booster indicator
Residual heat indicator
d
Indicators
e
Display
Guide to the appliance

Control symbols

Symbol Description
0 Cooking zone off
1–9 Power levels
B I Booster

Display

Symbol Description
No wok pan in place (see "Induction")
Auto heat-up activated
Booster activated
The system lock has been activated
 /  Safety switch-off (see "Safety features")
Overheating protection (see "Safety features")

Cooking zones

Wok basinØin cm* Rating in watts for 230 V**
30.0 Normal Booster
2400 3200
15
Guide to the appliance

Accessories supplied

The accessories supplied with your ap­pliance as well as a range of optional ones are available to order from Miele (see "Optional accessories").
Wok pan CSWP 1450

Wok rest

16

Using for the first time

Please stick the extra data plate for
the appliance supplied with this doc­umentation in the space provided in the "After sales service, data plate, guarantee" section of this booklet.
Remove any protective wrapping and
stickers.

Cleaning the CombiSet for the first time

Before using for the first time, clean
the hob with a damp cloth only and then wipe dry.

Switching on the CombiSet for the first time

When the wok is first connected, or after an interruption to the power sup­ply, all of the indicators in the display will light up for approx. 1 second for testing. As soon as they go out, the wok is ready for use.
The metal components have a protect­ive coating which may give off a slight smell when heated up for the first time. The induction coils may also give off a slight smell for the first few hours of op­eration. This smell will be less notice­able with each subsequent use before dissipating completely.
The smell and any vapours given off do not indicate a faulty connection or ap­pliance and they are not hazardous to health.
Please note that the heating up time on induction woks is very much shorter than on conventional woks.
17

Induction

How it works

An induction coil is located underneath the induction wok. When the appliance is switched on, this coil creates a mag­netic field. This magnetic field in turn creates, or induces, current in the base of the wok pan on it. The wok basin it­self is heated up indirectly by the heat given off by the wok pan.
Induction heating only works when the wok pan supplied is used (see "Suitable pans").
The symbol will light up if
– the wok it is switched on without the
wok pan in place.
– if the wok pan is removed from the
appliance whilst it is switched on.
If the wok pan is replaced within 3 minutes, the symbol will go out and you can continue as normal.
If the wok pan is not replaced, the wok will switch itself off automatically after 3 minutes. will flash alternately in the display with .
When the wok is switched on
either deliberately or by mistake, or when there is residual heat present, there is the risk of any metal items left on the wok heating up.
Danger of burning. Do not use the wok as a resting
place for items. Switch the wok off after use by turning the control to "0".
18
Induction

Noises

The following noises might occur in the wok pan when the induction wok is in operation:
On the higher power settings, it might buzz. This will decrease or cease alto­gether when the power setting is re­duced.
You might hear a clicking sound from the electronic switches, especially on lower power settings.
You might hear a whirring sound when the cooling fan switches on. It switches on to protect the electronics when the wok is being used intensively. The fan may continue to run after the appliance has been switched off.

Pans

Only use the wok pan supplied with
the appliance for cooking food. This wok pan is designed specifically for this appliance.
If other woks are used, there is a
risk of fat or food overheating, and burning.
19

Operation

Settings

Cooking process Set-
ting
range
Keeping food warm, melting chocolate
Warming food up 3-6 Stir-frying, e.g. Chinese dishes 7-9
1-2

Cooking zone controls

Do not turn the control to "0" by turning it past BI.

Switching on

Fire hazard.
Do not leave the hob unattended whilst it is being used. Please note that the heating up time on an induction hob is very much shorter than on a conventional hob.
Turn the cooking zone control clock-
wise to the setting you want.

Switching off

Turn the cooking zone control anti-
clockwise to0.
When all cooking zones are switched off the in-operation indicator will go out.

Residual heat indicator

If a cooking zone is hot, the residual heat indicator will light up when it has been switched off. The residual heat in­dicator will only go out when the cook­ing zone is safe to touch.
Danger of burning. Do not touch
the cooking zones whilst the residual heat indicators are lit up.
The in-operation indicator will light up. The residual heat indicator will light up after a certain temperature has been reached.
20
Operation

Auto heat-up

When Auto heat-up has been activated, the cooking zone switches on automat­ically at the highest power setting and then switches to the continued cooking setting. The heat-up time depends on which continued cooking setting has been chosen (see chart).

Activating

Turn the cooking zone control anti-
clockwise and hold until appears in the cooking zone display.
Now turn the cooking zone control
clockwise to the continued cooking setting you want.
The continued cooking level must be set within 5seconds of activating Auto heat-up. You can change the continued cook­ing level up to approx. 10 seconds after activating Auto heat-up.
If you hold down the cooking zone control for too long the system lock will be activated and will appear in the cooking zone display.
Continued cook-
ing setting
1 approx. 0:15
2 approx. 0:15
3 approx. 0:25
4 approx. 0:50
5 approx. 2:00
6 approx. 5:50
7 approx. 2:50
8 approx. 2:50
9 –
Heat-up time
[min : sec]
lights up in the cooking zone display during the heat-up time (see chart).

Deactivating

Select a different power level.
21
Operation

Booster

This induction wok is equipped with a booster function.
When activated, the power is boosted for a maximum of 10 minutes.
If the wok pan reaches the highest temperature permitted in under 10 minutes, the booster will switch itself off and the wok will continue on set­ting . Only the wok pan supplied with the appliance offers this safety feature.

To switch on the booster

Turn the control past power setting 9
to BI, and then back to 9.
appears in the display, and the B in­dicator also lights up.

To switch off the booster

Select a different power level.
The booster symbol and "B" will go out.
22

Safety features

System lock

The system lock can only be activated when the wok switched off.
Your wok is equipped with a system lock to prevent it being switched on by mistake.
If a power level is selected when the system lock is activated, appears in the display for approx. 3 seconds.

Activating

Turn the control anti-clockwise to the
point of resistance and hold it until appears in the display.

Deactivating

Turn the control anti-clockwise to the
point of resistance and hold it until goes out in the display.

Safety switch-off

The safety switch-off mechanism is triggered automatically if the wok is heated for an unusually long period of time. This period of time depends on the power level selected. Once ex­ceeded, the wok switches off and and flash alternately in the display. The wok can be operated again after it has been switched off and back on.
23
Safety features

Overheating protection

The induction coil is equipped with overheating protection. Before the in­duction coil gets too hot, overheating protection cuts in in one of the following ways:
– If the booster function is being used
it will be switched off.
– The set power level will be reduced.
– The induction wok switches itself off
automatically and appears in the display.
Turn the control to '0'.
If the control is not turned back to "0", and will flash in the display altern­ately.
You can use the wok again as usual when the fault code has gone out.
The overheating protection mechanism can be triggered by:
– the wok being used at maximum
power for too long.
– Insufficient ventilation to the under-
side of the hob.
If, despite removing the cause, the overheating protection mechanism trig­gers again, contact Miele.
24

Cleaning and care

Danger of burning.
The cooking zone must be switched off. The wok must have cooled down.
Danger of injury.
The steam from a steam cleaning ap­pliance could reach electrical com­ponents and cause a short circuit.
Do not use a steam cleaner to clean the wok.
The use of unsuitable cleaning agents can cause the surfaces to discolour or alter.
All surfaces are susceptible to scratching.
Remove any residual cleaning agent immediately.
Allow the CombiSet to cool down before cleaning.
The CombiSet and accessories
should be cleaned after each use.
Dry the CombiSet after using water to
clean it. This helps prevent limescale deposits.

Unsuitable cleaning agents

To avoid damaging the surfaces of your appliance, do not use:
– washing-up liquid,
– cleaning agents containing soda, al-
kalines, ammonia, acids or chlorides,
– cleaning agents containing descaling
agents,
– stain or rust removers,
– abrasive cleaning agents, e.g.
powder cleaners and cream cleaners,
– solvent-based cleaning agents,
– dishwasher cleaner,
– grill and oven cleaners,
– glass cleaning agents,
– hard, abrasive brushes or sponges,
e.g. pot scourers, or sponges which have been previously used with ab­rasive cleaning agents,
– melamine eraser blocks.
25
Cleaning and care

Ceramic surface

Do not clean the area between the glass-ceramic surface and the frame or the frame and the worktop with sharp, pointed objects.
This could damage the seals.
Do not use washing-up liquid to clean the appliance as washing-up li­quid will not remove all soiling and deposits.
It will form an invisible coating which will cause permanent discolouration of the ceramic surface.
Clean the wok regularly with a suit­able ceramic hob cleaning agent.
Wipe all coarse soiling off using a damp cloth. Stubborn soiling may need to be removed with a shielded scraper blade.
Then clean the wok with Miele ceramic and stainless steel hob cleaner (see "Optional accessories") or a suitable proprietary ceramic hob cleaning agent applied with kitchen paper or a clean cloth. Do not apply cleaning agent while the wok is still hot, as this could result in marking. Please follow the manufac­turer's instructions.
Danger of burning.
Protect your hands with oven gloves before using a shielded scraper blade to remove sugar, plastic or alu­minium residues from the hot hob.
Should any sugar, plastic or alu- minium foil spill or fall onto a hot hob, first switch off the appliance. Then carefully scrape off all the sugar, plastic or aluminium residues from the hob im- mediately whilst they are still hot, using a shielded scraper blade. Allow the ap­pliance to cool down, and then clean as described above.
Finally wipe the wok with a damp cloth, then dry with a soft, dry cloth. Residues can burn onto the appliance the next time it is used and cause damage to the ceramic surface. Ensure that all clean­ing agent residues are removed.
Spots caused by limescale, water and aluminium residues (spots with a metal­lic appearance) can be removed using Miele's ceramic and stainless steel hob cleaner.
26

Stainless steel frame/control panel

Clean the frame and the control panel
with a solution of warm water and a little washing-up liquid applied with a soft sponge.
You can also use a ceramic and stain­less steel cleaning agent. We recom­mend also using a stainless steel condi­tioning agent to help prevent resoiling (see "Optional accessories).
Do not use ceramic and stainless steel cleaner or stainless steel condi­tioning agent on the printing.
This would rub the printing off. These areas should be only cleaned
with a solution of warm water and a little washing-up liquid applied with a soft sponge.
Cleaning and care

Operating controls

Clean the control(s) with a solution of
warm water and a little washing-up li­quid applied with a soft sponge. Stubborn soiling should be soaked first.
Dry the control(s) with a clean cloth.
27

Problem solving guide

With the aid of the following guide, minor problems can be easily corrected without contacting Miele. If having followed the suggestions below, you still cannot resolve the problem, please contact Miele (see end of this booklet for contact details).
Danger of injury. Installation, maintenance and repairs may only be carried
out by a suitably qualified and competent person. Repairs and other work by unqualified persons could be dangerous. Miele can­not be held liable for unauthorised work. Do not attempt to open the casing of the CombiSet yourself.
Problem Cause and remedy
The wok does not heat up.
A smell and vapours are given off when the new wok is being used.
The symbol flashes in the display.
There is no power to the wok. Check if the mains fuse has tripped. If it has, con-
tact a qualified electrician or Miele (minimum fuse rating - see data plate).
There may be a technical fault.
Turn the control to 0.Disconnect the appliance from the electricity sup-
ply for approx. 1 minute. To do this: – switch off at the isolator, or – disconnect the mains fuse.
If, after resetting the trip switch in the mains fuse
box and switching the appliance back on, the ap­pliance will still not heat up, contact a qualified electrician or Miele.
The metal components have a protective coating. When the appliance is used for the first time, this causes a smell and possibly also vapour. The material from which the induction coils are made also gives off a smell in the first few hours of operation. This smell will be less noticeable with each subsequent use be­fore dissipating completely. The smell and any vapour given off do not indicate a faulty connection or appli­ance and they are not hazardous to health.
The wok pan is not in position. Place the wok pan in position or switch the wok
off.
28
Problem Cause and remedy
flashes in the display alternating with.
After switching the wok on, appears in the dis­play for a few seconds.
After switching on the wok appears in the display for a few seconds. The wok does not heat up.
The wok pan has been taken off the wok for more than 3minutes.
Replace the wok pan or switch the wok off.
The overheating protection mechanism has been ac­tivated.
See "Overheating protection".
The system lock has been activated. You need to deactivate the system lock (see "Sys-
tem lock").
Demonstration mode is activated. Turn the control twice briefly anti-clockwise to the
point of resistance then once again, holding it for approx. 3seconds.
Problem solving guide
29

Optional accessories

Miele offer a comprehensive range of useful accessories as well as cleaning and conditioning products for your Miele appliances.
These products can be ordered through the Miele Webshop.
These can also be ordered from Miele (see end of this booklet for contact de­tails) or from your Miele dealer.
Wok pan CSWP 1450

Cleaning and care products

Ceramic and stainless steel hob cleaner 250 ml

Removes heavy soiling, limescale de­posits and aluminium residues
Stainless steel conditioning agent 250ml
Removes water marks, flecks and finger prints. Helps keep the appliance looking good for longer.

Microfibre cloth

30
Removes finger marks and light soiling

Safety instructions for installation

Fit the wall units and cooker hood before fitting the CombiSet to avoid dam­aging it.
The veneer or laminate coatings of worktops (or adjacent kitchen
units) must be treated with 100°C heat-resistant adhesive which will not dissolve or distort. Any backmoulds must be of heat-resistant material.
The CombiSet must not be installed over a fridge, fridge-freezer,
freezer, dishwasher, washing machine, washer-dryer or tumble dryer.
This CombiSet must not be installed above an oven unless it has
a built-in cooling fan.
The electrical cable of the CombiSet must not come into contact
with any moving kitchen component (e.g. a drawer) or be subject to any mechanical action which could damage it.
Observe carefully the safety clearances listed on the following
pages.
All dimensions are given in mm.
31

Safety distances

Safety distance above the CombiSet

A minimum safety distance must be maintained between the CombiSet and the cooker hood above it. See the cooker hood manufacturer's operating and installation instructions for details. If the manufacturer's instructions are not available for the cooker hood a min­imum safety distance of at least 760mm must be maintained, or if any flammable objects (e.g. utensil rails, wall units etc) are installed above the CombiSet, a minimum safety distance of at least 760mm must be maintained between them and the CombiSet be­low.
When two or more CombiSets which have different safety distances are installed together below a cooker hood, you should observe the greatest safety distance.
32

Safety distances to the sides and back of the hob

The CombiSet may be installed with a wall at the rear and a tall unit or wall to one side (right or left) (see illustrations).
Minimum distance between the back of the worktop cut-out and the rear edge of the worktop: 50mm
Minimum distance between the worktop cut-out and a tall unit or wall to the right or left of it:
40 mm CS 1212 / CS 1212-1
CS 1221 / CS 1221-1 CS 1234 / CS 1234-1 CS 1223 CS 1222
50 mm CS 1112
CS 1122 CS 1134 CS 1326 CS 1327 CS 1411
Safety distances
Not allowed
Recommended
100 mm CS 1012 / CS 1012-1
150 mm CS 1421
CS 1312 CS 1322
200 mm CS 1034 / CS 1034-1
250 mm CS 1011 / CS 1021
Not recommended
Not recommended
33
Safety distances
Minimum safety distances un­derneath the hob
To ensure sufficient ventilation to the hob, a certain gap must be left between the underside of the hob and any oven, interim shelf or drawer.
The minimum gap between the under­side of the hob and
– the top of an oven is 15mm.
– the top of an interim shelf is 15mm.
– the base of a drawer is 75mm.

Interim shelf

It is not necessary to fit an interim shelf underneath the hob but one may be fit­ted if you wish.
Leave a gap of 10mm at the back of the shelf to accommodate the cable. We recommend a gap at the front of the shelf of 20mm to ensure good ventila­tion.
34
Safety distances

Safety distance when installing the appliance near a wall with additional niche cladding

A minimum safety distance must be maintained between the worktop cut-out and any niche cladding to protect it from heat damage.
If the niche cladding is made from a combustible material (e.g. wood) a minimum safety distance of 50 mm must be maintained between the cut-out and the cladding.
If the niche cladding is made from a non-combustible material (e.g. metal, natural stone, ceramic tiles) the minimum safety distance between the cut-out and the cladding will be 50 mm less the thickness of the cladding. Example: 15 mm niche cladding 50mm - 15mm = minimum safety distance of 35mm
a
Masonry
b
Niche cladding dimension x = thickness of the niche cladding material
c
Worktop
d
Worktop cut-out
e
Minimum distance to
combustible materials 50mm non-combustible materials 50mm - dimension x
35

Installation notes

Seal between the CombiSet and the worktop

Do not use sealant between the CombiSet and the worktop. This could result in damage to the CombiSet or the worktop if the CombiSet ever needs to be removed for servicing. The sealing strip under the edge of the top part of the appliance provides a sufficient seal for the worktop.

Tiled worktop

Grout lines and the hatched area un­derneath the CombiSet frame must be smooth and even. If they are not the CombiSet will not sit flush with the worktop and the sealing strip under­neath the top part of the appliance will not provide a good seal between the appliance and the worktop.
36

Building-in dimensions

a
Spring clamps
b
Front
c
Casing depth
d
Mains connection cable, L=2000mm
37

Building-in several CombiSets

Example: 3 CombiSets
a
Spring clamps
b
Spacer bars
c
Gaps between spacer bars and worktop
d
Cover strips
e
CombiSet width minus 8 mm
f
CombiSet width
g
CombiSet width minus 8 mm
h
Worktop cut-out
38
Building-in several CombiSets

Calculating the worktop cut-out

The frames of the CombiSets overlap the worktop at the outside right and left by 8mm on each side.
Add up the widths of the CombiSets and subtract 16mm from this figure.
Example: 288 mm + 288 mm + 380 mm = 956 mm - 16 mm = 940 mm
The CombiSets are 288mm, 380mm or 576mm wide depending on model (see "Building-in dimensions").

Spacer bars

When building-in several CombiSets a spacer bar must be fitted between each CombiSet. The position for securing the spacer bar will depend on the width of the CombiSet.

Installation with a downdraft extractor

Please refer to the separate "Downdraft extractor with CombiSet" instruction manual for details about worktop cut-out dimensions and fitting spacer bars.
39

Installation

Preparing the worktop

Make the worktop cut-out as shown
in "Building-in dimensions" or as cal­culated (see Building-in several CombiSets). Observe the safety dis­tances (see "Safety distances").

Wooden worktops

Seal the cut surfaces with a suitable
sealant to avoid swelling caused by moisture. The sealant must be heat­resistant.
Make sure that the sealant does not come into contact with the top of the worktop.
40
Position the spring clamps and
spacer bars on or at the top edge of the cut-out in the positions shown.
Secure the spring clamps and
spacer bars with the 3.5x25 mm wood screws supplied.

Natural stone worktops

You will need heavy duty double-side tape (not supplied) to secure the spring clamps and spacer bars.
Installation
Stick the tape to the top edge of
the cut-out in the positions shown in the diagram.
Position the spring clamps and
spacer bars on or at the top edge of the cut-out and press them firmly into place.
Apply silicone to the side and lower
edges of the spring clamps and the spacer bars.
Then fill gap between spacer
bar and the worktop with silicone.
41
Installation

Installation with a downdraft extractor

Please refer to the separate "Downdraft extractor with CombiSet" instruction manual for details about installing a downdraft extractor with a CombiSet appliance.

Installing the CombiSet

Feed the mains connection cable
down through the cut-out.
Starting at the front, position the
CombiSet in the worktop cut-out.
Using both hands, press down evenly
on the edges of the CombiSet until it clicks into position. When doing this make sure that the seal underneath the appliance sits flush with the work­top. This is important to ensure an ef­fective seal with the worktop.
Do not use sealant (e.g. silicone).
If the seal does not meet the worktop correctly on the corners, the corner ra­dius (≤R4) can be carefully scribed to suit.

Building in several CombiSets

Push the built-in CombiSet to the
side until the holes in the spacer bar can be seen.
Fit cover strip into the holes in
spacer bar .
Starting at the front, position the next
CombiSet in the worktop cut-out.
Proceed as described previously.
42

Connecting the CombiSet

Connect the CombiSet(s) to the
mains.
Check that each CombiSet works.

Removing the CombiSet

If the CombiSet cannot be accessed from below, you will need a special tool to remove it.
If the CombiSet can be accessed
from below, push it out from below. Push the rear side out first.
Installation
43

Electrical connection

All electrical work should be carried out by a suitably qualified and competent person in strict accordance with current local and national safety regulations (e.g. BS 7671 in the UK). Connection should be made via a switched socket. This will make it easier for service tech­nicians should the appliance need to be repaired. The electrical socket must be easily accessible after installation.
Danger of injury.
Miele cannot be held liable for unau­thorised installation, maintenance and repair work as this can be dan­gerous to users. Miele cannot be held liable for dam­age or injury caused by incorrect in­stallation, maintenance or repair work, or by an inadequate or faulty earthing system (e.g. electric shock).
If the plug is removed from the con­nection cable or if the cable is sup­plied without a plug, the appliance must be connected to the electrical supply by a suitably qualified electri­cian.
If the switched socket is not access­ible after installation, or if the appli­ance is to be hard-wired, an addi­tional means of disconnection must be provided for all poles. When switched off, there must be an all­pole contact gap of at least 3mm in the switch (including switch, fuses and relays). Connection data is shown on the data plate. It must match the mains electrical supply.
After installation ensure that all elec­trical components are shielded and cannot be accessed by users.

Total power rating

See data plate

Connection

AC 230 V, 50 Hz
The connection data is quoted on the dataplate. It must match the household supply.

Residual current device

For extra safety, it is advisable to pro­tect the CombiSet with a suitable resid­ual current device (RCD) with a trip range of 30 mA.
44
Electrical connection

Disconnecting from the mains

Danger of electric shock.
After disconnection, ensure the ap­pliance cannot be switched back on by mistake.
To disconnect the appliance from the mains power supply, do one of the fol­lowing depending on installation:

Safety fuses

Completely remove fuses

Automatic circuit breakers

Press the (red) button until the middle
(black) button springs out.

Built-in circuit breakers

Circuit breakers, type B or C: switch
the on-off switch from 1 (on) to 0 (off).

Residual current device (RCD)

Switch the main switch from 1 (on) to
0 (off) or press the test button.

Connecting the mains cable

Danger of electric shock.
The mains connection cable must be fitted by a suitably qualified and competent person in accordance with current local and national safety regulations. (e.g. BS 7671 in the UK).
If the mains cable needs to be replaced it must be replaced with a special con­nection cable, type H05VV-F (PVC-in­sulated), available from Miele.
The connection data is quoted on the data plate.
45

After sales service, data plate, guarantee

After sales service

In the event of any faults which you cannot easily remedy, please contact
– your Miele Dealer, or
– Miele Service.
See end of this booklet for contact details.
Please note that telephone calls may be monitored and recorded for training pur­poses.
N.B. A call-out charge will be applied to service visits where the problem could have been resolved as described in these instructions.
When contacting your Dealer or Miele, please quote the model and serial number of your appliance.

Data plate

Space in which to stick the extra data plate supplied with the appliance. Ensure that the model number is the same as the one on the back page of these instruc­tions.

Guarantee: UK

The appliance is guaranteed for 2 years from the date of purchase.
In the UK, you must activate your cover by calling 0330 160 6640 or registering online at www.miele.co.uk.

Guarantee: Other countries

For information on the appliance guarantee specific to your country please contact Miele. See end of this booklet for contact details.
46

Product data sheets

The following data sheets apply to the models described in this operating instruc­tion manual.

Information for domestic electric hobs

In acc. with regulation (EU) No. 66/2014
MIELE
Model name / identifier CS 1223-1
Number of cooking zones and/or areas 1
For circular cooking zones: diameter of useful sur­face area/cooking zone For non-circular cooking zones or areas: length and width of useful surface area per electric cook­ing zone or area
Energy consumption per cooking zone or area cal­culated per kg (EC
Energy consumption for the hob calculated per kg (EC
electric hob
electric cooking
)
)
1. = Ø 300 mm
2. =
3. =
4. =
5. =
6. =
-
-
47
United Kingdom
Miele Co. Ltd. Fairacres, Marcham Road Abingdon, Oxon, OX14 1TW Customer Contact Centre Tel: 0330 160 6600 E-mail: mielecare@miele.co.uk Internet: www.miele.co.uk
Australia
Miele Australia Pty. Ltd. ACN 005 635 398 ABN 96 005 635 398 1 Gilbert Park Drive, Knoxfield, VIC 3180 Tel: 1300 464 353 Internet: www.miele.com.au
Miele (Shanghai) Trading Ltd. 1-3 Floor, No. 82 Shi Men Yi Road Jing' an District 200040 Shanghai, PRC Tel: +86 21 6157 3500, Fax: +86 21 6157 3511 E-mail: info@miele.cn, Internet: www.miele.cn
China
41/F - 4101, Manhattan Place 23 Wang Tai Road Kowloon Bay, Hong Kong Tel: (852) 2610 1025, Fax: (852) 3579 1404 Email: customerservices@miele.com.hk Website: www.miele.hk
Miele (Hong Kong) Limited
Miele India Pvt. Ltd. Ground Floor, Copia Corporate Suites Plot No. 9, Jasola, New Delhi - 110025 Tel: 011-46 900 000, Fax: 011-46 900 001 E-mail: customercare@miele.in, Internet: www.miele.in
India
Miele Ireland Ltd. 2024 Bianconi Avenue Citywest Business Campus, Dublin 24 Tel: (01) 461 07 10, Fax: (01) 461 07 97 E-Mail: info@miele.ie, Internet: www.miele.ie
Ireland
Malaysia
Miele Sdn Bhd Suite 12-2, Level 12 Menara Sapura Kencana Petroleum Solaris Dutamas No. 1, Jalan Dutamas 1 50480 Kuala Lumpur, Malaysia Phone: +603-6209-0288 Fax: +603-6205-3768
Miele New Zealand Limited IRD 98 463 631 Level 2, 10 College Hill Freemans Bay, Auckland 1011, NZ Tel: 0800 464 353 Internet: www.miele.co.nz
New Zealand
Miele Pte. Ltd. 163 Penang Road # 04 - 03 Winsland House II Singapore 238463 Tel: +65 6735 1191, Fax: +65 6735 1161 E-Mail: info@miele.com.sg Internet: www.miele.sg
Singapore
Miele (Pty) Ltd 63 Peter Place, Bryanston 2194 P.O. Box 69434, Bryanston 2021 Tel: (011) 875 9000, Fax: (011) 875 9035 E-mail: info@miele.co.za Internet: www.miele.co.za
South Africa
Miele Appliances Ltd. Gold & Diamond Park Office No. 217-6, Sheikh Zayed Road P.O. Box 11 47 82 - Dubai Tel: +971 4 3044 999 Fax: +971 4 3418 852 800-MIELE (64353) E-Mail: info@miele.ae Internet: www.miele.ae
United Arab Emirates
Carl-Miele-Straße 29, 33332 Gütersloh, Germany
Manufacturer:
Miele & Cie. KG
CS 1223-1
M.-Nr. 09 551 700 / 02en-GB
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
