Nokia Bluetooth Headset BH-900 User Guide

9240373

Issue 1

HS-25W_UG_draft5-5.fm Page 2 Wednesday, January 25, 2006 3:02 PM

DECLARATION OF CONFORMITY We, NOKIA CORPORATION declare under our sole responsibility that the product HS-25W is in conformity with the provisions of the following Council Directive: 1999/5/EC. A copy of the Declaration of Conformity can be found at http://www.nokia.com/phones/ declaration_of_conformity/.

The crossed-out wheeled bin means that within the European Union the product must be taken to separate collection at the product end-of-life. Do not dispose of these products as unsorted municipal waste.

Reproduction, transfer, distribution or storage of part or all of the contents in this document in any form without the prior written permission of Nokia is prohibited.

Nokia and Nokia Connecting People are registered trademarks of Nokia Corporation. Other product and company names mentioned herein may be trademarks or tradenames of their respective owners.

Bluetooth is a registered trademark of Bluetooth SIG, Inc.

Nokia operates a policy of continuous development. Nokia reserves the right to make changes and improvements to any of the products described in this document without prior notice.

Under no circumstances shall Nokia be responsible for any loss of data or income or any special, incidental, consequential or indirect damages howsoever caused.

The contents of this document are provided "as is". Except as required by applicable law, no warranties of any kind, either express or implied, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose, are made in relation to the accuracy, reliability or contents of this document. Nokia reserves the right to revise this document or withdraw it at any time without prior notice.

The availability of particular products may vary by region. Please check with the Nokia dealer nearest to you.

Unauthorized changes or modifications to this device may void the user's authority to operate the equipment.

Export Controls This device may contain commodities, technology or software subject to export laws and regulations from the US and other countries. Diversion contrary to law is prohibited.

9240373/Issue 1 EN

HS-25W_UG_draft5-5.fm Page 3 Wednesday, January 25, 2006 3:02 PM

Contents

1. Introduction ......................... 4

Bluetooth wireless technology .......... 4

2. Get started............................ 5

Overview .................................................. 5

Chargers and batteries......................... 5

Charge the battery................................ 6

Switch the headset on or off ............. 6

Pair the headset with

a compatible phone.............................. 6

Disconnect the headset

from the phone................................... 7

Reconnect the paired headset

to your phone...................................... 7

Troubleshooting ..................................... 7

3. Basic use ............................... 9

Place the headset on the ear ............. 9

The sliding boom ................................... 9

Call handling......................................... 10

Adjust the earphone volume............ 10

Mute or unmute the

microphone ........................................... 10

Push to talk (PTT) calls....................... 10

Switch a call between

phone and headset.............................. 11

Use the headset with

several phones...................................... 11

Clear the settings ................................ 12

4. Battery information ........... 13

Care and maintenance ........... 14

FCC Notice .............................. 15

HS-25W_UG_draft5-5.fm Page 4 Wednesday, January 25, 2006 3:02 PM

Introduction

1. Introduction

The Nokia Bluetooth Headset BH-900 allows you freedom to make and receive calls while on the move or in the office. The headset has a sliding boom that allows to answer and end calls and to talk at a lower volume or in a noisy environment.

You can connect the headset to a compatible phone that supports Bluetooth wireless technology.

Read this user guide carefully before using the headset. Read also the user guide for your phone, which provides important safety and maintenance information. Keep the headset out of reach of small children.

■ Bluetooth wireless technology

Bluetooth wireless technology makes it possible to connect compatible communication devices without using cables. A Bluetooth connection does not require that the phone and the headset be in line of sight, but both devices should be within 10 meters (30 feet) of each other. Connections can be subject to interference from obstructions, such as walls or other electronic devices.

The wireless headset is compliant with Bluetooth Specification 2.0 supporting the following profiles: Headset Profile 1.1 and Handsfree Profile 1.5. Check with the manufacturers of other devices to determine their compatibility with this device.

There may be restrictions on using Bluetooth technology in some locations. Check with your local authorities or service provider.

HS-25W_UG_draft5-5.fm Page 5 Wednesday, January 25, 2006 3:02 PM

2. Get started

■ Overview

The headset contains the following parts as shown in the figure:

• Indicator light (1)

• Volume key (2)

• Power key (3)

• Sliding boom (4)

• Answer/end key (5)

• Charger connector (6)

• Earphone (7)

• Microphone (8)

Before you can start using the headset, you must charge the battery and pair the headset with a compatible phone.

Note: Parts of the headset are magnetic. Metallic materials may be attracted to the headset. Do not place credit cards or other magnetic storage media near the headset, because information stored on them may be erased.

Get started

■ Chargers

Check the model number of any charger before using it with this device. The Nokia Bluetooth Headset BH-900 is intended for use with the AC-3, AC-4, and DC-4 chargers.

Warning: Use only chargers approved by Nokia for use with this particular enhancement. The use of any other types may invalidate any approval or warranty, and may be dangerous.

For availability of approved enhancements, please check with your dealer. When you disconnect the power cord of any enhancement, grasp and pull the plug, not the cord.

HS-25W_UG_draft5-5.fm Page 6 Wednesday, January 25, 2006 3:02 PM

Get started

■ Charge the battery

This device has an internal, non-removable, rechargeable battery. Do not attempt to remove the battery from the device as you may damage the device.

1. Connect the charger to a wall outlet.

2. Connect the charger cable to the headset as shown in the figure.

The red indicator light is displayed during charging. If charging does not start, disconnect the charger, plug it in again, and retry. Charging the battery fully may take up to 2 hours.

3. When the battery is fully charged, the green indicator light is displayed. Disconnect the charger from the wall outlet and the headset.

The fully charged battery has power for up to 8 hours of talk-time or up to 180 hours of standby time. However, the talk and standby times may vary when used with different mobile phones or other compatible Bluetooth devices, usage settings, usage styles, and environments.

When the battery is running out of power, the headset beeps, and the red indicator light starts to flash.

■ Switch the headset on or off

To switch on, press and hold the power key. The headset beeps, and the green indicator light starts to flash. The indicator light turns blue when the headset is connected to your phone and ready for use.

To switch off, press and hold the power key. The headset beeps, and the red indicator light is displayed briefly.

■ Pair the headset with a compatible phone

1. Switch on your phone and the headset.

2. Activate the Bluetooth feature on the phone, and set the phone to search for Bluetooth devices. See the user guide of your phone for instructions.

HS-25W_UG_draft5-5.fm Page 7 Wednesday, January 25, 2006 3:02 PM

3. Select the headset (Nokia BH-900) from the list of found devices.

4. Enter the passcode 0000 to pair and connect the headset to your phone. In some phones you may need to make the connection separately after pairing. See the user guide of your phone for details. You only need to pair the headset with your phone once.

5. If the pairing was successful, the headset beeps and appears in the phone menu where you can view the currently paired Bluetooth devices.

Disconnect the headset from the phone

To disconnect the headset from your phone (for example, to connect the phone to another Bluetooth device), do one of the following:

• Switch off the headset.

• Disconnect the headset in the Bluetooth menu of your phone.

• Move the headset more than 10 meters (30 feet) away from the phone.

You do not need to delete the pairing with the headset to disconnect it.

Reconnect the paired headset to your phone

To connect the headset to your phone, switch on the headset, make the connection in the Bluetooth menu of your phone, or press and hold the answer/end key.

You can set your phone to connect with the headset automatically when the headset is switched on. To do this in Nokia phones, change your paired device settings in the Bluetooth menu.

Get started

■ Troubleshooting

If you cannot connect the headset to your phone, do as follows:

• Ensure that the headset is charged, switched on, and paired with your phone.

• Ensure that the Bluetooth feature is activated on your phone.

HS-25W_UG_draft5-5.fm Page 8 Wednesday, January 25, 2006 3:02 PM

Get started

• Check that the headset is within 10 meters (30 feet) of your phone and that there are no obstructions between the headset and the phone, such as walls or other electronic devices.

• To reset the headset if it stops functioning, although it is charged, plug the headset into a charger, and briefly press the power key and the middle of the volume key at the same time. This reset does not clear your settings (for example, pairing settings).

HS-25W_UG_draft5-5.fm Page 9 Wednesday, January 25, 2006 3:02 PM

3. Basic use

■ Place the headset on the ear

Place the headset over your ear into a comfortable position, and point it toward your mouth as shown in the figure.

■ The sliding boom

The sliding boom brings the microphone closer to your mouth, which improves the audio quality even when you talk at a low volume or in a noisy environment. You can use the boom to answer, end, or reject a call.

To use the boom, gently pull it down toward your mouth (1), or push it up to its initial position (2).

Basic use

■ Call handling

To make a call, use your phone in the normal way when the headset is connected to your phone.

If your phone supports redialing, press the answer/end key twice briefly when no call is in progress.

If your phone supports voice dialing, press and hold the answer/end key when no call is in progress, and proceed as described in the user guide of your phone.

To answer a call, pull the boom down toward your mouth, press the answer/end key, or use the phone keys. If the automatic answer function
