Nokia Bluetooth Stereo Headset BH-504 User Guide

???????

Issue 1 EN

HS-123W_UG_en1_with_FCC&IC_notice.fm Page 2 Tuesday, October 7, 2008 4:02 PM

DECLARATION OF CONFORMITY Hereby, NOKIA CORPORATION declares that this HS-123W product is in compliance with the

essential requirements and other relevant provisions of Directive 1999/5/EC. A copy of the Declaration of Conformity can be found at http://www.nokia.com/phones/ declaration_of_conformity/.

Nokia, Nokia Connecting People and the Nokia Original Accessories logo are trademarks or registered trademarks of Nokia Corporation. Other product and company names mentioned herein may be trademarks or tradenames of their respective owners.

Reproduction, transfer, distribution, or storage of part or all of the contents in this document in any form without the prior written permission of Nokia is prohibited.

Bluetooth is a registered trademark of Bluetooth SIG, Inc.

Nokia operates a policy of ongoing development. Nokia reserves the right to make changes and improvements to any of the products described in this document without prior notice.

To the maximum extent permitted by applicable law, under no circumstances shall Nokia or any of its licensors be responsible for any loss of data or income or any special, incidental, consequential or indirect damages howsoever caused.

The contents of this document are provided "as is". Except as required by applicable law, no warranties of any kind, either express or implied, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose, are made in relation to the accuracy, reliability or contents of this document. Nokia reserves the right to revise this document or withdraw it at any time without prior notice.

The availability of particular products may vary by region. Please check with your Nokia dealer for details.

Export controls This device may contain commodities, technology or software subject to export laws and regulations from the US and other countries. Diversion contrary to law is prohibited.

???????/Issue 1 EN

HS-123W_UG_en1_with_FCC&IC_notice.fm Page 3 Tuesday, October 7, 2008 4:02 PM

Contents

1. Introduction ......................... 4

Bluetooth wireless technology .......... 4

2. Get started............................ 5

Keys and parts ........................................ 5

Charge the battery................................ 5

Switch the headset on or off ............. 6

Switch on ............................................. 6

Switch off............................................. 6

Pair the headset with phone

or music player....................................... 6

Disconnect the headset.................... 7

Reconnect the headset..................... 8

3. Basic use ............................... 9

Place the headset over the head....... 9

Adjust the volume................................. 9

Calls........................................................... 9

Listen to music..................................... 10

Clear settings or reset........................ 10

4. Battery and charger

information..............................11

Care and maintenance ........... 12

FCC/Industry Canada notice .. 14

HS-123W_UG_en1_with_FCC&IC_notice.fm Page 4 Tuesday, October 7, 2008 4:02 PM

Introduction

1. Introduction

With the Nokia Bluetooth Stereo Headset BH-504, you can make and answer calls hands-free with your compatible mobile phone and listen to music from a compatible music player.

You can use the headset with compatible devices that support Bluetooth wireless technology.

Read this user guide carefully before using the headset. Also, read the user guide for the device that you connect to the headset. For more information, see www.nokia.com/support or your local Nokia website.

The product may contain small parts. Keep them out of the reach of small children.

■ Bluetooth wireless technology

Bluetooth wireless technology allows you to connect compatible devices without cables. The headset and the other device do not need to be in line of sight, but they should be within 10 metres (33 feet) of each other. The closer the headset and the other device are to each other, the better the performance. The optimal operating range is shown in dark grey in the picture. The connection is subject to interference from distance and obstructions (shown in light grey) or other electronic devices.

The headset is compliant with the Bluetooth Specification 2.1 + EDR supporting the following profiles: Headset Profile 1.1, Hands-Free Profile (HFP) 1.5, Advanced Audio Distribution Profile (A2DP) 1.0, and Audio Video Remote Control Profile 1.0. Check with the manufacturers of other devices to determine their compatibility with this device.

<10m

HS-123W_UG_en1_with_FCC&IC_notice.fm Page 5 Tuesday, October 7, 2008 4:02 PM

Get started

2. Get started

■ Keys and parts

The headset contains the following parts:

1. Indicator lights

2. Charger connector

3. Volume keys

4. Rewind key

5. Multifunction key

6. Play/pause key

7. Fast forward key

8. Microphone

Before using the headset, you must charge the battery and pair the headset with a compatible device.

Parts of the device are magnetic. Metallic materials may be attracted to the device. Do not place credit cards or other magnetic storage media near the device, because information stored on them may be erased.

■ Charge the battery

Before charging the battery, carefully read “Battery and charger information”, p. 11.

Warning: Use only chargers approved by Nokia for use with this particular model. The use of any other types may invalidate any approval or warranty, and may be dangerous.

When you disconnect the power cord of any accessory, grasp and pull the plug, not the cord.

1. Connect the charger to a wall outlet.

2. Connect the charger cable to the charger connector. The red

indicator light is displayed during charging.
