Nokia Bluetooth Display Car Kit CK-15W User and Installation Guide

9200326

Issue 1 EN

9200326_en1.fm Page 2 Thursday, January 25, 2007 11:09 AM

DECLARATION OF CONFORMITY Hereby, NOKIA CORPORATION, declares that this HF-15 product is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. The product is in conformity with the limits defined in Directive 2004/104/EC (amending Directive 72/245/ EEC), Annex I, paragraph 6.5, 6.6, 6.8 and 6.9. A copy of the Declaration of Conformity can be found at http://www.nokia.com/phones/declaration_of_conformity/.

Reproduction, transfer, distribution or storage of part or all of the contents of this document in any form without the prior written permission of Nokia is prohibited.

Nokia, Nokia Connecting People, and Navi are trademarks or registered trademarks of Nokia Corporation. Other product and company names mentioned herein may be trademarks or tradenames of their respective owners.

Bluetooth is a registered trademark of Bluetooth SIG, Inc.

Nokia operates a policy of ongoing development. Nokia reserves the right to make changes and improvements to any of the products described in this document without prior notice.

Under no circumstances shall Nokia be responsible for any loss of data or income or any special, incidental, consequential or indirect damages howsoever caused.

The contents of this document are provided “as is”. Except as required by applicable law, no warranties of any kind, either express or implied, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose, are made in relation to the accuracy, reliability or contents of this document. Nokia reserves the right to revise this document or withdraw it at any time without prior notice.

The availability of particular products may vary by region. Please check with the Nokia dealer nearest to you.

Unauthorized changes or modifications to this device may void the user's authority to operate the equipment.

Export Controls This device may contain commodities, technology or software subject to export laws and regulations from the US and other countries. Diversion contrary to law is prohibited.

9200326 / Issue 1 EN

9200326_en1.fm Page 3 Thursday, January 25, 2007 11:09 AM

Contents

For your safety......................... 4

Quick start................................ 5

The input device..................................... 5

First time setup ...................................... 6

1. Introduction ......................... 7

About this document............................ 7

Bluetooth wireless technology .......... 7

2. Get started............................ 9

Parts .......................................................... 9

Input device....................................... 10

Display and standby mode ............ 10

Navigate the menus............................ 11

Switch the car kit on or off .............. 11

Switch on ........................................... 11

Switch off........................................... 11

First time use........................................ 12

Pair and connect the car kit............. 12

Connect the car kit manually....... 13

Connect the car kit automatically 13

Disconnect the car kit..................... 13

Clear the list of paired devices..... 14

3. Call functions..................... 15

Adjust the loudspeaker volume ....... 15

Make a call............................................ 15

Speed dialing ........................................ 15

Answer a call ........................................ 16

Mute or unmute the microphone... 16 Switch a call between car kit

and connected device ........................ 16

Send DTMF tones................................. 17

4. Menu functions.................. 18

Contacts ................................................. 18

Search for a contact ....................... 18

Speed dials......................................... 18

Copy contacts from mobile

device to car kit................................ 19

Call register........................................... 19

Bluetooth settings............................... 19

Display settings.................................... 20

Other settings....................................... 20

Reset the car kit................................... 21

Troubleshooting ................................... 21

5. Installation.......................... 23

Safety information.............................. 23

Install the car kit in a vehicle .......... 24

Hands-free unit HF-15................... 25

Input device CU-8............................ 26

Display unit SU-29 .......................... 27

Loudspeaker SP-3 ............................ 28

Microphone MP-2............................ 28

Power cable PCU-4.......................... 29

Optional enhancements..................... 30

Mobile holder.................................... 30

Antenna coupler and

external antenna.............................. 30

Check the operation

of the car kit......................................... 31

Care and maintenance ........... 32

Additional safety

information............................. 33

FCC/Industry Canada

notice ...................................... 34

9200326_en1.fm Page 4 Thursday, January 25, 2007 11:09 AM

For your safety

Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user guide for further information.

Your device and its enhancements may contain small parts. Keep them out of reach of small children.

SWITCH ON SAFELY

Do not switch the device on when wireless phone use is prohibited or when it may cause interference or danger.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.

INTERFERENCE

All wireless devices may be susceptible to interference, which could affect performance.

SWITCH OFF WHEN REFUELING

Do not use the device at a refueling point. Do not use near fuel or chemicals.

SWITCH OFF NEAR BLASTING

Follow any restrictions. Do not use the device where blasting is in progress.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

ENHANCEMENTS

Use only approved enhancements. Do not connect incompatible products.

CONNECTING TO OTHER DEVICES

When connecting to any other device, read its user guide for detailed safety instructions. Do not connect incompatible products.

9200326_en1.fm Page 5 Thursday, January 25, 2007 11:09 AM

Quick start

This section briefly describes the basic features of the car kit. For details, refer to the respective sections in this guide.

■ The input device

Microphone mute key (1)

• Press to set the car kit volume to silent in the standby mode or when you receive a call.

• Press to mute or unmute the microphone during a call.

• Press and hold to switch an active call from the car kit to the compatible mobile device connected to it.

Voice dialing key (2)

• Press to activate voice dialing with a compatible mobile device when you are not in a call.

Call key (3)

• Press to make or answer a call or to switch between an active call and a call on hold.

• Press to view the list of last dialed numbers in the standby mode.

• Press twice to redial the last dialed number in the standby mode.

Quick start

End key (4)

• Press to end or reject a call.

• Press to delete a single character when you write text or numbers.

• Press to return to the previous menu level or display view.

• Press and hold to return to the standby mode from the menu functions.

9200326_en1.fm Page 6 Thursday, January 25, 2007 11:09 AM

Quick start

• Press and hold to switch the car kit on or off (if the car kit is not connected to the ignition system).

Indicator light (5)

Shows that the car kit is switched on.

NaviTM wheel (6)

• Turn left or right to adjust the volume during a call or to scroll through different lists.

• Turn left in the standby mode to enter a phone number or to use speed dialing.

• Turn right in the standby mode to search for a contact in Contacts.

• Press to perform the function shown at the bottom of the display.

■ First time setup

1. Switch on your mobile device and car kit (see p. 11).

2. When prompted to select a language for the texts on the car kit display, turn the Navi wheel to scroll to the desired language, and press the Navi wheel.

3. Activate the Bluetooth feature on your mobile device, and pair and connect the car kit with a compatible mobile device using Bluetooth wireless technology.

4. When you are prompted to copy the contacts from the connected mobile device to the car kit, turn the Navi wheel to scroll to Yes, and press the Navi wheel to start the copying. If you select No, you cannot use your saved contacts to make calls with the car kit.

9200326_en1.fm Page 7 Thursday, January 25, 2007 11:09 AM

Introduction

1. Introduction

With the Nokia Bluetooth Display Car Kit CK-15W you can conveniently make and answer calls hands-free. You can also copy contacts from your compatible mobile device to the car kit, and access the contacts on the supplied display. The car kit and its menu functions can be controlled with the supplied input device.

The car kit can be connected to a compatible mobile device using Bluetooth wireless technology.

Read this guide carefully before having the car kit professionally installed and using it. Also read the user guide for your mobile device, which provides important safety and maintenance information. Check www.nokia.com/support or your local Nokia website for the latest version of the user guide, additional information, downloads, and services related to your Nokia product.

Keep all enhancements out of the reach of small children.

■ About this document

The setup and operation of the car kit are described in “Get started,” p. 9 and “Menu functions,” p. 18.

The installation of the car kit is described in “Installation,” p. 23. The car kit should only be installed by a qualified service technician using the approved original Nokia parts supplied in the sales package of the car kit.

■ Bluetooth wireless technology

Bluetooth wireless technology allows you to connect compatible devices without cables. A Bluetooth connection does not require that the mobile device and the car kit be in line of sight, but both devices should be within 10 meters (30 feet) of each other. Connections may be subject to interference from obstructions, such as walls, or other electronic devices.

9200326_en1.fm Page 8 Thursday, January 25, 2007 11:09 AM

Introduction

The car kit is compliant with Bluetooth Specification 1.2 that supports the following profiles: Handsfree Profile 1.5 (to use the car kit hands free with your mobile device) and Phone Book Access Profile (PBAP) 1.0 (to copy contacts from your mobile device to the car kit). Check with the manufacturers of other devices to determine their compatibility with this device.

There may be restrictions on using Bluetooth technology in some locations. Check with your local authorities or service provider.

9200326_en1.fm Page 9 Thursday, January 25, 2007 11:09 AM

2. Get started

■ Parts

The car kit contains the following parts:

Get started

• Hands-free unit HF-15 (1)

• Microphone MP-2 (2)

• Loudspeaker SP-3 (3)

• Input device CU-8 (4)

• Display unit SU-29 including system cable CA-115 (5)

• Power cable PCU-4 (6)

9200326_en1.fm Page 10 Thursday, January 25, 2007 11:09 AM

Get started

Input device

The input device contains the following parts:

• Microphone mute key (1)

• Voice dialing key (2)

• Call key (3)

• End key (4)

• Indicator light (5)

• Navi wheel (6)

Display and standby mode

You can rotate the display up to approximately 30 degrees up, left, or right, and up to approximately 10 degrees down. Do not try to force the display to rotate more.

When the car kit is in the standby mode and connected to a compatible mobile device using Bluetooth wireless technology, and the mobile device is registered to a cellular network, the following information is shown on the display:

• Name of the mobile device, or the name of the car kit (1); the mobile device name can be defined in the Bluetooth menu of the device.

• Signal strength of the cellular network at the current location (2) if this information is provided by the mobile device; the higher the bar, the stronger the signal

• Name or logo of the network operator or service provider (3)

• Battery status of the mobile device (4) if this information is provided by the device; the higher the bar, the more power left

9200326_en1.fm Page 11 Thursday, January 25, 2007 11:09 AM

• Function that can be performed by pressing the Navi wheel (5); in the standby mode, pressing the Navi wheel opens the list of menu functions

To enter a phone number manually or use speed dialing, turn the Navi wheel to left.

To search for a contact from Contacts in the car kit, turn the Navi wheel to right.

■ Navigate the menus

Many of the car kit functions are grouped into menus.

To open the list of menu functions in the standby mode, press the Navi wheel when Menu is displayed at the bottom of the display.

To scroll to an item (such as a menu function) or through a list, turn the Navi wheel left or right. To select the item, press the Navi wheel.

To return to the previous menu level, press . To return to the standby mode, press and hold until the standby mode screen is displayed.

■ Switch the car kit on or off

Switch on

If the ignition sense wire is not connected, press and hold . (To connect the ignition sense wire, contact your service technician.)

If the ignition sense wire is connected, turn on the car ignition.

When the car kit is switched on, the display and the indicator light of the input device turn on.

Get started

Switch off

If the ignition sense wire is not connected, press and hold for 5 seconds. The car kit switches off after 2 minutes. When the car kit switches off, the display turns off. After you turn off the car ignition, do not leave the mobile device connected to the car kit to prevent accidental draining of the car battery.
