Nokia Home Music User Guide

???????

Issue 1

HD-1_UG_with_FCC&IC_notice_en1_Update2.fm Page 2 Wednesday, June 17, 2009 5:28 PM

DECLARATION OF CONFORMITY Hereby, NOKIA CORPORATION declares that this HD-1 product is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/ EC. A copy of the Declaration of Conformity can be found at http://www.nokia.com/phones/declaration_of_conformity/.

Nokia and Nokia Connecting People are trademarks or registered trademarks of Nokia Corporation. Other product and company names mentioned herein may be trademarks or tradenames of their respective owners.

Reproduction, transfer, distribution, or storage of part or all of the contents in this document in any form without the prior written permission of Nokia is prohibited.

Nokia operates a policy of ongoing development. Nokia reserves the right to make changes and improvements to any of the products described in this document without prior notice.

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, UNDER NO CIRCUMSTANCES SHALL NOKIA OR ANY OF ITS LICENSORS BE RESPONSI BLE FOR ANY L OSS OF DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES HOWSOEVER CAUSED.

THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS". EXCEPT AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE.

The availability of particular products and services for these products may vary by region. Please check with your Nokia dealer for details, and availability of language options.

Export controls This device may contain commodities, technology or software subject to export laws and regulations from the US and other countries. Diversion contrary to law is prohibited.

???????/Issue 1 EN

HD-1_UG_with_FCC&IC_notice_en1_Update2.fm Page 3 Wednesday, June 17, 2009 5:28 PM

Contents

1. Quick start............................ 5

Switch on................................................. 5

First time setup ...................................... 5

Listen to different audio

sources...................................................... 6

2. Introduction ......................... 7

Broadband internet connection......... 7

3. Your device........................... 9

Keys and parts ........................................ 9

Front view............................................. 9

Back view............................................ 10

Remote control ................................. 11

Antenna locations ............................... 12

Bass reflex tube.................................... 12

Textile front cover ............................... 12

4. Get started.......................... 13

Connect to a wall outlet.................... 13

Install remote control batteries....... 13

Switch on or off ................................... 14

Standby mode....................................... 14

Operate with the remote control .... 14

5. Basic functions................... 15

Main view .............................................. 15

Folders for different audio

sources ................................................ 15

Display indicators............................. 16

Scroll and select................................... 17

Adjust or mute the volume .............. 17

Save a preset or favourite ................ 18

Write text.............................................. 18

Common options................................. 19

6. Set up a connection........... 20

Connect to a network........................ 20

Connect to a WLAN ........................ 20

Connect to a LAN ............................ 21

Connect to a UPnP device............. 21

Connect directly to another

device ..................................................... 22

Connect to a USB device............... 22

Connect to an RCA or

S/PDIF device .................................... 22

Connect to headphones................. 23

Connect to an audio source

device.................................................. 23

7. Podcasts.............................. 24

Search for podcasts............................ 24

Listen to a podcast ............................. 25

Available options................................. 25

8. Radio ................................... 26

Listen to a radio station.................... 26

Search for internet radio

stations .................................................. 27

Search for FM radio stations........... 28

HD-1_UG_with_FCC&IC_notice_en1_Update2.fm Page 4 Wednesday, June 17, 2009 5:28 PM

9. Jukebox............................... 29

Listen to music from

a connected device............................. 29

10. Favourites and History.... 31

11. Alarms and sleep

timer ....................................... 32

Set alarms ............................................. 32

Sleep timer............................................ 33

12.Tools and settings ............ 34

Time and date ...................................... 34

Device settings..................................... 34

Network settings................................. 34

Maintenance tools.............................. 35

13.Miscellaneous ................... 37

Supported file formats and

protocols................................................ 37

Digital rights management .............. 37

Care and maintenance........... 39

Additional safety

information ............................ 41

FCC/Industry Canada

notice...................................... 43

Open source software

notice...................................... 44

HD-1_UG_with_FCC&IC_notice_en1_Update2.fm Page 5 Wednesday, June 17, 2009 5:28 PM

Quick start

1. Quick start

Nokia Home Music allows you to enjoy internet radio, podcasts, FM radio, and songs from different sources (such as mobile phones and PCs) at home.

■ Switch on

Plug the supplied AC adapter into the power connector on Nokia Home Music, and connect the adapter to a wall outlet.

To switch on, push the power switch up at the back of the device.

■ First time setup

1. Switch on Nokia Home Music.

2. When prompted, turn the scroll wheel and press the selection key to select the device language, and start the setup wizard to connect the device to your wired network (LAN) or a wireless network (WLAN).

If you want to connect the device to your LAN, plug a compatible ethernet cable into the device and your network router or LAN wall outlet.

3. Select the network type, and define the required settings. Protected networks are indicated by . For the correct settings, contact your network service provider. For details, see “Network settings”, p. 34.

HD-1_UG_with_FCC&IC_notice_en1_Update2.fm Page 6 Wednesday, June 17, 2009 5:28 PM

Quick start

After you have defined the settings, the device attempts to connect to the internet through the network.

4. Select your time zone, the country and city where you are located, and the time and date.

5. After you have defined the settings, the main view is displayed and you can start using the device with the specified connection.

■ Listen to different audio sources

Select one of the following folders in the main view:

• Podcast ( ) — Browse for hundreds of podcasts through the Nokia podcast directory.

• Radio ( ) — Search for FM and internet radio stations from all over the world.

• Favourites ( ) — Listen to radio broadcasts, podcasts, songs, and playlists that you have saved as favourites.

• Jukebox ( ) — Access the songs that you have in your mobile phone, PC, USB memory stick, and other compatible devices.

• History ( ) — Access the radio broadcasts, podcasts, songs, and playlists that you have listened to lately.

HD-1_UG_with_FCC&IC_notice_en1_Update2.fm Page 7 Wednesday, June 17, 2009 5:28 PM

Introduction

2. Introduction

With Nokia Home Music, you can listen to internet radio, podcasts, FM radio, and songs from different sources (such as mobile phones and PCs).

The device comes with a remote control that allows you to easily operate the device from a distance.

Read this guide carefully before using Nokia Home Music. Also read the user guides for the other devices that you connect to Nokia Home Music. For the latest guides, additional information, downloads, and services related to your Nokia product, see www.nokia.com/support or your local Nokia website.

Nokia may produce software updates that may offer new features, enhanced functions, or improved performance. To update the device software, see “Maintenance tools”, p. 35.

This product may contain small parts. Keep them out of the reach of small children. The surface of this device is nickel-free.

■ Broadband internet connection

To access podcasts or internet radio stations and to update the device software, you need a broadband internet connection. You must also have a compatible ethernet wired network or an IEEE 802.11 b/g compatible wireless network that is properly set up.

Listening to internet audio sources and downloading software updates may involve the transmission of large amounts of data through your

HD-1_UG_with_FCC&IC_notice_en1_Update2.fm Page 8 Wednesday, June 17, 2009 5:28 PM

Introduction

service provider's network. Contact your service provider for information about data transmission charges.

HD-1_UG_with_FCC&IC_notice_en1_Update2.fm Page 9 Wednesday, June 17, 2009 5:28 PM

Your device

3. Your device

■ Keys and parts

Parts of the device are magnetic. Metallic materials may be attracted to the device. Do not place credit cards or other magnetic storage media near the device, because information stored on them may be erased.

Front view

1. Standby key

2. Display

3. Scroll wheel

4. Infrared port

5. Option key

6. Home key

7. Favourites key

8. Back key

9. Selection key

10. Loudspeaker

11. P re se t ke ys

12. 3.5 mm headphone connector

13. Rewind key

14. Volume wheel

HD-1_UG_with_FCC&IC_notice_en1_Update2.fm Page 10 Wednesday, June 17, 2009 5:28 PM

Your device

15. Mute/Unmute key

16. Forward key

17. Play/Pause key

Back view

1. Power switch

2. Power connector

3. USB connector

4. Ethernet connector with indicator lights

5. 3.5 mm audio input (indicated with AUX IN)

6. S/PDIF optical output

7. RCA outputs

8. Connector for an FM radio antenna

9. Bass reflex tube

HD-1_UG_with_FCC&IC_notice_en1_Update2.fm Page 11 Wednesday, June 17, 2009 5:28 PM

Your device

Remote control

1. Infrared port

2. Standby key

3. Home key

4. Favourites key

5. Option key

6. Back key

7. Scroll key

8. Selection key

9. Play/Pause key

10. Rewind key

11. F or wa rd k ey

12. Volume down key

13. Volume up key

14. Mute/Unmute key

15. Preset keys

10 12 14

11 13

HD-1_UG_with_FCC&IC_notice_en1_Update2.fm Page 12 Wednesday, June 17, 2009 5:28 PM

Your device

■ Antenna locations

Your device has internal antennas. As with any radio transmitting device, avoid touching the antenna area unnecessarily while the antenna is transmitting or receiving. Contac t with such an antenna affects the communication quality and may cause the device to operate at a higher power level than otherwise needed.

■ Bass reflex tube

Nokia Home Music has a bass reflex tube that improves the reproduction of low sounds. Do not insert any objects into the tube.

For best sound quality, leave some free space behind the device so that air can flow freely from the tube.

■ Textile front cover

You can dust the textile of the front cover using a soft brush or a dry cloth.

To clean the textile, run a slightly damp white cloth over it. Avoid the use of printed absorbent cloths as they can release ink onto the textile.

Do not use the product with dirty or greasy hands.

HD-1_UG_with_FCC&IC_notice_en1_Update2.fm Page 13 Wednesday, June 17, 2009 5:28 PM

Get started

4. Get started

■ Connect to a wall outlet

Nokia Home Music is powered by the supplied AC adapter. The AC adapter is only meant for indoor use.

Plug the adapter into the power connector, and connect the adapter to a wall outlet.

When you disconnect the power cord, grasp and pull the plug, not the cord.

■ Install remote control batteries

The remote control is powered by two AAA batteries.

1. To remove the battery cover, press and hold the release button (1), and lift the cover (2).

2. Insert the batteries as indicated in the battery compartment.

3. To replace the cover, insert the catch at the top of the cover into the corresponding slot on the remote control, and push the cover against the remote control until it locks into place.

HD-1_UG_with_FCC&IC_notice_en1_Update2.fm Page 14 Wednesday, June 17, 2009 5:28 PM

Get started

■ Switch on or off

To switch on, push the power switch up at the back of the device. The display turns on, and Nokia Home Music tries to connect to the internet if you have defined the network settings. When the device is ready for use, the main view is displayed. For details, see “Main view”, p. 15.

To switch off, push the power switch down. The display turns off.

■ Standby mode

To set Nokia Home Music to standby mode, press the standby key. In standby mode, the current date and time are displayed.

To exit standby mode, press the standby key. If you were listening to an audio source when you set the device to standby mode, the source resumes playing.

■ Operate with the remote control

To operate Nokia Home Music with the supplied remote control, point the infrared port on the remote control towards the display.

Do not allow the infrared (IR) beam to interfere with other IR devices.

HD-1_UG_with_FCC&IC_notice_en1_Update2.fm Page 15 Wednesday, June 17, 2009 5:28 PM

Basic functions

5. Basic functions

■ Main view

When you switch on Nokia Home Music, the main view is displayed. The main view shows the folders for different audio sources, date and time, and details of the currently playing source (such as an internet radio station) if the details are provided by the source.

Folders for different audio sources

In the main view, the following folders are available:

• Podcast ( ) — Listen to podcast episodes. See “Podcasts”, p. 24.

• Radio ( ) — Listen to internet radio and FM radio stations. See “Radio”, p. 26.

• Favourites ( ) — Listen to radio broadcasts, podcasts, songs, and playlists that you have saved as favourites. See “Save a preset or favourite”, p. 18, and “Favourites and History”, p. 31.

• Jukebox ( ) — Listen to music from a compatible USB device or a Universal Plug and Play (UPnP) device such as a mobile phone. See “Jukebox”, p. 29.

• History ( ) — Listen to recently used audio sources. See “Favourites and History”, p. 31.
