MAXDATA M-Book 6000 G4 User Manual

V15.1.00

Preface

Notice

The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication. This publication and any accompanying software may not, in whole or in part, be reproduced, translated, transmitted or reduced to any machine readable form without prior consent from the vendor, manufacturer or creators of this publication, except for copies kept by the user for backup purposes. Brand and product names mentioned in this publication may or may not be copyrights and/or registered trademarks of their respective companies. They are mentioned for identification purposes only and are not intended as an endorsement of that product or its manufacturer. ©July 2015

Trademarks

Intel, Pentium and Intel Core are trademarks/registered trademarks of Intel Corporation.

Preface

R&TTE Directive

This device is in compliance with the essential requirements and other relevant provisions of the R&TTE Directive 1999/5/EC.

This device will be sold in the following EEA countries: Austria, Italy, Belgium, Liechtenstein, Denmark, Luxembourg, Finland, Netherlands, France, Norway, Germany, Portugal, Greece, Spain, Iceland, Sweden, Ireland, United Kingdom, Cyprus, Czech Republic, Estonia, Hungary, Latvia, Lithuania, Malta, Slovakia, Poland, Slovenia.

ErP Off Mode Power Consumption Statement:

The figures below note the power consumption of this computer in compliance with European Commission (EC) regulations on power consumption in off mode:

• Off Mode < 0.5W

III

Preface

CE Marking

This device has been tested to and conforms to the regulatory requirements of the European Union and has attained CE Marking. The CE Mark is a conformity marking consisting of the letters “CE”. The CE Mark applies to products regulated by certain European health, safety and environmental protection legislation. The CE Mark is obligatory for products it applies to: the manufacturer affixes the marking in order to be allowed to sell his product in the European market.

This product conforms to the essential requirements of the R&TTE directive 1999/5/EC in order to attain CE Marking. A notified body has determined that this device has properly demonstrated that the requirements of the directive have been met and has issued a favorable certificate of expert opinion. As such the device will bear the notified body number 0560 after the CE mark.

The CE Marking is not a quality mark. Foremost, it refers to the safety rather than to the quality of a product. Secondly, CE Marking is mandatory for the product it applies to, whereas mo st q uality marking s are voluntary.

Energy Star©

Energy Star© is a registered trademark of the U.S Environmental Protection Agency (EPA). As an Energy Star© partner, the manufacturer of this computer has determined that this product meets the Energy Star© guidelines for energy efficiency.

Preface

FCC Statement

(Federal Communications Commission)

You are cautioned that changes or modifications not expressly approved by the party responsible for comp liance could void the user's authority to operate the equipment.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Re orient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the service representative or an experienc e d ra di o/TV technician for help.

Operation is subject to the following two conditions:

1. This device may not cause interference. And

2. This device must accept any interference, including interference that may cause undesired operation of the

device.

Preface

FCC RF Radiation Exposure Statement:

1. This Transmitter must not be co-l ocated or operating in conjunction with any other antenna or transmitter.

2. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environ ment. This

equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.



Warning

Use only shielded cables to connect I/O devices to this equipment. You are cautioned that changes or modifications not expressly approved by the manufacturer for compliance with the above standard s could void your authority to operate the equipment.

If your purchase option includes both Wireless LAN and 3G/4G module s, then the appropriate antennas will be instal led. Note that In order to comply with FCC RF exposure compliance requirements, the antenna must not be co-located or operate in conjunction with any other antenna or transmitter.

Important Notice - 3G/4G & Bluetooth/Wireless LAN Modules

In order to comply with FCC regulations you should NOT operate the 3G/4G module and the Bluetooth/Wireless LAN modules at the same time as this may disrupt radio frequency, and cause interference. When the 3G/4G module is powered on, make sure that the Bluetooth/Wireless LAN modules are powered off.

Preface

IMPORTANT SAFETY INSTRUCTIONS

Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment:

1. Do not use this product near water, for example n ear a ba th tub, wash bowl, kitchen sink or laundry tu b, in a wet

basement or near a swimming pool.

2. Avoid using this equipment with a telephone line (other than a cordless type) during an electrical storm. There

may be a remote risk of electrical shock from lightning.

3. Do not use the telephone to report a gas leak in the vicinity of the leak.

4. Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They may

explode. Check with local codes for possible special disposal instructions.

5. This product is intended to be supplied by a Listed Power Unit with an AC Input of 100 - 240V, 50 - 60Hz, DC

Output of 19V, 3.42A (65 Watts) minimum AC/DC Adapter.

VII

Preface

Instructions for Care and Operation

The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions:

1. Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged.

2. Keep it dry, and don’t overheat it. Keep the computer and power supply away from any kind of heating ele-

ment. This is an electrical appliance. If water or any other liquid gets into it, the computer could be badly damaged.

Do not expose the computer to any shock or vibration.

Do not place it on an unstable surface.

Do not place anything heavy on the computer.

Do not expose it to excessive heat or direct sunlight.

Do not leave it in a place where foreign matter or moisture may affect the system.

Don’t use or store the computer in a humid environment.

Do not place the computer on any surface that will block the Vents/Fan Intakes.

VIII

Preface

3. Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other

strong magnetic fields. These can hinder proper performance and damage your data.

4. Follow the proper workin g proc edur es for t he computer. Shut the computer down properly and don’t forget

to save your work. Remember to periodically save your data as data may be lost if the battery is depleted.

5. Take care when using peripheral devices.

Do not turn off the power until you properly shut down all programs.

Do not turn off any peripheral devices when the computer is on.

Do not disassemble the computer by yourself.

Perform routine maintenance on your computer.

Use only approved brands of peripherals.

Unplug the power cord befor e attaching peripheral devices.

Preface

Power Safety

The computer has specific power requirements:

• Only use a power adapter approved for use with this computer.

• Your AC/DC adapter may be designed for international travel but it still requires a

steady , uninte rrupted power suppl y. If you are unsure of your local power specifications, consult your service representative or local power company.

• The power adapter may have either a 2-prong or a 3-prong grounded plug. The third

prong is an important safety feature; do not defeat its purpose. If you do not have access to a compatible outlet, have a qualified electrician install one.

• When you want to unplug the power cord, be sure to disconnect it by the plug head, not

by its wire.

• Make sure the socket and any extension cord(s) you use can support the total current

load of all the connected devices.

• Before cleaning the computer, make sure it is disconnected from any external power

supplies (i.e. AC/DC adapter or car adapter).

Do not plug in the power cord if you are wet.

Do not use the power cord if it is broken.

Do not place heavy objects on the power cord.



Power Safety

Warning

Before you undertake any upgrade procedures, make sure that you have turned off the power, and disconnected all peripherals and cables (including telephone lines and power cord).

You must also remove your battery in order to prevent accidentally turning the machine on. Before removing

the battery disconnect the AC/DC adapter from the computer.

Preface

Polymer Battery Precautions

Note the following information which is specific to polymer batteries only, and where applicable, this overrides the general battery precaution information overleaf.

• Polymer batteries may experience a slight expansio n or swelling, however this is part of the battery’s safety mecha-

nism and is not a cause for concern.

• Use proper handling procedures when using polymer batteries. Do not use polymer batteries in high ambient tempera-

ture environments, and do not store unused batteries for extended per iods.

See also the general battery precautionary information overleaf for further information.

Preface

Battery Precautions

• Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer.

• Do not remove any batteries from the computer while it is powered on.

• Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even

if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.

• If you do not use the battery for an extended period, then remove the battery from the computer for storage.

• Recharge the batteries using the notebook’s system. Incorrect recharging may make the battery explode.

• Do not try to repair a battery pack. Refer any battery pack repa ir or replac ement to your service repre sentati ve or qual-

ified service personnel.

• Keep children away from, and promptly dispose of a damaged battery. Always dispose of batteries carefully. Batteries

may explode or leak if exposed to fire, or improperly handled or discarded.

• Keep the battery away from metal appliances.

• Affix tape to the battery contacts before disposing of the battery.

• Do not touch the battery contacts with your hands or metal objects.



Battery Disposal & Caution

The product that you have purchased contains a rechargeable battery. The battery is recyclable. At the end of its useful life, under various state and local laws, it may be illegal to dispose of this battery in to the municipal waste stream. Check with your local solid waste officials for details in your area for recycling options or proper disposal.

Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalen t type recommended by the manufacturer. Discard used battery according to the manufacturer’s instructions.

XII

Preface

Cleaning

Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer.

Servicing

Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock. Refer all servicing to authorized service personnel. Unplug the computer from the power supply. Then refer servicing to qualified service personnel under any of the following conditions:

• When the power cord or AC/DC adapter is damaged or frayed.

• If the computer has been exposed to rain or other liquids.

• If the computer does not work normally when you follow the operating instructions.

• If the computer has been dropped or damaged (do not touch the poisonous liquid if the LCD panel breaks).

• If there is an unusual odor, heat or smoke coming from your computer.



Removal Warning

When removing any cover(s) and screw(s) for the purposes of device upg rade, remember to replace the cover(s) and screw(s) before restoring power to the system.

Also note the following when the cover is removed:

• Hazardous moving parts.

• Keep away from moving fan blades.

XIII

Preface

Travel Considerations

Packing

As you get ready for your trip, run through this list to make sure the system is ready to go:

1. Check that the battery pack and any spares are fully charged.

2. Power off the computer and peripherals.

3. Close the display panel and make sure it’s latched.

4. Disconnect the AC/DC adapter and cables. Stow them in the carrying bag.

5. The AC/DC adapter uses volt ages from 100 to 240 volt s so you won’t need a second volt age adapte r. However,

check with your travel agent to see if you need any socket adapters.

6. Put the notebook in its carrying bag and secure it with the bag’s straps.

7. If you’re taking any peripherals (e.g. a printer, mouse or digital camera), pack them and those devices’ adapters

and/or cables.

8. Anticipate customs - Some jurisdictions may have import restrictions or r equire proof of ownersh ip for both ha rd-

ware and software. Make sure your documents are prepared.



Power Off Before Traveling

Make sure that your notebook is completely powered off before putting it into a travel bag (or any such container). Putting a notebook which is powered on in a travel bag may cause the vent(s)/fan intake(s)/outlet(s) to be blocked. To pre vent your computer from overheating make sure nothing blocks the vent(s)/fan intake(s)/outlet(s) while the computer is in use.

XIV

Preface

On the Road

In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting, keep these points in mind:

Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common. Don’t check it with normal luggage. Baggage handlers may not be sufficiently careful. Avoid knocking the computer against hard objects.

Beware of Electromagnetic fields - Devices such as metal detectors & X-ray machines can damage the computer, hard disk, floppy disks, and other media. They may also destroy any stored data - Pass your computer and disks around the devices. Ask security officials to hand-inspect them (you may be asked to turn it on). Note: Some airports also scan luggage with these devices.

Fly safely - Most airlines have regulations about the use of computers and other electronic devices in flight. These restrictions are for your safety, follow them. If you stow the notebook in an overhead compartment, make sure it’s secure. Contents may shift and/or fall out when the compartment is opened.

Get power where you can - If an electrical outlet is available, use the AC/DC adapter and keep your battery(ies) charged.

Keep it dry - If you move quickly from a cold to a warm location, water vapor can condense inside the computer. Wait a few minutes before turning it on so that any moisture can evaporate.

Preface

Developing Good Work Habits

Developing good work habits is important if you need to work in fron t of the computer for long periods o f time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints. The following are some tips to reduce the strain:

• Adjust the height of the chair a nd/or desk so that the ke yboard is a t or sligh tly below the level

of your elbow. Keep your forearms, wrists, and hands in a relaxed position.

• Your knees should be slightly higher than your hips. Place your feet flat on the floor or on a

footrest if necessary.

• Use a chair with a back and adjust it to support your lower back comfortably.

• Sit straight so that your knees, hips and elbows form approximately 90-degree angles when

you are working.

• Take periodic breaks if you are using the computer for long periods of time.

Remember to:

• Alter your posture frequently.

• Stretch and exercise your body several times a day.

• Take periodic breaks when you work at the computer for long periods of time. Frequent and

short breaks are better than fewer and longer breaks.

XVI

Preface

Lighting

Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and shoulders.

• Position the display to avoid glare or reflecti ons from overhead lighting or outside sources of light.

• Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly.

• Position the display directly in front of you at a comfortable viewing distance.

• Adjust the display-viewing angle to find the best position.

LCD Screen Care

To prevent image persistence on LCD monitors (caused by the continuous display of graphics on the screen for an extended period of time) take the following precautions:

• Set the Windows Power Plans to turn the screen off after a few minutes of screen idle time.

• Use a rotating, moving or blank screen saver (this prevents an image from being displayed too long).

• Rotate desktop background images every few days.

• Turn the monitor off when the system is not in use.

LCD Electro-Plated Logos

Note that in computers featuring a raised LCD electro-plated logo, the logo is covered by a protective adhesive. Due to general wear and tear, this adhesive may deteriorate over time and the exposed logo may develop sharp edges. Be careful when handling the computer in this case, and avoid touching the raised LCD electro-plated logo. Avoid placing any other items in the carrying bag which may rub against the top of the computer during transport. If any such wear and tear develops contact your distributor/supplier.

XVII

Preface

Contents

Notice .............................................................................................................................................................I

ErP Off Mode Power Consumption Statement: ...........................................................................................II

Energy Star© ..............................................................................................................................................III

FCC Statement ............................................................................................................................................IV

FCC RF Radiation Exposure Statement: .....................................................................................................V

Instructions for Care and Operation ......................................................................................................... VII

Power Safety ...............................................................................................................................................IX

Polymer Battery Precautions .......................................................................................................................X

Battery Precautions .....................................................................................................................................XI

Cleaning .................................................................................................................................................... XII

Servicing ................................................................................................................................................... XII

Travel Considerations ..............................................................................................................................XIII

Quick Start Guide

Overview ....................................................................................................................................................1-1

Advanced Users .........................................................................................................................................1-2

Beginners and Not-So-Advanced Users ....................................................................................................1-2

Warning Boxes ..........................................................................................................................................1-2

Not Included ..............................................................................................................................................1-3

System Startup ...........................................................................................................................................1-4

System Software ........................................................................................................................................1-5

XVIII

Preface

Model Differences .....................................................................................................................................1-5

System Map: LCD Panel Open ..................................................................................................................1-6

LED Indicators ...........................................................................................................................................1-7

Keyboard ....................................................................................................................................................1-8

Keyboard Shortcuts ...................................................................................................................................1-9

Function/Hot Key Indicators ...................................................................................................................1-10

Control Center .........................................................................................................................................1-11

System Map: Front & Top Views ............................................................................................................1-12

System Map: Left View ...........................................................................................................................1-13

System Map: Right & Rear Views ..........................................................................................................1-14

System Map: Bottom View .....................................................................................................................1-16

3G/4G Module USIM Card Installation ..................................................................................................1-17

Docking Port ............................................................................................................................................1-18

Windows 8.1 Control Panel .....................................................................................................................1-19

Windows 8.1 Start Screen & Desktop .....................................................................................................1-22

Apps & Tiles ............................................................................................................................................1-23

Desktop Application ................................................................................................................................1-24

The Charms Bar .......................................................................................................................................1-25

Windows 8.1 Taskbar ..............................................................................................................................1-27

Video Features .........................................................................................................................................1-28

Power Options .........................................................................................................................................1-31

Running Apps ..........................................................................................................................................1-32

XIX

Preface

Features & Components

Overview ....................................................................................................................................................2-1

Hard Disk Drive .........................................................................................................................................2-2

Optical (CD/DVD) Device ........................................................................................................................2-3

Loading Discs ............................................................................................................................................2-3

Handling CDs or DVDs .............................................................................................................................2-4

DVD Regional Codes ................................................................................................................................2-5

Multi-In-1 Card Reader .............................................................................................................................2-6

ExpressCard Slot .......................................................................................................................................2-7

Inserting and Removing ExpressCards ......................................................................................................2-7

Touchpad and Buttons/Mouse ...................................................................................................................2-7

Gestures and Device Settings ....................................................................................................................2-8

Audio Features .........................................................................................................................................2-13

Setup for Audio Recording ......................................................................................................................2-14

Power Management

Overview ....................................................................................................................................................3-1

The Power Sources ....................................................................................................................................3-2

AC/DC Adapter .........................................................................................................................................3-2

Battery ........................................................................................................................................................3-2

Turning On the Computer ..........................................................................................................................3-3

Shutting the Computer Down ....................................................................................................................3-4

Preface

Power Plans ...............................................................................................................................................3-5

Power-Saving States ..................................................................................................................................3-7

Sleep ..........................................................................................................................................................3-7

Hibernate ....................................................................................................................................................3-8

Shut down ..................................................................................................................................................3-8

Configuring the Power Buttons .................................................................................................................3-9

Resuming Operation ................................................................................................................................3-11

Power Conservation Modes .....................................................................................................................3-12

Battery Information .................................................................................................................................3-15

Battery Power ..........................................................................................................................................3-15

Conserving Battery Power .......................................................................................................................3-16

Battery Life ..............................................................................................................................................3-17

New Battery .............................................................................................................................................3-17

Recharging the Battery with the AC/DC Adapter ...................................................................................3-17

Proper handling of the Battery Pack ........................................................................................................3-18

Battery FAQ .............................................................................................................................................3-19

Drivers & Utilities

What to Install ............................................................................................................................................4-1

Module Driver Installation ........................................................................................................................4-1

Driver Installation ......................................................................................................................................4-2

Updating/Reinstalling Individual Drivers ..................................................................................................4-5

XXI

Preface

User Account Control ................................................................................................................................4-6

Windows Security Message .......................................................................................................................4-6

New Hardware Found ................................................................................................................................4-6

Driver Installation Procedure .....................................................................................................................4-7

Chipset .......................................................................................................................................................4-7

Video (VGA) .............................................................................................................................................4-7

LAN ...........................................................................................................................................................4-7

CardReader ................................................................................................................................................4-7

Touchpad ...................................................................................................................................................4-7

Airplane .....................................................................................................................................................4-7

Hot Key ......................................................................................................................................................4-8

MEI Driver .................................................................................................................................................4-8

Audio .........................................................................................................................................................4-8

Optional Drivers ........................................................................................................................................4-9

BIOS Utilities

Overview ....................................................................................................................................................5-1

The Setup Utility ........................................................................................................................................5-2

Failing the POST .......................................................................................................................................5-3

Fatal Errors ................................................................................................................................................5-3

Non-Fatal Errors ........................................................................................................................................5-3

Setup Screens .............................................................................................................................................5-4

XXII

Preface

Main Menu .................................................................................................................................................5-5

System Time & Date (Main Menu) ...........................................................................................................5-5

SATA Port # (Main Menu) ........................................................................................................................5-6

System/Extended Memory: (Main Menu) .................................................................................................5-6

MB Series / BIOS Revision / KBC/EC firmware Revision ......................................................................5-6

Advanced Menu .........................................................................................................................................5-7

Advanced Chipset Control (Advanced Menu) ..........................................................................................5-8

VT-d (Advanced Menu > Advanced Chipset Control) ..............................................................................5-8

Intel Virtualization Technology (Advanced Menu > Advanced Chipset Control) ....................................5-8

Intel TXT(LT) Trusted Execution Technology Support

(Advanced Menu > Advanced Chipset Control) .......................................................................................5-8

mSATA/3G Slot Support

(Advanced Menu > Advanced Chipset Control) .......................................................................................5-9

USB 3.0 Power/ Card Reader Power / PCI Express Card Power /

E-SATA Power / (Advanced Menu > Advanced Chipset Control) .........................................................5-10

Intel Smart Connect Technology (Advanced Menu) ...............................................................................5-10

Intel(R) Rapid Start Technology (Advanced Menu) ...............................................................................5-10

SATA Mode (Advanced Menu) ..............................................................................................................5-11

Boot Logo (Advanced Menu) ..................................................................................................................5-11

Power On Boot Beep (Advanced Menu) .................................................................................................5-11

Battery Low Alarm Beep (Advanced Menu) ...........................................................................................5-11

Security Menu ..........................................................................................................................................5-12

XXIII

Preface

Set Supervisor Password (Security Menu) ..............................................................................................5-12

Set User Password (Security Menu) ........................................................................................................5-13

Password on boot (Security Menu) ..........................................................................................................5-13

Secure Boot Support (Security Menu) .....................................................................................................5-13

TPM Configuration (Security Menu) ......................................................................................................5-14

TPM State (Security Menu > TPM Support Enabled) .............................................................................5-15

Pending TPM operation (Security Menu > TPM Support & TPM State Enabled) .................................5-16

Boot Menu ...............................................................................................................................................5-17

Boot Option Priorities (Boot Menu) ........................................................................................................5-18

UEFI Boot (Boot Menu) ..........................................................................................................................5-18

Exit Menu ................................................................................................................................................5-19

Upgrading The Computer

Overview ....................................................................................................................................................6-1

When Not to Upgrade ................................................................................................................................6-2

Removing the Battery ................................................................................................................................6-3

Removing/Replacing the Component Bay Cover ......................................................................................6-4

Upgrading the Optical (DVD) Device .......................................................................................................6-5

Upgrading the Hard Disk Drive .................................................................................................................6-6

Upgrading the System Memory (RAM) ....................................................................................................6-9

Modules & Options

Overview ....................................................................................................................................................7-1

XXIV

Preface

PC Camera Module ....................................................................................................................................7-3

PC Camera Audio Setup ............................................................................................................................7-4

Camera App ...............................................................................................................................................7-5

Camera Options .........................................................................................................................................7-6

Taking Pictures/Capturing Video ..............................................................................................................7-7

Camera Roll ...............................................................................................................................................7-8

Wireless LAN Module .............................................................................................................................7-12

3rd Party 802.11b/g/n Driver Installation ................................................................................................7-13

Intel® WLAN Driver Installation ............................................................................................................7-13

WLAN Configuration in Windows .........................................................................................................7-14

Security Modules (Fingerprint & TPM) ..................................................................................................7-17

Fingerprint Reader Module ......................................................................................................................7-18

Fingerprint Reader Driver Installation .....................................................................................................7-18

Fingerprint Module Configuration ..........................................................................................................7-19

Bluetooth & WLAN Combo Module ......................................................................................................7-21

3rd Party Bluetooth (V4.0) Combo Driver Installation ...........................................................................7-22

Intel Bluetooth Combo Driver Installation ..............................................................................................7-22

Bluetooth Configuration in Windows ......................................................................................................7-23

Trusted Platform Module .........................................................................................................................7-26

Enabling & Activating TPM ....................................................................................................................7-27

Trusted Platform Module (TPM) Driver Installation ..............................................................................7-29

Initializing TPM .......................................................................................................................................7-30

XXV

Preface

Infineon Security Platform Settings Tool ................................................................................................7-32

Intel Rapid Storage Technology ..............................................................................................................7-40

IRST Driver Installation ..........................................................................................................................7-40

Intel® vPro™ Technology ......................................................................................................................7-41

Accessing the Intel Management Engine ................................................................................................7-41

Intel® Management and Security Status .................................................................................................7-43

Intel® Rapid Start Technology Driver ....................................................................................................7-47

Intel® Rapid Start Technology Configuration ........................................................................................7-48

Intel® Rapid Start Technology Driver Installation .................................................................................7-54

Intel® Smart Connect Technology ..........................................................................................................7-55

Intel® Smart Connect Technology Driver Installation ............................................................................7-55

Intel® Smart Connect Technology Configuration ...................................................................................7-56

Intel® Small Business Advantage ...........................................................................................................7-60

Installing Intel® Small Business Advantage ...........................................................................................7-60

SBA Application Modules .......................................................................................................................7-61

3G/4G Module .........................................................................................................................................7-67

3G/4G Configuration in Windows ...........................................................................................................7-69

EM820W 3G Module PIN Code & Power-Saving ..................................................................................7-72

Wireless Display ......................................................................................................................................7-74

Wireless Display Configuration ..............................................................................................................7-75

XXVI

Preface

Troubleshooting

Overview ....................................................................................................................................................8-1

Basic Hints and Tips ..................................................................................................................................8-2

Backup and General Maintenance .............................................................................................................8-3

Viruses .......................................................................................................................................................8-4

Upgrading and Adding New Hardware/Software ......................................................................................8-5

Problems and Possible Solutions ...............................................................................................................8-7

EM820W 3G Module PIN Code & Power-Saving ..................................................................................8-15

Resolving the “Insert a SIM” issue with the 3G Module (Windows 8.1) ...............................................8-17

Interface (Ports & Jacks)

Overview ...................................................................................................................................................A-1

Notebook Ports and Jacks .........................................................................................................................A-2

Control Center

Overview ...................................................................................................................................................B-1

Video Driver Controls

Video Driver Installation ..........................................................................................................................C-1

Dynamic Video Memory Technology ......................................................................................................C-1

Intel® HD Graphics Control Panel ...........................................................................................................C-2

Display Devices & Options ....................................................................................................................C-14

XXVII

Preface

Attaching Other Displays .......................................................................................................................C-15

Attaching Other Displays - Devices (Charms Bar) ................................................................................C-18

Configuring an External Display In Windows .......................................................................................C-19

HDMI Audio Configuration ...................................................................................................................C-21

Specifications

Processors .................................................................................................................................................D-2

Core Logic ................................................................................................................................................D-2

Display ......................................................................................................................................................D-2

Memory .....................................................................................................................................................D-2

Video .........................................................................................................................................................D-2

BIOS .........................................................................................................................................................D-2

Storage ......................................................................................................................................................D-3

Audio ........................................................................................................................................................D-3

Keyboard, Pointing Device & Buttons .....................................................................................................D-3

Card Reader .............................................................................................................................................D-3

Slots ..........................................................................................................................................................D-3

Interface ....................................................................................................................................................D-3

Communication (All Models) ...................................................................................................................D-3

Communication (Model A Only) ..............................................................................................................D-4

Communication (Model B Only) ..............................................................................................................D-4

XXVIII

Preface

Power Management ..................................................................................................................................D-4

Power ........................................................................................................................................................D-4

Security .....................................................................................................................................................D-4

LED Indicators ..........................................................................................................................................D-4

Operating System ......................................................................................................................................D-4

Design Features ........................................................................................................................................D-4

Environmental Spec ..................................................................................................................................D-4

Dimensions & Weight ..............................................................................................................................D-5

Docking Station Guide

Overview ...................................................................................................................................................E-1

Compatibility ............................................................................................................................................E-1

Computer and Docking Station ................................................................................................................E-2

Docked System Power ..............................................................................................................................E-2

System Map: Front View ..........................................................................................................................E-3

System Map: Rear View ...........................................................................................................................E-4

Power Button LED & Lock Switch LED Indicator ..................................................................................E-5

System Map: Left & Right Views ............................................................................................................E-6

Cold Docking the Computer to the Docking Station ................................................................................E-7

Cold Undocking the Computer from the Docking Station ..................................................................... E-10

Hot Docking the Computer to the Docking Station ................................................................................E-11

Hot Undocking the Computer from the Docking Station ....................................................................... E-14

XXIX

Preface

Power Button Configuration ...................................................................................................................E-17

Docking Station Ports & Jacks ...............................................................................................................E-18

Multiple Displays ....................................................................................................................................E-21

BIOS Controls - USB ports, Card Reader & ExpressCard .....................................................................E-21

One Button Hard Disk Backup ...............................................................................................................E-22

Backup Procedure ...................................................................................................................................E-23

System Image Backup ............................................................................................................................E-25

System Image Recovery .........................................................................................................................E-27

File History Backup ................................................................................................................................E-29

Restoring Files from File History Backup ..............................................................................................E-33

Specifications ..........................................................................................................................................E-37

Storage ....................................................................................................................................................E-37

Interface and Ports ..................................................................................................................................E-37

Buttons & Switches ................................................................................................................................E-37

Power ......................................................................................................................................................E-37

Security ...................................................................................................................................................E-37

LED Indicators ........................................................................................................................................E-37

Environmental Spec ................................................................................................................................E-37

Dimensions & Weight ............................................................................................................................E-37

Windows 10

Overview ................................................................................................................................................... F-1

XXX

Preface

Windows 10 Start Menu ........................................................................................................................... F-2

Right-Clicking the Windows Logo In Start Menu ................................................................................... F-3

Start Menu Apps & Tiles .......................................................................................................................... F-4

Pining/Unpinning Apps & Programs to/from the Start Menu .................................................................. F-5

Windows 10 Control Panel ....................................................................................................................... F-6

Settings ..................................................................................................................................................... F-7

Windows 10 Taskbar ................................................................................................................................ F-8

Video Features .......................................................................................................................................... F-9

To Configure Displays using Project ........................................................................................................ F-9

Power Options ........................................................................................................................................ F-12

Using the Power Button .......................................................................................................................... F-12

Minimum Screen Resolution Settings .................................................................................................... F-14

Windows 10 Drivers & Utilities ............................................................................................................. F-15

Driver Installation (Windows 10) ........................................................................................................... F-15

Driver Installation Procedure .................................................................................................................. F-17

Chipset .................................................................................................................................................... F-17

Video (VGA) .......................................................................................................................................... F-17

LAN ........................................................................................................................................................ F-17

CardReader ............................................................................................................................................. F-17

Touchpad ................................................................................................................................................ F-17

Airplane .................................................................................................................................................. F-18

Control Center ........................................................................................................................................ F-18

XXXI

Preface

MEI Driver .............................................................................................................................................. F-18

Audio ...................................................................................................................................................... F-18

Optional Drivers .....................................................................................................................................F-18

Wireless LAN Module ............................................................................................................................ F-19

3rd Party WLAN Driver Installation ...................................................................................................... F-20

Intel® WLAN Driver Installation ........................................................................................................... F-20

Fingerprint Reader Module ..................................................................................................................... F-21

Fingerprint Reader Driver Installation .................................................................................................... F-21

Fingerprint Module Configuration .........................................................................................................F-22

Bluetooth & WLAN Combo Module .....................................................................................................F-23

3rd Party Bluetooth Combo Driver Installation ...................................................................................... F-24

Intel Bluetooth Combo Driver Installation ............................................................................................. F-24

Bluetooth Configuration ......................................................................................................................... F-25

Intel® Rapid Storage Technology .......................................................................................................... F-26

IRST Driver Installation ......................................................................................................................... F-26

PC Camera .............................................................................................................................................. F-27

Trusted Platform Module ........................................................................................................................ F-28

TPM Management in Windows .............................................................................................................. F-28

3G/4G Module ........................................................................................................................................ F-29

3G/4G Configuration in Windows 10 .....................................................................................................F-30

XXXII

Preface

Overview 1 - 1

Quick Start Guide

Chapter 1: Quick Start Guide

Overview

This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following:

• Chapter 2 A guide to using some of the main features of the computer e.g. the storage devices (hard disk,

card reader & ExpressCard), Touchpad & Mouse & Audio.

• Chapter 3 The computer’s power saving options.

• Chapter 4 The installation of the drivers and utilities essential to the operation or improvement of some of the

computer’s subsystems.

• Chapter 5 An outline of the computer’s built-in software or BIOS (Basic Input Output System).

• Chapter 6 Instructions for upgrading your computer.

• Chapter 7 A quick guide to the computer’s PC Camera, Wireless LAN, Fingerprint Reader, 3G/4G, Bl ue-

tooth and Trusted Platform (TPM) modules (some of which may be optional depending on your purchase configuration).

• Chapter 8 A troubleshooting guide.

• Appendix A Definitions of the interface, ports/jacks which allow your computer to communicate with external

devices.

• Appendix B Information on the Control Center .

• Appendix C Information on the video driver controls.

• Appendix D The computer’s specification.

• Appendix E A guide to the Docking Station.

• Appendix F Information on the Windows 10 operating system.

1 - 2 Overview

Quick Start Guide

Advanced Users

If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “What to Install” on page 4 - 1, “BIOS Utilities” on page 5 - 1 and “Upgrading The Computer” on

page 6 - 1 in the reminder of the User’s Manual. You may also find the notes marked with a

 of interest to you.

Beginners and Not-So-Advanced Users

If you are new to computers (or do not have an advanced knowledge of them) then the information contained in the Quick Start Guide should be enough to get you up and running. Eventually you should try to look through all the documentation (more detailed descriptions of the functions, setup and system controls are covered in the remainder of the User’s Manual), but do not worry if you do not understand everything the first time. Keep this manual nearby and refer to it to learn as you go. You may find it useful to refer to the notes marked with a

 as indicated in the margin.

For a more detailed description of any of the interface ports and jacks see “Interface

(Ports & Jacks)” on page A - 1.

Warning Boxes

No matter what your level please pay careful attention to the warning and safety information indicated by the

 symbol. Also please note the safety and handling instructions as indicated in the Preface.



Notes

Check the light colored boxes with the mark above to find detailed information about the computer’s features.

Overview 1 - 3

Quick Start Guide

Not Included

Operating Systems (e.g. Windows 8.1) and applications (e.g. word processing, spreadsheet and database programs) have their own manuals, so please consult the appropriate manuals.



Drivers

If you are installing new system software, or are re-configuring your computer for a different system, you will need to install the drivers listed in “Drivers & Utilities” on page 4 - 1. Drivers are programs which act as an interface between the computer and a hardware component e.g. a wireless network module. It is very important that you install the drivers in the order listed. You will be unable to use most advanced controls until the necessary drivers and utilities are properly installed. If your system hasn’t been properly configured (your service representative may have already done that for you); refer to

Chapter 4 for installation instructions.

Ports and Jacks

See “Notebook Ports and Jacks” on page A - 2 for a description of the interface (ports & jacks) which allow your computer to communicate with external devices, connect to the internet etc.

1 - 4 System Startup

Quick Start Guide

System Startup

1. Remove all packing materials and place the computer on a stable surface.

2. Securely attach any pe ripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports.

3. Attach the AC/DC adapter to the DC-In jack on the left of the computer, then plug the AC power cord into an

outlet, and connect the AC power cord to the AC/DC adapter.

4. Use one hand to raise the

lid/LCD to a comfortable viewing angle (

do not exceed 135 degrees

);

use the other

hand to support the base of the computer (Note: Never lift the computer by the lid/LCD).

5. Press the power button on the top right of the computer for about 2 - 3 seconds to turn the computer on

Figure 1 - 1 - Opening the Lid/LCD & Computer with AC/DC Adapter Plugged-In



Shutdown

Note that you should always shut your computer down by choosing the Shut Down command from the bottom right of the Start menu in Win- dows. This will help prevent hard disk or system problems.

135°

System Startup 1 - 5

Quick Start Guide

System Software

Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, you will find the Windows 8.1 (64-bit) operating system is supported.

Model Differences

This notebook series includes two different models that vary slightly in design style, color, general appearance and features supported (see Appendix D for full details). Note that your computer may look slightly different from that pictured throughout this manual.



Windows Versions

Note that the information included on the following pages is for Windows 8.1 (64-bit) only.

Windows OS

In order to run Windows 8.1 (64-bit) without limitations or decreased performance, your computer requires a minimum 2GB of system memory (RAM).

1 - 6 System Map: LCD Panel Open

Quick Start Guide

System Map: LCD Panel Open

Figure 1 - 2

LCD Panel Open

1. Built-In PC Camera (

Optional

)

2. PC Camera LED

3. LCD

4. Power Button

5. LED Indicators

6. Keyboard

7. Built-In Microphone

8. Touchpad & Buttons

9. Fingerprint Reader Sensor

Note that the Touchpad and Buttons valid operational area is that indicated within the red dotted lines above.



Wireless Device

Operation Aboard

Aircraft

The use of any portable electronic transmission devices aboard aircraft is usually prohibited. Make sure the module(s) are OFF if you are using the computer aboard aircraft.

Use Fn + F11 Airplane Mode key combination to toggle Airplane Mode On/ Off, and check the LED indicator for the power status (see Table 1 - 3, on

page 1 - 10).

LED Indicators 1 - 7

Quick Start Guide

LED Indicators

The LED indicators on the computer display helpful information about the current status of the computer.

Table 1 - 1 - LED Indicators

Icon Color Description Icon Color Description

Orange AC/DC Power is Plugged In Green

Airplane Mode is ON (the WLAN,

Bluetooth & 3G/4G Modules are OFF)

Blinking

Orange

The Powered USB Port is On Blue Power Button

Green The Computer is On Green Hard Disk/ODD Activity

Blinking

Green

The Computer is in Sleep Mode Green

Number Lock Activated

(to activate press Fn & Num Lk)

Orange The Battery is Charging Green Caps Lock Activated

Green The Battery is Fully Charged Green

Scroll Lock Activated

(to activate press Fn & Scr Lk)

Blinking

Orange

The Battery has Reached Critically

Low Power Status

The powered USB 3.0 port

(see Figure 1 - 6 on page 1 - 13) may be toggled on /off by means of the Fn + Power Button

key combination. When the powered USB port is on it will supply power (for charging devices only, not for operating devices) when the system is off but still powered by the AC/DC adapter plugged into a working outlet, or powered by the battery with a capacity level above 20% (this may not work with certain devices).

1 - 8 Keyboard

Quick Start Guide

Keyboard

The keyboard has an embedded numerical keypad for easy numeric data input, and function keys to change operational features instantly.

Figure 1 - 3 - Keyboard



Other Keyboards

If your keyboard is damaged or you just want to make a change, you can use any standard USB keyboard. The system will detect and enable it automatically. However special functions/hot-keys unique to the system’s regular keyboard may not work.

NumLk & ScrLk

Hold down the Fn Key and either NumLk or ScrLk to enable number or scroll lock, and check the LED indicator for status.

Numerical Keypad

Play/Pause Key

Function Keys

NumLk & ScrLk Keys

Fn Key

Windows Logo Key

Menu/Application Key



Special Characters

Some software applications allow the number-keys to be used with Alt to produce special characters. These special characters can only be produced by using the numeric keypad. Regular number keys (in the upper row of the keyboard) will not work. Make sure that NumLk is on.

Keyboard 1 - 9

Quick Start Guide

Keyboard Shortcuts

The following Windows Logo Key (Winkey) keyboard shortcuts are useful for navigation/operation in

Windows 8.1

Table 1 - 2 - Keyboard Shortcuts

Windows Logo

Key +

Description

Tap Winkey

Toggle between the Start screen and the foremost running app or the

Windows Desktop

CDisplay Charms menu D Switch to the Windows Desktop and toggle show Desktop

Switch to the Windows desktop and launch Windows Explorer with

Computer displayed

F Display file Search

I Open the Settings charm

K Open the Connect charm

L Lock the computer and display the Lock screen P Display the Second Screen menu (see Figure 1 - 19 on page 1 - 28 ) R Switch to the Windows Desktop and display the Run dialog box Z Access the Customize Bar (see Figure 1 - 14 on page 1 - 23)



Windows Logo

Keyboard Shortcut

Use the Windows logo key + D key com- bination to switch from the Start screen to the Windows Desktop.

Menu/Application

Keyboard Shortcut

When the Desktop app is running you can use the Menu/Application key on the keyboard to act as a mouse right-click. In the Start screen this function is useful to quickly display Cus- tomize Apps.

1 - 10 Function/Hot Key Indicators

Quick Start Guide

Function/Hot Key Indicators

The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition to the basic function key combinations; visual indicators are available when the hot key utility is installed.

Keys Function Keys Function

Fn +

Play/Pause (in Audio/Video Programs)

Fn +

Brightness Decrease/Increase

Fn +

Touchpad Toggle

(Disable toggle by using

the Touchpad Switch)

Fn +

PC Camera

Power T oggle

Fn +

Turn LCD Backlight Off

(Press a key to or use TouchPad to turn on)

Fn +

Airplane

Mode Toggle

Fn +

Mute Toggle Fn + NumLk

Number Lock

Toggle

Fn +

Sleep Toggle Fn + ScrLk

Scroll Lock

Toggle

Fn +

Volume Decrease/Increase Caps Lock

Caps Lock

Toggle

Fn +

Display Switch Menu

Fn +

Fan Control

Toggle -

Automatic

Fan Control /

Full Power

Table 1 - 3 - Function & Hot Key Indicators

Control Center 1 - 11

Quick Start Guide

Control Center

When in the Windows Desktop application (not in the Start screen) press the Fn + Esc key combination, or double-click the icon

in the notification area of the taskbar to toggle the Control Center on/off. The Con-

trol Center gives quick access to frequently used controls and enables you to quickly turn the camera/touch pad

on/off (see Appendix B for full details).

Figure 1 - 4 - Control Center



Control Center Access

To run the Control Center press the Fn + Esc key combination, or double-click the icon in the notification area of the taskbar.

Close the Control Center by clicking the close icon in the top right of the panel (move the cursor onto the top right corner of the panel to highlight it).

1 - 12 System Map: Front & Top Views

Quick Start Guide

System Map: Front & Top Views

Figure 1 - 5

Front & Top Views

(with Optional

Docking Station)

1. Touchpad Switch

2. LED Indicators

3. Docking Station (Optional)



Touchpad Switch

Use the Touchpad Switch to disable the touchpad toggle function (i.e. the use of the Fn + F1 key combination).

When the switch is in the OFF position, then the Fn + F1 key combination will be disabled.



Docking

.If your purchase includes the docking station, open the docking port cover latch and align the computer with the placeholder on the docking station (see the accompanying docking station for full details of the docking procedure).

System Map: Left View 1 - 13

Quick Start Guide

System Map: Left View

Figure 1 - 6

Left View

1. DC-In Jack

2. External Monitor Port

3. RJ-45 LAN Jack

4. e-SATA Port

5. AC/DC Powered USB 3.0 Port

6. 2 * USB 3.0 Ports

7. HDMI Out Port

8. Multi-In-1 Card Reader

9. ExpressCard Slot



USB Ports

This model includes 3 * USB 3.0 ports (including one ACDC Powered USB

3.0 port) and 1* USB 2.0

port. USB 3.0 ports are denoted by their blue col-

or; USB 2.0 ports are col-

ored black.



Multi-In-1 Push-Push Card Reader

The card reader allows you to use the most popular digital storage card formats:

MMC (MultiMedia Card) / RS MMC

SD (Secure Digital) / Mini SD / SDHC / SDXC

MS (Memory Stick) / MS Pro / MS Duo

Powered USB 3.0 Port

The powered USB 3.0 port can supply power (for charging devices only, not for operating devices) when the system is off but still powered by the AC/DC adapter plugged into a working outlet, or powered by the battery with a capacity level above 20% (this may not work with certain devices - see page 8 - 11). Toggle power to this port by using Fn + power button. Power to this port may be enabled/disabled in the BIOS (see page 5 - 10).



External Monitor Port & RJ-

45 LAN Jack

If you are using a VGA cable plugged into the external monitor port, and a network cable connected to the RJ-45 LAN jack, it is recommended that you insert the VGA cable before inserting the LAN cable.

USB Port / Card Reader /

ExpressCard Power

Note that power to the USB ports, card reader and ExpressCard may be enabled/ disabled in the BIOS (see page 5 - 10).

1 - 14 System Map: Right & Rear Views

Quick Start Guide

System Map: Right & Rear Views

Figure 1 - 7

Right & Rear Views

1. Microphone-In Jack

2. Headphone- Out / S/PDIF Out Combo Jack

3. 1 * USB 2.0 Port

4. Optical Device

Drive Bay (for CD/ DVD Device)

5. Security Lock Slot

6. Battery

1 2 3



Headphone / S/PDIF Out Combo Jack

Headphones or speakers may be connected through this jack. Note: Set your system’s volume to a reduced level before connecting to this jack. As a S/PDIF (Sony/Philips Digital Interface Format) Out Port, this allows you to connect your DVD-capable PC to a Dolby AC3 compatible receiver for “5.1” or ‘dts’ surround sound.

Battery Information

Always completely discharge, then fully charge, a new battery before using it. Comp letely discharge and charge the battery at least once every 30 days or after about 20 partial discharges.

System Map: Right & Rear Views 1 - 15

Quick Start Guide



Disk Eject Warning

Don’t try to eject a CD/DVD while the system is accessing it. This may cause the system to “crash”. Stop the disk first then eject it, or press the stop button twice.

CD/DVD Emergency Eject

If you need to manually eject a CD/DVD (e.g. due to an unexpected power interruption) you may push the end of a straightened paper clip into the emergency eject hole. Do not use a sharpened pencil or any object that may break and become lodged in the hole. Don’t try to remove a floppy disk/CD/DVD while the system is accessing it. This may cause the system to “crash”.



Changing DVD Regional Codes

Go to the Control Panel and double-click Device Manager (Hardware and Sound), then click th e +

next to DVD/CD-ROM drives. Double-click on the DVD-ROM device to bring up the Properties dialog box, and select the DVD Region (tab) to bring up the control panel to allow you to adjust the regional code (see “DVD Regional Codes” on page 2 - 5).

DVD region detection is device dependent, not OSdependent. You can select your module’s region code 5 times. The fifth se lection is permanent. This cannot be altered even if you change your operating system or you use the module in another computer.

1 - 16 System Map: Bottom View

Quick Start Guide

System Map: Bottom View

Figure 1 - 8

Bottom View

1. Battery

2. Docking Port

3. Fan Intake/Vent

4. Component Bay Cover

5. HDD Bay Cover

6. Speakers



Battery Information

Always completely discharge, then fully charge, a new battery before using it. Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges.



CPU

The CPU is not a user serviceable part.

Overheating

To prevent your computer from overheating make sure nothing blocks the Vent/Fan Intake while the computer is in use.



Docking Port Cover

If your purchase option includes the docking station, make sure you keep the cover

closed when the computer is not docked in the station. This will help prevent foreign objects and/or dust getting in to the contact area. If your purchase option does not include the docking station, an insert will be provided to prevent accidentally opening the docking port. Do not attempt to open the cover or remove the insert in this case.

3G/4G Module USIM Card Installation 1 - 17

Quick Start Guide

3G/4G Module USIM Card Installation

If you have included an optional 3G/4G module in your purchase option, follow the instructions below to install the USIM card (which will be provided by your service provider), and then use the Charms Bar Wireless icon to access the 3G/4G network in the same manner as the WLAN (see page 7 - 69).

1. Turn off the computer, and turn it over and then remove the battery (slide the latches in the direction indicated below and slide the battery out).

2. Insert the USIM card into the slot at the rear of the battery compartment, as illustrated below, until it clicks fully into position, and replace the battery.

Figure 1 - 9 - Battery Removal & USIM Card Insertion



USIM Card

Orientation

Note that the USIM card’s readable side (with the gold-colored contacts) should face upwards as illustrated.

1 - 18 Docking Port

Quick Start Guide

Docking Port

Follow the instructions below before connecting the computer to the docking station, if included in your purchase configuration. Failure to open the cover of the docking port before connecting the computer to the docking station may result in irreparable damage to the connector on the docking station.

1. Turn the computer over.

2. Slide the docking port cover latch in the direction of the arrow at point to open the cover.

3. After disconnecting the computer from the docking station, slide the docking port cover latch in the direction of the arrow at point .



Docking Port

Cover

Make sure you keep the cover closed when the computer is not docked in the station. This will help prevent foreign objects and/or dust getting in to the contact area.

Figure 1 - 10 - Opening and Closing the Docking Port

Windows 8.1 Control Panel 1 - 19

Quick Start Guide

Windows 8.1 Control Panel

Throughout this manual you will see an instruction to open the Control Panel. R

ight-click the lower left hot corner to bring up the context menu (or use the Win-

dows Logo Key + X key combination)

and select Control Panel in both the

Desktop app or Start screen.

Figure 1 - 11 - Windows Context Menu



Windows Versions

Note that the information included on the following pages is for the latest updated version of Windows 8.1 only.

Make sure you enable Windows Update in order to get all the latest security updates etc. (see “Windows Up-

date” on page 4 - 8).

Move the mouse to the bottom left

Start Screen

Desktop app

of the screen and right-click to access the menu.

1 - 20 Windows 8.1 Control Panel

Quick Start Guide

The Control Panel can be accessed in a number of ways in Windows 8.1.

•Click Search in the Windows Charms Bar (see previous page) and the search pane will pop out. Type

Control Panel and select it from the results to the left.

• Click on This PC (in Apps, or you can to pin This PC to the Start screen), click on Computer in the

top menu and select Open Control Panel from the ribbon.

• When in the Desktop app (this does not apply to the Start screen) click on Settings in the Windows

Charms Bar and select Control Panel from the menu.

• Click the arrow at the bottom of the Start screen and click Control Panel in Apps (Windows System).

• Right-c lick the Start button to bring up the menu and select Control Panel (see Figure 1 - 12 on page 1

- 21).



Keyboard Shortcut to Control Panel

You can also use keyboard shortcuts to access the Contro l Pa nel. Press the W indows logo key and X to bring up the context menu, and then press P to bring up the Control Panel. Alternatively press the Windows logo key and R to bring up the Run dialog box, and then type “Control Panel” and press Enter to access the Control Panel.

Windows 8.1 Control Panel 1 - 21

Quick Start Guide

Right-click the Start button in the Desktop app (or use the Windows Logo Key

+ X key combination) to bring up an advanced context menu of useful features

such as Control Panel, Programs and Features, Power Options, Task Manager, Search, File Explorer, Command Prompt, Device Manager and Network Connections etc.

Figure 1 - 12 - Advanced Context Menu (Right-Click Start Button)



Display Most

Recently Used

Apps

If you are in the Start screen, Desktop or an app you can move your mouse to the upper left corner of the screen to get back to the most recently used app.

To view all the most recently used Apps hover over the top left of the screen and then move the mouse down along the left side of the screen to display the list.

Move the mouse to the bottom left of the screen

and right-click the Start button to access the menu.

1 - 22 Windows 8.1 Start Screen & Desktop

Quick Start Guide

Windows 8.1 Start Screen & Desktop

The Apps, control panels, utilities and programs within Windows are accessed from the Start screen and/or Windows Desktop app. The Desktop (which runs as an app within the Start screen) can be accessed by clicking

the Desktop item in the Start screen (or by using the Windows Logo Key + D key combination). Click the arrow at the bottom of the Start screen to access Apps.

Figure 1 - 13 - Windows Start Screen

Desktop App

Windows 8.1 Start Screen & Desktop 1 - 23

Quick Start Guide

Apps & Tiles

The Start screen will contain a number of apps, and many more will be installed as you add more applications etc. Not all of these apps can fit on one screen so you will often need use the slider at the bottom of the screen in order to view all the necessary Apps.

Accessing Pining/Unpinning All Apps

You can add and remove the tiles for apps and control panels in the Start screen. Right-click on an app to bring up the context menu and you pin the App to (or unpin from) the Start screen, or to the taskbar.

Figure 1 - 14 - Apps

Click the arrow at the bottom of the screen to access All Apps

1 - 24 Windows 8.1 Start Screen & Desktop

Quick Start Guide

Desktop Application

When the Desktop app is running (click the app in the Start screen or use the Windows Logo Key + D key combination) you can use lower left hot corner to switch between the Start screen and the Windows Desktop app. To do so move your mouse to hover over the bottom left corner of the Desktop app and left-click.

Figure 1 - 15 - Desktop

Move the mouse to the bottom left of the screen and click to switch back to the Start screen.

Windows 8.1 Start Screen & Desktop 1 - 25

Quick Start Guide

The Charms Bar

The right side of the screen (Start or Desktop) displays the Charms Bar. The Charms Bar contains the Search, Share, Start, Devices and Settings menus. To access up the Charms Bar move the cursor to the upper or lower

right corners of the screen, and then hover over one of the items in the Charms Bar to activate it (the bar will be black when it is active), or use the Windows Logo Key + C key combination.

Figure 1 - 16 - Start Screen with Charms Bar

Move the mouse over a Charms Bar icon to activate the menu

Move the mouse to the top/lower right icons to activate the Charms Bar

Move the mouse to the top/lower right icons to activate the Char ms Bar

1 - 26 Windows 8.1 Start Screen & Desktop

Quick Start Guide

Charms Bar Items

• Search : You can search for any file, application, Apps and control panel settings with instantaneous

results.

•Share : This button is used to share information with people via mail or social networks.

•Start : Click to bring up the Start screen (the same function as pressing the Windows Logo Key or click-

ing the bottom left of the screen).

• Devices : Click this button to change connected peripheral device settings e.g. an external display.

• Settings : This button gives instant access to the computer settings, such as Network, Audio, Notifica-

tions, Power and Keyboard (click Change PC Settings to activate the PC Settings menu).

Figure 1 - 17 - Settings Menu



Charms Bar - TouchPad Access

To quick access the Charms Bar using the TouchPad:

1. Place your finger off the TouchPad (slightly to the right of the pad resting on the computer).

2. Move your finger across to the left on to the TouchPad.

3. The Charms Bar will then pop-up.

Windows 8.1 Start Screen & Desktop 1 - 27

Quick Start Guide

Windows 8.1 Taskbar

In many instances throughout this manual you will see an instruction to access the notification area of the taskbar (system tray). In Windows 8.1 the taskbar can be directly accessed from the Desktop application; if you

are in the Start screen you will need to move the cursor to the bottom of the screen to display the taskbar. The taskbar is displayed at the bottom of the screen, and you can see the notification area (system tray) of the

taskbar in the bottom right of the screen. Some of the control panels and applications referred to during the course of this manual can be accessed from here.

Figure 1 - 18 - Taskbar & Notification Area (System Tray)

You can pin/unpin apps to/from the taskbar in much the same way as you can to the Start screen (see “Accessing

Pining/Unpinning All Apps” on page 1 - 23).

1 - 28 Video Features

Quick Start Guide

Video Features

You can switch display devices, and configure display options, from the Display control panel (in Appearances and Personalization) in Windows when running the Desktop app (see “Desktop Application ” on page 1 - 24). It is possible to quickly configure external displays from the Devices menu item in the Charms Bar (see “The

Charms Bar” on page 1 - 25).

To Configure Displays from Devices (Charms Bar):

1. Attach your display to the appropriate port, and turn it on.

2. Go the Charms Bar, select Devices.

3. Click Project (you may need to click Second Screen).

4. Click on any one of the options from the menu to select PC screen only, Duplicate, Extend or Second screen only.

Figure 1 - 19 - Devices (Project)

Video Features 1 - 29

Quick Start Guide

To access Display (Control Panel) and Screen Resolution in Windows 8:

1. Go to the Control Panel.

2. Click Display (icon) - In the Appearance and Personalization category.

3. Adjust resolution.

Figure 1 - 20 - Screen Resolution



Right-Click Desktop

App

1. You can right-click the desktop and select Screen reso- lution (Figure 1 -

20).

2. Use the dropbox to select the screen

Resolution

(Figure 1 - 20).

3. Click Advanced settings (Figure

1 - 20) to bring up the

Advanced properties tabs.

123

1 - 30 Video Features

Quick Start Guide

To access the Intel(R) HD Graphics Control Panel:

1. Click Advanced settings (Figure 1 - 20 on page 1 - 29) in the Screen Resolution control panel in Windows.

2. Click the Intel(R)... tab and click Graphics Properties (button) (Figure 1 - 21 on page 1 - 30) .

3. Right-click the desktop and select Graphics Properties from the menu.

4. Click the icon in the notification area of the Desktop taskbar and select Graphics Properties from the menu.

Figure 1 - 21 - Intel Graphics Control Panel

Power Options 1 - 31

Quick Start Guide

Power Options

Power Options (Hardware and Sound) can be accessed from the Control Panel. The Power Menu item in Set- tings in the Charms Bar in Windows 8.1 may be used to Shut down or Restart (you can also add Hibernate/ Sleep to the menu - see “Adding Hibernate/Sleep to the Power Menu” on page 3 - 10). You can also use the context menu (Shut down or sign out) shut the computer down/restart etc.

Figure 1 - 22 - Shut Down/Restart

Charms Bar

Desktop App Start Screen

Power Button Start Screen

1 - 32 Running Apps

Quick Start Guide

Running Apps

To run apps in Windows 8.1 you will need to check that the Screen Resolution and User Account Control Settings are compatible with the system requirements.

Screen Resolution Settings

1. Switch to the Windows Desktop (click the app or use th e Windows logo key + D key combination).

2. Right-click a blank area of the Windows Desktop and select Screen Resolution. Adjust the Resolution to make sure that it is at least 1024 * 768, although preferably 1366 * 768 or above (see sidebar).

Figure 1 - 23 - Screen Resolution



Screen Resolution for Apps

(Windows 8.1)

The minimum resolution in which Apps will run is 1024x768. The minimum resolution required to support a ll the features of

Windows 8 (including multitasking with snap) is 1366x768. These specs are the minimum screen resolution that supports

all the features of Windows 8.1 on a useful physical size.

Running Apps 1 - 33

Quick Start Guide

User Account Control Settings

If your computer meets the minimum screen resolution requirements, and still you can't run apps, then that you have to check the status of User Account Control (UAC). Apps may fail to open when the UAC is turned off. To check whether the UAC is on or off, follow the instructions below.

1. Open the Control Panel.

2. Click on User Accounts and then click on Change User Account Control settings (or click System and Security and click Change User Account Control Settings under Action Center).

3. If the slider is in the Never notify position, then the UAC is disabled.

4. To enable or turn on the UAC, move the slider to Always notify or Notify me when apps try to make changes to my computer (default) position, and then click OK.

Figure 1 - 24 - User Account Control

Quick Start Guide

1 - 34

Features & Components

Overview 2 - 1

Chapter 2: Features & Components

Overview

Read this chapter to learn more about the following main features and components of the computer:

•Hard Disk Drive

• Optical (CD/DVD) Device

• Multi-In-1 Card Reader

• ExpressCard Slot

• Touchpad and Buttons/Mouse

• Audio Features

Features & Components

2 - 2 Hard Disk Drive

Hard Disk Drive

The hard disk drive is used to store your data in the computer. The hard disk can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5 mm or 7 mm.

The hard disk is accessible from the bottom of your computer as seen below. For further details see “Upgrading the Optical (DVD) Device” on page 6 - 5.



Power Safety

Before attempting to access any of the internal components of your computer please ensure that the machine is not connected to the AC power, and that the machine is turned off. Also ensure that all peripheral cables, including phone lines, are disconnected from the computer.

Figure 2 - 1

Hard Disk Location

HDD Bay

Features & Components

Optical (CD/DVD) Device 2 - 3

Optical (CD/DVD) Device

There is a bay for a 5.25" optical (CD/DVD) device (12.7mm height). The actual device will depend on the module you purchased (see “Storage” on page D - 3). The optical device is usually labeled “Drive D:” and may be used as a boot device if properly set in the BIOS (see “Boot Menu” on page 5 - 13).

Loading Discs

To insert a CD/DVD, press the open button and carefully place a CD/DVD onto the disc tray with label-side facing up (use just enough force for the disc to click onto the tray’s spindle). Gently push the CD/DVD tray in until its lock “clicks” and you are ready to start. The busy indicator will light up while data is being accessed, or while an audio/video CD, or DVD, is playing. If power is unexpectedly interrupted, insert an object such as a straightened paper clip into the emergency eject hole

to open the tray.



Sound Volume

Adjustment

How high the sound volume can be set depends on the setting of the volume control within Win- dows. Click the Volume icon on the taskbar to check the setting (see

“Audio Features” on page 2 - 13).

Figure 2 - 2

Optical Device

123

Features & Components

2 - 4 Optical (CD/DVD) Device

Handling CDs or DVDs

Proper handling of your CDs/DVDs will prevent them from being damaged. Please follow the advice below to make sure that the data stored on your CDs/DVDs can be accessed.

Note the following:

• Hold the CD or DVD by the edges; do not touch the surface of the disc.

• Use a clean, soft, dry cloth to remove dust or fingerprints.

• Do not write on the surface with a pen.

• Do not attach paper or other materials to the surface of the disc.

• Do not store or place the CD or DVD in high-temperature areas.

• Do not use benzene, thinner, or other cleaners to clean the CD or DVD.

• Do not bend the CD or DVD.

• Do not drop or subject the CD or DVD to shock.



CD Emergency Eject

If you need to manually eject a CD (e.g. due to an unexpected power interruption) you may push the end of a straightened paper clip into the emergency eject hole. However please do NOT use a sharpened pencil or similar object that may break and become lodged in the hole.

Disk Eject Warning

Don’t try to remove a CD/DVD while the system is accessing it. This may cause the system to “crash”.

Features & Components

Optical (CD/DVD) Device 2 - 5

DVD Regional Codes

To change the DVD regional codes:

1. Go to the Control Panel

2. Double-click Device Manager (Hardware and Sound), then click the + next to DVD/CD-ROM drives.

3. Double-click on the DVD-ROM device to bring up the Properties dialog box, and select the DVD Region (tab) to bring up the control p anel to allow yo u to adjust the regional code.



DVD Region Note

DVD region detection is device dependent, not OS-dependent. You can select your module’s region code 5 times. The fifth selection is permanent. This cannot be altered even if you change your operating system or you use the module in another computer.

Figure 2 - 3

DVD Region Codes

• Region 1 - USA & Canada

• Region 2 - Western Europe, Japan,

South Africa, Middle East & Egypt

• Region 3 - South-East Asia, T aiwan,

South Korea, The Philippines, Indonesia, Hong Kong

• Region 4 - South & Central Amer-

ica, Mexico, Australia, New Zealand

• Region 5 - N Korea, Russia, Eastern

Europe, India & Most of Africa

• Region 6 - China

Features & Components

2 - 6 Multi-In-1 Card Reader

Multi-In-1 Card Reader

The card reader allows you to use some of the latest digital storage cards. Push the card into the slot and it will appear as a removable device, and can be accessed in the same way as your hard disk (s). Make sure you install the card reader driver (see

“CardReader” on page 4 - 7.

Note: Some of these cards require PC adapters that are usually supplied with the cards.



Push-Push Card

Reader

The card reader features a push-in/push-out card insertion and ejection mechanism. Simply push the card to insert and eject it, however MS Duo cards require an adapter.

Figure 2 - 4

Left View

1. Card Reader

• MMC (MultiMedia Card) / RS MMC

• SD (Secure Digital) / Mini SD / SDHC / SDXC

• MS (Memory Stick) / MS Pro / MS Duo

Features & Components

ExpressCard Slot 2 - 7

ExpressCard Slot

The computer is equipped with an ExpressCard/34/54 slot that reads Express Card/ 34 and ExpressCard/54 formats. ExpressCards are the successors to PCMCIA (PC Cards). Make sure you install the Card Reader driver

(see

“CardReader” on page 4

- 7

ExpressCard/54 is used for applications which require a larger interface slot, e.g. CompactFlash card reader. The number denotes the card width; 54mm for the Express Card/54 and 34mm for the ExpressCard/34.

Inserting and Removing ExpressCards

• Align the ExpressCard with the slot and push it in until it locks into place (as

pictured in the generic figure below).

• To remove an ExpressCard, simply press the card to eject it.



ExpressCard

Slot Cover

Make sure you keep the cover provided in the ExpressCard slot when not in use. This will help prevent foreign objects and/or dust getting in to the ExpressCard Slot.

Figure 2 - 5

Left View

1. ExpressCard Slot

Features & Components

2 - 8 Touchpad and Buttons/Mouse

Touchpad and Buttons/Mouse

The Touchpad is an alternative to the mouse; however, you can also add a mouse to your computer through one of the USB ports. The Touchpad buttons function in much the same way as a two-button mouse.

Once you have installed the Touchpad driver (see “Touchpad” on page 4 - 7) you can configure the functions by double-clicking the Touchpad driver icon in the notification area of the taskbar. You may then configure the Touchpad tapping, buttons, scrolling (see sidebar), pointer motion and sensitivity options to your preferences.



Touchpad Scrolling

This computer model series may feature different Touchpad versions.

These Touchpads may differ in their vertical scrolling function in most scrollable windows.

Some Touchpads require sliding the finger up and down on the right of the Touchpad to scroll the window. Other versions require tapping/holding down the finger at the top right or bottom right of the Touchpad to scroll the window.

Figure 2 - 6

Mouse Properties

Features & Components

Touchpad and Buttons/Mouse 2 - 9

Gestures and Device Settings

The Synaptics Gestures Suite application allows you to use a specific gesture (action) on the surface of the Touchpad to perform specific actions to manipulate documents, objects and applications.

You can configure the settings from the Device Settings tab in Mouse Properties:

1. Click

Start

, and click

Control Panel

(or point to

Settings

and click

Control Panel

2. Click Mouse (Hardware and Sound).

3. Click Device Settings (tab) and click Settings.

4. Use the menu tree on the left to access the user configurable settings.



Show Video

You can get a clearer view of the gestures involved by clicking the Show Video option for each gesture item.

Select the gesture (Pinch

Zoom, Rotating, Three Fingers Down and Three Finger Flick) in the Device Settings > Settings left tree menu

and click the Show Video button to see the demonstration video.

For more details on any of the gestures see the help in the lower part of the right menu window.

Figure 2 - 7

Mouse Properties -

Device Settings

Features & Components

2 - 10 Touchpad and Buttons/Mouse

Disabling the Touchpad

If you need to disable the Touchpad for any reason (e.g. you may find that when using the computer’s internal keyboard you accidentally trigger the Touchpad when resting your wrists or palms on it) you can do so by using Fn + F1 key combination.

You can also set the system to automatically disable the internal Touchpad when an external USB point device (e.g. a USB mouse) is attached.

1. Go to the Mouse Properties control panel.

2. Click to select Device Settings (tab).

3. Click to place a check in the “Disable internal pointing device when external USB pointing device is attached” check box.

4. Click OK to save the setting.

Figure 2 - 8

Mouse Properties

(Disable Touchpad)

Features & Components

Touchpad and Buttons/Mouse 2 - 11

Scrolling

The Two-Finger scrolling feature works in most scrollable windows and allows you to scroll horizontally and vertically. Place two fingers, slightly separated, on the Touchpad surface and slide both fingers in the direction required (in a straight continuous motion).

Zooming

The Pinch Zoom gesture can be used to perform the same function as a scroll wheel in Windows applications that support CTRL + scroll wheel zoom functionality. Place two fingers on the Touchpad (for best results use the tips of the fingers) and slide them apart to zoom in, or closer together to zoom out.

Figure 2 - 9

Scrolling Gesture



Mouse Driver

If you are using an external mouse your operating system may be able to auto-configure your mouse during its installation or only enable its basic functions. Be sure to check the device’s user documentation for details.

Figure 2 - 10

Zooming Gesture

Features & Components

2 - 12 Touchpad and Buttons/Mouse

Rotating

Use the Pivot Rotate gesture to rotate objects (e.g. photos) in 90 degree increments. Place a finger down on the left “target” zone and keep it stationary. Place another finger near the middle of the Touchpad and slide it in a circular motion around the stationary finger (clockwise or counterclockwise) to rotate the object.

Three Finger-Flick/Three Fingers Down (Press)

The Three Finger-Flick gesture may be used to enhance navigation with a variety of applications such as browsing the Internet or scrolling through a photo viewer. The Three Fingers Down gesture may be used to launch user-selectable applications.

Figure 2 - 11

Rotating Gesture

Figure 2 - 12

Flick/Press

Gesture

Features & Components

Audio Features 2 - 13

Audio Features

You can configure the audio options on your computer from the Sound control panel in Windows, or from the Realtek HD Audio Manager icon in the taskbar notification area/control panel (right-click the taskbar notification area icon to bring up an audio menu). The volume may also be adjusted by means of the volume icon in the taskbar or the audio slider in the Settings menu (see sidebar).



Volume Adjustment

The sound volume level can be set using the volume control in the Set-

tings menu in the Charms Bar.

Figure 2 - 13

Realtek Audio

Manager

Right-click the icon to access the menu above.

Features & Components

2 - 14 Audio Features

Setup for Audio Recording

To record audio sources on your computer at optimum quality follow the instructions below:

1. Go to the

Control Panel

2. Click Realtek HD Audio Manager (Hardware and Sound), or right-click the taskbar icon and select Sound Manager.

3. Click Microphone Effects (tab) in Microphone (tab), and then click to select Noise Suppression (button), or adjust the Recording Volume level to around 60, to obtain the optimum recording quality.

4. Click OK to close the control panel and save the settings.

Figure 2 - 14

Realtek Audio

Manager -

Recording Setup

Power Management

Overview 3 - 1

Chapter 3: Power Management

Overview

To conserve power, especially when using the battery, your computer power management conserves power by controlling individual components of the computer (the monitor and hard disk drive) or the whole system. This chapter covers:

• The Power Sources

• Turning On the Computer

• Shutting the Computer Down

• Power-Saving States

• Configuring the Power Buttons

• Battery Information

The computer uses enhanced power saving techniques to give the operating system (OS) direct control over the power and thermal states of devices and processors. For example, this enables the OS to set devices into low-power states based on user settings and information from applications.



OS Note

Power management functions will vary slightly depending on your operating system. For more information it is best to refer to the user’s manual of your operating system.

(Note: All pictures used on the following pages are from the Windows

8.1 OS.)

Power Options

Power management in Windows is configured from Power Options (Hardware and Sound), which can be accessed from the Con- trol Panel (see page 1 -

25).

Power Management

3 - 2 The Power Sources

The Power Sources

The computer can be powered by either an AC/DC adapter or a battery pack.

AC/DC Adapter

Use only the AC/DC adapter that comes with your computer. The wrong type of AC/ DC adapter will damage the computer and its components.

1. Attach the AC/DC adapter to the DC-In jack on the left of the computer, then plug the AC power cord into an outlet, and connect the AC power cord to the AC/DC adapter.

2. Raise the lid/LCD to a comfortable viewing angle.

3. Press the power button to turn “On”.

Battery

The battery allows you to use your computer while you are on the road or when an electrical outlet is unavailable. Battery life varies depending on the applications and the configuration you're using. To increase battery life, let the battery discharge completely before recharging (see “Battery FAQ” on page 3 - 19).

We recommend that you do not remove the battery. For more information on the battery, please refer to “Battery Information” on page 3 - 15.



Forced Off

If the system “hangs”, and the Ctrl + Alt + Del key combination doesn’t work, press the power button for 4 seconds, or longer, to force the system to turn itself off.

Power Management

Turning On the Computer 3 - 3

Turning On the Computer

Now you are ready to begin using your computer. To turn it on simply press the power button on the front panel.

When the computer is on, you can use the power button as a Stand by/Hibernate/ Shutdown hot-key button when it is pressed for less than 4 seconds (pressing and holding the power button for longer than this will shut the computer down). Use Power Options (Hardware and Sound) in the Windows control panel to configure this feature.



Power Button as Stand by or Hibernate Button

You can use the OS’s “Power Options” control panel to set the power button to send the system into Stand by or Hibernate mode (see your OS’s documentation, or “Configuring

the Power Buttons” on page 3 - 9 for details).

Power Management

3 - 4 Shutting the Computer Down

Shutting the Computer Down

Note that you should always shut your computer down by choosing the Shut down command as this will help prevent hard disk or system problems. Use the Shut down or sign out item in the Context Menu (right-click the lower left corner of the screen to bring up the menu).

You can also use the Power Menu in Settings in the Windows 8.1 Charms Bar. If you want to add Hibernate/Sleep to the Power Menu see “Adding Hibernate/Sleep

to the Power Menu” on page 3 - 10.

Figure 3 - 1

Shut Down/Restart

Charms Bar Desktop App Start Screen

Power Management

Power Plans3-5

Power Plans

The computer can be configured to conserve power by means of power plans. You can use (or modify) an existing power plan, or create a new one.

The settings may be adjusted to set the display to turn off after a specified time, and to send the computer into Sleep after a period of inactivity.

Click Change plan settings and then click Change advanced power settings to access further configuration options in Advanced Settings.



Resuming

Operation

See Table 3 - 1, on

page 3 - 11 for informa-

tion on how to resume from a power-saving state.

Password

It is recommended that you enable a password on system resume in order to protect your data.

Figure 3 - 2

Power Plan

Advanced Settings

Power Management

3 - 6 Power Plans

Each Windows power plan will also adjust the processor performance of your machine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power).

Choose High performance (you may need to click Show additional plans to view the High performance plan) for maximum performance when the computer is powered from an AC power source. Choose the Power saver (bear in mind that this scheme may slow down the overall performance of the computer in order to save power) for maximum power saving when the computer is battery (DC power) powered.

Figure 3 - 3

Power Plans

Click to Show/Hide additional power plans

Power Management

Power-Saving States 3 - 7

Power-Saving States

You can use power-saving states to stop the computer’s operation and restart where you left off. Win 8.1 uses the Sleep, Hibernate and Shut Down power-saving states.

Sleep

In Sleep all of your work, settings and preferences are saved to memory before the system sleeps. When you are not using your computer for a certain length of time, which you specify in the operating system, it will enter Sleep to save power.

The PC wakes from Sleep within seconds and will return you to where you last left off (what was on your desktop) without reopening the application(s) and file(s) you last used.

If your mobile PC in Sleep is running on battery power the system will use only a minimum amount of power. After an extended period the system will save all the information to the hard disk and shut the computer down before the battery becomes depleted.

To add Sleep to the Power Menu see “Adding Hibernate/Sleep to the Power

Menu” on page 3 - 10.



Wake On LAN

Support

(Windows 8)

Wake-On-LAN is only supported from Sleep or

Hibernate states in Windows 8.

If you require your computer to wake up from network activity in Windows 8 then make sure that the computer is either in Sleep or Hiber- nate.

Wake-On-LAN is not supported from Shutdown states in Win- dows 8.

Power Management

3 - 8 Power-Saving States

Hibernate

Hibernate uses the least amount of power of all the power-saving states and saves all of your information on a part of the hard disk before it turns the system off. If a power failure occurs the system can restore your work from the hard disk; if a power failure occurs when work is saved only to memory, then the work will be lost. Hi- bernate will also return you to where you last left off within seconds. You should put your mobile PC into Hibernate if you will not use the computer for a period of time, and will not have the chance to charge the battery. To add Hibernate to the Power Menu see “Adding Hibernate/Sleep to the Power Menu” on page 3 - 10.

Shut down

You should Shut down the computer if you plan to install new hardware (don’t forget to remove the battery and follow all the safety instructions in Chapter 6), plan to be away from the computer for several days, or you do not need it to wake up and run a scheduled task. Returning to full operation from Shut down takes longer than from Sleep or Hibernate.

Figure 3 - 4

Power Menu

Power Management

Configuring the Power Buttons 3 - 9

Configuring the Power Buttons

The power/sleep button (Fn + F4 key combo) and closed lid may be set to send the computer in to a power-saving state. Click Choose what the power buttons do on the left menu in Power Options to bring up the menu.



Password

Protection

It is recommended that you enable a password on wake up in order to protect your data.

However you can disable this setting from the Power Options menu by clicking Require a

password on wakeup

in the left menu, and selecting the options (click

Change settings that are currently unavailable).

Figure 3 - 5

Power Options

Define Power

Buttons

Power Management

3 - 10 Configuring the Power Buttons

Adding Hibernate/Sleep to the Power Menu

Add Hibernate/Sleep to the Power Menu as follows.

1. Go to the Power Options (Hardware and Sound) control panel.

2. Click “Change settings that are currently unavailable” .

3. Click Choose what the power buttons do.

4. Click to put a check in the Hibernate/Sleep box under Shutdown settings.

5. Click Save Changes and close the control panel.

Figure 3 - 6

Power Options

Define Power

Buttons - Shutdown

Settings

Power Management

Configuring the Power Buttons 3 - 11

Resuming Operation

You can resume operation from power-saving states by pressing the power button, or in some cases pressing the sleep button (Fn + F4 key combo).

Power Status

Icon Color

To Resume

Power Off Off Press the Power Button

Sleep Blinking Green

Press the Power Button

Press the Sleep Button (Fn + F4 Key Combo)

Hibernate

Off (battery)

Press the Power Button

Orange (AC/DC adapter)

Display Turned Off Green Press a Key or Move the Mouse/Touchpad

Table 3 - 1

Resuming

Operation



Closing the Lid

If you have chosen to send the computer to Sleep when the lid is closed, raising the lid will wake the system up.



Power Button

When the computer is on, you can use the power button as a Sleep/Hibernate/Shut Down hot key button when it is pressed for less than 4 seconds (pressing and holding the power button for longer than this will force the computer to shut down).

Power Management

3 - 12 Configuring the Power Buttons

Power Conservation Modes

This system supports Energy Star power management features (see over) that place computers (CPU, hard drive, etc.) into a low-power sleep modes after a designated period of inactivity. Adjust Power Conservation Modes from the Control Center:

1. Press the Fn + Esc key combination to toggle the Control Center on/off.

2. Click either the Performance, Balanced or Energy Star button.



Power Conservation

Modes

The Energy Star setting will result in maximum power saving, but with the possible loss of some performance.

Setting the mode to Bal- ance will give power saving matched with performance.

Performance will give optimum computer performance but with less power conservation.

Note that the Energy Star setting will put the display into sleep after no more than 15 minutes of user inactivity.

Figure 3 - 7

Control Center

Power Management

Configuring the Power Buttons 3 - 13



Energy Star Notes

Display Mode Off

By factory default the Energy Star setting will put the display into sleep within 15 minutes of user inactivity in order to reduce power consumption. The display will wake up upon sensing a key press or mouse movement. To adjust this setting go to Power Options in the control panel and click “Choose when to turn off the display”. Select an option from the dropdown menu and then click Save Changes to apply the changes to the setting.

System Sleep Mode

To switch to System Sleep mode for this computer you can press the Fn + F4 key combination (or press Alt + F4 from the Desktop app in Wind ows 8 , s elect Sleep from the dropdown menu, and press OK). To wake the system from sleep press the power button.

Note: The default power management settings selected for co mpliance with Energy Star have been recommended by the Energy Star program for optimal energy savings.

If the system is plugged-in Sleep will be activated after no more tha n 30 minutes (15 minutes if the system is battery powered) of user inactivity, by default in Windows.

Power Management

3 - 14 Configuring the Power Buttons

Ctrl + Alt + Delete Key Combination

You can use the CTRL + ALT + DEL key combination from almost any of the Windows 8 interfaces/Apps to bring up a full-screen displaying Lock, Switch User, Log

off, Change a password and Task Manager options. If you click the Power icon in the lower right corner of the screen a power management option menu appears to display Sleep, Shut down, and Restart.

To fully control all the power options (including Hibernate mode) go to the Power Options control panel and configure the power button, sleep button and lid to perform the function selected.

Figure 3 - 8

Ctrl + Alt + Delete

Power Management

Battery Information 3 - 15

Battery Information

Follow these simple guidelines to get the best use out of your battery.

Battery Power

Your computer’s battery power is dependent upon many factors, including the programs you are running, and peripheral devices attached. You can set actions to be taken (e.g. Shut down, Hibernate etc.), and set critical and low battery levels from power plan Change plan settings > Change advanced power settings (see Figure

3 - 3 on page 3 - 6).

Click the battery icon in the notification area to see the current battery level and charge status.



Low Battery

Warning

When the battery is critically low, immediately connect the AC/DC adapter to the computer or save your work, otherwise, the unsaved data will be lost when the power is depleted.

Figure 3 - 9

Battery Icon

(Notification Area) &

Battery Advanced

Settings

Power Management

3 - 16 Battery Information

Conserving Battery Power

•Use a power plan that conserves power (e.g Power saver), however note that

this may have an affect on computer performance.

• Lower the brightness level of the LCD display. The system will decrease LCD

brightness slightly to save power when it is not powered by the AC/DC adapter.

• Reduce the amount of time before the display is turned off.

• Close wireless, Bluetooth, modem or co mmunication applications when they are

not being used (e.g. put the system in Airplane Mode).

• Disconnect/remove any unnecessary external devices e.g. USB devices,

ExpressCards etc.



Windows Mobility

Center

The Windows Mobility Center control panel

provides an easy point of access for information on battery status, power plans used and wireless device status etc.

Figure 3 - 10

Windows Mobility

Center

Power Management

Battery Information 3 - 17

Battery Life

Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days.

We recommend that you do not remove the battery yourself. If you do need to remove the battery for any reason (e.g. long term storage) see “Removing the Battery”

on page 6 - 3.

New Battery

Always completely discharge, then fully charge, a new battery (see “Battery FAQ”

on page 3 - 19 for instructions on how to do this).

Recharging the Battery with the AC/DC Adapter

The battery pack automatically recharges when the AC/DC adapter is attached and plugged into an electrical outlet. If the computer is powered on, and in use, it will take several hours to fully recharge the battery. When the computer is turned off but plugged into an electrical outlet, battery charge time is less. Refer to “LED Indica-

tors” on page 1 - 8 for information on the battery charge status, and to “Battery Information” on page 3 - 15 for more information on how to maintain and properly

recharge the battery pack.

Power Management

3 - 18 Battery Information

Proper handling of the Battery Pack

• DO NOT disassemble the battery pack under any circumstances

• DO NOT expose the battery to fire or high temperatures, it may explode

• DO NOT connect the metal terminals (+, -) to each other



Caution

Danger of explosion if battery is incorrectly replaced.

Replace only with the same or equivalent type recommended by the manufacturer. Discard used battery according to the manufacturer’s instructions.



Damaged Battery Warning

Should you notice any physical defects (e.g. the battery is bent ou t of shape after being dropped), or any unusual smells emanating from the notebook battery, shut your computer down immediately and contact your distributor/supplier. If the battery has been dropped we do not recommend using it any further, as even if the comp uter continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire. It is recommended that you replace your computer battery every two years.

MAXDATA M-Book 6000 G4 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
