DVD Changer
TABLE OF CONTENTS
SECTION PAGE
1. TECHNICAL SPECIFICATIONS ................................................................................................................ 1
2. PRODUCT SAFETY SERVICING GUIDELINES FOR VIDEO PRODUCTS ............................................. 2
3. SERVICING PRECAUTIONS ..................................................................................................................... 3
4. REGIONAL CODES ................................................................................................................................... 4
5. INFORMATIONS ........................................................................................................................................ 5
6. SERVICING HINT ....................................................................................................................................... 6
7. LOCATION OF CUSTOMER CONTROLS .................................................................................................7
8. DISASSEMBLY ........................................................................................................................................ 10
9. EXPLODED VIEWS/MECHANICAL PARTS LIST ................................................................................... 12
10. ELECTRICAL TROUBLESHOOTING GUIDE .......................................................................................... 15
11. BLOCK DIAGRAMS ................................................................................................................................. 25
12. CIRCUIT DIAGRAMS ............................................................................................................................... 31
13. PRINTED CIRCUIT DIAGRAMS .............................................................................................................. 53
14. ELECTRICAL PARTS LIST ...................................................................................................................... 57
15. DVD DECK MECHANISM SECTION ...................................................................................................... 2-1
Service
Manual
VC5200 /U1B
Please use this service manual with referring to the user guide (D.F.U) without fail.
R
VC5200
346W855010 ACT
First Issue:2002.01
VC5200
Printed on 100%Recycled Paper
Printed in Japan
Page 2
MARANTZ DESIGN AND SERVICE
Using superior design and selected high grade components, MARANTZ company has created the ultimate in stereo sound.
Only original MARANTZ parts can insure that your MARANTZ product will continue to perform to the specifications for which
it is famous.
Parts for your
MARANTZ equipment are generally available to our National Marantz Subsidiary or Agent.
ORDERING PARTS :
Parts can be ordered either by mail or by Fax.. In both cases, the correct part number has to be specified.
The following information must be supplied to eliminate delays in processing your order :
1. Complete address
2. Complete part numbers and quantities required
3. Description of parts
4. Model number for which part is required
5. Way of shipment
6. Signature : any order form or Fax. must be signed, otherwise such part order will be considered as null and void.
SHOCK, FIRE HAZARD SERVICE TEST :
CAUTION : After servicing this appliance and prior to returning to customer, measure the resistance between either primary AC
cord connector pins ( with unit NOT connected to AC mains and its Power switch ON ), and the face or Front Panel of product and
controls and chassis bottom.
Any resistance measurement less than 1 Megohms should cause unit to be repaired or corrected before AC power is applied, and
verified before it is return to the user/customer.
Ref. UL Standard No. 1492.
In case of difficulties, do not hesitate to contact the Technical
Department at above mentioned address.
010620 ACT
USA
MARANTZ AMERICA, INC
MARANTZ AMERICA, INC.
1100 MAPLEWOOD DRIVE
ITASCA, IL. 60143
USA
PHONE : 630 - 741 - 0300
FAX : 630 - 741 - 0301
BRAZIL
PHILIPS DA AMAZONIA IND. ELET. ITDA
CENTRO DE INFORMACOES AO
CEP 04698-970
SAO PAULO, SP, BRAZIL
PHONE : 0800 - 123123
(Discagem Direta Gratuita)
FAX : +55 11 534. 8988
JAPAN
Technical
MARANTZ JAPAN, INC.
35- 1, 7- CHOME, SAGAMIONO
SAGAMIHARA - SHI, KANAGAWA
JAPAN 228-8505
PHONE : +81 42 748 1013
FAX : +81 42 741 9190
EUROPE / TRADING
MARANTZ EUROPE B.V.
P.O.BOX 80002, BUILDING SFF2
5600 JB EINDHOVEN
THE NETHERLANDS
PHONE : +31 - 40 - 2732241
FAX : +31 - 40 - 2735578
TECHNICAL AUDIO GROUP PTY, LTD
558 DARLING STREET,
BALMAIN, NSW 2041,
AUSTRALIA
PHONE : 61 - 2 - 9810 - 5300
FAX : 61 - 2 - 9810 - 5355
CANADA
LENBROOK INDUSTRIES LIMITED
633 GRANITE COURT,
PICKERING, ONTARIO L1W 3K1
CANADA
PHONE : 905 - 831 - 6333
FAX : 905 - 831 - 6936
AUSTRALIA
QualiFi Pty Ltd,
24 LIONEL ROAD,
MT. WAVERLEY VIC 3149
AUSTRALIA
PHONE : +61 - (0)3 - 9543 - 1522
FAX : +61 - (0)3 - 9543 - 3677
NEW ZEALAND
WILDASH AUDIO SYSTEMS NZ
14 MALVERN ROAD MT ALBERT
AUCKLAND NEW ZEALAND
PHONE : +64 - 9 - 8451958
FAX : +64 - 9 - 8463554
THAILAND
MRZ STANDARD CO.,LTD
746 - 754 MAHACHAI ROAD.,
WANGBURAPAPIROM, PHRANAKORN,
BANGKOK, 10200 THAILAND
PHONE : +66 - 2 - 222 9181
FAX : +66 - 2 - 224 6795
TAIWAN
PAI- YUING CO., LTD.
6 TH FL NO, 148 SUNG KIANG ROAD,
TAIPEI, 10429, TAIWAN R.O.C.
PHONE : +886 - 2 - 25221304
FAX : +886 - 2 - 25630415
MALAYSIA
WO KEE HONG ELECTRONICS SDN. BHD.
SUITE 8.1, LEVEL 8, MENARA GENESIS,
NO. 33, JALAN SULTAN ISMAIL,
50250 KUALA LUMPUR, MALAYSIA
PHONE : +60 3 - 2457677
FAX : +60 3 - 2458180
AMERICAS
SUPERSCOPE TECHNOLOGIES, INC.
MARANTZ PROFESSIONAL PRODUCTS
2640 WHITE OAK CIRCLE, SUITE A
AURORA, ILLINOIS 60504 USA
PHONE : 630 - 820 - 4800
FAX : 630 - 820 - 8103
AUSTRALIA
KOREA
MK ENTERPRISES LTD.
ROOM 604/605, ELECTRO-OFFICETEL, 16-58,
3GA, HANGANG-RO, YONGSAN-KU, SEOUL
KOREA
PHONE : +822 - 3232 - 155
FAX : +822 - 3232 - 154
SINGAPORE
WO KEE HONG DISTRIBUTION PTE LTD
130 JOO SENG ROAD
#03-02 OLIVINE BUILDING
SINGAPORE 368357
PHONE : +65 858 5535 / +65 381 8621
FAX : +65 858 6078
Page 3
1
1. TECHNICAL SPECIFICATIONS
Power supply AC120 V, 60 Hz
Power consumtion 16 W
Mass 5.7 kg (12.6 lbs)
External dimensions 440 x 118 x 423 (W x H x D)
Signal system NTSC
Laser (DVD) Semiconductor laser, wavelength 650 nm
(CD) 780 nm
Frequency range (audio) DVD : fs = 96 kHz 4 Hz - 44 kHz
fs = 48 kHz 4 Hz - 22 kHz
CD: 4 Hz - 20 kHz
Signal-to-noise ratio (audio) More than 105dB (EIAJ)
Audio dynamic range (audio) More than 100dB (EIAJ)
Harmonic distortion (audio) 0.003%
Wow and flutter Below measurable level (less than +0.001%(W.PEAK)) (EIAJ)
Operations Temperature : 5˚C(41˚F) to 35˚C(95˚F),
Operation status : Horizontal
OUTPUTS
Video outputs
DVD VIDEO PLAYER
1.0V(p-p), 75Ω, negative sync., RCA jack x 1
S-video outputs (Y)1.0V(p-p), 75Ω, negative sync., Mini DIN 4-pin x 1
(C)0.286V(p-p), 75Ω
Component video output (Y)1.0V(p-p), 75Ω ,negative sync., RCA jack x 1
(Cb)/(Cr) 0.7V(p-p), 75Ω
Audio output (Optical) Optical Connector x 1
0.5V(p-p), 75Ω, RCA jack x 1
(Coaxial)
Audio output (analog audio) 2.0Vrms (1kHz, 0dB), 330ΩΩ, RCA jack (L, R) x 2
*Designs and specifications are subject to change without notice.
REMARK
This service manual corresponds to service modification code number "MZ01" and later. When exchanging MAIN
PCB on the product of the service modification code "MZ00", it is necessary to also exchange the following parts on
the I/O PCB simultaneously.
(The service modification code is mentioned in the number label on the rear panel. Ex.MZ01xxxxxxxxxx)
Two kinds of MPEG ICs (IC501) exist in this model. Since the conventional IC (Pantera-2) became a production stop,
this was generated. Since power supply voltage is changed, new IC (Pantera-2 Plus) has change in a power supply
part. In the case of repair, please fix after checking the version of IC.
Service modification code
MZ00 MZ01
Location <Pantera-2> <Pantera-2 Plus>
D116 1N17 Tin Wire
D117 1N17 Tin Wire
C127 2200uF/6.3V 220uF/6.3V
