03 - 2010
UC3530A (MCC)
15.0A CHAIN SAW 14” 3/8”
1
2
3
4
5
6
7
8
17
16
11
18
15
19
9
10
14
21
13
22
24
26
27
28
29
25
12
20
30
33
32
34
35
36
37
44
42
43
45
59
57
58
40
39
63
38
64
41
53
52
48
49
50
46
47
51
54
55
56
60
66
67
68
69
65
70
71
72
73
74
75
88
A04
87
76
77
78
79
86
80
85
84
A03
83
82
81
Item No. Part No. Description QtyUnit
1 226743-8 STRAIGHT BEVEL GEAR 14 1 PC.
2 419410-4 BAFFLE PLATE 1 PC.
3 211111-8 BALL BEARING 6301LLB 1 PC.
4 240001-8 FAN 80 1 PC.
5 616966-0 ARMATURE 115V 1 PC.
6 681666-1 RESIN WASHER 1 PC.
7 210081-8 BALL BEARING 629ZZ 1 PC.
8 639532-6 FIELD 115V 1 PC.
9 266095-5 TAPPING SCREW 5X55 2 PC.
10 265995-6 TAPPING SCREW 4X18 1 PC.
11 188820-3 HANDLE SET 1 SET
11 INC. 810199-1 CAUTION LABEL 1 PC.
13 867109-9 UC3530A NAME PLATE 1 PC.
14 650577-1 SWITCH SD-006-BB2AA-AA 1 PC.
15 631720-1 CONTROLLER 1 PC.
16 682574-9 CORD GUARD 10-90 1 PC.
17 664980-0 CORD W/PLUG 2P-14-0.3M 1 PC.
18 687124-5 STRAIN RELIEF 1 PC.
19 265995-6 TAPPING SCREW 4X18 2 PC.
20 416178-3 LOCK-OFF BUTTON 1 PC.
21 233173-6 COMPRESSION SPRING 4 1 PC.
22 419411-2 SWITCH LEVER 1 PC.
24 651923-1 SWITCH TG70B SINGLE W/O LOCK 1 PC.
25 643650-4 BRUSH HOLDER CAP 6.5-13.5 2 PC.
26 194986-9 CARBON BRUSH CB-153 1 SET
27 154867-9 MOTOR HOUSING COMPLETE 1 PC.
27 INC. 643653-8 BRUSH HOLDER 6.5-13.5 2 PC.
28 188820-3 HANDLE SET 1 SET
28 INC. 810199-1 CAUTION LABEL 1 PC.
29 265995-6 TAPPING SCREW 4X18 1 PC.
30 265995-6 TAPPING SCREW 4X18 5 PC.
32 154870-0 TANK CAP COMPLETE 1 PC.
33 158050-0 GEAR HOUSING COVER COMPLETE 1 PC.
33 INC. 810891-9 CAUTION LABEL 1 PC.
34 140089-7 OIL PUMP COMPLETE 1 PC.
35 213039-6 O RING 6 1 PC.
36 421959-2 SPONGE SEAL 1 PC.
37 419407-3 OIL TANK 1 PC.
38 416274-7 CAP 1 PC.
39 231975-4 SPRING 1 PC.
40 421958-4 OIL TUBE 1 PC.
41 419408-1 GEAR HOUSING 1 PC.
42 419413-8 ROD 1 PC.
43 233174-4 COMPRESSION SPRING 6 1 PC.
44 451130-4 FRONT HAND GUARD 1 PC.
45 158044-5 LINK PLATE COMPLETE 1 PC.
46 234005-0 COMPRESSION SPRING 9 1 PC.
47 213039-6 O RING 6 1 PC.
48 211012-0 BALL BEARING 606ZZ 1 PC.
49 450230-7 CRANK 1 PC.
50 417405-1 CAM 1 PC.
51 259034-2 RETAINING RING E TYPE 10 1 PC.
52 266095-5 TAPPING SCREW 5X55 2 PC.
53 266173-1 TAPPING SCREW 5X30 4 PC.
54 226741-2 STRAIGHT BEVEL GEAR 43 1 PC.
55 324662-3 SPINDLE 1 PC.
56 211107-9 BALL BEARING 6201ZZ 1 PC.
3 MODEL UC3530A
Item No. Part No. Description QtyUnit
57 419409-9 FRONT HANDLE 1 PC.
58 266173-1 TAPPING SCREW 5X30 2 PC.
59 921452-1 HEX. BOLT M8X30 1 PC.
60 318013-0 BEARING HOUSING 1 PC.
63 345651-5 SPIKE BUMPER 1 PC.
64 266173-1 TAPPING SCREW 5X30 2 PC.
65 168426-3 BRAKE BAND 1 PC.
66 267195-4 FLAT WASHER 4 1 PC.
67 266026-4 TAPPING SCREW BIND CT 4X12 1 PC.
68 125331-7 BRAKE DRUM ASSEMBLY 1 PC.
69 253215-0 FLAT WASHER 8 1 PC.
70 259033-4 RETAINING RING E TYPE 6 1 PC.
71 266007-8 TAPPING SCREW BIND PT 3X10 1 PC.
72 419241-1 COVER 1 PC.
73 227496-2 STRAIGHT BEVEL GEAR 14 1 PC.
74 227495-4 STRAIGHT BEVEL GEAR 14 1 PC.
75 154869-5 SPROCKET COVER COMPLETE 1 PC.
76 419233-0 DIAL 40 1 PC.
77 253874-0 FLAT WASHER 4 1 PC.
78 915106-0 BINDING HEAD SCREW M4X8 1 PC.
79 233033-2 COMPRESSION SPRING 4 1 PC.
80 216008-6 STEEL BALL 4 1 PC.
81 154763-1 LEVER COMPLETE 1
82 951122-8 SPRING PIN 4-28 1 PC.
83 419271-2 CUP WASHER 20 1 PC.
84 317977-5 LEVER HOLDER 1 PC.
85 231025-5 COMPRESSION SPRING 8 1 PC.
86 252168-0 HEX. NUT M8-13 1 PC.
87 324621-7 ADJUST PIN 1 PC.
88 324620-9 ADJUST SCREW 1 PC.
089 188858-8 SPROCKET COVER SET 1 PC.
090 188859-6 LEVER COMPLETE SET 1 PC.
100 810276-9 CAUTION LABEL 1 PC.
PC.
ACCESSORIES
A01 419288-5 CHAIN COVER F/14" 1 PC.
A02 158024-1 HOOK COMPLETE 1 PC.
A03 165201-8 GUIDE BAR 14" 1 PC.
A04 528 092 652 SAW CHAIN 14" 1 PC.
4 MODEL UC3530A
