Makita DCS5121, DCS5121R User Manual
DCS5121 (Makita Teal)
DCS5121R (Makita Red)
PS-510 (Dolmar Red)
rev 6_03-05-20
15
16
13
8
14
11
10
24
9
6
3
17
18
23
20
2
4
12
21
5
7
1
22
25
DCS5121, DCS5121R
PS-510
1
Tank, Handle
2rev 6_03-05-20
PS-510
PPrroodduuccttss wwiitthh mmuullttiippllee vveerrssiioonnss aarree lliisstteedd iinn ssuubbssiiddiinngg oorrddeerr wwiitthh tthhee nneewweesstt vveerrssiioonn oonn ttoopp nnoott iinnddeenntteedd..
Tech Bulletin
Notes
Section
Fig. No.
Part No.
Description
DCS5121
DCS5121R
1 1 168507-3 TANK CP.,BLUE 1
1 1 181-114-202 TANK CP.,BLUE 1
1 1 181-114-720 TANK CP.,BLUE 1
1 1 181-114-280 TANK CPL. RED 1 1
1 2 181-117-050 GRIP, O.S. BLACK, DCS510 1 1 1
1 3 181-117-132 CATCH LEVER, DCS510 1 1 1
1 4 181-117-031 SPRING, DCS510 1 1 1
1 5 181-117-081 ROCKER, DCS510 1 1 1
1 6 181-117-111 SPRING, DCS5121 1 1 1
1 7 010-117-050 MODIFICATION SET, DCS510 1 1 1
1 8 935-930-240 CYLINDRAL PIN 3X24, DCS460 1 1 1
1 9 181-117-121 THROTTLE LEVER, DCS460 1 1 1
1 10 957-114-061 AIR VALVE CPL, DCS6401 1 1 1
1 11 913-455-204 SCREW M5.5X20, DCS6800I 1 1 1
1 12 181-114-065 FUEL LINE, DCS510 1 1 1
1 12 181-114-064 FUEL LINE, DCS510 1 1 1
1 13 010-114-010 SUCTION HEAD, DPC7001 1 1 1
1 14 010-114-020 FILTER SET FOR SUCTION HEAD,DCS510 1 1 1
1 15 168507-3 TANK CAP CPL., DPC7331 1 1 1
1 15 181-114-202 TANK CAP CPL., DPC7331 1 1 1
1 16 213080-9 PACKING RING, DPC7331 1 1 1
1 16 963-229-036 PACKING RING, DPC7331 1 1 1
1 17 181-114-301 DAMPING SPRING, CPL. 1 1 1
1 17 181-114-300 SPRING CPL. 1 1 1
1 18 181-114-301 DAMPING SPRING, CPL. 1 1 1
1 18 181-114-300 SPRING CPL. 1 1 1
1 20 913-455-204 SCREW M5.5X20, DCS6800I 1 1 1
1 21 266478-9 SELF-CUTTING SCREW,DCS520I 2 2 2
1 21 913-455-164 SELF-CUTTING SCREW,DCS520I 2 2 2
1 22 181-114-652 COVER , BLUE 1
1 22 181-114-650 COVER, BLUE 1
1 22 181-114-051 COVER,RED 1 1
DCS5121, DCS5121R
PS-510
1
Tank, Handle
3rev 6_03-05-20
PS-510
PPrroodduuccttss wwiitthh mmuullttiippllee vveerrssiioonnss aarree lliisstteedd iinn ssuubbssiiddiinngg oorrddeerr wwiitthh tthhee nneewweesstt vveerrssiioonn oonn ttoopp nnoott iinnddeenntteedd..
Tech Bulletin
Notes
Section
Fig. No.
Part No.
Description
DCS5121
DCS5121R
1 23 908-006-205 F.H.SCREW, DCS460 1 1 1
1 24 913-455-204 SCREW M5.5X20, DCS6800I 1 1 1
1 25 181-310-251 TUBULAR HANDLE, DCS510 1 1 1
1 25 181-310-250 TUBULAR HANDLE, DCS510 1 1
DCS5121, DCS5121R
PS-510
1
Tank, Handle
4rev 6_03-05-20
DCS5121, DCS5121R
PS-510
2
Cover, Air Filter, Muer
52
43
27
31
148
26
144
34
29
49
28
30
142
45
Previous models
Machines d’ancienne production
32
33
47
48
63
41
40
42
Not included
with Fig No. 40.
37
46
44
63
57
USA
AU
NZ
58
54
50
NO
POTS
39
55
56
38
36
108
109
110
CAT
62
60
61
59
5rev 6_03-05-20
PS-510
PPrroodduuccttss wwiitthh mmuullttiippllee vveerrssiioonnss aarree lliisstteedd iinn ssuubbssiiddiinngg oorrddeerr wwiitthh tthhee nneewweesstt vveerrssiioonn oonn ttoopp nnoott iinnddeenntteedd..
Tech Bulletin
Notes
Section
Fig. No.
Part No.
Description
DCS5121
DCS5121R
2 26 181-118-621 HOOD CPL. GREY 1
2 26 181-118-250 HOOD CPL. BLACK 1 >2012-03
2 26 181-118-251 HOOD CPL. BLACK 1 1 2012-04>
2 27 181-118-060 INSERT, DCS510 1 1 1
2 28 181-173-090 AIR FILTER CPL.NYLON,DCS510 1 1 1
2 28 181-173-180 AIR FILTER ASS’Y 1 1 1
2 28 181-173-240 AIR FILTER CPL.,ne 1 1
2 28 181-173-190 AIR FILTER CPL., FLEECE, EA5000P 1 1 1
2 29 181-171-050 AIR FILTER CLIP, DCS510 1 1 1
2 30 010-117-050 MODIFICATION SET, DCS510 1 1 1
2 31 266480-2 TORX SCREW 5X55, EHW120 2 2 2
2 31 908-505-555 TORX SCREW 5X55, EHW120 2 2 2
2 32 181-155-020 CHOKE ON/OFF SWITCH 1 1
2 33 970-311-550 EARTH CABLE 1 1
2 34 266478-9 SELF-CUTTING SCREW,DCS520I 1 1 1
2 34 913-455-164 SELF-CUTTING SCREW,DCS520I 1 1 1
2 36 181-131-603 BOTTOM BLUE 1
2 36 181-131-601 BOTTOM BLUE 1
2 36 181-131-103 BOTTOM RED 1 1
2 37 266472-1 CYLINDER SCREW W/LOCKWASHER M5X20, DCS460 4 4 4
2 37 908-805-205 CYLINDER SCREW W/LOCKWASHER M5X20, DCS460 4 4 4
2 38 038-118-110 RUBBER FLAP, DCS460 1 1 1
2 39 938-650-062 RIVET, DCS460 1 1 1
2 40 181-171-150 FLANGE CPL.,DCS510 1 1 1
2 41 181-131-090 TUBE, DCS510 1 1 1
2 42 181-131-041 SUCTION HOSE, DCS510 1 1 1
2 42 181-131-040 SUCTION HOSE, DCS510 1 1 1
2 43 181-118-160 INSERT FOR SUMMER/WINTER(SNOW), DCS460 1 1 1
2 44 233971-8 ANNULAR SPRING, DCS510 1 1 1
2 44 181-131-070 ANNULAR SPRING, DCS510 1 1 1
2 45 266478-9 SELF-CUTTING SCREW,DCS520I 1 1 1
2 45 913-455-164 SELF-CUTTING SCREW,DCS520I 1 1 1
2 46 181-155-010 CONTACT SPRING 1 1 2010-01
2 47 181-155-080 GUIDE, DCS5121 1 1 1 2012-04>
DCS5121, DCS5121R
PS-510
2
Cover, Air Filter, Muer
6rev 6_03-05-20
PS-510
PPrroodduuccttss wwiitthh mmuullttiippllee vveerrssiioonnss aarree lliisstteedd iinn ssuubbssiiddiinngg oorrddeerr wwiitthh tthhee nneewweesstt vveerrssiioonn oonn ttoopp nnoott iinnddeenntteedd..
Tech Bulletin
Notes
Section
Fig. No.
Part No.
Description
DCS5121
DCS5121R
2 47 181-155-030 ADJUSTING GUIDE, PS-S510 1 >2012-03
2 48 266478-9 SELF-CUTTING SCREW,DCS520I 1 1 1
2 48 913-455-164 SELF-CUTTING SCREW,DCS520I 1 1 1
2 49 928-405-000 WASHER, DCS340 1 1 1
2 50 980-114-928 LABEL, DCS510 1
2 52 181-173-250 SNOW FILTER, DCS510 1 1 1
2 54 181-174-201 MUFFLER 1 1 >2009-12
2 55 181-174-250
2 56 915-035-120 SCREW 1 1 >2009-12
2 57 181-174-061 COVER PLATE 1 1 1
2 58 181-174-050 GASKET, DCS510 1 1 1
2 59 908-005-205 SCREW M5X20, DCS460 2 2 2
2 60 181-174-091 PROTECTION COVER, DCS460 1 1 1
2 61 266474-7 SCREW M5X9, DCS5200I 2 2 2
2 61 908-005-095 SCREW M5X9, DCS5200I 2 2 2
2 62 908-805-205 CYLINDER SCREW W/LOCKWASHER M5X20, DCS460 1 1 1
2 63 346413-4 INSERT FOR SUCTION HOSE, DCS460 1
2 63 185-131-020 INSERT FOR SUCTION HOSE, DCS460 1 1 1
2 63 181-131-021 INSERT FOR SUCTION HOSE, DCS460 1 1 1
2 108 181-174-301 MUFFLER 1 1 1 2010-01>
2 109 181-174-470 SPARK ARRESTER SCREEN CPL. 1 1 1 2010-01>
2 11 0 266474-7 SCREW M5X9, DCS5200I 2 2 2
2 110 908-005-095 SCREW M5X9, DCS5200I 2 2 2
2 142 181-155-011 CONTACT SPRING 1 1 1
2 144 970-311-580 EARTH CABLE 1 1 1
2 148 181-155-070 CHOKE ON/OFF SWITCH 1 1 1
SPARK ARRESTER
SCREEN CPL.
DCS5121, DCS5121R
PS-510
2
Cover, Air Filter, Muer
1 1 >2009-12
7rev 6_03-05-20
