Magellan Maestro 4000 User Manual
Magellan®
Maestro™ 4000
User Manual
Magellan Navigation, Inc. 960 Overland Court, San Dimas, CA 91773
IMPORTANT SAFETY WARNINGS
The Magellan Maestro is a vehicle-navigation aid designed to assist you in arriving to your selected destinations. When using
the Magellan Maestro, these safety rules must be followed to prevent accidents that can result in injury or death to yourself
or others:
• California and Minnesota law prohibits mounting any item to your windshield. Please check with your state or local law
enforcement for applicable regulations regarding windshield mounting. Go to www.magellanGPS.com for alternate
mounting solutions. An adhesive disk is supplied with the Magellan RoadMate for use as an alternate mounting solution
to the dashboard.
• When driving, the need to view the display is minimal. Voice prompts will guide you to your destination. The driver
should enter data or program the Magellan Maestro only when the vehicle is stopped. Only a vehicle passenger should
enter data or program the Magellan Maestro while the vehicle is moving.
• It is your responsibility to comply with all traffic laws.
• Every attempt is made to ensure that the database is accurate. However, roadways, points of interest (POIs), and
business and service locations may change over time. The database does not include, analyze, process, consider, or
reflect any of the following: legal restrictions (such as vehicular type, weight, height, width, load and speed restrictions);
road slope or grade; bridge height, width, weight, or other limits; population density; neighborhood quality or safety;
availability or proximity of law enforcement, emergency rescue, medical, or other assistance; construction work zones or
hazards; road or lane closures; road, traffic, or traffic facilities’ safety or condition; weather conditions; pavement
characteristics or conditions; special events; traffic congestion. It is your responsibility to disregard any unsafe,
hazardous, or illegal route suggestions.
• Keep the Magellan Maestro safe from extreme temperature conditions. For example, do not leave it exposed to direct
sunlight for an extended period of time.
• Take care when mounting the Magellan Maestro in your vehicle, whether using the windshield mount or other mount or
accessories, that it does not obstruct the driver's view of the road, interfere with the operation of the vehicle's safety
devices such as air bags, or present a hazard to occupants of the vehicle should the Magellan Maestro be dislodged
while driving. You assume the risks associated with damage to your vehicle or vehicle occupants as the result of your
choices in mounting the Magellan Maestro.
• Laws in some states prohibit wearing stereo headphones while operating a motor vehicle. Please contact your state’s
Department of Motor Vehicles for information.
• The battery in the Magellan Maestro is rechargeable and should not be removed. In the event it should need to be
replaced, please contact Magellan Technical Support.
About Charging the Magellan Maestro
• Use only the AC adapter approved for your Magellan Maestro. Use of another type of AC adapter can result in
malfunction and/or possible fire hazard due to battery over heating.
• Use only the car charger approved for / supplied with your Magellan Maestro. Use of another type of car charger will
result in malfunction and/or damage to the receiver.
• The Magellan Maestro is intended to be supplied with a LISTED Power Unit marked with "LPS", "Limited Power Source"
and output rated + 5 V dc / 2.0 A".
• The Magellan Maestro cannot be charged through the USB cable.
• For safety reasons, the battery in your Magellan Maestro will stop charging when the ambient temperature is less than
32°F (0°C) or more than 113°F (45°C)
i
IMPORTANT SAFETY WARNINGS
About the AC Adapter
• Do not use the adapter in a high moisture environment. Never touch the adapter when your hands or feet are wet.
• Allow adequate ventilation around the adapter when using it to operate the device or charging the battery. Do not cover
the AC adapter with paper or other objects that will reduce cooling. Do not use the AC adapter while it is inside a
carrying case.
• Connect the adapter to a proper power source. The voltage and grounding requirements are found on the product case
and/or packaging.
• Do not use the adapter if the cord becomes damaged.
• Do not attempt to service the Magellan Maestro. There are no serviceable parts inside. Replace the Magellan Maestro if
it is damaged or exposed to excess moisture.
About the Battery
• Do not attempt to replace the battery. Please contact Magellan Technical Support for issues related to the battery.
• Use the charger approved for your Magellan Maestro.
ii
IMPORTANT SAFETY WARNINGS
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one of the following measures:
• -Reorient or relocate the receiving antenna.
• -Increase the separation between the equipment and receiver.
• -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• -Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) this device must accept any interference received, including interference that
may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate this equipment.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must
follow the specific operating instructions for satisfying RF exposure compliance.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
In order to maintain compliance with FCC regulations, shielded cables must be used with this equipment. Operation with
non-approved equipment or unshielded cables is likely to result in interference to radio and TV reception. The user is
cautioned that changes and modifications made to the equipment without the approval of manufacturer could void the user's
authority to operate this equipment.
The Magellan Maestro must be installed and operated at a distance no closer then 8 inches (20 cm) from the user.
This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.
Cet appareil numerique de la classe B respecte toutes les exigences du Reglement sur le materiel brouilleur du Canada.
iii
IMPORTANT SAFETY WARNINGS
IC statement
Operation is subject to the following two conditions:
1. This device may not cause interference and
2. This device must accept any interference, including interference that may cause undesired operation of the
device.
IMPORTANT NOTE:
IC Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. End users must follow
the specific operating instructions for satisfying RF exposure compliance.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
© 2007 Magellan Navigation, Inc. All rights reserved. The Magellan Logo, Magellan, Maestro, Turn it on and go, TrueView,
QuickSpell, SmartDetour, and SmartVolume are trademarks of Magellan Navigation, Inc. No part of this user manual may be
reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, for
any purpose other than the purchaser’s personal use, without the prior written permission of Magellan Navigation, Inc.
631447-01 B
iv
Table of Contents
Magellan Maestro 4000 ..........................................................................................................1
Front View ............................................................................................................. 2
Side Views ............................................................................................................. 2
Back View ............................................................................................................. 2
Installation Instructions ...........................................................................................................3
Selecting the Location ............................................................................................ 3
Cleaning the Area ................................................................................................... 3
Applying the Adhesive Disk ..................................................................................... 3
Attach the Cradle ................................................................................................... 3
Attach the Adjustable Mount ................................................................................... 4
Secure the Mount to the Windshield or Adhesive Disk ................................................ 4
Adjust the Mount for Optimum Viewing .................................................................... 4
Connecting Power .................................................................................................. 4
Security ................................................................................................................ 4
Fundamentals 5
Powering on the Magellan Maestro ...........................................................................5
Turning the Magellan Maestro On ........................................................................ 5
Turning the Magellan Maestro Off ....................................................................... 5
Selecting Auto-Power Shutdown Time .................................................................. 5
Volume .................................................................................................................. 5
Changing the Volume from the Map Screen. ......................................................... 5
Changing the Volume from User Options .............................................................. 6
Brightness ............................................................................................................. 6
Accessing the Brightness Control ........................................................................ 6
The Main Menu ...................................................................................................... 6
Accessing the Main Menu ................................................................................... 6
.Main Menu - Page 1 ......................................................................................................7
.Main Menu - Page 2 ......................................................................................................8
The Keypad ........................................................................................................... 9
Keypad Overview ............................................................................................................9
Special Keys ..................................................................................................... 9
Selecting From List .........................................................................................................9
QuickSpell™ ................................................................................................................10
Notes on Entering Data .................................................................................................10
Table of Contents Magellan Maestro 4000 1
Map Screen .......................................................................................................................... 11
Accessing the Map Screen ................................................................................ 13
2D Mode ......................................................................................................................13
Setting the Map Modes (2D or 3D) .................................................................... 13
Panning on the Map ......................................................................................... 13
Saving a Position While Panning ....................................................................... 13
Routing to a Panned Position ............................................................................ 14
Current Location Screen ....................................................................................... 14
Accessing the Current Location Screen .............................................................. 14
Saving Your Current Location to Your Address Book ............................................ 14
Maneuver List Screen ........................................................................................... 15
Accessing the Maneuver List ............................................................................. 15
Excluding a Maneuver ...................................................................................... 15
GPS Status Screen ............................................................................................... 16
Accessing the GPS Status Screen ..................................................................... 16
Zoom Levels ........................................................................................................ 16
Setting Zoom Levels ........................................................................................ 16
Volume ................................................................................................................ 16
Changing the Volume from the Map Screen. ....................................................... 16
Home Address .......................................................................................................................17
Creating a Home Address ................................................................................. 17
Creating a Route to the Home Address ............................................................... 17
Changing the Home Address ............................................................................. 17
Accessing the Home Address from the Address Book .......................................... 18
Enter Address ........................................................................................................................19
Entering an Address .............................................................................................19
Creating a Route to a New Address .................................................................... 19
My Addresses ....................................................................................................... 21
Accessing the My Addresses Menu .................................................................... 21
Previous Destinations ...................................................................................................21
Routing to a Previous Destination ...................................................................... 21
Saving a Previous Destination to Your Address Book ............................................ 22
Deleting a Previous Destination ......................................................................... 22
Address Book ...............................................................................................................22
Accessing an Address in Your Address Book ....................................................... 22
Routing to an Address in Your Address Book ...................................................... 23
Editing an Address in Your Address Book. .......................................................... 23
Deleting an Address in Your Address Book. ........................................................ 23
Table of Contents Magellan Maestro 4000 2
Favorites ......................................................................................................................23
Accessing an Address from Favorites ................................................................. 23
Routing to an Address from Your Favorites List ................................................... 24
Editing an Address from Your Favorites List ....................................................... 24
Deleting an Address from Your Favorites List ...................................................... 24
Creating a New Entry ....................................................................................................24
Creating a New Entry to You Address Book by Selecting on the Map ..................... 24
Creating a New Entry to You Address Book by Entering an Address ....................... 25
Creating a New Entry to You Address Book from a POI ........................................ 25
Creating a New Entry to You Address Book from by Intersections .......................... 26
Intersection ......................................................................................................... 26
Creating a Route to Two Intersecting Streets ...................................................... 26
Points of Interest (POI) ..........................................................................................................27
Categories and Subcategories ................................................................................ 27
Creating a Route to a POI by Category ............................................................... 27
Creating a Route to a POI by Name ................................................................... 28
Enhanced POIs .................................................................................................... 28
Loading a POI File ........................................................................................... 28
Selecting Categories for Display on the Map ....................................................... 29
Setting Alarms ................................................................................................ 29
Setting Alarm Parameters ................................................................................. 30
Routing to an Enhanced POI ............................................................................. 30
Saving an Enhanced POI to Your Address Book .................................................. 31
AAA TourBook® ................................................................................................... 31
AAA TourBook® ....................................................................................................................32
Overview .............................................................................................................. 32
AAA TourBook® ................................................................................................... 32
Accessing the AAA TourBook® .......................................................................... 32
AAA TourBook® Information ................................................................................. 33
Getting AAA TourBook® Information .................................................................33
Routing To the Selected POI ............................................................................. 33
Show Your Card & Save® ...................................................................................... 34
Getting Show Your Card & Save® Information ..................................................... 34
Routing to the Selected POI ............................................................................. 34
Approved Automotive Repairs ................................................................................ 35
Getting Approved Automotive Repair Information ................................................ 35
Routing to the Selected Automotive Facility ....................................................... 35
AAA Branch Offices .............................................................................................. 36
Getting AAA Branch Office Information .............................................................. 36
Table of Contents Magellan Maestro 4000 3
Routing to the Selected AAA Branch Office ........................................................ 36
Campgrounds ....................................................................................................... 37
Getting Campground Information ...................................................................... 37
Routing To the Selected Campground ................................................................ 37
Travelling on a Route ............................................................................................................38
Map Screen ......................................................................................................... 38
Split-Screen ..................................................................................................................38
Maneuver List ...............................................................................................................38
You Have Arrived .......................................................................................................... 39
Types of Routes ...................................................................................................39
Route Method ...................................................................................................... 39
Special Routing Functions .................................................................................... 40
Routing to a POI Near an Approaching Freeway Exit ............................................ 40
Cancelling a Route .......................................................................................... 40
Detouring off a Route ....................................................................................... 40
Changing the Route Method ............................................................................. 41
AAA Roadside Assistance ......................................................................................................42
Overview .............................................................................................................. 42
The AAA Roadside Assistance Screen ..................................................................... 42
Accessing AAA Roadside Assistance .................................................................. 42
Entering Your AAA Membership Number ............................................................ 42
Trip Planner ..........................................................................................................................43
Creating a Trip ................................................................................................ 43
Starting a Trip ................................................................................................. 44
Editing a Trip .................................................................................................. 45
Deleting a Trip ................................................................................................ 45
Renaming a Trip .............................................................................................. 46
Exit POIs ...............................................................................................................................47
Routing to a POI Near an Approaching Freeway Exit ............................................ 47
User Options ......................................................................................................................... 48
Setting Map Region ......................................................................................... 48
Accessing System Settings ............................................................................... 48
Checking Battery Life ....................................................................................... 48
Adjusting the Volume ....................................................................................... 49
Adjusting the Display Brightness ....................................................................... 49
Setting Auto Power Off Time ............................................................................. 49
Table of Contents Magellan Maestro 4000 4
Selecting Language ......................................................................................... 50
Setting Time Zone ........................................................................................... 50
Selecting Units of Measure ............................................................................... 51
Displaying Contact Us Information .................................................................... 51
Displaying Product Information ......................................................................... 51
Performing Diagnostics .................................................................................... 52
Accessing the Trip Computer ............................................................................ 52
Selecting POIs to be Displayed on the Map ........................................................ 53
Deleting Addresses from the Address Book (Global) ............................................ 53
Setting the Map in 3D or 2D Mode .................................................................... 53
Setting the Map Display to Heading Up or North Up ...........................................54
Setting Split Screen (TrueView™) Options ......................................................... 54
Setting Auto Night Map Display ........................................................................ 54
Setting Detour Options ..................................................................................... 55
Using the Simulator ......................................................................................... 55
Setting Tone Options ....................................................................................... 56
Viewing Technical GPS Information ................................................................... 56
Setting the GPS Position .................................................................................. 56
Backing Up and Restoring Data ........................................................................ 57
Backing Up Data ............................................................................................. 57
Restoring Data ................................................................................................ 57
Viewing Map Information .................................................................................. 58
Appendix A - POI Categories / Subcategories .......................................................................A - 1
Appendix B - Specifications .................................................................................................B - 1
Appendix C - Frequently Asked Questions (FAQ) ....................................................................C - 1
Table of Contents Magellan Maestro 4000 5
Magellan Maestro 4000
The Magellan Maestro 4000 is a vehicle navigation product that utilizes GPS signals from satellites to
calculate your precise location and compute details about its travel. Knowing its position and
®
movement, it can then overlay this information on detailed maps provided by NAVTEQ
visual representation of your location.
With the Magellan Maestro 4000 you can:
• Store your home address and quickly get routing details to your home.
• Create and save addresses in your address book that can be accessed at any time and get
routing information to that address.
• Route to an address that you enter using the keypad and Magellan’s QuickSpell feature for
easy, errorless entry.
• Route to any point of interest (POI) that has been preloaded into your Magellan Maestro.
(Custom POIs can also be created and uploaded using the POI Manager software supplied
on the included CD-ROM.)
• Route to a POI that appears on the map while traveling simply by tapping on the POI icon.
• Route to an intersection by selecting the streets.
to provide a
®
• Use the AAA TourBook
®
AAA TourBook
also includes ratings, discount information for AAA members, hours of
to select a destination and get routing details to travel by. The
operation, information about the POI and other valuable facts,
• AAA Roadside Assistance for quick and easy access to information about your location to
assist in getting AAA services to your location.
• A trip planner to create a trip with multiple destinations. Handy for business people who
need routing information to many destinations.
• An exit POI tool that provides you with a list of gas stations, restaurants, hotels and auto
repair shops located nearby exits you are approaching that you can route to while traveling
on a freeway.
• Options that provide means to customize your Magellan Maestro to meet your needs.
The interface for the Magellan Maestro is easy and simple to follow once you understand the basics.
You may never need to refer to this manual but if you do we have tried to present it in a form that you
can access the function you are trying to complete and follow the steps provided.
The Magellan Maestro has a built-in battery so in most cases you will be able to follow these
instructions while reading them on your computer screen without plugging it in to AC power. You
should note that while indoors you may not get any satellite signals so your location information would
not be updated. However, the power of the SiRFstarIII™ chipset installed in the Magellan Maestro
will get satellite signals in some very rough locations so you may notice the Magellan Maestro
computing a position, even indoors.
This document is set up to be printed on 8.5” x 11” (letter) paper should you desire a printed version
for your reference.
Magellan Maestro 4000 1
Front View
Side Views
4.3” Display
A SD/MMC card slot
B Power on/off
A
C USB connector
Back View
D Reset
B
E Headphone Jack (3.5mm mini jack)
C
F Power input from cigarette lighter
E
adapter or AC power adapter (+5
D
VDC / 2A).
A
F
A Speaker
Magellan Maestro 4000 2
Installation Instructions
Installation of the Magellan Maestro is simple and easy. The hardest part will be picking the best
location.
Selecting the Location
A few tips on selecting the proper location.
• Mount the Magellan Maestro in a place where it can be easily seen and will not interfere
with your view of the road.
• The Magellan Maestro should be mounted in such a way that the antenna, (located in the
top of the receiver), has an unobstructed view of the sky through the windshield.
• Select whether it will be mounted using the adjustable mount to the windshield or the
supplied adhesive disk. Be sure to check your local and regional laws before mounting to
the windshield. Some states, like California and Minnesota, have laws restricting the
mounting of any device on the windshield.
• If planning to use the adhesive disk, a smooth surface on the dash board will need to be
selected. Do not attach the adhesive disk to the windshield.
• Make sure that the Magellan Maestro or any cabling will not be disturbed in the event that
the airbags are deployed.
Cleaning the Area
Use the alcohol pad that came with the Magellan Maestro to clean the area on the windshield or dash
that has been selected for mounting the Magellan Maestro.
Applying the Adhesive Disk
(Skip if mounting directly to the windshield.) Remove the protective tape from the back of the
adhesive disk. Apply the disk with the adhesive side towards the dash. Maintain pressure on the disk
for 5 minutes to allow it to set in place. Allow the disk 24 hours to cure before continuing.
Attach the Cradle
Line up the two mounting tabs on the cradle with
the mounting slots on the bottom of the Magellan
Maestro. Press the back of the cradle until it
snaps in place with the back of the receiver.
Please note that the mounting bracket supplied with the Magellan Maestro may be different then the one shown in this
document.
Installation 3
Attach the Adjustable Mount
Line up the two tabs on the adjustable mount with
the holes on the back of the cradle. Once the
adjustable mount is flush with the cradle, push the
cradle and receiver assembly down until they lock
in place with the adjustable mount.
Secure the Mount to the Windshield or Adhesive Disk
Make sure that the lever at the base of the adjustable mount is in the up position. Place the base of
the mount firmly over the area of the windshield to be used or the adhesive disk. Push the lever at
the base of the mount all the way down until it snaps in place. Carefully let go of the assembly,
making sure that it is securely mounted.
Adjust the Mount for Optimum Viewing
Loosen the adjustment locking knobs and position the Magellan Maestro for optimum viewing. Once
set, tighten the locking knobs. (Never attempt to adjust the mount while driving.)
Connecting Power
Plug the end of the cigarette lighter adapter into a
12 VDC cigarette lighter receptacle in the vehicle.
Connect the other end to the Magellan Maestro as
shown. There is a wire catch on the side of the
cradle to run the power cable through to prevent it
from disconnecting. If there is power at the
receptacle, the Magellan Maestro will power on.
(Note: some vehicles apply power to the cigarette
lighter receptacle only when the ignition is on.)
Security
It is recommended that the Magellan Maestro is not left in plain view while unattended for reasons of
theft. The easiest method for removing the Magellan Maestro once the mount is in place is to unsnap
it from the cradle by pressing on the tab at the top of the cradle.
Installation 4
Fundamentals
Powering on the Magellan Maestro
The On/Off button is the silver button located on the left side of the Magellan Maestro as shown in the
Overview chapter.
Turning the Magellan Maestro On
1. Press and hold the On/Off button for 1-2 seconds.
2. Read the Warnings and tap OK.
Turning the Magellan Maestro Off
1. Press and hold the On/Off button for 1-2 seconds.
Selecting Auto-Power Shutdown Time
The Magellan Maestro can be set up to shut down automatically using the time durations you can
select. The receiver will turn off after the selected duration has passed when; A) the position hasn’t
changed and B) the touchscreen hasn’t been pressed.
1. Access the Main Menu.
2. Tap the Next arrow to access the Main Menu Page 2.
3. Tap User Options.
4. Tap System Settings.
5. Tap Power.
6. Select Auto-Power Off time; Never, 10 Minutes, 20 Minutes or 30 Minutes.
7. Tap Save.
8. Tap the Back arrow to return to the Main Menu.
Volume
There arre two ways to access the volume controls; one
is tapping the speaker icon on the Map screen and the
other is through User Options.
Changing the Volume from the Map Screen.
1. Tap the speaker icon .
2. Tap on the Mute button to mute the volume or
tap inside the volume adjust bar below the
Mute button to change the volume levels.
3. Tap .
If you have the volume muted the speaker icon is displayed with a line through it indicating it is
muted. To unmute, tap the speaker icon again.
Fundamentals 5
Changing the Volume from User Options
1. Access the Main Menu.
2. Tap the Next arrow to access the Main Menu Page 2.
3. Tap User Options.
4. Tap System Settings.
5. Tap Volume.
6. Tap on the Mute button to mute the volume or tap inside the volume adjust bar below the
Mute button to change the volume levels.
7. Tap .
Brightness
Accessing the Brightness Control
1. Access the Main Menu.
2. Tap the Next arrow to access the Main Menu
Page 2.
3. Tap User Options.
4. Tap System Settings.
5. Tap Brightness.
6. Tap inside the brightness adjust bar to set the desired brightness.
7. Tap .
On the Brightness screen there is a checkbox for “On-battery dimming (75%)” When checked, the
Magellan Maestro will dim to 75% of the brightness when operating exclusively on battery power.
This prolongs the battery life between charges. It can be turned off by tapping on the checkbox.
The Main Menu
The Main Menu screen is the center for all the available functions for the Magellan Maestro. The
Main Menu consists of two pages with large, easy to access icons.
Accessing the Main Menu
From the Map screen tap the Menu button.
From the other screens, tap the Back button.
Fundamentals 6
.Main Menu - Page 1
Show Map: Displays the map with your current position (if computing a position from the GPS
signals) indicated by the blue triangle. See the Map Screen chapter for details.
Enter Address: Displays Enter Address menu. Addresses can be entered by first entering the city, zip
code, or by selecting a city from a list of cities you have already used as destinations. Also provides
access to your address book (my addresses) or to create a route to an intersection. See the chapter on
Routing to an Address for details.
Points of Interest: Displays the Search Points of Interest menu. Search for POIs by entering the
name or by selecting from a list of available categories. The AAA TourBook™ is also accessed from
the Search Points of Interest menu. Additionally, POIs that have been created and installed using the
POI Manager software (found on the CD-ROM) can be accessed from this menu. For more
information on the Search Points of Interest menu, see the Points of Interest chapter.
Home: If you have created a Home address, press the Home button for quick access for routing to
your home. If a Home address has not been created, a prompt is displayed to do so. See the Home
Button chapter for more information.
AAA Roadside Assistance: Displays the AAA Roadside Assistance screen. For more information on
the AAA Roadside Assistance screen, see the chapter on AAA Roadside Assistance.
Fundamentals 7
.Main Menu - Page 2
Trip Planner: Opens the Trip Planner menu where you can create, edit, delete, rename or activate a
trip.
Exit POI’s: (Accessible only while on a freeway.) Provides a listing of restaurants, gas stations, auto
repair shops or hotels near approaching freeway exits. You can select one of the POIs presented and
create a route to it.
User Options: Accesses the User Options menu. This menu can be used to access functions used to
customize the Magellan Maestro to your personal needs.
Home: If you have created a Home address, press the Home button for quick access for routing to
your home. If a Home address has not been created, a prompt is displayed to do so. See the Home
Button chapter for more information.
AAA Roadside Assistance: Displays the AAA Roadside Assistance screen. For more information on
the AAA Roadside Assistance screen, see the chapter on AAA Roadside Assistance.
Fundamentals 8
The Keypad
Understanding the keypad while entering an address is an important part of using your Magellan
Maestro. The keypad is the most common means of entering data into the Magellan Maestro, and
with such key features as QuickSpell, makes entering data quick and easy.
Keypad Overview
Special Keys
Alphabetic Keypad Numeric Keypad
Symbols Keypad Spacebar
Backspace
Accept Cancel
Selecting From List
After tapping “OK” to accept your input you may get a
list of items found in the database. The sample here
shows the result of tapping “OK” after entering “LOS
A”. Use the scroll bar to move up and down the list and
tap on the desired item in the list to continue.
Fundamentals 9
QuickSpell™
QuickSpell uses the information in the database to limit the keys that can be pressed to present only
those which can access information in the database.
For example, if you are looking for Los Angeles. As you
‘type’ in the name Los Angeles, only keys that can spell
a city in the database are shown. In the screen to the
right, ‘LOS “ has been entered. Keys that would not
continue to spell a city in the database are grayed out..
This is done to enable the city and street names to be
entered quickly and without any errors due to typos.
Notes on Entering Data
If you are having trouble getting the results you expected here are a few useful tips.
• Make sure that you have spelled the name correctly. If you are unsure of the spelling, just
enter a few characters and tap “OK”. A long list of names will be displayed but you can
step through the list and probably be able to find the correct spelling.
• Check for apostrophes. If searching a for Lowe’s Home Improvent Center you need to
enter the apostrophe. Entering ‘LOWES’ without the apostrophe will not display what you
are searching for.
• When entering a street name you can use the street prefix (N. E. W. S. etc.) to narrow the
search. For example to find N. Main St. you could enter “N. Main” or “N Main”.
• The more characters you enter, the smaller the list of POIs found will be.
Fundamentals 10
Map Screen
The most commonly used screen will be the Map screen. Whether on a route or just travelling around
town, chances are the Map screen will be displayed. There are two unique modes that the Map
screen can be displayed in; normal and routing.
In normal mode, your position is shown on the map along with the time and your speed. As you
travel, your position will be updated, giving you a clear view of your position and surrounding streets.
A
B
K
C
J
D
I
E
F
Map Screen - Normal Mode
A Street name currently on.
B Direction indicator. Tap to view the Current Location screen where you can save your
position into your Address Book.
C Zoom out
D POI icon. Sample shown here is for a gas station. Tap on the POI icon to create a route to
that POI. Note: If there are multiple POIs in the same area, a list of those POIs will be
displayed. Tap on the name in the list to access the routing function.
E Current position icon
F Time of da y
G Main Menu button. Tap to display the Main Menu.
H Current speed of travel
I Volume control. Tap to display the Volume Setting screen where the loudness can be
adjusted or muted. (If the volume has been muted, tapping this button unmutes the volume
without displaying the Volume Setting screen.)
J Zoom in
G H
K Satellite Status. All four bars in green in optimal. Tap to display the GPS Status screen.
Map Screen 11
In routing mode additional information is displayed providing detailed information about the route
you’ve selected.
A
B
N
C
M
D
L
E
K
J
F
G
Map Screen - Routing Mode
H I
A Street name currently on.
B Direction indicator. Tap to view the Current Location screen where you can save your
position into your Address Book.
C Zoom out
D POI icon. Sample shown here is for a gas station. Tap on the POI icon to create a route to
that POI. Note: If there are multiple POIs in the same area, a list of those POIs will be
displayed. Tap on the name in the list to access the routing function.
E Current position icon
F Next maneuver icon. Tap on the icon to display the Maneuver List screen.
G Distance to next maneuver. Tap to repeat the last voice command.
H Main Menu button. Tap to go to the Main Menu screen. Note that the Main Menu screen is
different when there is an active route. See the chapter on Routing for details.
I Tap to toggle between distance remaining to reach destination and approximately how long
it will take to arrive at the destination.
J Street name for the next maneuver
K Graphical representation of the route
L Volume control. Tap to display the Volume Setting screen where the loudness can be
adjusted or muted. (If the volume has been muted, tapping this button unmutes the volume
without displaying the Volume Setting screen.)
M Zoom in
N Satellite Status. All four bars in green in optimal. Tap to display the GPS Status screen.
Map Screen 12
Accessing the Map Screen
1. On the Main Menu, tap Show Map.
2D Mode
The map is normally displayed in 3D mode but you
can set the map to 2D mode if so desired. Choose
the mode that is best suited for you.
In 2D mode, you can pan across the map looking for
a location to route to or save in your address book.
Setting the Map Modes (2D or 3D)
1. From the Map screen, tap MENU.
2. Tap the Next arrow to access page 2 of the
Main Menu.
3. Tap User Options.
4. Tap Map Options.
5. Tap 3D Map or 2D Map.
6. Tap Save.
Map Screen in 2D Mode
Panning on the Map
1. While viewing the Map screen in 2D mode, slide your finger or stylus across the map.
2. The location icon changes to . (The circle is the crosshairs for a position and the red
arrow points to your current location.
3. To exit panning, tap and the map is returned to your current position.
Saving a Position While Panning
1. Pan the map until the icon crosshairs are over the location you want to save to your address
book. (Must be a position that is does not have a POI icon displayed.)
2. Tap in the center of the icon circle. (If nothing happens then you are not zoomed in enough.
Tap the zoom in icon and try again.)
3. On the Route To This Address? screen, tap .
4. Edit Information:
Tap on the Edit Name line to create a name for this location.
Tap on any of the three (work, home, mobile) phone buttons to enter a phone number.
Tap on the Edit Information line to add additional information. (Up to 35
characters can be entered.)
5. If you want to tag this location as one of your favorites, tap on the “Favorite” check box.
Map Screen 13
Loading...
