Adobe® FrameMaker® 9 MIF Reference

If this guide is distributed with software that includes an end-user agreement, this guide, as well as the software described in it, is furnished under license and may be used or copied only in accordance with the terms of such license. Except as permitted by any such license, no part of this guide may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, recording, or otherwise, without the prior written permission of Adobe Systems Incorporated. Please note that the content in this guide is protected under copyright law even if it is not distributed with software that includes an end-user license agreement.

The content of this guide is furnished for informational use only, is subject to change without notice, and should not be construed as a commitment by Adobe Systems Incorporated. Adobe Systems Incorporated assumes no responsibility or liability for any errors or inaccuracies that may appear in the informational content contained in this guide.

Please remember that existing artwork or images that you may want to include in your project may be protected under copyright law. The unauthorized incorporation of such material into your new work could be a violation of the rights of the copyright owner. Please be sure to obtain any permission required from the copyright owner.

Any references to company names in sample templates are for demonstration purposes only and are not intended to refer to any actual organization.

Adobe, the Adobe logo, Acrobat, Distiller, Flash, FrameMaker, and PostScript are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries.

Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. UNIX is a trademark in the United States and other countries, licensed exclusively through X/Open Company, Ltd. Sun is a trademark or registered trademark of Sun Microsystems, Inc. in the United States and other countries. Palatino is a trademark of Heidelberger Druckmaschinen AG exclusively licensed through Linotype Library GmbH, and may be registered in certain jurisdictions. All other trademarks are the property of their respective owners.

This work is licensed under the Creative Commons Attribution Non-Commercial 3.0 License. To view a copy of this license, visit http://creativecommons.org/licenses/bync/3.0/us/

This product contains either BSAFE and/or TIPEM software by RSA Data Security, Inc.

This product contains color data and/or the Licensed Trademark of The Focoltone Colour System.

PANTONE® Colors displayed in the software application or in the user documentation may not match PANTONE-identified standards. Consult current PANTONE Color Publications for accurate color. PANTONE® and other Pantone, Inc. trademarks are property of Pantone, Inc. © Pantone, Inc. 2003. Pantone, Inc. is the copyright owner of color data and/or software which are licensed to Adobe Systems Incorporated to distribute for use only in combination with Adobe FrameMaker. PAN TONE C olor Data a nd /or So ft ware shall not be copied onto another disk or into memory unless as part of the execution of Adobe FrameMaker software.

Software is produced under Dainippon Ink and Chemicals Inc.'s copyrights of color-data-base derived from Sample Books.

This product includes software developed by the Apache Software Foundation (http://www.apache.org/).

Portions contributed by Gilles Vollant.

Certain Spelling portions of this product is based on Proximity Linguistic Technology. ©Copyright 1990 Merriam-Webster Inc. ©Copyright 1990 All rights reserved. Proximity Technology A Division of Franklin Electronic Publishers, Inc. Burlington, New Jersey USA. ©Copyright 2003 Franklin Electronic Publishers Inc.©Copyright 2003 All rights reserved. Proximity Technology A Division of Franklin Electronic Publishers, Inc. Burlington, New Jersey USA. Legal Supplement ©Copyright 1990/1994 Merriam-Webster Inc./Franklin Electronic Publishers Inc. ©Copyright 1994 All rights reserved. Proximity Technology A Division of Franklin Electronic Publishers, Inc. Burlington, New Jersey USA. ©Copyright 1990/1994 Merriam-Webster Inc./Franklin Electronic Publishers Inc. ©Copyright 1997All rights reserved. Proximity Technology A Division of Franklin Electronic Publishers, Inc. Burlington, New Jersey USA ©Copyright 1990 Merriam-Webster Inc. ©Copyright 1993 All rights reserved. Proximity Technology A Division of Franklin Electronic Publishers, Inc. Burlington, New Jersey USA. ©Copyright 2004 Franklin Electronic Publishers Inc. ©Copyright 2004 All rights reserved. Proximity Technology A Division of Franklin Electronic Publishers, Inc. Burlington, New Jersey USA. ©Copyright 1991 Dr. Lluis de Yzaguirre I Maura ©Copyright 1991 All rights reserved. Proximity Technology A Division of Franklin Electronic Publishers, Inc. Burlington, New Jersey USA. ©Copyright 1990 Munksgaard International Publishers Ltd. ©Copyright 1990 All rights reserved. Proximity Technology A Division of Franklin Electronic Publishers, Inc. Burlington, New Jersey USA. ©Copyright 1990 Van Dale Lexicografie bv ©Copyright 1990 All rights reserved. Proximity Technology A Division of Franklin Electronic Publishers, Inc. Burlington, New Jersey USA. ©Copyright 1995 Van Dale Lexicografie bv ©Copyright 1996 All rights reserved. Proximity Technology A Division of Franklin Electronic Publishers, Inc. Burlington, New Jersey USA. ©Copyright 1990 IDE a.s. ©Copyright 1990 All rights reserved. Proximity Technology A Division of Franklin Electronic Publishers, Inc. Burlington, New Jersey USA. ©Copyright 1992 Hachette/Franklin Electronic Publishers Inc. ©Copyright 2004 All rights reserved. Proximity Technology A Division of Franklin Electronic Publishers, Inc. Burlington, New Jersey USA. ©Copyright 1991 Text & Satz Datentechnik ©Copyright 1991 All rights reserved. Proximity Technology A Division of Franklin Electronic Publishers, Inc. Burlington, New Jersey USA. ©Copyright 2004 Bertelsmann Lexikon Verlag ©Copyright 2004 All rights reserved. Proximity Technology A Division of Franklin Electronic Publishers, Inc. Burlington, New Jersey USA. ©Copyright 2004 MorphoLogic Inc. ©Copyright 2004 All rights reserved. Proximity Technology A Division of Franklin Elect ronic Publishers, Inc. Burlington, New Jersey USA. ©Copyright 1990 William Collins Sons & Co. Ltd. ©Copyright 1990 All rights reserved. Proximity Technology A Division of Franklin Electronic Publishers, Inc. Burlington, New Jersey USA. ©Copyright 1993-95 Russicon Company Ltd. ©Copyright 1995 All rights reserved. Proximity Technology A Division of Franklin Electronic Publishers, Inc. Burlington, New Jersey USA. ©Copyright 2004 IDE a.s. ©Copyright 2004 All rights reserved. Proximity Technology A D ivision of Franklin El ectronic Publishers, Inc. Burlington, New Jersey USA. The Hyphenation portion of this product is based on Proximity Linguistic Technology. ©Copyright 2003 Franklin Electronic Publishers Inc.©Copyright 2003 All rights reserved. Proximity Technology A Division of Franklin Electronic Publishers, Inc. Burlington, New Jersey USA. ©Copyright 1984 William Collins Sons & Co. Ltd. ©Copyright 1988 All rights reserved. Proximity Technology A Division of Franklin Electronic Publishers, Inc. Burlington, New Jersey USA. ©Copyright 1990 Munksgaard International Publishers Ltd. ©Copyright 1990 All rights reserved. Proximity Technology A Division o Burlington, New Jersey USA. ©Copyright 1997 Van Dale Lexicografie bv ©Copyright 1997 All rights reserved. Proximity Technology A Division of Franklin Electronic Publishers, Inc. Burlington, New Jersey USA. ©Copyright 1984 Editions Fernand Nathan ©Copyright 1989 All rights reserved. Proximity Technology A Division of Franklin Electronic Publishers, Inc. Burlington, New Jersey USA. ©Copyright 1983 S Fischer Verlag ©Copyright 1997 All rights reserved. Proximity Technology A Division of Franklin Electronic Publishers, Inc. Burlington, New Jersey USA. ©Copyright 1989 Zanichelli ©Copyright 1989 All rights reserved. Proximity Technology A Division of Franklin Electronic Publishers, Inc. Burlington, New Jersey USA. ©Copyright 1989 IDE a.s. ©Copyright 1989 All rights reserved. Proximity Technology A D ivision of Franklin El ectronic Publishers, Inc. Burlington, New Jersey USA. ©Copyright 1990 Espasa-Calpe ©Copyright 1990 All rights reserved. Proximity Technology A Division of Franklin Electronic Publishers, Inc. Burlington, New Jersey USA. ©Copyright 1989 C.A. Stromberg AB. ©Copyright 1989 All rights reserved. Proximity Technology A Division of Franklin E lectronic Publishers, Inc. Burlington, New Jersey USA.

Portions of Adobe Acrobat include technology used under license from Autonomy, and are copyrighted.

Adobe Systems Incorporated, 345 Park Avenue, San Jose, California 95110, USA.

Notic e to U.S. gov ernment end user s. The so ftware a nd document ation are “Comm ercial Items,” as that te rm is de fined at 48 C.F.R. §2.101, consisting of “Commercial Computer Software” and “Commercial Computer Software Documentation,” as such terms are used in 48 C.F.R. §12.212 or 48 C.F.R. §227.7202, as applicable. Consistent with 48 C.F.R.

§12.212 or 48 C.F.R. §§227.7202-1 through 227.7202-4, as applicable, the Commercial Computer Software and Commercial Computer Software Documentation are being licensed to U.S. Government end users (a) only as Commercial items and (b) with only those rights as are granted to all other end users pursuant to the terms and conditions herein. Unpublished-rights reserved under the copyright laws of the United States. For U.S. Government End Users, Adobe agrees to comply with all applicable equal opportunity laws including, if appropriate, the provisions of Executive Order 11246, as amended, Section 402 of the Vietnam Era Veterans Readjustment Assistance Act of 1974 (38 USC 4212), and Section 503 of the Rehabilitation Act of 1973, as amended, and the regulations at 41 CFR Parts 60-1 through 60-60, 60-250, and 60-741. The affirmative action clause and regulations contained in the preceding sentence shall be incorporated by reference.

f Franklin Electronic Publishers, Inc.

Chapter 1: Introduction

Why use MIF? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Using this manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Style conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Overview of MIF statements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

MIF statement syntax . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Chapter 2: Using MIF Statements

Working with MIF files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Creating a simple MIF file for FrameMaker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Creating and applying character formats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Creating and formatting tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Specifying page layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Creating markers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Creating cross-references . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Creating variables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Creating conditional text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Creating filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Including template files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Setting View Only document options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Applications of MIF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Debugging MIF files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Other application tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Where to go from here . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

iii

Chapter 3: MIF Document Statements

MIF file layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

MIFFile statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Control statements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Macro statements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Track edited text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Conditional text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Boolean expressions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Filter By Attribute . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Paragraph formats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Character formats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Color . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Variables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

Cross-references . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

Global document properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Pages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102

Graphic objects and graphic frames . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104

Text flows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122

Text insets (text imported by reference) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130

Chapter 4: MIF Book File Statements

MIF book file overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137

MIF book file identification line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138

Book statements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138

Chapter 5: MIF Statements for Structured Documents and Books

Structural element definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148

Attribute definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151

Format rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152

Format change lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 158

Elements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 165

Filter By Attribute . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167

XML data for structured documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 168

Preference settings for structured documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 169

Text in structured documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172

Structured book statements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172

MIF Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175

Chapter 6: MIF Equation Statements

Document statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177

Math statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 181

MathFullForm statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 182

Chapter 7: MIF Asian Text Processing Statements

Asian Character Encoding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201

Combined Fonts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 202

Kumihan Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 205

Rubi text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 215

Chapter 8: Examples

Text example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 219

Bar chart example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 220

Pie chart example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 223

Custom dashed lines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 224

Table examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 226

Database publishing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 229

Chapter 9: MIF Messages

General form for MIF messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 236

List of MIF messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 236

Chapter 10: MIF Compatibility

MIF syntax changes in FrameMaker 8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 239

Changes between version 6.0 and 7.0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 240

Changes between version 5.5 and 6.0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 241

Changes between version 5 and 5.5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 242

Changes between versions 4 and 5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 243

Changes between versions 3 and 4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 247

Chapter 11: Facet Formats for Graphics

Facets for imported graphics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 251

Basic facet format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 252

Graphic insets (UNIX versions) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 253

General rules for reading and writing facets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 258

Chapter 12: EPSI Facet Format

Specification of an EPSI facet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 259

Example of an EPSI facet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 259

Chapter 13: FrameImage Facet Format

Specification of a FrameImage facet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 261

Specification of FrameImage data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 261

Differences between monochrome and color . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 264

Sample unencoded FrameImage facet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 265

Sample encoded FrameImage facet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 266

Chapter 14: FrameVector Facet Format

Specification of a FrameVector facet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 268

Specification of FrameVector data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 268

Sample FrameVector facet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 284

Chapter 1: Introduction

MIF (Maker Interchange Format) is a group of ASCII statements that create an easily parsed, readable text file of all the text, graphics, formatting, and layout constructs that Adobe® FrameMaker® native representation of a FrameMaker document, it allows FrameMaker and other applications to exchange information while preserving graphics, document content, and format.

understands. Because MIF is an alter-

Why use MIF?

You can use MIF files to allow FrameMaker and other applications to exchange information. For example, you can write programs to convert graphics and text into MIF and then import the MIF file into FrameMaker with the graphics and text intact. You can also save a FrameMaker document or book file as a MIF file and then write a program to convert the MIF file to another format. These conversion programs are called filters; filters allow you to convert FrameMaker document files into foreign files (files in another word processing or desktop publishing format), and foreign files into FrameMaker document files.

You can use MIF files with database publishing applications, which allow you to capture changing data from databases and format the data into high-quality documents containing both text and graphics information. You use the database to enter, manipulate, sort, and select data. You use FrameMaker to format the resulting data. You use MIF files as the data interchange format between the database and FrameMaker.

You can also use MIF files to do the following:

• Share documents with earlier versions of FrameMaker

• Perform custom document processing

• Set options for online documents in View Only format

These tasks are described in “Applications of MIF” on page 47. You can use other FrameMaker to perform some of these tasks. See “Other application tools” on page 51.

Using this manual

This manual:

• Describes the layout of MIF files.

• Provides a complete description of each MIF statement and its syntax.

• Provides examples of how to use MIF statements.

• Includes MIF statements for version 7.0 of FrameMaker

To get the most from this manual you should be familiar with FrameMaker. For information about FrameMaker and its features, see the documentation for your product. In addition, if you are using MIF as an interchange format between FrameMaker and another application, you should be familiar with the tools needed to create and manipulate the other application, such as a programming language or database query language.

This chapter provides basic information about working with MIF files, including opening and saving MIF files in FrameMaker. It goes on to provide detailed information about the MIF language and its syntax.

ADOBE FRAMEMAKER 9

MIF Reference

For an introduction to writing MIF files, read , “Using MIF Statements.” You can then use the statement index, subject index, and table of contents to locate more specific information about a particular MIF statement.

For a description of a MIF statement, use the table of contents or statement index to locate the statement.

For a description of the differences between the MIF statements for this version of FrameMaker and earlier versions, see , “MIF Compatibility.”

Style conventions

This manual uses different fonts to represent different types of information.

• What you type is shown in

text like this.

• MIF statement names, pathnames, and filenames are also shown in

text like this.

• Placeholders (such as MIF data) are shown in

text like this

• For example, the statement description for PgfTag is shown as:

<PgfTag

• Yo u r ep la ce

This manual also uses the term FrameMaker, (as in FrameMaker document, or FrameMaker session) to refer to FrameMaker and to refer to structured or unstructured documents.

tagstring

with the tag of a paragraph format.

Overview of MIF statements

When you are learning about MIF statements, you may find it useful to understand how FrameMaker represents documents.

How MIF statements represent documents

FrameMaker represents document components as objects. Different types of objects represent different components in a FrameMaker document. For example, a paragraph is considered an object; a paragraph format is considered a formatting object. The graphic objects that you create by using the Tools palette are yet another type of object.

Each object has properties that represent its characteristics. For example, a paragraph has properties that represent its left indent, the space above it, and its default font. A rectangle has properties that represent its width, height, and position on the page.

When FrameMaker creates a MIF file, it writes an ASCII statement for each object in the document or book. The statement includes substatements for the object’s properties.

For example, suppose a document (with no text frame) contains a rectangle that is 2 inches wide and 1 inch high. The rectangle is located 3 inches from the left side of the page and 1.5 inches from the top. MIF represents this rectangle with the following statement:

<Rectangle # Type of graphic object

# Position and size: left offset, top offset,

# width, and height

ADOBE FRAMEMAKER 9

FrameMaker also treats each document as an object and stores document preferences as properties of the document. For example, a document’s page size and page numbering style are document properties.

MIF Reference

FrameMaker documents have default objects

A FrameMaker document always has a certain set of default objects, formats, and preferences, even when you create a new document. When you create a MIF file, you usually provide the objects and properties that your document needs. However, if you don’t provide all the objects and properties required in a FrameMaker document, the MIF interpreter fills in a set of default objects and document formats.

The MIF interpreter normally provides the following default objects:

• Predefined paragraph formats for body text, headers, and table cells

• Predefined character formats

• A right master page for single-sided documents and left and right master pages for double-sided documents

• A reference page

• Predefined table formats

• Predefined cross-reference formats

• Default pen and fill values and dash patterns for graphics

• Default colors

• Default document preferences, such as ruler settings

• Default condition tags

Although you can rely on the MIF interpreter to provide defaults, the exact properties and objects provided may vary depending on your FrameMaker configuration. The MIF interpreter uses default objects and properties that are specified in setup files and in templates. In UNIX® versions, these templates are

plate

. You can modify these default objects and document formats by creating your own version of ASCIITem-

plate

or NewTemplate or by modifying your setup files.

For more information about modifying the default templates and setup files, see the online manual Customizing FrameMaker for UNIX versions of FrameMaker. For the and Windows® version, see the chapter on templates in your user manual.

ASCIITemplate and NewTem-

Current state and inheritance

FrameMaker has a MIF interpreter that reads and parses MIF files. When you open or import a MIF file, the interpreter reads the MIF statements and creates a FrameMaker document that contains the objects described in the MIF file.

When the interpreter reads a MIF file, it keeps track of the current state of certain objects. If the interpreter reads an object with properties that are not fully specified, it applies the current state to that object. When an object acquires the current state, it inherits the properties stored in that state.

For example, if the line width is set to 1 point for a graphic object, the interpreter continues to use a 1-point line width for graphic objects until a new value is specified in the MIF file. Similarly, if the MIF file specifies a format for a paragraph, the interpreter uses the same format until a new format is specified in the file.

The MIF interpreter keeps track of the following document objects and properties:

• Units

• Condition tag properties

• Paragraph format properties

• Character format properties

ADOBE FRAMEMAKER 9

MIF Reference

• Page properties

• Graphic frame properties

• Text frame properties

• Fill pattern

• Pen pattern

• Line width

• Line cap

• Line style (dash or solid)

• Color

• Text line alignment and character format

Because the interpreter also provides default objects for a document, the current state of an object may be determined by a default object. For example, if a document does not provide any paragraph formats, the interpreter applies a set of default paragraph properties to the first paragraph. Subsequent paragraphs use the same properties unless otherwise specified.

How FrameMaker identifies MIF files

A MIF file must be identified by a MIFFile or Book statement at the beginning of the file; otherwise FrameMaker simply reads the file as a text file. All other statements are optional; that is, a valid MIF file can contain only the

MIFFile statement. Other document objects can be added as needed; FrameMaker provides a set of default objects

if a MIF file does not supply them.

MIF statement syntax

The statement descriptions in this manual use the following conventions to describe syntax:

token data

descriptions later in this manual, and Markup statements are always delimited by angle brackets (< > ); macro statements are not. For the syntax of macro statements, see “Macro statements” on page 56.

A token is an indivisible group of characters that identify a reserved word in a MIF statement. Tokens in MIF are case-sensitive. A token cannot contain white space characters, such as spaces, tabs, or newlines. For example, the following MIF statement is invalid because the token contains white space characters:

When the MIF interpreter finds white space characters that aren’t part of the text of the document (as in the example MIF statement, statement, the MIF interpreter ignores the white space characters between the left angle bracket (<) and the first character of the token, the interpreter reads and parses the data portion of the statement. If the token is not valid, the interpreter ignores all text up to the corresponding right angle bracket (>), including any nested substatements. The interpreter then scans the file for the next left angle bracket that marks the beginning of the next MIF statement.

All statements, as well as all data portions of a statement, are optional. If you do not provide a data portion, the MIF interpreter assigns a default value to the statement.

where

token

represents one of the MIF statement names (such as Pgf) listed in the MIF statement

data

represents one or more numbers, a string, a token, or nested statements.

< Units Uin >), it interprets the white space as token delimiters. When parsing the example

Units. After reading the token, the MIF interpreter checks its validity. If the token is valid,

ADOBE FRAMEMAKER 9

MIF Reference

Statement hierarchy

Some MIF statements can contain other statements. The contained statements are called substatements. In this manual, substatements are usually shown indented within the containing statements as follows:

<Document

The indentation is not required in a MIF file, although it may make the file easier for you to read.

A MIF main statement appears at the top level of a file. A main statement cannot be nested within other statements. Some substatements can only appear within certain main statements.

The statement descriptions in this manual indicate the valid locations for a substatement by including it in all of the valid main statements. Main statements are identified in the statement description; for the correct order of main statements, see “MIF file layout” on page 52.

MIF data items

There are several general types of data items in a MIF statement. This manual uses the following terms and symbols to identify data items.

This term or symbol Means

string

tagstring

pathname

boolean

integer

dimension

degrees

percentage

metric

W H

Left quotation mark ( ` ), zero or more standard ASCII characters (in FrameMaker 9, you can also include UTF-8 characters), and a straight quotation mark ( ' ).

Example: `ab cdef ghij'

A string that names a format tag, such as a paragraph format tag. A unique; case is significant. A statement that refers to a

tagstring

acter set.

A string specifying a pathname (see “Device-independent pathnames” on page 7).

A value of either Yes or No. Case is significant.

Integer whose range depends on the associated statement name.

Integer that specifies a unique ID. An ID can be any positive integer between 1 and 65535, inclusive. A statement that refers to an ID must exactly match the ID.

Decimal number signifying a dimension. You can specify the units, such as 1.11", 72 pt, and

8.3 cm. If no units are specified, the default unit is used (see “Units statement” on page 54).

A decimal number signifying an angle value in degrees. You cannot specify units; any number is interpreted as a degree value.

A decimal number signifying a percentage value. You cannot specify units; any number is interpreted as a percentage value.

A dimension specified in units that represent points, where one point is 1/72 inch (see “Math

values” on page 6). Only used in MathFullForm statements.

Pair of dimensions representing width and height. You can specify the units.

value. A

tagstring

value can include any character from the FrameMaker char-

tagstring

must exactly match the

value must be

X Y

L T R B

L T W H

Coordinates of a point. Coordinates originate at the u pp er- le ft c or ner of t he pag e o r gr aph ic fra me. You can specify the units.

Coordinates representing left, top, right, and bottom indents. You can specify the units.

Coordinates representing the left and top indents plus the dimensions representing th e width and height of an object. You can specify the units.

This term or symbol Means

ADOBE FRAMEMAKER 9

MIF Reference

X Y W H

keyword

<token…>

Coordinates of a point on the physical screen represented by X and Y plus dimensions describing the width and height. Used only by the DWindowRect and DViewRect statements within the

Document statement and the BWindowRect statement within the Book statement. The

values are in pixels; you cannot specify the units.

A token value. The allowed token values are listed for each statement; you can provide only one value.

Ellipsis points in a statement indicate required substatements or arguments. The entire expanded statement occurs at this point.

Unit values

You can specify the unit of measurement for most dimension data items. The following table lists the units of measurement that FrameMaker supports and their notation in MIF.

Measurement unit Notation in MIF Relationship to other units

point pt or point 1/72 inch

inch " or in 72 points

millimeter mm or millimeter 1 inch is 25.4 mm

centimeter

pica

didot

cicero

cm or centimeter

pc or pica

dd or didot

cc or cicero

1 inch is 2.54 cm

12 points

0.01483 inches

12 didots

Dimension data types can mix different units of measurement. For example, the statement

> can be written as either of the following:

<CellMargins

L T R

Math values

The MathFullForm statement uses

metric

inch). The

type is a 32-bit fixed-point number. The 16 most significant bits of a

metric

values in formatting codes. A

metric

unit represents one point (1/72

metric

value represent the digits before the decimal; the 16 least significant bits represent the digits after the decimal. Therefore, 1 point is expressed as hexadecimal

0x10000 or decimal 65536. The following table shows how to convert

metric

values into

equivalent measurement units.

To get this unit Divide the metric value by this number

point 65536

inch 4718592

millimeter 185771

centimeter 1857713

pica 786432

didot 6997

cicero 839724

ADOBE FRAMEMAKER 9

MIF Reference

Character set in strings

MIF string data uses the FrameMaker character set (see the Quick Reference for your FrameMaker product). MIF strings must begin with a left quotation mark (ASCII character code (ASCII character code

0x27). Within a string, you can include any character in the FrameMaker character set.

However, because a MIF file can contain only standard ASCII characters and because of MIF parsing requirements, you must represent certain characters with backslash ( \ ) sequences.

Character Representation

Tab \ t

>\>

0x60) and end with a straight quotation mark

`\Q

\\\

nonstandard ASCII \x

Note: The \xnn character is supported only for legacy MIF files.

All FrameMaker characters with values above the standard ASCII range (greater than

string by using

notation, where nn represents the hexadecimal code for the character. The hexadecimal digits

\x7f) are represented in a

must be followed by a space.

When using special characters in a variable definition, you can also use a hexadecimal notation or Unicode notation. In the previous example, the hexadecimal notation for the paragraph symbol (¶) is \xa6. Alternatively, you can use the \u00B6 Unicode notation to represent the same character.

The following example shows a FrameMaker document line and its representation in a MIF string.

In a FrameMaker document In MIF

Some `symbols': > \Ø¿!

You ca n a ls o us e th e

Char statement to include certain predefined special characters in a ParaLine statement (see

`Some \Qsymbols\q: \> \\Ø¿!'

“Char statement” on page 125).

Device-independent pathnames

Several MIF statements require pathnames as values. You should supply a device-independent pathname so that files can easily be transported across different system types. Because of MIF parsing requirements, you must use the following syntax to supply a pathname:

`<code\>name<code\>name<code\>name…'

where

name

is the name of a component in the file’s path and

The following table lists codes and their meanings.

code

identifies the role of the component in the path.

Code Meaning

Root of UNIX file tree (UNIX only)

Volume or drive (Windows)

Host (Apollo only)

Component

Code Meaning

ADOBE FRAMEMAKER 9

MIF Reference

Up one level in the file tree

When you specify a device-independent pathname in a MIF string, you must precede any right angle brackets (>) with backslashes (\), as shown in the syntax above.

Absolute pathnames

An absolute pathname shows the location of a file beginning with the root directory, volume, or drive. The following table specifies device-independent, absolute pathnames for the different versions of FrameMaker.

In this version The pathname appears as this MIF string

UNIX

Windows

`<r\><c\>MyDirectory<c\>MySubdirectory<c\>Filename'

`<v\>c:<c\>mydir<c\>subdir<c\>filename'

Relative pathnames

A relative pathname shows the location of a file relative to the current directory. In all FrameMaker versions, the device-independent, relative pathname for the same file is:

`<c\>Filename '

Chapter 2: Using MIF Statements

MIF statements can completely describe any Adobe® FrameMaker® document, no matter how complex. As a result, you often need many MIF statements to describe a document. To learn how to use MIF statements, it helps to begin with some simple examples.

This chapter introduces you to MIF, beginning with a simple MIF example file with only a few lines of text. Additional examples show how to add common document objects, such as paragraph formats, a table, and a custom page layout, to this simple MIF file.

The examples in this chapter are also provided in online sample files. You can open these examples in FrameMaker and experiment with them by adding additional MIF statements. Look for the sample files in the following location:

In this version Look here

UNIX $FMHOME/fminit/

as usenglish

Windows The MIF directory under the samples directory

language

/Samples/MIF, where

language

is the language in use, such

Working with MIF files

A MIF file is an alternate representation of a FrameMaker document in ASCII format. MIF files are usually generated by FrameMaker or by an application that writes out MIF statements. You can, however, create MIF files by using a text editor or by using FrameMaker as a text editor. This section provides some general information about working with MIF files regardless of the method you use to create them.

Opening and saving MIF files

When you save a FrameMaker document, you usually save it in Normal format, FrameMaker’s binary format for document files. To save a document as a MIF file, choose Save As from the File menu. In the Save Document dialog box, choose Interchange (MIF) from the Format pop-up menu. You should give the saved file the suffix distinguish it from a file saved in binary format.

When you open or import a MIF file, FrameMaker reads the file directly, translating it into a FrameMaker document or book. When you save the document in Normal format, FrameMaker creates a binary document file. To prevent overwriting the original MIF file, remove the suffix).

If you use FrameMaker to edit a MIF file, you must prevent it from interpreting MIF statements when you open the file by holding down a modifier key and clicking Open in the Open dialog box.

In this version Use this modifier key

.mif file suffix and replace it with a different suffix (or no

.mif to

UNIX Shift

Windows Control or Shift

Save the edited MIF file as a text file by using the Save As command and choosing Text Only from the Format popup menu. Give the saved file the suffix to place carriage returns. For a MIF file, choose the Only between Paragraphs option.

.mif. When you save a document as Text Only, FrameMaker asks you where

ADOBE FRAMEMAKER 9

MIF Reference

In UNIX versions, FrameMaker saves a document in text format in the ISO Latin-1 character encoding. You can change the character encoding to ASCII by changing the value of an X resource. See the description of character encoding in the online manual Customizing FrameMaker. In the Windows version, press Esc F t c to toggle between FrameMaker’s character encoding and ANSI for Windows.

Importing MIF files

You can use the File menu’s Import>File command to import MIF files into an existing document, but you must make sure that the imported statements are valid at the location where you are importing them. A MIF file can describe both text and graphics; make sure that you have selected either a place in the text flow (if you are importing text or graphics) or an anchored frame (if you are importing graphics).

For example, to import a MIF file that describes a graphic, first create an anchored frame in a document, select the frame, and then import the MIF file (see “Bar chart example” on page 220).

When you import or include MIF files, make sure that object IDs are unique in the final document and that references to object IDs are correct (see “Generic object statements” on page 105). The object IDs must be unique for all objects (TextRect, TblId, Group, and AFrame use the ID for identification) in the document.

Editing MIF files

You normally use a text editor to edit a MIF file. If you use FrameMaker to enter text into a MIF file, be sure to open the MIF file as a text file and turn off Smart Quotes. If you leave Smart Quotes on, you must use a key sequence to type the quotation marks that enclose a MIF string ( straight quotation mark, type Control-'.

Although MIF statements are usually generated by a program, while you learn MIF or test and debug an application that generates MIF, you may need to manually generate MIF statements. In either case, you can minimize the number of MIF statements that your application needs to generate or that you need to type in.

The following suggestions may be helpful when you are working with MIF statements:

• Edit a MIF file generated by FrameMaker.

• You can edit a MIF file generated by FrameMaker or copy a group of statements from a MIF file into your file

and then edit the statements. An easy way to use FrameMaker to generate a MIF file is to create an empty document by using the New command and then saving it as a MIF file.

• Te st o n e o b j ec t at a ti m e.

• While testing an object in a document or learning about the MIF statements that describe an object, work with

just that object. For example, if you work with a document that contains both tables and anchored frames, start by creating the MIF statements that describe tables. Then add the statements that describe anchored frames.

• Use the default properties provided by FrameMaker.

• If you are not concerned with testing certain document components, let FrameMaker provide a set of default

document objects and formats.

`'). To enter a left quotation mark, type Control-`. To enter a

MIF file layout

FrameMaker writes the objects in a MIF document file in the following order:

This section Contains these objects

File ID MIF file identification line (MIFFile statement)

Units Default units (

Units statement)

This section Contains these objects

Catalogs Color

Condition

Paragraph Format

Element

Font or Character Format

Ruling

Table Format

Views

Formats Variable

Cross-reference

Objects Document

Dictionary

Anchored frames

Tab le s

Pages

Tex t flo ws

ADOBE FRAMEMAKER 9

MIF Reference

FrameMaker provides all of these objects, even if the object is empty. To avoid unpredictable results in a document, you must follow this order when you create a MIF file.

Creating a simple MIF file for FrameMaker

Note: The rest of this chapter explains how to create some simple MIF files for FrameMaker by hand. These instructions do not apply to structured documents, which require that you create elements first.

The most accurate source of information about MIF files is a MIF file generated by FrameMaker. MIF files generated by FrameMaker can be very lengthy because FrameMaker repeats information and provides default objects and formats for all documents. You may find it difficult to determine the minimum number of statements that are necessary to define your document by looking at a FrameMaker-generated MIF file.

To better understand how FrameMaker reads MIF files, study the following example. This MIF file uses only four statements to describe a document that contains one line of text:

<MIFFile 8.00> # The only required statement <Para # Begin a paragraph

<ParaLine # Begin a line within the paragraph

<String `Hello World'># The actual text of this document

> # end of Paraline #End of ParaLine statement

> # end of Para #End of Para statement

The MIFFile statement is required in each MIF file. It identifies the FrameMaker version and must appear on the first line of the file. All other statements are optional; that is, FrameMaker provides a set of default objects if you specify none.

Comments in a MIF file are preceded by a number sign (#). By convention, the substatements in a MIF statement are indented to show their nesting level and to make the file easier to read. The MIF interpreter ignores spaces at the beginning of a line.

ADOBE FRAMEMAKER 9

MIF Reference

This example is in the sample file hello.mif. To see how FrameMaker provides defaults for a document, open this file in FrameMaker. Even though the MIF file does not specify any formatting, FrameMaker provides a default Paragraph Catalog and Character Catalog. In addition, it provides a right master page, as well as many other default properties.

Save this document as a MIF file and open the FrameMaker-generated MIF file in a text editor or in FrameMaker as a text file. (For information on how to save and open MIF files, see “Opening and saving MIF files” on page 9.)

You’ll see that the MIF interpreter has taken the original 6-line file and generated over 1,000 lines of MIF statements that describe all the default objects and their properties. To see the actual text of the document, go to the end of the file.

This example demonstrates an important point about MIF files. Your MIF file can be very sparse; the MIF interpreter supplies missing information. Most documents are not this simple, however, and require some formatting. The following sections describe how to add additional document components, such as paragraph and character formats, a table, and custom page layouts, to this minimal MIF file.

Creating and applying paragraph formats

In a FrameMaker document, paragraphs have formatting properties that specify the appearance of the paragraph’s text. A paragraph format includes the font family and size, indents, tab stops, the space between lines in a paragraph, and the space before and after a paragraph. In a FrameMaker document, the end of a paragraph is denoted by a single carriage return. You control the amount of space above and below the paragraph by modifying the paragraph’s format, not by adding extra carriage returns.

In a FrameMaker document, you store paragraph formats in a Paragraph Catalog and assign a tag (name) to the format. You can then apply the same format to many paragraphs by assigning the format tag to the paragraphs. You can also format a paragraph individually, without storing the format in the Paragraph Catalog. Or, you can assign a format from the Paragraph Catalog and then override some of the properties within a particular paragraph. Formats that are not stored in the Paragraph Catalog are called local formats.

Creating a paragraph

In a MIF file, paragraphs are defined by a Para statement. A Para statement contains one or more ParaLine statements that contain the lines in a paragraph; the actual text of the line is enclosed in one or more

<Para # Begin a paragraph

<ParaLine # Begin a line within the paragraph

<String `Hello World'># The actual text of this document

> # End of ParaLine statement

> # End of Para statement

String statements:

The Para, ParaLine, and String statements are the only required statements to import text. You could use this example to import a simple document into FrameMaker by placing each paragraph in a paragraph text into a series of break up text lines within a

String statements contained in one ParaLine statement. It doesn’t matter how you

Para statement; the MIF interpreter automatically wraps lines when it reads the MIF file.

Para statement. Break the

Some characters must be represented by backslash sequences in a MIF string. For more information, see “Character

set in strings” on page 7.

Creating a paragraph format

Within a FrameMaker document, you define a paragraph format by using the Paragraph Designer to specify the paragraph’s properties. In a MIF file, you define a paragraph format by using the

The

Pgf statement contains a group of substatements that describe all of a paragraph’s properties. It has the

following syntax:

Pgf statement.

<Pgf

property value

...

ADOBE FRAMEMAKER 9

> >

MIF Reference

A Pgf statement is quite long, so learning how to relate its substatements to the paragraph’s properties may take some practice. Usually a MIF statement name is similar to the name of the setting within a dialog box. The following examples show the property dialog boxes from the Paragraph Designer with the related

Pgf substatements.

Suppose you have created a paragraph format for a numbered list item with Basic properties defined as follows in the Paragraph Designer.

Basic properties

The following table shows the corresponding MIF statements:

In MIF file In Paragraph Designer

Paragraph Tag

First Indent

Left Indent

Right Indent

Alignment

Space Above ¶

Space Below ¶

Line Spacing (leading is added to font size)

In MIF file In Paragraph Designer

ADOBE FRAMEMAKER 9

MIF Reference

<TabStop

Line Spacing (fixed)

Number of tab stops

Begin definition of tab

Tab position

Tab type

Tab leader (none)

> # end of TabStop

Turn off Next ¶ Tag feature

Next ¶ Tag name (none)

The Default Font properties are defined as follows in the Paragraph Designer.

Font properties

The following table shows the corresponding MIF statements:

In MIF file In Paragraph Designer

<PgfFont

Family

Size

In MIF file In Paragraph Designer

ADOBE FRAMEMAKER 9

MIF Reference

> # end of PgfFont

Angle

Weig ht

Language

Variation

Color

Spread

Stretch

Underline

Overline

Strikethrough

Change Bar

Superscript/Subscript

Capitalization

Pair Kern

Tsume (Asian systems only)

The Pagination properties are defined as follows in the Paragraph Designer.

ADOBE FRAMEMAKER 9

MIF Reference

Pagination properties

The following table shows the corresponding MIF statements:

In MIF file In Paragraph Designer

Start

Keep With Next Pgf

Keep With Previous Pgf

Widow/Orphan Lines

Format (paragraph placement)

Run-in Head Default Punctuation (a period followed by an em space)

The Numbering properties are defined as follows in the Paragraph Designer.

ADOBE FRAMEMAKER 9

MIF Reference

Numbering properties

The following table shows the corresponding MIF statements:

In MIF file In Paragraph Designer

Turn on Autonumber

Autonumber Format (a number followed by a period and a tab)

Character Format (Default ¶ Format)

Position (Start of Paragraph)

The Advanced properties are defined as follows in the Paragraph Designer.

ADOBE FRAMEMAKER 9

MIF Reference

Advanced properties

The following table shows the corresponding MIF statements:

In MIF file In Paragraph Designer

Automatic Hyphenation (on)

Max. # Adjacent

Shortest Word

Shortest Prefix

Shortest Suffix

Minimum Word Spacing

Optimum Word Spacing

Maximum Word Spacing

Allow Automatic Letter Spacing

Frame Above ¶

Frame Below ¶

The Asian properties are defined as follows in the Paragraph Designer.

ADOBE FRAMEMAKER 9

MIF Reference

Asian properties

The following table shows the corresponding MIF statements:

In MIF file In Paragraph Designer

<PgfMinJRomanLetterSpace

<PgfOptJRomanLetterSpace

<PgfMaxJRomanLetterSpace

<PgfMinJLetterSpace

<PgfOptJLetterSpace

<PgfMaxJLetterSpace

<PgfYakumonoType

percentage

string

percentage

Minimum (Western/Asian Spacing)

Optimum (Western/Asian Spacing)

Maximum (Western/Asian Spacing)

Minimum (Asian Character Spacing)

Optimum (Asian Character Spacing)

Maximum (Asian Character Spacing)

Asian Punctuation

The Table Cell properties are defined as follows in the Paragraph Designer.

ADOBE FRAMEMAKER 9

MIF Reference

Table cell properties

The following table shows the corresponding MIF statements:

In MIF file In Paragraph Designer

Cell Vertical Alignment

Cell Margins

Top

Bottom

Left

Right

Adding a Paragraph Catalog

In a MIF file, you define a Paragraph Catalog by using a PgfCatalog statement. The Paragraph Catalog contains one or more paragraph formats, which are defined by

<PgfCatalog

<Pgf…> # A paragraph format description <Pgf…> # More paragraph formats

> # end of PgfCatalog

The Pgf statement describes a complete paragraph format. For example, the sample file pgfcat.mif stores the paragraph format 1Heading in the Paragraph Catalog:

<MIFFile 8.00> # Hand generated

Pgf statements. A PgfCatalog statement looks like this:

ADOBE FRAMEMAKER 9

<PgfCatalog

<Pgf

<PgfTag `1Heading'> <PgfUseNextTag Yes > <PgfNextTag `Body'> <PgfAlignment Left > <PgfFIndent 0.0"> <PgfLIndent 0.0"> <PgfRIndent 0.0"> ...

> # end of Pgf

> # end of PgfCatalog

MIF Reference

If you open pgfcat.mif in FrameMaker, you’ll see that the Paragraph Catalog contains a single paragraph format called 1Heading. If you supply a Paragraph Catalog, the paragraph formats in your catalog replace those in the default catalog; they do not supplement the default formats.

If you do not supply a Paragraph Catalog in a MIF file, the MIF interpreter provides a default Paragraph Catalog with predefined paragraph formats.

Pgf statement provides only the name of a paragraph format, the MIF interpreter supplies default values for the

If a rest of the paragraph properties when it reads in the MIF file.

Applying a paragraph format

To apply a format from the Paragraph Catalog to a paragraph, use the PgfTag statement to include the format tag name within the the following statements:

<Para

<PgfTag `1Heading'> <ParaLine

> # end of ParaLine

> # end of Para

To apply a format from the Paragraph Catalog and then locally override some properties, use a partial Pgf statement within the alignment:

<Para

<PgfTag `1Heading'> <Pgf

> # end of Pgf <ParaLine

> # end of ParaLine

> # end of Para

To locally define a paragraph format, include a complete Pgf statement within the Para statement:

<Para

<Pgf

> # end of Pgf <ParaLine

Para statement. For example, to apply the previously defined format 1Heading to a paragraph, use

Para statement. The following MIF example applies the paragraph format 1Heading, then changes the

<PgfTag `2Heading'> <PgfUseNextTag Yes > <PgfNextTag `Body'> <PgfAlignment Left > <PgfFIndent 0.0"> <PgfLIndent 0.0"> ...

ADOBE FRAMEMAKER 9

> # end of ParaLine

> # end of Para

MIF Reference

For a complete description of Pgf property statements, see page 61.

How paragraphs inherit properties

Paragraphs can inherit properties from other paragraphs in a MIF file. If a Pgf statement does not provide values for each paragraph property, it acquires any property values explicitly defined in a previous the MIF interpreter sequentially reads MIF files, it uses the most recently defined

Pgf statement that occurs before

the current statement in the file.

For example, the following MIF code applies the default format named Body to the first paragraph in a document and locally overrides the paragraph font:

<Para

<Pgf

<PgfTag `Body'> <PgfFont

> # end of PgfFont > # end of Pgf <ParaLine

<String `First paragraph in document.'> > # end of ParaLine

> # end of Para <Para

<ParaLine

<String `Second paragraph in document.'> > # end of ParaLine

> # end of Para

The previous example is in the sample file pgffmt.mif. If you open this file in FrameMaker, you’ll find that the second paragraph also has the new font property.

A paragraph property remains in effect until the property value is changed by a subsequent MIF statement. To change a paragraph property to another state, supply a

Pgf statement containing the paragraph property statement

set to the new state.

Thus, in the previous example, you could change the font from Bold to Regular in a

Para statement:

<Para

<Pgf

<PgfFont

> # end of PgfFont > # end of Pgf <ParaLine

<String `Second paragraph in document.'> > # end of ParaLine

> # end of Para

To summarize, paragraphs inherit formats as follows:

• Formats in the Paragraph Catalog inherit properties from the formats above them.

• Locally defined paragraph formats inherit properties from previously specified formats.

• Text lines in anchored frames inherit font properties from previously specified formats, including the last

format in the Paragraph Catalog and previous text lines.

Pgf statement. Because

Pgf statement in the second

ADOBE FRAMEMAKER 9

MIF Reference

Tips

The following hints may help you minimize the MIF statements for paragraph formats:

• If possible, use the formats in the default Paragraph Catalog (don’t supply a PgfCatalog statement). If you

know the names of the default paragraph formats, you can tag paragraphs with the

PgfTag statement.

• If you know that a document will use a particular template when it is imported into a FrameMaker document,

you can just tag the paragraphs in the text flow. Don’t create a new Paragraph Catalog in MIF; it’s easier to create catalogs in FrameMaker document templates.

• If you need to provide a full Paragraph Catalog in a MIF file, you can still use FrameMaker to ease the task of

creating a catalog. Create a template in FrameMaker, save the template as a MIF file, and include the Paragraph Catalog in your document. For instructions, see “Including template files” on page 44.

Creating and applying character formats

You can define character formats locally or store them in the Character Catalog and apply the formats to text selections. Creating and applying character formats is very similar to creating and applying paragraph formats as described in the previous section. Because the two methods are similar, this section just summarizes how to create and apply character formats.

In a MIF file, the Character Catalog is contained in a named character formats in a list of

<FontCatalog

<Font...> # Describes a character format <Font...> # Describes a character format

> # end of FontCatalog

Font statements. A FontCatalog statement looks like this:

A Font statement specifies the properties of a character format; these are the same properties specified in the Character Designer. The

Font statement is just like the PgfFont statement that you use to define the default font in

a paragraph format. See “PgfFont and Font statements” on page 66 for a complete description of a

To apply a predefined character format to text, use the

<MIFFile 8.00> # Hand generated <FontCatalog

<Font

<FAngle `Italic'> > # end of Font

> # end of FontCatalog <Para

<PgfTag `Body'> <ParaLine

<Font

<FTag `Emphasis'> > # end of Font <String `applying'> <Font

> # end of ParaLine

> # end of Para

Remember to include a second Font statement to end the scope of the applied character format.

FontCatalog statement. The FontCatalog statement contains

Font statement.

FTag statement:

ADOBE FRAMEMAKER 9

Body rows

Footing row

Table 1: Coffee Inventory

Coffee Bags Status Price per bag

Brazil Santos 50 Prompt $455.00

Celebes Kalossi 29 In Stock $924.00

Colombian 25 In Stock $474.35

$1,853.35

Heading row

Title

MIF Reference

To locally define a character format, use a complete Font statement:

<Para

<PgfTag `Body'> <ParaLine

<String `You can also format characters by '> <Font

…character property statements

> # end of Font <String `applying'> <Font

> # end of ParaLine

> # end of Para

…

Like paragraph formats, character formats inherit properties from previously defined character formats. Unlike paragraph formats, however, a character format ends at the close of a

See the sample file

charfmt.mif for examples of using character formats.

Para statement.

Creating and formatting tables

You can create tables in FrameMaker documents, edit them, and apply table formats to them. Tables can have heading rows, body rows, and footing rows. Each row consists of table cells that contain the actual contents of the table.

Tables are like paragraphs in that they have a format. A table format controls the appearance of a table, including the number and width of columns, the types of ruling or shading in rows and columns, and the table’s position in a text column. Table formats can be named, stored in a Table Catalog, and applied to many tables. A table format can also be defined locally.

In a FrameMaker document, tables appear where they have been placed in the text flow. A table behaves like an anchored frame, so a table flows with the surrounding text unless you give it a specific location. In a MIF file, the document’s tables are collected in one place and a placeholder for each table indicates the table’s position in the text flow.

You create a table in a MIF file as follows:

• Specify the contents of the table by using a Tbl statement. An individual table is called a table instance. All table

instances are stored in one

Tbls statement. Assign each table instance a unique ID number.

ADOBE FRAMEMAKER 9

MIF Reference

• Indicate the position of the table in the text flow by using an ATbl statement. The ATbl statement is the place-

holder, or anchor, for the table instance. It refers to the table instance’s unique ID.

• Specify the table format by using a TblFormat statement. Formats can be named and stored in the Table

Catalog, which is defined by a

TblCatalog statement, or locally defined within a table.

Creating a table instance

All table instances in a document are contained in a Tbls statement. The Tbls statement contains a list of Tbl statements, one for each table instance. A document can have only one the table anchors in the text flow.

Tbl statement contains the actual contents of the table cells in a list of MIF substatements. Like other MIF state-

The ments, this list can be quite long. The following is a template for a

<Tbl

<TblID…> # A unique ID for the table <TblFormat…> # The table format <TblNumColumns…> # Number of columns in this table--required <TblColumnWidth…> # Column width, one for each column <TblH # The heading; omit if no heading

<Row # One Row statement for each row

<Cell…> # One statement for each cell in the row > # end of Row

<TblBody # The body of the table

<Row…> # One for each row in body

> # end of TblBody <TblF # The footer; omit if no footer

<Row…> # One for each row in footer

> # end of TblF

> # end of Tbl

The TblID statement assigns a unique ID to the table instance. The TblFormat statement provides the table format. You ca n u se t he

TblFormat statement to apply a table format from the Table Catalog, apply a format from the

catalog and override some of its properties, or completely specify the table format locally. Because the tables in a document often share similar characteristics, you usually store table formats in the Table Catalog. Table instances can always override the applied format.

TblNumColumns statement specifies the number of columns in the table instance. It is required in every table.

The

The TblH, TblBody, and TblF statements contain the table heading, body, and footer rows. If a table does not have a heading or footing, omit the statements.

Here’s an example of a simple table that uses a default format from the Table Catalog. The table has one heading row, one body row, and no footing rows:

Tbls statement, which must occur before any of

Tbl statement:

Coffee Price per Bag

Brazil Santos $455.00

You can use the following MIF statements to create this simple table:

<MIFFile 8.00> <Tbls

<Tbl

<TblID 1> # ID for this table <TblTag `Format A'> # Applies format from Table Catalog <TblNumColumns 2> # Number of columns in this table <TblColumnWidth 2.0"> # Width of first column <TblColumnWidth 1.5"> # Width of second column

ADOBE FRAMEMAKER 9

MIF Reference

<TblH # Begin table heading

<Row # Begin row

<Cell # First cell in row

<CellContent

<Para # Cells can contain paragraphs

<PgfTag `CellHeading'># Applies format from Paragraph Catalog <ParaLine

<String `Coffee'># Text in this cell

> # end of Para

> # end of CellContent > # end of Cell <Cell # Second cell in row

<CellContent

<Para

> # end of Para

> # end of CellContent > # end of Cell

> # end of Row

> # end of TblH

<TblBody # Table body

<Row # Begin row

<Cell # First cell in row

<CellContent

<Para

<PgfTag `CellBody'> <ParaLine

> # end of Para > # end of CellContent

> # end of Cell <Cell # Second cell in row

<CellContent

<Para

<PgfTag `CellBody'> <ParaLine

> # end of Para > # end of CellContent

> # end of Cell

> # end of Row

> # end of TblBody > # end of Tbl > # end of Tbls

A table cell is a text column that contains an untagged text flow not connected to any other flows. You can put any kind of text or graphics in a table cell. The cell automatically grows vertically to accommodate the inserted text or graphic; however, the width of the column remains fixed.

Adding a table anchor

To indicate the position of a table in the text flow, you must add an ATbl statement. The ATbl statement refers to the unique ID specified by the previous example, you would add the following statements to the minimal MIF file:

TblID statement in the table instance. For example, to insert the table defined in the

ADOBE FRAMEMAKER 9

<Para

<ParaLine

<String `Coffee prices for January'> <ATbl 1> # Matches table ID in Tbl statement

> # end of ParaLine > # end of Para

MIF Reference

This example is in the sample file table.mif. If you open this file in FrameMaker, you’ll see that the anchor symbol for the table appears at the end of the sentence. To place the table anchor between two words in the sentence, use the following statements:

<Para

<ParaLine

> # end of ParaLine > # end of Para

Note that the ATbl statement appears outside the String statement. A ParaLine statement usually consists of

String statements that contain text interspersed with statements for table anchors, frame anchors, markers, and

cross-references.

About ID numbers

The table ID used by the ATbl statement must exactly match the ID given by the TblID statement. If it does not, the MIF interpreter ignores the multiple

ATbl statements that refer to the same table ID.

ATbl statement and the table instance does not appear in the document. You cannot use

An ID can be any positive integer from 1 to 65535, inclusive. The only other statements that require an ID are

AFrame statements, linked TextRect statements, and Group statements. For more information about these state-

ments, see “Graphic objects and graphic frames” on page 104.

Rotated cells

A table can have rotated cells and straddle cells. The following table includes rotated cells in the heading row:

Coffee

Price

Brazil Santos $455.00

In a MIF file, a cell that is rotated simply includes a

<Cell

<CellContent…> > # end of Cell

CellAngle statement that specifies the angle of rotation:

Cells can only be rotated by 90, 180, or 270 degrees. Cells are rotated clockwise.

ADOBE FRAMEMAKER 9

MIF Reference

Straddle cells

The contents of a straddle cell cross cell borders as if there were a single cell. You can straddle cells horizontally or vertically. The following table includes a heading row that straddles two columns:

Brazilian Coffee

Coffee Price per Bag

Brazil Santos $455.00

The MIF code for the straddle cell includes a cell crosses. The contents of the straddle cell appear in the first of the straddle columns; the subsequent

CellColumns statement that specifies the number of columns that the

Cell state-

ments for the row must appear even if they are empty.

<Row

<Cell

<CellColumns 2> # Number of straddle columns. <CellContent # Content is in the first cell.

<Para

<PgfTag `CellHeading'> <ParaLine

> # end of Para

> # end of CellContent > # end of Cell <Cell # Second cell appears, even though

<CellContent # it is empty.

<Para

> # end of Para

> # end of CellContent > # end of Cell

> # end of Row

If the cell straddles rows, the substatement is CellRows.

Creating a table format

A table format includes the following properties:

• The properties specified by the Table Designer

• These include the row and column ruling and shading styles, the position of text within cell margins, the table’s

placement within the text column, and the table title position.

• The number and widths of columns

• The paragraph format of the first paragraph in the title (if there is one)

• The paragraph format of the topmost paragraph in the heading, body, and footing cell of each column

For example, you could change the format of the previous table to include shaded rows and a different ruling style:

Coffee Price per Bag

Brazil Santos $455.00

Celebes Kalossi $924.00

Coffee Price per Bag

Colombian $474.35

The following MIF statements define this table format:

<TblFormat

# Every table must have at least one TblColumn

# statement.

<TblColumn

<TblColumnNum 0> # Columns are numbered from 0.

<TblColumnWidth 2.0"> # Width of first column.

> # end of TblColumn <TblColumn

<TblColumnNum 1> # Second column.

<TblColumnWidth 1.5"> # Width of second column. > # end of TblColumn <TblCellMargins 6.0 pt 6.0 pt 6.0 pt 4.0 pt> <TblLIndent 0.0"> # These are exactly like paragraph <TblRIndent 0.0"> # format properties. <TblAlignment Center > <TblPlacement Anywhere > <TblSpBefore 12.0 pt> <TblSpAfter 12.0 pt> <TblBlockSize 1> <TblHFFill 15> # No fill for heading row. <TblHFColor `Black'> <TblBodyFill 5> # Use 10% gray fill for main body rows. <TblBodyColor `Black'> <TblShadeByColumn No > # Shade by row, not by column. <TblShadePeriod 1> # Shade every other row. <TblXFill 15> # No fill for alternate rows. <TblXColor `Black'> # Color for alternate rows. <TblAltShadePeriod 1> <TblLRuling `Thin'> # Use thin left outside rule. <TblBRuling `Thin'> # Use thin bottom outside rule. <TblRRuling `Thin'> # Use thin right outside rule. <TblTRuling `Medium'> # Use medium top outside rule. <TblColumnRuling `Thin'> # Use thin rules between columns. <TblXColumnRuling `Thin'> <TblBodyRowRuling `Thin'> # Use thin rules between rows. <TblXRowRuling `Thin'> <TblHFRowRuling `'> # No rules between heading rows. <TblSeparatorRuling `Medium'> # Use medium rule after heading row. <TblXColumnNum 1> <TblRulingPeriod 4> <TblLastBRuling No > <TblTitlePlacement InHeader> # Place title above table. <TblTitlePgf1 # Paragraph format for first

<PgfTag `TableTitle'> # paragraph in title. > # end of TblTitlePgf1 <TblTitleGap 6.0 pt> # Gap between title and table. <TblInitNumColumns 2> # Initial number of rows and <TblInitNumHRows 1> # columns for new tables with <TblInitNumBodyRows 4> # this format. <TblInitNumFRows 0> <TblNumByColumn No >

> # end of TblFormat

ADOBE FRAMEMAKER 9

MIF Reference

ADOBE FRAMEMAKER 9

MIF Reference

The TblColumn statement numbers each column and sets its width. A table can have more columns than

TblColumn statements; if a column does not have a specified format, the MIF interpreter uses the format of the most

recently defined column.

Note: A table instance must have at least one that includes a

TblColumn statement or it can include a local TblFormat statement that supplies the TblColumn

TblColumn statement. A table can use a format from the Table Catalog

statement.

Adding a Table Catalog

You can store table formats in a Table Catalog by using a TblCatalog statement. A document can have only one

TblCatalog statement, which must occur before the Tbls statement.

The

TblCatalog statement contains one TblFormat statement for each format, as shown in the following template:

<TblCatalog

<TblFormat…>

<TblFormat…> > # end of TblCatalog

As with the Paragraph Catalog, if your MIF file does not provide a Table Catalog, the MIF interpreter supplies a default catalog and formats. If you do provide a Table Catalog, your defined table formats supersede those in the default Table Catalog.

You can add a minimal table format to the catalog by simply supplying a table format tag name. The MIF interpreter supplies a set of default values to the table’s properties when it reads in the MIF file.

The ruling styles in a table format are defined in a separate catalog called the Ruling Catalog. You can define your own Ruling Catalog with the own, substatements that refer to ruling styles, such as the style from the Ruling Catalog. See “RulingCatalog statement” on page 79.

RulingCatalog statement. Whether you use the default ruling styles or create your

TblLRuling statement, must use the name of a ruling

Applying a table format

You can apply a table format from the Table Catalog or you can define a table format locally.

To apply a table format from the Table Catalog, use the

<Tbls

<Tbl

<TblTag `Format A'> # Tag of format in Table Catalog

<TblBody

...

> # end of TblBody > # end of Tbl

> # end of Tbls

To locally define a table format, use a complete TblFormat statement:

<TblColumn <TblColumnNum 0> <TblColumnWidth 1.0"> > # end of TblColumn

…table property statements

…

TblTag statement within the Tbl statement:

# Every table must have one TblColumn statement.

ADOBE FRAMEMAKER 9

MIF Reference

> # end of TblFormat > # end of Tbl > # end of Tbls

Creating default paragraph formats for new tables

You can use the TblFormat and TblColumn statements to define default paragraph formats for the columns in new tables. These default formats do not affect tables that are defined within the MIF file; they only affect tables that the user inserts after the MIF file has been opened in FrameMaker. Your filter or application should provide these defaults only for documents that might be edited later.

For example, the following MIF code assigns a paragraph format named Description to body cells in new tables that are given the format called Coffee Table:

<TblFormat

<TblTag `Coffee Table'> <TblColumn

<TblColumnBody

> # end of TblColumnBody > # end of TblColumn

> # end of TblFormat

Tables inherit properties differently

Tables inherit formatting properties somewhat differently than other document components. A table without an applied table format does not inherit one from a previously defined table. Instead, it gets a set of default properties from the MIF interpreter. Thus, if you apply a named format to a table, a following table will not inherit that format.

Paragraphs in table cells still inherit properties from previously defined paragraph formats. If you give a table cell a certain paragraph style, all subsequent cells inherit the same property unless it is explicitly reset. Table cells can inherit paragraph properties from any previously specified paragraph format, including other tables, paragraphs, or even the Paragraph Format catalog.

Tips

To avoid problems when creating tables:

• Give each table a unique ID number.

• Make sure that each Tbl statement has only one corresponding ATbl statement, and that each ATbl statement

has a corresponding

Tbl statement.

• Make sure that each ATbl statement matches the ID of its corresponding table instance.

Specifying page layout

FrameMaker documents have two kinds of pages that determine the position and appearance of text in the document: body pages and master pages.

ADOBE FRAMEMAKER 9

Untagged background text frame

Tagged template text frame

On body pages, you type in a column of a tagged text frame.

Untagged background text frame

Master page Body page

MIF Reference

Body pages contain the text and graphics that form the content of the document. Master pages control the layout of body pages. Each body page is associated with one master page, which specifies the number, size, and placement of the page’s text frames and the page background, such as headers, footers, and graphics.

Text frames define the layout of the document’s text on a page. A text frame can arrange text in one or more columns. In MIF, a text frame is represented by a number of columns in the text frame are specified by substatements under the

A text flow describes the text contained in one or more text frames. In MIF, a text flow is represented by a statement. The actual text of the document is specified by substatements under the

If the text flow has the autoconnect property (if the text flow uses the MIF statement

TextRect statement. The dimensions of the text frame and the

TextRect statement.

TextFlow

TextFlow statement.

<TFAutoConnect Yes>), the

text flow ru ns throu gh a ser ies of text fr ames; whe n you fil l up one text frame, text continue s int o the n ext te xt fra me. Most documents have only one text flow, although you can create many separate flows.

FrameMaker provides a default right master page for single-sided documents and default right and left master pages for double-sided documents. A MIF file can either use the default page layout or provide a custom layout.

Using the default layout

If you don’t need to control the page layout of a document, you can use the default page layout by putting all of the document’s text into a and body pages. The MIF file creates a single-column text frame for the body pages to contain the document’s text. The MIF interpreter associates the text flow with this text frame.

The following example is in the sample file

<MIFFile 8.00> # Hand generated <TextFlow # All document text is in this text flow.

<TFTag `A'> # Make this a tagged text flow. <TFAutoConnect Yes> # Automatically connect text frames. <Para

<ParaLine

> # end of ParaLine > # end of Para

> # end of TextFlow

A text flow must be tagged, and it must include <TFAutoConnect Yes>; otherwise, when the user adds text to the document, FrameMaker won’t create additional pages and text frames to hold the added text.

TextFlow statement. When reading the file, the MIF interpreter creates default master pages

defpage.mif:

# End of MIFFile

ADOBE FRAMEMAKER 9

MIF Reference

Creating a simple page layout

If you want some control of the page layout but do not want to create master pages, you can use the Document substatements the text frame in the document. The MIF interpreter uses this information to create master pages and body pages. These statements correspond to the Normal Page Layout options.

The following example is in the sample file

<MIFFile 8.00> # Hand generated <Document

<DPageSize 7.5" 9.0"> # Set the page size. <DMargins 2" 1" .5" .5"> # Set the margins. <DColumns 1> # Set the number of columns in the default

<DTwoSides No> # Set document to single-sided.

> # end of Document <TextFlow # Document text is in this text flow.

<TFTag `A'> # Make this a tagged text flow. <TFAutoConnect Yes> # Automatically connect text frames. <Para

> # end of Para

> # end of TextFlow

DPageSize, DMargins, and DColumns to specify the page size, margins, and number of columns in

columlay.mif:

# text frame.

<ParaLine

> # end of ParaLine

# End of MIFFile

Creating a single-sided custom layout

If the document that you’re importing needs a custom master page, you must specify a custom page layout. For example, a document might need a master page for background graphics.

To create a custom layout for a single-sided document, you do the following:

• Create a right master page.

• Create a single, empty body page.

• Create an empty, tagged text flow that is linked to the master page.

• Create a tagged text flow that is linked to the body page and contains all the document’s text.

The MIF code shown in this section is also in the sample file snglpage.mif.

To create the master page

To create a master page layout, use the Page statement to create the page and use the TextRect statement to create the text frame.

To specify the number of text columns in the text frame, use the frame’s specification does not include this statement, the text frame has only one column.

This example sets up a right master page with a text frame containing one text column:

<MIFFile 8.00> # Hand generated <Document <DPageSize 7.5" 9.0"> # Set the document page size. <DTwoSides No> # Make this a single-sided document. > # end of Document <Page # Create a right master page. <PageType RightMasterPage> <PageTag `Right'>

TRNumColumns statement. By default, if the text

ADOBE FRAMEMAKER 9

MIF Reference

<TextRect # Set up a text frame. <ID 1> # Give the text frame a unique ID. <Pen 15> # Set the pen style. <Fill 15> # Set the fill pattern (none). <ShapeRect 2" 1" 5" 7.5"> # Specify the text frame size. <TRNumColumns 1> # Specify number of text columns. <TRColumnGap 0.0"> # Specify gap between text columns. > # end of TextRect > # end of Page

The ID statement assigns a unique ID number to this text frame. You must give text frames a unique ID in a MIF file; other objects that require unique IDs are anchored graphic frames and table instances.

To create an empty body page

To create the body page, use the Page statement. Then use the TextRect statement to create a text frame with dimensions that are exactly the same as the text frame on the master page. Give the text frame a unique ID:

<Page <PageType BodyPage> <PageBackground `Default'> <TextRect <ID 2> # This text frame has a unique ID.

# The body page dimensions match those of the

# master page. <ShapeRect 2" 1" 5" 7.5"> <TRNumColumns 1> # The column layout must also match. <TRColumnGap 0.0"> > # end TextRect > # end Page

If the dimensions (specified by the ShapeRect statement) and column layout (specified by the TRNumColumns and

TRColumnGap st ateme nts ) of the mas ter page an d bo dy p age do n ot m atch, the body pag e wi ll n ot u se t he p age layou t

from the master page. Instead, the body page will use the page layout defined for the body page.

To create the text flow for the master page

The text flow for the master page is not contained in the Page statement; instead, it is contained in a TextFlow statement that is linked to the text frame on the master page. The

Page statements must come before any TextFlow

statements.

Link the text flow to the master page’s text frame by using the

TextRectID statement to refer to the text frame’s

unique ID:

<TextFlow

<TFTag `A'> # The text flow must be tagged. <TFAutoConnect Yes> # Autoconnect must be turned on. <Para

<ParaLine

<TextRectID 1> # Refers to text frame ID on master page.

> # end of ParaLine

> # end of Para

> # end of TextFlow

The text flow for the master page must be empty. Be sure to give the text flow the same flow tag that you give the text flow for the body page and to turn on the autoconnect feature.

ADOBE FRAMEMAKER 9

MIF Reference

To create the text flow for the body page

The text flow for the body page is contained in a separate TextFlow statement that is linked to the body page’s text frame. The text flow contains the actual text of the document in one or more

Para statements. If text overflows the

first text frame, the MIF interpreter creates another body page with a layout that matches the right master page and pours text into the body page’s text frame.

<TextFlow <TFTag `A'> <TFAutoConnect Yes> <Para <TextRectID 2> <PgfTag `Body'> <ParaLine <String `This appears on a body page within a text flow'> <String ` tagged A.'> > # end of ParaLine > # end of Para > # end of TextFlow

Why one body page?

The method you use to create body pages is different from the method that FrameMaker uses when it writes a MIF file. When FrameMaker writes a file, it knows where each page break occurs in the file, so it creates a series of

Page

statements that each contain the text and graphics located on that page. When you are importing a document, you do not know where page breaks will fall, so you cannot break the document into a series of

Page statements. Instead,

you simply create one text flow for the entire document and link it to a single, empty body page. When the MIF interpreter reads the file, it creates as many pages as the document requires and gives each page the background specified by the master page.

Creating a double-sided custom layout

If you import a two-sided document, you might need to specify different page layouts for right and left pages. For example, a document might have a wider inside margin to allow extra room for binding. You can do this in a MIF file by creating and linking a second master page and a second body page. As with a single-sided layout, all the document’s text is in one text flow. When the MIF interpreter reads the file, it adds alternate left and right body pages to the document. You can control whether the document starts with a right page or a left page by using the

DParity statement.

For an example of a document with left and right master pages, see the sample file dblpage.mif.

Creating a first master page

In addition to left and right master pages, you can create custom master page layouts that you can apply to body pages. For example, some books have a special layout for the first page in a chapter.

In a MIF file, you can create as many master pages as you need, but you cannot apply all of them to the appropriate body pages. You can only apply a left page, a right page, and one additional custom master page to the body pages. Furthermore, you can only link the custom master page to the first page in a document.

When you are importing a document into FrameMaker, you do not know how much text the MIF interpreter will put on a page; you can only determine where the first page begins. When the interpreter reads the MIF file, it applies the custom master page layout to the first page in the document. For each subsequent page, it uses the

DTwoSides statements to determine when to add a left page and when to add a

right page.

DParity and

ADOBE FRAMEMAKER 9

MIF Reference

Other master page layouts that you’ve defined are not lost when the interpreter reads a MIF file. The user can still apply these page layouts to individual body pages.

For an example of a MIF file with a first page layout, see the sample file

frstpage.mif.

Adding headers and footers

Headers and footers are defined in untagged text flows on the master pages of a document. When FrameMaker creates default master pages, it automatically provides untagged text flows for headers and footers.

If you are importing a document that has headers and footers, you define additional text frames on the master pages. Link an untagged text flow to each additional text frame on the master page. The untagged text flow contains the text of the header or footer.

For an example of a MIF file with a footer, see the sample file

footers.mif. Note that the footer text flow contains

a variable; you can place variables only in untagged text flows on a master page, not in tagged flows.

Creating markers

A FrameMaker document can contain markers that hold hidden text and mark locations. For example, you use markers to add index entries, cross-references, and hypertext commands to a document. FrameMaker provides both predefined marker types and markers that you can define as needed. (For more information about markers and marker types, see page 127.)

Within a FrameMaker document, you insert a marker by choosing the Marker command from the Special menu. In a MIF file you insert a marker by using a the marker text.

The following example inserts an index marker:

<Para

<ParaLine

<Marker

<MType 2> # Index marker

<MText `Hello world'># Index entry > # end of Marker <String `Hello world'>

> # end of ParaLine

> # end of Para

The MText statement contains the complete index entry.

When FrameMaker writes a Marker statement, the statement includes an MCurrPage substatement with the page number on which the marker appears. You do not need to provide an MIF file; this statement is ignored when the MIF interpreter reads a MIF file.

Marker statement. The Marker statement specifies the marker type and

MCurrPage statement when you generate a

Creating cross-references

In a FrameMaker document, you can create cross-references that are automatically updated. A cross-reference can refer to an entire paragraph or to a particular word or phrase in a paragraph. The text to which a cross-reference points is called the reference source; the actual location of the cross-reference is the reference point.

ADOBE FRAMEMAKER 9

MIF Reference

The format of a cross-reference determines its appearance and the wording. Cross-reference formats include building blocks, instructions to FrameMaker about what information to extract from the reference source. A common building block is

<$pagenum>, which FrameMaker replaces with the page number of the reference source.

Another common building block is <$paratext>, which FrameMaker replaces with the text content of the paragraph, excluding autonumbering and special characters such as tabs and forced line breaks.

Within a FrameMaker document, you insert and format cross-references by choosing Cross-Reference from the Special menu. In a MIF file, you create a cross-reference as follows:

• Create the format of cross-references by using XRefFormats and XRefFormat statements.

• Insert a marker at the reference source by using a Marker statement.

• Insert the reference point by using an XRef statement.

Creating cross-reference formats

The cross-reference formats for a document are defined in one XRefFormats statement. A document can have only

XRefFormats statement.

one

The

XRefFormats statement contains one or more XRefFormat statements that define the cross-reference formats.

A cross-reference format consists of a name and a definition.

<XRefFormats

<XRefFormat

> # end of XRefFormat

> # end of XRefFormats

The name can be any string allowed in a MIF file (see “Character set in strings” on page 7). In this example, a nonbreaking space ( must have a unique name; names are case-sensitive. The cross-reference definition contains text and cross-reference building blocks. See your user’s manual or the online Help system for a list of building blocks.

\x11) appears between the word “page” and the page number. Each cross-reference format

Inserting the reference source marker

To mark the location of the reference source, insert a Marker statement at the beginning of the reference source. The following example creates a cross-reference to a heading:

<Para

<PgfTag `Heading'> <ParaLine

<Marker

<MType 9> # Identifies this as a cross-reference

> # end of Marker <String `My Heading'>

> # end of ParaLine

> # end of Para

The <MType 9> statement identifies this as a cross-reference marker; it is required. The MText statement contains the cross-reference source text, which must be unique. When FrameMaker writes a cross-reference, it adds a unique number and the paragraph tag to the

MText statement, as shown in the previous example. While the number is not

required, it guarantees that the cross-reference points to a unique source when the number is present. In the previous example, the number in new cross-reference points to the

<MText> is not mandatory. However, the number in the example ensures that the

‘My heading’ heading.

# Cross-reference source

ADOBE FRAMEMAKER 9

MIF Reference

Inserting the reference point

The final step in creating a cross-reference is to insert an XRef statement at the position in text where the crossreference should appear. The

XRefFormat), the source text, and the pathname of the file containing the source:

<Para

<PgfTag `Body'> <ParaLine

<String `This is a cross-reference to '> <XRef

<XRefName `Page'> # Cross-reference format

<XRefSrcFile `'> # File containing source > # end of XRef <XRefEnd> <String `.'>

> # end of ParaLine

> # end of Para

The format name must exactly match the name of a format defined in XRefFormats. The source text must be unique and must match the string in the statement is only required if the reference source is in a different file from the reference point. It must be a valid MIF filename (see “Device-independent pathnames” on page 7).

You must also supply an

XRef statement provides the name of the cross-reference format (defined in

# Source text

MText statement in the corresponding reference point marker. The XRefSrcFile

XRefEnd statement after the XRef statement.

How FrameMaker writes cross-references

When FrameMaker writes a cross-reference, it provides the actual text that will appear at the reference point. This information is not required in a MIF input file. The previous example would be written as follows:

<XRef

> # end of XRef <String `page'> # The text that appears in the document; <Char HardSpace > # in this case, a page number followed a <String `1'> # hard space and the number 1 <XRefEnd> # End of cross-reference text

If you do include the text of the cross-reference, make sure that the XRefEnd statement follows the text. FrameMaker considers everything between the

XRef statement and the XRefEnd statement to be part of the cross-reference.

Creating variables

In a FrameMaker document, variables act as placeholders for text that might change. For example, many documents use a variable for the current date. A variable consists of a name, which is how you choose a variable, and a definition, which contains the text and formatting that appear where a variable is inserted.

FrameMaker provides two kinds of variables: system variables that are predefined by FrameMaker, and user variables that are defined by the user. System variables contain building blocks that allow FrameMaker to extract certain information from the document or the system, such as the current date or the current page number, and place it in text. Headers and footers frequently use system variables. You can modify a system variable’s definition but you cannot create new system variables. User variables contain only text and formatting information.

ADOBE FRAMEMAKER 9

MIF Reference

Within a FrameMaker document, you insert and define variables by choosing Variable from the Special menu. The variable appears in the document text where it is inserted.

In a MIF file, you define and insert variables as follows:

• Define and name the document variables by using VariableFormats and VariableFormat statements.

• Insert the variable in text by using the Variable statement.

Defining user variables

All variable definitions for a document are contained in a single VariableFormats statement. The Variable-

Formats

statement provides the variable name and definition.

<VariableFormats

> # end of VariableFormats

The variable name must be unique; case and spaces are significant. For a user variable, the variable definition can contain only text and character formats; you can provide any character format defined in the Character Catalog. The following example applies the default character format Emphasis to a variable:

<VariableFormat

> # end of VariableFormat

You can specify character formats as building blocks; that is, the character format name must be enclosed in angle brackets. Because of MIF parsing requirements, you must use a backslash sequence for the closing angle bracket.

statement contains a VariableFormat statement for each document variable. The VariableFormat

<VariableFormat

> # end of VariableFormat

Using system variables

Whenever you open or import a MIF file, the MIF interpreter provides the default system variables. You can redefine a system variable but you cannot provide new system variables.

System variables are defined by a

VariableFormat statement. For example, the following statement shows the

default definition for the system variable Page Count:

<VariableFormat

<VariableDef `<$lastpagenum\>'> > # end of VariableFormat

System variables contain building blocks that provide certain information to FrameMaker. These building blocks are preceded by a dollar sign (

$) and can only appear in system variables. Some system variables have restrictions

on which building blocks they can contain. These restrictions are discussed in your user’s manual and in the online Help system. You can add any text and character formatting to any system variable.

Inserting variables

To insert a user variable or a system variable in text, use the Variable statement. The following example inserts the system variable Page Count into a paragraph:

<Para

<ParaLine

<String `This document has '> <Variable

ADOBE FRAMEMAKER 9

> # end of Variable <String `pages.'>

> # end of ParaLine > # end of Para

MIF Reference

The VariableName string must match the name of a variable format defined in the VariableFormats statement.

Variables are subject to the following restrictions:

• You cannot place any variable in a tagged text flow on a master page.

• The system variable Current Page # and the system variables for running headers and footers can only appear

in untagged text flows on a master page.

• The system variables Table Continuation and Table Sheet can only appear in tables.

Creating conditional text

You can produce several slightly different versions of a document from a single conditional document. In a conditional document, you use condition tags to differentiate conditional text (text that is specific to one version of the document) from unconditional text (text that is common to all versions of the document).

In a MIF file, you create a conditional document as follows:

• Create the condition tags to be used in the document and specify their format via ConditionCatalog and

Condition statements.

• Apply one or more condition tags to the appropriate sections of the document via Conditional and Uncondi-

tional

statements.

• Show or hide conditional text by using the CState statement.

Creating and applying condition tags

In MIF, all condition tags are defined in a ConditionCatalog statement, which contains one or more Condition statements. A appears in the document window), a color, and a state (either hidden or shown).

For example, the following statements create a Condition Catalog with two conditional tags named Summer and Winter:

<ConditionCatalog

<Condition

> # end of Condition

<Condition

> # end of Condition > # end of ConditionCatalog

To mark conditional and unconditional passages within document text, use Conditional and UnConditional statements as shown in the following example:

<Para

<ParaLine

Condition statement specifies the condition tag name, the condition indicators (how conditional text

<CTag `Summer'> # Condition tag name <CState CHidden > # Condition state (now hidden) <CStyle COverline > # Condition indicator <CColor `Blue'> # Condition indicator

<CTag `Winter'> <CState CShown > # This condition is shown <CStyle CUnderline > <CColor `Red'>

# Unconditional text

<Conditional # Begin conditional text

<InCondition `Winter'> # Specifies condition tag > # end of Conditional <String `warm and soft sweaters'>

# Conditional text

<Conditional # Begin conditional text

<InCondition `Summer'> # Specifies condition tag > # end of Conditional <String `cool and comfortable tank tops'> <Unconditional > <String ` for those '> # Unconditional text

> # end of ParaLine <ParaLine

<Conditional

<InCondition `Winter'> > # end of Conditional <String `chilly winter'> <Conditional

<InCondition `Summer'> > # end of Conditional <String `hot summer'> <Unconditional > <String ` days.'>

> # end of ParaLine

> # end of Para

You can apply multiple condition tags to text by using multiple InCondition statements:

<Conditional

> # end of Conditional

ADOBE FRAMEMAKER 9

MIF Reference

Showing and hiding conditional text using Boolean expressions

You can also use Boolean expressions to show or hide conditional text. Boolean condition expressions are identified using the describe them in the set to ‘Active’ the show/hide state of the text in that document is governed by that Boolean condition expression. All text for which the expression evaluates to ‘True’ is shown, while the rest are hidden.

Consider a scenario where you have created Conditions summary, detail, comment, and a boolean expression "comment"OR"summary"OR"detail”. If the value of to determine the Show/Hide state of conditional text.

The

> # end of BoolCond

When you save a FrameMaker 8 document as MIF, the following system tags are displayed in the MIF:

• FM8_SYSTEM_HIDEELEMENT

• FM8_TRACK_CHANGES_ADDED

• FM8_TRACK_CHANGES_DELETED

Note: These tags are used by the system and are reserved for internal use only.

BoolCondTag. You can create these expressions by linking condition tags with boolean operators and

BoolCondExpr statement. If the value of BoolCondState of a Boolean condition expression is

BoolCondState is ‘Active’, FrameMaker uses this expression

BoolCond statement appears in the BoolCondCatalog as shown below :

ADOBE FRAMEMAKER 9

MIF Reference

How FrameMaker writes a conditional document

If you are converting a MIF file that was generated by FrameMaker, you need to understand how FrameMaker writes a file that contains hidden conditional text.

When FrameMaker writes a MIF file, it places all hidden conditional text in a text flow with the tag name Within the document text flow, a conditional text marker,

<Marker <MType 10>>, indicates where hidden condi-

tional text would appear if shown.

The marker text contains a plus sign (+) followed by a unique five-digit integer. The corresponding block of hidden text is in the hidden text flow. It begins with a conditional text marker containing a minus sign (–) and a matching integer and ends with a marker containing an equal sign (=) and the same integer. One or more

Para statements

appear between the markers. If the hidden conditional text doesn’t span paragraphs, all the text appears in one statement. If the hidden text spans paragraphs, each end of paragraph in the conditional text forces a new statement in the hidden text flow.

The following example shows how FrameMaker writes the sentence used in the previous example:

# This text flow contains the sentence as it appears in # the document body.

<TextFlow

<TFTag `A'> <TFAutoConnect Yes > <Para

<ParaLine

# This marker indicates that hidden text appears in the

<Marker

<MCurrPage 0> > # end of Marker <Conditional

<InCondition `Summer'> > # end of Conditional <String `cool and comfortable tank tops'> <Unconditional > ...

> # end of Para

> # end of TextFlow

<TextFlow

<TFTag `HIDDEN'> <Para

<PgfEndCond Yes > <ParaLine

<Marker

<MCurrPage 0> > # end of Marker <Conditional

<InCondition `Winter'> > # end of Conditional

<String `chilly winter'> <Marker

# hidden text flow.

# This text flow contains the hidden conditional text.

# This marker shows the beginning of hidden text. # Its ID matches the marker ID in the body text flow.

# Here's the hidden text.

HIDDEN.

Para

ADOBE FRAMEMAKER 9

# This marker shows the end of hidden text. It must

# match the marker that begins with a minus sign (-). <MText `=88793'> <MCurrPage 0>

> # end of Marker

> > # end of Para ...

> # end of TextFlow

MIF Reference

Creating filters

Structured FrameMaker allows specific components in a structured document to be processed differently to generate different output formats. Consider a case where you want some text in a document to be included in the Print output, but not in the HTML Help output. You can create a filter based on the values of the attributes of elements, and process only those elements in the document that match the filter, and include such elements in the Print output.

In a MIF file, you create a filter required for generating the output of a structured document using the

uesCatalog

, DefAttrValues, AttrCondExprCatalog, and AttrCondExpr statements.

All MIF 8 documents contain a catalog of predefined filters. The catalog is empty if a filter is not defined in a structured document. A filter comprises a tag called state of the filter which is stored in the

AttrCondState tag. The state of the filter indicates whether the filter is active

AttrCondExprTag, the expression tag AttrCondExprStr, and the

in the document. Although the catalog can have several filters, only one filter must be active at any time.

To create filters, use the

AttrCondExprCatalog statement as illustrated in the following example where two filters

are created:

<AttrCondExprCatalog <AttrCondExpr <AttrCondExprTag `NewExpr1'> <AttrCondExprStr `(A="val1" OR A="val11") AND (B="val2" OR B="val22")'> <AttrCondState `Inactive'> > # end of AttrCondExpr <AttrCondExpr <AttrCondExprTag `NewExpr2'> <AttrCondExprStr `(A="val4" OR A="val44") OR (B="val3" OR B="val33")'> <AttrCondState `Active'> > # end of AttrCondExpr > # end of AttrCondExprCatalog

The following statements create an empty filter catalog:

<AttrCondExprCatalog

> # end of AttrCondExprCatalog

All MIF 8 documents contain attribute-value pairs.

To create a catalog of attributes with values, use the

DefAttrValuesCatalog statement as illustrated in the

following example:

<DefAttrValuesCatalog <DefAttrValues <AttributeTag `A'> <AttributeValue `val1'> <AttributeValue `val2'> > # end of DefAttrValues <DefAttrValues <AttributeTag `B'>

DefAttrVal-

ADOBE FRAMEMAKER 9

MIF Reference

<AttributeValue `val3'> <AttributeValue `val4'> > # end of DefAttrValues > # end of DefAttrValuesCatalog

The following statements create a catalog of attributes without values:

<DefAttrValuesCatalog

> # end of DefAttrValuesCatalog

Including template files

When you write an application, such as a filter or a database publishing application, to generate a MIF file, you have two ways to include all formatting information in the file:

• Generate all paragraph formats and other formatting information directly from the application.

• Create a template document in FrameMaker, save it as a MIF file, and include the template file in your generated

MIF file.

It’s usually easier to create a template in FrameMaker than it is to generate the formatting information directly.

To create the template as a MIF file, do the following:

1 Create the template in FrameMaker and save it as a MIF file.

2 Edit the MIF file to preserve the formatting catalogs and the page definitions and delete the text flow.

3 Generate the text flow for your document and use the include statement to read the formatting information

from the template.

Creating the template

Create the template document in FrameMaker. Define the paragraph and character formats, table formats, variable and cross-reference formats, master pages, and any other formatting and page layout information that your document needs. Generally, a template contains some sample lines that illustrate each format in the document. Save the completed template as a MIF file. For more information about creating templates, see your user’s manual.

Editing the MIF file

You need to edit the resulting MIF file to extract just the formatting and page layout information.

1 Delete the MIFFile statement.

2 Search for the first body page and locate its TextRect statement.

T o find the first body page, search for the first occurrence of in your MIF file looks like this:

<PageType BodyPage>. Suppose the first body page

ADOBE FRAMEMAKER 9

<Fill 15> <PenWidth 1.0 pt> <ObColor `Black'> <DashedPattern <DashedStyle Solid> > # end of DashedPattern <ShapeRect 1.0" 1.0" 6.5" 9.0"> <TRNext 0> > # end of TextRect > # end of Page

MIF Reference

The ID for the TextRect on this body page is 7. Remember this ID number. If there is more than one TextRect on the body page, remember the ID of the first one.

3 Locate the text flow associated with the TextRect statement on the first body page and delete it.

Suppose you are working with the previous example. You would search for the statement

<TextRectID 7> to

locate the text flow. It might look similar to the following:

<TextFlow

<Notes> # end of Notes <Para

<ParaLine

> > # end of Para

> # end of TextFlow

Delete the entire text flow.

4 From your application, generate a MIF file that includes the edited template file.

Suppose the edited MIF file is called

mytemplate.mif. Y our application would generate the following two lines

at the top of any new MIF file:

<MIFFile 8.00> # Generated by my application include (mytemplate.mif)

The include statement is similar to a C #include directive. It causes the MIF interpreter to read the contents of the file named

mytemplate.mif. For more information about filenames in MIF, see “Device-independent

pathnames” on page 7.

5 From your application, generate a text flow that contains the entire document contents.

The text flow should use the ID and tag name of the text flow you deleted from the template file; this associates the new text flow with the first body page in the template.

The entire generated MIF file would look something like this:

<MIFFile 8.00> # Generated by my application include (mytemplate.mif) <TextFlow

<TFTag `A'> <TFAutoConnect Yes> <TextRectID 7> <Para

<ParaLine

> > # end of Para

> # end of TextFlow

A user can open the generated MIF file to get a fully formatted FrameMaker document.

ADOBE FRAMEMAKER 9

MIF Reference

Setting View Only document options

You can use MIF statements to control the display of View Only documents. A View Only document is a locked FrameMaker hypertext document that a user can open, read, and print but not edit. You can use MIF statements to control the appearance and behavior of the document window and to control the behavior of cross-references in locked documents.

The MIF statements for View Only documents are intended for hypertext authors who want more control over hypertext documents. They do not have corresponding commands in the user interface.

The View Only MIF statements described in this section must appear in a have no effect in an unlocked document. Make sure that the

Document statement also includes the following

substatement:

Changing the document window

You can use MIF statements to change the appearance and behavior of the document window in the following ways:

• To suppress the document window menu bar, use the following statement:

This statement has no effect in the Windows version of FrameMaker because those versions have an application menu bar rather than a document window menu bar.

• To suppress the display of scroll bars and border buttons in the document window, use the following statement:

• To suppress selection in the document window, include the following statement:

You can normally select text and objects in a locked document by Control-dragging in UNIX and Windows versions. Specifying

• To suppress the appearance of a document region pop-up menu, use the statement:

A document region pop-up menu is a menu activated by the right mouse button. For example, in UNIX versions of FrameMaker, the Maker menu can be accessed by pressing the right mouse button. If the statement has a value of statement has no effect in the Windows version of FrameMaker.

• To make a window behave as a palette window, use the following statement:

A palette window is a command window, such as the Equations palette, that exhibits special platform-dependent behavior. In UNIX versions of FrameMaker, a palette window can only be dismissed; it cannot be closed to an icon.

In Windows versions, a palette floats outside the main application window and cannot be unlocked. To edit the palette, you need to reset the FrameMaker.

<DViewOnlySelect No> prevents all selection in a locked document.

No, the background menu does not appear when the right mouse button is pressed. This

DViewOnlyWinPalette statement to No in the MIF file before opening it in

Document statement. These statements

DViewOnlyWinPopup

Using active cross-references

A locked document automatically has active cross-references. An active cross-reference behaves like a hypertext

gotolink command; when the user clicks on a cross-reference, FrameMaker displays the link’s destination page.

By default, the destination page is shown in the same document window as the link’s source.

ADOBE FRAMEMAKER 9

MIF Reference

You can use MIF statements to turn off active cross-references and to change the type of hypertext link that the cross-reference emulates. (By default, cross-references emulate the

gotolink behavior.)

• To make cross-references emulate the openlink command, which displays the destination page in a new

document window, use the following statement:

Use this setting to allow users to see both the source page and the destination page.

• To turn off active cross-references, use the following statement:

Use this setting to emulate the behavior in earlier FrameMaker versions.

You ca n u se t he

DViewOnlySelect statement to control whether active cross-references highlight the marker

associated with destination text.

• When cross-references are active and <DViewOnlySelect Yes> is specified, clicking a cross-reference in the

document highlights the marker associated with the destination text.

• When cross-references are active and <DViewOnlySelect UserOnly> is specified, clicking a cross-reference

does not highlight the marker. However, the user can select text in the locked document.

• When cross-references are active and <DViewOnlySelect No> is specified, clicking a cross-reference does not

highlight the marker. The user cannot select text in the locked document.

By default, clicking a cross-reference does not highlight the marker associated with the destination text but the user can select text in the locked document.

Disabling commands

You can disable specific commands in a View Only document. For example, a hypertext author might disable copy and print commands for sensitive documents.

To disable a command, you must supply the hex code, called an fcode, that internally represents that command in FrameMaker. For example, you can disable printing, copying, and unlocking the document by supplying the following statements:

<DViewOnlyNoOp 0x313># Disable printing <DViewOnlyNoOp 0x322># Disable copying <DViewOnlyNoOp 0xF00># Disable unlocking the document

The following table lists the files where you can find fcodes for commands:

For this version Look here

UNIX

Windows install_dir/fminit/configui/cmds.cfg, where install_dir is the directory where

$FMHOME/fminit/

use, such as

FrameMaker is installed

usenglish

language

/configui/Commands, where

language

is the language in

See the online manual Customizing FrameMaker for more information about the commands file in UNIX versions.

Applications of MIF

You can use MIF files any time you need access to FrameMaker’s formatting capabilities. This section provides some examples of how MIF can be used and some tips on minimizing MIF statements.

You ca n u se M IF t o:

ADOBE FRAMEMAKER 9

MIF Reference

• Share files with earlier versions of FrameMaker

• Perform custom document processing

• Write import and export filters for FrameMaker documents

• Perform database publishing

Sharing files with earlier versions

FrameMaker automatically opens documents created with an earlier version of FrameMaker (2.0 or higher).

To use an earlier version of FrameMaker (such as 5.5) to edit a document created with a late r version of FrameMaker (such as 7.0):

1 Use the newer FrameMaker product version to save the document in MIF.

2 Open the MIF file with the earlier version of FrameMaker.

Note: Earlier versions of FrameMaker do not support all MIF statements in the current version. For example, when you use version 5.5.6 or earlier of FrameMaker to open a document created in version 6.0 or later, MIF statements specifying optimized PDF size are skipped. You can ignore the related error messages. However, to regain the optimized PDF size you will need to use the Optimize Pdf Size command. For a description of the differences between MIF 7.0 and previous versions, see , “MIF Compatibility.”

Modifying documents

You can use MIF to perform custom document processing. For example, you can create a program or write a series of text editor macros to search for and change paragraph tags in a MIF file. You can also edit a MIF book file to easily add or change document names in a book.

For an example of using MIF to easily update the values in a table, see “Updating several values in a table” on

page 228.

Writing filters

MIF allows you to write filters to convert data from other formats to FrameMaker format and to convert a MIF file to another document format. While FrameMaker will change in future versions, MIF will always remain compatible with earlier versions, so your filters can continue to write MIF files.

Import filters

MIF statements can completely describe a FrameMaker document or book file. Because documents created with most word processors and text editors have fewer features than a FrameMaker document, your import filters normally use only a subset of MIF statements.

To write an import filter, first determine which MIF statements describe the format of the input file. Then write a program to translate the file from its original file format to MIF. If the imported document doesn’t use sophisticated formatting and layout features, don’t include the corresponding MIF statements in your filter.

For example, if the file was created by a word processor, your filter should convert document text to a single

TextFlow statement. Ignore line and page breaks (except forced breaks) in your source document, because the text

will be repaginated by the MIF interpreter. If the document uses style sheets, convert paragraph styles to paragraph formats in a

PgfCatalog statement, and convert table styles to table formats in a TblCatalog statement.

ADOBE FRAMEMAKER 9

MIF Reference

Output filters

You can write output filters that convert a MIF file to any format you want. While you should be familiar with all MIF statements to determine which ones you need to translate a FrameMaker document, your output filter doesn’t need to convert all the possible MIF statements.

In most cases, a MIF description of a FrameMaker document contains more information than you need. Because MIF appears as a series of nested statements, your output filter must be able to scan a MIF file for the information it needs and skip over statements that it will not use.

Installing a filter

In UNIX versions, you can set up FrameMaker to automatically start a script that runs a filter based on the filename suffix. The filter can convert a file to a MIF file. FrameMaker then interprets the MIF file, storing the results in a FrameMaker document. For more information about installing your filter, see the online manual Customizing FrameMaker.

Minimizing MIF statements

The following tips may help you minimize the number of MIF statements that your filter needs to generate:

• If you are not concerned about controlling the format of a document, use the default formats that FrameMaker

provides for new documents. The user can always change formats as needed within the FrameMaker document.

• If you are filtering a document from another application into FrameMaker and then back to the application, you

may want to import the filter’s MIF file into a FrameMaker document, save the document as a MIF file, and then convert the file back to the original format from the MIF file generated by FrameMaker. This technique takes advantage of FrameMaker’s syntactically complete MIF statements, but allows your filter to write a shorter MIF file.

• If your filter needs to generate fully-formatted MIF files, you can minimize the number of formatting statements

by creating a template in FrameMaker, saving the template as a MIF file, and then including the MIF template file in your filter’s generated document. You must edit the saved MIF template (see “Including template files” on

page 44). An advantage of this technique is that you can use the same template for more than one document.

• Define macros to ease the process of generating statements. For an example of using macros, see “Text example”

on page 219.

Database publishing

You can use MIF files to import information from an external application, such as a database, into a FrameMaker document. This type of information transfer is often called database publishing. For example, you can write a C program or a database script to retrieve information from a database and store that information as a MIF file. A user can then open or import the MIF file to get a fully formatted FrameMaker document that contains up-to-date information from the database.

There are four key elements to a typical database publishing solution:

• The database provides a system to enter, manipulate, select, and sort data. You can use any database that can

create text-based output files.

• MIF provides the data interchange format between the database and FrameMaker. MIF can completely describe

a document in ASCII format, including information such as text and graphics, page layout, and indexes and crossreferences.

• FrameMaker provides the text formatting. FrameMaker reads MIF files and dynamically manages line breaks,

page breaks, headers and footers, and graphics. The user can view, print, save, or even navigate through an online document using hypertext commands.

ADOBE FRAMEMAKER 9

CAD or Other Illustration Packages

Database

Text

MIF (ASCII text)

Final Document

MIF Reference

• Optional control programs allow you to tightly integrate the database and FrameMaker. Some database

publishing applications are controlled entirely from the database system or through hypertext commands embedded in a FrameMaker document. More complicated applications may require an external control program, such as a C program that issues queries and selects a FrameMaker document template.

For an example of a database publishing application, see “Database publishing” on page 229.

Debugging MIF files

When FrameMaker reads a MIF file, it might detect errors such as unexpected character sequences. In UNIX and Windows versions, FrameMaker displays messages in a console window. In the Windows version, you must turn on Show File Translation Errors in the Preferences dialog box to display messages in a window. If FrameMaker finds an error, it continues to process the MIF file and reads as much of the document as possible.

When you are debugging MIF files, you should examine the error messages for clues. The MIF interpreter reports line numbers for most errors. For a description of MIF error messages, see , “MIF Messages.”

In some cases, the MIF interpreter reports an “invalid opcode” message for a statement. If the statement seems correct to you, check the statements above it. A missing right angle bracket can cause the interpreter to parse a statement incorrectly.

If the MIF interpreter brings up an empty document when it reads your file, it has stopped trying to interpret your file and opened an empty custom document instead. Close the document and check your MIF file for errors. Try adding a

If your MIF statements are syntactically correct but cause unexpected results in the document, check for mismatched ID numbers and check the placement of statements. Many MIF statements are position-dependent and can cause errors if they appear in the wrong place in a file. For example, an corresponding

Verbose statement to your file to get more complete messages.

Tbl statement causes an error.

ATbl statement that comes before its

ADOBE FRAMEMAKER 9

Here are some additional tips for debugging MIF files:

MIF Reference

• Use the Verbose statement to generate comments. To debug a specific section of a MIF file, you can precede the

section with the

<Verbose Yes> statement and end the section with the <Verbose No> statement.

• Make sure angle brackets are balanced.

• Make sure that MIF statement names are capitalized correctly. MIF statement names and keyword values are

case-sensitive.

• Make sure that string arguments are enclosed in straight single quotation marks. (See “MIF data items” on

page 5 for an example.)

• Make sure ID numbers are unique.

• Make sure that every table anchor has a corresponding table instance, and that every table instance has an

anchor in the text flow.

• Make sure that tag names with spaces are enclosed in straight single quotation marks.

• Make sure paired statements are balanced. For example, XRef and XRefEnd statements must be paired.

• Make sure that right angle bracket (>) and backslash (\) characters in text are preceded by a backslash.

• Make sure that hexadecimal characters, for example \xe6, have a space after them.

Other application tools

The Frame Developer’s Kit (FDK) provides tools that you can use to write filters and to perform custom document processing. The FDK includes the Application Program Interface (API), which you can use to create a C application that can create and save documents, modify documents, and interact with the user. The FDK also includes the Frame Development Environment (FDE), which allows you to make your FDK clients portable to the platforms that FrameMaker supports.

MIF files can be used by C applications, text processing utilities, or UNIX shell scripts. You might want to work directly with MIF files if you are filtering large numbers of files in batch mode. You also might want to work with MIF files if you are doing simple document processing, such as changing a few tag names, or if you are setting options for View Only documents.

You can use the FDK and MIF files together; for example, a database publishing application can extract values from a database and write out the information as a table in a MIF file. An FDK client can then automatically open the MIF file as a FrameMaker document.

Where to go from here

This chapter has given you a start at working with MIF files. You can use the information in this chapter as guidelines for working with similar MIF statements. Once you have experimented with basic MIF files, you can learn about other MIF statements by creating small FrameMaker documents that contain a specific feature and saving these documents as MIF files. Because FrameMaker writes complete and precise MIF code, it is your ultimate source for learning about MIF statements.

For more information about document components not described in this chapter, see the MIF statement descriptions in , “MIF Document Statements”, , “MIF Book File Statements”, and , “MIF Statements for Structured Documents and Books”.

Chapter 3: MIF Document Statements

This chapter describes the structure of MIF document files and the MIF statements they can contain. Most MIF statements are listed in the order that they appear in a MIF file, as described in the following section. If you are looking for information about a particular statement, use this manual’s statement index to locate it. If you are looking for information about a type of object, such as a table or paragraph, use the table of contents to locate the MIF statements that describe the object.

MIF file layout

The following table lists the main statements in a MIF document file in the order that Adobe® FrameMaker® writes them. You must follow the same order that FrameMaker uses, with the exception of the macro statements and control statements, which can appear anywhere at the top level of a file. Each statement, except the statement, is optional. Most main statements use substatements to describe objects and their properties.

Statement Description

MIFFile

Control statements Establish the default units in a Units statement, the debugging setting in a Verbose

Macro statements Define macros with a define statement and read in files with an include statement.

ColorCatalog

ConditionCatalog

BoolCondCatalog

CombinedFontCatalog

PgfCatalog

ElementDefCatalog

FmtChangeListCatalog

Labels the file as a MIF document file. The MIFFile statement is required and must be the first statement in the file.

statement, and comments in a Comment statement. These statements can appear anywhere at the top level as well as in some substatements.

These statements can appear anywhere at the top level.

Describes document colors. The ColorCatalog statement contains Color statements that define each color and tag.

Describes condition tags. The ConditionCatalog statement contains Condition statements that define each condition tag and its properties.

Describes Boolean Condition Expressions. The BoolCondCatalog statement

BoolCond statements that define each Boolean condition expression with its

contains show/hide properties.

Describes combined fonts. The CombinedFontCatalog statement contains

CombinedFontDefn statements that define each combined font and its component

fonts.

Describes paragraph formats. The PgfCatalog statement contains Pgf statements that define the properties and tag for each paragraph format.

Defines the contents of the Element Catalog for a structured document. For more information, see ,“MIF Statements for Structured Documents and Books.”

Defines the contents of the Format Change List Catalog for a structured document. For more information, see ,“MIF Statements for Structured Documents and Books.”

DefAttrValuesCatalog

AttrCondExprCatalog

Defines the DefAttrValuesCatalog for a structured document. For more information, see ,“MIF Statements for Structured Documents and Books.”

Defines the AttrCondExprCatalog for a structured document. For more information, see ,“MIF Statements for Structured Documents and Books.”

Statement Description

ADOBE FRAMEMAKER 9

MIF Reference

FontCatalog

RulingCatalog

TblCatalog

KumihanCatalog

Views

VariableFormats

MarkerTypeCatalog

XRefFormats

Document

BookComponent

InitialAutoNums

Describes character formats. The FontCatalog statement contains Font statements that define the properties and tag for each character format.

Describes ruling styles for tables. The RulingCatalog statement contains Ruling statements that define the properties for each ruling style.

Describes table formats. The TblCatalog statement contains TblFormat statements that define the properties and tag for each table format.

Contains the Kumihan tables that specify line composition rules for Japanese text.

Describes color views for the document. The Views statement contains View statements that define which colors are visible in each color view.

Defines variables.The VariableFormats statement contains VariableFormat statements that define each variable.

Defines a catalog of user-defined markers for the current document. The MarkerType-

Catalog

user-defined marker.

Defines cross-reference formats. The XRefFormats statement contains XRef-

Format

Controls document features such as page size, margins, and column layout. Because the MIF interpreter assumes the same page defaults as the New command, this section is necessary only if you want to override those default settings.

Provides the setup information for files generated from the document. BookCompo-

nent

marker types to include.

Provides a starting value for the autonumber series in a document.

statement contains MarkerTypeCatalog statements that specify each

statements that define each cross-reference format.

statements describe the filename, filename suffix, file type, and paragraph tags or

Dictionary

AFrames

Tbls

Page

TextFlow

Lists allowed words in the document.

Describes all anchored frames in the document. The AFrames statement contains

Frame statements that define the contents ID number of each anchored frame. Later in

the MIF file, where the document contents are described, the MIF file must include an

AFrame statement that corresponds to each Frame statement. The AFrame state-

ment identifies where a specific anchored frame appears in a text flow; it need only supply the frame’s ID number.

Describes all tables in the document. The Tbls statement contains Tbl statements that define the contents of each table and its ID number. Later in the MIF file, where the document contents are described, the MIF file must include a short sponds to each appears in a text flow; it need only supply the table’s ID number.

Describes the layout of each page in the document. The descr iption includes the layout of each page, the dimensions of the text frames, and the objects and other graphic frames on that page. A MIF file created by FrameMaker includes a in the document, including the master pages. When you write an import filter, you can

Page statements; the MIF interpreter repaginates the document as needed.

omit

Represents the actual text in the document. Within TextFlow statements, the text is expressed in paragraphs which in turn contain paragraph lines. Line endings of

statements are not significant because the MIF interpreter wraps the contents of

Line

Tbl statement. The ATbl statement identifies where a specific table

ATbl statement that corre-

Page statement for each page

Para-

ParaLine statements into paragraphs.

ADOBE FRAMEMAKER 9

MIF Reference

MIFFile statement

The MIFFile statement identifies the file as a MIF file. The MIFFile statement is required and must be the first line of the file with no leading white space.

Syntax

<MIFFile

The

version

> #

comment

argument indicates the version number of the MIF language used in the file, and

(Required) Identifies a MIF file

comment

shows the name and version number of the program that generated the file. For example, a MIF file saved in version 9 of FrameMaker begins with the following line:

<MIFFile 9.00> # Generated by FrameMaker 9.0

MIF is compatible across versions, so a MIF interpreter can parse any MIF file. The results may sometimes differ from your intentions if a MIF file describes features that are not included in FrameMaker that reads the MIF file. For more information, see , “MIF Compatibility.”

Control statements

Control statements set defaults, provide debugging information, and insert comments.

Units statement

The Units statement specifies the default units for dimensions and coordinates in the document. It can appear anywhere at the top level or within any statement.

Syntax

<Units

Usage

keyword

Default units for document

keyword

Uin Ucm Umm Upica Upt Udd Ucc

can be one of:

If no Units statement is provided, the default value is Uin. A Units statement remains in effect until another Units statement is encountered. When FrameMaker writes a MIF file, it uses the document’s current display units.

CharUnits statement

The CharUnits statement specifies the default units for measuring font size and line spacing. This is to accommodate the Japanese “Q” units of measurement. This statement can appear anywhere at the top level or within any statement.

Syntax

<CharUnits

keyword

ADOBE FRAMEMAKER 9

Default units for font size and line spacing

keyword

CUpt CUQ

can be one of:

MIF Reference

Verbose statement

The Verbose statement turns on a debugging mode for MIF. It can appear anywhere at the top level or within any statement.

Syntax

Yes

<Verbose

boolean

Usage

When Verbose mode is on, the MIF interpreter writes detailed stream of processing descriptions to a window. In UNIX versions of FrameMaker, these descriptions appear in the window from which FrameMaker was started. To display messages in the Windows version, you must turn on Show File Translation Errors in FrameMaker’s Preferences dialog box. The messages appear in a console window in Windows. The processing descriptions can be quite long, but may be essential for debugging a program that creates MIF for input to FrameMaker. A can occur unnested or within markup statements, as explained later in this chapter. A in effect until the interpreter encounters another

turns on debugging information

Verbose statement

Verbose statement remains

Verbose statement that changes the setting.

Comment statement

The Comment statement identifies an optional comment.

Syntax

<Comment

comment-text

Usage

Comments can appear within Comment statements, or they can follow a number sign (#). When it encounters a number sign, the MIF interpreter ignores all text until the end of the line, including angle brackets.

Because

Comment statements can be nested within one another, the MIF interpreter examines all characters

following an angle bracket until it finds the corresponding angle bracket that ends the comment.

The MIF interpreter processes number signs within Comment statements as normal comments, ignoring the remainder of the line.

<Comment - When a number sign appears within a <Comment> statement, # the MIF interpreter ignores the rest of the characters in that # line--including angle brackets < >.> # End of <Comment> Statement.

Identifies a comment

ADOBE FRAMEMAKER 9

MIF Reference

Macro statements

MIF has two statements that allow you to define macros and include information from other files. Although these statements usually appear near the beginning of a MIF file, you need not put them in that position. However, the MIF interpreter does not interpret a macro that occurs before its definition.

define statement

The define statement creates a macro. When the MIF interpreter reads a MIF file, it replaces the macro name with its replacement text. A appear before any occurrences of the macro name.

Syntax

define (

Usage

name, replacement

Once a macro has been defined, you can use the macro name anywhere that the replacement text is valid. For example, suppose you define the following macro:

define (Bold, <Font <FWeight `Bold'>>)

When you use the macro in MIF statements, write <Bold>. The interpreter replaces <Bold> with <Font <FWeight

`Bold'>>

. Note that it retains the outer angle brackets in the replacement text.

Note that when you use a macro in a MIF file, you must enclose macro names in brackets to comply with the MIF syntax (for example, write correctly.

define statement can appear anywhere in a MIF file; however, the macro definition must

)

<Bold> instead of Bold). The MIF parser requires these brackets to interpret the macro

Creates a macro

include statement

The include statement reads information from other files. It is similar to an #include statement in a C program. When the MIF interpreter reads a MIF file, it replaces the

include statement can appear anywhere in a MIF file. However, make sure that the contents of the included file

An appear in a valid location when they are read into the MIF file.

Syntax

include (

Usage

The example,

pathname

/usr/doc/template.mif). For the Windows version of FrameMaker, use the following guideline for

)

argument specifies a UNIX-style pathname, which uses a slash (/ ) to separate directory names (for

specifying absolute pathnames:

• For Windows versions, start an absolute pathname with the drive name. For example, to include the file

myfile.doc from the directory mydir on the c: drive, specify the pathname c:/mydir/myfile.doc. Don’t start

an absolute path with a slash (/).

If you specify a relative pathname, the MIF interpreter searches for the file to include in the directory or folder that contains the file being interpreted. In UNIX versions of FrameMaker, the MIF interpreter also searches the

$FMHOME/fminit and the $FMHOME/fminit/filters directories for a file with a relative pathname.

include statement with the contents of the included file.

Reads in a file

ADOBE FRAMEMAKER 9

MIF Reference

In general, you would use an include statement to read a header file containing define statements that a filter needs to translate a file. Isolate the data in a header file to simplify the process of changing important mappings. You can also use an

include statement to read in a template file containing formatting information. Your application

can then simply generate a document’s text. For more information, see “Including template files” on page 44.

Track edited text

Reviewers can edit FrameMaker documents sent for review with the Track Text Edit feature enabled. In a MIF file, you can enable the Track Text Edit feature using the you can preview the final document with all the text edits incorporated in the document. Alternatively, you can preview the original document without the text edits incorporated in the document. To preview how a document will appear if you accept all text edits or reject all text edits , use the

Syntax

DTrackChangesOn statement. Before you accept all text edits,

DTrackChangesPreviewState statement.

Preserves the On/Off state of the Track Text Edit feature

Preserves the preview state of the Track Text Edit feature

The preview state can have one of the following values:

Preview Off: DTrackChangesPreviewState set with the value No

Preview On Final: DTrackChangesPreviewState set with the value All

Preview On Original: DTrackChangesPreviewState set with the value Yes

Conditional text

FrameMaker documents can contain conditional text. In a MIF file, the condition tags are defined by a Condition statement, which specifies whether the condition tag is hidden or shown. The condition tags for a document are stored in a

Within the text flow,

ConditionCatalog statement

The ConditionCatalog statement defines the contents of the Condition Catalog. A MIF file can have only one

ConditionCatalog statement, which must appear at the top level in the order given in “MIF file layout” on page 52.

ConditionCatalog statement.

Conditional and Unconditional statements show where conditional text begins and ends.

Syntax

<ConditionCatalog

<Condition…>

…

Defines a condition tag (see “Condition statement,” next)

Additional statements as needed

ADOBE FRAMEMAKER 9

MIF Reference

End of ConditionCatalog statement

Condition statement

The Condition statement defines the state of a condition tag and its condition indicators, which control how conditional text is displayed in the document window. The statement must appear in a The property statements can appear in any order.

Syntax

<Condition

<CTag

string

<CState

<CStyle

keyword

Condition tag string

Whether text with this tag is shown or hidden

keyword

CHidden CShown

can be one of:

Format of text with this condition

keyword

CAsIs CUnderline CDoubleUnderline CStrike COverline CChangeBar

can be one of:

ConditionCatalog statement.

<CColor

tagstring

<CSeparation

integer

Color for condition tag (see “ColorCatalog statement” on page 80)

Color for condition tag; no longer used, but written out by FrameMaker for backward-

compatibility (see “Color statements” on page 247)

End of Condition statement

Conditional and Unconditional statements

The Conditional statement marks the beginning of conditional text and the Unconditional statement marks the end. These statements must appear in a

Syntax

<Conditional

<InCondition

…

tagstring

Row or ParaLine statement.

Begin conditional text

Specifies condition tag from Condition Catalog

Additional statements as needed

End of Conditional statement

Returns to unconditional state

ADOBE FRAMEMAKER 9

MIF Reference

System generated colors

FrameMaker will automatically generate new colors when multiple tags are applied on text. The ColorTag tag that is generated is named with the "fm_gen_" prefix and appended with a system-generated integer.

Boolean expressions

A Boolean expression is defined in a BoolCond statement.

BoolCondCatalog statement

You can create Boolean expressions by linking different conditional tags using Boolean operators. In a MIF file, Boolean condition expressions are defined using a are stored in a

The

BoolCondCatalog statement defines the contents of Boolean Expression Catalog for conditional text. A MIF

file can have only one

Syntax

<BoolCondCatalog

BoolCondCatalog statement.

BoolCondCatalog statement, after Condition Catalog.

BoolCond statement. The Boolean expressions for a document

<BoolCond.........>

> #

Defines a Boolean expression

End of BoolCondCatalog

BoolCond statement

The BoolCond statement defines a new boolean expression, which is used to evaluate the show/hide state of conditional text. Statement must appear in order.

Syntax

<BoolCond

BoolCondCatalog statement. The property statement can appear in any

Tag name used for Boolean expressions.

Boolean expression used for show/hide evaluation of conditional text. (

OR, NOT, and AND are the operators and condition tags are

operands within a quoted string) For example, “

“Tag1”

Indicates whether the evaluation of showing or hiding conditional text is based on this expression.

The string must contain one of the following values:

Comment” OR

• 'Active'

• 'Inactive'

> #

End of BoolCond

ADOBE FRAMEMAKER 9

MIF Reference

Filter By Attribute

Elements in a structured document can have one or more attributes associated with them. Using FrameMaker, you can filter a structured document based on the value of these attributes.

All MIF 8 documents contain a catalog of predefined attribute values. If no values are defined, the catalog remains empty. Each definition in a catalog includes an attribute tag (

AttributeValue).

(

DefAttrValuesCatalog statement

The DefAttrValuesCatalog statement is used to define the contents of the Defined Attribute Values catalog. A MIF file can contain one

Syntax

<DefAttrValuesCatalog

DefAttrValuesCatalog statement only.

AttributeTag) and the corresponding list of values

<DefAttrValues.........>

> #

Defines an attribute and its corresponding values

Additional statements, as required.

End of DefAttrValuesCatalog

All MIF 8 documents contain a catalog of predefined filters.

DefAttrValues statement

The DefAttrValues statement is used to define a set of attributes with relevant values.

Syntax

<DefAttrValues

> #

Attribute Name

Attribute Value

Additional attribute values, as required.

End of DefAttrValues

AttrCondExprCatalog statement

The AttrCondExprCatalog statement is used to define the contents of the Attribute Expression catalog. A MIF file can contain one

AttrCondExprCatalog statement only.

Syntax

<AttrCondExprCatalog

<AttrCondExpr.........>

> #

Defines a filter

Additional filters, as required.

End of AttrCondExprCatalog

AttrCondExpr statement

The AttrCondExpr statement is used to define a set of attributes with values.

Syntax

<AttrCondExpr

ADOBE FRAMEMAKER 9

MIF Reference

> #

Expression Tag string

Expression string

Indicates whether the AttrCondExpr is applied to the document.

The string must have one of the following values:

'Active'

'Inactive'

End of AttrCondExpr

Paragraph formats

A paragraph format is defined in a Pgf statement. Paragraph formats can be defined locally or stored in the Paragraph Catalog, which is defined by a

PgfCatalog statement

The PgfCatalog statement defines the contents of the Paragraph Catalog. A MIF file can have only one

PgfCatalog statement, which must appear at the top level in the order given in “MIF file layout” on page 52.

Syntax

<PgfCatalog

PgfCatalog statement.

<Pgf…>

…

Defines a paragraph format (see “Pgf statement” on page 61)

Additional statements as needed

End of PgfCatalog statement

Usage

If you don’t include a PgfCatalog statement, the MIF interpreter uses the paragraph formats defined in NewTem-

plate

. (For information on defaults specified in templates, see page 3.) If you include PgfCatalog, paragraph formats in the MIF file replace default formats. The MIF interpreter does not add your paragraph format to the default Paragraph Catalog, although it provides default values for unspecified properties in a paragraph format (see

“Creating and applying paragraph formats” on page 12).

Pgf statement

The Pgf statement defines a paragraph format. Pgf statements can appear in many statements; the statement descriptions show where

Pgf can be used.

ADOBE FRAMEMAKER 9

MIF Reference

The Pgf statement contains substatements that set the properties of a paragraph format. Most of these properties correspond to those in the Paragraph Designer. Properties can appear in any order within a following exception: the

Syntax

Basic properties

PgfNumTabs statement must appear before any TabStop statements.

Pgf statement, with the

<Pgf

<PgfUseNextTag

<PgfNextTag

<PgfFIndent

boolean

tagstring

dimension

<PgfFIndentRelative

<PgfFIndentOffset

dimension

<PgfAlignment

keyword

<PgfLineSpacing

keyword

boolean

Begin paragraph format

Paragraph tag name

Turns on following paragraph tag feature

Tag name of following paragraph

First line left margin, measured from left side of current text column

Used for structured documents only

Left margin, measured from left side of current text column

Right margin, measured from right side of current text column

Alignment within the text column

keyword

LeftRight Left Center Right

Space above paragraph

Space below paragraph

Amount of space between lines in paragraph measured from baseline to baseline

keyword

Fixed (default font size) Proportional (largest font in line)

can be one of:

<PgfNumTabs

integer>

<TabStop

<TSType

keyword

Space below each line in a paragraph

Number of tabs in a paragraph

The statement is not required for input files; the MIF interpreter calculates the number of tabs. If it does appear, it must appear before any

TabStop statements; otherwise, the MIF interpreter ignores the tab

settings.

Begin definition of tab stop; the following property statements can appear in any order, but must appear within a

Horizontal position of tab stop

Tab stop alignment

keyword

Left Center Right Decimal

can be one of:

TabStop statement

ADOBE FRAMEMAKER 9

MIF Reference

<TSLeaderStr

string

<TabStop…>

Default font properties

<PgfFont…>

Pagination properties

<PgfPlacement

keyword

<PgfPlacementStyle

keyword

Tab stop leader string (for example, ` . ')

Align decimal tab around a character by ASCII value; in UNIX versions, type man ascii in a UNIX window for a list of characters and their corresponding ASCII values

End of TabStop statement

Additional statements as needed

Default font (see page 66)

Vertical placement of paragraph in text column

keyword

Anywhere ColumnTop PageTop LPageTop RPageTop

Placement of side heads, run-in heads, and paragraphs that straddle text columns

keyword

Normal RunIn SideheadTop SideheadFirstBaseline SideheadLastBaseline Straddle StraddleNormalOnly

See page 65

can be one of:

<PgfWithPrev

<PgfWithNext

<PgfBlockSize integer

Numbering properties

<PgfAutoNum

<PgfNumFormat

<PgfNumberFont

<PgfNumAtEnd

Advanced properties

<PgfHyphenate

<HyphenMaxLines integer

<HyphenMinPrefix integer

<HyphenMinSuffix integer

boolean

string

tagstring

boolean

Default punctuation for run-in heads

Yes keeps paragraph with previous paragraph

Yes keeps paragraph with next paragraph

Widow/orphan lines

Yes turns on autonumbering

Autonumber formatting string

Tag from Character Catalog

Yes places number at end of line, instead of beginning

Yes turns on automatic hyphenation

Maximum number of consecutive lines that can end in a hyphen

Minimum number of letters that must precede hyphen

Minimum number of letters that must follow a hyphen

ADOBE FRAMEMAKER 9

MIF Reference

<HyphenMinWord integer

<PgfLetterSpace

boolean

<PgfMinWordSpace integer

<PgfOptWordSpace integer

<PgfMaxWordSpace integer

<PgfLanguage

keyword

Minimum length of a hyphenated word

Spread characters to fill line

Minimum word spacing (as a percentage of a standard space in the paragraph’s default font)

Optimum word spacing (as a percentage of a standard space in the paragraph’s default font)

Maximum word spacing (as a percentage of a standard space in the paragraph’s default font)

Language to use for spelling and hyphenation. Note that FrameMaker writes this statement so MIF files can be opened in older versions of FrameMaker. However, the language for a paragraph format or character format is now properly specified in the PgfFont and Font statements (see page 66)

keyword

NoLanguage USEnglish UKEnglish German SwissGerman French CanadianFrench Spanish Catalan Italian Portuguese Brazilian Danish Dutch Norwegian Nynorsk Finnish Swedish Japanese TraditionalChinese SimplifiedChinese Korean

can be one of:

<PgfTopSeparator

<PgfTopSepAtIndent

<PgfTopSepOffset

<PgfBotSeparator

<PgfBotSepAtIndent

<PgfBotSepOffset

Table cell properties

<PgfCellAlignment

string

boolean

dimension

string

boolean

dimension

keyword

Name of reference frame (from reference page) to put above paragraph

Used for structured documents only

Name of reference frame (from reference page) to put below paragraph

Used for structured documents only

Vertical alignment for first paragraph in a cell

keyword

Top Middle Bottom

can be one of:

ADOBE FRAMEMAKER 9

MIF Reference

<PgfCellMargins

<PgfCellLMarginFixed

<PgfCellTMarginFixed

<PgfCellRMarginFixed

<PgfCellBMarginFixed

Miscellaneous properties

<PgfLocked

<PgfAcrobatLevel

L T R B

boolean

integer

boolean

Cell margins for first paragraph in a cell

Yes means left cell margin is added to TblCellMargins; No

means left cell margin overrides TblCellMargins

Yes means top cell margin is added to TblCellMargins; No

means top cell margin overrides TblCellMargins

Yes means right cell margin is added to TblCellMargins; No

means right cell margin overrides TblCellMargins

Yes means bottom cell margin is added to TblCellMargins; No

means width of bottom cell margin overrides TblCellMargins

Yes means the paragraph is part of a text inset that obtains its format-

ting properties from the source document. See page 65

Level at which the paragraph is shown in an outline of Acrobat Bookmarks; 0 indicates that the paragraph does not appear as a bookmark

Usage

Within a PgfCatalog statement, the PgfTag statement assigns a tag to a paragraph format. To apply a paragraph format from the Paragraph Catalog to the current paragraph, use the

If the

PgfTag statement within a text flow does not match a format in the Paragraph Catalog, then the Pgf statement

makes changes to the current paragraph format. That is, a

Pgf statement after PgfTag specifies how the paragraph

PgfTag statement in a ParaLine statement.

differs from the format in the catalog.

If a document has side heads, indents and tabs are measured from the text column, not the side head. In a table cell, tab and indent settings are measured from the cell margins, not the cell edges.

Usage of some aspects of the

Pgf statement is described in the following sections.

Paragraph placement across text columns and side heads

The PgfPlacementStyle statement specifies the placement of a paragraph across text columns and side heads in a text frame:

• If a paragraph spans across all columns and side heads, the PgfPlacementStyle statement is set to Straddle.

• If a paragraph spans across all columns, but not across the side heads in a text frame, the PgfPlacementStyle

statement is set to

Locked paragraphs and text insets

StraddleNormal.

The PgfLocked statement does not correspond to any setting in the Paragraph Designer. The statement is used for text insets that retain formatting information from the source document.

<PgfLocked Yes> statement appears in a specific paragraph, that paragraph is part of a text inset that retains

If the formatting information from the source document. The paragraph is not affected by global formatting performed on the document.

<PgfLocked No> statement appears in a specific paragraph, that paragraph is not part of a text inset, or is part

If the of a text inset that reads formatting information from the current document. The paragraph is affected by global formatting performed on the document.

For more information about text insets, see “Text insets (text imported by reference)” on page 130.

ADOBE FRAMEMAKER 9

MIF Reference

Character formats

A character format is defined by a PgfFont or a Font statement. Character formats can be defined locally or they can be stored in the Character Catalog, which is defined by a

FontCatalog statement

The FontCatalog statement defines the contents of the Character Catalog. A document can have only one

FontCatalog statement, which must appear at the top level in the order given in “MIF file layout” on page 52.

Syntax

<FontCatalog

FontCatalog statement.

<Font…>

…

Defines a character format (see “PgfFont and Font statements,” next)

Additional statements as needed

End of FontCatalog statement

PgfFont and Font statements

The PgfFont and Font statements both define character formats. The PgfFont statement must appear in a Pgf statement. The

New statements have been added to the PgfFont and Font statements to express combined fonts in FrameMaker documents. For more information, see “Combined Fonts” on page 202.

Syntax

<PgfFont|Font

<FTag

Font name

<FFamily

<FAngle

<FWeight

Font statement must appear in a FontCatalog, Para, or TextLine statement.

tagstring

string

Character format tag name

Name of font family

Name of angle, such as Oblique

Name of weight, such as Bold

<FVar

<FPostScriptName

<FPlatformName

string

Name of variation, such as Narrow

Name of font when sent to PostScript printer (see “Font name” on page 69)

Platform-specific font name, only read by the Windows version (see page 69)

Font language

ADOBE FRAMEMAKER 9

MIF Reference

<FLanguage

Font encoding

<FEncoding

keyword

Language to use for spelling and hyphenation

keyword

Specifies the encoding for this font. This is to specify the encoding for a double-byte font. If not present, the default is Roman.

keyword

FrameRoman JISX0208.ShiftJIS BIG5 GB2312-80.EUC KSC5601-1992

can be one of:

can be one of these:

Font size, color, and width

<FSize

<FColor

<FSeparation

<FStretch

Font style

<FUnderlining

<FOverline

<FStrike

dimension

tagstring

integer

percent

keyword

boolean

Size, in points only (or in Q on a Japanese system)

Font color (see “ColorCatalog statement” on page 80)

Font color; no longer used, but written out by FrameMaker for backwardcompatibility (see “Color statements” on page 247)

The amount to stretch or compress the font, where 100% means no change

Turns on underlining and specifies underlining style

keyword

FNoUnderlining FSingle FDouble FNumeric

Turns on overline style

Turns on strikethrough style

can be one of:

ADOBE FRAMEMAKER 9

MIF Reference

<FChangeBar

<FPosition

<FPairKern

<FCase

Kerning information

keyword

<FTsume

boolean

keyword

boolean

Turns on the change bar

Specifies subscript and superscript characters; font size and position relative to baseline determined by Document substatements (see page 90)

keyword

FNormal FSuperscript FSubscript

Turns on pair kerning

Applies capitalization style to string

keyword

FAsTyped FSmallCaps FLowercase FUppercase

Horizontal kern value for manual kerning expressed as percentage of an em; positive value moves characters right and negative value moves characters left

Vertical kern value for manual kerning expresse d as percentage of an em; positive value moves characters down and negative value moves characters up

Spread value for space between characters expressed as percentage of an em; positive value increases the space and negative value decreases the space

Yes turns on Tsume (variable width rendering) for Asian characters

can be one of:

Filter statements Valid when text properties are applied to a file imported into FrameMaker

<FPlain

<FBold

<FItalic

Miscellaneous information

<FLocked

boolean

Used only by filters

Yes means the font is part of a text in set that obtains its formatting properties

from the source document

End of PgfFont or Font statement

Usage

Use PgfFont within a Pgf statement to override the default font for the paragraph. Use Font within a FontCatalog statement to define a font or in a

PgfFont statements are optional. Like the Pgf substatements, Font substatements reset the current font.

and

When the MIF interpreter reads a reads another

Font statement or reads the end of the Para statement. You can set the character format back to its

previous state by providing an empty

Para statement to override the default character format. Substatements in the Font

Font statement, it continues using the character format properties until it either

FTag statement. A Font statement that does not supply all property substate-

ments inherits the current font state for those properties not supplied.

For more information about creating and applying character formats in a MIF file, see “Creating and applying

character formats” on page 23. For more information about character formats in general, see your user’s manual.

Usage of some aspects of the

PgfFont and Font statements is described in the following sections.

ADOBE FRAMEMAKER 9

Locked fonts and text insets

MIF Reference

The FLocked statement does not correspond to any setting in the Character Designer. The statement is used for text insets that retain formatting information from the source document.

<FLocked Yes> statement appears in a specific character format, that character format is part of a text inset

If the that retains formatting information from the source document. The character format is not affected by global formatting performed on the document.

<FLocked No> statement appears in a specific character format, either that character format is not part of a

If the text inset, or that character format is part of a text inset that reads formatting information from the current document. The character format is affected by global formatting performed on the document.

For more information about text insets, see “Text insets (text imported by reference)” on page 130.

Font name

When a PgfFont or Font statement includes all of the family, angle, weight, and variation properties, FrameMaker identifies the font in one or more of the following ways:

• The statement FPlatformName specifies a font name that uniquely identifies the font on a specific platform.

• The statements FFamily, FAngle, FWeight, and FVar specify how FrameMaker stores font information inter-

nally.

• The statement FPostScriptName specifies the name given to a font when it is sent to a PostScript printer

(specifically, the name that would be passed to the PostScript

FindFont operator before any font coordination

operations). The PostScript name is unique for all PostScript fonts, but may not be available for fonts that have no PostScript version.

For complete font specifications, FrameMaker always writes the

ScriptName

statement. A UNIX version of FrameMaker ignores

statements. In addition, the Windows version of FrameMaker also writes the FPlatformName

FPlatformName.

FFamily, FAngle, FWeight, FVar, and FPost-

When FrameMaker reads a MIF file that includes more than one way of identifying a font, it checks the font name in the following order:

1 Platform name

2 Combination of family, angle, weight, and variation properties

3 PostScript name

If you are writing filters to generate MIF, you do not need to use all three methods. You should always specify the PostScript name, if it is available. You should use the platform name only if your filter will be run on a specific platform. A filter running on a specific platform can easily find and write out the platform name, but the name cannot be used on other platforms.

Font encoding

The <FEncoding> statement specifies which encoding to use for a font. The default is Roman, or standard 7-bit encoding. If this statement is not included for a font, 7-bit encoding is assumed.

This statement takes precedence over all other font attributes. For example, if the document includes a font with

<FEncoding `JISX0208.ShiftJIS’>, but that font family is not available on the user’s system, then the text will

appear in some other font on the system that uses Japanese encoding. If there is no Japanese encoded font on the system, the text appears in Roman encoding and the user will see garbled characters.

FPlatformName statement

The <FPlatformName a font for a particular platform. The

string

> statement provides a platform-specific ASCII string name that uniquely identifies

string

value consists of several fields separated by a period.

Windows: The Windows platform name has the following syntax:

<FPlatformName W.

FaceName.ItalicFlag.Weight.Variation

Platform designator

ADOBE FRAMEMAKER 9

MIF Reference

FaceName

ItalicFlag

Weight

Variation

Windows face name (for more information, see your Windows documentation)

Whether font is italic; use one of the following flags:

I (Italic)

R (Regular)

Weight classification, for example 400 (regular) or 700 (bold)

Optional variation, for example Narrow

The following statements are valid representations of the Windows font Helvetica Narrow Bold Oblique:

Tables

Table formats are defined by a TblFormat statement. Table formats can be locally defined or they can be stored in a Table Catalog, which is defined by a

RulingCatalog statement.

In a MIF file, all document tables are contained in one statement. The

ATbl statement specifies where each table instance appears in the text flow.

TblCatalog statement. The ruling styles used in a table are defined in a

Tbls statement. Each table instance is contained in a Tbl

TblCatalog statement

The TblCatalog statement defines the Table Catalog. A document can have only one TblCatalog statement, which must appear at the top level in the order given in “MIF file layout” on page 52.

Syntax

<TblCatalog

<TblFormat…>

…

Defines a table format (see “TblFormat statement,” next)

Additional statements as needed

End of TblCatalog statement

TblFormat statement

The TblFormat statement defines the format of a table. A TblFormat statement must appear in a TblCatalog or

Tbl statement. A TblFormat statement contains property substatements that define a table’s properties. Table

in a property statements can appear in any order.

Syntax

Basic properties

<TblFormat

ADOBE FRAMEMAKER 9

MIF Reference

<TblTag

<TblLIndent

<TblRIndent

tagstring

dimension

<TblSpBefore

<TblSpAfter

dimension

<TblAlignment

<TblPlacement

dimension

keyword

keyword>

Table format tag name

Left indent for the table relative to the table’s containing text column; has no effect on right-aligned tables

Right indent for the table relative to the table’s containing text column; has no effect on left-aligned tables

Space above table

Space below table

Horizontal alignment within text column or text frame

keyword

Left Center Right Inside Outside

can be one of:

See page 74

Vertical placement of table within text column

keyword

Anywhere Float ColumnTop PageTop LPageTop RPageTop

can be one of:

<TblBlockSize integer

<TblCellMargins

L T R B

<TblTitlePlacement

<TblTitlePgf1

<PgfTag

tagstring

<Pgf…>

<TblTitleGap

<TblNumByColumn

Ruling properties

<TblColumnRuling

dimension

boolean

tagstring

keyword

Widow/orphan rows for body rows

Left, top, right, bottom default cell margins

Table title placement

keyword

InHeader InFooter None

Paragraph format of title for a new table created with the table format

Applies format from Paragraph Catalog

Overrides Paragraph Catalog format as needed (see page 61)

End of TblTitlePgf1 statement

Gap between title and top or bottom row

Autonumber paragraphs in cells; Yes numbers down each column and No numbers across each row

Ruling style for most columns; value must match a ruling style name specified in the

can be one of:

RulingCatalog statement

ADOBE FRAMEMAKER 9

MIF Reference

<TblXColumnNum integer

<TblXColumnRuling

<TblBodyRowRuling

<TblXRowRuling

tagstring

<TblRulingPeriod integer

<TblHFRowRuling

<TblSeparatorRuling

<TblLRuling

<TblBRuling

<TblRRuling

<TblTRuling

<TblLastBRuling

Shading properties

<TblHFFill integer

tagstring

boolean

<TblHFColor tagstring

Number of column with a right side that uses the TblXColumnRuling statement

Ruling style for the right side of column TblXColumnNum

Default ruling style for most body rows

Exception ruling style for every nth body row

Number of body rows after which TblXRowRuling should appear

Ruling style between rows in the heading and footing

Ruling style for rule between the last heading row and first body row, and also between the last body row and the first footing row

Left outside table ruling style

Bottom outside table ruling style

Right outside table ruling style

Top outside table ruling style

Yes means draw bottom rule on the last sheet only; No means draw rule on the

bottom of every sheet

Default fill pattern for table heading and footing (see page 106)

Default color for table heading and footing (see page 80)

<TblHFSeparation

integer

<TblBodyFill integer

<TblBodyColor

<TblBodySeparation

<TblShadeByColumn

tagstr

integer

boolean

<TblShadePeriod integer

<TblXFill integer

<TblXColor tagstring

<TblXSeparation

<TblAltShadePeriod

Column properties

<TblWidth

dimension

integer

<TblColumn

ing

Default color for table heading and footing; no longer used, but written out by FrameMaker for backward-compatibility (see “Color statements” on page 247)

Default fill pattern for body cells (see page 106)

Default color for body cells (see page 80)

Default color for body cells; no longer used, but written out by FrameMaker for backward-compatibility (see “Color statements” on page 247)

Yes specifies column shading; No specifies body row shading

Number of consecutive columns/rows that use TblBodyFill

Exception fill pattern for columns or body rows (see page 106)

Exception color for columns or body rows (see page 80)

Exception color for columns or body rows; no longer used, but written out by FrameMaker for backward-compatibility (see “Color statements” on page 247)

Number of consecutive columns/rows that use TblXFill; exception columns/rows alternate with default body columns/rows to form a repeating pattern

Not generated by FrameMaker, but can be used by filters to determine table width

Each table must have at least one TblColumn statement; a column without a statement uses the format of the rightmost column

ADOBE FRAMEMAKER 9

MIF Reference

<TblColumnNum integer

<TblColumnWidth

dimension

<TblColumnWidthP integer

<TblColumnWidthA

W W

<TblColumnH

<PgfTag

tagstring

<Pgf…>

<TblColumnBody

<PgfTag

tagstring

<Pgf…>

<TblColumnF

<PgfTag

tagstring

Column number; columns are numbered from left to right starting at 0

Width of column. See page 78

Not generated by FrameMaker, but a temporary column width when filtering proportionally-spaced tables from another application; converted to a fixed width when read in (see page 78)

Not generated by FrameMaker, but a width based on a cell width, for filters only; converted into a fixed width when read in. First value is minimum width; second value is maximum width. Values limit the range of a computed column width, and are usually set to a wide range (see page 78).

Default paragraph format for the column’s heading cells in new tables

Applies format from Paragraph Catalog

Overrides Paragraph Catalog format as needed (see page 61)

End of TblColumnH statement

Default paragraph format for the column’s body cells in new tables

Applies format from Paragraph Catalog

Overrides Paragraph Catalog format as needed (see page 61)

End of TblColumnBody statement

Default paragraph format for the column’s footing cells in new tables

Applies format from Paragraph Catalog

<Pgf…>

<TblColumn…>

…

New table properties

<TblInitNumColumns integer

<TblInitNumHRows

<TblInitNumBodyRows

integer

<TblInitNumFRows integer

Miscellaneous properties

<TblLocked

boolean

Overrides Paragraph Catalog format as needed (see page 61)

End of TblColumnF statement

End of TblColumn statement

More TblColumn statements as needed, one per column

Number of columns for new table

Number of heading rows for new table

Number of body rows for new tables

Number of footing rows for new tables

Yes means the table is part of a text inset th at obtains its formatting properties

from the source document

End of TblFormat statement

ADOBE FRAMEMAKER 9

MIF Reference

Usage

The basic properties, ruling properties, and shading properties correspond to settings in the Table Designer. The

tagstring

in the

TblBodyColor) must match a color tag defined in the ColorCatalog statement (see page 80).

Usage of some of the aspects of the

value specified in any ruling substatement (such as TblColumnRuling) must match a ruling tag defined

RulingCatalog statement (see page 79). The

TblFormat statement is described in the following sections.

tagstring

value specified in any color substatement (such as

Alignment of tables

The horizontal alignment of a table within a text column or text frame is specified by the TblAlignment statement:

• If the table is aligned with the left, center, or right side of a text column or text frame, the TblAlignment

statement is set to

Left, Center, or Right, respectively.

• If the table is aligned with the closer edge or farther edge of a text frame (closer or farther relative to the binding

of the book), the

Locked tables and text insets

TblAlignment statement is set to Inside or Outside, respectively.

The TblLocked statement does not correspond to any setting in the Table Designer. The statement is for text insets that retain formatting information from the source document.

<TblLocked Yes> statement appears in a specific table, that table is part of a text inset that retains formatting

If the information from the source document. The table is not affected by global formatting performed on the document.

<TblLocked No> statement appears in a specific table, that table is not part of a text inset or is part of a text

If the inset that reads formatting information from the current document. The table is affected by global formatting performed on the document.

For details about text insets, see “Text insets (text imported by reference)” on page 130.

Tbls statement

The Tbls statement lists the contents of each table in the document. A document can have only one Tbls statement, which must appear at the top level in the order given in “MIF file layout” on page 52.

Syntax

<Tbls

<Tbl…>

…

Beginning of tables list

Defines a table instance (see “Tbl statement,” next)

Additional statements as needed

End of Tbls statement

Tbl statement

The Tbl statement contains the contents of a table instance. It must appear in a Tbls statement.

Each

Tbl statement is tied to a location in a text flow by the ID number in a TblID statement. Each Tbl statement

has an associated must appear before the statement, and vice versa. For more information about the

ATbl statement within a ParaLine statement that inserts the table in the flow. The Tbl statement

ATbl statement that refers to it. Each Tbl statement can have only one associated ATbl

ATbl statement, see “ParaLine statement” on page 124.

Syntax

<Tbl

ADOBE FRAMEMAKER 9

MIF Reference

<TblID ID

<TblTag

tagstring

<TblFormat…>

Table columns

<TblNumColumns integer

<TblColumnWidth

dimension

…

<EqualizeWidths

<TblColumnNum integer

Table title

<TblTitle

<TblTitleContent

<Notes…>

Table ID number

Applies format from Table Catalog

Overrides Table Catalog format as needed (see page 70)

Number of columns in the table

Width of first column

Width of second column

Width of remaining columns as needed

Makes specified columns the same width as the widest column (for filters only, see page 78)

First column

More columns as needed

End of EqualizeWidths statement

Begin definition of table title

Table title’s content, represented in one or more Para statements

Footnotes for table title (see page 123)

<Para…>

…

Tab le r ows

<TblH

<Row…>

…

<TblBody

<Row…>

…

Title text (see page 124)

Additional statements as needed

End of TblTitleContent statement

End of TblTitle statement

Table heading rows; omit if no table headings

See “Row statement,” next

Additional statements as needed

End of TblH statement

Table body rows

See “Row statement,” next

Additional statements as needed

ADOBE FRAMEMAKER 9

MIF Reference

<TblF

<Row…>

End of TblBody statement

Table footing rows; omit if no table footing

See “Row statement,” next

Additional statements as needed

…

End of TblF statement

End of Tbl statement

Usage

The table column statements specify the actual width of the table instance columns. They override the column widths specified in the

TblFormat statement.

Row statement

A Row statement contains a list of cells. It also includes row properties as needed. The statement must appear in a

Tbl statement.

Syntax

<Row

<Conditional…>

Specifies conditional row (row is unconditional if the statement is omitted)

<RowWithNext

<RowWithPrev

<RowMinHeight

<RowMaxHeight

<RowHeight

dimension

<RowPlacement

<Cell…>

boolean

dimension

keyword

Keep with next body row

Keep with previous body row

Minimum row height

Maximum row height

Row height

Row placement

keyword

Anywhere ColumnTop LPageTop RPageTop PageTop

Each Row statement contains one Cell statement for each column (see “Cell statement,” next)

Additional statements as needed

can be one of:

…

End of Row statement

Usage

Each Row statement contains a Cell statement for each column in the table, even if a straddle hides a cell. Extra Cell statements are ignored; too few

Cell statements result in empty cells in the rightmost columns of the row.

ADOBE FRAMEMAKER 9

MIF Reference

When you rotate a cell to a vertical orientation, the width of unwrapped text affects the height of the row. You can

RowMaxHeight and RowMinHeight to protect a row’s height from extremes caused by rotating cells containing

use multiline paragraphs, or to enforce a uniform height for the rows.

FrameMaker writes out the

RowHeight statement for use by other programs. It is not used by the MIF interpreter.

Even if the statement is present, the MIF interpreter recalculates the height of each row based on the row contents and the

RowMinHeight and RowMaxHeight statements.

Cell statement

A Cell statement specifies a cell’s contents. It also includes format, straddle, and rotation information as needed. The statement must appear in a

Syntax

<Cell

Row statement.

<CellFill integer

<CellColor tagstring

<CellSeparation

<CellLRuling

<CellBRuling

<CellRRuling

<CellTRuling

<CellColumns integer

<CellRows integer

integer

tagstring

<CellAffectsColumnWidthA

<CellAngle

degrees

<CellContent

<Notes…>

<Para…>

boolean

Fill pattern for cell, 0–15 (see page 106)

Color for cell (see “ColorCatalog statement” on page 80)

Color for cell; no longer used, but written out by FrameMaker for backward-compatibility (see “Color statements” on page 247)

Left edge ruling style (from Ruling Catalog)

Bottom edge ruling style

Right edge ruling style

Top edge ruling style

Number of columns in a straddle cell

Number of rows in a straddle cell

Yes restricts column width to cell width

Angle of rotation in degrees: 0, 90, 180, or 270

Cell’s content

Footnotes for cell (see page 123)

Cell’s content, represented in one or more Para statements (see page 124)

Additional statements as needed

…

End of CellContent statement

End of Cell statement

Usage

You can use the Rotate command on the Graphics menu to change the CellAngle, but it does not affect the location of cell margins. 270 degrees, use information about aligning text in a cell, see

CellAngle affects only the orientation and alignment of the text flow. When CellAngle is 90 or

PgfCellAlignment to move vertically oriented text closer to or farther from a column edge. For

PgfCellAlignment on page 64.

ADOBE FRAMEMAKER 9

PTotal

----------------- -

PWidth×

MIF Reference

MIF uses CellAffectsColumnWidthA only with the TblColumnWidthA statement. The MIF default for computing a cell’s width is

TblColumnWidthA. However, if any cells in the column have <CellAffectsColumnWidthA Yes>,

then only those cells affect the computed column width.

Usage of MIF statements to calculate the width of a column is described in the following sections.

Determining table width

When FrameMaker writes MIF files, it uses TblColumnWidth in the Tbl statement to specify column width. However, filters that generate MIF files can use other statements to determine the table width.

This method Uses these statements To do this

Fixed width

Shrink-wrap

Restricted

Proportional

Equalized

TblColumnWidth

TblColumnWidthA

TblColumnWidthA and CellAf-

fectsColumnWidthA

TblColumnWidthP

EqualizeWidths and TblCol-

umnNum

Give a fixed value for column’s width (see page 73)

Fit a column within minimum and maximum values (see page 73)

Use particular cells to determine column width (see page 77)

Create a temporary value for a column width when filtering proportional-width columns from another application; the MIF interpreter converts the value to a fixed width (see page 73 and “Calculating proportional-width columns,” next)

Apply the width of the widest column to specified columns in the same table (see page 75)

The table example in “Creating an entire table” on page 226 shows several ways to determine column width.

Calculating proportional-width columns

MIF uses this formula to calculate the width of proportional-width columns::

The arguments have the following values:

Value of TblColumnWidthP

PT otal

Sum of the values for all TblColumnWidthP statements in the table

PWidth Available space for all proportional columns (TblWidth – the sum of fixed-width columns)

For example, suppose you want a four-column table to be 7 inches wide, but only the last three columns to have proportional width.

• The columns have the following widths:

Column 1 has a fixed-width value of 1":

Column 2 has a proportional value of 2: <TblColumnWidthP 2>

Column 3 has a proportional value of 1: <TblColumnWidthP 1>

Column 4 has a proportional value of 1: <TblColumnWidthP 1>

• Available width for proportional columns

• Sum of all proportional values

• Width for Column 2 is (2/

(PTotal)

PTotal

) x

(PWidth)

is 2 + 1 + 1 or 4.

PWidth

= (2/4) x 6" or 3".

is 7" – 1" or 6".

ADOBE FRAMEMAKER 9

MIF Reference

• Width for Column 3 or Column 4 is (1/

PTotal

) x

PWidth

= (1/4) x 6" or 1.5".

RulingCatalog statement

The RulingCatalog statement defines the contents of the Ruling Catalog, which describes ruling styles for tables. A document can have only one

RulingCatalog statement, which must appear at the top level in the order given in

“MIF file layout” on page 52.

Syntax

<RulingCatalog

<Ruling…>

…

Defines ruling style (see “Ruling statement” on page 79)

Additional statements as needed

End of RulingCatalog statement

Ruling statement

The Ruling statement defines the ruling styles used in table formats. It must appear within the RulingCatalog statement.

Syntax

<Ruling

<RulingTag

<RulingPenWidth

<RulingGap

<RulingColor tagstring

<RulingSeparation

<RulingPen integer

<RulingLines integer

tagstring

dimension

integer

Ruling style name; an empty string indicates no ruling style

Ruling line thickness

Gap between double ruling lines

Color of ruling line (see “ColorCatalog statement” on page 80)

Color of ruling line; no longer used, but written out by FrameMaker for backward-compatibility (see “Color statements” on page 247)

Pen pattern 0 through 7, or 15 (see page 106)

0 (none), 1 (single), or 2 (double) ruling lines

End of Ruling statement

Color

You can assign colors to text and objects in a FrameMaker document. A FrameMaker document has a set of default colors; you can also define your own colors and store them in the document’s Color Catalog. A FrameMaker document has three color models you can use to create colors: CMYK, RGB, and HLS. You can also choose inks from installed color libraries such as PANTONE

In a MIF file, colors are defined by a Color statement within a ColorCatalog statement. Regardless of the color model used to define a new color, colors are stored in a MIF file in CMYK.

ADOBE FRAMEMAKER 9

MIF Reference

You can define a color as a tint of an existing color. Tints are colors that are mixed with white. A tint is expressed by the percentage of the base color that is printed or displayed. A tint of 100% is equivalent to the pure base color, and a tint of 0% is equivalent to no color at all.

You can specify overprinting for a color. However, if overprinting is set for a graphic object, the object’s setting takes precedence. When a graphic object has no overprint statement, the overprint setting for the color is assumed.

You can set up color views to specify which colors are visible in a document. The color views for a document are specified in the

Views statement. The current view for the document is identified in a DCurrentView statement.

The color of a FrameMaker document object is expressed in a property statement for that object. In this manual, the syntax description of a FrameMaker document object that can have a color property includes the appropriate color property substatement.

ColorCatalog statement

The ColorCatalog statement defines the contents of the Color Catalog. A document can have only one Color-

Catalog

FrameMaker 9 automatically generates new colors while specific operations are performed. For example, FrameMaker generates new colors when multiple conditional tags are applied to text. These colors are identified by their

statement, which must appear at the top level in the order given in “MIF file layout” on page 52.

ColorTag, which contains the prefix “fm_gen_”.

Syntax

<ColorCatalog

<Color…>

…

Defines a color (see “Color statement,” next)

Additional statements as needed

End of ColorCatalog statement

Color statement

The Color statement defines a color. It must appear within the ColorCatalog statement. Note that MIF version

5.5 and later supports multiple color libraries. The

FamilyName

Syntax

<Color

<ColorTag

<ColorCyan

<ColorMagenta

<ColorYellow

and ColorInkName statements.

tagstring

percentage

ColorPantoneValue statement has been replaced by the Color-

Color tag name

Percentage of cyan (0–100)

Percentage of magenta (0–100)

Percentage of yellow (0–100)

<ColorBlack

percentage

Percentage of black (0–100)

Color library name

ADOBE FRAMEMAKER 9

MIF Reference

<ColorLibraryInkName

<ColorAttribute

string

keyword

<ColorTintBaseColor string

Specifies name of the color library pigment. Older versions of MIF that use ColorPantoneValue can still be read into MIF 5.5 and later. The full ink name must be used.

Identifies a default FrameMaker document color

keyword

ColorIsBlack ColorIsWhite ColorIsRed ColorIsGreen ColorIsBlue ColorIsCyan ColorIsMagenta ColorIsYellow ColorIsDarkGrey ColorIsPaleGreen ColorIsForestGreen ColorIsRoyalBlue ColorIsMauve ColorIsLightSalmon ColorIsOlive ColorIsSalmon ColorIsReserved

100% indicates solid color; less than 100% indicates a reduced percentage of the color

The name of the color from which the tint is derived. If the base color does not exist in the document, black will be used.

Yes indicates overprint is set for the color; No indicates knockout.

can be one of:

End of Color statement

Usage

In a MIF file, all colors are expressed as a mixture of cyan, magenta, yellow, and black. The ColorAttribute statement identifies a default FrameMaker document color; the default colors are all reserved (specified by the

ColorIsReserved keyword) and cannot be modified or deleted by the user. A reserved default color can have two ColorAttribute statements, for example:

A color tint must be based on an existing color. This has two implications:

• If the base color doesn’t exist in the document, black is used as the base color for the tint.

• The color value statements (values for CMYK, color family, and ink name) are ignored when included in a tint

statement. However, FrameMaker writes out color value statements for a tint, even though they will be ignored. To modify the color values of a tint, modify the color value statements for the base color used by the tint.

Views statement

The Views statement contains the color views for the document. A document can have only one Views statement, which must appear at the top level in the order given in “MIF file layout” on page 52.

Syntax

<Views

ADOBE FRAMEMAKER 9

MIF Reference

<View…>

…

Defines a color view (see “View statement,” next)

Additional statements as needed

End of Views statement

View statement

For each color view, the View statement specifies which colors will be displayed, which will be displayed as cutouts, and which will not be displayed at all. The

Syntax

<View

<ViewNumber integer

<ViewCutout

<ViewCutout…>

…

<ViewInvisible

<ViewInvisible…>

tagstring

View statement must appear in a Views statement.

View number (1–6)

Name of color to print as cutout separation

Additional statements as needed

Name of color to hide

Additional statements as needed

…

End of View statement

Variables

All variable definitions for a document are contained in a VariableFormats statement. Both user-defined and system-defined variables are defined by a variable name shows where the variable appears in text (see “ParaLine statement” on page 124).

VariableFormats and VariableFormat statements

The VariableFormats statement defines document variables to be used in document text flows. A MIF file can have only one

layout” on page 52.

VariableFormat statement supplies a variable name and its definition. The statement must appear in a

Each

VariableFormats statement.

VariableFormats statement, which must appear at the top level in the order given in “MIF file

VariableFormat statement. A Variable statement that refers to the

Syntax

<VariableFormats

<VariableFormat

ADOBE FRAMEMAKER 9

MIF Reference

<VariableName

<VariableDef

<VariableFormat…>

…

tagstring

string

Name of variable

Variable definition

End of VariableFormat statement

Additional statements as needed

End of VariableFormats statement

Usage

VariableName contains the name of the variable, used later in the MIF file by Variable to position the variable in

VariableDef contains the variable’s definition. A system-defined variable definition consists of a sequence of

text. building blocks, text, and character formats. A user-defined variable consists of text and character formats only.

The system variables for the current page number and running headers and footers can only appear on a master page in an untagged text flow. You cannot insert any variables in a tagged text flow on a master page. You can insert variables anywhere else in a text flow.

For more information about variables and the building blocks they can contain, see your user’s manual or the online Help system.

Cross-references

A FrameMaker document can contain cross-references that refer to other portions of the document or to other documents. A cross-reference has a marker that indicates the source (where the cross-reference points) and a format that determines the text and its formatting in the cross-reference.

All cross-reference formats in a document are contained in one is defined by an

XRefFormat statement. Within text, an XRef statement and a Marker statement indicate where each

XRefFormats statement. A cross-reference format

cross-reference appears.

XRefFormats and XRefFormat statements

The XRefFormats statement defines the formats of cross-references to be used in document text flows. A MIF file can have only one

on page 52.

XRefFormat statement supplies a cross-reference format name and its definition. The statement must appear

The

XRefFormats statement.

in an

Syntax

<XRefFormats

<XRefFormat

XRefFormats statement, which must appear at the top level in the order given in “MIF file layout”

ADOBE FRAMEMAKER 9

MIF Reference

<XRefName

<XRefDef

<XRefFormat…>

…

string

Cross-reference name

Cross-reference definition

End of XRefFormat statement

More cross-reference definitions as needed

End of XRefFormats statement

Usage

XRefName supplies the cross-reference format name, which is used later by the XRef statement to apply a format to

the text of the cross-reference. The

XRefDef statement supplies the cross-reference format definition, which is a

string that contains text and cross-reference building blocks.

For more information about cross-references and their building blocks, see your user’s manual or the online Help system.

Global document properties

A FrameMaker document has properties that specify the document page size, pagination style, view options, current user preferences, and other global document information. The user sets these properties by using various commands, such as the Document command, the View command, the Normal Page Layout command, and others.

In a MIF file, global document properties are specified as substatements in a provide these property statements, the MIF interpreter assumes the properties specified in information on defaults specified in templates, see page 3.

The

BookComponent statement specifies setup information for files generated from the document. The Dictionary

)

statement contains the user’s list of allowed words for the document.

Document statement. If you do not

NewTemplate. (For

Document statement

The Document statement defines global document properties. A document can have only one Document statement, which must appear at the top level in the order given in “MIF file layout” on page 52.

Document statement does not need any of these property substatements, which can occur in any order. It can also

A contain additional substatements describing standard equation formats. (See , “MIF Equation Statements.”)

Document File Info

For versions 7.0 and later, FrameMaker stores file information in packets (XMP) of encoded data. This data can be used by applications that support XMP. In MIF these data packets are expressed in the <DocFileInfo> statement. This data is generated by FrameMaker in an encoded form, and you should not edit the information. Note that this information corresponds to the values of fields in the File Info dialog box. It also corresponds to the data in the

<PDFDocInfo> statement. However, unlike <PDFDocInfo>, this XMP data also includes the values of the File Info

dialog box default fields for

Creator, Creation Date, and MetaData Date.

ADOBE FRAMEMAKER 9

MIF Reference

PDF Document Info

For versions 6.0 and later, FrameMaker stores PDF File Info in the document file. FrameMaker automatically supplies values for Creator, Creation Date and Metadata Date; these Document Info fields do not appear in MIF statements for PDF Document Info. However, a user can use the File Info dialog box to specify values for Author, Title, Subject, Keywords, Copyright, Web Statement, Job Reference, and Marked. The values for all these values appear in PDF Document Info. A document can also contain arbitrary Document Info fields if they have been entered via an FDK client or by editing a MIF file. In MIF, each Document Info entry consists of one and at least one

Key statement contains a string of up to 255 ASCII characters. The Key names a File Info field; in PDF the field

name can be up to 126 characters long. In MIF you represent non-printable characters via hexadecimal representation of a character, and to represent the “#” character. Zero-value hex-codes (

Value statement.

#HH, where # identifies a

HH is the hexadecimal value for the character. For example, use #23

#00) are illegal. In PDF, these hexadecimal representations are

Key statement

interpreted as PDFDocEncoding (see Portable Document Format Reference Manual, Addison-Wesley, ISBN 0-20162628-4).

Note that a a File Info field name can be up to 126 characters long, and a MIF string can contain up to 255 characters. Some characters in the key string may be hexadecimal representations, and each hexadecimal representation uses three ASCII characters. For example, a However, since a valid MIF string can only have up to 255 ASCII characters, such a

Key of 126 non-printing characters would require 378 ASCII characters.

Key statement would be invalid

in MIF.

The contents of the File Info field is represented by a series of

Value statements. Each value statement can contain

a string of up to 255 ASCII characters. In PDF the File Info contents can contain up to 32765 Unicode characters. To accommodate this number of Unicode characters, FrameMaker generates MIF in the following ways:

• It represents the Document Info contents as a series of Value statements, each one 255 ASCII characters long,

or less.

• It uses special codes to indicate Unicode characters that are outside the standard ASCII range. Mif represents

Unicode characters as

HHHH are as many hexadecimal values as are required to represent the character.

and

&#xHHHH;, where &#x opens the character code, the “;” character closes the character code,

Note that each Unicode representation of a character uses up to seven ASCII characters. For example, a string of 255 Unicode characters could require as many as 1785 ASCII characters.

For example, The following MIF statements show three possible Document Info fields:

<PDFDocInfo

> # end of PDFDocInfo

Syntax

<Document

Window properties

Document properties

Refers to the next object with a <Unique ated by FrameMaker and should not be used by filters

> statement; gener-

ADOBE FRAMEMAKER 9

MIF Reference

<DViewRect

X Y W H

<DViewScale

Column properties

<DMargins

<DColumns integer

<DColumnGap

<DPageSize

Pagination

percentage

L T R B

dimension

W H

<DStartPage integer

<DPageNumStyle

keyword

Position and size of document window based on position and size of the document region within containing window; DViewRect takes precedence over DWindowRect

Position and size of document window based on the containing window (including the title bar, etc.)

Current zoom setting

Not generated by FrameMaker, but used by filters to specify text margins; ignored unless DColumns is specified

Not generated by FrameMaker, but used by filters to specify number of columns

Not generated by FrameMaker, but used by filters to specify column gap

Document’s default page size and orientation; if W is less than H, the document’s orientation is portrait; otherwise it is landscape

Starting page number

Page numbering style

keyword

Arabic UCRoman LCRoman UCAlpha LCAlpha ZenLCAlpha ZenUCAlpha KanjiNumeric KanjiKazu BusinessKazu

can be one of:

<DPagePointStyle

<DTwoSides

<DParity

<DPageRounding

boolean

keyword

Point page number style

keyword

Arabic UCRoman LCRoman UCAlpha LCAlpha

Yes specifies two-sided layout

Specifies whether first page is left or right page

keyword

FirstLeft FirstRight

Method for removing blank pages or modifying total page count before saving or printing

keyword

DeleteEmptyPages MakePageCountEven MakePageCountOdd DontChangePageCount

can be one of:

ADOBE FRAMEMAKER 9

MIF Reference

<DFrozenPages

Document format properties

<DSmartQuotesOn

<DSmartSpacesOn

<DLinebreakChars

boolean

string

<DPunctuationChars

Conditional text defaults

<DShowAllConditions

<DDisplayOverrides

Footnote properties

<DFNoteTag

<DFNoteMaxH

<DFNoteRestart

string

dimension

keyword

<FNoteStartNum integer

string

boolean

Yes if Freeze Pagination is on

Use curved left and right quotation marks

Prevents entry of multiple spaces

OK to break lines at these characters

Punctuation characters that FrameMaker does not strip from run-in heads; these characters override the default punctuation set in

PgfRunInDefaultPunct (see page 63)

Shows or hides all conditional text

Turns format indicators of conditional text on or off

Paragraph and reference frame tag for document footnotes

Maximum height allowed for document footnotes

Document footnote numbering control by page or text flow

keyword

PerPage PerFlow

First document footnote number

can be one of:

<DFNoteNumStyle

<DFNoteLabels

<DFNoteAnchorPos

<DFNoteNumberPos

keyword

string

keyword

<DFNoteAnchorPrefix

string

Document footnote numbering style

keyword

Arabic UCRoman LCRoman UCAlpha LCAlpha ZenLCAlpha ZenUCAlpha KanjiNumeric KanjiKazu BusinessKazu Custom

Characters to use in custom document footnote numbers

Placement of document footnote number in text

keyword

FNSuperscript FNBaseline FNSubscript

Placement of number in document footnote

keyword

FNSuperscript FNBaseline FNSubscript

Prefix before document footnote number in text

can be one of:

ADOBE FRAMEMAKER 9

MIF Reference

<DFNoteAnchorSuffix

<DFNoteNumberPrefix

<DFNoteNumberSuffix

Table footnote properties

<DTblFNoteTag

<DTblFNoteLabels

<DTblFNoteNumStyle

string

keyword

<DTblFNoteAnchorPos

<DTblFNoteNumberPos

<DTblFNoteAnchorPrefix

<DTblFNoteAnchorSuffix

<DTblFNoteNumberPrefix

<DTblFNoteNumberSuffix

Change bar properties

<DChBarGap

<DChBarWidth

dimension

string

keyword

string

Suffix after document footnote number in text

Prefix before number in document footnote

Suffix after number in document footnote

Same meaning for the following statements as the corresponding document footnote properties

Change bar distance from column

Thickness of change bar

<DChBarPosition

<DChBarColor

<DAutoChBars

Document view properties

<DGridOn

<DPageGrid

<DSnapGrid

tagstring

boolean

dimension

<DSnapRotation

<DRulersOn

<DFullRulers

<DBordersOn

<DSymbolsOn

<DGraphicsOff

boolean

keyword

degrees

Position of change bar

keyword

LeftOfCol RightOfCol NearestEdge FurthestEdge

Change bar color (see “ColorCatalog statement” on page 80)

Turns automatic change bars on or off

Turns on page grid upon opening

Spacing of page grid

Spacing of snap grid

Angle of rotation snap

Turns on rulers upon opening

Turns on formatting ruler upon opening

Turns on borders upon opening

Turns on text symbols upon opening

Yes displays text only

can be one of:

ADOBE FRAMEMAKER 9

MIF Reference

<DPageScrolling

keyword

<DCurrentView integer

View Only document properties

<DViewOnly

<DViewOnlyXRef

<DViewOnlySelect

<DViewOnlyNoOp 0x

boolean

keyword

nnn

Specifies how FrameMaker displays consecutive pages

keyword

Variable Horizontal Vertical Facing

Specifies current color view (1-6)

Yes specifies View Only document (locked)

Changes behavior of active cross-references in View Only document (see page 46)

keyword

GotoBehavior OpenBehavior NotActive

Disables/enables user selection in View Only document, including selection with modifier keys, and sets highlighting style of destination markers for active cross-references (see “Using active cross-refer-

ences” on page 46)

keyword

No (disable user selection) Yes (enable user selection and highlighting) UserOnly (enable selection but not highlighting)

Disables a command in a View Only document; command is specified by hex function code (see page 47)

can be one of:

<DViewOnlyWinBorders

<DViewOnlyWinMenubar

<DViewOnlyWinPopup

<DViewOnlyWinPalette

Document default language

<DLanguage

Color printing

keyword

<DNoPrintSepColor

<DPrintProcessColor

<DPrintSeparations

boolean

tagstring

boolean

No suppresses display of scroll bars and border buttons in document

window of View Only document

No suppresses display of document window menu bar in View Only

document

No suppresses display of document-region pop-up menus in View

Only document

The dotted boundary line of a document is the document-region.

Yes makes window behave as command palette window in View

Only document

The FrameMaker console is the Command palette window.

Hyphenation and spell-checking language for text lines; for allowed keywords, see

Tag name of color not to print; any color not included here is printed. If you have multiple colors you don’t want to print, use multipl e statements.

Tag name of process color to print as separation

Yes prints separations

PgfLanguage on page 64

ADOBE FRAMEMAKER 9

MIF Reference

<DTrapwiseCompatibility

<DPrintSkipBlankPages

Superscripts and subscripts

boolean

<DSuperscriptSize percent

<DSubscriptSize percent

<DSmallCapsSize percent

<DSuperscriptShift percent

<DSubscriptShift percent

<DSuperscriptStretch percent

<DSubscriptStretch percent

<DSmallCapsStretch percent

<DRubiSize

percentage

When printing to a PostScript file, Yes generates postscript optimized for use with the TrapWise application

Yes skips blank pages when printing

Scaling factor for superscripts expressed as percentage of the current font size

Scaling factor for subscripts expressed as percentage of current font size

Scaling factor for small caps expressed as percentage of current font size

Baseline offset of superscripts expressed as percentage of current font size

Baseline offset of subscripts expressed as percentage of current font size

Amount to stretch or compress superscript, where 100% means no change

Amount to stretch or compress subscript, where 100% means no change

Amount to stretch or compress small caps, where 100% means no change

The size of the rubi characters, proporti onal to the size of the oyamoji characters (see “Rubi text” on page 215.)

Reference properties

<DUpdateXRefsOnOpen boolean

<DUpdateTextInsetsOnOpen boolean

Acrobat preferences

<DAcrobatBookmarksIncludeTagNames

boolean

<DGenerateAcrobatInfo

Document-specific menu bars

<DMenuBar string

<DVoMenuBar string

Math properties For more information, see , “MIF Equation Statements.”

Structure properties For more information, see , “MIF Statements for Structured Docu-

Track Text Edit properties

boolean

Yes specifies that cross-references are automatically updated when

the document is opened

Yes specifies that text insets are automatically updated when the

document is opened

Yes specifies that each Acrobat Bookmark title begi ns with the name

of the paragraph tag

Yes sets the document’s print options to their required states for

generating Acrobat information

Name of the menu bar displayed by an FDK client when the document is opened; if an empty string is specified or if the menu bar is not found, the standard FrameMaker menu bar is used

Name of the menu bar displayed by an FDK client when the document is opened in View Only mode; if an empty string is specified or if the menu bar is not found, the standard view-only menu bar is used

ments and Books.”

ADOBE FRAMEMAKER 9

MIF Reference

Preserves the On/Off state of the Track Text Edit option.

Preserves the preview state of edited text.

DTrackChangesPreviewState property can have one of the

following states:

• Preview Off: DTrackChangesPreviewState set with

the value No.

• Preview On Final: DTrackChangesPreviewState set

with the value All.

• Preview On Original: DTrackChangesPreviewState

set with the value Yes.

WebDAV properties

<WEBDAV

<DocServerUrl

string

> URL of the MIF document on the WEBDAV Server. Any HTTP path is

valid.

Example:

#http://mikej-xp/joewebdav is the path of the server.

<DocServerState> Indicates whether the MIF document is che cked in or checked out on

the WebDAV server.

The DocServerState property can contain one of the following values:

• CheckedOut

• CheckedIn

> End of WEBDAV Document statement

Miscellaneous properties

<DMagicMarker integer

<Document Document properties

<DNextUnique ID> Refers to the next object with a

Window properties

<DViewRect X Y W H> Position and size of document window based on position and size of

<DWindowRect X Y W H> Position and size of document window based on the containing

<DViewScale percentage> Current zoom setting

Column properties

<DMargins L T R B> Not generated by FrameMaker, but used by filters to specify text

Type number of the marker used to represent a delete mark

<Unique ID> statement; gener-

ated by FrameMaker and should not be used by filters

the document region within containing window ; DViewRect takes precedence over DWindowRect

window (including the title bar, etc.)

margins; ignored unless DColumns is specified

ADOBE FRAMEMAKER 9

MIF Reference

<DColumns integer> Not generated by FrameMaker, but used by filters to specify number

<DColumnGap dimension> Not generated by FrameMaker, but used by filters to specify column

<DPageSize W H> Document’s default page size and orientation; if W is less than H, the

Volume, chapter, and page numbering properties

Volume numbering

<VolumeNumStart integer> Starting volume number

<VolumeNumStyle keyword> Style of volume numbering

of columns

gap

document’s orientation is portrait; otherwise it is landscape

keyword

can be one of:

Arabic UCRoman LCRoman UCAlpha LCAlpha KanjiNumeric ZenArabic ZenUCAlpha ZenLCAlpha Kanjikazu BusinessKazu Custom

<VolumeNumText string> When VolumeNumStyle is set to Custom, this is the string to use

<VolNumComputeMethod keyword> Volume numbering

keyword

can be one of:

StartNumbering (restart numbering) ContinueNumbering (continue numbering from previous

document in book)

UseSameNumbering (use the same numbering as previous docu-

ment in book)

Chapter numbering

<ChapterNumStart integer> Starting chapter number

<ChapterNumStyle keyword> Style of chapter numbering

keyword

can be one of:

Arabic UCRoman LCRoman UCAlpha LCAlpha KanjiNumeric ZenArabic ZenUCAlpha ZenLCAlpha Kanjikazu BusinessKazu Custom

<ChapterNumText string> When ChapterNumStyle is set to Custom, this is the string to

use

<ChapterNumComputeMethod keyword> Chapter numbering

keyword

can be one of:

StartNumbering (restart numbering) ContinueNumbering (continue numbering from previous

document in book)

UseSameNumbering (use the same numbering as previous docu-

ment in book)

Section numbering

ADOBE FRAMEMAKER 9

MIF Reference

Starting section number

Style of section numbering

keyword

can be one of:

Arabic UCRoman LCRoman UCAlpha LCAlpha KanjiNumeric ZenArabic ZenUCAlpha ZenLCAlpha Kanjikazu BusinessKazu Custom

When SectionNumStyle is set to Custom, this is the string to use

Section numbering

keyword

can be one of:

StartNumbering (restart numbering) ContinueNumbering (continue numbering from previous

component)

UseSameNumbering (use the same numbering as previous

component)

ReadFromFile (use numbering set for the component’s docu-

ment)

Sub section numbering

Starting Sub section number

Style of Sub section numbering

keyword can be one of:

Arabic UCRoman LCRoman UCAlpha LCAlpha KanjiNumeric ZenArabic ZenUCAlpha ZenLCAlpha Kanjikazu BusinessKazu Custom

When SubSectionNumStyle is set to Custom, this is the string to use

ADOBE FRAMEMAKER 9

MIF Reference

Sub section numbering

keyword can be one of:

StartNumbering (restart numbering) ContinueNumbering (continue numbering from previous

component)

UseSameNumbering (use the same numbering as previous

component)

ReadFromFile (use numbering set for the component’s docu-

ment)

Page numbering

<DPageNumStyle keyword> Page numbering style

keyword

can be one of:

Arabic UCRoman LCRoman UCAlpha LCAlpha ZenLCAlpha ZenUCAlpha KanjiNumeric KanjiKazu BusinessKazu

<DPagePointStyle keyword> Point page number style

keyword

can be one of:

Arabic UCRoman LCRoman UCAlpha LCAlpha

<DStartPage integer> Starting page number

<ContPageNum boolean> Yes means continue page numbering from the previous document

Pagination

<DTwoSides boolean> Yes specifies two-sided layout

<DParity keyword> Specifies whether first page is left or right page

in the book

keyword

can be one of:

FirstLeft FirstRight

<DPageRounding keyword> Method for removing blank pages or modifying total page count

before saving or printing

keyword

can be one of:

DeleteEmptyPages MakePageCountEven MakePageCountOdd DontChangePageCount

<DFrozenPages boolean> Yes if Freeze Pagination is on

Document format properties

<DSmartQuotesOn boolean> Use curved left and right quotation marks

<DSmartSpacesOn boolean> Prevents entry of multiple spaces

<DLinebreakChars string> OK to break lines at these characters

ADOBE FRAMEMAKER 9

MIF Reference

<DPunctuationChars string> Punctuation characters that FrameMaker does not strip from run-in

heads; these characters override the default punctuation set in

PgfRunInDefaultPunct (see page 63)

Conditional text defaults

<DShowAllConditions boolean> Shows or hides all conditional text

<DDisplayOverrides boolean> Turns format indicators of conditional text on or off

Footnote properties

<DFNoteTag string> Paragraph and reference frame tag for document footnotes

<DFNoteMaxH dimension> Maximum height allowed for document footnotes

<DFNoteRestart keyword> Document footnote numbering control by page or text flow

keyword

can be one of:

PerPage PerFlow

<FNoteStartNum integer> First document footnote number

<DFNoteNumStyle keyword> Document footnote numbering style

keyword

can be one of:

Arabic UCRoman LCRoman UCAlpha LCAlpha ZenLCAlpha ZenUCAlpha KanjiNumeric KanjiKazu BusinessKazu Custom

<DFNoteLabels string> Characters to use in custom document footnote numbers

<DFNoteComputeMethod keyword> Footnote numbering

keyword

can be one of:

Continue (continue numbering from previous component in

book)

Restart (restart numbering)

<DFNoteAnchorPos keyword> Placement of document footnote number in text

keyword

ΦΝΣυπερσχριπτ ΦΝΒασελινε ΦΝΣυβσχριπτ

<DFNoteNumberPos keyword> Placement of number in document footnote

keyword

can be one of:

FNSuperscript FNBaseline FNSubscript

<DFNoteAnchorPrefix string> Prefix before document footnote number in text

<DFNoteAnchorSuffix string> Suffix after document footnote number in text

Macromedia FrameMaker - 9.0 User Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Contents

Chapter 1: Introduction

Why use MIF?

Using this manual

Style conventions

Overview of MIF statements

How MIF statements represent documents

FrameMaker documents have default objects

Current state and inheritance

How FrameMaker identifies MIF files

MIF statement syntax

Statement hierarchy

MIF data items

Unit values

Character set in strings

Device-independent pathnames

Chapter 2: Using MIF Statements

Working with MIF files

Opening and saving MIF files

Importing MIF files

Editing MIF files

MIF file layout

Creating a simple MIF file for FrameMaker

Creating and applying paragraph formats

Creating a paragraph

Creating a paragraph format

Adding a Paragraph Catalog

Applying a paragraph format

How paragraphs inherit properties

Tips

Creating and applying character formats

Creating and formatting tables

Creating a table instance

Adding a table anchor

Creating a table format

Adding a Table Catalog

Applying a table format

Creating default paragraph formats for new tables

Tables inherit properties differently

Tips

Specifying page layout

Using the default layout

Creating a simple page layout

Creating a single-sided custom layout

Creating a double-sided custom layout

Creating a first master page

Adding headers and footers

Creating markers

Creating cross-references

Creating cross-reference formats

Inserting the reference source marker

Inserting the reference point

How FrameMaker writes cross-references

Creating variables

Defining user variables

Using system variables

Inserting variables

Creating conditional text

Creating and applying condition tags

Showing and hiding conditional text using Boolean expressions

How FrameMaker writes a conditional document

Creating filters

Including template files

Creating the template

Editing the MIF file

Setting View Only document options

Changing the document window

Using active cross-references

Disabling commands

Applications of MIF

Sharing files with earlier versions

Modifying documents

Writing filters

Database publishing

Debugging MIF files

Other application tools
