Luxman E-1 User Manual

!

E-1

Phono Stage Amplifier

!

The lightning flash with arrowhead,
within an equilateral triangle, is
intended to alert the user to the
presence of uninsulated “dangerous
voltage” within the product’s enclosure
that may be of sufficient magnitude to
constitute a risk of electric shock to

The exclamation point within an
equilateral triangle is intended to
alert the user to the presence of
important operating and
maintenance (servicing) instructions
in the literature accompanying the
appliance.

!

McIntosh Laboratory, Inc. ! Chambers Street Binghamton, New York 13903-2699 Phone: [phone] FAX: [phone]

WARNING - TO REDUCE RISK OF!

FIRE OR ELECTRICAL SHOCK, DO!

NOT EXPOSE THIS EQUIPMENT TO!

RAIN OR MOISTURE.

IMPORTANT SAFETY

INSTRUCTIONS!

PLEASE READ THEM BEFORE

OPERATING THIS EQUIPMENT.

1. Read these instructions.

2. Heed all warnings.

3. Follow all instructions.

4.Do not use this apparatus near water.

5.Clean only with a dry cloth.

6. Do not block any ventilation openings.
Install in accordance with the
manufacturer’s instructions.

7. Do not install near any heat sources
such as radiators, heat registers,
stoves, or other apparatus (including
amplifiers) that produce heat.

8. Protect the power cord from being
walked on or pinched particularly at
plugs, convenience receptacles, and
the point where they exit from the
apparatus.

NO USER-SERVICEABLE PARTS!

INSIDE. REFER SERVICING TO!

QUALIFIED PERSONNEL.

To p r e ve n t t h e r is k of el e ct ri c sh o ck , do no t re m ov e c ov e r o r !

back plate. No user serviceable parts inside.

9. Only use attachments/accessories
specified by the manufacturer.

10. Unplug this apparatus during
lightning storms or when unused for
long periods of time.

11. Refer all servicing to qualified service
personnel. Servicing is required when
the apparatus has been damaged in
any way, such as liquid has been
spilled or objects have fallen into the
apparatus, the apparatus has been
exposed to rain or moisture, does not
operate normally, or has been
dropped.

12. Do not expose this equipment to
dripping or splashing and ensure
that no objects filled with liquids,
such as vases or beverages, are
placed on the equipment.

13. To completely disconnect this
equipment from the AC. mains,
disconnect the power supply cord
plug from the AC socket.

14. The power supply cord should be
kept in good condition, if it gets
chewed up by a pet, it should be
replaced.

!

Thank You

Your decision to purchase this Luxman E-1 Phono Stage Amplifier singles you out as one of the most discriminating
music listeners. Luxman have been hand-crafting exquisite audio reproducing equipment in Japan since 1925.

In terms of performance, we build our products to deliver natural sound that brings spiritual serenity to the listener.
And in aesthetic terms, we stress the interplay of light and shadow, so the Luxman products present a solid,
sculpture-like impression.

Please take a short time to read the information in this manual. We want you to be as familiar as possible with all the
features and functions of your new Luxman.

Important Safety Instructions Page 3
Contents 4
Quick Set Up Chart 5
Front Panel Controls 6
Rear Panel Inputs & Outputs 7
Installation 8
Connection to Other Components 9
Block Diagram 10
Specifications 11
Warranty 12 - 13
Luxman Worldwide Contacts 14.

! 10

Quick Set Up
