2855 North Franklin Road
Indianapolis, IN 46219-1385
Order: Document No. 555-660-116
Comcode: 108136029
Issue 1, February 1998
For assistance when installing or programming the system:
Call: National Service Assistance Center (NSAC) at
1 800 628-2888 or your Lucent Technologies representative
Notice
While reasonable efforts were made to ensure that the information
in this document was complete and accurate at the time of printing,
Lucent Technologies can assume no responsibility for errors.
Changes or corrections to the information in this document may be
incorporated into reissues.
Page 3
Trademarks
MERLIN LEGEND, DEFINITY, 5ESS, ACCUNET, CONVERSANT,
DEFINITY, MERLIN MAIL, MERLIN II, MERLIN Identifier, MLX-5,
MLX-5D, MLX-10, MLX-10D, MLX-10DP, MLX-16DP MLX-20L,
MLX-28D, Magic On Hold, MEGACOM, MultiQuest, MERLIN, and
SYSTIMAX are registered trademarks, and 4ESS, ProLogix,
AUDIX Voice Power, Fax Attendant System, HackerTracker,
PassageWay, Picasso, Lucent Technologies Attendant, MERLIN
PFC, and TransTalk are trademarks of Lucent Technologies in the
U.S. and other countries.
Mirage, StarSet, Supra, and Supra NC are registered trademarks
of Plantronics, Inc.
PagePac is a registered trademark, and Powermate and Zonemate
are trademarks of DRACON, a division of Harris Corp.
Microsoft is a registered trademark and Windows is a trademark of
Microsoft Corporation.
IBM is a registered trademark of International Business Machines,
Inc.
CLASS is a service mark of Bellcore.
NORTEL is a registered trademark and DMS a trademark of
Northern Telecom.
MCI, Prism, and Vnet are registered trademarks of MCI
Communications.
Novell and NetWare are registered trademarks of Novell
Corporation.
Page 4
MERLIN LEGEND Communications System Release 6.0
Pocket Reference
555-660-116
Issue 1
February 1998
Page 4
Page 5
MERLIN LEGEND Communications System Release 6.0
Pocket Reference
Environmental Specifications 26
Power and Grounding 28
Control Unit Interfaces 31
Network Interface Requirements 32
FCC Registration 32
DOC Registration 32
Hardware and Software Capacities 33
Ordering Codes 38
Control Unit Modules 70
Page 6
MERLIN LEGEND Communications System Release 6.0
Pocket Reference
Contents
555-660-116
Adjunct Summary 76
Power Supply Unit Load
Requirements 86
Unit Load Calculation Rules86
Unit Load Rating of System Modules 87
Unit Load Rating of System Trunks,
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Release 1.1 Enhancements
Release 1.1 Enhancements
Refer to
Release 1.1 Notes
enhancements. Release 1.1 includes all Release 1.0 functionality
plus the enhancements described in the following sections.
Language Selection
This selection allows you to program the system for the display of
prompts, menus, and messages on MLX display telephones in
English, French or Spanish. You can also program the following
options in any of these languages, independently of the system
language:
■ Individual extensions with MLX telephones
■ System Programming and Maintenance (SPM)
■ System pro grammi ng reports
■ SMDR report headers
®
MLX-10D
MLX-10
versions, with factory-set buttons in English, Spanish, or French.
(The MLX-10DP
addition, user and operator guides and telephone tray cards are
available in all three languages.
, MLX-20L®, and MLX-28D® display telephones and
®
nondisplay telephones are available in three separate
®
Programming and Ma intenance
Programming and maintenance enhancements include the
following:
■ Additional Inspect capability in system programming
■ Editing capability (Backspace selection) in extension
programming
■ Improvements to system reports
■ An access log that records the last 20 times maintenance or
system programming has been accessed
■ Longer (20-second) gap between ring cycles for programming
mode and Forced Idle tone
Operational
System operational enhancements include the following:
■ Automatic selection of an SA button when Conference is
invoked (Hybrid/PBX mode)
■ Prompting through Conference feature on MLX display
telephones
■ Relocation of the More prompt on the MLX-20L display
telephone
■ Display of the number saved on a programmed Last Number
Dial or Saved Number Dial button when the button is inspected
SPM
SPM enhancements include operation in English, French, or
Spanish; faster backup and restore; and automatic on-screen
display of reports as they are created with a Browse capability for
reading the reports.
for detailed descriptions of Release 1.1
is available in the English version only.) In
Issue 2
January 1998
Page 1
Page 8
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Release 2.0 Enhancements
Equipment
Additional equipment includes the 8102 and 8110 analog
telephones, four headsets, two headset amplifiers, and a
transparent protective cover for the MLX-10 and MLX-10D
telephones. The 8102 and 8110 telephones are also compatible
with Release 1.0.
PF Registration
PF registration number AS5USA-65646-PF-E is assigned by the
FCC for operating the MERLIN LEGEND
System in Hybrid/PBX mode in the United States. (The PF
registration is also applicable to Release 1.0 systems.
®
Communications
Release 2.0 Enhancements
Refer to
Release 2.0 Notes
and later enhancements. Release 2.0 includes all Release 1.1
functionality plus the enhancements listed below.
Programming
Programming enhancements include the following:
■ Extension Copy is a feature that reduces programming time by
allowing the use of any extension as a template for
programming another extension or block of extensions through
centralized telephone programming.
■ Integrated Administration provides a single interface through
Integrated Solutions III (IS III) for programming entries common
to the MERLIN LEGEND Communications System and AUDIX
Voice Power
■ Any SPM Version 2.xx (where xx is replaced by numbers)
provides a Convert function for use in upgrading the system
from Release 1.0 or 1.1 system to Release 2.0 and later format,
allowing reuse of existing system programming on the
upgraded system.
■ Forced Idle reductions keep system interruptions at a minimum.
In general, the smallest necessary component is forced idle
during programming activities. For example, renumbering a
single extension idles only one extension. Only a few systemwide programming activities, such as setting the system mode
and system renumbering, idle the entire system.
™.
Operational
System operational enhancements include the following:
■ Coverage VMS Off is a feature that prevents incoming outside
calls from going to voice mail. (All other coverage remains
active as programmed.) The feature is programmed extension
by extension, either through extension programming or through
centralized telephone programming.
■ A Night Service group can be programmed to include either
extensions or a calling group as members. However, you should
not program both individual extensions and a calling group into
the Night Service group because individuals will not have a
chance to answer before calling group members do.
for detailed descriptions of Release 2.0
Issue 2
January 1998
Page 2
Page 9
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Release 2.0 Enhancements
■ When AUDIX Voice Power sends a Leave Message notification
to an extension, the system identifies the voice mail system as
the sender of the message. When the voice mail subscriber
uses the Return Call feature, the call goes to any available
voice mail port, not just to the specific port that generated the
message. This reduces the chance of getting a busy port.
■ Coverage receivers can call coverage senders and have the call
receive coverage treatment. If a receiver calls a sender for
whom he or she is covering, and the sender is busy or
unavailable, the call proceeds to other points of coverage. It
does not come back to the receiver who originated the call.
■ Enhancements to display prompts include automatic posting of
a
'R1RW'LVWXUE
other multiline telephones, a Posted Message button must be
programmed for the
automatically). When a user activates the Do Not Disturb
feature, and confirmation messages when a user activates
message (for MLX display telephones or
'R1RW'LVWXUE
message to be posted
Hold, Privacy, Saved Number Dial, and Transfer.
■ Direct Inward Dialing (DID) trunk emulation on a T1 facility
provides up to 24 DID channels on a single DS1 interface,
instead of requiring 24 separate physical trunks.
■ A telephone user can send a timed flash (switchhook flash) on a
loop-start trunk call on a System Access (SA) button.
Fax Attendant System™
Fax Attendant is an application for sending and receiving fax
messages; its interface is similar to the voice mail interface
provided by AUDIX Voice Power. Fax Attendant System, which coresides with AUDIX Voice Power on the IS III platform, provides the
following services:
■ Fax Call Coverage. Receives and holds messages for
subscribers whose fax machines are busy or out of paper. this
service also allows a subscriber to have a personal fax number
without having a fax machine.
■ Fax Mail. Allows subscribers to create and use fax distribution
lists, send and receive fax messages, and record personal
greetings for incoming fax calls.
■ Fax Response. Prompts callers to select and receive faxes
from a customer-created menu of choices, using touch-tone
responses.
408 GS/LS-MLX Module
The 408 GS/LS-MLX module (Releases 2.0 and higher only)
combines four line/trunk jacks for ground-start or loop-start trunks
and eight extension jacks for MLX telephones on a single module in
the control unit.
Primary Rate Interface (PRI)
Primary Rate Interface (PRI) enhancements include the following:
■ Connectivity to the 5ESS
■ Multiple Incoming calls to directory number
■ Call-by-Call Service Selection
■ Password handling for FTS2000
■ Extension ID as Calling Party Number for Automatic Number ID
(ANI)
®
Generic 6
Issue 2
January 1998
Page 3
Page 10
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Release 2.1 Enhancements
Maintenance
Maintenance enhancements include the following:
■ Clear descriptions of module test failures
■ Optional printing of hard copy of error logs
■ Display that correlates extension numbers to slot/port and
logical ID
■ Display of the slots, trunks, and extensions that are
maintenance busy
■ Internal digital switching element (DSE) loopback test for all
modules
■ B-channel loopback test for MLX modules
■ B-channel line or call service states display
■ Error log entries for dual-port RAM errors
Release 2.1 Enhancements
Refer to Release 2.1 Notes for detailed descriptions of Release 2.1
enhancements. Release 2.1 includes all Release 2.0 functionality
plus the enhancements listed below.
Operational
System operational enhancements include the following:
■ When a call is forwarded to a multiline telephone that has an
Auto Dial or DSS button programmed for the forwarding
telephone, the green light next to the Auto Dial or DSS button
for the forwarding telephone does not flash.
■ People answering calls received on Cover buttons are allowed
to generate touch tones if their telephones are not outward- or
toll-restricted.
■ Calls received on personal lines with Do Not Disturb on go
immediately to coverage instead of waiting for the coverage
delay interval.
■ A call put on hold at a Cover button can be added to a
conference by someone who has a personal line for the call.
■ A call put on hold at a Cover button can be picked up by any
person who has a personal line for the call.
■ Calls that have been put on hold at a Cover, SA, Shared SA, or
Pool button can be picked up by a person who has a personal
line button for the call.
■ An inside call on hold at an SA button can be picked up and
transferred by any per son with a Shared SA button
corresponding to the button with the held call.
■ Calls that are on hold awaiting transfer can be picked up by any
user who has a personal line for the call.
■ Beginning with Integrated Solution III Version 1.2, the automatic
reconciliation program that was run automatically at 3:00 a.m.
has been disabled and can be invoked manually from the User
Maintenance menu.
■ When a telephone is programmed for Forced Account Code
entry, account codes do not have to be entered when using a
programmed Loudspeaker Paging button. In addition, an SMDR
record is not generated for calls made to paging ports.
Issue 2
January 1998
Page 4
Page 11
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Release 2.1 Enhancements
■ When an MLX telephone, other than an MLX-20L, is plugged
into an MLX port and the Personal Directory does not contain
any entries, the allocation of the Personal Directory resources is
released. If there are any entries in the Personal Directory, the
Personal Directory allocation and the entries in the Personal
Directory are saved in the MLX port.
■ SMDR call records for calls made on PRI facilities are more
accurate than SMDR call records for calls made on non-PRI
facilities. Outgoing calls made on PRI facilities receive “answer
supervision.” Consequently, SMDR timing for calls made on PRI
facilities begins when the call is answered. Timing for calls
made on non-PRI facilities begins when dialing is completed.
Therefore, an SMDR call record is not generated when a call
made on a PRI facility is not answered at the far end.
■ The Call Type field and the Called Number field on the SMDR
report have been changed for both the Basic and ISDN report
formats.
■ An 012 port that is programmed as a generic voice messaging
interface (VMI) port can transfer an outside call to an outside
number.
■ In a system where the transfer audible option is programmed for
Music On Hold and a music source is provided, outside callers
who are transferred to a calling group and are waiting in the
queue or who are parked or camped-on hear music while they
are waiting. Internal callers never hear music on hold while
waiting in the calling group queue or when the are parked,
camped-on, or being transferred to another extension.
Installation and Hardware
Installation and hardware enhancements include the following:
■ The control unit covers for the MERLIN LEGEND
Communications System are the same easy-to-use covers as
those for the MERLIN
■ A new 012 (T/R) module [apparatus code 517G13 (28) or higher
letter] contains a built-in ring generator. The maximum ring
equivalency number (REN) supported is 2.2, and the module
rings four ports at one time. Bridging of single-line telephones is
not supported due to poor transmission quality.
■ A new 008 OPT module (labeled “with RING GEN.”) contains a
®
II Communications System.
built-in ring generator. It rings four ports at a time.
■ Ferrite cores for the power supply modules are shipped from the
factory to comply with FCC Part 15 requirements.
■ 3129-WTWA (touch-tone outdoor telephone equipped with cast
aluminum housing and armored handset cord with bell ringers)
■ 3129-WRWA (rotary-dial outdoor telephone equipped with cast
aluminum housing and armored handset cord with bell ringers)
■ 3129-WAWA (auto dial outdoor telephone equipped with cast
aluminum housing and armored handset cord with bell ringers)
■ 3129-WNWA (nondial, automatic ringing on dedicated circuit for
outdoor telephone equipped with cast aluminum housing and
armored handset cord with bell ringers)
Issue 2
January 1998
Page 5
Page 12
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Release 2.1 Enhancements
Equipment and Operations
Equipment and operations enhancements include the following:
■ A new release (Version 2.16 of the System Programming and
Maintenance (SPM) software to support international use.
■ Support of PRI connection to DEFINITY
Systems
■ MLX-10DP telephone, identical to an MLX -10D, except that it
provides a jack for access to the PassageWay Solution and
®
Communications
PassageWay Direct Connection Solution application.
Additional Application Packag es, Telephones, Adjuncts, and
Adapter Enhancemen ts
Additional application packages, adjuncts, and adapter
enhancements include the following:
■ A Lucent Technologies Digital Announcer Unit, compatible with
all call management systems and tip/ring applications currently
available for the MERLIN LEGEND Communications System.
■ The HackerTracker
Accounting system (CAS) detects abnormal calling activity by
allowing monitoring of facilities or authorization code usage.
■ A new digital Magic on Hold unit is available in three
store, and use information provided by the local telephone
company, specifically, the telephone number of a caller in an
area where the service is also supported.
■ An Off-Premises Range Extender (OPRE) supports off-
premises operation with an off-premises extension capability
and extended range operation for tip/ring devices as well as
variable gain to improve voice transmission levels.
■ PagePac
■ PassageWay Solution (Release 1.0) software consisting of four
■ Four single-line telephones with memory buttons: 710, 715,
■ Four specialty handsets compatible with all MLX telephones
®
system adapters. The controller provides 8 built-in zones
(expandable to 56 zones by using up to 3 16-zone expansion
units), group zones, talkback, night bell, operator override,
tones, door supervision, microphone input, and system access
security codes as standard features.
applications that run with Microsoft
provide an interface between an IBM
computer and the MERLIN LEGEND system.
725, and 730.
and the 3101-series, 3178-NHL, 8102, and 8110 single-line
telephones.
™
system software enhancement to the Call
®
Identifier application enables people to receive,
Plus Loudspeaker Paging Systems do not require
®
Windows™ 3.1 or later and
®
-compatible personal
Issue 2
January 1998
Page 6
Page 13
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Release 3.0 Enhancements
Release 3.0 Enhancements
Release 3.0 includes all Release 2.1 functionality plus the
enhancements listed below.
Equipment
New hardware includes a variety of components. Additional details
are included elsewhere in this book.
■ CPU modifications include:
A processor running at 16 MHz with a 32-bit wide data bus
1.5 Mbytes of non-volatile (battery-backed) RAM
4.0 Mbytes of Flash ROM
PCMCIA memory card interface
A full-duplex 1200/2400 bps modem
Error/Status code display for maintenance support
■ An 800 GS/LS-ID line/trunk module delivers the calling party’s
telephone number to the customer premises (MLX display
telephones only) if the service is subscribed to by the customer
and if it is supported by the caller’s telephone company.
■ Videophone 2500 single-line phone with interactive video
display
■ Pre-fabricated and pre-drilled backboard
Installation, Upgrade Administration, and Maintenance
These are the new MERLIN LEGEND Communications System
capabilities:
■ SPM (Release 3.18) conversion of translations from Release
1.0, 1.1, 2.0, and 2.1 to 3.0
■ Remote operation at 1200/2400bps
■ Advice and feedback administration screens for new Release
3.0 functionality
■ PCMCIA Memory Card Interface (a Release 3.0 processor
board required) allowing:
■ Inter-digit dialing timer values are administrable
Still-Image telephone (for interactive display of still
— System software installation
— System software upgrade
— 800 GS/LS-ID port module firmware upgrade
— Integrated backup and restore of translations
Automatic and manual options for backup and restore are
available on the system. Automatic backup can be scheduled
weekly or daily to fit the customer’s needs.
Issue 2
January 1998
Page 7
Page 14
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Release 3.0 Enhancements
■ Inspection of Lines/Trunks displays only those lines and trunks
configured on system rather than all 80 facilities
■ Stations and facilities in Maintenance Busy (both manual and
automatic) can be identified by the maintenance monitor
User Features
Security
The Remote Access feature allows people at remote locations to
enter the system by dialing the number of a line or trunk designated
for remote access. The system can be programmed to require the
remote user to dial a barrier code (a type of password) after
reaching the system. In earlier versions, the system-wide barrier
code length is fixed at 4 digits. Release 3.0 allows a system-wide
barrier code length ranging from a minimum of 4 digits to a
maximum of 11 digits, with a default setting of 7 digits. SMDR
records are enhanced to provide information for remote access
calls. If the remote access call is received on a facility providing
Caller ID information (see below), the SMDR report can help trace
the call.
Caller ID
Caller information (telephone number) is furnished to MLX display
telephones by an 800 GS/LS-ID module using the LS (loop-start)
option. This allows customers to screen calls prior to answering the
phone, as well as providing calling party information for use with
various applications. This function is available only when the
customer subscribes to caller identification service from the local
telephone company, if the telephone company supports that
service.
Shared System Access (SSA)
A telephone may have up to 27 Shared SA buttons to expand
extension coverage.
Authorization Codes
The Authorization Code feature allows you to make calls using your
calling privileges when you are dialing from an extension other than
your own. When you enter your authorization code (ranging from 2
to 11 characters and unique across the system), the privileges and
restrictions assigned to your home extension override the current
restrictions at the host extension. This includes toll restriction,
outward restriction, Facility Restriction Level (FRL), Allowed Lists,
Disallowed Lists, Night Service Exclusion List, and Dial Access to
Pools. All other functions on the telephone are those of the local
telephone, not the home extension.
Authorization codes can also be used for the purposes of call
accounting through the SMDR printout. The SMDR account code
field can hold the authorization code extension number or the
authorization code itself.
Direct Voice Mail
If your company has voice mail, this feature allows you to dial a coworker’s voice mailbox directly without ringing that person’s
extension. Direct Voice Mail is especially useful for transferring
calls when a co-worker is not available.
Issue 2
January 1998
Page 8
Page 15
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Release 3.0 Enhancements
Additional Features
The status of Leave Word Calling (LWC) and Privacy are retained
across cold starts.
SM
Caller ID (CLASS
ICLID and PRI) are available on primary
coverage and return from transfer.
Additional Application Packag es, Adjuncts, and Adapter
Enhancements
PassageWay
PassageWay Direct Connection Solution (Release 2.0) is a Lucent
Technologies computer telephone integrated product that links a
desktop Windows PC to the MERLIN LEGEND’s MLX-10DP,
MLX-16DP, MLX-20L, or MLX-28D telephone. The Windows
applications are: Lucent Technologies Call (autodial/contact
manager), Lucent technologies Buzz (screen-pop applications),
Lucent Technologies Set (station programming interface), and Log
Viewer (call log application). PassageWay Direct Connection
Solution (Release 2.0) is the version supported on MERLIN
LEGEND 3.0.
TM
Direct Connection Solution
PagePal
PagePal connects several Lucent Technologies and other paging
systems to the MERLIN LEGEND Communications System. No
other system adapter is necessary for loudspeaker paging.
Fax Attendant 2.1.1
Fax Attendant Release 2.1.1., which co-resides with AUDIX Voice
Power on the IS III Release 1.2 platform, provides the same
functionality as earlier versions, plus the following enhancements:
■ Personal Fax Messaging. Inbound faxes can be stored until
the subscriber asks that they be printed, at any fax machine he
or she specifies, on company premises or off-site (when the
subscriber retrieves fax messages remotely).
■ Fax Mail. Allows subscribers to send fax messages, get fax
messages, record personal greetings, and program outcalling.
■ Fax Broadcast. Provides a simple way to send one fax to as
many as 1000 fax numbers.
Call Accounting System (CAS) for Windows
This stand-alone version of CAS takes advantage of the easy-touse graphical environment offered by Microsoft Windows. Through
data communications, it also allows one CAS system to serve
multiple business sites.
Group Video Conferencing
Group video conferencing is supported over DS1 (Digital Signal
Level 1) facilities with PRI. (Video conferencing has been available
since Release 2.0.)
Issue 2
January 1998
Page 9
Page 16
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Release 3.1 Enhancements
Release 3.1 Enhancements
Release 3.1 includes all Release 3.0 functionality plus the toll fraud
and security enhancements listed below.
Star Codes
Star codes are dialable codes for services provided by the CO. The
user has to contract with the CO to get these codes activated.
With this release, users can now add a star (*) code to Allowed and
Disallowed Lists to help prevent toll fraud. The MERLIN LEGEND
system checks if the star codes are allowed. If allowed, the system
then checks the remaining dialed digits against the calling
restrictions.
As a security enhancement, *03 requires a technician to enter a
maintenance password to access test procedures.
Second Dial Tone Timer
Users can program a delay period (Second Dial Tone Timer) during
which no dialing is allowed. This is useful in cases when the CO
sends a second dial tone (such as after a star code); the user may
start dialing before getting the second dial tone, creating a risk of
toll fraud or misrouted calls. If the timer is programmed and dialing
is attempted during the delay, the call is not completed.
Trunk-to-Trunk Transfer
This feature allows or disallows trunk-to-trunk transfer on a perstation basis. The default setting for all stations is restricted
(disallowed).
Toll Fraud Defaults
This feature changes these default settings:
■ No station or remote access user with a barrier code may dial
access to any pool.
■ Disallowed List 7 contains numbers most commonly abused for
toll fraud: 0, 10, 11, 1809, 1700, 1900, 976, 1ppp976 (p=any
number or character), *. Assign this list to extensions as
needed.
■ VMI ports are maximally restricted. Outward restriction is on and
they are assigned to Disallowed List 7.
■ FRL settings for VMI ports is 0, for local calls is 2, and for toll
calls is 3.
Release 4.0 Enhancements
Release 4.0 includes all Release 3.1 functionality plus the
enhancements listed below.
System Functionality
The MERLIN LEGEND Communications System functionality is
enhanced to include the following:
■ An expanded dial plan supporting up to 200 tip/ring devices.
■ National ISDN BRI service support for voice and data
connectivity to the CO. Data speeds are 14.4 kbps for analog
data and up to 64 kbps for digital data. Release 4.0 supports the
IOC Package “S” and Multiline Hunt service configurations.
Issue 2
January 1998
Page 10
Page 17
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Release 4.0 Enhancements
■ Certified 2B-data video/data applications that connect to MLX
ports and use NI-1 BRI, PRI, or T1 Switched 56 network
interfaces to make outside connections.
NOTE:
The 008 MLX and 408 MLX modules must have firmware
vintage other than 29. An earlier or later vintage firmware is
supported.
■ The use of T1 facilities for digital data transmission of up to
56 kbps per T1 channel.
Equipment
New hardware includes two new modules. They are:
■ An 016 module supporting 16 tip/ring devices and four TTRs.
All 16 ports can ring simultaneously. The module’s ringing
frequency (default 20 Hz) can be changed through
programming to 25 Hz for those locations that require it.
■ An 800 NI-BRI module supporting high-speed data and video
transmission.
Maintenance Support
The R4.0 software includes a Provisioning Test tool that
technicians can use to verify the operational status of installed
NI-1 BRI lines.
User Features
Product Enhancements
The following enhancements are added:
■ Delay Call Forwarding. Each user can program a Forwarding
Delay setting for calls that are forwarded using Forward,
Remote Call Forwarding, or Follow Me. The forwarding delay is
the number of times a call rings at the forwarding extension
before the call is sent to the receiver. During the delay, the user
may screen calls by checking the displayed calling number (if it
is available). The delay can be set at 0 to 9 rings. The factory
setting for Forwarding Delay is 0 rings (no delay).
■ Voice Announce on the QCC. The QCC operator can use the
fifth Call Button to announce a call on another user’s
speakerphone if the destination telephone has a Voice
Announce-capable SA button available. QCCs cannot receive
Voice Announce calls; they are received as ringing calls. The
factory setting for the fifth Call button is Voice Announce
disabled.
■ Timebased option for overflow on Calling Group. If the
Overflow Threshold Time is set to a value between 1-900
seconds, calls that remain in the Calling Group Queue for the
set time are sent to the Overflow Receiver. This is in addition to
the number of calls that are in the Queue (previously, the only
way to send calls to the Overflow Receiver). If the Overflow
Threshold Time is set to 0, Overflow by time is off. The factoryset time limit is 0 (overflow by time is off).
■ Downloadable Firmware for 016 T/R board and the NI-BRI
board. The PCMCIA technology introduced in Release 3.0
continues to support these two new boards in Release 4.0 for
installation and upgrade. A Release 3.0 or later processor is
required for PCMCIA technology.
Issue 2
January 1998
Page 11
Page 18
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Release 4.1 Enhancements
Single-Line Telephone Enhancements
The following enhancements are added to the single-line
telephones:
■ Disable Transfer. Through centralized programming, the
system manager can disable the ability to transfer calls by
removing all but one SA or ICOM button from the telephone.
■ No Transfer Return. When a handset bounces in its cradle, the
MERLIN LEGEND system interprets this as a switchhook flash
and attempts to transfer a call. This causes unintended ringing
at the user’s phone. In Release 4.0, a flash followed by an onhook state when a dial tone is present causes the call to be
disconnected.
■ Forward Disconnect. All ports on 012 and 016 modules now
send forward disconnect to all devices connected to them when
forward disconnect is received from the CO. This is a nonadministrable operation.
System Security
Greater system security is achieved by requiring a 7-digit
maintenance password when using SPM to perform remote
administration via the Remote Access Feature.
Release 4.1 Enhancements
Release 4.1 includes all Release 4.0 functionality plus the
enhancements listed below. There are no hardware changes in
Release 4.1.
■ Coverage Timers Progra mmed for Individual Extensions
Beginning with Release 4.1, coverage timers, which control the
duration of the delay before calls are sent to each level of
coverage, are changed as follows:
— The Group Coverage Ring Delay (1-9 rings) is programmed
on individual extensions and replaces the Coverage Delay
Interval programmed system-wide in previous releases.
— The Primary Cover Ring Delay (1-6 rings) and Secondary
Cover Ring Delay (1-6 rings) programmed on individual
extensions replace the Delay Ring Interval programmed
system-wide in previous releases.
These enhancements allow the system manager to customize
coverage call delivery to match individual extensions’ callhandling requirements.
Issue 2
January 1998
Page 12
Page 19
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Release 4.1 Enhancements
■ Night Service Coverage Control
Beginning with Release 4.1, a system manager can enable the
Night Service Coverage Control option to automatically control
the status of telephones programmed with Coverage VMS
(Voice Mail System) Off buttons according to Night Service
status.
When Coverage Control is enabled and the MERLIN LEGEND
Communications System is put into Night Service, all
programmed Coverage VMS Off buttons are automatically
turned off (LED is off) and all eligible outside calls are sent to
the assigned voice messaging system calling group with normal
ringing delay. When Night Service is deactivated during the day,
all programmed Coverage VMS Off buttons are automatically
turned on (LED is on) and voice mail coverage is disabled for
outside calls.
Users can override the Coverage VMS Off button status at any
time by pressing the programmed Coverage VMS Off button to
turn the LED on or off.
■ Night Service Group Line Assignment
Beginning with Release 4.1, a system manager can assign lines
to Night Service groups to control handling of after-hours calls
received on individual lines. This capability replaces the
automatic assignment to Night Service groups of only those
lines that ring on the Night Service operator console. An outside
line must be assigned to a Night Service group to receive Night
Service treatment.
With this enhancement, Night Service can be activated and
deactivated on lines that do not appear on operator consoles
(for example, personal lines), and lines appearing at operator
positions can be excluded from Night Service.
■ Forward on Busy
Beginning with Release 4.1, the Forward, Follow Me, and
Remote Call Forward features are enhanced to remove the
requirement that a call be ringing at an extension before it can
be forwarded. With the Forward on Busy enhancement, a call to
a station with no available SA (System Access) or ICOM
(Intercom) buttons is forwarded immediately to the programmed
destination, preventing the caller from hearing a busy signal
from the intended call recipient’s extension.
■ Maintenance Testing for BRI Facilities That Are Part of
Multiline Hunt Groups (MLHGs)
Beginning with Release 4.1, the NI-1 BRI (National Integrated
Services Digital Network-1 Basic Rate Interface) Provisioning
T est Tool is enhanced to include testing for BRI facilities that are
part of Multiline Hunt Groups (MLHGs).
The NI-1 BRI Provisioning Test Tool is used by Lucent
Technologies maintenance personnel on MERLIN LEGEND
Communications Systems that include a 800 NI-BRI module.
The tool is used during system installation and maintenance to
test the functionality of the BRI lines and report analyzed
results.
Issue 2
January 1998
Page 13
Page 20
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Release 4.2 Enhancements
Release 4.2 Enhancements
Release 4.2 includes all Release 4.1 functionality plus the
enhancements listed below. There are no hardware changes or
Release 4.2.
■ Additional Network Switch interface and Services Options
for ISDN Primary Rate Interface (PRI)
Release 4.2 of the system supports connectivity to MCI
local exchange carrier (LEC) PRI services and to the following
central office switch types (in addition to the 4ESS™ and 5ESS
switch types that are currently available for AT&T Switched
Network Services):
— Digital Switch Corporation DEX600E Generic 500-39.30
DMS™-100 Generic BCS 36 for local exchange
carrier services
serving the MCI network
Beginning with Release 4.2, the following MCI PRI and local
exchange carrier (LEC) PRI services (along with the AT&T
Switched Network Services) can be connected to users of the
MERLIN LEGEND Communications System:
— MCI Toll Services for DMS-250 or DEX600E switch type:
R
MCI Prism® service for domestic outgoing long-distance
and international voice calls; for domestic outgoing 56kbps restricted, 64-kbps unrestricted, and 64-kbps
restricted circuit-switched data calls
R
MCI VNet® service for incoming and outgoing domestic
and voice calls; for 56-kbps restricted, 64-kbps restricted,
and 64-kbps unrestricted circuit-switched data calls
R
MCI 800 for domestic, toll-free, incoming voice calls
R
MCI 900 service numbers
— Local Exchange Carrier Services for DMS-100 switch type:
R
DMS Virtual Private Network service for calls between the
MERLIN LEGEND Communications System and another
communications system (such as another MERLIN
LEGEND Communications System)
R
DMS INWATS (Inward Wide Area Telephone Service) for
domestic, toll-free, incoming voice calls
R
DMS OUTWATS (Outward Wide Area Telephone Service)
for domestic, outgoing, long-distance voice calls
R
DMS FX (foreign exchange) to provide local call rating for
calls from the local exchange to the area serviced by the
foreign exchange.
R
DMS Tie Trunk to provide private exchange call rating for
calls placed on a dedicated central office facility between
the MERLIN LEGEND Communications System and
another communications system (such as another
MERLIN LEGEND Communications System)
®
or
Issue 2
January 1998
Page 14
Page 21
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Release 4.2 Enhancements
■ Improvements to Station Message Detail Recording (SMDR)
and Support for MERLIN LEGEND Reporter Application
The SMDR feature is enhanced to provide more details about
calling group agent activities and help system managers assess
the effectiveness of call centers, in terms of both agent
performance and the adequacy of facilities to handle inbound
calls. These improvements apply to calling groups that are
programmed as Auto Login or Auto Logout type:
— TALK Field. For Auto Login and Auto Logout calling groups,
the TALK field records the amount of time a calling group
agent spends on a call.
— DUR. (DURATION) Field. Call timing begins when a call
arrives at the MERLIN LEGEND Communications System
and not after a preset number of seconds. This allows the
system manager to determine how long a caller waited for an
agent’s attention.
— Coding of Calls on Reports. An asterisk (*) appears in the
call record when:
a. A call is not answered by an Auto Login or Auto Logout
calling group agent and is abandoned while waiting for an
agent.
b. The call is answered by someone not a member of an
Auto Login or Auto Logout calling group.
An exclamation point (!) signals that an Auto Login or Auto
Logout agent handled a call that was answered by someone
who was not a member of that Auto Login or Auto Logout
with Overflow group. An ampersand (&) in the call record
indicates that the group’s overflow receiver answered the
call.
— MERLIN LEGEND Reporter. MERLIN LEGEND Reporter
provides basic call accounting system reports for all
incoming calls to Auto Login or Auto Logout type calling
groups. MERLIN LEGEND Reporter assists in determining
the effectiveness of calling group agents, assessing the level
of service provided to callers, and ascertaining whether
adequate incoming phone lines and agents are available to
handle peak call load. The following reports are provided:
R
Organization Detail Report
R
Organization Summary and Trends Report
R
Selection Detail Report
R
Account Code Report
R
Traffic Report
R
Extension Summary Report
R
Data Report
R
Talk and Queue Time Distribution Report
R
Time of Day Report
R
ICLID Call Distribution Report
R
Facility Grade of Service Report
Issue 2
January 1998
Page 15
Page 22
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Release 5.0 Enhancements
■ Maintenance Enhancements
— Change to Permanent Error Alarm
Beginning with Release 4.2, the most recent permanent error
alarm is not shown on the System Error Log menu screen but
is available as an option from that screen. For details, refer to
the Maintenance section of the technician guide, Installation,
Programming and Maintenance.
— Enhanced Extension Information Report
Beginning with Release 4.2, the Extension Information
Report includes the Extension Status (ESS) and supervisory
mode for each extension.
Release 5.0 Enhancements
Release 5.0 includes all Release 4.2 functionality plus the
enhancements listed below.
■ Computer Telephony Integration (CTI)
Beginning with Release 5.0, a PassageWay
Services CTI link from the MERLIN LEGEND Communications
System to a LAN server running Novell
allows Lucent Technologies-certified telephony applications to
control MLX and analog multiline telephone (BIS only)
operations that are monitored by the applications. The physical
connection for the CTI link is an MLX port on a 008 MLX or 408
MLX module on the MERLIN LEGEND Communications
System control unit and an ISDN link interface card plugged into
the customer’s server. The feature is available for Hybrid/PBX
mode systems only.
System Requirements for CTI link
Refer to Chapter 2 of the Network Manager’s Guide for detailed
installation instructions.
The following equipment and software are required:
■ An Intel i386, Intel i486, or Pentium class computer with at least
16 megabytes of RAM. Additional memory may be needed if
additional applications will be running on the server machine.
■ NetWare Version 4.10 or Version 3.12
■ 5 megabytes of disk space available on the SYS (system)
volume
■ Telephony Services for NetWare software, Releases 2.21 or
later, installed
■ An Eicon/G. Diehl SCOM card for the CTI link
■ A free 8- or 16-bit ISA slot for the Eicon/G. Diehl SCOM card
■ System software Release 5.0 or later installed on the MERLIN
LEGEND Communications system
■ The MERLIN LEGEND configured in Hybrid/PBX mode
■ An MLX port board (using firmware Version 28 or later, except
Version 29) installed in the MERLIN LEGEND
NOTE:
The 008 MLX and 408 MLX modules must have firmware
vintage other than 29. If the module has firmware 29,
administering a CTI link on the module is prevented. An earlier
or later vintage firmware is supported.
®
Telephony
®
NetWare® softw are
Issue 2
January 1998
Page 16
Page 23
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Release 5.0 Enhancements
■ If the MERLIN LEGEND switch has only one MLX port board,
you also need System Programming and Maintenance (SPM)
software, Version 5.01, to administer the CTI link
■ One port on the MLX board is used for the CTI link. This port
cannot be a potential operator port (2, 3, 4, 6, 7, and 8 must be
available) or a console programming port
■ For a NetWare 3.12 installation, ensure that either
NWSNUT.NLM, Version 4.11 or later, and TUI.NLM, Version
1.04 or later, is obtained from Novell and installed in the
SYS:\SYSTEM directory
NOTE:
To obtain these NLMs from Novell, access either the Novell
web site (http:\\www.novell.com) or the Novell FTP site
(ftp.novell.com). First, download IPXRT4.EXE and follow the
directions in the associated readme file. Then, download
NWSNUT.NLM and TUI.NLM.
■ Basic Call Control. A CTI link application on a user’s computer
can assume basic call control of the user’s analog multiline or
MLX telephone’s SA buttons. Basic call control includes:
— Answering calls arriving on an SA button
— Making calls from an SA button
— Hanging up calls
— Hold and retrieving a call on hold at the user’s extension
— Conference calls from a DLC or QCC operator
NOTE:
Transfer and 3-way conference, when handled through a
CTI link application, provide the original caller’s calling
number information or other information to the transfer
receiver or new conference participant, if the user has
screen-pop capability.
■ Screen Pop. Screen pop occurs when the calling number,
called number, or other user-defined identifier (such as an
account code that a voice-response unit prompts the caller to
dial) is used to display a screen associated with the calling
party. For example, Caller ID services can be used to support
screen pop on a system that includes a CTI link; using the
calling party number as a database key code, information about
a caller automatically appears on the user’s computer screen
when the call arrives at the extension. Depending on the
application, screen pop may be available for calls that arrive on
line buttons other than SA buttons and/or are answered
manually at the telephone rather than by the application.
Screen pop can occur on incoming calls from the following
sources:
— Calling group distribution
— ISDN PRI Routing by Dial Plan
— An extension on the MERLIN LEGEND Communications
System
Issue 2
January 1998
Page 17
Page 24
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Release 5.0 Enhancements
— Remote Access
NOTE:
In the case of remote access calls, the only information
that the application can collect about the caller is the
remote telephone number.
— A transfer of a call that was answered by a voice response
unit
— A transfer, redirection, or conference of a call that was
answered at a DLC or at a QCC
NOTES:
DLCs (Direct-Line Consoles) may use CTI applications. If
they do, they perform the same way as other extensions. A
DLC assigned to use a CTI link application is a monitored
DLC. When a DLC is used as a regular operator console
and not assigned as a CTI link extension, it is nonmonitored.
Calls to a QCC non-monitored DLC do not initiate screen
pop at the operator position., but when an operator directs
a call to an extension using a CTI application, caller
information does initiate screen pop.
Calls transferred from Cover buttons on non-monitored
DLCs do not initiate screen pop at the destination
extension.
■ HotLine Feature. The Release 5.0 HotLine feature is designed
for retail sales, catalogue sales, and other types of businesses
and organizations. It is available in all three modes of system
operation. The feature allows a system manager to program a
single-line telephone extension as a HotLine. When a user lifts
the handset at the HotLine extension, the telephone
automatically dials the inside extension or outside telephone
number programmed as the first Personal Speed Dial number
(code 01) for the extension. At HotLine extensions, calls cannot
be transferred, put on hold, or conferenced.
Personal Speed Dial codes can be programmed at the
extension prior to HotLine assignment (a system programming
function). Alternatively, a Personal Speed Dial code can be
programmed from the single-line telephone after HotLine
operation is assigned. However, because of security
considerations, this is a one-time opportunity. Once the
Personal Speed Dial number is programmed, any changes to it
or any other extension programming must be performed using
centralized telephone programming.
Any type of inside or outside line that is normally available to a
single-line telephone can be assigned to a HotLine extension.
Generally, the HotLine telephone does not receive calls, and its
line should be set to No Ring.
!
SECURITY ALERT:
A HotLine single-line telephone accesses a loop-start line,
the line should provide and be programmed for Reliable
Disconnect. If it is not, a caller may be able to stay on the
line after the initial call and access an outside line.
Issue 2
January 1998
Page 18
Page 25
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Release 5.0 Enhancements
■ Call Center Enhancements. Release 5.0 and later systems
include Group Calling features that enhance call center
operations.
— Most Idle Hunt Type. In addition to the Circular (factory
setting) and Linear hunt types supported in earlier releases,
a third hunt type distributes calling group calls in an order
based on which agent has waited the longest since
transferring or hanging up on an incoming calling group call.
For some applications, this hunt type is more efficient than
the circular type because it takes into account the varying
duration of calls. The system distributes calls based on when
an agent last completed a call, not on when he or she last
received one. This hunting method ignores non-calling group
calls. For example, if an agent transfers a call that arrived on
a line not assigned to the calling group, the calling group
member’s most-idle status is unaffected.
— Secondary Delay Announcement Device. The system
manager can designate an extension for an optional
secondary delay announcement device in addition to the
single device for each group that is available in Release 4.2
and earlier systems. One device is the primary device and
operates in the same fashion as a single delay
announcement device, playing once, as soon as it is
available, for the caller who has waited the longest for a
calling group agent. If a secondary announcement device is
used, it can be set to repeat or play only once for each caller,
the factory setting. The system manager programs the time
(0-900 seconds) between announcements. This setting
controls both the interval between primary and secondary
announcement and the interval between repetitions of the
secondary announcement if it is set to repeat.
The primary and secondary announcement options, when
used together, allow an initial message to play for callers,
followed by a repeating announcement that, for example,
urges callers to stay on the line and wait for a calling group
member.
— Enhanced Calls-in-Queue Alarm Thresholds. Three Calls-
in-Queue Alarm thresholds can be set to more clearly
indicate the real-time status of the queue according to the
behavior of programmed Calls-in-Queue Alarm buttons. In
earlier releases, only one Calls-in-Queue Alarm Threshold
setting is available to activate the LEDs at programmed
Calls-in-Queue Alarm buttons for a calling group.
Using all three levels, the system manager sets Threshold 1
to the lowest value, Threshold 2 to a middle value, and
Threshold 3 to the highest value. A Calls-in-Queue Alarm
button indicates the severity of the alarm conditions in the
following ways:
— If the number of waiting calls is less than the value
programmed for Threshold 1 or drops below that level, the
LED is unlit.
— If the number of waiting calls is greater than the
Threshold 1 value but less than the Threshold 2 value, the
LED winks.
Issue 2
January 1998
Page 19
Page 26
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Release 6.0 Enhancements
— If the number of waiting calls is greater than the
Threshold 2 value but less than the Threshold 3 value,
the LED flashes.
— If the number of waiting calls is greater than the highest
value, Threshold 3, the LED lights steadily.
NOTE:
A DSS (Direction Station Selector) button that is used as a
Calls-in-Queue Alarm button can only indicate two
threshold levels, either by flashing or by lighting steadily. If
a calling group must use this type of Calls-in-Queue Alarm
button, only two threshold levels should be programmed.
If all three thresholds are set to the same value, the result is
one threshold only. If two values are the same, then the
result is two alarm levels. The factory setting is one call for all
three thresholds.
An external alert only signals when the number of calls in the
queue exceeds the programmed Threshold 3 value.
— MLX-5 and MLX-5D Telephones. The MLX-5 nondisplay
and the MLX-5D display telephones are compatible with all
system releases. The display telephone includes a 2-line by
24-character display, and both telephones come with 5 line
buttons.
Release 6.0 Enhancements
Release 6.0 includes all Release 5.0 functionality, plus the
enhancements listed below.
■ Priva te Networks
In Hybrid/PBX mode systems only, MERLIN LEGEND
Communications Systems can be networked with one another
or with DEFINITY
and ProLogix
In previous releases, this functionality is available using tie
lines, but users handle calls between networked switches as
outside calls. In this release, dialing the pool access code is not
necessary for a call going from one networked switch to
another. Also, delay-start tie trunks or T1 trunks administered as
PRI can act as
Available for Hybrid/PBX mode systems, the private network
features of the MERLIN LEGEND Communications System
Release 6.0 provide the following advantages for
geographically dispersed organizational sites:
— Intersystem Calling. In a private network, users on one
local system can call extensions on other systems in the
network. Release 6.0 can support 2-, 3-, 4-, or 5-digit dial
plans. They dial these extensions as inside calls. To
implement this function, the system manager programs the
extension ranges of remote networked switches to create a
non-local dial plan. This programming does not actually
affect numbering on the remote system. To correctly set up
systems for transparent calling among non-local dial plan
extensions, the system manager assigns networking tie and/
or PRI tandem trunks to pools. Then he or she programs as
many as 20 patterns, associates with routes, Facility
®
Enterprise Communications Server (ECS)
™
Communications Systems in private networks.
tandem trunks
to connect networked systems.
Issue 2
January 1998
Page 20
Page 27
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Release 6.0 Enhancements
Restriction Levels (FRLs), digit absorption, and digit
prepending. This allows ARS-like routing of non-local dial
plan calls. In addition, system managers can control whether
calling name, calling number, or both are shown at MLX
display telephone for incoming calls across PRI tandem
trunks.
— Toll Savings. Private networked trunks may allow you to
realize significant cost savings on long-distance and toll calls
by performing tandem switching in the following two ways:
— Callers on a local system, or individuals dialing in to
remote access at a local system, can reach the public
switched telephone network (PSTN) via outside trunks
connected to other systems in a private network, avoiding
toll charges or decreasing the cost of toll calls. No special
dialing is required. For example, an organization might
have a main office in Boston and a subsidiary office in
New Jersey, connected by networked private tandem
trunks between two systems. A user in the New Jersey
office who wishes to make an outside call to the 617 area
code (Boston) can do so through a line/trunk connected to
the system in Boston. For example, he or she might dial,
call over the private network trunks and use the ARS
tables of the remote system in Boston to route this call.
The system managers at each end of a private network set
up ARS and Remote Access features to implement this
. The local ARS tables would route this
functionality.
— In addition, local organizations or incoming DID calls use
private networked trunks to make intersystem calls
between networked systems, which may be
geographically distant from one another, also resulting in
toll sav in g s.
— Service Cost Savings. In addition to toll call saving, there
are two ways that organizations can save on service costs
incurred from telecommunications providers that provide
public switched telephone network access:
— You order a point to point T1 facility from a service
provider, then use system programming to set it up for PRI
signalling. As necessary, a service provider can provide
amplification on the T1 facility, but does not supply
switching services.
— You can tailor your use of PRI B-channels with drop-and-
insert equipment that allows fractional use of B-channels
for dedicated data/video communications between
systems at speeds greater than 64kbps per channel or
128 kbps for 2B data, while keeping the remaining
B-channels for PRI voice traffic. The PRI D-channel
must remain active.
— You can tailor use of T1 channels to support both T1-
emulated tandem tie service and T1 Switched 56 service
for data communications at 56 kbps per channel, allowing
2B data transfers at 112 kbps. You can also use drop-andinsert equipment to provide fractional T1 use.
Issue 2
January 1998
Page 21
Page 28
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Release 6.0 Enhancements
— Voice Mail and Auto Attendant. Networked systems should
have their own local voice mail and/or auto attendant
applications as well as their own external alerts and Music
On Hold sources. However, a single auto attendant can
transfer calls throughout the network. It can answer only
those calls that arrive on the PSTN facilities of the system
where it is connected.
Although many features are available using tie trunks for
network connectivity, PRI tandem trunks provide greatly
enhanced features and faster call setup. For this reason, PRI is
recommended over tie functionality in private networks.
■ Group Calling Enhancements
Release 6.0 and later systems include Group Calling features
that enhance group calling operations.
— Queue Control
The system manager can control the maximum number of
calls allowed in the primary calling group queue for calls that
arrive on certain facilities often assigned to calling groups.
When the number of the calls in queue reaches the
programmed maximum, subsequent callers receive a busy
signal.
Queue control applies to calls received on the following types
of facilities:
— DID (Direct Inward Dialing)
— PRI facilities programmed for dial-plan routing
— All calls transferred from a VMI (voice messaging
interface) port
— Dial-in Tie
Queue control also applies to internal calls to a DGC group
and calls to a calling group through the QCC.
Internal calls that dial
calling group administered as Position-Busy Backup are
eligible for queue control. Calls that come in on a trunk
assigned to the Queued Call Console (QCC) are not eligible
for queue control if the call is directed to a calling group
or
and are directed to a
designated as Position-Busy Backup.
Remote-access calls to a calling group, coverage calls
directed to a calling group, calls directed to calling group
through QCC Position-Busy backup, and all other outside
calls are not eligible for queue control.
— Prompt-Based Overflow
System managers can activate the Prompt-Based Overflow
option. This option allows callers waiting in queue and
listening to a delay announcement to press the # key in order
to reach the overflow receiver for the group, which may be
the QCC queue or another calling group (including a calling
group assigned for a voice mail system).
All three overflow distribution options—based on the number
of calls, the time a caller has waited, and according to the
caller’s prompt—may be used at one time. In this case, time-
based and number-of-calls based options take precedence
over overflow distribution based on the caller’s prompt.
Issue 2
January 1998
Page 22
Page 29
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Release 6.0 Enhancements
When prompt-based overflow distribution is used, an extra
TTR must be provided for each delay announcement device
assigned to the associated calling group. The delay
announcement informs the caller of the # key option to exit
the queue and leave rather than waiting for an agent. If no
TTR is available when a calling group call arrives, the call is
not sent to a delay announcement extension.
■ Centrex Transfer via Remote Call Forwarding
Centrex Transfer via Remote Call Forwarding can be used in all
system modes of operation to send outside calls to a remote
telephone number or another Centrex station. In this context,
outside calls
the term
communications system, which may originate at extensions in
the Centrex system but not connected to the local MERLIN
refers to calls from outside the
LEGEND Communications System.
An outside call that uses this feature is defined as a call that
arrives on an analog Centrex loop-start line at the MERLIN
LEGEND Communications System. It may arrive directly or be
transferred without consultation or without transfer supervision
(in the case of an automated attendant). The forwarding call to
the outside number is made on the same line/trunk on which the
call arrived, conserving system facilities. The following
considerations and rules apply:
— Only outside Centrex calls are forwarded using this feature.
— The system must be equipped with analog loop-start Centrex
lines and
facilities. Loop-start lines do not have to provide reliable
disconnect for use by the Centrex Transfer via Remote Call
all
loop-start lines in the system must be Centrex
Forwarding feature.
— T o transfer calls outside the Centrex system, the organization
must subscribe to a Centrex trunk-to-trunk transfer feature.
Activating Centrex Transfer via Remote Call Forwarding is just
like activating regular Remote Call Forwarding and requires that
Remote Call Forwarding be enabled for the extension.
However, the user dials
Pause character may be required after the
service provider determines whether the Pause is needed.
Pause cannot be originated from a single-line telephone or a
remote access user. A multiline telephone user in the local
system must enter an authorization code to activate the feature.
instead of a dial-out code, and a
. The Centrex
A remote access user may activate the feature without using an
authorization code. Barrier code requirements do apply,
however.
Issue 2
January 1998
Page 23
Page 30
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Release 6.0 Enhancements
■ Authorization Codes a nd Remote Call Forwarding
In Release 6.0 and later Key or Hybrid/PBX mode systems,
forwarding features, including Centrex Transfer via Remote Call
Forwarding, but excluding Follow Me, can be activated or
deactivated at a multiline telephone by entering the
authorization code for the extension from which calls are to be
forwarded. The user enters the authorization code, then
activates or deactivates the forwarding feature in the normal
fashion. This is especially useful for a single-line telephone user
who must include a Pause character in a Centrex Transfer via
Remote Call Forwarding dialing sequence, because the
character cannot be dialed at a single-line telephone. It is also
useful when activating Call Forwarding or Remote Call
Forwarding at phantom stations, or via remote access (e.g. from
another switch in the network). No other features can be used
by entering an authorization code in this fashion.
Issue 2
January 1998
Page 24
Page 31
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Design Benefits
Design Benefits
Modular components allow easy, cost-effective growth in both
size and function. For upgrades from the MERLIN LEGEND
Communications System, all wiring and analog MERLIN system
telephones can be reused. For upgrades from the MERLIN II
Communications System, certain trunk and extension modules can
also be reused. The modules are 800, 400, 400EM, 012, 008, and
408.
Menu-driven system programming maintains the customer’s
command of business operations.
Built-in 1200/2400-bps modem allows fast access to the system
by customers, Lucent Technologies personnel, or authorized
dealers from a remote location for system programming and
maintenance.
Flexible mode of operation saves upgrade costs by allowing
system configuration in one of three modes: Hybrid/PBX, Key, and
Behind Switch. (The default setting on the 3.0 processor board is
Hybrid/PBX.)
Connectivity to other systems in the Behind Switch mode
optimizes existing resources by allowing the system to work as part
of another MERLIN LEGEND Communications System,
System 25, System 75, System 85, DEFINITY 75/85, or other
communications system. The control unit can connect to another
system’s control unit via either an off-premises telephone (OPT)
line or an analog or digital tie trunk.
Digital 2.048-MHz bus supplies a 64-kbps channel on each of the
216 time slots.
68EC020 Motorola CPU running at 16 MHz with zero wait states
provides fast system performance.
Memory data retention saves time by ensuring that system and
extension programming information is retained for 5 days,
depending on the system configuration, in case of power failure or
system shutdown.
Integrated voice and data capabilities allow users to talk while
transmitting data at speeds up to 64 kbps.
DS1 interface can be configured for connection of either T1 or PRI
for basic call control with the 4ESS or 5ESS PRI service
specifications.
Basic Rate interface (BRI) S/T protocol supports premier digital
multiline (MLX) telephones with superior display capabilities and
supports the ISDN terminal adapter Data Module for the connection
of adjuncts.
Issue 2
January 1998
Page 25
Page 32
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Environmental Specifications
Environmental Specifications
The control unit requires a regulated environment and can be
located in any room or closet that is temperature-controlled and
clean. Do not mount the control unit where it will be exposed to
dire ct sunlight.
In addition, the control unit should not be co-located with air
conditioning or ventilation units, compressors, fans and blowers,
heaters, arc welders, or other machinery that produces electrical
interference.
The control unit is mounted on a Lucent Technologies pre-drilled
backboard.
Once installed, it is important to keep the control unit site clear of
hazards, such as stacked paper or boxes, that block ventilation.
Installing any machinery in the vicinity of the control unit should be
avoided. If any pollution-producing work (such as sanding or spray
painting) is to be done in the area, care should be taken to protect
the unit.
The following table gives the environmental specifications for the
control unit.
Control Unit
Fully loaded basic carrier
Weight:45 lb. (20.4 kg)
Dimensions: 14 in. wide x 23 in. high x 12 in. deep
(35.6 cm x 58.4 cm x 30.5 cm)
Fully loaded 2-carrier system
(basic carrier plus 1 expansion carrier)
Weight:90 lb. (40.8 kg)
Dimensions: 25 in. wide x 23 in. high x 12 in. deep
(63.5 cm x 58.4 cm x 30.5 cm)
Fully loaded 3-carrier system
(basic carrier plus 2 expansion carriers)
Weight:135 lb. (61.2 kg)
Dimensions: 37 in. wide x 23 in. high x 12 in. deep
(94 cm x 58.4 cm x 30.5 cm)
Mean Time Between Failures
(mean/average time the system is expected to operate before any
type of failure occurs)
2.4 years
For a system configured with 24 trunks and 50 stations
(extensions)
Issue 2
January 1998
Page 26
Page 33
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Environmental Specifications
Backboard Mounting Hardware Requirements
This refers to the types of wall construction to which the backboard
will be attached.
Hardware has a combined pullout force of 650 lb. (294.8 kg). When
mounting to sheet-metal walls, attach to structural members.
Location
Within 5 ft. (1.5 m) of dedicated AC power outlet (1 plug per carrier)
Within 1000 cable ft. (304.8 m) of telephones
Heat Dissipation
Fully loaded basic carrier500 Btu/hr (35 cal/sec)
Fully loaded 2-carrier system1000 Btu/hr (70 cal/sec)
(basic carrier with one expansion carrier)
Fully loaded 3-carrier system1500 Btu/hr (105 cal/sec)
(basic carrier plus two expansion carriers)
Power Requireme nts
Basic carrier117 VAC60 Hz -15% to 10% 5.4A
2-carrier117 VAC60 Hz -15% to 10% 10.8A
3-carrier117 VAC60 Hz -15% to 10% 16.2A
Temperature/Humidity Range
40°–104°F (4°–40°C)
20%-80% relative humidity
Ventilation Clearances
1 in. (2.5 cm) on right and left sides
Radio Frequency Interference, Tolerance
1.0 V/m
Electromagnetic Interference (EMI)
To reduce electromagnetic interference emissions (possible
interference problems with handheld telephones), check the date of
manufacture of the CPU (517A27) units. If they were manufactured
before April 1993, replace them with a later version.
Issue 2
January 1998
Page 27
Page 34
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Power and Grounding
!
CAUTION:
■ For the control unit, do not use an AC outlet that is controlled
by a wall switch or some other switch.
■ Use an approved ground (AC receptacle for 3-prong plug).
■ Do not install the control unit outdoors.
■ Do not place the control unit near extreme heat (furnaces,
heaters, attics, or direct sunlight).
■ Do not expose the control unit to devices that generate
electrical interference (such as arc welders or motors).
■ Do not place anything on top of carriers.
■ Do not install the control unit under any device that may drip
fluid, such as an air conditioner.
■ Each auxiliary power unit requires one outlet.
■ Do not expose the control unit to moisture, corrosive gases,
dust, chemicals, spray paint, or similar materials.
Power and Grounding
Proper power and grounding are essential for correct and safe
functioning of the system.
Power Specifications
The system control unit plugs into a 117-VAC outlet. To avoid
accidental disconnection of the system, this outlet should not be
controlled by a wall switch.
Each carrier unit requires its own power supply. Each power supply
requires a maximum current of 5.4 amps. Therefore, if expansion
carrier units are added to the system, extra AC outlets may be
needed.
Grounding Req u irements
Proper grounding of the installation site protects the system against
the following:
■ Lightning
■ Power surges
■ Power crosses on outside lines/trunks
■ Electrostatic discharge (ESD)
The local telephone company is responsible for providing
protection of outside lines/trunks at the entrance to the site. The
protection should consist of the following:
■ Carbon blocks or gas discharge tubes connected to an
approved ground
■ Adequate bonding of the outside line/trunk protector ground and
the power company ground
!
WARNING:
An improper ground can result in equipment failures and
service outages. Verify that the AC power uses an approved
ground for its primary ground, that all voltage-limiting devices
are grounded to an approved ground, and that the ground is
one of the approved grounds listed below.
Issue 2
January 1998
Page 28
Page 35
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Power and Grounding
The following is a list of approved grounds, starting with the most
preferred:
■ Building steel
■ Acceptable water pipe, must be a metal, underground water
pipe at least 1/2-in. (30.4 cm) in diameter, and in direct contact
with the earth for at least 10 ft. (3 m).
— It must be electrically continuous so that the protector ground
is connected. (Check for insulated joints, plastic pipe, and
plastic water meters that might interrupt electrical continuity.)
— A metallic underground water pipe must be supplemented by
the metal frame of the building, a concrete-encased ground,
or a ground ring.
— Other local metal underground systems or local underground
structures such as tanks and piping systems
— Rod and pipe electrodes, a 5/8-in. (1.6-cm) solid rod or
3/4-in. (1.9-cm) conduit or pipe electrode driven to a
minimum depth of 8 ft. (244 cm)
— Plate electrode, a minimum of 2 square ft. (61 square cm) of
metallic surface exposed to the exterior soil
■ Concrete-encased ground, which must be an electrode,
consisting of one of the following:
— At least 20 ft. (6.1 m) of one or more steel reinforcing rods,
each being at least 0.5-in. (1.27 cm) in diameter
— 20 ft. (6.1 m) of bare copper conductor not smaller than
#4 AWG, encased in 2 in. (5 cm) of concrete. This electrode
must be located within and near the bottom of a concrete
foundation or roofing that is in direct contact with the earth.
— Ground ring, consisting of at least 20 ft. (6.1 m) of bare
copper conductor not smaller than #2 AWG, encircling the
building. The ground ring must be in direct contact with the
earth and buried at least 2.5 ft. (77 cm) below the earth’s
surface.
!
WARNING:
Do not use a metal underground gas piping system. This is a
safety risk.
For most power surges, the following standard grounding
requirements provide adequate lightning and surge protection:
■ Properly wired/grounded/bonded outside line protectors
■ Properly wired/grounded AC outlet
■ Properly grounded single-point ground bar
■ Properly wired connection between single-point ground and
power supplies
Issue 2
January 1998
Page 29
Page 36
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Power and Grounding
Additional Power Surge Protection
The 391A1 power supply has built-in AC line protection. This builtin protection handles almost all situations.
Occasionally, additional protection may be needed if the customer
is located in a heavy lightning area. A 147A surge protector can be
connected to the system to limit surges from the AC lines and
outside lines. One 147A protector provides protection for four
outside lines. Up to three 146A protectors can be added to the
147A to provide protection for a maximum of 16 outside lines. For
more than 16 lines, additional 147A protectors are required.
NOTE:
The 147A protector is usually not needed with the 391A1
power supply. It may be needed with the older 391A power
supply module in heavy lightning areas.
Complete installation instructions are provided with the protectors.
Issue 2
January 1998
Page 30
Page 37
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Control Unit Interfaces
Control Unit Interfaces
Signaling
Interface Applications
BRI S/T*Control unit to MLX telephone
ISDN Terminal Adapter
DS1Control unit to the following services:
RS-232-CControl unit to PC connected to
ATLControl unit to analog multiline telephone40kHz300–
Tip/Ring Control unit to single-line
* Call handling derived from CCITT recommendation Q.931.
■ T1
Emulated tie trunk
Emulated DID
Emulated loop-start
Emulated ground-start
■ PRI services
ACCUNET® switched digital service
MEGACOM® WATS
MEGACOM 800
Software Defined Network (SDN)
MultiQuest® 900 number services
Connectivity to 5ESS Generic
6/7/8/FTS 2000
Multiple incoming calls to
directory number
Call-by- Ca ll Ser vi ce S elec t ion
Password handling for FTS2000
SID-ANI as Calling Party Number
system programming port
Control unit to Lucent Technologies model
572 printer, PC with CAS, or CAT connected
to RS-232-C port
telephone, modem, fax, OPT, or
voice mail system
Channel
Rate
16 kbps (D)
64 kbps (B)
64 kbps (B)
and (D)
64 kbps
2400 bps
or
1200 bps
1200 bps
Audio/
Data
Rate
2400 bps
or
1200 bps
1200 bps
3400 Hz
Issue 2
January 1998
Page 31
Page 38
DEFINITY ECS Release 6
System Description Pocket Reference
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Hardware and Software
Hardware and Software Capacities
You can configure the system as a stand-alone unit or as part of a
private n etwork. Maximum system capacities are as follows:
■ Up to 108 simultaneous two-party conversations
IMPORTANT:
If more than 108 conversations are in progress at the same
time, blocking can occur.
■ Up to 80 line/trunk jacks, including loop-start, ground-start, DID,
and tie
■ Up to 255 extension endpoints that support a combination of the
following:
— Up to 255 physical extension jacks for tip/ring telephones
and adjuncts
— Up to 127 logical digital data ports (through ISDN terminal
adapters connected to jacks on the MLX module) providing
RS-232 connections to data terminals and personal
computers
■ System call-handling capability of 3888 hundred call seconds
per hour (ccs/hr)
■ Up to three 100D DS1 modules, maximum two per carrier
■ Up to five 800 NI-BRI modules, maximum three per carrier
(Release 4.0 and later)
■ One CTI link when operating in Hybrid/PBX mode
The system has a total capacity of 280 jacks (80 outside lines/
trunks plus 200 extensions); however, each MLX module extension
jack supports two logical endpoints (extension devices that can
operate simultaneously and independently of each other). For
example, an MLX telephone with a Multi-Function Module (MFM)
plugs into one extension jack, but the jack supports both the
telephone and the equipment (for example, a fax or an answering
machine) connected to the MFM.
Issue 2
January 1998
Page 33
Similarly, although the 100D module has only one jack, it can serve
up to 24 endpoints (emulated lines/trunks or PRI lines/trunks).
Thus, you can configure the system to connect up to 80 lines/trunks
and 255 extension endpoints-a total of 335 endpoints.
The following table, Table of Hardware and Software Capacities,
lists the hardware and software capacities of the system.
Constraining Factors appear with a checkmark (
explained at the end of the table.
) and are
Page 40
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Hardware and Software
Table of Hardware and Software Capacities
Limit
Account Codes
Digits per code16
Authorization Codes
Digits per code
Allowed/Disallowed Lists
Number of lists
Entries per list
Digits per entry
Automatic Route Selection (ARS)
Number of ARS tables
Subpatterns per table
Routes per subpattern
Entries per table
Entries across all tables
Default tables
Callback calls in queue64
Calling Groups
Number of groups
Members per group
Total agents and supervisors
Total supervisors
Groups per member
Delay announcements per system
Primary delay announcements per group
Secondary delay announcements per group
Groups per delay announcement
External alerts per group
Coverage groups per group
Carriers
Line/trunk and extension module slots per
basic carrier
Line/trunk and extension module slots per
expansion carrier
Maximum slots available for
line/trunk and extension modules
Coverage Groups
Number of groups
Senders per group
Groups per sender
Receiver buttons per group
Groups per QCC receiver
1600
Constraining
255
11
8
10
7
16
2
6
100
4
32
20
200
8
1
32
10
1
32
1
1
3
5
6
17
30
255
1
8
30
Factor
Issue 2
January 1998
Page 34
Page 41
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Hardware and Software
Table of Hardware and Software Capacities (
CTI Link1
Direct Inward Dialing
Number of blocks
Number of trunks
Data Hunt Groups
Number of groups
Members per group
Groups per member
Directories
System Directory
Listings
Extension Directory
Listings
Personal Directory (MLX-20L only)
Listings
100D Module (maxi mum 2 per carrier)3
800 NI-BRI Module
(maximum 3 per carrier)
Endpoints (devices)255
Extensions
Total physical jacks
Total endpoints
Fax machines with Message Waiting16
Lines/Trunks80
Night Service
Groups
Members per group
Calling groups per group
Groups per member
Emergency Allowed List entries
System Operating Consoles
Direct-line consoles (DLCs)
MLX-20L or MLX-28D
BIS-22D, BIS-34D, or MERLIN II Sys-
tem Display Consoles
QCCs
DSSs
Combination of DLCs plus QCCs
Number of consoles per module
Park codes (number of codes)8
Personal Lines64
continued
Limit
130
200
200
255
255
Constraining
2
80
32
20
1
1
1
48
50
5
8
1
8
10
8
8
4
16
8
2
)
Factor
Issue 2
January 1998
Page 35
Page 42
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Hardware and Software
Table of Hardware and Software Capacities (
Pool Buttons64
Ports (not simultaneously)
Total extensions (dialable)
Voice and Data (physical pools)
Voice Announce to Busy extensions
Voice-Mail interface (VMI)
ISDN Terminal Adapter
Paging
Delay announcements
Remote Access
Number of barrier codes
Digits per code, systemwide
Shared System Access Buttons
Number of buttons per principal extension
Speed Dial
Personal Speed Dial
Entries per telephone
Entries per system
Digits per entry
System Speed Dial
Entries per system
Digits per entry
System Programming Equipment
MLX-20L
RS-232 jack for PC with SPM
Modem (built in processor module)
Telephones (not simultaneously)
Analog multiline
Without Voice Announce to Busy
With Voice Announce to Busy
MLX-20L
All other MLX telephones
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Hardware and Software
Constraining Factors
This section describes the constraining factors that limit the
capabilities supplied in the table above.
Calling Groups
Members of groups
because the QCC position is set up as a system operator and has
its own queue that is different from the group’s queue.
Carriers
The first slot of the basic carrier is used for the processor module.
Coverage Groups
Senders per group
have coverage available and use Position-Busy instead.
CTI Link
One CTI link is supported in Hybrid/PBX mode only.
Fax machines with Message-Waiting
The system can support more than 16 fax machines, but those in
excess of 16 cannot use fax message-waiting indication.
System Operator Consoles
DLCs
. Two consoles are allowed for each MLX or analog module,
with a maximum of eight per system. Up to two DSSs can be
attached to an MLX operator console, and one is built into the
MERLIN II System Display Console.
QCCs
. Two consoles are allowed for each MLX module with a
maximum of four per system.
Ports (not simultaneously)
Voice-Mail interface
24 VMI ports, all the VMI ports must be in the same calling group,
and the maximum number of extension in a calling group is 20.
Speed Dial
Personal Speed Dial
System Programming Equipment
Remote access overrides on-site programming except during
backup or restore.
Telephones (not simultaneously)
Analog multiline with/without Voice Announce to Busy
ports/board.
MLX-20L
. RAM limit and the total includes the MLX-20L telephone
used for system programming.
All other MLX telephones
adapter cannot be connected to the same telephone (including the
MLX-20L) at the same time.
Single-line
Power failure transfer
Traffic (100 call seconds/hr/system)
Assumes 20 percent internal traffic.
Two-party conversati ons
216 time slots.
. QCCs cannot be members of calling groups
. QCCs cannot be senders because they do not
. Although the system software supports up to
. Single-line and 5- or 10-button telephones.
. 17 slots x 8
. RAM limit. An MFM and a ISDN terminal
. RAM limit
. 1 for each 4 LS/GS line/trunk jacks.
Issue 2
January 1998
Page 37
Page 44
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Ordering Codes
Ordering Codes
ComponentPECComcode App. Code
Control Unit
MERLIN LEGEND R6 Control Unit 6140-CU6
Power Supply Module107184848 391A3
Translation Card107779878 10A2
English (black)3156-0DB 107894735 7712D06D-003
English (white)3156-0DW 107894743 7712D06D-264
MLX-10
English (black)3156-02B107108722 7712D01D-003
English (white)3156-02W 107108748 7712D01D-264
French (black)3156-F2I107108797 7712D01D(29)-003
French (white)3156-F2I107108789 7712D01D(29)-264
Spanish (black)3156-S2I107108755 7712D01D(22)-003
Spanish (white)3156-S2I107108771 7712D01D(22)-264
MLX-10D
English (black)3156-03B107108870 7712D02D-003
English (white)3156-03W 107108888 7712D02D-264
French (black)3156-F3I107108938 7712D02D(29)-003
French (white)3156-F3I107108920 7712D02D(29)-264
Spanish (black)3156-S3I107108904 7712D02D(22)-003
Spanish (white)3156-S3I107108912 7712D02D(22)-264
MLX-10DP
English (black)3156-06B107108946 7712D04D-003
English (white)3156-06W 107108953 7712D04D-264
Issue 2
January 1998
Page 43
Page 50
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Ordering Codes
Ordering Codes (
ComponentPECComcodeApp. Code
Telephones (
MLX Telephones (
MLX-16DP
English (black)3156-07B 106922271 7715D01D-003
English (white)3156-07W 106922289 7715D01D-264
Spanish (black)3156-S7I 106987423 7715D01D(22)-003
Spanish (white)3156-S7I 106987456 7715D01D(22)-264
French (black3156-F7I 106987472 7715D01D(29)-003
French (white)3156-F7I 106987498 7715D01D(29)-264
East. Europe (black)3156-EE7 106987506 7715D01D(30)-003
East. Europe (white)3156-EE7 106987514 7715D01D(30)-264
MLX-20L
English (black)3156-05B 107108979 7713D01D-003
English (white)3156-05W 107108987 7713D01D-264
French (black)3156-F5I 107109027 7713D01D(29)-003
French (white)3156-F5I 107109019 7713D01D(29)-264
Spanish (black)3156-S5I 107108995 7713D01D(22)-003
Spanish (white)3156-S5I 107109001 7713D01D(22)-264
MLX-28D
English (black)3156-04B 107115800 713D02D-003
English (white)3156-04W 107115818 713D02D-264
French (black)3156-F4I 107115842 7713D02D(29)-003
French (white)3156-F4I 107115859 7713D02D(29)-264
Spanish (black)3156-S4I 106613599 7713D02D(22)-003
Spanish (white)3156-S4I 106613607 7713D02D(22)-264
MLX Secure Telephones
MLX-10DS
English (black)3156-03S 107185076 7712D02D1-003
MLX-28DS
English (black)3156-04S 107185050 7713D02D1-003
MLX-20LS
English (black)3156-05S 107185068 7713D01D1-003
Fiber Interface Card
with Ring Generator61393406981217 93030.2 FIB INT PRN
Chassis with Power
Supply, Blank Cover6139-SFS 406981225 93030.8C MINI
800 LS Card61394406981241 903030.3 2 WIRE PRN
Inactive MLX Telephones
MLX-5
French (black)107926834 7712D05D(29)-003
French (white)107926842 7712D05D(29)-264
Spanish (black)107926859 7712D05D(22)-003
Spanish (white)107926867 7712D05D(22)-264
Hungarian (black)107926875 7712D05D(30)-003
Hungarian (white)107926883 7712D05D(30)-264
MLX-5D
French (black)107926891 7712D06D(29)-003
French (white)107926909 7712D06D(29)-264
Spanish (black)107926917 7712D06D(22)-003
Spanish (white)107926925 7712D06D(22)-264
Hungarian (black)107926933 7712D06D(30)-003
Hungarian (white)107926941 7712D06D(30)-264
English (black)3156-DCB 106902463 604B1-003
English (white)3156-DCW 106902489 604B1-264
Spanish (black)3156-SDI107013294 604B1(22)-003
Spanish (white)3156-SDI107013302 604B1(22)-264
Inactive Consoles
MERLIN II105229744 7318H01A-003
System Display Console
continued
continued
)
)
Page 54
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Ordering Codes
Ordering Codes (
ComponentPECComcodeApp. Code
continued
)
Applications
SPM Version 2.16–DOS61495107259905
SPM Version 2.16–UNIX61496107259913
SPM Version 3.18–DOS61495107259905
SPM Version 3.18–UNIX61496107259913
SPM Version 4.15–DOS61508107886608
SPM Version 4.15–UNIX61509107886624
SPM Version 5.15–DOS61515108007774
SPM Version 5.15–UNIX61514108007782
SPM Version 6.15–DOS61526108096132
SPM Version 6.15–UNIX61527A108096140
Single Site, 50 stations1201-011
Single Site, 200 stations1201-012
Inactive CAS
CAS Plus V3.1.1
Bundle, Model 300
(does not include a printer)
Custom Rate Table
CAS Plus V3 Bundle
w/80-col. Parallel Printer
CAS Plus V3 Bundle
w/132-col. Parallel Printer
CAS Plus V3 Software406362244
Rate Table*
CAS Plus V3 Update (SW)406158444 3300EA51
CAS Plus upgrade406025916 3300KA2U
CAS V3 Hacker Tracker406774513 3399EA
(MS-DOS)
UNIX CAS Rate Tables406140764 3.5 SW ATT MTS
* Consult Lucent Technologies for other area-specific information.
Issue 2
January 1998
Page 48
Page 55
DEFINITY ECS Release 6
System Description Pocket Reference
Port406941542 3100-F1-550
Straight-Thru Cable
Terminal/Printer406941534 3100-F1-540
Modular DC Voltage Adapter406941492 3100-F1-250
Wall Mount Kit406941674 3100-F1-400
Cables for Mounting
25’ D4BU-29 Cord106472921 ASSY-4400-F1-
2’ D4BU-29 Cord106472905 ASSY-4400-F1-
Dial Back Modem FLD106842271 ASSY-3400-F2-
Dial Back Modem FAC106842289 ASSY-3400-G2-
Dial Back Modem NFLD106842305 ASSY-4000-F2-
Dial Back Modem NFAC106842297 ASSY-4000-G2-
Prism MUX Field106842313 ASSY-3400-F2-
CSU
533
530
201
201
201
201
200
Issue 2
January 1998
Page 58
Page 65
DEFINITY ECS Release 6
System Description Pocket Reference
Handset cord, 9’ (2.74 m), black105635429 H4DU-003 9 FT
Handset cord, 9’ (2.74 m), white105701809 H4DU-264 9’BULK
Handset cord, 12’ (3.66 m), black102401445 H4DU-3 12FT IP
Handset cord, 12’ (3.66 m), white102402609 H4DU-26412’IP
Handset cord, 25’ (7.62 m), black105523866 H4DU-3 25’
DSS line cord, 2’ (61 cm)106187545 CORD D8AC-87
Desk Stands and User Trays
Stand (large, black)846320851 S TAND-LARGE BL
Stand (large, white)846320844 S TAND-LARGE WH
Stand (small, black)846320810 STAND-SMALL BL
Stand (small, white)846320802 STAND-SMALL WH
User tray (black)846320240 USER TRAY DWR B
User tray (white)846320232 USE R TRAY DWR W
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Ordering Codes
Ordering Codes (
ComponentPECComcodeApp. Code
Analog Multiline Telephones—Miscellaneous Add-Ons/
Replacement Parts (
Button Label Sheets (
Display console (FM1)
(includes one faceplate)105299754 KIT PRTS-D-181727
Display console (FM2 & R3)
(includes one faceplate)105486252 KIT PRTS-D-182041
continued
continued
continued
)
)
)
Single-Line Telephones—Miscellaneous Add-Ons
Ground-Start Button31021405792839 Key-KS23566L1
Wiring Kits
Interconnect Wiring Kit
110AB1-100JP12104409396
110A1 trough104407960
D-Rings842139248
D8W cords103786802
Parts list
SYSTIMAX
CAT 3 Standard 4-Pair Wire 2782-004
CAT 3 Additional 4-Pair Run 2783-MU3
CAT 5 Standard 4-Pair Wire 2782-CT5
CAT 5 Additional 4-Pair Run 2782-MU5
®
MERLIN Wiring Kit3103-MER 106393671
110A1 trough (5)104407960
110AB1-100JP12
modular block (2)104409960
110AB1-100 FT punch
down block (1)103823845
D-Rings (6)842139248
Patch cords 12 cords,
4-pair, 5' (1.5 m)846619989
D8W cords
24 cords, 14' (4.3 m)103786802
Template846613933
Instruction sheet846613941
Parts List846623924
Issue 2
January 1998
Page 68
Page 75
DEFINITY ECS Release 6
System Description Pocket Reference
Ordering Codes
NOTES
555-230-211
Issue 2
January 1998
Page 69
Page 76
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Control Unit Modules
Control Unit Modules
ModuleTrunk TypeExtension Typ e
ProcessorN/AN/A
Power supplyN/AN/A
Issue 2
January 1998
Page 70
008N/A Analog multiline telephone; Call
008 MLXN/AMLX telephone; digital data device
008 OPTN/AOn-premises or off-premises
Management System; analog data
via a modem
(such as the ISDN terminal adapter)
CTI link connected to Passageway
Telephony services for NetWare
single-line telephone
Page 77
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Control Unit Modules
Specifications
Highlights: 68EC020 processor at 16 MHz, built-in 1200/2400-bps modem;
built-in diagnostics; Hybrid/PBX, Key, or Behind Switch mode option; 1.5 MB
RAM backup for 4 days; PCMCIA interface
Ports: Three RS-232-C ports. One for debugging (plugged to prevent
access), one for SMDR, and one for system administration
Power input: 117 VAC
Power output: +5 VDC (10 A), -5 VDC (2.50 A), -48 VDC (2.05 A)
Capacity: 54 unit loads
Capacity: 8 analog extensions
Signaling: Analog multiline telephone protocol (40 kbps)
Loop range: 1000 feet (305 m), in-building or in-range out-of-building (with
analog IROB protectors) only
Capacity: 8 digital extensions, each with 1 or 2 endpoints (each endpoint
assigned a separate extension number), including these extension types:
■ CTI link (only one per system)
■ digital voice only
■ digital voice with Voice Announce to Busy
■ digital voice and digital data (via ISDN terminal adapter)
■ digital voice and analog data
■ digital data only (ISDN Terminal Adapter)
Signaling: BRI S/T protocol (two 64-kbps B channels, one 16-kbps
D channel) on a passive bus
Power: 48 VDC phantom power to telephone, 48 VDC over a separate pair
(7–8) to an operator console with a DSS
Loop range: 3000 feet (914 m), in-building or in-range out-of-building (with
MLX IROB protectors) service only
Capacity: 8 T/R extensions* on 2-way voice transmission path with support
for telephones with message-waiting LEDs; built-in ring generator; 2 TTRs
Notice to Telephone Company: Meets FCC Class C
Ringing cur rent: 75-Vrms, 20-Hz trapezoidal ringing superimposed on -48
VDC.
REN: ≤ 1.0 per port
Disconnect signal: 900 ms (T/R short for answering machines, G3 fax, etc.)
Switchhook flash detection: 300–1200 ms
Loop resistance: Serves 2-wire loops to 1300 ohms, including extensions
dB loss†: 3dB (factory setting), 0dB if all calls are to another OPT station.
* The system recognizes the OPT module as an 012 module having 12
ports. However, the OPT module has only 8 jacks. Therefore, each
installed OPT module decreases the system’s capacity by 4 ports.
† If one OPT station calls another OPT station, the loss values of the two
OPT stations are added resulting in transmission levels that are too low.
008 OPT modules (517D28) may be hardware configured to 0dB loss,
however this should only be done if all or the maj ority of cal ls fr om the OPT
stations are to other OPT stations. Setting the loss value to 0dB violates
EIA-464-A-1 specifications. Contac t Tier 4 before modi fying the l oss val ue
settings of 008 OPT modules.
Issue 2
January 1998
Page 71
Page 78
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Control Unit Modules
Control Unit Modules (
continued
)
ModuleTrunk Type Extension Type
012 (T/R)
+ Ring Generator
N/ASingle-line telephone; AT&T Attendant;
MERLIN MAIL Voice Messaging System;
T/R adjunct (such as an answering or fax
machine); analog data device (such as a
modem)
REN: ≤ 4.0 per port
Disconnect signal: 900 ms (T/R short for answering machines, G3 fax, etc.)
Switchhook flash detection: 300–1200 ms
Capacity: 16 T/R extensions on 2-way voice transmission path with support
for telephones with message-waiting LEDs; 4 TTRs; built-in ring generator
REN: ≥ 4.0 per port
Disconnect signal: 900 ms (T/R short for answering machines, G3 fax, etc.)
Switchhook flash detection: 300–1200 ms
Capacity: 24 trunks for voice and analog data or 23 trunks for voice and data
with 1 channel used for signaling
Mode: Multiplexes 24 or 23 trunks into 1 facility and demultiplexes 1 facility
into 23 or 24 trunks
Speed: Up to 64 kbps
Signaling: DS1 over 4-wire; T1 uses robbed-bit or common-channel, PRI
uses 23 B+D
Capacity: Eight modular jacks each supporting one Digital Subscriber Line
Mode: National ISDN 1
Speed: Up to 64 kbps
Signaling: ISDN Basic Rate 2B+D
Capacity: 4 trunks, 4 TTRS, 1 PFT telephone
Signaling: Loop-start
Capacity: 4 tie lines
Method of completion: Automatic start, immediate-start, wink-start, or
delay-dial-start
Signaling: E&M type 1S, type 1C, type 5
Capacity: 4 trunks, 4 TTRs, 1 PFT telephone
Signaling: Loop-start or ground-start, optioned per port
Issue 2
January 1998
Page 73
Page 80
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Control Unit Modules
Control Unit Modules (
continued
)
ModuleTrunk Type Extension Type
408*
Loop-start Analog multiline telephone; Call
Management System; PFT telephone
Issue 2
January 1998
Page 74
408 GS/LSLoop-start or
408 GS/LS-MLX Loop-start or
800†
800 DIDDirect Inward
800 GS/LSLoop-start or
800 GS/LS-ID Loop-start or
* Although these MERLIN II modules are supported, the 400 GS/LS, the 408
GS/LS, and the 408 GS/LS-MLX are the recommended modules.
† Although this MERLIN II module is supported, the 800 GS/LS is the
recommended module.
ground-start
ground-start
Loop-startPFT telephone
Dialing
ground-start
ground-start
Analog multiline telephone; Call
Management System; PFT telephone
MLX telephone; digital data device (such
as ISDN Terminal Adapter)
CTI link connected to Passageway
Telephony services for NetWare
N/A
PFT telephone; button needed for
ground-start PFT
Calling number identification on MLX
display telephones. Calling number
identification is not available on
ground-start trunks
Page 81
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Control Unit Modules
Specifications
Capacity: 4 trunks, 8 extensions, 1 PFT telephone
Extension signaling: Analog multiline telephone (40 kbps)
Trunk signaling: Loop-start trunk, analog voice
Loop range: 1000 feet (305 m), in-building or in-range out-of-building
(with analog IROB protectors) only
Capacity: 4 trunks, 8 extensions, 1 PFT telephone
Extension signaling: Analog multiline telephone (40 kbps)
Trunk signaling: Loop-start or ground-start trunk (optional per port); voice
Loop range: 1000 feet (305 m), in-building or in-range out-of-building
(with analog IROB protectors) only
Capacity: 4 trunks, 8 digital extensions, 1 PFT telephone, 1 CTI link
Extension signaling: BRI S/T protocol (two 64-kbps B channels, one
16-kbps D channel) on a passive bus
Trunk signaling: Loop-start or ground-start trunk (optional per port), analog
voice
Loop range: 3000 feet (914 m), in-building or in-range out-of-building
(with MLX IROB protectors) only
trunks; no outgoing calls
Signaling: Loop-reverse battery; wink-start or immediate-start; accepts
touch-tone dialing
Capacity: 8 trunks, 2 PFT telephones
Signaling: Loop-start or ground-start
Capacity: 8 lines/trunks, 2 PFT telephones, 2 TTRs
Signaling: Loop-start or ground-start
Protocol: Requires calling number identification service from central office
Issue 2
January 1998
Page 75
Page 82
DEFINITY ECS Release 6
System Description Pocket Reference
Adjunct Summary
Adjunct Summary
555-230-211
Issue 2
January 1998
Page 76
Equipment
Type
Alerts (AC)
Alerts (DC) ■ Any audible or visual alert that
Answer/
record
machine
* Cannot be connected to a QCC.
† latest 012 T/R Module (517H13)
Specifications
*
■ Any audible or visual alert that
operates on 20–30 Hz ringing
signals
■ Associated with a specific
extension (supplemental alert) or
works on a programmed trunk port
(external alert)
operates on 48-VDC ringing signals
■ Associated with a specific
extension (supplemental alert) or
works on a programmed trunk port
(external alert)
■ Industry-standard machine
■ Low ringer equivalence (less than
*
0.15 or (4.0† total REN for T/R port)
■ Ability to recognize 600-ms
disconnect signal or other means of
automatic disconnect (such as voice
reset disconnect timer, fixed
recording time)
DEFINITY ECS Release 6
System Description Pocket Reference
Adjunct Summary
555-230-211
Issue 2
January 1998
Page 77
LS or
Interface
GS/LS
Line/
Trunk
Jack
T/RMFMGPASAA
012/016
Extension
Jack
MLX
Extension
Jack
Analog
Extension
Jack
Analog
Extension
Jack
*
* Requires Universal Paging Access Module (UPAM) to provide 48 VDC.
Page 84
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Adjunct Summary
Adjunct Summary (
continued
Equipment
Type
Cordless
Telephone*
Credit Card
Verification
Terminal*
Dial Dictation*■ A device that requires contact
Direct Station
Selector
* Cannot be connected to a QCC.
Specifications
■ Must have touch-tone dialing
capability when connected via
MFM; rotary or touch-tone dialing
can be used on T/R port.
■ Single line
■ Must have touch-tone dialing
capability when connected via
MFM; rotary or touch-tone dialing
can be used on T/R port
closure can be used on LS/GS line
jack only with UPAM
■ A maximum of 2 DSSs can be
connected to an operator console.
■ A 329A power unit must be added to
an operator console having 2 DSSs.
■ Connects to DSS jack on operator
console
Lucent
Technologies
Products
5650 Cordless
Telephone
5481 Cordless
Telephone
5552 Cordless
Telephone
N/A
N/A
Direct Station
Selector (DSS)
Issue 2
January 1998
Page 78
Page 85
DEFINITY ECS Release 6
System Description Pocket Reference
Adjunct Summary
555-230-211
Issue 2
January 1998
Page 79
LS or
GS/LS
Line/
Trunk
Jack
T/RMFMGPASAA
012/016
Extension
Jack
Interface
MLX
Extension
Jack
Analog
Extension
Jack
Analog
Extension
Jack
Page 86
DEFINITY ECS Release 6
System Description Pocket Reference
Adjunct Summary
Adjunct Summary (
continued
Equipment
Type
Fax*
Group Calling
Delay
Announcement*
Hands-Free
Unit
Headset for
analog multiline
telephone
* Cannot be connected to a QCC.
Specifications
■ Must have touch-tone dialing
capability when connected via
MFM; rotary or touch tone dialing
can be used on T/R port.
■ Industry-standard analog interface.
■ Industry-standard announcement
device
■ Must provide automatic disconnect
■ Each calling group can have its own
announcement (maximum 32).
■ A device can provide delay
announcement for more than one
group.
■ For use with analog multiline
telephones
■ Connects directly to telephone
N/AStarset
555-230-211
Lucent
Technologies
Products
Model 1330
Answering
Machine
Digital
Announcement
Unit
5202A
Mirage
Supra
Supra NC
Issue 2
January 1998
Page 80
Page 87
DEFINITY ECS Release 6
System Description Pocket Reference
Adjunct Summary
555-230-211
Issue 2
January 1998
Page 81
LS or
GS/LS
Line/
Trunk
Jack
Interface
T/RMFMGPASAA
012/016
Extension
Jack
can also use
008 OPT
Extension
Jack
MLX
Extension
Jack
Analog
Extension
Jack
Analog
Extension
Jack
Page 88
DEFINITY ECS Release 6
System Description Pocket Reference
Adjunct Summary
Adjunct Summary (
continued
Equipment
Type
Headset for MLX
telephone
Headset
Adapter
Loudspeaker
Paging
Message
Waiting
Indicator
Modem■ If the modem supports touch-
Specification
N/AStarset
■ Connects directly to telephone
OTHER jack.
■ External paging system using
DTMF signaling connected to LS
or GS line jack
■ CPE paging systems require an
interface unit; if CPE has 2-wire
input, the PagePal interface
(5335-700) can be used.
■ For single-line telephones
■ Connects directly to telephone
tone dialing via the associated
data terminal, the keyboard can
be used for dialing.
■ If the modem does not support
touch-tone dialing, an a ssociated
basic (single-line) telephone can
be used for dialing.
555-230-211
Lucent
Technologies
Products
Mirage
Supra
Supra NC
PagePac Plus
Amplicenters D20,
D100, D300
PagePac Plus
Controller
PagePac 6
PagePac 6 Plus
Z34A (PEC 3 1032)
Issue 2
January 1998
Page 82
Page 89
DEFINITY ECS Release 6
System Description Pocket Reference
Adjunct Summary
555-230-211
Issue 2
January 1998
Page 83
LS or
GS/LS
Line/
Trunk
Jack
T/RMFMGPASAA
012/016
Extension
Jack
*
* For 2224G Modem only.
Interface
MLX
Extension
Jack
Analog
Extension
Jack
Analog
Extension
Jack
Page 90
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Adjunct Summary
Adjunct Summary (
Equipment
Type
Music-on-Hold*
Speakerphone ■ Connect directly to telephone
SMDR Printer ■ Connects to upper RS-232-C jack
* If you use equipment that rebroadcasts music or other copyrighted
materials, you may be required to obtain a copyright license from and pay
license fees to a third party such as the American Society of Composers,
Artists, and Producers (AS CAP) or Broadcas t Music Incor porated (BMI). Or
you can purchase a Magic on Hold system, which does not require you to
obtain such a license, from Lucent Technologies or an authorized dealer.
† Requires 2500SM telephone.
continued
Specifications
■ Any FCC-registered 8-ohm music
source or recorded announcement
device
■ For single-line telephones only
on processor module
■ Must be located within 50 feet
(15 m) of control unit or use ADU
to extend distance
DEFINITY ECS Release 6
System Description Pocket Reference
Adjunct Summary
555-230-211
Issue 2
January 1998
Page 85
LS or
Interface
GS/LS
Line/
Trunk
Jack
* Music Coupler required (PEC 61398).
† As of Release 4.0
T/RMFMGPASAA
012/016
Extension
Jack
*
MLX
Extension
Jack
†
Analog
Extensio n
Jack
Analog
Extension
Jack
Page 92
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
Power Supply Unit Load
Power Supply Unit Load Requirements
Unit Load Calculation Rules
Installed
Mode
Hybrid/PBX,
Modified Key,
or
Behind Switch
Square Key
or
Behind Switch
Square Key or
Behind Switch
* The 391A1 and 391A2 power supply units generally support 6 modules of
any type in Hybrid/PBX mode. However, if all 6 carrier slots meet the
following conditions, the unit load total may ex ceed 54 and aux iliary power
may be required:
Only MLX or analog multiline station modules are installed.
More than 45 MLX-20L or 34-button analog multiline telephones are
installed.
The 391A3 power supply has a maximum rating of 75 unit loads. Use this
power supply in place of a 391A1 or 391A2 on systems where unit loads
will exceed 54.
Auxiliary Power Units cannot be used with the 391A3 power supply.
† The 391A1 power supply unit generally supports 4 modules of any type in
Square Key mode.
Modules
4 or fewer
6*
Calculation
Not required
†
Not required
5 or more■ Use the “Unit Load Rating of
System Modules” table and
instructions below to determine
the estimated unit loads (ULs):
— If the ULs < 75 and the
391A3 power supply is used,
then no calculation is
required. If a 391A1 or 391A2
power supply is used and the
ULs > 54, then an auxiliary
power supply is needed or
replace the power supply
with a 391A3.
— If ULs > 75, reconfigure the
system so that the total ULs
do not exceed 75 per carrier.
Issue 2
January 1998
Page 86
Page 93
DEFINITY ECS Release 6
System Description Pocket Reference
EICON board (CTI link interface in NetWare server)0.0
DSS console†
MFM‡
General Purpose Adapter1.0
0.9
1.3
Hands Free Unit1.0
Headset adapter1.0
* Unit loads are computed per trunk.
† Up to two DSS consoles (one DSS per MLX-28D or MLX-20L) can be
powered from each control uni t carrier. For ex ample, a 3-carrier s ystem can
have 6 system operator positions, each with one DSS powered from the
control unit.
‡ The MFM is powered by an individual wall power uni t l ocated at the stati on.
Page 95
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
System Feature Availability by
System Feature Availability
by Operating Mode
FeaturePBXKey
Account Code Entry
Authorization Codes
Automatic Maintenance Busy
Automatic Route Selection
Callback
Calling Restrictions
Centrex Transfer via Remote
Call Forwarding
Coverage
Coverage VMS Off
CTI Link
Delayed Ring interval
Direct Inward Dialing
Direct-Line Console options
Direct Voice Mail
Directory
Extension Status
Forced Account Code Entry
Group Calling (DGC)
Headset Status
Hold disconnect
Inside dial tone
Labeling
Language selection
Loudspeaker Paging
Microphone Disable
Night Service
DEFINITY ECS Release 6
System Description Pocket Reference
555-230-211
System Feature Availability by
System Feature Availability
by Operating Mode (
FeaturePBXKey
Paging groups
Park
Pickup groups
Pools (trunk groups)
Queued Call Console options
Recall interval
Reminder Cancel
Remote Access
Remote Call Forward
Station Message Detail Recording
System Numbering
System Restart
System Speed Dial
Tandem Trunking
To l l Type
Touch-tone or rotary signaling
Transfer options
Uniform Dial Plan (UDP)
Voice Announce to Busy
