Lucent Technologies
User’s Guide
C
AJUN
M770
ATM S
WITCH
M
ANAGER
June 1999
Contents
List of Figures ................................................................................................... vii
List of Tables ..................................................................................................... ix
Chapter 1 Welcome to Cajun M770 ATM Switch Manager............................................. 1
The Purpose of this Manual............................................................................... 1
Who Should Use This Manual........................................................................... 1
Organization of this Manual ............................................................................... 1
Starting Cajun M770 ATM Switch Manager .................................................... 2
What To Do First ..................................................................................... 2
Running Cajun M770 ATM Switch Manager from Windows .............2
Running Cajun M770 ATM Switch Manager from UNIX ..................2
Using Zoom View................................................................................................ 3
Selecting Elements .................................................................................. 3
Using Zoom View Features .....................................................................3
Chapter 2 Agent Configuration............................................................................................ 7
Master Agent and Sub Agents............................................................................ 7
Overview of Agent Configuration...................................................................... 7
Downloading New Agent Software ........................................................7
Viewing the Agent Information Box.................................................................. 8
Designating Managers ........................................................................................ 8
Viewing the Managers Table ..................................................................9
Adding Managers to the Managers Table ..............................................9
Removing Managers from the Managers Table ....................................9
Editing the Managers Table .................................................................10
Chapter 3 ATM Switch Configuration.............................................................................. 11
Viewing ATM Switch Information .................................................................. 11
Viewing Module Configuration........................................................................ 12
Viewing Port Configuration.............................................................................. 13
Enabling Physical Ports .........................................................................14
Disabling Physical Ports ........................................................................15
Port PNNI Information .................................................................................... 15
Resetting Elements........................................................................................... 16
Resetting the ATM Switch ...................................................................16
Resetting the Module ............................................................................ 16
Viewing Neighbor Information........................................................................ 17
Cajun M770 ATM Switch Manager User’s Guide iii
Chapter 4 Fault Management ............................................................................................ 19
Configuring Traps ............................................................................................. 19
Viewing Traps.................................................................................................... 20
Viewing Traps in a Dialog Box .............................................................20
Viewing Traps in the Event Log ..........................................................20
Assigning Severity Degrees in UNIX.............................................................. 20
Accessing Severity Degrees ...................................................................20
Editing Severity Degrees ......................................................................21
Chapter 5 Monitoring Performance ................................................................................... 23
Viewing Port Counters......................................................................... 23
Viewing CPU Counters ....................................................................... 24
Viewing VC Counters.......................................................................... 25
Viewing LECS Statistics...................................................................... 26
Viewing Management LEC Counters................................................. 27
Chapter 6 Managing Switch VCs ....................................................................................... 29
Viewing All VC Connections for a Switch....................................................... 29
Viewing All VCs on a Port................................................................................. 30
Chapter 7 Managing LANE Services ................................................................................ 31
Resilient LANE................................................................................................. 31
Choosing the LES Address for a LEC............................................................. 31
Setting Up the LECS........................................................................................ 32
Configuring the Local LECS ................................................................32
Viewing Resilient LECS Table ............................................................32
Configuring the LECS ELANs Table .................................................33
Viewing Registered LESs .....................................................................35
Configuring the LES/BUS Table .........................................................36
Chapter 8 Managing Routing ............................................................................................. 39
Managing the Static Routes Table....................................................... 39
Viewing the Static Routes table ............................................................39
Updating the Static Routes Table ........................................................40
Managing the PNNI Table .................................................................. 40
Viewing PNNI information ...................................................................41
Editing the PNNI Summary Table ......................................................41
Appendix A Cajun M770 ATM Switch Manager Menus.................................................... 45
Configuration Menu.......................................................................................... 45
Performance Menu............................................................................................ 46
Administer Menu............................................................................................... 47
Help Menu......................................................................................................... 47
Appendix B Configuration Fields.......................................................................................... 49
iv Cajun M770 ATM Switch Manager User’s Guide
Appendix C Counter Fields ................................................................................................... 65
Appendix D Trap Fields ........................................................................................................ 69
Cajun M770 ATM Switch Manager User’s Guide v
vi Cajun M770 ATM Switch Manager User’s Guide
List of Figures
Figure 1.1 Zoom View .....................................................................................4
Figure 2.1 Agent Information Window.......................................................... 8
Figure 2.2 Managers Table .............................................................................9
Figure 3.1 Device Information Window ...................................................... 12
Figure 3.2 Module Configuration.................................................................13
Figure 3.3 Port Configuration.......................................................................14
Figure 3.4 Port PNNI Dialog Box................................................................16
Figure 3.5 Neighbor Information ................................................................. 17
Figure 3.6 Neighbor PNNI Info Window.................................................... 18
Figure 4.1 Traps Configuration Dialog Box ................................................19
Figure 5.1 Port Counters Window................................................................ 24
Figure 5.2 CPU Counters Window...............................................................25
Figure 5.3 VC Counters Window .................................................................26
Figure 5.4 LECS Statistics Window............................................................. 27
Figure 5.5 Management LEC Counters Window....................................... 28
Figure 6.1 Table of all VCs............................................................................29
Figure 6.2 Total VCs Window.......................................................................30
Figure 7.1 LECS Configuration Dialog Box ............................................... 32
Figure 7.2 Resilient LECS Table ................................................................33
Figure 7.3 LECS ELANs Table ..................................................................33
Figure 7.4 Expanded LECS ELANs Table................................................34
Figure 7.5 Registered LESs on ELAN Window......................................... 35
Figure 7.6 LES/BUS Table ..........................................................................36
Figure 7.7 Expanded LES/BUS Table........................................................ 37
Figure 7.8 LANE Clients on LES................................................................ 38
Figure 8.1 Static Routes Table.....................................................................39
Figure 8.2 Static Routes Add Dialog Box .................................................... 40
Figure 8.3 Static Routes Edit Dialog Box.................................................... 40
Figure 8.4 PNNI Information....................................................................... 41
Figure 8.5 PNNI Summary Table................................................................ 42
Figure 8.6 PNNI Summary Add Dialog Box...............................................42
Figure 8.7 PNNI Summary Edit Dialog Box .............................................. 43
Cajun M770 ATM Switch Manager User’s Guide vii
List of Figures
viii Cajun M770 ATM Switch Manager User’s Guide
List of Tables
Table 1.1 Zoom View Toolbar........................................................................4
Table A.1 Configuration Menu......................................................................45
Table A.2 Performance Menu........................................................................46
Table A.3 Administer Menu ..........................................................................47
Table A.4 Help Menu.....................................................................................47
Cajun M770 ATM Switch Manager User’s Guide ix
List of Tables
x Cajun M770 ATM Switch Manager User’s Guide
Chapter 1
Welcome to Cajun M770 ATM Switch Manager
Welcome to Cajun M770 ATM Switch Manager. This chapter provides an introduction
to the structure and assumptions of this manual. It includes the following sections:
•
The purpose of this manual
intended audience.
•
Organization of the manual
various chapters of the manual.
•
Starting Cajun M770 ATM Switch
Cajun M770 ATM Switch Manager from your management platform.
•
Using the Zoom View
Manager Zoom View, including instructions on how to select elements, and how to
use the menu bar and the toolbar buttons.
The Purpose of this Manual
The Cajun M770 ATM Switch Manager manual contains all of the information needed
to use the system efficiently and effectively. For information on managing Cajun M770
ATM Switches using a command line interface, refer to the
User's Guide
.
- A description of the goals of the manual and the
- A brief description of the subjects contained in the
Manager - Instructions on how to access
- A brief introduction to the Cajun M770 ATM Switch
Cajun M770 ATM Switch
Who Should Use This Manual
This manual is intended for network managers familiar with network management and
its fundamental concepts.
Organization of this Manual
This manual contains the following subjects:
• Chapter 1,
purpose and organization and gives instructions on starting the Cajun M770 ATM
Switch Manager and using the Cajun M770 ATM Switch Zoom View.
• Chapter 2,
explains how to view agent configuration and designate managers.
•Chapter 3,
Cajun M770 ATM Switch configurations.
•Chapter 4,
the agent.
Cajun M770 ATM Switch Manager User’s Guide 1
Welcome to Cajun M770 ATM Switch Manager
Agent Configuration
ATM Switch Configuration
Fault Management
, describes the Master Agent and Sub Agents and
, explains how to view and modify the different
, explains how to configure traps and view traps sent by
, describes the manual’s
Chapter 1 Welcome to Cajun M770 ATM Switch Manager
• Chapter 5,
counters, VC counters, Management LEC counters and LECS statistics.
• Chapter 6,
switch.
• Chapter 7,
their use with the Cajun M770 ATM Switch.
• Chapter 8,
PNNI.
• Appendix A,
structure of the menus in the Cajun M770 ATM Switch Manager.
• Appendix B,
mentioned in this manual.
• Appendix C,
• Appendix D,
• Appendix E,
• Appendix F, Reference Guide, provides in-depth descriptions of networking terms
and concepts.
Monitoring Performance
Managing Switch VCs
Managing LANE Services
Managing Routing
Cajun M770 ATM Switch Manager Menus
Glossary
Configuration Fields
Counter Fields
Trap Fields
, provides definitions for many of the terms and concepts
, provides a description of the trap fields.
, explains how to view Port counters, CPU
, explains how to list all SVC connections for a
, provides an overview of LANE services and
, explains how to manage the static routes table and
, provides a description of the configuration fields.
, provides a description of the counter fields.
Starting Cajun M770 ATM Switch Manager
The following sections provide instructions for starting the Cajun M770 ATM Switch
Manager from the various supported management umbrellas.
, provides the full menu
What To Do First
1 Login to the system using your account name.
2 Ensure that the management platform system is running correctly.
Running Cajun M770 ATM Switch Manager from Windows
To start Cajun M770 ATM Switch Manager from HP OpenView:
1 Double-click the icon representing the Cajun M770 ATM Switch you wish to work
with.
OR
1 Select the Cajun M770 ATM Switch.
2 Open the
Running Cajun M770 ATM Switch Manager from UNIX
If you are using
1 From the Management platform map, select the Cajun M770 ATM Switch you
wish to work with.
2 Open the
OR
2 Cajun M770 ATM Switch Manager User’s Guide
Lucent
Tools
menu and select
NetView/6000
menu and select
:
Lucent
Zoom
.
Device Manager
.
1 Right-click on the Cajun M770 ATM Switch you wish to work with.
2 Select
If you are using
1 From the management platform map, select the ATM Switch you wish to work
with.
2 Click in the OpenView toolbar.
OR
Open the
OR
1 Right-click on the Cajun M770 ATM Switch you wish to work with.
2 Select
Using Zoom View
The Cajun M770 ATM Switch Zoom View displays only the modules installed in the
ATM Switch now being managed. This does not include DomainX modules and ATM
modules of another switch in the same hub.
In order to manage DomainX modules, change the overall device configuration, and
view hardware configuration:
1 Click .
OR
Open the
Multifunction Switch Manager application appears.
For more information, refer to the
or on line-help.
Chapter 1 Welcome to Cajun M770 ATM Switch Manager
Lucent: Device Manager
.
OpenView 4.x (Solaris or HPUX)
menu and select
Tools
Lucent: Device Manager
Administer
menu and select
Lucent
.
Cajun M770 Multifunction Switch Manager User’s Guide
:
Device Manager
Launch Hub Manager
.
. The Cajun M770
Selecting Elements
Within the Zoom View, you can select the following elements:
•Modules
• Ports
To select an element, click it using the left mouse button. The selected element is
highlighted. To select multiple elements, press the CTRL key while clicking on each
element to be selected.
Using Zoom View Features
The Zoom View consists of a graphical representation of the hub, a Menu bar, and a
Toolbar. The Toolbar provides shortcuts to the main Zoom View functions.
In a Windows environment the toolbar may be displayed as a floating horizontal toolbar
or as a docked, vertical toolbar. To display the toolbar, open the
select
ToolBar
. A check is placed next to the Toolbar option when it is activated. To
Administer
menu and
dock the toolbar, drag it to the right edge of the Zoom View. To hide the toolbar, open
Cajun M770 ATM Switch Manager User’s Guide 3
Chapter 1 Welcome to Cajun M770 ATM Switch Manager
the
Administer
menu and select
Figure 1.1 Zoom View
ToolBar
.
The table below describes the Toolbar buttons and gives the equivalent menu options.
Table 1.1 Zoom View Toolbar
Icon Description Menu Item
Exit the application.
View M770 ATM Switch
Configuration
Configuration
Exit Zoom
Device Information...
information.
4 Cajun M770 ATM Switch Manager User’s Guide
Chapter 1 Welcome to Cajun M770 ATM Switch Manager
Table 1.1 Zoom View Toolbar (Continued)
Icon Description Menu Item
View the Managers table.
View M770 ATM Switch
Configuration
Configuration
Managers Table...
Agent...
agent information.
Launch Cajun M770
Administer
Launch Hub Manager...
Multifunction Hub for
viewing Ethernet modules,
device information, and
power supply
configuration.
View Static Routes
Configuration
Static Routes...
information.
View Switch VCs
Configuration
Switch VCs...
information.
Open on-line Help.
Help
Contents...
When placing the cursor on a toolbar icon for 1 second, a label appears with the name of
the button.
To open context-sensitive help, press ALT + H.
Cajun M770 ATM Switch Manager User’s Guide 5
Chapter 1 Welcome to Cajun M770 ATM Switch Manager
6 Cajun M770 ATM Switch Manager User’s Guide
Chapter 2
Agent Configuration
In order to ensure that your network or Cajun M770 ATM Switch works properly, your
network agent must be configured correctly. This chapter helps you manage your agent
and includes helpful configuration notes for the different types of agents. The following
sections are included:
• Overview of Master Agent and Sub Agents
• Overview of Agent Configuration
• Viewing Agent Configuration Information
• Designating Managers
Master Agent and Sub Agents
The Cajun M770 Switch is a fully distributed switch. Each module has its own
switching and CPU power supply. In order to present the switch as a single and united
entity, one module is automatically elected as a Master Agent while the other modules
are Sub Agents. The NMA (Network Management Agent) LED is lit on the module
which has been elected to be the Master Agent.
The Master Agent is the one hosting the Management LEC with all of its functionality:
IP Address and switch-wide information.
All the information configured on the Master Agent is backed up by the Sub Agents. If
the Master Agent is removed or reset, another module will be elected, and all previous
configuration settings will be kept.
Overview of Agent Configuration
The Master Agent is responsible for managing the modules contained in the hubs. The
Master Agent enables handling many of the Cajun M770 ATM Switch Manager
features, such as statistical reporting, configuration information and trap reporting.
If your agent is not properly configured for your network or can not communicate with
Cajun View, your network will not achieve its maximum functionality. Therefore, it is
essential that your agent is configured correctly.
Downloading New Agent Software
Downloading agent software is done using the Cajun Download Manager. For
instructions, refer to the on-line help for the Cajun Download Manager, or the
Download Manager User’s Guide
Cajun M770 ATM Switch Manager User’s Guide 7
included in the
Additional Applications User’s Guide
Cajun
.
Chapter 2 Agent Configuration
Viewing the Agent Information Box
Every agent has an Agent Information window that provides details about the agent. To
view the configuration of an agent:
1 Open the Cajun M770 ATM Switch Zoom View.
2 Click .
OR
Open the
displayed.
Figure 2.1 Agent Information Window
Configuration
menu and select
. The Agent Information window is
Agent
The Agent Information window provides detailed information about the agent such as
the agent type, the versions of its software, the agent’s addresses, and LEC information.
For a full description of the configuration fields in the Agent Information window, refer
to Appendix B,
Configuration Fields
.
Designating Managers
Agents send alarms to Manager workstations that are included in the agent's Manager
list. Alarms are not sent to any other network management stations (NMS).
If you wish to properly manage an ATM Switch, your station should be one of its
designated Managers. The Manager can be a Cajun M770 ATM Switch Manager station
or any other SNMP (Simple Network Management Protocol) management console.
Note:
Managers list using the command line interface.
8 Cajun M770 ATM Switch Manager User’s Guide
Refer to the
Cajun M770 ATM Switch User’s Guide
for a method of editing the
Viewing the Managers Table
To view the Managers list of a Cajun M770 ATM Switch:
1 Open the Cajun M770 ATM Switch Zoom View.
2 Click .
OR
Open the
Configuration
displayed.
Figure 2.2 Managers Table
menu and select
Chapter 2 Agent Configuration
Managers Table
. The Managers Table is
The dialog box lists the IP addresses and device names of the managers, and their trap
reporting status.
Adding Managers to the Managers Table
To add managers to the list:
1 Click on the IP address field and enter the IP address of the designated
management station. After the changes take effect, the management station’s name
will be displayed automatically in the
Device Name column, if available.
2 Repeat the procedure for each manager.
3 Click
. The change takes effect immediately.
Apply
Removing Managers from the Managers Table
To remove managers from the list:
1 Click on the IP address field.
2Enter
Cajun M770 ATM Switch Manager User’s Guide 9
0.0.0.0
.
Chapter 2 Agent Configuration
OR
Press DEL.
3 Repeat the procedure for each manager.
4 Click
Apply
.
Editing the Managers Table
To edit the managers list:
1 Click on the IP address field and change the IP address of the designated
management station. After the changes take effect, the management station’s name
will be displayed automatically in the
2 Click
. The change takes effect immediately.
Apply
3 Repeat the procedure for each manager.
Device Name
column, if available.
Note:
It is recommended to keep the list limited to actual and relevant managers, so as
not to place undue stress on the agent.
Note:
The indicated manager receives trap reports only when the Trap Report check
box for that manager is checked.
10 Cajun M770 ATM Switch Manager User’s Guide
Chapter 3
ATM Switch Configuration
This chapter explains how to view and set the various configuration parameters relevant
to the ATM Switches on your network. It includes the following sections:
• Viewing information about the Cajun M770 ATM Switch.
• Viewing configuration information for the Cajun M770 ATM modules.
• Viewing configuration information specific to the ports on the Cajun M770 ATM
modules.
• Viewing PNNI information specific to a selected port.
• Resetting various elements of the Cajun M770 ATM Switch.
• Viewing Neighbor Information.
Note:
To view agent configuration, refer to Chapter 2,
Viewing ATM Switch Information
The Device Information window provides high level information about the Cajun
M770 ATM Switch. To view information about the Cajun M770 ATM Switch:
1 Open the Cajun M770 ATM Switch Zoom View.
2 Click in the toolbar.
OR
Open the
Information window is displayed.
Configuration
menu and select
Agent Configuration
Device Information
.
. The Device
Cajun M770 ATM Switch Manager User’s Guide 11
Chapter 3 ATM Switch Configuration
Figure 3.1 Device Information Window
The Device Information window provides high level switch information, such as the
ATM Switch type, system name, contact, location, and description, and its ESI (MAC)
address.
Note:
after the switch is reset.
For a full description of the fields in the Device Information dialog box, refer to
Appendix B,
The Current ATM Prefix will be updated with the Configured ATM Prefix only
Configuration Fields
Viewing Module Configuration
The Module Configuration window provides information about the selected module.
To view the configuration of a Cajun M770 ATM module:
1 Open the Cajun M770 ATM Switch Zoom View.
2 Select a module by clicking its label.
3 Open the
OR
Double-click the module label.
OR
Right-click the module’s label and select
Configuration window is displayed.
Configuration
menu and select
.
Module.
Module Configuration
. The Module
12 Cajun M770 ATM Switch Manager User’s Guide
Chapter 3 ATM Switch Configuration
Figure 3.2 Module Configuration
The Module Configuration window provides module information such as the module
type and software version, slot number, serial number, and information about the
module’s configuration.
For a full description of the fields in the Module Configuration window, refer to
Appendix B,
Configuration Fields
.
Viewing Port Configuration
The Port Configuration dialog box provides you with information specific to a selected
port. To view the configuration of a port:
1 Open the Cajun M770 ATM Switch Zoom View.
2 Select a port by clicking on its symbol.
3 Open the
OR
Double-click a port symbol.
OR
Right-click a port and select
is displayed.
Cajun M770 ATM Switch Manager User’s Guide 13
Configuration
menu and select
Port Configuration
Configuration.
Port
. The Port Configuration dialog box
Chapter 3 ATM Switch Configuration
Figure 3.3 Port Configuration
The Port Configuration dialog box provides information such as the type of port and its
functionality, the current state of the physical port and the virtual port, and any faults
that occurred on the port. The fields in the Port Configuration dialog box may change
according to the type of port selected.
Note:
must be set to
Port Admin Status
To change the physical parameters of a port, the
disable
. To change the root virtual parameters of a port, the
must be set to
disable
.
Physical Port Admin Status
Root Virtual
For a full description of the fields in the Port Configuration dialog box, refer to
Appendix B,
Configuration Fields
.
Enabling Physical Ports
To enable a port:
1 Select the port in the Zoom View.
2 Open the
Configuration
menu and select
Enable Port
. A confirmation box is
displayed.
3 Click
14 Cajun M770 ATM Switch Manager User’s Guide
Yes
.
OR
1 Right-click the port and select
2 Click
Yes
OR
1 Open the Port Configuration dialog box.
2 Change the Admin Status of the Physical Port to “
selected port is enabled.
To enable more than one port:
1 Select multiple ports by holding down the CTRL key as you click the ports.
2 Open the
displayed.
3 Click
Yes
Disabling Physical Ports
To disable a port:
1 Select the port in the Zoom View.
2 Open the
displayed.
3 Click
Yes
OR
1 Right-click the port and select
2 Click
Yes
OR
1 Open the Port Configuration dialog box.
2 Change the Admin Status of the Physical Port to “
selected port is disabled.
Enable Port
.
Configuration
menu and select
. The selected ports are enabled.
Configuration
menu and select
.
Disable Port
.
Chapter 3 ATM Switch Configuration
. A confirmation box is displayed.
enable
Enable Port
Disable Port
” and click
. A confirmation box is
. A confirmation box is
Apply
. The
. A confirmation box is displayed.
disable
” and click
Apply
. The
To disable more than one port:
1 Select multiple ports by holding down the CTRL key as you click the ports.
2 Open the
Configuration
menu and select
Disable Port
. A confirmation box is
displayed.
3 Click
. The selected ports are disabled.
Yes
Port PNNI Information
The Port PNNI dialog box provides you with PNNI information specific to the selected
port. To view the Port PNNI dialog box:
1 Open the Cajun M770 ATM Switch Zoom View.
2 Select a port by clicking on its symbol.
Cajun M770 ATM Switch Manager User’s Guide 15
Chapter 3 ATM Switch Configuration
3 Open the
OR
Right-click a port and select
Figure 3.4 Port PNNI Dialog Box
The Port PNNI dialog box provides information about the port’s link type, number of
Hellos sent and received, and information about the calculation of the cost of routing to
and from the port. The weight of various cost factors may be edited in the dialog box.
To apply any changes to the fields in the dialog box, click
For a full description of the fields in the Port PNNI dialog box, refer to Appendix B,
Configuration Fields
Resetting Elements
Configuration
.
menu and select
. The Port PNNI dialog box appears.
PNNI
Port
PNNI
.
Apply
.
Modules in the Cajun M770 ATM Switch may be reset without resetting the entire
ATM switch.
Resetting the ATM Switch
To reset the entire Cajun M770 ATM Switch with all its modules and subsystems:
1 Open the
Configuration
menu and select
Reset
. A confirmation box is
Switch
displayed.
2 Click
. The entire switch is reset.
Yes
Resetting the Module
To reset a module:
1 Select a module.
2 Open the
Configuration
menu and select
Reset
Module
.
OR
Right-click a module and select
3 Click
16 Cajun M770 ATM Switch Manager User’s Guide
. Only the selected module is reset.
Yes
. A confirmation box is displayed.
Reset
Viewing Neighbor Information
The Neighbor Information window provides information on the neighbor device
connected to the port. If the attached device is a UNI device, only ILMI information is
displayed.
To view neighbor information:
1 Open the Cajun M770 ATM Zoom View and select a port.
2 Open the
OR
Right-click a port and select
displayed.
Figure 3.5 Neighbor Information
Configuration
menu and select
Neighbor Info
Chapter 3 ATM Switch Configuration
Port
Neighbor Info
.
. The Neighbor Info window is
The Neighbor Info window provides information about the neighbor device connected
to the port such as its name and addresses.
Note:
ILMI information is displayed only if ILMI is enabled.
If the neighbor device is a PNNI device, you can view its PNNI information by
expanding the Neighbor Info window. To expand the Neighbor Info window:
1 Click
Cajun M770 ATM Switch Manager User’s Guide 17
Neighbor PNNI Info
. The Neighbor PNNI Info window is displayed.
Chapter 3 ATM Switch Configuration
Figure 3.6 Neighbor PNNI Info Window
To hide the neighbor PNNI information, click
Close PNNI Info
.
For a full description of the configuration fields in the Neighbor Info window, refer to
Appendix B,
Configuration Fields
.
18 Cajun M770 ATM Switch Manager User’s Guide
Chapter 4
Fault Management
Fault management consists of the following:
•
Configuring Traps
the event log.
•
Viewing Traps
In UNIX:
•
Severity Degrees
Configuring Traps
A trap is an SNMP message sent by the agent to its managers. Trap messages may
appear in the affected port configuration windows of the management stations listed in
the Managers Table. You can set the types of traps that the agent forwards to the
management station which you are configuring.
- Defining the types of traps that are sent to the managers and
- Viewing the traps sent by the agent.
- Defining, accessing and understanding severity degrees.
To configure traps:
1 Open the
appears.
Figure 4.1 Traps Configuration Dialog Box
2 Select the check boxes for the types of traps that you want the agent to forward to
the management station that you are configuring.
3 Click
For a full description of the traps in the Traps Configuration dialog box, refer to
Appendix D,
Cajun M770 ATM Switch Manager User’s Guide 19
Configuration
.
Apply
Trap Fields
menu and select
.
Traps
. The
Traps Configuration
dialog box
Chapter 4 Fault Management
Viewing Traps
Traps that are sent by the agent to its managers may be viewed in two places:
• In the Port Configuration dialog box.
• In the Event Log.
Viewing Traps in a Dialog Box
A list of traps sent by the agent is maintained by the management application. The list
can be viewed in a dropdown list box in the Port Configuration dialog box of the
appropriate port.
Viewing Traps in the Event Log
HP OpenView maintains a list of all traps sent by the agents on the network. They may
be viewed by opening the Event Log from the HP OpenView network map window.
For a full description of the Event Log, refer to the
Assigning Severity Degrees in UNIX
HP OpenView Administrator’s Guide
.
Management applications, using the Event Configuration application, allow you to set
fault severity degrees system-wide, (for all hubs on the network simultaneously), or for
specific hubs (per IP). If the system-wide setting and an individual hub's setting
disagree, the individual hub's setting takes precedence.
For more information refer to
Accessing Severity Degrees
Only events whose category is “Status Events” affect the device’s status. Events in this
category may be found under the enterprises Lannet (.1.3.6.1.4.1.81) and CajunM770
(.1.3.6.1.4.1.81.17.1.15).
Severity degree settings may be accessed from the Event Configuration application. To
open the Event Configuration application:
1 From the umbrella management application, open the
Lucent
OR
Open the
application appears.
20 Cajun M770 ATM Switch Manager User’s Guide
Event Configuration
Options
menu and select
Severity Degrees
.
in
The Reference Guide
Event Configuration
.
menu and select
Tools
.The Event Configuration
Editing Severity Degrees
Severity degrees may be changed for faults on a system-wide basis, or for specific hubs
(per IP).
Chapter 4 Fault Management
Caution:
Do not change the Event Object Identifier of a fault.
Editing Severity Degrees System-Wide
To edit severity degree settings system-wide:
1 Select the enterprise which contains the fault whose settings you want to edit. A list
of the faults under the enterprise appears in the
Event Identification
window.
2 Select the fault whose settings you want to edit.
3 Open the
menu and select
Edit
Modify Event
.
OR
Double-click the fault whose settings you want to edit. The Event Configurator
window appears.
4 Change the severity setting using the
5 Click
OK
.
Severity
pull-down list.
6 Save the changes.
— In HP OpenView: Select
— In NetView: Click
Apply
File
.
Save
.
Editing Severity Degrees for Specific Hubs
To edit severity degree settings for specific hubs:
1 Select the enterprise which contains the fault whose settings you want to edit. A list
of the faults under the enterprise appear in the
Event Identification
window.
2 Select the fault whose settings you want to edit.
3 Copy the fault by opening the
menu and selecting
Edit
Copy Event
. The Event
Configurator window appears.
4 Enter a name for the fault in the
5Set
to the IP address/es of the specific hub/s you want the changes to be
Source
Event Name
field.
effective on.
6 Change the severity setting using the
7 Click
OK
.
Severity
pull-down list.
8 Save the changes.
— In HP OpenView: Select
— In NetView: Click
Apply
File
.
Save
.
Cajun M770 ATM Switch Manager User’s Guide 21
Chapter 4 Fault Management
Note:
All changes to the severity degrees will only take effect after the changes are
saved.
Refer to the HPOV Event Configuration application help for more information.
22 Cajun M770 ATM Switch Manager User’s Guide
Chapter 5
Monitoring Performance
This chapter explains the available options for monitoring the performance of
supported ATM Switches. It includes the following sections:
•
Viewing Port Counters
•
Viewing CPU Counters
AAL5 interface of the CPU in each module.
•
Viewing VC (Virtual Channel) Counters
for each VC.
•
Viewing LECS Statistics
module.
•
Viewing Management LEC Counters
Management LEC information of the switch.
Viewing Port Counters
The Port Counters table lets you accurately view the packet flow activity of each port.
Once you learn the normal packet activity for your network, Port Counters can help you
determine network malfunctions, bottlenecks, and overloads.
To view Port Counters from the Cajun M770 ATM Switch Zoom View:
1 Select a port or ports to be monitored.
— To select a single port, click the port’s symbol.
— To select multiple ports, hold the CTRL key as you click additional ports.
— To select all ports of a module, click the module’s symbol.
2 Open the
window is displayed.
Performance
menu and select
- Provides a breakdown of the activity through each port.
- Displays a breakdown of the packets going through the
- Displays a breakdown of the cells
- Displays a breakdown of the LECS statistics in each
- Displays a breakdown of the
Port Counters
. The Port Counters
Cajun M770 ATM Switch Manager User’s Guide 23
Chapter 5 Monitoring Performance
Figure 5.1 Port Counters Window
Unicast Ethernet Packet Counters are gathered for each selected port. The display is
updated automatically approximately every thirty seconds. To manually update the
display, click
Click
Clear Counters
Counters
button appears in the
Start
.
the counters are not reset on the agent.
For a full description of all port counters, refer to Appendix C,
to reset all counter values to 0. The exact time you click the
Counters Cleared At
field. When you click this button,
Counter Fields
.
Clear
Viewing CPU Counters
The CPU Counters table enables you to view at a glance a breakdown of the bytes and
packets going through the AAL5 interface of the CPU in a selected module.
To view CPU Counters from Zoom View:
1 Select a module to be monitored.
— To select multiple modules, hold the CTRL key as you click additional
modules.
2 Open the
Performance
OR
Right-click the module label and select
is displayed.
24 Cajun M770 ATM Switch Manager User’s Guide
menu and select
CPU Counters
CPU Counters
.
. The CPU Counters window
Chapter 5 Monitoring Performance
Figure 5.2 CPU Counters Window
CPU Counters are gathered for each selected module. The display is updated
automatically approximately every thirty seconds. To manually update the display, click
.
Start
Click
Clear Counters
Counters
button appears in the
to reset all counter values to 0. The exact time you click the
Counters Cleared At
field. When you click this button,
Clear
the counters are not reset on the agent.
For a full description of all CPU counters, refer to Appendix C,
Counter Fields
.
Viewing VC Counters
The VC Counters table enables you to view at a glance the number of cells received for
each VC on the module’s CPU port or a selected port.
To view VC Counters from Zoom View:
1 Select a module or port to be monitored.
2 Open the
Performance
OR
Right-click a module and select
displayed.
Cajun M770 ATM Switch Manager User’s Guide 25
menu and select
VC Counters
VC Counters
.
. The VC Counters window is
Chapter 5 Monitoring Performance
Figure 5.3 VC Counters Window
VC Counters are gathered for each selected module or port. The display is updated
automatically approximately every thirty seconds. To manually update the display, click
.
Start
Click
Clear Counters
Counters
button appears in the
the counters are not reset on the agent.
For a full description of all VC counters, refer to Appendix C,
to reset all counter values to 0. The exact time you click the
Counters Cleared At
field. When you click this button,
Counter Fields
.
Clear
Viewing LECS Statistics
The LECS Statistics window enables you to view the number of configuration requests
successfully granted or rejected by the LECS on the module.
To view LECS Statistics from Zoom View:
1 Select a module to be monitored.
2 Open the
Performance
menu and select
LECS Statistics
window is displayed.
26 Cajun M770 ATM Switch Manager User’s Guide
. The LECS Statistics
Chapter 5 Monitoring Performance
Figure 5.4 LECS Statistics Window
LECS Statistics are gathered for each selected module for which the local LECS is
enabled. The display is updated automatically approximately every thirty seconds. To
manually update the display, click
Click
Clear Counters
Counters
button appears in the
to reset all counter values to 0. The exact time you click the
Counters Cleared At
Start
.
Clear
field. When you click this button,
the counters are not reset on the agent.
For a full description of all LECS statistics, refer to Appendix C,
Counter Fields
.
Viewing Management LEC Counters
The Management LEC Counters window lets you view the amount of traffic flowing
between the management LEC and a chosen module. Counters are displayed for the
following types of traffic:
•Bytes
• Packet information
• Frame error information
• LAN Emulation information
You can also view the total number of bytes that the management LEC receives and
transmits, the number of frames that the management LEC discards, and the number of
SVCs (Switched Virtual Connections) that have failed to be set up.
To view Management LEC Counters:
1 Open the
Performance
LEC Counters window appears.
Cajun M770 ATM Switch Manager User’s Guide 27
menu and select
Mng LEC Counters
. The Management
Chapter 5 Monitoring Performance
Figure 5.5 Management LEC Counters Window
Management LEC Counters are gathered on the Master Agent. The display is updated
automatically approximately every thirty seconds. To manually update the display, click
.
Start
Click
Clear Counters
Counters
button appears in the
the counters are not reset on the agent.
For a full description of all Management LEC counters, refer to Appendix C,
.
Fields
to reset all counter values to 0. The exact time you click the
Counters Cleared At
field. When you click this button,
Counter
Clear
28 Cajun M770 ATM Switch Manager User’s Guide
Chapter 6
Managing Switch VCs
Managing switch VCs enables you to list all VC connections for a switch and to view a
list of all traffic descriptions.
Viewing All VC Connections for a Switch
You can view a breakdown of the connections that are currently set up on the Cajun
M770 ATM Switch. To list all VCs:
1 Click .
OR
Open the
appears.
Figure 6.1 Table of all VCs
Configuration
menu and select
Switch VCs
. A table listing all the VCs
The Switch VCs table provides a statistical breakdown of point-to-point and point-tomultipoint connections that are currently set up on a Cajun M770 ATM Switch.
To update the Table of All VCs:
1 Click
For a description of the fields in the Table of All VCs, refer to Appendix B,
Fields
Cajun M770 ATM Switch Manager User’s Guide 29
Refresh
.
Configuration
Chapter 6 Managing Switch VCs
Viewing All VCs on a Port
The Total VCs table displays a list of all traffic going through the VCs on the selected
port. To view a description of all traffic on a port:
1 Select a port to be monitored.
2 Open the
OR
Right-click a port and select
Figure 6.2 Total VCs Window
Configuration
menu and select
Total VCs
. The Total VCs window appears.
Port
Total VCs
.
The Total VCs window provides a list of the total number of VCs including SVCs and
PVCs for the selected port. The Total VCs window also provides a method for editing
the SVC VCI range.
Note:
Note:
Signalling, and Proprietary LANE.
For a description of the fields in the Total VCs window, refer to Appendix B,
Configuration Fields
30 Cajun M770 ATM Switch Manager User’s Guide
To edit the SVC VCI range, the virtual port must be disabled.
The port will always have at least three point-to-point PVCs used for ILMI,
Chapter 7
Managing LANE Services
This section explains how to manage the LAN Emulation (LANE) services provided by
the Cajun M770 ATM Switch. It includes the following topics:
• Resilient LANE
• Choosing the LES Address for a LEC
• Setting Up the LECS
For more information on LAN Emulation, refer to
.
Guide
Resilient LANE
The Cajun M770 ATM Switch, in addition to LANE 1.0, supports proprietary
redundant LANE services.
For more information on Resilient LANE, refer to
Reference Guide
.
LAN Emulation
Proprietary Redundant Services
in
The Reference
in
The
Choosing the LES Address for a LEC
When a LEC starts up, it connects to the LECS as usual. The LECS may have several
different possible LESs for a particular ELAN (if it is in distributed mode), so it must
decide which one to give to the LEC. It is possible to configure one of three possible
options:
• Round Robin - Each LES address is used in turn.
• Group Address - Every LES uses the same address. When a LEC requests that
ELAN, it is given the “common” address of the LESs. The LEC connects with the
“nearest” switch via routing.
• Best Match - The LES address supplied is the one which best matches the ATM
address of the LEC (and so should also be the “nearest” LES in many cases,
especially if a hierarchical addressing scheme is used).
Round Robin is the default because it will normally guarantee an even spread of clients
amongst all possible LESs. However, it is preferable in some cases to use Group
Address or Best Match.
Group Address usually gives the fastest recovery time. If a LES fails, it normally takes
the LECS at least 90 seconds to time out on the address of this LES. If the scheme used
is Best Match, any clients applying to join the ELAN during this period will be directed
to the failed LES address. However, if the scheme is Group Address, then the address is
Cajun M770 ATM Switch Manager User’s Guide 31
Chapter 7 Managing LANE Services
still valid, and an active LES will be found as soon as PNNI reconfigures the routing
tables. If the ELAN is configured for Round Robin, then the recovery time is
unpredictable, and may be faster or slower.
Setting Up the LECS
Any ATM network which uses LANE must have one LECS that acts as a central
co-ordinator, ensuring that all LAN Emulation Clients (LECs) join the correct ELANs.
This section describes how to configure the LECS in the Cajun M770 ATM Switch
Manager.
You can view the resilient LECS table, and you can configure the local LECS, the
LECS ELANs table, and the LES/BUS Table.
Configuring the Local LECS
You can view and configure the local LECS using the LECS Configuration dialog box.
To configure the local LECS:
1 Select the module you want to manage.
2 Open the
LECS Configuration dialog box is displayed.
Figure 7.1 LECS Configuration Dialog Box
Configuration
menu and select
LANE
LECS Configuration
. The
The LECS Configuration dialog box provides information on the local and remote
LECSs’ configuration, such as the local LECS’s status and mode.
For a full description of the fields in the LECS Configuration window, refer to
Appendix B,
Viewing Resilient LECS Table
To view the Resilient LECS Table:
32 Cajun M770 ATM Switch Manager User’s Guide
Configuration Fields
.
1 Select the module you want to manage.
2 Open the
Configuration
Resilient LECS Table is displayed.
Figure 7.2 Resilient LECS Table
The Resilient LECS Table provides information about the resilient LECSs, such as
their address format, status, and priority.
For a full description of the fields in the Resilient LECS Table, refer to Appendix B,
Configuration Fields
.
Configuring the LECS ELANs Table
When a LEC contacts the LECS, it usually specifies the ELAN name or the ELAN
type that it wants to join. The LECS in a Cajun M770 ATM module enables you to
define up to 64 different ELAN names.
If there is a local LECS on the selected module, you must configure an ELAN name in
this table for every ELAN that is to be used in your ATM network.
menu and select
Chapter 7 Managing LANE Services
LANE
Resilient LECS Table
. The
Viewing the LECS ELANs Table
To view the LECS ELANs Table:
1 Select the module you want to manage.
2 Open the
Configuration
menu and select
LANE
LECS ELANs Table
. The LECS
ELANs Table is displayed.
Figure 7.3 LECS ELANs Table
Cajun M770 ATM Switch Manager User’s Guide 33
Chapter 7 Managing LANE Services
The LECS ELANs Table provides information about the ELANs that are recognized
by the LECS, such as the ELAN type, security, and LES information.
For a full description of the fields in the LECS ELANs Table, refer to Appendix B,
Configuration Fields
.
Adding ELANs
To add ELANs to the LECS ELANs table:
1 Click
. The LECS ELANs Table expands to enable editing.
Add
Figure 7.4 Expanded LECS ELANs Table
2 Enter the appropriate information in the LECS ELANs table, describing the
ELAN you wish to add.
OR
Click on an ELAN in the upper part of the dialog box to insert the ELAN
information for an existing ELAN into the fields. Make desired changes to the
fields.
3 Click
4 To clear the information in the fields of the dialog box, click
5 To hide the lower part of the dialog box, click
34 Cajun M770 ATM Switch Manager User’s Guide
. The new ELAN is added to the LECS ELANs table.
Apply
Cancel
.
Add
.
Updating the LECS ELANs Table
To update the LECS ELANs Table:
1 Select an ELAN from the LECS ELANs table by clicking on it and Click
OR
Double-click an ELAN from the LECS ELANs table. The LECS ELANs table
expands to allow editing. The fields contain the ELAN information of the selected
ELAN.
2 Change the information in the lower part of the dialog box.
3 Click
Apply
4 To hide the lower part of the dialog box, click
Deleting ELANs
To delete ELANs from the LECS ELANs Table:
1 Select an ELAN from the LECS ELANs table by clicking on it.
2 Click
3 Click
Delete
Yes
Viewing Registered LESs
Additional information about LESs that are registered with an ELAN may be viewed in
the Registered LESs on ELAN window.
To view the Registered LESs on ELAN window:
1 Highlight an ELAN in the LECS ELANs Table.
2 Click the
Chapter 7 Managing LANE Services
.
.
Cancel
. A confirmation box is displayed.
. The ELAN is no longer recognized by the LECS.
Registered
button. The Registered LESs on ELAN window is displayed.
Update
.
Figure 7.5 Registered LESs on ELAN Window
The Registered LESs on ELAN window lists the ATM address, mode, and LEC ID
range of each registered LES for the selected ELAN.
Note:
Each module that hosts a resilient LECS must have the same LECS ELAN
configuration.
Cajun M770 ATM Switch Manager User’s Guide 35
Chapter 7 Managing LANE Services
For a full description of the fields in the Registered LESs on ELAN window, refer to
Appendix B,
Configuration Fields
Configuring the LES/BUS Table
The LES/BUS Table contains a list of all of the LESs configured on a module. In the
LES/BUS Table dialog box you can view, add, and edit the LESs situated on this
module.
A Cajun M770 ATM module can provide up to 16 combined LES/BUSes.
To configure the LES/BUS Table:
1 Select the module you want to manage.
2 Open the
Configuration
Table is displayed.
Figure 7.6 LES/BUS Table
.
menu and select
LANE
LES/BUS Table
. The LES/BUS
The LES/BUS Table provides information on the LESs that are configured on the
selected module, such as the LESs name, type, status, and registration mode.
Adding LESs
To add LESs to the LES/BUS Table:
1 Click
36 Cajun M770 ATM Switch Manager User’s Guide
. The LES/BUS Table expands to enable editing.
Add
Chapter 7 Managing LANE Services
Figure 7.7 Expanded LES/BUS Table
2 Enter the appropriate information in the LES/BUS table, describing the LES you
wish to add.
OR
Click on a LES in the upper part of the dialog box to insert the LES information for
an existing LES into the fields. Make desired changes to the fields.
3 Click
4 To clear the information in the fields of the dialog box, click
5 To hide the lower part of the dialog box, click
. The new LES is added to the LES/BUS table.
Apply
Cancel
.
Add
.
Updating the LES/BUS Table
To update the LES/BUS table:
1 Select a LES from the LES/BUS table by clicking on it and Click
Update
.
OR
Double-click a LES from the LES/BUS table. The LES/BUS table expands to
allow editing. The fields contain the LES information of the selected LES.
2 Change the information in the lower part of the dialog box.
3 Click
4 To hide the lower part of the dialog box, click
Apply
.
.
Cancel
Deleting LESs
To delete LESs from the LES/BUS Table:
1 Select a LES from the LES/BUS table by clicking on it.
2 Click
3 Click
Cajun M770 ATM Switch Manager User’s Guide 37
. A confirmation box is displayed.
Delete
. The LES is no longer configured for the selected module.
Yes
Chapter 7 Managing LANE Services
Viewing LANE Clients
You can also view information regarding LANE clients on a LES by choosing an ELAN
and clicking the
Clients
Figure 7.8 LANE Clients on LES
The LANE Clients on LES table provides information about those LECs that are on
the selected LES, such as their addresses, states, and LEC IDs.
For a full description of the fields in the LES/BUS Table and LANE Clients on LES
window, refer to Appendix B,
button in the LES/BUS Table window.
Configuration Fields
.
38 Cajun M770 ATM Switch Manager User’s Guide
Chapter 8
Managing Routing
This chapter explains the routing options of the Cajun M770 ATM Switch. It includes
the following sections:
• Managing the static routes table
• Managing PNNI (Private Network-Network Interface)
Managing the Static Routes Table
The Static Routes Table provides information about all routes in the Cajun M770 ATM
Switch database.
In the Static Routes Table you can:
• View the ports associated with an ATM address.
• View the origin of the routing entry.
• Update the routing table.
Viewing the Static Routes table
To view the Static Routes Table:
1 Click .
OR
Open the
appears.
Configuration
menu and select
Static Routes
. The Static Routes Table
Figure 8.1 Static Routes Table
The Static Routes Table provides information on static routes, such as port, address
prefix, origin, and status.
Cajun M770 ATM Switch Manager User’s Guide 39
Chapter 8 Managing Routing
For a full description of the fields in the Static Routes table, refer to Appendix B,
Configuration Fields
.
Updating the Static Routes Table
To add information to the Static Routes table:
1 Click
. The Add dialog box appears.
Add
Figure 8.2 Static Routes Add Dialog Box
2 Enter information in the fields of the dialog box.
3 Click
. The new route is added to the Static Routes Table immediately.
OK
To delete information from the Static Routes table:
1 Select a row and click
To edit information in the Static Routes table:
1 Select a row and click
information for the selected route in the fields.
.
Delete
. The Edit dialog box appears with the current
Edit
Figure 8.3 Static Routes Edit Dialog Box
2 Edit the information, and click
. The information is updated immediately.
OK
Managing the PNNI Table
The PNNI Table provides information about the PNNI interface of the Cajun M770
ATM Switch.
40 Cajun M770 ATM Switch Manager User’s Guide
Managing the PNNI table includes:
• Viewing PNNI information.
• Changing PNNI configuration parameters.
• Editing the PNNI summary table.
Viewing PNNI information
The PNNI information table displays node information. To view PNNI information:
1 Open the
window appears.
Figure 8.4 PNNI Information
The PNNI Information window provides node information, such as Node Level, Node
ID, Node ATM address and Node Peer Group ID. You can update the Node Level and
Node Peer Group ID.
You may wish to change the peer group ID, if you notice that multiple switches you
have on the network have different peer group IDs, and are not connected successfully.
Changes made to the fields in the PNNI Information window will only take affect after
the switch is reset.
Configuration
menu and select
PNNI Info
Chapter 8 Managing Routing
. The PNNI Information
Note:
Changing the node level, changes the first byte of the peer group ID, and the
first byte of the Node ID.
For a full description of the fields in the PNNI Information window, refer to Appendix
B,
Configuration Fields
.
Editing the PNNI Summary Table
The PNNI specification defines that each PNNI node advertises the addresses that are
locally connected to it. Since it is not possible to specify that each node advertises all of
its local Reachable Addresses (RA), PNNI defines a way that the node advertises
summaries of its Reachable Addresses. For the lowest level node, the ATM address of a
switch is the switch default summary, as all directly connected hosts and edge devices
Cajun M770 ATM Switch Manager User’s Guide 41
Chapter 8 Managing Routing
that use ILMI for address registration get the switch prefix as the prefix to their address.
To view the PNNI Summary Table:
1 Open the
Configuration
Summary Table appears.
Figure 8.5 PNNI Summary Table
The PNNI Summary Table provides a list of all the summaries that were defined,
either manually or by default (i.e. the switch prefix).
You can edit, add or delete information in the table.
To add information to the PNNI Summary table:
1 Click
. The Add dialog box appears.
Add
menu and select
PNNI Summary Table
. The PNNI
Figure 8.6 PNNI Summary Add Dialog Box
2 Enter information in the fields of the dialog box.
3 Click
. The new summary is added to the PNNI Summary table immediately.
OK
To delete information from the PNNI Summary table:
1 Select a row and click
Delete
.
To edit information in the PNNI Summary table:
1 Select a row and click
. The Edit dialog box appears with the current
Edit
information for the selected route in the fields.
42 Cajun M770 ATM Switch Manager User’s Guide
Figure 8.7 PNNI Summary Edit Dialog Box
Chapter 8 Managing Routing
2 Edit the information, and click
. The information is updated immediately.
OK
For a full description of the fields in the PNNI Summary Table, refer to Appendix B,
Configuration Fields
.
Cajun M770 ATM Switch Manager User’s Guide 43
Chapter 8 Managing Routing
44 Cajun M770 ATM Switch Manager User’s Guide
Appendix A
Cajun M770 ATM Switch Manager Menus
This appendix gives the full menu structure of the menus in the Cajun M770 ATM
Switch Manager application.
Configuration Menu
Table A.1 Configuration Menu
Item Description
Device Information
Agent
Module
Port
Port
Port
Port
Enable Port
Disable Port
Managers Table
Traps
Switch VCs
Static Routes
PNNI Info
Configuration
Neighbor Info
Total VCs
PNNI
Displays information for the ATM Switch.
Displays configuration information for an agent.
Displays configuration information for a module.
Displays configuration information for a port.
Displays the neighbor ATM Switch information for a
port.
Displays total VCs information for a port.
Displays PNNI information for a port.
Enables the selected port/s.
Disables the selected port/s.
Displays managers configuration information.
Displays trap configuration information.
Displays configuration information for switch VCs.
Displays configuration information for static routes.
Displays node information.
PNNI Summary Table
Provides information about the PNNI interface of the
Cajun M770 ATM Switch.
LANE
Configuration
Cajun M770 ATM Switch Manager User’s Guide 45
LECS
Displays and enables configuration of the LECS.
Table A.1 Configuration Menu (Continued)
Item Description
LANE
Table
LANE
Table
LANE
Reset
Reset
Exit Zoom
Resilient LECS
LECS ELANs
LES/BUS Table
Switch
Module
Performance Menu
Table A.2 Performance Menu
Item Description
Port Counters
CPU Counters
Displays information of the resilient LECS on the
network.
Displays and enables configuration of the ELANs
known to the local LECS.
Displays and enables configuration of the LES/BUS
pairs located on the selected module.
Resets the entire ATM Switch with all its modules.
Resets the selected module.
Exits Zoom View.
Displays the packet flow in a selected port.
Displays a breakdown of the bytes and packets going
through the CPU in a selected module.
VC Counters
Displays a breakdown of the cells going through a
selected module.
LECS Statistics
Displays the number of configuration requests
successfully granted or rejected by the LECS on the
module.
Mng LEC Counters
Displays the amounts of traffic types flowing through
the management LEC, the total number of bytes that
the management LEC receives and transmits, and the
number of frames that the management LEC
discards.
46 Cajun M770 ATM Switch Manager User’s Guide
Administer Menu
Table A.3 Administer Menu
Item Description
Help Menu
Table A.4 Help Menu
ToolBar
Launch Hub Manager
Item Description
Contents
About Cajun M770 ATM
Switch Manager
(In Windows only) Toggles the toolbar on and off.
Launches the Cajun M770 Multifunction Switch
Manager.
Opens the help module for information.
Displays copyright information about the Cajun M770
ATM Switch Manager.
Cajun M770 ATM Switch Manager User’s Guide 47
48 Cajun M770 ATM Switch Manager User’s Guide
Appendix B
Configuration Fields
Field Name Description
Address The ATM address of the port.
Address Format The ATM address that the LECS will advertise.
Address Suppress The state of summary address advertising. Possible
Possible values are:
• WKA - A Well Known Address.
• Selector - Selector means the module address plus
a selector byte.
states are:
•
- The summary is not advertised, and all
on
addresses that fall under this summary are not
known in the PNNI domain.
•
- The summary is advertised.
off
Address Type The type of RAs the summary applies to. Possible
types are:
•
Internal
Addresses within the PNNI domain.
•
Exterior
Addresses that are outside the PNNI domain.
Admin Status The administration status of the Physical Port, Root
Virtual Port, or Virtual Channel.
Agent Slot Number The number of the slot holding the Master Agent.
Agent SW Version The version of the application software running on
the module or agent.
Agent Type The agent type.
ATM Address The ATM address of the selected port, agent, LEC,
or Neighbor device.
BUS Address The BUS ATM address for the selected LES.
Cajun M770 ATM Switch Manager User’s Guide 49
- The summary applies to Reachable
- The summary applies to Reachable
Field Name Description
Call Use The type of VC (Virtual Channel):
• PVC - Permanent VC
• SVC - Switched VC
Configuration Symbol For Module Configuration: The version of the
module. The version is updated whenever there is a
functional modification to the module.
For Agent Configuration: The version of the hardware
and firmware of the agent.
Configured ATM prefix The configured ATM address prefix of the Cajun
M770 ATM Device. When the switch is reset, this
becomes the Current ATM Address.
Configured ELAN Name The name of the ELAN that the management LEC
expects to join when it next leaves and re-enters the
network. This information is sent to the LECS, which
uses it to determine the ELAN that the management
LEC should join. If you do not specify an ELAN
name, the management LEC will join the default
ELAN of the type that you specify.
Configured ILMI Status The configured state of the ILMI protocol stack.
Configured Node Id The identifier of the node within the PNNI domain.
Ensure that the Node ID is unique within the
domain.
Configured Node Level The PNNI hierarchy level in which the node resides.
Configured Node Peer
Group Id
Configured Signalling
Type
Configured Termination
Type
CrossConnected Id Index of the VC in the Cross Connect table.
Current ATM prefix The current ATM prefix of the Cajun M770 ATM
50 Cajun M770 ATM Switch Manager User’s Guide
The Peer Group ID in which the node resides.
The configured type of signalling to be used by the
root virtual port.
The configured UNI termination on the root virtual
port.
Device.
Field Name Description
Current ELAN Name The name of the ELAN that the management LEC
has currently joined.
Current ILMI Status The current state of the ILMI protocol stack.
Current Signalling Type The type of signalling used by the root virtual port.
Current State Current state of the LEC with regard to the LES.
Possible states are:
•
•
•
•
•
•
For more information refer to
Components
Current Status In the Routing table:
The status of the routing entry.
•
•
In LES configuration:
The operational state of the LES. When in the Up
state, the LES will respond to LEC requests.
- The LEC state is unknown.
other
noLesConnect
the LES.
lesConnect
connection to the LES.
joining
by the LES.
addLec
Distribute VCC to the LEC.
joinedLes
Valid
Invalid
be because the port is down or disabled.
- a LEC JOIN request has been received
- The LES is setting up a Control
on page 17 of
- The route is functional.
- The route is non-functional. This could
- The LEC is not connected to
- The LEC has established a VCC
- The LEC has joined the LES.
LAN Emulation
The Reference Guide
.
Current Termination Type The current UNI (User to Network Interface)
termination on the root virtual port. This can be either
on the user side or network side.
Device Name The name of the manager.
Device Type The device type.
Cajun M770 ATM Switch Manager User’s Guide 51
Field Name Description
Discovery The method used for determining the address of the
LES. Possible methods are:
•
•
- The address of the LES is discovered using
Auto
the proprietary ’automatic LES address
determination method’.
Manual
- The LES’s address is manually entered.
Early Packet Discard
Threshold
ELAN Name The name of the ELAN.
ELAN Type The type of ELAN. Possible types are:
ESI (MAC) Address The End Station Identifier (ESI) is the MAC address
Faults A list of faults.
There are two packet discard thresholds for each
option card, called Early Packet Discard (EPD) and
Partial Packet Discard (PPD). By default, both
thresholds have a default set limit and are enabled.
The Cajun M770 ATM Device uses EPD to discard
entire AAL5 frames for ABR and UBR traffic (rather
than random cells from different frames), when it
determines that it is about to become congested. The
Cajun M770 ATM Device passes through the last cell
of each AAL5 frame so that end stations are aware that
a discard has taken place. You can configure a
threshold at which the EPD will be invoked. The
threshold is a percentage of the overall shared buffer
space.
•Ethernet
•Token Ring
of the master agent. The ATM address of the switch
consists of the ATM prefix and the ESI.
Group LES Address Unique 20 byte address to be used when the LEC to
LES assignment is by Group.
Interface Address The ATM address of the Cajun M770 ATM module
to which the port belongs.
Last Active The time since this resilient LECS was last elected as
active.
52 Cajun M770 ATM Switch Manager User’s Guide
Field Name Description
Last Change The time since the last change in the operational
status of the VC.
Latest Software Event
Description
Latest Software Event
Level
LEC ID A unique number which identifies a LEC on the
LEC ID range The range of LEC IDs that the selected LES is
LEC If Index The logical interface number assigned to the
LEC Security The security mode of an ELAN. Possible security
An error description for the last software event that
caused a SNMP trap to be sent by the Cajun M770
ATM module to a network management station.
The error code of the last software event that caused a
SNMP trap to be sent by the Cajun M770 ATM
module to a network management station. Software
events are assigned error codes of increasing severity
from 1 to 16.
ELAN.
responsible for.
management LEC. It is used to identify
corresponding rows in the Interfaces MIB.
modes are:
•
•
- Any LEC can request to join the ELAN.
open
This is the default security mode of an ELAN
when it is created.
- Only LECs that have client mappings to
closed
the ELAN will be able to access the ELAN. The
mapping can only be configured through the
command line interface.
Cajun M770 ATM Switch Manager User’s Guide 53
Field Name Description
LEC Status The management LEC can have the following status
messages:
• Initial state - Indicates that the management LEC
in not currently connected to a LECS.
• LECS connect phase - Indicates that the
management LEC is trying to set up an SVC to a
LECS.
• Configuration phase - Indicates that the
management LEC has sent a configuration request
to the LECS and is waiting for a response.
• Join phase - Indicates that the management LEC
is joining the ELAN.
• Initial registration - Indicates that the management
LEC is registering its MAC address and ATM
address with the LES.
• Connecting to the BUS - Indicates that the
management LEC is connecting to a bus.
• Operational - Indicates that the management LEC
is fully active.
LEC to LES assignment The algorithm according to which the LECS decides
which LES’s address to give a LEC. This is only used
if the registration type is set to distributed.
• By Longest - The LECS supplies the LES address
that best matches the ATM address of the LEC.
• By Equal (Round Robin) - The LEC is assigned to
the next distributed LES address in sequence
(each distributed LES is used in turn). This is also
known as Round Robin.
• By Group - Each distributed LES on the ELAN is
assigned a group address. It is this address that is
returned to every LEC by the LECS. When this
option is selected, you must supply the Group
LES Address, a 20 byte unique address.
54 Cajun M770 ATM Switch Manager User’s Guide
Field Name Description
LEC-LES assignment The method by which a LEC is assigned to a LES.
Possible methods are:
• By longest address match
• By group LES address
• By round robin
For more information, refer to
on page 63.
LECS ATM Address The ATM address advertised by the LECS.
LECS Discovery Indicates the method used by the management LEC
to establish a direct configuration VCC to the LECS.
Length The length of the ATM address, expressed as a
number of bits. The maximum length is 152 bits, as
ATM routing is done for only 19 byte addresses.
LES Activity Status The activity status of the LES. Possible statuses are:
•
•
LES Address The ATM address of the LES.
- The LES has resilient or distributed
active
capability and is active.
standby
on standby.
- The LES has resilient capability and is
LEC to LES assignment
LES ATM Address The ATM address of the LES that the management
LEC has joined.
LES ELAN Name The name of the ELAN.
LES ELAN Type The type of ELAN. Possible types are:
•Ethernet
•
Token Ring
LES Name The name of the LES. This must correspond to an
ELAN with the same name.
Cajun M770 ATM Switch Manager User’s Guide 55
Field Name Description
LES Registration Type The LES registration mode to be supported by the
LECS. Possible modes are:
•
Prop LANE autosense
the proprietary registration version from the first
registering LES.
•
Prop LANE resilient
allow a LES using the proprietary registration
method which supports resilient LESs.
•
Prop LANE distributed
allow a LES using the proprietary registration
method which supports distributed LESs.
LES Required State The required state of the LES. Possible states are:
•up
• down
- The LECS will adopt
- The LECS will only
- The LECS will only
Local at switch address
with Selector
Local at WKA A LECS is created on this module and it will advertise
Local LECS Mode Selects whether the LECS will be resilient.
Local LECS Resilient
Priority
Local LECS Status The operational status of the local LECS. Possible
MAC Address The MAC address of the device, agent, or ring
A one byte Selector appended to the module’s 19 byte
ATM address, to form the address advertised by the
selected LECS.
the WKA.
The priority level of the LECS. The default priority is
128. A priority of 255 ensures that it is always elected.
A priority of 0 ensures that it is never elected.
statuses are:
• Resilient Active
• Resilient Standby
• Not Resilient.
This field will be blank if the LECS location is
remote.
interface.
56 Cajun M770 ATM Switch Manager User’s Guide
Field Name Description
Manual, LES at address The address of the LES. This field is only significant
if the discovery method of the LES is set to Manual.
For more information, refer to
Max Number of Slots Maximum number of ATM Switch modules that can
work together as a single switch within the device.
Discovery
on page 52.
Maximum Active LESs (1-
10)
Module Type The module type.
Name if Known The name of the LEC that has been assigned by the
Neighbor IP The IP address of the immediate neighbor switch that
Node ATM Address The ATM address of the PNNI node. This may be
Node Oper Status The operational status of the PNNI node.
nrt-VBR Admin Weight The administrative weight given to the nrt-VBR
Number of Configured
VCs
Number of Ports The number of ports located on the module.
The maximum number of LESs that can be
configured for the ELAN.
user. The name can be assigned using the Lucent
Name Server.
the VC passed through or of the end station where the
VC terminates.
important when the node acts as a PNNI border node
and/or a PNNI Peer Group Leader.
(non-realtime-Variable Bit Rate) class of service, when
determining the cost of a link.
The number of virtual channels that are currently
configured.
Number of Virtual Ports The number of virtual ports on the physical port.
Oper Status Operational status of the port or VC (Virtual Channel).
Possible statuses are up and down.
Cajun M770 ATM Switch Manager User’s Guide 57
Field Name Description
Origin Source from which the routing entry was learned.
Possible sources are:
•
•
•
•
Physical Type This field is only displayed for 155Mbps Option
Cards. It allows you to select the physical type of the
port. The type can be either SONET (Synchronous
Optic Network) or SDH (Synchronous Digital
Hierarchy).
Port Classification The level of importance of the port. Ports are
classified as follows:
•
•
•
For more information refer to
page 36 of
- The routing entry has been learned from the
ilmi
ILMI protocol.
Internal
switch).
LANE
automatically added by LANE services.
Static
entered.
Backbone
important).
Valuable
important).
Regular
- The routing entry is local (in the
- The routing entry has been
- The routing entry has been manually
- device or switch connections (most
- servers or critical users (less
- normal users (least important).
Port Classification
The Reference Guide
.
on
Port Functionality The physical media type of the selected port. If the
port conforms to a certain standard (Repeater,
Transceiver, 10BaseT, etc.), this standard is
displayed. If the port does not conform to any
standard, Private is displayed.
Port Name The user can define a logical name to the port for ease
of use.
Port Type The port type; optionally includes reference to the
module to which it is attached and port connector
type.
58 Cajun M770 ATM Switch Manager User’s Guide
Field Name Description
Prefix Length The length of the ATM address, expressed as a
number of bits. The maximum length is 152 bits, as
ATM routing is done for only 19 byte addresses.
Priority The resilient priority of this LECS. For more
information, refer to
page 56.
Propagate Status The state of status propagation on the port or module.
When enabled, the status of a port or module is passed
up one level.
For example, when the Propagate Status field of a
problematic port is enabled, the port’s icon as well as
the module that the port is located on appears red. If
Propagate Status is disabled, only the port icon
appears red.
The following colors indicate the status of the port or
module:
• Red - Fatal
• Grey - Disabled (port only)
• Yellow - Warning
• Green - Okay
By default, status propagation is enabled for all ports
and modules.
Local LECS Resilient Priority
on
Proxy LEC Identifies if the selected LEC is a Proxy LEC or not.
Possible states are:
•proxy
•non-proxy
PVC p2mp Leaf The number of point-to-multipoint leaf PVCs
currently defined on this port.
PVC p2mp Root The number of point-to-multipoint root PVCs
currently defined on this port.
PVC p2p The number of point-to-point PVCs currently defined
on this port.
Rcv Hellos The number of Hello packets received on the
selected PNNI link.
Cajun M770 ATM Switch Manager User’s Guide 59
Field Name Description
Receive Congestions The number of times a station does not have the
available buffer space to accept a frame addressed to
the station's specific address.
Receive TD Receive Traffic Descriptor - A set of parameters
describing the traffic class (CBR, VBR, UBR and
ABR) and service required on the connection for the
receive side.
Registration Mode The type of LES declared to the LECS during
registration. Possible modes are:
•
manual
proprietary automatic LES address determination
method’.
•
None
•
Prop LANE resilient
with the LECS using the proprietary ’automatic
LES address determination method’, and it will
act as a resilient LES.
•
Prop LANE distributed
with the LECS using the proprietary ’automatic
LES address determination method’, and it will
act as a distributed LES.
Note: If the LES mode is set to ’manual’, and the
LES is moved, you will need to reconfigure the
LECS manually, so that it will find the LES.
-The LECS does not support the
- The LES is not registered with the LECS.
- The LES will register
- The LES will register
Remote at Address This module will advertise via ILMI the 20 byte
LECS address specified here that is located on a
remote module.
Remote at Resilient LECS This module will advertise via ILMI the resilient
elected LECS address that is located on a remote
module.
Remote at WKA This module will advertise via ILMI the LECS
address at the WKA which is located on a remote
module.
Remote Node Id Node ID of the peer node.
Remote Port Number Port number of the peer node.
60 Cajun M770 ATM Switch Manager User’s Guide
Field Name Description
Required State The required state of the LES. Possible states are:
•up
•down
Root Virtual Port - SVC
VCI range
rt-VBR Admin Weight The administrative weight given to the rt-VBR
Rx Cell discards Number of cell discards on hardware elements of the
S/W Version The version of the application software running on
Scrambling Enables or disables payload scrambling. To enable
Serial Number A unique number assigned by Lucent Technologies
Shape Port Speed Maximum speed of data transfer allowed on this port.
Signalling Status The status of the signaling process at an ATM port.
Slot The slot number where the selected M770 ATM
VCI values allowed for use on this Root Virtual Port.
(realtime-Variable Bit Rate) class of service, when
determining the cost of a link.
module since the last reset.
the module or agent.
payload scrambling for a port, select the Scrambling
check box. By default, payload scrambling for a port is
disabled.
to the selected hardware.
Possible values are: up,
module is installed.
down
.
Cajun M770 ATM Switch Manager User’s Guide 61
Field Name Description
Slot Number The slot number in which the module is located. Slots
are numbered from left to right, starting with number
1 as the leftmost slot.
This number may be 1 - 14. The agent module is
inserted in either slot 15 or 16. A module which
occupies two enclosure slots, will be identified by the
number of the second slot (the right-hand slot). The
slot number is the position in which the module is
located. There can be up to 5 modules in a device.
The Slot Number is set using the rotary switch on the
back panel of the device.
Slot/Port The slot number and port number where the VC
(Virtual Channel) starts/terminates. Port 0 is the CPU
port.
State The state of the summary address indicates whether
or not it is advertised.
• Advertising - This summary is being advertised.
• Suppressed - This summary is not being
advertised.
• Inactive - No addresses fall under this summary.
State Unchanged for The amount of time measured in days, hours,
minutes, and seconds, that the LEC’s state regarding
the LES has not changed. For more information, refer
to
Current State
on page 51.
Status Resilient status and link status of the selected LES.
Summary Address Summary of ATM addresses that are connected to this
node. The Summary Addresses may be advertised
throughout the PNNI domain.
Suppress The state of summary address advertising. Possible
states are:
•
- The summary is not advertised, and all
on
addresses that fall under this summary are not
known in the PNNI domain.
•
- The summary is advertised.
off
62 Cajun M770 ATM Switch Manager User’s Guide
Field Name Description
SVC p2mp Leaf The number of point-to-multipoint leaf SVCs
currently established on this port.
SVC p2mp Root The number of point-to-multipoint root SVCs
currently established on this port.
SVC p2p Calling in The number of point-to-point SVCs that where
established from the line into the switch.
SVC p2p Calling out The number of point-to-point SVCs that where
established from the switch to the line.
System Contact Individual responsible for maintenance of the device.
System Description A description of the type of system being used.
System Location The current physical location of the device.
System Name Logical name of the system as defined on the SNMP
agent of the Terminal Server.
System Up Time The length of time that the Cajun M770 ATM Device
has been running since the last reset.
Transmit TD Transmit Traffic Descriptor - A set of parameters
describing the traffic class (CBR, VBR, UBR and
ABR) and service required on the connection for the
transmit side.
Type In the PNNI Summary table:
• Type of summary address. Refer to
page 49.
In the LECS ELANs Table:
• Type of ELAN. Refer To
UBR Admin Weight The administrative weight given to the UBR
(Unspecified Bit Rate) class of service, when
determining the cost of a link.
UNI version The version of the User to Network Interface (UNI)
protocol used in the ATM port.
Cajun M770 ATM Switch Manager User’s Guide 63
ELAN Type
Address Type
on page 52.
on
Field Name Description
VCI Virtual Circuit Identifier. A unique numerical tag as
defined by a 16 bit field in the ATM cell header that
identifies a virtual circuit, over which the cell has to
travel.
Virtual Port The virtual port number.
Virtual Port State The state of the root virtual port.
VPI Virtual Path Identifier. An eight bit field in the ATM
cell header which indicates the virtual path over
which the cell should be routed.
VPort The number of the virtual port.
Xmt Hellos The number of Hello packets transmitted by the
selected PNNI link.
64 Cajun M770 ATM Switch Manager User’s Guide
Appendix C
Counter Fields
Field Description
AAL5 CRC Errors The number of packets received in error.
Abort Transmit The number of times a station transmits an abort
AC Errors The number of times a station receives a frame from a
Access Denied The number of CONFIGURE requests rejected due
Align Errors Total number of frames on the port with align errors.
Broadcast Packets Total number of good packets directed to the
delimiter while transmitting.
station that cannot set the AC bits properly.
to the “access denied” error.
broadcast address that were received on the port or
module.
Burst Errors The number of times a station detects the absence of
transitions for five consecutive half-bit times (burstfive error).
Bytes The number of bytes that the management LEC has
received (In) and transmitted (Out).
Bytes In The number of bytes that the management LEC has
received.
Bytes Out The number of bytes that the management LEC has
transmitted.
Cell Discards The number of cells discarded due to insufficient
resources.
Cell In Number of incoming cells.
Configuration Requests
Successfully Granted
Cajun M770 ATM Switch Manager User’s Guide 65
The number of configuration requests successfully
granted by the management LEC on the module.
Control Frames The number of LANE control frames that the
management LEC has received (In) and transmitted
(Out).
Discards The number of frames that the management LEC has
discarded because of insufficient buffer space.
Errors The number of frames that the management LEC has
discarded because they contained errors.
HEC Error In The number of cells with HEC errors received by the
port.
Insufficient Info The number of CONFIGURE requests rejected due
to the “insufficient information” error.
Insufficient Resources The number of CONFIGURE requests rejected due
to the “insufficient resources to grant request” error.
Invalid ATM Address The number of CONFIGURE requests rejected due
to the “invalid ATM address” error.
Invalid Destination The number of CONFIGURE requests rejected due
to the “invalid destination” error.
Invalid Parameters The number of CONFIGURE requests rejected due
to the “invalid request parameter” error.
Invalid Requester-ID The number of CONFIGURE requests rejected due
to the “invalid requester ID” error.
LE-ARP requests The number of responses to LAN Emulation Address
Resolution Protocol (LE_ARP) requests that the LES
has forwarded to this management LEC (In), because
the LES did not know the ATM address. If the
management LEC owns the address, it will respond
directly to the LEC that sent the request.
The number of LE_ARP requests that the
management LEC has sent to the LES (Out), because
it needs an ATM address. If the LES knows the ATM
address, it sends it to the management LEC. If it does
not know the ATM address, the LES forwards the
address request to any proxy LECs that are registered
with it, so that they can respond directly if they own
the address.
66 Cajun M770 ATM Switch Manager User’s Guide
LE-ARP responses The number of responses to LAN Emulation Address
Resolution Protocol (LE_ARP) requests that the
management LEC has received (In) and the number
of LE_ARP requests that it has responded to (Out).
LE_Configure error The number of CONFIGURE requests rejected due
to the “LE_Configure” error.
LEC not recognized The number of CONFIGURE requests rejected due
to the “LEC not recognized” error.
Malformed Requests The number of malformed CONFIGURE requests
dropped by the LECS.
Module The slot number of the Cajun M400 module selected.
Multicast Packets Total number of good packets received that were
directed to a multicast address. Note that this number
does not include packets directed to the broadcast
address.
Rx Errors Total number of error frames received on the port.
Short Events Total number of events on the port whose activity
duration is less than the allowed value
SVC failures The number of SVCs that have failed to be set up.
Too Long Frames Total number of frames on the port with octet sizes
greater than the allowed value.
Total Errors The total number of errors which have occurred on
the relevant ports.
Total Frames The total number of frames on the ring.
Total Frames Received The total number of frames of valid frame length that
have been received on the ports in this module.
Total Octets The total number of octets contained in the valid
frames that have been received on the ports in this
module.
Total Packets The total number of packets of valid frame length that
have been received on the ports in this module.
Total Rejected The total number of rejected CONFIGURE requests.
Cajun M770 ATM Switch Manager User’s Guide 67
Total Rx Frames The total number of frames that have been received
on the Fast Ethernet ports.
Total Traffic The total number of Token Ring frames processed by
the module.
Total Tx Frames OK The number of frames of valid frame length that have
been transmitted from the Fast Ethernet ports.
Unicast Packets The total number of unicast packets that the
management LEC has received (In) and transmitted
(Out) for a single ATM switch on the network.
Unknown protocols In The number of frames that the management LEC has
discarded because it did not recognize the protocol.
VCI Virtual Circuit Identifier. A unique numerical tag as
defined by a 16 bit field in the ATM cell header that
identifies a virtual circuit.
VPI Virtual Path Identifier. An 8 bit field in the ATM cell
header which indicates the virtual path over which the
cell should be routed.
68 Cajun M770 ATM Switch Manager User’s Guide
Appendix D
Trap Fields
Agent LANE Traps A group of traps which report the failure of the agent
Authentication Traps An SNMP request with an illegal community was
Config. Change Traps A group of traps which report a change in the
Connection Traps A group of traps which report a problem in the ATM
Fault Traps A group of traps which report a fault in the device.
LANE Traps A group of traps which report a status change in one of
to contact a particular ELAN.
received.
configuration of the device.
connection software. e.g. Signalling, ILMI.
the LANE components.
Management Traps A group of traps which report an error in software
management events. e.g. telnet, memory.
Module Insert Traps The trap reports the insertion of a module in the
device.
Module Remove Traps The trap reports the removal of a module from the
device.
Cajun M770 ATM Switch Manager User’s Guide 69
70 Cajun M770 ATM Switch Manager User’s Guide
Index
A
Accessing Severity Degrees 20
Adding
ELANs 34
information to PNNI summary table 42
LESs to the LES/BUS table 36
managers to the Managers Table 9
route to the static routes table 40
Administer menu 47
Agent
configuration 7
master and sub 7
software downloading 7
ATM switch
configuration 11
information 11
resetting 16
C
Choosing LES address for a LEC 31
Configuration fields 49
Configuration menu 45
Configuring
Agent 7
ATM switch 11
LECS ELANs table 33
LES/BUS tabl e 36
local LECS 32
traps 19
Counter fields 65
Counters
CPU 24
management LEC 27
port 23
VC 25
CPU counters 24
D
Deleting
ELANs 35
information from PNNI summary table 42
LESs from the LES/BUS table 37
route from static routes table 40
Designating managers 8
Device information 11
Disabling physical ports 15
Downloading new agent software 7
E
Editing
information in PNNI summary table 42
Managers Table 10
PNNI summary table 41
route in static routes table 40
Elements, reseting 16
Elements, selecting from Zoom View 3
Enabling
physical ports 14
F
Fault Management 19
First thing to do when starting 2
H
Help menu 47
How to
add ELANs to the LECS ELANs table 34
add information to PNNI summary table 42
add LESs to the LES/BUS table 36
add managers to Managers Table 9
add route to static routes table 40
choose a LES address for a LEC 31
configure an ATM switch 11
configure LECS ELANs table 33
configure local LECS 32
configure the agent 7
configure the LES/BUS table 36
configure traps 19
Cajun M770 ATM Switch Manager User’s Guide 71
delete ELANs 35
delete information from PNNI summary table
42
delete LESs from the LES/BUS table 37
delete route from static route table 40
designate managers 8
disable physical ports 15
download new agent software 7
edit information in PNNI summary table 42
edit PNNI summary table 41
edit route in static routes table 40
edit the Managers Table 10
enable physical ports 14
manage faults 19
manage LANE services 31
manage PNNI table 40
manage routing 39
manage switch VCs 29
manage the agent 7
manage the static routes table 39
monitor performance 23
remove managers from Managers Table 9
reset elements 16
reset the ATM switch 16
reset the module 16
run from UNIX 2
run from Windows 2
select elements from Zoom View 3
start Cajun M770 switch manager 2
update LECS ELANs table 35
update the LES/BUS table 37
update the static routes table 40
use the toolbar buttons 4
use Zoom View 3
use Zoom View features 3
view agent information 8
view all VCs on a port 30
view ATM switch information 11
view CPU counters 24
view device information 11
view LANE clients 38
view LECS ELANs table 33
view LECS statistics 26
view management LEC counters 27
view managers information 9
view module configuration 12
view neighbo r information 17
view PNNI information 41
view port configuration 13
view port counters 23
view registered LESs 35
view resilient LECS table 32
view the static routes table 39
view traps 20
view traps in a dialog box 20
view traps in the Event Log 20
view VC connections 29
view VC counters 25
L
LAN Emulation
choosing a LES address 31
managing services 31
resilient 31
LEC
choosing the LES address 31
configuring 32
counters 27
LECS
configuring 32
configuring LECS ELANs table 33
setting up 32
viewing LECS ELANs table 33
viewing resilient table 32
viewing statistics 26
LES
choosing LES address 31
configuring LES/BUS table 36
deleting from the LES/BUS table 37
registered 35
updating LES/BUS table 37
M
Management LEC counters 27
Managers Table
adding 9
editing 10
removing 9
Managers, designating 8
Managing
72 Cajun M770 ATM Switch Manager User’s Guide
agent 7
faults 19
LANE services 31
PNNI table 40
routing 39
static routes table 39
switch VCs 29
Master agent 7
Menus
Administer 47
Configuration 45
Help 47
Performance 46
Modules
reset 16
Monitoring performance 23
N
Neighbor information 17
NetView/6000 2
O
OpenView 4.x (Solaris or HPUX) 3
Organization of manual 1
P
Performance menu 46
Performance monitoring 23
PNNI table 40
Port
configuration 13
counters 23
disabling 15
enabling 14
Purpose of th is manual 1
Running
from UNIX 2
from Windows 2
S
Selecting elements 3
Severity Degrees
Accessing 20
Software, downloading 7
Starting
Cajun M770 ATM switch manager 2
from UNIX 2
from Windows 2
Static routes table 39
Statistics, LECS 26
Sub agent 7
T
Toolbar buttons 4
Trap fields 69
Traps
configuring 19
in a dialog box 20
in the Event Log 20
viewing 20
U
Updating
LECS ELANs table 35
LES/BUS table 37
static routes table 40
Using
the toolbar buttons 4
Zoom View 3
Zoom View features 3
R
Registered LESs 35
Removing managers from Managers table 9
Resetting
ATM switch 16
elements 16
module 16
Resilient
LANE 31
LECS table 32
Routing 39
Cajun M770 ATM Switch Manager User’s Guide 73
V
VC
connections for a switch 29
counters 25
managing 29
viewing all VCs on a port 30
Viewing
agent information 8
all VCs on a port 30
ATM switch information 11
CPU counters 24
device information 11
LANE clients 38
LECS ELANs table 33
LECS statistics 26
management LEC counters 27
managers information 9
module configuration 12
neighbor information 17
PNNI information 41
port configuration 13
port counters 23
registered LESs 35
resilient LECS table 32
static routes table 39
traps 20
traps in a dialog box 20
traps in the Event Log 20
VC connections for a switch 29
VC counters 25
W
Welcome to Cajun M770 ATM Switch Manager
1
What to do first 2
Who should use this manual 1
Z
Zoom View 3
74 Cajun M770 ATM Switch Manager User’s Guide
