LINKSYS WRT54G2V1 User Manual

Appendix A

Troubleshooting

Appendix A:
Troubleshooting

Your computer cannot connect to the Internet.

Follow these instructions until your computer can connect
to the Internet:

Make sure that the Router is powered on. The Power

•

LED should be green and not flashing.

If the Power LED is flashing, then power off all of

•

your network devices, including the modem, Router,
and computers. Then power on each device in the
following order:

Cable or DSL modem

1.

Router

2.

Computer

3.

Check the cable connections. The computer should

•

be connected to one of the ports numbered 1-4 on
the Router, and the modem must be connected to the
Internet port on the Router.

The modem does not have an Ethernet port.

The modem is a dial-up modem for traditional dial-up
service. To use the Router, you need a cable/DSL modem
and high-speed Internet connection.

When you double-click the web browser, you are
prompted for a username and password. If you want to
get rid of the prompt, follow these instructions.

Launch the web browser and perform the following steps
(these steps are specific to Internet Explorer but are similar
for other browsers):

Select Tools > Internet Options.

1.

Click the Connections tab.

2.

Select Never dial a connection.

3.

Click OK.

4.

The Router does not have a coaxial port for the cable
connection.

The Router does not replace your modem. You still need
your cable modem in order to use the Router. Connect your
cable connection to the cable modem, insert the setup
CD into your computer, and then follow the on-screen
instructions.

The computer cannot connect wirelessly to the network.

Make sure the wireless network name or SSID is the same
on both the computer and the Router. If you have enabled
wireless security, then make sure the same security
method and key are used by both the computer and the
Router.

You need to modify the settings on the Router.

You cannot use the DSL service to connect manually to
the Internet.

After you have installed the Router, it will automatically
connect to your Internet Service Provider (ISP), so you no
longer need to connect manually.

The DSL telephone line does not fit into the Router’s
Internet port.

The Router does not replace your modem. You still need
your DSL modem in order to use the Router. Connect
the telephone line to the DSL modem, insert the setup
CD into your computer, and then follow the on-screen
instructions.

Open the web browser (for example, Internet Explorer or
Firefox), and enter the Router’s IP address in the address
field (the default IP address is 192.168.1.1). When
prompted, leave the User name field blank and enter the
password to the Router (the default is admin). Click the
appropriate tab to change the settings.

WEB: If your questions are not addressed here,

refer to the Linksys website, www.linksys.com.

Wireless-G Broadband Router

22

Appendix B

V1

18 dBm ( average )

Appendix B:
Specifications

Model WRT54G2
Standards IEEE 802.3, IEEE 802.3u,

IEEE 802.11g, IEEE 802.11b
Ports Internet: One 10/100 RJ-45 Port
Button Reset
LEDs Power, WLAN, LAN (1-4),

Internet, Wifi Protected Setup
(WPS)

Cabling Type CAT5
# of Antennas 2 Internal Antennas
RF Power Output 18 dBm
UPnP able/cert Able
Security Features Stateful Packet Inspection (SPI)

Firewall, Internet Policy
Wireless Security Wi-Fi Protected Access™2 (WPA2),

WEP, Wireless MAC Filtering

Specifications

Environmental

Dimensions 7.99" x 1.38" x 6.30"
(203 x 35 x 160 mm)

Weight 9.88 oz (280 g)
Power External, 12V DC, 0.5A
Certifications FCC, CE, IC-UL Wi-Fi (802.11b,

802.11g), WPA2, WMM
Operating Temp. 32 to 104ºF (0 to 40ºC)
Storage Temp. -4 to 140ºF (-20 to 60ºC)
Operating Humidity 10 to 85%, Noncondensing
Storage Humidity 5 to 90%, Noncondensing

Wireless-G Broadband Router

23

Appendix C

Warranty and Regulatory Information

Appendix C:
Warranty and Regulatory
Information

Limited Warranty

Linksys warrants to You that, for a period of one year
(the "Warranty Period"), your Linksys Product will be
substantially free of defects in materials and workmanship
under normal use. Your exclusive remedy and Linksys’
entire liability under this warranty will be for Linksys at
its option to repair or replace the Product or refund Your
purchase price less any rebates. This limited warranty
extends only to the original purchaser.

If the Product proves defective during the Warranty
Period call Linksys Technical Support in order to obtain
a Return Authorization Number, if applicable. BE SURE
TO HAVE YOUR PROOF OF PURCHASE ON HAND WHEN
CALLING. If You are requested to return the Product, mark
the Return Authorization Number clearly on the outside
of the package and include a copy of your original proof
of purchase. RETURN REQUESTS CANNOT BE PROCESSED
WITHOUT PROOF OF PURCHASE. You are responsible
for shipping defective Products to Linksys. Linksys pays
for UPS Ground shipping from Linksys back to You only.
Customers located outside of the United States of America
and Canada are responsible for all shipping and handling
charges.

TO THE EXTENT NOT PROHIBITED BY LAW, IN NO EVENT
WILL LINKSYS BE LIABLE FOR ANY LOST DATA, REVENUE
OR PROFIT, OR FOR SPECIAL, INDIRECT, CONSEQUENTIAL,
INCIDENTAL OR PUNITIVE DAMAGES, REGARDLESS OF THE
THEORY OF LIABILITY (INCLUDING NEGLIGENCE), ARISING
OUT OF OR RELATED TO THE USE OF OR INABILITY TO
USE THE PRODUCT (INCLUDING ANY SOFTWARE), EVEN
IF LINKSYS HAS BEEN ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. IN NO EVENT WILL LINKSYS’ LIABILITY
EXCEED THE AMOUNT PAID BY YOU FOR THE PRODUCT.
The foregoing limitations will apply even if any warranty or
remedy provided under this Agreement fails of its essential
purpose. Some jurisdictions do not allow the exclusion or
limitation of incidental or consequential damages, so the
above limitation or exclusion may not apply to You.

Please direct all inquiries to: Linksys, P.O. Box 18558, Irvine,
CA 92623.

ALL IMPLIED WARRANTIES AND CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE ARE LIMITED TO THE DURATION OF
THE WARRANTY PERIOD. ALL OTHER EXPRESS OR
IMPLIED CONDITIONS, REPRESENTATIONS AND
WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF
NON-INFRINGEMENT, ARE DISCLAIMED. Some jurisdictions
do not allow limitations on how long an implied warranty
lasts, so the above limitation may not apply to You. This
warranty gives You specific legal rights, and You may also
have other rights which vary by jurisdiction.

This warranty does not apply if the Product (a) has been
altered, except by Linksys, (b) has not been installed,
operated, repaired, or maintained in accordance with
instructions supplied by Linksys, or (c) has been subjected
to abnormal physical or electrical stress, misuse,
negligence, or accident. In addition, due to the continual
development of new techniques for intruding upon and
attacking networks, Linksys does not warrant that the
Product will be free of vulnerability to intrusion or attack.
