Wireless-G Ethernet Bridge
Table of Contents
Chapter 1: Introduction |
1 |
The Wireless-G Ethernet Bridge |
1 |
Features |
1 |
Chapter 2: Getting to Know the Wireless-G |
|
Ethernet Bridge |
2 |
The Wireless-G Ethernet Bridge’s Back Panel |
2 |
The Wireless-G Ethernet Bridge’s Front Panel LEDs |
3 |
Chapter 3: Planning Your Wireless Network |
4 |
Network Topology |
4 |
Ad-Hoc versus Infrastructure Mode |
4 |
Chapter 4: Connecting the Wireless-G Ethernet |
|
Bridge for Setup |
7 |
Chapter 5: Setting Up the Wireless-G Ethernet |
|
Bridge |
8 |
Chapter 6: Connecting the Wireless-G Ethernet |
|
Bridge for Network Use |
16 |
Connection to a Network Device |
16 |
Placement Options |
17 |
Chapter 7: Using the Wireless-G Ethernet Bridge |
|
Web-based Utility |
18 |
Overview |
18 |
Starting the Web-based Utility |
18 |
Setup |
20 |
Password |
25 |
Advanced |
26 |
Status |
29 |
Help |
31 |
Appendix A: Troubleshooting |
32 |
Common Problems and Solutions |
32 |
Frequently Asked Questions |
33 |
WET54G-UG-30404C JL
Instant Wireless® Series
Appendix B: Glossary |
37 |
Appendix C: Specifications |
43 |
Environmental |
44 |
Appendix D: Warranty Information |
45 |
Appendix E: Contact Information |
46 |
Wireless-G Ethernet Bridge
Chapter 1: Introduction
r
The Wireless-G Ethernet Bridge
The versatile Wireless-G Ethernet Bridge can make any wired Ethernetequipped device a part of your wireless network. At home, use the Bridge to connect game consoles, set-top boxes, or computers to your Wireless-G network and its shared high-speed Internet connection. In the office, convert your Ethernet-wired printer, scanner, camera, notebook or desktop into a wireless networked device.
It’s completely driver-free, so it works on any platform and under any operating system! Since there are no drivers to load, setup is a snap—configure the network settings through your PC’s web browser, then plug it into your device and go. And physical installation is simplified by support for Power over Ethernet. With an optional PoE Adapter, you can mount the Bridge wherever you want—power and data are both supplied through the Category 5 Ethernet cable.
You can also use the Wireless-G Ethernet Bridge as a kind of “cable-less cable” to connect remote areas together. Maybe Shipping is all the way across the warehouse from Receiving. Or maybe you want to set up a home office in your detached garage. With a Wireless-G Ethernet Bridge in the garage, and another one (or a Wireless-G Access Point) in the house, you’re connected—no digging trenches, and no overhead wires.
Let the Wireless-G Ethernet Bridge from Linksys open up exciting new possibilities for your wireless network.
Features
•Converts wired-Ethernet devices to Wireless-G (draft 802.11g) network connectivity
•Operates in the 2.4GHz frequency spectrum with throughput of up to 54Mbps
•Complies with IEEE draft 802.11g standard, and backwards compatible with IEEE 802.11b products
•Installs in minutes with easy-to-use Setup Wizard
•Built-in web user interface for easy configuration from any web browser
•Security of up to 128-bit WEP encryption
•Supports Power over Ethernet for easy deployment
•Equipped with one standard 10/100Base-TX interface
1
Instant Wireless® Series
Chapter 2: Getting to Know the Wireless-G Ethernet Bridge
The Wireless-G Ethernet Bridge’s Back Panel
Reset |
The Reset button resets the Bridge to its |
|
|
factory default settings. |
|
X-II |
The X-II (MDI/MDI-X) slide switch |
|
|
offers a choice between two settings. |
|
|
Use the X setting if you are connecting |
|
|
the Bridge to a network adapter. Use the |
|
|
II setting if you are connecting the |
|
|
Bridge to a hub or switch. |
|
LAN |
The LAN port is where you will con- |
|
|
nect the Ethernet network cable. |
|
Power |
The Power port is where you will con- |
|
|
nect the power adapter. |
|
|
|
|
|
Note: If you use a Power over Ethernet (PoE) |
|
|
device to supply data and power through the |
|
|
Ethernet network cable, then you do not need |
|
|
|
|
|
to connect the power adapter to the Power |
|
|
port. |
|
|
|
|
Figure 2-1
Wireless-G Ethernet Bridge
The Wireless-G Ethernet Bridge’s Front Panel LEDs
Power Green. The Power LED will light up when the Bridge is powered on.
Ethernet Green. The Ethernet LED will be lit steadily when the Bridge is connected to the wired network. The LED will blink when there is wired network traffic.
Wireless-G Green. The Wireless-G LED will be lit steadily when the Bridge is connected to the wireless network. The LED will blink when there is wireless network traffic.
Figure 2-2
2 |
3 |
Instant Wireless® Series
Chapter 3: Planning Your Wireless
Network
Networkrk Topology
A wireless local area network (WLAN) is exactly like a regular local area network (LAN), except that each computer in the WLAN uses a wireless device to connect to the network. Computers in a WLAN share the same frequency channel and SSID, which is an identification name for wireless devices.
Ad-Hoc versus Infrastructure Mode
Unlike wired networks, wireless networks have two different modes in which they may be set up: infrastructure and ad-hoc. An infrastructure configuration is a WLAN and wired LAN communicating to each other through an access point. An ad-hoc configuration is wireless-equipped computers communicating directly with each other. Choosing between these two modes depends on whether or not the wireless network needs to share data or peripherals with a wired network or not.
If the computers on the wireless network need to be accessible by a wired network or need to share a peripheral, such as a printer, with the wired network computers, the wireless network should be set up in Infrastructure mode. The basis of Infrastructure mode centers around an access point, which serves as the main point of communications in a wireless network (see Figure 3-1). Access points transmit data to PCs equipped with wireless network cards, which can roam within a certain radial range of the access point. Multiple access points can be arranged to work in succession to extend the roaming range, and can be set up to communicate with your Ethernet hardware as well.
Wireless-G Ethernet Bridge
Figure 3-1
If the wireless network is relatively small and needs to share resources only with the other computers on the wireless network, then the Ad-Hoc mode can be used. Ad-Hoc mode allows computers equipped with wireless transmitters and receivers to communicate directly with each other, eliminating the need for an access point. The drawback of this mode is that in Ad-Hoc mode, wirelessequipped computers are not able to communicate with computers on a wired network. And, of course, communication between the wireless-equipped computers is limited by the distance and interference directly between them.
4 |
5 |
|
Instant Wireless® Series |
Wireless-G Ethernet Bridge |
|
|||||
Figure 3-2 shows a typical scenario |
|
|
Chapter 4: Connecting the |
|||||
of four Wireless-G Ethernet Bridges |
|
|
||||||
in ad-hoc mode. Figure 3-3 shows a |
|
|
Wireless-G Ethernet Bridge for |
|||||
typical wireless bridging scenario |
|
|
||||||
using two Wireless-G Ethernet |
|
|
||||||
|
|
Setup |
|
|
|
|
|
|
Bridges. Each wireless network is |
|
|
|
|
|
|
|
|
connected to a Wireless-G Ethernet |
|
|
|
|
|
|
|
|
Bridge through a switch. A separate |
|
|
|
|
|
|
|
|
notebook computer is equipped with |
|
|
1. Attach the external antenna. |
|
||||
a wireless PC card and can commu- |
|
|
|
|
|
|
|
|
nicate with both wireless networks as |
|
|
2. Plug the included Ethernet |
|
||||
long as it has the same SSID and |
|
|
network |
cable |
into |
the |
|
|
channel as both wireless networks. |
Figure 3-2 |
LAN port |
on |
the |
back |
|
||
|
|
|
panel of the Bridge. |
|
|
|||
|
|
|
3. The X-II (MDI/MDI-X) |
|
||||
|
|
|
slide switch offers a choice |
|
||||
|
|
|
between two settings. Slide |
|
||||
|
|
|
the X-II switch to the X |
|
||||
|
|
|
position if you are con- |
|
||||
|
|
|
necting |
the |
Bridge |
to a |
Figure 4-1 |
|
|
|
|
PC’s network |
adapter. |
|
|||
|
|
|
Slide the X-II selection switch to the II position if you are connecting the |
|||||
|
|
|
Bridge to a hub or switch. |
|
||||
|
|
|
4. Plug the other end of the |
|
||||
Figure 3-3 |
|
|
Ethernet |
network cable |
|
|||
|
|
into the RJ-45 port of the |
|
|||||
|
|
|
hub, switch, or PC you |
|
||||
|
|
|
wish to use to configure |
|
||||
|
|
|
the Bridge. |
|
|
|
|
|
|
|
|
5. Plug the supplied power |
|
||||
|
|
|
cable into the Power port |
|
||||
|
|
|
on the back panel of the |
Figure 4-2 |
||||
|
|
|
Bridge. |
Then |
plug |
the |
|
other end into an electrical outlet.
Proceed to the next section, “Chapter 5: Setting Up the Wireless-G
Ethernet Bridge.”
6 |
7 |
Instant Wireless® Series
Chapter 5: Setting Up the
Wireless-G Ethernet Bridge
Now that you’ve connected the Wireless-G Ethernet Bridge to your wired network, you are ready to set it up. The Setup Wizard will guide you through all the steps necessary.
1.Insert the Setup CD-ROM into your PC’s CD-ROM drive. The Setup Utility should run automatically, and the screen in Figure 5-1 should appear. If it does not, click the Start button and choose Run. In the field that appears, enter D:\setup.exe (if “D” is the letter of your CD-ROM drive).
Figure 5-1
•Setup - Click the Setup button to proceed with the Setup Wizard.
•User Guide - Click the User Guide button to open the PDF file of this User Guide.
•LINKSYS Web - Click the LINKSYS Web button to access the Linksys website using an active Internet connection.
•Exit - Click the Exit button to exit the Setup Wizard.
2. Click the Setup button to begin the setup process.
Wireless-G Ethernet Bridge
3.The screen shown in Figure 5-2 shows the two ways to configure the Bridge using this Setup Wizard. Optimally, you should perform this setup through a PC on your wired network. You can also set up the Bridge through one of the PCs on your wireless network. Click the Next button.
Figure 5-2
4.The screen shown in Figure 5-3 displays a list of Wireless-G Ethernet Bridges on your network, along with the status information for each Bridge. (If you have only one Bridge on your network, it will be the only one displayed.) Select the Bridge you are currently installing by clicking its name in the Selection box. Write down the IP address of the Wireless-G Ethernet Bridge, so you can use it to access the Web-based Utility later. Click the Yes button.
Figure 5-3
8 |
9 |
Instant Wireless® Series
5.For security purposes, you will be asked for your password in order to access the Bridge. In lowercase letters, enter admin in the Password field (later you can change the password through the Web-based Utility). Then click the Enter button.
Figure 5-4
6.The screen shown in Figure 5-5 shows a choice of two wireless modes. Click the Infrastructure radio button if you want your wireless computers to network with computers on your wired network using a wireless access point. Click the Ad-Hoc radio button if you want multiple wireless computers to network directly with each other. Do not use the Ad-Hoc mode if you want to network your wireless computers with computers on your wired network.
In the WB Name field, enter a unique name for the Bridge. Memorable names are helpful, especially if you are using multiple bridges on the same network. Click the Next button to continue or the Back button to return to the previous screen.
Figure 5-5
Wireless-G Ethernet Bridge
7.The Wireless Settings screen will now appear. Enter your wireless network’s SSID. If you chose Ad-Hoc mode, select the channel at which the network broadcasts its wireless signal.
If you have Wireless-G (draft 802.11g) and Wireless-B (802.11b) devices in your network, then keep the default Network Mode setting, Mixed. If you have only Wireless-G devices, select G-Only. Then click the Next button to continue or the Back button to return to the previous screen.
Figure 5-6
•SSID - The SSID is the unique name shared among all devices in a wireless network. The SSID must be identical for all devices in the wireless network. It is case-sensitive and must not exceed 32 alphanumeric characters, which can be any keyboard character.
•Channel - From the drop-down menu, select the appropriate channel to match your network settings (available for Ad-Hoc mode only). All devices in your wireless network must use the same channel in order to function correctly.
•Network Mode - Keep the default setting, Mixed, if you have Wireless-G and Wireless-B devices in your network. Select G-Only if you have only Wireless-G devices in your network.
10 |
11 |
