LINKSYS USBBT100V2 Users Manual

USB Adapter

3.0

Manual and

Application note

Index

INTRODUCTION 1

CHAPTER 1
Package 2
Features 2
Bluetooth profile support 2
Drivers support 3

CHAPTER 2
Setup for Windows 98SE/ME/2000/XP 4

CHAPTER 3
Application note for Windows
98SE/ME/2000/XP 11
Icons used for Bluetooth devices and
services 11
Network sharing setting for Windows 13
File transfer setting for Wind ows 24
Dial-up networking setting for Windows 27
FAX setting 30
PIM Item Transfer setting 31
PIM Synchronization setting 33
Serial Port setting 35
ActiveSync setting 36
Audio Gateway setting for windows 39
Personal area network setting for
Windows 41

CHAPTER 4
Advanced features 46
How to setup Hyper Terminal for
Bluetooth transfer 46
How to HotSync with Palm Bluetooth SDIO
and Tungsten T 52
How to dial-up from Palm Tungsten T to
my PC’s modem to surf the internet 55
Sending FAX via mobile phone with
WinFAXPro 56

TROUBLESHOOTING
Troubleshooting 61

i

Introduction

Bluetooth is an open specification for a cutting-edge technology that enables short-range
wireless connections between desktop and laptop computers, personal digital assistants,
cellular phones, printers, scanners, digital cameras and even home appliances — on a
globally available band (2.4GHz) for worldwide compatibility. In a nutshell, Bluetooth
unplugs your digital peripherals and makes cable clutter a thing of the past. Now you can
connect your PDA or PC to Bluetooth™ enabled mobile phone with this Bluetooth™
adapter.

You can access e-mail & Internet no matter where you are with just a little help from your
Bluetooth™ mobile phone.
Plus, when you are back in the office, you can hook yourself up to your office network as
well as communicate with other Bluetooth™-enabled devices.

1

Chapter1

Package

 One Bluetooth adapter
 One driver and software disk
 This user manual

Fea tures

1

 Bluetooth v1.2 compliant
 USB Bluetooth adapter support full speed USB v1.1 Interface.
 Wireless communication within a radius of 32 Feet (10 Meters) for Class 2 Bluetooth

devices.

 Wireless communication within a radius of 328 Feet (100 Meters) for Class 1

Bluetooth devices.

 Connect up to 7 different Bluetooth enabled devices
 Encryption and authentication to ensure safe, secure communications
 Low power consumption

Bluetooth profile support

Generic Access Profile (GAP)

Serial Port Profile (SPP)

Service Discovery Application Profile (SDAP)

Generic Object Exchange Profile (GOEP)

Object Push Profile (OPP)

File Transfer Profile (FTP)

Dial-up Network Profile (DUN)

LAN Access Profile (LAP)

2

Fax Profile (FAX)

Synchronization Profile

Headset Profile

Personal Area Network (PAN)

Human Interface Device (HID)

BIP Basic Image Profile (BBIP)

Drivers support

Windows 98SE, ME, 2000, XP

3

2

Chapter 2

Setup for Windows 98SE/ME/2000/XP

Installing Bluetooth software for Windows

(1) Place installation CD into PC and the setup menu should launch automatically.

If the setup menu does not launch automatically, use Windows Explorer to navigate to the

appropriate CD-ROM drive and run "bsetup".
(2) Select “Install Drivers and Application Software”.

4

(3) Please select your device from the menu.

5

(4) Complete the following steps to install Bluetooth software:

(a) Exit all applications.

(b) InstallShield Wizard setup dialog box will automatically be displayed.

(c) Follow the instructions on screen:

(d) On the Welcome screen, click the “Next“ button.

6

(e) When the License Agreement screen is displayed, read the License Agreement, then
click the radio button to the left of "I accept the terms in the license agreement" and
click the “Next“ button.

7

(f) You can choose the destination folder in your system, if you do not want to change the

destination folder please click “Next“. On the Destination Folder screen, click the Change

button to browse to a new destination folder for the Bluetooth software. Otherwise, click

the “Next“ button to accept the default folder.

8

(g) The system is ready to install the Bluetooth software. If you need to review or change

any settings, click the "Back" button. Click the "Cancel" button to exit the Wizard.
Otherwise, click the "Install" button.

(h) For Windows 2000/XP users, system will popup a "Driver Signature Notice", please
click the "OK" button.

9

(i) During the installation, system will try to detect your Bluetooth device, please plug in

your Bluetooth device when the following message is displayed. Then click "OK" to
continue, or you can click "Cancel" to continue the installation without the Bluetooth

device.

(j) When the installation is completed, please click the "Finish" button.

For more information of Bluetooth software Configuration & User’s Guide,

please refer to Chapter 3 of this application note.

10

3

Chapter 3

Application note for Windows 98SE/ME/2000/XP

3.1 Icons used for Bluetooth de vices and services

Bluetooth icons provide at-a-glance feedback about a device or service's status by

changing appearance.
The Bluetooth icon in the Windows system tray provides feedback about Bluetooth status.

Basic Bluetooth Icon

Device Icons for Windows 98SE, Me and 2K

Service Icons for Windows 98SE, Me and 2K

11

Device Icons for Windows XP

Service Icons for Windows XP

12

NOTE: Only available services are displayed in the menus

13

3.2. Network sharing setting for Windows

The Network Access service permits a Bluetooth enabled PC (client) to access the
Internet via another Bluetooth enabled PC (Server) that already has an Ethernet

connection.

Windows network sharing setting

PC to PC (Windows 2000 or Windows XP)

1. To enable Internet Connection Sharing on the server PC.

2. Click on Start menu → Network Connections and find your Local Area Connection

(LAN) that is connected to the Internet.

3. Right click the active LAN connection to open the "Properties" dialog box.

14

4. Click on "Advanced" tab and select the "Internet Connection Sharing" checkbox to

enable Internet sharing.

15

5. Click on "Settings..." button and select the services you wish to provide other

Bluetooth devices. Click "OK" to save the changes.

6. Go back to the “Network Connections" window, right click the "Bluetooth LAN

Access Server Driver" and select "Properties".

16

7. Under "General" tab, click on "Internet Protocol (TCP/IP)" and "Properties".

17

8. Under "General" tab, assign a virtual IP as shown in the picture below. Then click

"OK" to save the changes.

9. This allows the server PC to act as a DHCP server towards the client PCs.

NOTE: For Win98SE and WinMe, please download and install WinRoute (or
similar program) on the Server PC to allow DHCP service.

10. On the client PC, launch the Bluetooth software stack by clicking the "My Bluetooth

Places" icon located on the desktop.

11. Click the "Search for devices in range" icon to search for other Bluetooth devices

nearby.

18

12. After searching is completed, locate the computer name of the Server PC and double

click it to discover the Bluetooth services it has to offer. (i.e. Bluetooth Serial Port,

Desktop, Personal Digital Assistant, Network Access Point, etc.).

19

13. Click on the “Server PC " icon to connect to the shared Internet server PC.

14. Click OK without entering any username or password. If one is already present, click

OK anyway and it will still connect.

20
