LG PH550GV Quick Setup Guide
Quick User Guide for Projector eNGLISH
•Connect a smart device (smartphone, tablet, etc.) or laptop to the projector using the wired/wireless connection to enjoy the smart device or laptop screen enlarged by the projector.
To connect a smart device (smartphone, tablet, etc.) or laptop to the projector using the wireless connection
Press the INPUT
button on the projector remote control and select SCreeN SHAre. Launch the relevant SCREEN SHARE function* on the device you want to connect. Search for the projector on the smart device to connect. After the connection is made, the smart device screen will be displayed through the projector.
(For specifi c instructions regarding this function, refer to the owner's manual for the smart device.)
*SCREEN SHARE functions
-Android OS smart device: Miracast (LG Electronics, etc.), Screen Mirroring (Samsung
Electronics, etc.), Wireless Mirroring, etc. - Windows OS laptop: Intel WiDi, Miracast, etc.
NOTE
To connect a smart device (smartphone, tablet, etc.) to the projector using the wired connection
Connect a smart device to the projector using a cable* and set the external input of the projector to HDMI. The smart device screen will then be displayed through the projector. For model-specifi c instructions regarding use of the wired connection, please check with the smart device manufacturer.
Supported smart devices may change depending on the circumstances of each manufacturer.
*Examples of how to connect a cable to different smart devices (cable purchased separately).
|
|
|
Charging port of a |
|
HDMI cable |
Slimport adapter |
smart device |
|
|
||
Slimport supported |
|
|
Charging |
devices |
|
|
|
Projector HDMI port |
|
cable of |
|
|
|
a smart |
|
|
|
|
device |
|
|
Projector USB port |
Charger |
|
|
MHL cable |
|
MHL (5-pin) supported |
|
|
|
devices |
Projector HDMI port |
|
Charging port of |
|
|
||
|
(MHL supported port) |
|
a smart device |
|
|
5-pin to 11-pin |
|
|
|
converter |
|
MHL (11-pin) supported |
MHL cable |
|
|
|
|
|
|
devices |
|
|
|
|
Projector HDMI port |
|
Charging port of |
|
(MHL supported port) |
|
a smart device |
|
HDMI cable |
Lightning Digital AV |
|
|
|
adapter |
|
Apple Lightning Digital AV |
|
|
|
adapter supported devices |
Projector HDMI port |
|
Charging port of |
|
|
|
|
|
|
|
a smart device |
|
HDMI cable |
Apple 30-pin |
|
|
Digital AV |
|
|
|
|
|
|
|
|
adapter |
|
Apple 30-pin Digital AV |
Projector HDMI port |
|
|
adapter supported devices |
|
|
|
Charging port of a smart device
* The picture may look different from the actual product.
To Connect a Bluetooth Audio Device (Speaker/Headset)
The Bluetooth feature of the projector searches for nearby Bluetooth audio devices and enables you to connect your desired Bluetooth device and your projector wirelessly, so you can hear the audio from your projector via your desired Bluetooth audio device.
The following is how to connect a Bluetooth audio device:
*The menus in the images may differ in the actual product.
NOTE
Search Device
1Press the SeTTINGS button on your remote control and set WIreLeSS → Bluetooth to On.
|
|
|
|
|
|
WIRELESS |
|
Move OK |
|||||
|
|
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
• |
SCREEN SHARE |
|
: [PJTR][LG][0000] |
|
|
||
PICTURE |
AUDIO |
TIME |
WIRELESS |
|
|
|
|
|
Would you like to turn on Bluetooth? |
||||
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Yes |
|
|
No |
|
|
|
|
|
|
|
• |
Bluetooth |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
OPTION 1 |
OPTION 2 |
INPUT |
MY MEDIA |
|
|
|
• |
Search Device |
|
|
|||
|
|
|
|
|
|
|
• List of registered devices |
|
|
||||
|
|
|
|
|
|
|
|
|
|||||
PressOK( )tosetyourwirelesssettings. |
|
|
|
|
|
• |
AV Sync. Adjust |
|
|
||||
CustomerSupport Exit
2 Set your desired Bluetooth audio device to Pairing mode.
(For information on how to set up the Pairing mode, see the manual of your Bluetooth audio device.)
3Select the Search Device option to search for a device to connect to. (The total search time is about 15 seconds. When your desired device appears in the list, you can stop the search by selecting Stop searching. The time it takes to connect to a device may vary according to the signal strength and the number of devices.)
|
WIRELESS |
Move OK |
|
Search Device |
|
|
|
Search Device |
|
||||
|
|
|
|
|
|
|
|
||||||
|
• |
SCREENSHARE |
:[PJTR][LG][0000] |
|
List |
Searching... |
|
List |
Search complete |
||||
|
|
• |
Group |
|
Please wait. |
|
|
HBS-700 |
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
• |
Channel |
|
|
|
|
|
|
|
|
|
|
|
• |
Bluetooth |
: On |
|
|
|
|
|
|
|
|
|
|
|
|
• |
Search Device |
|
|
|
|
|
|
|
|
|
|
|
|
• List of registered devices |
|
|
|
|
|
Press OK( ) to connect the device. |
|||||
|
|
• |
AV Sync. Adjust |
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
Stop searching |
|
Close |
|
|
Re-search |
|
|
Close |
List of registered devices
Bluetooth audio devices that have been connected to your product at least once are automatically added to List of registered devices so that you can select and connect your desired device without a search later on. The following is how to connect a Bluetooth audio device:
* The menus in the images may differ in the actual product.
1Press the SeTTINGS button on your remote control and set WIreLeSS → Bluetooth to On.
2 Select WIreLeSS → List of registered devices.
(Make sure that your desired Bluetooth audio device is turned on.)
|
|
List of registered devices |
WIRELESS |
Move OK |
List |
|
||
|
|
|
• SCREEN SHARE |
: [PJTR][LG][0000] |
HBS-700 |
•Group
•Channel
• Bluetooth |
: On |
•Search Device
•Listofregistereddevices
• AV Sync. Adjust |
Delete |
|
Press OK( ) to connect the device.
Delete All |
Close |
3Select the Bluetooth audio device you want to connect to, and then the device will be connected.
NOTE
4Select the device you want to connect to after the search is completed, and then the Bluetooth audio device will be connected and added to List of registered devices automatically.
