Owner's Manual
LG Minibeam Nano
DLP Projector
Please read the safety information carefully before using this product.
PH300S
*MFL68162417*
P/NO : MFL68162417 (1505-REV00)
www.lg.com
Page 2
SAFETY PRECAUTIONS
2
SAFETY PRECAUTIONS
Please take note of safety instructions to prevent any potential accident or
misuse of the product.
• Safety precautions are given in two forms, i.e. WARNING and CAUTION.
WARNING and CAUTION are understood to mean as follows:
WARNING: Failure to follow the instructions may cause serious
injury and even death
CAUTION: Failure to follow the instructions may cause minor injury
to people or damage to the product
• Read the owner's manual carefully and keep it handy for future reference.
Read these instructions.
Keep these instructions.
Heed all warnings.
The lightning ash with
arrowhead symbol, within
an equilateral triangle, is
intended to alert the user to the
presence of uninsulated
“dangerous voltage” within the
product’s enclosure that may be of
sufcient magnitude to constitute a
risk of electric shock to persons.
The exclamation point within
an equilateral triangle is
intended to alert the user to
the presence of important operating
and maintenance (servicing)
instructions in the literature
accompanying the appliance.
WARNING/CAUTION
- TO REDUCE THE RISK OF FIRE
AND ELECTRIC SHOCK, DO
NOT EXPOSE THIS PRODUCT
TO RAIN OR MOISTURE.
WARNING:
This product contains
chemicals known to the State of
California to cause cancer and birth
defects or other reproductive harm.
Wash hands after handling.
Follow all instructions.
Indoor Installation
WARNING
• Do not use the projector outside
and do not expose the product
to any humidity or water.
- Since the product is not
waterproof, this may result in
a re or electric shock.
• Do not place the projector in
direct sunlight or near heat
sources such as radiators, fires,
stoves, etc.
- This may result in re.
• Do not place flammable
materials such as aerosols near
the projector.
- This may result in re.
Page 3
SAFETY PRECAUTIONS
3
• Do not allow children to cling to
or climb up to the projector.
- This may cause the projector
to fall, causing injury or
death.
• Do not install the product in a
place with no ventilation (e.g.,
on a bookshelf or in a closet) or
on a carpet or cushion.
- This may result in re due
to the increase in internal
temperature.
• Do not place the product close
to sources of steam, oil or oil
mist, such as humidifiers and
kitchen counters.
- Failure to do so may result
in re, electric shock, or
corrosion.
• Do not install the product onto
a wall or ceiling that is close to
sources of oil or oil mist.
- The product may be
damaged and fall, resulting in
serious injury.
• Do not place the projector where
it might be exposed to dust.
- This may result in re.
• Do not use the projector in a
damp place such as a bathroom
where it is likely to get wet.
- This may result in re or
electric shock.
• Do not allow a tablecloth or
curtain to block the air vent.
- This may result in re due to
the increase in the internal
temperature.
• Ensure good ventilation around
the projector. The distance
between the projector and the
wall should be at least 30 cm
(11.81 inches).
- This will prevent re due to
the increase in the internal
temperature.
CAUTION
• When placing the projector on a
table or shelf, be careful not to
put it near the edge.
- The projector could fall due
to bal ance problems, which
may cause personal injury or
damage to the product. Make
sure to use the pro jector
cabinet or stand that ts the
projector.
• When moving the projector,
make sure to switch it off and
remove the power plug and
cords.
- The power cord may be
damaged, resulting in re or
electric shock.
• Do not place the projector on
an unstable or vibrating surface
such as a wobbly shelf or a
slope.
- It may fall and cause injury.
• Be careful not to tip the projector
over when connecting external
devices to the projector.
- This may cause personal
injury or damage to the
projector.
Page 4
SAFETY PRECAUTIONS
4
Power
WARNING
• The appliance coupler is used
as the disconnect device.
- Please make sure the device
is installed near the wall
outlet to which it is connected
and that the outlet is easily
accessible.
• The grounding wire should be
con nected.
- Ensure that you connect the
ground ing cable to avoid
electric shock. If it is not
possible to ground the unit,
have a qualied electrician
install a separate circuit
breaker.Do not try to ground
the projector by connecting it
to telephone wires, lightning
rods or gas pipes.
• The power plug should be
inserted fully into the power
outlet.
- An unstable connection may
cause a re.
• Do not place heavy objects on
the power cord.
- This may result in re or
electric shock.
• Never touch the power plug with
wet hands.
- This may result in electric
shock.
• Do not plug too many devices
into one multi-power outlet.
- This may result in re due to
the power outlet overheating.
• Prevent dust from collecting on
the power plug pins or outlet.
- This may result in re.
• To turn off the main power,
remove the power plug, which
should be positioned so it is
easy to access for operation.
CAUTION
• Hold the plug firmly when
unplugging.
- A damaged wire may create
a re hazard.
• Ensure the power cord and plug
are not damaged, modified,
severely bent, twisted, pulled,
sandwiched or hot. Do not use
the product if the power outlet
is loose.
- This may result in re or
electric shock.
• Keep the power cord away from
heating devices.
- The wire's sheath may melt,
which may result in re or
electric shock.
• Place the projector where
people will not trip over or tread
on the power cord to protect the
power cord and plug from any
damage.
- This may result in re or
electric shock.
• Do not turn the projector on or
off by plugging in the power plug
or unplugging it from the wall
outlet. (Do not use the power
plug as a switch.)
- This may result in electric
shock or damage to the
product.
Page 5
SAFETY PRECAUTIONS
5
• Do not insert a conductor
into the other side of the wall
outlet while the power plug is
inserted into the wall outlet.
In addition, do not touch the
power plug immediately after it
is disconnected from the wall
outlet.
- This may result in electric
shock.
• Only use the official power cord
pro vided by LG Electronics. Do
not use other power cords.
- This may result in re or
electric shock.
When in Use
WARNING
• Do not place anything containing
liquid on top of the projector
such as a vase, flower pot,
cup, cosmetics, or medicine; or
ornaments, candles, etc.
- This may result in re or
electric shock, or cause injury
due to falling.
• In the event that there is a
heavy impact or the cabinet is
damaged, switch it off, unplug
it from the power outlet and
contact an authorized ser vice
center.
- This may result in electric
shock.
• Do not insert pieces of metal
such as coins, hairpins or metal
debris, nor flammable materials
such as paper or matches into
the projector.
- This is to prevent electric
shock or re.
• In the event that liquid or a
foreign object falls into the
projector, switch it off and
unplug it from the power outlet
and contact our service center.
- This may result in re or
electric shock.
• Make sure that a child does not
swallow the batteries when you
replace the old remote control
batteries with new ones. Keep
batteries out of reach of children.
- If a child swallows a battery,
consult a doctor immediately.
• Never open any cover on the
projector.
- There is a high risk of electric
shock.
• Do not look directly into the lens
when the projector is in use.
- The bright light may damage
your eyes.
• When the lamp is on or has just
been turned off, avoid touching
the air vent or lamp, because
these will be very hot.
• If there is a gas leak in the
room with the projector, do not
touch the projector or power
outlet. Open the windows for
ventilation.
- Sparks may cause re or
burns.
• Never touch the product or
power cord during storms with
thunder or lightning.
- This may cause electric
shock.
Page 6
SAFETY PRECAUTIONS
6
• Do not use the projector near
electronic devices that generate
a strong magnetic field.
• Keep the plastic film used for
packaging the product out of the
reach of children.
- If not handled safely, it can
cause suffocation.
• Do not keep your hand on the
projector for a long time when it
is running.
• When you play a game by
connecting a game console to
a projector, it is recommended
that you maintain a distance
of more than four times the
diagonal length of the screen.
- Make sure that the
connecting cable is long
enough. Otherwise, the
product may fall causing
personal injury or damage to
the product.
• Do not place the projector or its
remote control with battery in
an extremely high temperature
environment.
- This may result in re.
CAUTION
• Do not place heavy objects on
the projector.
- It may fall down and cause
personal injury.
• Be careful not to allow any impact
to the lens during transport.
• Do not touch the lens of the
projector.
- The lens may be damaged.
• Do not use any sharp tools on
the projector, such as a knife
or hammer, because this may
damage the casing.
• In the event that no image
appears on the screen or no
sound is heard, stop using the
projector. Switch off the projector,
unplug it from the power outlet
and contact our service center.
- This may result in re or
electric shock.
• Do not drop anything onto the
projector or allow anything to
impact the projector.
- This may cause personal
injury or the projector to
malfunction.
• It is recommended that you
maintain a distance of more
than 5 to 7 times the diagonal
length of the screen.
- If you watch the screen at
a close distance for a long
time, your eye sight may
become worse.
• Do not block the light beam
emitted from the projector using
a book or other object.
- Lengthy exposure to the
projector beam may result in
re. In addition, the lens may
be overheated and damaged
by the reected heat.
• Do not start the projector with
the volume turned up high.
- High volume may damage
hearing.
Page 7
SAFETY PRECAUTIONS
7
• Do not use high voltage
electrical equipment near the
projector, (e.g. bug zapper).
- This may result in product
malfunction.
Cleaning
WARNING
• Do not spray water directly to the
projector when cleaning. Do not
allow water to get into the product
or do not allow it to get wet.
- This may result in re or
electric shock.
• When there is smoke or a
strange smell coming out from
the projector or a foreign object
falls into the projector, switch it
off and unplug it from the power
outlet and contact our service
center.
- Otherwise, this may result in
re or electric shock.
• Use an air spray or soft cloth
or cotton swab moistened with
a lens cleaning chemical or
alcohol to remove dust or stains
from the front projection lens.
CAUTION
• Contact the sales representative
or service center for internal
cleaning of the projector about
once a year.
- If you do not clean the
projector, dust will accumulate
inside and may create a re
hazard or malfunction.
• When cleaning plastic parts,
such as the projector case,
disconnect the product from the
power first and wipe with a soft
cloth. Do not spray with water
or wipe with a wet cloth. Never
use glass cleaner, automobile
or industrial shiner, abrasives
or wax, benzene, alcohol, etc.
when cleaning plastic parts,
such as the projector case as
they can damage the product.
- This may also create a re
hazard, result in electric
shock or product damage
(deformation, corrosion or
breakage).
• Remove the plug from the outlet
before cleaning the product.
- Otherwise, this may result in
electric shock.
Others
WARNING
• When you go out, place the
projector out of reach of
animals, and remove the power
plug from the wall outlet.
- Using a damaged power cord
may result in short circuit
or re.
• Do not use the projector near
high-precision electronic devices
or those that transmit weak
radio signal.
- This may affect the operation
of the product, causing an
accident.
Page 8
SAFETY PRECAUTIONS
8
• Only a qualified technician
can disassemble or modify
the projector. For diagnosis,
adjustment, or repair, contact
your seller or our service center.
- This may result in re or
electric shock.
• Do not stare directly into lens
when in operation, eye damage
can occur.
• No user serviceable parts
inside unit. High voltage parts
can cause shock and even
electrocution.
• Proper ventilation required, do
not block airflow around unit.
Doing so can cause injury and
internal overheating.
• Do not touch the lens; doing so
can result in burns or damage
to lens. Lens and unit may be
HOT during and immediately
after use. Use caution when
handling unit, allowing for proper
cool down.
• Only use a grounded electrical
outlet.
• Do not insert anything into or
cover up the exhaust vents.
- This may result in re or
electric shock.
• Follow all maintenance
guidelines for optimal use;
service only at an authorized
service center.
• Keep it out of reach of children.
- Failure to do so may result in
personal injury and damage
to the product.
CAUTION
• Do not use or store the projector
outdoors for long periods of time.
• Be sure to unplug if the projector
is not to be used for a long
period.
- Accumulated dust may result
in re or electric shock due to
overheating, ignition, or poor
insulation.
• Only use the specified type of
battery.
- Burst or leaking batteries
may result in damage or
injury.
Page 9
SAFETY PRECAUTIONS
9
• Make sure you use the
same type of batteries for
replacement.
- Otherwise, the battery may
discharge early and the
remote control may not
work properly due to a bad
connection.
• The battery contains lithium-ion,
so it must be handled with care.
- This may result in explosion
or re.
• Dispose of used batteries
properly.
- This may result in explosion
or re. The correct method of
disposal may vary depending
on your country or region.
Dispose of the battery pack
as instructed.
• Do not throw or disassemble the
bat tery.
- This may result in re or
explosion due to damage to
the battery.
• Always use batteries approved
and certified by LG Electronics.
- This will prevent damage
or re.
• Store batteries away from
metallic ob jects, such as keys
and paper clips.
- Excess current may
cause a rapid increase in
temperature, resulting in re
or burns.
• Do not store the batteries near
any heat source, such as a
heater.
- This may result in re or
damage to the product.
• Do not store batteries at
temperatures higher than 60 °C
(140 °F) or in high humidity.
- This may result in explosion
or re.
• Make sure that the battery is
connected correctly.
- This prevent explosion or re.
• Incorrect battery replacement
may cause fire.
• Make sure you use the same
type of battery for replacement.
(Battery type: CR2032 / 3 V)
- In the event of a battery
contact failure, the battery
may drain quickly or the
remote control may not work
properly.
Page 10
SAFETY PRECAUTIONS
10
USA
Federal Communications
Commission (FCC) Statement
You are cautioned that changes
or modications not expressly
approved by the part responsible
for compliance could void the
user’s authority to operate the
equipment.
This equipment has been tested
and found to comply with the
limits for a Class B digital device,
pursuant to part 15 of the FCC
rules. These limits are designed
to provide reasonable protection
against harmful interference in
a residential installation. This
equipment generates, uses and
can radiate radio frequency
energy and, if not installed
and used in accordance with
the instructions, may cause
harmful interference to radio
communications. However, there
is no guarantee that interference
will not occur in a particular
installation. If this equipment does
cause harmful interference to
radio or projector reception, which
can be determined by turning the
equipment off and on, the user is
encouraged to try to correct the
interference by one or more of the
following measures:
- Reorient or relocate the receiving
antenna.
- Increase the separation between
the equipment and receiver.
- Connect the equipment into an
outlet on a circuit different from
that to which the receiver is
connected.
- Consult the dealer or an
experienced radio/projector
technician for help.
This device complies with Part
15 of the FCC Rules. Operation
is subject to the following two
conditions:
1) this device may not cause
harmful interference, and
2) this device must accept any
interference received, including
interference that may cause
undesired operation of the
device.
CAUTION : Any changes or
modications not expressly
approved by the party responsible
for compliance could void the
user’s authority to operate this
equipment.
Risk Group 2
CAUTION Possibly hazardous
optical radiation emitted from this
product. Do not stare at operating
lamp. May be harmful to the eye.
Page 11
LICENSES
NOTE
LICENSES
Supported licenses may differ by model. For more information about
licenses, visit www.lg.com.
Manufactured under license from Dolby
Laboratories. Dolby and the double-D symbol are
trademarks of Dolby Laboratories.
This DivX Certied® device has passed rigorous
testing to ensure it plays DivX® video.
To play purchased DivX movies, rst register your
device at vod.divx.com. Find your registration
code in the DivX VOD section of your device
setup menu.
DivX Certied
1080p, including premium content.
DivX
trademarks of DivX, LLC and are used under
license.
Covered by one or more of the following U.S.
patents:
7,295,673; 7,460,668; 7,515,710; 7,519,274.
The terms HDMI and HDMI High-Denition
Multimedia Interface, and the HDMI logo are
trademarks or registered trademarks of HDMI
Licensing LLC in the United States and other
countries.
®
to play DivX® video up to HD
®
, DivX Certied® and associated logos are
11
This device meets the EMC requirements for home appliances
(Class B) and is intended for home usage. This device can be used in
all regions.
• Image shown may differ from your projector.
• Your projector’s OSD (On Screen Display) may differ slightly from
that shown in this manual.
Page 12
CONTENTS
12
CONTENTS
SAFETY PRECAUTIONS 2
LICENSES 11
PREPARATION 13
Accessories 13
Optional Extras 14
Parts and Components 15
- Main Unit 15
- Back 16
Installation 17
- Installation Precautions 17
- Projection Distance per
Screen Size 18
- How to Install the Projector
On a Tripod 19
- Kensington Security System 20
REMOTE CONTROL 21
USING THE PROJECTOR 23
Using the battery 23
Battery using time information 23
Watching Projector 25
- Turning the Projector On 25
- Focus of the Screen Image 25
- Using the projector 26
Additional Options 27
- Adjusting Aspect Ratio 27
- Using the Keystone Function 28
- Changing input device 28
- Blank Function 29
Using the Quick Menu 30
MY MEDIA 31
Before Using 31
- Connecting a USB Device 31
- Removing a USB Device 31
To Use My Media 33
- Watching the Videos 35
- Viewing the Photos 41
- Listening to Music 44
- Viewing Files 47
CUSTOMIZING SETTINGS 50
SETTINGS 50
PICTURE Settings 51
AUDIO Settings 56
TIME Settings 58
INFORMATION 59
OPTION 1 Settings 60
OPTION 2 Settings 61
CONNECTING DEVICES 63
Connecting HD Receiver, DVD
Player, or VCR Player 64
- HDMI Connection 64
Connecting Headphones 65
Using the Mirroring Function
of a Mobile Phone 66
- MHL/Slimport Connection 66
MAINTENANCE 67
Cleaning 67
- Cleaning the Lens 67
- Cleaning the Projector Case 67
SPECIFICATIONS 68
Page 13
PREPARATION
The pictures may differ slightly from the actual product.
Accessories
Accessories included with the projector are show below.
Accessories are subject to change without prior notice.
New accessories may be added or old ones removed.
POWER
INPUT
MUTE
PAGE
VOLUME
BLANK
OK
EXIT
ꕣ
SETTINGS Q.MENU
RATIO
STILL
USB
HELP KEY.S K EY.S
Remote Control,
Lithium Battery (CR2032 / 3 V)
(See page 21.)
Power cord AC-DC Adaptor
Owner's Manual
PREPARATION
13
HDMI cable Tripod
Page 14
PREPARATION
14
• When connecting an HDMI or USB
cable, or connecting a USB flash drive
to the HDMI or USB port, use a product
that has a width of 18 mm (0.7 inches)
or less and a height of 10 mm
(0.39 inches) or less. If the USB cable
or USB flash drive does not fit the USB
ports of the projector, use an extension
cable that supports USB 2.0.
• Use a certified cable with the HDMI logo attached.
• If you do not use a certified HDMI cable, the screen may not display or a
connection error may occur. (Recommended HDMI cable types)
- High-Speed HDMI®/TM Cable
- High-Speed HDMI®/TM Cable with Ethernet
Optional Extras
To purchase optional accessories, visit an electronics store or online
shopping site or contact the retail store where you purchased the product.
Optional accessories are subject to change without prior notice.
Projection Screen MHL or Slimport Cable
Page 15
PREPARATION
15
Parts and Components
This projector is manufactured using high-precision technology. You may,
however, see tiny black dots and/or bright colored dots (red, blue or green)
that continuously appear on the projector screen. This is a normal result of
the manufacturing process and does not indicate a malfunction.
Main Unit
Speaker
1)
Vent
Lens
2)
Button Description
(POWER)
(SETTINGS)
Turns the projector on or off.
Displays or closes the Settings menu.
Sets the function or moves the cursor.
, , ,
( , button: The volume can be adjusted
according to the input mode)
(OK)
Shows the current mode and saves changes to
the settings.
Control panel
Focus Ring
1) Due to the high temperature of vent area, do not get close to the vent
area.
2) Do not touch the lens when using the projector. The lens may be
damaged.
Page 16
PREPARATION
16
Back
1
6
No. Description
1
(Headphone Port)
HDMI/MHL Port
2
OFF/ON Switch
- OFF: Turns the projector off completely.
- ON: Turns the projector on and the projector goes into
3
Standby mode.
Place the switch to Off when you move the projector or when
you intend not to use the projector for long periods of time.
Battery Charge Indicator
- Red: Charging
4
- Green: Charging complete
DC IN Port
5
6
7
(USB port)
Kensington security system connector
2 3 4 5
HDMI / MHL
OFF / ON
DC IN
7
Page 17
PREPARATION
17
Installation
Installation Precautions
• Place the projector in a well-
ventilated environment.
- To prevent internal
overheating, install the
projector in a well-ventilated
place.
Do not place anything near
the projector. That may block
its air vents. If the air vents
are blocked, the internal
temperature of the projector
will increase.
- Do not place the projector
on a carpet or rug. If the
projector's inlet vent is on
the bottom, be careful not to
block the vent and always
use the projector on a solid,
level surface.
- Be sure to prevent foreign
objects such as paper debris
from entering the projector.
- Leave an adequate open
area [30 cm (11.81 inches) or
more] around the projector.
• Do not install the projector in a
hot or humid environment.
- Only install the projector
in a place of moderate
temperature and low
humidity.
• Do not install the projector in a
place where it can attract dust.
- There is a risk of re.
• Never open any cover on the
projector. There is a high risk of
electric shock.
• This projector is manufactured
using high-precision technology.
You may, however, see tiny
black dots and/or bright colored
dots that continuously appear
on the projector screen.
This is a normal result of the
manufacturing process and
does not indicate a malfunction.
• The remote control may not
work in an environment where
a lamp equipped with electronic
ballasts or a three-wavelength
fluorescent lamp is installed.
Replace the lamp with an
international standard lamp
for the remote control to work
normally.
Page 18
PREPARATION
Y/2 Y/2
27.0 mm
18
Projection Distance per Screen Size
1 Place the projector on a sturdy, level surface, together with the
computer or audio/video source.
2 Place the projector an appropriate distance away from the screen.
The distance between the projector and the screen determines the
actual size of the image.
3 Position the projector so that the lens is at a right angle to the screen.
If the lens is not perpendicular to the screen, the projected image will
appear distorted. To correct the distortion, use the Keystone function.
(See page 28.)
4 Connect the power cords of the projector and the connected devices to
the wall outlet.
Screen Height(X)
X/2 X/2
Ratio of upward projection: 100 %
Screen Width (Y)
Screen
Screen
(1.06 inches)
Projection Distance (D)
Projection Distance (D)
16:9 Aspect Ratio
Screen Size
Screen
Width (Y)
Screen
Height (X)
Projection
Distance (D)
(mm) (inches) (mm) (inches) (mm) (inches) (mm) (inches)
508 20 443 17.44 249 9.80 742 29.21
635 25 553 21.77 311 12.24 931 36.65
762 30 664 26.14 374 14.72 1119 44.05
889 35 775 30.51 436 17.16 1308 51.49
1016 40 886 34.88 498 19.60 1497 58.93
1143 45 996 39.21 560 22.04 1686 66.37
1270 50 1107 43.58 623 24.52 1875 73.81
1397 55 1218 47.95 685 26.96 2063 81.22
1524 60 1328 52.28 747 29.40 2252 88.66
1651 65 1439 56.65 809 31.85 2441 96.10
1778 70 1550 61.02 872 34.33 2630 103.54
1905 75 1660 65.35 934 36.77 2818 110.94
2032 80 1771 69.72 996 39.21 3007 118.38
2159 85 1882 74.09 1058 41.65 3196 125.82
2286 90 1992 78.42 1121 44.13 3385 133.26
2413 95 2103 82.79 1183 46.57 3574 140.70
2540 100 2214 87.16 1245 49.01 3762 148.11
Page 19
PREPARATION
CAUTION
How to Install the Projector On a Tripod
• You can install the projector using a camera tripod.
• As shown below, you can mount the projector instead of a camera on
the tripod.
• When stabilizing the tripod, we recommend using a locking bolt of
standard size 4.5 mm (0.17 inches) or less. The maximum size allowed
for the locking bolt is 5.5 mm (0.21 inches). (If it is longer than the
maximum allowed size, it may damage the projector.)
Tripod
Bolt used to
attach the
projector to
the tripod
Bottom of the
Projector
The projector is
connected to
this part.
19
• If you are using a tripod, be careful not to apply external force to the
tripod. Doing so may damage the projector.
• Do not place the tripod on an unstable surface.
• Be sure to use a tripod with a maximum load capacity of 3 kg or
more.
• To use the projector safely, position the tripod legs so that they are
as wide and stable as possible and be sure to securely attach the
projector to the tripod.
• Be sure to use the provided tripod for this product only.
LG Electronics Inc. is not liable for any problems caused by the use
of the tripod with other products.
Page 20
PREPARATION
20
Kensington Security System
• This projector has a Kensington Security Standard connector as an
anti-theft mechanism. Connect a Kensington Security System cable as
shown below.
• For more information on installation and use of the Kensington Security
System, refer to the user’s guide provided with the Kensington Security
System.
• The Kensington Security System is an optional accessory.
• What is Kensington?
Kensington is a company that provides safety systems for laptops and
other electronic devices.
Website: http://www.kensington.com
Page 21
REMOTE CONTROL
,
Open the lid at the back of the remote control
and insert the batteries as described in the
instructions. Use new batteries.
POWER
VOLUME
EXIT
SETTINGS Q.MENU
STILL
HELP KEY.S KEY.S
MUTE
OK
RATIO
INPUT
PAGE
USB
BLANK
ꕣ
POWER
Turns the projector on or off.
MUTE
Mutes the sound of the projector.
INPUT
Changes the input source.
VOLUME +, -
Adjusts the volume level.
PAGE
Moves to the previous/next page.
Changes the picture mode.
BLANK
Turns the projector screen on or off.
Up/Down/Left/Right buttons
Sets the function or moves the cursor.
OK
Shows the current mode and saves
changes to the settings.
EXIT
Exits the menu.
REMOTE CONTROL
21
Returns to the previous screen.
SETTINGS
Displays or closes the Settings menu.
Q.MENU
Enters the quick menu.
Page 22
REMOTE CONTROL
,
NOTE
22
POWER
VOLUME
MUTE
INPUT
PAGE
STILL
Freezes the moving image.
(Available in any mode other than USB
mode.)
EXIT
SETTINGS Q.MENU
STILL
HELP KEY.S KEY.S
RATIO
BLANK
OK
ꕣ
RATIO
Resizes an image.
USB
Accesses USB mode.
HELP
USB
Enables the self-diagnosis.
KEY.S
Adjusts Keystone.
Playback Control Buttons
Controls playback of MY MEDIA.
Color buttons
Sets detailed settings or gesture for each
menu.
• When using the remote control, the
optimal operation range is 3 meters
HDMI / MHL
OFF / ON
(9.84 feet) or less (left/right) and within
a 30 degree arc of the remote control
IR receiver.
• For seamless operation, do not block the
IR receiver.
• When you carry the remote control in the
portable bag, make sure that the buttons
on the remote control are not pressed by
POWER
EXIT
MUTE
VOLUME
OK
SETTINGS Q.MENU
RATIO
STILL
HELP KEY.S KEY.S
INPUT
PAGE
BLANK
ꕣ
USB
the projector, cables, documents or any
other accessories in the bag. Otherwise, it may significantly reduce
the battery life.
DC IN
Page 23
USING THE PROJECTOR
USING THE PROJECTOR
Using the battery
Low battery! The projector will
turn off soon
• It is displayed when the battery is running out.
• As your battery is low, the projector will be turned off in a minute.
• If the screen shows a low battery message, be sure to charge the
battery.
Battery using time information
Status Time and Display
Charging About 3 hours
Up to 2.5 hours
Usage
Hours
Battery
Level
Indicator
(Available battery using time up to 2.5 hours when
Energy Saving mode set to Max.
Changing the Energy Saving mode default values will
reduce battery life.)
Step 1 Step 2 Step 3 Step 4
23
Page 24
USING THE PROJECTOR
24
• If you do not intend to use the projector for a long time, leave the battery
charged at 40 % to 50 %.
• The battery is automatically recharged when the projector is connected
to a power supply.
• Charge the battery fully when you first use the projector.
• The battery standard usage time given in the manual is based on
measurements taken by LG; the actual time may vary depending upon
usage.
• Battery usage time may vary depending on broadcast type, operating
temperature, period of use, and user preferences.
• As the battery is consumable, its lifetime gradually decreases. When the
battery’s life is reduced by half, replace it with a new battery from an LG
Electronics customer center.
• Do not charge the battery using any equipment other than that supplied
with the product. This may damage the battery or cause a fire.
• Always use a battery that is approved and certified by LG Electronics,
Inc. Failure to do so may result in an explosion or fire.
• If the battery is leaking or giving off an odor, discontinue its use
immediately and contact LG Electronics Customer Support Center.
• The battery contains lithium-ion, so please handle with care. Failure to
do so may result in an explosion or fire.
Page 25
USING THE PROJECTOR
25
Watching Projector
Turning the Projector On
The menu screen display in this owner's manual is an example to help
users understand how to operate the product and may look different from
the actual screen.
1 Connect the power cord correctly to turn the projector on.
2 Place the OFF/ON switch on the rear port area to ON and press the
POWER button on the control panel or on the remote control. (If the
switch is placed to OFF, the projector will not turn on.)
3 On the Language Selection screen, select the language you want.
4 Select the input signal you want using the INPUT button on the remote
control.
Focus of the Screen Image
When an image appears on the screen, check if it is in focus and ts the
screen properly.
To adjust the focus of the image, rotate the focus ring.
Focus Ring
Page 26
USING THE PROJECTOR
,
26
Using the projector
1 When in standby mode, press the POWER button to turn the projector
on.
2 Press the INPUT button and select the input signal you want.
3 Control the projector using the following buttons while watching the
screen.
Button Description
VOLUME +, - Adjusts the volume level.
MUTE
Q.MENU Enters the quick menu. (See page 30.)
RATIO Resizes an image.
KEY.S
Mutes the sound of the projector.
Adjusts Keystone. (See page 28.)
4 To turn the projector off, press the POWER button.
Page 27
USING THE PROJECTOR
NOTE
Additional Options
Adjusting Aspect Ratio
1 Press the Q.MENU button.
2 Use the , buttons to select Aspect Ratio and press the OK
button.
Menu Description
16:9 Resizes images to the 16:9 ratio.
Displays the picture in the original size without cutting off
Just Scan
Set By
Program
4:3 Displays the screen with a 4:3 aspect ratio.
Zoom
Cinema
Zoom1
the edges.
• If you select Just Scan, you may see image noise at
the edge or edges of the screen.
Displays the picture in the same aspect ratio as the
original image.
Enlarges an image to t the screen width. The top and
bottom of the image may be truncated.
• Use the , buttons to enlarge or reduce the image.
• Use the , buttons to move the image.
Formats an image to the cinemascope ratio, 2.35:1. It
ranges from 1 to 16.
• Use the , buttons to enlarge or reduce the image.
• Use the , buttons to move the image.
• If you enlarge or reduce the image, it may become
distorted.
27
• The available screen sizes may differ depending on the input signal.
• You can also use the RATIO button.
Page 28
USING THE PROJECTOR
28
Using the Keystone Function
To prevent the screen image from becoming trapezoidal, Keystone
adjusts the top and bottom width of the image if the projector is not set up
at a right angle to the screen.
Because the Keystone function may cause inferior screen image quality,
use this function only when it is not possible to set up the projector at an
optimal angle.
L R
• Keystone 0
◀
▶
Close
1 Press the SETTINGS button.
2 Use the , , , buttons to select OPTION 2 and press the
OK button.
3 Use the , buttons to select Keystone and press the OK button.
4 Use the , buttons to adjust Keystone.
5 Keystone can be adjusted from -40 to 40.
6 Press the OK button when nished.
Changing input device
To select an external input
You can select inputs connected to the projector.
• Press the INPUT button on the remote control to display the input
selection screen.
- Connected inputs are displayed rst.
• Select an input signal using the remote control's INPUT button to
connect the projector to the desired input.
You can use the or button to switch between all the input modes.
Input List
USB HDMI
ꔂ Move ꔉ OK
Input Label
Exit
Page 29
USING THE PROJECTOR
Selecting an Input Label
Displays which devices are connected to which input ports.
Input Label
HDMI
Close
1 Press the INPUT button on the remote control to display the input
selection screen.
2 Press the Red button.
3 Use the or button to select one of the input labels.
Blank Function
Using the Blank Function
This function may be effective when you need to draw attention during a
meeting or training.
1 Press the BLANK button, and the screen is covered by the
background color. You can change the background color by referring to
Selecting the background color of the blank image.
2 Press any button to clear the blank function. To cover the screen
temporarily, press the BLANK button on the remote control. Do not
block the lens with any object while the projector is running. It may
become overheated and deformed or even cause a re.
29
Page 30
USING THE PROJECTOR
30
Selecting the background color of the blank image
1 Press the SETTINGS button.
2 Press the , , , or buttons to select OPTION 2 and press
the OK button.
3 Press the , buttons to select Blank Image and press the OK
button.
4 Press the or button to move to the setting or option you want
and press the OK button.
Using the Quick Menu
You can easily customize your frequently used menus.
1 Press the Q.MENU button.
2 Press the or button to select a menu and press OK button.
Menu Description
Aspect Ratio Resizes the picture.
PJT Mode
Picture Mode Changes the picture mode.
Sound Mode Sets the sound mode.
Sleep Timer
Clear Voice II
Energy
Saving
USB Device
Turns the projected image upside down or ips it
horizontally.
Sets the projector to be turned off at the specied
time.
Makes the voice from the projector crisp and clear.
Reduces power consumption by adjusting peak
screen brightness.
Allows you to remove a connected USB device in a
safe manner.
(The menu is displayed only when the USB device is
connected.)
3 Press the , button to scroll through the following menus.
Page 31
MY MEDIA
NOTE
31
MY MEDIA
Before Using
Connecting a USB Device
Connect a USB device (external
HDD, USB memory) to the USB port
of projector to enjoy the content les
stored in the USB device with your
projector. You cannot write or delete
data in the USB device. Connect a
USB ash drive as shown below.
Removing a USB Device
1 Press the Q.MENU button.
2 Use the or button to move to USB Device and press the OK
button.
3 Select a USB to remove. Wait for conrmation that the USB device has
stopped before removing the USB.
USB ash
Drive
• If detached early, an error may occur on the projector or the USB
storage device.
• Once a USB device has been selected for removal, it can no longer
be read. Remove the USB storage device and then re-connect it.
Page 32
MY MEDIA
32
Tips for using a USB device
• If the USB storage device has a built-in auto recognition program or uses
its own driver, it may not work.
• Some USB storage devices may not work or may work incorrectly.
• If you use a USB extension cable, the USB device may not be
recognized or may not work properly.
• Use only USB storage devices formatted with the Windows FAT32 or
NTFS file system.
• For external USB HDDs, it is recommended that you use devices with a
rated voltage of less than 5 V and a rated current of less than 500 mA.
It is recommended to use a Hard Disk Drive with its own power supply.
•
(If the power being supplied is not sufficient, the USB storage device
may not be detected correctly.) Note, a USB Hub is not supported.
• It is recommended that you use USB flash drives of 32 GB or less and
USB HDDs of 1 TB or less.
• If a USB HDD with power-saving function does not work properly, turn
the power off and on. For more information, refer to the user manual of
the USB HDD.
• Data in USB storage device can be damaged so be sure to back
up important files to other devices. Data maintenance is the user's
responsibility and the manufacturer is not responsible for data loss.
Page 33
MY MEDIA
To Use My Media
1 Press the SETTINGS button on the remote control.
2 Select MY MEDIA.
Select desired le from the list. Watch the chosen le.
Sets play related settings by checking option during disk playback.
My Media supporting file
• Maximum data transmission rate: 20 Mbps (Mega bit per second)
• External supported subtitle formats:*.smi, *.srt, *.sub (MicroDVD,
SubViewer 1.0/2.0), *.ass, *.ssa,*.txt (TMPlayer), *.psb (PowerDivX)
• Internal supported subtitle formats: SRT/ASS/SSA (Supports internal
subtitles generated from DivX6)
Video Supported Codec
Maximum resolution: 1920 x 1080 @ 30p
(only Motion JPEG 640 x 480 @ 30p)
Extension Codec
.asf, .wmv
.divx, .avi
.mp4, .m4v,
.mov
.mkv
.ts, .trp, .tp,
.mts, .m2ts
.vob
.mpg
Video VC-1 Advanced Prole, VC-1 Simple and Main Proles
Audio WMA Standard, WMA 9 Professional
Video DivX3.11, DivX4, DivX5, DivX6, XVID, H.264/AVC
MPEG-1 Layer I, II, MPEG-1 Layer III (MP3), Dolby
Audio
Digital
Video H.264 / AVC, MPEG-4 Part 2
Audio AAC
Video H.264 / AVC
Audio HE-AAC, Dolby Digital
Video H.264 / AVC, MPEG-2, VC-1
MPEG-1 Layer I, II, MPEG-1 Layer III (MP3), Dolby
Audio
Digital, Dolby Digital Plus, AAC
Video MPEG-1, MPEG-2
Audio Dolby Digital, MPEG-1 Layer I, II, DVD-LPCM
Video MPEG-1
Audio MPEG-1 Layer I, II
33
Page 34
MY MEDIA
34
Supported audio files
File
Format
MP3
AC3
MPEG
AAC,
HEAAC
CDDA
LPCM
Item Info
Bit rate 32 Kbps to 320 Kbps
Sampling Rate 32 kHz to 48 kHz
Bit rate 32 kbps to 640 kbps
Sampling Rate 32 kHz, 44.1 kHz, 48 kHz
Bit rate 32 kbps to 448 kbps
Sampling Rate 32 kHz to 48 kHz
Bit rate 24 kbps to 3844 kbps
Sampling Rate 8 kHz to 96 kHz
Bit rate 1.44 Kbps
Sampling Rate 44.1 kHz
Bit rate 1.41 Mbps to 9.6 Mbps
Sampling Rate
Multi Channel: 44.1 kHz, 88.2 kHz /
48 kHz, 96 kHz
Stereo: 176.4 kHz, 192 kHz
Page 35
MY MEDIA
Page 1/1
35
Watching the Videos
In the Movie List, you can watch movies stored on the connected USB
device.
Controls playback and sets options while viewing videos.
Tips for Playing Video Files
• Some subtitles created by users may not work properly.
• The video and subtitle files should be placed in the same folder. For
subtitles to display correctly, the video and subtitle files must have the
same name.
• We do not support any stream that contains GMC (Global Motion
Compensation) or Qpel (Quarterpel Motion Estimation).
• Only H.264 / AVC profile level 4.1 and lower is supported.
• Video files that exceed 50 GB (gigabyte) are not supported for playback.
The file size limit is dependent on the encoding environment.
• DTS audio codec is not supported.
Browsing Movie List
Play a video le stored from a connected device.
1 Connect a USB storage device.
2 Press the USB button.
3 Use the , or button to select Movie List and press the OK
button.
4 Use the , , , or button to select the le you want and press
the OK button.
1
2
3
4 5
Movie List
USB STORAGE DEVICE
Butterfly_...
01:34:33
Go to root folder
Drive1 Drive5Drive3 Drive4
Drive2
Go to upper folder
7 8 9
Page Change
PAGE
Page 1/1
6
Exit
Page 36
MY MEDIA
36
No. Description
Thumbnails
Abnormal le
1
File not supported
File List
2
Moves to the upper level folder.
3
Current page/Total no. of folder pages
4
Displays the remaining battery life.
5
Current page/Total no. of le pages
6
Moves to the top level folder.
7
Moves to the upper level folder.
8
Exit Movie List.
9
5 Control playback by using the following buttons.
Option
Q.MENU
Item Description
Shows the current playing position. Use , buttons to
move forward or backward.
Stops playing and returns to Movie List.
Returns to normal playback.
나가기
Hide
Exit
Page 37
Item Description
Pauses the media player.
If no button is pressed on the remote control for 10 minutes
after pausing, the playback is restarted.
Displays in slow motion.
Whenever this button is pressed, the playback speed is
changed.: x2, x4, x8, x16, x32
Reduces power consumption by adjusting peak screen
brightness.
Option A pop-up window will appear.
Hide
Options for Movie List
Hides the playback bar. Press the OK button to make it appear.
Exit Returns to the Movie List screen.
MY MEDIA
37
1 Press the Q.MENU button.
2 Use the or button to move to a desired option and press the OK
button.
3 Use the , , , or button to set up each item.
Set Video Play.
Item Description
Selects the size of a playback screen.
Size
Audio
Language
• Full: Files are played in full screen mode according to
the aspect ratio of video.
• Original: Displays the video in the original size.
Allows you to select the language you want for the le with
multiple audio tracks. This option is not available if the le
has only one audio track.
Page 38
MY MEDIA
38
Item Description
The subtitle can be turned on or off.
• Language: One of any of the available languages can
be selected.
• Code Page: A character set used for a subtitle can
Subtitle
Language
be selected. By default, the subtitle is displayed in a
language configured in OPTION 1 → Language.
- Sync: If a subtitle is not synchronized with its video,
you can adjust its speed at 0.5 seconds unit.
- Position: Moves the location of a subtitle.
- Size: Changes the subtitle font size.
Turns the repeat function On or Off.
Repeat
When it is set to off, the next le can be played
sequentially if the le name is similar.
Subtitle Language
Subtitle
Language
Language
English, Spanish, French, German, Italian, Swedish,
Latin1
Finnish, Dutch, Portuguese, Danish, Romanian, Norwegian,
Albanian, Gaelic, Welsh, Irish, Catalan, Valencian
Latin2
Bosnian, Polish, Croatian, Czech, Slovak, Slovenian,
Serbian, Hungarian
Latin4 Estonian, Latvian, Lithuanian
Cyrillic Bulgarian, Macedonian, Russian, Ukranian, Kazakh
Greek Greek
Turkish Turkish
Hebrew Modern Hebrew
Chinese Simplied Chinese
Korean Korean
Arabic Arabic
Set Video.
You can change video settings. (Refer to PICTURE Settings on page 51.)
Set Audio.
You can change audio settings. (Refer to AUDIO Settings on page 56.)
Page 39
MY MEDIA
NOTE
Registering the DivX code
Checks DivX Reg. Code for replaying DivX protected videos. Register at
http://vod.divx.com.
Use Reg. Code to rent or purchase movies at www.divx.com/vod.
1 In the Settings menu, move to OPTION 1 and press DivX(R) VOD.
Registration
Deregistration
Close
2 Press the or button to move to Registration and press the OK
button.
You must register your device to
play DivX(R) protected videos.
Registration Code: XXXXXXXXXX
Register at http://vod.divx.com
OK
3 Check the DivX Registration Code.
• Rented/purchased DivX files cannot be played if the DivX
Registration Code of a different device is used. Use only the DivX
Registration Code granted to this specific device.
• Converted files not conforming to the DivX Codec Standard may not
play or may produce abnormal sound.
39
Page 40
MY MEDIA
NOTE
40
To deregister the DivX code
Use the DivX deregistration code to deactivate the DivX DRM function.
1 In the Settings menu, move to OPTION 1 and press DivX(R) VOD.
2 Use the or button to go to Deregistration and press the OK
button.
3 Select Yes.
Your device is already registered.
Are you sure you wish to deregister?
Yes
Deregistration code : ********
Deregister at http://vod.divx.com
Continue with registration?
Yes
No
No
• What is DRM [Digital Rights Management]?
DRM technologies and services protect the interests and rights of
copyright holders by preventing illegal use of digital content. Files
can be played after the license is verified through an online method,
etc.
Page 41
MY MEDIA
41
Viewing the Photos
You can view photos stored on a connected device.
Supported Photo Files
PHOTO (*.JPEG)
Baseline: 64-pixel (width) x 64-pixel (height) - 15360-pixel (width) x
8640-pixel (height)
Progressive: 64-pixel (width) x 64-pixel (height) - 1920-pixel (width) x
1440-pixel (height)
• Only JPEG files are supported.
• Non-supported files are displayed in the form of an icon.
• An error message is displayed for corrupted files or file formats that
cannot be played.
• Corrupted files may not be displayed properly.
• It may take some time to view high-resolution images in full screen.
Browsing Photo List
1 Connect a USB storage device.
2 Press the USB button.
3 Use the , or buttons to select Photo List and press the OK
button.
4 Use the , , , or button to select the le you want and press
the OK button.
4
1
2
3
5
Photo List
USB STORAGE DEVICE
Butterfly_...
06/09/2014
Go to root folder
Drive1 Drive5Drive3 Drive4
Drive2
Go to upper folder
Page 1/1
7 8 9
Page Change
PAGE
Page 1/1
6
Exit
Page 42
MY MEDIA
42
No. Description
Thumbnails
Abnormal le
1
File not supported
File List
2
Moves to the upper level folder.
3
Current page/Total no. of folder pages
4
Displays the remaining battery life.
5
Current page/Total no. of le pages
6
Moves to the top level folder.
7
Moves to the upper level folder.
8
Exits Photo List.
9
5 Control playback by using the following buttons.
2008/12/10
1920 x 1080
479 KB
[1/4]
Slideshow
BGM
Q.MENU
Option
Item Description
Selects the previous or next photo.
All photos are displayed during slide show.
Slideshow
• Set Slide Speed in the Option → Set Photo View.
menu.
Hide Exit
Page 43
Item Description
BGM
Option A pop-up window will appear.
Hide
Exit Exit from full screen photo view.
Options for Photo List
You can listen to music while viewing photos in full size.
Set the BGM in Option → Set Photo View. menu.
Rotates photos.
• Rotates a photo 90°, 180°, 270°, 360° clockwise.
• Photos cannot be rotated if their width is greater than
the height of the max. supported resolution.
Views the photo in full mode or original mode.
Press the blue button to enlarge the image.
Reduces power consumption by adjusting peak screen
brightness.
Hides the menu on the full size screen.
• To see the menu, press the OK button on the remote
control.
MY MEDIA
43
1 Press the Q.MENU button.
2 Use the or button to move to a desired option and press the OK
button.
3 Use the , , , or button to set up each item.
Set Photo View.
Item Description
Slide speed Selects a slideshow speed.
Selects a music folder for the background music.
• You cannot change the music folder while the
background music is playing.
BGM
• For background music, only the folder from the same
device can be selected.
- Repeat: Selects repeat play.
- Random: Selects random play.
Page 44
MY MEDIA
Page 1/1
44
Set Video.
You can change video settings. (Refer to PICTURE Settings on page 51.)
Set Audio.
You can change audio settings. (Refer to AUDIO Settings on page 56.)
Listening to Music
You can play audio les stored on the connected device.
Supported Music Files
*.MP3
Bit rate range 32 Kbps to 320 Kbps
• Sampling rate MPEG1 Layer3: 32 kHz, 44.1 kHz, 48 kHz
• Sampling rate MPEG2 Layer3: 16 kHz, 22.05 kHz, 24 kHz
Browsing Music List
1 Connect a USB storage device.
2 Press the USB button.
3 Use the , or button to select Music List and press the OK
button.
4 Use the , , , or button to select the le you want and press
the OK button.
5
4
1
2
3
Music List
USB STORAGE DEVICE
Go to root folder
Drive1 Drive5Drive3 Drive4
Drive2
Butterfly_...
01:34:33
Go to upper folder
7 8 9
Page Change
PAGE
Page 1/1
6
Exit
Page 45
No. Description
Thumbnails
Abnormal le
1
File not supported
File List
2
Moves to the upper level folder.
3
Current page/Total no. of folder pages
4
Displays the remaining battery life.
5
Current page/Total no. of le pages
6
Moves to the top level folder.
7
Moves to the upper level folder.
8
Exits Music List.
9
5 Control playback by using the following buttons.
Music List
USB STORAGE DEVICE
Butterfly_...
01:34:33
Drive1
Page 1/1
PAGE
MY MEDIA
Page Change
Page 1/1
45
002. - B02.mp3
Q.MENU
Option Hide
Item Description
Changes the playing position.
Stops playing.
Exit
Page 46
MY MEDIA
46
Item Description
Returns to normal playback.
Pauses the media player.
Plays the previous/next le.
Reduces power consumption by adjusting peak screen
brightness.
Option Sets up the options of Music List.
Hide
Exit Returns to the Music List screen.
Options for Music List
Hides the playback bar.
• Press the OK button to make the playback bar appear.
1 Press the Q.MENU button.
2 Use the or button to move to a desired option and press the OK
button.
3 Use the , , , or button to set up each item.
Set Audio Play.
Item Description
Repeat Selects repeat play.
Random Selects random play.
Set Audio.
You can change audio settings. (Refer to AUDIO Settings on page 56.)
Page 47
MY MEDIA
DOC
47
Viewing Files
You can see document les stored on a connected device.
Supported File Formats
XLS, XLSX, DOC, DOCX, PPT, PPTX, TXT, PDF, HWP
Microsoft Ofce: 97/2000/2002/2003/2007 Version
Adobe PDF: 1.0/1.1/1.2/1.3/ 1.4 Version
Hangul: 97/2003/2007 Version
• File Viewer realigns a document, so it may look different from what is
displayed on a PC.
• For documents that include images, the resolution may look lower during
the realigning process.
• If the document is large or has many pages, it may take longer to load.
• Unsupported fonts may be replaced by other fonts.
• The file viewer may not open for Office documents that contain many
high resolution images. In that case, reduce the image file size, save it
on a USB storage device and run the file viewer again or connect your
PC to the projector and open the file on your PC.
Browsing File List
1 Connect a USB storage device.
2 Press the USB button.
3 Use the , or button to select File List and press the OK button.
4 Use the , , , or button to select the le you want and press
the OK button.
3
1
2
4
Page 1/1
Page Change
File List
USB STORAGE DEVICE
Butterfly_...
06/09/2014
Go to root folder
Drive1 Drive5Drive3 Drive4
Drive2
Go to upper folder
PAGE
Page 1/1
5
Exit
6 7 8
Page 48
MY MEDIA
48
No. Description
File List
1
Moves to the upper level folder.
2
Current page/Total no. of folder pages
3
Displays the remaining battery life.
4
Current page/Total no. of le pages
5
Moves to the top level folder.
6
Moves to the upper level folder.
7
Exits File List.
8
5 Control playback by using the following buttons.
• Click Go Page then the pop-up window for selecting the number of page
appears. Input the page to move to the page you want.
• Press the VOLUME +, - button to zoom in or zoom out.
Press the OK button and then use the Up/Down/Left/Right buttons to
move to Go Page or Zoom.
Go Page Zoom Option Hide Exit
Q.MENU
ꔦ
Item Description
Moves to the page you want.
Go Page
Use the Up/Down/Left/Right buttons to select a page
and press the OK button.
Zoom Enlarges or reduces the document.
Option Sets up the options of File Viewer.
Hide
Hides the menu.
• Press the OK button to make it appear.
Exit Returns to the File Viewer screen.
Page 49
MY MEDIA
Options for File List
1 Press the Q.MENU button.
2 Use the , , , or button to set up each item.
Set FileViewer Option
Item Description
Loads and displays pages one by one. The
On
initial loading time is short but a content heavy
page may be displayed slowly.
Single Page
Loading
Image Quality
Docu ment
Align
File View settings are default, so close the currently opened document to
apply changes to the new document, if any.
Loads all pages of a le to memory before it
starts to display them. The initial loading time is
long but you can navigate pages quickly after
Off
loading is complete.
If a le is too large, it may fail to load all the
pages.
You can set the quality of the image included in the
document. The following three options are available
for the image quality: High, Medium, Low. Higher the
image quality, lower the display time.
Selects initial document align method.
49
Page 50
CUSTOMIZING SETTINGS
50
CUSTOMIZING SETTINGS
SETTINGS
1 Press the SETTINGS button.
2 Use the , , , or button to select the desired item and press
the OK button.
3 Use the , , , or button to set up the desired item and press
the OK button.
4 Press the EXIT button when completed.
Menu Description
PICTURE Adjusts the image quality for optimal viewing.
AUDIO Adjusts the sound quality and volume level.
TIME Sets time-related settings.
INFORMATION Shows information about the Projector.
OPTION 1 Customizes the general settings.
OPTION 2 Customizes the settings related the projector.
INPUT Selects the desired input source.
MY MEDIA Accesses photo, music, movie, and document les.
Page 51
PICTURE Settings
CUSTOMIZING SETTINGS
51
1 Press the SETTINGS button.
2 Use the , , , or
buttons to select PICTURE
and press the OK button.
3 Use the , , , or
button to set up the desired
item and press the OK button.
- To return to the previous
menu, press the button.
• ꕊ Energy Saving : Minimum
• Picture Mode : Standard
• Contrast 100
• Brightness 50
• Sharpness 20
• Color 60
• Tint 0
4 Press the EXIT button when
completed.
The available picture settings are described as follows.
Menu Description
Reduces power consumption by adjusting peak
screen brightness.
Energy Saving
Minimum/
Medium/
Maximum
Applies the pre-set Energy Saving
mode.
MODE
ꔂ Move ꔉ OK
G
R
Page 52
CUSTOMIZING SETTINGS
52
Menu Description
Selects the picture mode optimized for the viewing
environment or the program.
You can also customize advanced options for each
mode.
MODE
Maximizes the visual effect of video.
Vivid
Heightens contrast, brightness, and
sharpness to display vivid images.
Displays images in standard levels of
contrast, brightness, and sharpness.
Displays the optimized images for
natural scenery.
Picture Mode
Standard
Eco
Cinema Optimizes the image for a movie.
Optimizes the image for sports by
Sport
emphasizing primary colors and
dynamic actions.
Game
Optimizes the image for playing games
on fast-moving screens.
Menu for adjusting picture quality that
allows experts and amateurs to enjoy
the best projector viewing.
Expert1 /
Expert2
- Expert mode is for picture tuning
professionals to control and ne-tune
using a specic image. For normal
images, the effects may not be
dramatic.
Contrast
Adjusts the difference between bright and dark
regions of the screen.
Brightness Adjusts the overall screen brightness.
Adjusts the sharpness of the borders between bright
Sharpness
and dark. Horizontal and Vertical Sharpness are
available only in Expert1 / Expert2.
Color Adjusts the intensity of all colors.
Tint Adjusts the balance between red and green levels.
Advanced
Control
Customizes the advanced settings.
Page 53
Menu Description
Picture Option Sets optional settings.
Resets values customized by the user.
Picture Reset
Each picture mode is reset. Select the picture mode
you wish to reset.
Aspect Ratio Resizes the picture.
Advanced Control
Menu Description
Dynamic
Contrast
Dynamic
Color
Adjusts contrast and colour to the optimal level
according to the screen’s brightness.
Adjusts colours for more natural-looking colours.
Selects the range of colours that can be expressed.
Color
Gamut
• Standard: Displays the original colors of an input
signal regardless of the display features.
• Wide: Makes use of the display's rich colors.
Skin Color
Skin colour spectrum can be separately set to
implement the skin colour as dened by the user.
Sky Color Sky colour is set separately.
Grass Color
Gamma
Natural colour spectrum (meadows, hills, etc.) can be
separately set.
Sets the gradation curve according to the output of the
picture signal in relation to the input signal.
CUSTOMIZING SETTINGS
53
* Depending on input signal or other picture settings, the range of detailed
items for adjustment may differ.
Page 54
CUSTOMIZING SETTINGS
54
Expert Control
Menu Description
Dynamic
Contrast
Adjusts contrast and colour to the optimal level
according to the screen’s brightness.
Selects the range of colours that can be expressed.
Color Gamut
• Standard: Displays the original colors of an input
signal regardless of the display features.
• Wide: Makes use of the display's rich colors.
Edge Enhancer
Color Filter
Shows clearer and distinctive yet natural edges of
the video.
Filters a specic colour spectrum in RGB colours to
ne-tune colour saturation and hue accurately.
In Expert mode, you can customize the options of
each mode.
Gamma: Select 1.9, 2.2,or 2.4.
a. Method: 2 Points
- Pattern: Inner, Outer
- Points: Low, High
- Red/Green/Blue: The adjustment range for
each color is from -50 to +50.
- Apply to all inputs: The values of the Color
Color
Temperature
Temperature is applied to all the input modes.
b. Method: 20 Point IRE
- Pattern: Inner, Outer
- IRE (Institute of Radio Engineers) is the unit
indicating the size of a video signal and can
be set to 5,10,15, ... 100. You can ne-tune for
each setting as shown below.
- Luminance: The adjustment range is 50 to
500.
- Red/Green/Blue: The adjustment range is -50
to +50.
- Apply to all inputs: The values of the Color
Temperature is applied to all the input modes.
Page 55
CUSTOMIZING SETTINGS
Menu Description
Adjusts Red/Green/Blue/Cyan/Magenta/Yellow
colors. Allows an expert to adjust the tint using a test
pattern. Six colors (Red/Green/Blue/Cyan/Magenta/
Yellow) can be selectively adjusted without affecting
Color
Management
System
other colors. You may not see colors change on a
normal picture even after adjustment.
- Saturation Red/Green/Blue/Yellow/Cyan/
Magenta,
Tint Red/Green/Blue/Yellow/Cyan/Magenta,
Luminance Red/Green/Blue/Yellow/Cyan/
Magenta:
The adjustment range is -30 to +30 each.
* Depending on input signal or other picture settings, the range of detailed
items for adjustment may differ.
Picture Option
Menu Description
Noise Reduction Reduces screen noise in the video.
MPEG Noise
Reduction
Eliminates noise generated while creating digital
picture signals.
Adjusts the brightness or darkness of the screen
Black Level
to suit the black level of the picture input using the
degree of darkness (black level) of the screen.
Real Cinema Optimizes the screen for movie viewing.
Color
Temperature
Adjusts the overall color of the screen to suit your
preference.
Select Warm, Natural, Cool, or Medium.
55
Page 56
CUSTOMIZING SETTINGS
56
AUDIO Settings
1 Press the SETTINGS button.
AUDIO
2 Use the , , , or
button to select AUDIO and
press the OK button.
3 Use the , , , or
button to set up the desired
item and press the OK button.
- To return to the previous
menu, press the button.
• Sound Mode : Standard
• Sound Effect
• Auto Volume: On
4 Press the EXIT button when
completed.
The available audio settings are described as follows.
Menu Description
Sets the sound mode.
MODE
Sound
Mode
Standard Suitable for all types of video.
News / Music
/ Cinema /
Sport / Game
Sets audio optimized for a specic genre.
ꔂ Move ꔉ OK
Page 57
Menu Description
The user can select various sound effects.
MODE
Clear Voice II
Makes the voice from the projector crisp
and clear.
LG’s proprietary audio processing
Virtual
Surround
technology allows 5 channel-like
surround sound from two speakers.
• When Clear Voice II is set to on,
Virtual Surround cannot be selected.
Sound
Effect
Adjusts the volume to a level of your
choice using the Equalizer.
• Audio-band (100 Hz/ 300 Hz/ 1 kHz/
Equalizer
3 kHz/ 10 kHz) can be adjusted from
-10 to 10.
• Reset: Resets voice options that the
user has changed.
Adjusts the balance of the left and right
speakers.
Initialize the applied effect under the
Sound Effect menu.
Auto
Volume
Balance
Reset
Automatically adjusts the volume level.
CUSTOMIZING SETTINGS
57
Page 58
CUSTOMIZING SETTINGS
58
TIME Settings
1 Press the SETTINGS button.
TIME
2 Use the , , , or
button to select TIME and
press the OK button.
3 Use the , , , or
button to set up the desired
item and press the OK button.
- To return to the previous
menu, press the button.
• Sleep Timer : Off
• Auto Off : 60 min.
• Automatic Standby : Off
4 Press the EXIT button when
completed.
The available time settings are described as follows.
Menu Description
Sleep
Timer
Auto Off
Automatic
Standby
Turns off the Projector after a preset number of minutes.
To cancel the Sleep Timer, select Off.
If there is no input signal or button press, the projector
automatically turns off after the preset time has elapsed.
Turns off the projector automatically after a set period of
time if there is no button input on the projector.
ꔂ Move ꔉ OK
Page 59
INFORMATION
CUSTOMIZING SETTINGS
59
1 Press the SETTINGS button.
INFORMATION
2 Use the , , ,
or button to select
INFORMATION and press the
OK button.
The following are INFORMATION-related items.
Menu Description
Model Name Shows the model name of the product.
INPUT Shows the current status of inputs.
• Model Name : PH300
• INPUT : HDMI
ꔂ Move ꔉ OK
Page 60
CUSTOMIZING SETTINGS
60
OPTION 1 Settings
1 Press the SETTINGS button.
2 Use the , , , or
button to select OPTION 1 and
press the OK button.
3 Use the , , , or
button to set up the desired
item and press the OK button.
- To return to the previous
menu, press the button.
OPTION 1
• Language
• DivX(R) VOD
• Initial Setting
ꔂ Move ꔉ OK
4 Press the EXIT button when
completed.
The available option 1 settings are described as follows.
Menu Description
Language Selects a desired Menu Language.
DivX(R) VOD Sets DivX related settings.
Initial Setting Resets all the projector settings to the factory default.
Page 61
OPTION 2 Settings
-
+
CUSTOMIZING SETTINGS
61
1 Press the SETTINGS button.
OPTION 2
2 Use the , , , or
button to select OPTION 2 and
press the OK button.
3 Use the , , , or
button to set up the desired
item and press the OK button.
- To return to the previous
menu, press the button.
• Keystone 0
• Auto Keystone : On
• PJT Mode : Front
• High Altitude : Off
• Blank Image : Blue
• Auto Power : Off
• Self Diagnosis
4 Press the EXIT button when
completed.
The settings for OPTION 2 are described as follows.
Menu Description
To prevent the screen image from becoming trapezoidal,
Keystone
Auto
Keystone
PJT Mode
Keystone adjusts the top and bottom width of the image if
the projector is not set at a right angle to the screen.
Auto Keystone provides a rectangular screen image
by automatically adjusting the Keystone number when
there is a trapezoidal screen image caused by tilting of
the projector.
Item
On Automatically adjusts the Keystone number.
Off Manually adjusts the Keystone number.
This function turns the projected image upside down or
ips horizontal.
• Select Rear when projecting from the back of the
transparent screen purchased separately.
• Select Front Ceiling when installing the product on the
ceiling.
• When the PJT Mode is Rear Ceiling/Front Ceiling,
the left/right of the speaker changes automatically.
ꔂ Move ꔉ OK
Page 62
CUSTOMIZING SETTINGS
62
Menu Description
If the projector is used at an altitude higher than 1200
meters, turn this on.
High
Altitude
Otherwise, the projector may overheat or its protection
function may be activated. If this happens, turn the
projector off and then on again after waiting for several
minutes.
Blank
Selects a background for blank Image.
Makes the projector turn on automatically when the
adaptor plug is inserted.
Auto
Power
Self
Diagnosis
When the AC/DC plug is connected to the
On
projector, it turns on automatically.
When the AC/DC plug is connected to the
Off
projector, it goes into standby mode.
Troubleshoots functional problems that can arise while
using the product.
Item
Page 63
CONNECTING DEVICES
CONNECTING DEVICES
You can connect various external devices to the projector.
63
Computer/Notebook
Digital Device
Headphone
DVD
Mobile Phone
HDMI - Page 64
USB Device - Page 31
Headphone - Page 65
Mobile Phone (MHL/Slimport) - Page 66
Video
USB
Games
Console
Page 64
CONNECTING DEVICES
HDMI / MHL
OFF / ON
DC IN
64
Connecting HD Receiver, DVD Player, or VCR Player
You can use various features after
connecting a HD receiver, DVD
player,VCR player, PC, laptop,
etc. to the projector with an HDMI
cable.
HDMI Connection
With an HDMI cable, you can
enjoy high quality picture and
sound.
Using a HDMI cable, connect the
HDMI/MHL port of the projector to
the HDMI output port of the device
to connect. Both video and audio
are output at the same time.
Press the INPUT button on the
remote control and select HDMI.
HDMI / MHL
OFF / ON
DC IN
The table below shows examples
of switching the output. For more
information, refer to the External
Output, Connecting to an External
Monitor, or similar sections of the
owner's manual of your computer.
Brand
Switching
Output
NEC [Fn]+[F3]
Panasonic [Fn]+[F3]
Toshiba [Fn]+[F5]
IBM
[Fn]+[F7]
Sony [Fn]+[F7]
Fujitsu
[Fn]+[F10]
LG [Fn]+[F7]
Samsung [Fn]+[F4]
Adjust the control
Macintosh
panel to enable
mirroring after
start-up.
Accessories
Page 65
Connecting
HDMI / MHL
OFF / ON
DC IN
Headphones
You can listen to the audio through
a headphone.
CONNECTING DEVICES
65
HDMI / MHL
OFF / ON
DC IN
Optional Extras
Page 66
CONNECTING DEVICES
NOTE
66
Using the Mirroring Function of a Mobile Phone
MHL/Slimport Connection
You must use a HDMI adapter to connect your cell phone to the projector
and to output images and sound from your cell phone to the projector.
The compatible HDMI adapters are different, depending upon your cell
phone type. Therefore, purchase an appropriate MHL or Slimport adapter.
(To nd out whether your device is MHL/Slimport-certied, please contact
your device manufacturer.)
HDMI / MHL
Optional Extras
• When you connect a mobile phone to the HDMI/MHL port, you can
see the mobile phone screen through a projector.
- This only applies to mobile phones that support MHL/Slimport.
- You can use the remote control for some applications.
• Disconnect the MHL/Slimport cable from the projector when:
- The MHL/Slimport function is disabled.
- Your mobile device is fully charged in standby mode.
Page 67
MAINTENANCE
67
MAINTENANCE
Clean your projector to keep it in optimal condition.
Cleaning
Cleaning the Lens
If there is any dust or staining on the lens surface, you must clean the lens.
Use an air spray or a cleaning cloth to clean the lens.
To remove dust or stains, use an air spray or apply a small amount of
cleaning agent onto a swab or soft cloth to lightly rub the lens.
Please be aware that liquid may ow into the lens if the product is sprayed
directly onto the lens.
Cleaning the Projector Case
To clean the projector case, rst unplug the power cord.
To remove dust or stains, use only a dry, lint-free, nonabrasive cloth to
polish the lens.
Do not use alcohol, benzene, thinners, or other chemicals, which may
damage the case.
Page 68
SPECIFICATIONS
68
SPECIFICATIONS
MODELS PH300S (PH300S-GL)
Resolution (Pixel) 1280 (Horizontal) × 720 (Vertical)
Aspect Ratio
Projection
Distance
(Video size)
Ratio of Upward
Projection
Working range of
the remote control
AC-DC Adaptor
Audio Output 1 W + 1 W
Height (mm)
Width (mm) 113.6 (4.47 inches)
Depth (mm) 85.5 (3.36 inches)
Weight (g) 430 (0.94 lb)
USB Device 5 V, 0.5 A (max.)
Power AC 100 - 240 V~, 50/60 Hz
Operation
environment
16:9 (Horizontal:Vertical)
0.74 m to 3.76 m (50.8 cm to 254 cm)
2.42 feet to 12.33 feet (20 inches to 100 inches)
100 %
3 m (9.84 feet)
19 V , 2.1 A
(Adaptor Input 100-240 V @ 50/60 Hz)
63.9 (front) (2.51 inches) /
54.5 (rear) (2.14 inches),
65.9 (with foot) (2.59 inches)
Temperature
Operation 0 °C to 40 °C (32 °F to 104 °F)
Storage -20 °C to 60 °C (-4 °F to 140 °F)
Relative humidity
Operation 0 % to 80 %
Storage 0 % to 85 %
* Contents in this manual may be changed without prior notice due to
upgrade of product functions.
Page 69
Supported HDMI (PC) Modes
SPECIFICATIONS
69
Resolution
Horizontal Frequency
(kHz)
Vertical Frequency
(Hz)
640 x 350 31.468 70.09
640 x 480 31.469 59.94
720 x 400 31.469 70.08
800 x 600 37.879 60.31
1024 x 768 48.363 60.00
1152 x 864 54.348 60.053
1280 x 800 49.68 60
1280 x 1024 63.981 60.02
1360 x 768 47.712 60.015
1400 x 1050 65.317 59.979
1680 x 1050 65.3 60
• If an invalid signal is input into the projector, it will not be displayed
properly on the screen or a message such as No Signal or Invalid
Format will be displayed.
• The projector supports the DDC1/2B type as the Plug & Play function
(Auto-recognition of PC monitor).
Page 70
SPECIFICATIONS
70
Supported HDMI/DVI-DTV Mode
Resolution
480p
Horizontal Frequency
(kHz)
31.47
31.47
31.50
Vertical Frequency
(Hz)
60
59.94
60
576p 31.25 50
720p
1080i
1080p
45.00
44.96
37.5
33.75
33.72
28.125
67.500
67.432
27.000
26.97
33.75
33.71
56.25
60.00
59.94
50
60
59.94
50
60
59.939
24.000
23.976
30.000
29.97
50
• To provide the best picture quality, a 1280 x 720 (720p) resolution is
recommended.
Open Source Software Notice Information
To obtain the source code under GPL, LGPL, MPL, and other open source
licenses, that is contained in this product, please visit http://opensource.lge.com.
In addition to the source code, all referred license terms, warranty
disclaimers and copyright notices are available for download.
LG Electronics will also provide open source code to you on CD-ROM for a
charge covering the cost of performing such distribution (such as the cost of
media, shipping, and handling) upon email request to opensource@lge.com.
This offer is valid for three (3) years from the date on which you purchased the
product.
