Before reading this user guide and getting started, please review the
separate Product Safety and Warranty Information guide for important
product safety and warranty information about your device.
1
Table of Contents
2
Important Customer Information...........................................................1
Table of Contents ...................................................................................2
The Basics ...............................................................................................5
Index ................................................................................................... 202
Phone Overview
Front View
Earpiece
The Basics
Front Camera
Lens
Proximity
Sensor
Home screen
5
Search Key
Back Key
Microphone
.
NOTES
Menu Key
Home Key
ţ
All screen shots in this guide are simulated. Actual displays may vary
ţ
From the Home screen, tap the Apps Key
full device guides, video tutorials, and icon glossary. You can get information in detail
right from your phone.
then tap Help to access the brief &
1. Earpiece Lets you hear callers and automated prompts.
2. Menu Key Opens an Options menu with options that affect the current
screen or application.
3. Home Key Returns to the Home screen. If you’re already viewing one
of the Home screen extension canvases, it navigates you to the central
Home screen canvas. Tap and hold to view the most recently used
applications.
4. Microphone Transmits your voice to the other caller and for
voice-activated functions.
5. Back Key Returns to the previous screen. Also closes pop-up display
items, such as menus, dialog boxes, and the on-screen keyboard.
6. Search Key Opens the Quick Search Box™ From the Home screen to
search the phone and the web.
The Basics
6
7. Home screen Displays all of the information needed to operate your
phone, such as applications, call status, date, time, signal status, and
battery strength.
8.
Proximity Sensor Senses proximity toward other objects (such as your
head) so that tap commands are not accidentally activated during a call.
ţ The use of a film cover produced by manufacturers other than LG can cause a
ţ
Do not block the sensor or near the sensor to avoid problems with the tap operations.
NOTES
disturbance in tap operations, the display, etc.
9. Front Camera Lens Use for taking pictures and recording videos of
yourself. You can also use this for video chatting. Keep it clean for
optimal performance.
Rear View
Flash
Rear Camera
Lens
Back Cover
Speaker
10. Flash This would brighten the image up when you turn on the flash.
11. Rear Camera Lens Use for taking pictures and recording videos. Keep
it clean for optimal performance.
12. Back Cover Encloses the battery compartment.
13. Speaker Sound comes from the rear speaker instead of the earpiece
(e.g., the speakerphone function, music player function, etc.).
The Basics
Top View and Side Views
3.5mm
Headset Jack
Power/
Lock Key
Volume Keys
USB/Charger
Port
14. 3.5mm Headset Jack Allows you to plug in an optional headset for
convenient, hands-free conversations. You can also plug in headphones
to listen to music.
15. Volume Keys Allow you to adjust the ringer, media volumes, or the in-
call volume during a call.
16. USB/Charger Port Allows you to connect the phone charger, USB
Cable, or other compatible accessories.
17. Power/Lock Key Press to lock/unlock the screen. Press and hold to
turn the phone on/off, restart it, activate/deactivate airplane mode, and
change the sound settings.
7
The Basics
8
Setting Up Your Phone
Step1. Remove the Back Cover
Place your fingernail in the cutout at the bottom of the phone and pop the
cover off.
Step2. Insert the Battery
Insert the battery, making sure to align the gold contacts. Press down
gently to secure the battery.
Step3. Replace the Back Cover
Place the cover over the back of the phone, then press down along the
edges to secure the cover.
The Basics
Step4. Charge the phone
Before turning on your phone, charge it fully. Be sure to use the charger
that came with your phone.
Installing the Battery and microSD Card
It is important to fully charge the battery before initial use of the phone.
NOTE
Installing the battery
The phone comes with a rechargeable battery. Keep the battery charged
while not in use in order to maximize talk, use, and standby time. The
battery charge level is shown at the top right corner of the screen.
Use the fingertip
1
cutout at the bottom
of the phone to
remove the back
cover.
Align the battery
2
contacts with the
terminals in the
battery compartment
and push the battery
down until it clicks
into place.
Place the back cover
3
over the battery
compartment, then
press it downward
until it clicks into
place.
9
The Basics
10
Removing the battery
1.
Turn the phone off and use the fingertip cutout at the bottom of the phone
to remove the back cover.
2. Use the fingertip cutout at the bottom of the battery compartment to lift the
battery out.
Be careful not to scratch or damage the inside of the back cover as this is where the antenna
NOTE
is located.
Inserting a microSD card
The microSD card is sold separately.
NOTE
1. Turn the power off.
2. Remove the back cover (as demonstrated in the
previous instructions) and locate the microSD card
slot (microSD is inscribed near the slot opening).
3. Position the microSD card with the Verizon logo facing up and slide it into
place until it is fully inserted and locked in place.
The microSD card can be easily damaged by improper operation. Please be careful when
NOTE
inserting, removing or handling it.
To unmount the microSD card
It is important to unmount the microSD card before removing it from the
slot to avoid damage to the card or data saved on the card.
1. From the Home screen, tap the Apps Key
2. Tap Settings
> Storage.
3. Tap Unmount SD card > OK.
.
To remove the microSD card
1. Turn the power off.
2. Remove the cover and locate the microSD card
slot.
3. Carefully push the microSD card in to release it
from the slot, then gently pull the microSD card out to remove it.
Memory encryption
㻌
You can encrypt all data in phone and the SD card.
㻌
Data cannot be encrypted when the battery level is less than 80%.
㻌
While encrypting, you cannot access other functions
㻌
Do not unplug your chager while encrypting.
㻌
Do not connect the USB Cable while encoding.
㻌
Do not take out the SD card while encoding.
㻌
Do not take out the battery while encoding.
㻌
Do not press the Power/Lock Key
㻌
While encrypting phone, your phone will reboot several times.
㻌
After encrypting the SD card and performing a Factory reset, you
cannot access encrypted data in the SD card.
㻌
After encrypting Phone or the SD card, you cannot use ‘None’, ‘Slide’,
‘Face Unlock’, ‘Pattern’ in ‘Select screen lock’ menu.
while encoding.
The Basics
11
The Basics
12
Charging the Phone
Your phone comes with an adapter and a USB Cable which connect
together to charge your phone. To charge your phone:
Please use only an approved charging accessory to charge your phone.
NOTICE
1. Connect the USB Cable into the adapter.
2. Plug the USB Cable (as shown below) into the phone’s USB/Charger
Improper handling of the USB/Charger Port, as well as the use of an incompatible
charger, may cause damage to your phone and void the warranty.
When connecting, as shown below, the LG logo on the USB Cable will
face toward you.
Port.
USB Cable
Correctly orient the USB Cable with the phone's port. The 'B' side of the USB Cable
NOTE
should be facing upwards.
Adapter
Charging with the USB Cable
You can use your computer to charge your
phone. To be able to charge with the USB
Cable, you need to have the necessary
USB drivers installed on your PC first.
Connect one end of the USB Cable to
the USB/Charger Port on your phone and
connect the other end to a USB port on
your PC. It is best to use the rear USB port when connecting to a desktop
PC. The USB hub should be powered by an external power source.
If there is not enough charge in the battery to turn on the phone, the LED lights at the
NOTE
bottom of the keypad flash to indicate that the battery is charging. Once the battery has
enough charge to turn the phone on, the flashing stops and the battery charge animation
appears on the touchscreen.
The Basics
Optimizing Battery Life
You can extend your battery’s life between charges by turning off features
that run in the background. You can also monitor how applications and
system resources consume battery power.
Tips to extend the life of your battery
㻌
Turn off radio communications that you aren’t using. If you aren’t
using Wi-Fi, Bluetooth, or GPS, use the Settings menu to turn them
off (Note that the GPS receiver is only turned on when you’re using an
application that makes use of it).
㻌
Turn down screen brightness and set a shorter screen timeout.
㻌
Turn off automatic syncing for Gmail, Calendar, Contacts, and other
applications if you don’t need it.
㻌
Use the Power Saver in the Settings menu or the Power Control widget
to control the wireless connections, GPS connection, Bluetooth power,
display brightness, and syncing activity.
To check the battery charge level
㻌
From the Home screen, tap the Apps Key
phone > Battery.
The battery status (Charging or Discharging) and level (as a percentage
of fully charged) will be displayed at the top of the screen.
To monitor and control what uses the battery
The Battery use screen allows you to see which applications are consuming
the most battery power. Information on this screen allows you to identify
downloaded applications you may want to turn off when not being used, so
you can get the most out of your battery power.
㻌
From the Home screen, tap the Apps Key
phone > Battery > Battery
times. It lists all of the applications or services using battery power
from the greatest amount of energy used to the least amount.
use. This screen displays battery usage
> Settings > About
>
Settings
> About
13
The Basics
14
㻌
Tap an application or service in the Battery use screen to see the
details about its power consumption, including either how long since
last connected to a power source or how long you were last running
on battery power. Different applications or services offer different
kinds of information, and they may even include options to modify the
settings so you can reduce power consumption by that application.
Power Saver mode
If the battery charge level drops to low levels, the phone automatically
activates Power Saver mode to conserve battery power until you can
recharge it. You can set the phone to activate Power Saver mode at 10%,
20%, 30%, 50%, 70%, or Immediately. From the Home screen, tap the
Apps Key >
low, a notification is displayed prompting you to turn on Power Saver.
Settings
> Power saver. When the battery charge is
Turning the Phone On and Off
Turning the phone on
㻌
Press and hold the Power/Lock Key
the screen turns on.
Turning the phone off
1. Press and hold the Power/Lock Key until the Phone options menu
appears.
2. Tap Power off in the dialog box that appears.
3. Tap OK to confirm that you want to turn off the phone.
for a couple of seconds until
Restarting the phone
1. Press and hold the Power/Lock Key until the Phone options menu appears.
2. Tap Power off and restart in the dialog box that appears.
3. Tap OK to confirm that you want to restart the phone.
The Basics
To unlock the phone
If you don’t use the phone for a while, the screen and
backlight will shut off to conserve battery power. To
unlock the phone:
1. Press the Power/Lock Key
. Your Lock Screen will
appear.
2. Tap the screen and when the circle appears, slide in
any direction to unlock it. The last screen you were
working on opens.
Shortcuts on the lock screen
There are four icons in the center of your lock screen
that you can use for quick access to the Phone
application, the Messaging application, the Google
application, and the Camera application. Tap and drag
any of these icons upwards to immediately open and
use its application. There’s no need to unlock the
screen or tap any other keys.
ţ
TIP
This is the default Lock Screen. If you've set up an Unlock
Pattern, use your fingertip to draw the pattern.
ţ
Different clock themes can be applied to the lock screen.
About Lock Screen Improvement
Notification Viewing from Lock Screen
Save tedious swiping time when unlocking the screen to check Notification
alerts.
From the lock screen simply slide the Notification Bar down to see the
latest notifications, all in one step.
$VTUPNJ[BCMF-PDL4DSFFOţ-(&9$-64*7&
Hot keys are customizable with any app on the device and can unlock
directly to it.
Face Unlock
Using front facing camera, consumers can now use their actual faces (yes,
it’s not a picture, but their actual face) to unlock the device with the facial
recognition technology that comes with ICS.
15
The Basics
16
Selectively Clear Notifications by Swiping
After receiving several download, app upgrade, notification texts, and
emails, the Notification Bar can get really full. There are times when users
want to keep some of the notifications in the bar while dismissing others,
just like a “to do” list. Now, with a swipe left or right, users can clear
the notification they want to remove from the list. See page 44 for the
reference.
To turn the phone sounds off
If you’re in a place where your phone sounds may disturb others, you can
quickly silence your phone From the Home screen.
1. Press and hold the Power/Lock Key
until the phone options menu
appears.
2. Tap Silent mode
.
OR
1. Press the down Volume Key
on the side of the phone until
all sounds are turned off.
You can also use these keys to quickly turn the phone sounds back on. Press and hold
NOTE
the Power/Lock Key
Key
(continue pressing to increase volume).
, then tap and . While in Silent mode, press the up Volume
once to activate Vibration mode and twice to turn on phone sounds
Setting Up Your Device
Follow the onscreen instructions to quickly set up your phone and email
accounts.
To set up your device, follow the steps below:
1. Select your language and tap Next.
2. Tap Activate to activate your device. Then follow the spoken instructions
until you hear that activation is complete.
3. On the Welcome screen, tap Next to set up your device.
4. If you are already subscribed, tap Next to continue to set up the email
accounts.
If not, put a checkmark in the checkbox and tap Next to sign in Backup
Assistant Plus or uncheck the checkbox to skip it.
The Basics
5. Set up your email accounts or tap Skip.
6. Read the Privacy caution and tap tap the I agree to share my location
checkbox if you want to activate the location function. Then tap Next.
7. On the Help screen, you can select to view how-to tutorials, My Verizon
video, or additional guides. Tap Next to continue to the next step.
8. Select Sign in to sign into your Google Account or Get an account to
create one.
Tap Not now to skip to the next step. With a Google Account, Google
applications are automatically synced between your phone and computer
regardless of where you make an update.
9. Read the Google location information and select if you want to allow the
specified services. Then tap Next.
10. Tap Done with setup to start using the phone.
For more information on how to set up your email, visit smartphones.
verizonwireless.com/. Hover over the Support tab and under Get Help
With Your click on Device. Then search for your phone.
Setting up your Google Account
Your Gmail, Google Contacts, and Google Calendar events will all be loaded
to your phone automatically after setting up your Google Account.
1. At the setup screen, tap Existing or New.
2. Enter your username and password or any other necessary information if
creating an account, then touch Sign in.
Tap the Back Key to close the keyboard.
NOTE
3. Choose to join Google+ which makes sharing on the web more like reallife sharing. You can choose Circles, Instant Upload, and Messenger.
Touch Join Google+ or Not Now.
4. Complete the Backup and restore screen to allow your Google Account
to back up your apps, settings, and other data, then touch Next.
5. Touch Finish to start using your phone. Now your Gmail, Google
Contacts, and Google Calendar events will all be loaded to your phone
automatically.
17
The Basics
18
This is automatic for the first Google account you add. When adding additional Google
NOTE
accounts, you have to select which options to synchronize
Record your Google account information. Please keep this document in a
safe place.
You must sign into a Google Account to use Gmail, Google Talk, Google
Calendar, and other Google Applications; to download applications from Play
Store; to back up your settings to Google servers; and to take advantage of
other Google services on your phone.
IMPORTANT
ţ
If you want to restore your settings to this phone, from another phone that was running
Android release 2.0 or later
If you wait until after setup is complete, your settings are not restored.
ţ
t have a Google Account, you’re prompted to create one.
If you don’
ţ
If you have an enterprise account through your company or other organization, your IT
department may have special instructions on how to sign into that account.
ţ
When you sign in, your contacts, Gmail messages, Calendar events, and other
information from these applications and services on the web are synchronized with
your phone.
ţ
t sign into a Google Account during setup, you are prompted to sign in or to
If you don’
create a Google Account the first time you start an application that requires one, such
as Gmail or Play Store.
ţ
When you sign in, you’re prompted to enter your username and password using the
on-screen keyboard.
, you must sign into your Google Account now, during setup.
Help
The Help application allows you to quickly view information about your
phone, including the user guide and video tutorials.
To access Help, From the Home screen, tap the Apps Key
> Help .
The Basics
Phone’s Status Icons
The Status Bar appears at the top of every screen. It displays icons
indicating that you’ve received notifications (on the left) and icons indicating
the phone’s status (on the right), along with the current time.
19
Notification icons
Status icons
If you have more notifications than can fit in the Status Bar, a plus icon
prompts you to open the Notifications panel to view them all. To open the
Notifications panel, tap and drag the Status Bar down.
The following icons indicate the status of your phone.
Call icons
Muted microphone during a call
In callIn call using Bluetooth device
Speaker onPrivacy call
Missed call
Calendar and Alarm icons
Alarm setCalendar event
Email and Messaging icons
New email receivedFailed to send email
New message received
High priority message
received
Failed to send messageNew voicemail received
New visual voicemail receivedNew voicemail playing
Google Talk message receivedGmail received
Select input method
Sound icons
Music playingSilent mode
Vibrate modePhone jack connected
The Basics
20
Network icons
3G network connected
Download
network
Downloading dataUploading data
Acquiring GPS dataGPS on
No serviceWeak network signal
Strong network signal
Airplane modeRoaming
Location service onLocation service off
Download complete
Connectivity icons
Weak Wi-Fi signalStrong Wi-Fi signal
USB debugging connectedUSB connected
Bluetooth onBluetooth device connected
USB tethering onMobile Hotspot on
Wi-Fi Direct on
System icons
SmartShare onMore notifications available
System errorSD card inserted
Preparing SD cardSD card error
Sync in processSync error
Battery emptyBattery full
Battery chargingBattery status unknown
ing data through 3G
3G network in use
Upload
ing data through 3G
network
Connected to network
extender service
The Basics
(FUUJOHUP,OPXUIF)PNFTDSFFO
The Home screen is your starting point to access all of the features on your
phone. It displays application shortcuts, icons, widgets, and other features.
Status Bar
Shows device status information,
including the time, signal strength, battery
status, and notification icons.
Application Icon
Tap an icon (application, folder, etc.) to
open the application and use it.
Quick Keys
Provide easy, one-tap access to
the phone functions used most often.
2VJDL,FZT
The Quick Keys are located at the bottom of the Home screen and the
Applications screen.
: Opens the Phone application which displays a dial pad so you can
dial an unsaved number. You can also make calls using your Call logs,
Contacts, and Favorites by tapping the tabs across the top of the
screen.
Tap the Favorites tab to access a quick list of your frequently called contacts.
TIP
:
Opens the Contacts application and displays your Contact list. You
can also access your Groups and Favorites by tapping the tabs
across the top of the screen.
: Opens the Messaging application. You can send text messages or
multimedia messages, which can contain pictures, videos, audio,
maps of your location, slideshows, and vCard files.
:
Opens the Applications screen which displays phone options and
applications. You can also access your list of downloaded files and
a list of available widgets by touching the tabs across the top of the
screen.
Add Icon
Touch to add icons and
widgets to the Home
screen.
Apps Key
Tap to open the
Apps screen to view
all of your installed
applications.
21
The Basics
22
New features for the Home screen
Items (including Quick Keys bar) on the Home screen can be
temporarily hidden to highlight the wallpaper. Pinch out to clean the
screen and pinch in to restore.
Clean view can be used to check the background picture without any
icons and widgets.
Shortcut can be changed to Widgets on the Home screen.
- Tap and hold the shortcut and release to be able to drag the
shortcut’s corners.
- Drag the corner to change it to a widget
- Widget size can be also customized
To return to the Home screen
㻌
Tap the Home Key
at any time, from any application.
To view other Home screen canvases
㻌
Slide your finger left or right across the Home screen. The Home
screen spans up to seven screen widths, allowing more space for
icons, widgets, shortcuts, and other items.
The white bar near the bottom of the screen indicates which Home screen canvas you are viewing.
Pinch in on the Home screen to display the
TIP
mini canvas view, then tap the Home screen
canvas you want to view. Tap and hold the
desired canvas to move it. Drag the canvas to
the Remove icon to remove it.
Tap here to set the default canvas.
Home screen Canvas Indicator
The Basics
Mini canvas view
Mini canvas view allows direct access to any of the canvases and also
allows you to manage your Home screen canvases. You can add up to two
additional Home screen canvases (from 5 screens to 7 screens), delete
canvases, and even rearrange canvas order to suit your needs.
Pinch in on any of the Home screen canvases to change from full screen view
to mini canvas view. From mini canvas view you have the following options:
㻌
To go directly to any Home screen canvas, simply tap the one you
want.
㻌
To add another Home screen canvas, tap Add
space.
㻌
To delete a Home screen canvas, tap and hold the canvas to delete,
then drag it to Remove
turns to
㻌
To rearrange your canvases, tap and hold the canvas to move, drag it
on top of the canvas position where you want it, then lift your finger.
The canvases swap places.
㻌
To set another canvas as the default Home screen, touch the Set
default home screen button at the bottom of the screen, then touch
the screen you want to set as the default screen.
, lift your finger.
at the top of the screen. When the
on an empty canvas
23
The Basics
24
)PNF4DSFFO'PMEFS$SFBUJPO*DPO&EJU.PEF
LG EXCLUSIVE
Customizable Folder Creation
The ability to create folders by dragging and dropping icons on each other
is a great feature for those who like organization. You can now have folders
specifically designated for work items, your children’s games, icons that
help with family or home organization, and even one just for games, etc.
This new organization also allows for more applications to be placed on
the main Home screen or Applications screen, yet provides easy viewing
without distraction.
Icon Editing and Customizing
Users can now edit the icons on the Quick Keys Bar, Home screen or
Applications screen, by creating their own icons with the camera or gallery
images. This gives consumers the ability to replace the generic icons and
have images of loved ones—or with any other image they capture. With
customization, it’
contact or a frequently used app.
Clean View
Wallpapers can now be seen without intrusion, simply by using the “pinch”
technique that will temporarily hide the icons on the Home screen. This is
a great upgrade because users can now really show off the picture of their
loved ones or the awesome concert they saved as wallpaper
s easy to access what is most important, like a special
LG EXCLUSIVE
ţ
ţ
LG EXCLUSIVE
ţ
.
The Basics
Touchscreen
Your touchscreen provides an excellent way to interact with and use your
Android phone. With the tap of your finger, you can download and use
available applications, make menu selections, and access data saved to your
phone.
The following terms are used for describing the different available actions
using the touchscreen:
Touch or tap
(e.g., application or menu item), tap words (e.g., menu selection or to
answer an on-screen question), or tap letters and numbers to type.
Tap and hold
lifting your finger until an action occurs. For example, to open a Context
menu for customizing the Home screen, tap a call log entry until the
Context menu appears.
Drag
finger
You can drag items on the Home screen to reposition them and drag the
Status Bar downward to open the Notifications panel.
Swipe or slide
without pausing when you first tap it (so you don’
For example, you can slide the screen up or down to scroll a list, or
browse through the different Home screens by swiping from left to right
(and vice versa).
Double-tap
quickly double-tap a section of a web page to zoom in or out on that
section to fit the width of the screen. Y
the zoom in Maps and in other applications.
Pinch-to-Zoom
motion to zoom in or out when using the Browser
This motion can also be used to expand or compress the Applications
screen items. It also changes the Home screen to mini canvas view.
A single finger tap selects an item. For example, tap an icon
Tap and hold an item on the screen by tapping it and not
Tap and hold an item for a moment and then, without lifting your
, move your finger on the screen until you reach the target position.
Move your finger quickly across the surface of the screen,
t drag an item instead).
Double-tap to zoom a web page or a map. For example,
ou can also double-tap to control
Use your index finger and thumb in a pinch or spread
, a map, or pictures.
25
26
The Basics
Aspect ratio correction
From many applications, the orientation of the
screen rotates with the phone as you turn it from upright to sideways and
back again.
Rotate the phone sideways for
landscape orientation.
Rotate the phone upright for portrait
orientation.
Text Input Methods
On-screen Keyboard
You can easily enter text using the on-screen keyboard. The on-screen
keyboard displays automatically when you need to enter text. To manually
display the keyboard, simply tap a text field where you want to enter text.
Toggles between
different languages
(only available if multiple
languages are set).
Toggles from 123/SYM
mode to ABC mode. Tap
and hold to set various LG
Keyboard settings.
The Basics
Typing tips
Tap the Numbers Key
Enter other characters
keyboard and tap
symbols. Tap the Letters Key
symbols keyboard.
Enter one capital letterTap the Shift Key
Enter all capital letters
Highlight text
Cut or copy selected text
Paste cut or copied text
Tap the Shift Key
Tap again to revert to lowercase.
Double-tap a word to highlight it. To highlight a
range of text, double-tap the screen, then drag
the blue highlight markers to highlight the text
you want.
Tap and hold the highlighted text, then tap Cut or
Copy in the Context menu.
Tap and hold the location to paste the text, then
tap Paste in the Context menu.
Delete a characterTap the Delete Key
to see the the symbols
to see additional
to exit from the
.
twice.
.
Tap and hold the Language Key to open a
menu to set alternate languages. Then while
Language toggle
typing, simply tap the Language Key
between your language keyboards.
The Language Key appears on the keyboard only
NOTE
after you have selected more than one language to
use.
to toggle
Text input settings
To change your text entry settings and see the dictionary of terms you’ve
used, From the Home screen, tap the Apps Key
Language & input. The following options are available.
Language - Allows you to change the keyboard language.
Personal dictionary - Allows you to add personal words that are not in the
standard dictionaries.
Default - Allows you to choose the default keyboard to use when entering
text.
Google voice typing - Checkmark to select Google voice typing to enter
text. Tap
to change the Google voice typing settings.
> Settings >
27
The Basics
28
Select input languages: Allows you to select the languages to support
with Google voice typing.
Block offensive words: Checkmark to hide recognized offensive text.
LG Keyboard - Checkmark to select the LG Keyboard to enter text. Tap
to change the following settings.
Input language & type: Allows you to select the keyboard language and
type.
Word suggestion: Allows you to set word prediction and auto word
correction.
Auto capitalize: Checkmark so capitalize the first letter of the word
automatically.
Auto punctuation: Checkmark to insert a period when double tapping
the space key.
Voice typing key: Checkmark to display the Voice typing key on the
keyboard.
Touch feedback: Allows you to set key preview, sound feedback, and
vibrate feedback when typing.
Handwriting: Allows you to set the pen width, color, and delay time.
Hide keyboard: Checkmark to allow the keyboard to hide by swiping
down.
Fuzzy pinyin: Checkmark to automatically correct common pinyin
mistakes.
Software version: Displays the LG Keyboard software version.
Swype - Checkmark to select the Swype keyboard to enter text. Tap
change the following settings.
How to Swype: Displays help information to learn how to use Swype in
quick steps.
Personal Dictionary: Allows you to manage your personal dictionary.
Preferences: Allows you to view and modify Swype options.
Language Options: Allows you to activate and set languages.
to
The Basics
Voice Search - Allows you to set various voice search options.
Text-to-speech output - Allows you to set the preferred speech engine,
speech rate, and listen to an example of the speech engine.
Applications: How to View, Open and Switch
Home screen
29
From the Home screen,
tap the Apps Key
open the Apps screen.
Slide the screen left or right to
bring more icons into view.
Tap an application icon to open
the application.
to
App screen
All of the applications on your phone, including any applications that you
downloaded and installed from Play Store or other sources, are grouped
together on the Applications screen, which you access from your Home
screen. If you have more applications than can fit on the Applications
screen, you can slide the screen up or down to view more.
ţ
NOTE
Y
ou can touch the Menu Key
experience for those who want to have denser view of apps.
ţ
Folders can be created in a menu as well as on the Home screen for organizing
purpose.Create folders after pressing the Settings button
and drop an item over another one.
then Show small icons to get better viewing
on the top right and drag
The Basics
30
Your Home screen
Customizing an application icon From the Home screen
You can further personalize the Home screen by editing application icons
using the images in your Gallery.
1. Touch and hold an icon until the canvas grid is displayed, then release the
icon. An editing icon
icon.
2. Touch the icon and select the desired icon design.
OR
Touch the Create photo icon button and select T
Camera application and take a picture or Select from Gallery to choose
one of the available pictures.
Opening and Closing the Applications screen
Opening the Applications screen
It’s easy to access the Applications screen no matter what feature you’re
currently using. Simply tap the
appears at the upper right side of the application
ake photo to open the
Home Key
, then tap the Apps Key .
Closing the Applications screen
To manually close the Applications screen, tap the Home Key .
The Applications screen closes automatically when you tap an icon to open its application.
NOTE
Dragging an icon onto your Home screen also closes the Applications screen automatically.
The Basics
Customizing the Applications screen
The phone includes a wide variety of applications and you can download
even more applications to your device. You can customize these items on
the Applications screen for faster access (less scrolling) to the applications
you use most often.
Rearranging the Applications screen icons
1. From the Home screen, tap the
2. Touch the Apps tab (if necessary), then touch Settings
of the tab bar. The Settings icon changes to a checkmark.
3. Touch and hold the application icon you want to move, drag it to its new
position, then lift your finger. The remaining icons shift to the right.
If you drag the application icon onto another application icon, it creates a folder with both
NOTE
of the applications in it.
Apps Key
.
at the top right
Reverting to alphabetical order
1. To revert all of your application icons on the Applications screen back to
alphabetical order (with no folders), tap the
Apps Key
and make sure
you are viewing the Apps tab.
2. Tap the Menu Key
> Order alphabetically > OK.
Checking application information
To check on an application’s detail information from the Applications screen:
1. From the Home screen, tap the Apps Key .
2. Touch the Apps tab (if necessary), then touch Settings at the top right
of the tab bar. The Settings icon changes to a checkmark.
3. Touch any of the application icons to display an information dialog box.
4. Touch the OK button to exit.
31
The Basics
32
Opening and Switching Applications
Multi-tasking is easy with Android™ because open applications keep
running even when you open another application. There’s no need to quit an
application before opening another. You can use and switch among several
open applications. Android manages each application, stopping and starting
them as needed, to ensure that idle applications don’t consume resources
unnecessarily.
Opening an application
Open an application simply by tapping its icon on the screen.
You can customize your Home screen with the application icons you use most often.
TIP
Applications are located on the Applications screen, but you can copy any application icon
to your Home screen for faster access. No matter where the icon is, on the Applications
screen or your Home screen, just tap it to open and use it.
Opening multiple applications
1. Tap an application icon to open it.
2. Tap the Home Key
If the application icon you want is on your Home screen, simply tap the icon to open and
NOTE
use it.
.
3. From the Home screen, tap the Apps Key .
4. Tap the icon for the other application you want to open.
Switching between multiple applications
1. Tap and hold the Home Key . A screen with the icons of applications
that you’ve used recently will appear.
2. Tap the application icon you want to open or tap the Back Key
return to the current screen.
If you flick the application preview to the
right or left, the icon would disappear
from the recent app list.
to
Tap a preview to open an application
you’ve used recently.
The Basics
Adding application icons to the Home screen
Customize your Home screen with the applications you use most often.
1. Open the Applications screen.
2. Tap and hold the application icon you want to add to your Home screen.
Your Applications screen will close so that you can place the icon on the
Home screen.
3. Lift your finger to place it or drag the icon to where you want it on the
screen, then lift your finger.
Moving applications to other Home screen panels
You can place application icons on any of the Home screen canvases.
Simply tap and hold, then drag the icon to the left or right edge of the
screen to advance to the other screen canvases before lifting your
finger.
The Move home screen items option must be enabled under the
Gesture settings. From the Home screen, tap the Menu KeySettings > Gesture and then checkmark Move home screen items.
Tap and hold the icon to move, then tip the device in the direction of
the canvas you want. The Home screen canvases slide in the tipped
direction. Lift your finger to drop it on the canvas you want.
>
33
The Basics
34
Working With Menus
There are two kinds of Android menus: Options menus and Context menus.
Options menus
Options menus contain tools that apply to the activities of the current
screen or application, not to any specific item on the screen. To open the
available Options menu, tap the Menu Key
Options menus; if you tap the Menu Key
Options menu, nothing will happen.
Some applications have more Options menu items than can fit in the
Options menu. To view the additional menu items, tap More
Context menus
Context menus contain options that apply to a specific item on the screen.
To open a Context menu, tap and hold an item on the screen. Not all items
have Context menus. If you tap and hold an item that has no Context menu,
nothing will happen.
When you tap and
hold certain items on
a screen, a Context
menu opens.
. Not all applications have
on a screen that has no
.
The Basics
Managing Notifications
Notification icons report the arrival of new messages, calendar events,
alarms, as well as ongoing events, such as when you are on a call.
When you receive a notification, the notification icon will be displayed in the
Status Bar. You can open the Notifications panel to view a list of all recent
notifications. Depending on your settings, you may hear a notification sound
and/or the phone may vibrate.
To open the Notifications panel
Tap and drag the Status Bar to the bottom of the screen.
The Status Bar is sensitive to the drag motion so just beginning the downward drag
NOTE
will open the Notifications panel.
Tap to edit which Quick
Settings are displayed on
the Notifications panel. You
can add up to eight icons.
Tap a notification to open it.
To respond to a notification
1. Open the Notifications panel. Your current notifications are listed in the
panel, each with a brief description.
2. Tap a notification to view it.
The Notifications panel will close and the application that corresponds to
your response will open. For example, new voicemail notifications dial
your voicemail box, and Gmail notifications open the Gmail application so
you can read your new messages.
35
The Basics
36
To clear all notifications
1. Open the Notifications panel.
2. Tap Clear
.
All event-based notifications will be cleared; ongoing notifications will
remain in the list.
You can also swipe the notifications to the left or right to remove them.
TIP
To close the Notifications panel
Tap and drag the tab at the bottom of the Notifications panel to the top of
the screen or just tap the Back Key
.
The panel will also close when you tap a notification.
The tab at the bottom of the Notifications panel is sensitive to the drag motion so just
NOTE
beginning the upward drag will close the panel.
Quick settings on the Notifications panel
The top of the Notifications panel includes Quick Settings. These icons
allow quick and easy access to set modes including Sound, Bluetooth, GPS,
Airplane, Data, and more. Tap Edit
your Quick Settings by checking the items you want to appear.
Tap any of the Quick Settings to toggle through the available settings:
Sound
Rotation On
Bluetooth On
GPS On
Airplane mode On
Sync On
100% brightness
Data On
NOTE
, Vibrate , and Silent .
and Rotation Off .
and Bluetooth Off .
and GPS Off .
and Airplane mode Off .
and Sync Off .
, 50% brightness , and no brightness .
and Data Off .
If necessary, scroll horizontally to see all of the available icons.
to open a dialog box to customize
The Basics
Searching Your Phone and the Web
You can search for information on your phone and on the web using the
Search application. Some applications, such as Gmail, Contacts, and Browser
have the ability to search contents within those specific applications.
You can conduct the search by typing in the search terms or saying what you’re
looking for. Typing can be useful because the search application can provide
suggestions so you don’t necessarily have to type out your full request.
Phone and Web search using text entry
1. Tap the Search Key on the Home screen or in the other applications
that support this feature. The Quick Search Box will open automatically.
2. Enter the text you’re searching for in the Quick Search Box.
Voice Search
Tap to search by voice.
Search results
Provides a one-tap shortcut to
matching search items and past
searches.
As you type, search results from your phone,
previous search terms, and web search
suggestions appear. Tap an item to activate that
search result.
37
The Basics
38
You can use the Search preferences to configure some aspects of web
search (for example, whether it makes suggestions below the Quick
Search Box as you type), and what phone features you want to include in
searches. To access these settings,tap the Search Key to open the
Search application and tap the Menu Key > Settings.
Locking the Screen
Your phone automatically uses a default Lock Screen to simply prevent
unintentional function activation. You can choose to secure your phone so
that only you can unlock it to make calls, access your data, buy applications,
and so on. For added security to guard against unauthorized use, you can
set a pattern, PIN, or password that will need to be entered to unlock.
Setting Swipe, Face Unlock, Pattern, PIN, or Password
Follow these steps to set an unlock sequence for the first time or after you
disable a previously set unlock sequence.
1. From the Home screen, tap the Apps Keyscreen.
2. Tap Select screen lock.
3. Tap None, Swipe, Face Unlock, Pattern, PIN, or Password.
None: No lock screen is enabled so the screen will never be locked from
use.
Swipe: A swipe motion in any direction on the touchscreen will unlock
the screen.
Face Unlock: Unlocks the screen using face recognition. Keep in mind
that Face unlock is less secure than a pattern, PIN or password because
it uses generalized shape and dimension to verify your face.
Pattern: Locks the screen using a pattern you draw with your finger.
The first time you set an unlock pattern, you will see a tutorial with
instructions on how to create it. Read the tutorial and tap Next. Draw
your pattern (connect at least 4 dots) and tap Continue. Then redraw
your pattern and tap Confirm.
Follow the on-screen instructions to create a backup PIN number in case you forget your
NOTE
pattern.
> Settings > Lock
The Basics
PIN: Locks the screen with a number sequence. Enter a PIN (at least 4
digits) and tap Continue. Reenter your PIN and tap OK to confirm it.
Password: Locks the screen with an alphanumeric sequence. Enter
a password (at least 4 characters) and tap Continue. Reenter your
password and tap OK to confirm it.
From then on, any time you want to turn the phone on or unlock the
screen, you will need to draw your unlock pattern or enter your PIN or
password to unlock the screen.
Disabling the lock sequence
If you change your mind about using a lock sequence to secure your phone,
you can disable it.
1. From the Home screen, tap the Apps Keyscreen.
2. Tap Select screen lock.
3. Confirm your unlock information.
4. Tap None to disable the previously set lock security.
> Settings > Lock
Changing Your Unlock Pattern
1. From the Home screen, tap the Apps Key > Settings > Lock
screen.
2. Tap Select screen lock.
3. Draw your current unlock pattern.
4. Tap Pattern to change it.
5. You’re prompted to draw and redraw your new pattern.
6. Enter a Backup PIN and touch Continue. Then confirm your Backup PIN
and touch OK.
39
The Basics
40
Changing your PIN or Password to Lock the Screen
1. From the Home screen, tap the Apps Key > Settings > Lock
screen.
2. Tap Select screen lock.
3. Enter your current lock sequence.
4. Tap PIN to change your number lock sequence or tap Password to
change your alphanumeric lock sequence.
5. You’re prompted to enter and reenter your new lock sequence.
From then on, you will need to enter the sequence and tap OK to unlock
the screen.
- If you’ve created a Google Account on the phone, tap Forgot pattern?. Then you
ţ
Y
NOTES
ou have 5 opportunities to enter your unlock pattern, PIN or password. If you used
all of opportunities, you can try again after 30 seconds.
ţ
If you have set up a Microsoft Exchange account, you are only allowed to set up a
password.
ţ
When you can’
are required to sign in with your Google Account to unlock your phone or enter the
Backup PIN.
t recall your unlock pattern:
Security lock timer
If a security lock is enabled, tap Security lock timer in the Screen unlock
section to set the amount of time before the screen automatically locks due
to inactivity.
To adjust the Security lock timer, tap the Menu Key
screen > Settings > Lock screen > Security lock timer. Then select the
desired amount.
From the Home
Power button instantly locks
If a security lock is enabled, checkmark the box to enable Power button
instantly locks so that pressing the Power/Lock Key
the screen or remove the checkmark to disable it.
will instantly lock
The Basics
The default Lock screen
Press the Power/Lock Key to illuminate the touchscreen if it has timed
out. If the unlock sequence is set to Swipe, a default Lock screen is
displayed, but you can still conveniently check the date, time, and Status
Bar icons. You can drag the Status Bar down to open the Notifications
Panel without unlocking the screen. In addition, you can also quickly access
four applications (Phone, Messaging, Search, and Camera) without fully
unlocking the screen. Simply swipe the icon upward to open and use it.
Changing the items on the default Lock Screen
1. From the Home screen, touch the Apps Key > Settings > Lock
screen.
2. Touch Clocks & shortcuts.
To change the Quick access icons, touch one of the icons at the
bottom of the screen, then touch the application you want to replace
it with.
To change the date and time format, swipe left or right until the one
you want is displayed.
3. Touch the Save button to save these settings.
41
The Basics
42
Customizing the Home screen
You can personalize your Home screen by adding application icons,
shortcuts, widgets, and other items to any Home screen canvas. You can
also change the wallpaper.
To add an item to the Home screen
1. From the Home screen, touch and hold an empty space on a Home
screen canvas.
2. The following four category tabs appear at the bottom of the screen:
Apps, Downloads, Widgets, and Wallpapers. Touch the one that
corresponds to the item you want to add.
O
Apps: Displays all installed applications.
O
Downloads: Displays all downloaded applications.
O
Widgets: Displays all installed widgets.
O
Wallpapers: Allows you to change the Charging and Home screen
wallpapers to preloaded images or pictures from your Gallery.
Slide the screen right or left to view
different home screen canvas.
Tap and hold an icon and drag it to the
desired screen.
Tap to access the tab.
3. Swipe left and right to scroll through the available choices in the category
tab you selected. Touch and hold the item you want, then drag it onto
the Home screen canvas.
To move an item on the Home screen
1. Tap and hold the item.
2. Drag the item to a new location on the screen.
Pause at the left or right edge of the screen to drag the item onto the
next available Home screen canvas.
The Basics
3. When the item is where you want it, lift your finger.
If Move home screen items is enabled in the Gesture settings, simply tilt the device in
NOTE
the direction you want to move the item to one of the canvases. Lift your finger when it
arrives at the canvas you want.
To remove an item From the Home screen
1.
Tap and hold the item.
2.
Drag the item to the Remove icon
.
3. When the Remove icon changes to , lift your finger.
To change the Home screen wallpaper
1. From the Home screen, tap the Menu Key > Home screen settings
> Wallpaper.
You can also tap and hold an empty spot on the Home screen and then
tap Wallpapers in the menu that opens.
2. Tap Charging wallpapers, Gallery, Live wallpapers, or Wallpapers.
Tap Charging wallpapers to choose the wallpaper you want to be
displayed when you charge your phone.
Tap Gallery to use a picture you’ve taken with your camera as the
wallpaper. You can crop the picture before setting it as your wallpaper.
Tap Live Wallpapers to choose from animated wallpapers installed on
your phone.
Live wallpapers can change according to the time of day, respond to
tapping the screen, tell the time, or offer other information.
Tap Wallpapers to choose from picturesque static images to apply to
your device.
3. Tap Set wallpaper or OK.
43
To change the Home screen Theme
Four different themes are provided, which come with a dedicated Home
screen wallpaper, Lock screen and applications list per theme.
1. From the Home screen, tap the Menu Key
2. Select from Optimus, Cozywall, Opart and Playworld.
and select Theme.
The Basics
44
To rename a folder
1. Tap the folder icon to open it.
2. Tap the folder window’s title bar.
3. Enter the new folder name.
4. Tap OK.
You can also change the folder color under the Folder color section.
NOTE
To reposition Home screen canvases
1. Pinch in on the Home screen to display the mini canvas view.
2. Tap and hold the canvas you want to move, then drag it to the new
position and lift your finger. If the position has an existing canvas, the
canvases shift to the right.
To add additional Home screen canvases
There is enough space for up to seven Home screen canvases. While in the
mini canvas view, tap the Add icon
on an empty Home screen canvas to
add an additional canvas to that spot.
The Add icon is only available when one or more canvases have been deleted.
NOTE
To remove Home screen canvases
While in the mini canvas view, tap and hold the canvas that you want
removed. Drag the canvas to
appears.
the Remove icon
and lift your finger when
The Basics
Connecting Quickly With Your Contacts
As you build up your list of contacts on your phone, you can use Quick
Contact for Android to quickly chat, email, text message, place a call, or
locate your contacts. Quick Contact for Android is a special set of icons that
you can use to quickly and easily connect to a contact.
Open your Contacts list and tap the contact’s picture
Taping the contact’s picture opens a Quick Contact bubble displayed
directly above the contact’s name. This bubble displays icons for all of
the ways you can communicate with that contact. The available icons
depend on the information you have saved for that contact.
Tap a Quick Contact icon to communicate with the contact. Depending
on the icon you’ve tapped, a different application will open.
Adding a shortcut for a contact to your Home screen allows you to open Quick Contact
TIP
for that contact without opening the Contacts application.
.
45
Connecting to Networks and Devices
46
Connecting to Wi-Fi Networks
Wi-Fi is a wireless networking technology that can provide Internet access
at distances of up to 100 meters, depending on the Wi-Fi router and your
surroundings.
To use Wi-Fi on your phone, you must connect to a wireless access point,
or “hotspot.” Some access points are open and you can simply connect to
them. Others are hidden or implement other security features, so you must
configure your phone so it can connect to them.
Turn off Wi-Fi when you’re not using it, to extend the life of your battery.
The following Status Bar icon indicates your Wi-Fi status.
Connected to a Wi-Fi network (waves indicate connection strength)
When you connect to a Wi-Fi network, the phone obtains a network
address and other information it needs from the network, using the
DHCP protocol. To configure the phone with a static IP address and other
advanced settings, from the Wi-Fi settings screen tap the Menu KeyAdvanced
To turn Wi-Fi on and connect to a Wi-Fi network
1. From the Home screen, tap the Apps Key > Settings .
2. Touch Wi-Fi. If the Wi-Fi button is on the left and the icon is grey-
colored, drag the button to the right. Your device scans for available Wi-Fi
networks and the icon turns blue when successful.
3. Tap a network to connect to it.
O
If the network is secured, you will be prompted to enter a password
O
When you’re connected to a network, you can tap the network name
.
(Ask your network administrator for details).
in the Wi-Fi settings screen for details about the speed, security,
address, and related settings.
>
Connecting to Networks and Devices
New network detection and notification
Checkmark the Notify Me box in the Wi-Fi settings screen to be notified
when new networks are detected.
When Wi-Fi is on and the user launches an application that uses Wi-Fi,
a dialog box will appear when new networks are detected.
When Wi-Fi is off and the user launches an application that uses Wi-
Fi, the device will turn on Wi-Fi and display a dialog box when new
networks are detected.
If the Notify Me checkbox is not marked and Wi-Fi is off, the device
will not display a dialog box when new networks are detected.
To add a Wi-Fi network
You can add a Wi-Fi network so the phone will remember it, along with any
security credentials, and connect to it automatically when it is in range. You
can also add a Wi-Fi network manually if it does not broadcast its name
(SSID) or if you want to add a Wi-Fi network when you are out of its range.
To add a secured network, you need to contact the network’s administrator
to obtain the password or other required security credentials.
1. Turn on Wi-Fi, if it’s not already on.
2. From the Wi-Fi settings screen, tap ADD NETWORK.
3. Enter the Network SSID (name) of the network.
If the network is secured, tap the Security dropdown menu
the type of security deployed on the network.
4. Enter the required passwords and security credentials.
5.Tap Save.
The phone will connect to the wireless network. Any credentials that you
entered are saved, so you’re connected automatically the next time you
come within range of this network.
and tap
47
Connecting to Networks and Devices
48
To forget a Wi-Fi network
You can make the phone forget about the details of a Wi-Fi network that
you added. For example, if you don’t want the phone to connect to it
automatically or if it’s a network that you no longer use.
1. Turn on Wi-Fi, if it’s not already on.
2. In the Wi-Fi settings screen, tap and hold the name of the network that
you want to forget.
3. Tap Forget network in the Context menu that appears.
Wi-Fi Direct connection
You can make a connection directly with Wi-Fi devices without any access
point. Your device can create a group connection or individual connection.
1. From the Home screen, tap the Apps Key
(WIRELESS & NETWORKS section).
2. Tap Wi-Fi Direct to set up your Wi-Fi Direct connection settings.
Checkmark the Wi-Fi Direct checkbox to turn it on. A pop-up screen
with instructions on how to connect with Wi-Fi Direct and Wi-Fi
devices appears after checking the Wi-Fi Direct checkbox.
Tap Device name to open a dialog box to enter a name for your device.
Tap Password to set or change your password for Wi-Fi Direct
connection.
> Settings > More...
Connecting Your Device to Your Computer
Before using your device’s mass storage capabilities, you need to prepare
your device’s data services to synchronize with your desktop or laptop
computer. Once you have connected the device to the computer, you can
transfer your data to or from the device memory.
To connect your device to a computer via USB:
1. Use the USB cable that came with your phone to connect the phone to a
USB port on your computer.
2. Open the Notifications panel and tap the USB connection type.
3. Tap the connection mode you want to use to connect to the PC.
Choose from the following options: Charge only, Mass storage, Media Sync(MTP), Internet connection or Camera(PTP).
Connecting to Networks and Devices
USB Autorun
USB Autorun is a feature that allows your phone to connect to a PC using a
USB Cable and set it up on that PC without a physical CD-ROM.
Automatically installs the LG USB Modem driver.
Allows the phone to be used as mass storage when a microSD card is
present in the phone. It allows transfer of unprotected content from the
phone to the PC and vice versa.
User content such as photos, videos, and voice recordings can be stored on a removable
NOTE
microSD card that is inserted in your phone.
To select USB mode for Autorun
1. From the Home screen, tap the Apps Key > Settings >
Connectivity > USB connection type.
2. Tap Mass storage to connect to the PC for Autorun.
Tap Charge only to use only the charging function and not the USB
function.
Tap Internet connection to use the ethernet function and not the default
USB function.
ţ
USB Autorun only works with Windows® XP, Windows® Vista, and Windows® 7
NOTES
operating systems.
ţ
Autorun automatically installs the USB device driver for every USB mode.
Log on to the PC as Administrator. Non-Administrator accounts have insufficient
privilege to install the USB Modem driver and don’t run the Autorun feature.
ţ
Do not unplug the USB Cable during Autorun.
ţ
If Autorun doesn't function properly
storage mode.
, unplug and plug the USB Cable to set Mass
49
Internet connection mode
You can share your phone’s internet connection with your PC using a USB
Cable. After connecting with a USB Cable, set the USB connection mode to
Internet connection. Then select either Ethernet or Modem.
Ethernet: This mode changes the phone to USB tethering mode from
the PC. From the Home screen, tap the Apps Key
> Settings >
Connecting to Networks and Devices
50
More... > USB tethering > Mobile Broadband Connect.
This mode can only be used by a user registered to a tethering plan.
NOTE
Modem: This mode changes the phone to Modem mode from the PC.
Ask on connection
You can choose to be asked to confirm the USB connection when
connecting to a computer.
When Ask on connection is checkmarked, the USB selection window is
displayed when the USB Cable is connected.
Autorun is not available when:
Phone is booting (powering up).
PC operating system is not set to Autorun (automatic execute command).
To change the Connection mode settings while Autorun is running:
You can change the settings while Autorun is running. From the Home
screen, tap the Apps Key
> Settings > Connectivity > USB
connection type > Mass storage.
Be sure to checkmark the box Ask on connection if you want to be asked to confirm
NOTE
the USB connection mode when the phone is connected to a computer.
Using the Status Bar to change the settings
The Status Bar shows the current USB connection mode so you can easily
open the Status Bar and change the settings as needed.
When connected via USB, the current USB connection mode also appears
on the Notifications panel. Tap the connection setting to display a screen
where you can change the USB connection mode.
If the Ask on connection checkbox is marked, the screen is only provided during USB
NOTE
connection, but is not provided in the notification area.
Step 1. Connecting the phone to a PC
Connect your phone to your PC with a compatible USB Cable
(supplied). LG Autorun starts automatically.
Click ‘I accept the terms in the agreement’ then ‘Yes’.
Connecting to Networks and Devices
ţ
Autorun is only supported for Windows® XP, Windows® Vista, and Windows®7.
NOTES
ţ
The USB Autorun feature works only under an Administrator account. The installer has
insufficient privileges under a Non-Administrator account. Log on as Administrator
device is switched back to the user set mode within 30 seconds.
Step 2. Downloading the LG USB Modem Driver.
ţ
If a previous version of the LG USB Modem driver is installed in the computer
NOTES
automatically be updated to the recent version.
ţ
If a recent version of the LG USB Modem driver is installed in the computer
Autorun skips ‘Step 2.’
51
. The
, it will
, LG
Connecting to Networks and Devices
52
Step 3. Installing the LG USB Modem Driver.
Step 4. Installing the Utility Application.
Make Your Device a Mobile Hotspot
The Mobile Hotspot application can share the phone’s data connection
with any Wi-Fi capable devices.
1. From the Home screen, tap the Apps Key > Mobile Hotspot .
2. Tap the Mobile Hotspot checkbox to enable this feature.
3. Read the disclaimers and Help information, then tap OK.
4. Your portable Wi-Fi Hotspot is now created.
The following Status Bar icon indicates your Wi-Fi Hotspot status.
WARNING!
There are security risks associated with creating a Wi-Fi network open to the public. It is
highly recommended that you take steps to protect your Wi-Fi network from unauthorized
access.
You can use this menu to enable and disable the connection. Once the
connection is active, go to the device you want to connect and configure
its wireless connection to the Network SSID for your Android device
and input the password (if you are using WPA2 PSK). You will now have
wireless access on your device.
WEP is highly vulnerable to hacking. WPA2 is recommended by the IEEE.
NOTE
Portable Wi-Fi Hotspot is active
microSD Card
microSD Card
The microSD card is sold separately.
NOTE
Unmounting and removing the microSD Card
To safely remove the microSD card from your device, you must first
unmount it before removing it from the phone.
1. From the Home screen, tap the Apps Key >
Unmount SD card > OK. Now you can safely remove the microSD card.
2. Remove the back cover.
3. Carefully push the edge of the microSD card in to release it from the slot,
then gently pull it out of the slot.
You can easily damage the microSD card and its adapter by improper operation. Please
NOTE
be careful when inserting, removing, or handling them.
Viewing Memory Information
1. From the Home screen, tap the Apps Key > Settings > Storage.
2. Review the available information.
The storage page is divided into five sections: Total memory, System
memory, Internal memory, and SD Card.
Settings
> Storage >
53
microSD Card
54
Formatting the microSD Card
Formatting a microSD card permanently removes all files stored on the card.
1. From the Home screen, tap the Apps Key > Settings > Storage.
2. Tap Unmount SD card > OK to release the microSD card from device
use. An icon appears within the Notifications panel to indicate an
unmounted microSD card.
3. Once released, tap Erase SD card > Erase SD card > Erase everything.
Once completely formatted, the card is automatically re-mounted
(reconnected for use by the device).
The formatting procedure erases all of the data on the microSD card, after which the files
NOTE
CANNOT be retrieved. To prevent the loss of important data, please check (and backup,
if necessary) the contents before you format the card.
Using Media sync (MTP) mode
When you connect the phone and PC using a USB Cable and set your
device’s USB connection mode to Media sync (MTP), you will see two
removable disks on the PC. You can copy files to/from the removable
microSD card.
Calls
1MBDJOHBOE&OEJOH$BMMT
You place calls using the Phone application. Calls can be manually dialed
using the Dial tab. You can also dial from your phone’s memory using the
Call logs tab, the Contacts tab, or the Favorites tab.
To open the Phone application
From the Home screen, tap the Phone Key in the Quick Keys bar.
To place a call by dialing
1. Open the Phone application.
To dial an international
number, tap and hold the
0 key to enter the plus (+)
symbol. Then, enter the
international prefix for the
country; followed by the
full phone number.
Tap to dial using your
voice.
2. Tap the keys on the dialpad to manually enter a phone number.
If you enter a wrong number, tap the Delete Key
one by one.
To erase the entire number, tap and hold the Delete Key
To dial an international number, tap and hold the
plus ( + ) symbol. Then, enter the international prefix for the country;
followed by the full phone number.
Tap to send a text or
multimedia message to
the number you entered.
Tap the Call Key
the number that you entered.
to dial
to erase digits
.
Key to enter the
55
Calls
56
3. Tap the Call Key to dial the number that you entered.
You can use other phone features while the call is underway. If you
open another application, the Call icon
appears in the Status Bar for
the duration of the call.
Press the Volume Keys to adjust the call volume.
Use the on-screen buttons to enter additional numbers, place the
call on hold and take an incoming call, add another call, use the
speakerphone, end the call, and other options.
If you opened other applications while on a call, you'll need to return to the Call screen
NOTE
and tap End call
(in the Quick Keys bar) or tap the Contact's name or number at the top right corner of
the Home screen to open the call screen. You can also drag the Notifications panel down
and tap End call
to end the call. You can tap the Home Key , then the Phone Key
.
Instant List
Instant list is displayed on the Dial tab to help you to use the information
stored in your Contacts list and Call log without needing to open and search
those applications first. Once you enter three or more numbers you want
to dial, Instant list displays entries from your Contacts list or Call log that
match the sequence that you entered.
Sequence matches
The device searches for the entered sequence anywhere in the number,
beginning, end, or anywhere in-between. The matching number sequence
is displayed within the number in orange text. The name and type of
number (i.e., Mobile, Work, etc.) associated with the number you enter is
displayed above the dial pad. When there are multiple matches, tap the
Instant list icon
to view more matching entries.
Calls
Selecting an Instant list entry
Tap an entry in the Instant list to insert it on the dialpad and tap the CallKey
to dial it.
Instant list Icon
Tap to view more of the Instant list.
Instant List
Airplane mode
Some locations may require you to turn off your phone’s wireless
connections by placing your phone in Airplane mode.
1. Press and hold the Power/Lock Key
2. Tap Airplane mode.
The Wireless & networks setting also has a checkbox to enable or disable Airplane mode
NOTE
and the Notifications panel has an Airplane mode icon which toggles it on or off.
.
57
Calls
58
Answering or Rejecting Calls
When you receive a phone call, the Incoming call screen opens with the
caller ID and any additional information about the caller that you have saved
in the Contacts list. All incoming calls are recorded in the Call log.
To answer a call
If the screen is unlocked, simply tap the Answer Key .
If the screen is locked, swipe the Answer icon
If you were already on a call, tap the Answer Key
call on hold while you answer the new call.
To silence the incoming call ringer, press the Volume Keys.
NOTE
Unlocked ScreenLocked Screen
in any direction.
to place the first
Tap the
Answer Key
to answer the
call.
Swipe the
Answer icon in
any direction to
answer the call.
Calls
To decline a call and divert it to voicemail
If the screen is unlocked, tap the Decline Key .
If the screen is locked, swipe the Decline icon
The caller is sent directly to your voicemail box to leave a message.
Unlocked ScreenLocked Screen
in any direction.
59
Tap the Quick
msg Key to send
a quick message
to the caller and
forward them to
your voicemail.
NOTE
Tap the Decline Key to decline
the call and send the caller
directly to your voicemail box
to leave a message.
To silence the ringer, press the Volume Keys.
Swipe the Quick msg icon in any
direction to send a quick message to
the caller and forward them to your
voicemail.
Swipe the
Decline icon in
any direction to
decline the call and
send the caller to
voicemail.
To decline a call and send a text message
1. When you receive an incoming call and the screen is unlocked, tap the
Quick msg icon . If the screen is locked, swipe the Quick msg icon
in any direction.
2. Tap the text message you want to send in place of answering the call.
This feature can only be used to send a message to another mobile phone. It is not
NOTE
applicable to incoming landline calls.
Calls
60
Working with the Call Log
The Call log is a list of all of the calls you’ve dialed, received, or missed. It
offers a convenient way to redial a number, return a call, or add a number to
your Contacts list.
To open the Call log
Tap the Phone Key (in the Quick Keys bar) and then the Call logs
tab
at the top of the screen.
All calls (sent, received, and missed) are listed in the Call logs tab.
The most recent calls are located at the top of the list. Scroll down to
see older entries.
The Call logs tab displays the
history of all your calls.
To dial a number in the Call log
From the Call log, tap the Call Key at the right of the call entry.
You can also tap the entry’s picture to open the Quick contact menu
with more options to communicate with that contact.
To add an entry’s number to your Contacts
1. Tap and hold the call entry.
2. Tap Add to Contacts in the Context menu.
3. Tap Create new contact and enter the Contact information or tap an
existing contact to add the new number to.
Calls
To take other actions on a Call log entry
Tap a Call log entry to open a screen where you can call the contact,
send the contact a message, add the number to your Contacts list (or
view contact information), delete the call from the log, and learn more
about the original call.
Tap and hold a Call log entry to open a Context menu where you can
perform more actions.
To clear the Call log
Clearing the Call log all at once
1. Tap the Phone Key (in the Quick Keys bar), then the Call logs tab
at the top of the screen.
2. Tap the Menu Key
.
3. Tap Clear all > OK.
Selectively clearing the Call log
1. Tap the Phone Key (in the Quick Keys bar), then the Call logs tab
at the top of the screen.
2. Tap the Menu Key
.
3. Tap Clear and then checkmark the call entries you want to delete.
4. Tap Clear > OK.
You can also selectively delete by tapping and holding a Call log entry, then tap Clear all
NOTE
logs of this number > OK.
Filtering Call log entries
1. Tap the Phone Key (in the Quick Keys bar), then the Call logs tab
at the top of the screen.
2. Tap the Menu Key
3. Tap Received calls, Dialed calls, or Missed calls.
You can also access advanced filters by tapping Advanced filtering, selecting your
NOTE
criteria, then tapping Apply.
> Filter.
61
Calls
62
Calling Your Contacts
Instead of manually dialing phone numbers using the dial pad, you can use
your Contacts list to dial quickly and easily.
You can also quickly call a contact using Quick Contact.
If you have contacts on the web, you can choose whether to synchronize
with your phone when you first set up your Google™ Account.
To call a contact
1. Tap the Contacts Key in the Quick Keys bar.
2. Tap the contact you want to call.
3. Tap the contact’s phone number you want to call.
To call a favorite contact
1. Tap the Contacts Key , tap the Favorites tab at the top of the
screen.
2. Tap the contact you want to call.
3. Tap the contact’s phone number you want to call.
Calls
Voice Dialer
You can use the Voice Dialer application to place a phone call by speaking
the name of a contact or a phone number.
To place a call by speaking
1. Tap Voice Dialer in the Applications screen.
If you have a Bluetooth device that supports "voice-recognition" or "voice
dialing" you may be able to open Voice Dialer by pressing your headset’s
main button or in some other way, and dial by voice using your headset.
For details, see the documentation that came with your headset.
2. Say "Call" followed by the name of the contact or say "Dial" followed by a
phone number.
Options During a Call
Tap to turn the speakerphone on or off. The
Speaker Key lights up to indicate that the
speakerphone is on.
Tap to mute the microphone during a call.
The Mute Key lights up to indicate that the
microphone is muted.
Tap to switch between a Bluetooth headset and
the phone.
63
Calls
64
To mute the microphone during a call
Tap Mute .
The light bar on the Mute button illuminates blue to indicate that the
microphone is muted. The Muteicon
will appear in the Status Bar
to remind you that the microphone is turned off.
While viewing the in-call screen, you can unmute the microphone by
tapping Mute again.
The microphone is unmuted automatically when the call ends.
To turn the speakerphone on or off
Tap Speaker .
The light bar on the Speaker button illuminates blue to indicate that
the speakerphone is on. The Speaker icon
will appear in the
Status Bar and the sound from your call is played through the phone’s
speaker on the back of the device.
While viewing the in-call screen, you can turn the speakerphone off by
tapping Speaker again.
The speaker is turned off automatically when the call ends.
WARNING!
To avoid damage to your hearing, do not hold the phone against your ear when the
speakerphone is turned on.
To switch between a Bluetooth device and the phone
When a Bluetooth device is paired and connected to your phone, you can
conduct calls on it for hands-free conversations. During a call, you can easily
switch between using the Bluetooth device and your phone.
When using the Bluetooth device during a call, the Ongoing Call notification
icon is blue in the Status Bar (the icon is green when using the phone).
Tap Bluetooth
vice versa.
to switch the call from the headset to the phone, or
Calls
Managing Multiple Calls
Contact your wireless service provider to learn whether they support
conference calls and how many participants you can include.
To switch between current calls
Tap Swap .
The current call will be placed on hold and you will be connected with
the other incoming call.
To set up a conference call
Contact your wireless service provider to learn whether they support
conference calls and how many participants you can include.
1. Place a call to the first participant.
2. When you’re connected, tap Add call
3. The Phone application opens. Enter a phone number, then tap the Call Key
.
Tap the keys on the dialpad to manually enter a phone number.
Tap the Contacts tab
Tap the Call log tab
Tap the Favorites tab
Tap a Frequent list entry to enter it.
4. After you’re connected, tap Merge call
the conference call.
to select a number from your Contacts list.
to select an entry in your Call log.
to select one of your Favorites.
.
. The participant is added to
65
Tap here to merge call.
Calls
66
Listening to Your Voicemail
When you have a new voicemail message, the Voicemail notification icon
appears in the Status Bar. If you have not set up your voicemail number,
or if you need to change it, you can do that in the Call settings.
To listen to your Voicemail
Open the Notifications panel and tap New voicemail.
OR
From the Home screen, tap the Phone Key
then tap the Voicemail Key
system guides you through the process of listening to and managing
your voicemail. The first time you call your voicemail, it also guides you
through the process of recording greetings, setting a password, etc.
. Typically, your carrier’s voicemail
To set up your Voicemail
1. Tap the Phone Key in the Quick Keys bar on the Home screen. (The
Phone application can also be accessed from the Applications screen.)
2. Tap the Voicemail Key
3. If you hear a system greeting, tap
4. Follow the setup tutorial.
5. Select a password.
6. Record a voice signature and greetings for your voice mailbox.
to dial your voice mailbox.
to interrupt it, if applicable.
To access your voicemail from your wireless device
1. Tap the Phone Key in the Quick Keys bar on the Home screen.
2. Tap the Voicemail Key
system greeting or your own greeting, tap the
interrupt the system greeting and follow the prompts.
3. Follow the prompts to enter your password and retrieve your messages.
to dial your voice mailbox. If you hear a
in the Quick Keys bar,
immediately to
Web
Browser
The Browser application allows you to access the internet from your
Verizon Wireless device. Access and selections within this feature are
dependent upon your service provider. For specific information on Browser
access through your phone, contact your service provider.
Internet
Learn to access and bookmark your favorite web pages.
s You may incur additional charges for accessing the web and downloading media. For
NOTES
details, contact your service provider.
s A
Browse web pages
1. From the Home screen, tap the Apps Key > Browser or tap the
2. Navigate web pages using the following:
3. While browsing the web page, use the following options using the
To go to the previous page, tap Back
To go to a next page in history, tap Forward
vailable icons may vary depending on your region.
Browser icon directly from Home screen. To access a specific web
page, enter the web address (URL) of the web page, and tap on the
keyboard.
URL Field
Tap here to enter a web address
for the web page you want to
access.
Drag the tab at the top of the
toolbar to display it. You can
also tap the Menu Key Settings > General and uncheck
the Toolbar option so that it is
not displayed at the bottom of
the screen.
>
Toolbar
toolbar:
in the toolbar or tap the Back
Key .
.
67
68
Web
To zoom in or out, double-tap the screen. You can also use the
pinch to zoom method. Place your two fingers on the screen and
slowly pinch or spread them apart. You can also tap and hold Zoom
and tilt the phone up to zoom in or down to zoom out.
To open a new window, tap New tab
To view the list of bookmarks, tap Bookmarks
can also add, edit, or delete a bookmark from this menu.
To reload the current web page, tap
To stop loading a web page, tap the Stop icon in the URL field. The
Stop icon only appears while a web page is loading. You can also tap
the Menu Key > Stop.
To bookmark the current web page, tap the
bookmarks.
To open the home page, tap the
To send the web address (URL) of the web page to others, tap the
Menu Key
To search for text on the web page, tap the
page.
To change the current mobile page to a desktop page, tap the
Key
To access the current web page later, you can save in the device
storage by tapping the Menu Keyreading to access when offline. You can check the saved web pages
by tapping
To adjust the brightness from the Browser, tap the Menu Key
Brightness.
To view your downloads, tap the Menu Key
To customize the Browser settings, tap the Menu Key
To close the browser module, tap the Menu Key
the Browser using this method, you will be connected to the home
page the next time the Browser is opened.
> Share page.
and check the Request desktop site option.
from the toolbar and then the Saved pages tab.
in the toolbar.
in the toolbar. You
the Menu Key
Menu Key
Menu Key
> Go to Homepage.
Menu Key
and then Save for offline
> Downloads.
> Refresh.
> Settings.
> Exit. If you exit
> Saveto
> Find on
Menu
>
To view the currently active windows, tap Tabs next to the URL
field. You can scroll up and down to view the open tabs. To close
the tab, tap
or swipe the window to the right or left. The tab will
disappear, indicating it has been closed.
To open new incognito tab, tap the Tabs
Menu Key
> New
>
incognito tab.
To copy text from a web page, tap and hold the desired text. The
selected text will be highlighted and a pop-up appears with the
following options: Select all, Copy, Share, Find, and Web Search. If
you want to adjust the range of the highlighted text, drag the cursor
from each edge of the text.
To view the web page details, tap the icon to the left of URL field.
When you are in a secure page, tap View certificate on the Page info. screen to see the
NOTE
certificate for the current page.
Bookmark your favorite web pages
If you know the web address of the web page, you can manually add a
bookmark. To add a bookmark:
1. Tap the
Menu Key
2. You can edit the Label and Address (URL). You can also select what
location to place your bookmark.
3. Tap OK to save the bookmark.
> Save to bookmarks.
Web
69
70
Web
From the bookmarks list, tap and hold a bookmark and use the following
options:
To open the web page in the current window, tap Open.
To open the web page in a new window, tap Open in new tab.
To edit the bookmark details, tap Edit bookmark.
To add the bookmark as a shortcut to one of the Home screen
canvases, tap Add shortcut to home.
To send the web address (URL) of the web page to others, tap Share
link.
To copy the web address (URL) of the web page, tap Copy link URL.
To delete the bookmark, tap Delete bookmark.
To use the web page as your Browser homepage, tap Set as
homepage.
To delete multiple bookmarks at once, tap the Menu Key
Delete. You can individually choose the bookmarks you want to delete
or tap Select all to select all of the available bookmarks. Then tap
Delete > OK.
To move a bookmark list, tap the Menu Key
individually choose the bookmarks you want to move or tap Select all
to select all of the available bookmarks. Then tap Move and select the
folder you want to move it to.
To view the recently visited web pages, tap the History tab, which
will display your history in chronological order. You can also access the
most visited web pages.
To view the saved pages, tap the Saved pages tab.
> Move. You can
>
Changing Browser settings
You can configure a number of Browser settings, including how you view
and use pages as well as allowing you to manage your privacy.
To open the Browser settings screen, tap the Menu Key
Browser and tap Settings.
from the
Web
(FOFSBM
Set homepage: Allows you to set the homepage to the following options:
Current page, Blank page, Default page, Most visited sites, Other.
Toolbar: Allows you to display the toolbar at the bottom of the screen.
AUTO-FILL
Form auto-fill: Fill out web forms with a single touch.
Auto-fill
text: Set up text to auto-fill in web forms.
Privacy & Security
Clear cache: Allows you to clear locally cached content and databases.
Clear history: Allows you to clear the navigation history.
Show security warnings: Checkmark to show a warning if there is a
problem with a site’s security.
COOKIES
Accept cookies: Checkmark to allow sites to save and read cookie data.
Clear all cookie data: Allows you to clear all Browser cookie data.
FORM DATA
Remember form data: Checkmark to allow the Browser to remember
data you type in forms for later use.
Clear form data: Allows you to clear all saved form data.
LOCATION
Enable location: Checkmark to allow sites to request access to your location.
Clear location access: Allows you to clear location access for all websites.
PASSWORDS
Remember passwords: Checkmark to allow the Browser to save
usernames and passwords for websites.
Clear passwords: Allows you to clear all saved passwords.
71
72
Web
Accessibility
Force enable zoom: Override a website’s request to control zoom
behavior.
TEXT SIZE
Preview: Allows you to preview the text size.
Text scaling: Adjust the text scaling by scrolling the button.
Zoom on double-tap: Adjust the default zoom percentage when you
double-tap a web page.
Minimum font size: Adjust the minimum font size of web pages by
scrolling the button.
INVERTED SCREEN RENDERING
Preview: Allows you to preview the inverted screen rendering.
Inverted rendering
white and vice versa.
Contrast: Allows you to adjust the contrast level. This option is only
available when the Inverted rending option is selected.
: Checkmark for inverted rendering. Black becomes
Advanced
Set search engine: Tap to set the default search engine.
Open in background: Checkmark to open new tabs behind the current
tab.
Enable javascript: Checkmark to enable javascript.
Enable plug-ins: Allows you to enable plug-ins.
Website settings: Allows you to manage advanced settings for individual
websites.
PAGE CONTENT
Default zoom: Select the default zoom.
Open pages in overview: Checkmark to show overview of newly-opened
pages.
Auto-fit pages: Checkmark to format webpages to fit the screen.
Block pop-ups: Checkmark for block pop-ups.
Text encoding: Tap to set text encoding.
RESET DEFAULTS
Reset to default: Restore defaults settings.
Bandwidth management
Search result preloading: Allow browser to preload high confidence
search results in the background.
Load images: Allows the browser to display images on Web pages.
Labs
Quick controls: Slide finger from left or right edge to open quick controls
and hide URL bar and Toolbar.
Fullscreen: Use fullscreen mode to hide the Status Bar.
Maps
Tap here to access Map, Local,
Offers, Navigation, Join
Latitude, Location history,
Check in, My Places.
Web
73
Tap here to access Directions.
Tap here to access Search.
Tap here to access Local.
Tap here to access Layers.
To search for a location
A pop-up appears upon initial use. Read the information and tap OK to continue.
NOTE
1. From the Home screen, tap the Apps Key > Maps .
2. Tap the search box at the top of the screen.
3. In the search box, enter the place you’re looking for. You can enter an
address, a city, or a type of business or establishment. For example,
"theater in New York".
74
Web
4. Tap a suggestion or tap the Search Key on the keyboard.
Red markers indicate search matches on the map.
You can tap a marker to open a balloon that contains a label. Tap the
balloon to open a screen with more information about the location, as
well as options for obtaining directions.
To get directions
1. From the Home screen, tap the Apps Key > Maps .
2. Tap Directions
.
3. Enter a starting point in the first text box and your destination in the
second text box. You can also select an address from your Favorites,
Contacts list, or Contacts History tab.
When you search for a location in the Maps application, the Directions function
NOTE
automatically enters your location as the starting point and the last red marker you
touched as the destination.
4. Tap the Car icon for driving directions, the Transit icon for transit
directions, the Cycling icon for cycling directions, or the Walking icon
for walking directions.
5. Tap GET DIRECTIONS.
6. Your route is displayed on a map.
Tap a white marker on the map to see direction change indicators.
Tap
to display each direction instruction sequentially in a bubble at
each juncture. You can tap
to step backward through the direction
instructions.
To view the directions in text format, tap DIRECTIONS LIST.
Tap the Back Key
To reverse directions, tap the Menu Key > Reverse Start & End when entering the
NOTE
start and end points.
to return to map view.
Switching between common features
The Maps application has a toolbar at the top of the screen for easy access
to many common features used when searching for the places you want to
go.
Web
Tap the Maps menu icon in the top left corner of the screen to
access Map, Local, Offers, Navigation, Join Latitude, Location history
and My Places.
Tap the Layers icon
at the bottom of the screen to access
Traffic, Satellite, Terrain, Transit Lines, Latitude, My Maps, Bicycling,
Wikipedia, and your search history.
Touch the Local icon
in the Maps toolbar at the bottom of the
screen to search for places near your location or your destination.
Touch the Directions icon
in the Maps toolbar at the bottom of the
screen to get directions.
Touch the Search icon
in the Maps toolbar at the bottom left of the
screen to conduct a new search.
Tap the My Location icon
in the top right corner of the screen to
display your current location on the map.
Checking the Weather
The Weather application provides weather forecasts. You can place a
Weather widget on your Home screen for a summary of your local weather.
Access the Weather application for more detailed weather information.
To get details about the weather
Tap the Weather widget on the Home screen to open the Weather
application to view summarized and detailed weather information.
75
Weather Widget
Weather
Application
76
Web
Swipe right or left to scroll through the weather information for each
of the cities in your list.
Tap the Refresh Icon
in the lower right corner of the Weather
application screen to update the current weather of the city displayed
on the weather application screen.
Tap the Add city icon
Google Location Services must be checkmarked to update the current weather. From
NOTE
the Home screen, tap the Apps Key
location service.
to add another city to your list.
> Settings > Location services > Google's
To update or add city
The City list screen allows you to manage a list of cities that you want to
monitor. Tap Add
screen.
Tap Current location at the top of the screen to update your current
location.
Type in the city, state or ZIP code to search the name.
at the top right corner of the Weather application
Changing Weather Settings
You can configure a number of settings for the Weather application.
The location and related settings also affect the display of the Weather
widget application.
To open the Weather settings screen, tap the Menu Key >
-*454&55*/(4
Edit city list: Manages the list of cities you monitor. Tap Add at the top
of the screen to add a new city to your list. To remove a city, tap and hold
the desired city and tap Delete. To rearrange the order of the cities viewed
when you swipe across the Weather application screen, tap
side of the screen and drag it to where you want it in the list.
Settings
.
on the right
DATA AND SYNCHRONIZATION
Update data: Allows the device to update data automatically when the
widget is set on the Home screen.
Web
Refresh interval: Allows you to set how often to update (Every 1 hour,
Every 3 hours, Every 6 hours, Every 12 hours, Daily) the weather. More
frequent updates trade the convenience of current information for increased
data use and decreased battery life between charges.
(&/&3"-4&55*/(4
Temperature unit: Allows you to set it to display degrees in Fahrenheit or
Celsius.
Wind speed unit: Allows you to set the wind speed unit to m/s or MPH.
Backup Assistant Plus
How to access and register Contacts backup settings from Backup
Assistant Plus
If you didn’t set up Backup Assistant Plus when you turned on your phone
for the first time, you can enable it in the Settings application.
1. From the Home screen, tap the Apps Key
Assistant Plus
2. Read the information provided on the screen and tap Start.
3. The Registration complete screen appears and your first back-up process
begins. Tap Done .
.
Backup Assistant Plus can be accessed directly from the Contacts
application
1. Open the Contacts application.
2. Tap the Menu Key
If you’ve already registered your Backup Assistant Plus account, a
background backup will be performed. If not, the Backup Assistant Plus
registration screen will be displayed for you to complete registration then
back up your files.
> Backup now.
> Settings > Backup
77
78
Web
Using Backup Assistant Plus
Using Backup Assistant Plus On the schedule you selected, the Backup
Assistant Plus application checks the phone’s address book to see if any
changes have occurred since the last backup. If changes are detected, the
application will launch and the backup. process will start. If no changes
are detected, Backup Assistant Plus sleeps until the next daily automatic
backup is triggered.
Manually backing up your contacts
1. From the Home screen, tap the Apps Key > Settings > Backup
Assistant Plus
2. Tap Backup now to begin the backup process.
Changing the backup schedule
1. From the Home screen, tap the Apps Key > Settings > Backup
Assistant Plus
2. Tap Daily backup schedule then tap the timeframe you want. For
example, Every late night (12am-6am).
.
Daily backup schedule screenSettings screen
.
Communication
Contacts
The Contacts application allows you to store names, phone numbers and
other information in your phone’s memory.
Using Your Contacts
Use the Contacts application to add, view, and communicate with your
friends and acquaintances.
To open your Contacts application
From the Home screen, tap the Apps Key >
OR
Tap the Contacts Key in the Quick Keys bar.
All of your contacts are displayed alphabetically in a list. If you have a
new phone and haven’t added any contacts yet, the Contacts application
will display hints on how to start adding contacts to your phone.
To open a list of your favorite contacts
Open your Contacts application and tap the Favorites tab at the
top of the screen.
Favorites lists the contacts you’ve added to the list, followed by a list
of your most frequently called contacts.
Contacts
.
79
Communication
80
To view details about a contact
1. Open your Contacts application.
2. Tap the contact whose details you want to view.
3. The Contact Info tab displays by default. Tap an icon to call, message, or
open other applications.
The Dial icon
The Message icon
The Mail icon
The Chat icon
Tap the Menu Key for the following menu options: Delete, Share,
Join, Export, Add to home screen, and All calls to voicemail. Tap to
edit the contact.
places a call to the number.
starts a message.
starts an email.
starts a chat.
Adding Contacts
You can add contacts on your phone and synchronize them with the
contacts in your Google™ Account, Microsoft Exchange account, or other
accounts that support syncing contacts.
Since your contacts can come from a variety of sources, the Contacts
application attempts to join new information with existing similar contact
entries, to create a single entry. You can also manage that process manually
by joining or splitting entries.
To add a new contact
1.
Open the Contacts application.
Communication
2. Tap the New contact icon to the right of the Search box to start a
new contact entry.
3. If you have more than one account with contacts, tap Contact type at
the top of the screen and choose the account to which you want to add
the contact.
4. Enter the contact’s name.
5. Tap a category of contact information, such as phone number or email
address, to enter that kind of information about your contact.
6. Tap a category’s plus icon
category. For example, in the phone number category, enter a work
number and add a home number. Tap the label button to the left of the
entered information to open a dialog box of preset labels. For example,
Work or Home for a phone number.
7. Tap the Picture frame icon
name in your list of contacts and in other applications.
8. When you’re finished, tap Save.
to add more than one entry for that
to select a picture to display next to the
Importing, &YQPSUJOHand Sharing Contacts
If you have contacts stored in vCard format on a microSD card you can
import them into your Contacts application on your phone. You can also
export contacts in vCard format onto a microSD card. Exporting your
contacts to a microSD card allows you to back them up to a computer or
other device. It also allows you to send the contact via email.
To import contacts from your microSD card
You can copy contacts, in vCard format, onto your microSD card then
import them into your phone.
1. Insert the microSD card (that contains the vCard files) into your phone.
2. Open the Contacts application.
3. Tap the Menu Key
4. Tap Import from SD card.
5. If you have more than one account on your phone, tap the account into
which you want to import the contacts.
> Import/Export.
81
Communication
82
6. Tap the contacts you want to import from the microSD card. Then tap
Import to confirm.
To export contacts to your microSD card
You can export all of the contacts on your phone to your microSD card, as
vCard files. You can then copy this file to a computer or another device that
is compatible with this format, such as an address book application.
1. Open the Contacts application.
2. Tap the Menu Key
3. Tap Export to SD card.
4. Tap the contacts you want to export to the microSD card. To export all
of the contacts, tap the Select all checkbox in the top left corner of the
screen.
5. Then tap Export and OK.
> Import/Export.
To share a contact
You can share a contact with someone by sending it to them as a vCard file.
1. Open the Contacts application.
2. Tap the contact you want to share to view its details.
3. Tap the Menu Key
4. Choose the method for sending.
5. Enter the necessary information and share it.
> Share.
Adding a Contact to Your Favorites
The Favorites tab contains a short list of the contacts you communicate
with most often, including your list of Favorites.
To add a contact to your Favorites list
1. Open the Contacts application.
2. Tap a contact to view its details.
3. Tap the star to the right of the contact’s name.
When the contact is added to your Favorites list, the star will be yellowcolored.
Communication
To remove a contact from your Favorites list
1. Open the Contacts application.
2. Tap the contact to view its details.
If you have a long list of contacts, it may be faster to tap the Favorites tab then tap
TIP
the contact entry to view its details.
3. Tap the yellow star to the right of the contact’s name.
The grey-colored star indicates that the contact was removed from your
Favorites list.
Searching for a Contact
It’s easy to search for a contact by name.
To search for a contact
1. Open the Contacts application.
2. Tap the search box or tap the Search Key
3. Start entering the name of the contact you’re searching for. As you type,
contacts with matching names will appear below the search box.
4. Tap a matching contact in the list to view its details.
You can also search by nickname, email, organization and number.
The pinch-to-zoom gesture can be used in your Contacts list. Pinch in to compress the
NOTE
entries into horizontal alphabetical bars, then simply tap the bar with the desired letter to
open the entries that begin with that letter.
.
83
Communication
84
&EJUJOH$POUBDU%FUBJMT
You can change or add details saved in your contact entries. You can also
set specific ringtones to specific contacts.
Some contact entries contain information from multiple sources:
information that you added manually, information that Contacts joined from
multiple accounts to consolidate duplicates, etc.
If you find duplicate entries in Contacts, you can join them into a single entry.
Changes made to information from one source do not automatically change
the information on the other sources. For example, if you have information
about a contact from a Google Account and an Exchange account and both
are configured to sync contacts, changes to the contact from the Google
Account are synced to that account on the web, but the information from
the Exchange account will remain unchanged.
To edit contact details
1. Open the Contacts application.
2. Tap and hold the contact whose details you want to edit. In the Context
menu that opens, tap Edit contact.
3. Edit the contact information.
4. Tap Save to save the changes.
To change a contact’s default phone number
The default phone number is used when you initiate a call or send a text
message using the Context menu that opens when you tap and hold the
contact’s entry.
1. Open the Contacts application.
2. Tap the name of a contact in the list to view its details.
3. Tap and hold the phone number to use as the contact’s default phone
number.
4. Tap Set as default number in the dialog box that opens.
The default phone number is indicated by a checkmark.
Communication
To delete a contact
1. Open your Contacts list or Favorites list.
2. Tap the name of a contact in the list to view its details.
3. Tap the Menu Key
> Delete.
If you delete a contact from Google Contacts (or another account with
editable contacts), the contact is also deleted from Contacts on the
web the next time you sync your phone.
If the contact contains information from both editable accounts (such
as Contacts) and from a read-only account, a dialog box informs you
that the information from the read-only account will be hidden, not
deleted.
4. Tap OK to confirm that you want to delete the contact.
Communicating with Your Contacts
From the Groups, Contacts, or Favorites tab, you can quickly call or send
a text (SMS) or multimedia (MMS) message to a contact’s default phone
number. You can also open a list of all of the ways you can communicate
with that contact.
This section describes ways to initiate communication when viewing your
list of contacts. The Contacts application shares your contacts with many
other applications, such as Gmail™ and Messaging.
To connect using Quick Contact for Android™
1. Tap a contact’s picture to open Quick Contact for Android.
The entry's Quick
Contact options are
displayed after tapping
the contact's picture.
Tap a contact's picture.
85
Communication
86
2. Tap the icon corresponding to the type of communication you want to
start.
The communication icons displayed in Quick Contact depend on the
types of information you saved in the contact information.
To communicate with a contact
1. Open the Contacts application.
2. Tap the contact with whom you want to communicate.
3. In the contact’s details screen, tap the way to start communicating with
the contact.
The Dial icon
The Message icon
The Mail icon
The Chat icon
Anytime you see the Dial icon next to a number, such as in your Favorites or Call log,
NOTE
just tap it to call that number.
places a call to the number.
starts a message.
starts an email.
starts a chat.
To forward a Contact’s info
1. Open the Contacts application.
2. Tap and hold the contact you want to message.
3. Tap Forward contact in the Context menu that opens.
To change which Contacts are displayed
1. Open the Contacts application.
2. Tap the Menu Key
3. Tap an account to display its list of available groups.
4. Touch All contacts to display contacts from all of your synchronized
accounts, touch a single account, or touch Customize to select more
than one (but not all) account types to display their contacts.
> Display options.
Communication
Joining Contacts
When you add an account or add contacts in other ways, such as by
exchanging emails, the Contacts application attempts to avoid duplication by
joining contact information automatically. You can also join contacts manually.
To join contacts
1. Open the Contacts application.
2. Tap the contact entry to which you want to add information. The contact
name for this entry will remain unchanged after you join it with another
contact.
3. Tap the Menu Key
4. Tap the contact whose information you want to join with the first contact.
The information from the two contacts will be merged and displayed
under the name from the first contact.
5. The contact information will be displayed in one contact entry.
> Join.
Separating Contact Information
Each contact entry on your phone may contain ‘joined’ information from a
variety of sources.
If contact information from different sources was joined in error, you can
separate the information back into individual contact entries on your phone.
To separate contact information
1. Open the Contacts application.
2. Tap the contact entry whose information you want to separate.
3. Tap the Menu Key
4. Tap OK to confirm you want to separate the entries. The contact
information will separated into individual contact entries in the Contacts
list.
> Separate.
87
Communication
88
&NBJM
&NBJMJDPOT
New Exchange mail
message received or sending
succeeded
AOL mail message received
or sending succeeded
Yahoo! mail message received
or sending succeeded
Gmail message received or
sending succeeded
Hotmail received or sending
succeeded
Verizon.net mail received or
sending succeeded
Other mail received or sending
succeeded
Exchange mail message
sending or receiving failed
AOL mail message sending or
receiving failed
Yahoo! mail message sending
or receiving failed
Gmail message sending or
receiving failed
Hotmail message sending or
receiving failed
Verizon.net mail message
sending or receiving failed
Other mail message sending
or receiving failed
0QFOJOH&NBJMBOEUIF"DDPVOUT4DSFFO
You can use the Email application to read email from services other than
Gmail™. The Email application supports the following account types:
Microsoft Exchange, Windows Live Hotmail, Yahoo! Mail, AOL Mail,
Verizon and other accounts.
To open the Email application
From the Home screen, tap the Apps Key > Email or tap the
Email icon
Tap
Tap
The first time you open the Email application, a setup wizard opens to
help you add an email account. After the initial setup, the Email application
displays the contents of your Inbox.
directly from Home screen.
on the action bar to compose the new message.
to add favorite messages from the inbox.
Communication
The Accounts screen
The Accounts screen lists all of your accounts.
Open the Email application. If you’re not on the Accounts screen, tap
the Menu Key
> Accounts.
Each account on the Accounts screen displays the number of unread
mail.
You can tap an account to view its Inbox.
The account from which you send email by default is indicated with a
checkmark.
Reading Your mail
You can read mail from the Inbox, or from other folders within each
individual account.
To read a mail
From the Accounts screen, simply tap any account to display that account’s
folders and contents.
You can also go to the folder list of the account by tapping the Menu Key
> Folders from the Inbox.
When new email arrives, a notification appears in the Status Bar. Drag the Notifications
NOTE
panel downward and tap the email notification.
Email settings
To access the Email account settings, tap the Menu Key > Settings
from the Accounts screen.
89
ACCOUNTS
Tap an account to access settings specific to that email account.
(&/&3"-4&55*/(4
Tap Set default account to open a dialog box to select which email
account to designate as your default account.
Communication
90
Tap Roaming to checkmark this setting to automatically retrieve email
while roaming outside your home network. Data fee will be charged.
/05*'*$"5*0/4&55*/(4
Tap Notifications to set whether you want to be notified of new email
notifications.
Tap Notification sound to open a dialog box to set the sound when
you receive a new email notification.
Tap Vibrate to open a dialog box to set a vibration when you receive a
new email notification.
"114&55*/(4
Tap Screen after deleting to choose which screen to show after you
delete email
Tap Ask before deleting to checkmark this setting if you want to be
asked before deleting mail.
Tap Show image to open a dialog box to set when to show images.
Tap Storage to select the depository for attachment files.
Tap Conversational view to checkmark this setting if you want your
email Inbox to display your email messages by conversation threads.
Tap Email preview to open a dialog box to set how many lines of
email text to download for previewing on your device.
Tap Brightness to set the Email app brightness level.
.*$3040'5&9$)"/(&4&55*/(4
Touch Corporate directory to checkmark this setting to search the
online directory for the entered recipient.
Communication
(NBJM
0QFOJOH(NBJMBOE:PVS*OCPY
When you open the Gmail application, the most recent conversations are
displayed in your Inbox.
To open the Gmail application
From the Home screen, tap the Apps Key > Gmail .
All of your conversations are displayed in your Inbox unless you delete,
archive, or filter them.
The current Google Account is displayed at the top right of the Inbox. If
you have more than one account, you can switch accounts to view the
messages in each Inbox.
Conversations with new messages are displayed with bold subject lines.
To read a message in a conversation, tap its subject line text.
indicates that you were CC’d on this message.
indicates that this message was sent directly to you.
To open your Inbox when Gmail is running
If you are viewing a message or another label, tap the Back Key until
you return to your Inbox.
OR
While reading a message or viewing another label, tap
corner of the screen.
at the top left
91
To switch accounts
Gmail displays conversations and messages from one Google Account at
a time. If you have more than one account, you can open the Accounts
screen to view how many unread messages you have in each account and
to switch accounts.
1. From your Gmail Inbox, tap
at the top of the screen.
Communication
92
Tap here to switch accounts
and labels.
2. Tap the account that contains the email you want to read.
Reading Your Messages
While viewing a list of conversations in your Inbox or in any list of labeled
conversations, you can open a conversation to read its messages.
To read a message
Tap a conversation that contains the message you want to read.
The conversation opens to the first new (unread) message, or to the
first starred message, if you’ve previously starred a message in the
conversation.
Tap here to Reply all or
Forward.
Communication
The Google Talk online status will appear next to the name of the
sender of each message if the sender has a Google Account. Tap the
contact’s picture to open Quick Contact.
While reading messages in a conversation, you can use the keys
at the bottom of the screen to archive the entire conversation
delete it
conversation, you can tap Undo in the bar that appears at the bottom
of the screen to undo the last action and restore the message to its
previous location.
You can also swipe the screen to the left or the right to read the next
or prior message.
While viewing a message, touch the message action icons on the
message header to access options which include
important,
reply to all address and Forward to forward the message to someone
else.
, add a label , or set it as unread . After you delete a
to mark it as
to reply to the sender, and to access Reply all to
,
To reread a message
When you open a conversation, messages that you’ve already read are
minimized into a tab that indicates the number of hidden messages.
1. From the Home screen, tap the Apps Key
conversation you want to view.
2. Tap the contact name to open that message.
While reading a message you can tap
unread state. For example, to remind yourself to read it again later.
> Gmail . Then tap the
to return a read message to the
93
Communication
94
Composing and Sending a Message
You can compose and send a message to people or groups with Gmail
addresses or other email addresses.
To compose and send a message
1.
From the Home screen, tap the Apps Key
.
2. Enter a recipient’s address.
As you enter text, matching addresses are offered from your Contacts
list. You can tap a suggested address or continue entering text to enter a
new one.
3. Tap the Menu Key
recipients, if necessary.
4. Enter a subject for the message in the Subject field.
5. Continue into the next field to enter your email message.
6. Tap the Menu Key
attachment to the email.
7. Tap Send
If you’re not ready to send the message, tap the Menu Key
Save draft to save the message as a Draft. You can read your drafts by
opening messages with the Draft label.
To erase the message, tap the Menu Key
saved drafts).
If you aren’t connected to a network, for example, if you’re working in
Airplane mode, the messages that you send are stored on your phone
with the Outbox label until you connect to a network again.
at the top of the screen to send your message.
> Add Cc/Bcc to copy (normal or blind copy)
> Attachpicture or Attachvideo to add an
>
Gmail
> Compose
> Discard (including any
>
Communication
Replying to or Forwarding a Message
You can continue an email conversation by replying to a message or by
forwarding it.
To reply to or forward a message
1. Tap the message actions icon on the message header to access action
options for the message.
2. Tap
to reply or and choose Reply all or Forward.
Replying to or forwarding messages without changing the subject adds
your reply to the current conversation.
Changing the subject starts a new conversation.
The message will open in a new screen where you can add or remove
addresses, edit the subject, and add or remove text or attachments.
You can add one or more people to an ongoing conversation by replying
to all and then adding the new person’s address(es) to the reply.
Note that the conversation text and previous messages are also included
in your reply (or forward).
3. Tap Send
at the top of the screen to send your message.
95
Communication
96
Messaging
To open Messaging
Tap the Home Key , then tap the Messaging Key in the Quick
Keys bar.
The Messaging screen will open, where you can create a new
message or open an ongoing message thread.
Tap here to create a new message.
Tap New message to start a new text or multimedia message.
Tap an existing message thread to open it.
Tap
When a New Message notification pops up, choose to reply quickly without accessing
To delete a message thread from the Messaging window
1. Tap and hold the message thread.
2. Tap Delete thread in the Context menu that opens.
3. Tap Delete to confirm you want to delete the message thread.
to make a call in the message screen.
TIP QUICK REPLY
the Messaging application by tapping the T
text message, or tap Call
to dial the contact or Delete to delete the message.
ext field in the notification to respond with a
Communication
&YDIBOHJOH.FTTBHFT
You can send text messages (SMS) of up to 160 characters to another
mobile phone. If you type more than the allotted text amount (up to 7 pages
of 153 characters), the message is delivered as a series of messages (EMS).
If you keep typing after the limit, your message is delivered as multimedia
messages (MMS).
Multimedia messages (MMS) can contain text and a picture, location, a
recorded voice, an audio file, a video, or a picture slideshow.
The Messaging application automatically converts a message into a
multimedia message if you add a subject or attach a media file.
To send a text message
1. On the Messaging screen, tap New message .
2. Enter a mobile phone number in the To field.
As you enter the mobile phone number, matching contacts appear. You
can tap a suggested recipient or continue entering the phone number.
3. Tap the text field to start entering your message.
Tap here to enter numbers from your call logs,
contacts, groups, or favorites.
The character counter displays the number of
characters entered and amount remaining.
Tap here to attach the files.
97
Communication
98
A counter is displayed in the top right corner of the text field to tell you
how many characters are left and the number of pages.
If you tap the Back Key
as a draft in your Messaging application. Tap the message to resume
composing it.
4. Tap Send to send the message.
Your message is displayed and responses appear in the same window,
creating a message thread with that contact.
while composing a message, it’s saved
To create and send a multimedia message
1. On the Messaging screen, tap New message .
2. Enter a mobile phone number or email address in the To field. As you
type, matching contacts appear. You can tap a suggested contact or
continue typing.
3. Tap the text field to start entering your message.
4. Tap the Menu Key
5. Tap the Attachment icon
the type of media file to attach to the message.
Tap Picture to select a picture from your Gallery.
Tap Capture picture to take a picture and attach it.
Tap Video to select a video from your Gallery.
Tap Capture video to record a video and attach it.
Tap Audio to select an audio file from your microSD card.
Tap Record voice to record an audio message and attach it.
Tap Location to attach My current location, Places of Interests,
Enter address, Contact and From geotagged media.
Tap Slideshow to assemble photos, audios, videos, texts into a
slideshow (up to 10 slides) to attach to the message. Use the buttons
in the slideshow screen to preview the message, replace or add a
picture, or remove a slide. Tap Done when you finish editing the
slideshow.
> Add subject to add a message subject.
to open a dialog box where you can choose
Loading...
+ hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
