LG MU-60PZ10B User Manual
TM
TM
MU-60PZ10B
•Screen Size: 60" (16:9)
•Thickness: 3.9"
•Resolution: 1280 x 720
•Brightness: 200cd/m
2
•Picture in Picture Function
•Viewing Angle Over 160˚
www.LGeus.com
34.8"
3.9"
57.3"
34.8"
MU-60PZ10B
TM
Screen Type/Size Plasma/60” Diagonal
Video Aspect Ratio 16:9
Native Display
Resolution 1280 x 720 (HD/XGA)
Cell Pitch
Displayable Colors 16.77 million
Peak Brightness 200cd/m
Contrast Ratio 250:1 (w/o filter: 500:1)
Viewing Angle Over 160
Input Freq. Range For PC: Autoscanning
Max Input Resolution For PC: 1280x1024@75Hz
HD/DVD/DTV Support 480i/480p/720p/1080i
Input Terminals
PC and RGB DTV / Audio D-Sub 15 (VGA type) / RCA phono jacks
Video/Audio NTSC composite (RCA phono jacks)
S-Video Mini DIN 4-pin
60
Component/DVD/DTV RCA jacks Y, Pb/Cb, Pr/Cr
Output Terminals Speaker: 10W+10W (8 ohms)
Power Requirements AC120V, 60Hz
Power Consumption 650W (Max. Audio: 700W)
Monitor Controls Power (Main and Stand-by)
Remote Control Functions Power, Input Select, APC, DASP, ARC, Still, PIP, Twin Picture,
On Screen Controls Picture (APC, Digital Reality Picture, Contrast, Brightness, Tint,
Dimensions
Shipping Dimensions
Weight 158.4 lbs.(72KG) set only
Shipping Weight 180.4 lbs. (82KG)
Operating Temperature 32
Operating Humidity 30%~80%
EMI Regulations FCC Class B for EMC
Safety Regulations C-UL
Accessories Remote Control, D-Sub 15 pin PC VGA cable, Power Cord, User's Manual
Other Features 3D motion adaptive scan converter minimizes jaggies on angled lines
Mounting Options Desktop Stand, Floor Stand, Wall Mount, Ceiling Mount
UPC#: 719192164727
(H x V) 0.343 x 1.032 mm
2
(w/o filter: 400cd/m2)
0
Hf: 31.5~80KHz Vf: 56~120Hz
Input Select, Volume +/-
PIP Input, Position, Menu, Mute, Sleep, Vol+/-, Select +/-, OK(enter)
Color, Sharpness), OSD Transparency Sound (Digital Auto Sound DASP,
Auto Volume Level, Treble, Bass, Balance), ARC (Picture format
of 16:9, 4:3 or Zoom), Screen (PC adjustments for Auto config,
V-position, H-position, phase, reset), Language (English, French,
Spanish, Portugese), PIP (small, large, input, position), Twin Picture
on/off, Input (RGB(PC)/Video/Component)
(W x H x D) 57.3 x 34.8 x 3.9 inches, (1455 x 883 x 99 mm) set only
(W x H x D) 66.2 x 44 x 23.4 inches, (1681 x 1118 x 594 mm)
0
F~1040F (00C~400C)
Film mode for proper handling of 3:2 pulldown material
ISM feature to minimize image burn
Picture in Picture function
Twin Picture (side by side)
Still function (freeze current image)
”
LG ELECTRONICS U.S.A., INC.
HEADQUARTERS
1000 Sylvan Avenue, Englewood Cliffs, NJ 07632 ◗ Tel: (201) 816-2000, Fax: (201) 816-0636 ◗ www.LGeus.com
© 2001 LG Electronics U.S.A., Inc. All trademarks are the property of their respective owners. Design and specifications subject to change without notice.
The Energy Star emblem does not represent EPA endorsement of any product of service. Printed in USA, 08/01
