LG Lucid 4G User Guide

This booklet is printed with soy ink. Printed in Mexico

This booklet is made from 60% post-consumer recycled paper.

USER GUIDE

P/N: MFL67378201 (1.0) G

P/N: MFL67202801(1.0) H

USUARIO GUÍA DEL

Copyright©2012 LG Electronics, Inc. All rights reserved. LG and the LG logo are registered trademarks of LG Group and its related entities. Lucid is a trademark of LG Electronics, Inc. All other trademarks are the property of their respective owners.

Important Customer Information

When using this product, the safety precautions below must be taken to avoid possible legal liabilities and damages.

Retain and follow all product safety and operating instructions. Observe all warnings in the product operating instructions. To reduce the risk of bodily injury, electric shock, ﬁre, and damage to the equipment, observe the following precautions.

ELECTRICAL SAFETY

This product is intended for use when supplied with power from the designated battery or power supply unit. Other usage may be dangerous and will invalidate any approval given to this product.

SAFETY PRECAUTIONS FOR PROPER GROUNDING INSTALLATION

CAUTION: Connecting to improperly grounded equipment can result in an electric shock to your device. This product is equipped with a USB cable for connecting to a desktop or notebook computer. Be sure your computer is properly grounded (earthed) before connecting this product to the computer. The power supply cord of a desktop or notebook computer has an equipment-grounding conductor and a grounding plug. The plug must be plugged into an appropriate outlet which is properly installed and grounded in accordance with all local codes and ordinances.

SAFETY PRECAUTIONS FOR POWER SUPPLY UNIT

Use the correct external power source

A product should be operated only from the type of power source indicated on the electrical ratings label. If you are not sure of the type of power source required, consult your authorized service provider or local power company. For a product that operates from battery power or other sources, refer to the operating instructions that are included with the product.

Important Customer Information

Handle battery packs carefully

This product contains a Li-ion battery. There is a risk of ﬁre and burns if the battery pack is handled improperly. Do not attempt to open or service the battery pack. Do not disassemble, crush, puncture, short external contacts or circuits, dispose of in ﬁre or water, or expose a battery pack to temperatures higher than 60°C (140°F).

WARNING: Danger of explosion if battery is incorrectly replaced. To reduce risk of ﬁre or burns, do not disassemble, crush, puncture, short external contacts, expose to temperature above 60°C (140°F), or dispose of in ﬁre or water. Replace only with speciﬁed batteries. Recycle or dispose of used batteries according to the local regulations or reference guide supplied with your product.

Take extra precautions

Keep the battery or device dry and away from water or any liquid as it

may cause a short circuit.

Keep metal objects away so they don’t come in contact with the battery or its connectors as it may lead to short circuit during operation.

The phone should be only connected to products that bear the USB-IF

logo or have completed the USB-IF compliance program.

Do not use a battery that appears damaged, deformed, or discolored, or

one that has any rust on its casing, overheats, or emits a foul odor.

Always keep the battery out of the reach of babies and small children,

to avoid swallowing of the battery. Consult a doctor immediately if the battery is swallowed.

Only use the battery with a charging system that has been qualiﬁed with

the system per this standard, IEEE-Std-1725-200x. Use of an unqualiﬁed battery or charger may present a risk of ﬁre, explosion, leakage or other hazard.

Replace the battery only with another battery that has been qualiﬁed with

the system per this standard, IEEE-Std-1725-200x. Use of an unqualiﬁed battery may present a risk of ﬁre, explosion, leakage or other hazard.

Important Customer Information

Avoid dropping the phone or battery. If the phone or battery is dropped,

especially on a hard surface, and the user suspects damage, take it to a service center for inspection.

If the battery leaks:

Do not allow the leaking ﬂuid to come in contact with skin or clothing. If

contact occurs, ﬂush the affected area immediately with clean water and seek medical advice.

Do not allow the leaking ﬂuid to come in contact with eyes. If contact

occurs, DO NOT rub; rinse with clean water immediately and seek medical advice.

Take extra precautions to keep a leaking battery away from ﬁre as there

is a danger of ignition or explosion.

SAFETY PRECAUTIONS FOR DIRECT SUNLIGHT

Keep this product away from excessive moisture and extreme temperatures. Do not leave the product or its battery inside a vehicle or in places where the temperature may exceed 140°F (60°C), such as on a car dashboard, window sill, or behind glass that is exposed to direct sunlight or strong ultraviolet light for extended periods of time. This may damage the product, overheat the battery, or pose a risk to the vehicle.

PREVENTION OF HEARING LOSS

CAUTION: Permanent hearing loss may occur if earphones or headphones are used at high volume for prolonged periods of time.

SAFETY IN AIRCRAFT

Due to the possible interference caused by this product to an aircraft’s navigation system and its communications network, using this device’s phone function on board an airplane is against the law in most countries. If you want to use this device when its use is restricted on board an aircraft, remember to switch to Airplane Mode which turns off RF functions that could cause interference.

Important Customer Information

ENVIRONMENT RESTRICTIONS

Do not use this product in gas stations, fuel depots, chemical plants or where blasting operations are in progress, or in potentially explosive atmospheres such as fueling areas, fuel storehouses, below deck on boats, chemical plants, fuel or chemical transfer or storage facilities, and areas where the air contains chemicals or particles, such as grain, dust, or metal powders. Please be aware that sparks in such areas could cause an explosion or ﬁre resulting in bodily injury or even death.

EXPLOSIVE ATMOSPHERES

When in any area with a potentially explosive atmosphere or where ﬂammable materials exist, the product should be turned off and the user should obey all signs and instructions. Sparks in such areas could cause an explosion or ﬁre resulting in bodily injury or even death. Users are advised not to use the equipment at refueling points such as service or gas stations, and are reminded of the need to observe restrictions on the use of radio equipment in fuel depots, chemical plants, or where blasting operations are in progress. Areas with a potentially explosive atmosphere are often, but not always, clearly marked. These include fueling areas, below deck on boats, fuel or chemical transfer or storage facilities, and areas where the air contains chemicals or particles, such as grain, dust, or metal powders.

ROAD SAFETY

Vehicle drivers in motion are not permitted to use communication services with handheld devices, except in the case of emergency. In some countries, using hands-free devices as an alternative is allowed.

Important Customer Information

SAFETY PRECAUTIONS FOR RF EXPOSURE

Avoid using your phone near metal structures (for example, the steel

frame of a building).

Avoid using your phone near strong electromagnetic sources, such as

microwave ovens, sound speakers, TV and radio.

Use only original manufacturer-approved accessories, or accessories that

do not contain any metal.

Use of non-original manufacturer-approved accessories may violate your

local RF exposure guidelines and should be avoided.

INTERFERENCE WITH MEDICAL EQUIPMENT FUNCTIONS

This product may cause medical equipment to malfunction. The use of this device is prohibited in most hospitals and medical clinics.

If you use any personal medical device(s), consult the manufacturer of your device(s) to determine if the device(s) are adequately shielded from external RF energy. Your physician may be able to assist you in obtaining this information. Turn your phone OFF in health care facilities when any regulations posted in these areas instruct you to do so. Hospitals or health care facilities may be using equipment that could be sensitive to external RF energy.

HEARING AIDS

Some digital wireless phones may interfere with some hearing aids. In the event of such interference, you may want to consult your service provider, or call the customer service line to discuss alternatives.

Important Customer Information

NON-IONIZING RADIATION

Your device has an internal antenna. This product should be operated in its normal-use position to ensure the radiative performance and safety from interference. As with other mobile radio transmitting equipment, users are advised that for satisfactory operation of the equipment and for personal safety, it is recommended that no part of the human body be allowed to come too close to the antenna during operation of the equipment. only the supplied internal antenna. Use of unauthorized or modiﬁed antennas may impair call quality and damage the phone, causing loss of performance and SAR levels exceeding the recommended limits as well as result in noncompliance with local regulatory requirements in your country. optimal phone performance and ensure human exposure to RF energy is within the guidelines set forth in the relevant standards, always use your device only in its normal-use position. Contact with the antenna area may impair call quality and cause your device to operate at a higher power level than needed. Avoiding contact with the antenna area when the phone is IN USE optimizes the antenna performance and the battery life.

To assure

HAC

This phone has been tested and rated for use with hearing aids for some of the wireless technologies that it uses. However, there may be some newer wireless technologies used in this phone that have not been tested yet for use with hearing aids. It is important to try the different features of this phone thoroughly and in different locations, using your hearing aid or cochlear implant, to determine if you hear any interfering noise. Consult your service provider or the manufacturer of this phone for information on hearing aid compatibility. If you have questions about return or exchange policies, consult your service provider or phone retailer.

Use

Table of Contents

Important Customer Information...........................................................1

Table of Contents ................................................................................... 7

Technical Details ................................................................................... 10

The Basics ............................................................................................. 15

Phone Overview ..................................................................................................................15

Installing the Battery and microSD Card .........................................................................18

Charging the Phone ...........................................................................................................21

Optimizing Battery Life .....................................................................................................22

Turning the Phone On and Off ........................................................................................23

Guided Tours.......................................................................................................................27

SmartShare ........................................................................................................................27

Phone’s Status Icons .........................................................................................................28

Getting to Know the Home Screen ................................................................................. 30

Mini canvas view ................................................................................................................31

Touchscreen........................................................................................................................32

Applications: How to View, Open and Switch .................................................................35

Working With Menus ........................................................................................................ 40

Managing Notiﬁcations ......................................................................................................41

Searching Your Phone and the Web ................................................................................43

Locking the Screen ............................................................................................................44

Customizing the Home Screen ........................................................................................ 47

Connecting Quickly With Your Contacts ........................................................................ 50

Connecting to Networks and Devices ................................................ 51

Connecting to Wi-Fi Networks ..........................................................................................51

Make Your Device a Mobile Hotspot ................................................................................ 57

microSD Card .......................................................................................59

Calls ........................................................................................................61

Placing and Ending Calls ...................................................................................................61

Answering or Rejecting Calls ............................................................................................64

Working with the Call Log .................................................................................................66

Calling Your Contacts ........................................................................................................68

Voice Dialer .........................................................................................................................69

Table of Contents

Options During a Call ........................................................................................................ 69

Managing Multiple Calls ...................................................................................................70

Listening to Your Voicemail ............................................................................................... 72

Web ........................................................................................................73

Browser ...............................................................................................................................73

Maps ....................................................................................................................................79

Checking the Weather ........................................................................................................81

Changing Weather Settings ..............................................................................................82

Backup Assistant Plus .......................................................................................................83

Communication ....................................................................................87

Contacts ..............................................................................................................................87

Email ...................................................................................................................................97

Voicemail ..........................................................................................................................100

Gmail ..................................................................................................................................101

Talk ..................................................................................................................................... 115

The Phone Application .................................................................................................... 123

Voice Dialer .......................................................................................................................125

Camera ............................................................................................................................. 126

Video Camera...................................................................................................................130

Gallery ............................................................................................................................... 132

Video Producer ................................................................................................................ 142

Market ............................................................................................................................... 144

Music .................................................................................................................................148

SmartShare ...................................................................................................................... 155

Video Player ..................................................................................................................... 157

......................................................................................................................... 158

YouTube

Voice Recorder ................................................................................................................. 160

Tools ..................................................................................................... 162

Calendar ........................................................................................................................... 162

Calculator ......................................................................................................................... 170

Alarm/Clock ...................................................................................................................... 171

Polaris Ofﬁce.................................................................................................................... 173

ShareGenie ........................................................................................................................174

Settings ............................................................................................... 176

Table of Contents

Safety ...................................................................................................193

TIA Safety Information.................................................................................................... 193

Safety Information ........................................................................................................... 197

Caution: Avoid potential hearing loss. ..........................................................................200

FDA Consumer Update .................................................................................................. 203

10 Driver Safety Tips .......................................................................................................210

Consumer Information on SAR ...................................................................................... 212

FCC Hearing-Aid Compatibility (HAC) Regulations for Wireless Devices ................214

Speciﬁcations ..................................................................................... 216

FAQ ...................................................................................................... 217

LIMITED WARRANTY STATEMENT ............................................... 224

Index ................................................................................................... 227

Technical Details

CDMA

Standard

Basic Air Interface

Designator Description

TIA/EIA-95A

TSB-74

ANSI J-STD-008

TIA/EIA-IS2000

CDMA Dual-Mode Air Interface

14.4kbps Radio Link Protocol and Inter-band Operations

IS-95 Adapted for PCS Frequency Band CDMA2000 1xRTT Air Interface

Network

Service

1x EV-DO

Interface

TIA/EIA/IS-634

TIA/EIA/IS-651

TIA/EIA/IS-41-C

TIA/EIA/IS-124

TIA/EIA/IS-96-B

TIA/EIA/IS-637

TIA/EIA/IS-657

IS-801

TIA/EIA/IS-707-A

TIA/EIA/IS-856

TIA/EIA/IS-878

TIA/EIA/IS-866

TIA/EIA/IS-890

MAS-BS

PCSC-RS

Intersystem Operations

Non-Signaling Data Communications

Speech CODEC

Short Message Service

Packet Data

Position Determination Service (gpsOne)

High Speed Packet Data

CDMA2000 High Rate Packet Data Air Interface

1x EV-DO Inter-Operability Speciﬁcation for HRPD Access Network Interfaces

Recommended Minimum Performance Standards for HRPD High Rate Packet Data Access Terminal

Test Application Speciﬁcation (TAS) for High Rate Packet Data Air Interface

LTE Standard Designator Description

Evolved Universal Terrestrial Radio Access (E-UTRA);

User Equipment (UE) radio transmission and reception

Evolved Universal Terrestrial Radio Access (E-UTRA);

Basic

Air Interface

TS 36.101

TS 36.104

Base Station (BS) radio transmission and reception

Evolved Universal Terrestrial Radio Access (E-UTRA);

User Equipment (UE) conformance speciﬁcation;

Radio transmission and reception;

Part 1: Conformance testing

Evolved Universal Terrestrial Radio Access (E-UTRA);

Conformance

Test

TS 36.521-1

TS 36.521-2

User Equipment (UE) conformance speciﬁcation;

Radio transmission and reception;

Part 2: Implementation Conformance

TS 36.521-3

Statement (ICS)

Evolved Universal Terrestrial Radio Access (E-UTRA);

User Equipment (UE) conformance speciﬁcation;

Radio transmission and reception;

Part 3: Radio Resource Management (RRM) conformance testing

Technical Details

FCC RF Exposure Information

Read this information before operating the phone.

WARNING!

In August 1996, the Federal Communications Commission (FCC) of the United States, with its action in Report and Order FCC 96-326, adopted an updated safety standard for human exposure to Radio Frequency (RF) electromagnetic energy emitted by FCC regulated transmitters. Those guidelines are consistent with the safety standard previously set by both U.S. and international standards bodies. The design of this phone complies with the FCC guidelines and those international standards.

Bodily Contact During Operation

This device was tested for typical use with the back of the phone kept

0.39 inches (1.0 cm) from the body. To comply with FCC RF exposure requirements, a minimum separation distance of 0.39 inches (1.0 cm) must be maintained between the user’s body and the back of the phone, including the antenna. Third-party belt-clips, holsters, and similar accessories containing metallic components should not be used. Avoid the use of accessories that cannot maintain 0.39 inches (1.0 cm) distance between the user’s body and the back of the phone and have not been tested for compliance with FCC RF exposure limits.

Vehicle-Mounted External Antenna

(Optional, if available.)

To satisfy FCC RF exposure requirements, keep 8 inches (20 cm) between the user / bystander and vehicle-mounted external antenna. For more information about RF exposure, visit the FCC website at www.fcc.gov.

Technical Details

FCC Notice and Cautions

This device and its accessories comply with part 15 of FCC rules. Operation is subject to the following two conditions: (1) This device and its accessories may not cause harmful interference, and (2) this device and its accessories must accept any interference received, including interference that causes undesired operation.

Any changes or modiﬁcations not expressly approved in this user guide could void your warranty for this equipment. Use only the supplied antenna. Use of unauthorized antennas (or modiﬁcations to the antenna) could impair call quality, damage the phone, void your warranty and/or violate FCC regulations.

Don’t use the phone with a damaged antenna. A damaged antenna could cause a minor skin burn. Contact your local dealer for a replacement antenna.

Part 15.19 statement

This device and its accessories comply with part15 of FCC rules. Operation is subject to the following two conditions:

(1) This device & its accessories may not cause harmful interference.

(2) This device & its accessories must accept any interference received,

including interference that may cause undesired operation.

Part 15.21 statement

Changes or modiﬁcations that are not expressly approved by the manufacturer could void the user’s authority to operate the equipment.

Part 15.105 statement

This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a

Technical Details

particular installation. If you experience interference with reception (e.g., television), determine if this equipment is causing the harmful interference by turning the equipment off and then back on to see if the interference is affected. If necessary, try correcting the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

The phone operates on Verizon’s 4G network, based on Long Term Evolution (LTE) technology and Mobile Broadband 4G networks in the United States*.

Now you can connect easily at high speeds to the Internet, your corporate Intranet, and your email while you’re away from the ofﬁce.

* Service not available everywhere. Visit website (verizonwireless.com/4G) for a

* Information subject to change.

complete list of available areas.

Cautions

㻌

The user interface of Google applications (Google Search, Google



Maps, Navigation, etc.) can vary depending on its software version.

㻌

Locations are inaccurate when GPS and WIFI are not set.



㻌

With the Android operating system, some available Market



applications only operate correctly with phones that have a speciﬁc screen resolution. Please be advised that some of the applications on the Android Market may not be available for your phone due to LCD resolution requirement that does not match your phone. In addition, please be aware that 3rd party applications with programming defects may cause issues with your phone, including lock ups and resets.

The Basics

Phone Overview

Front View

Earpiece

Front Camera Lens

Proximity Sensor

Quick Keys

- Phone Key

- Contacts Key

- Messaging Key

- Apps Key

Menu Key

Home Key

O All screen shots in this guide are simulated. Actual displays may vary.

NOTES

Instructions to perform tasks in this guide are based on the default phone settings and

may change depending on the software version on your phone.

1. Earpiece Lets you hear callers and automated prompts.

Quick Keys

- Phone Key Opens the Phone application for access to the dialpad, Call

log, Contacts list, and Groups.

Contacts Key Opens the Contacts application.

Messaging Key Opens the Messaging application.

Apps Key Opens the Applications screen, where you can view all of

- your installed applications.

3. Menu Key Opens an Options menu with options that affect the current

screen or application.

4. Home Key Returns to the Home screen. If you’re already viewing one

of the Home screen extension canvases, it navigates you to the central Home screen canvas. Touch and hold to view the most recently used applications.

Home screen

Search Key

Back Key

Microphone

The Basics

5. Microphone Transmits your voice to the other caller and for

voice-activated functions.

6. Back Key Returns to the previous screen. Also closes pop-up display

items, such as menus, dialog boxes, and the on-screen keyboard.

7. Search Key Opens the Quick Search Box

from the Home screen to

search the phone and the web.

Home screen Displays all of the information needed to operate your

phone, such as applications, call status, date, time, signal status, and battery strength.

Proximity Sensor Senses proximity toward other objects (such as your

head) so that touch commands are not accidentally activated during a call.

Do not block the sensor or near the sensor to avoid problems with the touch

NOTES

O The use of a ﬁlm cover produced by manufacturers other than LG can cause a

operations.

disturbance in touch operations, the display, etc.

10. Front Camera Lens Use for taking pictures and recording videos of

yourself. You can also use this for video chatting. Keep it clean for optimal performance.

Rear View

LED Flash

Rear Camera Lens

Back Cover

Speaker

LED Flash This would brighten the image up when you turn on the

11.

ﬂash.

The Basics

12. Rear Camera Lens Use for taking pictures and recording videos. Keep

it clean for optimal performance.

13. Back Cover Encloses the battery compartment.

14. Speaker Sound comes from the rear speaker instead of the earpiece

(e.g., the speakerphone function, music player function, etc.).

Top View and Side Views

3.5mm Headset Jack

Power/ Lock Key

Volume Keys

USB/Charger Port

3.5mm Headset Jack Allows you to plug in an optional headset for

15.

convenient, hands-free conversations. You can also plug in headphones to listen to music.

Volume Keys Allow you to adjust the ringer, media volumes, or the in-

16.

call volume during a call.

17.

USB/Charger Port Allows you to connect the phone charger, USB

Cable, or other compatible accessories.

Power/Lock Key Press and hold to power the phone on or off. If your

18.

screen turns off, press the Power/Lock Key to turn in back on.

The Basics

Installing the Battery and microSD Card

It is important to fully charge the battery before initial use of the phone.

NOTE

Installing the battery

The phone comes with a rechargeable battery. Keep the battery charged while not in use in order to maximize talk, use, and standby time. The battery charge level is shown at the top right corner of the screen.

Use the ﬁngertip

cutout at the bottom of the phone to remove the back cover.

Removing the battery

Turn the phone off and use the ﬁngertip cutout at the bottom of the phone to remove the back cover.

Align the battery

contacts with the terminals in the battery compartment and push the battery down until it clicks into place.

Place the back cover

over the battery compartment, then press it downward until it clicks into place.

2. Use the ﬁngertip cutout at the bottom of the battery compartment to lift the

battery out.

Be careful not to scratch or damage the inside of the back cover as there is antenna located.

NOTE

The Basics

Installing the SIM card

If not already inserted, follow the instructions below to insert your SIM Card.

NOTE

Turn the power off. Remove the back cover and the battery (as demonstrated in the previous instructions). Locate the SIM card slot (a SIM card graphic is inscribed near the slot opening). Position the SIM card with the label side facing up and slide it into place until it is fully inserted and locked in place.

Removing the SIM card

Turn the power off. Remove the back cover and take the battery out. Locate the SIM card slot. Gently slide the SIM card out to remove it.

When switching to a new SIM, the device displays the message saying all e-mail

CAUTION

accounts would be deleted. On other Android devices, if you change SIMs it asks the user to enter their password to keep all the accounts on the device.

Inserting a microSD card

The microSD card is sold separately.

NOTE

Turn the power off. Remove the back cover (as demonstrated in the previous instructions) and locate the microSD card slot (microSD is inscribed near the slot opening). Position the microSD card with the label side facing up and slide it into place until it is fully inserted and locked in place.

The microSD card can be easily damaged by improper operation. Please be careful when

NOTE

inserting, removing or handling it.

The Basics

To unmount the microSD card

It is important to unmount the microSD card before removing it from the slot to avoid damage to the card or data saved on the card.

1. From the Home Screen, touch the Apps Key

2. Touch Settings

3. Touch Unmount SD card > OK.

> Storage.

To remove the microSD card

Turn the power off. Remove the cover and locate the microSD card slot. Carefully push the microSD card in to release it from the slot, then gently pull the microSD card out to remove it.

Memory encryption

㻌

Internal data for Email, Contacts, and Calendar is encoded.



㻌

Data cannot be encoded when the battery level is less than 50%.



㻌

Encoding can only be done when there is sufﬁcient storage space



available; a minimum of 650MB of free space in the internal memory and 500MB in the microSD card is needed for encoding.

㻌

While encoding, you cannot access Email, Contacts, and Calendar.



Some settings will not be available as well.

㻌

Do not connect the USB Cable while encoding.



㻌

Do not take out the microSD card while encoding.



㻌

Do not take out the battery while encoding.



㻌

Do not press the Power/Lock Key



㻌

After encoding, your phone will reboot to arrange the data.



㻌

If you encode the microSD card then perform a factory reset without



the microSD card inserted, you cannot decode the microSD card.

while encoding.

The Basics

Charging the Phone

Your phone comes with an Wall Charger and a USB Cable which connect together to charge your phone. To charge your phone:

Please use only an approved charging accessory to charge your phone.

NOTICE

Improper handling of the USB/Charger Port, as well as the use of an incompatible charger, may cause damage to your phone and void the warranty.

1. Connect the USB Cable into the Wall Charger.

When connecting, as shown below, the LG logo on the USB Cable will face toward you.

2. Plug the USB Cable (as shown below) into the phone’s USB/Charger

Port.

USB Cable

Correctly orient the USB Cable with the phone's port. The 'B' side of the USB Cable

NOTE

should be facing upwards.

Wall Charger

Charging with the USB Cable

You can use your computer to charge your phone. To be able to charge with the USB Cable, you need to have the necessary USB drivers installed on your PC ﬁrst. Connect one end of the USB Cable to the USB/Charger Port on your phone and connect the other end to a USB port on your PC. It is best to use the rear USB port when connecting to a desktop PC. The USB hub should be powered by an external power source.

If there is not enough charge in the battery to turn on the phone, the LED lights at the

NOTE

bottom of the keypad ﬂash to indicate that the battery is charging. Once the battery has enough charge to turn the phone on, the ﬂashing stops and the battery charge animation appears on the touchscreen.

The Basics

Optimizing Battery Life

You can extend your battery’s life between charges by turning off features that run in the background. You can also monitor how applications and system resources consume battery power.

Tips to extend the life of your battery

㻌

Turn off radio communications that you aren’t using. If you aren’t



using Wi-Fi, Bluetooth, or GPS, use the Settings menu to turn them off (Note that the GPS receiver is only turned on when you’re using an application that makes use of it).

㻌

Turn down screen brightness and set a shorter screen timeout.



㻌

Turn off automatic syncing for Gmail, Calendar, Contacts, and other



applications if you don’t need it.

㻌

Use the Power Saver in the Settings menu or the Power Control widget



to control the wireless connections, GPS connection, Bluetooth power, display brightness, and syncing activity.

To check the battery charge level

㻌

From the Home Screen, touch the Apps Key



phone > Battery. The battery status (Charging or Discharging) and level (as a percentage of fully charged) will be displayed at the top of the screen.

To monitor and control what uses the battery

The Battery use screen allows you to see which applications are consuming the most battery power. Information on this screen allows you to identify downloaded applications you may want to turn off when not being used, so you can get the most out of your battery power.

㻌

From the Home Screen, touch the Apps Key



About phone > Battery > Battery usage times. It lists all of the applications or services using battery power from the greatest amount of energy used to the least amount.

use. This screen displays battery

> Settings > About

Settings

The Basics

㻌

Touch an application or service in the Battery use screen to see the



details about its power consumption, including either how long since last connected to a power source or how long you were last running on battery power. Different applications or services offer different kinds of information, and they may even include options to modify the settings so you can reduce power consumption by that application.

Power Saver mode

If the battery charge level drops to low levels, the phone automatically activates Power Saver mode to conserve battery power until you can recharge it. You can set the phone to activate Power Saver mode at 10%, 30%, 50%, 70%, or Never. From the Home Screen, touch the Key

Settings

notiﬁcation is displayed prompting you to turn on Power Saver.

> Power Saver. When the battery charge is low, a

Apps

Power Control Widget

The Power Control widget helps users to conserve battery life easier.

㻌

Easy to control battery usage when battery life is low.



㻌

The Turn off all option disables all the setting items on the Power



control widget to save battery life.

㻌

The Power Saver option launches the Power Saver application.



To access the Power Control widget, touch and hold an empty space on a Home screen canvas. With Widgets Tap the screen to add the widget to the display canvas.

selected, touch Power Control .

Turning the Phone On and Off

Turning the phone on

㻌

Press and hold the Power/Lock Key



the screen turns on.

Turning the phone off

1. Press and hold the Power/Lock Key until the Phone options menu

appears.

for a couple of seconds until

The Basics

2. Touch Power off in the dialog box that appears.

3. Touch OK to conﬁrm that you want to turn off the phone.

Restarting the phone

1. Press and hold the Power/Lock Key until the Phone options menu appears.

2. Touch Restart in the dialog box that appears.

3. Touch OK to conﬁrm that you want to restart the phone.

To unlock the phone

If you don’t use the phone for a while, the screen and backlight will shut off to conserve battery power. To unlock the phone:

1. Press the Power/Lock Key

. Your Lock Screen will

appear.

2. Slide the screen up to unlock it. The last screen you

were working on opens.

The default Lock Screen simply locks the screen to prevent

NOTE

unintentional actions. For more security to guard against unauthorized use, you can set a pattern, PIN, or password that will need to be entered to unlock it.

Shortcuts on the lock screen

There are four icons in the center of your lock screen that you can use for quick access to the Phone application, the Messaging application, the Voicemail application, and the Camera application. Touch and drag any of these icons downward to immediately open and use its application. There’s no need to unlock the screen or touch any other keys.

Four frequently used shortcut icons are provided on the lock screen. Slide the icon

TIP

you want to use downwards to unlock the screen and provide the direct access to the chosen application.

To turn the phone sounds off

If you’re in a place where your phone sounds may disturb others, you can quickly silence your phone from the Home screen.

The Basics

1. Press and hold the Power/Lock Key until the Phone options menu

appears.

2. Touch Silent mode.

1. Press the down Volume Key

on the side of the phone until

all sounds are turned off.

You can also use these keys to quickly turn the phone sounds back on. Press and hold

NOTE

the Power/Lock Key in Silent mode, press the up Volume Key and twice to turn on phone sounds (continue pressing to increase volume).

, then touch Silent mode to toggle between on and off. While

once to activate Vibration mode

Setting Up Your Device

When you turn on your wireless device for the ﬁrst time, you have the option to quickly set up various accounts. Simply follow the on-screen instructions to complete the initial setup of your wireless device.

To set up your device, follow the steps below:

1. Select your language and touch Next.

2. Your SIM card will be activated now (if necessary). Otherwise, touch

Start the Setup Wizard.

3. Read the Welcome message and touch Continue.

4. Select whether to Skip or Start the Backup Assistant Plus application.

5. Set up your email accounts or touch Skip.

6. Read the Verizon backup information and touch Next to continue or Skip.

7. Select whether to Skip or Start the Google Account setup. With a

Google Account, Google applications are automatically synced between your phone and computer regardless of where you make an update.

8. Read the Privacy caution and touch Next. Then set your Location

settings (VZW Location Services/ Standalone GPS Services/ Google Location Services) and touch Next.

After successfully setting up your device, you can choose to view options that teach you

NOTE

about your new phone including Watch & Learn / My Verizon Mobile Video / Guided tours / Go to My Verizon. These options can be viewed later by accessing the Tools

section of the Applications screen.

The Basics

9. Touch Finish to start using the phone.

For more information on how to set up your email, visit smartphones.

verizonwireless.com/. Hover over the Support tab and under Get Help With Your click on Device. Then search for your phone.

Setting up your Google Account

1. At the setup screen, touch Create or Sign in.

2. Enter your username and password or any other necessary information (if

creating an account).

Touch the Back Key to close the keyboard.

NOTE

3. Touch Sign in to sign in to your account.

Now your Gmail, Google Contacts, and Google Calendar events will all be loaded to your phone automatically.

This is automatic for the ﬁrst Google account added. When adding additional Google

NOTE

accounts, you have to select which options to synchronize.

You can use the area below to record your Google Account information for future reference.

Username:___________________________________________@gmail.com

Password:____________________________________________

Your Google Account

You must sign into a Google Account to use Gmail, Google Talk, Google Calendar, and other Google Applications; to download applications from Android Market; to back up your settings to Google servers; and to take advantage of other Google services on your phone.

IMPORTANT

If you want to restore your settings to this phone, from another phone that was

running Android release 2.0 or later, you must sign into your Google Account now, during setup. If you wait until after setup is complete, your settings are not restored.

If you don’t have a Google Account, you’re prompted to create one.

If you have an enterprise account through your company or other organization, your IT

department may have special instructions on how to sign into that account.

When you sign in, your contacts, Gmail messages, Calendar events, and other

The Basics

information from these applications and services on the web are synchronized with your phone.

If you don’t sign into a Google Account during setup, you are prompted to sign in or to

create a Google Account the ﬁrst time you start an application that requires one, such as Gmail or Android Market.

When you sign in, you’re prompted to enter your username and password using the

on-screen keyboard.

Guided Tours

The Guided Tours application allows you to quickly view information about your phone, including the user guide and video tutorials.

To access Guided Tours, From the Home Screen, touch the Apps Key Guided Tours

SmartShare

SmartShare uses DLNA (Digital Living Network Alliance) technology to share digital content through a wireless network. Both devices must be DLNA certiﬁed to support this feature.

To share your media ﬁles using SmartShare, From the Home Screen, touch the Apps Key

SmartShare Tips

SmartShare requires a Wi-Fi or Wi-Fi Direct network connection. Please connect device to network you want to share content.

Touch to select the device from the content library list, such as another phone or PC.

> SmartShare .

Touch to select the device from the renderer device list, such as a TV.

Select an item to share.

The Basics

Phone’s Status Icons

The Status Bar appears at the top of every screen. It displays icons indicating that you’ve received notiﬁcations (on the left) and icons indicating the phone’s status (on the right), along with the current time.

Notiﬁcation icons

If you have more notiﬁcations than can ﬁt in the Status Bar, a plus icon prompts you to open the Notiﬁcations panel to view them all. To open the Notiﬁcations panel, touch and drag the Status Bar down. The following icons indicate the status of your phone.

Status icons

Call icons

Microphone muted during a call

In call In call using Bluetooth device

Speaker is on Privacy call

Missed call

Calendar & Alarm icons

Calendar event notiﬁcation An alarm is set

Alarm notiﬁcation Memo reminder alert

Email and Messaging icons

Others Email event received Sending Others Email failed

New message received High priority message received

Sending message failed New Voicemail received

New Visual Voicemail received

Google Talk message received

Playing Visual Voicemail in background

Sound icons

Music currently playing Silent mode is on

Vibrate mode is on Wired headset connected

+ 203 hidden pages
