LG DVT699H User Manual

ENGLISH ITALIANOESPAÑOL

OWNER’S MANUAL

DVD Player with Digital
Tuner

Please read this manual carefully before operating
your set and retain it for future reference.

DVT699H

P/NO : MFL63266742

Safety Information

Getting Started 3

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC

SHOCK DO NOT REMOVE COVER (OR BACK) NO

USER-SERVICEABLE PARTS INSIDE REFER SERVICING

TO QUALIFIED SERVICE PERSONNEL.

This lightning ash with arrowhead
symbol within an equilateral triangle
is intended to alert the user to the
presence of uninsulated dangerous

enclosure that may be of sucient magnitude to
constitute a risk of electric shock to persons.

instructions in the literature accompanying the
product.

WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK
HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN
OR MOISTURE.

WARNING: Do not install this equipment in a
conned space such as a book case or similar unit.

CAUTION: Do not block any ventilation openings.
Install in accordance with the manufacturer’s
instructions.
Slots and openings in the cabinet are provided for
ventilation and to ensure reliable operation of the
product and to protect it from over heating. The
openings shall be never be blocked by placing
the product on a bed, sofa, rug or other similar
surface. This product shall not be placed in a built­in installation such as a bookcase or rack unless
proper ventilation is provided or the manufacturer’s
instruction has been adhered to.

voltage within the product’s

The exclamation point within an
equilateral triangle is intended
to alert the user to the presence
of important operating and
maintenance (servicing)

CAUTION: This product employs a Laser System.
To ensure proper use of this product, please read
this owner’s manual carefully and retain it for future
reference. Shall the unit require maintenance,
contact an authorized service center.
Use of controls, adjustments or the performance of
procedures other than those specied herein may
result in hazardous radiation exposure.
To prevent direct exposure to laser beam, do not try
to open the enclosure. Visible laser radiation when
open. DO NOT STARE INTO BEAM.

CAUTION concerning the Power Cord

Most appliances recommend they be placed upon
a dedicated circuit;

That is, a single outlet circuit which powers only
that appliance and has no additional outlets or
branch circuits. Check the specication page of this
owner’s manual to be certain. Do not overload wall
outlets. Overloaded wall outlets, loose or damaged
wall outlets, extension cords, frayed power cords, or
damaged or cracked wire insulation are dangerous.
Any of these conditions could result in electric
shock or re. Periodically examine the cord of your
appliance, and if its appearance indicates damage
or deterioration, unplug it, discontinue use of the
appliance, and have the cord replaced with an
exact replacement part by an authorized service
center. Protect the power cord from physical or
mechanical abuse, such as being twisted, kinked,
pinched, closed in a door, or walked upon. Pay
particular attention to plugs, wall outlets, and
the point where the cord exits the appliance. To
disconnect power from the mains, pull out the
mains cord plug. When installing the product,
ensure that the plug is easily accessible.

1

Getting Started

Getting Started4

This device is equipped with a portable battery or
accumulator.

Safety way to remove the battery or the
battery from the equipment: Remove the

1

old battery or battery pack, follow the steps

Getting Started

in reverse order than the assembly. To prevent
contamination of the environment and bring on
possible threat to human and animal health, the
old battery or the battery put it in the appropriate
container at designated collection points. Do
not dispose of batteries or battery together with
other waste. It is recommended that you use
local, free reimbursement systems batteries and
accumulators. The battery shall not be exposed to
excessive heat such as sunshine, re or the like.

CAUTION: The apparatus shall not be exposed to
water (dripping or splashing) and no objects lled
with liquids, such as vases, shall be placed on the
apparatus.

Notes on Copyrights

yThis product incorporates copyright protection

technology that is protected by U.S. patents
and other intellectual property rights. Use of
this copyright protection technology must be
authorized by Rovi Corporation, and is intended
for home and other limited viewing uses only
unless otherwise authorized by Rovi Corporation.
Reverse engineering or disassembly is prohibited.

yUnder the U.S. Copyright laws and Copyright

laws of other countries, unauthorized recording,
use, display, distribution, or revision of television
programs, videotapes, DVDs, CDs and other
materials may subject you to civil and/or criminal
liability.

Disposal of your old appliance

1. When this crossed-out wheeled bin
symbol is attached to a product it
means the product is covered by the
European Directive 2002/96/EC.

2. All electrical and electronic products
should be disposed of separately
from the municipal waste stream
via designated collection facilities
appointed by the government or the
local authorities.

3. The correct disposal of your old
appliance will help prevent potential
negative consequences for the
environment and human health.

4. For more detailed information about
disposal of your old appliance, please
contact your city oce, waste disposal
service or the shop where you
purchased the product.

LG Electronics hereby declares that this/
these product(s) is/are in compliance
with the essential requirements and

other relevant provisions of Directive 2004/108/EC,
2006/95/EC, and 2009/125/EC.

European representative: LG Electronics Service
Europe B.V.Veluwezoom 15, 1327 AE Almere. The
Netherlands (Tel : [phone])

Notes on Discs

yDo not touch the playback side of the disc. Hold

the disc by the edges so that ngerprints do not
get on the surface. Never stick paper or tape on
the disc.

yAfter playing, store the disc in its case. Do not

expose the disc to direct sunlight or sources of
heat and never leave it in a parked car exposed
to direct sunlight.

Notes on the Unit

yPlease save the original shipping carton and

packing materials. If you need to ship the unit,
for maximum protection, re-pack the unit as it
was originally packed at the factory.

yTo clean the unit, use a soft, dry cloth. If the

surfaces are extremely dirty, use a soft cloth
lightly moistened with a mild detergent solution.
Do not use strong solvents such as alcohol,
benzine, or thinner, as these might damage the
surface of the unit.

yThe unit is a high-tech, precision device. If the

optical pick-up lens and disc drive parts are dirty
or worn, the picture quality could be diminished.
For details, please contact your nearest
authorized service center.

Table of Contents 5

Table of Contents

1 Getting Started

3 Safety Information
6 Introduction
6 – About the “7” Symbol Display
6 – Symbols Used in this Manual
6 – Supplied Accessories
6 – Playable Discs
7 – File compatibility
7 – Regional Code
8 Remote control
9 Front panel
9 Rear panel

2 Connecting

10 Connecting to your TV
10 – Connecting antenna
10 – Connecting Video / Audio cable
10 – Connecting SCART cable
11 – Connecting Component Video cable
11 – Connecting HDMI cable
11 – Resolution Setting
12 Connecting to an Amplifier
12 – Connecting Audio cable
12 – Connecting COAXIAL

(digital audio) cable
12 – Connecting HDMI cable
13 – General about digital broadcast

3 System Setting

14 Settings
14 – Adjust the Setup Settings
14 – [LANGUAGE] Menu
14 – [DISPLAY] Menu
15 – [AUDIO] Menu
15 – [LOCK] Menu
15 – [OTHERS] Menu
16 DVB-T or DAB settings
16 – Adjust the DVB-T or DAB Settings
16 – [TV] Menu
17 – [TIME] Menu

17 – [LOCK] Menu
18 – [OTHERS] Menu
18 – Displaying the channel information
18 – Changing the Channel
18 – Changing the Channel with Channel

list
19 The digital EPG
19 – Using the digital EPG
19 – About the digital EPG
19 – Viewing a Teletext service
20 – Selecting teletext page
20 – Special Teletext Functions

4 Operating

20 General Playback
20 – Selecting an operating mode
20 – Playing a Disc
20 – Playing a file
21 – On-Screen display
21 – General operation
22 Advanced Playback
22 – Movie
22 – Music
23 – Photo

5 Troubleshooting

24 Troubleshooting

6 Appendix

25 Area Code List
26 Language Code List
27 Specifications
27 Trademarks and Licenses

1

2

3

4

5

6

Getting Started6

Introduction

About the “7” Symbol Display

1

Getting Started

“7” may appear on your TV display during
operation and indicates that the function explained
in this owner’s manual is not available on that
specic media.

Symbols Used in this Manual

A section whose title has one of the following
symbols are applicable only to the disc or le
represented by the symbol.

r
t

y

u

i

Supplied Accessories

RCA Video/Audio
cable (1)

DVD-Video, DVD±R/RW

Audio CDs

Video les contained in the
USB/Disc

Audio les contained in the
USB/Disc

Photo les contained in the
USB/Disc

Remote control (1)

Playable Discs

DVD-VIDEO (8 cm / 12 cm disc)

-Discs such as movies that can be
purchased or rented.

DVD±R (8 cm / 12 cm disc)

-Video mode and nalized only

-Supports the dual layer disc also

-DVD±R discs that contain Video,
Audio or Photo les.

DVD-RW (8 cm / 12 cm disc)

-VR mode, Video mode and
nalized only

-DVD-RW discs that contain Video,
Audio or Photo les.

DVD+RW (8 cm / 12 cm disc)

-Video mode and nalized only

-DVD+RW discs that contain Video,
Audio or Photo les.

Audio CD (8 cm / 12 cm disc)

CD-R/RW (8 cm / 12 cm disc)

-CD-R/RW discs that contain audio
titles, Video, Audio or Photo les.

Note

,

You have to set the disc format option
to [Mastered] in order to make the discs
compatible with the players when formatting
rewritable discs. When setting the option
to Live System, you cannot use it on player.
(Mastered/Live File System: Disc format system
for windows Vista)

Battery (1)

Getting Started 7

File compatibility

Overall

Available File extensions: “.avi”, “.mpg”, ”.mpeg”,
“.mp3”, “.wma”, “.jpg”, “.jpeg”

yThe le name is limited to 35 characters.

yDepending on the size and number of the les,

it may take several minutes to read the contents
on the media.

Maximum Files/Folder: Less than 600 (total
number of les and folders)

CD-R/RW, DVD±R/RW Format: ISO 9660

Video Files

Available resolution size: 1280 x 720 (W x H)
pixels

Playable subtitle: SubRip (.srt/.txt), SAMI (.smi),
SubStation Alpha (.ssa/.txt), MicroDVD (.sub/.txt),
VobSub (.Sub), SubViewer 2.0 (.sub/.txt), TMPlayer
(.txt), DVD Subtitle System (.txt),

Playable Codec format: “DIVX3.xx”, “DIVX4.xx”,
“DIVX5.xx”, “XviD”, “MP43”, ”3IVX”

Playable Audio format: “Dolby Digital”, ”DTS”
“PCM”, “MP3”, “WMA”

Sampling frequency: within 8 to 48 kHz (MP3),
within 32 to 48 kHz (WMA)

Bit rate (MP3/WMA): within 8 to 320 kbps (MP3),
within 32 to 192 kbps (WMA),

Bit rate (DivX):

less than 7.2 Mbps (CD-R/RW)
less than 9.7 Mbps (USB, DVD±R/RW)

Note

,

This unit does not support les that are
recorded with GMC
encoding techniques in MPEG4 standard, like
DivX have.

*1 GMC – Global Motion Compensation

*2 Qpel – Quarter pixel

*1

or Qpel*2. Those are video

Photo Files

Photo size: Less than 2M recommended.

yProgressive and lossless compression photo

image les are not supported.

Note of USB Device

,

yDo not extract the USB device during

operation (play, etc.).

yA USB device which requires additional

program installation when you have
connected it to a computer, is not
supported.

yUSB device: USB device that supports

USB1.1 and USB2.0.

yMovie, music and photo les can be played.

For details of operations on each le, refer to
relevant pages.

yRegular back up is recommended to

prevent data loss.

yIf you use a USB extension cable, USB HUB

or USB Multi-reader, the USB device may not
be recognized.

ySome USB device may not work with this

unit.

yDigital camera and mobile phone are not

supported.

yUSB Port of the unit cannot be connected

to PC. The unit cannot be used as a storage
device.

Regional Code

This unit has a regional code printed on the rear of
the unit. This unit can play only DVD discs labeled
same as the rear of the unit or “ALL”.

1

Getting Started

Audio Files

Sampling frequency: within 8 to 48KHz (MP3),
within 32 to 48KHz (WMA)

Bit rate: within 8 to 320 kbps (MP3), within 32 to
192kbps (WMA)

Getting Started8

Remote control

1

Getting Started

• • • • • • a • • • • •

POWER (1): Switches the unit
ON or OFF.

OPEN/CLOSE (B): Opens and
closes the disc tray.

Numerical buttons: Selects
numbered items in a menu.

SETUP: Accesses or exits the
setup menu.

TV Control Buttons: Control the
sound volume, channel, sources,
and power On/O on TV.

• • • • • • b • • • • •

SCAN (

c/v

backward or forward.

SKIP (

C/V

next or previous chapter / track /
le.

PAUSE/STEP (M): Pauses
playback.

PLAY (z): Starts playback.

STOP (Z): Stops playback.

): Searches

): Goes to the

• • • • • • c • • • • •

MODE: Switches a operation
mode (DVB-T, DAB or Disc).

CH (+/-): Scans up or down
through memorized channels in
DVB-T or DAB mode.

DVD MENU: Accesses or exits the
DVD menu.

CH LIST: Displays the channel list.

FAV. (+/-): Tunes to your favorite

channels.

w/s/a/d

menus.

ENTER (b): Conrms menu
selection.

DISPLAY: Accesses or exits On­Screen Display.

RETURN (x): Moves backward
or exit the menu. Changes to the
USB mode.

• • • • • • d • • • • •

INDEX (-) / ZOOM: Moves to
Index screen or page 100 in the
teletext mode. Enlarges video
image in disc mode.

TEXT (`): Switches between
teletext mode and normal TV
viewing.

EPG: Displays the EPG menu.

MIX (~) / TITLE: Displays the

teletext pages superimposed
on the TV picture. Accesses the
disc’s title menu in disc mode, if
available.

Color buttons: Use when tuned
to a teletext program of a digital
broadcast. The function of each
button will be described on­screen, and changes depending
on the screen being displayed.

REPEAT: Repeats a chapter, track,
title or all.

: Navigates the

A-B: Repeats a section.

PROGRAM: Enters the program

edit mode.

CLEAR: Removes a track number
on the Program List

AUDIO ([): Selects an audio
language or audio channel.

SUBTITLE (]): Selects a subtitle
language.

ANGLE (}): Selects a DVD
camera angle, if available.

RESOLUTION: You can change
the resolution depending on your
TV.

Battery Installation

Remove the battery cover on the
rear of the Remote Control, and
insert a R03 (size AAA) battery
with 4 and 5 matched correctly.

Code number to control
TVs

While holding down TV POWER
button, press the number buttons
to select the Maker code for your
TV (see the table below). Release
TV POWER button.

Maker Code Number

LG 1(Default), 2

Zenith 1, 3, 4

GoldStar 1, 2

Samsung 6, 7

Sony 8, 9

Hitachi 4

Front panel

Getting Started 9

9

1

Getting Started

Disc Tray

a

Remote Sensor

b

Display Window

c

(Open/Close)

d B

(Play)

e d

*1 CH(+/-): Scans up or down through memorized channels in DVB-T or DAB mode.

*2 MODE: Switches a operation mode (DVB-T, DAB or Disc)

f C/V
g Z
h 1

USB Port

i

*2

(Stop)

(Power)

*1

(Skip)

Rear panel

AC power cord

a

HDMI OUTPUT

b

DIGITAL AUDIO OUTPUT (COAXIAL)

c

AUDIO OUTPUT (Left/Right)

d

VIDEO OUTPUT

e

ANTENNA IN

f

ANTENNA OUT

g

SCART (TO TV)

h

COMPONENT / PROGRESSIVE SCAN

i

OUTPUT (Y P

B PR

)

10

COAXIAL ANTENNA IN

COMPONENT VIDE

VIDEO IN L

P

B

Y

Connecting

Connecting to your TV

Connecting antenna

Antenna connection

Connect the Terrestrial TV antenna to the ANTENNA
IN jack on the unit. If you want to use an indoor

2

antenna, use one with a signal amplier rated at 5V,

Connecting

100mA and set [Antenna Feed 5V] to [ON] in the
setup menu (See page 17)

Antenna connection to your TV

Connect one end of the RF cable to ANTENNA OUT
jack on the unit and other end to ANTENNA IN jack
on your TV. Passes the signal from the ANTENNA IN
jack to your TV/monitor.

Rear of the Unit

RF Cable

Connecting Video / Audio
cable

Connect the VIDEO/AUDIO OUTPUT on the unit
to VIDEO/AUDIO IN on TV with A/V cable, such as
VIDEO with yellow, AUDIO Left/Right with white/
red.

Rear of the Unit

A/V Cable

TV

Connecting SCART cable

Connect the TO TV jack on the unit and your TV
using the SCART cable.

For SCART connections, resolution must be set to
576i(480i) by pressing RESOLUTION button.

TV

Rear of the Unit

SCART
Cable

TV

yYou must set the [TV Output Select] option to

[RGB] on the setup menu to use this connection.

Connecting 11

COAXIAL

Connecting Component Video
cable

Connect the COMPONENT/PROGRESSIVE SCAN
OUTPUT jacks on the unit to the corresponding
input jacks on the TV using Component video
cable, such as Y with green, Pb with blue, and Pr
with red.

Rear of the Unit

Component
Cable

TV

yYou must set the [TV Output Select] option

to [YPbPr] on the setup menu to use this
connection.

yYou should still connect the AUDIO cable

between the unit and TV.

Connecting HDMI cable

Connect the HDMI OUTPUT on the unit to the
HDMI IN on compatible TV with HDMI cable.
(Type A, High Speed HDMI™ Cable)

Rear of the Unit

HDMI Cable

TV

Additional Information for HDMI

yWhen you connect a HDMI or DVI compatible

device, make sure of the following:

-Try switching o the HDMI/DVI device and this
unit. Next, switch on the HDMI/DVI device and
leave it for around 30 seconds, then switch on
this unit.

-The connected device’s video input is set
correctly for this unit.

-The connected device is compatible with
720x576i(480i), 720x576p(480p), 1280x720p,
1920x1080i or 1920x1080p video input.

-The 1080p, 720p and 576p(480p) resolutions are
the progressive scan applied resolution.

yNot all HDCP-compatible DVI devices will work

with this unit.

-The picture will not be displayed properly with
non-HDCP device.

Resolution Setting

The unit provides several output resolutions for
HDMI OUTPUT and COMPONENT / PROGRESSIVE
SCAN OUTPUT jacks. You can change the resolution
using RESOLUTION button.

yThe unit is able to provide a 1080p full HD image

to most 1080p-capable TVs in the market today.
However, there are some 1080p TVs available
from certain companies that are limited in the
types of 1080p images that can be accepted.
Specically, 1080p-capable TVs that don’t accept
images in 60Hz can’t display an image from this
unit.

yFor 720p, 1080p and 1080i resolution on the

Component / progressive scan output, only non­copy protected discs can be played back. If the
disc is copy protected, it will be displayed at the
576p(480p) resolution.

yDepending on your TV, some of the resolution

settings may result in the picture disappearing
or an abnormal picture appearing. In this case,
press RESOLUTION repeatedly until the picture
re-appears.

2

Connecting

Connecting12

OPTICAL

COAXIAL

OUT

Connecting to an
Amplifier

Connecting Audio cable

Connect the AUDIO OUTPUT on the unit to 2CH
AUDIO IN on amplier with Audio cable, such as
AUDIO Left/Right with white/red.

2

Connecting

Audio
Cable

Receiver / Amplier

Connecting COAXIAL
(digital audio) cable

Connect one of the unit’s DIGITAL AUDIO OUTPUT
(COAXIAL) jacks to the corresponding jack on your
amplier.

Rear of the Unit

yIf your TV is not capable of handling 96 kHz

sampling frequency, set the [Sample Freq.]
option to [48 kHz] on the setup menu.

yIf your TV is not equipped with Dolby Digital

and MPEG decoder, set the [Dolby Digital] and
[MPEG] options to [PCM] on the setup menu.

yChanging the resolution when the unit is

connected with HDMI connector may result in
malfunctions. To solve the problem, turn o the
unit and then turn it on again.

Note

,

yIf the audio format of the digital output

does not match the capabilities of your
amplier, the amplier will produce a strong,
distorted sound or no sound at all.

yTo see the audio format of the current disc

in the on-screen display, press AUDIO.

yThis unit does not perform internal (2

channel) decoding of a DTS sound track.
To enjoy DTS multi channel surround, you
must connect this unit to a DTS compatible
amplier via one of this unit’s digital audio
outputs.

Connecting HDMI cable

Connect the HDMI OUTPUT on the unit to the
HDMI IN on amplier with HDMI cable.
(Type A, High Speed HDMI™ Cable).
Connect the HDMI OUT jack on amplier to HDMI
IN jack on TV with HDMI cable, if the amplier has
HDMI OUTPUT jack.

Coaxial
Cable

Rear of the Unit

Receiver / Amplier

Rear of the Unit

TV

HDMI
Cable

HDMI
Cable

Receiver /
Amplier

General about digital
broadcast

Picture and sound

Digital TV is a transmission technology that replaces
the traditional analogue technique.

This means that several TV channels, radio channels
and other digital services can be transmitted on the
same space as just one channel took up before. As
a consumer you get access to many more channels
and services than before at the same time as they
are received with perfect picture and audio quality.

Coverage

Before buying this product it is anticipated that you
have made sure that there are digital transmissions
covering your region.

Antenna / Signal source

Depending on the reception your unit may be
connected to a simple indoor antenna or to an
existing outdoor antenna system. If you live in a
at you should make sure that the digital terrestrial
signals are distributed to your wall antenna outlet. If
you have your own antenna system you must make
sure that it is equipped with antennas, lter and/
or amplier that can handle those frequencies that
the digital channels are transmitted on.

Connecting 13

2

Connecting

Cable-TV

Please observe that this unit is not designed for the
reception of regular digital cable-TV signals (QAM­signal). Despite this, operators of smaller cable
networks may have chosen to distribute the digital
terrestrial signals (COFDM-signal) in the network.
In this case this unit may well be used. Check with
your landlord if you are insecure about what type
of TV-signal that is provided in the wall antenna
outlet.

System Setting14

Settings

When the unit is turned-on at the rst time, you
have to select the desired language.

Adjust the Setup Settings

You can change the settings of the unit in the
[Setup] menu.

1. Press SETUP.

2. Use
press d to move to the second level.

3. Use

3

System Setting

press d to move to the third level.

4. Use
ENTER (b) to conrm your selection.

[LANGUAGE] Menu

Menu Language

Select a language for the Setup menu and on­screen display.

Disc Audio/Subtitle/Menu

Select a language for the Disc Audio/Subtitle/
Menu.

[Original]: Refers to the original language in
which the disc was recorded.

[Other]: To select another language, press
number buttons then ENTER (b) to enter the
corresponding 4-digit number according to
the language code list. (See page 26) If you make
a mistake while entering number, press CLEAR
to delete numbers then correct it.

[O](for Disc Subtitle): Turn o Subtitle.

to select the rst setup option, and

w/s

to select a second setup option, and

w/s

to select a desired setting, and press

w/s

[DISPLAY] Menu

TV Aspect

Select which screen aspect to use based on the
shape of your TV screen.

[4:3]: Select when a standard 4:3 TV is
connected.

[16:9]: Select when a 16:9 wide TV is
connected.

Display Mode

If you selected 4:3, you’ll need to dene how you
would like widescreen programs and lms to be
displayed on your TV screen.

[Letterbox]: This displays a widescreen picture
with black bands at the top and bottom of the
screen.

[Panscan]: This lls the entire 4:3 screen,
cropping the picture as necessary.

TV Output Select

Select an option according to the TV connection
type.

[RGB]: When your TV is connected with the TO
TV (SCART ) jack.

[YPbPr]: When your TV is connected with the
COMPONENT/PROGRESSIVE SCAN OUTPUT
jacks on the unit.

System Setting 15

[AUDIO] Menu

Dolby Digital / DTS / MPEG

Set the unit’s Audio options according to various
disc output type you use.

Sample Freq. (Frequency)

Selects the sampling frequency of the audio signal
between [48kHz] and [96kHz].

DRC (Dynamic Range Control)

Make the sound clear when the volume is turned
down (Dolby Digital only). Set to [On] for this eect.

Vocal

Set to [On] only when a multi-channel karaoke DVD
is playing. The karaoke channels on the disc mix
into normal stereo sound.

[LOCK] Menu

Firstly, you have to create the 4-digit password on
[Area Code] to use the LOCK menu.

If you forget your password you can reset it. First,
remove the disc in the unit. Display setup menu
then input the 6-digit number “210499”. The “P CLr”
appear in the display window and the password is
deleted.

[OTHERS] Menu

B.L.E (Black Level Expansion)

To select the black level of playback pictures, set
your preference and monitor’s ability.

It just operates when TV system is set to NTSC.

DivX(R) VOD

ABOUT DIVX VIDEO: DivX® is a digital video format
created by DivX, Inc. This is an ocial DivX Certied®
device that plays DivX video. Visit divx.com for more
information and software tools to convert your les
into DivX video.

ABOUT DIVX VIDEO-ON-DEMAND: This DivX
Certied® device must be registered in order to play
purchased DivX Video-on-Demand (VOD) movies.
To obtain your registration code, locate the DivX
VOD section in your device setup menu. Go to vod.
divx.com for more information on how to complete
your registration.

3

System Setting

Rating

Select a rating level. The lower the level, the stricter
the rating. Select [Unlock] to deactivate the rating.

Password

Sets or changes the password for lock settings.

Area Code

To input the standardized area code referring the
Area Code List on page 25.

System Setting16

DVB-T or DAB settings

When the rst time to turn on the unit, the “First
time installation” menu will appear. Select [YES] and
press ENTER (b) for auto channel scanning. (see “
Auto Scan” below for details)

Adjust the DVB-T or DAB
Settings

1. Press MODE to select the DVB-T or DAB mode.

2. Press SETUP.

3. Use

3

System Setting

press d to move to the second level.

4. Use
press d to move to the third level.

5. Use
ENTER (b) to conrm your selection.

[TV] Menu

Auto Scan

This option automatically scans and sets the
available channels. Currently selected mode (TV or
Radio) will not be changed after the Auto channel
scanning.

[Country]: Use
you operate this unit.

[Auto Scan]: Use
press ENTER (b) to start the channel scanning.

TV Channel / Radio Channel

Displays the TV or Radio channel list.

Use d to select the [Select] then press ENTER (b)
to display the channel list. You can also display the
channel list pressing CH LIST while in DVB-T or DAB
mode.

While displaying channel list, press
favorite channel list.

to select the rst setup option, and

w/s

to select a second setup option, and

w/s

to select a desired setting, and press

w/s

select a country where

a/d

s/a/d

to select [Yes] then

a/d

to display

Channel Class

This option allows you to set the favorite channel.
Use
(b) to set the favorite class on each channel.
(shows Fav icon on top of the screen)

select the a channel and press ENTER

w/s

Channel Edit

This option allows you to edit the channels.

[Add]: This option allows you to add a new
channel. Use
press ENTER (b) to add the selected channel.

[Select]: This option allows you to delete
or move the preset channels. To move the
location of the preset channel, use

to highlight the channel you want to move

d

on the [Move] column and press ENTER (b).
Use

w/s

desired position and then press ENTER (b) to
complete move.
To delete a preset channel, use
to highlight the channel you want to delete
on the [Delete] column and press ENTER (b).
Themarked channel will not be displayed on
the channel list. Press ENTER (b) again to clear
the

mark.

to select the channel and

w/s

w/s/a/

to move the selected channel to the

w/s/a/d

System Setting 17

Aspect Ratio

Selects the aspects ratio of the connected TV.

[4:3 PS]: Select this when connecting to a
standard 4:3 screen TV and prefer the wide
picture on the entire screen cuts o the
portions that do not t.

[4:3 LB]: Select this when connecting to a
standard 4:3 screen TV and prefer the wide
picture with bands on the upper and lower
portions of the screen.

[16:9]: Select this when connecting to a wide­screen TV.

Antenna Feed 5V

If you are using an indoor antenna, use one with a
signal amplier rated at DC 5 V, 100 mA and set this
option to [ON].

[ON]: Power is supplied to the connected
antenna.

[OFF]: The unit does not supply power to the
connected antenna.

[TIME] Menu

Set the channel that broadcasts a clock signal and
the clock will be set automatically. If the clock that
has automatically set is dierent with your local
clock, you can adjust time using [Time Oset]
option (For example, when summer time is started
in local area.).
Press d to select [Time Oset] option. Press
to select a value then press ENTER (b) (O, +/-30
min, +/-60 min, +/-90 min, +/-120 min). Select “O”
if the clock that has automatically set is identied
with your local clock.

w/s

Change Pin

Changes the password. Enter the new password
twice after entering the current password.

Channel Lock

You can lock certain unsuitable channels to prevent
children from accessing them, use
a channel you want to lock and then press ENTER
(b) to lock the channel. If you want to watch a
locked channel. You should input the password.

w/s

Parental Guidance

Blocks TV programs that you or your family may not
wish to watch, based on the rating scheme set.
Select a rating then press ENTER (b).

[3 Years] - [18 Years]: Rating [3 Years] has the
most restrictions and rating [18 Years] is the
least restrictive.

[Blocking O]: Permits all programs.

to select

3

System Setting

[LOCK] Menu

To access the [Change Pin], [Channel Lock],
[Parental Guidance] options, you must enter the
4-digit password. If you have not yet entered a
password you are prompted to do so. Enter a
4-digit password. Enter it again to verify. If you make
a mistake while entering number, press CLEAR to
delete numbers.
If you forget your password, you can reset it. Display
the SETUP menu. Input ‘210499’ and press ENTER
(b). The password has now been cleared.

System Setting18

[OTHERS] Menu

OTA (Over the Air)

Your unit is able to keep the built-in digital tuner
up to date with the latest software. The unit does it
automatically at regular interval. While the unit is in
updating, there may have a disruption in reception
for a few hours. The reception should return to
normal after the update is complete. This unit must
be plugged into AC power to receive updates. Do
not unplug your unit while an update is in progress.
The update is not available during viewing digital
text or EPG menu.

3

System Setting

[ON]: Updates the software when this unit is
turned on.

[OFF]: Select this if you do not want to do not
use this function.

Default Setting

You can reset the unit to its original factory settings.
Press ENTER (b) while [Select] option is selected.
Select [Yes] on the pop-up message to return to
the default setting.

Displaying the channel
information

In DVB-T or DAB mode, press DISPLAY to display
the information displayed on-screen. If you press
DISPLAY twice, the signal strength and quality will
appear on the screen.

Indicates channel number, station name, and

a

the present time.

Indicates the channel signal strength, quality.

b

Changing the Channel

Use CH - / + on the remote control to change the
channel in memory to select a channel directly.

Changing the Channel with
Channel list

You can display channel list using the CH LIST
button and switch into other channel on the
channel list.

In DVB-T or DAB mode, press CH LIST to display
the channel list. Select your desired channel using
the
channel. You can switch the channel list to All or
Favorite by pressing

and press ENTER (b) to change another

w/s

.

a/d

System Setting 19

The digital EPG

Using the digital EPG

1. Press MODE to select the DVB-T or DAB mode.

2. Press EPG to display the EPG menu.

3. Use

w/s/a/d

About the digital EPG

The digital EPG shows a table of scheduled digital
TV programs and detailed information about
individual program. The digital EPG screen consists
of program information, channel list and general
program list.

Note that the unit’s clock must be set to the
correct time and date to ensure all relevant EPG
information is displayed.

to select a program.

Viewing a Teletext service

Teletext is a free broadcasting service by some TV
stations which gives up-to-the-minute information
on news, weather, television programs, share prices
and many other topics.

The unit gives you access to teletext which is
greatly improved in various aspects such as text
and graphics. This teletext can be accessed by
special teletext services and specic services which
broadcast teletext.

In DVB-T mode, use numbered (0-9) buttons or CH

- / + on the remote control to change the channel
which broadcast teletext. Press TEXT to access the
teletext.

Follow the indications on teletext and move onto
the next or previous step by pressing color (Red
or Green) or
(x) to turn the teletext o and return to TV
viewing.

buttons. Press TEXT or RETURN

w/s

3

System Setting

Operating20

Selecting teletext page

Enter the desired page number as a three digit
number with the numbered buttons. If during
selection you press a wrong number, you must
complete the three digit number and then enter
the correct page number again.

Use Red/Green buttons to move up and down
pages.

Special Teletext Functions

MIX button

Displays the teletext pages superimposed on the
TV picture. To switch the TV picture o press this
button again.

INDEX button

Moves to Index screen or page 100 in the teletext

4

mode.

Operating

General Playback

Selecting an operating mode

You must select one of the operating modes before
operating. Press MODE repeatedly to change the
mode among DVB-T, DAB or Disc.

Disc: You should select the Disc mode before using
playback functions or disc setup setting.

DVB-T: You should select the DVB-T mode before
watching TV channel or using TV setup setting.

DAB: You should select the DAB mode before
listening to the radio or using radio setup setting.

Playing a Disc

1. Press OPEN/CLOSE (B), and place a disc on the
disc tray.

2. Press OPEN/CLOSE (B) to close the disc tray

For the most DVD-ROM discs, playback starts
automatically.

For the Audio CD, select a track using

, and press PLAY (z) or ENTER (b) to

a/d

play the Track.

Playing a file

1. Press OPEN/CLOSE (B) to place a disc on the
disc tray, or connect the USB device.

2. Select a le using
(z) or ENTER (b) to play the le.

rt

w/s/

yui

w/s/a/d

, and press PLAY

RETURN (x) Changes between Disc and

TITLE Changes the mode.

USB Device.

(Music : Photo : Movie)

Operating 21

On-Screen display

You can display and adjust various information and
settings about the content.

1. While playback, press DISPLAY to show various
playback information.

2. Select an option using

3. Use
selected option value.

4. Press RETURN(x) to exit the On-Screen display.

and numerical button to adjust the

a/d

Current title number/total
number of titles

Current chapter number/total
number of chapters

Elapsed playing time
Selected total time of current
title/le

Selected audio language or
channel

Selected subtitle

Selected angle/total number
of angles

ry

.

w/s

General operation

To Do this
Playback Press PLAY (z)

Pause Press PAUSE/STEP (M)
Stop Press STOP (Z)

Skip to the next
or previous

Fast forward or
fast reverse

Resume
playback

Playback disc
or USB device
with several
kinds of les

System Select You must select the appropriate

Screen Saver Leave the unit in Stop mode for

Last Scene
Memory

Press C or V during
playback

Press
playback. (Press and hold C
or

Press STOP (Z) during playback
to save the stopped point.

yPress STOP (Z) once:

yPress STOP (Z) twice:

Select the proper menu by
continuously pressing TITLE as
[MUSIC], [PHOTO], and [MOVIE].

system mode for your TV system.
Remove any disc that might
be in the unit, press and hold
PAUSE/STEP (M) for more than
ve seconds to be able to select
a system (PAL, NTSC).

about ve minutes, then the
screen saver appears.
If the Screen Saver is displayed
for ve minutes, the unit auto­matically turns itself o.

Turn o the unit, then the unit
memorize the lastly viewed
scene even if disc is inserted
again after removal or unit is
turned on after o with same
disc. (DVD/ Audio CD only)

or

v

during

c

on the front panel)

V

Displayed MZ on the screen
(Resume Stop)

Displayed Z on the screen
(Complete Stop)

4

Operating

22

Operating

Advanced Playback

Movie

To Do this

Display disc
menu

Play
repeatedly

Play frame-by­frame

Repeat a

4

specic

Operating

portion

Set the desired
starting time of
playback

Change the
subtitle code
page
(Video le
only)

Slow down the
playing speed
(Forward only)

ry

Press DVD MENU. (DVD Only)

Press REPEAT during playback. To
select an option to be repeated,
Press REPEAT repeatedly.

• DVD: Chapter/ Title/ O

• MOVIE: Track/ All/ O

Press PAUSE/STEP (M) while
Video le playback and press
PAUSE/STEP (M) repeatedly to
play Frame-by-Frame playback.

Press A-B at the beginning of the
portion you wish to repeat and
again at the end of the portion.
To return to normal playback,
press A-B to select [O ].

Searches for the starting point
of entered time code. Press
DISPLAY then select clock
icon. Enter a time then press
ENTER(b).
For example, to nd a scene
at 1 hour, 10 minutes, and 20
seconds, enter “11020” and press
ENTER(b).
If you enter the wrong number,
press CLEAR to enter again.

Press and hold SUBTITLE for 3
seconds during playback. The
language code will appear.
Press a/d to select another
language code until the subtitle
is displayed properly and then
press ENTER (b)

While the playback is paused,
press v repeatedly to play
various speeds of slow motion.
Press PLAY (z) to continue play
at normal speed.

Watch an
enlarged video

Music

To Do this

Play
repeatedly

Create or
delete your
own program

Display le
information
(ID3 TAG)

During playback or pause mode,
press ZOOM repeatedly to select
zoom mode.

ZOOM: 100% : 200% : 300%

400% : 100%

:

w/s/a/d

zoomed picture.

tu

Press REPEAT during playback.
To select an item to be repeated,
Press REPEAT repeatedly.

• TRACK / ALL

Press the PROGRAM to select
desired le and then, { mark
appears on screen.

Using
to add a music le(s) on the
program list,

If you add desired music le(s),
press PROGRAM to end edit
program list.

To clear a music le(s) from the
program list, select the music
le you want to clear then press
CLEAR in program edit mode.

To clear all music le(s) from the
program list, select [Clear All]
then press ENTER (b) in program
edit mode.

While playing a MP3 le
containing le information, you
can display the information by
pressing DISPLAY repeatedly.

yDepending on the MP3 les,

information may not be
displayed on the screen.

: Move through the

and ENTER (b)

w/s

Operating 23


To Do this

View photo
les as a slide
show

Adjust slide
show speed

Rotate a photo Use

Watch an
enlarged Photo

Listen to music
during slide
show

i

Use

w/s/a/d

(`) icon then press ENTER (b)
to start slide show.

You can change slide show
speed using
icon is highlighted.

w/s

full screen counterclockwise or
clockwise while viewing a photo
in full screen.

While viewing a photo in full
screen, press ZOOM repeatedly
to select zoom mode.

ZOOM: 100% : 200% : 300%

400% : 100%

:

w/s/a/d

zoomed photo.

You can listen to music during
slide show, if the disc contain
music and photo les together.
Use

w/s/a/d

(~) icon then press ENTER (b)
to start slide show.

to highlight

when (J)

a/d

to rotate the photo in

: Move through the

to highlight

4

Operating

Troubleshooting24

Troubleshooting

Symptom Cause Solution

No power The power cord is disconnected. Plug the power cord into the wall outlet

The power is on, but
the unit does not work.

The unit does not start
playback.

The remote control
does not work properly.

Poor picture quality
and sound distortion

No picture The TV is not set to receive the

5

Troubleshooting

No sound The equipment connected with

securely.

No disc is inserted. Insert a disc.

An unplayable disc is inserted. Insert a playable disc. (Check the disc type

The rating level is set. Change the rating level.

The remote control is not
pointed at the remote sensor
on the unit.

The remote control is too far
from the unit.

Fingerprints and dust are
stained on the disc.

signal from the unit.

The video cable is not
connected securely.

The video cable is not
connected securely.

the audio cable is not set to
receive the signal from the unit.

The AUDIO options are set to
the wrong position.

and regional code.)

Point the remote control at the remote
sensor of the unit.

Operate the remote control closer to the unit.

Wipe the disc from the center to out with
a clean cloth. Do not use strong solvents.
(alcohol, benzine, thinner, commercially
available cleaners)

Select the appropriate video input mode on
the TV.

Connect the video cable securely.

Press RESOLUTION repeatedly to select
appropriate resolution.

Select the correct input mode of the audio
amplier.

Set the AUDIO settings to the correct
position.

Appendix 25

Area Code List

Choose an area code from this list.

Area Code Area Code Area Code Area Code

Afghanistan AF

Argentina AR

Australia AU

Austria AT

Belgium BE

Bhutan BT

Bolivia BO

Brazil BR

Cambodia KH

Canada CA

Chile CL

China CN

Colombia CO

Congo CG

Costa Rica CR

Croatia HR

Czech Republic CZ

Denmark DK

Ecuador EC

Egypt EG

El Salvador SV

Ethiopia ET

Fiji FJ

Finland FI

France FR

Germany DE

Great Britain GB

Greece GR

Greenland GL

Hong Kong HK

Hungary HU

India IN

Indonesia ID

Israel IL

Italy IT

Jamaica JM

Japan JP

Kenya KE

Kuwait KW

Libya LY

Luxembourg LU

Malaysia MY

Maldives MV

Mexico MX

Monaco MC

Mongolia MN

Morocco MA

Nepal NP

Netherlands NL

Antilles AN

New Zealand NZ

Nigeria NG

Norway NO

Oman OM

Pakistan PK

Panama PA

Paraguay PY

Philippines PH

Poland PL

Portugal PT

Romania RO

Russian
Federation RU

Saudi Arabia SA

Senegal SN

Singapore SG

Slovak Republic SK

Slovenia SI

South Africa ZA

South Korea KR

Spain ES

Sri Lanka LK

Sweden SE

Switzerland CH

Taiwan TW

Thailand TH

Turkey TR

Uganda UG

Ukraine UA

United States US

Uruguay UY

Uzbekistan UZ

Vietnam VN

Zimbabwe ZW

6

Appendix

Appendix26

Language Code List

Use this list to input your desired language for the following initial settings: [Disc Audio],
[Disc Subtitle] and [Disc Menu].

Language Code Language Code Language Code Language Code

Lithuanian 7684

Macedonian 7775

Malagasy 7771

Malay 7783

Malayalam 7776

Maori 7773

Marathi 7782

Moldavian 7779

Mongolian 7778

Nauru 7865

Nepali 7869

Norwegian 7879

Oriya 7982

Panjabi 8065

Pashto, Pushto 8083

Persian 7065

Polish 8076

Portuguese 8084

Quechua 8185

Rhaeto-Romance 8277

Rumanian 8279

Russian 8285

Samoan 8377

Sanskrit 8365

Scots Gaelic 7168

Serbian 8382

Serbo-Croatian 8372

Shona 8378

6

Appendix

Afar 6565

Afrikaans 6570

Albanian 8381

Ameharic 6577

Arabic 6582

Armenian 7289

Assamese 6583

Aymara 6588

Azerbaijani 6590

Bashkir 6665

Basque 6985

Bengali; Bangla 6678

Bhutani 6890

Bihari 6672

Breton 6682

Bulgarian 6671

Burmese 7789

Byelorussian 6669

Chinese 9072

Croatian 7282

Czech 6783

Danish 6865

Dutch 7876

English 6978

Esperanto 6979

Estonian 6984

Faroese 7079

Fiji 7074

Finnish 7073

French 7082

Frisian 7089

Galician 7176

Georgian 7565

German 6869

Greek 6976

Greenlandic 7576

Guarani 7178

Gujarati 7185

Hausa 7265

Hebrew 7387

Hindi 7273

Hungarian 7285

Icelandic 7383

Indonesian 7378

Interlingua 7365

Irish 7165

Italian 7384

Japanese 7465

Kannada 7578

Kashmiri 7583

Kazakh 7575

Kirghiz 7589

Korean 7579

Kurdish 7585

Laothian 7679

Latin 7665

Latvian, Lettish 7686

Lingala 7678

Sindhi 8368

Singhalese 8373

Slovak 8375

Slovenian 8376

Spanish 6983

Sudanese 8385

Swahili 8387

Swedish 8386

Tagalog 8476

Tajik 8471

Tamil 8465

Telugu 8469

Thai 8472

Tonga 8479

Turkish 8482

Turkmen 8475

Twi 8487

Ukrainian 8575

Urdu 8582

Uzbek 8590

Vietnamese 8673

Volapük 8679

Welsh 6789

Wolof 8779

Xhosa 8872

Yiddish 7473

Yoruba 8979

Zulu 9085

Appendix 27

Specifications

Power
requirements

Power
consumption

Dimensions
(W x H x D)

Net Weight
(Approx.)

Operating
temperature

Operating
humidity

Laser Semiconductor laser

Signal system PAL/NTSC

Bus Power
Supply (USB)

ANTENNA IN Antenna input, 75 Ω

VIDEO
OUTPUT

COMPONENT /
PROGRESSIVE
SCAN OUTPUT

HDMI OUTPUT
(video/audio)

ANALOG
AUDIO
OUTPUT

DIGITAL
OUTPUT
(COAXIAL)

AC 200-240 V, 50 / 60Hz

11 W

(430 x 35 x 195) mm

1.7 kg

5 °C to 35 °C

5 % to 90 %

DC 5V 0 500 mA

1.0 V (p-p), 75 Ω, sync
negative, RCA jack x 1 / SCART
(TO TV)

(Y ) 1.0 V (p-p), 75 Ω, sync
negative, RCA jack x 1, (Pb)/
(Pr) 0.7 V (p-p), 75 Ω, RCA jack
x 2

19 pin (Type A, HDMI™
Connector)

2.0 Vrms (1 kHz, 0 dB), 600 Ω,
RCA jack (L, R) x 1 / SCART (TO
TV )

0.5 V (p-p), 75 Ω, RCA jack x 1

Trademarks and
Licenses

Manufactured under license from Dolby
Laboratories. Dolby and the double-D symbol
are trademarks of Dolby Laboratories.

HDMI, the HDMI logo and High-Denition
Multimedia Interface are trademarks or registered
trademarks of HDMI licensing LLC.

“DVD Logo” is a trademark of DVD Format/Logo
Licensing Corporation.

DivX®, DivX Certied® and associated logos are
trademarks of DivX, Inc. and are used under
license.

6

Appendix

Design and specications are subject to change
without prior notice.
