LG CU 515 User Manual
L G
C U 5 1 5
push
to
talk
Instantly talk to family, friends and co-workers
talk
L G
C U 5 1 5
push
to
talk
Instantly talk to family, friends and co-workers
L G
C U 5 1 5
push
to
talk
Instantly talk to family, friends and co-workers
Refer to the User Manual for instructions in Spanish.
PTT
Key
PUSH TO TALK GUIDE
The Keys to Push to Talk
Push to Talk (PT T) from AT&T lets you see
whether your family, friends, and co-workers
are available to talk before you call. You can
reach them individually or everyone at once
via a group call, all in an instant. No other
Push to Talk ser vice enables you to do all this.
Left Soft Key
OK Key
Clear & B ack Key
Microphone
Right S oft Key
Navigation Key
Power/End Key
This handset supports centralized corporate
contact management via the Push to Talk
Corporate Administrator website. Contact
your business sales representative, or
www.wireless. att .com/ptt for
more information.
2
PTT
Pointers:
Getting
Started
PTT Helpful Tips
1. Make sure you’re holding the PT T Key down while you talk.
Release the PT T Key when you are finished talking.
2. The microphone is located to the right of the “6” key. Make
sure you aren’t covering it up with your grip.
PTT Key Functions
Screen PTT Key Result
Idle Screen Press PTT Contacts List
Press & Hold PTT History
Contacts List Press & Hold Initiates PTT Call
Connected Press & Hold To Talk
PTT Icon Descriptions
My Availability PTT Contact Availability
Indi vidual: Group:
Available Available Available
PTT Message Silent/Vibrate Silent/Vibrate
Do Not Disturb Do Not Disturb Do Not Disturb
Unavailable Unavailable Unavailable
Invitation in Invitation in
Progress Progress
3
PUSH TO TALK GUIDE
Initializing Push to Talk Service
Your phone offers an exciting new
Push to Talk (PT T) service. The first step
in using the Push to Talk (PTT) service
is initializing the phone.
1. From standby mode, press the PT T Key
on the left side of the phone.
2. A screen will appear asking if you want to
initialize PT T. Press for Yes.
3. You will be asked to register a name in
the PT T system. Enter a name (up to 20
characters) and press .
4. A screen will flash to inform you that the
process of initialization has begun.
Initialization can take several minutes.
When the process is complete, a icon
will appear next to the signal indicator on
your idle screen.
4
Adding a Push to Talk Contact
After initializing PTT, you must add
individuals or groups to your PT T contact
list before you can place a PTT call.
Individuals and group members must
subscribe to the AT&T PTT service.
1. Select the Push to Talk (1) menu and
press .
2. Select Add Contact (2) and press .
3. Enter the name and number and press .
4. The network will check to see if the contact
is a valid PTT subscriber. When confirmed,
an invitation is sent, which the other user
must accept. You will see a icon next to
the new contact name while the invitation
is in progress.
5
