CF360
User Guide
Part 15.21 statement
" Change or Modifications that are not expressly approved by the manufacturer could void
the user's authority to operate the equipment. "
Part 15.105 statement
This equipment has been tested and found to comply with the limits for a class B digital device,
pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a
residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. if this
equipment does cause harmful interference or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected
- Consult the dealer or an experienced radio/TV technician for help.
T-coil statement
- Achieve optimal antenna performance of the phone by
sliding the phone open to make or receive a call.
LIMITED WARRANTY STATEMENT
1. WHAT THIS WARRANTY COVERS:
LG offers you a limited warranty that the enclosed subscriber unit and its enclosed accessories will be
free from defects in material and workmanship, according to the following terms and conditions:
(1) The limited warranty for the product extends for ONE (1) year beginning on the data of purchase
of the product.
(2) The limited warranty extends on to the original purchaser of the product and is not assignable or
transferable to any subsequent purchaser/end user.
(3) This warranty is good only to the original purchaser of the product during the warranty period as
long as it is in the U.S., including Alaska, Hawaii, U.S. Territories and Canada.
(4) The external housing and cosmetic parts shall not be covered under these limited warranty terms.
(5) Upon request from LG, the consumer must provide information to reasonably prove the date of
purchase.
(6) The customer shall bear the cost of shipping the product to the Customer Service Department of
LG. LG shall bear the cost of shipping the product back to the consumer after the completion of
service under this limited warranty.
2. WHAT THIS WARRANTY DOES NOT COVER:
(1) Defects or damages resulting from use of the product i n other than its normal and customary
manner.
(2) Defects or damages from abnormal use, abnormal conditions, improper storage, exposure to
moisture or dampness, unauthorized modifications, unauthorized connections, unauthorized repair,
misuse, neglect, abuse, accident, alteration, improper installation, or other acts which are not the
fault of LG, including damage caused by shipping blown fuses spills of food or liquid.
(3) Breakage or damage to antennas unless caused directly by defects in material or workmanship.
(4) That the Customer Service Department at LG was net notified by consumer of the alleged defect
or malfunction of the product during the applicable limited warranty period.
(5) Products which have had the serial number removed or made illegible.
(6) The limited warranty is in lieu of all other warranties, express or implied either in fact or by
operations law, statutory or otherwise, including, but limited to any implied warranty of
marketability or fitness for a particular use.
(7) Damage resulting from use of non-LG approved accessories.
(8) All plastic surfaces and all other externally exposed parts that are scratched or damaged due to
normal customer use.
(9) Products operated outside published maximum ratings.
3
(10) Products used or obtained in a rental prog ram.
(11) Consumables (such as fuses).
3. STATE LAW RIGHTS:
No other express warranty is applicable to this product. THE DURATION OF ANY IMPLIED
WARRANTIES, INCLUDING THE IMPLIED WARRANTY OF MARKETABILITY, IS LIMITED
TO THE DURATION OF THE EXPRESS WARRANTY HEREIN. LG INFOCOMM INC. SHALL
NOT BE LIABLE FOR THE LOSS OF THE USE OF THE PRODUCT, INCONVENIENCE, LOSS
OR ANY OTHER DAMAGES, DIRECT OR CONSEQUENTIAL, RISING OUT OF THE USE OF,
OR INABILITY TO USE, THIS PRODUCT OR FOR ANY BREACH OF ANY EXPRESS OR
IMPLIED WARRANTY, INCLUDING THE IMPLIED W ARRA NTY OF MAR KETABILITY
APPLICABLE TO THIS PRODUCT. Some states do not allow the exclusive of imitation of incidental
or consequential damages or limitations on how long an implied warranty lasts; so these limitations or
exclusions may not apply to you. This warranty gives you specific legal rights and you may also have
other rights which vary from state to state.
4. HOW TO GET WARRANTY SERVICE:
To obtain warranty service, please call the following web address:
www.lgeservice.com
8
For Your Safety
Important Information
This user guide contains important information on the use and
operation of this phone. Please read all the information
carefully for optimal performance and to prevent any damage
to or misuse of the phone. Any changes or modifications not
expressly approved in this user guide could void your warranty
for this equipment.
Before You Start
Safety Instructions
WARNING! To reduce the possibility of electric shock, do not
expose your phone to high humidity areas, such as the
bathroom, swimming pool, etc.
Always store your phone away from heat. Never store your
phone in settings that may expose it to temperatures less than
32°F or greater than 104°F, such as outside during extreme
weather conditions or in your car on a hot day. Exposure to
excessive cold or heat will result in malfunction, damage
and/or catastrophic failure.
Be careful when using your phone near other electronic
devices. RF emissions from your mobile phone may affect
nearby in adequately shielded electronic equipment. You
should consult with manufacturers of any personal medical
devices such as pacemakers and hearing aides to determine if
they are susceptible to interference from your mobile phone.
Turn off your phone in a medical facility or at a gas station.
Never place your phone in a microwave oven as this will
cause the battery to explode.
IMPORTANT! Please read the TIA SAFETY INFORMATION on
page 78 before using your phone.
Safety Information
Read these simple guidelines. Breaking the rules may be
dangerous or illegal. Further detailed information is given in this
user guide.
] Never use an unapproved battery since this could damage
the phone and/or battery and could cause the battery to
explode.
] Never place your phone in a microwave oven as it will
cause the battery to explode.
] Do not dispose of your battery by fire or with hazardous or
flammable materials.
] Make sure that no sharp-edged items come into contact
with the battery. There is a risk of this causing a fire.
] Store the battery in a place out of reach of children.
] Be careful that children do not swallow any parts such as
rubber plugs (earphone, connection parts of the phone,
etc.). This could cause asphyxiation or suffocation.
9
For Your Safety
] Unplug the power cord and charger during lightning storms
to avoid electric shock or fire.
] When riding in a car, do not leave your phone or set up the
hands-free kit near to the air bag. If wireless equipment is
improperly installed and the air bag is activated, you may be
seriously injured.
] Do not use a hand-held phone while driving.
] Do not use the phone in areas where its use is prohibited.
(For example: aircraft).
] Do not expose the battery charger or adapter to direct
sunlight or use it in places with high humidity, such as a
bathroom.
] Never store your phone in temperatures less than- 4°F or
greater than 122°F.
] Do not use harsh chemicals (such as alcohol, benzene,
thinners, etc.) or detergents to clean your phone. There is a
risk of this causing a fire.
] Do not drop, strike, or shake your phone severely. Such
actions may harm the internal circuit boards of the phone.
] Do not use your phone in high explosive areas as the phone
may generate sparks.
] Do not damage the power cord by bending, twisting, pulling,
or heating. Do not use the plug if it is loose as it may cause
a fire or electric shock.
] Do not place any heavy items on the power cord. Do not
allow the power cord to be crimped as it may cause fire or
electric shock.
] Do not handle the phone with wet hands while it is being
charged. It may cause an electric shock or seriously
damage your phone.
] Do not disassemble the phone.
] Do not place or answer calls while charging the phone as it
may short-circuit the phone and/or cause electric shock or
fire.
] Only use the batteries, antennas, and chargers provided by
LG. The warranty will not be applied to products provided by
other suppliers.
] Only authorized personnel should service the phone and its
accessories. Faulty installation or service may result in
accidents and consequently invalidate the warranty.
] Do not hold or let the antenna come in contact with your
body during a call.
] An emergency call can be made only within a service area.
For an emergency call, make sure that you are within a
service area and that the phone is turned on.
10
For Your Safety
FCC RF Exposure Information
WARNING! Read this information before operating the phone.
In August 1996, the Federal Communications (FCC) of he United
States, with its action in Report and Order FCC 96-326, adopted
an updated safety standard for human exposure to radio
frequency (RF) electromagnetic energy emitted by FCC
regulated transmitters. Those guidelines are consistent with
the safety standard previously set by both U.S. and
international standards bodies.
The design of this phone complies with the FCC guidelines and
these international standards.
CAUTION
Use only the supplied and approved antenna. Use of
unauthorized antennas or modifications could impair call
quality, damage the phone, void your warranty and/or result in
violation of FCC regulations. Do not use the phone with a
damaged antenna. If a damaged antenna comes into contact
with skin, a minor burn may result. Contact your local dealer
for a replacement antenna.
Body-worn Operation
This device was tested for typical body-worn operations with
the back of the phone kept 0.79 inches (2cm) between the
user’s body and the back of the phone. To comply with FCC RF
exposure requirements, a minimum separation distance of 0.79
inches(2cm) must be maintained between the user's body
and the back of the phone. Third-party belt-clips, holsters, and
similar accessories containing metallic components should not
be used. Body-worn accessories that cannot maintain 0.79
inches(2cm) separation distance between the user's body
and the back of the phone, and have not been tested for typical
body-worn operations may not comply with FCC RF exposure
limits and should be avoided.
11
For Your Safety
Vehicle Mounted External Antenna
(optional, if available)
A minimum separation distance of 8 inches (20cm) must be
maintained between the user/bystander and the vehicle
mounted external antenna to satisfy FCC RF exposure
requirements. For more information about RF exposure, visit
the FCC website at www.fcc.gov
FCC Part 15 Class B Compliance
This device and its accessories comply with part 15 of FCC
rules. Operation is subject to the following two conditions:
(1) This device and its accessories may not cause harmful
interference, and (2) this device and its accessories must
accept any interference received, including interference that
may cause undesired operation.
Cautions for Battery
] Do not disassemble.
] Do not short-circuit.
] Do not expose to high temperature: 60°C (140°F).]
] Do not incinerate.
Battery Disposal
] Please dispose of your battery properly or bring to your
local wireless carrier for recycling.
] Do not dispose in fire or with hazardous or flammable
materials.
Adapter (Charger) Cautions
] Using the wrong battery charger could damage your phone
and void your warranty.
] The adapter or battery charger is intended for indoor use
only.
Do not expose the adapter or battery charger to direct sunlight
or use it in places with high humidity, such as the bathroom.
Your Phone
Phone Components
1. Earpiece
2. Left soft key
3. Navigation key
4. Volume keys
5. Send key
6. Alphanumeric keys
7. Display screen
8. OK key
9. Message key
10. Right soft key
11. Task menu key
12. End /Power key
13. Clear key
14. Camera key
15. Microphone
10
Your Phone’s Features
Your Phone
1. Earpiece
2, 10. Left soft key/Right soft key: Each of
these keys perform the functions indicated
by the text on the display immediately
above them.
3. Navigation key: Use for quick access to
phone functions.
4. Volume keys: These keys are used to
control the volume of ringtone in standby
mode and speaker volume during a call.
5. Send key: You can dial a phone number
and answer incoming calls. Press this key
in standby mode to quickly access the most
recent incoming, outgoing and missed calls.
6. Alphanumeric keys: These keys are used
to dial a number in standby mode and to
enter number or characters in edit mode.
7. Display screen: Displays phone status
icons, menu items, web information,
pictures and more in full color.
8. OK key: Short press will launch the WAP
browser. Allows you to select and confirm
menu options.
9. Message key: Use to send either text or
multimedia messages.
11. Task menu key: Multitask
simultaneously with voice and data browse the web, make calls, play games,
send and receive messages, and listen to
MP3s. All at once.
12. End/Power key: Allows you to power
the phone on or off, end calls, or return to
Standby Mode.
13. Clear key: Allows you to delete the
characters entered or return you to the
previous screen.
14. Camera key: Press this key to use the
camera feature. Directly goes to the
camera mode.
15. Microphone: Can be muted during a call
for privacy.
11
Your Phone
Removable memory port
Camera
Headset jack
Task menu key
Advice to the customer
In order to allow better antenna sensitivity LG suggests that you
hold the handset as depicted in the figure below.
Please do not cover the antenna area with your hand during a call
and using a bluetooth connection. It may degrade speech quality.
Side keys
• Control the volume
of ringtone in
standby mode
• Speaker volume
during a call
12
Display Information
Announciator area
Text and graphic
area
Soft key indications
Area Description
First line Displays various icons.
Display messages,
Middle lines
Last line
instructions and any
information that you enter,
such as number to be
dialed.
Shows the functions
currently assigned to the
two soft keys.
Your Phone
13
Your Phone
On-Screen Icons
The table below describes various display
indicators or icons that appear on the phone’s
display screen.
Icon Description
Indicates the strength of the 3G
network signal.
Indicates the strength of the
network signal.
Indicates that GPRS service is
available. Indicates that the EDGE
service is available. Connection
to the EDGE service allows you
to transfer data at a speed of
200Kb/s(depending on network
availability). Check with your
operator for network coverage and
service availability.
Indicates that GPRS service is
available.
Indicates that Flight mode has
Icon Description
Indicates the status of the battery
charge.
Indicates that a call is in progress.
Indicates that the alarm has been
set and is on.
Indicates the Schedule function.
Indicates the receipt of a message.
Indicates the receipt of a
Voicemail.
Indicates that Ring has been set
for alert.
Indicates that Silent has been set
for alert.
Indicates that Vibration has been
set for alert.
Indicates that the speakerphone
has been activated.
Indicates that the Bluetooth®
function has been activated.
been activated.
®
* The Bluetooth
word mark and logos are owned by the Bluetooth SIG, Inc. and any use of
such marks by LG Electronics is under license. Other trademarks and trade names are those of
their respective owners. Bluetooth QD ID B013133
14
Your Phone
Icon Description
Indicates that the data is being
transmitted using a Bluetooth
connection.
Indicates that the connection to a
headset with Bluetooth has been
activated.
Indicates that the connection to a
hands-free with Bluetooth has been
activated.
Indicates that the connection to a
stereo Bluetooth device has been
activated.
Indicates that the connection to a
hand-free & stereo with Bluetooth
has been activated.
Indicates that the Multitasking
function has been activated.
Indicates that the TTY has been set
and is on.
Indicates that the connection to a
headset with Bluetooth has been
activated.
Indicates that the phone is accessing
the WAP or data service.
Icon Description
Indicates that the status of PTT is
Available .
Indicates that the status of PTT is
Unavailable.
Indicates that the status of PTT is Do
Not Disturb.
Indicates a PTT Message is waiting
in the PTT Menu.
15
Getting Started
Installing the SmartChip
When you subscribe to a cellular network,
you are provided with a plug-in SmartChip
loaded with your subscription details, such as
your PIN, any optional services available and
many others.
n
Important!
The plug-in SmartChip and its contacts can be
easily damaged by scratches or bending, so be
careful when handling, inserting or removing
the card. Keep all SmartChips out of the reach
of small children.
1. If necessary, switch off the phone by
holding down the [END] key until the
power-off image appears.
2. Remove the battery. To do so:
16
3. Slide the SmartChip into the SmartChip
socket so that it locks the card into place.
Make sure that the notched corner is at the
top left and the gold contacts of the card
face into the phone.
n
Note
When you need to remove the SmartChip, slide
it, as shown, and take it out of the socket.
Getting Started
4. To insert the battery, align the golden
contacts of the battery with the
corresponding connectors on the battery
compartment. Press down on the opposite
end of the battery until it snaps into place.
5. Attach back cover by sliding it up into
position until it clicks.
Charging the Battery
Use of unauthorized accessories could
damage your phone and void your warranty.
To use the travel charger provided with your
phone:
1. With the battery in position in the phone,
connect the lead from the travel charger
to the bottom of the phone. Check that
the arrow on the lead connector is facing
towards the front of the phone.
2. Connect the travel charger to a standard AC
wall outlet. Only use the travel charger that
comes with the package.
n
Warning
The travel charger must be unplugged before
you remove the battery, otherwise, the phone
could be damaged.
Tip!
You need to put the battery first before
charging.
17
Getting Started
3. When a phone has been charged fully,
disconnect the travel charger from the
phone by pulling the connector out.
n
Note
]
If your phone is powered on while charging,
you’ll see the bars on the battery indicator
icon cycle.
When the battery is fully charged, color of it
is changed from yellow to green.
]
If the sufficient power is not supplied on USB
Port, recharging through USB would not work
properly. This matter would be caused by the
problems on PC or USB Hub, so we suggest
you to contact producers.
If the battery fails to charge completely:
]
After turning the phone on and off, please
attempt to recharge the battery.
]
After detaching and reattaching the battery,
please attempt to recharge the battery.
18
Tip!
When the battery is fully charged, color of it
is changed from yellow to green.
Memory card slot
The CF360 supports the microSD memory
card. The memory card can be inserted into
the side of the CF360 device. You can use this
card to save data files such as MP3 songs.
n
Note
Always insert/remove the memory card with the
handset power off.
The gold connectors must be face up and
inserted first into the TransFlash memory
card slot.
Use only memory cards that have been
approved by the manufacturer. Some memory
cards might not be compliant with the handset.
Getting Started
Inserting the memory card
Insert the memory card into the slot until the
memory card is fully inserted into the slot, as
shown in the figure below:
n
Note
The gold connectors must be face up and
inserted first into the memory card slot.
Removing the memory card
1. Push the memory card down into the slot
with the tip of your finger.
2. Carefully pull the memory card out of slot.
Turning Your Phone On and
Off
1. Hold down the [END] key until the
phone switches on.
2. If the phone asks for a PIN, enter the PIN
and press the
The phone searches for your network and
after finding it goes to the idle screen as
illustrated below. From the idle screen, you
can make or receive a call.
n
Note
The display language is preset to Automatic at
the factory. To change the language, use the
Languages menu option (Menu 9.2.6).
key.
19
Getting Started
3. When you wish to switch the phone off,
hold down the [END] key until the
power-off image displays.
Access Codes
You can use the access codes described
in this section to avoid unauthorized use
of your phone. The access codes can be
changed by using the Change Codes feature
(Menu 9.6.4).
Security code (4 digits)
The security code protects the unauthorized
use of your phone. The default security code
is set to ‘0000’ and the security code is
required to delete all phone entries and to
activate the Restore Factory Settings menu.
The security code default setting can be
modified from the Security Settings menu.
20
Barring Password
The barring password function is required
when you use the Call Barring function.
The password is obtained from the service
provider when you subscribe to this function.
General Functions
Making a Call
1. Make sure your phone is powered on.
2. Enter a phone number including the area
code. To edit a number on the display
screen, simply press the
erase one digit at a time.
]
Press and hold the key to erase
the entire number.
3. Press the
number.
4. When finished, press the
[SEND] key to call the
Making a Call by Send Key
1. Press the [SEND] key, and the most
recent incoming, outgoing and missed
phone numbers will be displayed.
2. Select the desired number by using the
navigation key.
3. Press the
[SEND] key.
key to
[END] key.
Making International Calls
1. Press and hold the key and the
international access character ‘+’ will
appear.
2. Enter the country code, area code, and the
phone number.
3. Press the
[SEND] key.
Ending a Call
When you have finished a call, press the
[END] key.
Making a Call From the Contacts
You can store names and phone numbers
dialed frequently in the SmartChip as well as
in the phone memory known as the Contacts.
You can dial a number by simply selecting a
name in the contacts and pressing the
[SEND] key.
21
General Functions
Adjusting the Volume
During a call, if you want to adjust the
earpiece volume, use the side keys of the
phone.
In idle mode, you can adjust the ring volume
using the side keys.
Answering a Call
When you receive a call, the phone rings
and the flashing phone icon appears on the
screen. If the caller can be identified, the
caller’s phone number (or name if stored in
your Address Book) is displayed.
1. Open the Flip and press the
key or the left soft key to answer an
incoming call. If Any Key has been set as
the answer mode (Menu 9.5.4), any key
press will answer a call except for the
[END] key or the right soft key.
[SEND]
n
Note
]
If Open Flip has been set as the Answer
Mode (Menu 9.5.4), you do not need to press
any key. You can answer the call simply by
opening the flip.
2. End the call by closing the phone or
pressing the [END] key.
n
Notice
You can answer a call while using the Address
Book or other menu features.
Vibrate Mode (Quick)
Vibrate Mode can be activated by pressing
and holding down the [Star] key.
Signal Strength
If you are inside a building, being near a
window may give you better reception. You
can see the strength of your signal by the
signal indicator on your phone’s display
screen.
22
General Functions
Entering Text
You can enter alphanumeric characters by
using the phone’s keypad. For example,
storing names in the Address Book, writing a
message, or creating scheduling events in the
calendar all require entering text.
The following text input methods are
available on the phone.
T9 Mode
This mode allows you to enter words with
only one keystroke per letter. Each key on the
keypad has more than one letter. The T9 mode
automatically compares your keystrokes with
an internal linguistic dictionary to determine
the correct word, thus requiring far fewer
keystrokes than the traditional ABC mode.
ABC Mode
This mode allows you to enter letters by
pressing the key labeled with the required
letter once, twice, three or four times until the
letter is displayed.
123 Mode (Numbers Mode)
Type numbers using one keystroke per
number. To change to 123 mode in a text
entry field, press key until 123 mode
is displayed.
A long press changes the mode to 123.
Symbolic Mode
This mode allows you to enter special
characters.
n
Note
You can select a different T9 language from the
menu option. The default setting on the phone
is T9 disabled mode.
Changing the Text Input Mode
Change the text input mode by pressing
. You can check the current text input
mode in the upper right corner of the screen.
23
General Functions
Using the T9 Mode
The T9 predictive text input mode allows you
to enter words easily with a minimum number
of key presses. As you press each key, the
phone begins to display the characters that
it thinks you are typing based on a built-in
dictionary. As new letters are added, the word
changes to reflect the most likely candidate
from the dictionary.
1. When you are in the T9 predictive text
input mode, start entering a word by
pressing keys
key per letter.
]
The word changes as letters are typed
- ignore what’s on the screen until the
word is typed completely.
]
If the word is still incorrect after typing
completely, press the [Star] key
once or more to cycle through the other
word options.
]
If the desired word is missing from the
word choices list, add it by using the ABC
mode.
24
to . Press one
2. Enter the whole word before editing or
deleting any keystrokes.
3. Complete each word with a space by
pressing the
navigation key.
To delete letters, press
down to erase the letters continuously.
n
Notice
To exit the text input mode without saving your
input, press the
key or the right
. Press and hold
[END] key.
Using the ABC Mode
Use the keypad keys to enter your text.
1. Press the key labeled with the required
letter:
]
Once for the first letter
] Twice for the second letter
]
And so on
2. To insert a space, press the key
once. To delete letters, press the
key. Press and hold down the key to
erase the letters continuously.
n
Note
Refer to the table below for more information
on the characters available using the keys.
Characters in the Order Display
Key
Upper Case Lower Case
1 . , ‘ @ ? ! - : / 1 . , ‘ @ ? ! - : / 1
2 A B C 2 a b c 2
3 D E F 3 d e f 3
4 G H I 4 g h i 4
5 J K L 5 j k l 5
6 M N O 6 m n o 6
7 P Q R S 7 p q r s 7
8 T U V 8 t u v 8
9 W X Y Z 9 w x y z 9
0
Space Key,
0 (Long press)
Space Key,
0 (Long press)
General Functions
Using the 123 (Numbers) Mode
The 123 Mode enables you to enter numbers
in a text message (a telephone number, for
example) more quickly.
Press the keys corresponding to the required
digits before manually switching back to the
appropriate text entry mode.
Using the Symbol Mode
The Symbol Mode enables you to enter
various symbols or special characters.
To enter a symbol, press the
[Star] key.
Use the navigation keys to select the desired
symbol and press the [OK] key.
T9 dictionary
The T9 dictionary is a feature that allows the
user to add any unique or personal words
to the T9 standard language database. The
T9 dictionary function can be selected from
the Text Entry Settings sub menu under
the Options soft key menu. Within the T9
dictionary function, the user can add, modify,
delete or reset personal words.
25
Selecting Functions and Options
Your phone offers a set of functions that allow you to customize the phone. These functions are
arranged in menus and sub-menus, accessed via the two soft keys marked the left soft
key and the right soft key. Each menu and sub-menu allows you to view and alter the
settings of a particular function.
Soft key functions vary depending on the mode of the phone. The label on the bottom of the display
screen immediately above the soft keys indicates the current function.
Press the left soft key
to access the available
Menu.
26
Press the right soft key
to access the available
Options.
A short press will launch the WAP browser. A short
press allows you to select and confirm menu options.
In-Call Menu
Your phone provides a number of control
functions that you can use during a call. To
access these functions during a call, press the
right soft key [Options].
During a Call
The menu displayed on the handset screen
during a call is different from the default main
menu displayed when in idle screen, and the
options are described below.
Making a Second Call
You can select a number you wish to dial
from the Address Book to make a second call.
Press the right soft key then select Contacts.
Swapping Between Two Calls
By using three methods, you can switch
between two calls.
1. Press the
2. Press the left/right navigation key.
3. Press the right soft key and then select
“Swap Calls”.
[Send] key.
Answering an Incoming Call
To answer an incoming call when the handset
is ringing, simply press the [SEND] key.
The handset is also able to warn you of an
incoming call while you are already on a call.
A tone sounds in the earpiece, and the display
will show that a second call is waiting. This
feature, known as Call Waiting, is only
available if your network supports it.
If Call Waiting is on, you can put the first
call on hold and answer the second call, by
pressing the
[SEND] key.
Rejecting an Incoming Call
You can reject an incoming call without
answering by simply pressing the
[END] key.
During a call, you can reject an incoming call
by pressing the
[END] key.
27
In-Call Menu
Muting the Microphone
You can mute the microphone during a call by
pressing the left soft key [Mute]. The handset
can be unmuted by pressing the left soft key
[Unmute]. When the handset is muted, the
caller cannot hear you, but you can still hear
the caller.
Using the Speakerphone
You can use the integrated Speakerphone
during a call by pressing the key. The
loudspeaker is automatically deactivated
when you end the call.
n
Warning
Due to higher volume levels, don’t place the
phone near your ear while the speakerphone
is enabled.
28
Conference Calls
The conference service provides you with the
ability to have a simultaneous conversation
with more than one caller. The conference
call feature can be used only if your network
service provider supports this feature.
A conference call can only be set up when
you have one call active and one call on hold,
meaning both calls must have been answered.
Once a conference call is set up, calls may
be added, disconnected or separated (that
is, removed from the conference call but
still connected to you) by the person who
set up the conference call. These options
are all available from the In-Call menu. The
maximum number of callers in a conference
call is five. Once started, you are in control
of the conference call, and only you can add
calls to the conference call.
In-Call Menu
Making a Second Call
You can make a second call while currently
on a call simply by entering the second
number and pressing the
When the second call is connected, the first
call is automatically placed on hold. You can
swap between calls, by pressing the
[SEND] key.
[SEND] key.
Setting Up a Conference Call
To set up a conference call, place one call on
hold, conference in the second active call by
pressing the right soft key and select the Join
Calls sub menu option from the Conference
Call menu.
Activate the Conference Call
on Hold
To activate a conference call on hold, press
the [SEND] key.
Adding Call to the Conference
Call
To add a call to an existing conference call,
press the right soft key, and then select the
Join Calls sub menu from the Conference
Call option.
Private Call in a Conference Call
To have a private call with one caller from a
conference call, press the right soft key and
select the Private Menu from the Conference
Call option. When the numbers of the callers
are displayed, select the one you wish to
speak in private.
Ending a Conference Call
Currently active conference call can be
disconnected by pressing the [END] key.
29
In-Call Menu
Video Share Calling
Making and Answering a Video
Share Call
You can make or answer a Video Share call
with other 3G video phones. In order to start
a Video Share call, both sides must have 3G
Video Share capable phone and both must be
in 3G coverage area.
n Note
Before you start a Video Share Call you must
check the following:
• Phone must be in a AT&T 3G service area.
• Icon should be present next to 3G sign on top
left corner of the screen.
30
To use Video Share follow these steps:
1. Make a phone call by dialing a number, or
selecting a number either from contact list
or recent call list.
From Recent call or Contact list, you
can also directly make a Video Share by
selecting [Options] > [Video Share Call] and
selecting Video Type (Live or Recorded). In
this case skip step 2-3.
2. A few seconds after the connection is
established, “Video Share Ready” prompt
will appear on the screen given other party
is ready to use Video Share service.
3. To start Video Share with other party,
you can press Video key
Camera key and select Video type (Live or
Recorded).
or
In-Call Menu
n Note
The Speakerphone will be automatically
activated when a Video Share session begins,
unless a hands-free (Bluetooth or wired head
set) is connected.
- Live: You can share a real-time video
stream with the other party while having a
conversation.
- Recorded: You can share a pre-recorded
video clip with the other party while having a
conversation.
(Note that H.263, MPEG4 video formats in
176x144 siez are supported)
4. If the other party press [Accept]
key, the Video Share will begin. (After
accepting, it may take several seconds
before actual Video Share starts)
During the Video Share, you can do followings
via
[Options] key.
- Audio to Bluetooth/Audio to Phone:
When Audio to Bluetooth is selected, you
can have a conversation using Bluetooth.
When Audio to Phone is selected, you
can have a conversation using either
speakerphone or headset.
- Stop Video Share: You can stop video
sharing and proceeds with voice call only by
selecting Stop Video Share.
- Brightness: You can adjust the brightness
of the screen by selecting Brightness.
- Mute/Unmute: You can mute/unmute the
microphone by selecting mute/unmute.
31
In-Call Menu
- Record Video Share/Stop Recording:
You can start recording the live video by
selecting ‘Record Video Share’. Once you are
recording the video, you can stop recording
by selecting ‘Stop Recording’.
- End Call: You can end phone call by
selecting ‘End Call’.
(Note: Video Share will stop as well)
- Hold Call: You can hold phone call by
selecting ‘Hold Call’. (Note: Video Share will
stop when you select ‘Hold Call’)
During the Video Share session, you can turn
on/off speakerphone using Spk. off / Spk. on
.
key
You can record a current video clip via Options
menu, and the recorded video will be saved in
[My stuff] – [Video].
32
5.1. You can stop Video Share call and
proceed to voice call by
1. Press Stop Key
2. Select [Opton] > [Stop Video share]
5.2. You can End Voice call along with Video
Share call by
1. Press End Key
2. Select [Option] > [End Call]
n
Note
1. A Video Share Call will be terminated in the
following cases:
• When trying to make a conference call /
second call during a call.
• When voice call is placed on hold.
• When the voice call is disconnected.
• When moving out of a AT&T 3G service
area.
• When the network connection is poor.
Loading...
