Owner's Manual
LCD PROJECTOR
Please read the safety information carefully before using the product.
BG630
BG650
www.lg.com (Brazil : www.lge.com)
2 LICENSE
LICENSE
Manufactured under license from Dolby Laboratories. "Dolby" and the double-D symbol are trademarks of Dolby Laboratories.
ABOUT DIVX VIDEO: DivX® is a digital video format created by
DivX, LLC, a subsidiary of Rovi Corporation. This is an official DivX Certified® device that plays DivX video. Visit divx.com for more information and software tools to convert your files into
DivX videos.
ABOUT DIVX VIDEO-ON-DEMAND: This DivX
Certified® device must be registered in order to play purchased
DivX Video-on-Demand (VOD) movies. To obtain your registration code, locate the DivX VOD section in your device setup menu. Go to vod.divx.com for more information on how to complete your registration.
DivX Certified® to play DivX® video up to HD 1080p, including premium content.
DivX®, DivX Certified® and associated logos are trademarks of
Rovi Corporation or its subsidiaries and are used under license.
Covered by one or more of the following U.S. patents:
7,295,673; 7,460,668; 7,515,710; 7,519,274
The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
This device meets the EMC requirements for home appliances (Class B) and is intended for home usage. This device can be used in all regions.
NOTE
yyThe product images and On-Screen Display (OSD) in this manual are examples to help you understand how to operate the product, so they may be different from the actual product.
SAFETY PRECAUTIONS |
3 |
SAFETY PRECAUTIONS
Please take note of the safety instructions to prevent any potential accident or misuse of the product.
yySafety precautions are given in two forms, i.e. Warning and Caution as detailed below.
WARNING : Failure to follow the instructions may cause serious injury and even death.
WARNING (HOT SURFACE. DO NOT TOUCH.)
: Violating this instruction may cause burns.
CAUTION : Failure to follow the instructions may cause injury to persons or damage to the product.
yyRead the owner's manual carefully and keep it handy.
WARNING/CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrowheadWA symbol, within anRIS equilateral triangle, is intended to alert the user
to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
|
The exclamation point within |
ION |
an equilateral triangle is |
OCK |
intended to alert the user to |
|
the presence of important |
|
operating and maintenance(servicing) |
|
instructions in the literature accompa- |
|
nying the appliance. |
WARNING/CAUTION
-TO REDUCE THE RISK OF FIRE AND ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO
RAIN OR MOISTURE.
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Indoor Installation
WARNING
yyDo not place the product in direct sunlight or near heat sources such as radiators, fires, stoves, etc.
- This may cause fire.
yyDo not place inflammables such as flammable spray near the projector. - This may cause fire.
yyDo not allow children to cling to or climb up to the projector.
- This may cause the projector to fall, causing injury or death.
yyDo not place the product directly on a carpet, rug or place where ventilation is restricted such as a book shelf or closet.
- This may cause the product's internal temperature to rise and cause fire.
yyDo not place the product close to sources of steam or oil such as a humidifier or kitchen counter.
- This may cause fire or electric shock.
4 SAFETY PRECAUTIONS
yyDo not place the product where it might be exposed to dust.
- This may cause fire.
yyDo not use the product in a damp place, such as a bathroom or a place exposed to the wind and rain, where it is likely to get wet.
- This may cause fire or electric shock.
yyDo not allow a tablecloth or curtain to block the vents.
- This may cause the internal temperature of the product to rise and cause fire.
yyWhen the projector is in use, make sure that the air inlet (Dust filter) at the bottom of the product is not blocked.
yyThe distance between the projector and the wall should be more than
30 cm for ventilation purposes.
- Otherwise, this may cause the internal temperature of the projector to rise and cause a fire.
CAUTION
yyWhen installing the projector on a table, be careful not to place it near the edge.
- The projector may fall, causing injury to persons or damage to the projector. Make sure that you use a cabinet or stand that fits the projector.
yyTurn off the projector, disconnect the power supply, and remove all connections before moving the projector.
- A damaged cord may cause a fire or an electric shock.
yyDo not place the product on an unstable or vibrating surface such as a wobbly shelf or a slope.
- It may fall or flip and cause injury.
yyBe careful not to tip or drop the product over when connecting external devices to the product.
- This may cause injury to persons or damage to the product.
Power
WARNING
yyThe grounding wire should be connected.
- Be sure to connect the grounding wire to avoid damage to the product or an electric shock when there is a short circuit.
If it is not possible to ground the unit, purchase a circuit breaker and connect the product to its wall outlet. Do not try to ground the product to the gas pipe, water pipe, lightning rod, or telephone line, etc.
yyThe power plug should be inserted fully into the power outlet.
- An unstable connection may cause fire.
yyDo not place heavy objects on the power cord.
- This may cause fire or electric shock.
yyNever touch the power plug with a wet hand.
-This may cause an electric shock. yyDo not plug too many devices into
one multi-power outlet.
-This may cause fire due to the power outlet overheating.
yyRemove dust or contaminants around power plug pins or wall outlets.
- Failure to do so may cause fire. yyTo turn off the main power, remove the power plug, which should be
positioned so it is easy to access for operation.
|
|
|
|
SAFETY PRECAUTIONS |
|
5 |
|
yyTo prevent damage to lamp, unit must |
When in Use |
|
|||||
|
remain plugged in for approximately |
|
|
|
|
|
|
|
3 minutes after power down to allow |
|
WARNING |
|
|
||
|
for proper cooldown. |
yyDo not place anything containing |
|
||||
|
|
|
|
||||
|
|
|
|
liquid on top of the projector, such as |
|||
|
CAUTION |
|
|||||
|
|
|
a vase, flower pot, cup, cosmetics, or |
||||
yyHold the plug firmly when unplugging. |
|
||||||
|
medicine; or ornaments, candles, etc. |
||||||
|
- A broken wire in the cord may cause |
|
- This may cause fire, an electric |
|
|||
|
fire. |
|
shock, or injury due to falling. |
|
|||
yyEnsure the power cord and plug are |
yyIn the event that there is a big impact |
||||||
|
not damaged, modified, severely |
|
to the projector or the cabinet is dam- |
||||
|
bent, twisted, pulled, sandwiched, |
|
aged, switch it off, unplug it from the |
|
|||
|
or hot. Do not use the product if the |
|
wall outlet and contact an authorized |
||||
|
power outlet is loose. |
|
service center. |
|
|||
|
- This may cause fire or electric |
|
- Otherwise, this may cause fire or an |
||||
|
shock. |
|
electric shock. |
|
|||
yyKeep the power cord away from any |
yyDo not insert pieces of metal, such |
|
|||||
|
heating devices. |
|
as coins, hairpins, or metal debris, or |
||||
|
- The cord coating may melt and |
|
flammable materials, such as paper |
|
|||
|
cause fire or electric shock. |
|
or matches, into the projector. |
|
|||
yyPlace the projector where people will |
|
- This may cause fire or electric |
|
||||
|
not trip over step on the power cord |
|
shock. |
|
|||
|
to protect the power cord and plug |
yyIn the event that liquid or a foreign |
|
||||
|
from any damage. |
|
object falls into the projector, please |
|
|||
|
- This may cause fire or electric shock. |
|
switch it off and unplug it from the |
|
|||
yyDo not turn the projector on or off by |
|
wall outlet |
|
||||
|
plugging in the power plug or unplug- |
|
and contact an LG Electronics Ser- |
|
|||
|
ging it from the wall outlet. |
|
vice Center. |
|
|||
|
(Do not use the power plug as a |
|
- Otherwise, this may cause a fire or |
|
|||
|
switch.) |
|
an electric shock. |
|
|||
|
- This may cause an electric shock or |
yyMake sure that a child does not swal- |
|||||
|
product malfunction. |
|
low the batteries when you replace |
|
|||
yyDo not insert a conductor into the other |
|
the old remote control batteries with |
|
||||
|
side of the wall outlet while the power |
|
new ones. Keep batteries out of the |
|
|||
|
plug is inserted into the wall outlet. |
|
reach of children. |
|
|||
|
In addition, do not touch the power |
|
- If a child swallows a battery, consult |
||||
|
plug immediately after it is discon- |
|
a doctor immediately. |
|
|||
|
nected from the wall outlet. |
yyNever open any cover on the projec- |
|
||||
|
- This may cause an electric shock. |
|
tor. There is a high risk of electric |
|
|||
yyOnly use the official power cord pro- |
|
shock. |
|
||||
|
vided by LG Electronics. Do not use |
yyDo not look directly into the lens when |
|||||
|
other power cords. |
|
the projector is in use. The strong |
|
|||
|
- This may cause fire or an electric shock. |
|
light may damage your eyes. |
|
6 SAFETY PRECAUTIONS
yyWhen the lamp is on or has just been turned off, avoid touching the air vent or lamp, because these will be very hot.
yyIf there is a gas leak, do not touch the wall outlet. Open the window for ventilation.
-A spark may cause a fire or burn. yyNever touch the product or power
cord during thunder or lightning.
-This may cause an electric shock. yyDo not use the projector near elec-
tronic devices that generate a strong magnetic field.
yyDo not wear the plastic package used to pack the projector around your head.
-This may cause suffocation.
yyDo not keep your hand on the projector for a long time when it is running. yyWhen you play a game by connecting a game console to a projector, it
is recommended that you maintain a distance of more than four times the diagonal length of the screen.
yyMake sure that the length of connecting cable is long enough.
- Otherwise, the product may fall, causing personal injury or damage to the product.
yyDo not insert anything into or cover up the exhaust vents.
WARNING
CAUTION
yyDo not place a heavy object on the product.
- It may fall down and cause physical injury.
yyBe careful to protect the lens from heavy impact during transportation.
yyDo not touch the lens of the projector. The lens may be damaged.
yyDo not use any sharp tools on the projector, such as a knife or hammer, because this may damage the casing.
yyIn the event that no image appears on the screen or no sound is heard, stop using the projector. Please switch off the projector, unplug it from the power outlet and contact the LG Electronics Service Center.
- It may cause a fire or an electric shock.
yyDo not drop an object onto the projector or apply heavy pressure to it.
- This may cause injury to persons or product malfunction.
yyIt is recommended that you maintain a distance of more than 5-7 times the diagonal length of the screen between your eyes and the screen.
- If you watch the screen at a close distance for a long time, your eyesight may become worse.
yyDo not touch the lens when using the projector because it is very hot.
- It may cause burns.
SAFETY PRECAUTIONS |
7 |
Cleaning
WARNING
yyDo not spray the projector with water when cleaning. Do not allow water to get into the product or do not allow it to get wet.
- This may cause fire or an electric shock.
yyIn the unlikely event of smoke or a strange smell coming out from the projector, switch off the projector, unplug it from the power outlet and contact our service center.
- Otherwise, this may cause fire or an electric shock.
yyUse an air spray or soft cloth or cotton swab moistened with a lens cleaning chemical or alcohol to remove dust or stains on the front projection lens.
CAUTION
yyContact your seller or the Service Center once a year to clean the internal parts of the projector.
- If you do not clean the contaminated interior of the projector for a long time, there may be a fire or product malfunction.
yyWhen cleaning plastic parts such as the projector case, unplug the power first and wipe with a soft cloth. Do not spray with water or wipe with a wet cloth. When cleaning the plastic parts, such as the projector case, do not use cleanser, automobile or industrial shiner, abrasive or wax, benzene, alcohol, etc., which can damage the product.
- This can cause fire, an electric shock or product damage (deformation, corrosion and damage).
Others
WARNING
yyOnly a qualified technician can disassemble or modify the projector. For inspection, adjustment, or repair, contact your seller or our service center. - Otherwise, this may cause fire or an electric shock.
yyDo not charge the battery using any devices other than the one provided with the product.
- This may cause damage to the battery or fire.
yyDispose of the used battery properly. -Failure to do so may cause explosion or fire. The correct method of disposal may vary depending on your country or region. Dispose of the battery pack according to the appropriate instructions.
yyDo not throw or disassemble the battery.
-This may cause fire or explosion due to damage to the battery.
yyAlways use batteries approved and certified by LG Electronics.
- Failure to do so may cause fire or explosion.
yyLamp contains mercury and as such must be disposed of according to local, state and federal laws.
yyDo not store the battery near metallic objects, such as keys and paper clips.
- Excess current may cause a rapid increase in temperature, resulting in fire or burns.
yyDo not store the battery near any heat source, such as a heater.
- This may cause fire or product malfunction.
8 SAFETY PRECAUTIONS
yyDo not store it at temperatures higher than 60 °C or in high humidity.
-This may cause explosion or fire. yyKeep the battery out of reach of
children.
-Failure to do so may cause personal injury or product malfunction.
yyMake sure that the battery is installed correctly.
- Failure to do so may cause explosion or fire.
yyThe battery contains lithium-ion, so it must be handled with care.
- Failure to do so may cause explosion or fire.
yyMake sure you use the same type of battery for replacement.
yyIncorrect battery replacement may cause fire.
CAUTION
yyDo not mix new batteries with old batteries.
- This may cause fire or an electric shock caused by overheating and leakage.
yyUnplug the power cord if the projector is not used for a long period.
- Accumulated dust may cause an electric shock due to overheating, ignition, poor insulation, or fire due to a short circuit.
yyOnly use the specified type of battery. - Burst or leaking batteries may cause fire or an electric shock.
CONTENTS 9
CONTENTS
LICENSE |
2 |
SAFETY PRECAUTIONS |
3 |
PREPARATION |
10 |
Accessories |
10 |
Optional Accessories |
11 |
Part names |
12 |
-- Main body |
12 |
-- Connecting Part |
13 |
Projector status indicator |
14 |
Installation |
15 |
-- Installation Precautions |
15 |
-- Projection Distance per Screen Size 16
-- Kensington Security System |
17 |
REMOTE CONTROL |
18 |
WATCHING WITH THE |
|
PROJECTOR |
20 |
Watching with the Projector |
20 |
-- Turning on the Projector |
20 |
-- Focus and Position of the Screen |
|
Image |
20 |
-- Watching with the Projector |
20 |
Do not turn off the projector |
21 |
-- Do not turn off the projector |
21 |
-- Be careful when replacing the lamp |
21 |
-- Purchasing a replacement lamp |
21 |
-- Disposing of the lamp |
21 |
Additional Options |
22 |
-- Adjusting the Aspect Ratio |
22 |
-- Using the Keystone Function |
23 |
-- Using the Input List |
23 |
-- Blank Function |
24 |
Using the Quick Menu |
24 |
ENTERTAINMENT |
25 |
-- Wireless Display Setup |
|
(Notebook) |
25 |
-- Wireless Display Setup |
|
(Moblie phone) |
25 |
My media |
26 |
-- Connecting a USB Device |
26 |
-- Removing a USB Device |
26 |
-- Watching the Videos |
28 |
-- Viewing the Photos |
35 |
-- Listening to Music |
37 |
-- Viewing the Files |
39 |
CUSTOMIZING SETTINGS |
41 |
Settings |
41 |
PICTURE Settings |
42 |
AUDIO Settings |
46 |
TIME Settings |
47 |
OPTION Settings |
48 |
CONNECTING EXTERNAL |
|
DEVICES |
50 |
Connecting HD Receiver, DVD, |
|
or VCR Player |
51 |
-- HDMI connection |
51 |
-- HDMI to DVI Connection |
51 |
Connecting PC |
52 |
-- RGB Connection |
52 |
-- RGB to DVI Connection |
52 |
Connecting to the AV INPUT |
53 |
-- AV Connection |
53 |
-- Component Connection |
53 |
Connecting Headphones |
54 |
MAINTENANCE |
55 |
Cleaning |
55 |
-- Cleaning the Lens |
55 |
-- Cleaning the Projector Case |
55 |
-- Cleaning the Air Inlet and Outlet |
55 |
Replacing the lamp |
56 |
SERIAL COMMUNICATION |
|
FUNCTION |
57 |
Using Serial Communication |
57 |
Establishing Serial Communication |
57 |
Communication Protocol |
58 |
Key Code |
65 |
SPECIFICATIONS 66
10 PREPARATION
PREPARATION
Accessories
Check the accessories provided with the product.
The picture may be different from the actual product.
MARK
SOUND
TIMER
SETTINGS
Remote Control |
Owner's Manual |
eZ-net program CD |
|
AAA battery |
|||
|
|
Computer Cable |
Power Cord |
Owner's Manual CD |
yyWhen connecting a cable to the HDMI or USB port, be sure to use the jack that fits into the USB/HDMI port.
Use a standard sized jack.
PREPARATION 11
Optional Accessories
To purchase optional accessories, visit an electronics store or online shopping site or contact the retail store where you purchased the product.
Without prior notice, optional extras are subject to change in order to improve the performance of the product, and new optional accessories may be added.
Projection Screen |
HDMI Cable |
Replacement lamp |
Video Cable |
Audio Cable |
LAN cable |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
RGB to Component Cable |
Component Cable |
RS-232C Cable |
DVI to HDMI Cable
12 PREPARATION
Part names
*The projector is manufactured using high-precision technology. You may, however, see tiny black dots and/or bright colored dots (red, blue or green) that continuously appear on the projector screen. This is a normal result of the manufacturing process and does not indicate a malfunction.
Main body
Control Panel
S
Zoom ring |
Focus
Ring
Lens2
Vent1
Bottom
Air inlet
( Air filter)
Button |
Description |
(Power) |
Turns the projector on or off. |
S (Settings) |
Selects or closes settings. |
, , , |
Moves between menus and changes the settings. |
|
( , button: The volume can be adjusted according |
|
to the input mode.) |
(OK) |
Shows the current mode and saves changes to the settings. |
1 Due to the high temperature of the vent area, do not get close to the vent area.
2Do not touch the lens while using the projector. The lens may be damaged.
NOTE
yyAir inlet ( Air filter)
It prevents dust or foreign objects from entering the product.
Clean the Air filter regularly. If the filter is damaged, replace it with a new one.
PREPARATION 13
Connecting Part
RS-232C
AUDIO IN
RGB IN2 (PC1/DVI)(PC2)
RGB OUT |
HDMI/DVI IN |
USB
RGB IN1
LAN
RGB |
RGB IN 2 |
(PC1/DVI) (PC2) |
HDMI/DVI |
USB |
AUDIO IN |
||||
|
|
|
|
LAN |
RGB OUT |
RS 232C |
|
|
|
|
|
|
Speaker |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
AC IN Kensington Security AUDIO OUT |
VIDEO |
|||||||
|
System Connector |
|
|
|
|
|
|
|
|
R-AUDIO-L |
|||||||
|
|
|
14 PREPARATION
Projector status indicator
Activity Indicator

|
Projector status indicator |
Off |
Power cable disconnected. |
Red |
STAND-BY. (Power standby) |
Green |
Running state |
Orange |
High temperature warning |
|
Turn off the projector and check its ventilation holes. |
Red (blinking) |
Turn off power to the lamp and cool down the lamp. |
|
The projector is being turned off. |
Green (blinking) |
Lamp cooling until the lamp is turned on. |
|
The projector is being turned on. |
Orange (blinking) |
The projector is turned off due to high temperature. |
Red, Orange |
A problem related to projector lamp or lamp occurs. |
(switching) |
Turn on the projector again after waiting for suf- |
|
ficient time. |
|
If this indicator is blinking in red again, contact |
|
the nearest LG Electronics Service Center. |
Green, Orange |
The projector is turned off because the internal |
(switching) |
fan is not working. |
|
Please contact the nearest service center. |
Red, Green (switching) |
lamp case open warning |
Red, Green, Orange |
lamp worn-out warning |
(switching) |
|
Red, Orange, Green, |
iris initialize fail |
(switching) |
|
PREPARATION 15
Installation
Installation Precautions
yyMake sure to remove the protective film attached to the projector.
- If you use the projector without removing the protective film, the product may not work properly.
yyPlace the projector in a well-ventilated environment.
- To prevent internal heat from building up, install the projector in a well-ventilated place.
Do not place anything near the projector as this may block its air vents. If the air vents are blocked, the internal temperature will increase.
-Do not place the projector on a carpet or rug. If a product has its inlet vent on its bottom, do not block the vent and use the product on a leveled solid surface.
-Be sure to prevent foreign objects, such as scraps of paper, from entering the inlet vent.
-Leave an adequate distance (30 cm or more) around the projector.
yyDo not place the product in a hot or humid environment.
- Do not place the product in a hot, cold, or humid environment.
yyDo not place the product in a dusty place.
- This may cause fire.
yyNever open any cover on the projector. There is a high risk of electric shock.
yyThe projector is manufactured using high-precision technology. You may, however, see tiny black dots and/ or bright colored dots (red, blue or green) that continuously appear on
the projector screen. This is a normal result of the manufacturing process and does not indicate a malfunction.
yyThe remote control may not work in an environment where a lamp equipped with electronic ballasts or
a three-wavelength fluorescent lamp is installed. Replace the lamp with an international standard lamp for the remote control to work normally.
16 PREPARATION
Projection Distance per Screen Size
1 Place the projector on a sturdy, level surface, together with the computer or audio/ video source.
2 Place the projector at an appropriate distance from the screen. The distance between the projector and the screen determines the actual size of the image.
3 Position the projector so that the lens is perpendicular to the screen. If the lens is not perpendicular to the screen, the projected image will look distorted. If the screen image is crooked, use the Keystone function. (See page 23.)
4 Connect the power cords of the projector and the connected devices to the wall outlet.
(X) Height Screen
Projection Offset: 90 %
DISPLAY
X/2
X/2
Projection Distance (D)
(Y) Width Screen
Y/2
DISPLAY
Y/2 95 mm
Projection Distance (D)
4 : 3 aspect ratio
Screen Size (mm) |
Screen Width (Y) |
Screen Height (X) |
Shortest Distance |
Longest Distance |
|
(mm) |
(mm) |
(D) (mm) |
(D) (mm) |
||
|
|||||
762 |
610 |
457 |
873 |
1052 |
|
1016 |
813 |
610 |
1172 |
1411 |
|
1270 |
1016 |
762 |
1471 |
1771 |
|
1524 |
1219 |
914 |
1771 |
2130 |
|
1778 |
1422 |
1067 |
2070 |
2489 |
|
2032 |
1626 |
1219 |
2369 |
2849 |
|
2286 |
1829 |
1372 |
2668 |
3208 |
|
2540 |
2032 |
1524 |
2968 |
3567 |
|
3048 |
2438 |
1829 |
3566 |
4286 |
|
3810 |
3048 |
2286 |
4464 |
5363 |
|
5080 |
4064 |
3048 |
5961 |
7160 |
|
6350 |
5080 |
3810 |
7457 |
8957 |
|
7620 |
6096 |
4572 |
8953 |
10753 |
yyThe Shortest Distance/Longest Distance is the adjusted status by rotating the zoom ring using the zoom function.
yyThe projection distance for each screen size is just a reference and there is about
±5 % deviation.
PREPARATION 17
Kensington Security System
yyThis projector has a Kensington Security Standard connector. Connect a Kensington Security System cable as shown below.
yyFor more information on installation and use of the Kensington Security System, refer to the user’s guide provided with the Kensington Security System.
yyThe Kensington Security System is an optional accessory. yyWhat is Kensington?
Kensington is a company that provides safety systems for laptops and other electronic devices.
Website: http://www.kensington.com
18 REMOTE CONTROL
REMOTE CONTROL
Open the battery cover on the back of the remote control and insert the batteries which are specified in the battery room with
poles pointing in the correct direction. The new and same type of batteries (1.5 V AAA) must be used.
CAUTION
yyDo not mix new batteries with old ones.
MARK |
SOUND |
TIMER |
SETTINGS
Power
Turns the projector on or off.
USB/MY MEDIA
Changes to the USB mode.
INPUT
Changes the input source.
Playback control buttons
Adjusts the play of My Media.
Key's
Adjusts the Keystone settings.
SOUND
Changes the SOUND mode.
SLEEP
Sets the sleep timer.
Changes the picture mode.
ENERGY SAVING
Changes the ENERGY SAVING mode.
TIMER
Changes the settings of the presentation timer.
VOL +, -
Adjusts the volume level.
RATIO
Changes the aspect ratio.
BLANK
Displays the empty screen for a while.
MUTE
Mutes the sound of projector.
PAGE ,
Moves to the previous or next screen.
REMOTE CONTROL 19
|
|
|
SETTINGS |
|
|
|
Selects or closes menus. |
|
|
|
STILL |
|
|
|
Freezes the moving image. |
|
|
|
(The STILL function works in all the modes other than USB |
|
|
MARK |
mode.) |
|
|
Q.MENU |
|
|
SOUND |
|
|
|
|
Enters the quick menu. |
|
|
|
TIMER |
|
|
|
Up/Down/Left/Right buttons |
|
|
|
|
|
|
|
|
Sets the function or moves the cursor. |
|
|
|
OK |
|
|
|
Shows the current mode and saves changes to the settings. |
SETTINGS |
|
|
BACK |
|
|
|
Returns to the previous screen. |
|
|
|
AUTO |
|
|
|
Optimizes the screen automatically in RGB-PC input mode. |
|
|
|
EXIT |
|
|
|
Closes the settings window. |
Color buttons
Sets detailed settings or gesture for each menu.
yyMARK button is used when a software update is required. (MARK button is not available for a user.)
NOTE
yyWhen using the remote control, the optimal remote range is less than
6 m (left/right) and within a 30° arc of the IR receiver.
yyIf cables are connected, the remote range is less than 3 meters
(left/right) and within a 30° arc of the IR receiver. yyFor seamless operation, do not block the IR receiver.
30° 30°
MARK
SOUND
TIMER
SETTINGS
20 Watching with the Projector
Watching with the Projector
Watching with the Projector
Turning on the Projector
1 Connect the power cord correctly.
2 After waiting for a moment, press the POWER button on the remote control or the control panel.
(The light on the control panel will be turned on.)
3 In the Language Selection screen, select a language.
4 Select an input signal by using the INPUT button on the remote control.
To move the screen image upward/ downward, adjust the height of foot at
the bottom of the projector.

Front foot adjustment button
yyWhile pressing the front foot adjustment button, adjust the project upward/downward until the screen image is correctly located.
yyWhen you release the front foot adjustment button, the front foot is fixed at the current position.
Focus and Position of the Screen Image
When an image appears on the screen, check if it is in focus and fits the screen properly.

Zoom ring
Focus Ring
yyTo adjust the focus of the image, rotate the focus ring that is the outer ring of projector lens.
yyTo adjust the size of the image, rotate the inner zoom ring.
Watching with the Projector
1 In Standby mode, press the POWER button to turn the projector on.
2 Press the INPUT button and select the input signal you want.
3 Control the projector using the following buttons while watching the screen.
Button |
Description |
VOL -, + |
Adjusts the volume level. |
MUTE |
Mutes the sound of |
|
projector. |
Q.MENU |
Enters the quick menu. |
|
(See page 24.) |
|
|
RATIO |
Changes the aspect ratio. |
Key's |
Adjusts the Keystone |
|
settings. (See page 23.) |
4 To turn the projector off, press the POWER button.
Watching with the Projector 21
Do not turn off the projector
Do not turn off the projector
The lifetime of the lamp depends on the environment in which the projector is used.
You can check how long the projector lamp has been used in the Option menu.
Make sure to replace the lamp in the following situations:
yyThe projected image gets darker or starts to deteriorate in quality.
yyThe lamp warning indicator is red.
yyThe message Replace the lamp appears on the screen when turning the projector on.
Be careful when replacing the lamp
yyTurn off the power by pressing the POWER button on the remote control or on the control panel.
yyDo not remove the power cord when the operation indicator is blinking in orange, i.e. the fan is working (about
20 sec.). When the operation indicator turns orange, remove the power code.
yyAllow the lamp to cool down for
1 hour before replacing it.
yyReplace only with the same type of lamp from a reseller or an LG Electronics Service Center.
Using another manufacturer's lamp may damage the projector and lamp.
yyRemove the lamp only when replacing it.
yyKeep the lamp unit out of reach of children. Keep the lamp away from heat sources such as radiators, stoves etc. There is a risk of fire or burning.
yyDo not expose the lamp to liquids or foreign materials. The lamp may burst.
yyDo not insert any flammable or metal objects into the lamp socket after removing the lamp. This can result in electrical shock or damage the product.
yyFix the new lamp with screws securely. If it is not securely fixed, the projected image may become darker and there may be a fire risk.
yyDo not touch the front glass of the new lamp or the glass of the lamp container. Picture quality and lamp lifetime may suffer.
Purchasing a replacement lamp
Check the lamp model and then purchase it from an LG Electronics Service Center. (Use a lamp designed specifically for the projector, otherwise
it may cause damage to the projector.)
Disposing of the lamp
Dispose of the used lamp by returning it to an LG Electronics Service Center.
