OWNER’S MANUAL

LG Digital Signage

(MONITOR SIGNAGE)

Please read this manual carefully before operating your set and retain it for future reference.

32SE3D

43SE3D

49SE3D

55SE3D

65SE3D

32SE3KD

43SE3KD

49SE3KD

55SE3KD

65SE3KD

43SH7DD

49SH7DD

55SH7DD

www.lg.com

TABLE OF CONTENTS

ENGLISH

IMPORTANT PRECAUTIONS .........3

- Electrical Power Related Precautions ....................3

- Precautions for installing the Product ..................5

- Precautions for Moving the Product ......................6

- Precautions for Using/Cleaning the Product .....7

- Product Disposal (Only, Hg lamp used LCD

Monitor) .................................................................................7

LICENSES .......................................8

ASSEMBLY AND PREPARATION ..9

- Optional Accessories ....................................................10

- Parts and Buttons .........................................................12

- Connecting the Stand ................................................. 13

- Connecting the Speakers ..........................................15

- Using the IR Receiver ...................................................18

- Portrait Layout ................................................................19

- Attaching and removing

the LG Logo Bracket ....................................................20

- Installing on a Wall ........................................................22

REMOTE CONTROL .................... 24

- Displaying the Device Name Connected to an

Input Port ...........................................................................26

- White Balance Adjust Menu ....................................26

MAKING CONNECTIONS ........... 27

- Connecting to a PC.......................................................27

- External Device Connection .....................................27

TROUBLESHOOTING .................. 29

PRODUCT SPECIFICATIONS ...... 32

WARNING -This equipment is compliant with Class A of CISPR 32. In a residential environment this equipment may cause radio interference.

IMPORTANT PRECAUTIONS

Please read these safety precautions carefully before using the product.

WARNING

Failure to follow those warnings may result in death, serious injury or damage to the product or other property.

CAUTION

If you ignore the caution message, you may be slightly injured or the product may be damaged.

WARNING

• Indoor Use Only.

Electrical Power Related Precautions

WARNING

• Use only the power cord supplied with the unit or another manufacturer’s authorized cord.

- Failure to do so may result in fire or electrical shock or damage to the product.

• Use only a properly grounded plug and receptacle.

- If you do not you may be electrocuted or injured. Or the product might be damaged.

• Do not use a damaged or loose plug.

- This may cause electrical shock or fire.

• Operate the display only from a power source(i.e. voltage) indicated in the product specification.

- Otherwise the product can be damaged, fire can occur or you may be electrocuted. If you are not sure what type of power supply you have, consult a certified electrician.

• In the presence of thunder and lightning, never touch the power cord and signal cable because it can be very

dangerous.

- It can cause electric shock.

• Do not connect several extension cords, electrical appliances or electrical heaters to a single outlet. Use a power strip

with a grounding terminal designed for exclusive use with the computer.

- A fire can break out due to overheating.

• Do not touch the power plug with wet hands. Additionally, if the cord pin is wet or covered with dust, dry the power

plug completely or wipe dust off before plugging in the cord.

- You may be electrocuted due to excess moisture.

ENGLISH

• If you don’t intend to use the product for a long time, unplug the power cable from the product.

ENGLISH

- Layers of dust can cause a fire, or insulation deterioration can cause electric leakage, electric shock or fire.

• Insert the power plug firm so it cannot come loose.

- A loose connection can cause fire.

• Hold the plug when pulling out the power cable. Do not pull the plug out by the wire. Do not bend the power cord

with excessive force or put heavy objects on the power cord.

- The power line can be damaged, which may cause electric shock or fire.

• Do not insert metal or other conductive materials into the product openings. Additionally, do not touch the power

cable right after plugging into the wall input terminal.

- You may be electrocuted.

• Use an appliance coupler as a disconnect device.

• Please make sure the device is installed near the wall outlet to which it is connected and that the outlet is easily

accessible.

• Do not unplug the power cord while the product is in use.

- Electrical shock can damage the product.

• As long as this unit is connected to the AC wall outlet, it is not disconnected from the AC power source even if the

unit is turned off.

Precautions for installing the Product

WARNING

• Keep away from heat sources like heaters or open flames.

- Electrical shock, fire, malfunction or deformation may occur.

• Keep the packing anti-moisture material or vinyl packing out of the reach of children.

- Anti-moisture material is harmful if swallowed. If swallowed by mistake, force the patient to vomit and visit the nearest hospital. Additionally, vinyl packing can cause suffocation. Keep it out of the reach of children.

• Do not put heavy objects on the product or sit upon it.

- If the product collapses or is dropped, you may be injured. Prevent Children from climbing or pulling on the unit.

• Do not leave the power or signal cable where someone can trip over it.

- Pedestrians may become entangled in the cables and cause the device to become damaged causing electrical shock, fire, or serious injury.

• Install the product in a neat and dry place. Do not use near water.

- Dust or moisture can cause electrical shock, fire or product damage.

• Do not add accessories that have not been designed for this display.

• If you smell smoke or other odors or hear a strange sound from the product unplug the power cord and contact LG

Customer Service.

- If you continue to use without taking proper measures, electrical shock or fire can occur.

• If you dropped the product or the case is broken, turn off the product and unplug the power cord.

- If you continue to use without taking proper measures, electrical shock or fire can occur. Contact LG Customer Service.

• Do not drop an object on or apply impact to the product. Do not throw any toys or objects at the product.

- It can cause injury to humans, problems to the product and damage the display.

• Keep out of reach of children and do not place toys near the product.

• Make sure the product ventilation hole is not blocked. Install the product more than 100 mm (3.9 inches) from the

wall.

- If you install the product too close to the wall, it may be deformed or fire can break out due to internal heat buildup.

• Do not cover the product with cloth or other material (eg. plastic) while plugged in.

- The product can be deformed or fire can break out due to internal overheating.

• Place the product on a flat and stable surface that is large enough to support the product.

- If the product is dropped, you may be injured or the product may be broken.

• Install the product where no Electromagnetic Interference occurs.

• Keep the product away from direct sunlight.

- The product can be damaged.

• Do not place the product on the floor.

- Small Children and others may trip over it.

• Do not install this product on a wall if it could be exposed to oil or oil mist.

- This may damage the product and cause it to fall.

• For displays with glossy bezels the user should consider the placement of the display as the bezel may cause

unwanted reflections from surrounding light and bright surfaces.

ENGLISH

Precautions for Moving the Product

ENGLISH

WARNING

• Make sure to turn off the product.

- You may be electrocuted or the product can be damaged.

• Make sure to remove all cables before moving the product.

- You may be electrocuted or the product can be damaged.

• When lifting or moving the product, do not hold it upside down while holding only the stand.

- This may cause the product to fall resulting in damage or injury.

• Do not shock the product when moving it.

- You may be electrocuted or the product can be damaged.

• Make sure the panel faces forward and hold it with both hands to move.

- If you drop the product, the damaged product can cause electric shock or fire.

• Do not place the product face down.

- This may damage the TFT-LCD screen.

Precautions for Using/Cleaning the Product

WARNING

• Do not attempt to disassemble, repair or modify the product yourself.

- Fire or electric shock can occur.

- Contact LG Customer Service for repair.

• When cleaning the product, unplug the power cord and scrub gently with a soft cloth to prevent scratching. Do not

clean with a wet cloth or spray water or other liquids directly onto the product. An electric shock may occur. (Do not use chemicals such as benzene, paint thinners or alcohol.)

• Keep the product away from water.

- Fire or electric shock accident can occur.

• Avoid high temperatures and humidity.

• Do not put or store flammable substances near the product.

- There is a danger of explosion or fire.

• Keep the product clean at all times.

• Take a comfortable and natural position when working with the product.

• Take a regular break when working with the product for a long time.

• Do not press on the panel with a hand or sharp object such as nail, pencil or pen, or make a scratch on it.

• Keep proper distance from the product and rest from time-to-time.

- Your vision may be impaired if you look at the product too closely or for too long.

• Set the appropriate resolution by referring to the User’s Guide.

• Keep small accessories out of the reach of children.

• Displaying a still image for long time on the monitor may leave persistent image or stain on the monitor screen. To

avoid this problem, use a screen saver and power off when this product is not used. Persistent image or stain caused by long time usage are not covered by the warranty on this product.

• Do not use products using high voltage around the Monitor. (ex. Electrical Swatter)

- Monitor may have malfunction as its electrical shock.

• Spray water onto a soft cloth 2 to 4 times, and use it to clean the front frame;wipe in one direction only. Too much

moisture may cause staining.

ENGLISH

WATER

CHEMICALS

Product Disposal (Only, Hg lamp used LCD Monitor)

• The fluorescent lamp used in this product contains a small amount of mercury.

• Do not dispose of this product with general household waste.

• Disposal of this product must be carried out in accordance to the regulations of your local authority.

LICENSES

ENGLISH

Supported licenses may differ by model. For more information of the licenses, visit www.lg.com.

The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.

This DivX Certified® device has passed rigorous testing to ensure it plays DivX® video. To play purchased DivX movies, first register your device at vod.divx.com. Find your registration code in the DivX VOD

section of your device setup menu. DivX Certified® to play DivX® video up to HD 1080p, including premium content. DivX®, DivX Certified® and associated logos are trademarks of DivX, LLC and are used under license. Covered by DivX Patents 7,295,673; 7,515,710; RE45,052; and others available at [www.divx.com/patents]

Manufactured under license from Dolby Laboratories. Dolby, Dolby Vision, Dolby Audio, and the double-D symbol are trademarks of Dolby Laboratories.

ASSEMBLY AND PREPARATION

CAUTION

• Always use genuine components to ensure safety and product performance.

• The product warranty will not cover damage or injury caused by the use of counterfeit components.

NOTE

• The accessories provided with your product may vary depending on the model or region.

• Product specifications or contents in this manual may be changed without prior notice due to upgrade of product

functions.

• SuperSign Software & Manual

- Downloading from the LG Electronics website.

- Visit the LG Electronics website (http://partner.lge.com) and download the latest software for your model.

• The warranty will not cover any damage caused by using the product in an excessively dusty environment.

ENGLISH

Optional Accessories

ENGLISH

Without prior notice, optional accessories are subject to change to improve the performance of the product, and new accessories may be added. The illustrations in this manual may differ from the actual product and accessories.

Stand kit

Screws

Diameter 4.0 mm x Pitch 0.7 mm

Stand

ST-322T 32SE3*

ST-432T 43SE3*/43SH7DD

ST-492T

ST-652T 65SE3*

49SE3*/49SH7DD 55SE3*/55SH7DD

Stand Spacers

32SE3* -

43SE3* 43SH7DD 49SE3* 49SH7DD 55SE3* 55SH7DD 65SE3*

2 EA

(Diameter 0.1 inches x Pitch 0.02 inches)

Length

Model

32SE3*

43SE3*/43SH7DD 49SE3*/49SH7DD 55SE3*/55SH7DD

65SE3*

(including spring

washer)

10 mm

(0.3 inches)

14 mm

(0.5 inches)

16 mm

(0.6 inches)

Quantity

6 EA

8 EA

Speakers SP-5000

Cable

holder/

Cable Tie

Speaker kit

(Only for **SE3D model)

Screws

Diameter 4.0 mm x

Pitch 0.7 mm x Length 8 mm

(Diameter 0.1 inches x Pitch

0.02 inches x Length 0.3 inches) (including spring washer)

Screws

Diameter 4.0 mm x

Pitch 1.6 mm x Length 10 mm

(Diameter 0.1 inches x Pitch

0.06 inches x Length 0.3 inches) (including spring washer)

Media Player kit

(It may not be supported depending on the model.)

Screws

Media Player

MP500/ MP700

Diameter 3.0 mm x Pitch 0.5 mm

x Length 6mm

(Diameter 0.1 inches x Pitch 0.01

inches x Length 0.2 inches)

Wi-Fi Dongle kit

AN-WF500

CD (Owner’s Manual)/ Cards

NOTE

• Cable holder/Cable tie may not be available in some areas or for some models.

• Optional accessories are available for some models. If necessary, please purchase them separately.

• Before you attach the Media Player, connect the cable to the port.

• Please turn off the power before connecting or removing the Wi-Fi dongle kit.

ENGLISH

Parts and Buttons

ENGLISH

The image may be different according to the model.

• : Changes the input source.

• : Accesses the main menus, or saves your input and exits the menus.

• : Adjust the up and down.

• : Moves left and right.

• : Displays the current signal and mode.

• : Turns the power on or off.

Buttons

Connecting the Stand

- For certain models only.

- The image may be different according to the model.

32SE3*

ENGLISH

43/49/55/65SE3*, 43/49/55SH7DD

ENGLISH

Connecting the Speakers

- For certain models only.

- The image may be different according to the model.

32SE3D

1 Connect an input signal cable before installing the speakers.

2 Mount the speakers by using screws as shown below. Make sure the power cable is disconnected before making a

connection.

Basic installation

ENGLISH

3 Then connect the speaker cable. After installing your speakers, use holders and cable ties to organize the speaker

ENGLISH

cables.

Basic installation

43/49/55/65SE3D

1 Connect an input signal cable before installing the speakers.

2 Mount the speakers by using screws as shown below. Make sure the power cable is disconnected before making a

connection.

ENGLISH

3 Then connect the speaker cable. After installing your speakers, use holders and cable ties to organize the speaker

cables.

NOTE

• Please turn off the power before removing the cable. Connecting or removing the speaker cable while turned on may

result in no sound.

Using the IR Receiver

ENGLISH

- The image may be different according to the model. This allows a remote control sensor to be placed in a custom location. Then that display can control other displays via an RS-232C cable. Install the IR receiver towards the front of the set.

IR Receiver cable

NOTE

• When you see from the back of the set, if the IR receiver cable does not face front, the signal reception range may

shorten.

• The IR receiver is made with a magnet.It is detachable at the bottom (typical installation) or back (wall installation) of

the set.

• Make sure that you unplug the power cord before connecting or removing the IR Receiver.

Portrait Layout

When installing in a portrait layout, rotate the monitor counterclockwise 90 degrees (when facing the screen).

Using Kensington Lock

(This is not available for all models.) The Kensington security system connector is located at the back of the monitor. For more information on installation

and use of this system, refer to the manual provided with the Kensington security system or visit http://www.kensington.com.

Connect the Kensington security system cable between the monitor and a table.

ENGLISH

NOTE

• The Kensington security system is optional. You can obtain additional accessories from most electronics retail stores.

• The illustration shows a general example of installation and may look different from the actual product.

Attaching and removing the LG Logo Bracket

ENGLISH

- For certain models only.

- The image may be different according to the model.

Removing the LG Logo Bracket

1 Lay a clean cloth on the floor, and then put the monitor on it with the screen face down. Using a screwdriver,

remove the screw that secures the LG Logo Bracket to the bottom rear of the monitor.

LG Logo Bracket

2 After removing the screw, remove the LG Logo Bracket. When re-attaching the LG Logo Bracket, repeat the process

in reverse order.

Attaching the LG Logo Bracket on the right side

1 Lay a clean cloth on the floor, and then put the monitor on it with the screen face down. Using a screwdriver,

remove the screw that secures the LG Logo Bracket to the bottom rear of the monitor.

2 After removing the screw, remove the LG Logo Bracket. Attach the LG Logo Bracket with a screw, aligning it with

the hole on the right side.

ENGLISH

Installing on a Wall

ENGLISH

For proper ventilation, allow a clearance of 100 mm on each side and from the wall. Detailed installation instructions are available from your dealer, see the optional Tilt Wall Mounting Bracket Installation and Setup Guide.

100 mm

100 mm (3.9 inches)

To install your monitor on a wall, attach a wall mounting bracket (optional part) to the back of the monitor. Make sure that the wall mounting bracket is securely fixed to the monitor and to the wall.

100 mm

1 Use only screws and wall mounting brackets that conform to VESA standards. 2 Screws which are longer than standard length may damage the inside of the monitor.

3 A non-VESA standard screw may damage the product and cause the monitor to fall. LG Electronics is not liable for

any accidents related to the use of non-standard screws.

4 Please use VESA standard as below.

• 785 mm (30.9 inches) and above

* Fixing screws: Diameter 6.0 mm (0.2 inches) x Pitch 1.0 mm (0.03 inches) x Length 12 mm (0.47 inches)

785 mm

CAUTION

• Disconnect the power cord before moving or installing the monitor to avoid risk of electric shock.

• If you install the monitor on a ceiling or slanted wall, it may fall and result in injury. Use an authorized LG wall mount

and contact your local dealer or qualified personnel to assist with the installation.

• Do not over tighten the screws as this may damage the monitor and void your warranty.

• Use only screws and wall mounting brackets that meet the VESA standard. Any damage or injuries caused by misuse

or use of improper accessories are not covered by the warranty.

NOTE

• The wall mount kit includes the installation guide and all necessary parts.

• The wall mounting bracket is optional. You can obtain additional accessories from your local dealer.

• The length of screws required may differ depending on the wall mount. Be sure to use the correct length.

• For more information, please refer to the guide provided with the wall mount.

ENGLISH

REMOTE CONTROL

ENGLISH

The descriptions in this manual are based on the buttons on the remote control. Please read this manual carefully to use the monitor correctly. To install batteries, open the battery cover, place batteries (1.5 V AAA) matching and

terminals to the labels inside the compartment, and close the battery cover. To remove the batteries, perform the

installation actions in reverse. The illustrations may differ from the actual accessories.

CAUTION

• Do not mix old and new batteries, as this may damage the remote control.

• Be sure to point the remote control toward the remote control sensor on the monitor.

• Some features of the remote control may not be supported in certain models.

(POWER) Turns the monitor on or off.

Turns the monitor on.

Turns the monitor off.

Reduces power consumption by adjusting peak

screen brightness.

Selects the input mode.

Used for viewing 3D videos.

Toggles between numerical and alphabetical.

Number and Alphabet buttons

Enters numerical or alphabetical characters depending upon the setting.

Deletes the entered numerical or alphabetical character.

Volume Up/Down Button Adjusts the volume.

Selects the Aspect Ratio mode.

Automatically adjusts picture position and minimizes image

instability (available for RGB input only).

Mutes all sounds.

supported in this model.

Adjusts the brightness of the display. function is not

Selects the Picture Mode.

Views the information of the currently program and the screen.

Enters the White Balance menu.

Accesses the main menus or saves your input and exit menus.

SuperSign menu key.

Navigation Buttons Scrolls through menus or options.

Selects menus or options and confirms your input.

Allows you to move back one step in the user interaction

function.

Quit all OSD tasks and applications.

Allows you to control various multimedia devices to enjoy multimedia simply by using the remote control through the SimpLink menu.

Selects the TILE Mode.

When the Picture ID number matches the Set ID

number, you can control whichever monitor you want in multi-display format.

USB Menu Control Buttons Controls media playback.

ENGLISH

Displaying the Device Name Connected to an Input Port

ENGLISH

Display which devices are connected to which external input ports.

1 Access the Input list screen and press the red (input label) button on the remote control. 2 You can assign an input label for every input except USB.

NOTE

• External inputs supported: HDMI, DVI-D

• Labels available: PC, DTV

• The input labels are displayed on the Input Label screen or at the top left of the screen when you change the external

input setting.

• For DTV/ PC-compatible signals, such as 1080p 60 Hz, the screen settings may change according to the input label.

The Just Scan option is available if a PC is connected as an external device.

White Balance Adjust Menu

Press the button on the remote control.

• R-Gain: Adjusts the level of red. The higher the number, the redder the set. Decrease the number if the screen looks

too red.

• G-Gain: Adjusts the level of green. The higher the number, the greener the set. Decrease the number if the screen

looks too green.

• B-Gain: Adjusts the level of blue. The higher the number, the bluer the set. Decrease the number if the screen looks

too blue.

• Backlight: Adjusts the brightness. The higher the number, the brighter the set. This works in the same way as the

backlight of the user menu.

• Reset: Resets the white balance value to the factory settings.

MAKING CONNECTIONS

You can connect various external devices to your monitor. Change the input mode and select the external device you want to connect. For more information about external device connections, see the user manual provided with each device.

Connecting to a PC

Some of the cables are not provided. This monitor supports the Plug and Play* feature.

* Plug and Play: a feature that enables a PC to recognize devices attached by the user without device configuration or

user intervention when powering up.

External Device Connection

Connect a HD receiver, DVD, or VCR player to the monitor and select an appropriate input mode. Some of the cables are not provided. For the best picture and sound quality, connecting external devices to your

monitor using HDMI cables is recommended.

ENGLISH

NOTE

• For the best image quality, using the monitor with HDMI connection is recommended.

• To comply with the specifications of the product, use a shielded interface cable with ferrite core, such as a D-sub

15-pin cable and DVI-D/HDMI cable.

• If you turn the monitor on when the set is cold, the screen may flicker. This is normal.

• Sometimes red, green, or blue spots may appear on the screen. This is normal.

• Use a High Speed HDMI®/TM cable.

• Use a certified cable with the HDMI logo attached. If you do not use a certified HDMI cable, the screen may not

display or a connection error may occur.

• Recommended HDMI Cable Types

- High-Speed HDMI®/TM Cable

- High-Speed HDMI®/TM Cable with Ethernet

• If you cannot hear any sound in HDMI mode please check your PC settings. Some PCs require you to manually change

the default audio output to HDMI.

• If you want to use HDMI-PC mode, you must set your PC/DTV to PC mode.

• You may experience compatibility issues if you use HDMI-PC mode.

• Make sure the power cable is disconnected.

• If you connect a gaming device to the monitor, use the cable provided with the gaming device.

• It is recommended to use the speakers that are provided as optional accessories.

• High Speed HDMI®/TM cables transmit a HD signal up to 1080p and higher.

CAUTION

• Connect the signal input cable and tighten it by turning the screws clockwise.

• Do not press the screen with your finger for a prolonged period as this may result in temporary distortion on the

screen.

• Avoid displaying static images on the screen for a long period of time to prevent image burn. Use a screensaver if

possible.

• A wireless communication device near your monitor can affect the image.

TROUBLESHOOTING

No image is displayed.

Problem Action

Is the product power cord connected? • Check if the power cord is correctly plugged into the power outlet. Does the “Invalid Format” message

appear?

Does the “No Signal” message appear? • The signal cable between PC and product is not connected. Check the

The Unknown Product message appears when the product is connected.

Problem Action

Did you install the driver? • Check if the Plug and Play function is supported by referring to the

The screen image looks abnormal.

Problem Action

Is the screen position wrong? • Check if the graphics card resolution and frequency are supported by

The screen is displayed abnormally. • The proper input signal is not connected to the signal port. Connect the

• The signal from the PC (Graphics card) is out of the vertical or

horizontal frequency range of the product. Adjust the frequency range by referring to the Specifications in this manual.

signal cable.

• Access the input menu to check the input signal.

graphics card user manual.

the product. If the frequency is out of range, set to the recommended resolution in the [Control Panel] → [Display] → [Setting] menu. (The settings may differ depending on your operating system.)

signal cable that matches with the source input signal.

ENGLISH

After-image appears on the product.

ENGLISH

Problem Action

After-image appears when the product is turned off.

The audio function does not work.

Problem Action

No sound? • See if the audio cable is connected properly.

Sound is too dull. • Select the appropriate equalizer sound. Sound is too low. • Adjust the volume.

Screen color is abnormal.

Problem Action

Screen has poor color resolution (16 colors).

Screen color is unstable or mono-colored. • Check the connection status of the signal cable. Or, re-insert the PC

Do black spots appear on the screen? • Several pixels (red, green, blue, white, or black color) may appear on the

• If you use a fixed image for a long time, the pixels may be damaged.

Use the screen-saver function.

• When a dark image is displayed on the screen after an image with high

contrast (black and white or gray), this may cause image sticking. This is normal for LCD screen products.

• Adjust the volume.

• See if the sound is set properly.

• Set the number of colors to more than 24 bits (true color). Select

[Control Panel] → [Display] → [Settings] → [Color Table] in Windows. (The settings may differ depending on your operating system.)

graphics card.

screen, which can be attributable to the unique characteristics of the LCD panel. This is not a malfunction of the LCD.

The operation does not work normally.

Problem Action

The power suddenly turned off. • Is the Timer set?

• Check the power control settings. Power interrupted.

CAUTION

• Image sticking does not occur when using constantly changing images but may occur when using a fixed image for an

extended period of time. Therefore, it is recommended that you use the instructions below to decrease the likelihood of image sticking occurring when using a fixed image. It is recommended that you change the screen at least once every 12 hours at the very minimum; if done more frequently, the prevention of image sticking is more effective.

Recommended operating conditions

1 Change the background and the character colors using the same time interval.

ID: UPM 123 PW: ****

When changing colors, using complementary colors helps to prevent image sticking.

BM BM BM

ITO or MoTi Pixel Layer

2 Change the image using the same time interval.

Glass

TFT Layers

Glass

ID: UPM 123 PW: ****

CFCFCF

ENGLISH

Make sure that the characters or images before changing the image remain in the same location after changing the image.

What is image sticking?

When the LCD panel displays a static image for an extended period of time, it can cause a voltage difference between the electrodes that operate the liquid crystals. When the voltage difference between the electrodes builds up over time, liquid crystals have a tendency to remain aligned in one direction. During this process, a previously displayed image remains visible. This phenomenon is referred to as image sticking.

ENGLISH

PRODUCT SPECIFICATIONS

The product specifications below may be changed without prior notice due to upgrade of product functions. “ ” refers to alternating current (AC), and “ ” refers to direct current (DC).

LCD screen Screen type Thin Film Transistor (TFT)

Liquid Crystal Display (LCD) Screen

Video signal Maximum resolution 1920 x 1080 @ 60 Hz

- This may not be supported on some OS or graphics card types.

Recommended resolution 1920 x 1080 @ 60 Hz

- This may not be supported on some OS or graphics card types.

Horizontal frequency RGB: 30 kHz to 83 kHz

HDMI: 30 kHz to 83 kHz

Vertical frequency RGB: 50 Hz to 75 Hz

HDMI: 56 Hz to 60 Hz

Synchronization Separate Sync, Digital

Input/output ports

Embedded battery Applied

Environmental Conditions

**SE3D HDMI1 IN, HDMI2 IN, DVI-D IN, RGB IN, Audio IN/OUT, Speaker

OUT, EXT IR IN, USB, RS-232C IN/OUT, LAN

**SE3KD, **SH7DD HDMI1 IN, HDMI2 IN, DVI-D IN, RGB IN, Audio IN/OUT, EXT IR

IN, USB, RS-232C IN/OUT, LAN

Operating Temperature 0 °C to 40 °C (32 °F to 104 °F)

Operating Humidity 10 % to 80 %

Storage Temperature -20 °C to 60 °C (-4 °F to 140 °F)

Storage Humidity 5 % to 85 %

* Applicable only for models that support the speakers

Audio RMS Audio Output 10 W + 10 W (R + L)

Input Sensitivity 0.7 Vrms

Speaker Impedance 6 Ω

32SE3D

LCD screen Pixel pitch

Power Rated power

Power consumption

Dimensions (Width x Height x Depth) / Weight

Head

Head + Stand

Head + Speaker

Head + Speaker + Stand

32SE3KD

LCD screen Pixel pitch

Power Rated power

Power consumption

Dimensions (Width x Height x Depth) / Weight

Head

Head + Stand

0.36375 mm (H) x 0.36375 mm (V)

ENGLISH

AC 100-240 V ~ 50/60 Hz 0.8 A

On Mode: 45 W (Typ.)

Sleep Mode: ≤ 0.5 W Off Mode: ≤ 0.5 W

729.4 mm x 428.9 mm x 55.5 mm / 5.2 kg

(28.7 inches x 16.8 inches x 2.1 inches / 11.4 lbs)

729.4 mm x 481 mm x 154.2 mm / 6 kg

(28.7 inches x 18.9 inches x 6.0 inches / 13.2 lbs)

729.4 mm x 428.9 mm x 95.7 mm / 5.7 kg

(28.7 inches x 16.8 inches x 3.7 inches / 12.5 lbs)

729.4 mm x 481 mm x 154.2 mm / 6.5 kg

(28.7 inches x 18.9 inches x 6.0 inches / 14.3 lbs)

0.36375 mm (H) x 0.36375 mm (V)

AC 100-240 V ~ 50/60 Hz 0.8 A

On Mode: 45 W (Typ.)

Sleep Mode: ≤ 0.5 W Off Mode: ≤ 0.5 W

729.4 mm x 428.9 mm x 55.5 mm / 5.4 kg

(28.7 inches x 16.8 inches x 2.1 inches / 11.9 lbs)

729.4 mm x 481 mm x 154.2 mm / 6.2 kg

(28.7 inches x 18.9 inches x 6.0 inches / 13.6 lbs)

43SE3D

ENGLISH

LCD screen Pixel pitch

Power Rated power

Dimensions (Width x Height x Depth) / Weight

43SE3KD

LCD screen Pixel pitch

Power Rated power

Dimensions (Width x Height x Depth) / Weight

Power consumption

Head

Head + Stand

Head + Speaker

Head + Speaker + Stand

Power consumption

Head

Head + Stand

0.4902 mm (H) X 0.4902 mm (V)

AC 100-240 V~ 50/60 Hz 0.9 A

On Mode: 55 W (Typ.)

Sleep Mode: ≤ 0.5 W Off Mode: ≤ 0.5 W

969.6 mm x 563.9 mm x 38.6 mm / 9.6 kg

(38.1 inches x 22.2 inches x 1.5 inches / 21.1 lbs)

969.6 mm x 622.2 mm x 193 mm / 12.1 kg

(38.1 inches x 24.4 inches x 7.5 inches / 26.6 lbs)

969.6 mm x 563.9 mm x 67.9 mm / 10.1 kg

(38.1 inches x 22.2 inches x 2.6 inches / 22.2 lbs)

969.6 mm x 622.2 mm x 193 mm / 12.6 kg

(38.1 inches x 24.4 inches x 7.5 inches / 27.7 lbs)

0.4902 mm (H) X 0.4902 mm (V)

AC 100-240 V~ 50/60 Hz 0.9 A

On Mode: 55 W (Typ.)

Sleep Mode: ≤ 0.5 W Off Mode: ≤ 0.5 W

969.6 mm x 563.9 mm x 54 mm / 10.0 kg

(38.1 inches x 22.2 inches x 2.1 inches / 22.0 lbs)

969.6 mm x 622.2 mm x 193 mm / 12.5 kg

(38.1 inches x 24.4 inches x 7.5 inches / 27.5 lbs)

43SH7DD

LCD screen Pixel pitch

Power Rated power

Power consumption

Dimensions (Width x Height x Depth) / Weight

Head

Head + Stand

0.4902 mm (H) X 0.4902 mm (V)

AC 100-240 V~ 50/60 Hz 1.3 A

On Mode: 75 W (Typ.)

Sleep Mode: ≤ 0.5 W Off Mode: ≤ 0.5 W

969.6 mm x 563.9 mm x 54 mm / 10.0 kg

(38.1 inches x 22.2 inches x 2.1 inches / 22.0 lbs)

969.6 mm x 622.2 mm x 193 mm / 12.5 kg

(38.1 inches x 24.4 inches x 7.5 inches / 27.5 lbs)

49SE3D

LCD screen Pixel pitch

Power Rated power

Power consumption

Dimensions (Width x Height x Depth) / Weight

Head

Head + Stand

Head + Speaker

Head + Speaker + Stand

49SE3KD

LCD screen Pixel pitch

Power Rated power

Power consumption

Dimensions (Width x Height x Depth) / Weight

Head

Head + Stand

0.55926 mm (H) X 0.55926 mm (V)

ENGLISH

AC 100-240 V~ 50/60 Hz 1.0 A

On Mode: 60 W (Typ.)

Sleep Mode: ≤ 0.5 W Off Mode: ≤ 0.5 W

1102.2 mm x 638.5 mm x 38.6 mm / 13.9 kg

(43.3 inches x 25.1 inches x 1.5 inches / 30.6 lbs)

1102.2 mm x 696.8 mm x 219.6 mm / 17.2 kg

(43.3 inches x 27.4 inches x 8.6 inches / 37.9 lbs)

1102.2 mm x 638.5 mm x 67.9 mm / 14.4 kg

(43.3 inches x 25.1 inches x 2.6 inches / 31.7 lbs)

1102.2 mm x 696.8 mm x 219.6 mm / 17.7 kg

(43.3 inches x 27.4 inches x 8.6 inches / 39 lbs)

0.55926 mm (H) X 0.55926 mm (V)

AC 100-240 V~ 50/60 Hz 1.0 A

On Mode: 60 W (Typ.)

Sleep Mode: ≤ 0.5 W Off Mode: ≤ 0.5 W

1102.2 mm x 638.5 mm x 54 mm / 14.3 kg

(43.3 inches x 25.1 inches x 2.1 inches / 31.5 lbs)

1102.2 mm x 696.8 mm x 219.6 mm / 17.6 kg

(43.3 inches x 27.4 inches x 8.6 inches / 38.8 lbs)

49SH7DD

LCD screen Pixel pitch

Power Rated power

Power consumption

Dimensions (Width x Height x Depth) / Weight

Head

Head + Stand

0.55926 mm (H) X 0.55926 mm (V)

AC 100-240 V~ 50/60 Hz 1.4 A

On Mode: 85 W (Typ.)

Sleep Mode: ≤ 0.5 W Off Mode: ≤ 0.5 W

1102.2 mm x 638.5 mm x 54 mm / 14.3 kg

(43.3 inches x 25.1 inches x 2.1 inches / 31.5 lbs)

1102.2 mm x 696.8 mm x 219.6 mm / 17.6 kg

(43.3 inches x 27.4 inches x 8.6 inches / 38.8 lbs)

55SE3D

ENGLISH

LCD screen Pixel pitch

Power Rated power

Dimensions (Width x Height x Depth) / Weight

55SE3KD

LCD screen Pixel pitch

Power Rated power

Dimensions (Width x Height x Depth) / Weight

Power consumption

Head

Head + Stand

Head + Speaker

Head + Speaker + Stand

Power consumption

Head

Head + Stand

0.630 mm (H) x 0.630 mm (V)

AC 100-240 V~ 50/60 Hz 1.1 A

On Mode: 65 W (Typ.)

Sleep Mode: ≤ 0.5 W Off Mode: ≤ 0.5 W

1238 mm x 714.9 mm x 38.6 mm / 17.1 kg

(48.7 inches x 28.1 inches x 1.5 inches / 37.6 lbs) 1238 mm x 773.4 mm x 219.6 mm / 20.4 kg

(48.7 inches x 30.4 inches x 8.6 inches / 44.9 lbs) 1238 mm x 714.9 mm x 67.9 mm / 17.6 kg

(48.7 inches x 28.1 inches x 2.6 inches / 38.8 lbs) 1238 mm x 773.4 mm x 219.6 mm / 20.9 kg

(48.7 inches x 30.4 inches x 8.6 inches / 46.0 lbs)

0.630 mm (H) x 0.630 mm (V)

AC 100-240 V~ 50/60 Hz 1.1 A

On Mode: 65 W (Typ.)

Sleep Mode: ≤ 0.5 W Off Mode: ≤ 0.5 W

1238 mm x 714.9 mm x 54 mm / 17.5 kg

(48.7 inches x 28.1 inches x 2.1 inches / 38.5 lbs) 1238 mm x 773.4 mm x 219.6 mm / 20.8 kg

(48.7 inches x 30.4 inches x 8.6 inches / 45.8 lbs)

55SH7DD

LCD screen Pixel pitch

Power Rated power

Power consumption

Dimensions (Width x Height x Depth) / Weight

Head

Head + Stand

0.630 mm (H) x 0.630 mm (V)

AC 100-240 V~ 50/60 Hz 1.5 A

On Mode: 95 W (Typ.)

Sleep Mode: ≤ 0.5 W Off Mode: ≤ 0.5 W

1238 mm x 714.9 mm x 54 mm / 17.5 kg

(48.7 inches x 28.1 inches x 2.1 inches / 38.5 lbs) 1238 mm x 773.4 mm x 219.6 mm / 20.8 kg

(48.7 inches x 30.4 inches x 8.6 inches / 45.8 lbs)

65SE3D

LCD screen Pixel pitch

Power Rated power

Power consumption

Dimensions (Width x Height x Depth) / Weight

Head

Head + Stand

Head + Speaker

Head + Speaker + Stand

65SE3KD

LCD screen Pixel pitch

Power Rated power

Power consumption

Dimensions (Width x Height x Depth) / Weight

Head

Head + Stand

0.744 mm (H) x 0.744 mm (V)

ENGLISH

AC 100-240 V~ 50/60 Hz 1.4 A

On Mode: 90 W (Typ.)

Sleep Mode: ≤ 0.5 W Off Mode: ≤ 0.5 W

1456.9 mm x 838 mm x 41.1 mm / 27.7 kg

(57.3 inches x 32.9 inches x 1.6 inches / 61.0 lbs)

1456.9 mm x 898.1 mm x 293.7 mm / 32.9 kg

(57.3 inches x 35.3 inches x 11.5 inches / 72.5 lbs)

1456.9 mm x 838 mm x 70.4 mm / 28.2 kg

(57.3 inches x 32.9 inches x 2.7 inches / 62.1 lbs)

1456.9 mm x 898.1 mm x 293.7 mm / 33.4 kg

(57.3 inches x 35.3 inches x 11.5 inches / 73.6 lbs)

0.744 mm (H) x 0.744 mm (V)

AC 100-240 V~ 50/60 Hz 1.4 A

On Mode: 90 W (Typ.)

Sleep Mode: ≤ 0.5 W Off Mode: ≤ 0.5 W

1456.9 mm x 838 mm x 56.5 mm / 27.9 kg

(57.3 inches x 32.9 inches x 2.2 inches / 61.5 lbs)

1456.9 mm x 898.1 mm x 293.7 mm / 33.1 kg

(57.3 inches x 35.3 inches x 11.5 inches / 72.9 lbs)

RGB (PC) Support Mode

ENGLISH

Resolution Horizontal frequency (kHz) Vertical frequency (Hz)

720 x 400 31.468 70.8

640 x 480 31.469 59.94

800 x 600 37.879 60.317

1024 x 768 48.363 60

1280 x 720 44.772 59.855

1280 x 960 60 60

1152 x 864 57.717 59.934

1280 x 1024

1920 x 1080 67.5 60

HDMI/ DVI-D (PC) Support mode

Resolution Horizontal frequency (kHz) Vertical frequency (Hz)

640 x 480 31.469 59.94

800 x 600 37.879 60.317

1024 x 768 48.363 60

1280 x 720 44.772 59.855

1366 x 768 47.7 60

1280 x 1024 63.981 60.02

1680 x 1050 65.29 59.954

1920 x 1080 67.5 60

63.981 60.02

HDMI (DTV) Support Mode

Resolution Horizontal frequency (kHz) Vertical frequency (Hz)

480/60p 31.5 60

576/50p 31.25 50

720/50p 37.5 50

720/60p

1080/50i 28.1 50

1080/60i

1080/50p 56.25 50

1080/60p 67.5 60

45 60

33.75 60

NOTE

• Resolutions available for the Input Label option in RGB, HDMI/ DVI-D input modes.

- PC resolutions: 640 x 480 / 60 Hz, 1280 x 720 / 60 Hz, 1920 x 1080 / 60 Hz

- DTV resolutions: 480p, 720p, 1080p

• Vertical frequency: The product display functions by the screen image changing dozens of times every second like a

fluorescent lamp. The vertical frequency or refresh rate is the number of image displays per second. The unit is Hz.

• Horizontal frequency: The horizontal interval is the time taken to display one horizontal line. When 1 is divided by

the horizontal interval, the number of horizontal lines displayed every second can be tabulated as the horizontal frequency. The unit is kHz.

ENGLISH

ENERGY STAR® is a set of power-saving

S. A.,

Make sure to read the Safety Precautions before using the product.

The model and serial numbers of the SET are located on the back and one side of the SET. Record it below should you ever need service.

guidelines issued by the U.S.Environmental Protection Agency (EPA). As an ENERGY STAR® Partner LGE U. Inc. has determined that this product meets the ENERGY STAR® guidelines for

energy efficiency. Refer to ENERGYSTAR.gov for more information on the ENERGY STAR® program.

MODEL

SERIAL

Temporary noise is normal when powering ON or OFF this device.

SW USER GUIDE

LG Digital Signage

(MONITOR SIGNAGE)

Please read this manual carefully before operating your set and retain it for future reference.

L15

www.lg.com

TABLE OF CONTENTS

ENGLISH

USING THE MONITOR ...................3

- Using the Input List .........................................................3

- Adjusting Aspect Ratio ..................................................3

ENTERTAINMENT .........................5

- Using the Network .......................................................... 5

Connecting to a Network

Network Status

- Using the My Media ........................................................ 9

Connecting USB storage devices

Browsing Files

Viewing Movies

Viewing Photos

Listening to Music

Viewing the Contents List

CUSTOMIZING SETTINGS ......... 21

- Accessing Main Menus ...............................................21

PICTURE Settings

AUDIO Settings

TIME Settings

OPTION Settings

NETWORK Settings

- PICTURE ID Settings ....................................................32

IR CODES .................................... 33

TO CONTROL MULTIPLE

PRODUCTS .................................. 34

- Connecting the Cable .................................................. 34

- RS-232C Configurations ...........................................35

4P Cable

RS-232C Cable

- Communication Parameter ......................................35

- Command Reference List ..........................................36

- Transmission / Receiving Protocol ........................38

Open Source Software Notice Information

To obtain the source code under GPL, LGPL, MPL, and other open source licenses, that is contained in this product, please visit http://opensource.lge.com.

In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download.

LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping, and handling) upon email request to opensource@lge.com.

This offer is valid for a period of three years after our last shipment of this product. This offer is valid to anyone in receipt of this information.

USING THE MONITOR

Using the Input List

1 Press to access the Input List. 2 Press the navigation buttons to scroll to one of the input mode and press .

- RGB-PC

- HDMI

- HDMI2

- DVI-D

- USB

- Display Port

- OPS

NOTE

• Some input signals may not be supported depending on the model.

Adjusting Aspect Ratio

Resize the image to view the image at its optimal size by pressing ARC while you are watching monitor set.

MODE

Aspect Ratio

16:9 o o o o o o o o o Just Scan

Set By Program

4:3

Zoom

Cinema Zoom1

RGB HDMI DVI-D Display Port OPS

PC DTV PC DTV PC DTV PC DTV PC

x o x o x o x o x

o o o o o o o o o

x o x o x o x o x

ENGLISH

NOTE

• You can also change the image size by accessing the main menus.

• The Just Scan mode operates when a video signal has resolution of 720p or higher.

ENGLISH

CAUTION

• If a fixed image displays on the screen for a long period of time, it will be imprinted and become a permanent

disfigurement on the screen. This is image burn or burn-in and not covered by the warranty.

• If you don’t use your monitor, turn the power off or set a screen saver program from the PC or the system to prevent

image retention.

• If the aspect ratio is set to 4:3 for a long period of time, image burn may occur on the letterboxed area of the screen.

• 16:9 : This selection will allow you to adjust the picture horizontally, in linear proportion, to fill the entire screen

(useful for viewing 4:3 formatted DVDs).

• Just Scan : This Selection will allow you view the picture of best quality without loss of original picture in high

resolution image. Note: If there is noise in original Picture, You can see the noise at the edge.

• Set By Program : Depending on the input signal, screen aspect ratio changes to 4:3 or 16:9.

• 4:3 : This selection will allow you to view a picture with an original 4:3 aspect ratio, black bars will appear on both the

left and right of the screen.

• Zoom : This selection will allow you to view the picture without any alteration, while filling the entire screen. However,

the top and bottom of the picture will be cropped.

• Cinema Zoom1 : Choose Cinema Zoom when you want to enlarge the picture in correct proportion. Note: When

enlarging or reducing the picture, the image may become distorted.

ENTERTAINMENT

Using the Network

Connecting to a Network

For wired network connections, connect the display to a local area network (LAN) via the LAN port as shown on the following diagram. Then, set up the network settings. For wireless network connections, connect the Wi-Fi USB module to the USB port. Then, set up the network settings.

After making a physical connection, a small number of home networks may require the display network settings to be adjusted. For most home networks, the display will connect to automatically without any adjustments.

For detail information, contact your internet provider or router manual.

LAN

Router

LANWAN

ENGLISH

Cable modem

ETHERNET

Internet

CAUTION

• Do not connect a modular phone cable to the LAN port.

• Since there are various connection methods, please follow the specifications of your telecommunication carrier or

internet service provider.

To set up the network settings: (Even if your display has already connected automatically, running setup again will not

ENGLISH

harm anything),

Connecting to a wired network

1 Press to access the main menus. 2 Press the navigation buttons to scroll to NETWORK and press .

3 Press the navigation buttons to select Network Setting and press . 4 If you already set network setting, select Resetting. The new connection settings resets the current network

settings.

5 Select IP Auto Setting or IP Manual Setting.

- IP Manual Setting press the navigation and number buttons. IP addresses will need to be input manually.

- IP Auto Setting Select this if there is a DHCP server (Router) on the local area network (LAN) via wired connection, the display will automatically be allocated an IP address. If you’re using a broadband router or broadband modem that has a DHCP (Dynamic Host Configuration Protocol) server function. The IP address will automatically be determined.

6 When you are finished, press .

Connecting to a wireless network

1 Press to access the main menus. 2 Press the navigation buttons to scroll to NETWORK and press .

3 Press the navigation buttons to select Network Setting and press . 4 Select Setting from the AP list or Simple setting (WPS-button mode).

- Setting from the AP list Select an AP to connect to a wireless network.

- Simple setting (WPS-button mode) Press the button on the wireless router that supports PBC to easily connect to the router.

5 When you are finished, press .

CAUTION

• Network setting menu will not be available until the display connected to physical network.

• Since there are various connection methods, please follow the specifications of your telecommunication carrier or

internet service provider.

• When a Wi-Fi dongle is used with a model that has only one USB input port, the distribution or content schedule via

the SuperSign software is not available.

NOTE

• If you want to access the Internet directly on your display, the Internet connection should always be on.

• If you cannot access the Internet, check the network conditions from a PC on your network.

• When you use Network Setting, check the LAN cable or check if DHCP in the router is turned on.

• If you do not complete the network settings, the network may not work properly.

• When connected to a network that supports IPv6, you can select IPv4/IPv6 in the advanced wired/wireless network

setting. But, IPv6 connection only supports automatic connection.

Tips for Network setting

• Use a standard LAN cable with this display. Cat5 or better with a RJ45 connector.

• Many network connection problems during set up can often be fixed by re-setting the router or modem. After

connecting the display to the home network, quickly power off and/or disconnect the power cable of the home network router or cable modem. Then power on and/or connect the power cable again.

• Depending on the internet service provider (ISP), the number of devices that can receive internet service may be

limited by the applicable terms of service. For details, contact your ISP.

• LG is not responsible for any malfunction of the display and/or the internet connection feature due to communication

errors/malfunctions associated with your internet connection, or other connected equipment.

• LG is not responsible for problems within your internet connection.

• You may experience undesired results if the network connection speed does not meet the requirements of the

content being accessed.

• Some internet connection operations may not be possible due to certain restrictions set by the Internet service

provider (ISP) supplying your Internet connection.

• Any fees charged by an ISP including, without limitation, connection charges are your respon- sibility.

• A 10 Base-T or 100 Base-TX LAN port is required when using a wired connection to this display. If your internet

service does not allow for such a connection, you will not be able to connect the display.

• A DSL modem is required to use DSL service and a cable modem is required to use cable modem service. Depending

on the access method of and subscriber agreement with your ISP, you may not be able to use the internet connection feature contained in this display or you may be limited to the number of devices you can connect at the same time. (If your ISP limits subscription to one device, this display may not be allowed to connect when a PC is already connected.)

• The use of a router may not be allowed or its usage may be limited depending on the policies and restrictions of your

ISP. For details, contact your ISP directly.

Tips for Wireless Network Setting

• Wireless networks can be subject to interference from other devices operating at a frequency of 2.4 GHz (wireless

phones, Bluetooth devices, or microwave ovens). There may also be interference from devices with a frequency of 5 GHz, same as other Wi-Fi devices.

• The surrounding wireless environment can cause the wireless network service to run slowly.

• For an AP connection, an access point device that supports wireless connection is required and the wireless

connection feature must be enabled on the device. Contact your service provider regarding availability of wireless connection on your access point.

• Check the SSID and security settings of the AP for AP connection. Refer to the appropriate documentation for SSID

and security settings of the AP.

• Invalid settings on network devices (wired/wireless line sharer, hub) can cause the monitor to run slowly or not

operate properly. Install the devices correctly according to the appropriate manual and set the network.

• Connection method may differ according to the AP manufacturer.

ENGLISH

Network Status

ENGLISH

1 Press to access the main menus. 2 Press the navigation buttons to scroll to NETWORK and press .

3 Press the navigation buttons to select Network Status. 4 Press to check the network status. 5 When you are finished, press .

Option Description

Setting Return to the network setting menu.

Test Test the current network status after setting the network.

Close Return to the previous menu.

Using the My Media

Connecting USB storage devices

Connect USB storage devices such as a USB flash memory, external hard drive to the display and use multimedia features.

Connect a USB flash memory or USB memory card reader to the Display as shown on the following illustration. The My Media screen appears.

ENGLISH

CAUTION

• Do not turn the display off or remove a USB storage device while MY MEDIA menu is activated, as this could result

in loss of files or damage to the USB storage device.

• Back up your files saved on a USB storage device frequently, as you may lose or damage the files and this may be not

covered by the warranty.

Tips for using USB storage devices

ENGLISH

• Only a USB storage device is recognizable.

• If the USB storage device is connected through a USB hub, the device is not recognizable.

• A USB storage device using an automatic recognition program may not be recognized.

• A USB storage device which uses its own driver will not be recognized.

• The recognition speed of a USB storage device may depend on each device.

• Please do not turn off the display or unplug the USB device when the connected USB storage device is working.

When such a device is suddenly separated or unplugged, the stored files or the USB storage device may be damaged.

• Please do not connect the USB storage device which was artificially maneuvered on the PC. The device may cause the

product to malfunction. Only use a USB storage device which has normal music files, image files or movie files.

• Please only use USB storage devices formatted using the FAT32 file system. Storage devices formatted with utility

programs that are not supported by Windows may not be recognized.

• Please connect power to a USB storage device (over 0.5 A) which requires an external power supply. If not, the device

may not be recognized.

• Please connect a USB storage device with the cable included by the device maker.

• Some USB storage devices may not be supported or operate smoothly.

• File alignment method of USB storage devices is similar to Window XP and the monitor can recognize up to 100

English characters.

• Be sure to back up important files since data stored on a USB memory device may be damaged. We will not be

responsible for any data loss.

• If the USB HDD does not have an external power source, the USB device may not be detected. So be sure to connect

the external power source.

- Please use a power adaptor for an external power source.

• If your USB memory device has multiple partitions, or if you use a USB multi-card reader, you can use up to 4

partitions or USB memory devices.

• If a USB memory device is connected to a USB multi-card reader, its volume data may not be detected.

• If the USB memory device does not work properly, disconnect and reconnect it.

• How fast a USB memory device is detected differs from device to device.

• If the USB is connected in Standby Mode, that drive will automatically be loaded when the display is turned on.

• The recommended capacity is 1 TB or less for a USB external hard disk and 32 GB or less for USB memory.

• Any device with more than the recommended capacity may not work properly.

• If a USB external hard disk with a Energy Saving function does not work, turn the hard disk off and on again to make

it work properly.

• USB storage devices below USB 2.0 are supported as well. But they may not work properly with videos.

• A maximum of 999 folders or files can be recognized under one folder.

• A USB 3.0 storage device may not work.

• Data on some USB storage devices may be damaged in a high temperature environment.

• It is recommended that you avoid playing contents using more than two USB ports simultaneously.

Browsing Files

Browse files saved in a USB storage device.

1 Press to access the main menu. 2 Press the search button to scroll to and press .

3 Press the Search button to go to the Movie List, Photo List, Music List, or Content List that you want, and press

Supported file format

Type Supported file format

Movie Codec Media Container Profile

Video MPEG1 / MPEG2 DAT, MPG, MPEG,

TS, TP

MPEG4 (DivX 3.11, DivX 4, DivX 5, DivX 6, Xvid 1.01, Xvid 1.02, Xvid

1.03, Xvid 1.10-beta1/2)

H.264 AVI, MP4, MKV, TS,

Audio MP3 MP3 8 kbps - 320 kbps(Bit rate)

AC3 AC3 32 kbps - 640 kbps(Bit rate)

MPEG MP3 32 kbps - 448 kbps(Bit rate)

AAC, HEAAC MP4 8 kHz - 48 kHz(Sample rate)

AVI, DIVX, MP4, MKV, TS, TRP

TRP, TP

1080P @ 30 fps

1080P @ 60 fps

16 kHz - 48 kHz(Sample rate)

32 kHz, 44.1 kHz, 48 kHz(Sample rate)

16 kHz - 48 kHz(Sample rate)

ENGLISH

LPCM AVI, WAV 64 kbps - 1.5 Mbps(Bit rate)

8 kHz - 48 kHz(Sample rate)

Bit rate : within 8 kbps to 320 kbps(MP3) External Subtitle format : *.smi/*.srt/*.sub(MicroDVD, Subviewer1.0/2.0)/*.ass/*.ssa/*.txt(TMPlayer)/

*.psb(PowerDivX) Internal Subtitle format : only, XSUB (It is the subtitle format used in DivX6 files)

Type Supported file format

Photo Min : 64 x 64

ENGLISH

Music mp3

Content (when using SuperSign software)

Max : Normal Type: 15360 (W) x 8640 (H) Progressive Type: 1920 (W) x 1440 (H) BMP Min : 64 x 64 Max : 9600 x 6400 PNG Min : 64 x 64 Max : Interlace: 1200 x 800 Non-Interlace: 9600 x 6400

• Non-supported files are displayed in the form of predefined icon.

[Bit rate] 32 kbps ~ 320 kbps [Sample freq] 16 kHz ~ 48 kHz [Support] MPEG1, MPEG2, Layer2, Layer3 AAC [Bit rate] Free Format [Sample freq.] 8 kHz ~ 48 kHz [Support] ADIF, ADTS M4A [Bit rate] Free Format [Sample freq.] 8 kHz ~ 48 kHz [Support] MPEG-4 OGG [Bit rate] Free Format [Sample freq.] ~ 48 kHz [Support] Vorbis WMA [Bit rate] 128 kbps ~ 320 kbps [Sample freq.] 8 kHz ~ 48 kHz [Support] WMA7, 8, 9 Standard WMA 10 Pro [Bit rate] ~768 kbps [Channel / Sample freq.] M0 : Up to 2 / 48 kHz M1 : Up to 5.1 / 48 kHz M2 : Up to 5.1 / 96 kHz [Support] WMA 10 Pro

File Extensions : *.cts/ *.sce Movie File Extensions: *.mpg/*.mpeg/*.dat/*.ts/*.trp/*.tp/*.mp4/*.mkv/*.avi/*. avi(motion JPEG)/*.

mp4(motion JPEG)/*.mkv(motion JPEG) Video format: MPEG1, MPEG2, MPEG4,H.264, DivX 3.11, DivX 4, DivX 5, DivX 6,

Xvid 1.00,Xvid 1.01, Xvid 1.02, Xvid 1.03,Xvid 1.10-beta1/2, JPEG Audio format: MP3, Dolby Digital, LPCM, AAC, HE-AAC

Viewing Movies

Plays movie files saved in the USB storage device.

1 Press to access the main menu. 2 Press the navigation button to scroll to MY MEDIA and press .

3 Press the navigation button to scroll to Movie List and press . 4 Press the navigation buttons to scroll to a folder you want and press . 5 Press the navigation buttons to scroll to a file you want and press .

- Change Device : Selects the USB storage device. (Depending on model)

- Go to root folder : Returns to the home screen of My Media.

- Go to upper folder : Returns to the previous screen.

- Exit : Exits My Media.

6 During movie playback, press to access the following settings.

Remote

button

Stops the playback.

Plays a video.

Pauses or resumes the playback.

Scans backward in a file.

Scans forward in a file.

Adjusts the screen brightness to save energy.

Show the Option menu.

Hide the menu on the full-sized screen.

Returns to Movie List.

Skips to specific points in a file during playback. The time of a specific point will appear on the status bar. In some files, this function may not work properly.

Description

ENGLISH

Tips for using playing video files

ENGLISH

• Some user-created subtitles may not work properly.

• Some special characters are not supported in subtitles.

• HTML tags are not supported in subtitles.

• Subtitles in languages other than the supported languages are not available.

• The screen may suffer temporary interruptions (image stoppage, faster playback, etc.) when the audio language is

changed.

• A damaged movie file may not be played correctly, or some player functions may not be usable.

• Movie files produced with some encoders may not be played correctly.

• If the video and audio structure of recorded file is not interleaved, either video or audio is outputted.

• HD videos with a maximum of 1920 x 1080 @ 25/30p or 1280 x 720 @ 50/60p are supported, depending on the

frame.

• Videos with resolutions higher than 1920 x 1080 @ 25/30p or 1280 x 720 @ 50/60p may not work properly

depending on the frame.

• Movie files other than the specified types and formats may not work properly.

• Max bitrate of playable movie file is 20 Mbps. (only, Motion JPEG : 10 Mbps)

• We do not guarantee smooth playback of profiles encoded level 4.1 or higher in H.264/AVC.

• DTS Audio codec is not supported.

• A movie file more than 30 GB in file size is not supported for playback.

• A DivX movie file and its subtitle file must be located in the same folder.

• A video file name and its subtitle file name must be identical for it to be displayed.

• Playing a video via a USB connection that doesn’t support high speed may not work properly.

• Files encoded with GMC(Global Motion Compensation) may not be played.

Video options

1 Press to access the Pop-Up menus. 2 Press the navigation buttons to scroll to Set Video Play, Set Video, or Set Audio, and press .

NOTE

• The option values changed in Movie List do not affect Photo List or Music List. Therefore, they are not affected by

option values changed in Photo List or Music List.

• The option values changed in Photo List and Music List do affect each other.

• When replaying the video file after stopping, you can play from where it stopped previously.

Select Set Video Play to access the following menus:

Menu Description Picture Size Selects your desired picture format during movie play. Audio

Language Subtitle

Language Language Activated for SMI subtitle and can select the language within the subtitle. Code Page Can select the font for subtitle.

Sync Adjusts the time synchronisation of the subtitle from -10 secs to +10 secs by steps of 0.5 secs

Position Changes the position of the subtitle either up or down during movie play. Size Selects your desired Subtitle size during movie play.

Repeat Turn on/off repeat function of movie playback. When turned on, the file within the folder will be

Changes the Language Group of the audio during movie play. Files with a single audio track cannot be selected.

Turn on/off the subtitle.

When set to default, same font as general menu will be used.

during movie play.

played back repeatedly. Even when the repeated playback is turned off, it can run the playback if the file name is similar to the previous file.

NOTE

• Only 10,000 of sync blocks can be supported within the subtitle file.

• When playing a video, you can adjust the picture size by pressing the ARC button.

• Subtitles in your language are only supported when the OSD menu is also in this language.

• The code page options may be disabled depending on the language of the subtitle files.

• Select the appropriate code page for the subtitle files.

ENGLISH

Viewing Photos

View image files saved in the USB storage device.

ENGLISH

1 Press to access the main menu. 2 Press the navigation button to scroll to MY MEDIA and press .

3 Press the navigation button to scroll to Photo List and press . 4 Press the navigation buttons to scroll to a folder you want and press . 5 Press the navigation buttons to scroll to a file you want and press .

- Change Device : Selects the USB storage device. (Depending on model)

- Go to root folder : Returns to the home screen of My Media.

- Go to upper folder : Returns to the previous screen.

- Exit : Exits My Media.

6 While viewing photos, you can access the following settings.

Menu Description

Slideshow Starts or stops a slideshow with selected photos. If there are no selected photos, all photos saved

in the current folder display during a slideshow. To set a slideshow speed, select Option.

BGM Turns the background music on or off. To set the background music folder, select Option.

You can adjust option by button on the remote control.

Rotates photos clockwise (90 °, 180 °, 270 °, 360 °).

NOTE

• The supported photo size is limited. You cannot rotate a photo if the resolution of the rotated

width is larger than the supported resolution size.

Enlarges the photo by 100 %, 200 % or 400 %.

Adjusts the brightness of the screen for energy saving.

Option To display the options.

Hide Hides the option window.

Exit Return to Photo List.

Photo options

1 Press to show the Option menus. 2 Press the navigation buttons to scroll to Set Photo View, Set Video, or Set Audio, and press .

NOTE

• The option values changed in Movie List do not affect Photo List or Music List. Therefore, they are not affected by

option values changed in Photo List or Music List.

• The option values changed in Photo List and Music List do affect each other.

Select Setting Photo View to access the following menus:

Menu Description

Slide Speed Select a slideshow speed.

(Options: Fast, Medium, or Slow.)

BGM Selects a music folder for the background music.

Repeat Plays background music on repeat.

Random Plays background music in random order.

Listening to Music

Plays music files saved in the USB storage device.

1 Press to access the main menu. 2 Press the navigation button to scroll to MY MEDIA and press .

3 Press the navigation button to scroll to Music List and press . 4 Press the navigation buttons to scroll to a folder you want and press . 5 Press the navigation buttons to scroll to a file you want and press .

- Change Device : Selects the USB storage device. (Depending on model)

- Go to root folder : Returns to the home screen of My Media.

- Open Music Player : Opens the settings window for music. This feature is activated only during playback.

- Go to upper folder : Returns to the previous screen.

- Exit : Exits My Media.

6 During music playback, press to access the following settings.

Remote

button

Stops playing back the file and moves back to the Music List.

Plays a music file.

Pauses or resumes playback.

Skips to the previous file.

Skips to the next file.

Adjusts the brightness of the screen for energy saving (Off and Screen Off work only.)

Show the Option menu.

Hides the option window.

Description

ENGLISH

Return to Music List.

Tips for playing music files

• This unit cannot support the ID3 Tag embedded MP3 files.

Skips to specific points in a file during playback. The time of a specific point will appear on the status bar. In some files, this function may not work properly.

NOTE

• A damaged or corrupted music file does not play but displays 00:00 in playtime.

• A music downloaded from a paid service with copyright protection does not start but displays inappropriate

information in playtime.

• If you press , buttons, screen saver is stopped.

• The , , , , buttons on the remote control are also available in this mode.

• You can use the button to select the next music and the button to select the previous music.

ENGLISH

HR1.mp3

01:40 / 03:03

Time elapsed/ Duration

Music options

file name

1 Press to access the pop-up menus. 2 Press the navigation buttons to scroll to Set Audio Play or Set Audio and press .

NOTE

• The option values changed in Movie List do not affect Photo List or Music List. Therefore, they are not affected by

option values changed in Photo List or Music List.

• The option values changed in Photo List and Music List do affect each other.

When you select the Set Audio Play,

Menu Description

Repeat Repeats the music playback.

Random Plays random music tracks.

Viewing the Contents List

You can play the files saved using the Export function to an external file in the SuperSign Software.

1 Press to access the main menu. 2 Press the navigation button to scroll to MY MEDIA and press .

3 Press the navigation button to scroll to Contents List and press . 4 Press the navigation buttons to scroll to a folder you want and press . 5 Press the navigation buttons to scroll to a file you want and press .

- Change Device : Selects the USB storage device. (Depending on model)

- Go to root folder : Returns to the home screen of My Media.

- Go to upper folder : Returns to the previous screen.

- Exit : Exits My Media.

NOTE

• While playing media files from Contents List, only the , , or volume button are available. Selecting the

or button stops playing media files and returns to the Contents List.

• When you use the distribution feature which utilizes SuperSign Software, the storage device used to store contents

is determined based on the size of the remaining memory space. (Note: If USB ports 1 and 2 have the same memory space, contents will be saved on the storage device connected to USB port 1.(Depending on model))

• If there is the AutoPlay folder in the USB device and its files are in supported formats, they can be played back

automatically when the USB device is connected to the monitor.

• It is recommended that you avoid playing contents using more than two USB ports simultaneously.

• With respect to the playback of distribution or contents schedules through SuperSign Software, the schedule

executed last time is played.

ENGLISH

Supported Video Codec

ENGLISH

Extension Codec

.asf .wmv

.divx .avi

.mp4 .m4v .mov

.3gp .3g2

.mkv Videos H.264/AVC

.ts .trp .tp .mts .m2ts

.mpg .mpeg

.vo b Videos MPEG-1, MPEG-2

Videos VC-1 Simple and Main Profiles

Audio WMA Standard, WMA 10 Professional

Videos DivX3.11, DivX4, DivX5, DivX6, XViD, H.264/AVC, Motion Jpeg, MPEG-4 Part2

Audio MPEG-1 Layer I, II, MPEG-1 Layer III (MP3), Dolby Digital, LPCM, ADPCM, DTS

Videos H.264/AVC, MPEG-4 Part2

Audio AAC, MPEG-1 Layer III (MP3)

Videos H.264/AVC, MPEG-4 Part2

Audio AAC, AMR-NB, AMR-WB

Audio HE-AAC, Dolby Digital

Videos H.264/AVC, MPEG-2

Audio MPEG-1 Layer I, II, MPEG-1 Layer III (MP3), Dolby Digital, Dolby Digital Plus,

Videos MPEG-1, MPEG-2

Audio MPEG-1 Layer I, II, MPEG-1 Layer III (MP3), AAC

Audio Dolby Digital, MPEG-1 Layer I, II, DVD-LPCM

AAC, PCM

Tips for Playing Video Files

• A damaged movie file may not play correctly, or some player features may not be usable.

• Movie files produced with some encoders may not be played correctly.

• Movie files other than the specified types and formats may not work properly.

• Max bit rate of playable movie file is 20 Mbps. (For Motion JPEG: 10 Mbps only)

• We do not guarantee smooth playback of profiles encoded level 4.1 or higher in H.264 / AVC.

• Video files larger than 50 MB may not upload properly from mobile devices. We recommend that you play such files

via USB/SD storage devices.

• [For Ultra HD models only] Ultra HD image: 3840 X 2160

Some HEVC-encoded Ultra HD videos other than the content officially provided by LG Electronics may not be played.

Extension Codec

.mkv .mp4 .ts

• Some codecs can be used after upgrading software.

Video H.264/AVC, HEVC

Audio Dolby Digital, Dolby Digital Plus, AAC, HE-AAC

CUSTOMIZING SETTINGS

Accessing Main Menus

1 Press to access the main menus. 2 Press the navigation buttons to scroll to one of the following menus and press .

3 Press the navigation buttons to scroll to the setting or option you want and press . 4 When you are finished, press . When you return to the previous menu, press .

- PICTURE : Adjusts the image size, quality, or effect.

- AUDIO : Adjusts the sound quality, effect, or volume level.

- TIME : Sets the time, date, or timer feature.

- OPTION : Customizes the general settings.

- NETWORK : Sets up the network setting.

- MY MEDIA : Display and play movie, photo and music contents stored on your USB or signage device (Internal storage device).

PICTURE Settings

1 Press to access the main menus. 2 Press the navigation buttons to scroll to PICTURE and press .

3 Press the navigation buttons to scroll to the setting or option you want and press .

- To return to the previous level, press .

4 When you are finished, press .

When you return to the previous menu, press .

ENGLISH

The available picture settings are described in the following:

ENGLISH

Setting Description

Energy

Saving

Smart Energy

Saving

Picture Mode Selects the picture mode optimized for the viewing environment or the programme.

Aspect Ratio Changes the image size to view images at its optimal size.

reduces power consumption by adjusting peak screen brightness.

Level Off Disables Energy Saving function.

Minimum/Medium/ Maximum

Screen Off The screen turns off in 3 seconds.

Adjusts the backlight and contrast depending on the screen brightness.

Level

Off Disables the Smart Energy Saving function.

On Enables the Smart Energy Saving function to save power consumption as

Mode

Vivid Heightens contrast, brightness, and sharpness to display vivid images.

Standard Displays images in standard levels of contrast, brightness, and sharpness. APS APS ( Auto power saving ) mode reduces power consumption by dimming

Cinema Optimizes the video image for a cinematic look to enjoy movies as if you are

Sport Optimizes the video image for high and dynamic actions by emphasizing

Game Optimizes the video image for a fast gaming screen such as PCs or games.

Calibration Applies user-customized white balance based on Standard.

Expert1·2 Menu for adjusting picture quality that allows experts and amateurs to enjoy

Selects the brightness level of the backlight.

much as the value set in the smart energy saving rate.

control.

in a movie theater.

primary Colors such as white, grass, or sky blue.

the best Monitor viewing.

Setting Description

Screen

(In RGB Mode Only)

Basic image options

Setting Description

Backlight

Contrast Increases or decreases the gradient of the video signal. You may use Contrast when the bright

Brightness Adjusts the base level of the signal in the picture. You may use Brightness when the dark part of

Sharpness

Color

Tint

Color Temp.

Customizes the PC display options in RGB mode.

Option

Resolution Selects a proper resolution.

Auto Configure Sets to adjust the screen position, clock, and phase automatically.

The displayed image may be unstable for a few seconds while the configuration is in progress.

Position/Size/ Phase

Reset Restores the options to the default setting.

Adjusts the brightness of the screen by controlling the LCD backlight. If you decrease the brightness level, the screen becomes darker and the power consumption will be reduced without any video signal loss.

part of the picture is saturated.

the picture is saturated. Adjusts the level of crispness in the edges between the light and dark areas of the picture. The

lower the level, the softer the image. Adjusts intensity of all colors.

Adjusts the balance between red and green levels.

Set to warm to enhance hotter Colors such as red, or set to cool to make picture bluish.

Adjusts the options when the picture is not clear, especially when characters are shaky, after the auto configuration.

ENGLISH

Advanced Control/

Expert Control

Picture Option

Picture Reset

You can adjust the picture for each Picture Mode, or adjust the picture settings according to a specific picture image. First, select a desired Picture Mode.

* This option is unavailable if Picture Mode is set to Vivid.

Sets additional picture option.

Restores the options to the default setting.

NOTE

• When you select a picture mode, related menus are set automatically.

• When using the Smart Energy Saving function, the screen may look saturated in the white area of a still image.

• If Energy Saving is set to Minimum, Medium, or Maximum, the Smart Energy Saving function is disabled.

Advanced Control - Picture Mode (Standard/ APS/ Sport/ Game/ Calibration)

ENGLISH

Setting Description

Dynamic Contrast

Dynamic Color

Color Gamut

Skin Color Skin color spectrum can be separately set to implement the skin color as defined by the

Sky Color Sky color is set separately.

Grass Color Natural color spectrum (meadows, hills, etc.) can be separately set.

Gamma

Expert Control - Picture Mode (Cinema/ Expert1/ Expert2)

Setting Description

Dynamic Contrast

Color Gamut

Edge Enhancer

Color Filter

Color Temperature

Color Management System

Adjusts the contrast to the optimal level according to the brightness of the image.

Adjusts color for more natural-looking colors.

Selects the range of colours that can be expressed.

user.

Sets the gradation curve according to the output of the picture signal in relation to the input signal.

Adjusts the contrast to the optimal level according to the brightness of the image. (Function works in the following mode - HDMI-DTV) Selects the range of colours that can be expressed.

Shows clearer and distinctive yet natural edges of the video.

Filters a specific colour spectrum in RGB colours to fine-tune colour saturation and hue accurately.

Adjusts the overall tone of the screen as desired. In Expert mode, detailed fine-tuning can be set via Gamma method, etc.

This is a system that experts use when they adjust colour with a test pattern. They can select from six colour areas (Red / Green / Blue / Cyan / Magenta / Yellow) without affecting other colours. For normal images, adjustments may not result in noticeable colour changes.

Picture Option - HDMI(DTV) Mode

Setting Description

Noise Reduction

MPEG Noise

Reduction

Black Level

Real Cinema

TruMotion

(This feature is supported by 65SE3B and 65SE3KB only.)

Reduces screen noise in the video.

Reduces noise caused by compressing digital video.

Adjusts the black level of the picture to correct the brightness and contrast of the picture.(Recommended settings according to input signal: RGB 0–255: High, RGB 16–235: Low, YCbCr: Low)

Optimizes the screen for movie viewing.

Corrects images to display smoother motion sequences.

• Off : Turn off the TruMotion.

• Smooth/ Clear : De-Judder / De-Blur can be set Auto.

• User : De-Judder / De-Blur can be set manually.

- De-Judder : This function adjusts juddering of the screen.

- De-Blur : This function adjusts and eliminates blurring of the screen.

TruMotion

• De-Judder Auto

• De-Blur Auto

ENGLISH

Smooth

AUDIO Settings

ENGLISH

1 Press to access the main menus. 2 Press the navigation buttons to scroll to and press .

3 Press the navigation buttons to scroll to the setting or option you want and press .

- To return to the previous level, press .

4 When you are finished, press .

When you return to the previous menu, press .

The available audio options are described in the following:

Setting Description

Sound Mode

Sound Effect

AV Sync. Adjust

Allows optimized sound for custom Monitor installation.

Level

Standard

News/ Music/ Cinema/ Sport/ Game

The user can select various sound effects.

- Sound Effect function is available only for Standard mode in Sound Mode menu.

Level

Clear Voice ll

Virtual Surround

Equalizer Adjusts the volume to a level of your choice using the Equalizer. Balance Adjusts left/right audio balance. Reset You can reset the settings under the Sound Effects menu.

Synchronizes video and audio directly when they do not match. If you set AV Sync. to ON, you can adjust the sound output to the screen image.

• Speaker: Adjusts the synchronization of the sound from the speakers. The “-” button makes

the sound output faster and the “+” button slower than the default value.

• Bypass : The audio of an external device without audio delay. Audio may be output before

video as it takes time to process video input into the Monitor.

Suitable for all types of video.

Sets audio optimized for a specific genre.

Boosts voice clarity.

LG’s proprietary audio processing technology allows 5.1ch-like surround sound from two speakers.

- If Clear Voice ll is set to On, Virtual Surround will not be chosen.

NOTE

• Some models may not have built-in speakers. In that case, you need to connect external speakers to listen to sound.

TIME Settings

1 Press to access the main menus. 2 Press the navigation buttons to scroll to TIME and press .

3 Press the navigation buttons to scroll to the setting or option you want and press .

- To return to the previous level, press .

4 When you are finished, press .

When you return to the previous menu, press .

The available time settings are described in the following:

Setting Description

Clock Sets the time feature.

Level

Auto

Manual

On/Off Time Sets the time to turn on or off the monitor set.

Auto Off (15Min.) If Auto-off is active and there is no input signal, the set switches to off mode automatically

after 15 minutes.

Automatic Standby If the monitor is left unattended for a set period of time, it automatically goes into standby

mode.

Daylight Saving Time

Set the start and end times for Daylight Saving Time. The DST start/end times function only when you set them more than one day apart from each other.

The current time is entered according to the selected country when connected to a network.

The current time needs to be entered manually.

NOTE

• Off Time/ On Time can be saved for up to seven schedules; the monitor is turned on or off at the preset time in the

schedule list. If multiple preset times are stored in the schedule list, this function works at the nearest time from the current time.

• Once the on or off time is set, these functions operate daily at the preset time.

• When the scheduled power-on and power-off times are the same, the power-off time has priority over the power-on

time if the set is turned on, and vice versa if the set is turned off.

• If port 123 is blocked by a firewall, your monitor cannot receive the current time from the network.

ENGLISH

OPTION Settings

ENGLISH

1 Press to access the main menus. 2 Press the navigation buttons to scroll to OPTION and press .

3 Press the navigation buttons to scroll to the setting or option you want and press .

- To return to the previous level, press .

4 When you are finished, press .

When you return to the previous menu, press .

The available option settings are described in the following:

Setting Description

Language Selects a language for the display text.

Country Select your country.

DivX(R) VOD Registers or releases DivX.

Checks DivX Registration Code for playing DivX-protected videos. Register at http://vod.divx.com. Uses Registration Code to rent or purchase movies at www.divx.com/vod. * Rented/purchased DivX files cannot be played if the DivX Registration Code of a different

device is used. Use only the DivX Registration Code granted to this device. * Converted files not conforming to the DivX Codec Standard may not play or may produce

abnormal images.

Initial Setting Deletes all optional settings and returns to initial default mode.

Set ID You can assign a unique Set ID NO (name assignment) to each product when several products

are connected for display. Specify the number (1 to 255 or 1 to 1,000) using the button and exit. Use the assigned Set ID to individually control each product using the Product Control Program.

Tile Mode Tile Mode To use this function

- Must be displayed with various other products.

- Select Tile Mode, set rows and columns, and then enter the tile ID to set the location.

- Tile Mode: row x column (row = 1-15, column = 1-15).

- 15 x 15 available.

Auto Config. Sets to adjust the screen position, clock, and phase automatically.

Position Moving the screen position horizontally and vertically.

Size Adjust the horizontal and vertical size of the screen taking into account the

Natural The image is omitted by the distance between the screens to be naturally

Reset Function to initialize and release Tile.

The displayed image may be unstable for a few seconds while the configuration is in progress.

size of the bezel.

shown.

All Tile setting are released when selecting Tile recall and the screen returns to Full screen.

Setting Description

Contents Schedule Creates simple schedules and sets playback using files in My Media.

Level

Add Schedule Creates a contents schedule.

- Media: Select the file to which you want to apply the contents schedule.

- Select [Create] to register the contents schedule.

Play Plays a contents schedule.

Delete All Deletes all registered schedules.

NOTE

• Information about registered schedules is stored on your USB storage device. This feature

does not work when your USB storage device has been removed.

• The picture size is 1920 x 1080.

• You can use photo and video files only.

• You can add up to 50 files (photo files + video files = 50).

• Only photos whose resolution is 1920 x 1080 or below are supported.

• The default display time for photos is 1 minute. Playback time for movies differs depending

on the running time.

• You can create up to 7 schedules.

• You cannot register a schedule when no file has been selected.

• Contents schedules that have had information forcibly modified using a PC, etc. may not

function properly.

• With respect to the playback of distribution or contents schedules through SuperSign

Software, the schedule executed last time is played.

ENGLISH

Tile Mode

ENGLISH

This monitor can be tiled with additional monitors to create a large tiled display.

Off

When the Tile Mode option is disabled

1X2

When using 2 monitors Tile ID

2X2

When using 4 monitors

3X3

When using 9 monitors

ID 3

ID 2

ID 4

ID 2

ID 7

ID 12

ID 17

ID 22

ID 3

ID 8

ID 13

ID 18

ID 23

ID 1

ID 4

ID 7

ID 4 ID 5

ID 9 ID 10

ID 14 ID 15

ID 19

ID 24

ID 2

ID 5

ID 8

ID 20

ID 25

ID 3

ID 6

ID 9

ID 1

Tile ID

4X4

When using 16 monitors

ID 1

ID 5

ID 9

ID 13

Tile Mode - Natural mode

When active, the part of the image that would normally be displayed in the gap between the monitors is omitted.

Before After

ID 2

ID 6

ID 10

ID 14

ID 3

ID 7

ID 11

ID 15

ID 2

ID 4

ID 8

ID 12

ID 16

ID 1

5X5

When using 25 monitors

ID 1

ID 6

ID 11

ID 16

ID 21

NETWORK Settings

1 Press to access the main menus. 2 Press the navigation buttons to scroll to NETWORK and press .

3 Press the navigation buttons to scroll to the setting or option you want and press .

- To return to the previous level, press .

4 When you are finished, press .

When you return to the previous menu, press .

The available option settings are described in the following:

Setting Description

Network Setting Configure the network settings.

Network

setting

Network Status Display the network status.

Network Connection Options

Setting Description

Setting from the AP list Select an AP to connect to a wireless network.

Simple setting

(WPS-button mode)

When the Wi-Fi dongle is connected, you can view and connect to any available wireless network.

Press the button on the wireless router that supports PBC to easily connect to the router.

ENGLISH

AUDIO

(RGB/DVI)

REMOTE

CONTROL IN

RS-232C OUT

RS-232C IN

RS-232C OUT

RS-232C IN

RS-232C OUT

RS-232C IN

PICTURE ID Settings

ENGLISH

• Only applies to certain models.

is used to change the settings of a specific set (display) using a single IR receiver for multi-vision.

Communication is possible between a monitor with an IR receiver and other monitors using RS-232C cables. Each monitor is identified by a Set ID. If you assign the using the remote control, only displays with matching

and Set ID can be controlled remotely.

1 Assign the Set ID to the installed monitors as shown below.

IR & Light Sensor

RS-232C cables

PICTURE ID ON [2]

2 Press the red ON button on the remote control to assign the PICTURE ID. 3 Assign the Set ID to the selection of your choice.

• A set with a different Set ID from the PICTURE ID cannot be controlled by IR signals.

NOTE

• If PICTURE ID is set to 2, only the upper right monitor, which has a Set ID of 2, can be controlled by IR signals.

• If you press the green OFF button for PICTURE ID, the PICTURE IDs for all monitors are turned off. If you then press

any button on the remote control, all monitors can be controlled by IR signals regardless of Set ID.

IR CODES

• All models do not support the HDMI/USB function.

• Some key codes are not supported depending on the model.

Code (Hex) Function Note

C4 MONITOR ON

C5 MONITOR OFF

DC R/C BUTTON

10 to 19 Number Key 0 to 9

2F R/C BUTTON

5F R/C BUTTON

40 Up

41 Down

07 Left

06 Right

3F R/C BUTTON

(Power)

/ /

( + )

( - )

R/C BUTTON

( )

R/C BUTTON

ENGLISH

Code (Hex) Function Note

R/C BUTTON

Red Key ( )

Green Key ( )

Yellow Key

Blue Key

R/C BUTTON

TO CONTROL MULTIPLE PRODUCTS

• Use this method to connect several products to a single PC. You can control several products at a time by connecting

them to a single PC.

• In the Option menu, Set ID must be between 1 and 255 (or from 1 to 1,000) without being duplicated.

Connecting the Cable

Connect the RS-232C cable as shown in the picture.

• The RS-232C protocol is used for communication between the PC and product. You can turn the product on or off,

select an input source or adjust the OSD menu from your PC.

Monitor 1 Monitor 2 Monitor 3Monitor 4

RS-232C

OUT

RS-232C

OUT

RS-232C

OUT

4P Cable (not included)

RS-232C

OUT

RS-232C

RS-232C Gender

RS-232C Cable (not included)

RS-232C Configurations

4P Cable

• 4-Wire Configurations (Standard RS-232C cable)

RXD TXD GND

NOTE

• When using three-wire connections (non-standard), an IR daisy chain cannot be used.

• If you want to control multiple units simultaneously, use 3.5 mm 4-pole cables (sold separately).

RS-232C Cable

• 8-Wire Configurations (Standard RS-232C cable)

DCD

RXD

TXD

GND

DTR

DSR

RTS

CTS

D-Sub 9 D-Sub 9

(Female) (Female)

RS-232C

Gender

1 3 2 5 6 4 8 7

TXD RXD GND

DCD TXD RXD GND DSR DTR CTS RTS

ENGLISH

Communication Parameter

• Baud Rate : 9600 BPS

• Data Length : 8 bit

• Parity Bit : None

• Stop Bit : 1 bit

• Flow Control : None

• Communication Code : ASCII code

• Use a crossed (reverse) cable

Command Reference List

ENGLISH

COMMAND

1 2

01 Power k a 00 to 01

02 Select input x b See [Select input]

03 Aspect ratio k c See [Aspect ratio]

04 Energy saving j q See [Energy saving]

05 Picture mode d x See [Picture mode] 06 Contrast k g 00 to 64

07 Brightness k h 00 to 64

08 Sharpness k k 00 to 32

09 Color k i 00 to 64

10 Tint k j 00 to 64 11 Color temperature x u 00 to 64 12 H position f q 00 to 64 13 V position f r 00 to 64 14 H size f s 00 to 64

15 Auto Config. j u 01

16 Balance k t 00 to 64 17 Sound Mode d y See [Sound mode] 18 Mute k e 00 to 01 19 Volume k f 00 to 64

20 Clock 1 (year/month/day) f a See [Clock 1]

21 Clock 2 (hour/minute/second) f x See [Clock 2]

22 Off time schedule f c 00 to 01

23 On time schedule f b 00 to 01

24 Off timer (repeat mode/time) f e See [Off timer]

25 On timer (repeat mode/time) f d See [On timer]

26 On timer input f u See [On timer input]

27 Automatic Standby m n 00 to 01

28 Auto off f g 00 to 01

29 Language f i See [Language]

30 Reset f k 00 to 02

31 Current temperature d n FF

32 Key m c See [Key]

33 Time elapsed d l FF

DA TA

(Hexadecimal)

COMMAND

1 2

34 Product serial number f y FF

35 Software version f z FF

36 White balance red gain j m 00 to FE

37 White balance green gain j n 00 to FE

38 White balance blue gain j o 00 to FE 39 White Balance Red Offset s x 00 to 7F

40 White Balance Green Offset s y 00 to 7F

41 White Balance Blue Offset s z 00 to 7F

42 Backlight m g 00 to 64

43 Screen off k d 00 to 01

44 Tile Mode d d See [Tile Mode]

45 Tile Mode Check d z FF

46 Tile ID d i Refer to ‘Tile ID'.

47 Tile H Position d e 00 to 32

48 Tile V Position d f 00 to 32

49 Tile H Size d g 00 to 32

50 Tile V Size d h 00 to 32

Natural Mode (In Tile mode)

d j

00 to 01

DA TA

(Hexadecimal)

NOTE

• During USB operations such as Dvix or EMF, all commands except Power (k a) and Key (m c) are not executed and

treated as NG.

• Some commands are not supported depending on the model.

• The ‘f f’ command which shows the status of a certain command does not display the OSD as the result in order to be

compatible with SuperSign program.

ENGLISH

Transmission / Receiving

ENGLISH

Protocol

Transmission

[Command1][Command2][ ][Set ID][ ][Data][Cr]

* [Command1] Identifies the factory setting and the user setting modes.

* [Command2] Controls monitors.

* [Set ID] Used for selecting a set you want to control. A Set ID can be assigned to each set from 1 to

255 (from 01H to FFH), or from 1 to 1,000 (from 001H to 3e8H) in certain models, under OPTION in the OSD menu. Selecting '00H' or '000H' for Set ID allows the simultaneous control of all connected monitors. (It may not be supported depending on the model.)

* [Data] Transmits command data.

Data count may increase depending on the command.

* [Cr] Carriage Return. Corresponds to '0x0D' in ASCII code.

* [ ] White Space. Corresponds to '0x20' in ASCII code.

Acknowledgement

[Command2][ ][Set ID][ ][OK/NG][Data][x]

* The Product transmits an ACK (acknowledgement)

based on this format when receiving normal data. At this time, if the data is FF, it indicates the present status data. If the data is in data write mode, it returns the data of the PC computer.

* If a command is sent with Set ID ‘00’ (=0x00) or ‘000

(=0x000)’, the data is reflected to all monitor sets and they do send any acknowledgement (ACK).

* If the data value ‘FF’ is sent in control mode via RS-

232C, the current setting value of a function can be checked (only for some functions).

* Some commands may not be supported on some

models.

01. Power (Command: k a)

Controls the power on/off of the set.

Transmission

[k][a][ ][Set ID][ ][Data][Cr]

Data 00: Off 01: On

Acknowledgement

[a][ ][Set ID][ ][OK/NG][Data][x]

* Only when the monitor is fully powered on, the

acknowledgement signal is returned properly.

* There may be a delay between the transmission and

acknowledgement signals.

02. Select input(Command: x b)

Selects an input signal.

Transmission

[x][b][ ][Set ID][ ][Data][Cr]

Data 20: AV 40: Component 60: RGB 90: HDMI (HDMI1) (DTV) A0: HDMI (HDMI1) (PC) 91: HDMI2/OPS (DTV) A1: HDMI2/OPS (PC) 70: DVI-D(PC) 80: DVI-D(DTV) C0:DP(DTV) D0:DP(PC)

Acknowledgement

[b][ ][Set ID][ ][OK/NG][Data][x]

* Some input signals may not be supported on some

models.

03. Aspect ratio (Command: k c)

Adjusts the aspect ratio.

Transmission

[k][c][ ][Set ID][ ][Data][Cr]

Data 01: 4:3 02: 16:9 04: Zoom (HDMI)(DTV) 06: Auto ratio(HDMI)(DTV)

09: Original (≥ 720p) (HDMI) (DTV)

10 to 1F: Cinema zoom 1 to 16 (HDMI) (DTV)

* Available data types differ depending on the input

signal. For more information, see the aspect ratio section of the owner’s manual.

* The aspect ratio may differ depending on the model’s

input configuration.

Acknowledgement

[c][ ][Set ID][ ][OK/NG][Data][x]

04. Energy saving (Command: j q)

Sets the energy saving function.

Transmission

[j][q][ ][Set ID][ ][Data][Cr]

Data 00: Off 01: Minimum 02: Medium 03: Maximum 04: Automatic 05: Screen off

Acknowledgement

[q][ ][Set ID][ ][OK/NG][Data][x]

* This may not be supported on some models.

05. Picture mode (Command: d x)

Selects a picture mode.

Transmission

[d][x][ ][Set ID][ ][Data][Cr]

Data 00: Vivid 01: Standard 02: Cinema 03: Sport 04: Game 05: Expert 1 06: Expert 2 08: Eco 11 : Calibration

Acknowledgement

[x][ ][Set ID][ ][OK/NG][Data][x]

ENGLISH

06. Contrast (Command: k g)

ENGLISH

Adjusts the screen contrast.

Transmission

[k][g][ ][Set ID][ ][Data][Cr]

Data 00 to 64: Contrast 0 to 100

Acknowledgement

[g][ ][Set ID][ ][OK/NG][Data][x]

07. Brightness (Command: k h)

Adjusts the screen brightness.

Transmission

[k][h][ ][Set ID][ ][Data][Cr]

Data 00 to 64: Brightness 0 to 100

Acknowledgement

[h][ ][Set ID][ ][OK/NG][Data][x]

08. Sharpness (Command: k k)

Adjusts the screen sharpness.

Transmission

[k][k][ ][Set ID][ ][Data][Cr]

Data 00 to 32: Sharpness 0 to 50

Acknowledgement

[k][ ][Set ID][ ][OK/NG][Data][x]

09. Color (Command: k i)

Adjusts the screen color.

Transmission

[k][i][ ][Set ID][ ][Data][Cr]

Data 00 to 64: Color 0 to 100

Acknowledgement

[i][ ][Set ID][ ][OK/NG][Data][x]

10. Tint (Command: k j)

Adjusts the screen tint.

Transmission

[k][j][ ][Set ID][ ][Data][Cr]

Data 00 to 64: Tint red 50 to green 50

Acknowledgement

[j][ ][Set ID][ ][OK/NG][Data][x]

11. Color temperature (Command: x u)

Adjusts the screen color temperature.

Transmission

[x][u][ ][Set ID][ ][Data][Cr]

Data 00 to 64: Warm 50 to cool 50

Acknowledgement

[u][ ][Set ID][ ][OK/NG][Data][x]

12. H position (Command: f q)

Adjusts the horizontal position of the screen. This function is only available when the Tile Mode is set

to Off.

* The operational range varies depending on the RGB

input resolution. (Only available in RGB-PC input mode)

Transmission

[f][q][ ][Set ID][ ][Data][Cr]

Data 00 to 64: Min -50 (left) to max 50 (right)

Acknowledgement

[q][ ][Set ID][ ][OK/NG][Data][x]

13. V position (Command: f r)

Adjusts the vertical position of the screen. This function is only available when the Tile Mode is set

to Off.

* The operational range varies depending on the RGB

input resolution. (Only available in RGB-PC input mode)

Transmission

[f][r][ ][Set ID][ ][Data][Cr]

Data 00 to 64: Min -50 (down) to max 50 (up)

Acknowledgement

[r][ ][Set ID][ ][OK/NG][Data][x]

14. H size (Command: f s)

Adjusts the horizontal size of the screen. This function is only available when the Tile Mode is set

to Off.

* The operational range varies depending on the RGB

input resolution. (Only available in RGB-PC input mode)

Transmission

[f][s][ ][Set ID][ ][Data][Cr]

Data 00 to 64: Min -50 (small) to max 50 (large)

Acknowledgement

[s][ ][Set ID][ ][OK/NG][Data][x]

15. Auto Config. (Command: j u)

Automatically corrects position and shaking of the picture. (Only available in RGB-PC input mode)

Transmission

[j][u][ ][Set ID][ ][Data][Cr]

Data 01: Execution

Acknowledgement

[u][ ][Set ID][ ][OK/NG][Data][x]

16. Balance (Command: k t)

Adjusts the sound balance.

Transmission

[k][t][ ][Set ID][ ][Data][Cr]

Data 00 to 64: Left 50 to right 50

Acknowledgement

[t][ ][Set ID][ ][OK/NG][Data][x]

18. Mute (Command: k e)

Mutes/unmutes the sound.

Transmission

[k][e][ ][Set ID][ ][Data][Cr]

Data 00: Mute 01: Unmute

Acknowledgement

[e][ ][Set ID][ ][OK/NG][Data][x]

19. Volume (Command: k f)

Adjusts the playback volume.

Transmission

[k][f][ ][Set ID][ ][Data][Cr]

Data 00 to 64: Volume 0 to 100

Acknowledgement

[f][ ][Set ID][ ][OK/NG][Data][x]

20. Clock 1 (year/month/day) (Command: f a)

Adjusts the Clock 1 (year/month/day) value.

Transmission

[f][a][ ][Set ID][ ][Data1][ ][Data2][ ][Data3][Cr]

Data1 00 to 14: Year 2010 to 2040 Data2 01 to 0C: January to December Data3 01 to 1F: 1st to 31st * Enter “fa [Set ID] ff” to view the Clock 1 (year/

month/day) settings.

Acknowledgement

[a][ ][Set ID][ ][OK/NG][Data1][Data2][Data3][x]

ENGLISH

17. Sound mode (Command: d y)

Selects a sound mode.

Transmission

[d][y][ ][Set ID][ ][Data][Cr]

Data 01: Standard 02: Music 03: Cinema 04: Sport

05. Game

07. News

Acknowledgement

[y][ ][Set ID][ ][OK/NG][Data][x]

21. Clock 2 (hour/minute/second) (Command: f x)

ENGLISH

Adjusts the Clock 2 (hour/minute/second) value.

Transmission

[f][x][ ][Set ID][ ][Data1][ ][Data2][ ][Data3][Cr]

Data1 00 to 17: 00 to 23 hours Data2 00 to 3B: 00 to 59 minutes Data3 00 to 3B: 00 to 59 seconds

* Enter “fa [Set ID] ff” to view the Clock 2 (hour/

minute/second) settings.

* This function is only available when Clock 1 (year/

month/day) is set.

Acknowledgement

[x][ ][Set ID][ ][OK/NG][Data1][Data2][Data3][x]

22. Off time schedule (Command: f c)

Enables/disables the on time schedule.

Transmission

[f][c][ ][Set ID][ ][Data][Cr]

Data 00: Off 01: On

Acknowledgement

[c][ ][Set ID][ ][OK/NG][Data][x]

23. On time schedule (Command: f b)

Enables/disables the on time schedule.

Transmission

[f][b][ ][Set ID][ ][Data][Cr]

Data 00: Off 01: On

Acknowledgement

[b][ ][Set ID][ ][OK/NG][Data][x]

24. Off timer (repeat mode/time) (Command: f e)

Configures the off time (repeat mode/time) settings.

Transmission

[f][e][ ][Set ID][ ][Data1][ ][Data2][ ][Data3][Cr]

Data1

1. F1 to F7 (reading data) F1: Read the 1st off timer data F2: Read the 2nd off timer data F3: Read the 3rd off timer data F4: Read the 4th off timer data F5: Read the 5th off timer data F6: Read the 6th off timer data F7: Read the 7th off timer data

2. E1 to E7 (deleting one index), E0 (deleting all indexes)

E0: Erase all off timer setting E1: Erase the 1st off timer setting E2: Erase the 2nd off timer setting E3: Erase the 3rd off timer setting E4: Erase the 4th off timer setting E5: Erase the 5th off timer setting E6: Erase the 6th off timer setting E7: Erase the 7th off timer setting

3. 01 to 0C (setting the day of the week for off timer) 01: Once

02. Daily 03: Mon - Fri 04: Mon - Sat 05: Sat - Sun

06. Every Sunday

07. Every Monday

08. Every Tuesday

09. Every Wednesday 0A. Every Thursday 0B. Every Friday 0C. Every Saturday Data2 00 to 17: 00 to 23 hours Data3 00 to 3B: 00 to 59 minutes

* To read or delete the Off Time list, set FFH for

[Data2] and [Data3]. Example 1: fe 01 f1 ff ff - Read the 1st index data from off timer Example 2: fe 01 e1 ff ff - Delete the 1st index data from off timer.

Example 3: fe 01 04 02 03 - Sets Off Timer to 02:03 for Monday-Saturday.

* This function is only available when Clock 1 (year/

month/day) and Clock 2 (hour/minute/second) are set.

Acknowledgement

[e][ ][Set ID][ ][OK/NG][Data1][Data2][Data3][x]

25. On timer (repeat mode/time) (Command: f d)

Configures the on time (repeat mode/time) settings.

Transmission

[f][d][ ][Set ID][ ][Data1][ ][Data2][ ][Data3][Cr]

Data1

1. F1 to F7 (reading data) F1: Read the 1st on timer data F2: Read the 2nd on timer data F3: Read the 3rd on timer data F4: Read the 4th on timer data F5: Read the 5th on timer data F6: Read the 6th on timer data F7: Read the 7th on timer data

2. E1 to E7 (deleting one index), E0 (deleting all indexes)

E0: Erase all on timer setting E1: Erase the 1st on timer setting E2: Erase the 2nd on timer setting E3: Erase the 3rd on timer setting E4: Erase the 4th on timer setting E5: Erase the 5th on timer setting E6: Erase the 6th on timer setting E7: Erase the 7th on timer setting

3. 01 to 0C (setting the day of the week for the on timer)

01: Once

02. Daily 03: Mon - Fri 04: Mon - Sat 05: Sat - Sun

06. Every Sunday

07. Every Monday

08. Every Tuesday

09. Every Wednesday 0A. Every Thursday 0B. Every Friday

0C. Every Saturday Data2 00 to 17: 00 to 23 hours Data3 00 to 3B: 00 to 59 minutes

* To read or delete an on timer list you have set,

[Data2][Data3] must be set to FFH. Example 1: fd 01 f1 ff ff - Read the 1st index data from on timer. Example 2: fd 01 e1 ff ff - Delete the 1st index data from on timer. Example 3: fd 01 04 02 03 - Set on timer at 02:03 on Monday to Saturday.

* This function is only available when Clock 1 (year/

month/day) and Clock 2 (hour/minute/second) are set.

Acknowledgement

[d][ ][Set ID][ ][OK/NG][Data1][Data2][Data3][x]

26. On timer input (Command: f u)

Adds a new schedule entry by selecting input for the current on timer setting.

Transmission

[f][u][ ][Set ID][ ][Data1][Cr]

[f][u][ ][Set ID][ ][Data1][Data2][Cr]

Data (adding schedule) 20: AV 40: Component 60: RGB 70: DVI-D 90: HDMI (HDMI1) (DTV) 91: HDMI2/OPS (DTV) C0: DISPLAYPORT (DTV)

Data1

1. f1h to f7h (reading data) F1: Select the 1st schedule input source F2: Select the 2nd schedule input source F3: Select the 3rd schedule input source F4: Select the 4th schedule input source F5: Select the 5th schedule input source F6: Select the 6th schedule input source F7: Select the 7th schedule input source

ENGLISH

Data2

ENGLISH

1. ffh (reading data) To read the schedule input, enter FFH for [Data2]. If no schedule is available for [Data1] when attempting

to read or change the schedule data, the text NG will be displayed and the operation will fail.

(Example 1: fu 01 60 - Move existing schedule entries down one row each and save RGB as input source for the 1st schedule entry.)

(Example 2: fu 01 f1 ff - Read the 1st schedule input data.)

* This function is only supported when 1 (year/month/

date), 2 (hour/minute/second) and On Time (repeat mode/time) are set.

* Input may not be supported on some models.

Acknowledgement

[u][ ][Set ID][ ][OK/NG][Data][x]

[u][ ][Set ID][ ][OK/NG][Data1][Data2][x]

27. Automatic standby (Command: m n)

Configures the automatic standby settings.

Transmission

[m][n][ ][Set ID][ ][Data][Cr]

Data 00: Off (Will not turn off after 4/6/8 hours) 01: 4 hours (Off after 4 hours) 02: 6 hours (Off after 6 hours) 03: 8 hours (Off after 8 hours)

Acknowledgement

[n][ ][Set ID][ ][OK/NG][Data][x]

28. Auto off (Command: f g)

Configures the automatic off settings.

Transmission

[f][g][ ][Set ID][ ][Data][Cr]

Data 00: Off (Will not turn off after 15 minutes) 01: On (Off after 15 minutes)

Acknowledgement

[g][ ][Set ID][ ][OK/NG][Data][x]

29. Language (Command: f i)

Sets the OSD language.

Transmission

[f][i][ ][Set ID][ ][Data][Cr]

Data 00: Czech 01: Danish 02: German 03: English 04: Spanish (Europe) 05: Greek 06: French 07: Italian 08: Dutch 09: Norwegian 0A: Portuguese 0B: Portuguese (Brazil) 0C: Russian 0D: Finnish 0E: Swedish 0F: Korean 10: Chinese (Cantonese) 11: Japanese 12: Chinese (Mandarin) 13: Arabic

Acknowledgement

[i][ ][Set ID][ ][OK/NG][Data][x]

* This may not be supported on some models.

30. Reset (Command: f k)

Resets settings for Picture, Screen and Audio or restores factory settings.

(Screen reset can only be performed in RGB input mode.)

Transmission

[f][k][ ][Set ID][ ][Data][Cr]

Data 00: Picture reset 01: Screen reset 02: Initial settings (factory reset)

Acknowledgement

[k][ ][Set ID][ ][OK/NG][Data][x]

31. Current temperature (Command: d n)

Checks the inside temperature value.

Transmission

[d][n][ ][Set ID][ ][Data][Cr]

Data FF: Check status

Acknowledgement

[n][ ][Set ID][ ][OK/NG][Data][x]

[n][ ][Set ID][ ][OK/NG][Data1][Data2][Data3][x]

* Temperature is displayed as a hexadecimal value.

32. Key (Command: m c)

Sends a key code for the IR remote control.

Transmission

[m][c][ ][Set ID][ ][Data][Cr]

Data IR_KEY_CODE

Acknowledgement

[c][ ][Set ID][ ][OK/NG][Data][x]

For key codes, see IR Codes.

* Some key codes may not be supported on some

models.

33. Time elapsed (Command: d l)

Checks the elapsed time.

Transmission

[d][l][ ][Set ID][ ][Data][Cr]

Data FF: Read status

Acknowledgement

[l][ ][Set ID][ ][OK/NG][Data][x]

* The data received is shown as a hexadecimal value.

34. Product serial number (Command: f y)

Checks the serial number of the product.

Transmission

[f][y][ ][Set ID][ ][Data][Cr]

Data FF: Check product serial number

Acknowledgement

[y][ ][Set ID][ ][OK/NG][Data][x]

* Data is in ASCII code.

35. Software version (Command: f z)

Checks the software version of the product.

Transmission

[f][z][ ][Set ID][ ][Data][Cr]

Data FF: Check software version

Acknowledgement

[z][ ][Set ID][ ][OK/NG][Data][x]

36. White balance red gain (Command: j m)

Adjusts the white balance red gain value.

Transmission

[j][m][ ][Set ID][ ][Data][Cr]

Data 00 to FE: Red gain 0 to 254

Acknowledgement

[m][ ][Set ID][ ][OK/NG][Data][x]

37. White balance green gain (Command: j n)

Adjusts the white balance green gain value.

Transmission

[j][n][ ][Set ID][ ][Data][Cr]

Data 00 to FE: Green gain 0 to 254

Acknowledgement

[n][ ][Set ID][ ][OK/NG][Data][x]

38. White balance blue gain (Command: j o)

Adjusts the white balance blue gain value.

Transmission

[j][o][ ][Set ID][ ][Data][Cr]

Data 00 to FE: Blue gain 0 to 254

Acknowledgement

[o][ ][Set ID][ ][OK/NG][Data][x]

ENGLISH

39. White Balance Red Offset(Command: s x)

ENGLISH

Adjusts the white balance red offset value.

Transmission

[s][x][ ][Set ID][ ][Data][Cr]

Data 00 to 7F: Red offset 0 to 127 FF: Confirms red offset value

Acknowledgement

[x][ ][Set ID][ ][OK/NG][Data][x]

40. White Balance Green Offset (Command: s y)

Adjusts the white balance green offset value.

Transmission

[s][y][ ][Set ID][ ][Data][Cr]

Data 00 to 7F: Green offset 0 to 127 FF: Confirms green offset value

Acknowledgement

[y][ ][Set ID][ ][OK/NG][Data][x]

41. White Balance Blue Offset (Command: s z)

Adjusts the white balance blue offset value.

Transmission

[s][z][ ][Set ID][ ][Data][Cr]

Data 00 to 7F: Blue offset 0 to 127 FF: Confirms blue offset value

Acknowledgement

[z][ ][Set ID][ ][OK/NG][Data][x]

42. Backlight (Command: m g)

Adjusts the back light brightness.

Transmission

[m][g][ ][Set ID][ ][Data][Cr]

Data 00 to 64: Back light brightness 0 to 100

Acknowledgement

[g][][set ID][][OK/NG][Data][x]

* This may not be supported on some models.

43. Screen off (Command: k d)

Turns the screen on or off.

Transmission

[k][d][ ][Set ID][ ][Data][Cr]

Data 00: Turns the screen on 01: Turns the screen off

Acknowledgement

[d][ ][Set ID][ ][OK/NG][Data][x]

44. Tile Mode (Command: d d)

To set a Tile Mode and Tile Column/ Row values.

Transmission

[d][d][ ][Set ID][ ][Data][Cr]

Data 00 to FF: 1st byte - Tile Row

2nd byte - Tile Column

* 00, 01, 10, 11 means Tile Mode Off

* It may not be supported depending on the model.

Acknowledgement

[d][ ][Set ID][ ][OK/NG][Data][x]

45. Tile Mode Check (Command: d z)

To check Tile Mode status.

Transmission

[d][z][ ][Set ID][ ][Data][Cr]

Data FF: Check Tile Mode status.

* It may not be supported depending on the model.

Acknowledgement

[z][ ][Set ID][ ][OK/NG][Data1][Data2][Data3][x]

Data1 00: Tile Mode Off 01: Tile Mode On Data2 00 to 0F: Tile Row Data3 00 to 0F: Tile Column

46. Tile ID (Command: d i)

To set Tile ID.

Transmission

[d][i][ ][Set ID][ ][Data][Cr]

Data 01 to E1: Tile ID 01 to 225** FF: Check Tile ID

* Data could not be set over (Tile Column) x (Tile Row).

* It may not be supported depending on the model.

Acknowledgement

[i][ ][Set ID][ ][OK/NG][Data][x]

* NG will be return if data is over (Tile Column) x (Tile

Row), except 0xFF.

47. Tile H Position (Command: d e)

To adjust the Tile Horizontal position.

* This function is available only when the Natural option

of the Tile Mode is set to Off while the Tile Mode set to On.

Transmission

[d][e][ ][Set ID][ ][Data][Cr]

Data 00 to 32: -50 (Left) to 0 (Right)

* Left/Right values depend on Tile H size.

* It may not be supported depending on the model.

Acknowledgement

[e][ ][Set ID][ ][OK/NG][Data][x]

48. Tile V Position (Command: d f)

To adjust the Tile Vertical position.

* This function is available only when the Natural option

of the Tile Mode is set to Off while the Tile Mode set to On.

Transmission

[d][f][ ][Set ID][ ][Data][Cr]

Data 0 to 32: 0 (Bottom) to 50 (Top)

* Bottom/Top values depend on Tile Vertical size.

* It may not be supported depending on the model.

Acknowledgement

[f][ ][Set ID][ ][OK/NG][Data][x]

Acknowledgement

[g][ ][Set ID][ ][OK/NG][Data][x]

50. Tile V Size (Command: d h)

To adjust the Tile Vertical size.

* Set Tile V Position to 0x00 before setting Tile V Size.

* This function is available only when the Natural option

of the Tile Mode is set to Off while the Tile Mode set to On.

Transmission

[d][h][ ][Set ID][ ][Data][Cr]

Data 00 to 32: 0 to 50

* It may not be supported depending on the model.

Acknowledgement

[h][ ][Set ID][ ][OK/NG][Data][x]

51. Natural Mode (In Tile Mode) (Command: d j)

To display the image naturally, the part of the image that would normally be displayed in the gap between the monitors is omitted.

Transmission

[d][j][ ][Set ID][ ][Data][Cr]

Data 00: Off 01: On

Acknowledgement

[j][ ][Set ID][ ][OK/NG][Data][x]

ENGLISH

49. Tile H Size (Command: d g)

To adjust the Tile Horizontal Size.

* Set Tile H Position to 0x32 before setting Tile H Size.

* This function is available only when the Natural option

of the Tile Mode is set to Off while the Tile Mode set to On.

Transmission

[d][g][ ][Set ID][ ][Data][Cr]

Data 00 to 32: 0 to 50

* It may not be supported depending on the model.

INSTALLATION MANUAL

LG Digital Signage

(MONITOR SIGNAGE)

Please read this manual carefully before operating your set and retain it for future reference.

L15

www.lg.com

TABLE OF CONTENTS

ENGLISH

ACCESSING INSTALLATION MENU

........................................................4

INSTALLATION MENU ..................5

- LG Digital Signage Setup menu ................................5

Signage Mode Operation

Power On Status

Key Operation

IR Operation / Local Key Operation

Limited Mode

Input Source Change

Menu Display

OSD Display

Power On Default (Input Source, A/V Setting, Aspect Ratio)

Input Source

A/V Setting

Aspect Ratio

Wake On LAN

DPM

Digital Audio Input

Speaker

Power On Delay

Pivot Mode

OSD Portrait Mode (Off, 90, 270)

Intelligent Auto

Master/Slave Mode

Time Sync Clock

Sync Mode

DPM Wakeup Control

Still Image Detecting

PM Mode

Factory Reset

OPS/PC Power Control

Interface Selection

Check Screen

Factory Reset VS Initial Setting

- USB Cloning .....................................................................13

Ez Download

Receive from USB

Send to USB

Logo Image Download

Send to DaisyChain

- Password Change ..........................................................18

- Set ID Setup ......................................................................19

Set ID Lock

Set ID

Auto Set ID

Reset ID

- Configuration Setup .....................................................20

Splash Offset Time

U SB Auto Playback

15 Min Auto Off

Automatic Standby

Screen Saver Cube

- Lock Mode ......................................................................... 22

USB

Initial Setting

- External Speaker / Audio out ..................................23

Output Control

- Fail Over ..............................................................................24

You can set Mode to Off, Auto, or Manual.

You can set USB to Off, Movie, or Photo.

Fail Over priority when set to Auto

- ISM Method ...................................................................... 26

Mode

Timer

Period

Time

Still Image Detecting and ISM Method

Bar Image

Bar Color

Bar Transparency

Bar Direction

User Image

- Easy Brightness Control ............................................30

- SuperSign Server Setup .............................................31

Player Name

Server IP Setting

Server IP Status

- Holiday Schedule ............................................................32

- No Signal Image ..............................................................33

- Crestron ..............................................................................34

- Digital Signage Media Player ...................................34

Executable content

Using the My Media menu to play files

Auto-play on USB insertion

Distributing and playing content via SuperSign W

ENGLISH

ACCESSING INSTALLATION MENU

ENGLISH

1 Press and hold the SETTINGS button for more than 5 seconds.


OPTION

AUDIO TIME

NETWORK

MY MEDIA

2 Enter the correct password (default: 0000) and press the OK button.

HDMI

(DTV)

No Signal

3 When the Installation Menu is displayed, select the desired item.

Installation Menu (V 3.0)

LG Digital Signage Setup

USB Cloning

Password Change

Set ID Setup

Configuration Setup

Lock Mode

External Speaker / Audio out

Fail Over

ISM Method

Easy Brightness Control

Installation Menu (V 3.0)

SuperSign Server Setup

Holiday Schedule

No Signal Image

Crestron

S/W : xx.xx.xx.xx Micom : x.xx.x

INSTALLATION MENU

NOTE

• Default values may differ by region.

LG Digital Signage Setup menu

• Use this menu to configure the Digital Signage after in stallation.

Installation Menu (V 3.0)

LG Digital Signage Setup

USB Cloning Password Change Set ID Setup Configuration Setup Lock Mode External Speaker / Audio out Fail Over ISM Method Easy Brightness Control

S/W : xx.xx.xx.xx Micom : x.xx.x

Installation Menu (V 3.0)

SuperSign Server Setup

Holiday Schedule

No Signal Image

Crestron

S/W : xx.xx.xx.xx Micom : x.xx.x

LG Digital Signage Setup

Signage Mode Operation

• Power On Status

• Key Operation

• IR Operation

• Local Key Operation

• Limited Mode

• Input Source Change

• Menu Display

• OSD Display

ENGLISH

Yes

LST

Normal

Yes

LG Digital Signage Setup

• Power On Default

• Input Source

• A/V Setting

• Aspect Ratio

• Wake On LAN

• DPM

• Digital Audio Input

• Speaker

• Power On Delay

Off

Disable

Off

10min.

Analog

Off

LG Digital Signage Setup

• Pivot mode

• OSD Portrait Mode

• Intelligent Auto

• Master/Slave Mode

• Time Sync Clock

• Sync Mode

• DPM Wakeup Control

• Still Image Detecting

• PM Mode

Off

Slave

Stand-by

Off

Clock

Yes

Power Off

LG Digital Signage Setup

• OPS/PC Power Control

• Factory Reset

Off

Signage Mode Operation

ENGLISH

• Enable or disable all Signage Mode Operation functions by setting the feature to Yes or No.

• If you set Signage Mode Operation to Yes, all Signage Mode functions are enabled.

• If you set Signage Mode Operation to No, all Signage Mode functions are disabled, and the product operates with its

default settings. (Depending on the model, this feature may not be supported.)

Power On Status

• You can select the operating status of the monitor when the main power is turned on.

• You can choose PWR, STD, or LST.

• PWR sets the monitor status to On whenever the main power is turned on.

• STD sets the monitor status to Standby when the main power is turned on.

• LST sets the monitor status back to its previous status. As in Power Backup mode, if you turn off the main power

while the monitor is turned on, the monitor status changes back to On. Also, if you turn off the main power while the monitor is in standby mode, the monitor goes into standby mode. (This feature may not be available with some models.)

Key Operation

• This feature allows you to manage the usability and operation of the local/front keys and your remote control. It

works according to the “IR Operation” settings. (This feature may not be available with some models.)

IR Operation / Local Key Operation

• This feature allows you to set how the product operates after receiving a signal from a LG remote control or local key.

(0 - Normal, 1 - Use PWR Only, 2 - Block All)

• Selecting ‘Block All’ blocks any signal coming from a LG remote control/local key. (Power On feature is available.)

• Selecting ‘Use PWR Only’ blocks any signal coming from a LG remote control/local key, except the Power button.

• Selecting ‘Normal’ enables signals from any LG remote control/local key to be received normally.

• There are keys that must be operated in ‘Service mode’ when ‘Use PWR Only’ or ‘Block All’ is selected: In-Start, In-

Stop, Power-Only, ADJ, Installation Menu, P-Check, and S-check. (This feature may not be available with some models.)

NOTE

• When all IR key signals or all local key signals are blocked, the “Power On Status” value switches to “PWR”. Changing

this value is not impossible to ensure the correct powering on operation. (To prevent mistakes by the user)

Limited Mode

• This feature allows you inhibit the operations of particular Signage functions. This feature works according to the

‘Input Source Change’, ‘Menu Display’, or ‘OSD Display’ settings. (This feature may not be available with some models.)

Input Source Change

• Enable or disable input source changes by setting this feature to Yes or No.

• If you set this feature to No (changes disabled), the INPUT key is disabled.

• If you set this feature to Yes (changes enabled), the input source can be changed.

(This feature may not be available with some models.)

Menu Display

• Setting this feature to Yes will display the menu. Setting this feature to No will hide the menu.

• However, even if you have set this feature to No, you can easily open the Installation Menu by pressing and holding

the Menu button for more than 5 seconds. (This feature may not be available with some models.)

OSD Display

• Enable or disable OSDs by setting this feature to Yes (displayed) or No (not displayed).

• If you set this feature to No (not displayed), OSDs other than Installation Menu are not displayed.

(This feature may not be available with some models.)

Power On Default (Input Source, A/V Setting, Aspect Ratio)

• You can configure ‘Input Source’, ‘A/V Setting’, and ‘Aspect Ratio’ after the monitor is turned on.

• You can set this feature to Yes (enabled) or No (disabled).

• If you set ‘Power On Default’ to No, the settings for ‘Input Source’, ‘A/V Setting’, and ‘Aspect Ratio’ are not

applied.

• If you set ‘Power On Default’ to Yes, the settings for the menus above are applied.

(This feature may not be available with some models.)

Input Source

• This feature allows you to set whether to use a new input source or a pre-existing input source.

• Set ‘Input Source’ to Off to use the pre-existing input source.

• You can use any of the sources supported by the given model as the input source.

• If both ‘Input Source’ and ‘On Time’ have been set, ‘Input Source’ takes priority.

(This feature may not be available with some models.)

A/V Setting

• When your monitor is powered on, you can set certain video options.

• If you set this feature to Yes, the video settings configured before entering the Installation Menu are saved. In

addition, even if you changed the video settings before turning off the monitor, the saved settings are restored when you turn the monitor on again.

• Saves video settings: Picture Mode, DPM Select, Smart Energy Saving, Backlight, Contrast, Brightness, Sharpness,

Color, Tint, and Color Temp.

• Saves audio settings: Sound Mode and Balance.

(This feature may not be available with some models.)

Aspect Ratio

• This feature allows you to set the screen aspect ratio applied to your monitor when turned on.

• Selecting ‘Disable’ sets the screen aspect ratio to ‘Aspect Ratio’ when the monitor is turned on.

• Selecting ‘Set By Program’ sets the screen aspect ratio to ‘Set By Program’ when the monitor is turned on.

• Selecting ‘4:3’ sets the screen aspect ratio to ‘4:3’ when the monitor is turned on.

• Selecting’16:9’ sets the screen aspect ratio to ‘16:9’ when the monitor is turned on.

(This feature may not be available with some models.)

ENGLISH

Wake On LAN

ENGLISH

• Set whether to use the ‘Wake On LAN’ feature.

• You can set ‘Wake On LAN’ to On or Off.

• If you set this feature to On, ‘Wake On LAN’ is enabled and you can turn the product on remotely via a LAN.

• If you set this feature to Off, ‘Wake On LAN’ is disabled.

(This feature may not be available with some models.)

DPM

• Set whether to use ‘Display Power Management (DPM)’.

• You can set this feature to Off, 5 sec, 10 sec, etc.

• If this feature is not set to Off, the monitor will enter Power Saving Mode when there is no input signal.

• If you set this feature to Off, DPM is disabled.

(This feature may not be available with some models.)

Digital Audio Input

• You can set the audio for each input as ‘Analog’ or ‘Digital’.

• In the case of RGB input, audio is fixed as ‘Analog’.

• In the case of digital input, you can select ‘Analog’ or ‘Digital’ for audio.

(This feature may not be available with some models.)

Speaker

• You can restrict the audio settings by choosing whether or not to use the speakers.

• If you set this feature to Off, audio output is disabled, and you cannot enter the ‘Audio’ menu.

• If you set this feature to On, audio output is enabled, and the ‘Audio’ menu is accessible.

(This feature may not be available with some models.)

Power On Delay

• When multiple monitors are connected, this feature enables the monitors to turn on at specified time intervals to

prevent overload. You can choose an interval value between 1 and 250 seconds. (This feature may not be available with some models.)

Pivot Mode

• This feature allows you to rotate the screen 180 degrees.

• Both the input signal and OSD rotate.

• You can set this feature to On or Off.

• If you set this feature to Off, the function is disabled.

• If you set this feature to On, the screen rotates 180°.

• If any changes are made, they are applied after reboot.

(This feature may not be available with some models.)

OSD Portrait Mode (Off, 90, 270)

• This feature allows you to rotate the OSD clockwise.

• You can set this feature to Off/90/270.

• If you set this feature to Off, the function is disabled.

• If you set this feature to 90, the OSD rotates clockwise 90 degrees.

• If you set this feature to 270, the OSD rotates clockwise 270 degrees.

(This feature may not be available with some models.)

Intelligent Auto

• You can set this feature to On (enabled) or Off (disabled).

• If you change the screen resolution after setting this feature to ‘Yes’, the display is automatically adjusted to the new

resolution. (This feature may not be available with some models.)

Master/Slave Mode

• This feature allows you to sync monitors connected via RS-232C.

• When various monitors are connected via RS-232C, the forefront monitor becomes the Master.

• Once the Master is selected, the rest become Slaves.

• If you want to change the Master monitor, you must change it in Master/Slave Mode.

(This feature may not be available with some models.)

NOTE

• The Master/Slave Mode menu is only enabled when Picture ID is set to Off.

• When entering or editing Master/Slave Mode, the menu cursors on the Slave monitors may not be moved.

Time Sync Clock

• This feature syncs the Slave monitors’ clocks to the Master monitor’s at a specified time via RS-232C.

• On the Master monitor, you can set the sync time as well as setting Time Sync Clock to Off .

• You can select a sync time between 0:00 - 23:00.

• While Time Sync Clock is performed, RS-232C control of other commands may not work.

(This feature may not be available with some models.)

NOTE

• To synchronize Time Sync Clock, be sure to set each slave monitor’s clock so that they are at least one minute later

than the master monitor’s clock.

• If the Clock setting is Auto, the setting is changed to Manual when Time Sync Clock runs.

ENGLISH

Sync Mode

ENGLISH

• This feature allows you to sync the start times of contents (videos or images that have been distributed by SuperSign

Software) played back on the Master and Slave monitors.

• If you set Sync Mode to Off, the sync feature is disabled.

• A Slave monitor plays contents at the same time as the Master monitor.

• While Sync Mode is performed, RS-232C control of other commands may not work.

(This feature may not be available with some models.)

DPM Wakeup Control

• This feature sets conditions for releasing the DPM status according to the DVI/HDMI’s processing of digital signals.

• Clock: Checks the clock signal of the digital signal and, if the clock signal exists, releases the DPM status.

• Sync: Releases the DPM status when both the clock signal and data of the digital signal are entered.

Still Image Detecting

• This feature detects still images.

• If you set this feature to Yes, you can use the RS-232C command for detecting still images.

PM Mode

• This feature activates some of the monitor’s functions after it enters Off status, allowing the monitor to remain

practically the same as when it is turned on.

• Power Off: All functions remain turned off except some functions (Power, Time, etc.) when the monitor turns off.

(Extended Display Identification Data (EDID) may be sustained depending on the input and model.)

• Sustain Aspect Ratio: Sustains Extended Display Identification Data (EDID) even when the monitor is turned off.

• Screen Off: Only turns off the screen and audio when the monitor enters Auto Off/Automatic Standby/DPM.

Network-based control is possible.

• Screen Off Always: Has the same function as PM Mode’s Screen Off. Entering and releasing the Screen Off status

using a remote control is also possible.

Factory Reset

• This feature allows you to restore all set values to their factory default values.

• If you set this feature to Yes, all Signage settings except UTT setting (the Signage panel’s operational hours) are

restored to their factory default settings. (This feature may not be available with some models.)

All user settings will be reset.

Still Continue?

Yes No

OPS/PC Power Control

• You can control the power of the OPS (media player) by turning the display power on or off.

• Disable: Disables the PC Power Control.

• Sync (on): Synchronizes the power status of the OPS (media player) only when the monitor is turned on.

• Sync (on/off): Synchronizes the power status of the OPS (media player) with the monitor.

• The PC Power Control feature can be used with the external RS-232C connection of the media player.

(This feature may not be supported in certain models.)

Interface Selection

• You can configure serial communication with the connected OPS.

• RS-232C: Enables communication with external devices via the serial port.

• OPS: Enables communication via the OPS connected to the product.

• Interface Selection is enabled only when the OPS kit is connected.

(This feature may not be supported in certain models.)

Check Screen

• The Check Screen feature judges whether there are abnormalities on the edges of the screen. R, G, and B OSDs are

formed on the screen at one second intervals and an RGB sensor tests the areas.

• If set to On, the Check Screen feature is enabled.

• If set to Off, the Check Screen feature is disabled.

• If the Portrait mode is set to 90 or 270, the Check Screen feature is off and deactivated.

• If the Pivot mode is On, the Check Screen feature is off and deactivated.

• When the Portrait mode and Pivot mode is off, the Check Screen feature is activated.

(This feature may not be supported in certain models.)

ENGLISH

DPM Off/5sec/10sec/15sec/1min/3min/5min/10min 10min

Power On Status LST, STD, PWR LST

Key Operation Yes/no No

IR Operation Normal/Use PWR Only/Block All Normal Local Key Operation Normal/Use PWR Only/Block All Normal Limited Mode Yes/No NO Input Source Change Yes/No Yes Menu Display Yes/No Yes OSD Display Yes/No Yes

Power On Default Yes/No No

Input Source Variable Off

A/V Setting Yes/No No

Aspec Ratio Disable/4:3/16:9/Set By Program Disable

Wake On LAN On/Off Off

Digital Audio Input Digital/Analog Digital

Speaker On/Off On

Power on Delay Off/1~250sec Off

Pivot Mode On/Off Off

OSD Portrait Mode Off/90/270 Off

Intelligent Auto On/Off On

Master / Slave Mode Master / Slave Slave

Time Sync Clock Off / Standby Stand-by

Sync Mode Off / On Off

DPM Wakeup Control Clock/Sync Clock

Still Image Detection On/Off Yes

PM mode Power Off/Sustain aspect ratio/Screen off/Screen Off

OPS/PC Power Control Disable/Sync(On)/Sync(On/Off) Disable

Factory Reset Confirm

** User: User settings

LG Digital Signage Setup Initial setting /

always

Factory Reset

Power Off

Factory Reset VS Initial Setting

Item Factory Reset Initial Setting

Set ID 1 User

IP Reset to default value “0” User

** The rest are the same as each other.

LG 32SE3D, 43SE3D, 49SE3D, 55SE3D, 65SE3D User Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

OWNER’S MANUAL

IMPORTANT PRECAUTIONS

Electrical Power Related Precautions

Precautions for installing the Product

Precautions for Moving the Product

Precautions for Using/Cleaning the Product

Product Disposal (Only, Hg lamp used LCD Monitor)

LICENSES

ASSEMBLY AND PREPARATION

Optional Accessories

Parts and Buttons

Connecting the Stand

Connecting the Speakers

Using the IR Receiver

Portrait Layout

Attaching and removing the LG Logo Bracket

Installing on a Wall

REMOTE CONTROL

Displaying the Device Name Connected to an Input Port

White Balance Adjust Menu

MAKING CONNECTIONS

Connecting to a PC

External Device Connection

TROUBLESHOOTING

PRODUCT SPECIFICATIONS

SW USER GUIDE

USING THE MONITOR

Using the Input List

Adjusting Aspect Ratio

ENTERTAINMENT

Using the Network

Connecting to a Network

Network Status

Using the My Media

Connecting USB storage devices

Browsing Files

Viewing Movies

Viewing Photos

Listening to Music

Viewing the Contents List

CUSTOMIZING SETTINGS

Accessing Main Menus

PICTURE Settings

AUDIO Settings

TIME Settings

OPTION Settings

NETWORK Settings

PICTURE ID Settings

IR CODES

TO CONTROL MULTIPLE PRODUCTS

Connecting the Cable

RS-232C Configurations

4P Cable

RS-232C Cable

Communication Parameter

Command Reference List

INSTALLATION MANUAL

ACCESSING INSTALLATION MENU

INSTALLATION MENU

LG Digital Signage Setup menu

Signage Mode Operation

Power On Status

Key Operation

IR Operation / Local Key Operation

Limited Mode

Input Source Change

Menu Display

OSD Display

Power On Default (Input Source, A/V Setting, Aspect Ratio)

Input Source

A/V Setting

Aspect Ratio

Wake On LAN

Digital Audio Input

Speaker

Power On Delay
