OWNER’S MANUAL

LCD TV / LED LCD TV / PLASMA TV

Please read this manual carefully before operating the set and retain it for future reference.

www.lg.com

LICENSES

Supported licenses may differ by model. For more information of the licenses, visit www.lg.com.

<Analogue TV> Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby Laboratories.

<Digital TV> Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby Laboratories.

HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.

ENGLISH

ENG

ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, Inc. This is an official DivX Certified® device that plays DivX video. Visit www.divx.com for more information and software tools to convert your files into DivX video.

ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified® device must be registered in order to play purchased DivX Video-on-Demand (VOD) movies. To obtain your registration code, locate the DivX VOD section in your device setup menu. Go to vod.divx.com for more information on how to complete your registration.

“DivX Certified® to play DivX® and DivX Plus ™ HD (H.264/MKV) video up to 1080p HD including premium content.”

“DivX®, DivX Certified® and associated logos are trademarks of DivX, Inc. and are used under license.”

“Covered by one or more of the following U.S. patents : 7,295,673; 7,460,668; 7,515,710; 7,519,274”

LICENSES

ENGENGLISH

TABLE OF CONTENTS

ENGLISH

ENG

TABLE OF CONTENTS

2 LICENSES

6 ASSEMBLING AND PREPAR-

ING

6 Unpacking 11 Separate purchase 12 Parts and buttons 18 Lifting and moving the TV 18 Setting up the TV 18 - Attaching the stand 20 - Mounting on a table 22 - Mounting on a wall 23 - Tidying cables 25 - Not using the Dest-Type Stand

26 REMOTE CONTROL

29 Magic Motion Remote Control Functions 30 - Registrating Magic Motion Remote

Control

30 - How to use Magic Motion Remote Con-

trol

30 - Precautions to Take when Using the

Magic Motion Remote Control

31 WATCHING TV

31 Connecting to an antenna 31 - Connecting an antenna 31 - Connecting with a satellite dish 32 Turning the TV on for the first time 33 Watching TV 33 Accessing Home menu 34 Managing programmes 34 - Automatically setting up programme 35 - Satellite DTV Setting 35 - Manually setting up programme (In

digital mode)

36 - Manually setting up programme (In

analogue mode) 38 - Editing your programme list 39 - Using favourite programmes 40 Using additional options 40 - Adjusting aspect ratio 41 - Changing AV modes 42 - Using the input list 43 Using the quick menu

44 ENTERTAINMENT

44 Connecting the TV to a network 44 - Connecting the wired network 45 - Connecting the wireless network 46 - To set up the network settings, 47 - When a security code is already set 50 - Network Status 51 Premium card function 53 TV Apps. card function 53 - Registration TV Apps. 54 - Sign in with your TV Apps. account 55 - Using TV Apps. 55 - Using My Apps. 56 My Media Card Function 56 - Connecting USB storage devices 57 - DLNA DMP (Digital Living Network Alli-

ance, Digital Media Player)

61 - DLNA DMR (Digital Living Network Alli-

ance, Digital Media Renderer) 62 - Browsing files 63 - Viewing videos 66 - DivX registration code 67 - Viewing photos 69 - Listening to music 71 Timeshift Card Function 71 - Precautions when using the USB De-

vice 72 - TIMESHIFT (PAUSE & REPLAY OF

LIVE TV) 75 - RECORDING 77 - SCHEDULE 79 - RECORDED TV 82 EPG (Electronic Programme Guide) Card

Function (In digital mode) 82 - Switch on/off EPG 82 - Select a programme 83 - NOW/NEXT Guide Mode 83 - 8 Day Guide Mode 83 - Date Change Mode 83 - Extended Description Box 84 MHEG (Multimedia and Hypermedia In-

formation coding Expert Group) (In digital

mode) 84 - Teletext Within Digital Service 84 - Teletext in Digital Service 85 - Switch on/off MHEG 85 - Select a programme 85 - Programme Listing Mode 85 - NOW/NEXT Guide Mode

TABLE OF CONTENTS

86 3D IMAGING

86 3D TECHNOLOGY 87 - When using 3D Glasses 87 - 3D Imaging viewing range 88 Viewing 3D Imaging 88 - Setting 3D Imaging

90 CUSTOMIZING TV SETTINGS

90 Accessing SETUP Menu 91 Customizing settings 91 - SETUP settings 92 - PICTURE settings 99 - AUDIO settings 103 - TIME settings 104 - LOCK settings 105 - OPTION settings 109 - NETWORK settings 110 - SUPPORT settings

111 MAKING CONNECTIONS

112 Connection overview 113 Connecting to a HD receiver, DVD, or

VCR player 113 - HDMI connection 113 - DVI to HDMI connection 114 - Component connection 114 - Composite connection 115 Connecting to a PC 115 - HDMI connection 116 - DVI to HDMI connection 116 - RGB Connection 118 Connecting to an audio system 118 - Digital optical audio connection 118 - Headphone connection 119 Connecting to a USB 120 Connecting to an External Equipment

Wireless 120 SIMPLINK connection 121 - Activating and Using the SIMPLINK

menus

122 - Direct Page Selection 123 Fastext 123 - Page selection 123 Special Teletext Function

124MAINTENANCE

124 Updating the TV firmware 125 Cleaning your TV 125 - Screen and frame 125 - Cabinet and stand 125 - Power cord 125 Preventing “Image burn” or “Burn-in” on

your TV screen

126TROUBLESHOOTING

128SPECIFICATIONS

140IR CODES

ENGENGLISH

141EXTERNAL CONTROL DEVICE

SETUP

141 RS-232C Setup 141 Type of connector;

D-Sub 9-Pin Male 142 RS-232C Configurations 143 Communication Parameters 143 Command reference list 144 Transmission / Receiving Protocol

149OPEN SOURCE SOFTWARE

NOTICE

151OPEN SOURCE LICENSE

122TELETEXT

122 Switch On/Off 122 Simple Text 122 - Page selection 122 Top Text 122 - Block / Group / Page Selection

ASSEMBLING AND PREPARING

Unpacking

Check your product box for the following items. If there are any missing accessories, contact the local dealer where you purchased your product. The illustrations in this manual may differ from the actual product and item.

ENGLISH

ENG

Remote control and batteries (AAA)

(See p. SS)

Polishing cloth1

(This item is not included for all

models.)

1 Gently wipe the spots on the cabinet with the polishing cloth.

2 Wipe spots on the exterior only with the cleasing cloths. Do not wipe roughly when removing stains. Excessive pressure

may cause scratches or discolouration.

For cleaning front frame, please slowly wipe in one direction after

spraying water 1-2 times on cleansing cloths. Please remove excessive moisture after cleaning. Excessive moisture may cause water stains on the frame.

Nero MediaHome 4 Essentials CD

Cleansing Cloths (Mitt)

(This item is not included for all

models.)

Owner’s manual

Ferrite core

(This item is not included for all

models.)

Water

ASSEMBLING AND PREPARING

Only 32/37/42/47/55LV55

x 8

M4 x 16

(Only

42/47/55LW65**,

47/55LW95**)

Screw for assembly Screw for fixing

Component gender cable Composite gender cable 3D Glasses (AG-P110)

, 42/47LW57**, 42/47/55LW65**, 47/55LW77**, 47/55LW95

x 8

M4 x 12

(Except for

42/47/55LW65**,

47/55LW95**)

(Only 32LV55**)

(Only 42/47LW57**,

42/47/55LW65**)

Cable holder

x 2

3D Glasses (AG-S250)

(Only 47/55LW77**,

47/55LW95**)

ENGENGLISH

Motion Remote Control,

Only 32/42/47LV37

Strap,

Batteries (AA)

(Only 47/55LW77**,

47/55LW95**)

x 8

M4 x 12

Screw for assembly Screw for fixing

(Only 32LV37**)

Cable holder

ASSEMBLING AND PREPARING

ENGLISH

ENG

Only 47/55LZ96

Screw for assembly Motion Remote Control,

Component gender cable Composite gender cable Cable holder

x 8

M4 x 12

3D Glasses (AG-S250)

Strap,

Batteries (AA)

x 2

Power Cord

ASSEMBLING AND PREPARING

Only 50/60PZ57

Screw for assembly Cable holder Protection cover Power Cord

3D Glasses

(AG-S250)

Only 50/60PZ95

x 8

M4 x 12

Power Cord holder

ENGENGLISH

x 4

M4 x 26 M5 x 14

(Only 50PZ95

Power Cord Wireless LAN for Broad-

Power Cord holder

x 3

) (Only 60PZ95**) Cable holder Protection cover

Screw for assembly

x 4

M4 x 28

band

/DLNA Adaptor

(AN-WF100)

x 4

M5 x 14

3D Glasses

(AG-S250)

Motion Remote 3

(AN-MR200)

ASSEMBLING AND PREPARING

CAUTION

y Do not use any pirated items to ensure the safety and product life span. y Any damages or injuries by using pirated items are not covered by the warranty.

NOTE

The items supplied with your product may vary depending on the model.

Product specifications or contents of this manual may be changed without prior notice due to

upgrade of product functions. How to use the ferrite core

- White (Only Plasma TV) Use the ferrite core to reduce the electromagnetic interference in the LAN cable.

Wind the LAN cable on the ferrite core once. Place the ferrite core far from the TV.

ENGLISH

ENG

[to an External device]

[to the TV]

- Black (Only LED LCD TV / LCD TV) Use the ferrite core to reduce the electromagnetic waves that interfere with the TV. Place the

ferrite core on the power cable close to the wall plug.

y For an optimal connection, HDMI cables and USB devices should have bezels less than 10 mm

thick and 18 mm width.

*A 10 mm *B 18 mm

ASSEMBLING AND PREPARING

Separate purchase

Separate purchase items can be changed or modified for quality improvement without any notification. Contact your dealer for buying these items. This device only works with compatible LG LED LCD TV, LCD TV or Plasma TV.

Wireless Media Box

(AN-WL100W)

(Except for 32/42/47LV37**)

Wireless LAN for Broadband

/DLNA Adaptor

(AN-WF100)

(Except for 47/55LW95**)

3D Glasses

(AG-S230, AG-S250, AG-S270)

(Except for 32/42/47LV37**,

32/37/42/47/55LV55

Motion Remote 3

(AN-MR200)

(Except for 47/55LW77**,

47/55LW95

, 47/55LZ96**)

)

ENGENGLISH

Multi Mode Remote (MMR)

(TBD)

ASSEMBLING AND PREPARING

Parts and buttons

Image shown may differ from your TV.

NOTE

TV can be placed in standby mode in order to reduce the power consumption. And TV should be

switched off using the power switch on the TV if it will not be watched for some time, as this will reduce energy consumption. The energy consumed during use can be significantly reduced if the level of brightness of the

picture is reduced, and this will reduce the overall running cost.

CAUTION

y Do not step on the glass stand or subject it to any impact. It may break, causing possible injury from

fragments of glass, or the TV may fall.

y Do not drag the TV. The floor or the product may be damaged.

ENGLISH

ENG

ASSEMBLING AND PREPARING

Only 47/55LW77**, 47/55LW95

Emitter

Screen

Remote control and intelligent

sensors

Power indicator

Speakers

INPUT

Touch buttons

USB IN 2

USB IN 1

ENGENGLISH

COMPONENT

IN 1

WIRELESS CONTROL

VIDEO

AV IN 1

VIDEO

RS-232C IN (CONTROL&SERVICE)

L/MONO

AUDIO

AV IN 2

OPTICAL DIGITAL

RGB IN (PC)

AUDIO IN (RGB/DVI)

LAN

AUDIO OUT

ANTENNA/ CABLE IN

AUDIO / VIDEO

COMPONENT IN 2

AUDIO / Y PB P

/DVI /DVI /DVI /DVI

IN 1 IN 2 IN 3 IN 4

H/P

Rear Connection panel (See p.111)

Touch button

INPUT Changes the input source. HOME Accesses the Home menu, or saves your input and exits the menus.

󰭺

P Scrolls through the saved programmes.

Description

Turns the power on or off.

Selects the highlighted menu option or confirms an input. Adjusts the volume level.

1 Intelligent sensor - Adjusts the image quality corresponding to the surrounding environment. 2 All of the buttons are touch sensitive and can be operated through simple touch with your finger. 3 It is the part equipped with the emitter exchanging signal with 3D glasses. Please be careful not to block

the screen with objects or people while watching a 3D Video.

NOTE

y You can set the Power indicator to on or off by selecting OPTION in the Home menus - SETUP.

ASSEMBLING AND PREPARING

ENGLISH

ENG

Only 42/47/55LW65

Emitter

Screen

Remote control and intelligent

sensors

Power indicator

Speakers

INPUT

Touch buttons

USB IN 2

USB IN 1

COMPONENT

IN 1

WIRELESS CONTROL

VIDEO

AV IN 1

VIDEO

RS-232C IN (CONTROL&SERVICE)

L/MONO

AUDIO

AV IN 2

OPTICAL DIGITAL

RGB IN (PC)

AUDIO IN

(RGB/DVI)

LAN

AUDIO OUT

ANTENNA/ CABLE IN

AUDIO / VIDEO

COMPONENT IN 2

AUDIO / Y PB P

/DVI /DVI /DVI /DVI

IN 1 IN 2 IN 3 IN 4

H/P

Rear Connection panel (See p.111)

Touch button

INPUT Changes the input source. HOME Accesses the Home menu, or saves your input and exits the menus.

󰭺

P Scrolls through the saved programmes.

Description

Turns the power on or off.

Selects the highlighted menu option or confirms an input. Adjusts the volume level.

the screen with objects or people while watching a 3D Video.

NOTE

y You can set the Power indicator to on or off by selecting OPTION in the Home menus - SETUP.

ASSEMBLING AND PREPARING

Only 32/37/42/4755LV55**, 42/47LW57

Emitter

RS-232C IN (CONTROL&SERVICE)

LAN

RGB IN (PC)

32/42/47LV37

**,

Screen

Speakers

COMPONENT

IN 1

WIRELESS CONTROL

VIDEO

AV IN 1

VIDEO

L/MONO

AUDIO

AUDIO IN

(RGB/DVI)

OPTICAL DIGITAL

AUDIO OUT

ANTENNA/ CABLE IN

Remote control and intelligent

sensors

Power indicator

INPUT

Touch buttons

USB IN 2

USB IN 1

ENGENGLISH

/DVI /DVI /DVI /DVI

IN 1 IN 2 IN 3 IN 4

AV IN 2

AUDIO / VIDEO

COMPONENT IN 2

H/P

AUDIO / Y PB P

Rear Connection panel (See p.111)

Description

Turns the power on or off.

Touch button

INPUT Changes the input source. HOME Accesses the Home menu, or saves your input and exits the menus.

󰭺

P Scrolls through the saved programmes.

Selects the highlighted menu option or confirms an input. Adjusts the volume level.

the screen with objects or people while watching a 3D Video.

NOTE

y You can set the Power indicator to on or off by selecting OPTION in the Home menus - SETUP.

ASSEMBLING AND PREPARING

ENGLISH

ENG

Only 47/55LZ96

Emitter

Screen

Remote control and intelligent

sensors

Power indicator

Speakers

INPUT

Touch buttons

USB IN 2

USB IN 1

COMPONENT

IN 1

WIRELESS CONTROL

VIDEO

AV IN 1

VIDEO

RS-232C IN (CONTROL&SERVICE)

L/MONO

AUDIO

AV IN 2

OPTICAL DIGITAL

RGB IN (PC)

AUDIO IN (RGB/DVI)

LAN

AUDIO OUT

ANTENNA/ CABLE IN

AUDIO / VIDEO

COMPONENT IN 2

AUDIO / Y PB P

/DVI /DVI /DVI /DVI

IN 1 IN 2 IN 3 IN 4

H/P

Rear Connection panel (See p.111)

Touch button

INPUT Changes the input source. HOME Accesses the Home menu, or saves your input and exits the menus.

󰭺

P Scrolls through the saved programmes.

Description

Turns the power on or off.

Selects the highlighted menu option or confirms an input. Adjusts the volume level.

the screen with objects or people while watching a 3D Video.

NOTE

y You can set the Power indicator to on or off by selecting OPTION in the Home menus - SETUP.

ASSEMBLING AND PREPARING

Only 50/60PZ57

USB input

HDMI IN

AV (Audio and

Video) IN

, 50/60PZ95

Emitter

AUDIO

L/MONO

VIDEO

AV IN 2

USB IN

IN 2

Screen

Power indicator

Remote

Speakers

VIDEO

COMPONENT IN

AUDIO

control and intelligent sensors

MENU OK

INPUT

OPTICAL

AV IN 1

VIDEO

L/MONO

AUDIO

DIGITAL

AUDIO OUT

RGB IN (PC)

RS-232C IN

(CONTROL & SERVICE)

HDMI/DVI IN

AUDIO IN (RGB/DVI)

ANTENNA

Touch buttons

Rear Connection

ENGENGLISH

panel (See p.111)

Description

Turns the power on or off.

Touch button

INPUT Changes the input source. HOME Accesses the Home menu, or saves your input and exits the menus.

󰭺

P Scrolls through the saved programmes.

Selects the highlighted menu option or confirms an input. Adjusts the volume level.

the screen with objects or people while watching a 3D Video.

NOTE

y You can set the Power indicator to on or off by selecting OPTION in the Home menus - SETUP.

ASSEMBLING AND PREPARING

ENGLISH

ENG

Lifting and moving the TV

When moving or lifting the TV, read the following to prevent the TV from being scratched or damaged and for save transportation regardless of its type and size.

CAUTION

Avoid touching the screen at all times, as

this may result in damage on the screen.

It is recommended to move the TV in the box

or packing material that the TV originally came in. Before moving or lifting the TV, disconnect the

power cord and all cables. When holding the TV, the screen should face

away from you to damage.

Setting up the TV

Put your TV on a pedestal stand and mount the TV on a table or wall.

Attaching the stand

Only 47/55LW77

Lay the TV with the screen side down on a flat

surface.

CAUTION

Lay a foam mat or soft protective cloth

on the surface to protect the screen from damage. Make sure not objects press against the screen.

Assemble the parts of the Stand Body with the

Stand Base of the TV.

Model Screw for

47/55LW77 47/55LW95

, 47/55LW95

** **

assembly

M4 x 16 4

Number of screws

Hold the top and bottom of the TV frame firmly.

Make sure not to hold the transparent part, speaker, or speaker grill area.

When transporting a large TV, there should be

at least 2 people. When transporting the TV by hand, hold the

TV as shown in the following illustration.

When transporting the TV, do not expose the

TV to jolts or excessive vibration. When transporting the TV, keep the TV

upright, never turn the TV on its side or tilt towards the left or right.

Stand Body

Stand Base

Assemble the parts of the Stand Rear Cover

with the TV.

Stand Rear Cover

4 Secure the TV and the stand with the 4 screws.

Model Screw for

47/55LW77 47/55LW95

** **

assembly

M4 x 16 4

Number of screws

ASSEMBLING AND PREPARING

Only 32/42/47LV37**, 32/37/42/47/55LV55**, 42/47LW57**, 42/47/55LW65

Lay the TV with the screen side down on a flat

surface.

Assemble the parts of the Stand Body with the

Stand Base of the TV.

Model Screw for

32/42/47LV37 32/37/42/47/55LV55**,

42/47LW57 42/47/55LW65

assembly

M4 x 12 4

Number of screws

Stand Body

Stand Base

Only 50/60PZ57**, 50/60PZ95

Lay the TV with the screen side down on a flat

surface.

Assemble the parts of the Stand Body with the

Stand Base of the TV.

Model Screw for

50PZ95 60PZ95

** **

assembly

M5 x 14 3 M5 x 14 4

Number of screws

Stand Body

Stand Base

ENGENGLISH

3 Secure the TV and the stand with the 4 screws.

Model Screw for

32/42/47LV37 32/37/42/47/55LV55**,

42/47LW57 42/47/55LW65

assembly

M4 x 12 4

Number of screws

Stand Body

Stand Base

3 Secure the TV and the stand with the 4 screws.

Model Screw for

50PZ95 60PZ95

** **

assembly

M4 x 26 4 M4 x 28 4

CAUTION

y Tighten the screws firmly to prevent

the TV from tilting forward. Do not over tighten.

Number of screws

ASSEMBLING AND PREPARING

ENGLISH

ENG

Mounting on a table

Lift and tilt the TV into its upright position on a

table.

- Leave a 10 cm (minimum) space from the wall for proper ventilation.

10 cm

Connect the power cord to a wall outlet.

CAUTION

y Do not place the TV near or on sources

of heat, as this may result in fire or other damage.

10 cm

Securing the TV to a table

(Only 32LV55**, 32LV37 Fix the TV to a table to prevent from tilting forward, damage, and potential injury. Mount the TV on a table, and then insert and tighten the supplied screw on the rear of the stand.

)

WARNING

y To prevent TV from falling over, the TV

should be securely attached to the floor/ wall per installation instructions. Tipping, shaking, or rocking the TV may cause injury.

NOTE

y Swivel 20 degrees to the left or right and

adjust the angle of the TV to suit your view.

2020

ASSEMBLING AND PREPARING

Securing the TV to a wall

(This feature is not available for all models.)

1 Insert and tighten the eye-bolts, or TV brackets

and bolts on the back of the TV.

- If there are bolts inserted at the eye-bolts position, remove the bolts first.

2 Mount the wall brackets with the bolts to the

wall. Match the location of the wall bracket and the

eye-bolts on the rear of the TV.

Using the Kensington security system (optional)

(This feature is not available for all models.) The Kensington security system connector is located at the rear of the TV. For more information of installation and using, refer to the manual provided with the Kensington security system or visit http:// www.kensington.com.

Connect the Kensington security system cable between the TV and a table.

ENGENGLISH

3 Connect the eye-bolts and wall brackets tightly

with a sturdy rope. Make sure to keep the rope horizontal with the

flat surface.

CAUTION

y Make sure that children do not climb on

or hang on the TV.

NOTE

y Use a platform or cabinet that is strong

and large enough to support the TV securely.

ASSEMBLING AND PREPARING

ENGLISH

ENG

Mounting on a wall

Attach an wall mount at the rear of the TV carefully and install the wall mount on a solid wall perpendicular to the floor. When you attach the TV to other building materials, please contact qualified personnel.

10 cm

Make sure to use screws and wall mounts that meet the VESA standard. Standard dimensions for the wall mount kits are described in the following table.

Separate purchase(Wall Mounting Bracket)

Model 32LV37

VESA (A x B) 200 x 100 200 x 200 Standard screw M4 M6 Number of screws 4 4 Wall mount bracket

32LV55

LSW100B, LSW100BG

37LV55

LSW200B, LSW200BG

Model

VESA (A x B) 400 x 400 600 x 400 Standard screw M6 M8 Number of screws 4 4 Wall mount

bracket

50PZ57

50PZ95

PSW400B, PSW400BG, DSW400BG

60PZ57 60PZ95

PSW600B, PSW600BG,

CAUTION

y Disconnect the power first, and then

move or install the TV. Otherwise electric shock may occur.

y If you install the TV on a ceiling or slant-

ed wall, it may fall and result in severe injury. Use an authorized LG wall mount and contact the local dealer or qualified personnel.

y Do not over tighten the screws as this

may cause damage to the TV and void your warranty.

y Use the screws and wall mounts that

meet the VESA standard. Any damages or injuries by misuse or using an improper accessory are not covered by the warranty.

** **

Model

VESA (A x B) 400 x 400 Standard screw M6 Number of screws 4 Wall mount bracket

42LV37 42/47/55LV55 42/47/55LW65 42/47LW57 47/55LW77 47/55LW95 47/55LZ96

LSW400B, LSW400BG, DSW400BG

NOTE

** ** ** **

y Use the screws that are listed on the

VESA standard screw specifications.

y The wall mount kit includes an installation

manual and necessary parts.

y The length of screws may differ depend-

ing on the wall mount. Make sure to use the proper length.

y For more information, refer to the manual

supplied with the wall mount.

ASSEMBLING AND PREPARING

Tidying cables

Only 32/42/47LV37

1 Gather and bind the cables with the cable

holder.

Only 32/37/42/47/55LV55 47/55LW95

1 Gather and bind the cables with the cable

holder.

, 42/47/55LW65

**,

Only 42/47LW57**, 47/55LW77**, 47/55LZ96

1 Gather and bind the cables with the cable man-

agement clip.

2 Fix the cable management clip firmly to the TV.

1 Secure the power cord with the cable holder

on the TV back cover. It will help prevent the power cable from being removed by accident.

2 Gather and bind the cables with the cable

holder.

ENGENGLISH

CAUTION

Do not move the TV by holding the

cable management clip, as the cable management clip may break, and injuries and damage to the TV may occur.

ASSEMBLING AND PREPARING

ENGLISH

ENG

Only 50/60PZ57**, 50/60PZ95

1 Install the Power Cord Holder and Power

Cord. It will help prevent the power cable from

being removed by accident.

(Only 60PZ95**)(Only 50PZ95**)

Power Cord Holder

2 Gather and bind the cables with the Cable

Holder.

Cable Holder

CAUTION

y Do not move the TV by holding the Cable

Holder & Power Cord Holder, as the

Cable holders may break, and injuries and damage to the TV may occur.

Not using the Dest-Type Stand

Only 50/60PZ57**, 50/60PZ95

When installing the wall mounting bracket, use

the

Protection cover

This will protect the opening from accumulating

dust and dirt.

Push the supplied protection cover into the

opening at the bottom of the TV until it locks in place.

ASSEMBLING AND PREPARING

Protection cover

ENGENGLISH

ENGLISH

AV MODE INPUT

TV/ RAD

ENERGY

SAVING

LZ9600/LW9500/LW6500/LW5700 LV5500/LV3700/LV370S

AV MODE INPUT

TV/ RAD

ENERGY

SAVING

AV MODE INPUT

TV/ RAD

ENERGY

LIST

Q.VIEW

SAVING

1 2

ABC3 DEF

GHI5 JKL6

MNO

PQRS8 TUV

WXYZ

LZ9600/LW9500/LW6500/LW5700 LV5500/LV3700/LV370S

ENG

REMOTE CONTROL

The descriptions in this manual are based on the buttons of the remote control. Please read this manual carefully and use the TV correctly.

To replace batteries, open the battery cover, replace batteries (1.5 V AAA) matching battery cover. Be sure to point the remote control to the remote control sensor on the TV.

To remove the batteries, perform the installation actions in reverse.

y y

Make sure to point the remote control to the remote control sensor on the TV.

and ends to the label inside the compartment, and close the

CAUTION

Do not mix old and new batteries, as this may damage the remote control. In Analogue TV and some countries, some remote control keys may not work.

(POWER)

Turns the TV on or off.

ENERGY

SAVING

AV MODE INPUT

TV/ RAD

ENERGY SAVING (See p.93) Adjusts the brightness of the screen to reduce energy consumption. AV MODE (See p.41) Selects an AV mode. INPUT (See p.42) Changes the input source; Turns the TV on.

TV/RAD

Selects Radio, TV and DTV programme.

1 2

ABC3 DEF

GHI5 JKL6

PQRS8 TUV

LIST

MNO

WXYZ

Q.VIEW

Alphanumeric buttons

Enters letters and numbers. LIST (See p.38) Accesses the saved programme list.

Q.VIEW

Returns to the previously viewed programme.

REMOTE CONTROL

AV MODE INPUT

TV/ RAD

ENERGY

LIST

Q.VIEW

FAV

MUTE

MARK

P A G E

SAVING

1 2

ABC3 DEF

GHI5 JKL6

MNO

PQRS8 TUV

WXYZ

CHAR/NUM

DELETE

AV MODE INPUT

TV/ RAD

ENERGY

LIST

Q.VIEW

FAV

RATIO

MUTE

MARK

P A G E

SAVING

BACK

EXIT

Q.MENU

Home

1 2

ABC3 DEF

GHI5 JKL6

MNO

PQRS8 TUV

WXYZ

CHAR/NUM

DELETE

Premium

GUIDE

LZ9600/LW9500/LW6500/LW5700 LV5500/LV3700/LV370S

AV MODE INPUT

TV/ RAD

ENERGY

LIST

Q.VIEW

SAVING

1 2

ABC3 DEF

GHI5 JKL6

MNO

PQRS

TUV

WXYZ

AV MODE INPUT

TV/ RAD

ENERGY

LIST

Q.VIEW

FAV

RATIO

MUTE

MARK

P A G E

SAVING

1 2

ABC3 DEF

GHI5 JKL6

MNO

PQRS8 TUV

WXYZ

CHAR/NUM

DELETE

LZ9600/LW9500/LW6500/LW5700 LV5500/LV3700/LV370S

AV MODE INPUT

TV/ RAD

ENERGY

LIST

Q.VIEW

SAVING

1 2

ABC3 DEF

GHI5 JKL6

MNO

PQRS8 TUV

WXYZ

AV MODE INPUT

TV/ RAD

ENERGY

LIST

Q.VIEW

FAV RATIO

MUTE

MARK

P A G E

SAVING

1 2

ABC3 DEF

GHI5 JKL6

MNO

PQRS8 TUV

WXYZ

CHAR/NUM

DELETE

MARK

FAV

Premium

BACK

Premium

BACK

CHAR/NUM

DELETE

MUTE

CHAR/NUM

RATIO

Home

GUIDE

Home

GUIDE

MARK

DELETE

MUTE

FAV

3D OPTION

Q.MENU

EXIT

Q.MENU

EXIT

P A G E

P A G

+ -

Adjusts the volume level.

MARK

Selects a menu or option. FAV (See p.39) Accesses your favorite programme list.

CHAR/NUM

Switches between Letter and Number input modes. 3D(See p.86) Uses for viewing 3D video. RATIO (See p.40) Resizes an image

DELETE Deletes letters and numbers.

MUTE

Mutes all sounds.

Scrolls through the saved programmess.

PAGE

Moves to the previous or next screen.

Premium

Accesses the Premium menus. Home

Accesses the Home menus. Q. MENU (See p.43)

Accesses the quick menus. 3D OPTION (Only 3D models)(See p.86) Used for viewing 3D video. Navigation buttons (up/down/left/right) Scrolls through menus or options.

Selects menus or options and confirms your input.

BACK

Returns to the previous level.

GUIDE

Shows programme guide.

EXIT

Clears all on-screen displays and return to TV viewing.

ENGENGLISH

WATCHING TV

AV MODE INPUT

TV/ RAD

ENERGY

LIST

Q.VIEW

FAV

MUTE

MARK

P A G E

SAVING

BACK

EXIT

Q.MENU

Home

1 2

ABC3 DEF

GHI5 JKL6

MNO

PQRS

TUV

WXYZ

CHAR/NUM

DELETE

3D OPTION

Premium

GUIDE

AV MODE INPUT

TV/ RAD

ENERGY

LIST

Q.VIEW

FAV

RATIO

MUTE

MARK

P A G E

SAVING

BACK

EXIT

Q.MENU

Home

1 2

ABC3 DEF

GHI5 JKL6

MNO

PQRS8 TUV

WXYZ

CHAR/NUM

DELETE

Premium

GUIDE

LZ9600/LW9500/LW6500/LW5700 LV5500/LV3700/LV370S

AV MODE INPUT

TV/ RAD

ENERGY

LIST

Q.VIEW

FAV RATIO

MUTE

MARK

P A G E

SAVING

BACK

EXIT

Q.MENU

Home

1 2

ABC3 DEF

GHI5 JKL6

MNO

PQRS

TUV

WXYZ

CHAR/NUM

DELETE

Premium

GUIDE

AV MODE INPUT

TV/ RAD

ENERGY

LIST

Q.VIEW

FAV RATIO

MUTE

MARK

P A G E

SAVING

BACK

EXIT

Q.MENU

Home

1 2

ABC3 DEF

GHI5 JKL6

MNO

PQRS8 TUV

WXYZ

CHAR/NUM

DELETE

Premium

GUIDE

AV MODE INPUT

TV/ RAD

ENERGY

LIST

Q.VIEW

FAV

MUTE

MARK

P A G E

SAVING

BACK

EXIT

Q.MENU

Home

1 2

ABC3 DEF

GHI5 JKL6

MNO

PQRS8 TUV

WXYZ

CHAR/NUM

DELETE

3D OPTION

Premium

GUIDE

AV MODE INPUT

TV/ RAD

ENERGY

LIST

Q.VIEW

FAV

RATIO

MUTE

MARK

P A G E

SAVING

BACK

EXIT

Q.MENU

Home

1 2

ABC3 DEF

GHI5 JKL6

MNO

PQRS8 TUV

WXYZ

CHAR/NUM

DELETE

Premium

GUIDE

REC

LIVE TV

INFO

LZ9600/LW9500/LW6500/LW5700 LV5500/LV3700/LV370S

Coloured buttons

These buttons are used for teletext (on TELETEXT models only), Programme edit.

TELETEXT BUTTONS (See p.122) These buttons are used for teletext. For further details, see the ‘Teletext’ section.

ENGLISH

ENG

LIVE TV

REC

INFO

RATIO

REC

INFO

SUBTITLE

Recalls your preferred subtitle in digital mode.

Control buttons (

)

Controls the Timeshift or MY MEDIA menus or the SIMPLINK compatible devices (USB,SIMPLINK or Timeshift).

LIVE TV (See p.71) Return to the LIVE TV.

REC

Uses to adjust Timeshift Mode. INFO (See p.82)

Views the information of the currently programme and the screen. RATIO (See p.40) Resizes an image

SIMPLINK (See p.120) Accesses the AV devices connected to the TV; Opens the SIMPLINK menu.

WATCHING TV

Magic Motion Remote Control Functions

This item is not included for all models.

The descriptions in this manual are based on the buttons of the remote control. Please read this manual carefully and use the TV correctly.

When the message "Magic motion remote control battery is low. Change the battery." is displayed, replace the battery.

To replace batteries, open the battery cover, replace batteries (1.5 V AA) matching and ends to the label inside the compartment, and close the battery cover. Be sure to point the remote control to the remote control sensor on the TV.

To remove the batteries, perform the installation actions in reverse.

CAUTION

Do not mix old and new batteries, as this may damage the remote control.

In Analogue TV and some countries, some remote control keys may not work.

Make sure to point the remote control to the remote control sensor on the TV.

(POWER)

Turns the TV on or off.

Navigation buttons

(up/down/left/right)

Scrolls through menus or options.

MUTE

Mutes all sounds.

Pointer Receiver Blinks the light when operating.

HOME Accesses the Home menus.

Display the pointer when it disappears from the screen. You can control the TV by selecting Quick Menu on the screen.

+ -

Adjusts the volume level.

󰮽󰮾

Scrolls through the saved programmes.

ENGENGLISH

Home menu Programme List

Quick Menu

WATCHING TV

ENGLISH

ENG

Registrating Magic Motion Remote Control

The Magic Motion Remote Control operates by pairing with your TV. Register the Magic Motion Remote Control after purchasing the TV.

How to register the Magic Motion Remote Control

To register the Remote Control, press the OK button on the Remote Control while aiming it at your TV.

How to Re-register the Magic Motion Remote Control after Registration Failure

Reset the remote control by pressing and holding both the (Once the reset is complete, the light on the Pointer RF Receiver blinks.) Then repeat the above procedure to register the remote control.

and MUTE buttons for 5 seconds.

How to use Magic Motion Remote Control

Precautions to Take when Using the Magic Motion Remote Control

y Use the remote control within the maximum

communication distance (10 m). Using the remote control beyond this distance, or with an object obstructing it, may cause a communication failure.

y A communication failure may occur due to

nearby devices. Electrical devices such as a microwave oven or wireless LAN product may cause interference, as this will use the same bandwidth (2.4 GHz) as the Magic Motion Remote Control.

y The Magic Motion Remote Control may be

damaged or may malfunction if it is dropped or receives a heavy impact.

y When playing a game using the Magic

Motion Remote Control, hold it securely by wrapping its strap around your wrist and adjusting the length with the adjustable ring.

y Take care not to bump into nearby furniture

or other people when using the Magic Motion Remote Control.

y Manufacturer and installer cannot provide

service related to human safety as the applicable wireless device has possibility of electric wave interference.

1 Press

button if there is no pointer on your TV screen. The pointer will then appear on the screen. If the pointer has not been used for a certain

period of time, it will disappear.

2 You can move the pointer by aiming the Pointer

Receiver of the remote control at your TV then move it left, right, up or down. If the pointer does not work properly after clicking the

button, leave the remote control for

10 seconds then use it again.

WATCHING TV

Connecting to an antenna

Connect an antenna to watch TV referring to the following. To prevent damage do not connect to the mains outlet until all connections are made between the devices.

Connecting an antenna

Connect the TV to a wall antenna socket with a RF cable (75 ohm).

Connecting with a satellite dish

(Only Satellite models)

Connect the TV to a satellite dish to a satellite socket with a satellite RF cable (75 ohm).

13/18V

700mA Max

LNB IN

Satellite

ENGENGLISH

Wall Antenna Socket

NOTE

Use a signal splitter to use more than 2

TVs. If the image quality is poor, install a signal

amplifier properly to improve the image quality. If the image quality is poor with an

antenna connected, aim the antenna to the proper direction. An antenna cable and converter are not

supplied.

Satellite Dish

WATCHING TV

ENGLISH

ENG

Turning the TV on for the first time

When you turn the TV on for the first time, the Initial setting screen appears. Select a language and customize the basic settings.

Connect the power cord to a power outlet.

In Standby mode, press (Power) to turn the

TV on. The Initial setting screen appears if you turn

the TV on for the first time.

NOTE

You can also access Factory Reset by

accessing OPTION in the Home menu SETUP.

Follow the on-screen instructions to customize

your TV settings according to your preferences.

Language



Mode Setting



Power Indicator



Country



Time Zone



Network Setting



Auto Tuning

Selects a language to display. (Except for Australia, New Zealand, Singapore, South Africa),

Selects Home Use for the Home environment.

Sets the power indicator. (When you select Home Use from Mode Setting - only LED LCD TV)

Selects a country to display. (Only Australia, New Zealand)

Selects the time zone and daylight saving.(Only Australia)

Sets your network to enable network-related feature on the TV.(Only 47/55LW95**)

Scans and saves available channels automatically.

NOTE

DTV mode control buttons may not

function based on country broadcasting circumstances. (Only DTV) For those countries without confirmed

DTV broadcasting standards, some DTV features might not work, depending on the DTV broadcasting environment.(Only DTV) To display images in the best quality for

your home environment, select Home Use. Store Demo is suitable for the retail

environment. If you select Store Demo, the previously

customized settings will switch to the default settings of Store Demo in 5 minutes.

4 When the basic settings are complete,

press OK.

NOTE

y If you do not complete the Initial setting, it

will appear whenever the TV turns on.

y Disconnect the power cord from the

power outlet when you do not use the TV for a long period of time.

5 To turn the TV off, press (Power).

Watching TV

In Standby mode, press (Power) to turn the TV on.

Press INPUT and select Antenna.

To turn the TV off, press (Power).

The TV switches to Standby mode.

Accessing Home menu

Press HOME to access the Home menu.

Press the Navigation buttons to scroll to one of the following menus and press OK.

Press the Navigation buttons to scroll to the setting or option you want and press OK.

When you are finished, press EXIT.

Premium Card

WATCHING TV

Live TV

INPUT,

SETUP,

Favourite List

Current Date, Time

15-0

INPUT SETUP

More AppStore

Favorite List

Boing Boing

Quick Apps

Premium

Miro Fox News

TV Apps

HD Trailer

ENGENGLISH

Exit Sign In

HOT NEW

TV Apps

WATCHING TV

ENGLISH

ENG

Managing programmes

Automatically setting up programme

Selecting Antenna,

Use this to automatically find and store all available programmes. When you start auto programming, all previously stored service information will be deleted.

1 Press HOME to access the Home menus.

2 Press the Navigation buttons to scroll to

SETUP and press OK.

3 Press the Navigation buttons to scroll to

SETUP and press OK.

4 Press the Navigation buttons to scroll to

Auto Tuning and press OK.

5 Select Start to start automatic tuning.

The TV scans and saves available programmes automatically.

6 When you are finished, press EXIT.

When you return to the previous menu, press

BACK.

Selecting Satellite,

(Only Satellite models)

1 Press HOME to access the Home menus. 2 Press the Navigation buttons to scroll to

SETUP and press OK.

3 Press the Navigation buttons to scroll to

SETUP and press OK.

4 Press the Navigation buttons to scroll to

Auto Tuning and press OK.

5 Press the Navigation buttons to scroll to

Satellite and press OK.

6 Press the Navigation buttons to scroll to

Satellite DTV Setting and press OK.

7 Press the Navigation buttons or Number but-

tons to scroll make appropriate adjustments and press OK.

8 Press the Navigation buttons to scroll to

Close and press OK.

9 Select Start to start automatic tuning.

The TV scans and saves available programmes automatically.

NOTE

y If the TV scans a blocked programme, you

will be prompted to enter your password to keep the programme scanned.

y If you wish to keep on auto tuning select

Start using the Navigation buttons. Then, press the OK button. Otherwise select Close.

y Automatic Numbering: Decide whether

to use the programme numbers as sent by broadcasting stations for tuning. (Only DTV)

10 When you are finished, press EXIT.

When you return to the previous menu, press

BACK.

NOTE

y Programme Type : You can select All

Programmes, FTA Programme or Paid Programme.

y Network Search : You can search through

both an existing Transponder List and the

Transponder List that was transmitted via NIT.

y You can change the Setting ID Info from the

Setting menu.

y You can Add/Delete the Setting ID from the

Satellite DTV Setting menu.

WATCHING TV

Satellite DTV Setting

(Only Satellite models)

You can add or delete a satellite setting ID.

1 Press HOME to access the Home menus. 2 Press the Navigation buttons to scroll to

SETUP and press OK.

3 Press the Navigation buttons to scroll to

SETUP and press OK.

4 Press the Navigation buttons to scroll to Satel-

lite DTV Setting and press OK.

5 Select your desired Source. 6 When you are finished, press EXIT.

When you return to the previous menu, press

BACK.

NOTE

y If you set LNB Frequency to User or Satel-

lite to Others when adding a setting ID, you can add a transponder during Manual Tuning.

y You can add up to 16 setting IDs. y All setting IDs can be deleted, except for

Setting ID 1.

y When selecting 22KHz Tone and DiSEqc, or

Tone Burst and DiSEqc, you must connect

them in the same position as displayed on the OSD.

y If a motor is connected, 22KHz Tone, Tone

Burst and DiSEqc are disabled on the TV

OSD.

Manually setting up programme (In digital mode)

Manual Tuning lets you manually add a programme to your programme list.

Selecting Antenna,

1 Press HOME to access the Home menus. 2 Press the Navigation buttons to scroll to

SETUP and press OK.

3 Press the Navigation buttons to scroll to

SETUP and press OK.

4 Press the Navigation buttons to scroll to

Manual Tuning and press OK.

5 Press the Navigation buttons to scroll to DTV

and press OK.

6 Scroll through the programme types, and then

add or delete programmes.

7 When you are finished, press EXIT.

When you return to the previous menu, press

BACK.

NOTE

y If the TV scans a blocked programme, you

will be prompted to enter your password to keep the programme scanned.

(Only DTV)

ENGENGLISH

WATCHING TV

ENGLISH

ENG

Selecting Satellite,

(Only Satellite models)

1 Press HOME to access the Home menus. 2 Press the Navigation buttons to scroll to

SETUP and press OK.

3 Press the Navigation buttons to scroll to

SETUP and press OK.

4 Press the Navigation buttons to scroll to

Manual Tuning and press OK.

5 Press the Navigation buttons to scroll to Satel-

lite DTV and press OK.

6 Make appropriate adjustments. 7 When you are finished, press EXIT.

When you return to the previous menu, press

BACK.

NOTE

y If the TV scans a blocked programme, you

will be prompted to enter your password to keep the programme scanned.

y Transponder : If there is no transponder to

use, you can add a transponder by logging in as User.

y If there is no transponder, you cannot use

Auto Tuning. In this case, you must add a transponder using Manual Tuning.

Manually setting up programme (In analogue mode)

Manual Tuning lets you manually tune and arrange the stations in whatever order you desire.

1 Press HOME to access the Home menus. 2 Press the Navigation buttons to scroll to

SETUP and press OK.

3 Press the Navigation buttons to scroll to

SETUP and press OK.

4 Press the Navigation buttons to scroll to

Manual Tuning and press OK.

5 Press the Navigation buttons to scroll to

TV and press OK. (Only DTV)

6 Scroll through the programme types, and then

add or delete programmes.

7 Press the Navigation buttons to scroll to

TV System. (Except for Australia)

8 Press the Navigation buttons to scroll to

V/UHF or Cable.

9 Press the Navigation buttons or Number but-

tons to scroll to the desired channel number.

10 Press the Navigation buttons to scroll to

commence searching.

11 Press the Navigation buttons to scroll to

Store and press OK.

12 When you are finished, press EXIT.

When you return to the previous menu, press BACK.

NOTE

y Use NUMBER buttons to input a 4-digit

password in Lock System ‘On’.

y BG : PAL B/G (New Zealand / South Africa

/ Singapore / Indonesia / Israel / Malaysia / Vietnam / Asia)

DK : PAL D/K (New Zealand / South Africa / Singapore / Indonesia / Israel / Malaysia / Vietnam / Asia)

I : PAL I/II (New Zealand / South Africa / Singapore / Indonesia / Israel / Malaysia /

Vietnam / Asia) B/B : Australia M : NTSC-M (South Africa / Indonesia /

Israel / Malaysia / Vietnam / Asia)

y To store another channel, repeat steps 5 to

10.

WATCHING TV

Assigning a station name

You can assign a station name with five characters to each programme number.

1 Press HOME to access the Home menus. 2 Press the Navigation buttons to scroll to

SETUP and press OK.

3 Press the Navigation buttons to scroll to

SETUP and press OK.

4 Press the Navigation buttons to scroll to

Manual Tuning and press OK.

5 Press the Navigation buttons to scroll to

TV. (Only DTV)

6 Press the Navigation buttons to scroll to

Name and press OK.

7 Press the Navigation buttons to scroll Select

the position and make your choice of the second character, and so on. You can use an the alphabet A to Z, the number 0 to 9, +/ -, and blank and press OK.

8 Press the Navigation buttons to scroll to

Close and press OK.

Fine Tuning

Normally fine tuning is only necessary if reception is poor.

1 Press HOME to access the Home menus. 2 Press the Navigation buttons to scroll to

SETUP and press OK.

3 Press the Navigation buttons to scroll to

SETUP and press OK.

4 Press the Navigation buttons to scroll to

Manual Tuning and press OK.

5 Press the Navigation buttons to scroll to

TV. (Only DTV)

6 Press the Navigation buttons to scroll to

Fine.

7 Fine tune for the best picture and sound. 8 Press the Navigation buttons to scroll to

Store and press OK

9 When you are finished, press EXIT.

When you return to the previous menu, press

BACK.

ENGENGLISH

9 Press the Navigation buttons to scroll to

Store and press OK

10 When you are finished, press EXIT.

When you return to the previous menu, press

BACK.

WATCHING TV

ENGLISH

ENG

Editing your programme list

When a programme number is skipped, it means that you will be unable to select it using P ton during TV viewing. If you wish to select the skipped programme, directly enter the programme number with the NUMBER buttons or select it in the Programme edit menu. This function enables you to skip the stored programmes. You can change the programme number using “Move”function, if “Automatic Numbering” is unchecked when you start Auto Tuning (Only DTV).

1 Press HOME to access the Home menus.

2 Press the Navigation buttons to scroll to

SETUP and press OK.

3 Press the Navigation buttons to scroll to

SETUP and press OK.

4 Press the Navigation buttons to scroll to Pro-

gramme Edit and press OK.

but-

Selecting a programme on the programme list

1 Press LIST to access the programme list.

Button Description

Selects programme list or recent programme list.

Scrolls through programme.

OK P

Red button Edits Channel. FAV Sets up a favourite programme list.

Selects the highlighted programme to view.

Moves to the previous or next page.

2 When you are finished, press EXIT.

When you return to the previous menu, press

BACK.

NOTE

y If you select the blocked programme, you will

be prompted to enter your password.

5 Edit channels using the following buttons.

Button Description

Highlight the channel type (DTV, RADIO, TV).

Scrolls through programme types or programmes.

Edits programmes.

Watch

Set as Favourite

Red button

Green button Starts Satellite Programme Sort. (Only

Skip Programme

Number Edit

Block

Moves to the previous or next page. Selects your desired favourite pro-

gramme group.

Satellite models)

Selects the highlighted programme to view.

Registers or cancels the current programme in favourite programme list.

Selects a programme number to be skipped.

Selects your desired programme number.

Blocks or unblocks a programme.

6 When you are finished, press EXIT.

When you return to the previous menu, press

BACK.

Using favourite programmes

Add the programmes that you watch frequently to the favourite list.

1 Select a programme to add to the favourite list. 2 Press FAV.

NOTE

y You can also access the input favourite list

by selecting Favourite List in the Home menu.

Button Description

Selects a desired programme group.

Red button Moves to the Programme Edit. Green button FAV Moves to the Programme List.

Moves to the previous or next page.

WATCHING TV

3 When you are finished, press EXIT.

NOTE

y You can also setup Favourite List in the

SETUP menu - Programme Edit.

ENGENGLISH

WATCHING TV

ENGLISH

ENG

Using additional options

Adjusting aspect ratio

Resize an image to view at its optimal size by pressing RATIO while you are watching TV.

NOTE

y You can also change the image size by

pressing Q. MENU or accessing Aspect Ratio in the PICTURE menus.

y For Zoom Setting, select 14:9, Zoom

and Cinema Zoom in Ratio Menu.

After completing Zoom Setting, the display goes back to Q.Menu. You can only select 4:3, 16:9 (Wide), 14:9, Zoom/Cinema Zoom in Component mode. You can only select 4:3, Original, 16:9 (Wide), 14:9, Zoom/Cinema Zoom in HDMI mode. You can only select 4:3, 16:9 (Wide) in RGB-PC, HDMI-PC mode only.

y In DTV/HDMI/Component (over 720p)

mode, Just Scan is available.

y In DTV(over 576p) mode, Just Scan is

available in Austalia only.

- Just Scan: Displays video images in the

original size without disappearing parts at the edge of the image.

Just Scan

NOTE

y If you select Just Scan, you may see

image noises at the edge of the original signal.

Original: When your TV receives a wide

screen signal it will automatically change to the picture format broadcast.

Original

Full Wide(Only DTV): When TV receives the

wide screen signal,it will lead you to adjust the picture horizontally or vertically, in a linear proportion,to fill the entire screen fully.

Original

- 16:9: Resizes images to fit the screen width.

4:3 and 14:9 video is supported in full screen without any video distortion through DTV input.

Full Wide

- 4:3: Resizes images at the standard 4:3 with-

out distortion.

14:9 : You can view a picture format of 14:9

or a general TV programme in the 14:9 mode. The 14:9 screen is viewed in the same way as in 4:3, but is moved to the up and down.

- Zoom: Enlarges an image to fit the screen

width. The top and bottom of the image may not appear.

NOTE

y If you access, Aspect Ratio in the quick

menus,

- Press the Navigation buttons to stretch an image vertically.

- Press the Navigation buttons to move the zoom focus up or down.

WATCHING TV

Changing AV modes

Each AV mode has the optimized image and sound settings. Press AV MODE repeatedly to select an

appropriate mode.

Mode Description

Off Changes to the previously customized

Cinema or THX Cinema

Sport (Only Plasma TV)

Game Use the optimized image and sound

y If you select Off in AV mode, the picture

and image which you initially set will be selected.

settings. Use the optimized image and sound

setting for the cinematic look. Use the optimized image and sound

setting for dynamic action sports.

setting for fast gaming. When playing a video game using PlayStation or Xbox, it is recommended to use the Game mode. When in Game mode, functions related to picture quality will be optimized for playing games.

NOTE

ENGENGLISH

- Cinema Zoom: Choose Cinema Zoom when

you want to enlarge the picture in correct proportion.

To change the ratio of the cinema zoom,

press To move the zoom focus up or down, press

y If you enlarge or reduce an image, the

image may be distorted.

and its range is from 1 to 16.

NOTE

WATCHING TV

ENGLISH

ENG

Using the input list

Selecting an input source

1 Press INPUT to access the input sources.

- The connected device displays on each input source.

NOTE

y You can also access the input source list

by selecting INPUT in the Home menus.

Press the Navigation buttons to scroll to one of

the input sources and press OK.

Image shown may differ from your TV.

Input List

Antenna USB 1

USB 2

▼

NETWORK

AV1

Page 1/2

AV2

The connected input sources display in black and the disconnected input sources in grey.

- To add an input label, press the Green button. You can easily identify a device connected to each input source.

- If you connect a new external device to the TV, a pop-up window appears. Select Yes on the pop-up window to select an input source.

- To access the SIMPLINK, press the Red button. If you select “SIMPLINK and On”, the pop-up window for the HDMI input will not display.

Component1

Input source Description

Antenna or Satellite

USB Use the movie, photo or music file. NETWORK Use it for DLNA. AV Watch the contents in a VCR or other

Component Watch the contents in a DVD or other

RGB View a PC display on the screen. HDMI Watch contents in a HTS or other high

Component2

RGB

▼

SIMPLINK

Watch TV over the air and digital cable broadcast.

external devices.

external devices, or through a digital set-top box.

definition devices.

HDMI2 HDMI3HDMI1

Input Label

Exit

WATCHING TV

Adding an Input label

Add a label to an input source so that you can easily identify a device connected to each input source.

Image shown may differ from your TV.

Input Label

AV1 AV2 Component1 Component2 RGB

▼

◄

Page 1/2

►

1 Press INPUT to access the input sources. 2 Press the Green button. 3 Press the Navigation buttons to scroll to one of

the input sources.

4 Press the Navigation buttons to scroll to one of

the input labels.

5 When you are finished, press EXIT. When you return to the previous menu, press

BACK.

Using the quick menu

Customize the frequently using menus.

Press Q. MENU to access the quick menus.

Press Navigation buttons to scroll through the

following menus and press OK.

Menu Description (Depending on model)

Aspect Ratio Changes the image size (16:9, Just

Picture Mode Changes the image mode (Intelligent

Sound Mode Changes the sound mode (Standard,

Sleep Timer Sets the length of time until the TV to

Subtitle Language

Audio or Audio Language

Energy Saving Reduces the power consumption

AV Mode Sets the optimized image and sound

Skip Off/On Sets the Skip Off/On. USB Device Eject a USB device.

Scan, Original, Full Wide, 4:3, 14:9, Cinema Zoom)

Sensor, Vivid, Standard, Cinema or THX Cinema or THX Bright Room, Game, Expert1, Expert2)

Music, Cinema, Sport, Game)

turns off Recalls your preferred subtitle in

digital mode. Changes the sound output.

by adjusting the screen brightness. (Intelligent Sensor, Auto, Off, Minimum, Medium, Maximum, Screen Off)

settings (Off, Cinema,Game)

ENGENGLISH

NOTE

The available menus and options may

differ from the input source that you are using.

Press Navigation buttons to scroll to the option

you want.

When you are finished, press Q. MENU.

ENTERTAINMENT

-232

(CO

NTR

ERVI

)

B IN

OPTICAL DIGITAL

AUDIO OUT

DIGIT

TICAL DIGIT

(RGB/DVI)

AUDIO IN

ANTENNA/

CABLE IN

AUDIO /

VIDE

COMPO

NENT IN

UDIO / Y PB P

H/P

WIRELE

NTROL

UDI

IDEO

COMPO

NEN

UDIO

IDE

I /

ENGLISH

ENG

ENTERTAINMENT

Connecting the TV to a network

Connecting the wired network

Connect the TV and a local area network (LAN) via the LAN port as shown on the following illustration and set up the network settings. If wired and wireless networks are both available, wired is the preferred method. After making a physical connection, a small number of home networks may require the TV network settings to be adjusted. For detail information, contact your internet provider or router manual.

LAN

RGB IN (P

CAUTION

y Do not connect a modular phone cable to the

LAN port.

y Since there are various connection meth-

ods, please follow the specifications of your telecommunication carrier or internet service provider.

y After connecting the LAN port, use the

Premium or TV Apps menu. For more information about Premium or TV App setup and troubleshooting, visit http:// lgknowledgebase.com. Search for NetCast.

To set up the network settings,

1 Press HOME to access the Home menus. 2 Press the Navigation buttons to scroll to

SETUP and press OK.

3 Press the Navigation buttons to scroll to NET-

WORK and press OK.

4 Press the Navigation buttons to select Net-

work Setting and press OK.

Internet

Router

Cable modem

LAN WAN

ETHERNET

5 If wired and wireless are simultaneously con-

nected, press the Navigation buttons to select Wired and press OK.

6 If you already set Network Setting, select

Resetting. The new connection settings resets the current network settings.

7 Select IP Auto Setting or IP Manual Setting.

- If selecting IP Manual Setting, press the Navigation and Number buttons. IP addresses will need to be input manually.

- IP Auto Setting: Selects if there is a DHCP server on the local area network (LAN) via wired connection, the TV will automatically be allocated an IP address. If you’re using a broadband router or broadband modem that has a DHCP (Dynamic Host Configuration Protocol) server function. The IP address will automatically be determined.

- IP Manual Setting: Selects if there is no DHCP server on the network and you want to set the IP address manually.

8 When you are finished, press EXIT.

ENTERTAINMENT

IDVI /

NOTE

y If you want to access the Internet directly on

your TV, the broadband internet connection should always be on.

y If you cannot access the Internet, check the

network conditions.

y When you use Network Setting, check the

LAN cable or check if the DHCP in the router turns on.

y If you do not complete the network settings,

the network may not work properly.

Connecting the wireless network

(Unnecessary this setup for 47/55/60LW95**) The LG Wireless LAN for Broadband/DLNA Adap-

tor, which is sold separately, allows the TV to connect to a wireless lan network. The network configuration and connection method may vary depending on the equipment in use and the network environment. Refer to the setup instructions supplied with your access point or wireless router for detailed connection steps and network settings. Setting up the AP (Access Point) or the wireless router is required before connecting the TV to the network.

USB IN 2

USB IN 1

AV IN 2

UDIO / VIDE

OMPONENT IN 2

AUDIO / Y P

H/P

Router

Internet

Cable modem

LAN WAN

ETHERNET

ENGENGLISH

NOTE

y For enjoying pictures, music, or video stored

in the PC using the router, the use of wired port in the router is recommended.

y When the wireless port of the router is used,

there may be restrictions for some functions.

y It is recommended that an Access Point

(AP) is installed more than 1 m away from the TV. If the AP is installed closer than 1 m, the magic motion remote controller may not perform as expected due to frequency interference.

ENTERTAINMENT

ENGLISH

ENG

To set up the network settings,

1 Press HOME to access the Home menus. 2 Press the Navigation buttons to scroll to

SETUP and press OK.

3 Press the Navigation buttons to scroll to NET-

WORK and press OK.

4 Press the Navigation buttons to select Net-

work Setting and press OK.

5 Press the Navigation buttons to select Wire-

less and press OK.

6 If you already set Network Setting, select Re-

setting and press OK. The new connection settings resets the current

network settings.

7 Press the Navigation buttons to select Setting

from the AP list and press OK.

- Scan the all available AP (Access Point) or wireless routers within range and display them as a list.

9 Press the Number buttons to Input the security

key of AP and press OK.

Inserting the security key

 

Insert hexadecimal (0~9, A~F) 10 or 26 digits, insert 5 or 13 ASCII characters.

OK Cancel

Exit Previous

10 Repeat step 6-7 on “Connecting the wired

network”.

Selecting the wireless network setting type

Select the wireless network setting type.

Setting from the AP list

Simple setting (WPS-button mode)

Setting Ad-hoc network

󰭺Next

ꕉ Previous 󰯠 Exit

8 Press the Navigation buttons to select an AP

(Access Point) or wireless router on the list. (If your AP is locked, insert the security key of AP) and press OK.

Selecting AP

Select AP you want to connect.

Input the new SSID

FREEO_AP HEASSET

Meteor

PIN Connect

▼

Page 1/10

Access Point

ꔉ

▼

Exit

ENTERTAINMENT

When a security code is already set

PIN (Personal Identification Number)

If you want to connect the AP (Access Point) or router with PIN, use this feature.

1 Repeat step 1-7 on “Connecting the wireless

network”.

2 Press the Red button to connect the access

point with PIN mode.

3 You can see the Network ID and Security Key

on your TV screen. Enter the PIN number to your device.

PIN number is the unique 8 digit number of the dongle.

4 Press OK to select Connect.

Connecting with PIN mode

Insert PIN number at the AP webpage and

press [Connect] button.

PIN NUBMER : 12345670

Connect

For more information, check the AP manual.

󰭺Next

󰮺Previous

󰯠 Exit

WPS (Wi-Fi Protected Setup)

If your access point or wireless router that supports PIN or WPS(Wi-Fi Protected Setup), it’s available to use your access point or wireless router within 120 counts. You do not need to know the access point name (SSID: Service Set Identifier) and security code of your access point or wireless router.

1 Repeat step 1-7 on “Connecting the wireless

network”.

2 Press the Navigation buttons to select the

Simple setting (WPS-button mode).

3 Press OK to select Connect. 4 Repeat step 6-7 on “Connecting the wired

network”.

ENGENGLISH

5 Repeat step 6-7 on “Connecting the wired

network”.

ENTERTAINMENT

ENGLISH

ENG

Ad-hoc Mode

This is the method of communicating directly with the machine to communicate without AP. This is the same as connecting two PCs with a cross cable.

1 Repeat step 1-5 on “Connecting the wireless

network”.

2 Press the Navigation buttons to select Setting

Ad-hoc network and press OK.

3 Press the Navigation buttons to select OK and

press OK.

4 Press OK to select Connect to connect Ad-hoc

network.

- You can see the Network ID and Security Key on your TV screen.

- Enter this Network ID and Security Key to your device.

- If a network may not operate, change the setting information using the Red button.

NOTE

Example of the PC setting that supports a wireless network

y Find a wireless network device in your

PC.

y Select LGTV10 that appears in the list.

(Select the same name as the network ID that appears on your TV screen.)

y Type 1111111111 in the Inserting the se-

curity key dialog. (Type the security key that appears on your TV screen.)

5 Press the Navigation buttons to insert the IP

address and press OK.

Option Description

y Internet Protocol(TCP/IP) of PC

needs to be set manually.

y IP address, Subnet Mask, and

PC Setting

TV Setting

default Gateway can be set with your own discretion.

y i.e) IP address: 192.168.0.1 / Sub-

net Mask: 255.255.255.0 / default Gateway: 192.168.0.10

y Verify IP address and gateway of

PC.

y Input Gateway address of PC to

IP Address, and IP Address of PC to Gateway, and select OK.

y i.e) IP address: 192.168.0.10 /

Subnet Mask: 255.255.255.0 / default Gateway: 192.168.0.1

6 Press the Navigation buttons to select Close

after Network setting is completed.

7 Press the OK.

ENTERTAINMENT

Tips for Network setting

y For more information about Premium or TV App

setup and troubleshooting, visit http://lgknowledgebase.com. Search for NetCast.?

y Use a standard LAN cable with this TV. Cat5 or

better with a RJ45 connector.

y Many network connection problems during set

up can often be fixed by re-setting the router or modem. After connecting the player to the home network, quickly power off and/or disconnect the power cable of the home network router or cable modem. Then power on and/or connect the power cable again.

y Depending on the internet service provider

(ISP), the number of devices that can receive internet service may be limited by the applicable terms of service. For details, contact your ISP.

y LG is not responsible for any malfunction of the

TV and/or the internet connection feature due to communication errors/malfunctions associated with your broadband internet connection, or other connected equipment.

y LG is not responsible for problems within your

internet connection.

y Some content available through the network

connection may not be compatible with the TV. If you have questions about such content, please contact the producer of the content.

y You may experience undesired results if the

network connection speed does not meet the requirements of the content being accessed.

y Some internet connection operations may not

be possible due to certain restrictions set by the Internet service provider (ISP) supplying your broadband Internet connection.

y Any fees charged by an ISP including, without

limitation, connection charges are your responsibility.

y A 10 Base-T or 100 Base-TX LAN port is re-

quired for connection to this TV. If your internet service does not allow for such a connection, you will not be able to connect the TV.

y A DSL modem is required to use D SL service

and a cable modem is required to use cable modem service. Depending on the access method of and subscriber agreement with your ISP, you may not be able to use the internet connection feature contained in this TV or you may be limited to the number of devices you can connect at the same time. (If your ISP limits sub-scription to one device, this TV may not be allowed to connect when a PC is already connected.)

y The use of a “Router” may not be allowed or its

usage may be limited depending on the policies and restrictions of your ISP. For details, contact your ISP directly.

y The wireless network operates at 2.4 GHz

radio frequencies that are also used by other household devices such as cordless telephone, Bluetooth® devices, microwave oven, and can be affected by interference from them.It can be interrupted by the device using 5 Ghz radio frequencies. It is same device with LG wireless media box, cordless telephone, other Wi-Fi device.

y It may decrease the service speed using Wire-

less network by surrounding wireless condition.

y Turn off all unused network equipment in your

local home network. Some devices may generate network traffic.

y In some instances, placing the access point or

wireless router higher up away from the floor may improve the reception.

y The reception quality over wireless depends on

many factors such as type of the access point, distance between the TV and access point, and the location of the TV.

y When connecting internet through the wired/

wireless sharing machine, it may interrupt the connection because of the use limitation and confirmation of service company.

y To connect wireless AP, an AP that supports the

wireless connection is necessary, and the wireless connection function of the AP needs to be activated. Please enquire to the AP supplier for the possibility of AP wireless connections.

y Please verify the security settings of AP SSID for

wireless AP connection, and enquire to the AP supplier for the AP SSID security settings.

y The TV can become slower or malfunction with

wrong settings of network equipments (wired/ wireless router, hub, etc). Please install correctly by referring to the manual of the equipment, and set the network.

y When AP is set to include 802.11 n, and if

Encryption is designated as WEP(64/128bit) or WPA(TKIP/AES), the connection may not be possible. There may be different connection methods according to the AP manufacturers.

ENGENGLISH

ENTERTAINMENT

Network Status

1 Press HOME to access the Home menus. 2 Press the Navigation buttons to scroll to

SETUP and press OK.

3 Press the Navigation buttons to scroll to NET-

WORK and press OK.

4 Press the Navigation buttons to select Net-

work Status.

5 Press OK to check the network status.

Option Description

Setting

Test Close Return to the previous menu.

Return to the network setting menu or wireless network setting type menu.

Test the current network status after setting the network.

ENGLISH

ENG

ENTERTAINMENT

Premium card function

LG’s Premium technology allows you to access a variety of online services or contents directly on your TV. Your TV offers instant streaming of movies, TV shows, videos, and Widget-based services with Premium and the Internet connection. Enjoy entertainment including not only entertainment content, but also up-to-the minute news, stock information, weather updates, photo management, and more by simply using the TV’s remote control without a separate PC.

1 Press Premium to access the Premium option. 2 Press the Navigation buttons to scroll to the

contents you want and press OK.

3 Enjoy Online service.

CAUTION

y These services are provided by separate

Content Provider.

y Please visit the content providers web

site for specific information on their service (But, some content manual maybe not provide depending on Content Provider).

y Premium menu can differ by country. y If a service requires you to log in, you

must first sign up to the service website on your computer and then log into the service on the TV.

y Note that content may be updated

automatically depending on the service provider, so the content layout or operation method may change without notice. Please refer to the help menu on the screen.

y Content may be changed or deleted with-

out prior notice depending on the Content Provider.

y All content furnished by the contents pro-

vider are subject to change at any time including, but not limited to the removal of content. Should you have any inquiry or problem related to the content, you may refer to the cervice provider’s website for the most up-to-date information. Please note that LG is not responsible for any content provided by the content provider or any changes concerning such content.

y Some content may be harmful to minors

depending on the service provider.

ENGENGLISH

NOTE

y The videos list searched from the TV may

different with the list searched from a web browser on PC.

y The playback of videos may be paused,

stopped or buffering occurring often depending on your broadband speed.

y For service that requires log in, join the ap-

plicable service on the website using the PC and log in through the TV to enjoy various additional functionalities.

ENTERTAINMENT

ENGLISH

ENG

Legal Notice

IMPORTANT NOTICE RELATING TO NETWORK SERVICE

All content and services accessible through this device belong to third parties and are protected by copyright, patent, trademark and/or other intellectual property laws. Such content and services are provided solely for your personal noncommercial use. You may not use any content or services in a manner that has not been authorized by the content owner or service provider. Without limiting the foregoing, unless expressly authorized by the applicable content owner or service provider, you may not copy, upload, post, transmit, translate, sell, modify, create derivative works, or distribute in any manner or medium any content or services displayed through this device. YOU EXPRESSLY ACKNOWLEDGE AND AGREE THAT THE DEVICE AND ALL THIRD PARTY CONTENT AND SERVICES ARE PROVIDED "AS IS" WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED. LG ELECTRONICS EXPRESSLY DISCLAIMS ALL WARRANTIES AND CONDITIONS WITH RESPECT TO ANY CONTENT AND SERVICES, EITHER EXPRESS OR, IMPLIED, INCLUDING BUT NOT LIMITED TO, WARRANTIES OF MERCHANTABILITY, OF SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR PURPOSE, AND NON-INFRINGEMENT OF THIRD PARTY RIGHTS. LG DOES NOT GUARANTEE THE ACCURACY, VALIDITY, TIMELINESS, LEGALITY, OR COMPLETENESS OF ANY CONTENT OR SERVICE MADE AVAILABLE THROUGH THIS DEVICE AND DOES NOT WARRANT THAT THE DEVICE OR SERVICES WILL MEET YOUR REQUIREMENTS, OR THAT OPERATION OF THE DEVICE OR SERVICES WILL BE UNINTERRUPTED OR ERROR-FREE. UNDER NO CIRCUMSTANCES, INCLUDING NEGLIGENCE, SHALL LG BE LIABLE, WHETHER IN CONTRACT OR TORT, FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES, OR ANY OTHER DAMAGES ARISING OUT OF, ANY INFORMATION CONTAINED IN, OR ANY CONTENT OR SERVICE ACCESSED BY YOU OR ANY THIRD PARTY, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Third party services may be changed, suspended, removed, terminated or interrupted, or access may be disabled at any time, without notice, and LG

makes no representation or warranty that any content or service will remain available for any period of time. Content and services are transmitted by third parties by means of networks and transmission facilities over which LG has no control. LG may impose limits on the use of or access to certain services or content, in any case and without notice or liability. LG expressly disclaims any responsibility or liability for any change, interruption, disabling, removal of or suspension of any content or service made available through this device. LG is neither responsible nor liable for customer service related to the content and services. Any question or request for service relating to the content or services should be made directly to the respective content and service providers.

ENTERTAINMENT

TV Apps. card function

You can download various applications from LG App Store and enjoy them on your TV.

4 53

Option Description

Exit

TV Apps.

Quick Apps.

My Apps.

used apps among all downloads. To change the list of Quick Apps, see the "Using My Apps" section. Moves to My Apps.

Registration TV Apps.

1 Press HOME to access the Home menu. 2 Press Red button to register.

- You can only register as a free member from your TV.

3 Create your ID and password.

Press the Navigation buttons to select alphabet and number and select OK.

4 The registraion is completed.

ENGENGLISH

ENTERTAINMENT

ENGLISH

ENG

To enjoy your TV Apps with your account, you need sign in with your TV Apps account.

1 Press HOME to access the Home menu. 2 Press red button to sign in.

It displays the keyboard menu for entering ID and password.

- If you are not a member, press Red button again. You can only register as a free member from your TV.

3 Press the Navigation buttons to scroll to the

alphabet or number and press OK.

ID Management

1 After sign in, press red button again.

A pop-up window will appears.

2 Press the Navigation buttons to scroll to the

desired menu option and press OK.

Account Setting

Change User

Sign Out

3 Manage the ID by using following menu.

Option Description

Account Setting

Change User Sign Out

Check basic information, apps you purchased and apps installed on your TV.

Delete or change your account.

4 Enjoy TV Apps.

You can enjoy Premium service, TV Apps, My Apps and much more.

NOTE

y If you wish to become a paid member or

change your information, please use your PC and visit http://www.????.

y You can download a paid app on up to five

TV sets.

Using TV Apps.

1 Press HOME to access the Home menu. 2 Sign in your TV. 3 Press the Navigation buttons to scroll to the TV

Apps and press OK.

4 Edit the Apps by using following menu.

3 4

Using My Apps.

ENTERTAINMENT

Option Description

Live TV Watches the current channel.

Advertise-

ment

Apps Cat-

egory

Apps Sorting y Hot: Most downloaded apps

? Available buttons on the

remote control.

y All: ? y Game: ? y Entertainment: ? y Life: ? y Education: ? y News: ?

in the past 7 days

y New: Most recently re-

leased apps

y Top Paid: Most downloaded

paid apps

y ? y ABC: Alphabetical order

1 Enter the TV Apps after sign in. 2 Press the Navigation buttons to scroll to My

Apps. and press OK.

ENGENGLISH

3 Press Green button to edit My Apps.

A pop-up window will appears.

Move

Delete

Give Grades

Cancel

Purchasing and Installing Apps.

1 Press the Navigation buttons to select Apps

you want and press OK. You can see the information of the App.

2 Press Purchase to buy a App.

4 Edit the Apps by using following menu.

Option Description

Move Delete Give Grades

ENTERTAINMENT

I /

ENGLISH

ENG

My Media Card Function

Connecting USB storage devices

Connect USB storage devices such as a USB flash memory, external hard drive, or MP3 player to the TV and use multimedia features (See p.62). Connect a USB flash memory or USB memory card reader to the TV as shown on the following illustration. The My media screen appears.

USB IN 2

USB IN 1

To disconnect a USB storage device, make sure to end the connection properly to prevent damages to the TV or files.

1 Press Q.MENU to access the quick menus. 2 Press the Navigation buttons to scroll to USB

Device and press OK.

3 Disconnect the USB storage device only when

the message says that it is safe to remove.

CAUTION

y Do not turn the TV off or remove a USB stor-

age device while the USB storage device is connected to the TV, as this could result in loss of files or damage to the USB storage device.

y Back up your files saved on a USB storage

device frequently, as you may lose or damage the files and this may be not covered by the warranty.

Tips for using USB storage devices

y The TV recognizes only a USB storage

device.

y If you connect a USB storage device to the

TV through a USB hub, your TV may not recognize the USB storage device.

y The TV may not recognize a USB storage

device that uses its own.

y The recognition speed of a USB storage

device may differ depending on the device.

y Only use a USB storage device which has

normal music or image files.

y Use only USB storage devices that are for-

matted as a FAT 32 or NTFS file system.

y If you format a USB storage device as a

NTFS file system, you cannot delete the saved files.

y You may need to connect a USB storage

device to an external power supply with a power adapter.

y If the TV does not recognize a connected

USB storage device, replace the cable and try again. Do not use an excessively long cable.

y The TV does not support some USB storage

devices properly.

y You can use a multi-partition (up to 4) USB

storage device.

y You can use up to 4 USB storage devices at

a time by using a USB multi-card reader.

y The file alignment method of a USB storage

device is similar to the one of Window XP.

y You cannot create or delete a folder saved in

a USB storage device directly on the TV.

y The number of characters for a file name is

up to 100 English characters.

y The recommended capacity for a USB exter-

nal hard disk is 1 TB or less and for a USB storage device is 32 GB or less.

y If a USB external hard disk with the Energy

Saving feature does not work, turn the USB external hard disk off and on again to make it work properly. For more information, refer to the user manual of the USB external hard disk.

y USB storage devices below USB 2.0 are

supported as well. But they may not work properly in the movie list.

ENTERTAINMENT

DLNA DMP (Digital Living Network Alliance, Digital Media Player)

This TV can display and play many types of movie, photo and music files from your DLNA server and has been certified by DLNA for photos. The Digital Living Network Alliance (DLNA) is a cross-industry organization of consumer electronics, computing industry and mobile device companies. Digital Living provides consumers with easy sharing of digital media through a wired or wireless network in the home. The DLNA certification logo makes it easy to find products that comply with the DLNA Interoperability Guidelines. This unit complies with DLNA Interoperability Guidelines v1.5. When a PC running DLNA server software or other DLNA compatible device is connected to this TV, some setting changes of software or other devices may be required. Please refer to the operating instructions for the software or device for more information. Please refer to "Using integrated media features"

for additional information on supported file types

and other instructions.

NOTE

y The supplied Nero MediaHome 4 Essentials

CD-ROM is a customized software edition only for sharing files and folders to this TV.

y The supplied Nero MediaHome 4 Essentials

software does not support following functions: Transcoding, Remote UI, TV control, Internet services and Apple iTunes

y This manual explains operations with the

English version of Nero MediaHome 4 Essentials as examples. Follow the explanation referring to the actual operations of your language version.

y If there are too many folders and files in one

folder, it may not operate properly.

y For the DLNA option, use the Nero Media-

Home programme that is provided with the TV. However, we cannot guarantee that third party programme will work perfectly.

y You can select a channel while viewing

the small preview channel list on your TV screen.

y Check your network settings when the DLNA

option does not work properly.

y If there is an abnormal operation or an er-

ror occurs in Nero Media Home, the DLNA option may not work properly. In this case, exit Nero Media Home and restart the programme. You can download the latest version of Nero Media Home by clicking the question mark at the bottom-left of the program.

y When the network is unstable, the device

may be slower or may need to load during playback.

y When playing a video in DLNA mode, the

Multi Audio and Closed Caption features are not supported.

y When selecting Full Screen in DLNA mode,

the ratio of the outputted screen may differ from the original.

y When more than one TV is connected to

a single server in DLNA mode, a file may not play properly, depending on the server performance.

ENGENGLISH

ENTERTAINMENT

NOTE

y If the play time information is not provided by

the server, it is displayed as "--:--:--."

y When using Movie List, DRM files in the

DLNA server cannot be played.

y DLNA operation may not work properly ac-

cording to the AP manufacturers.

ENGLISH

ENG

ENTERTAINMENT

Installing Nero MediaHome 4 Essentials

Nero MediaHome 4 Essentials is easy to use DLNA server software for Windows.

Requirement PC system before you install Nero MediaHome 4 Essentials

y Windows® XP (Service Pack 2 or higher),

Windows Vista® (no Service Pack required), Windows® XP Media Center Edition 2005 (Service Pack 2 or higher), Windows Server® 2003

y Windows Vista® 64-bit edition (application

runs in 32-bit mode)

y Hard drive space: 200 MB hard drive space

for a typical installation of Nero MediaHome stand-alone

y 1.2 GHz Intel® Pentium® III or AMD Sem-

pron™ 2200+ processors

y Memory: 256 MB RAM y Graphics card with at least 32 MB video

memory, minimum resolution of 800 x 600 pixels, and 16-bit colour settings

y Windows® Internet Explorer® 6.0 or higher y DirectX® 9.0c revision 30 (August 2006) or

higher

y Network environment: 100 Mb Ethernet,

WLAN (IEEE 802.11b/g/n)

lection of data, select the check box and click the Next button.

9 Click the Exit button to complete the installa-

tion.

Sharing files and folders

After installing Nero MediaHome, you must add folders you wish to share.

1 Double-click the Nero MediaHome 4 Essentials

icon on the desktop.

2 Click Network icon on the left and define your

network name in the Network name field. The Network name you enter will be recognized by your TV.

3 Click Shares icon on the left. 4 Click Local Folders tab on the Shared screen. 5 Click Add icon to open the Browse Folder win-

dow.

6 Select the folder containing the files you want

to share. The selected folder is added to the list of shared folders.

7 Click Start Server icon to start the server.

ENGENGLISH

1 Start up your computer. 2 Close all Microsoft Windows programmes and

exit any anti-virus software that may be running.

3 Insert the Nero MediaHome 4 Essentials CD-

ROM into your computer’s CD-ROM drive.

4 Click Nero MediaHome 4 Essentials. The

installation is prepared and the installation wizard appears.

5 Click the Next button to display the serial

number input screen. Click Next to go to the next step.

6 If you accept all conditions, click I accept the

License Conditions check box and click Next. Installation is not possible without this agreement.

7 Click Typical and click Next. The installation

process is started.

8 If you want to take part in the anonymous col-

NOTE

y If the shared folders or files are not displayed

on the TV, click the folder on the Local Folders tab and click Rescan Folder at the More button.

y Visit

http://www.nero.com

tion and software tools.

for more informa-

ENTERTAINMENT

ENGLISH

ENG

Playing back shared contents

Display and play movie, photo and music content stored on your USB or other DLNA media servers.

1 Press HOME to access the Home menus. 2 Press the Navigation buttons to scroll to

SETUP and press OK.

3 Press the Navigation buttons to scroll to MY

MEDIA and press OK.

4 Press the Navigation buttons to select Movie

List, Photo List or Music List. and press OK.

5 Press the Navigation buttons to select DLNA.

Depending on the media server, this TV may need to get the permission from the server. If you want to re-scan available media server, press blue colour button.

NOTE

y To play the file on the media server, the TV

and the media server must be connected to the same access point.

y Because the compatibility and available

playback functions on the My Media menu are tested on the bundle DLNA server (Nero MediaHome 4 Essentials) environment, file requirements and playback functions on the My Media may differ depending on media servers.

y The file requirements on this page are not

always compatible. There may have some restrictions by file features and media server’s ability.

y Even the files that are not supported can

be displayed in photo thumbnail or music thumbnail.

y Movie thumbnail is only supported when

DLNA server supports a Movie thumbnail.

y If there is an unplayable music file in the My

Media menu, the TV will skip the file and play next file.

y The file information indicated on the screen

may not always correct for music and movie files in My Media menu

y This TV only supports movie subtitle files

supplied by Nero MediaHome 4.

y The subtitle file name and movie file name

have to be the same and located at the same folder.

y If subtitle files have been added after a direc-

tory has been indexed already, the user has to remove and re-add the folder to the list of shares.

y The playback and operating quality of the

My Media function may be affected by your home network condition.

y The files from removable media such as

USB drive, DVD-drive etc. on your media server may not share properly.

y When playing the Media through DLNA con-

nection, it does not support the DivX file play which is protected by DRM.

y Up to 999 including folders and files can be

recognized.

y If there are too many folders and files in one

folder, it may not operate properly.

y Files in a folder can be played only when

they are of the same type.

DLNA DMR (Digital Living Network Alliance, Digital Media Renderer)

If the PC uses Windows 7, or a device (e.g. mobile phone) with the DLNA DMC certificate is connected to a network, you can play music, videos or photos etc. on the TV.

The DMR function only works properly when the TV and PC are configured to use the same network.

1 To play a file, select the file by using the "Re-

mote Play" feature in Windows 7. To do this, right-click on the file you want to play.

Refer to the mobile phone's user manual to

find out how to use it to play a file.

You can change the name of a connected TV by double-clicking the item you want to change in Control Panel > Network and Internet > View network computers and devices.

ENTERTAINMENT

ENGENGLISH

You cannot change the name of a TV while DMR media is playing. Change it when playback is stopped.

2 To exit, press the Exit button on the remote

control. During play, only the volume, mute, exit and backwards buttons are available.

NOTE

y The DMR function may not work properly

in a wireless network.

y The seek function of the DMC only works

on video files.

y The DMR is not available when another

function is operating (recording, playback or my media work etc.).

ENTERTAINMENT

ENGLISH

ENG

Browsing files

Access the photo, music, or movie lists and browse files.

1 Connect a USB storage device. 2 Press HOME to access the Home menus. 3 Press the Navigation buttons to scroll to My

Media and press OK.

4 Press the Navigation buttons to scroll to the

device you want and press OK.

4 Press Navigation buttons to scroll to Movie

List, Photo List, or Music List and press OK.

5 Press Navigation buttons to scroll to All Media,

Movie List, Photo List, or Music List and press OK.

- All Media: Shows all files in the file list.

- Movie List, Photo List, or Music List: Shows only one type of file in the file list.

6 Press Navigation buttons to select a folder or

file you want.

All Media

USB1 External

Drive 1

󰭶Change device 󰭶Go to root folder 󰭶Go to upper folder

No.

Thumbnail information

Movie

All Media

Movie List Photo List Music List

Shows all media folder.

Current page number/total number of pages

of folder. Moves to the previous or next page.

Current page number/total number of pages

of contents. Files info or thumbnail.

Available buttons on the remote control.

Type

Abnormal files Non-supported files

Page 1/1

Description

󰮦Page Change

Page 1/2

Exit

3 4

Tips for using USB storage devices

Type Supported file format

Video


Music

y MPG, MPEG, DAT, TS, TRP, TP, VOD, MP4,

MOV, MKV, DivX, AVI, Motion JPEG (AVI, MP4, MKV), ASF, WMV, FLV

y Resolution:

under 1920 pixel (width) x 1080 pixel (height)

y Frame Rate:

under 30 frame/sec (1920 x 1080), under 60 frame/sec (1280 x 720)

y Max bitrate of playable movie file: 20 Mbps

(Mega bit per second)

y Bit rate of audio format: within 32 kbps to

320 kbps (MP3)

y Supported subtitle format: *.smi, *.srt, *.sub

(MicroDVD, SubViewer 1.0/2.0), *.ass, *ssa, *txt (TMPlayer), *.psb (PowerDivX)

y JPG, MPO (Only 3D models) y Available size

Baseline: 64 pixel (W) x 64 pixel (H) - 15360 pixel (W) x 8640 pixel (H) Progressive: 64 pixel (W) x 64 pixel (H) 1920 pixel (W) x 1440 pixel (H) * The TV cannot display most of the JPG files saved in the progressive option.??

y It may take some time to view high-resolu-

tion images in full screen.

Only 3D models

File Extensions

2D jpeg

jpg jpe

3D mpo Supproted

y MP3 y Bit rate range 32 Kbps - 320 Kbps y Sampling rate (Sampling Frequency)

MPEG1 layer 3: 32 kHz, 44.1 kHz, 48 kHz MPEG2 layer 3: 16 kHz, 22.05 kHz, 24 kHz MPEG2.5 layer 3: 8 kHz, 11.025 kHz, 12 kHz * A copy-protected file will not play.

Item Profile

Supproted file format

Photo size y Min: 64 x 64

file format Photo size

y SOF0: base- y SOF1: Extend y SOF2: Pro-

y Max - Normal

y Progressive

y mpo

y 4:3 size: 3,648

y 3:2 size: 3,648

line Sequential gressive

Type: 15360 (W) x 8640 (H)

Type: 1920 (W) x 1440 (H)

x 2,736 2,592 x 1,944 2,048 x 1,536

x 2,432


Music

Viewing videos

ENTERTAINMENT

Play video files on the TV. Your TV can display video files from a USB storage device.

1 Press HOME to access the Home menu. 2 Press the Navigation buttons to scroll to My

Media and press OK.

3 Press the Navigation buttons to scroll to Movie

List and press OK.

4 Press Navigation buttons to select a folder or

file you want and press OK.

5 Play a movie by using the following menus/but-

tons.

Movie List

USB2 External

M13

󰭶Change device 󰭶Go to root folder 󰭶Go to upper folder

Drive1

M10

M14

Page 1/1

M11

M15

Button Description

Navigation button

Scrolls the file.

OK Plays the highlighted file.

Red button

Moves to the previous or next page.

Change device: Changes to a different input.

Green button Go to root folder. Yellow but-

ton

Go to upper folder.

󰮦Page Change

Page 1/2

M12

Chapter

Button Description

󰯈

󰯇

󰯉

󰯋

󰯊

󰯉 and 󰯊 Plays videos in slow motion

Red button

and

ENERGY

SAVING

(Only 3D

models)

Q.MENU Shows the Option menu (See p. 65).

AV MODE Select the desired source

BACK

EXIT Moves to the previous menu screen.

Stops the playback. Plays a video.

Pauses or resumes the playback Scans backward in a file Scans forward in a file

Selects the frame directly. The entire file is divided into 10 frames. Frames may not be displayed depending

< >

on the file. Increases or deceases the brightness

of your screen. Views the 3D imaging.

Hides the menu on screen. To see the menu again, press OK button to display.

Option Hide

Exit

ENGENGLISH

ENTERTAINMENT

ENGLISH

ENG

Tips for playing video files

y Some user-created subtitles may not work

properly.

y Subtitles may not display some special char-

acters or HTML tags.

y Subtitles in the non-supported languages are

unavailable.

y The time information in an external subtitle

file should be arranged in ascending order to play.

y The screen may suffer from temporary

interruptions such as image stoppage or faster playback when you change the audio language.

y If you play a damaged video file, the video

file may not be played correctly or some player functions may not be unavailable.

y The TV may not properly play the video files

produced with certain encoders.

y If the recorded file does not have video or

audio, either video or audio is not outputted

y If the TV plays the recorded file without video

or audio, either video or audio is not outputted.

y The TV may not smoothly play the video files

with a resolution higher than the supported resolution for each frame.

y The TV may not properly play the video

files not included on the specified type and format.

y The TV may not play the files encoded with

GMC (Global Motion Compensation) or quarter-pel motion estimation.

y The TV supports the only files saved in AS-

CII code in subtitles.

y The maximum number of characters dis-

played on each subtitle line is 500 (English), and 500 (Numbers).

y The TV supports the only 10,000 sync blocks

within the subtitle file.

y The TV supports the H.264 codec up to the

profile level 4.1.

y The TV does not support DTS audio codec. y The TV cannot play a video file whose size is

larger than 30 GB.

y If you play a video file through the USB con-

nection that does not support the high speed, the video player may not work properly.

y The TV supports a USB storage device

whose version is lower than 2.0. However, the USB storage device may not work properly in the movie list.

y The video file and its subtitle should be in the

same folder and the name of the video file and subtitle should be identical.

y You can adjust the image by using E and A.

But you cannot customize image options of each mode.

y The TV may not play the video files in the

supported file format depending on the encoded condition.

y The TV will not play the video files that has a

damaged index or no index.

ENTERTAINMENT

Q.MENU options for movie list

1 Press Q. MENU.

A pop-up window will appears.

2 Press the Navigation buttons to scroll to movie

list option and press OK.

3 Press the Navigation buttons to scroll to one of

the following options and press OK.

Set Video Play.

Option Description

Selects your desired picture format for videos.

y Full Mode: Files are played in full

Picture Size

Audio Language

Subtitle Language

Language

Code Page

screen mode regardless of the aspect ratio of video.

y Original Mode: Files are played

according to the aspect ratio of video.

Changes the Language Group of the audio for video files. Files with a single audio track cannot be selected.

The subtitles can be turned on or off.

Activated for SMI subtitles and can select the language within the subtitle.

Subtitle font selection. When set to default, contents are displayed in the language set in "Option - Language - Menu Language."

Subtitle Language Group

Latin1 English, French,

Cyrillic Russian Thai Thai Hebrew Hebrew Arabic Arab, Parsi, Krudish Unicode

(UTF-16)

Supported Language

Spanish, Portuguese, Malaysia, Indonesia

Vietnamese language

NOTE

y Option values changed in Movie List does

not affect Photo List and Music List.

y Option value changed in Photo List and

Music List are changed likewise in Photo List and Music List excluding Movie List.

y When replaying a video file after stopping,

you can play from where it stopped automatically.

y If you select “Yes” when playing the same file

after the video file has been stopped, it will restart where it stopped previously.

y If continuous series files exist within the fold-

er, the next file will automatically be played. But, this excludes cases when the Repeat function of Movie List Option is turned “On”.

Set Video.

Control the menu option (Refer to “PICTURE Settings” on page 92).

ENGENGLISH

Set Audio.

Control the menu option (Refer to “AUDIO Settings” on page 99).

Set DivX PLUS HD

Option Description

Title Edition Authorized

Chapter

Sync

Position Move the location of the subtitles. Size Changes the subtitle font size.

Repeat

When the video is not synchronized with the captions, it can be adjusted by 0.5 second.

Turn on/off repeat function of movie playback. When turned on, the file within the folder will be played back repeatedly. When turned off, if the next file name is similar to the previous file, it can be played sequentially.

ENTERTAINMENT

ENGLISH

ENG

DivX registration code

Registering the DivX code

Check and register the DivX registration code of your TV so that you can rent or purchase the latest movies at www.divx.com/vod. To play a rented or purchased DivX file, the file’s registration code should be same with your TV’s DivX registration code.

1 Press HOME to access the Home menus. 2 Press the Navigation buttons to scroll to

SETUP and press OK.

3 Press the Navigation buttons to scroll to My

Media Setting (DivX/DLNA) and press OK.

4 Press the Navigation buttons to scroll to DivX

VOD Registration and press OK.

5 View the registration code of your TV.

You must register your device to

play DivX protected videos.

Registration code : xxxxxxxxxx

Deactivating the DivX feature

Deactivate all of the devices through the web server and block devices from activating. Delete the existing authentication information to receive a new DivX user authentication for the TV. Once this function is executed, a DivX user authentication is required again to see DivX DRM files.

1 Press HOME to access the Home menus. 2 Press the Navigation buttons to scroll to

SETUP and press OK.

3 Press the Navigation buttons to scroll to My

Media Setting (DivX/DLNA) and press OK.

4 Press the Navigation buttons to scroll to DivX

Deactivation and press OK.

5 Select Yes to confirm.

Deregistration code:

Deregister at http://vod.divx.com

********

Continue with registration?

Yes No

6 When you are finished, press EXIT.

NOTE

y While you are checking the registration code,

some buttons may not work.

y If you use the DivX registration code of

another device, you cannot play the rented or purchased DivX file. Make sure to use the DivX registration code assigned to your TV.

y The video or audio files that are not con-

verted by the standard DivX codec may be corrupted or not be played.

y The DivX VOD code allows you to activate

up to 6 devices under one account.

6 When you are finished, press EXIT.

ENTERTAINMENT

Viewing photos

View image files saved in a USB storage device. The displays on the screen may differ from the model.

1 Press HOME to access the Home menu. 2 Press the Navigation buttons to scroll to MY

MEDIA and press OK.

3 Press the Navigation buttons to scroll to Photo

List and press OK.

4 Press the Navigation buttons to scroll to a

folder/file you want and press OK.

5 View photos by using the following menus/but-

tons.

Photo List

USB2 External

P13

󰭶Change device 󰭶Go to root folder 󰭶Go to upper folder

Drive1

P10

P14

Page 1/1

P11

P15

󰮦Page Change

Page 1/2

P12

P16

Exit

6 Use the following options while viewing photos.

01_a.jpg 2008/12/10 1920 x 1080 479 KB [1/66]

Slideshow BGM

Option Description

Starts or stops a slideshow. All photos saved in the current folder

Slideshow

display during a slideshow. To set a slideshow speed, select Option.

Turns the background music on or off. To set the background music folder, select Option.

BGM

(Background

Music)

y You can’t change or set-up the

BGM while viewing the *.mpo file (3D camera file).

Rotates photos clockwise (90°, 180°, 270°, 360°).

NOTE

Option Hide

Exit

ENGENGLISH

Button Description

Navigation

button

Scrolls the file.

OK Views the highlighted file.

Red button

Moves to the previous or next page.

Change device: Changes to a different input.

Green button Go to root folder.

Yellow but-

ton

Go to upper folder.

(Rotate)

(ENERGY

SAVING)

(Only 3D

models)

Option

Hide

Exit

NOTE

y The supported photo size is

limited. You cannot rotate a photo if the resolution of the rotated width is larger than the supported resolution size.

Views the photo in full mode or original mode.

Increases or decreases the brightness of your screen.

Views the 3D imaging.

Shows the Option menu (See p. 68). Hides the option window.

To display the options, press OK. Moves to the previous menu screen.

ENTERTAINMENT

Q.MENU options for photo list

1 Press Q. MENU.

A pop-up window will appears.

2 Press the Navigation buttons to scroll to photo

list option and press OK.

3 Press the Navigation buttons to scroll to one of

the following options and press OK.

Set Photo View.

Option Description

Slide Speed

Selects a slideshow speed (Fast, Medium, Slow).

Selects a music folder for the background music. Select Repeat or Random option.

ENGLISH

ENG

BGM

NOTE

y You cannot change the music

folder while the background music is playing.

NOTE

y Option values changed in Photo List do not

affect Movie List and Music List.

y Option values changed in Photo List or

Music List are changed likewise in Photo List and Music List, but not Movie List.

y You cannot select the Option in 3D imaging

mode. (Only 3D models)

Set Video.

Control the menu option (Refer to “PICTURE Settings” on page 92).

Set Audio.

Control the menu option (Refer to “AUDIO Settings” on page 99).

ENTERTAINMENT

Listening to music

1 Press HOME to access the Home menu. 2 Press the Navigation buttons to scroll to My

Media and press OK.

3 Press the Navigation buttons to scroll to Music

List and press OK.

4 Press the Navigation buttons to select a folder

or file you want and press OK.

5 Play music by using the following menus/but-

tons.

Music List

USB2 External

M13

Change device Go to root folder Go to upper folder

Drive1

M10

M14

M11

M15

Button Description

Navigation

button

Scrolls the file.

OK Plays the highlighted file.

Red button

Moves to the previous or next page.

Change device: Changes to a different input.

Green button Go to root folder.

Yellow button Go to upper folder.

Blue button

Open music player. It is enabled during palying a music.

Page 1/1

M12

M16

Page Change

Page 1/2

Exit

6 Control playback by using the following but-

tons.

Music List

USB2 External

001. - B01.mp3 00:00

005. - B05.mp3 00:00

009. - B09.mp3 00:00

013. - B13.mp3 00:00

󰯇

002. - B02.mp3 00:00

006. - B06.mp3 00:00

010. - B10.mp3 00:00

014. - B014.mp3 00:00

M2 M3

Option

003. - B03.mp3 00:00

007. - B07.mp3 00:00

011. - B011.mp3 00:00

015. - B15.mp3 00:00

Hide

Button Description

Stops playback. Plays a music file.

Pauses or resumes playback.

Skips to the next file. Skips to the previous file. Indicates a cursor.

(ENERGY

SAVING)

Q.MENU

BACK

EXIT

Increases or deceases the brightness of your screen.

Shows the Option menu (See p. 70). Hides the option window.

To display the options, press OK. Moves to the previous menu screen.

Page 1/1

Page Change

Page 1/2

004. - B04.mp3 00:00

008. - B08.mp3 00:00

012. - B012.mp3 00:00

016. - B016.mp3 00:00

00:03 / 02:58001. - B01.mp3

Exit

ENGENGLISH

ENTERTAINMENT

ENGLISH

ENG

Q.MENU options for music list

1 Press Q. MENU.

A pop-up window will appears.

2 Press the Navigation buttons to scroll to photo

list option and press OK.

3 Press the Navigation buttons to scroll to one of

the following options and press OK.

NOTE

y Option values changed in Movie List does

not affect Photo List and Music List.

y Option value changed in Photo List and

Music List are changed likewise in Photo List and Music List excluding Movie List.

y You can listen to the music only within the

device currently played.

Set Audio Play.

Select Repeat or Random option.

Set Audio.

Control the menu option (Refer to “AUDIO Settings” on page 99).

NOTE

y A copy-protected file will not play. y If the TV is not in use for some time during

playback, the information box as a screensaver will appear to prevent image burn. To return to the Music list screen, press OK.

File name

002. B02.mp3 00:31 / 04:04

Time elapsed /Duration

Timeshift Card Function

(This feature is not available for all models.)

Precautions when using the USB Device

NOTE

Only a USB storage device is recognizable.

If the USB storage device is connected

through a USB hub, the device is not recognizable. A USB storage device using an automatic

recognition programme may not be recognized. A USB storage device which uses its own

driver may not be recognized. In case of several paritions or a card reader,

up to four memory cards are concurrently recognizable. The recognition speed of a USB storage

device may depend on each device. Please do not turn off the TV or unplug

the USB device when the connected USB storage device is working. When such device is suddenly separated or unplugged, the stored files or the USB storage device may be damaged. Please connect power to a USB storage

device which requires an external power supply. If not, the device may not be recognized. Please connect a USB storage device with

cable is offered by USB maker. If connected with cable is not offered by USB maker or an excessively long cable, the device may not be recognized. Some USB storage devices may not be

supported or operate properly. The TV will display up to 128 characters of a

files name. Please backup important files because data

on USB device may be damaged. Data management is consumer’s responsibility and as a result, the manufacturer does not cover data damage. The recommended capacity is 1TB or less

for a USB HDD and 40GB or over for USB memory.

TIME MACHINE

Any device with more than the recommended

capacity may not work properly. Playing a movie via a USB connection that

doesn’t support high speed may not work properly. USB storage devices below USB 2.0 are

supported as well. But they may not work properly in the movie list. Please maintain the stability of external HDD

by using the HDD benchmarking tool in order to guarantee smooth action of HDD. The HDD benchmarking tools is checking the

performance of HDD that is read/write rate, access time, stability. It will be able to search at website and use easily it after download the HDD benchmarking tool. Timeshift USB hard disk supports only SSD

or HDD disk types. (USB storage is not supported.) A SSD (Solid State Drive) has a limited

number of write/delete cycles. A HDD (Hard Disk Drive) is recommended for this product.

ENGENGLISH

TIME MACHINE

I /

ENGLISH

ENG

TIMESHIFT (PAUSE & REPLAY OF LIVE TV)

This function allows the unit to automatically record live TV and make it available for viewing at any time. With the Timeshift turned on, you may pause and rewind normal TV viewing at any time without missing any of the live broadcast. Timeshift and Recording functions may not work if the signal strength is weak. This function is only operated after initializating USB Device.

Connecting USB storage devices

USB IN 2

USB IN 1

USB device Initialization

To use LG Timeshift feature, USB

storage device needs to be formatted. Do you want to continue?

◄

Cancel

►

Initializing will delete all existing data

in the USB device. Once initialized to DVR format, the USB device cannot be used with PC. To continue to initialize, select OK.

Initialization completed. Ready to

record.

Timeshift Mode

Connect an unformatted USB for DVR and

press REC to initialize the USB device.

Press the Navigation buttons to scroll to OK

and press OK.

1 Connect the USB device to the USB IN 1 jacks

on the side of TV.

2 To use the USB device (over 40 GB) for

Timemachine, execute USB Device Initialization.

NOTE

y It initializes the HDD connected to the USB

as disk mode for Timeshift.

y It is activated only when the USB HDD avail-

able for Timemachine is connected.

y When USB Device Initialization is executed,

all the data stored in the USB device is deleted.

y While performing USB Device Initialization,

do not remove the USB device. It may cause error on the TV and the storage device.

Press Navigation buttons to scroll to On or Off

and press OK.

NOTE

y When initialization is completed, a popup

notice of completion is displayed and the connected USB HDD is available for Timemachine.

y Depending on the capacity of the USB de-

vice, the initialization time may vary.

y The initialized USB device is not recognized

by the PC.

y When a USB device of less than 40 GB is

connected, the USB Device Initialization is not activated.

y Supported maximum external HDD size for

back-up is up to 1TB.

TIME MACHINE

Timeshift Mode change during using Timeshift

Record/Schedule

You can see the recorded TV.

Recorded List Schedule List

Recording starts

After selecting Timeshift Mode-On, press the

Timeshift Mode

Schedule list Initialization

USB device Initialization

� Recording starts.

►

◄

Free Space 100GB

79h 03m 31h 37m

Select schedule

by date

Option

Apr.2 2010 15:30

Select schedule

by programme

OK button.

Press

Yellow button

to show the Timeshift

option menu and press Q.MENU.

Press the Navigation buttons to scroll to

Timeshift Mode and press OK.

Press Navigation buttons to scroll to On or Off

and press OK.

5 When you are finished, press EXIT.

When you return to the previous menu, press BACK.

Exit

USB Device Reinitialization during using Timeshift

After selecting Timeshift Mode-On, press the

OK button.

Press

Yellow button

to show the Timeshift

option menu and press Q.MENU.

Press the Navigation buttons to scroll to USB

device Initialization and press OK.

When you are finished, press EXIT.

When you return to the previous menu, press

BACK.

ENGENGLISH

Menu Description

Recorded List

Schedule List

Select schedule by

date

Select schedule by

programme

Moves to the Recorded List.

Moves to the Schedule List.

Moves to the Manual Timer.

Set up timer recording by going to the Programme Guide.

NOTE

y Timeshift Mode is available in DTV mode. y Radio or satellite programmes cannot be

recorded.

TIME MACHINE

ENGLISH

ENG

Timeshift Progress

󰯇

After selecting Timeshift Mode-On, press the

00:35

󰭻󰭼

󰭵Recording starts 󰯈Live TV

󰯇 󰯉 󰯋 󰯊

󰭶Recorded List

󰭶Rec./Schedule 󰮺Hide

00:35

OK button.

As soon as Timeshift starts, a progress bar

indicating the current recording status is displayed in the bottom of the screen.

It Press the BACK button to hide the ‘Progress

Bar’ or press the OK button to display the ‘Progress Bar’.

This function is preserved even change a

programme on progressing the Timeshift.

The ‘Progress Bar’? This function indicates what Timeshift

reviewing is possible, a current on-screen and live broadcasting position.

NOTE

y In order to save hard-disk space, nothing is

saved when there is no signal.

y Timeshift can be used for maximum of 2

hours.

y You can’t do the programme change or input

conversion on recording.

y When turning power on, it may take up to a

maximum of 3 minutes to initialize the HDD.

y Recording or playing the recorded pro-

gramme may not initiate for a copy-protected programme.

y Instant recording time is set to 3 hours and

supported maximum time is up to 5 hours.

y A thumbnail is created every 3 minutes for

recordings longer than 18 minutes and every 1 to 3 minutes for recordings shorter than 18 minutes.

y Up to 6 thumbnails are created on one

screen.

Preview

Current location and progress time in

playback

Total progress time of the

Timeshift

Playback

Fast forward Rewind

Pause

Direct view + Direct view - By one screen Slow playback

TIME MACHINE

Playback during the Timeshift

During the Timeshift play, the following options are available.

Use of remote control

You can playback the temporarily saved part in various methods during the Timeshift.

Button Description

During playback, repeatedly, press the REW ( ) or FF ( ) button to speed up.

Every time you press the button, the

search speed will increase by stage (up to 5 stages).

During playback, press the Pause( ) button.

Pause screen is displayed.

Every time you press the Pause( )

button from the pause screen, it will move screen by screen (

Press the Pause( ) button and then

use the FF ( ( ).

, OK

LIVE TV To view the current live broadcast,

When you move the cursor using the

Timeshift

playback, and then press the OK button, the screen will directly play at the applicable screen where the cursor is located. (

press the LIVE TV button during playback.

) button for slow motion

( ) button during

)

RECORDING

Use this function when you cannot watch the desired programme due to being out.

Start/Stop record

You can record the programme you are watching.

Start record

Press REC to start the recording.

Stop record

Recording in progress. Stop

recording?

Recording stop

Recording end time modify

� Recording starts.

Press REC to stop the recording.

Press Navigation buttons to scroll to Recording

stop and press OK.

NOTE

y You can also stop the recording by

pressing STOP.

ENGENGLISH

TIME MACHINE

ENGLISH

ENG

Modify recording end time

Recording in progress. Stop

recording?

Recording stop

Recording end time modify

� Recording starts.

Select time to record.

Press REC to stop the recording.

Press Navigation buttons to scroll to Recording

Start Time 10 : 37

End Time 13 : 37

CancelOK

end time modify and press OK.

Manual Timer

This function is easy to register to reserved recording. Timer recording is set.

Record/Schedule

Timer recording is set.

Recorded List Schedule List

󰭵 Recording starts

Manual Timer

Select the date to schedule.

Mon. Tue. Wed. Thu. Fri. Sat.

Sun.

28 29 30

Select schedule

1 2 3

Free Space 100GB

󰮛79h 03m󰮜31h 37m

Apr.2 2010 15:30

Select schedule

by date

󰰎 Option

by programme

Free Space 100GB

󰮛79h 03m󰮜31h 37m

Apr.2 2010 15:30

Once

Daily Weekly (Fri.) Mon. ~ Fri.

Apr.2 2010

Cancel

Exit

󰭺

󰮒

No schedule list

Press Navigation buttons to scroll to set the

recording start/end time and press OK.

NOTE

y When recording, if the available storage

space is not sufficient, the recording will automatically Stop.

y Recordings of less than 10 seconds will not

be saved.

y To save disk space while recording broad-

casts, no data will be saved if there is no signal.

y The recording function will not initiate for a

copy-protected programme.

y The displayed time may differ slightly from

the actual time.

y When there is no signal or a film source is

being viewed, the displayed time may differ slightly from the actual time.

Move Repeat Option

󰭶Programme Guide

After selecting Timeshift Mode-On, press the

󰭶Schedule List

OK button.

Press

Press Navigation buttons to scroll to Select

Yellow button.

schedule by date and press OK.

Press Navigation buttons to scroll to select a

date and press OK.

Press Navigation buttons to scroll to select

repeat option and press OK.

Press Navigation buttons to scroll to set the

schedule type, time and programme and press OK.

7 When you are finished, press EXIT.

When you return to the previous menu, press BACK.

Exit

TIME MACHINE

NOTE

y Recording is not possible with copy-protect-

ed programmes.

Programme with copy protection : failed to record.

y When a poor quality external source is

recorded the quality of the recording will not be optimal.

y Manual Recording available time is maxi-

mum 5 hours and minimum 2 minutes.

y When broadcasting station send the wrong

time information, reserved recording may be failed.

y If different programmes are set for the same

time for on time and reserved recording, this TV is powered on to the reserved recording programme.

y If you turn off the power during the record-

ing, the programme being recorded may not be saved. Therefore it is good to press the

󰯈

STOP ( corded list, and then turn off the power.

y Recording cannot be reserved for a period

less than 10 seconds.

y Because the title and time of the programme

for Record/Remind is based on the information transmitted from the broadcasting station, they may be different than the actual ones depending on the situation of the broadcasting station.

y Recording time may differ depending on

resolution of input signal or USB HDD capacity.

y When it is time for the reserved recording

to start and the power of the TV is turned off, the TV will turn on the power of the part required for the recording and proceed to the reservation.

y When it is time for the reserved recording

to start and the Immediate recording is in progress, the recording of the programme currently being recorded will be stopped and saved, and then proceed to the reserved recording.

y If the TV is unplugged once or turn off, the

reserved recording will not work.

) button and check the reserved/re-

SCHEDULE

Schedule List

This function is used to show scheduled recordings. You can store up to 30 programmes.

Record/Schedule

You can see the schedule list.

Recorded List Schedule List

󰭵 Recording starts

Select schedule

Schedule List

Page1/1

Start Date

Remind DTV 19 Dave (Fri.)06/05/2007 16:00

󰭶Manual Timer

After selecting Timeshift Mode-On, press the

󰭶Programme Guide

Start Time

6 May 16:00 Friend1

6 May 18:00 Friend2

OK button.

Press

Press Navigation buttons to scroll to Schedule

Yellow button.

List and press OK.

Press Navigation buttons to select a desired

programme and press OK.

When you are finished, press EXIT.

When you return to the previous menu, press BACK.

Free Space 100GB

󰮛79h 03m󰮜31h 37m

Apr.2 2010 15:30

Select schedule

by date

󰰎 Option

by programme

Apr.2 2007 15:30

Title

Friend2

16:00

Modify

Delete Delete All

ꔀ

Move Modify/Delete

Exit

►

ENGENGLISH

TIME MACHINE

ENGLISH

ENG

Menu Description

Modify

Edit the contents of Start date/ Start time/End time/Title/Repeat.

You must press the BACK button to save the edited contents. This feature is disable in reserved reminding.

Delete

Delete All

Delete the selected item in the list.

Delete all items in the list.

Close the pop-up menu.

Schedule List Initialzation

This function is to reset the schedule list.

Timeshift Mode

Schedule list Initialization

USB device Initialization

� Recording starts.

The schedule list is deleted after

initialization. To continue initialization, select OK.

►

◄

Cancel

Programme Guide

This function is easy to register to reserved recording. Timer recording is set.

Record/Schedule

Timer recording is set.

Recorded List Schedule List

Recording starts

Programme Guide

That ’70s show

DTV 1 YLE TV1 25 Nov. 2008 09:45~10:15

ALL

1 YLE TV1 2 YLE TV2 4 TV.. 5 YLE FST 6 CNN 8 YLE24

Mode

After selecting Timeshift Mode-On, press the

Legenen om Den....

Naturtimmen Lyssna Glamour

i Information

INFO

Date

NOW

That ’70s show

Your World Today

Watch/Schedule

Select schedule

▲

▼

Free Space 100GB

79h 03m 31h 37m

Apr.2 2010 15:30

RADIO

Option

Select schedule

by programme

25 Nov. 2008 10:05

FAV

by date

Keno World Business Fantomen Kritiskt ABC

Tänään otsikoissa

TV/

RAD

Schedule ListManual Timer

Exit

FAVOURITE

Exit

OK button.

Press

Yellow button.

After selecting Timeshift Mode-On, press the

OK button.

Press

Yellow button

to show the Timeshift

option menu and press Q.MENU.

Press the Navigation buttons to scroll to

Schedule list Initialization and press OK.

Press Navigation buttons to scroll to OK and

press OK. Start the Schedule List Initialization.

5 When you are finished, press EXIT.

When you return to the previous menu, press BACK.

Press Navigation buttons to scroll to Select

schedule by programme and press OK.

Press Navigation buttons to scroll to select a

programme and press OK.

When you are finished, press EXIT.

When you return to the previous menu, press

BACK.

TIME MACHINE

RECORDED TV

You can view the recorded programme list at a glance.

The recorded programme stored in the USB device can be played.

Recorded TV List

Record/Schedule

You can see the schedule list.

Recorded List Schedule List

Recording starts

Recorded List

USB

USB1 XTICK

No Information Playing time 00:02:30 /Date:2010.01.01

Select schedule

Free Space 100GB

79h 03m 31h 37m

by date

Option

Play

Free Space 100GB

79h 03m 31h 37m

Apr.2 2010 15:30

Select schedule

by programme

Page Change

1/1 Page

Exit

NOTE

y If there is a bad sector in the disk, part or

all of the items of the Recording list can be deleted.

y Maximum number of recordings within the

Recording list is 200. When the number of recordings in the Recording list is 200, you cannot record any more.

y When the full duration of the recording is

played back, the screen will stay in the stopped condition for 10 seconds and then automatically end the playback.

y The recording can be played back even dur-

ing the recording/reserved recording.

y During the playback of the recording, the

hard disk can generate a certain level of noise.

y This noise is irrelevant from the performance

and reliability of the product and is normal

y for a hard drive to have a certain level of

noise.

ENGENGLISH

Mark Mode

After selecting Timeshift Mode-On, press the

Exit

OK button.

Press

Press Navigation buttons to scroll to Recorded

Green button.

List and press OK.

Press Navigation buttons to recorded

programme and press OK.

When you are finished, press EXIT.

When you return to the previous menu, press

BACK.

TIME MACHINE

ENGLISH

ENG

Mark Mode

Play

Recorded List

USB

USB1 XTICK

No Information Playing time 00:02:30 /Date:2010.01.01

After selecting Timeshift Mode-On, press the

79h 03m 31h 37m

Mark Mode

Page Change

Free Space 100GB

1/1 Page

Exit

OK button.

Press

Press Navigation buttons to scroll to Recorded

Green button.

List and press OK.

Press Navigation buttons to select a desired

recorded programme.

Press FAV to mark your desired recorded

programme.

Press Yellow button to play the marked

recorded programme.

Playing Recorded programmes

You can play a selected programme from the recorded list.

After selecting Timeshift Mode-On, press the

󰭻󰭼

󰯈 󰯇 󰯉 󰯋 󰯊

00:35

󰭶Clip-Edit

00:35

󰭶Repeat 󰭶Option 󰮺Hide

OK button.

Press

Press Navigation buttons to scroll to Recorded

Green button.

List and press OK.

Press Navigation buttons to recorded

programme and press OK.

Press Navigation buttons to scroll to select play

option and press OK.

When you are finished, press EXIT.

When you return to the previous menu, press BACK.

Exit

Button Description

Red button Unmark All: Change marked recorded

programmes to unmarked recorded programmes.

Green button Mark All: Mark all recorded

programmes in the list.

Yellow button Play Marked: Play the first selected

file. Once recorded programmes finishes playing, the next selected one will be played automatically.

Blue button Delete Marked: Delete the marked

recorded programmes.

FAV Exit Mark Mode.

Menu Description

Play on previous

playtime.

Play from the start

Resumes playing at the previously stopped point.

Playback of selected recorded programmes.

Rename

Delete

Rename the programme.

Delete the programme.

The ‘Progress Bar’? This function indicates what Timeshift

reviewing is possible, a current on-screen and live broadcasting position.

Preview

Current location and progress time in

playback

Total progress time of the Timeshift

Playback

Fast forward Rewind

Pause

Direct view + Direct view By one screen

Slow playback (Blue) Start repeat interval (Yellow) Start clip-edit interval (Blue) End repeat interval (Yellow) End clip-edit interval Repeating interval

TIME MACHINE

Use of remote control

You can adjust various method during the recorded programme play.

Button Description

During playback, repeatedly, press the REW ( ) or FF ( ) button to speed up.

- Every time you press the button, the search speed will increase by stage (up to 5 stages).

Green button Option: Press the GREEN button to

Yellow button Clip-Edit:

Blue button Repeat:

, OK

3D Uses for viewing 3D video.

switch between video/audio settings.

Press the YELLOW button at the starting point where you want to set the Interval clip-edit and press it again at the ending point. To save, select Yes.

- The start of the Interval clip-edit is displayed as and end of the Interval clip-edit as in the

recording progress bar at the bottom of the screen. Start and end of the Interval clip-edit can be set both in forward and reverse direction.

- Interval shorter than 10 seconds cannot be save.

Press the BLUE button at the starting point where you want to set the Interval repeat and press it again at the ending point. To cancel the playback for the interval repeat, press the BLUE button one more time.

- The start of the Interval repeat is displayed as and end of the Interval repeat as in the

recording progress bar at the bottom of the screen. Start and end of the Interval repeat can be set both in forward and reverse direction.

- Interval shorter than 10 seconds cannot be set.

- When the Interval repeat is canceled, it will return to normal playback from the end point of the interval.

During playback, press the Pause( ) button.

- Pause screen is displayed.

- Every time you press the Pause( )

button from the pause screen, it will move screen by screen ( ).

- Press the Pause( ) button and then use

the FF ( ) button for slow motion ( ).

- If you don’t press any button 10

minutes after the pause, it will return to the playback.

When you move the cursor using the Timeshift ( ) button during playback, and then press the OK button, the screen will directly play at the applicable screen where the cursor is located. (

)

ENGENGLISH

EPG (ELECTRONIC PROGRAMME GUIDE) (IN DIGITAL MODE)

EPG (Electronic Programme Guide) Card Function (In digital mode)

Do you want to set a reminder for the

selected programme?

Bob The Builder Special DTV 1 ABC TV Sydney 22 Dec. 2009 10:15~10:58

ENGLISH

ENG

This feature is disabled in New Zealand.

This system has an Electronic Programme Guide (EPG) to help your navigation through all the possible viewing options. The EPG supplies information such as programme listings, start and end times for all available services. In addition, detailed information about the programme is often available in the EPG (the availability and amount of these programme details will vary, depending on the particular broadcaster).

This function can be used only when the EPG information is broadcast by broadcasting companies. The EPG displays the programme details for next 8 days. You must set the Clock in the Time menu, before us- ing EPG function.

Pr. Change

Wed. 7 Feb. 19:28

Watch

MHEG

4:3

...

576i

DTV 18 The HITS

Movers and Shakers : 86-06

18:00 PM 19:30 PM

A look back at the hottest dance moves of the past 20 years.

y Press INFO to show current programme

information.

Displayed with a TV or DTV Programme. Displayed with a Radio Programme.

Displayed with a MHEG Programme.

HE-AAC

Displayed with a HE-AAC Programme.

Aspect ratio of broadcasting programme. Aspect ratio of broadcasting programme. Displayed with a Teletext Programme. Displayed with a Subtitle Programme. Displayed with a Scramble Programme. Displayed with a Dolby Digital Programme.

Displayed with a Dolby Digital PLUS Programme.

576i/p, 720p, 1080i/p : Resolution of broadcasting programme

Shows next programme information. Shows other programme information.

Yes No

OK A pop-up window for remind settings appear. < > Select Timer Remind setting mode.

Switch on/off EPG

1 Press GUIDE to switch on or off EPG.

Select a programme

1 Press Navigation buttons or P to select

desired programme.

Programme Guide

That ’70s show

DTV 1 YLE TV1 25 Nov. 2008 09:45~10:15

ALL

1 YLE TV1 2 YLE TV2 4 TV.. 5 YLE FST 6 CNN 8 YLE24

Mode

That ’70s show

Your World Today

Legenen om Den....

Naturtimmen Lyssna Glamour

i Information

INFO

▲

NOW

Keno World Business Fantomen Kritiskt ABC

Tänään otsikoissa

▼

Watch/Schedule

Manual Timer Schedule List

TV/

RADIO

RAD

25 Nov. 2008 10:05

Exit

FAV

Favourite

EPG (ELECTRONIC PROGRAMME GUIDE) (IN DIGITAL MODE)

NOW/NEXT Guide Mode

You can view a programme being broadcasted and one scheduled to follow.

Button Description

Red button Change EPG mode. Yellow button Enter Manual Timer mode. (See p. 76) Blue button Enter Schedule List mode. (See p. 77)

When ‘NOW’ is selected, it is moved to

P GUIDE

EXIT TV/RAD Select DTV or RADIO Programme. INFO Detail information on or off.

selected programme and EPG disappears. When ‘NEXT’ is selected, a reservation pop-up window appears.

Select NOW or NEXT Programme. Select the Broadcast Programme. Page Up/Down.

Switch off EPG.BACK

Date Change Mode

Button Description

Green button

Switch off Date setting mode.v

BACK OK Change to the selected date.

Select a date.

GUIDE EXIT

Switch off EPG.

Extended Description Box

Button Description

INFO The detail information on or off.

Text Up/Down.

GUIDE EXIT

Switch off EPG.

ENGENGLISH

8 Day Guide Mode

Button Description

Red button Change EPG mode. Green button Enter Date setting mode. Yellow button Enter Manual Timer mode.(See p. 76) Blue button Enter Schedule List mode.(See p. 77)

When ‘Currently broadcasting programme is selected, it is moved to se-

P GUIDE

EXIT TV/RAD Select DTV or RADIO Programme. INFO Detail information on or off.

lected programme and EPG disappears When ‘Future broadcasting programme is selected, a reservation pop-up window appears.

Select Programme. Select the Broadcast Programme. Page Up/Down.

Switch off EPG.BACK

MHEG (MULTIMEDIA AND HYPERMEDIA INFORMATION CODING EXPERT GROUP) (IN DIGITAL MODE)

ENGLISH

ENG

MHEG (Multimedia and Hypermedia Information coding Expert Group) (In digital mode)

This feature is enabled only in South Africa and Malaysia.

The TV gives you access to digital teletext which is greatly improved in various aspects such as text, graphics etc. This digital teletext can access special digital teletext services and specific services which broadcast digital teletext.

Teletext Within Digital Service

1 Press the numeric or P button to select a

digital service which broadcasts digital teletext.

2 Follow the indications on digital teletext and

move onto the next step by pressing TEXT, OK, Navigation buttons, Red buttons, Green

buttons, Yellow buttons, Bluebuttons or NUMBER buttons and etc.

Teletext in Digital Service

1 Press the numeric or P button to select

a certain service which broadcasts digital teletext.

2 Press the TEXT or coloured button to switch on

teletext.

3 Follow the indications on digital teletext and

move onto the next step by pressing OK, Navigation buttons, Red buttons, Green buttons, Yellow buttons, Bluebuttons or NUMBER buttons and so on.

4 Press the TEXT or colour button to switch off

digital teletext and return to TV viewing.

Some services may allow you to access text

services by pressing the RED button.

3 To change digital teletext service, select a dif-

ferent service by the numeric or

P button.

MHEG (MULTIMEDIA AND HYPERMEDIA INFORMATION CODING EXPERT GROUP) (IN DIGITAL MODE)

This feature is enabled only in New Zealand.

- In New Zealand, pressing the Guide key will display MHEG EPG provided by New Zealand on the screen.

This system has an MHEG(Multimedia and hypermedia information coding expert group) to help your navigation through all the possible viewing options.

Pr. Change

Wed. 7 Feb. 19:28

Watch

MHEG

4:3

...

576i

DTV 18 The HITS

Movers and Shakers : 86-06

18:00 PM 19:30 PM

A look back at the hottest dance moves of the past 20 years.

y Press INFO to show current programme

information.

Displayed with a TV or DTV Programme. Displayed with a Radio Programme.

Displayed with a MHEG Programme.

HE-AAC

Displayed with a HE-AAC Programme.

Displayed with a Dolby Digital PLUS Programme.

576i/p, 720p, 1080i/p : Resolution of broadcasting programme

Shows next programme information. Shows other programme information.

Switch on/off MHEG

1 Press GUIDE to switch on or off MHEG.

Select a programme

1 Press Navigation buttons to preview the Broad-

cast Programme Information.

2 Press Navigation buttons to change to desired

channel.

3 Press OK to disappear MHEG after moving to

a selected channel.

Next Week

EPG/Guide

Programme Listing Mode

Button Description

Select the Broadcast Programme Information.

Select Channel.

Yellow button Change to Next Week or Prev Day. Blue button Change to Next Day or Today.

OK GUIDE Change to Now/Next mode.

BACK Switch off MHEG. INFO Detail information on or off.

The MHEG will disappear after moving to a selected channel.

NOW/NEXT Guide Mode

You can view a channel being broadcasted and one scheduled to follow.

Button Description

Select desired channel.

OK GUIDE Change to Listing mode.

BACK Switch off MHEG. INFO Detail information on or off.

The MHEG will disappear after moving to a selected channel.

ENGENGLISH

3D IMAGING

(Only 3D Models)

ENGLISH

ENG

3D TECHNOLOGY

This TV can display in 3D via 3D broadcasting or when the TV is connected to a compatible device, such as a Blu-ray 3D Player. You need such a device to watch the TV in 3D. The 3D TV displays two separate pictures formatted for each eye. The viewer needs to wear 3D glasses in order to see these images in 3D format.

WARNING

y When viewing 3D imaging, watch the TV

from an effective viewing angle and within the appropriate distance. The appropriate angel and distance are provided on the next page of this manual. If you exceed this viewing angle or distance, you may not be able to view the 3D imaging. Furthermore, the 3D imaging may not display if it is viewed while you are lying down.

y If you watch the 3D imaging too closely or

for a long period of time, it may harm your eyesight.

y Watching the TV or playing video games that

incorporate 3D imaging with the 3D glasses for a long period of time can cause drowsiness, headaches or fatigue to you and/or your eyes. If you have a headache, or otherwise feel fatigued or drowsy, stop watching the TV and take a rest.

y Pregnant woman, seniors, persons with

heart problems or persons who experience frequent drowsiness should refrain from watching 3D TV.

y Some 3D imaging may cause you to duck

or dodge the image displayed in the video. Therefore, it is best if you do not watch 3D TV near fragile objects or near any objects that can be knocked over easily.

y Please prevent children under the age of 5

from watching 3D TV. It may affect their vision development.

y Warning for photosensitization seizure:

Some viewers may experience a seizure or epilepsy when exposed to certain factors, including flashing lights or images in TV or video games. If you or anybody from your

family has a history of epilepsy or seizure, please consult with your doctor before watching 3D TV. Also certain symptoms can occur in unspecified conditions without any previous history. If you experience any of the following symptoms, immediately stop watching the 3D imaging and consult a doctor: dizziness or lightheadedness, visual transition or altered vision, visual or facial instability, such as eye or muscle twitching, unconscious action, convulsion, loss of conscience, confusion or disorientation, loss of directional sense, cramps, or nausea. Parents should monitor their children, including teenagers, for these symptoms as they may be more sensitive to the effects of watching 3D TV.

y Risk of photosensitization seizure can be

reduced with the following actions. » Take frequent breaks from watching 3D

TV.

» For those who have vision that is differ-

ent in each eye, they should watch the TV after taking vision correction measures.

» Watch the TV so that your eyes are on the

same level as the 3D screen and refrain from sitting too closely to the TV.

» Do not watch the 3D imaging when tired

or sick, and avoid watching the 3D imaging for a long period of time.

» Do not wear the 3D glasses for any other

purpose than viewing 3D imaging on a 3D TV.

» Some viewers may feel disoriented after

watching 3D TV. Therefore, after you watch 3D TV, take a moment to regain awareness of your situation before moving.

3D IMAGING

NOTE

y To watch the TV in 3D, you must put on your

3D glasses. For best results, you should wear LG Brand 3D glasses. The 3D imaging may not display properly when using another brand of 3D glasses. Please see the 3D glasses manual for instructions on how to use the 3D glasses.

y After powering on the TV, a few seconds

may be needed for your TV to calibrate.

y It may take a moment for you to see the

3D imaging if you look away from the TV and then revert your eyes back to the 3D program.

y The TV may flicker slightly if the 3D imaging

is displayed under 3 wavelength fluorescent light (50 Hz - 60 Hz) or magnetic fluorescent lamp (50Hz - 60 Hz). In such instances, it is recommended to turn the lights off.

y If there is an obstacle between the TV and

the 3D glasses, the 3D imaging may not display properly.

y Do not use the TV in close proximity to other

electronic equipments and IR or RF equipments.

y In Analog TV, 3D Imaging does not work. y When watching 2D images, it is recommend-

ed to take off the 3D glasses. If you watch 2D images with the 3D glasses on, you may

see distorted images.

When using 3D Glasses

CAUTION

y 3D glasses are sold separately. Refer to the

3D glasses manual for operating instructions.

y Do not use the 3D glasses to replace your

corrective glasses, sunglasses or protective goggles.

y Do not store the 3D glasses in hot or cold

locations.

y Do not drop objects onto the 3D glasses. Do

not drop or bend the glasses.

y Since the lenses of the 3D glasses are

easily scratched, make sure to clean only with a soft cloth. Shake off any dust before using the cloth since the glasses are easily scratched.

3D Imaging viewing range

TV size, viewing angle & other circumstances may change the viewing distance and the angle of view.

Viewing Distance Viewing Angle

2 m - 15 m

120 ° (When the viewing

distance is 2 m)

ENGENGLISH

2 m

◦

15 m

2 m

◦

3D IMAGING

ENGLISH

ENG

Viewing 3D Imaging

1 Play the video produced in 3D. 2 Press 3D to watch 3D imaging. 3 Wear the 3D glasses. 4 Press the Navigation buttons to scroll the OK

and press OK.

5 Press the Navigation buttons to scroll the

shape and press OK.

Mode Description

Side by Side

Top & Bottom

Checker Board

Frame Sequential

6 Press 3D button to 2D Off or 3D Off.

Changed from 2D imaging to 3D imaging.

Setting 3D Imaging

1 Press the 3D SETTING while viewing 3D

imaging. A pop-up window will appears.

2 Press the Navigation buttons to scroll to one

of the following options and press OK.

Choose options.

3D Mode Setting

Set Video. Set Audio.

Previous Close

3D Mode Setting (Only LED LCD TV/ LCD TV)

Button Description

Image View Mode

3D Image Type

3D Effects

3D Viewpoint

3D Optimization

Select Left/Right. Adjusts the distance between the

object and the background in the picture to enhance the 3D effect in 2D to 3D mode.

Brings the picture (including both the object and background images) to the front or back to enhance the 3D effect in 3D mode.

Adjusts the brightness and the contrast difference between the left and the right sides of the 3D image, which is caused during recording or due to certain features of the camera.

NOTE

3D IMAGING

(Only Plasma TV)

Button Description

Image View Mode

3D Picture Size

3D Effects

3D Viewpoint

3D Picture Balance

Cuts off the outer edges of the picture and stretch it to fit the full screen in 3D mode.

Adjusts the distance between the object and the background in the picture to enhance the 3D effect in 2D to 3D mode.

Brings the picture (including both the object and background images) to the front or back to enhance the 3D effect in 3D mode.

Adjusts the colour and brightness difference between the right and left sides of the picture in 3D mode.

Set Video.

Control the menu option (Refer to “PICTURE Settings” on page 92).

Set Audio.

Control the menu option (Refer to “AUDIO Settings” on page 99).

y If you select 3D mode, “Power indicator”

is turned off automatically.

y You can only choose “Standard or

Cinema” with the AV MODE button on

the remote control. AV Mode is set as Standard while playing in 3D.

y Energy Saving is disabled while playing

in 3D.

ENGENGLISH

CAUTION

y Some menus may not work while viewing

3D imaging.

y The 3D imaging is disabled automatically

when switching input source.

y The screen may not be displayed prop-

erly if you view 2D DTV images in 3D imaging mode.

y 3D effect can be seen when 3D Mode is

selected appropriately for the 3D input signal supplied to the TV.

y For *mpo files (3D camera files), the 3D

imaging mode is enabled automatically.

y To enable the 3D imaging mode, you can

also press the OK button on the Magic Motion remote control.

CUSTOMIZING SETTINGS

CUSTOMIZING TV SETTINGS

Accessing SETUP Menu

1 Press HOME to access the Home menu. 2 Press the Navigation buttons to select the SETUP menu and press OK. 3 Press the Navigation buttons to scroll to one of the following menus and press OK. 4 Press the Navigation buttons to scroll to the setting or option you want and press OK. 5 When you are finished, press EXIT.

Menu Description

SETUP Sets up and edit programmes.

PICTURE Adjusts the image size, quality, or effect.

ENGLISH

ENG

AUDIO Adjusts the sound quality, effect, or volume level.

TIME Sets the time, date, or timer feature.

LOCK Locks or unlocks channels and programmes.

OPTON Customizes the general settings.

NETWORK Sets up the network setting.

SUPPORT Checks the customer information.

CUSTOMIZING SETTINGS

Customizing settings

Image shown may differ from your TV.

SETUP settings

1 Press HOME to access the Home menus. 2 Press the Navigation buttons to scroll to SETUP and press

OK.

3 Press the Navigation buttons to scroll to SETUP and press

OK.

4 Press the Navigation buttons to scroll to the setting or option

you want and press OK.

- To return to the previous level, press BACK.

5 When you are finished, press EXIT.

The available programme settings are described in the following:

Setting Description

Auto Tuning Tunes and stores all available programmes through antennas or cable inputs (See p. 34). Manual Tuning Tunes and stores the programmes you want manually (See p.35). Programme Edit Adds or deletes pregrammes on the programmes (See p. 38). Satellite DTV

Setting

(Only Satellite models)

Sets various options for viewing satellite DTV. (See p. 35).

SETUP

● Auto Tuning

● Manual Tuning

● Programme Edit

Move

Exit

ENGENGLISH

CUSTOMIZING SETTINGS

Image shown may differ from your TV.

ENGLISH

ENG

PICTURE settings

1 Press HOME to access the Home menu. 2 Press the Navigation buttons to scroll to SETUP and press

OK.

3 Press the Navigation buttons to scroll to PICTURE and press

OK.

4 Press the Navigation buttons to scroll to the setting or option

you want and press OK.

- To return to the previous level, press BACK.

5 When you are finished, press EXIT.


● Aspect Ratio : 16:9

● Set 3D Video

● Picture Wizard

●

󰮻

Energy Saving : Off

● Picture Mode : Standard

● Backlight 70

● Contrast 100

● Brightness 50

● Sharpness 70

● Colour 60

● Tint 0

● Colour Temp. 0

● Advanced Control

● Picture Resest

● TruMotion : Low

● Screen

● LED Local Dimming: Low

The available picture settings are described in the following.

Setting Description

Aspect Ratio Changes the image size to view images at its optimal size (See p.40). Picture Wizard

(Only LED LCD TV / LCD TV)

Adjusts the image quality and calibrates the screen by following the on-screen instructions. The customized options will be saved as Expert1 in the Picture Mode.

Standard

Mode to set standard picture quality. (

Black Level, White Level, Tint, Colour, Horizontal Sharpness, Vertical

Sharpness, Backlight(Only LCD TV/LED LCD TV))

Preferred

Mode to set user preferred picture quality rather than standard picture. (

Black Level, White Level, Tint, Colour, Sharpness, Dynamic Contrast,

Colour Temperature, Backlight(Only LCD TV/LED LCD TV))

Move

Exit

R G

W C

Set 3D Video (Only 3D models)

NOTE

y If you stop the setting before the final stage, the changes will not be applied. y If you use Picture Wizard, the Energy saving feature will turn off automatically. y To reset changes made by Picture Wizard, operate Picture Reset when Picture Mode is

on Expert1.

y In RGB-PC/HDMI-PC/DVI-PC mode, the changed Colour, Tint and H/V Sharpness

values are not applied.

Sets the 3D imaging option. (See p. 86)

CUSTOMIZING SETTINGS

Setting Description

Energy Saving Reduces the power consumption by adjusting the screen brightness.

Option Auto (Only LCD

TV/LED LCD TV)

Intelligent sensor

(Only Plasma TV)

Off The Energy Saving is off. Minimum/Me-

dium/Maximum Screen off

(Only LCD TV/LED LCD TV)

*This feature is not available for all models. The backlight is adjusted automatically corresponding to the surroundings when selecting Auto using the Intelligent sensor feature.

*This feature is not available for all models. The backlight is adjusted automatically corresponding to the surroundings.

Selects the brightness level.

The screen turns off in 3 seconds.

NOTE

y When adjusting Energy Saving in MHEG mode, the Energy Saving setting is applied

after MHEG is finished.

y Selecting ‘Screen Off’ while tuned to a radio station channel will reduce power consump-

tion. If you adjust “Energy Saving-Auto, Maximum”, Backlight feature will not work.

y If you adjust “Energy Saving-Intelligent Sensor”, Sharpness, Colour, Colour Tempera-

ture feature will not work. You can also adjust this feature by selecting Energy Saving button on the remote control.

ENGENGLISH

ENGLISH

ENG

CUSTOMIZING SETTINGS

Setting Description

Picture Mode Selects one of the preset image or customizes options in each mode for the best TV screen per-

formance. You are also able to customize advanced options of each mode. The available preset picture modes vary depending on the TV.

Mode Intelligent sensor

(Only LCD TV/ LED LCD TV)

Vivid Adjusts the video image for the retail environment by enhancing the con-

Standard Adjusts the image for the normal environment.

(Only Plasma TV) Cinema (Only LED

LCD TV/LCD TV)

Cinema (Only Plasma TV)

Bright Room

(Only Plasma TV) Sport

(Only Plasma TV) Game Optimizes the video image for a fast gaming screen such as PCs or games.

Expert

*This feature is not available for all models. Adjusts picture according to the surrounding conditions.

trast, brightness, colour, and sharpness.

Optimizes power consumption.

Optimizes the video image for a cinematic look to enjoy movies as if you are in a movie theater.

Provides the experience of watching a movie at home. The user will be able enjoy the best level of satisfactory screen quality in any movie without any separate adjustments. it is darkest.

When selecting it, Aspect Ratio changes to Just Scan. Optimizes TV viewing in Bright Room.

When selecting it, As pect ratio changes to Just scan. Optimizes the video image for high and dynamic actions by emphasizing

primary colours such as white, grass, or sky blue.

Adjusts the detailed video image settings for video experts as well as general viewers.

Cinema express the optimal screen quality when

NOTE

Picture Mode

the Picture Mode menu based on the programme category.

When the Intelligent sensor function is on, the most suitable picture is automatically

adjusted according to the surrounding conditions.

You can also adjust Picture Mode in the Q. Menu.

Intelligent Sensor : Adjusts picture according to the surrounding conditions.

(Auto Power Saving) : Maximize reducting the power consumption without hurting

the picture quality. (Only Plasma TV)

If you adjust “Picture Mode-

Intelligent Sensor, Minimum, Medium, Maximum” feature will not work. (Only Plasma TV) If you adjust “Picture Mode-

feature will not work. (Only Plasma TV)

Cinema (Only Plasma TV) :This is cinema quality mode to provide you the experience of watching a movie at home.The user will be able enjoy the best level of satisfactory screen quality in any movie without any separate adjustments.Cinema expresses the optimal screen quality when it is darkest. When selecting Cinema,

Bright Room Aspect ratio changes to Just scan.

Cinema(Thomlinson Holman ’s Experiment)is the audio and video certification standard of THX established by George Lucas,who directed the movie Star Wars,and Thomlinson. This is the product to be certified in THX display area and guarantees screen quality that exceeds the display standard specification in both hardware and software.

adjusts the TV for the best picture appearance. Select the preset value in

Cinema, Bright Room”, “Energy Saving-

”, “Energy Saving-Off, Minimum, Medium, Maximum”

Setting Description

TruMotion

(Only LCD TV/LED LCD TV)

*This feature is not available for all models. Advance video technology that provides clearer, smoother images, even during fast action scenes

creating a more stable structure for a crisper picture. TruMotion works with all inputs except PC mode.

NOTE

y If you enable “TruMotion”, noise may appear on the screen. If this occurs, set “TruMo-

tion” to “Off”.

y If you select “Picture Mode-Game ”, set “TruMotion” to “Off”. y This feature is disable in RGB-PC, HDMI-PC and MY MEDIA-Photo List mode.

Mode

High Provides smoother picture movement. Low Provides smooth picture movement. Use this setting for standard use. Off Turn off TruMotion operation.

User User can adjust Judder and Blur level in TruMotion Operation, separately.

De-Judder Adjusts noise of the screen. De-Blur Adjusts after-image of the screen.

SCREEN Customizes the PC display options.

Option

Resolution Selects a proper resolution when your PC uses. Auto Configure Sets the TV to optimize the options automatically for the TV display.

Position Locates the image at the proper position. Size Adjusts the image size. Phase Eliminates horizontal streaking.

Reset Restores the options to the default setting.

LED Local Dimming

(Only LED LCD TV)

*This feature is not available for all models. After analyzing the signal of the input video by areas of the screen, it adjusts the backlight to

improve the contrast ratio.

CUSTOMIZING SETTINGS

ENGENGLISH

ENGLISH

ENG

CUSTOMIZING SETTINGS

Basic image options

Setting Description

Backlight

(LCD TV/LED LCD TV only)

Adjusts the brightness of the screen by controlling the LCD backlight. If you decrease the brightness level, the screen becomes darker and the power consumption will be reduced without any video signal loss.

NOTE

y If you use the “Energy saving - Auto, Minimum, Medium”, Backlight will be available.

y Benefits of using Backlight

- The electricity consumption is reduced by up to 60 %.

- The black brightness is reduced. (As the black has greater depth, you can enjoy a better quality definition.)

- You can adjust brightness with maintaining original signal resolution.

Contrast Increases or decreases the gradient of the video signal. You may use Contrast when the

Brightness Adjusts the base level of the signal in the picture. Sharpness Adjusts the level of crispness in the edges between the light and dark areas of the picture.

Colour Adjusts intensity of all colours. Tint Adjusts the balance between red and green levels. Colour Temp. Set to warm to enhance hotter colours such as red, or set to cool to enhance cooler colours

Advanced Control or Expert Control

Picture Reset Restores the options of each mode to the factory default

bright part of the picture is saturated.

The lower the level, the softer the image.

such as blue. Customizes the advanced options

CUSTOMIZING SETTINGS

Advanced image options (Depending on model)

Setting Description

Dynamic Contrast Adjusts the contrast to keep it at the best level according to the brightness of the screen. The

Dynamic Colour Adjusts screen colours so that they look livelier, richer and clearer. This feature enhances

Clear White Make the white area of screen brighter and more white. Skin Colour It detects the skin area of video and adjusts it to express a natural skin colour. Noise Reduction Reduces screen noise without compromising video quality. Digital Noise Reduc-

tion Super Resolution This function provides a crystal-clear picture by improving the details in an area that has a

MPEG Noise Reduction

Gamma You can adjust brightness of dark area and middle gray level area of the picture.

Black Level

Eye Care Adjusts the brightness of the screen to prevent the screen from being too bright. Dims ex-

Film Mode or Real Cinema

Colour Gamut Advanced Control

Edge Enhancer Shows clearer and distinctive yet natural edges of the video. xvYCC This is produces richer colours.

Colour Filter This is the function to filter the specific colours of the video.

Expert Pattern This is the pattern used for expert adjustment

picture is improved by making bright parts brighter and dark parts darker.

hue, saturation and luminance so that red, blue and green white look more vivid.

Reduces noise regarding MPEG compressed video.

blurry or unclear picture. Reduces noise regarding MPEG compressed video.

Low: Make the dark and middle gray level areas brighter.

Medium: Express the original picture level.

High: Make the dark and middle gray level area darker.

Sets black level of the screen to proper level. This function is available in the following modes: AV (NTSC-M), HDMI or Component.

Low: The reflection of the screen gets darker.

High: The reflection of the screen gets brighter.

tremely bright pictures. This feature is disable in “Picture Mode-Vivid, Cinema, Expert1, Expert2, Intelligent Sensor”.

Makes video clips recorded in film look more natural by eliminating judder effect. Uses this function when you watch film-originated movie contents. This function can also work when TruMotion is off.

Maximizess the utilization of colour to increase colour quality.

Standard: Displays standard set of colours.

Wide: Increase number of colours used.

Expert Control

Displays colour domain of the signal.

Standard: Displays standard set of colours.

Wide: Increase number of colours used.

EBU: Mode to display EBU standard colour area.

SMPTE: Mode to display SMPTE standard colour area.

BT709: Mode to display BT709 standard colour area.

This feature represents rich colours as much as a conventional video signal. This function is enabled in “Picture mode - Cinema, Expert” when xvYCC signal is inputted through HDMI.

You can use the RGB filter to set colour saturation and hue accurately.

This function is enabled in “Picture Mode - Expert” when you watch DTV.

ENGENGLISH

ENGLISH

ENG

CUSTOMIZING SETTINGS

Advanced image options (Depending on model)

Setting Description

Colour Temperature Adjusts the overall colour of the screen by changing the white baseline.

b. Method : 20 Point IRE

y IRE (Institute of Radio Engineers) is the unit to

display the size of the video signal and can be set among 5, 10, 15 - 100 Plasma TV. You can adjust Red, Green or Blue according to each setting.

y Red/Green/Blue: The adjustment range is -50 - +50.

c. Apply to all inputs b. Method : 10 Point IRE

y Pattern: Inner, Outer y IRE (Institute of Radio Engineers) is the unit to

display the size of the video signal and can be set among 10, 20, 30 - 100. You can adjust Red, Green or Blue according to each setting.

y Luminance: This function displays calculated lumi-

nance value for 2.2 gamma. You can input luminance value you want at 100 IRE, than the target luminance value for 2.2 gamma is displayed at every 10 steps from 10 IRE to 90 IRE.

Red/Green/Blue: The adjustment range is -50 - +50.

c. Apply to all inputs

Colour Manage System

Plasma TV a. Method : 2 Points

y Pattern: Inner, Outer y Red/Green/Blue

Contrast, Red/Green/ Blue Brightness: The adjustment range is

-50 to +50.

LED LCD TV / LCD TV

As the tool used by the experts to make adjustments by using the test patterns, this does not affect other colours but can be used to selectively adjust the 6 colour areas (Red/Green/Blue/ Yellow/Cyan/Magenta). Colour difference may not be distinctive even when you make the adjustments for the general video. Adjusts Red/Green/Blue/Yellow/Cyan, Magenta.

y Red/Green/Blue/Yellow/Cyan, Magenta Colour: The adjustment range is -30 - +30. y Red/Green/Blue/Yellow/Cyan, Magenta Tint: The adjustment range is -30 - +30.

This feature is disable in RGB-PC and HDMI-PC mode.

CUSTOMIZING SETTINGS

Image shown may differ from your TV.

AUDIO settings

Press HOME to access the Home menu.

Press the Navigation buttons to scroll to SETUP and press

OK.

Press the Navigation buttons to scroll to AUDIO and press

OK.

Press the Navigation buttons to scroll to the setting or

option you want and press OK.

- To return to the previous level, press BACK.

When you are finished, press EXIT.

AUDIO

● Auto Volume : Off

● Clear Voice II : Off

● Balance 0

● Sound Mode : Standard

• Infinite 3D Surround : Off

• Treble 50

• Bass 50

• Sound Reset

● Sound Optimizer : Normal

● Digital Audio Out : PCM

● TV Speaker : On

● ARC Mode : Off

● DTV Audio Setting : Auto

● AV Sync. : Off

Move

󰮶

The available audio settings are described in the following.

Setting Description

Auto Volume Activates the Auto Volume feature to keep the volume level consistent whenever you change

channels. The volume level may not be consistent due to different signal conditions of broadcasting stations.

Clear Voice

Sets whether to enhance human voice clarity. You can adjust the level of clarity when you set this feature on.

NOTE

Exit

ENGENGLISH

If you select “On” for Clear Voice II, Infinite 3D Sound feature will not work.

Select levels from ‘-6’ to ’+6’.

Balance Adjust balance between the left and right speakers according to your room environment. Sound Mode Selects one of the preset sound modes or customizes options in each mode.

Mode

Standard Select when you want standard-quality sound. Music Select when you listen to music. Cinema Select when you watch movies. Sport Select when you watch sports events. Game Select when you play games.

NOTE

You can also adjust Sound Mode in the Q.Menu.

Option

Infinite 3D Surround Patents LG proprietary sound processing technology that strives im-

mersive 5.1 surround sound with just two front speakers.

Treble Controls the dominant sounds in the output. When you turn up the

treble, it will increase the output to the higher frequency range.

Bass Controls the softer sounds in the output. When you turn up the bass, it

will increase the output to the lower frequency range.

Sound Reset Resets the sound mode to the default setting.

ENGLISH

ENG

CUSTOMIZING SETTINGS

100

Setting Description

Sound Optimizer

Digital Audio Out

TV Speaker Turns on the internal speaker of the TV when using an external Hi-Fi system. You can use the TV

This function optimizes the sound depending on the environment in which the TV is installed.

Option

Normal Normal sound mode. Wall Mount Type Optimized sound mode for a wall-mounted TV. Stand Type Optimized sound mode for a stand-type TV. It is possible to use in DTV, HDMI, DivX mode.

This function allows you to select your preferred Digital Audio Output. When Dolby Digital is available, selecting Auto in the Digital Audio Out menu will set SPDIF(Sony Philips Digital InterFace) output to Dolby Digital. If Auto is selected in the digital audio out menu when Dolby Digital is not available, SPDIF output will be PCM(Pulse-code modulation). Even if both Dolby Digital and Audio language have been set in a channel which broadcast Dolby Digital Audio, only Dolby Digital will be played.

Item Audio Input Digital Audio output

MPEG

Auto

PCM

speaker as an audio output device even if there is no video input.

Dolby Digital Dolby Digital Plus HE-AAC

All PCM

PCM Dolby Digital Dolby Digital Dolby Digital

NOTE

When the TV speaker is turned off while the Simplink home theater is operating, the sound

output automatically switches to the Home theater speaker, but when the TV speaker is turned on, the sound output the TV speaker.

Some menus in AUDIO are disabled when TV speaker is set to Off.

ARC Mode (Audio Return Channel)

When using an external audio device with the Audio Return Channel (ARC) feature, optical SPDIF can be output using only a High Speed HDMI cable without an additional optical cable, and SIMPLINK can be enabled.

NOTE

y Some HDMI cables may not support this mode. (A High Speed HDMI cable is recommended.) y The ARC mode only works for HDMI 1.

Mode

On If the device with the ARC feature is turned on, the device speaker is automati-

cally used when SIMPLINK is enabled.

Off Even if the device with the ARC feature is turned on and SIMPLINK is enabled,

the device speaker is not automatically used.

LG 32LV3730 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

LICENSES

ASSEMBLING AND PREPARING

Unpacking

Separate purchase

Parts and buttons

Lifting and moving the TV

Setting up the TV

Attaching the stand

Mounting on a table

Mounting on a wall

Tidying cables

Not using the Dest-Type Stand

REMOTE CONTROL

Magic Motion Remote Control Functions

Precautions to Take when Using the Magic Motion Remote Control

WATCHING TV

Connecting to an antenna

Connecting an antenna

Connecting with a satellite dish

Turning the TV on for the first time

Watching TV

Accessing Home menu

Managing programmes

Satellite DTV Setting

Manually setting up programme (In digital mode)

Manually setting up programme (In analogue mode)

Editing your programme list

Using favourite programmes

Using additional options

Adjusting aspect ratio

Changing AV modes

Using the input list

Using the quick menu

ENTERTAINMENT

Connecting the wired network

Connecting the wireless network

To set up the network settings,

When a security code is already set

Network Status

Premium card function

TV Apps. card function

Registration TV Apps.

Using TV Apps.

Using My Apps.

My Media Card Function

Browsing files

Viewing videos

DivX registration code

Viewing photos

Listening to music

Timeshift Card Function

Precautions when using the USB Device

TIMESHIFT (PAUSE & REPLAY OF LIVE TV)

RECORDING

SCHEDULE

RECORDED TV

EPG (Electronic Programme Guide) Card Function (In digital mode)

Switch on/off EPG

Select a programme

NOW/NEXT Guide Mode

Date Change Mode

Extended Description Box

8 Day Guide Mode

MHEG (MULTIMEDIA AND HYPERMEDIA INFORMATION CODING EXPERT GROUP) (IN DIGITAL MODE)

Teletext Within Digital Service

Teletext in Digital Service

Switch on/off MHEG

Select a programme

Programme Listing Mode

NOW/NEXT Guide Mode

3D IMAGING

3D TECHNOLOGY

When using 3D Glasses

3D Imaging viewing range

Viewing 3D Imaging

Setting 3D Imaging
