LG 200C User Manual

ENGLISH

LG200C

Please read this manual carefully before operating your mobile
phone. Retain it for future reference.

USER GUIDE

P/N : MMBB0236501(1.0

)

G

Copyright ©2007 LG Electronics, Inc. All rights reserved.
LG and the LG logo are registered trademarks of LG
Group and its related entities. All other trademarks are the
property of their respective owners.

IMPORTANT SAFETY PRECAUTIONS

Read these instructions. Breaking the rules may be dangerous or
illegal. Further detailed information is given in this user guide.

WWAARRNN IINN GG!!

iinnjjuurr yy oorr ddeeaatthh..

1. Never use an unapproved battery since this could

2. Never place your phone in a microwave oven as it will

3. Never store your phone in temperatures less than

4. Do not dispose of your battery by fire or with

5. When riding in a car, do not leave your phone or set

6. Do not use a hand-held phone while driving.

7. Do not use the phone in areas where its use is

VV ii ooll aatt ii oonn ooff tthhee iinnssttrruucc tt iioonnss mmaayy ccaauussee sseerriioouuss

damage the phone and/or battery and could cause
the battery to explode.

cause the battery to explode.

-4°F or greater than 122°F.

hazardous or flammable materials.

up the hands-free kit near to the air bag. If wireless
equipment is improperly installed and the air bag is
deployed, you may be seriously injured.

prohibited. (For example: aircraft)

IMPORTANT SAFETY PRECAUTIONS

1

IMPORTANT SAFETY PRECAUTIONS

1. Do not expose the battery charger or adapter to direct
sunlight or use it in places with high humidity, such as
a bathroom.

2. Do not use harsh chemicals (such as alcohol, benzene,
thinners, etc.) or detergents to clean your phone. This

IMPORTANT SAFETY PRECAUTIONS

2

could cause a fire.

3. Do not drop, strike, or shake your phone severely. It
may harm the internal circuit boards of the phone.

4. Do not use your phone in high explosive areas as the
phone may generate sparks.

5. Do not damage the power cord by bending, twisting,
pulling, or heating. Do not use the plug if it is loose as
it may cause a fire or electric shock.

6. Do not place any heavy items on the power cord. Do
not allow the power cord to be crimped as it may
cause electric shock or fire.

7. Do not handle the phone with wet hands while it is
being charged. It may cause an electric shock or
seriously damage your phone.

8. Do not disassemble the phone.

1. Do not place or answer calls while charging the phone as
it may short-circuit the phone and/or cause electric
shock or fire.

2. Do not hold or let the antenna come in contact with
your body during a call.

3. Make sure that no sharp-edged items such as animal’s
teeth or nails, come into contact with the battery. This
could cause a fire.

4. Store the battery out of reach of children.

5. Be careful that children do not swallow any parts (such
as rubber plugs, earphone, connection parts of the
phone, etc.) This could cause asphyxiation or
suffocation resulting in serious injury or death.

6. Unplug the power cord and charger during lightning
storms to avoid electric shock or fire.

7. Only use the batteries and chargers provided by LG. The
warranty will not be applied to products provided by
other suppliers.

8. Only authorized personnel should service the phone and
its accessories. Faulty installation or service may result in
accidents and consequently invalidate the warranty.

9. An emergency call can be made only within a service
area. For an emergency call, make sure that you are
within a service area and that the phone is turned on.

IMPORTANT SAFETY PRECAUTIONS

3

WELCOME

Thank you for choosing the advanced and compact LG200C cellular phone, designed to
operate with the latest digital mobile communication technology, Code Division Multiple Access
(CDMA). Along with the many advanced features of the CDMA system, such as significantly
enhanced voice clarity, this phone offers:

●

Large, easy-to-read, 7-line backlight
LCD with status icons.

●

Paging, messaging, voice mail, and
caller ID.

●

22-key keypad.

●

Speaker phone feature.

●

Menu-driven interface with prompts
for easy operation and
configuration.

●

Any key answer, auto answer, auto
retry, one-touch and speed dialing
with 99 memory locations.

WELCOME

●

Bilingual (English and Spanish)
capabilities.

●

Internal antenna described as
antenna throughout this user guide.

Earpiece

Flip

LCD

Screen

OK Key

Left Soft Key

Headset Jack

SEND Key

BACK Key

Manner

Mode Key

Navigation
Keys

Right Soft
Key

END/PWR
Key

Alphanumeric
Keypad

Microphone

Important Information

This user’s guide provides important
information on the use and operation of your
phone. Please read all the information
carefully prior to using the phone for the
best performance and to prevent any
damage to or misuse of the phone. Any
unapproved changes or modifications will
void your warranty.

4

FCC Part 15 Class B Compliance

This device and its accessories comply with
part 15 of FCC rules. Operation is subject to
the following two conditions: (1) This device
and its accessories may not cause harmful
interference, and (2) this device and its
accessories must accept any interference
received, including interference that causes
undesired operation.

FCC RF Exposure Information

WARNING! Read this

information before operating the
phone.

In August 1996, the Federal Communications
Commission (FCC) of the United States, with
its action in Report and Order FCC 96-326,
adopted an updated safety standard for
human exposure to Radio Frequency (RF)
electromagnetic energy emitted by FCC
regulated transmitters. Those guidelines are
consistent with the safety standard
previously set by both U.S. and international
standards bodies.

The design of this phone complies with the
FCC guidelines and these international
standards.

Bodily Contact During Operation

This device was tested for typical use with
the back of the phone kept 0.79 inches (2
cm) from the body. To comply with FCC RF
exposure requirements, a minimum
separation distance of 0.79 inches (2 cm)
must be maintained between the user’s body
and the back of the phone, including the
antenna, whether extended or retracted.
Third-party belt-clips, holsters, and similar
accessories containing metallic components

should not be used. Avoid the use of
accessories that cannot maintain 0.79 inches
(2 cm) distance between the user’s body and
the back of the phone and have not been
tested for compliance with FCC RF exposure
limits.

Vehicle-Mounted External Antenna
(Optional, if available)

A minimum distance of 8 inches (20cm)
must be maintained between the user/
bystander and the vehicle-mounted external
antenna to satisfy FCC RF exposure
requirements. For more information about RF
exposure, visit the FCC website at
www.fcc.gov.

Caution

Use only the supplied and approved antenna.
Use of unauthorized antennas or
modifications could impair call quality,
damage the phone, void your warranty
and/or result in violation of FCC regulations.

Do not use the phone with a damaged
antenna. If a damaged antenna comes into
contact with the skin a minor burn may
result. Contact your local dealer for a
replacement antenna.

WELCOME

5

GETTING STARTED WITH YOUR PHONE

Installing the Battery

To install the battery, insert the battery into
the opening on the back of the phone. Put
the battery cover on the battery and push it
slightly upwards.

GETTING STARTED WITH YOUR PHONE

Removing the Battery

Turn the power off. Lift the release latch to
detach the battery.

Charging the Battery

To use the charger provided with your
phone:

1. Plug the end of the adapter into the
phone’s charger port and the other end
into an electrical outlet.

2. The charge time varies depending upon
the battery level.

Turning the Phone On

1. Install a charged battery or connect the
phone to an external power source such as
a cigarette lighter charger or hands-free
car kit.

2. Press until the LCD screen lights up.

6

Turning the Phone Off

1. Press and hold until the display turns
off.

Making Calls

1. Make sure the phone is turned on. If not,
press for about 3 seconds.

2. Enter the phone number (include the area
code if needed).

3. Press . lf the phone is locked, enter
the lock code.

4. Press to end the call.

Receiving Calls

1. When the phone rings or vibrates press

to answer.

2. Press twice to end the call.

Manner Mode

Use Manner Mode in public places. When
Manner Mode is set, is displayed on
the screen, the key tones are silent, and the
phone is set to vibrate.

Manner Mode Quick Activation

1. From Standby Mode press for 3
seconds.

PREPAID

Manner Mode Quick Cancellation

1. Press to switch to Normal Mode.

Lock Mode

Use Lock Mode to prevent others from using
your phone. When Lock Mode is set, your 4­digit password(

number)

Lock Mode Quick Cancellation

1. Press Right Soft Key

the last 4 digits of your phone

is required to use the phone.

enter your 4-digit password.

[Unlock]

then

Menu Access

Press Left Soft Key [Menu] to have
access to six phone menus. There are two
methods to access menus and submenus:

●

Use the navigation key to highlight and
select, or

●

Press the number key that corresponds to
the menu or submenu.

Prepaid

The Prepaid Menu allows you to make use of
your phone with cool features and cut
corners efficiently as much as you pay in
advance. Don't miss the opportunity and
navigate the following sub-menus for your
understanding of Prepaid functionality.

1. Add Airtime

Add Airtime allows you to start an over-the­air request for additional airtime.

2. Buy Airtime

Buy Airtime allows you to start an over-the­air request for purchase additional airtime.

3. My Phone Number

Phone Number displays the phone's
programmed MSID or MDN.

4. Airtime Info

Airtime Info displays the amount of airtime
by the unit and due date information.

, ,

, ,

, ,

, ,

PREPAID

7

CONTACTS

5. Airtime Display

Airtime Display allows you to disable/enable
the display of idle screen, prepaid-related
information.

6. Serial Number

Serial Number simply displays the
information of your phone’s MEID.

7. Code Entry Mode

Code Entry Mode will allow the phone to

CONTACTS

accept Tracfone-related codes in order to add
units, modify specific data and troubleshoot
the phone. In using the Code Entry Mode,
you can't receive incoming calls or use events
alert.

8

, ,

, ,

, ,

Contacts

The Contacts Menu allows you to store
names, phone numbers and other information
in your phone’s memory. When you list your
Contacts, the number in parenthesis
represents the number of entries you have
stored (up to 300).

1. Contact List

Allows you to view your Contacts list.
Options from here:

●

Press to scroll through your
Contacts alphabetically.

●

Press Right Soft Key
select one of the following:

Send Message/ Find Name/ Find
Number/ Find Speed Dial/ Find Group/
Find E-mail/ Erase

●

Press Left Soft Key
a New Number or New E-mail.

2. New Number

Allows you to add a new number as a new
Contact entry.

, ,

[Options]

[New]

to store

, ,

to

NNoottee

Using this sub-menu, the number is saved
as a new Contact. To save the number into
an existing Contact, edit the Contact
entry.

1. Enter the number, then press .

2. Select the Label you want and press .

3. Enter the name, then press .

4. Continue saving the entry as necessary.

3. New E-mail

Allows you to save a new e-mail address as a
new Contact entry.

NNoottee

Using this sub-menu, the e-mail is saved as
a new Contact. To save the e-mail into an
existing Contact, edit the Contact entry.

1. Enter the e-mail address, then press .

2. Enter the name, then press .

3. Continue saving the entry as necessary.

4. Groups

Allows you to view your grouped Contacts,
add a new group, change the name of a
group, or delete a whole group.

●

Use to highlight a group to view,
then press .

, ,

, ,

●

Press Left Soft Key
new group to the list.

●

Use to highlight a group, then
press Right Soft Key
change the name of the group or delete
the group.

Edit Group/ Erase Group

5. Speed Dials

Allows you to view your Speed Dials list,
designate new Speed Dials, or remove Speed
Dial designations entered in your Contacts.

1. Use to highlight the Speed Dial
position, or enter the Speed Dial digit and
press .

2. Use to highlight the Contact and
press .

3. Use to highlight the number and
press .
A confirmation message is displayed.

6. Voice Dials

Allows you to view the list of numbers
programmed with voice dialing or add a Voice
Dial command to a number stored in your
Contacts.

Options from here:

●

Press Left Soft Key [New] to record

[Add]

to add a

[Options]

, ,

, ,

to

CONTACTS

9

RECENT CALLS

a new Voice Dial command. Follow the
phone’s prompts.

●

Use to highlight a Voice Dial and

press Right Soft Key [Options] to

choose one of the following:

Play/ Re-record/ Erase/ Erase All

Recent Calls

The Recent Calls Menu is a list of the last
phone numbers or Contact entries for calls
you placed, accepted, or missed. It is
continually updated as new numbers are
added to the beginning of the list and the
oldest entries are removed from the bottom

RECENT CALLS

of the list.

1. Dialed Calls

Allows you to view the list of outgoing calls;
up to 30 entries.

1. Use to highlight an entry, then

●

Press to view the entry.

●

Press to call the number.

●

Press Right Soft Key [Options] to
select: Save(Contact Info)/ Send Msg/

Prepend/ Erase/ Erase All

10

, ,

2. Received Calls

, ,

Allows you to view the list of incoming calls;
up to 30 entries.

1. Use to highlight an entry, then

●

Press to view the entry.

●

Press to call the number.

●

Press Right Soft Key [Options] to
select: Save(Contact Info)/ Send Msg/

Prepend/ Erase/ Erase All

3. Missed Calls

Allows you to view the list of missed calls; up
to 30 entries.

1. Use to highlight an entry, then

●

Press to view the entry.

●

Press to call the number.

●

Press Right Soft Key [Options] to
select: Save(Contact Info)/ Send Msg/

Prepend/ Erase/ Erase All

4. Erase Calls

Allows you to erase selected call list(s).

1. Use to highlight the list of calls to
erase, then press .

, ,

, ,
