LEXUS AGL20R, GGL25R owners manuals

Not for Reproduction
Pictorial index
Not for Reproduction
For safety
1
and security
Search by illustration
Make sure to read through them
2
Instrument cluster
Operation of each
3
component
4
Driving
5
Interior features
Maintenance
6
and care
When trouble
7
arises
Vehicle
8
specifications
How to read the gauges and meters, the variety of warning lights and indicators, etc.
Opening and closing the doors and windows, adjustment before driving, etc.
Operations and advice which are necessary for driving
Usage of the interior features, etc.
Caring for your vehicle and maintenance procedures
What to do in case of malfunction or emergency
Vehicle specifications, customizable features, etc.
Index
Search by symptom
Search alphabetically
2
Not for Reproduction
TABLE OF CONTENTS
For your information...................................8
Reading this manual.................................. 12
How to search.............................................13
Pictorial index.............................................. 14
1
For safety and security
1-1. For safe use
Before driving.................................26
For safety drive...............................28
Seat belts..........................................30
SRS airbags .....................................34
Exhaust gas precautions............44
1-2. Child safety
Riding with children......................45
Child restraint systems...............46
1-3. Theft deterrent system
Engine immobilizer system.......66
Alarm .................................................67
2
Instrument cluster
2. Instrument cluster
Warning lights and
indicators.......................................74
Gauges and meters.....................79
Multi-information display...........83
Head-up display..........................104
Fuel consumption
information..................................109
Operation of each
3
component
3-1. Key information
Keys ....................................................114
3-2. Opening, closing and
locking the doors
Side doors........................................119
Back door....................................... 126
Power back door ..........................131
Smart entry & start system......148
3-3. Adjusting the seats
Front seats......................................153
Rear seats....................................... 154
Driving position memory.........163
Head restraints.............................168
3-4. Adjusting the steering
wheel and mirrors
Steering wheel .............................170
Inside rear view mirror...............172
Outside rear view mirrors........174
3-5. Opening, closing
the windows and moon roof
Power windows ........................... 178
Moon roof......................................182
Panoramic moon roof...............186
3
Not for Reproduction
4
Driving
4-1. Before driving
Driving the vehicle......................192
Cargo and luggage....................201
Trailer towing...............................203
4-2. Driving procedures
Engine (ignition) switch ............210
Automatic transmission............215
Turn signal lever.......................... 221
Parking brake..............................222
Brake Hold....................................226
4-3. Operating the lights and
wipers
Headlight switch.........................228
AHS (Adaptive
High-beam System)................231
Automatic High Beam.............236
Fog light switch...........................240
Windshield wipers and
washer...........................................241
Rear window wiper and
washer..........................................247
4-4. Refueling
Opening the fuel tank
cap.................................................249
4-5. Using the driving
support systems
Lexus Safety System+ ..............253
PCS (Pre-Crash Safety
system).........................................259
LKA
(Lane-Keeping Assist)..........272
Dynamic radar cruise
control with full-speed
range.............................................281
Cruise control .............................293
Stop & Start system...................297
Lexus parking
assist-sensor..............................307
BSM (Blind Spot Monitor)...... 315
• BSM function..........................319
• RCTA function......................323
Driving mode select
switch ...........................................329
All-wheel drive lock
switch ...........................................333
Driving assist systems...............334
4-6. Driving tips
Winter driving tips ......................341
Utility vehicle
precautions................................345
1
2
3
4
5
6
7
8
4
Not for Reproduction
TABLE OF CONTENTS
5
Interior features
5-1. Basic operation of
the Remote Touch screen
Remote Touch............................ 350
12.3-inch display.........................354
5-2. Using the air conditioning
system and defogger
Lexus Climate Concierge......356
Automatic air
conditioning system...............357
Heated steering wheel/
seat heaters/
seat ventilators........................ 368
5-3. Using the interior lights
Interior lights list..........................372
• Interior lights..........................373
• Personal lights.......................374
5-4. Using the storage features
List of storage features ............376
• Glove box ...............................377
• Console box...........................377
• Cup holders ...........................378
• Door pockets.........................379
• Bottle holders .......................380
• Coin box.................................380
• Auxiliary boxes ......................381
Luggage compartment
features........................................382
5-5. Using the other interior
features
Other interior features ............387
• Sun visors ................................387
• Vanity mirrors........................387
• Clock........................................388
• Wireless charger ................388
• Power outlets.........................394
• Front passenger footwell
hooks.........................................395
• Rear door sunshades..........396
• Armrest....................................396
• Assist grips..............................397
• Coat hooks.............................397
5
Not for Reproduction
6
Maintenance and care
6-1. Maintenance and care
Cleaning and protecting
the vehicle exterior................400
Cleaning and protecting
the vehicle interior.................405
6-2. Maintenance
Maintenance
requirements............................408
6-3. Do-it-yourself maintenance
Do-it-yourself service
precautions.................................410
Hood ................................................412
Positioning a floor jack..............413
Engine compartment................. 414
Tires .................................................426
Tire inflation pressure...............433
Wheels............................................435
Air conditioning filter................437
Windshield wiper inserts ........440
Electronic key battery..............442
Checking and replacing
fuses..............................................444
Light bulbs.....................................446
7
When trouble arises
7-1. Essential information
Emergency flashers ................. 458
If your vehicle has to be
stopped in an
emergency.................................459
7-2. Steps to take in an
emergency
If your vehicle needs to be
towed ...........................................460
If you think something is
wrong...........................................466
Fuel pump shut off system ...... 467
If a warning light turns
on or a warning buzzer
sounds..........................................468
If a warning message is
displayed.....................................474
If you have a flat tire...................479
If the engine will not start ........490
If the electronic key does
not operate properly.............492
If the vehicle battery is
discharged.................................496
If your vehicle overheats........ 500
If the vehicle becomes
stuck.............................................503
1
2
3
4
5
6
7
8
6
Refer to the “Navigation System Owner’s Manual” for information regarding the equipment listed below.
• Navigation system
• Audio/visual system
• Lexus parking assist monitor
• Panoramic view monitor
•Lexus Enform
Not for Reproduction
8-1. Specifications
8-2. Customization
8-3. Initialization
What to do if...
Alphabetical index................................540
TABLE OF CONTENTS
8
Vehicle specifications
Maintenance data
(fuel, oil level, etc.)..................506
Fuel information...........................519
Customizable features........... 520
Items to initialize.........................533
Index
(Troubleshooting)...............................536
7
Not for Reproduction
1
2
3
4
5
6
7
8
8
Not for Reproduction

For your information

Main Owner’s Manual

Please note that this manual applies to all models and explains all equipment, including options. Therefore, you may find some explanations for equipment not installed on your vehicle.
All specifications provided in this manual are current at the time of printing. However, because of the Lexus policy of continual product improvement, we reserve the right to make changes at any time without notice.
Depending on specifications, the vehicle shown in the illustrations may differ from your vehicle in terms of color and equipment.

Accessories, spare parts and modification of your Lexus

A wide variety of non-genuine spare parts and accessories for Lexus vehicles are cur­rently available in the market. Using these spare parts and accessories which are not genuine Lexus products may adversely affect the safety of your vehicle, even though these parts may be approved by certain authorities in your country. Toyota Motor Cor­poration therefore cannot accept any liability or guarantee spare parts and accessories which are not genuine Lexus products, nor for replacement or installation involving such parts.
This vehicle should not be modified with non-genuine Lexus products. Modification with non-genuine Lexus products could affect its performance, safety or durability, and may even violate governmental regulations. In addition, damage or performance problems resulting from the modification may not be covered under warranty.

Installation of an RF-transmitter system

Not for Reproduction
The installation of an RF-transmitter system in your vehicle could affect electronic sys­tems such as:
Multiport fuel injection system/sequential multiport fuel injection system
Dynamic radar cruise control with full-speed range
Cruise control system
Anti-lock brake system
Vehicle dynamics integrated management
SRS airbag system
Seat belt pretensioner system
Be sure to check with your Lexus dealer for precautionary measures or special instruc­tions regarding installation of an RF-transmitter system.
Further information regarding frequency bands, power levels, antenna positions and installation provisions for the installation of RF-transmitters, is available on request at your Lexus dealer.

Vehicle data recordings

Your Lexus is equipped with several sophisticated computers that will record certain data, such as:
• Engine speed
• Accelerator status
•Brake status
• Vehicle speed
•Shift position The recorded data varies according to the vehicle grade level and options with which it is equipped. Furthermore, these computers do not record conversations, sounds or pic­tures.
Data usage
Lexus may use the data recorded in these computers to diagnose malfunctions, con­duct research and development, and improve quality.
Lexus will not disclose the recorded data to a third party except:
• With the consent of the vehicle owner or with the consent of the lessee if the vehicle
is leased
• In response to an official request by the police, a court of law or a government
agency
• For use by Lexus in a law suit
• For research purposes where the data is not tied to a specific vehicle or vehicle
owner
9
10
Not for Reproduction

Event data recorder

This vehicle is equipped with an event data recorder (EDR). The main purpose of an EDR is to record, in certain crash or near crash-like situations, such as an airbag deployment or hitting a road obstacle, data that will assist in understanding how a vehicle’s systems performed. The EDR is designed to record data related to vehicle dynamics and safety systems for a short period of time, typically 30 seconds or less. However, data may not be recorded depending on the severity and type of a crash.
The EDR in this vehicle is designed to record such data as:
• How various systems in your vehicle were operating;
• How far (if at all) the driver was depressing the accelerator and/or brake pedal; and,
• How fast the vehicle was traveling. These data can help provide a better understanding of the circumstances in which crashes and injuries occur.
NOTE: EDR data are recorded by your vehicle only if a non-trivial crash situation occurs; no data are recorded by the EDR under normal driving conditions and no personal data (e.g., name, gender, age, and crash location) are recorded. However, other parties, such as law enforcement, could combine the EDR data with the type of personally identifying data routinely acquired during a crash investigation. To read data recorded by an EDR, special equipment is required, and access to the vehi­cle or the EDR is needed. In addition to the vehicle manufacturer, other parties, such as law enforcement, that have the special equipment, can read the information if they have access to the vehicle or the EDR.
Disclosure of the EDR data
Lexus will not disclose the data recorded in an EDR to a third party except when:
• An agreement from the vehicle’s owner (or the lessee for a leased vehicle) is
obtained
• In response to an official request by the police, a court of law or a government
agency
• For use by Lexus in a law suit
However, if necessary, Lexus may:
• Use the data for research on vehicle safety performance
• Disclose the data to a third party for research purposes without disclosing informa-
tion about the specific vehicle or vehicle owner

Scrapping of your Lexus

WARNING
Not for Reproduction
The SRS airbag and seat belt pretensioner devices in your Lexus contain explosive chemicals. If the vehicle is scrapped with the airbags and seat belt pretensioners left as they are, this may cause an accident such as fire. Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Lexus dealer before you scrap your vehicle.
General precautions while driving
Driving under the influence: Never drive your vehicle when under the influence of alcohol or drugs that have impaired your ability to operate your vehicle. Alcohol and certain drugs delay reaction time, impair judgment and reduce coordination, which could lead to an accident that could result in death or serious injury.
Defensive driving: Always drive defensively. Anticipate mistakes that other drivers or pedestrians might make and be ready to avoid accidents.
Driver distraction: Always give your full attention to driving. Anything that distracts the driver, such as adjusting controls, talking on a cellular phone or reading can result in a collision with resulting death or serious injury to you, your occupants or others.
General precaution regarding children’s safety
Never leave children unattended in the vehicle, and never allow children to have or use the key.
Children may be able to start the vehicle or shift the vehicle into neutral. There is also a danger that children may injure themselves by playing with the windows, the moon roof or panoramic moon roof, or other features of the vehicle. In addition, heat build-up or extremely cold temperatures inside the vehicle can be fatal to children.
11
12
Not for Reproduction

Reading this manual

WARNING: Explains something that, if not obeyed, could cause death or serious injury to people.
NOTICE: Explains something that, if not obeyed, could cause damage to or a mal­function in the vehicle or its equipment.
Indicates operating or working procedures. Follow the steps in numerical order.
Indicates the action (pushing, turning, etc.) used to operate switches and other devices.
Indicates the outcome of an operation (e.g. a lid opens).
Indicates the component or posi­tion being explained.
Means “Do not”, “Do not do this”, or “Do not let this happen”.

How to search

Not for Reproduction
Searching by name
• Alphabetical index...............P. 540
Searching by installation position
• Pictorial index .............................P. 14
Searching by symptom or sound
• What to do if...
(Troubleshooting) ................P. 536
13
Searching by title
• Table of contents .........................P. 2
14
*
1
Not for Reproduction

Pictorial index

Pictorial index
Exterior
The shape of the lights may differ depending on the grade, etc. (P. 446)
Side doors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 119
Locking/unlocking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 119
Opening/closing the side windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 178
Locking/unlocking by using the mechanical key . . . . . . . . . . . . . . . . . . . . . . . P. 492
2
Back door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 126, 131
Opening from inside the cabin* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 132
Opening from outside . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 126, 133
3
Outside rear view mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 174
Adjusting the mirror angle. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 174
Folding the mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 175
Driving position memory
Defogging the mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 362
*
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 163
Pictorial index
10
12
14
Not for Reproduction
4
Windshield wipers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 241
Precautions against winter season . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 341
To prevent freezing (windshield wiper de-icer)
Precautions against car wash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 402
5
Fuel filler door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 249
Refueling method. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 251
Fuel type/fuel tank capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 509
6
Tires. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 426
Tire size/inflation pressure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 517
Winter tires/tire chain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 341
Checking/rotation/tire pressure warning system . . . . . . . . . . . . . . . . . . . . . . P. 426
Coping with flat tires. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 479
7
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 412
Opening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 412
Engine oil. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 510
Coping with overheat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 500
Light bulbs of the exterior lights for driving (Replacing method: P. 446, Watts: P. 518)
8
Headlights/front position lights/daytime running lights . . . . . . . . . . .P. 228
9
Turn signal lights. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 221
Front fog lights/rear fog lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 240
11
Cornering lights
Stop/tail lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 228
Emergency brake signal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 335
13
License plate lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 228
Back-up lights
Shifting the shift lever to R . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 215
15
Rear side marker lights. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 228
*
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 229
*
. . . . . . . . . . . . . . . . . . . . . . . P. 362
15
*
: If equipped
16
3
Not for Reproduction
Instrument panel
Pictorial index
1
Engine switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 210
Starting the engine/changing the modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 210
Emergency stop of the engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 459
When the engine will not start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 490
2
Shift lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 215
Changing the shift position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 215
Precautions against towing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 460
When the shift lever does not move. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 219
Meters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 79
Reading the meters/adjusting the instrument panel light. . . . . . . . . . . . . .P. 79, 81
Warning lights/indicator lights. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 74
When the warning lights come on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 468
Pictorial index
10
11
12
Not for Reproduction
4
Multi-information display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 83
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 83
When the warning messages are displayed. . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 474
5
Parking brake switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 222
Applying/releasing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 222, 223
Precautions against winter season . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 342
Warning buzzer/message. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 224, 474
6
Turn signal lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 221
Headlight switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 228
Headlights/front position lights/tail lights/rear side marker lights/
license plate lights/daytime running lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 228
Front fog lights/rear fog lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 240
7
Windshield wiper and washer switch . . . . . . . . . . . . . . . . . . . . . . . . . P. 241, 247
Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 241, 247
Adding washer fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 425
8
Emergency flasher switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 458
9
Hood lock release lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 412
Tilt and telescopic steering control switch. . . . . . . . . . . . . . . . . . . . . . . . . . P. 170
Adjustment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 170
Driving position memory
Air conditioning system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 357
Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 357
Rear window defogger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 362
Audio system
Audio system Hands-free system
2
*
2
*
1
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 163
*
2
*
17
1
*
: If equipped
2
*
: Refer to “Navigation System Owner’s Manual”.
18
2
3
5
6
Not for Reproduction
Switches
4
7
Pictorial index
1
“ODO/TRIP” switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 86
Instrument panel light control switches. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 81
1
*
Adaptive High-beam System switch Automatic High Beam switch
Power back door switch
HUD (Head-up display) switch
1, 2
Camera switch
Heated steering wheel switch
*
*
1
*
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 132
*
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 231
1
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 236
1
*
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 104
1
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 369
Pictorial index
1
2
4
5
Not for Reproduction
19
Driving position memory switches
Window lock switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 178
3
Power window switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 178
Door lock switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 122
Outside rear view mirror switches. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 174
1
*
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 163
*
2
*
: Refer to “Navigation System Owner’s Manual”.
1
: If equipped
20
1
2
4
5
6
7
Not for Reproduction
Pictorial index
Audio remote control switches
Paddle shift switches
3
Meter control switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 85
Vehicle-to-vehicle distance button
Cruise control switch
Dynamic radar cruise control with full-speed range Cruise control
LKA (Lane-Keeping Assist) switch
Talk switch
8
Telephone switches
*
1
*
2
*
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 216, 217
2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 293
1
*
1
*
2
*
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 287
2
*
. . . . . . . . . . . . . . . . . . P. 281
2
*
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 272
Pictorial index
2
5
8
Not for Reproduction
21
1
Remote Touch
Wireless charger switch
3
Brake hold switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 226
4
Front seat heater switches
Seat ventilator switches
6
VSC OFF switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 336
7
Driving mode select switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 329
All-wheel drive lock switch
9
Stop & Start cancel switch
1
*
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 350
2
*
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 388
2
*
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 370
2
*
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 371
2
*
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 333
2
*
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 297
1
*
: Refer to “Navigation System Owner’s Manual”.
2
*
: If equipped
22
3
6
9
Not for Reproduction
Interior
Pictorial index
1
SRS airbags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 34
2
Floor mats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 26
Front seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 153
4
Head restraints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 168
5
Seat belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 30
Console box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 377
7
Inside lock buttons. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 122
8
Cup holders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 378
Assist grips. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 397
Pictorial index
1
4
7
*
1
:If equipped
*
2
: The illustration shows the front, but they are also equipped in the rear.
*
3
: NEVER use a rearward facing child
restraint on a seat protected by an ACTIVE AIRBAG in front of it, DEATH or SERIOUS INJURY to the CHILD can occur. (P. 52)
Not for Reproduction
23
Moon roof switches Panoramic moon roof switches
2
Intrusion sensor cancel switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 69
3
Interior light Personal lights
Auxiliary box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 381
5
Inside rear view mirror . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 172
6
Sun visors
Vanity mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 387
*
3
*
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 387
1
*
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 182
2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 373
2
*
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 374
1
*
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 186
24
Not for Reproduction
Pictorial index
25
Not for Reproduction
For safety and security
1
1-1. For safe use
Before driving.................................26
For safety drive..............................28
Seat belts..........................................30
SRS airbags.....................................34
Exhaust gas precautions............ 44
1-2. Child safety
Riding with children.....................45
Child restraint systems............... 46
1-3. Theft deterrent system
Engine immobilizer system.......66
Alarm................................................. 67
26
1
*
2
Not for Reproduction
1-1. For safe use

Before driving

Floor mat

Use only floor mats designed specifically for vehicles of the same model and model year as your vehicle. Fix them securely in place onto the carpet.
Insert the retaining hooks (clips) into the floor mat eyelets.
Turn the upper knob of each retain­ing hook (clip) to secure the floor mats in place.
*
: Always align the marks.
The shape of the retaining hooks (clips) may differ from that shown in the illus­tration.
1-1. For safe use
WARNING
Check that the floor mat is securely fixed in the correct place with all the provided retain­ing hooks (clips). Be especially careful to per­form this check after cleaning the floor.
With the engine stopped and the shift lever in P, fully depress each pedal to the floor to make sure it does not interfere with the floor mat.
Not for Reproduction
Observe the following precautions. Failure to do so may cause the driver’s floor mat to slip, possibly interfering with the ped­als while driving. An unexpectedly high speed may result or it may become difficult to stop the vehicle. This could lead to an accident, resulting in death or serious injury.
When installing the driver’s floor mat
Do not use floor mats designed for other models or different model year vehicles, even if they are Lexus Genuine floor mats.
Only use floor mats designed for the driver’s seat.
Always install the floor mat securely using the retaining hooks (clips) provided.
Do not use two or more floor mats on top of each other.
Do not place the floor mat bottom-side up or upside-down.
Before driving
27
1
For safety and security
28
1
2
3
4
Not for Reproduction
1-1. For safe use

For safety drive

For safe driving, adjust the seat and mirror to an appropriate position before driving.

Correct driving posture

Adjust the angle of the seatback so that you are sitting straight up and so that you do not have to lean forward to steer. (P. 153)
Adjust the seat so that you can depress the pedals fully and so that your arms bend slightly at the elbow when gripping the steering wheel. (P. 153)
Lock the head restraint in place with the center of the head restraint closest to the top of your ears. (P. 168)
Wear the seat belt correctly. (P. 30)

Correct use of the seat belts

Make sure that all occupants are wearing their seat belts before driving the vehi­cle. (P. 30) Use a child restraint system appropriate for the child until the child becomes large enough to properly wear the vehicle’s seat belt. (P. 46)

Adjusting the mirrors

Make sure that you can see backward clearly by adjusting the inside and outside rear view mirrors properly. (P. 172, 174)
1-1. For safe use
WARNING
Not for Reproduction
Observe the following precautions. Failure to do so may result in death or serious injury.
Do not adjust the position of the driver’s seat while driving. Doing so could cause the driver to lose control of the vehicle.
Do not place a cushion between the driver or passenger and the seatback. A cushion may prevent correct posture from being achieved, and reduce the effec­tiveness of the seat belt and head restraint.
Do not place anything under the front seats. Objects placed under the front seats may become jammed in the seat tracks and stop the seat from locking in place. This may lead to an accident and the adjustment mech­anism may also be damaged.
Always observe the legal speed limit when driving on public roads.
When driving over long distances, take regular breaks before you start to feel tired. Also, if you feel tired or sleepy while driving, do not force yourself to continue driving and take a break immediately.
29
1
For safety and security
30
Release button
1
2
Release button
1
2
Not for Reproduction
1-1. For safe use

Seat belts

Make sure that all occupants are wearing their seat belts before driving the vehicle.

Correct use of the seat belts

Extend the shoulder belt so that it comes fully over the shoulder, but does not come into contact with the neck or slide off the shoulder.
Position the lap belt as low as possi­ble over the hips.
Adjust the position of the seatback. Sit up straight and well back in the seat.
Do not twist the seat belt.

Fastening and releasing the seat belt

Adjusting the seat belt shoulder anchor height (front seats)

To fasten the seat belt, push the plate into the buckle until a click sound is heard.
To release the seat belt, press the release button.
Push the seat belt shoulder anchor down while pressing the release but­ton.
Push the seat belt shoulder anchor up.
Move the height adjuster up and down as needed until you hear a click.
1-1. For safe use
Not for Reproduction

Seat belt pretensioners (front and outboard rear seats)

The pretensioners help the seat belts to quickly restrain the occupants by retracting the seat belts when the vehi­cle is subjected to certain types of severe frontal or side collision.
The pretensioners do not activate in the event of a minor frontal impact, a minor side impact, a rear impact or a vehicle rollover.
Emergency locking retractor (ELR)
The retractor will lock the belt during a sudden stop or on impact. It may also lock if you lean forward too quickly. A slow, easy motion will allow the belt to extend so that you can move around fully.
Child seat belt usage
The seat belts of your vehicle were principally designed for persons of adult size.
Use a child restraint system appropriate for the child, until the child becomes large enough to properly wear the vehicle’s seat belt. (P. 46)
When the child becomes large enough to properly wear the vehicle’s seat belt, follow the instructions regarding seat belt usage. (P. 30)
Replacing the belt after the pretensioner has been activated
If the vehicle is involved in multiple collisions, the pretensioner will activate for the first collision, but will not activate for the second or subsequent collisions.
Seat belt regulations
If seat belt regulations exist in the country where you reside, please contact your Lexus dealer for seat belt replacement or installation.
31
1
For safety and security
32
WARNING
Obtain medical advice and wear the seat belt in the proper way. (P. 30)
Women who are pregnant should position the lap belt as low as possible over the hips in the same manner as other occupants, extending the shoulder belt completely over the shoulder and avoiding belt contact with the rounding of the abdominal area.
If the seat belt is not worn properly, not only the pregnant woman, but also the fetus could suffer death or serious injury as a result of sudden braking or a collision.
Not for Reproduction
1-1. For safe use
Observe the following precautions to reduce the risk of injury in the event of sudden braking, sudden swerving or an accident. Failing to do so may cause death or serious injury.
Wearing a seat belt
Ensure that all passengers wear a seat belt.
Always wear a seat belt properly.
Each seat belt should be used by one person only. Do not use a seat belt for more than one person at once, including children.
Lexus recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system.
To achieve a proper seating position, do not recline the seat more than necessary. The seat belt is most effective when the occupants are sitting up straight and well back in the seats.
Do not wear the shoulder belt under your arm.
Always wear your seat belt low and snug across your hips.
Pregnant women
People suffering illness
Obtain medical advice and wear the seat belt in the proper way. (P. 30)
1-1. For safe use
WARNING
Not for Reproduction
When children are in the vehicle
P. 58
Seat belt pretensioners
If the pretensioner has activated, the SRS warning light will come on. In that case, the seat belt cannot be used again and must be replaced at your Lexus dealer.
Adjustable shoulder anchor
Always make sure the shoulder belt is positioned across the center of your shoulder. The belt should be kept away from your neck, but not falling off your shoulder. Failure to do so could reduce the amount of protection in an accident and cause death or serious injuries in the event of a sudden stop, sudden swerve or accident. (P. 30)
Seat belt damage and wear
Do not damage the seat belts by allowing the belt, plate, or buckle to be jammed in the door.
Inspect the seat belt system periodically. Check for cuts, fraying, and loose parts. Do not use a damaged seat belt until it is replaced. Damaged seat belts cannot protect an occupant from death or serious injury.
Ensure that the belt and plate are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact your Lexus dealer.
Replace the seat assembly, including the belts, if your vehicle has been involved in a serious accident, even if there’s no obvious damage.
Do not attempt to install, remove, modify, disassemble or dispose of the seat belts. Have any necessary repairs carried out by your Lexus dealer. Inappropriate handling may lead to incorrect operation.
33
1
For safety and security
34
1
3
Not for Reproduction
1-1. For safe use

SRS airbags

The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury.
SRS front airbags
SRS driver airbag/front passenger airbag Can help protect the head and chest of the driver and front passenger from impact with interior components
2
SRS knee airbag Can help provide driver protection
SRS seat cushion airbag Can help restrain the front passenger
1-1. For safe use
Not for Reproduction
SRS side and curtain shield airbags
4
SRS front side airbags Can help protect the torso of the front seat occupants
5
SRS rear side airbags Can help protect the torso of occupants in the rear outer seats
6
SRS curtain shield airbags Can help protect primarily the head of occupants in the outer seats
35
1
For safety and security
36
1
2
3
4
5
6
7
8
9
14
16
Not for Reproduction
1-1. For safe use

SRS airbag system components

Side impact sensors (rear) Front side airbags Curtain shield airbags Driver airbag SRS warning light Front passenger airbag Front impact sensors Side impact sensors (front door) Seat belt pretensioners and force
limiters
The main SRS airbag system components are shown above. The SRS airbag sys­tem is controlled by the airbag sensor assembly. As the airbags deploy, a chemi­cal reaction in the inflators quickly fills the airbags with non-toxic gas to help restrain the motion of the occupants.
10
Airbag sensor assembly
11
Passenger seat cushion airbag
12
Front passenger’s seat belt buckle switch
13
Driver’s seat belt buckle switch Driver’s knee airbags
15
Driver’s seat position sensor Rear side airbags
1-1. For safe use
WARNING
Not for Reproduction
SRS airbag precautions
Observe the following precautions regarding the SRS airbags. Failure to do so may cause death or serious injury.
The driver and all passengers in the vehicle must wear their seat belts properly. The SRS airbags are supplemental devices to be used with the seat belts.
The SRS driver airbag deploys with considerable force, and can cause death or seri­ous injury especially if the driver is very close to the airbag.
Since the risk zone for the driver’s airbag is the first 50 - 75 mm (2 - 3 in.) of inflation, placing yourself 250 mm (10 in.) from your driver airbag provides you with a clear margin of safety. This distance is measured from the center of the steering wheel to your breastbone. If you sit less than 250 mm (10 in.) away now, you can change your driving position in several ways:
• Move your seat to the rear as far as you can while still reaching the pedals com­fortably.
• Slightly recline the back of the seat. Although vehicle designs vary, many drivers can achieve the 250 mm (10 in.) dis­tance, even with the driver seat all the way forward, simply by reclining the back of the seat somewhat. If reclining the back of your seat makes it hard to see the road, raise yourself by using a firm, non-slippery cushion, or raise the seat if your vehicle has that feature.
• If your steering wheel is adjustable, tilt it downward. This points the airbag toward your chest instead of your head and neck.
The seat should be adjusted as recommended above, while still maintaining control of the foot pedals, steering wheel, and your view of the instrument panel controls.
The SRS front passenger airbag also deploys with considerable force, and can cause death or serious injury especially if the front passenger is very close to the airbag. The front passenger seat should be as far from the airbag as possible with the seatback adjusted, so the front passenger sits upright.
Improperly seated and/or restrained infants and children can be killed or seriously injured by a deploying airbag. An infant or child who is too small to use a seat belt should be properly secured using a child restraint system. Lexus strongly recom­mends that all infants and children be placed in the rear seats of the vehicle and prop­erly restrained. The rear seats are safer for infants and children than the front passenger seat. (P. 46)
37
1
For safety and security
38
WARNING
Do not sit on the edge of the seat or lean against the dashboard.
Do not allow a child to stand in front of the SRS front passenger airbag unit or sit on the knees of a front passenger.
Do not allow the front seat occupants to hold items on their knees.
Do not lean against the door, the roof side rail or the front, side and rear pillars.
Do not allow anyone to kneel on the passen­ger seats toward the door or put their head or hands outside the vehicle.
Not for Reproduction
1-1. For safe use
SRS airbag precautions
WARNING
Do not attach anything to or lean anything against areas such as the dashboard, steering wheel pad and lower portion of the instru­ment panel. These items can become projectiles when the SRS driver, front passenger and knee airbags deploy.
Do not attach anything to areas such as a door, windshield, side windows, front or rear pillar, roof side rail and assist grip.
Not for Reproduction
SRS airbag precautions
Do not hang coat hangers or other hard objects on the coat hooks. All of these items could become projectiles and may cause death or serious injury, should the SRS cur­tain shield airbags deploy.
If a vinyl cover is put on the area where the SRS knee airbag will deploy, be sure to remove it.
Do not use seat accessories which cover the parts where the SRS side airbags and SRS seat cushion airbag inflate as they may interfere with inflation of the SRS airbags. Such accessories may prevent the side airbags and SRS seat cushion airbag from activating correctly, disable the system or cause the side airbags and SRS seat cush­ion airbag to inflate accidentally, resulting in death or serious injury.
Do not strike or apply significant levels of force to the areas around the SRS airbag components or the front doors. Doing so can cause the SRS airbags to malfunction.
Do not touch any of the component parts immediately after the SRS airbags have deployed (inflated) as they may be hot.
1-1. For safe use
39
1
For safety and security
40
WARNING
Not for Reproduction
1-1. For safe use
SRS airbag precautions
If breathing becomes difficult after the SRS airbags have deployed, open a door or window to allow fresh air in, or leave the vehicle if it is safe to do so. Wash off any resi­due as soon as possible to prevent skin irritation.
If the areas where the SRS airbags are stored, such as the steering wheel pad and front and rear pillar garnishes, are damaged or cracked, have them replaced by your Lexus dealer.
Modification and disposal of SRS airbag system components
Do not dispose of your vehicle or perform any of the following modifications without consulting your Lexus dealer. The SRS airbags may malfunction or deploy (inflate) accidentally, causing death or serious injury.
Installation, removal, disassembly and repair of the SRS airbags
Repairs, modifications, removal or replacement of the steering wheel, instrument panel, dashboard, seats or seat upholstery, front, side and rear pillars, roof side rails, front door panels, front door trims, or front door speakers
Modifications to the front door panel (such as making a hole in it)
Repairs or modifications of the front fender, front bumper, or side of the occupant compartment
Installation of a grille guard (bull bars, kangaroo bar, etc.), snow plows or winches
Modifications to the vehicle’s suspension system
Installation of electronic devices such as mobile two-way radios (RF-transmitter) and CD players
Modifications to your vehicle for a person with a physical disability
If the SRS airbags deploy (inflate)
Slight abrasions, burns, bruising etc., may be sustained from SRS airbags, due to the extremely high speed deployment (inflation) by hot gases.
A loud noise and white powder will be emitted.
Parts of the airbag module (steering wheel hub, airbag cover and inflator) as well as the front seats, parts of the front and rear pillars, and roof side rails, may be hot for several minutes. The airbag itself may also be hot.
The windshield may crack.
1-1. For safe use
Not for Reproduction
SRS airbag deployment conditions (SRS front airbags)
The SRS front airbags will deploy in the event of an impact that exceeds the set thresh­old level (the level of force corresponding to an approximately 20-30 km/h [12-18 mph] frontal collision with a fixed wall that does not move or deform).
However, this threshold velocity will be considerably higher in the following situations:
• If the vehicle strikes an object, such as a parked vehicle or sign pole, which can move or deform on impact
• If the vehicle is involved in an underride collision, such as a collision in which the front of the vehicle “underrides”, or goes under, the bed of a truck
Depending on the type of collision, it is possible that only the seat belt pretensioners will activate.
The SRS seat cushion airbag on the front passenger seat will not operate if the occu­pant is not wearing a seat belt.
SRS airbag deployment conditions (SRS side and curtain shield airbags)
The SRS side and curtain shield airbags will deploy in the event of an impact that exceeds the set threshold level (the level of force corresponding to the impact force produced by an approximately 1500 kg [3300 lb.] vehicle colliding with the vehicle cabin from a direction perpendicular to the vehicle orientation at an approximate speed of 20 -30 km/h [12 -18 mph]).
The SRS side and curtain shield airbags will deploy in the event of a severe frontal colli­sion.
Conditions under which the SRS airbags may deploy (inflate), other than a collision
The SRS front airbags and SRS side and curtain shield airbags may also deploy if a seri­ous impact occurs to the underside of your vehicle. Some examples are shown in the illustration.
Hitting a curb, edge of pavement or hard sur­face
Falling into or jumping over a deep hole
Landing hard or falling
41
1
For safety and security
Types of collisions that may not deploy the SRS airbags (SRS front airbags)
The SRS front airbags do not generally inflate if the vehicle is involved in a side or rear collision, if it rolls over, or if it is involved in a low-speed frontal collision. But, whenever a collision of any type causes sufficient forward deceleration of the vehicle, deployment of the SRS front airbags may occur.
Collision from the side
Collision from the rear
Vehicle rollover
42
Not for Reproduction
1-1. For safe use
Types of collisions that may not deploy the SRS airbags (SRS side and curtain shield airbags)
The SRS side and curtain shield airbags may not activate if the vehicle is subjected to a collision from the side at certain angles, or a collision to the side of the vehicle body other than the passenger compartment.
Collision from the side to the vehicle body other than the passenger compartment
Collision from the side at an angle
The SRS side and curtain shield airbags do not generally inflate if the vehicle is involved in a rear collision, if it rolls over, or if it is involved in a low-speed side or low-speed frontal collision.
Collision from the rear
Vehicle rollover
When to contact your Lexus dealer
In the following cases, the vehicle will require inspection and/or repair. Contact your Lexus dealer as soon as possible.
Any of the SRS airbags have been inflated.
The front of the vehicle is damaged or deformed, or was involved in an accident that was not severe enough to cause the SRS front airbags to inflate.
Not for Reproduction
A portion of a door or its surrounding area is damaged, deformed or has had a hole made in it, or the vehicle was involved in an accident that was not severe enough to cause the SRS side and curtain shield airbags to inflate.
1-1. For safe use
43
The pad section of the steering wheel, dash­board near the front passenger airbag or lower portion of the instrument panel is scratched, cracked, or otherwise damaged.
The front passenger’s seat cushion surface is scratched, cracked, or otherwise damaged.
The surface of the seats with the side airbag is scratched, cracked, or otherwise damaged.
The portion of the front pillars, rear pillars or roof side rail garnishes (padding) containing the curtain shield airbags inside is scratched, cracked, or otherwise damaged.
1
For safety and security
44
WARNING
Not for Reproduction
1-1. For safe use

Exhaust gas precautions

Harmful substance to the human body is contained in exhaust gases if inhaled.
Exhaust gases contain harmful carbon monoxide (CO), which is colorless and odorless. Observe the following precautions. Failure to do so may cause exhaust gases enter the vehicle and may lead to an accident caused by light-headedness, or may lead to death or a serious health hazard.
Important points while driving
Keep the back door closed.
If you smell exhaust gases in the vehicle even when the back door is closed, open the windows and have the vehicle inspected at your Lexus dealer as soon as possible.
When parking
If the vehicle is in a poorly ventilated area or a closed area, such as a garage, stop the engine.
Do not leave the vehicle with the engine running for a long time. If such a situation cannot be avoided, park the vehicle in an open space and ensure that exhaust fumes do not enter the vehicle interior.
Do not leave the engine running in an area with snow build-up, or where it is snowing. If snowbanks build up around the vehicle while the engine is running, exhaust gases may collect and enter the vehicle.
Exhaust pipe
The exhaust system needs to be checked periodically. If there is a hole or crack caused by corrosion, damage to a joint or abnormal exhaust noise, be sure to have the vehicle inspected and repaired by your Lexus dealer.
1-2. Child safety
WARNING
Not for Reproduction

Riding with children

Observe the following precautions when children are in the vehicle. Use a child restraint system appropriate for the child, until the child becomes large enough to properly wear the vehicle’s seat belt.
45
It is recommended that children sit in the rear seats to avoid accidental con­tact with the shift lever, wiper switch, etc.
Use the rear door child-protector lock or the window lock switch to avoid children opening the door while driving or operating the power window acci­dentally. (P. 123, 178)
Do not let small children operate equipment which may catch or pinch body parts, such as the power window, hood, back door, seats etc.
Never leave children unattended in the vehicle, and never allow children to have or use the key.
Children may be able to start the vehicle or shift the vehicle into neutral. There is also a danger that children may injure themselves by playing with the windows, the moon roof or panoramic moon roof, or other features of the vehicle. In addition, heat build-up or extremely cold temperatures inside the vehicle can be fatal to children.
1
For safety and security
46
Not for Reproduction
1-2. Child safety

Child restraint systems

Before installing a child restraint system in the vehicle, there are precautions that need to be observed, different types of child restraint systems, as well as installation methods, etc., written in this manual.
Use a child restraint system when riding with a small child that cannot properly use a seat belt. For the child’s safety, install the child restraint system to a rear seat. Be sure to follow the installation method that is in the operation manual enclosed with the restraint system.

Table of contents

Points to remember ....................................................................................................... P. 46
Child restraint system ................................................................................................... P. 48
When using a child restraint system ......................................................................... P. 51
Child restraint system installation method
• Fixed with a seat belt................................................................................................ P. 54
• Fixed with an ISOFIX rigid anchor.................................................................... P. 58
• Using a child restraint anchor fitting ................................................................. P. 64

Points to remember

Prioritize and observe the warnings, as well as the laws and regulations for child restraint systems.
Use a child restraint system until the child becomes large enough to properly wear the vehicle’s seat belt.
Choose a child restraint system appropriate to the age and size of the child.
Note that not all child restraint systems can fit in all vehicles. Before using or purchasing a child restraint system, check the compatibility of the child restraint system with seat positions. (P. 55, 60)
1-2. Child safety
WARNING
Not for Reproduction
When a child is riding
Observe the following precautions. Failure to do so may result in death or serious injury.
For effective protection in automobile accidents and sudden stops, a child must be properly restrained, using a seat belt or child restraint system which is correctly installed. For installation details, refer to the operation manual enclosed with the child restraint system. General installation instruction is provided in this manual.
Lexus strongly urges the use of a proper child restraint system that conforms to the weight and size of the child, installed on the rear seat. According to accident statistics, the child is safer when properly restrained in the rear seat than in the front seat.
Holding a child in your or someone else’s arms is not a substitute for a child restraint system. In an accident, the child can be crushed against the windshield or between the holder and the interior of the vehicle.
Handling the child restraint system
If the child restraint system is not properly fixed in place, the child or other passengers may be seriously injured or even killed in the event of sudden braking, sudden swerv­ing, or an accident.
If the vehicle were to receive a strong impact from an accident, etc., it is possible that the child restraint system has damage that is not readily visible. In such cases, do not reuse the restraint system.
Depending on the child restraint system, installation may be difficult or impossible. In those cases, check whether the child restraint system is suitable for installment in the vehicle. (P. 54, 58) Be sure to install and observe the usage rules after carefully reading the child restraint system fixing method in this manual, as well as the opera­tion manual enclosed with the child restraint system.
Keep the child restraint system properly secured on the seat even if it is not in use. Do not store the child restraint system unsecured in the passenger compartment.
If it is necessary to detach the child restraint system, remove it from the vehicle or store it securely in the luggage compartment.
47
1
For safety and security
48
Not for Reproduction
1-2. Child safety

Child restraint system

Install the available child restraint system in vehicle upon confirming the following items.
Standards for child restraint systems
Use a child restraint system that conforms to ECE R44 The following approval mark is displayed on child restraint systems which are
conformed. Check for an approval mark attached to the child restraint system.
Example of the displayed regulation number
1
ECE R44 approval mark The weight range of the child who is applicable for an ECE R44 approval mark is indicated.
2
ECE R129 approval mark The height range of the child who is applicable as well as available weights for an ECE R129 approval mark is indicated.
3
*
3
*
1
*
or ECE R129
1, 2
*
.
1
*
: ECE R44 and ECE R129 are U.N. regulations for child restraint systems.
2
*
: The child restraint systems mentioned in the table may not be available outside of
the EU area.
3
*
: The displayed mark may differ depending on the product.
1-2. Child safety
Not for Reproduction
Mass group (ECE R44 only)
This Mass group table is required when confirming the child restraint system compatibility. Confirm in accordance with the child restraint system compati­bility table. (P. 55, 60)
The child restraint system which conforms to the standard of ECE R44 is cat­egorized into 5 groups according to the weight of the child.
Mass group Child weight Reference age
Group 0 until 10 kg (22 lb.) about 9 months
Group 0+ until 13 kg (28 lb.) about 1.5 years
Group I 9 - 18 kg (20 to 39 lb.) from 9 months - about 4 years
Group II 15 - 25 kg (34 to 55 lb.) from 3 years - about 7 years
Group III 22 - 36 kg (49 to 79 lb.) from 6 years - about 12 years
*
: The age range is a standard approximation. Choose according to the weight of the
child.
*
49
1
For safety and security
50
Not for Reproduction
1-2. Child safety
Types of child restraint system installation methods
Confirm with the operation manual enclosed with the child restraint system about the installation of the child restraint system.
Installation method Page
Seat belt attachment P. 54
ISOFIX rigid anchor
attachment
Child restraint anchor
fitting attachment
P. 58
P. 64
1-2. Child safety
Not for Reproduction

When using a child restraint system

When installing a child restraint system to a front passenger seat
For the safety of a child, install child restraint systems to a rear seats. When installing child restraint system to a front passenger seat is unavoidable, adjust the seat as follows and install the child restraint system.
Raise the seatback as much as possible
Move the seat to the rearmost position
Raise the seat to the highest posi­tion
If the head restraint interferes with the installation of the child restraint system, and the head restraint can be removed, remove the head restraint
If the head restraint cannot be removed, raise it to the uppermost position.
51
1
For safety and security
52
WARNING
Extreme Hazard! Do not use a rearward fac­ing child restraint on a seat protected by an airbag in front of it! This is because the force of the rapid inflation of the front passenger airbag can cause death or serious injury to the child. There is a label(s) on the passenger side sun visor, indicating it is forbidden to attach a rear­facing child restraint system to the front pas­senger seat. Details of the label(s) are shown in the illustra­tion below.
Not for Reproduction
1-2. Child safety
When using a child restraint system
Observe the following precautions. Failure to do so may result in death or serious injury.
1-2. Child safety
WARNING
Only put a forward-facing child restraint sys­tem on the front seat when unavoidable. When installing a forward-facing child restraint on the front passenger seat, move the seat as far back as possible. Failing to do so may result in death or serious injury if the airbags deploy (inflate).
Do not allow the child to lean his/her head or any part of his/her body against the door or the area of the seat, front or rear pillars, or roof side rails from which the SRS side airbags or SRS curtain shield airbags deploy even if the child is seated in the child restraint system. It is dangerous if the SRS side airbags and curtain shield airbags inflate, and the impact could cause death or serious injury to the child.
If the driver’s seat interferes with the child restraint system and prevents it from being attached correctly, attach the child restraint system to the left-hand rear seat.
Adjust the front passenger seat so that it does not interfere with the child restraint system.
Not for Reproduction
When using a child restraint system
When a junior seat (booster seat) is installed, always ensure that the shoulder belt is positioned across the center of the child’s shoulder. The belt should be kept away from the child’s neck, but not so that it could fall off the child’s shoulder.
Use child restraint system suitable to the age and size of the child and install it to the rear seat.
53
1
For safety and security
54
1
2
Not for Reproduction
1-2. Child safety

Child restraint system fixed with a seat belt

Child restraint system compatibility for various seating positions
The child restraint system suitability table (P. 55), with symbols, displays the types of usable child restraint systems and possible seating position installa­tion for the child restraint system owned by the customer. Confirm also in accordance with [Confirming the possible installation seating positions and the Mass Group for the seat belt installation type child restraint systems].
Confirming the possible installation seating positions and the Mass Group for the seat belt installation type child restraint systems
Confirm the corresponding [Mass group] from the weight of the child (P. 49)
(Ex. 1) When the weight is 12 kg (27 lb.), [Mass group 0+] (Ex. 2) When the weight is 15 kg (34 lb.), [Mass group I] Confirm and select the appropriate possible seating position for the child
restraint system and the corresponding type of system from the [Child restraint system suitability table]. (P. 55)
1-2. Child safety
Not for Reproduction
Child restraint system suitability table (Installed using seat belts)
If your child restraint system is of “universal” category, you can install it on the positions mentioned by U or UF in the table below (UF is for forward-facing child restraint systems only). Child restraint systems category and mass group can be found in the child restraint system manual. If your child restraint system is not of the “universal” category (or if you cannot find information in the table below), please refer to the child restraint system “vehicle list” for compatibility information or ask the retailer of your child seat.
Seating position
55
1
For safety and security
Mass groups
0 Up to 10 kg (22 lb.)
0+ Up to 13 kg (28 lb.)
I 9 to 18 kg (20 to 39 lb.)
II, III 15 to 36 kg (34 to 79 lb.)
Front seat Rear seat
Passenger seat Outboard Center
XUU
XUU
Rearward-facing —
X
Forward-facing —
UF
UF
1, 2
*
1, 2
*
2
U
*
2
U
*
2
U
*
2
U
*
56
Not for Reproduction
1-2. Child safety
Key of letters inserted in the above table: X: Not suitable seat position for children in this mass group. U: Suitable for “universal” category child restraint systems approved for use in
this mass group.
UF: Suitable for forward-facing “universal” category child restraint systems
approved for use in this mass group.
1
*
: Adjust the seatback angle to the most upright position. Move the front seat fully rear-
ward. If the passenger seat height can be adjusted, move it to the upper most position.
2
*
: If the head restraint interferes with your child restraint system, and the head restraint
can be removed, remove the head restraint. Otherwise, put the head restraint in the upper most position.
When securing some types of child restraint systems in second row seats, it may not be possible to properly use the seat belts in positions next to the child restraint without interfering with it or affecting seat belt effectiveness. Be sure your seat belt fits snugly across your shoulder and low on your hips. If it does not, or if it interferes with the child restraint, move to a different position. Failure to do so may result in death or serious injury.
1-2. Child safety
1
2
345
Not for Reproduction
Installing child restraint system using a seat belt
Install the child restraint system in accordance to the operation manual enclosed with the child restraint system.
Adjust the seat
When using the front passenger seat
If installing the child restraint system to the front passenger seat is unavoid­able, refer to P. 51 for the front passenger seat adjustment.
When using the rear seat
If there is a gap between the child seat and the seatback, adjust the seatback angle until good contact is achieved.
Remove the head restraint if it interferes with your child restraint system. (P. 168)
If the head restraint cannot be removed, raise it to the uppermost position.
Run the seat belt through the child restraint system and insert the plate into the buckle. Make sure that the belt is not twisted. Securely fix the seat belt to the child restraint system in accor­dance to the directions enclosed with the child restraint system.
57
1
For safety and security
If your child restraint system is not equipped with a lock-off (a seat belt locking feature), secure the child restraint system using a locking clip.
After installing the child restraint system, rock it back and forth to ensure that it is installed securely. (P. 58)
58
WARNING
Not for Reproduction
1-2. Child safety
Removing a child restraint system installed with a seat belt
Press the buckle release button and fully retract the seat belt.
When releasing the buckle, the child restraint system may spring up due to the rebound of the seat cushion. Release the buckle while holding down the child restraint system.
Since the seat belt automatically reels itself, slowly return it to the stowing position.
When installing a child restraint system
You may need a locking clip to install the child restraint system. Follow the instructions provided by the manufacturer of the system. If your child restraint system does not pro­vide a locking clip, you can purchase the following item from your Lexus dealer: Locking clip for child restraint system (Part No. 73119-22010)
When installing a child restraint system
Observe the following precautions. Failure to do so may result in death or serious injury.
Do not allow children to play with the seat belt. If the seat belt becomes twisted around a child’s neck, it may lead to choking or other serious injuries that could result in death. If this occurs and the buckle cannot be unfastened, scissors should be used to cut the belt.
Ensure that the belt and plate are securely locked and the seat belt is not twisted.
Shake the child restraint system left and right, and forward and backward to ensure that it has been securely installed.
After securing a child restraint system, never adjust the seat.
When a junior seat (booster seat) is installed, always ensure that the shoulder belt is positioned across the center of the child’s shoulder. The belt should be kept away from the child’s neck, but not so that it could fall off the child’s shoulder.
Follow all installation instructions provided by the child restraint system manufacturer.

Child restraint system fixed with an ISOFIX rigid anchor

ISOFIX rigid anchors (ISOFIX child restraint system)
Lower anchors are provided for the outboard rear seats. (Tags displaying the location of the anchors are attached to the seats.)
1-2. Child safety
1
2
1
Not for Reproduction
Child restraint system compatibility for various seating positions
The child restraint system suitability table (P. 60), with symbols, displays the types of usable child restraint systems and possible seating position installa­tion for the child restraint system owned by the customer. Confirm in accor­dance with the listed Size class, Anchor, as well as [Confirming the Mass group and Size class for ECE R44 ISOFIX corresponding child restraint sys­tems].
Confirming the Mass group and Size class for ECE R44 ISOFIX corre­sponding child restraint systems
Confirm the corresponding [Mass group] from the weight of the child (P. 49)
(Ex. 1) When the weight is 12 kg (27 lb.), [Mass group 0+] (Ex. 2) When the weight is 15 kg (34 lb.), [Mass group I] Confirming Size class Select the Size class corresponding to [Mass group] confirmed in step
*
from the [Child restraint system suitability] (P. 60) (Ex. 1) When [Mass group 0+], the corresponding size class is [C], [D], [E]. (Ex. 2) When [Mass group I], the corresponding size class is [A], [B], [B1],
[C], [D].
*
: However, listings that are marked with [X] cannot be selected, despite having the
corresponding size class in the suitability table of the [Seating position].
.
59
1
For safety and security
60
Not for Reproduction
1-2. Child safety
Child restraint system suitability table (Installed using ISOFIX [Child restraint system conforms with ECE R44])
ISOFIX child restraint systems are divided in different “size class”. According to this “size class”, you will be allowed to use it in the vehicle seating position mentioned in the table below. To know your child restraint system “size class” and “mass group”, please refer to the child restraint system manual. If your child restraint system has no “size class” (or if you cannot find information in the table below), please refer to the child restraint system “vehicle list” for compatibility information or ask the retailer of your child seat.
Size class Description
A Full-height, forward-facing child restraint systems
B Reduced-height forward-facing child restraint systems
B1 Reduced-height forward-facing child restraint systems
C Full-size rearward-facing child restraint systems
D Reduced-size rearward-facing child restraint systems
E Rearward-facing infant seat
F Left lateral-facing (carrycot) infant seat
G Right lateral-facing (carrycot) infant seat
1-2. Child safety
Not for Reproduction
Seating position
61
Mass groups Size class
Carrycot
0 Up to 10 kg (22 lb.)
0+ Up to 13 kg (28 lb.)
I 9 to 18 kg (20 to 39 lb.)
Key of letters inserted in the above table: X: Not suitable seat position for ISOFIX child restraint systems in this mass
group and/or size class.
IUF: Suitable for ISOFIX forward-facing child restraint systems of “universal”
category approved for use in this mass group.
IL: Suitable for ISOFIX child restraint systems of the categories for “specific
vehicles”, “restricted”, or “semi-universal”, approved for use in this mass group.
*
: If the head restraint interferes with your child restraint system, and the head restraint
can be removed, remove the head restraint. Otherwise, put the head restraint in the upper most position.
When securing some types of child restraint systems in second row seats, it may not be possible to properly use the seat belts in positions next to the child restraint without interfering with it or affecting seat belt effectiveness. Be sure your seat belt fits snugly across your shoulder and low on your hips. If it does not, or if it interferes with the child restraint, move to a different position. Failure to do so may result in death or serious injury.
FX XX
GX X X
EX ILX
EX ILX
DX IL X
CX ILX
DX IL X
CX ILX
BXIUF
B1 X IUF
AXIUF
Front seat Rear seat
Passenger seat Outboard Center
* * *
X
X
X
1
For safety and security
62
Not for Reproduction
1-2. Child safety
Child restraint system suitability table (Installed using i-Size [Child restraint system conforms with ECE R129])
If your child restraint system is of “i-Size” category, you can install it on the positions mentioned by i-U in the table below. Child restraint system category can be found in the child restraint system manual.
Seating position
Front seat Rear seat
Passenger seat Outboard Center
i-Size child restraint systems
Key of letters inserted in the above table: X: Not suitable for use with i-Size child restraint systems. i-U: Suitable for i-Size “universal” child restraint systems forward and rearward
facing.
*
: If the head restraint interferes with your child restraint system, and the head restraint
can be removed, remove the head restraint. Otherwise, put the head restraint in the upper most position.
When securing some types of child restraint systems in second row seats, it may not be possible to properly use the seat belts in positions next to the child restraint without interfering with it or affecting seat belt effectiveness. Be sure your seat belt fits snugly across your shoulder and low on your hips. If it does not, or if it interferes with the child restraint, move to a different position. Failure to do so may result in death or serious injury.
X
i-U
*
X
1-2. Child safety
123
4
Not for Reproduction
Installation with ISOFIX rigid anchor (ISOFIX child restraint system)
Install the child restraint system in accordance to the operation manual enclosed with the child restraint system.
Adjust the seat If there is a gap between the child seat and the seatback, adjust the
seatback angle until good contact is achieved. Remove the head restraint if it interferes with your child restraint system.
(P. 168)
If the head restraint cannot be removed, raise it to the uppermost position.
Check the positions of the exclu­sive fixing bars, and install the child restraint system to the seat.
The bars are installed in the clear­ance between the seat cushion and seatback.
63
1
For safety and security
After installing the child restraint system, rock it back and forth to ensure that it is installed securely. (P. 58)
64
WARNING
Upper anchorage strap
Anchor
fittings
Not for Reproduction
F
1-2. Child safety
When installing a child restraint system
Observe the following precautions. Failure to do so may result in death or serious injury.
After securing a child restraint system, never adjust the seat.
When using the lower anchors, be sure that there are no foreign objects around the anchors and that the seat belt is not caught behind the child restraint system.
Follow all installation instructions provided by the child restraint system manufacturer.
Using child restraint anchorages
WARNING: child restraint anchorages are designed to withstand only those loads imposed by correctly fitted child restraints. Under no circumstances are they to be used for adult seatbelts, harnesses, or for attaching other items or equipment to the vehicle.

Using a child restraint anchor fitting

Child restraint anchor fitting
Anchor fittings are provided for each rear seat.
Use anchor fitting when fixing the strap.
1-2. Child safety
1
Upper anchorage strap
Attaching c
lip
2
WARNING
NOTICE
Not for Reproduction
Fixing the strap to the anchor fitting
Install the child restraint system in accordance to the operation manual enclosed with the child restraint system.
Remove the head restraint if it interferes with your child restraint system. (P. 168)
If the head restraint cannot be removed, raise it to the uppermost position.
Open the anchor fitting cover, latch the attaching clip onto the anchor fitting and tighten the upper anchorage strap.
Make sure the upper anchorage strap is securely latched. (
When installing the child restraint system with the head restraint being raised, be sure to have the upper anchorage strap pass underneath the head restraint.
When installing a child restraint system
Observe the following precautions. Failure to do so may result in death or serious injury.
Firmly attach the upper anchorage strap and make sure that the belt is not twisted.
Do not attach the upper anchorage strap to anything other than the anchor fitting.
After securing a child restraint system, never adjust the seat.
Follow all installation instructions provided by the child restraint system manufacturer.
When installing the child restraint system with the head restraint being raised, after the head restraint has been raised and then the anchor fitting has been fixed, do not lower the head restraint.
Using child restraint anchorages
WARNING: child restraint anchorages are designed to withstand only those loads imposed by correctly fitted child restraints. Under no circumstances are they to be used for adult seatbelts, harnesses, or for attaching other items or equipment to the vehicle.
P. 58)
65
1
For safety and security
Child restraint anchor fitting
When not in use, make certain to close the lid. If it remains open, the lid may be dam­aged.
66
NOTICE
Not for Reproduction
1-3. Theft deterrent system

Engine immobilizer system

The vehicle’s keys have built-in transponder chips that prevent the engine from starting if a key has not been previously registered in the vehicle’s on­board computer.
Never leave the keys inside the vehicle when you leave the vehicle.
This system is designed to help prevent vehicle theft but does not guarantee absolute security against all vehicle thefts.
The indicator light flashes after the engine switch has been turned off to indicate that the system is operating.
The indicator light stops flashing after the engine switch has been turned to ACCESSORY or IGNITION ON mode to indicate that the system has been canceled.
System maintenance
The vehicle has a maintenance-free type engine immobilizer system.
Conditions that may cause the system to malfunction
If the grip portion of the key is in contact with a metallic object
If the key is in close proximity to or touching a key registered to the security system (key with a built-in transponder chip) of another vehicle
To ensure the system operates correctly
Do not modify or remove the system. If modified or removed, the proper operation of the system cannot be guaranteed.
1-3. Theft deterrent system
Not for Reproduction

Alarm

The alarm

The alarm uses light and sound to give an alert when an intrusion is detected. The alarm is triggered in the following situations when the alarm is set:
A locked door is unlocked or opened in any way other than using the entry function, wireless remote control or mechanical key. (The doors will lock again automatically.)
The hood is opened.
The intrusion sensor detects something moving inside the vehicle. (An intruder gets in the vehicle.)
Any of the windows are broken.

Setting the alarm system

Close the doors and hood, and lock all the doors. The system will be set auto­matically after 30 seconds.
The indicator light changes from being on to flashing when the system is set.
67
1
For safety and security

Deactivating or stopping the alarm

Do one of the following to deactivate or stop the alarm.
Unlock the doors.
Turn the engine switch to ACCESSORY or IGNITION ON mode, or start the engine. (The alarm will be deactivated or stopped after a few seconds.)
68
NOTICE
Not for Reproduction
1-3. Theft deterrent system
System maintenance
The vehicle has a maintenance-free type alarm system.
Items to check before locking the vehicle
To prevent unexpected triggering of the alarm and vehicle theft, make sure of the follow­ing.
Nobody is in the vehicle.
The windows and moon roof or panoramic moon roof are closed before the alarm is set.
No valuables or other personal items are left in the vehicle.
Triggering of the alarm
The alarm may be triggered in the following situations: (Stopping the alarm deactivates the alarm system.)
A person inside the vehicle opens a door or hood, or unlocks the vehicle.
The battery is recharged or replaced when the vehicle is locked. (P. 498)
Alarm-operated door lock
In the following cases, depending on the situation, the door may automatically lock to prevent improper entry into the vehicle:
When a person remaining in the vehicle unlocks the door and the alarm is activated.
While the alarm is activated, a person remaining in the vehicle unlocks the door.
When recharging or replacing the battery
To ensure the system operates correctly
Do not modify or remove the system. If modified or removed, the proper operation of the system cannot be guaranteed.
1-3. Theft deterrent system
1
2
Not for Reproduction

Intrusion sensor

The intrusion sensor detects intruders or movement in the vehicle. This system is designed to deter and prevent vehicle theft but does not guarantee
absolute security against all intrusions.
Setting the intrusion sensor
The intrusion sensor will be set automatically when the alarm is set. (P. 67)
Canceling the intrusion sensor
If you are leaving pets or other moving things inside the vehicle, make sure to disable the intrusion sensor before setting the alarm, as they will respond to movement inside the vehicle.
Turn the engine switch off.
Press the intrusion sensor cancel switch.
A message will be shown on the multi-information display in the instrument cluster. The intrusion sensor will revert to on each time the engine switch is turned to IGNITION ON mode.
69
1
For safety and security
Canceling and automatic re-enabling of the intrusion sensor
The alarm will still be set even when the intrusion sensor is canceled.
After the intrusion sensor is canceled, pressing the engine switch or unlocking the doors using the entry function or wireless remote control will re-enable the intrusion sensor.
The intrusion sensor will automatically be re-enabled when the alarm system is reacti­vated.
70
Not for Reproduction
1-3. Theft deterrent system
Intrusion sensor detection considerations
The sensor may trigger the alarm in the following situations:
People or pets are in the vehicle.
A window or the moon roof, panoramic moon roof is open.
In this case, the sensor may detect the follow­ing:
• Wind or the movement of objects such as leaves and insects inside the vehicle
• Ultrasonic waves emitted from devices such as the intrusion sensors of other vehi­cles
• The movement of people outside the vehi­cle
Unstable items, such as dangling accessories or clothes hanging on the coat hooks, are in the vehicle.
The vehicle is parked in a place where extreme vibrations or noises occur, such as in a parking garage.
Ice or snow is removed from the vehicle, caus­ing the vehicle to receive repeated impacts or vibrations.
1-3. Theft deterrent system
NOTICE
Do not spray air fresheners or other products directly into the sensor holes.
To ensure that the sensors operate properly, do not touch or cover them.
Not for Reproduction
The vehicle is inside an automatic or high-pressure car wash.
The vehicle experiences impacts, such as hail, lightning strikes, and other kinds of repeated impacts or vibrations.
To ensure the intrusion sensor functions correctly
71
1
For safety and security
Installing accessories other than genuine Lexus parts or leaving objects between the driver’s seat and front passenger’s seat may reduce the detection performance.
72
Not for Reproduction
1-3. Theft deterrent system
73
Not for Reproduction
Instrument cluster
2

2. Instrument cluster

Warning lights and
indicators....................................... 74
Gauges and meters.....................79
Multi-information display..........83
Head-up display.......................... 104
Fuel consumption
information .................................109
74
Not for Reproduction
2. Instrument cluster

Warning lights and indicators

The warning lights and indicators on the instrument cluster, center panel and outside rear view mirrors inform the driver of the status of the vehicle’s vari­ous systems.
For the purpose of explanation, the following illustration displays all warning lights and indicators illuminated.
Except F SPORT models
F SPORT models
2. Instrument cluster
Not for Reproduction

Warning lights

Warning lights inform the driver of malfunctions in any of the vehicle’s systems.
1
*
Brake system warning light (P. 468)
(if equipped)
LKA indicator (P. 469)
75
(if equipped)
*
1, 3
*
1
*
Brake system warning light (P. 468)
1
*
Charging system warning light (P. 468)
1
*
Malfunction indicator lamp (P. 468)
1
*
SRS warning light (P. 468)
1
*
ABS warning light (P. 468)
3
Parking brake indicator (P. 469)
Brake hold operated indicator (P. 469)
1, 3
*
(if equipped)
1, 2, 3
*
(if equipped)
1
*
Slip indicator (P. 469)
PCS warning light (P. 470)
Stop & Start cancel indicator (P. 470)
Low fuel level warning light (P. 470)
Driver’s and front passenger’s seat belt reminder light (P. 470)
4
*
Rear passengers’ seat belt reminder light (P. 470)
1
*
Tire pressure warning light (P. 471)
2
Instrument cluster
1
*
Electric power steering system warning light (P. 469)
1
*
Electric power steering system warning light (P. 469)
1
*
Master warning light (P. 471)
76
Not for Reproduction
2. Instrument cluster
1
*
: These lights turn on when the engine switch is turned to IGNITION ON mode to
indicate that a system check is being performed. They will turn off after the engine is started, or after a few seconds. There may be a malfunction in a system if a light does not come on, or turn off. Have the vehicle inspected by your Lexus dealer.
2
*
: When the start-up display is displayed on the multi-information display, this light may
not turn on even though the engine switch has been turned to IGNITION ON mode.
3
*
: This light flashes to indicate a malfunction.
4
*
: This light illuminates on the center panel.

Indicators

The indicators inform the driver of the operating state of the vehicle’s various sys­tems.
(if equipped)
Turn signal indicator (P. 221)
Tail light indicator (P. 228)
Headlight high beam indicator (P. 228)
Automatic High Beam
1
*
indicator (P. 236) Adaptive High-beam Sys­tem indicator (P. 231)
Front fog light indicator (P. 240)
Rear fog light indicator (P. 240)
Cruise control indicator (P. 281, 293)
(if equipped)
(if equipped)
*
(if equipped)
(if equipped)
(if equipped)
(if equipped)
Cruise control “SET” indicator (P. 281, 293)
LKA indicator (P. 272)
LKA indicator (P. 272)
5
LKA indicator (P. 272)
Lexus parking assist-sensor indicator (P. 307)
“BSM” indicator (P. 315)
“RCTA” indicator (P. 315)
3, 4
*
BSM outside rear view mirror indicators (P. 315)
(if equipped)
Radar cruise control indicator (P. 281)
(if equipped)
2. Instrument cluster
Not for Reproduction
77
1, 5
*
1, 6
*
1, 6
*
(if equipped)
1, 2
*
(if equipped)
1, 2, 6
*
(if equipped)
Slip indicator (P. 336)
VSC OFF indicator (P. 337)
PCS warning light (P. 263)
Stop & Start indicator (P. 297)
Stop & Start cancel indicator (P. 300)
Parking brake indicator (P. 222)
(AWD
models only)
*
1
*
Brake hold standby indicator (P. 226)
1
*
Brake hold operated indicator (P. 226)
1
*
Eco Driving Indicator Light (P. 101)
7
*
Security indicator (P. 66, 67)
1
*
All-wheel drive lock indicator (P. 333)
8
Low outside temperature indicator (P. 79)
2
Instrument cluster
Drive mode indicators
Except F SPORT models
(if equipped)
(if equipped)
Eco drive mode indicator (P. 329)
(if equipped)
“SPORT S” indicator (P. 329)
(if equipped)
“Customize” indicator (P. 329)
“SPORT” indicator (P. 329)
“SPORT S+” indicator (P. 329)
78
WARNING
Not for Reproduction
2. Instrument cluster
F SPORT models
Eco drive mode indicator (P. 329)
“SPORT S+” indicator (P. 329)
1
*
: These lights turn on when the engine switch is turned to the IGNITION ON mode to
indicate that a system check is being performed. They will turn off after the engine is started, or after a few seconds. There may be a malfunction in a system if a light does not come on, or turn off. Have the vehicle inspected by your Lexus dealer.
2
*
: When the start-up display is displayed on the multi-information display, this light may
not turn on even though the engine switch has been turned to IGNITION ON mode.
3
*
: In order to confirm operation, the BSM outside rear view mirror indicators illuminate
in the following situations:
• When the BSM function is enabled on of the multi-information display, the engine switch is turned to IGNITION ON mode.
• When the engine switch is in IGNITION ON mode, the BSM function is enabled on of the multi-information display.
If the system is functioning correctly, the BSM outside rear view mirror indicators will turn off after a few seconds. If the BSM outside rear view mirror indicators do not illuminate or do not turn off, there may be a malfunction in the system. If this occurs, have the vehicle inspected by your Lexus dealer.
4
*
: This light illuminates on the outside rear view mirrors.
5
*
: The light flashes to indicate that the system is operating.
6
*
: The light comes on when the system is turned off.
7
*
: This light illuminates on the center panel.
8
*
: When the outside temperature is approximately 3°C (37°F) or lower, the indicator
will flash for approximately 10 seconds, then stay on.
“SPORT S” indicator (P. 329)
“CUSTOMIZE” indicator (P. 329)
If a safety system warning light does not come on
Should a safety system light such as the ABS and SRS warning lights not come on when you start the engine, this could mean that these systems are not available to help pro­tect you in an accident, which could result in death or serious injury. Have the vehicle inspected by your Lexus dealer immediately if this occurs.

Gauges and meters

Not for Reproduction
Except F SPORT models
F SPORT models
2. Instrument cluster
79
2
Instrument cluster
80
2
3
5
7
9
Not for Reproduction
2. Instrument cluster
1
Engine coolant temperature gauge
Displays the engine coolant temperature
Tachometer
Displays the engine speed in revolutions per minute F SPORT models: When sport mode is selected for the driving mode, the periph-
ery of the tachometer will change color and the scale of the tachometer will be emphasized.
Outside temperature
Displays the outside temperature within the range of -40°C (-40°F) to 50°C (122°F). Low outside temperature indicator comes on when the ambient tempera­ture is 3°C (37°F) or lower.
4
Multi-information display
Presents the driver with a variety of vehicle data (P. 83) Displays warning messages in case of a malfunction (P. 474)
Clock
Time displayed is linked to the analog clock on the instrument panel. (P. 388)
6
Speedometer Fuel gauge
8
Shift position display Odometer and trip meter
(P. 215)
(P. 99)
1
2
Not for Reproduction
Rev indicator (F SPORT models)
When the engine reaches a set speed, a ring-shaped indicator will be displayed on the tachometer.
The desired engine speed at which the Rev indicator will begin to be dis-
played can be set on of the multi­information display. (P. 93)
2. Instrument cluster
81
Rev peak (F SPORT models)
The engine speed reaches or exceeds 5000 rpm, an afterimage of the tachometer will be displayed at the highest engine speed for approximately 1 second.

Instrument panel light control

The brightness of the instrument panel lights can be adjusted.
Darker Brighter
The brightness of the instrument panel lights can be adjusted individually for day mode and night mode
*
: Day mode and night mode: P. 82
*
.
2
Instrument cluster
82
NOTICE
Not for Reproduction
2. Instrument cluster
The meters and display illuminate when
The engine switch is in IGNITION ON mode.
Brightness of the meters (day mode and night mode)
The brightness of the meters is changed between day mode and night mode.
Day mode: When the tail lights are off or when the tail lights are on but the surrounding area is bright
Night mode: When the tail lights are on and the surrounding area is dark
Outside temperature display
In the following situations, the correct outside temperature may not be displayed, or the display may take longer than normal to change.
• When stopped, or driving at low speeds (less than 20 km/h [12 mph])
• When the outside temperature has changed suddenly (at the entrance/exit of a garage, tunnel, etc.)
When “” or “E” is displayed, the system may be malfunctioning. Take your vehicle to your Lexus dealer.
Clock settings screen
If the clock adjustment screen is displayed continuously when attempting to change the clock settings, the system may be malfunctioning. Have the vehicle inspected by your Lexus dealer.
Customization
Some functions can be customized. (P. 93)
To prevent damage to the engine and its components
Do not let the indicator needle of the tachometer enter the red zone, which indicates the maximum engine speed.
The engine may be overheating if the engine coolant temperature gauge is in the red zone (H). In this case, immediately stop the vehicle in a safe place, and check the engine after it has cooled completely. (P. 500)
2. Instrument cluster
1
2
3
Not for Reproduction

Multi-information display

Summary of functions

The multi-information display presents the driver with a variety of driving-related data, such as the current outside temperature. The multi-information display can also be used to change the display settings and other settings.
Except F SPORT models
83
2
Instrument cluster
Menu icon display area
Displays the following items. When a menu icon is not selected, the outside temperature and clock are displayed.
•Menu icons (P. 87)
• Outside temperature (P. 79)
•Clock (P. 79)
Content display area
A variety of information can be displayed by selecting a menu icon. Additionally, warning or suggestion/advice pop-up displays will be displayed in some situations.
• Menu icon content (P. 87)
• Suggestion function (P. 100)
• Warning message (P. 474)
Indicator/shift position display area
Displays the following items:
•Indicators (P. 74)
• Shift position display (P. 215)
84
4
5
6
1
2
3
4
5
6
7
8
Not for Reproduction
2. Instrument cluster
Odometer/trip meter display area (P. 99)
Displays the following items:
• Odometer/trip meter
Distance until next engine oil change
Stop & Start system operation time (current) (if equipped)
Meter control switches (P. 85) “ODO/TRIP” switch (P. 86)
F SPORT models
Outside temperature (P. 79) Menu icons (P. 87) Content display area
A variety of information can be displayed by selecting a menu icon. Additionally, warning or suggestion/advice pop-up displays will be displayed in some situations.
• Menu icon content (P. 87)
• Suggestion function (P. 100)
• Warning message (P. 474)
Indicators/clock
•Indicators (P. 74)
•Clock (P. 79)
Shift position display (P. 215) Odometer/trip meter display area (P. 99)
Displays the following items:
• Odometer/trip meter
Distance until next engine oil change
Meter control switches (P. 85) “ODO/TRIP” switch (P. 86)
2. Instrument cluster
1
2
3
Not for Reproduction

Using the multi-information display

Using the content display area
The content display area is operated using the meter control switches.
:Select menu icons
: Change displayed con-
tent, scroll up/down the screen and move the
cursor Press: Enter/Set Press and hold: Reset Return to the previous screen
Pressing and holding the switch will display the first screen of the selected menu icon.
4
Press: Display the top screen Press and hold: Register current screen as the top screen
Registering a top screen
The displayed top screen can be changed to a registered screen of your choice.
To register a screen as the top screen, display the desired screen and press and hold .
• A message asking to confirm if registration is desired will be displayed. If the selected screen cannot be registered, a registration failure message will be dis­played.
• When no screen has been registered, the drive information screen will be dis­played.
85
2
Instrument cluster
86
Not for Reproduction
2. Instrument cluster
Resetting drive information
To reset the average fuel economy (after reset)/average vehicle speed (after
reset)/elapsed time (after reset) that are displayed on , display the desired
item and press and hold .
If both of the displayed items are resettable, a message will be displayed asking which item(s) to reset.
Using the odometer/trip meter display area
Items in this area are operated using the “ODO/TRIP” switch.
Press: Change displayed item
Each time the switch is pressed, the displayed item will be changed.
Press and hold: Reset
Display the desired trip meter and press and hold the switch to reset the trip meter.
2. Instrument cluster
Not for Reproduction

Menu icons

Select a menu icon to display its content.
Drive information (P. 88)
Select to display various drive data.
Navigation system-linked display
Select to display the following navigation system-linked information.
•Route guidance
• Compass display (heading-up display)
Audio system-linked display
Select to enable selection of an audio source or track on the meter using the meter control switches.
Driving assist system information (if equipped)
Select to display the operational status of the following systems:
• Dynamic radar cruise control with full-speed range (P. 281)
• LKA (Lane-Keeping Assist) (P. 272)
Stop & Start system information (if equipped) (P. 92, 297)
87
2
Instrument cluster
Select to display the operational status of the Stop & Start system.
Warning message display (P. 474)
Select to display warning messages and measures to be taken if a malfunction is detected.
Settings display (P. 93)
Select to change the meter display settings and other settings.
88
Not for Reproduction
2. Instrument cluster
Drive information ( )
Drive information 1/Drive information 2/Drive information 3
Displays drive information such as the following:
Drive information 1
• Current fuel consumption
• Average fuel economy (after reset)
Drive information 2
• Distance (driving range)
• Average vehicle speed (after reset)
Drive information 3
• Average fuel economy (after refuel)
• Elapsed time (after start)
Displayed items (listed below) can be changed on . (P. 93)
Item Content
Current fuel consumption Displays instantaneous current fuel consumption
After reset
Average fuel economy
Average vehicle speed
Elapsed time
Distance
Other Blank No item
After start
After refuel Displays average fuel consumption since refuel
After reset
After start Displays average vehicle speed since engine start
After reset Displays elapsed time since display reset
After start Displays elapsed time since engine start
Driving range Displays driving range with remaining fuel
After start Displays drive distance since vehicle start
Displays average fuel consumption since display reset
*
Displays average fuel consumption since engine
2
start
*
Displays average vehicle speed since display reset
*
1, 2
1
2, 3
*
1
*
3, 4
*
2. Instrument cluster
Not for Reproduction
1
*
: Resetting: P. 86
2
*
: Use the displayed fuel consumption as a reference.
3
*
: When only a small amount of fuel is added to the tank, the display may not be
updated. When refueling, turn the engine switch off. If the vehicle is refueled without turning the engine switch off, the display may not be updated.
4
*
: This distance is computed based on your average fuel consumption. As a result, the
actual distance that can be driven may differ from that displayed.
Eco Driving Indicator
P. 101
Sway warning (if equipped)
Detects the sway of the vehicle within a lane, which is often associated with a decrease in the driver's attention level, and displays the decrease in attention using a bar display. The shorter the bar length, the more the driver may need to rest.
This display is a part of the LKA (Lane-Keeping Assist) system. The display is enabled when the operating conditions of the vehicle sway warning are met. (P. 272)
AWD Control (if equipped)
Displays the driving force applied to each wheel using segments. The greater the number of segments displayed, the greater the driving force
applied.
89
2
Instrument cluster
90
2
Not for Reproduction
2. Instrument cluster
Boost gauge/engine oil temperature gauge/engine oil pressure gauge (if equipped)
1
Boost gauge Displays the boost pressure. The display will change color if the specified pressure is exceeded.
Engine oil temperature gauge Displays the engine oil tempera­ture. The display will flash if the engine oil temperature exceeds 140 °C (284 °F).
3
Engine oil pressure gauge Displays the engine oil pressure. A buzzer will sound and warning message will be displayed if the engine oil pressure becomes low. (P. 476)
This display is intended for use as a guideline. Depending on factors such as the road surface condition, temperature and vehicle speed, the display may not show the actual condition of the vehicle.
2. Instrument cluster
2
4
6
Not for Reproduction
G-force (if equipped)
Displays lateral G-forces on the vehicle. Also displays, around the periphery of the G-force display, the left and right steering amount, accelerator pedal input, and brake fluid pressure.
1
Acceleration G-force on the vehicle
Current G-force value (analyzed value of front/rear and left/right G-forces)
3
Record of the maximum G-forces Accelerator pedal input
5
Brake fluid pressure Steering amount
This display is intended for use as a guideline. Depending on factors such as the road surface condition, temperature and vehicle speed, the display may not show the actual condition of the vehicle.
Resetting the record of maximum G-forces Press and hold to reset the record.
Peak hold function If lateral G-forces of 0.5 G or greater are generated, the G-force value
display will turn amber and be held for 2 seconds.
Tire pressure
P. 427
Blank (No items)
Displays no drive information contents.
91
2
Instrument cluster
92
Not for Reproduction
2. Instrument cluster
Stop & Start system information ( ) (if equipped)
Stop & Start system operation time (current)/status notification
Displays the current amount of time the engine has been stopped due to the operation of the Stop & Start system. Also shows the status of the Stop & Start system with a pop-up display. (P. 304)
Stop & Start system total operation time/amount of fuel saved
Press or on the steering wheel to display the following items:
Stop & Start system operation time (after start/after reset) Displays the accumulated total of the following:
• Stop & Start system operation time since engine start
• Stop & Start system operation time since display was reset
Amount of fuel saved (after start/after reset) Displays the accumulated total of the following:
• Amount of fuel saved since engine start
• Amount of fuel saved since display was reset
Use the displayed amount of saved fuel for reference only.
Stop & Start system settings
Press on the steering wheel to display the Stop & Start system settings screen.
On this screen, the following operations can be performed:
Stop & Start
The length of time the Stop & Start system will operate when the “A/C” switch of the air conditioning system is on can be set to 2 different levels. This setting can
also be changed on .
Reset
Select to reset the Stop & Start system operation time/amount of fuel saved dis­play. To reset, move the cursor to “Reset”, and then press and hold .
2. Instrument cluster
1
2
3
Not for Reproduction
Settings display ( )
Changing settings
Use the meter control switches on the steering wheel to change settings.
Press or to select . Operate the switches to select a desired item. Change the setting by referring to the message displayed on the screen.
Setting items
LKA (Lane-Keeping Assist) (if equipped) (P. 272)
The following LKA system settings can be changed:
Item Settings Details
93
2
Instrument cluster
Lane center tracing
Steering assist
Alert
Alert sensitivity
Sway warning
Sway sensitivity
1
*
: If the lane-keeping assist function is enabled/disabled, steering wheel assistance will
also be enabled/disabled accordingly.
2
*
: If the steering wheel assistance is disabled, lane-keeping assist function will also be
disabled automatically.
On
Off
On
Off
High
Normal
On
Off
High
Medium
Low
Select to enable/disable the lane­keeping assist function.
Select to enable/disable steering wheel assistance.
Select to set a vibrator or buzzer as the notification method used to warn the driver.
Select to set the warning sensitivity.
Select to enable/disable the vehicle sway warning.
Select to set the vehicle sway warning sensitivity.
1
*
2
*
94
Not for Reproduction
2. Instrument cluster
PCS (Pre-Crash Safety system) (if equipped) (P. 259)
The following pre-crash safety system settings can be changed:
Item Settings Details
PCS
Warning sensitivity Select to change the warning timing.
BSM (Blind Spot Monitor) (if equipped) (P. 315)
The following Blind Spot Monitor settings can be changed:
Item Settings Details
BSM
RCTA
*
*
: The Rear Cross Traffic Alert function can be enabled/disabled only when the Blind
Spot Monitor function is enabled.
Lexus parking assist-sensor (if equipped) (P. 307)
Item Settings Details
On
Off
On
Off
On
Off
Select to enable/disable the pre-crash safety system.
Select to enable/disable the Blind Spot Monitor function.
Select to enable/disable the Rear Cross Traffic Alert function.
Lexus parking assist­sensor
On
Off
Select to enable/disable the Lexus parking assist-sensor.
Not for Reproduction
HUD (Head-up display) (if equipped) (P. 104)
The following head-up display settings can be changed:
Item Settings Details
Select to adjust the brightness/posi­tion of the head-up display.
Brightness/Position
Gauge information
No display
Eco Driving Indica­tor
Tachometer
Navigation system
• Press the / switch to adjust the display brightness.
• Press the / switch to adjust the display position.
Select to set the content displayed on the head-up display.
2. Instrument cluster
95
2
Instrument cluster
Driving support
Clock (on multi-information display) (P. 79)
The following clock setting can be changed:
Item Settings Details
Display mode
Driving Assist
Compass
Audio system
12-hour display
24-hour display
Select to enable/disable head-up dis­play content.
Select to set the display mode of the clock.
96
Not for Reproduction
2. Instrument cluster
Vehicle settings
Item Settings Details
PBD (Power back door) (if equipped) (P. 131)
The following power back door settings can be changed:
All On
System settings
Open position adjust­ment
Volume
Stop & Start system (if equipped) (P. 297)
Stop & Start sys-
tem operation time
Touchless Sensor Off (if equipped)
All Off
3 (Loud)
2 (Medium)
1 (Low)
Standard
Extended
Select to enable the power back door system.
Select to disable the touchless sensor. (Other power back door functions remain enabled.)
Select to disable the power back door system.
Select to set the open position at which the power back door will stop when opened automatically.
Select to set the volume of the buzzer which sounds when the power back door is operated.
Select to set the length of time the Stop & Start system will operate when the “A/C” switch of the air condition­ing system is on.
Item Settings Details
Not for Reproduction
TPMS (Tire pressure warning system) (P. 427)
Select to initialize the Tire pressure warning system. To perform initializa-
Tire pressure warning system initialization
tion, press and hold the switch. Before performing initialization, make sure to adjust the inflation pressure of each tire to the specified level. (P. 428)
2. Instrument cluster
97
Oil maintenance
Engine oil maintenance data reset
Meter settings
Item Settings Details
Language
Units
(Eco Driving
Indicator Light)
Switch settings
Drive information 1
Drive information 2
Drive information 3
On
Off
Select to reset the engine oil mainte­nance information (message indicat­ing maintenance is required and distance until the next oil change) after engine oil maintenance is per­formed. (P. 419)
Select to change the language dis­played.
Select to change the units of measure displayed.
Select to enable/disable the Eco Driv­ing Indicator Light. (P. 101)
Select to display how to change the top screen.
Select to select up to 2 items that will be displayed on each Drive informa­tion screen (Drive information 1 screen, Drive information 2 screen, and Drive information 3 screen) respectively. (Selectable items: P. 88)
2
Instrument cluster
98
Not for Reproduction
2. Instrument cluster
Item Settings Details
Intersection guid­ance
Incoming calls
Pop-up display
Color (except F SPORT models)
Needle (F SPORT models)
Rev indicator (F SPORT models)
Rev peak (F SPORT models)
Default setting
Duration
(if equipped)
Status
(if equipped)
Brightness adjust­ment
2 available colors
3 available colors
On
Off
Rev setting
On
Off
Select to enable/disable the pop-up display.
Select to set the color of the cursor on the multi-information display.
Select to set the tachometer needle color.
Select to enable/disable the Rev indi­cator. (P. 81)
Select to set the desired engine speed at which the Rev indicator will begin to be displayed. Selectable engine speed range: 2000 r/min to 6500 r/min
Select to enable/disable the Rev peak. (P. 81)
Select to reset the meter display set­tings to the default setting.
