LEXUS AVV60R, GSV60R owners manuals

Download

NOT FOR REPRODUCTION

Pictorial index

NOT FOR REPRODUCTION

For safety

and security

Search by illustration

Make sure to read through them

Instrument cluster

Operation of each

component

Driving

Interior features

Maintenance

and care

When trouble

arises

Vehicle

specifications

How to read the gauges and meters, the variety of warning lights and indicators, etc.

Opening and closing the doors and windows, adjustment before driving, etc.

Operations and advices which are necessary for driving

Usage of the interior features, etc.

Caring for your vehicle and maintenance procedures

What to do in case of malfunction or emergency

Vehicle specifications, customizable features, etc.

Index

Search by symptom

Search alphabetically

TABLE OF CONTENTS2

NOT FOR REPRODUCTION

For your information ...................................8

Reading this manual.................................. 14

How to search.............................................. 15

Pictorial index .............................................. 16

For safety and security

1-1. For safe use

Before driving.................................28

For safety drive...............................30

Seat belts ..........................................32

SRS airbags .....................................37

Safety information

for children....................................48

Child restraint systems................49

Installing child restraints.............57

Exhaust gas precautions............68

1-2. Hybrid system

Hybrid system features

(hybrid vehicles) .........................69

Hybrid system precautions

(hybrid vehicles) .........................73

1-3. Theft deterrent system

Engine immobilizer system

(gasoline vehicles) .....................79

Immobilizer system

(hybrid vehicles) ........................ 80

Alarm ..................................................81

Instrument cluster

2. Instrument cluster

Warning lights and

indicators.......................................86

Gauges and meters...................... 91

Multi-information display...........95

Energy monitor/

consumption screen...............105

Operation of each

component

3-1. Key information

Keys.....................................................112

3-2. Opening, closing and

locking the doors and trunk

Smart entry & start system........115

Wireless remote control ..........128

Doors .................................................131

Trunk.................................................136

3-3. Adjusting the seats

Front seats......................................143

Driving position memory......... 145

Head restraints...............................151

3-4. Adjusting the steering

wheel and mirrors

Steering wheel.............................155

Inside rear view mirror...............157

Outside rear view mirrors .......159

NOT FOR REPRODUCTION

3-5. Opening, closing the windows

and moon roof

Power windows ............................ 162

Moon roof......................................165

Driving

4-1. Before driving

Driving the vehicle.......................172

Cargo and luggage....................183

Trailer towing.................................184

4-2. Driving procedures

Engine (ignition) switch

(gasoline vehicles) ...................185

Power (ignition) switch

(hybrid vehicles) .......................192

EV drive mode

(hybrid vehicles) .......................199

Automatic transmission

(gasoline vehicles) ..................202

Hybrid transmission

(hybrid vehicles) ..................... 205

Turn signal lever ..........................209

Parking brake................................210

Horn....................................................211

4-3. Operating the lights

and wipers

Headlight switch..........................212

Fog light switch.............................215

Windshield wipers

and washer.................................. 216

Headlight cleaner switch........220

4-4. Refueling

Opening the fuel tank cap....... 221

4-5. Using the driving support

systems

Cruise control .............................226

Dynamic radar cruise

control..........................................230

Lexus

parking assist-sensor.............244

Driving mode select switch....256

Driving assist systems.............. 258

Hill-start assist control

(hybrid vehicles) ......................265

PCS (Pre-Crash Safety

system)......................................... 267

BSM (Blind Spot Monitor)......274

• Blind Spot Monitor

function.....................................278

• Rear Cross Traffic Alert

function......................................281

4-6. Driving tips

Hybrid vehicle driving tips

(hybrid vehicles) ......................284

Winter driving tips.....................287

TABLE OF CONTENTS4

NOT FOR REPRODUCTION

Interior features

5-1. Using the air conditioning

system and defogger

Front automatic

air conditioning system.........294

Rear air conditioning

system......................................... 306

Seat heaters/seat

ventilators..................................308

5-2. Using the interior lights

Interior lights list.............................311

• Interior light.............................312

• Personal lights.........................312

5-3. Using the storage features

List of storage features.............. 314

• Glove box.................................316

• Console box............................ 317

• Cup holders.............................318

• Auxiliary boxes.......................319

Trunk features..............................320

5-4. Other interior features

Sun visors and vanity

mirrors.........................................322

Clock...............................................323

Power outlet .................................324

Armrest..........................................325

Rear sunshade/

rear door sunshades..............326

Trunk storage extension ..........329

Coat hooks ...................................330

Assist grips.....................................331

Maintenance and care

6-1. Maintenance and care

Cleaning and protecting

the vehicle exterior.................334

Cleaning and protecting

the vehicle interior.................338

6-2. Maintenance

Maintenance

requirements..............................341

NOT FOR REPRODUCTION

6-3. Do-it-yourself maintenance

Do-it-yourself service

precautions................................344

Hood ...............................................347

Positioning a floor jack............ 348

Engine compartment.................351

12-volt battery (hybrid

vehicles)......................................366

Tires....................................................371

Tire inflation pressure...............380

Wheels............................................382

Air conditioning filter............... 384

Electronic key battery ............. 386

Checking

and replacing fuses................388

Light bulbs.................................... 400

When trouble arises

7-1. Essential information

Emergency flashers....................418

If your vehicle has to be

stopped in an emergency..... 419

7-2. Steps to take in an emergency

If your vehicle needs to

be towed...................................... 421

If you think something is

wrong...........................................427

Fuel pump shut off system

(gasoline vehicles)..................428

If a warning light turns on

or a warning buzzer

sounds..........................................429

If a warning message is

displayed.....................................437

If you have a flat tire...................459

If the engine will not start

(gasoline vehicles)..................468

If the hybrid system will not

start (hybrid vehicles)............470

If the shift lever cannot be

shifted from P............................ 472

If the electronic key does not

operate properly ..................... 473

If the 12-volt battery is

discharged (gasoline

vehicles).......................................476

If the 12-volt battery is

discharged (hybrid

vehicles).....................................480

If your vehicle overheats

(gasoline vehicles)..................484

If your vehicle overheats

(hybrid vehicles) ......................487

If the vehicle becomes

stuck...............................................491

TABLE OF CONTENTS6

NOT FOR REPRODUCTION

Vehicle specifications

8-1. Specifications

Maintenance data

(fuel, oil level, etc.)...................494

Fuel information..........................507

8-2. Customization

Customizable features............508

8-3. Initialization

Items to initialize ..........................519

Index

What to do if...

(Troubleshooting)................................522

Alphabetical index.................................528

For information regarding the equipment listed below, refer to the “Navigation System Owner’s Manual”.

• Navigation system

• Lexus parking assist monitor

• Audio/video system

NOT FOR REPRODUCTION

For your information

Main Owner’s Manual

Please note that this manual applies to all models and explains all equipment, including options. Therefore, you may find some explanations for equipment not installed on your vehicle.

All specifications provided in this manual are current at the time of printing. However, because of the Lexus policy of continual product improvement, we reserve the right to make changes at any time without notice.

Depending on specifications, the vehicle shown in the illustrations may differ from your vehicle in terms of color and equipment.

Accessories, spare parts and modification of your Lexus

A wide variety of non-genuine spare parts and accessories for Lexus vehicles are currently available in the market. Using these spare parts and accessories which are not genuine Lexus produces may adversely affect the safety of your vehicle, even though these parts may be approved by certain authorities in your country. Toyota Motor Corporation therefore cannot accept any liability or guarantee spare parts and accessories which are not genuine Lexus products, nor for replacement or installation involving such parts.

This vehicle should not be modified with non-genuine Lexus products. Modification with non-genuine Lexus products could affect its performance, safety or durability, and may even violate governmental regulations. In addition, damage or performance problems resulting from the modification may not be covered under warranty.

Installation of an RF-transmitter system

NOT FOR REPRODUCTION

The installation of an RF-transmitter system in your vehicle could affect electronic systems such as:

● Multiport fuel injection system/sequential multiport fuel injection system

● Dynamic radar cruise control system

● Cruise control system

● Anti-lock brake system

● SRS airbag system

● Seat belt pretensioner system

Be sure to check with your Lexus dealer for precautionary measures or special instructions regarding installation of an RF-transmitter system.

Further information regarding frequency bands, power levels, antenna positions and installation provisions for the installation of RF-transmitters, is available on request at your Lexus dealer.

Hybrid vehicles: High voltage parts and cables on the hybrid vehicles emit approximately the same amount of electromagnetic waves as the conventional gasoline powered vehicles or home electronic appliances despite of their electromagnetic shielding.

Hybrid vehicles: Unwanted noise may occur in the reception of the radio frequency transmitter (RF-transmitter).

NOT FOR REPRODUCTION

Vehicle data recordings

Your Lexus is equipped with several sophisticated computers that will record certain data, such as:

• Engine speed

• Electric motor speed (traction motor speed) (hybrid vehicles)

• Accelerator status

•Brake status

• Vehicle speed

•Shift position

• Hybrid battery (traction battery) status (hybrid vehicles) The recorded data varies according to the vehicle grade level and options with which it is equipped. Furthermore, these computers do not record conversations, sounds or pictures.

● Data usage

Lexus may use the data recorded in these computers to diagnose malfunctions, conduct research and development, and improve quality.

Lexus will not disclose the recorded data to a third party except:

• With the consent of the vehicle owner or with the consent of the lessee if the

vehicle is leased

• In response to an official request by the police, a court of law or a government

agency

• For use by Lexus in a lawsuit

• For research purposes where the data is not tied to a specific vehicle or vehicle

owner

Event data recorder

NOT FOR REPRODUCTION

This vehicle is equipped with an event data recorder (EDR). The main purpose of an EDR is to record, in certain crash or near crash-like situations, such as an airbag deployment or hitting a road obstacle, data that will assist in understanding how a vehicle’s systems performed. The EDR is designed to record data related to vehicle dynamics and safety systems for a short period of time, typically 30 seconds or less. However, data may not be recorded depending on the severity and type of a crash.

The EDR in this vehicle is designed to record such data as:

• How various systems in your vehicle were operating;

• How far (if at all) the driver was depressing the accelerator and/or brake pedal;

and,

• How fast the vehicle was traveling.

These data can help provide a better understanding of the circumstances in which crashes and injuries occur.

NOTE: EDR data are recorded by your vehicle only if a nontrivial crash situation occurs; no data are recorded by the EDR under normal driving conditions and no personal data (e.g., name, gender, age, and crash location) are recorded. However, other parties, such as law enforcement, could combine the EDR data with the type of personally identifying data routinely acquired during a crash investigation. To read data recorded by an EDR, special equipment is required, and access to the vehicle or the EDR is needed. In addition to the vehicle manufacturer, other parties, such as law enforcement, that have the special equipment, can read the information if they have access to the vehicle or the EDR.

● Disclosure of the EDR data

Lexus will not disclose the data recorded in an EDR to a third party except when:

• An agreement from the vehicle’s owner (or the lessee for a leased vehicle) is

obtained

• In response to an official request by the police, a court of law or a government

agency

• For use by Lexus in a lawsuit

However, if necessary, Lexus may:

• Use the data for research on vehicle safety performance

• Disclose the data to a third party for research purposes without disclosing infor-

mation about the specific vehicle or vehicle owner

NOT FOR REPRODUCTION

Scrapping of your Lexus

The SRS airbag and seat belt pretensioner devices in your Lexus contain explosive chemicals. If the vehicle is scrapped with the airbags and seat belt pretensioners left as they are, this may cause an accident such as fire. Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Lexus dealer before you scrap your vehicle.

CAUTIO N

■ General precautions while driving

Driving under the influence: Never drive your vehicle when under the influence of alcohol or drugs that have impaired your ability to operate your vehicle. Alcohol and certain drugs delay reaction time, impair judgment and reduce coordination, which could lead to an accident that could result in death or serious injury.

Defensive driving: Always drive defensively. Anticipate mistakes that other drivers or pedestrians might make and be ready to avoid accidents.

Driver distraction: Always give your full attention to driving. Anything that distracts the driver, such as adjusting controls, talking on a cellular phone or reading can result in a collision with resulting death or serious injury to you, your occupants or others.

■ General precaution regarding children’s safety

Never leave children unattended in the vehicle, and never allow children to have or use the key.

Children may be able to start the vehicle or shift the vehicle into neutral. There is also a danger that children may injure themselves by playing with the windows, the moon roof, or other features of the vehicle. In addition, heat build-up or extremely cold temperatures inside the vehicle can be fatal to children.

NOT FOR REPRODUCTION

Reading this manual

CAUTION: Explains something that, if not obeyed, could cause death or serious injury to people.

NOTICE: Explains something that, if not obeyed, could cause damage to or a malfunction in the vehicle or its equipment.

Indicates operating or working procedures. Follow the steps in numerical order.

Indicates the action (pushing, turning, etc.) used to operate switches and other devices.

Indicates the outcome of an operation (e.g. a lid opens).

Indicates the component or position being explained.

Means “Do not”, “Do not do this”, or “Do not let this happen”.

■ Different writing styles for gasoline and hybrid vehicles

Information for hybrid vehicles is written in brackets next to the information for gasoline vehicles

Example Turn the “START STOP ENGINE”*1 <“POWER”>*2 switch to IGNI-

TION ON*1 <ON>*2 mode.

:Hybrid vehicles*1: Gasoline vehicles

How to search

NOT FOR REPRODUCTION

■ Searching by name

• Alphabetical index..........P. 528

■ Searching by installation posi-

tion

• Pictorial index ........................P. 16

■ Searching by symptom or sound

• What to do if...

(Troubleshooting)............ P. 522

■ Searching by title

• Table of contents.................... P. 2

NOT FOR REPRODUCTION

Pictorial index

■Exterior

Doors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 131

Locking/unlocking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 116, 128

Opening/closing the door glasses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 162

Locking/unlocking by using the mechanical key . . . . . . . . . . . . . . . . . . . . P. 473

Warning lights/warning messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 432, 441

Trunk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 136

Opening from inside. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 136

Opening from outside . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 116, 128

Opening by using the mechanical key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 474

Warning lights/warning messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 432, 442

Outside rear view mirrors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 159

Adjusting the mirror angle. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 159

Folding the mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 159

Defogging the mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 298

Pictorial index

NOT FOR REPRODUCTION

Windshield wipers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 216

Precautions against winter season . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 287

Precautions against car wash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 336

Fuel filler door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 221

Refueling method. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 221

Fuel type/fuel tank capacity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 496

Tires. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 371

Tire size/inflation pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 505

Winter tires/tire chain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 287

Checking/rotation/tire pressure warning system. . . . . . . . . . . . . . . . . . . . .P. 371

Coping with flat tires. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 459

Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 347

Opening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 347

Engine compartment cover. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 353

Engine oil. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 49 7

Coping with overheat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 484, 487

Warning messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 441

Light bulbs of the exterior lights for driving

(Replacing method: P. 400, Watts: P. 506)

Headlights/front position lights/daytime running lights . . . . . . . . . . . . .P. 212

Fog lights. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 215

Turn signal lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 209

Tail lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 212

Stop/tail lights

Emergency brake signal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 259

Hill-start assist control

License plate lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 212

Back-up lights

Shifting the shift lever to R . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 202, 205

*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 265

*: Hybrid vehicles

NOT FOR REPRODUCTION

Pictorial index

■Instrument panel

“START STOP ENGINE” <“POWER”> switch . . . . . . . . . . . . . . . . P. 185, 192

Starting the engine <hybrid system>/changing the modes . . . . . . .P. 185, 192

Emergency stop of the engine <hybrid system> . . . . . . . . . . . . . . . . . . . . . .P. 419

When the engine <hybrid system> will not start . . . . . . . . . . . . . . . P. 468, 470

Warning messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 450

Shift lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 202, 205

Changing the shift position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 202, 205

Precautions against towing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 421

When the shift lever does not move. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 472

Meters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 91

Reading the meters/adjusting the instrument panel light . . . . . . . . . . . . . . P. 91

Warning lights/indicator lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 86

When the warning lights come on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 429

Pictorial index

NOT FOR REPRODUCTION

Multi-information display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 95

Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 95

When the warning messages are displayed. . . . . . . . . . . . . . . . . . . . . . . . . P. 437

Parking brake. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 210

Applying/releasing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 210

Precautions against winter season . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 288

Warning buzzer/message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 437

Turn signal lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 209

Headlight switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 212

Headlights/front position lights/tail lights/daytime running lights. . . . .P. 212

Fog lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 215

Windshield wiper and washer switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 216

Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 216

Adding washer fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 365

Warning messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 448

Emergency flasher switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 418

Fuel filler door opener. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 223

Refueling method. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 221

Fuel type/fuel tank capacity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 496

Trunk opener . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 136

Hood lock release lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 347

Tilt and telescopic steering control switch

Tilt and telescopic steering lock release lever

Air conditioning system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 294

Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 294

Rear window and outside rear view mirror defoggers. . . . . . . . . . . . . . .P. 298

Audio system

. . . . . . . . . . . . . . . . . . . . . . . . P. 155

. . . . . . . . . . . . . . . . . . . . P. 155

: If equipped

: Refer to “Navigation System Owner’s Manual”.

NOT FOR REPRODUCTION

■Switches

Pictorial index

Instrument panel light control switches. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 92

Odometer/trip meter and trip meter reset button . . . . . . . . . . . . . . . . . . .P. 92

Outside rear view mirror switches. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 159

Headlight cleaner switch

Manual headlight leveling dial

BSM (Blind Spot Monitor) main switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 274

Lexus parking assist-sensor switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 244

Tire pressure warning reset switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 372

* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 220

*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 213

Pictorial index

NOT FOR REPRODUCTION

Driving position memory switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 145

Power window switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 162

Door lock switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 131

Window lock switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 162

Trunk opener main switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 137

PCS OFF switch

* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 268

*: If equipped

NOT FOR REPRODUCTION

Pictorial index

Audio remote control switches*

Back switch*

Ta l k sw i t c h *

Telephone switches*

“DISP” button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 96

Vehicle-to-vehicle distance button

Cruise control switch

Dynamic radar cruise control switch

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 226

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 233

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 230

Pictorial index

NOT FOR REPRODUCTION

Seat heater switches*2/seat heater and ventilator switches*2. . . . P. 308

Rear sunshade switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 326

Driving mode select switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 256

EV drive mode switch

VSC OFF switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 260

Remote Touch

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 199

: Refer to “Navigation System Owner’s Manual”.

: If equipped

: Hybrid vehicles

NOT FOR REPRODUCTION

■Interior

Pictorial index

SRS airbags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 37

Floor mats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 28

Front seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 143

Head restraints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 151

Seat belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 32

Console box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 3 1 7

Inside lock buttons. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 131

Cup holders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 3 18

Pictorial index

NOT FOR REPRODUCTION

Inside rear view mirror . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 157

Sun visors

Vanity mirrors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 322

Interior light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 312

Personal lights

Moon roof switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 165

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 322

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 312

: NEVER use a rearward facing child

restraint on a seat protected by an ACTIVE AIRBAG in front of it, DEATH or SERIOUS INJURY to the CHILD can occur. (→P. 66)

: The illustration shows the front, but they are also equipped in the rear.

NOT FOR REPRODUCTION

Pictorial index

NOT FOR REPRODUCTION

For safety and security

1-1. For safe use

Before driving.................................28

For safety drive...............................30

Seat belts..........................................32

SRS airbags......................................37

Safety information

for children...................................48

Child restraint systems...............49

Installing child restraints............. 57

Exhaust gas precautions............68

1-2. Hybrid system

Hybrid system features

(hybrid vehicles).........................69

Hybrid system precautions

(hybrid vehicles)..........................73

1-3. Theft deterrent system

Engine immobilizer system

(gasoline vehicles)..................... 79

Immobilizer system

(hybrid vehicles).........................80

Alarm.................................................. 81

NOT FOR REPRODUCTION

1-1. For safe use

Before driving

Floor mat

Use only floor mats designed specifically for vehicles of the same model and model year as your vehicle. Fix them securely in place onto the carpet.

Insert the retaining hooks (clips) into the floor mat eyelets.

Turn the upper knob of each retaining hook (clip) to secure the floor mats in place.

*: Always align the marks.

The shape of the retaining hooks (clips) may differ from that shown in the illustration.

1-1. For safe use

NOT FOR REPRODUCTION

CAUTIO N

Observe the following precautions. Failure to do so may cause the driver’s floor mat to slip, possibly interfering with the pedals while driving. An unexpectedly high speed may result or it may become difficult to stop the vehicle. This could lead to an accident, resulting in death or serious injury.

■ When installing the driver’s floor mat

● Do not use floor mats designed for other models or different model year vehicles,

even if they are Lexus Genuine floor mats.

● Only use floor mats designed for the driver’s seat.

● Always install the floor mat securely using the retaining hooks (clips) provided.

● Do not use two or more floor mats on top of each other.

● Do not place the floor mat bottom-side up or upside-down.

■ Before driving

● Check that the floor mat is securely fixed in

the correct place with all the provided retaining hooks (clips). Be especially careful to perform this check after cleaning the floor.

● With the engine <hybrid system> stopped

and the shift lever in P, fully depress each pedal to the floor to make sure it does not interfere with the floor mat.

For safety and security

NOT FOR REPRODUCTION

1-1. For safe use

For safety drive

For safe driving, adjust the seat and mirror to an appropriate position before driving.

Correct driving posture

Adjust the angle of the seatback

so that you are sitting straight up and so that you do not have to lean forward to steer. (→P. 143)

Adjust the seat so that you can

depress the pedals fully and so that your arms bend slightly at the elbow when gripping the steering wheel. (→P. 143)

Lock the head restraint in place with the center of the head restraint

closest to the top of your ears. (→P. 15 1) Wear the seat belt correctly. (→P. 32)

Correct use of the seat belts

Make sure that all occupants are wearing their seat belts before driving the vehicle. (→P. 32) Use a child restraint system appropriate for the child until the child becomes large enough to properly wear the vehicle’s seat belt. (→P. 49 )

1-1. For safe use

NOT FOR REPRODUCTION

Adjusting the mirrors

Make sure that you can see backward clearly by adjusting the inside and outside rear view mirrors properly. (→P. 157, 159)

CAUTIO N

Observe the following precautions. Failure to do so may result in death or serious injury.

● Do not adjust the position of the driver’s seat while driving.

Doing so could cause the driver to lose control of the vehicle.

● Do not place a cushion between the driver or passenger and the seatback.

A cushion may prevent correct posture from being achieved, and reduce the effectiveness of the seat belt and head restraint.

● Do not place anything under the front seats.

Objects placed under the front seats may become jammed in the seat tracks and stop the seat from locking in place. This may lead to an accident and the adjustment mechanism may also be damaged.

● When driving over long distances, take regular breaks before you start to feel

tired. Also, if you feel tired or sleepy while driving, do not force yourself to continue driving and take a break immediately.

For safety and security

NOT FOR REPRODUCTION

1-1. For safe use

Seat belts

Make sure that all occupants are wearing their seat belts before driving the vehicle.

Correct use of the seat belts

● Extend the shoulder belt so that it

comes fully over the shoulder, but does not come into contact with the neck or slide off the shoulder.

● Position the lap belt as low as

possible over the hips.

● Adjust the position of the seat-

back. Sit up straight and well back in the seat.

● Do not twist the seat belt.

Fastening and releasing the seat belt

To fasten the seat belt, push the

plate into the buckle until a click sound is heard.

To release the seat belt, press the

release button.

Release button

1-1. For safe use

NOT FOR REPRODUCTION

Adjusting the seat belt shoulder anchor height (front seats)

Push the seat belt shoulder

anchor down while pressing the release button.

Push the seat belt shoulder

anchor up.

Move the height adjuster up and down as needed until you hear a click.

Seat belt pretensioners (front and outboard rear seats)

The pretensioners help the seat belts to quickly restrain the occupants by retracting the seat belts when the vehicle is subjected to certain types of severe frontal collision.

For safety and security

The pretensioners do not activate in the event of a minor frontal impact, a side impact, a rear impact or a vehicle rollover.

Pre-crash seat belts (front seats of vehicles with pre-crash safety system)

If the system determines that a collision is unavoidable, the front seat belts will retract before the collision. (→P. 267 )

NOT FOR REPRODUCTION

■ Emergency locking retractor (ELR)

■ Child seat belt usage

■ Replacing the belt after the pretensioner has been activated

■ Seat belt regulations

1-1. For safe use

The retractor will lock the belt during a sudden stop or on impact. It may also lock if you lean forward too quickly. A slow, easy motion will allow the belt to extend so that you can move around fully.

The seat belts of your vehicle were principally designed for persons of adult size.

● Use a child restraint system appropriate for the child, until the child becomes large

enough to properly wear the vehicle’s seat belt. (→P. 4 9)

● When the child becomes large enough to properly wear the vehicle’s seat belt, fol-

low the instructions regarding seat belt usage. (→P. 32 )

If the vehicle is involved in multiple collisions, the pretensioner will activate for the first collision, but will not activate for the second or subsequent collisions.

If seat belt regulations exist in the country where you reside, please contact your Lexus dealer for seat belt replacement or installation.

1-1. For safe use

NOT FOR REPRODUCTION

CAUTIO N

Observe the following precautions to reduce the risk of injury in the event of sudden braking, sudden swerving or an accident. Failure to do so may cause death or serious injury.

■ Wearing a seat belt

● Ensure that all passengers wear a seat belt.

● Always wear a seat belt properly.

● Each seat belt should be used by one person only. Do not use a seat belt for more

than one person at once, including children.

● Lexus recommends that children be seated in the rear seat and always use a seat

belt and/or an appropriate child restraint system.

● To achieve a proper seating position, do not recline the seat more than necessary.

The seat belt is most effective when the occupants are sitting up straight and well back in the seats.

● Do not wear the shoulder belt under your arm.

● Always wear your seat belt low and snug across your hips.

■ Pregnant women

Obtain medical advice and wear the seat belt in the proper way. (→P. 32 )

Women who are pregnant should position the lap belt as low as possible over the hips in the same manner as other occupants, extending the shoulder belt completely over the shoulder and avoiding belt contact with the rounding of the abdominal area.

If the seat belt is not worn properly, not only the pregnant woman, but also the fetus could suffer death or serious injury as a result of sudden braking or a collision.

For safety and security

NOT FOR REPRODUCTION

1-1. For safe use

CAUTIO N

■ People suffering illness

Obtain medical advice and wear the seat belt in the proper way. (→P. 32 )

■ When children are in the vehicle

Do not allow children to play with the seat belt. If the seat belt becomes twisted around a child’s neck, it may lead to choking or other serious injuries that could result in death. If this occurs and the buckle cannot be unfastened, scissors should be used to cut the belt.

■ Seat belt pretensioners

If the pretensioner has activated, the SRS warning light will come on. In that case, the seat belt cannot be used again and must be replaced at your Lexus dealer.

■ Adjustable shoulder anchor

Always make sure the shoulder belt is positioned across the center of your shoulder. The belt should be kept away from your neck, but not falling off your shoulder. Failure to do so could reduce the amount of protection in an accident and cause death or serious injuries in the event of a sudden stop, sudden swerve or accident. (→P. 33 )

■ Seat belt damage and wear

● Do not damage the seat belts by allowing the belt, plate, or buckle to be jammed

in the door.

● Inspect the seat belt system periodically. Check for cuts, fraying, and loose parts.

Do not use a damaged seat belt until it is replaced. Damaged seat belts cannot protect an occupant from death or serious injury.

● Ensure that the belt and plate are locked and the belt is not twisted.

If the seat belt does not function correctly, immediately contact your Lexus dealer.

● Replace the seat assembly, including the belts, if your vehicle has been involved in

a serious accident, even if there is no obvious damage.

● Do not attempt to install, remove, modify, disassemble or dispose of the seat belts.

Have any necessary repairs carried out by your Lexus dealer. Inappropriate handling may lead to incorrect operation.

1-1. For safe use

NOT FOR REPRODUCTION

SRS airbags

The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury.

For safety and security

◆ SRS front airbags

SRS driver airbag/front passenger airbag

Can help protect the head and chest of the driver and front passenger from impact with interior components

SRS knee airbags

Can help provide driver and front passenger protection

NOT FOR REPRODUCTION

1-1. For safe use

◆ SRS side and curtain shield airbags

SRS front side airbags

Can help protect the torso of the front seat occupants

SRS rear side airbags Can help protect the torso of occupants in the rear outer seats

SRS curtain shield airbags

Can help protect primarily the head of occupants in the outer seats

SRS airbag system components

NOT FOR REPRODUCTION

1-1. For safe use

For safety and security

Knee airbags

Front passenger airbag

Curtain shield airbags

Seat belt pretensioners and

force limiters

Side impact sensors (front)

Front side airbags

SRS warning light

Driver airbag

Rear side airbags

Side impact sensors (rear)

Driver’s seat belt buckle switch

Airbag sensor assembly

Front impact sensors

The main SRS airbag system components are shown above. The SRS airbag system is controlled by the airbag sensor assembly. As the airbags deploy, a chemical reaction in the inflators quickly fills the airbags with non-toxic gas to help restrain the motion of the occupants.

NOT FOR REPRODUCTION

1-1. For safe use

CAUTIO N

■ SRS airbag precautions

Observe the following precautions regarding the SRS airbags. Failure to do so may cause death or serious injury.

● The driver and all passengers in the vehicle must wear their seat belts properly.

The SRS airbags are supplemental devices to be used with the seat belts.

● The SRS driver airbag deploys with considerable force, and can cause death or

serious injury especially if the driver is very close to the airbag.

Since the risk zone for the driver’s airbag is the first 50 - 75 mm (2 - 3 in.) of inflation, placing yourself 250 mm (10 in.) from your driver airbag provides you with a clear margin of safety. This distance is measured from the center of the steering wheel to your breastbone. If you sit less than 250 mm (10 in.) away now, you can change your driving position in several ways:

• Move your seat to the rear as far as you can while still reaching the pedals comfortably.

• Slightly recline the back of the seat. Although vehicle designs vary, many drivers can achieve the 250 mm (10 in.) distance, even with the driver seat all the way forward, simply by reclining the back of the seat somewhat. If reclining the back of your seat makes it hard to see the road, raise yourself by using a firm, non-slippery cushion, or raise the seat if your vehicle has that feature.

• If your steering wheel is adjustable, tilt it downward. This points the airbag toward your chest instead of your head and neck.

The seat should be adjusted as recommended above, while still maintaining control of the foot pedals, steering wheel, and your view of the instrument panel controls.

1-1. For safe use

NOT FOR REPRODUCTION

CAUTIO N

■ SRS airbag precautions

● The SRS front passenger airbag also deploys with considerable force, and can

cause death or serious injury especially if the front passenger is very close to the airbag. The front passenger seat should be as far from the airbag as possible with the seatback adjusted, so the front passenger sits upright.

● Improperly seated and/or restrained infants and children can be killed or seri-

ously injured by a deploying airbag. An infant or child who is too small to use a seat belt should be properly secured using a child restraint system. Lexus strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are safer for infants and children than the front passenger seat. (→P. 49 )

● Do not sit on the edge of the seat or lean

against the dashboard.

● Do not allow a child to stand in front of the

SRS front passenger airbag unit or sit on the knees of a front passenger.

● Do not allow the front seat occupants to

hold items on their knees.

For safety and security

● Do not lean against the door, the roof side

rail or the front, side and rear pillars.

NOT FOR REPRODUCTION

1-1. For safe use

CAUTIO N

■ SRS airbag precautions

● Do not allow anyone to kneel on the pas-

senger seats toward the door or put their head or hands outside the vehicle.

● Do not attach anything to or lean anything

against areas such as the dashboard, steering wheel pad, lower portion of the instrument panel and door of the glove box. These items can become projectiles when the SRS driver, front passenger and knee airbags deploy.

● Do not attach anything to areas such as a

door, windshield glass, side door glass, front or rear pillar, roof side rail and assist grip.

● Do not hang coat hangers or hard objects on the coat hooks. All of these items

could become projectiles and may cause death or serious injury, should the SRS curtain shield airbags deploy.

● If a vinyl cover is put on the area where the SRS knee airbag will deploy, be sure to

remove it.

1-1. For safe use

NOT FOR REPRODUCTION

CAUTIO N

■ SRS airbag precautions

● Do not use seat accessories which cover the parts where the SRS side airbags

inflate as they may interfere with inflation of the airbags. Such accessories may prevent the side airbags from activating correctly, disable the system or cause the side airbags to inflate accidentally, resulting in death or serious injury.

● Do not strike or apply significant levels of force to the area of the SRS airbag

components. Doing so can cause the SRS airbags to malfunction.

● Do not touch any of the component parts immediately after the SRS airbags have

deployed (inflated) as they may be hot.

● If breathing becomes difficult after the SRS airbags have deployed, open a door

or window to allow fresh air in, or leave the vehicle if it is safe to do so. Wash off any residue as soon as possible to prevent skin irritation.

● If the areas where the SRS airbags are stored, such as the steering wheel pad and

front and rear pillar garnishes are damaged or cracked, have them replaced by your Lexus dealer.

■ Modification and disposal of SRS airbag system components

Do not dispose of your vehicle or perform any of the following modifications without consulting your Lexus dealer. The SRS airbags may malfunction or deploy (inflate) accidentally, causing death or serious injury.

● Installation, removal, disassembly and repair of the SRS airbags

● Repairs, modifications, removal or replacement of the steering wheel, instrument

panel, dashboard, glove box, seats or seat upholstery, front, side and rear pillars or roof side rails

● Repairs or modifications of the front fender, front bumper, or side of the occupant

compartment

● Installation of a grille guard (bull bars, kangaroo bar, etc.), snow plows or winches

● Modifications to the vehicle’s suspension system

● Installation of electronic devices such as mobile two-way radios (RF-transmitter)

and CD players

● Modifications to your vehicle for a person with a physical disability

For safety and security

NOT FOR REPRODUCTION

■ If the SRS airbags deploy (inflate)

■ SRS airbag deployment conditions (SRS front airbags)

■ SRS airbag deployment conditions (SRS side and curtain shield airbags)

1-1. For safe use

● Bruising and slight abrasions may result from contact with a deploying (inflating)

SRS airbag.

● A loud noise and white powder will be emitted.

● Parts of the airbag module (steering wheel hub, airbag cover and inflator) as well as

the seats, parts of the front and rear pillars, and roof side rails may be hot for several minutes. The airbag itself may also be hot.

● The windshield may crack.

● The SRS front airbags will deploy in the event of an impact that exceeds the set

threshold level (the level of force corresponding to an approximately 20 - 30 km/h [12 - 18 mph] frontal collision with a fixed wall that does not move or deform).

However, this threshold velocity will be considerably higher in the following situations:

• If the vehicle strikes an object, such as a parked vehicle or sign pole, which can move or deform on impact

• If the vehicle is involved in an underride collision, such as a collision in which the front of the vehicle “underrides”, or goes under, the bed of a truck

● Depending on the type of collision, it is possible that only the seat belt pretension-

ers will activate.

● The SRS side and curtain shield airbags will deploy in the event of an impact that

exceeds the set threshold level (the level of force corresponding to the impact force produced by an approximately 1500 kg [3300 lb.] vehicle colliding with the vehicle cabin from a direction perpendicular to the vehicle orientation at an approximate speed of 20 - 30 km/h [12 - 18 mph]).

● The SRS curtain shield airbags may also deploy in the event of a severe frontal colli-

sion.

1-1. For safe use

NOT FOR REPRODUCTION

■ Conditions under w hich the SRS airbags may deploy (inflate), other than a c ollision

The SRS front airbags and SRS curtain shield airbag may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration.

● Hitting a curb, edge of pavement or hard

surface

● Falling into or jumping over a deep hole

● Landing hard or falling

■ Types of collisions that may not deploy the SRS airbags (SRS front airbags)

The SRS front airbags do not generally inflate if the vehicle is involved in a side or rear collision, if it rolls over, or if it is involved in a low-speed frontal collision. But, whenever a collision of any type causes sufficient forward deceleration of the vehicle, deployment of the SRS front airbags may occur.

● Collision from the side

● Collision from the rear

● Vehicle rollover

For safety and security

NOT FOR REPRODUCTION

■ Types of collisions that may not deploy the SRS airbags (SRS side and curtain shield

1-1. For safe use

airbags)

The SRS side and curtain shield airbags may not activate if the vehicle is subjected to a collision from the side at certain angles, or a collision to the side of the vehicle body other than the passenger compartment.

● Collision from the side to the vehicle body

other than the passenger compartment

● Collision from the side at an angle

The SRS side airbags do not generally inflate if the vehicle is involved in a frontal or rear collision, if it rolls over, or if it is involved in a low-speed side collision.

● Collision from the front

● Collision from the rear

● Vehicle rollover

The SRS curtain shield airbags do not generally inflate if the vehicle is involved in a rear collision, if it rolls over, or if it is involved in a low-speed side or low-speed frontal collision.

● Collision from the rear

● Vehicle rollover

1-1. For safe use

NOT FOR REPRODUCTION

■ When to contact your Lexus dealer

In the following cases, the vehicle will require inspection and/or repair. Contact your Lexus dealer as soon as possible.

● Any of the SRS airbags have been inflated.

● The front of the vehicle is damaged or

deformed, or was involved in an accident that was not severe enough to cause the SRS front airbags to inflate.

● A portion of a door is damaged or

deformed, or the vehicle was involved in an accident that was not severe enough to cause the SRS side and curtain shield airbags to inflate.

● The pad section of the steering wheel, dash-

board near the front passenger airbag or lower portion of the instrument panel is scratched, cracked, or otherwise damaged.

For safety and security

● The surface of the seats with the side airbag

is scratched, cracked, or otherwise damaged.

● The portion of the front pillars, rear pillars or

roof side rail garnishes (padding) containing the curtain shield airbags inside is scratched, cracked, or otherwise damaged.

NOT FOR REPRODUCTION

1-1. For safe use

Safety information for children

Observe the following precautions when children are in the vehicle. Use a child restraint system appropriate for the child, until the child becomes large enough to properly wear the vehicle’s seat belt.

● It is recommended that children sit in the rear seats to avoid accidental

contact with the shift lever, wiper switch etc.

● Use the rear door child-protector lock or the window lock switch to

avoid children opening the door while driving or operating the power window accidentally. (→P. 132, 162)

● Do not let small children operate equipment which may catch or pinch

body parts, such as the power window, hood, trunk, seats etc.

CAUTIO N

Never leave children unattended in the vehicle, and never allow children to have or use the key.

Children may be able to start the vehicle or shift the vehicle into neutral. There is also a danger that children may injure themselves by playing with the windows, the moon roof or other features of the vehicle. In addition, heat build-up or extremely cold temperatures inside the vehicle can be fatal to children.

Child restraint systems

NOT FOR REPRODUCTION

Lexus strongly urges the use of child restraint systems.

1-1. For safe use

Points to remember

Studies have shown that installing a child restraint on a rear seat is much safer than installing one on the front passenger seat.

● Choose a child restraint system that suits your vehicle and is appropri-

ate to the age and size of the child.

● For installation details, follow the instructions provided with the child

restraint system. General installation instructions are provided in this manual. (→P. 57 )

● If child restraint system regulations exist in the country where you

reside, please contact your Lexus dealer for the child restraint system installation.

● Lexus recommends that you use a child restraint system which con-

forms to the regulation ECE No.44.

For safety and security

NOT FOR REPRODUCTION

1-1. For safe use

Types of child restraints

Child restraint systems are classified into the following 5 groups according to the regulation ECE No.44:

Group 0: Up to 10 kg (22 lb.) (0 - 9 months)

Group 0+: Up to 13 kg (28 lb.) (0 - 2 years)

Group I: 9 to 18 kg (20 to 39 lb.) (9 months - 4 years)

Group II: 15 to 25 kg (34 to 55 lb.) (4 years - 7 years)

Group III: 22 to 36 kg (49 to 79 lb.) (6 years - 12 years)

In this owner’s manual, the following 3 types of popular child restraint systems that can be secured with the seat belts are explained:

X Baby seat (infant seat) X Child seat (convertible seat)

Equal to Group 0 and 0+ of ECE No.44

X Junior seat (booster seat)

Equal to Group II and III of ECE No.44

Equal to Group 0+ and I of ECE No.44

1-1. For safe use

NOT FOR REPRODUCTION

Child restraint system suitability for various seating positions

Information provided in the table shows your child restraint system suitability for various seating positions.

Seating position

Mass groups

0 Up to 10 kg (22 lb.) (0 - 9 months)

0+ Up to 13 kg (28 lb.) (0 - 2 years)

I 9 to 18 kg (20 to 39 lb.) (9 months - 4 years)

II, III 15 to 36 kg (34 to 79 lb.) (4 - 12 years)

Front passenger

seat

Never put

Rear-

facing — X

Never put

For ward -

facing — UF

* UU

Rear seat

Outboard Center

For safety and security

NOT FOR REPRODUCTION

1-1. For safe use

Key of letters inserted in the above table:

U: Suitable for “universal” category child restraint system approved for

the use in this mass group.

UF: Suitable for forward-facing “universal” category child restraint sys-

tem approved for the use in this mass group.

L: Suitable for “LEXUS G0+, BABY SAFE PLUS with SEAT BELT FIX-

ATION, BASE PLATFORM” approved for the use in this mass group.

X: Not suitable seat position for children in this mass group.

NOTE:

*: When you use a child restraint system in this position, move the seatback to the

most upright position and the seat cushion to the highest position.

If the head restraint interferes with your child restraint system, and the head restraint can be removed, remove the head restraint.

The child restraint system mentioned in the table may not be available outside of the EU area.

Other child restraint system which is different from the system mentioned in the table can be used, but the suitability of the systems must be carefully checked with the child restraint system manufacturer concerned and the seller of those seats.

1-1. For safe use

NOT FOR REPRODUCTION

Child restraint system suitability for various seating positions (with ISOFIX rigid anchors)

Information provided in the table shows your child restraint system suitability for various seating positions.

Mass groups Size class Fixture

FISO/L1 X

Carrycot

Group 0 Up to 10 kg (22 lb.)

Group 0+ Up to 13 kg (28 lb.)

Group I 9 to 18 kg (20 to 39 lb.)

GISO/L2 X

EISO/R1 X

DISO/R2 X

CISO/R3 X

DISO/R2 X

CISO/R3 X

BISO/F2 IUF

B1 ISO/F2X IUF*

AISO/F3 IUF*

Vehicle ISOFIX

positions

Rear outboard

(1) X

For safety and security

(1) X

Group II 15 to 25 kg (34 to 55 lb.)

Group III 22 to 36 kg (49 to 79 lb.)

(1) X

NOT FOR REPRODUCTION

1-1. For safe use

(1) For the child restraint system which do not carry the ISO/XX size

class identification (A to G), for the applicable mass group, the car manufacturer shall indicate the vehicle specific ISOFIX child restraint system(s) recommended for each position.

Key of letters inserted in the above table:

IUF: Suitable for ISOFIX forward-facing child restraint systems of univer-

sal category approved for use in this mass group.

X: ISOFIX position not suitable for ISOFIX child restraint systems in

this mass group and/or this size class.

*: Remove the head restraint if it interferes with your child restraint system. Do not

sit on rear center seat when child restraint system is installed to rear left seat.

The child restraint system mentioned in the table may not be available outside of the EU area.

Other child restraint systems different from the systems mentioned in the table can be used, but the suitability of the systems must be carefully checked with the child restraint system manufacturer and retailer.

■ When installing a child restraint system on the front passenger seat

When you have to use a child restraint system on the front passenger seat, adjust the following:

● The seatback to the most upright position

● The seat cushion to the highest position

● The seat cushion to the fully rearward posi-

tion

■ Selecting an appropriate child restraint system

● Use a child restraint system appropriate for the child until the child becomes large

enough to properly wear the vehicle’s seat belt.

● If the child is too large for a child restraint system, sit the child on a rear seat and use

the vehicle’s seat belt. (→P. 3 2)

1-1. For safe use

NOT FOR REPRODUCTION

CAUTIO N

■ Using a child restraint system

The use of a child restraint system not suitable for the vehicle may not properly secure the infant or child. It may result in death or serious injury (in the event of sudden braking or an accident).

■ Child restraint precautions

● For effective protection in automobile accidents and sudden stops, a child must

be properly restrained, using a seat belt or child restraint system depending on the age and size of the child. Holding a child in your arms is not a substitute for a child restraint system. In an accident, the child can be crushed against the windshield, or between you and the vehicle’s interior.

● Lexus strongly urges the use of a proper child restraint system that conforms to

the size of the child, installed on the rear seat. According to accident statistics, the child is safer when properly restrained in the rear seat than in the front seat.

● Never install a rear-facing child restraint system on the front passenger seat.

In the event of an accident, the force of the rapid inflation of the front passenger airbag can cause death or serious injury to the child if the rear-facing child restraint system is installed on the front passenger seat.

● A forward-facing child restraint system may be installed on the front passenger

seat only when it is unavoidable. A child restraint system that requires an upper anchorage strap should not be used in the front passenger seat since there is no anchor fitting for the front passenger seat. Adjust the seatback as upright as possible and always move the seat as far back as possible because the front passenger airbag could inflate with considerable speed and force. Otherwise, the child may be killed or seriously injured.

For safety and security

NOT FOR REPRODUCTION

1-1. For safe use

CAUTIO N

■ Child restraint precautions

● Do not allow the child to lean his/her head or any part of his/her body against the

door or the area of the seat, front and rear pillars or roof side rails from which the SRS side airbags or SRS curtain shield airbags deploy even if the child is seated in the child restraint system. It is dangerous if the SRS side airbags and curtain shield airbags inflate, and the impact could cause death or serious injury to the child.

● Make sure you have complied with all installation instructions provided by the

child restraint manufacturer and that the system is properly secured. If it is not secured properly, it may cause death or serious injury to the child in the event of a sudden stop, sudden swerve or accident.

■ When children are in the vehicle

■ When the child restraint system is not in use

● Keep the child restraint system properly secured on the seat even if it is not in use.

Do not store the child restraint system unsecured in the passenger compartment.

● If it is necessary to detach the child restraint system, remove it from the vehicle or

store it securely in the trunk. This will prevent it from injuring passengers in the event of a sudden stop, sudden swerve or accident.

1-1. For safe use

NOT FOR REPRODUCTION

Installing child restraints

Follow the child restraint system manufacturer’s instructions. Firmly secure child restraints to the seats using a seat belt or ISOFIX rigid anchors. Attach the upper anchorage strap when installing a child restraint.

Seat belts (An ELR belt requires a locking clip)

ISOFIX rigid anchors (ISOFIX child restraint system)

Lower anchors are provided for the outboard rear seats. (Buttons displaying the location of the anchors are attached to the seats.)

For safety and security

Child restraint anchor fitting

An anchor fitting is provided for each rear seat.

NOT FOR REPRODUCTION

1-1. For safe use

Installing child restraints using a seat belt

■ Rear-facing  Baby seat (infant seat)/child seat (convertible seat)

Lower the head restraint in place at the lowest position.

Place the child restraint system on the rear seat facing the rear of the vehicle.

Run the seat belt through the child restraint system and insert the plate into the buckle. Make sure that the belt is not twisted.

Install a locking clip near the tab of the lap and shoulder belt by inserting the lap and shoulder webbing through the recesses of the locking clip. Buckle the belt again. If the belt has any slack, release the buckle and reinstall the locking clip.

NOT FOR REPRODUCTION

Latch the attaching clip of the upper anchorage strap onto the anchor fitting. (→P. 64)

Make sure the seat belt is tightly secured, and that there is no slack in the belt.

1-1. For safe use

For safety and security

NOT FOR REPRODUCTION

1-1. For safe use

■ Forward-facing  Child seat (convertible seat)

Lower the head restraint in place at the lowest position.

Place the child restraint system on the seat facing the front of the vehicle.

Run the seat belt through the child restraint system and insert the plate into the buckle. Make sure that the belt is not twisted.

NOT FOR REPRODUCTION

Latch the attaching clip of the upper anchorage strap onto the anchor fitting. (→P. 64)

Make sure the seat belt is tightly secured, and that there is no slack in the belt.

1-1. For safe use

For safety and security

NOT FOR REPRODUCTION

1-1. For safe use

■ Junior seat (booster seat)

Place the child restraint system on the seat facing the front of the vehicle.

Sit the child in the child restraint system. Fit the seat belt to the child restraint system according to the manufacturer’s instructions and insert the plate into the buckle. Make sure that the belt is not twisted.

Check that the shoulder belt is correctly positioned over the child’s shoulder and that the lap belt is as low as possible. (→P. 3 2)

Removing a child restraint installed with a seat belt

Push the buckle release button and fully retract the seat belt.

1-1. For safe use

NOT FOR REPRODUCTION

Installation with ISOFIX rigid anchor

Lower the head restraint in place at the lowest position.

Widen the gap between the seat cushion and seatback slightly.

Latch the buckles onto the exclusive fixing bars.

If the child restraint system has an upper anchorage strap, the upper anchorage strap should be latched onto the anchor fitting.

For safety and security

NOT FOR REPRODUCTION

1-1. For safe use

Child restraint systems with an upper anchorage strap

Lower the head restraint in place at the lowest position.

Secure the child restraint system using the seat belt or ISOFIX rigid anchors.

Open the anchor fitting cover, latch the attaching clip onto the anchor fitting and tighten the upper anchorage strap.

Make sure the upper anchorage strap is securely latched.

Attaching clip

Upper anchorage strap

Anchor fitting

■ When installing a child restraint system on the front passenger seat or center rear

seat

You need a locking clip to install the child restraint system. Follow the instructions provided by the manufacturer of the system. If your child restraint system does not provide a locking clip, you can purchase the following item from your Lexus dealer:

Locking clip for child restraint system (Part No. 73119-22010)

Front of vehicle

1-1. For safe use

NOT FOR REPRODUCTION

CAUTIO N

■ When installing a child restraint system

Follow the directions given in the child restraint system installation manual and fix the child restraint system securely in place. If the child restraint system is not correctly fixed in place, the child or other passengers may be seriously injured or even killed in the event of sudden braking, sudden swerving or an accident.

● If the driver’s seat interferes with the child

restraint system and prevents it from being attached correctly, attach the child restraint system to the left-hand rear seat.

● Adjust the front passenger seat so that it

does not interfere with the child restraint system.

● Only put a forward-facing child restraint

system on the front seat when unavoidable.

When installing a forward-facing child restraint system on the front passenger seat, move the seat as far back as possible. Failure to do so may result in death or serious injury if the airbags deploy (inflate).

For safety and security

NOT FOR REPRODUCTION

1-1. For safe use

CAUTIO N

■ When installing a child restraint system

● Extreme Hazard! Do not use a rearward

facing child restraint on a seat protected by an airbag in front of it! This is because the force of the rapid inflation of the front passenger airbag can cause death or serious injury to the child.

● There is a label(s) on the passenger side

sun visor, indicating it is forbidden to attach a rear-facing child restraint system to the front passenger seat.

Details of the label(s) are shown in the illustration below.

1-1. For safe use

NOT FOR REPRODUCTION

CAUTIO N

■ When installing a child restraint system

● If child restraint system regulations exist in the country where you reside, please

contact your Lexus dealer for the child restraint system installation.

● When a junior (booster) seat is installed, always ensure that the shoulder belt is

positioned across the center of the child’s shoulder. The belt should be kept away from the child’s neck, but not so that it could fall off the child’s shoulder. Failing to do so may result in death or serious injury in the event of sudden braking, sudden swerving or an accident.

● Ensure that the belt and plate are securely locked and the seat belt is not twisted.

● Shake the child restraint system left and right, and forward and backward to

ensure that it has been securely installed.

● After securing a child restraint system, never adjust the seat.

● Follow all installation instructions provided by the child restraint system manufac-

turer.

● When using the left-hand rear seat for the

child restraint system, do not sit in the center rear seat.

Seat belt function may be impaired, such as being positioned overly high or loosefitting, which may result in death or serious injury in the event of sudden braking, sudden swerving or an accident.

For safety and security

■ To correctly attach a child restraint system to the anchors

When using the lower anchors, be sure that there are no foreign objects around the anchors and that the seat belt is not caught behind the child restraint system. Make sure the child restraint system is securely attached, or it may cause death or serious injury to the child or other passengers in the event of sudden braking, sudden swerving or an accident.

■ Using child restraint anchorages

WARNING: child restraint anchorages are designed to withstand only those loads imposed by correctly fitted child restraints. Under no circumstances are they to be used for adult seatbelts, harnesses, or for attaching other items or equipment to the vehicle.

NOT FOR REPRODUCTION

1-1. For safe use

Exhaust gas precautions

Harmful substance to the human body is included in exhaust gases if inhaled.

CAUTIO N

Exhaust gases include harmful carbon monoxide (CO), which is colorless and odorless. Observe the following precautions. Failure to do so may cause exhaust gases enter the vehicle and may lead to an accident caused by light-headedness, or may lead to death or a serious health hazard.

■ Important points while driving

● Keep the trunk lid closed.

● If you smell exhaust gases in the vehicle even when the trunk lid is closed, open

the windows and have the vehicle inspected at your Lexus dealer as soon as possible.

■ When parking

● If the vehicle is in a poorly ventilated area or a closed area, such as a garage, stop

the engine <hybrid system>.

● Do not leave the vehicle with the engine running <hybrid system operating> for a

long time. If such a situation cannot be avoided, park the vehicle in an open space and ensure that exhaust fumes do not enter the vehicle interior.

● Do not leave the engine running <hybrid system operating> in an area with snow

build-up, or where it is snowing. If snowbanks build up around the vehicle while the engine is running <hybrid system is operating>, exhaust gases may collect and enter the vehicle.

■ Exhaust pipe

The exhaust system needs to be checked periodically. If there is a hole or crack caused by corrosion, damage to a joint or abnormal exhaust noise, be sure to have the vehicle inspected and repaired by your Lexus dealer.

1-2. Hybrid system

NOT FOR REPRODUCTION

Hybrid system features (hybrid vehicles)

Your vehicle is a hybrid vehicle. It has characteristics different from conventional vehicles. Be sure you are closely familiar with the characteristics of your vehicle, and operate with care.

The hybrid system combines the use of a gasoline engine and an electric motor (traction motor) according to driving conditions, improving fuel efficiency and reducing exhaust emissions.

For safety and security

Gasoline engine

Electric motor (traction motor)

NOT FOR REPRODUCTION

1-2. Hybrid system

◆ When stopped/during start off

The gasoline engine stops when the vehicle is stopped. During start off, the electric motor (traction motor) drives the vehicle. At slow speeds or when traveling down a gentle slope, the engine is stopped and the electric motor (traction motor) is used.

◆ During normal driving

The gasoline engine is predominantly used. The electric motor (traction motor) charges the hybrid battery (traction battery) as necessary.

◆ When accelerating sharply

When the accelerator pedal is depressed heavily, the power of the hybrid battery (traction battery) is added to that of the gasoline engine via the electric motor (traction motor).

◆ When braking (regenerative braking)

The electric motor (traction motor) charges the hybrid battery (traction battery).

1-2. Hybrid system

NOT FOR REPRODUCTION

■ Regenerative braking

In the following situations, kinetic energy is converted to electric energy and deceleration force can be obtained in conjunction with the recharging of the hybrid battery (traction battery).

● The accelerator pedal is released while driving with the shift position in D or S.

● The brake pedal is depressed while driving with the shift position in D or S.

■ EV indicator

The EV indicator comes on when driving the vehicle using only the electric motor (traction motor).

■ Conditions in which the gasoline engine may not stop

The gasoline engine starts and stops automatically. However, it may not stop automatically in the following conditions:

● During gasoline engine warm-up

● During hybrid battery (traction battery) charging

● When the temperature of the hybrid battery (traction battery) is high or low

● When the heater is switched on

■ Charging the hybrid battery (traction battery)

● As the gasoline engine charges the hybrid battery (traction battery), the battery

does not need to be charged from an outside source. However, if the vehicle is left parked for a long time the hybrid battery will slowly discharge. For this reason, be sure to drive the vehicle at least once every few months for at least 30 minutes or 16 km (10 miles). If the hybrid battery becomes fully discharged and you are unable to jump-start the vehicle with the 12-volt battery, contact your Lexus dealer.

● If the shift lever is in N, the hybrid battery (traction battery) will not be charged.

Always put the shift lever in P when the vehicle is stopped. When driving in heavy traffic, operate the vehicle with the shift lever in D or S to avoid discharging the battery.

■ Charging the 12-volt battery

→P. 48 2

For safety and security

NOT FOR REPRODUCTION

■ After the 12-volt battery has discharged or has been changed or removed

■ Sounds and vibrations specific to a hybrid vehicle

■ Maintenance, repair, recycling, and disposal

■ Customization

1-2. Hybrid system

The gasoline engine may not stop even if the vehicle is running on the hybrid battery (traction battery). If this continues for a few days, contact your Lexus dealer.

There may be no engine sounds or vibration even though the vehicle is able to move. For safety, apply the parking brake and make sure to shift the shift position to P when parked.

The following sounds or vibrations may occur when the hybrid system is operating and are not a malfunction:

● Motor sounds may be heard from the engine compartment.

● Sounds may be heard from the hybrid battery (traction battery) behind the rear

seats when the hybrid system starts or stops.

● Sounds from the hybrid system may be heard when the trunk lid is open.

● Sounds may be heard from the hybrid transmission when the hybrid system starts

or stops.

● Engine sounds may be heard when accelerating sharply.

● Sounds may be heard due to regenerative braking when the brake pedal is

depressed.

● Vibration may be felt when the gasoline engine starts or stops.

● Cooling fan sounds may be heard from the air intake vent on the rear left seat.

Contact your Lexus dealer regarding maintenance, repair, recycling and disposal. Do not dispose of the vehicle yourself.

Settings (e.g. on/off operation of the EV indicator) can be changed. (Customizable features →P. 50 8 )

1-2. Hybrid system

NOT FOR REPRODUCTION

Hybrid system precautions (hybrid vehicles)

Take care when handling the hybrid system, as it contains a high voltage system (about 650V at maximum) as well as parts that become extremely hot when the hybrid system is operating. Obey the caution labels attached to the vehicle.

For safety and security

Air conditioning compressor

Power control unit with DC/DC

converter

High voltage cables (orange)

Hybrid battery (traction bat-

tery)

Service plug

Electric motor (traction motor)

Caution label

NOT FOR REPRODUCTION

1-2. Hybrid system

Hybrid battery (traction battery) air vent

There is an air intake vent beside the rear left seat for the purpose of cooling the hybrid battery (traction battery). If the vent becomes blocked, the hybrid battery may overheat, leading to a reduction in hybrid battery output.

Emergency shut off system

When a certain level of impact is detected by the impact sensor, the emergency shut off system blocks off the high voltage current and stops the fuel pump to minimize the risk of electrocution and fuel leakage. If the emergency shut off system activates, your vehicle will not restart. To restart the hybrid system, contact your Lexus dealer.

Hybrid warning message

A message is automatically displayed when a malfunction occurs in the hybrid system or an improper operation is attempted.

If a warning message is shown on the multi-information display, read the message and follow the instructions. (→P. 437 )

1-2. Hybrid system

NOT FOR REPRODUCTION

■ If a warning light comes on, a warning message is displayed, or the 12-volt battery is

disconnected

The hybrid system may not start. In that case, try to start the system again. If the “READY” indicator does not come on, contact your Lexus dealer.

■ Running out of fuel

When the vehicle has run out of fuel and the hybrid system cannot be started, refuel the vehicle with at least enough gasoline to make the low fuel level warning light (→P. 432) go off. If there is only a small amount of fuel, the hybrid system may not be able to start. (The minimum amount of fuel to add to make the low fuel level warning light go out is about 11.3 L [3.0 gal., 2.5 Imp.gal.], when the vehicle is on a level surface. This value may vary when the vehicle is on a slope.)

■ Electromagnetic waves

● High voltage parts and cables on the hybrid vehicles incorporate electromagnetic

shielding, and therefore emit approximately the same amount of electromagnetic waves as conventional gasoline powered vehicles or home electronic appliances.

● Your vehicle may cause sound interference in some third party-produced radio

parts.

■ Hybrid battery (traction battery)

The hybrid battery (traction battery) has a limited service life. The lifespan of the hybrid battery (traction battery) can change in accordance with driving style and driving conditions.

For safety and security

NOT FOR REPRODUCTION

1-2. Hybrid system

CAUTIO N

■ High voltage precautions

The vehicle has high voltage DC and AC systems as well as a 12-volt system. DC and AC high voltage is very dangerous and can cause severe burns and electric shock that may result in death or serious injury.

● Never touch, disassemble, remove or replace the high voltage parts, cables or

their connectors.

● The hybrid system will become hot after starting as the system uses high voltage.

Be careful of both the high voltage and the high temperature, and always obey the caution labels attached to the vehicle.

● Never try to open the service plug access

hole located behind the rear seats. The service plug is used only when the vehicle is serviced and is subject to high voltage.

1-2. Hybrid system

NOT FOR REPRODUCTION

CAUTIO N

■ Road accident cautions

Observe the following precautions to reduce the risk of death or serious injury:

● Pull your vehicle off the road, apply the parking brake, shift the shift lever to P, and

turn the hybrid system off.

● Do not touch the high voltage parts, cables and connectors.

● If electric wires are exposed inside or outside your vehicle, an electric shock may

occur. Never touch exposed electric wires.

● If a fluid leak occurs, do not touch the fluid as it may be strong alkaline electrolyte

from the hybrid battery (traction battery). If it comes into contact with your skin or eyes, wash it off immediately with a large amount of water or, if possible, boric acid solution. Seek immediate medical attention.

● If a fire occurs in the hybrid vehicles, leave the vehicle as soon as possible. Never

use a fire extinguisher that is not meant for electric fires. Using even a small amount of water may be dangerous.

● If your vehicle needs to be towed, do so with front wheels raised. If the wheels

connected to the electric motor (traction motor) are on the ground when towing, the motor may continue to generate electricity. This may cause an electricity leakage leading to a fire. (→P. 4 21 )

● Carefully inspect the ground under the vehicle. If you find that liquid has leaked

onto the ground, the fuel system may have been damaged. Leave the vehicle as soon as possible.

For safety and security

NOT FOR REPRODUCTION

1-2. Hybrid system

CAUTIO N

■ Hybrid battery (traction battery)

● Your vehicle contains a sealed nickel-metal hydride battery. Never resell, hand

over or modify the hybrid battery. To prevent accidents, hybrid batteries that have been removed from a disposed vehicle are collected through Lexus dealer. Do not dispose of the battery yourself.

Unless the battery is properly collected, the following may occur, resulting in death or serious injury:

• The hybrid battery may be illegally disposed of or dumped, and it is hazardous to the environment or someone may touch a high voltage part, resulting in an electric shock.

• The hybrid battery is intended to be used exclusively with your hybrid vehicle. If the hybrid battery is used outside of your vehicle or modified in any way, accidents such as electric shock, heat generation, smoke generation, an explosion and electrolyte leakage may occur.

When reselling or handing over your vehicle, the possibility of an accident is extremely high because the person receiving the vehicle may not be aware of these dangers.

● If your vehicle is disposed of without the hybrid battery having been removed,

there is a danger of serious electric shock if high voltage parts, cables and their connectors are touched. In the event that your vehicle must be disposed of, the hybrid battery must be disposed of by your Lexus dealer or a qualified service shop. If the hybrid battery is not disposed of properly, it may cause electric shock that can result in death or serious injury.

NOTICE

■ Hybrid battery air vent

● Do not put foreign objects near the air vent. The hybrid battery (traction battery)

may overheat and be damaged.

● Clean the air vent regularly to prevent the hybrid battery (traction battery) from

overheating.

● Do not wet or allow foreign substances to enter the air vent as this may cause a

short circuit and damage the hybrid battery (traction battery).

● Do not carry large amounts of water such as water cooler bottles in the vehicle. If

water spills onto the hybrid battery (traction battery), the battery may be damaged. Have the vehicle inspected by your Lexus dealer.

1-3. Theft deterrent system

NOT FOR REPRODUCTION

Engine immobilizer system (gasoline vehicles)

The vehicle’s keys have built-in transponder chips that prevent the engine from starting if a key has not been previously registered in the vehicle’s on-board computer.

Never leave the keys inside the vehicle when you leave the vehicle.

This system is designed to help prevent vehicle theft but does not guarantee absolute security against all vehicle thefts.

The indicator light flashes after the “START STOP ENGINE” switch has been turned off to indicate that the system is operating.

The indicator light stops flashing after the “START STOP ENGINE” switch has been turned to ACCESSORY or IGNITION ON mode to indicate that the system has been canceled.

For safety and security

■ System maintenance

The vehicle has a maintenance-free type engine immobilizer system.

■ Conditions that may cause the system to malfunction

● If the grip portion of the key is in contact with a metallic object

● If the key is in close proximity to or touching a key to the security system (key with a

built-in transponder chip) of another vehicle

NOTICE

■ To ensure the system operates correctly

Do not modify or remove the system. If modified or removed, the proper operation of the system cannot be guaranteed.

NOT FOR REPRODUCTION

1-3. Theft deterrent system

Immobilizer system (hybrid vehicles)

The vehicle’s keys have built-in transponder chips that prevent the hybrid system from starting if a key has not been previously registered in the vehicle’s on-board computer.

Never leave the keys inside the vehicle when you leave the vehicle.

This system is designed to help prevent vehicle theft but does not guarantee absolute security against all vehicle thefts.

The indicator light flashes after the “POWER” switch has been turned off to indicate that the system is operating.

The indicator light stops flashing after the “POWER” switch has been turned to ACCESSORY or ON mode to indicate that the system has been canceled.

■ System maintenance

The vehicle has a maintenance-free type immobilizer system.

■ Conditions that may cause the system to malfunction

● If the grip portion of the key is in contact with a metallic object

● If the key is in close proximity to or touching a key to the security system (key with a

built-in transponder chip) of another vehicle

NOTICE

■ To ensure the system operates correctly

Do not modify or remove the system. If modified or removed, the proper operation of the system cannot be guaranteed.

1-3. Theft deterrent system

NOT FOR REPRODUCTION

Alarm

The alarm

The alarm uses light and sound to give an alert when an intrusion is detected.

The alarm is triggered in the following situations when the alarm is set:

● A locked door or trunk is unlocked or opened in any way other than

using the entry function, wireless remote control or mechanical key. (The doors will lock again automatically.)

● The hood is opened.

Setting the alarm system

Close the doors, trunk and hood, and lock all the doors. The system will be set automatically after 30 seconds.

For safety and security

The indicator light changes from being on to flashing when the system is set.

Deactivating or stopping the alarm

Do one of the following to deactivate or stop the alarm:

● Unlock the doors or open the trunk.

● Turn the “START STOP ENGINE” <“POWER”> switch to ACCES-

SORY or IGNITION ON <ON> mode, or start the engine <hybrid system>. (The alarm will be deactivated or stopped after a few seconds.)

NOT FOR REPRODUCTION

■ System maintenance

■ Items to check before locking the vehicle

■ Triggering of the alarm

1-3. Theft deterrent system

The vehicle has a maintenance-free type alarm system.

To prevent unexpected triggering of the alarm and vehicle theft, make sure of the following:

● Nobody is in the vehicle.

● The windows and moon roof are closed before the alarm is set.

● No valuables or other personal items are left in the vehicle.

The alarm may be triggered in the following situations: (Stopping the alarm deactivates the alarm system.)

● A person inside the vehicle opens a door,

the trunk or hood.

● The 12-volt battery is recharged or replaced when the vehicle is locked. (→P. 478 )

X Gasoline vehicles

X Hybrid vehicles

1-3. Theft deterrent system

NOT FOR REPRODUCTION

■ Alarm-operated door lock

● When the alarm is operating, the doors are locked automatically to prevent intrud-

ers.

● Do not leave the key inside the vehicle when the alarm is operating, and make sure

the key is not inside the vehicle when recharging or replacing the 12-volt battery.

NOTICE

■ To ensure the system operates correctly

Do not modify or remove the system. If modified or removed, the proper operation of the system cannot be guaranteed.

For safety and security

NOT FOR REPRODUCTION

1-3. Theft deterrent system

NOT FOR REPRODUCTION

Instrument cluster

2. Instrument cluster

Warning lights and

indicators.......................................86

Gauges and meters.......................91

Multi-information display ..........95

Energy monitor/

consumption screen ...............105

NOT FOR REPRODUCTION

2. Instrument cluster

Warning lights and indicators

The warning lights and indicators on the instrument cluster and center panel inform the driver of the status of the vehicle’s various systems.

For the purpose of explanation, the following illustration displays all warning lights and indicators illuminated.

◆ Instrument cluster

Some indicators may differ depending on the grade/type.

◆ Outside rear view mirrors

NOT FOR REPRODUCTION

2. Instrument cluster

◆ Center panel

Instrument cluster

NOT FOR REPRODUCTION

2. Instrument cluster

Warning lights

Warning lights inform the driver of malfunctions in the indicated vehicle’s systems.

1, 2

(Flashes)

(if equipped)

Brake system warning light (→P. 42 9 )

Charging system warning light (→P. 4 30 )

Malfunction indicator lamp (→P. 43 0)

SRS warning light (→P. 43 0)

ABS warning light (→P. 43 0)

Electric power steering

system warning light (→P. 43 1)

“PCS” warning light (→P. 43 1)

Slip indicator (→P. 4 31 )

(hybrid

vehicles )

(if equipped)

Brake system warning light (→P. 4 31)

Automatic headlight leveling system warning light (→P. 4 31)

Open door warning light (→P. 4 32)

Low fuel level warning light (→P. 4 32)

Seat belt reminder light (→P. 4 32)

Rear passengers’ seat belt reminder lights (→P. 43 1)

Master warning light (→P. 4 32)

Tire pressure warning light (→P. 4 33 )

: These lights turn on when the “START STOP ENGINE” <“POWER”> switch is

turned to IGNITION ON <ON> mode to indicate that a system check is being performed. They will turn off after the engine <hybrid system> is on, or after a few seconds. There may be a malfunction in a system if the lights do not turn on, or turn off. Have the vehicle inspected by your Lexus dealer.

: The light flashes to indicate a malfunction.

2. Instrument cluster

NOT FOR REPRODUCTION

Indicators

The indicators inform the driver of the operating state of the vehicle’s various systems.

(hybrid

vehicles)

(hybrid

vehicles)

1, 3

(if equipped)

Turn signal indicator (→P. 209)

Tail light indicator (→P. 212)

Headlight high beam indicator (→P. 2 13 )

Fog light indicator (→P. 21 5)

“READY” indicator (→P. 192)

EV indicator (→P. 7 1)

“PCS” warning light (→P. 26 8 )

(if equipped)

1, 2

(gasoline

vehicles )

Radar cruise control indicator (→P. 2 30 )

Cruise control “SET” indicator (→P. 2 26 )

Lexus parking assist-sensor indicator (→P. 24 5)

Slip indicator (→P. 259, 265)

VSC OFF indicator (→P. 260)

BSM outside rear view mirror indicators (→P. 2 74)

Eco Driving Indicator Light (→P. 1 02 )

Instrument cluster

Cruise control indicator (→P. 22 6)

NOT FOR REPRODUCTION

2. Instrument cluster

: These lights turn on when the “START STOP ENGINE” <“POWER”> switch is

: The light flashes to indicate that the system is operating.

: The light turns on when the system is turned off. The light flashes quickly to indi-

cate that the system is operating.

: In order to confirm operation, the BSM outside rear view mirror indicators illumi-

nate in the following situations:

• When the “START STOP ENGINE” <“POWER”> switch is turned to IGNITION ON <ON> mode while the BSM main switch is set to ON.

• When the BSM main switch is set to ON while the “START STOP ENGINE” <“POWER”> switch is in IGNITION ON <ON> mode.

If the system is functioning correctly, the BSM outside rear view mirror indicators will turn off after a few seconds.

If the BSM outside rear view mirror indicators do not illuminate or do not turn off, there may be a malfunction with the system. If this occurs, have the vehicle inspected by your Lexus dealer.

CAUTIO N

■ If a safety system warning light does not come on

Should a safety system light such as the ABS and SRS warning light not come on when you start the engine <hybrid system>, this could mean that these systems are not available to help protect you in an accident, which could result in death or serious injury. Have the vehicle inspected by your Lexus dealer immediately if this occurs.

Gauges and meters

NOT FOR REPRODUCTION

Engine coolant temperature gauge

Displays the engine coolant temperature

Tachometer/Hybrid System Indicator

X Tachometer

2. Instrument cluster

Instrument cluster

For gasoline vehicles, or hybrid vehicles with sport mode selected (→P. 2 56 )

Displays the engine speed in revolutions per minute

X Hybrid System Indicator

For hybrid vehicles with other than sport mode selected (→P. 2 56 )

Displays hybrid system output or regeneration level (→P. 93 )

ECO lamp and SPORT lamp

Changes colors according to driving mode (→P. 9 4)

Multi-information display

Presents the driver with a variety of driving-related data (→P. 9 5)

Speedometer

Displays the vehicle speed

NOT FOR REPRODUCTION

2. Instrument cluster

Fuel gauge

Displays the quantity of fuel remaining in the tank

Shift position and shift range

Displays the selected shift position or selected shift range (→P. 202, 205)

Odometer and trip meter display

X Odometer

Displays the total distance the vehicle has been driven

X Trip meter

Displays the distance the vehicle has been driven since the meter was last reset. Trip meters “A” and “B” can be used to record and display different distances independently.

Changing the display

Switches between odometer and trip meter displays. When the trip meter is displayed, pressing and holding the button will reset the trip meter.

Instrument panel light control

The brightness of the instrument panel lights can be adjusted.

Darker

Brighter

2. Instrument cluster

NOT FOR REPRODUCTION

■ The meters and display illuminate when

The “START STOP ENGINE” <“POWER”> switch is in IGNITION ON <ON> mode.

■ Instrument panel brightness adjustment

The instrument panel brightness levels when the tail lights are on and off can be adjusted individually. However, when the surroundings are bright (daytime, etc.), turning on the tail lights will not change the instrument panel brightness.

■ Limitation of brightness adjustment

The brightness of the instrument panel lights is automatically adjusted based on the light sensor detecting how bright the surroundings are. However, if the instrument panel brightness has been manually set to either the brightest or darkest setting, the automatic adjustment will not be performed.

■ Hybrid System Indicator (hybrid vehicles)

Power area

Shows that an Eco-friendly driving range is being exceeded (during full power driving etc.)

Eco area

Shows that the vehicle is being driven in an Eco-friendly manner.

Hybrid Eco area

Shows that gasoline engine power is not being used very often.

The gasoline engine will automatically stop and restart under various conditions.

Charge area

Shows regenerative charging

Instrument cluster

● Hybrid System Indicator is displayed when the driving mode is other than the sport

mode.

● By keeping the indicator needle within Eco area, more Eco-friendly driving can be

achieved.

● Charge area indicates regeneration* status. Regenerated energy will be used to

charge the battery.

*: When used in this manual, “regeneration” refers to the conversion of energy cre-

ated by the movement of the vehicle into electrical energy.

NOT FOR REPRODUCTION

■ ECO lamp and SPORT lamp

■ Tachometer (hybrid vehicles)

■ Engine speed (hybrid vehicles)

■ Odometer and trip meter display

■ Customization

2. Instrument cluster

● When sport mode is selected, SPORT lamp (red) will illuminate.

● When all of the following conditions are satisfied and Eco-friendly driving, ECO

lamp (blue) will illuminate. (ECO lamp will become brighter the more Eco-friendly driving you perform. Also, while the vehicle is stopped or the acceleration exceeds Zone of Eco driving, ECO lamp turns off. (→P. 102) However, when Eco drive mode is selected, while the vehicle is stopped or the acceleration exceeds Zone of Eco driving, ECO lamp does not turn off.):

• Driving with the shift lever in D

• Either normal mode or Eco drive mode is selected.

• The vehicle speed is approximately 130 km/h (80 mph) or below.

Hybrid System Indicator automatically switches to the tachometer when driving mode is in sport mode.

Engine speed is precisely controlled in order to help improve fuel efficiency and reduce exhaust emissions etc. There are times when the engine speed that is displayed may differ even when vehicle operation and driving conditions are the same.

→P. 18 9, 196

Settings (e.g. on/off operation of ECO lamp) can be changed. (Customizable features →P. 50 8 )

NOTICE

■ To prevent damage to the engine and its components

● Do not let the indicator needle of the tachometer enter the red zone, which indi-

cates the maximum engine speed.

● The engine may be overheating if the engine coolant temperature gauge is in the

red zone (H). In this case, immediately stop the vehicle in a safe place, and check the engine after it has cooled completely. (→P. 484, 487)

2. Instrument cluster

NOT FOR REPRODUCTION

Multi-information display

Display contents

The multi-information display presents the driver with a variety of drivingrelated data including the current outside air temperature.

● Eco Driving Indicator Zone Dis-

play (gasoline vehicles) (→P. 1 02 )

● Energy monitor (hybrid vehicles)

(→P. 105)

● Outside temperature display

(→P. 9 6)

● Trip information (→P. 96)

Displays driving range, fuel consumption and other cruising related information

Drive monitor (→P. 99)

●

Instrument cluster

● Lexus parking assist-sensor display* (→P. 246 )

● Dynamic radar cruise control display* (if equipped) (→P. 23 0)

● Warning messages (→P. 4 37 )

Automatically displayed when a malfunction occurs in one of the vehicle’s systems. Display can be switched by pressing the “DISP” button. (→P. 9 6)

*: Automatically displayed when the system is used. Display can be switched by

pressing the “DISP” button. (→P. 96 )

NOT FOR REPRODUCTION

2. Instrument cluster

Trip information

■ Switching the display

Items displayed can be switched by pressing the “DISP” button.

■ Eco Driving Indicator Zone Display (gasoline vehicles)

→P. 1 02

■ Energy monitor (hybrid vehicles)

→P. 1 05

■ Outside temperature

Displays the outside air temperature

The temperature range that can be displayed is from

-40°C (-40°F) to 50°C (122°F)

■ Current fuel consumption

Displays the current rate of fuel consumption

■ Average fuel consumption after refueling

NOT FOR REPRODUCTION

Displays the average fuel consumption since the vehicle was last refueled

Use the displayed average fuel consumption as a reference.

■ Average fuel consumption

2. Instrument cluster

Displays the average fuel consumption since the function was reset

■ Average vehicle speed

Displays the average vehicle speed since the function was reset

• The function can be reset by pressing the “DISP” button for longer than 1 second when the average fuel consumption is displayed.

• Use the displayed average fuel consumption as a reference.

The function can be reset by pressing the “DISP” button for longer than 1 second when the average vehicle speed is displayed.

Instrument cluster

NOT FOR REPRODUCTION

2. Instrument cluster

■ Driving range

■ Elapsed time

Displays the estimated maximum distance that can be driven with the quantity of fuel remaining

• This distance is computed based on your average fuel consumption. As a result, the actual distance that can be driven may differ from that displayed.

• When only a small amount of fuel is added to the tank, the display may not be updated. When refueling, turn the “START STOP ENGINE” <“POWER”> switch off. If the vehicle is refueled without turning the “START STOP ENGINE” <“POWER”> switch off, the display may not be updated.

Displays the elapsed time since the engine <hybrid system> was started

2. Instrument cluster

NOT FOR REPRODUCTION

Drive monitor

Outside temperature, average fuel consumption after refueling or driving range can be selected and displayed. If displayed on the drive monitor, other trip information or warning messages can be displayed simultaneously.

For display and selection procedures, follow the “Setting up the displays”.

The information displayed on the drive monitor will not be displayed on the trip information screen.

Instrument cluster

LEXUS AVV60R, GSV60R owners manuals

Specifications and Main Features

Frequently Asked Questions

User Manual

TABLE OF CONTENTS2

For your information

Reading this manual

How to search

Pictorial index

For safety and security

Before driving

For safety drive

Seat belts

SRS airbags

Safety information for children

Child restraint systems

Installing child restraints

Exhaust gas precautions

Hybrid system features (hybrid vehicles)

Hybrid system precautions (hybrid vehicles)

Engine immobilizer system (gasoline vehicles)

Immobilizer system (hybrid vehicles)

Alarm

Instrument cluster

Warning lights and indicators

Gauges and meters

Multi-information display
