P330 Tiny Setup Guide
Rear Vi e w
English
Mini DisplayPort® connectors (4)
Security-lock slot
Wi-Fi antenna slot
Ethernet connector
USB 3.1 connectors Gen 2 (2)
USB 3.0 connector
HDMI™-out connector
USB 3.0 connector
DisplayPort® connector
Power-cord connector
• Bottom cover
• Power adapter bracket*
Unpack
Computer
Documentation
Keyboard* *Available on some models
Power cord*
Mouse*
Rear view
Read the statement on USB transfer rate in the User Guide. Refer to the Safety and Warranty
Guide for accessing the User Guide.
Customer Replacement Units (CRU)
• Computer cover
• Dust shield*
• External optical drive*
• External optical drive box*
• Internal speaker
• Keyboard*
• M.2 solid-state drive*
• Memory module
• Mouse*
• Power adapter
• Power cord
• Vertical stand*
• VESA mount bracket*
• Coin-cell battery
• Graphics card*
• PCIe converter*
• Storage drive*
• Storage drive bracket*
• System fan
• Wi-Fi card*
• Wi-Fi card shield*
*Available on some models
Refer to the User Guide for CRU definition.
Compliance with the Radio Equipment Directive
Hereby, Lenovo (Singapore) Pte. Ltd., declares that the radio
equipment type ThinkStation P330 Tiny is in compliance with
Directive 2014/53/EU. For further information about EU regulatory
compliance, refer to the Safety and Warranty Guide that comes
with your computer.
E-manual
Third Editi on (January 2020)
© Copyright Lenovo 2019, 2020.
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to
a General Services Administration “GSA” contract, use, reproduction, or disclosure is subject
to restrictions set forth in Contract No. GS-35F-05925.
