11e 5th Gen / Yoga 11e 5th Gen
Setup Guide
Printed in China
Unpack
1
2
3
2
Initial Setup
E-manual
Overview
2
3
12
1
1
5
4
6
7
8
9
10
11
13
14
15
16
17
18
2
12
1
1
4
3
6
7
8
9
10
11
13
14
15
16
17
18
Yoga 11e 5th Gen
11e 5th Gen
[English]
1. Microphones
2. Front camera
3. Multi-touch screen*
4. Speakers
5. Rear camera*
6. Pen tether hole
7. Security-lock slot
8. USB-C
TM
connector
9. USB 3.0 connector
10. Audio connector
11. Power button
12. Touch pad
13. microSD card slot
14. Always On USB 3.0 connector
15. HDMI
TM
connector
16. Ethernet connector
17. Power connector
18. Pen tether hole
* for selected models
Read the statement on USB transfer rate in the Use r Guide. Refer to the Safety and Warranty
Guide for accessing the User Guide.
Customer Replacement Units (CRUs)
• ac power adapter
• Base cover assembly
• Keyboard
• M.2 solid-state drive
• Power button card
• Power cord
• Speaker assembly*
• ThinkPad Pen Pro charger*
• Wireless LAN card
for selected models
*
Refer to the User Guide for CRU definition.
Compliance with the EU Radio Equipment Directive
The following applies to models with a radio device.
Hereby, Lenovo (Singapore) Pte. Ltd., declares that the
radio equipment type ThinkPad 11e 5t h Gen and Yoga 11e
5th Gen
are in compliance with Directive 2014/53/EU.
For further information about EU regulatory compliance,
refer to the Safety and Warranty Guide that comes with
your computer.
Specific Absorption Rate (ICNIRP)
YOUR DEVICE MEETS INTERNATIONAL GUIDELINES
FOR EXPOSURE TO RADIO WAVES.
Your device is a radio transmitter and receiver. It is
designed not to exceed the limits for exposure to radio
waves (radio frequency electromagnetic fields)
recommended by international guidelines. The
guidelines were developed by an independent scientific
organization (ICNIRP) and include a substantial safety
margin designed to assure the safety of all persons,
regardless of age and health.
Second Edition (January 2020)
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services
Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract
© Copyright Lenovo 2018, 2020.
The radio wave exposure guidelines use a unit of
measurement known as the Specific Absorption Rate, or
SAR. The Europe 10g SAR limit for mobile devices is 2.0
W/kg. Tests for SAR are conducted using standard
operating positions with the device transmitting at its
highest certified power level in all tested frequency
bands. The highest SAR values under the ICNIRP
guidelines for your device are as follows:
Maximum body-worn SAR with 0 mm separation
distance: 0.855 W/ kg
During us e, the actual SAR values for you r device are
usually well below the values stated. This is because, for
purposes of system efficiency and to minimize
interference on the network, the operating power of
your mobile device is automatically decreased when full
power is not needed for the data connection. The lower
the power output of the device, the lower its SAR value.
If you are interested in further reducing your RF
exposure then you can easily do so by limiting your
usage or simply keeping the device away from the body.
No. GS-35F-05925.
Reduce I Reuse I Recycle
