Lenco MDV-8 User Manual

DVD MICRO HI-FI

SYSTEM WITH

USB & SD/MMC

MDV-8

For information and support, www.lenco.eu

User manual

Table of Content

Safety Information

Locations and function of the player

Connection 6

Remote Control 9

DVD Operation

Radio Operation

Troubleshooting

Specification 25

Dear Customer:

Thank you for purchasing this DVD MICRO HI-FI SYSTEM WITH USB & SD/MMC. When opening the box for the first time, please check whether all the accessories are present. Before connecting parts and power, please carefully read the user manual and always keep these instructions close by your DVD MICRO HI-FI SYSTEM WITH USB & SD/MMC.

Accessoires list:

1 pcs main unit 2 pcs speaker 1 pcs remote control

1 set battery for remote control 1 pcs AV cable 1 pcs antenna

Safety In formation

The lightning flash with an arrowhead symbol within an equilateral triangle is intended to alert the user of the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user of the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS:

(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED. INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED.

Us e r M a nua l

1. All the safety and operating instructions should be read before the product is operated.

2. Retain Instructions - The safety and operating instructions should be retained for future reference.

3. All warnings on the product and in the operating instructions should be adhered to.

4. All operating and use instructions should be followed.

La s e r

This Digital Video Disc Player employs a Laser System of the class 1.

1. Make sure the device is shut down prior to opening player lid.

2. Do not open the appliance. Do not attempt to dismantle the appliance.

3. In order to avoid any danger: Have service work only carried out by the manufacturer or an authorized service workshop.

4. Visible laser radiation when open and interlocks defeated.

5. Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.

USB connection

The USB memory stick should be plug in the unit directly. USB extension cable should not be used to avoid failing of data transferring and interference caused.

Front Panel

Locations and Function of the Player

1. POWER

2. / 7. VOLUME knob

3. Stop button

4. /CHANNEL- button

5. /CHANNEL+ button

Notes:

□

Use the FUNCTION button to select the proper input signal source. The sequence

is DVD —> Radio —>AUX 1 IN—> AUX 2 IN. The DVD operation includes the source for USB and CARD. When in DVD mode, you can press FUNCTION button on the remote control to select USB or CARD signal source.

6. /AUTO

8. /FM/AM

9. CARD READER interface

10. USB interface

Locations and Function of the Player

Playback Content from USB or CARD

This unit has a USB/SD interface, you can insert a USB device or an SD card with USB/SD Interface to play the audio/video files and JPEG files. All the function is the same with the DISC operation. You can switch between the DVD/USB/SD function by pressing the FUNCTION button.

The unit starts to read the table of content (TOC) of the storage and displays the results into the file browser. By using the navigation buttons you can choose the content which you want to playback and start the playback by pressing the ENTER button.

Note :

To avoid damage, do not pull out the USB/SD when you playback the files in the USB. If you want to pull out the USB, please press STOP button first.

Locations and Function of the Playe

Rear Panel

Eleme n t s of t h e rear s i d e

1. SPEAKER OUTPUT

2. AM Antenna jack

3. FM Antenna jack

4. AUDIO INPUT jacks

5. AUDIO OUTPUT jacks

6. COAXIAL OUTPUT jack

7. VIDEO OUTPUT jacks

8. AC Power cable

9. Scart socket

Connecting to TV/Amplifier

Connection

T o T V co mp o si te A UD IO /V ID EO I N P UT ja c ks

Connection

Connecting the Speakers

Pl a c e t h e S p ea k er s

For the best result, please arrange the two speakers as shown in the following picture:

Align the speakers vertically at the ear level and at a horizontally angle of 45 degrees to the primary listening area.

1. Position of the unit and the TV set.

2. Left speaker

3. Right speaker

4. Position to enjoy sound and video

Co n n ec t th e Sp e a k e rs

1.Please make sure, that the power is turned off and is not connected to the power outlet.

2.Press down the thumb levers and insert fully each tip of the wire into the connector. Then release the thumb levers to lock the wire in place.

3.Please pay attention that the color of the wire correspondent to the color of the thumb levers on

the speaker and on the player itself.

No t e s :

To prevent damage to circuits, do not short-circuit the positive and negative speaker output

jacks.

Make sure the exposed tips of each speaker wire are separated to the distance that they can

not touch each other after they are inserted into the connectors.

Do not connect any other speakers or devices that are not included with this system.
