Lenco MDV-6 User Manual
MDV-6
Home Cinema Set
FOREWORD
THANKS
Thank you for purchasing this product!
Your choice of the product sufficiently displays your expertise in acoustic equipment.
We are honored to provide you with more satisfactory products. To bring
the functionality of your device into full play, it is suggested that you try to find some time
To read this user manual before connecting and operating your system, so that you can
Grasp system connections and requirements in use, and get enhanced enjoyment and
Pleasure in using the product from the very beginning.
IMPORTANT NOTICE
Please unpack carefully, and keep all the accessories in the same place.
Please check any possibilities in shipping damage. If your devices are damaged
or cannot be operated, please notify your local dealers immediately. If the
device is shipped to your place directly, please contact the carrier as soon as
possible. Only the consignee(individual or company to receive the devices) is
entitled to claim indemnity to the carrier in the light of shipping damages. We
recommend that you keep the original cartons and packing materials soundly for
future shipping.
ACCESSORIES
CONTENT
-2-
FOREWORD…………………………………………………………………………………….2
A
CONTENT………………………………………………………………………………………..3
WARNING……..……………………………………………………………………………...….3
FRONT PANEL...………………………………………………………………………………..4
BACK PANEL……………………………………………………………………………………5
REMOTE CONTROL……………………………………………………………………………6
CONNTECTION WITH TV……………………………………………………………………...7
CONNECTION WITH AMPLIFIER…………………………………………………………….8
SYSTEM CONNECTION……………………………………………………………………….9
BASIC OPERATION………………………………………………………………………..10-16
DVD MENU SETUP…..…………………………………………………………………….17-21
SPECIFICATION…………………………………………………………………………….….22
TROUBLESHOOTING…………………………………………………………………………23
WARNING
Please read and understand all the warnings given in the following and those marked on
The unit. This unit has been designed and manufactured to assure personal safety.
Only use the power by sign on
user manual or system!
void direct sunshine and
close heat source.
Protect power cable: avoid high
pressure and stamp on; do not
pull and bend excessively.
Keep unit and power plug
away from water!
Never open the cover, avoid metals
dropping in, like needle, hairpin,
coin, etc.
Unplug the set from the outlet when
you do not use it for a long time
FRONT PANEL
-3-
1. REMOTE CONTROL SENSOR
2. POWER ON/OFF BUTTON
3. STOP BUTTON
4. DISC DOOR
5. EJECT BUTTON
6. AUDIO BUTTON、MONO/STEREO
BUTTON
7. PLAY/ENTER BUTTON
8.. DISPLAY SCREEN
9. FAST REWIND/FAST FORWARD
(TUNE-/+) BUTTON
10. VOLUME+/-
11. PREVIOUS/NEXT(CH-/+) BUTTON
12. FM BUTTON、SEARCH BUTTON
13. DVD BUTTON、SAVE BUTTON
-4-
BACK PANEL
1. FM ANTENNA INTERFACE
2. COAXIAL OUTPUT
3. SCART OUTPUT
4. POWER SUPPLY INPUT
5. S-VIDEO OUTPUT
6. OPTICAL FIBER OUTPUT
7. L/R AUDIO INPUT
8. L/R SPEAKER OUTPUT
9. SUBWOOFER OUTPUT
10. VIDEO OUTPUT
11. Pb/Cb, Y, Pr/Cr COMPONENT OUTPUT
12. L/R AUDIO OUTPUT
-5-
REMOTE CONTROL
NOTE:
1. Place the batteries in the remote control and turn on the player, put the emitter against the sensor of
player for remote control.
2. The distance of remote control should not exceed 7 meters, or else, it will be invalid.
3. If the sensor or remote control emitter is stuck with foreign matters, it may result in the malfunction in
signal reception or not at all.
4. The remote control function may be affected under the strong interference signals, such as power
supply and other strong high-frequency signals.
REMARK: Remote Control Battery Type: Size: AAA Standard Voltage: 1.5V
-6-
CONNECTION WITH TV
1. If you TV has AV terminal, connect this unit to TV with A/V cables, and set TV to be AV status
after confirming the connection is correct. (Figure 1)
2. If your TV has S-Video terminal, please use the S-Video connection cable to connect the player
and TV, to obtain a higher quality image. (Figure 2)
3. If your TV has chromatics output terminal, please use three connection cables to connect the
player and TV, to obtain a more vivid image. (Figure 3)
4. This unit has an output interface for SCART output
(Figure 4)
, which can directly be connected with TV.
Note:
1. It is a must to turn off the switch of both player and TV before they are connected and unplug
the power line from the socket.
2. You may adjust the corresponding system according to your TV system while watching various
discs.
3. If there are multiple connections between video player and TV, please select one and unplug
others so as not to affect the quality of images and sound.
4. Do not switch on and off or press power switch frequently, switching on and off each time must
have an interval of 3 seconds.
5. Do not connect the digital optical or coaxial output jack of this player with the analogue signal
input terminal for reception.
-7-
