Lenco DVD-07 User Manual
SAFETY INFORMATION
TO REDUCE THE RISK OF FIRE AND ELECTRIC SHOCK, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.
:
CAUTION
the risk of fire and electric shock,
do not remove the cover (or back)
of the unit. Refer servicing only to
The lightning flash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of uninsulated
"dangerous voltage" within product's enclosure that may be of
sufficient magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operation and servicing
instructions in the literature accompanying the appliance.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO
NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF
PLUG TO WIDE SLOT, FULLY INSERT.
IMPORTANT SAFEGUARDS
In addition to the careful attention devoted to quality standards
in the manufacture of your video product, safety is a major factor
in the design of every instrument. However, safety is your
responsibility, too. This sheet lists important information that will
help to assure your enjoyment and proper use of the video
product and accessory equipment. Please read them carefully
before operation and using your video product.
Installation
Read and Follow Instructions- All the safety and operation instructions
1.
should be read before the video product is operated. Follow all operating
instructions.
2.
Retain Instructions- The safety and operating instructions should be retained
for future reference.
3.
Heed all Warnings-Comply with all warnings on the video product and in the
operating instructions.
4.
Polarization- This video product is equipped with a polarized alternating current line plug . This plug will fit into the power outlet,try reversing the
plug. If the plug still fails to fit, contact your electrician to replace your
obsolete outlet. To prevent electric shock, do not use this polarized plug
with an extension cord, receptacle, or other outlet unless the blades can be
fully inserted without blade exposure. If you need an extension cord, use a
polarized cord.
5.
Power Sources- This video product should be operated only from the type
of power source indicated on the marking label.If you are not sure of the
type of power supply to your home, consult your video dealer or local power
company. For video products intended to operate from battery power, or
other sources, refer to the operating instructions.
6.
Overloading- Do not overload wall outlets or extension cords as this can
result in a risk of fire or electric shock. Overloaded AC outlets, extension
cords, frayed power cords, damaged or cracked wire insulation, and
broken plugs are dangerous, They may result in a shock or fire hazard.
Periodically examine the cord, and if its appearanceindicated damage or
deteriorated insulation, have it replaced by your service technician.
7.
Power-Cord Protection- Power-supply cords should be routed so that they
are not likely to be walked on or pinched by items placed upon or against
them, paying particular attention to cords at plugs, convenience receptacles,
and the point where they exit from the video product.
8.
Ventilation- Slots and openings in the case are provided for ventilation to
ensure reliable operation of the video product and to protect it from
overheating. These openings must not the blocked or covered. The openings
should never be blocked by placing the video product on a bed, sofa, rug, or
heat register. This video product should not be placed in a built-in installation
such as a book case or rack, unless proper ventilation is provided or the
video product manufacturer's instructions have been followed.
9.
Attachments- Do not use attachments unless recommended by the video
product manufacturer as they may cause hazards.
Water and Moisture- do not use this video product near water for example,
10.
near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement,
or near a swimming pool and the like. Caution: Maintain electrical safety.
Powerline operated equipment or accessories connected to this unit
should bear safety certification mark on the accessory itself and should not
be modified so as to defeat the safety features. This will help avoid any
qualified service personnel.
To reduce
danger and shouldnot be modified so as to defeat the safety features. This
will help avoid any potential hazard from electrical shock or fire. If in doubt,
contact qualified service personnel.
11.
Accessories- Do not place this video product on an unstable cart, stand,
tripod, bracket, or table. The video productmay fall, causing serious injury
to a child or adult as well as serious damage to the video product. Use this
video product only with a cart, stand,tripod, bracket, or table recommended
by the manufacturer's or sold with the video product. Any mounting of the
product should follow the manufacturer's instructions and use of a mounting
accessory recommended by the manufacturer.
12.
A video product and cart combination should be moved with care. Quick
stops, excessive force, and uneven surfaces may cause the video product
and cart combination to overturn.
Note to CATV system installer
This reminder is provided to call the CATV system installer's attention to
Section 820-40 of the NEC which provides guidelines for proper grounding
and, in particular, specifies that the cable ground shall be connected to the
grounding system of the building, as close to the point of cable entry as
practical.
Outdoor Antenna Grounding- If an outside antenna or cable system is
13.
connected to the video product, be sure the antenna or cable system is
grounded so as to provide some protection against voltage surges and builtup static charges. Section 810 of the National Electrical Code, ANSI/NFPA
No.70-1984 (Section 54 of Canadian Electrical Code, Part1) provides
information with respect to proper grounding of the mast and supporting
structure, grounding of the lead-in wire to an antenna-discharge unit,
connection to grounding electrodes, and requirements for the grounding
electrode.
14.
Power Lines-An outside antenna system should not be located in the vicinity
of overhead power lines, other electric light or power circuits, or where it can
fall into such power lines or circuits. When installing an outside antenna
system, extreme care should be taken to keep from touching or approaching
such power lines or circuits, as contact with them might be fatal. Installing an
outdoor antenna can be hazardous and should be left to a professional
antenna installer.
Use
15.
Cleaning- Unplug this video product from the wall outlet before cleaning.Do
not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
16.
Objects that may touch dangerous voltage points or "short-out" parts could
result in a fire or electric shock. Never spill liquid of any kind on the video
product.
17.
Lightning-For added protection for this video product during a lightning storm,
or when it is left unattended and unused for long periods of time, unplug it
from the wall outlet and disconnect the antenna or cable system. This will
prevent damage to the video product due to lightning and power line surges.
Service
Servicing-Do not attempt to service this video product yourself, as opening
18.
or removing covers may expose you to dangerous voltage or other hazards.
Refer all servicing to qualified service personnel.
19.
Conditions requiring service-unplug this video product from the wall outlet,
refer servicing to qualified service personnel under the following conditions:
A. When the power-supply cord or plug is damaged.
B. If liquid has been spilled, or objects have fallen into the video product.
C. If the video product has been exposed to rain or water.
D. If the video does not operate normally by following the instruction manual..
Adjust only those controls that are covered by operating instructions.
Improper adjustment of other controls may result in damage and will
often require extensive work by a qualified technician to restore the
video product to its normal operation.
E. If the video product has been dropped or cabinet has been damaged.
F. When the video productexhibits a distinct change in performance-this
indicates a need for service.
20.
Replacement Parts-When replacement parts are required, have the service
technician verify that the replacements he uses have the same safety
characteristics as the original parts. Use of replacements specified by the
video product manufacturer can prevent fire, electric shock, or other hazards.
21.
Safety Check-Upon completion of any service or repairs to this video product,
ask the service technician to perform safety checks recommended by the
manufacturer to determinethat the video product is in safe operating
condition.
Wall or Ceiling Mounting- The product should be mounted to a wall or ceiling
22.
only as recommended by the manufacturer.
Heat-The product should be situated away from heat sources such as
23.
radiators, heat registers, stoves, or other products(including amplifiers)
that products heat.
INTRODUCTION
About DVD
DVD (Digital Versatile Disc) is a digital video medium
under the MPEG II format, featuring a variety of
revolutionary entertainment capabilities. The MPEG II
video compression technology provides capacity for an
excellent picture ofminimum 500 lines resolution on
screen, up to 8 language soundtracks, up to 9 views
from different camera angles and up to 32 language
subtitles (provided by the DVD disc itself which supports
these features).
Disc information
Disc types
D
ecoding
Method
Capacity
Disc size
Horizontal
Resolution
Sub-titles
Sound tracks
Symbol
DVD features symbols
Each DVD disc contains various features depending
on production ofthe disc. Below are some of the
symbols representing the features:
2
Number of Audio Tracks
2
Number of Subtitles
DVD
Digital / MPEGII
Single-layer / Singleside
4.7GB = 2 hr
Single-layer / Doublesides
8.5GB = 4 hr
Double-layers / Singleside
9.4GB = 4.5 hr
Double-layers / Double sides
17GB = 8 hr
12cm / 8cm
500 lines up
32
8
650MB = 74min
L B
16 : 9
+
CD
Digital
12cm / 8cm
-
-
1
Screen Format
Zoom
Select a DVD disc
DVD Region Code
DVD discs and DVD players are manufactured
under the worldwide agreed DVD Regional
Code System that the player will operate only
with corresponding disc of the same Regional
Code.
Region code
Region
1
Canada, USA
2
Europe (incl. Poland, Romania, The Czech
republic), Japan, MiddleEast (incl. Saudi
Arabia, Egypt, Iran, South Africa)
East Asia (incl. Hong Kong, Taiwan, South
3
Korea),
South-East Asia
Australia, Caribbean, Central & South
4
America, Mexico,
New Zealand
Africa, Former Soviet Union, India, North
5
Korea, Pakistan,Turkmenistan
China
6
Care of disc
Video disc contains high-density compressed data
that needs properhandling
Hold the disc with fingers. Hold the disc's outer
edge and/or the center spindle hole. Do not touch
the disc surface.
Do not bend or press the disc. Do NOT expose the
disc to direct sunlight or heating sources.
2
Angle Indicator
The player has built in copyright
protection technology that
prevents copying from a DVD
disc to any media.
If a video recorder is connected to
the player, the video output image
will be distorted during recording.
Some features contained in this DVD playerare related to
the DVD disc's software.
Some features cannotbe performed if the disc does not
support the feature, or requires special settings.
Check the features printed on the disc's packing or follow
the instructions ofthe Disc's on screen menu.
REMARK
Store discs in cabinet vertically, in dry condition.
Prevent exposure to:
Direct sunlight
Heat or exhaust from a heating device.
Extreme humidity.
Clean the disc surface with a soft, dry cleaning cloth.
Wipe the disc surface gently, radically, from center
toward the outer edge.
Do not apply thinner, alcohol chemical solvent, or
sprays when cleaning. Such cleaning fluids will
permanently damage the disc surface.
Loading...
