DIGITAL ALARM CLOCK RADIO
INSTRUCTION MANUAL
For information and support, www.lenco.eu
CR3302 LENCO ENG FM ONLY IM 98 x1 1 11/5/2009 9:14:35
GB 1
WARNINGS
ATTENTION
To reduce the risk of electric shock, do not remove the cover.
There are no user serviceable parts inside the unit. Refer all servicing to qualied
personnel.
The lightening ash with arrowhead symbol within the triangle is a warning sign alerting the
user of "dangerous voltage" inside the unit.
The exclamation point within the triangle is a warning sign alerting the user of important
instructions accompanying the product.
WARNING
To reduce the risk of re or electric shock, do not expose this appliance to rain or moisture.
IMPORTANT
DO NOT THROW BATTERIES IN FIRE !
THE APPARATUS SHALL NOT BE EXPOSED TO DRIPPING OR SPLASHING.
ENSURE A MINIMUM DISTANCE OF 5 CM AROUND THE APPARATUS FOR SUFFICIENT
VENTILATION.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CR3302 LENCO ENG FM ONLY IM 98 x2 2 11/5/2009 9:14:35
ENSURE THAT THE VENTILATION IS NOT IMPEDED BY COVERING THE VENTILATION
OPENINGS WITH ITEMS, SUCH AS NEWSPAPERS, TABLE-CLOTHS, CURTAINS, ETC..
DO NOT PLACE NAKED FLAME SOURCES, SUCH AS LIGHTED CANDLES ON THE
APPARATUS.
DO NOT PLACE NAKED FLAME SOURCES, SUCH AS LIGHTED CANDLES ON THE
APPARATUS.
TAKE ATTENTION TO THE ENVIRONMENTAL ASPECTS OF BATTERY DISPOSAL.
USE THE APPARATUS ONLY IN MODERATE CLIMATES (NOT IN TROPICAL CLIMATES).
DO NOT EXPOSE THE APPARATUS TO DRIPPING OR SPLASHING.
DO NOT PLACE OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES, ON THE
APPARATUS.
BATTERY SHALL NOT BE EXPOSED TO EXCESSIVE HEAT SUCH AS SUNSHINE, FIRE
OR THE LIKE.
THE MARKING INFORMATION IS LOCATED AT THE BOTTOM OF APPARATUS.
In case of malfunction due to electrostatic discharge, the apparatus has to be reset by
disconnecting it from mains supply.
The mains plug shall remain readily operable.
GB 2
CR3302 LENCO ENG FM ONLY IM 98 x3 3 11/5/2009 9:14:35
GB 3
CR3302 LENCO ENG FM ONLY IM 98 x4 4 11/5/2009 9:14:35
1. Alarm 1 Button
2. Alarm 2 button
3. Time set buttom
4. Hour Button
5. Minute Button
6. Sleep button
7. Radio Button
8. Snooze button
9. Alarm display
10. Alarm 1 indicator
11. Alarm 2 indicator
12. LED display
LOCATIONS OF PARTS AND CONTROLS
13. Alarm 1 standby indicator
14. Alarm 2 standby indicator
15. Dial scale
16. Battery compartment
17.
Alarm 2 switch
18.
Alarm 1 switch
19. Volume control
20. Tuning control
21. Wire antenna
22. 230V power supply cable
23. Speaker
GB 4
POWER SUPPLY
This unit is designed to operate from AC230~50Hz household mains supply.
The 3V 2 x "AAA " size batteries is used for clock back up only.
Note: When inserted a back up battery the unit will conserve the settings during power
outage.
the disconnect device shall remain readily operable.
CR3302 LENCO ENG FM ONLY IM 98 x5 5 11/5/2009 9:14:35
LISTEN TO THE RADIO
1. Press the Radio button to turn the radio on.
2. Adjust the Volume Control into the desired listening level and select your favourite station
with the Tuning Control.
3. To turn off the radio, press Radio button.
TO SET THE TIME
1. Press and hold the Time set button.
2. Press the Hour button to set hours.
3. Press the Minute button to set minutes.
4. Release the Time set button. The correct time is shown on the display.
SETTING THE ALARM
Hold the ALARM 1 button for 2 seconds and press HOUR button to set the ALARM 1 hour
digit, hold the ALARM 1 button press the MINUTE button to set the ALARM 1 minute digit.
Hold the ALARM 2 button for 2 seconds and press HOUR button to set the ALARM 2 hour
digit, hold the ALARM 2 button press MINUTE button to set the ALARM 2 minute digit, the
ALARM 2 will show on alarm display when ALARM 2 button is pressed.
SETTING THE WAKE MODE
Switch the ALARM 1-AUTO/BUZZER/OFF and or ALARM 2-AUTO/BUZZER/OFF to select the
mode below:
AUTO: will wake up by radio when the time reach
BUZZER: will wake up by buzzer when the time reach
OFF: no wake up
The ALARM 1 standby indicator or ALARM 2 standby indicator on the real time display
become on when select AUTO or BUZZER.
GB 5
CR3302 LENCO ENG FM ONLY IM 98 x6 6 11/5/2009 9:14:35
SNOOZE FUNCTION
When the radio or buzzer sounds, press the SNOOZE to temporarily stop for 9min
until alarm reach, press ALARM 1-SET/OFF to terminate the ALARM 1,
press ALARM 2-SET/OFF to terminate the ALARM 2.
TO USE THE SLEEP TIMER
When the radio is power on, press SLEEP button to activate the sleep timer, sleep time will
display 00-10-20-30-40-50-60-70-80-90 by each press, timer will start after SLEEP button
release for 2sec, and the radio will auto shut off when timer reach, or press the RADIO button
to turn off immediately.
ANTENNA
The FM radio has a exible wire antenna on the back side of the unit, uncoil the wire and extend
to its full length for best reception.
GB 6
CR3302 LENCO ENG FM ONLY IM 98 x7 7 11/5/2009 9:14:35
GB 7
If at any time in the future you should need to dispose of this product please note that
Waste electrical products should not be disposed of with household waste.Please
recycle where facilities exist. Check with your Local Authority or retailer for recycling
advice. (Waste Electrical and Electronic Equipment Directive)
Where to place the item :
Today’s furniture is coated with a wide variety of lacquers and synthetic-coatings that are treated
with an extensive range of cleaning products. Therefore, the possibility that some of these
substances contain components that react adversely to the rubber feet of the item and soften
them, cannot be completely excluded. The rubber feet of the appliance can cause discoloring
to furniture surfaces. If necessary, place the appliance on a non-slide surface.
SPECIFICATIONS
Power Source: AC : 230V ~ 50Hz
DC : 3V backup ( 2 x "AAA")
Frequency range: FM : 87.5 - 108 MHz
Power Consumption 4.5 W
Dimension: 126(L) x 99(D) x 101(H) mm
Weight 0.56 kg
Due to continuing improvement, the features and the design are subject to change without
notice.
For information and support, www.lenco.eu
