Leica RFID
„LID Module 1.0“

Instructions for use

This Statement has to printed in the User Manuel of the End-Product

Leica Microsystems CMS GmbH. Instructions for use, 11XXXXXX, Revision 1.0, 2015-06-15

Contents

2

1. General .......................................................... 4

1.1 Product Description .................................... 4

1.2 Specifications LID Module 1.0 ................... 4

1.3 Specifications RFID Tag D6.7 special ....... 4

1.4 FCC / IC Compliance .................................... 5

Contents

1. General

3

1. General

1.1 Product Description

This microscope contains the RFID module „LID
Module 1.0“.

It recognizes the used filter cubes in the fluotur­ret.
The different filter cubes are equipped with cor­responding passive tags (Type D6.7 special).
During initialization phase of the turret, these
tags are read by the LID Module 1.0.

The tags cannot be written or modified by the LID
Module 1.0.

1.2 Specifications LID Module 1.0

Supply Voltage 5V

Dimensions 36 x 25 x 9.8 mm

RFID Protocol ISO 15693

Transmit frequncy 13,56 MHz

Operating temperature -5°C to +65°C

Storage temperature -20°C to +85°C

Communication interface I

2

C

1.3 Specifications RFID Tag D6.7 special

Modulation Scheme Close coupling

Dimensions D=6,7mm TH=2,6mm

RFID Protocol ISO 15693

Transmit frequncy 13,56 MHz

Read write type 2kbit EEProm

Operating temperature -15°C to +65°C

Storage temperature -25°C to +125°C

LID Module 1.0

1. General

4

1.4 FCC / IC Compliance

Note:

This equipment has been tested and found to
comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference when the equip­ment is operated in a commercial environment.
This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and
used in accordance with the instruction manual,
may cause harmful interference to radio com­munications. Operation of this equipment in a
residential area is likely to cause harmful inter­ference in which case the user will be required
to correct the interference at his own expense.

!

Notice:

This device complies with Part 15 of the FCC
Rules [and with Industry Canada licence-exempt
RSS standard(s)].
Operation is subject to the following two condi­tions:

1. this device may not cause harmful interfer­ence, and

2. this device must accept any interference
received, including interference that may
cause undesired operation.

!

Notice:

Changes or modifications made to this equipment
not expressly approved by Leica Microsystems
CMS GmbH may void the FCC authorization to op­erate this equipment.
