Kyocera PRINTER DRIVER User Guide

Download

Legal Notes

Unauthorized reproduction of all or part of this guide is prohibited.

The information in this guide is subject to change without notice.

We cannot be held liable for any problems arising from the use of this product, regardless of the information herein.

Regarding Trademarks

Microsoft®, Windows®, Windows 8®, Windows 7®, Windows Vista®, Windows XP®, Windows Server®, Word®, and Powerpoint® are registered trademarks of Microsoft Corporation in the U.S. and/or other countries. KPDL is a trademark of Kyocera Corporation. PCL® is a trademark of Hewlett-Packard Company. TrueType® and Mac OS® are registered trademark of Apple Inc. Adobe®, Acrobat®, Adobe Reader®, Photoshop® and PostScript® are trademarks of Adobe Systems, Incorporated. UNIX® is a trademark in the United States and other countries, licensed exclusively through X/Open Company Limited.

All other brand and product names herein are registered trademarks or trademarks of their respective companies.

Examples of the operations given in this guide support the Windows 7 printing environment. Essentially the same operations are used for Microsoft Windows 8, Windows Vista, Windows XP, Windows Server 2003, Windows Server 2008, and Windows Server 2012 environments.

This user guide and its contents were developed for the 6.0 driver.

Chapter 1 Installation

Preparing to Install the Driver ........................................................................................................ 1-1

European Default Duplex .............................................................................................................. 1-2

Express Install ............................................................................................................................... 1-2

Installing with Express Install ................................................................................................... 1-2

Custom Install ............................................................................................................................... 1-3

Installing with Custom Install ................................................................................................... 1-4

Custom Installing Utilities Only ................................................................................................ 1-5

Editing Driver Properties .......................................................................................................... 1-6

Editing Utility Properties .......................................................................................................... 1-7

Specifying Communication Settings ........................................................................................ 1-7

Upgrade ........................................................................................................................................ 1-7

Upgrading Driver Components ................................................................................................ 1-8

Maintenance ................................................................................................................................. 1-8

Optional Printer Components .................................................................................................. 1-8

Documents .................................................................................................................................... 1-9

Uninstall ........................................................................................................................................ 1-9

Uninstalling Driver Components .............................................................................................. 1-9

Printer Driver Settings Access ..................................................................................................... 1-10

Changing the Default Driver Settings .................................................................................... 1-10

Chapter 2 Driver Overview

Overview Images .......................................................................................................................... 2-1

Selecting a PDL in Printing Preferences ....................................................................................... 2-1

Settings List ................................................................................................................................... 2-2

Print Preview ................................................................................................................................. 2-2

Previewing a Print Job ............................................................................................................. 2-2

Kyocera Logo ................................................................................................................................ 2-2

Displaying Version Information ................................................................................................ 2-2

Displaying Plug-in Information ................................................................................................. 2-3

Chapter 3 Device Settings

Accessing Device Settings ............................................................................................................ 3-1

Device Options .............................................................................................................................. 3-1

Setting Device Options ............................................................................................................ 3-1

Setting Punch Options ............................................................................................................. 3-2

Setting up Virtual Mail Boxes ................................................................................................... 3-2

Setting up Custom Boxes ........................................................................................................ 3-3

Auto Configure .............................................................................................................................. 3-3

Enabling Auto Configuration .................................................................................................... 3-4

Memory ......................................................................................................................................... 3-4

Setting the Memory ................................................................................................................. 3-5

RAM Disk ...................................................................................................................................... 3-5

Setting RAM Disk .................................................................................................................... 3-5

Administrator Settings ................................................................................................................... 3-5

Printer Driver i

General .................................................................................................................................... 3-6

Lock Settings ......................................................................................................................... 3-10

User Login ............................................................................................................................. 3-11

Job Accounting ...................................................................................................................... 3-13

Policy Manager ...................................................................................................................... 3-14

User Settings ............................................................................................................................... 3-16

Identification .......................................................................................................................... 3-16

Units ...................................................................................................................................... 3-17

Language Preference ............................................................................................................ 3-17

PDL (Page Description Language) .............................................................................................. 3-17

PDL Options .......................................................................................................................... 3-18

PDF ....................................................................................................................................... 3-20

XPS Driver ............................................................................................................................. 3-22

Compatibility Settings .................................................................................................................. 3-22

Media Source Enumeration ................................................................................................... 3-22

Disable Face-Up Reverse Page Order .................................................................................. 3-23

Ignore Application Collation ................................................................................................... 3-23

Combine Source and Media Type Lists ................................................................................. 3-24

Enable Manual Duplex on Network Port ................................................................................ 3-24

Removing a Plug-in ..................................................................................................................... 3-24

Chapter 4 Quick Print

Quick Print Options ....................................................................................................................... 4-1

Orientation ............................................................................................................................... 4-1

Color ........................................................................................................................................ 4-1

Collate ..................................................................................................................................... 4-1

Duplex Printing ........................................................................................................................ 4-2

Manual Duplex ........................................................................................................................ 4-2

Pages per Sheet ...................................................................................................................... 4-2

EcoPrint ................................................................................................................................... 4-2

Staple ...................................................................................................................................... 4-3

Punch ...................................................................................................................................... 4-3

Edit Quick Print ........................................................................................................................ 4-3

Profiles .......................................................................................................................................... 4-4

Selecting a Profile .................................................................................................................... 4-4

Saving a Profile ....................................................................................................................... 4-4

Editing a Profile ....................................................................................................................... 4-5

Importing a Profile ................................................................................................................... 4-6

Exporting a Profile ................................................................................................................... 4-6

Application Based Printing ....................................................................................................... 4-6

Chapter 5 Basic

Print Size and Page Size ............................................................................................................... 5-1

Creating a Custom Page Size ................................................................................................. 5-1

Printing with Custom Size Pages ............................................................................................. 5-2

Source ........................................................................................................................................... 5-2

Copies ........................................................................................................................................... 5-2

Carbon Copies .............................................................................................................................. 5-2

Printing Carbon Copies ........................................................................................................... 5-2

Collate ........................................................................................................................................... 5-3

Printing Collated Documents ................................................................................................... 5-3

Orientation .................................................................................................................................... 5-4

Media Type ................................................................................................................................... 5-4

Destination .................................................................................................................................... 5-4

Color ............................................................................................................................................. 5-4

EcoPrint ........................................................................................................................................ 5-5

ii User Guide

Duplex Printing .............................................................................................................................. 5-5

Printing in Duplex Mode .......................................................................................................... 5-5

Manual Duplex .............................................................................................................................. 5-5

Printing with Manual Duplex .................................................................................................... 5-5

Chapter 6 Layout

Multiple Pages per Sheet .............................................................................................................. 6-1

Printing Multiple Pages per Sheet ........................................................................................... 6-1

Scaling .......................................................................................................................................... 6-1

Setting Scaling on the Page .................................................................................................... 6-1

Gutter ............................................................................................................................................ 6-2

Creating a Gutter ..................................................................................................................... 6-2

Full Bleed ...................................................................................................................................... 6-2

Printing with Full Bleed ............................................................................................................ 6-3

Poster ............................................................................................................................................ 6-3

Printing a Poster ...................................................................................................................... 6-4

Booklet .......................................................................................................................................... 6-4

Printing a Booklet .................................................................................................................... 6-5

Chapter 7 Finishing

Separation ..................................................................................................................................... 7-1

Offset Jobs .............................................................................................................................. 7-1

Rotate Copies .......................................................................................................................... 7-1

Tri-Fold .......................................................................................................................................... 7-2

Printing with Tri-Fold ................................................................................................................ 7-2

Bi-Fold ........................................................................................................................................... 7-3

Printing with Bi-Fold ................................................................................................................. 7-3

Finishing Edge .............................................................................................................................. 7-3

Finishing Edge Combinations .................................................................................................. 7-3

Positioning Options for Finishing Edge .................................................................................... 7-4

Custom Finishing Edge Settings ............................................................................................. 7-4

Setting the Finishing Edge ....................................................................................................... 7-4

Gutter ............................................................................................................................................ 7-5

Creating a Gutter ..................................................................................................................... 7-5

Staple ............................................................................................................................................ 7-5

Stapling a Print Job ................................................................................................................. 7-6

Punch ............................................................................................................................................ 7-6

Creating Punch Holes for a Print Job ....................................................................................... 7-6

Chapter 8 Imaging

Print Quality and Custom Quality .................................................................................................. 8-1

Selecting Print Quality ............................................................................................................. 8-1

Trapping ........................................................................................................................................ 8-2

Setting Trapping Values .......................................................................................................... 8-2

Fonts ............................................................................................................................................. 8-2

Font Settings ........................................................................................................................... 8-3

Font Substitution ..................................................................................................................... 8-3

Disable Device Fonts ............................................................................................................... 8-4

Half Speed Mode .......................................................................................................................... 8-4

Graphics ........................................................................................................................................ 8-5

Pattern Scaling ........................................................................................................................ 8-5

Line Thinning ........................................................................................................................... 8-5

Halftone Screen ....................................................................................................................... 8-6

Inversion Options .................................................................................................................... 8-7

Optimization ............................................................................................................................ 8-8

Printer Driver iii

CIE Option ............................................................................................................................... 8-8

Image Compression Mode ...................................................................................................... 8-8

Gloss Mode ................................................................................................................................... 8-8

EcoPrint ........................................................................................................................................ 8-8

Selecting EcoPrint ................................................................................................................... 8-9

Color ............................................................................................................................................. 8-9

Color Reproduction ....................................................................................................................... 8-9

Color Correction .................................................................................................................... 8-10

Selecting Color Correction ..................................................................................................... 8-11

Setting a Default Color Profile ............................................................................................... 8-12

Color Adjustment ......................................................................................................................... 8-13

Selecting Custom Color Adjustment ...................................................................................... 8-13

Adjusting HSL (Hue, Saturation, Lightness) .......................................................................... 8-13

Adjusting Color Balance ........................................................................................................ 8-14

Black and White Adjustment ....................................................................................................... 8-14

Adjusting Black and White Settings ....................................................................................... 8-14

Color Conversion ........................................................................................................................ 8-15

Text and Graphics Effects ........................................................................................................... 8-15

Chapter 9 Publishing

Cover Mode ................................................................................................................................... 9-1

Cover Mode Options ................................................................................................................ 9-1

Printing Covers ........................................................................................................................ 9-4

Transparency Interleaving ............................................................................................................. 9-4

Inserting Backing Sheets Between Transparencies ................................................................ 9-5

Page Insert .................................................................................................................................... 9-5

Page Insertion Options ............................................................................................................ 9-5

Printing Page Inserts ............................................................................................................... 9-6

Index Tab Dividers ........................................................................................................................ 9-7

Index Tab Dividers Options ..................................................................................................... 9-7

Inserting Index Tab Dividers .................................................................................................... 9-9

Chapter 10 Job

Job Storage (e-MPS) .................................................................................................................. 10-1

Temporary ................................................................................................................................... 10-1

Permanent .................................................................................................................................. 10-2

Placing a Barcode on a Print Job ................................................................................................ 10-2

Virtual Mail Box ........................................................................................................................... 10-3

Custom Box ................................................................................................................................. 10-3

Quick Copy .................................................................................................................................. 10-4

Proof and Hold ............................................................................................................................ 10-5

Private Print ................................................................................................................................. 10-6

Job Storage ................................................................................................................................. 10-7

Synergy Print Box ....................................................................................................................... 10-7

Form Gallery ............................................................................................................................... 10-8

Job Name .................................................................................................................................... 10-9

Storing a Temporary Print Job ............................................................................................... 10-1

Storing a Permanent Print Job ............................................................................................... 10-2

Storing a Job in a Virtual Mail Box ......................................................................................... 10-3

Storing a Job in a Custom Box .............................................................................................. 10-3

Printing a Quick Copy Job ..................................................................................................... 10-5

Printing a Proof and Hold Job ................................................................................................ 10-5

Storing a Private Print Job ..................................................................................................... 10-6

Storing a Job Storage Job ..................................................................................................... 10-7

Storing a Job in a Synergy Print Box ..................................................................................... 10-8

Storing an Image in the Form Gallery .................................................................................... 10-8

iv User Guide

Don't Use Application Name .................................................................................................. 10-9

Overwrite Job Name .............................................................................................................. 10-9

Selecting a Job Name ........................................................................................................... 10-9

Job Option ................................................................................................................................. 10-10

Chapter 11 Advanced

Prologue/Epilogue ....................................................................................................................... 11-1

Selecting a Prologue/Epilogue File ........................................................................................ 11-1

Editing a Prologue/Epilogue File ........................................................................................... 11-1

Deleting a Prologue/Epilogue File ......................................................................................... 11-1

Assigning a Prologue/Epilogue File ....................................................................................... 11-2

Unassigning a Prologue/Epilogue File ................................................................................... 11-2

Specifying the Insertion Point ................................................................................................ 11-2

Watermark .................................................................................................................................. 11-3

Adding or Editing a Watermark .............................................................................................. 11-3

Selecting Pages for Watermark ............................................................................................. 11-4

Security Watermark ..................................................................................................................... 11-5

Adding or Editing a Security Watermark ................................................................................ 11-6

Adjusting Security Watermark Calibration ............................................................................. 11-7

Selecting Pages for Security Watermark ............................................................................... 11-7

Color Optimizer ........................................................................................................................... 11-8

Optimizing RGB Color for Printing ......................................................................................... 11-8

Status Monitor Versions .............................................................................................................. 11-9

Status Monitor Notification ..................................................................................................... 11-9

Status Monitor ..................................................................................................................... 11-11

EMF Spooling ............................................................................................................................ 11-13

Enable Client Profile .................................................................................................................. 11-13

Printer Driver v

1 Installation

A printer driver is an application that manages communication between a printer and your computer. Once installed, the printer driver settings must be configured in the printer Properties and Printing Preferences. There are two methods of installation. Express Install is a quick way to install a driver and certain features in package form. With Custom Install, you select from individual drivers and utilities. In the Product Library window you can also uninstall drivers and utilities with the Uninstall option.

You can click Maintenance to run certain utilities from the Product Library window. Click Documents to access the release notes, printing system operation guide, and other materials. With Upgrade you can update the driver and utilities to a newer version. Upgrade is only available if there is a product that needs to be upgraded. (Selections vary according to printing system model, optional devices, or driver version.)

Note: In Windows operating systems, you must be logged in with administrator rights to install the printer driver.

Preparing to Install the Driver

This section describes the initial steps to take before you install the printer driver.

In Windows 8, Windows 7, and Windows Vista with a USB connection, a driver installation can be made from the Microsoft Windows Update site if a certified driver is available and the system is connected to the web. We recommend you continue to install the driver from the supplied installation disc for an expanded feature set. In Windows, if the Found New Hardware Wizard dialog box appears during the installation process, click Cancel. If the Hardware Installation warning dialog box appears, click Continue Anyway.

Turn on the computer and the printer.

Insert the Product Library disc into the disc drive. The application should start

automatically.

Note: If the Product Library fails to start after inserting it into the disc drive, use Windows Explorer to locate Setup.exe on the local drive and double-click to open.

The Product Library window appears with the license dialog box. Read the

license agreement and then click Accept to proceed.

At the bottom of the Product Library window, select your language from the

list.

1-1 User Guide

European Default Duplex

Printing on both sides of a sheet of paper (duplex mode) reduces paper consumption and helps conserve environmental resources. Duplex mode also lowers costs by reducing the amount of paper that must be purchased. We recommend that printing systems capable of duplex printing use duplex mode by default. This can be set in the printer driver installation process for European locations only.

After clicking Accept in the license dialog box, if the operating system locale is EU and time zone is GMT 0, GMT +1 or GMT +2, a message about resource and energy conservation appears. Read the message, and then click OK.

After installation is successful, an Enable Duplex check box is displayed on the Finished page. Select the check box to have the driver automatically default to duplex mode. Exceptions to the default can afterward be made by selecting options in the driver Quick Print or Basic tabs.

Express Install

Express Install refers to quick device, driver, and utility installation for a USB or

network connection. The installation application discovers printing devices that are turned on, and connected by USB or network cable. One or more feature packages can be installed together.

Installation

Installing with Express Install

This section describes the express installation procedure of devices, drivers, and utilities in Windows operating systems.

If the installer cannot find your printing system, contact your system administrator.

Note: You must install .NET Framework 4.0 or later to use Status Monitor.

Ensure that your printing system and computer are turned on and connected by

USB or network cable.

In the Express Install window, the installer looks for your printing system. Each

discovered device is displayed in the device list as an icon with a model name and location (USB port or IP address).

If your device is discovered, select your model in the device list.

If discovery does not find your device, remove and reinsert the USB or network cable, and ensure that it is connected properly. Click the circular arrow icon to refresh the discovery.

You can also find a device by typing a partial or full search term in the search

text box above the device list. You can search the discovered devices by model name, IP address, or USB port. The results are displayed in the device list. If the search finds your device, select it. Click the x icon to clear the text box, and return to the list of all discovered devices.

You can select Use host name as port name to use a host name for the

Standard TCP/IP port. (Not available with a USB connection.)

Printer Driver 1-2

Installation

The installer automatically selects the packages in the feature list. Or you can

click each to switch between clearing and selecting. Move the pointer over an icon to see a description of the contents.

Review your settings. At least one device and one feature must be selected to

enable the Install button. If your settings are correct, click Install.

During the installation, you can expand or collapse the installation detail by

clicking the arrow. When the installation completes successfully, on the Finished page you can select from the following options. These options only appear after a printer driver installation.

Print a test page

Select this option to test the connection and operation of the printing system. If the installation is successful, the Windows Printer Test Page, containing your computer name and information on your printer driver and port settings, prints at the newly installed printing system.

Device Settings

Select the Device Settings check box to open Device Settings where you can choose installed options for your printing system. (The Device Settings check box appears only in Windows XP with a network connection.)

Enable event notification

Select the check box to enable event notification in the Status Monitor Notification dialog box.

Show Quick Print tab

The Quick Print tab lets you define basic print options into group profiles that can be accessed easily. The Show Quick Print tab option also appears in Device Settings > Administrator > General.

Click the plus sign icon to expand the list of options:

The Set Quick Print tab as default option makes the Quick Print tab the first tab you see when you open the driver.

The Set Basic tab as default option makes the Basic tab the first tab you see when you open the driver.

The Hide other tabs option makes the Quick Print tab the only tab in the driver.

To exit the installer application click Finish.

A message may appear if there is a software installation failure. After clicking Finish, retry the installation. If the same message appears again, contact your system administrator.

The installation of the printing system is now complete. If prompted, restart your computer.

Custom Install

Custom Install applies to detailed device, driver, and utility installation for a

USB or network connection. The installer can discover devices that are turned on, and connected by USB or network cable, or you can manually select your own printing system model and port name.

When you make a selection in the Custom Install window, it is highlighted with a blue background. Drag and drop functionality is supported. You can click an

1-3 User Guide

arrow to expand or collapse a selection box. You can install more than one product from each list, but they must be selected and moved to the Products to Install list.

In Windows 8, Windows 7, Windows Vista, Windows Server 2008, Windows Server 2008 R2, and Windows Server 2012 only, the XML Paper Specification (XPS) driver provides the most efficient method for displaying, processing, and printing documents.

Installing with Custom Install

This section describes the custom installation of printing devices, drivers, and utilities in Windows operating systems. If you want to install utilities only, see the next section for details.

If the installer cannot find your printing system, contact your system administrator.

Note: You must install .NET Framework 4.0 or later to use Status Monitor.

Ensure that your printing device and computer are turned on and connected by

USB or network cable.

Click Custom Install.

To discover a printing system, proceed to step 3. To add a printing system model and port name, proceed to step 5.

Installation

In the Custom Install window, the installer searches for your printing device.

Each discovered printing system is displayed in the Devices list as an icon with a model name and location (USB port or IP address). To view the list without icons, under the Devices list click the Switch to list view icon. Under the Devices list, you can also click one of the icons to select all devices, or clear all devices. If your printing device is not discovered, proceed to step 5.

Select a printing device from the Devices list, and click the arrow to move it to

the Products to Install list. Proceed to step 6.

If discovery does not find your printing device, you can add it. Click the Add

custom device icon.

In the Devices dialog box, select from the Model list of supported models, and the Port name list of all local and network ports. To add a port connected to your system, click Add Port. Click OK in the Devices dialog box. The printing device appears in the Products to Install list.

Select a driver from the Drivers list, and click the arrow to move it to the

Products to Install list. One or more drivers are required to enable the Install

button.

Select a utility from the Utilities list, and click the arrow to move it to the

Products to Install list. If the most recent version of a utility is installed, the

utility is disabled in the list and shows a message that a newer version is installed.

Printer Driver 1-4

Installation

If you want to remove a product from the Products to Install list, select it and

click Remove at the bottom of the list box. To remove all products, click Remove all.

You can select Use host name as port name to use a host name for the

Standard TCP/IP port. (Not available with a USB connection.)

For each printing device and driver combination in the Products to Install list,

you can click the Edit icon to open a dialog box with installation options for the drivers. Make your selections from the available options.

Review your settings. At least one printing system, driver, or a utility, must be

selected to enable the Install button. If your settings are correct, click Install.

During the installation, you can expand or collapse the installation detail by

clicking the arrow. When the installation completes successfully, on the Finished page you can select from the following options. These options only appear after a printer driver installation.

Print a test page

Device Settings

Enable event notification

Select the check box to enable event notification in the Status Monitor Notification dialog box. You can set up sound and speech notifications for

printing system events.

Show Quick Print tab

The Quick Print tab lets you define basic print options into group profiles that can be accessed easily. The Show Quick Print tab option also appears in Device Settings > Administrator > General.

To exit the installer application click Finish.

A message may appear if there is a software installation failure. After clicking Finish, retry the installation. If the same message appears again, contact your system administrator.

The installation of the printing system is now complete. If prompted, restart your computer.

Custom Installing Utilities Only

This section describes the custom installation of utilities without printing systems or drivers.

Ensure that your printing device and computer are turned on and connected by

USB or network cable.

1-5 User Guide

Click Custom Install.

Select a utility from the Utilities list, and click the arrow to move it to the

Products to Install list. If the most recent version of a utility is installed, the

utility is disabled in the list and shows a message that a newer version is installed.

If you want to remove a product from the Products to Install list, select it and

click Remove at the bottom of the list box. To remove all products, click Remove all.

Review your settings. At least one utility must be selected to enable the Install

button. If your settings are correct, click Install.

To exit the installer application click Finish.

A message may appear if there is a software installation failure. After clicking Finish, retry the installation. If the same message appears again, contact your system administrator.

The installation of the utilities are now complete. If prompted, restart your computer.

Installation

Editing Driver Properties

In the Product Library window, click Custom Install.

In the Devices list, select a device and click the arrow to move it to the

Products to Install list.

In the Drivers list, select a driver and click the arrow to move it to the Products

to Install list.

In the Products to Install list, click the Edit pencil icon in one of the device

products. If the pencil icon is not visible, scroll to the end of the product description to reveal it.

The Device dialog box opens and shows the model name and the IP address or

USB. If there is a driver assigned, the following driver properties appear. If there are multiple drivers, the settings for each driver are separated into tabs. Select the tab of the driver you want to configure.

Type a Printer name for the device to a maximum of 63 characters.

Select Share the printer if you want others to use this printing system.

If Share the printer is selected, you can type a shared name for the printing

system to a maximum of 63 characters.

If you prefer most or all of your print jobs go to this printing device, select Set as

default printer.

Printer Driver 1-6

Installation

Click OK for the application to save your settings and return to the Custom

Install window.

Editing Utility Properties

In the Product Library window, click Custom Install.

In the Utilities list, select KYOCERA Net Viewer and click the arrow to move it

to the Products to Install list.

In the Products to Install list, click the Edit pencil icon in the KYOCERA Net

Viewer utility product.

A dialog box opens to show the utility options. Make your selections.

KYOCERA Net Viewer

Device Management

Finds devices and manages device settings.

Account Management

Establishes accounts for device groups and manages the account settings.

Host Management

Manages printer drivers and print queues.

Click OK.

Specifying Communication Settings

You can specify a different SNMP Read community name that is used during device discovery. This name is like a password for SNMP communication. The default name is public. An administrator can require a more restricted name.

If a discovery is in process, or at least one discovery device has been added to the Products to install list, the Communication Settings icon is unavailable.

Click Custom Install.

Under the Devices box, click the Communications Settings icon.

In the Communication Settings dialog box, type a Read community name in

the text box. You can click Reset if you want to return the default name (public) to the text box.

Click OK.

Note: If you entered a different Read community name, the Devices list is cleared. Click the circular arrow Refresh icon to rediscover devices.

Upgrade

The installer can detect older driver or utility components. It creates a list of those components in the Upgrade window.

1-7 User Guide

Maintenance

Upgrading Driver Components

You can select driver or utility components and upgrade them to the most recent version. If there are upgrades available, Upgrade displays as the default window when the installer starts.

In the Product Library window, click Upgrade.

From the Products to Upgrade list, select drivers and utilities to upgrade on

your computer.

To start the upgrade, click Upgrade.

In the Finished dialog box, click Finish.

In the Product Library window, click Maintenance to access utilities that provide useful features. Select an application and click Run. The following utilities are available:

Optional Printer Components

This option can expand the functionality of your printer driver with Help modules in other languages, common printer profiles, plug-in modules, and the Policy Manager application.

Quick Network Setup

This option provides configuration of the most common networking settings using an easy-to-use wizard.

Installation

Optional Printer Components

You can expand the functionality of your printer driver by installing optional components.

For the XPS driver, only Common Profiles and Help Modules can be installed.

Installing Optional Printer Components

Click Maintenance.

Select Optional Printer Components and click Run.

On the Select Printer page, select one or more printing systems. and click

Next. On any page you can click Back to correct any settings.

On the Select Components page, click the plus sign icons to expand options.

Click each option to open a dialog box with more detailed selections.

Under Common components, you can select Help modules in additional languages.

Under each printing system model, you can select one or more common profiles

of predefined print settings.

Printer Driver 1-8

Installation

Under each printing system model, you can select one or more plug-in modules.

Output to PDF

This option lets you print and save documents from multiple sources to PDF.

Security Watermark

This option lets you print a nearly invisible image or text against a background pattern. The security watermark appears only when the printed page is photocopied.

Color Optimizer

This option lets you match a single color accurately in a print job.

Under each printing system model, you can select Driver integration with

Policy Manager. Policy Manager is a server-based application that provides

centralized user authentication, authorization, user access control, and secure pull printing features.

When your settings are correct, click Install.

When the Printer Components Installation Completed page appears. Click

Finish.

When you have completed installing printers and optional components, if prompted, restart your computer.

Documents

Uninstall

In the Product Library window, click Documents to access documents about the driver, utilities, and printing system operation. Select a document and click Open. Acrobat Reader 8.0 or newer is required to view PDF files.

The uninstaller can find the printing system drivers on your local drive. It creates a list of those components in the Uninstall window. If you uninstall a driver, devices using that driver will also be removed.

Uninstalling Driver Components

You can select drivers or utilities to remove from your local drive.

In the Product Library window, click Uninstall.

Select components from the list to uninstall. Select by device model, or click the

plus sign to expand a list of individual devices. Below the list you can also click icons to select all the check boxes, or to clear them.

To start the uninstall, click Uninstall.

In the Finished dialog box, click Finish.

1-9 User Guide

Printer Driver Settings Access

The printer driver software can be accessed from the Print dialog box of an application, or from Start. If accessed from an application, then changes made to driver settings remain in effect until the application ends. If accessed from

Start, changes are maintained as the default printer settings.

Changing the Default Driver Settings

Depending on your operating system:

Windows 8 and Windows Server 2012: open the Control Panel, and then click View devices and printers.

Windows 7 and Windows Server 2008 R2: click Start, and then click Devices and Printers.

Windows Vista and Windows Server 2008: click Control Panel and then click or double-click Printers.

Windows XP and Windows Server 2003: click Start > Printers and Faxes.

Right-click your printing system model and click Printing Preferences.

Installation

In the Printing Preferences dialog box, select the desired features in all tabs.

Click OK to save the settings.

Printer Driver 1-10

Overview Images

2 Driver Overview

The lower part of the Printing Preferences dialog box contains overview features that illustrate driver selections. Overview images and the settings list are available when selecting settings. After selecting driver settings, you can use Print preview to check the print job. (Selections vary according to printing system model, optional devices, or driver version.)

If the vertical screen resolution of your computer is 864 pixels or less, the lower part of the Printing Preferences dialog box does not appear. Under this condition, the button showing the current PDL is on the bottom left, and the Print preview check box is on the bottom right of the visible dialog box.

Overview images appear in the lower part of the Printing Preferences dialog box. Each image illustrates different driver settings. Images are changed automatically when some driver settings are selected, or you can click the tabs on the left side to change the image.

The printing system image displays most attached devices. Source and Destination selections are highlighted in green. For some models, the hard disk icon appears when a job storage option is selected in the Job tab.

The page image is updated based on page selections made in the Quick Print tab, Basic tab, Layout tab, and Finishing tab.

The color image illustrates color settings for color models. For black and white models or color models with Black selected, the image illustrates grayscale settings.

The current page description language (PDL) is displayed in all of the images. You can change the PDL temporarily from any Printing Preferences tab to enable driver features.

Overview images are not available in Generic color or Generic mono drivers.

Selecting a PDL in Printing Preferences

You can change the PDL temporarily from any Printing Preferences tab to enable driver features.

In the overview image area, click the PDL button.

In the PDL Settings dialog box, select the desired page description language

from the Select PDL list.

You can select the GDI compatible mode option to improve the output quality

of graphics created by your application.

Click Settings when the PDL is set to KPDL or PDF, or for some models, PCL

XL.

2-1 User Guide

Settings List

Driver Overview

If you select PCL XL, you can click Settings to open the PCL XL Settings dialog box and select Skip printing blank pages, Enable smart duplex printing, and Disable auto media type switching.

If you select KPDL, you can click Settings to open the KPDL Settings dialog box and select Allow data passthrough and Enable smart duplex printing. Note that if you select Allow data passthrough, EMF spooling is unavailable in the Advanced tab.

If you select PDF, you can click Settings to open the PDF Settings dialog box.

Click OK in the PDL Settings dialog box.

The tree view in the lower part of each tab displays current settings for most driver features. You can scroll down to view features for all driver tabs. As each option is selected, the current selection is displayed in the tree view. You can click the minus (-) or plus (+) signs to hide or show details.

The settings list is not available in Generic color or Generic mono drivers.

Print Preview

The Print preview check box appears in the lower part of each tab. After selecting driver settings, you can use Print preview to check the print job. Text and images are displayed in the preview, along with any optional Watermark or Security Watermark. If you are satisfied with the preview, you can print. Or you can cancel printing if you want to change driver settings.

Previewing a Print Job

Select desired driver settings in all tabs, or select a profile.

In any tab, select Print preview.

Click OK in the Printing Preferences and Print dialog boxes.

When the Print preview dialog box appears:

Click the arrow buttons to view document pages.

To close the preview and make additional changes in driver settings before printing, click the “X” button.

If you are satisfied with the preview, click the printer button to print the job.

Kyocera Logo

The Kyocera logo appears on the bottom portion of any Printing Preferences screen or Device Settings screen. Click the logo to open the About dialog box that displays the driver version number and driver plug-in information.

Displaying Version Information

In Device Settings or the Printing Preferences dialog box, click Kyocera logo

> Version to view the following driver information:

Printer Driver 2-2

Driver Overview

File Name

Version

Description

Date

Manufacturer

Comments

To view copyright information, click Legal Notices.

Click OK to close the driver information dialog boxes.

Displaying Plug-in Information

In Device Settings or the Printing Preferences dialog box, click Kyocera logo

> Plug-in to view the following plug-in information:

Module

Description

Version

Click OK to close the driver information dialog boxes.

2-3 User Guide

3 Device Settings

In Device Settings you can select installed printing system options so the associated features can be used with the printer driver. You can also match the memory setting in the driver with the memory installed in your printing system, which lets the driver manage font downloads more efficiently. Administrator, User, PDL (Page Description Language), and Compatibility settings can also be selected. (Selections vary according to printing system model and optional devices.)

Accessing Device Settings

Depending on your operating system:

Windows 8 and Windows Server 2012: open the Control Panel, and then click View devices and printers.

Windows 7 and Windows Server 2008 R2: click Start, and then click Devices and Printers.

Windows Vista and Windows Server 2008: click Control Panel and then click or double-click Printers.

Windows XP and Windows Server 2003: click Start > Printers and Faxes.

Device Options

Right-click your printing system model, then:

Windows 8, Windows Server 2012, Windows 7, and Windows Server 2008 R2: click Printer properties.

Windows Vista, Windows Server 2008, Windows XP, and Windows Server 2003: click Properties.

Click Device Settings.

Optional devices extend the capabilities of your printing system for source, finishing, and job storage.

In a client/server environment, this feature is unavailable to a client logged in as a restricted user.

Setting Device Options

In Device Settings > Device options, select the check boxes for all installed

devices.

Click OK in the Properties dialog box.

Printer Driver 3-1

Device Settings

Setting Punch Options

Before using the Punch option in the Finishing tab, you must set punch options in Device Settings.

In Device Settings > Device options, select a finishing device that supports

punch. Or if already selected, double-click the blue text.

Depending on the punch unit attached, select one option:

None

No punch option available in the Finishing tab.

2 hole

2 hole option available in the Finishing tab.

2 & 3 hole

2 hole and 3 hole options available in the Finishing tab.

2 & 4 hole

2 hole and 4 hole options available in the Finishing tab.

Click OK in the Punch Unit Settings and Properties dialog boxes.

Setting up Virtual Mail Boxes

Virtual mail boxes must be set up in Device Settings in order to use the Virtual mail box feature in the Job tab. You must also install a hard disk in the printing

system. After jobs are sent to a Virtual mail box, they can be printed from the printing system's operation panel.

In Device Settings > Device options, select Hard disk. Or if already selected,

double-click the blue text. If necessary, clear the RAM disk check box.

In the Hard Disk Settings dialog box, click New.

A new Mailbox name and Virtual output tray number appear.

If desired, change the name and number in the Mailbox name and Virtual

output tray boxes. The name length can be a maximum of 31 characters, and

number must be within a range of 1 to 255.

Click OK in the Hard Disk Settings and Properties dialog boxes.

The new mail box name appears in the Virtual Mailbox Selection dialog box when printing.

You can remove a Virtual mail box by selecting it in the Defined names list and clicking Delete.

You can import a Virtual mail box list by clicking Import and browsing for a valid Virtual Mail box list file (.CSV).

You can save the Virtual mail box list (.CSV) in your computer or network by clicking Export. A saved list can be imported into another printer driver.

3-2 User Guide

Device Settings

Setting up Custom Boxes

Custom boxes must be set up in Device Settings in order to use the Custom box feature in the Job tab. You can create up to 1000 custom boxes for storing

print jobs. Custom boxes can be assigned to users who can print the jobs later from the printing system's operation panel. For some models, SSD appears instead of Hard disk in the Device options list.

In Device Settings > Device options, select Hard disk or SSD. Or if already

selected, double-click the blue text. If necessary, clear the RAM disk check box.

In the Hard Disk Settings or SSD Settings dialog box, click Add.

In the Defined custom boxes list, a new Box number and Box name appear.

If desired, change the number and name in the Box number and Box name boxes. The number must be within a range of 1 to 1000, and the name length can be a maximum of 32 characters. You can also type a user name to a maximum of 20 characters.

If the box will be used by multiple users, select Shared box.

Auto Configure

Note: For some models, Shared box is selected by default.

Check box selected: All network users can save jobs in the box.

Check box clear: Only the box owner and network administrator can save jobs in the box.

To require users of a shared box to type a password before printing, select

Require password, and type a password to a maximum of 16 characters.

Click OK in the Hard Disk Settings or SSD Settings and Properties dialog

boxes.

The new custom box appears in the Custom Box dialog box when printing.

You can remove a custom box by selecting it in the Defined custom boxes list and clicking Delete.

You can import a custom box list by clicking Import and browsing for a valid custom box list file (.CSV or .KXU).

You can save the current custom box list (.CSV or .KXU) in your computer or network by clicking Export. A saved list can be imported into another printer driver.

Auto Configure detects the devices installed on the printing system if it is connected over a network. Auto Configure can detect printing system devices such as input devices, output devices, RAM disk size, and storage device size. If a TCP/IP or WSD port is selected, the Auto Configure button appears in

Device Settings. Auto Configure updates the Device options list, Memory, RAM disk, and overview images to keep the printer driver consistent with the

printing system configuration. For some models, custom media types set in the printing system are updated in all driver media type lists. Auto Configure varies by operating system.

Printer Driver 3-3

Device Settings

Not all installed devices are detected by using Auto Configure. Before selecting OK in Device Settings, check the settings to make sure that they are correct.

Note: The default setting for Windows XP Service Pack 2 is for the Windows Firewall to be set to On. The setting can be changed to allow communication between the printing system and your computer. In the Windows Security

Alert dialog box, click Unblock.

Silent Auto Configuration

Silent auto configuration checks the printing system every 10 minutes for

changes in optional devices or memory. When a change is detected, the driver is automatically updated with the new settings. Silent auto configuration is only available for printer drivers installed in Windows 8, Windows Server 2012, Windows 7, Windows Vista, Windows Server 2008, or Windows Server 2008 R2.

In a client/server environment, this feature is unavailable to a client logged in as a restricted user.

Enabling Auto Configuration

The Auto Configure button can be used to detect all available device options when the printing system is connected to a network through a TCP/IP or WSD port.

Memory

Verify that all optional devices are attached to the printing system, and that it is

turned on and ready to print.

In Device Settings, click Auto Configure.

In Windows XP, the driver settings are updated immediately.

In Windows 8, Windows Server 2012, Windows 7, and Windows Vista, the Auto Configure dialog box opens. (For some models, the driver settings are updated immediately.) Select from Auto configure options:

Auto Configure Now

Click the button at any time to retrieve the current settings from the printing system. It is recommended to do this when the driver is first installed and when Silent auto configuration is turned off.

Silent auto configuration

Select to let the driver check the printing system at every occurrence of a fixed time period. The driver regularly checks for any changes in optional devices or memory.

Click OK in the Auto Configure and Properties dialog boxes.

Memory is the amount of standard and optional memory installed in the printing system. To maximize the downloading of printing system fonts, the driver must be set to match the total printing system memory.

3-4 User Guide

RAM Disk

Device Settings

Setting the Memory

By default, the Memory setting matches the standard memory in the printing system. If optional memory is installed, set the memory in the printer driver to match the total amount of memory.

Install optional DIMM memory in the printing system.

In Device Settings > Memory, type or select the amount of total installed

memory by clicking the up and down arrows until the text box shows the correct number of megabytes (MB).

If your printing system includes the Auto Configure feature, you can use it to obtain information about the memory size.

The RAM disk functions as a virtual storage device, saving print requests into the printing system’s memory. Because the RAM disk is temporary memory, all data stored there is lost when the power is turned off.

In a client/server environment, this feature is unavailable to a client logged in as a restricted user.

Note: When a storage device is installed, the RAM disk feature is inactive.

If selected, the Ignore application collation feature in the Compatibility Settings dialog box lets the driver control collation. RAM disk can then increase the print speed of collated multiple copies by sending the print job just once.

Setting RAM Disk

You can set the RAM disk to save print requests into the printing system’s memory.

At the printing system's operation panel, turn on RAM disk and set its size.

In Device Settings > Device options, select RAM disk.

In the RAM disk text box, type or select the desired RAM disk size. Click the up

and down arrows until the text box shows the correct number of megabytes (MB) available physically on the operation panel.

The maximum RAM disk size depends on the amount of installed memory.

Administrator Settings

Administrator Settings lets you set options that include controlling

accessibility, displaying features in the interface and setting a password to control access to the Administrator Settings options.

In a client/server environment, this feature is unavailable to a client logged in as a restricted user.

Printer Driver 3-5

Device Settings

General

In the General tab, an administrator can control the display of the Quick Print tab and the operation panel message. Some SNMP settings, a job e-mail notification, and other miscellaneous settings can also be selected.

Show Quick Print Tab

This option lets you control the display of the Quick Print tab. You can define basic print options into group profiles for improved accessibility.

With a cleared check box for Show Quick Print tab, the tab does not appear in the Printing Preferences dialog box.

To enable this feature, in Device Settings > Administrator > General, select Show Quick Print tab.

With a selected check box for the Show Quick Print tab, the tab appears in the Printing Preferences dialog box. When you select the Show Quick Print tab check box, you can access additional check boxes:

Hide other tabs displays only the Quick Print tab to the user.

Set Quick Print tab as default opens to this tab when you access Printing Preferences.

Hide Edit Quick Print control prevents users from customizing the Quick Print tab.

Operation Panel Message

You can specify settings to display the job name, user name, or department for the current job on the printing system's operation panel during printing. The printing system default names appear unless you set your own custom names.

You can set job name in the Job tab, and set the user name and department in the User Settings dialog box, accessed from Device Settings.

Displaying the Operation Panel Message

You can select job information to display on the operation panel.

In Device Settings > Administrator > General, select Operation panel

message.

Select from the following options to display on the operation panel during

printing:

Display job name

Display user name

Display department

Click OK in the Administrator Settings and Properties dialog boxes.

Send Count Information

This option lets you embed count information in the print job, which can be used by some applications for accounting purposes. Count information includes the number of copies produced as well as duplex printing, multiple pages per sheet, color mode, color page count, and paper size values.

When PDF is selected as the PDL, only color page count information is sent with PDF.

3-6 User Guide

Device Settings

To enable this feature, in Device Settings > Administrator > General, select Send Count information.

Send Application Name

This option lets you send the application name with a print job, so that a different printing process is used for each application.

This option is unavailable when PDF is selected as the PDL.

To enable this feature, in Device Settings > Administrator > General, select

Send Application name.

Associate Profile with Application

This option lets you set all printing from each installed application to use the same driver settings as defined in a profile. Before using this feature:

A profile must be created in the Profiles dialog box, accessed from any Printing Preferences tab.

An association must be created between a profile and an application in the Application Based Printing dialog box, accessed from the Profiles dialog box.

This feature is enabled by default. To disable this feature, in Device Settings > Administrator > General, clear the Associate Profile with application check box.

Note: Application Based Printing is only available for 32-bit operating systems.

Password Protect Administrator Settings

You can set Password protect administrator settings in the Administrator Settings dialog box to prevent unauthorized changes in this dialog box. If

selected, this setting prompts you to enter a password and confirm the password. This password protection blocks access to all Administrator

Settings options.

Setting the Administrator Password

In Device Settings > Administrator > General, select Password protect

administrator settings.

In the Password dialog box, enter a password, using at least 4 and no more

than 16 characters. Reenter the password in Confirm password and click OK.

Clearing the Administrator Password

In Device Settings, click Administrator.

In the Enter Password dialog box, type the password and click OK.

In the Administrator Settings dialog box, clear the Password protect

administrator settings check box and click OK.

Hide Factory Default Profile

This option lets you hide or show the Factory Default profile in the Quick Print tab and the Profiles dialog box.

Check box selected: The Factory Default profile does not appear in the lists.

Printer Driver 3-7

Device Settings

Check box clear: The Factory Default profile appears in the lists.

SNMP

Simple Network Management Protocol (SNMP) is an application layer protocol that governs the management of devices agents, and network management systems. Managed devices, such as printing systems, collect and store management information for the network management systems. Using the Auto Configure feature, SNMP security levels are set. With SNMPv3, encryption, and authentication support are provided. SNMP settings must be made in the printer driver and in the printing system’s home page.

The following SNMP options are available:

SNMPv1/v2c

It communicates with the managed device using Read community name and Write community name.

SNMPv3

Security enhancements for authentication and encryption require a user name and password. Authentication and privacy options are available by clicking Settings.

Apply to other models

This option displays a list of installed printing systems to apply the selected

SNMP settings.

SNMPv3 Options

You can select SNMPv3 options for secure communication with the printing system.

For some models, SNMPv3 is enabled when an optional network card is installed. These settings must match the network card settings. The network card has settings for both an authentication password and an encryption password, but they must both match the driver password.

Authentication

This option provides an algorithm to check that a transferred file has arrived intact. Message Digest 5 (MD5) and Secure Hash Algorithm 1 (SHA1) are hash algorithms used to authenticate packet data.

MD5

This option provides a cryptographic hash function with a 128–bit hash value.

SHA1

This option produces a message digest that is 160 bits long. SHA1 is the successor to MD5.

Privacy

This option uses encryption for secure communication. It is available after you select the Authentication option. You may select one privacy option. (The network card does not support AES encrypted communication.)

DES

This option uses the Data Encryption Standard for encryption. DES turns cleartext into ciphertext via an encryption algorithm. It encrypts and decrypts data using 8-byte blocks and a 56-bit key.

AES

3-8 User Guide

Device Settings

This option uses the Advanced Encryption Standard for encryption. AES is a symmetric block cipher that can process data blocks of 128 bits, using cipher keys with lengths of 128, 192, and 256 bits. It is more secure than DES.

Selecting SNMP Settings

SNMP settings in the driver must be set to match the settings in the printing

system’s home page.

In Device Settings > Administrator > General, click SNMP Settings.

Select SNMPv1/v2c or SNMPv3.

For SNMPv1/v2c, type the Read community name and Write community name, to a maximum of 32 characters.

For SNMPv3, type a User name to a maximum of 32 characters, and a Password from 8 to 32 characters.

To set authentication and privacy options for SNMPv3, click Settings.

In the SNMPv3 Settings dialog box, select from the available options, and click

OK.

Optional: Under Apply to other models, you can choose from available

models. The SNMP settings are applied to all selected models.

Click OK in the SNMP Settings dialog box.

Job E-mail Notification

This option lets you send an e-mail address with a print job. When the job finishes printing, the device sends an e-mail notification to the e-mail address. This is useful when the device is printing many jobs and a user must wait for a job to print.

For a restricted user in a client/server environment, the Administrator button in Device Settings becomes the Identity button. A user can enter e-mail notification data in the Identity Settings dialog box.

Selecting E-mail Notification Options

You can send an e-mail address with a print job, to notify you when the job finishes printing.

In Device Settings > Administrator > General, select Notify when printing is

completed.

Choose an e-mail address option:

Select Use specific e-mail address, and type a valid e-mail address. In a client/server environment, a client user can change this address.

Select Prompt for e-mail address, and click OK. When you click OK in the

Print dialog box, type a valid e-mail address in the Print Options or Identity Settings dialog box, and click OK.

Click OK in The Administrator Settings and Properties dialog boxes.

Printer Driver 3-9

Device Settings

Lock Settings

An administrator can specify settings at the tab or feature level in the driver, and then lock them. The settings are then applied to all print jobs, and changes are restricted. The settings are locked in Device Settings > Administrator > Lock Settings. For example, a driver setting could be set for printing duplex documents. This would save paper, resulting in cost savings and ecological benefits.

Locking a setting will also lock the feature where it appears in other tabs. For example, selecting Duplex will select and lock that feature in the Quick Print and Basic tabs.

The administrator can also set a password that is required to temporarily unlock a feature.

In a client/server environment, this feature is unavailable to a client logged in as a restricted user.

Lock Settings Options

The Lock Settings tab displays driver settings that an administrator can lock. Once locked, user changes are restricted and the settings are applied to all print jobs. Once the settings are made, the Password settings option can be accessed. This lets an administrator control usage of paper and toner amounts.

Black & White mode

This option disables all color settings and prints all jobs with black toner only.

EcoPrint

This option locks the EcoPrint setting.

Duplex

This option locks the current Print on both sides setting selected in the Quick Print or Basic tabs.

Multiple pages per sheet

This option locks the current Pages per sheet setting in the Quick Print tab and the Multiple pages per sheet setting in the Layout tab. The Pages per

sheet option in the Layout tab is not locked.

Profile with application

This option locks a defined profile of driver settings by application.

Application Based Printing is only available for 32-bit operating systems.

Job tab

This option locks settings selected in the Job tab.

Security settings

This option locks the Security Watermark in the Advanced tab. Security Watermark is an optional plug-in.

Password settings

The password set by the administrator locks the selected driver features. When the administrator sets the password, the Unlock icon appears in the driver tabs or the Application Based Printing dialog box. To unlock a feature, click Unlock and type the password.

Locking Driver Settings

In Device Settings > Administrator, click Lock Settings.

Select the check box for each driver feature to be locked.

3-10 User Guide

Device Settings

Select the Password settings check box if you wish to set a password to

temporarily unlock settings.

In the Password Settings dialog box, type a password from 4 to 16 characters. Retype the password in Confirm password, and click OK.

To remove the password, clear the Password settings check box. In the Unlock Password dialog box, type the password, and click OK.

To save your Lock Settings selections, click OK.

When a password is set, the Unlock icon appears in driver tabs where the locked features appear. To unlock a feature and change its settings temporarily, click Unlock and type the password.

User Login

User login provides job restriction by user, in contrast to the Job accounting

feature, which assigns privileges by division or department. A maximum of 1000 login user names and passwords can be can be created and stored in the printer driver and registered on the printing system. For some models, this feature is supported as User IDs and supports a maximum of 20 User IDs and passwords in the printing system, and 100 User IDs and passwords in the printer driver for use with multiple printing systems.

Users are identified by user name and password. The user name can be in the user principal name UPN format: username@domain.com. This feature limits printing privileges to specified users for secure printing and accounting. The number of pages printed by each user is tracked by the printing system.

Users added in the printer driver must also be manually registered at the printing system’s operation panel.

In a client/server environment, some options are unavailable to a client.

For a restricted user in a client/server environment, the Administrator button in Device Settings becomes the Identity button. A user can enter User Login data in the Identity Settings dialog box.

User Login Options

User login settings selected in the driver are applied to every print job sent from

your computer.

Note: For some models, the label "user ID" appears instead of "name" in the Administrator Settings dialog box.

Use specific name

This option can be used to specify a name and password to use the same User login for every print job. If this option is selected, the user does not have to type the name and password for each print job.

A client in a client/server environment can accept the default name and password set by the administrator or type another name and password. Clicking Reset restores the default values.

Prompt for name

This option prompts the user for a name and password. You can use a name that is not on the list, and the name is not added to the list. When sending a print job, type a name and password when prompted, and then click OK to print.

Printer Driver 3-11

Device Settings

If you type a name that is not registered on the printing system, the job prints only if Unknown ID Job is set to Permit on the printing system.

Prompt for name and validate

This option prompts for a name and password. For the job to print, the name and password entered must be on the Login user name list. You can use the Login user names entered in the Login user name list of the driver. When sending a print job, type a name and password when prompted, and then click OK to print. This option ensures that the job prints, only after verifying that the selected name is saved in the driver.

Validate user name (computer) or prompt for login user name

This option searches for the Windows User name in the driver’s Login user name list. Validation is done every time the user prints a job. If the Windows

User name exists in the Login user name list, the associated driver Login user name and password from the list are used for the print job. To release the print job, the user must enter the Login user name and password at the printing system's operation panel.

If a match is not found, the driver checks for administrator or user permissions. With user permissions, the print job is canceled, and the user is prompted to contact an administrator to establish printing permissions. With administrator permissions, the driver prompts for the Login user name and password. Along with the Windows User name, these are then added to the list so succeeding print jobs do not require the user to enter a Login user name and password again.

Click to add, delete, edit, import, or export login user names and passwords. Once a Login user name list is created, the list can be exported as a group by saving it as a text file (.CSV, .KXC, and .TXT). To import a Login user

name list, browse for an existing list and save it in your printer driver.

Printing with User Login

After login user names are assigned and user login mode is enabled on the printing system, you can choose User login to print in user login mode.

In a client/server environment, the client is automatically set to the User Login selection made in the server.

Note: For some models, the label “user ID” appears instead of “name” in the Administrator Settings dialog box.

In Device Settings > Administrator > User Login, select User Login.

Select a User Login option:

Use specific name

Prompt for name

The remaining User Login options become available when you create a login user name list.

Note: If you select the Use specific name or Prompt for name option, continue to step 5.

Under the Login user name list, click the buttons to view and manage the list.

Select from the remaining User Login options:

3-12 User Guide

Device Settings

Prompt for name and validate

Validate user name (computer) or prompt for login user name

Click OK in all dialog boxes.

Print the document from the application.

When the Print Options or Identity Settings dialog box appears, type or select

a name and password, and click OK. Login is required for some options.

Job Accounting

Job accounting gives an administrator control of a printing system. With Job accounting, account IDs (identification numbers) can be assigned to users or

departments. A specific account ID can be assigned, and then required before printing. After account IDs are created, from the printing system operation panel you can view the number of copies associated with a specific ID, as well as limit the number of copies for individual IDs. Account IDs can be a maximum of 8 digits. For some models, account IDs must be 4 digits or 7 digits.

Note: Job accounting must be enabled on the printing system. A maximum of 1000 account IDs can be assigned on the printing system and stored in the printer driver. The maximum number varies by printing system model.

In a client/server environment, some options are unavailable to a client.

For a restricted user in a client/server environment, the Administrator button in Device Settings becomes the Identity button. A user can enter Job Accounting data in the Identity Settings dialog box.

Job Accounting Options

Job accounting supports the following options:

Use specific account ID

Select this option to track the print jobs of a user or group with an account ID. It sends the account ID with each print job. An administrator can restrict a user or group from changing their account ID by using the Password protect administrator settings in the Administrator Settings dialog box.

A client computer in a client/server environment can accept the default account ID set by the administrator or type another account ID. Clicking

Reset restores the default values.

Prompt for account ID

Select this option to track the print jobs of a user or group with an account ID as well as prompt for an account ID. At the time a print job is sent, the user is prompted to enter a Job accounting ID.

Prompt for account ID and validate

Select this option to prompt for an account ID that is saved in the driver. When sending a print job, type an account ID when prompted, and then click OK to print. The account ID is validated against the account ID list. If typed incorrectly, you are prompted to type it again.

Display account ID list

Select this option to display the account ID list at the time of printing. The print job can be assigned to a user or group. The account ID list is stored in the driver and more than one ID must be established for the list to appear.

Printer Driver 3-13

Device Settings

Account IDs

Add, edit, or delete account IDs from the list stored in the driver. Account ID descriptions match the user or group with an account ID. After an account ID list is created, the list can be exported as a group by saving it as a text file (.CSV, .KXC, .TXT). To import an account ID list, browse for an existing list and open it.

Printing with Job Accounting

In Device Settings > Administrator > Job Accounting, select Job

accounting.

Select a Job Accounting option:

Use specific account ID

Prompt for account ID

The remaining Job accounting options become available when you create an account ID list.

Note: If you select the Use specific account ID or Prompt for account ID option, continue to step 5.

Under the Account IDs list, click the buttons to add, delete, edit, import, or

export Account IDs in the list.

Select from the remaining Job accounting options:

Prompt for account ID and validate

Display account ID list

Click OK in all dialog boxes.

Print the document from the application.

For some options, when the Print Options or Identity Settings dialog box

appears, type or select an account ID, and click OK.

Policy Manager

Policy Manager is a server-based application that provides centralized user

authentication, authorization, user access control, and secure pull printing features. The KYOCERA Net Policy Manager application must be installed separately. It is also necessary to make settings in the printer driver Device Settings > Administrator > Policy Manager to integrate with Policy Manager. This Policy Manager driver feature is installed as an optional component of the driver.

The XPS driver does not support Policy Manager. For more information about Policy Manager, please contact your printing system dealer.

An administrator can set the Policy Manager server and user information for users and groups to print according to defined policies.

When policies restrict printing features, Policy Manager reconfigures the printer driver so that the restricted printing features are unavailable to the user or group. The Policy Manager options let you choose how conflicts are handled between a policy and a driver selection.

3-14 User Guide

Device Settings

Secure pull printing lets the user choose a printing system after the job is sent. To use the secure pull printing feature, the driver must be connected to the Policy Manager spooler server using the Policy Manager spooler port. Print jobs are held in the Policy Manager spooler server until the user is authenticated on the printing system.

When KYOCERA Net Policy Manager 2.0 is installed, the driver displays user accounting information while printing.

For a restricted user in a client/server environment, the Administrator button in Device Settings becomes the Identity button. A user can enter Policy Manager data in the Identity Settings dialog box.

Selecting Policy Manager Options

After Policy Manager is installed and the server is set up, you can use the printer driver’s Policy Manager tab to set server and user information.

In Device Settings > Administrator > Policy Manager, select Policy

Manager.

Enter the server address and port number. The default port number is 9094.

Select an authentication option:

Use Windows authentication

Select to use Windows login information for Policy Manager authentication. The Policy Manager Login dialog box does not appear during printing unless Windows authentication fails. If selected, continue to step 5.

Use specific name

Select to enter specific login information. When selected, continue to step 4.

Type the Login user name and Password. For some models, type the user

name after the domain name that appears automatically, or you can remove the domain name. The Login user name can be in the user principal name (UPN) format to support multiple domains: username@domain.com

You can select No notifications for policy conflicts if you do not want a

message to appear when policy conflicts occur during printing. When selected, choose a printing result:

Continue printing

Apply the policy and print the job

Cancel printing

Cancel the print job

You can select Display user accounting information if you want an

accounting information message to appear after printing. The message displays a summary of pages printed. Printing limits and pages remaining also appear if limits were set in Policy Manager.

Click OK in all dialog boxes.

Printer Driver 3-15

Device Settings

Printing with Policy Manager

With Policy Manager set to on in the driver, you can send a private and secure print job.

Print the document from the application. You can click Preferences or

Properties to open the Properties dialog box and view printing restrictions set

by the policy.

If the Policy Manager Login or Identity Settings dialog box appears, enter a

Login user name and password. This dialog box is generated when an invalid or blank Policy Manager user name or password is set in the driver. The Policy Manager Login dialog box does not appear if Use Windows authentication is selected in Administrator > Policy Manager, except when the Windows authentication fails.

You can click Do not ask again to use the most recently-saved Login user

name and password for each print job. When selected, the Policy Manager Login dialog box does not appear again.

Click Log in to send the print job to the KYOCERA Net Policy Manager spooler

server, where the Login user name and password are authenticated. Otherwise you can print directly to the printing system instead of using the KYOCERA Net Policy Manager spooler server.

The print job appears in the Spooler folder in KYOCERA Net Policy Manager or in Client Viewer.

User Settings

Before the job is printed, the Print Options dialog box appears with information

about your print quota. Click OK to continue.

After the print job is sent to the KYOCERA Net Policy Manager spooler server,

the Policy Manager dialog box appears displaying a summary of pages printed. Printing limits and the number of remaining pages also appear if limits were set in Policy Manager. Click OK.

On the printing system’s operation panel, enter the Login user name and

password to print all jobs under the Login user name. You can print from any printing system managed by the KYOCERA Net Policy Manager server.

User Settings lets you specify user and department names, select the default unit of measure, and change the driver display language.

In a client/server environment, this feature is unavailable to a client logged in as a restricted user.

Identification

Identification lets you identify your print job with a User name and Department information, to a maximum of 31 characters. For some models,

they can appear in the Operation panel message, or the User name can be used to identify a print job stored on the storage device.

3-16 User Guide

Device Settings

Setting User Identification

In Device Settings > User, type your preferred name in the User name text

box.

Type your department or group name in the Department text box.

You can type a maximum of 31 characters in the User name and Department text boxes.

Click OK in the User Settings and Properties dialog boxes.

Units

You can set Inches or Millimeters as the unit of measurement. This is used for the following settings:

Custom page size setting in the Page Sizes dialog box in the Basic tab.

Spacing setting in the Add Watermark and Edit Watermark dialog boxes in the Advanced tab.

Poster settings in the Layout tab.

Gutter settings in the Layout or Finishing tab.

Index tab dividers settings in the Publishing tab.

Selecting a Unit of Measurement

In Device Settings > User, select Inches or Millimeters.

Click OK in the User Settings and Properties dialog boxes.

Language Preference

The Language preference option specifies the user interface language of Device Settings in Properties and all tabs of Printing Preferences.

Available languages vary depending on your locale and your computer settings.

Setting Language Preference

In Device Settings > User, select the desired language from the Select

language list.

Click OK in the User Settings and Properties dialog boxes.

PDL (Page Description Language)

A Page Description Language (PDL) specifies the contents and layout of a printed page. In Device Settings, you can choose from PCL XL (Printer Command Language XL), PCL 5e/c, KPDL (Kyocera Page Description Language), or PDF (Portable Document Format). To add PDF to the list of PDL choices, you must install the Output to PDF plug-in. The printer default is PCL XL, which is suitable for most printing purposes. For some color models the default is KPDL.

After you select a PDL, the selection appears in the lower corner of the overview image in Device Settings and in all Printing Preferences tabs. You can change the PDL temporarily from any Printing Preferences tab.

Printer Driver 3-17

Device Settings

In GDI compatible mode, vector graphics are rasterized for printing as bitmap images. Use the GDI compatible mode option to improve the output quality of the graphic created by the application.

In a client/server environment, this feature is unavailable to a client logged in as a restricted user.

If your application supports the XML Print Specification, then XPS printing can be performed after installing the XPS driver. With the XPS driver, the only available PDL is XPS.

PDL Options

The PDL options, available in the PDL Settings dialog box, are accessed in Device Settings.

PCL XL

The most recent version of HP PCL and PCL 6. This PDL includes PCL 5e/c features. PCL XL lacks backward compatibility with earlier PCL versions, though it is enhanced over PCL 5e/c in these areas:

Reduced file size

Better print speed

Faster return to application

Supports Security watermark

PCL 5e/c

Fully compatible with earlier PCL versions

Bidirectional communication support

Wide selection of fonts for use with Microsoft Windows applications

Allows more options for utilizing PRESCRIBE commands within applications

Complex graphics might not print as well

Fast 1200 dpi and Form gallery unavailable

Start of the page / End of the page available in Prologue/Epilogue

KPDL

KPDL is used when printing from applications that support PostScript 2 or 3.

An emulation of PostScript printing

An optional KPDL upgrade kit may be required for some models

Strong graphics reproduction

Print speeds may be slower than PCL 5e/c

Requires more printer memory than PCL 5e/c

Enables native TrueType font downloading

Supports most Graphics Settings options

EMF Spooling unavailable when Allow data passthrough is selected

Supports EcoPrint; for some models, you can select varying toner levels

PDF

Output to PDF is a plug-in that lets you print or save documents from multiple

sources to Adobe Portable Document Format (PDF). The PDF format is

3-18 User Guide

Device Settings

independent of the operating system and application software used to create documents.

Use as an alternative to existing commercial applications for creating PDF documents

Documents saved as PDF retain their original appearance, and can be viewed and printed with the free Adobe Reader on Windows, Mac OS, and UNIX platforms

With PDF selected as the PDL, only a limited set of driver options is available

PDL Settings

For some page description languages, additional settings are available when you click Settings.

PCL XL Settings or KPDL Settings

Enable smart duplex printing

This option automatically keeps a sheet of paper from being sent through the duplex unit if the sheet is only printed on one side. The duplex unit is bypassed for the following types of print jobs: a one page document, one page from a multi-page document, or a multi-page document that prints onto a single sheet. Selecting this option can reduce wear on the mechanical duplex unit, and result in comparatively faster printing times. Some models support this feature and bypass the duplex unit even if the check box is not selected.

PCL XL Settings

Skip printing blank pages

This option prevents the printing system from outputting any page that contains no data, or that has, at most, one space character. Selecting this option can save paper, and result in comparatively faster printing times. This feature is for regular printing (not for booklet, duplex or multiple pages per sheet).

Disable auto media type switching

This option controls how automatic media switching behaves when the selected paper source runs out paper. When selected, printing stops until you load more paper of the same size and type. When the check box is clear, the printing system automatically switches to another paper source loaded with the same page size and media type. This option is available for some models.

KPDL Settings

Allow data passthrough

This option reduces errors when printing complex jobs from applications that use PostScript formatting. When selected, EMF spooling is unavailable in the Advanced tab.

PDF Settings

Provides options for printing and saving documents to Adobe PDF format. See PDF topics for details.

Selecting a PDL in Device Settings

You can select a default page description language (PDL) and additional settings. You can also change the PDL temporarily from any Printing Preferences tab.

Printer Driver 3-19

Device Settings

In Device Settings > PDL, select the desired page description language from

the Select PDL list.

You can select the GDI compatible mode option to improve the output quality

of graphics created by your application.

Click Settings if the PDL is set to PCL XL, KPDL or PDF.

If you select PCL XL, you can click Settings to open the PCL XL Settings dialog box and select Skip printing blank pages, Enable smart duplex printing, and Disable auto media type switching.

If you select PDF, you can click Settings to open the PDF Settings dialog box.

Click OK in the PDL Settings and Properties dialog boxes.

PDF

Output to PDF is a plug-in that lets you print and save documents from multiple

sources to Adobe PDF format. This feature can be used as an alternative to existing commercial applications for creating PDF documents. Documents saved as PDF retain their original appearance, and can be viewed and printed on Windows, Mac OS, or UNIX operating systems.

For a document using mixed paper sizes, all pages in the PDF use the size of the first page.

Note: With PDF selected as the PDL, only a limited set of driver options are available.

PDF Options

You can select PDF options if you have installed the Output to PDF plug-in.

The PDF Settings dialog box contains the following options.

PDF Settings

Embed fonts

This option ensures that document fonts appear accurately in the PDF file on screen. This option ensures accurate reproduction but significantly increases the file size.

Compress data

This option enables flat compression for the generated PDF document. This option significantly reduces the file size. Additional compression options are available within Adobe Acrobat.

Security

This option applies encryption to the PDF document. Click Settings for additional Security settings. See the next section for details.

Print and save

This option lets you print and save a document as a PDF file. Click Settings for additional Print and save settings.

3-20 User Guide

Device Settings

Security Settings

This option lets you select an encryption level and create passwords for the generated PDF file.

The following security options are available:

Encryption

Encryption provides password protection so that a document cannot be opened or altered by unauthorized users.

Arc4 40 (some models, 40 bit)

This encryption option provides low level security for a PDF document. This option supports Adobe Acrobat and Adobe Reader 6.0, or earlier.

Arc4 128 (some models, 128 bit)

This encryption option provides low level security for a PDF document. This option supports Adobe Acrobat and Adobe Reader 6.0, or later.

AES 128

This encryption option provides high level security for a PDF document. This option supports Adobe Acrobat and Adobe Reader 7.0, or later.

AES 256

This encryption option provides high level security for a PDF document. This option supports Adobe Acrobat and Adobe Reader 9.0, or later.

Passwords

Select passwords for changing security settings and for opening a document. Passwords are supported to a maximum of 16 characters in length.

Require password to change security settings

Type an Owner password. Within Adobe Acrobat, this password is required to change the document restrictions in the Files > Properties > Security section. When a document with this password is opened in Adobe Reader, it cannot be printed or edited, and document data cannot be copied.

Require password to open document

Type a User password. The user password must be entered at the time the PDF document is opened. This password must be different from the owner password.

Print and Save Settings

This option lets you print and save a document as a PDF file.

Save to file only

A PDF file is created and saved locally.

Save to file and print

A PDF file is created, saved locally, and sent to print.

After you select between these two options, you can choose the following option:

Automatically save to default file

A PDF file can be saved automatically as a default file to be used again.

You can then select from the following options:

Replace default file

This option replaces an existing file having the default file name KxPdf.pdf.

Use default file + date and time

Printer Driver 3-21

Device Settings

This option lets you use the default name and add a date and time stamp each time the document is saved.

Default file directory

This option lets you browse to a location to save your PDF.

Printing and Saving to PDF

You can print a document and save it to Adobe PDF, if you have installed the Output to PDF plug-in.

In Device Settings > PDL, in the Select PDL list select PDF.

Click Settings.

In the PDF Settings dialog box, select Print and save.

Click Settings, and select from print and save options. See the PDF Options

topic for details.

Click OK in all dialog boxes.

Open and print the document.

Name and save the PDF file.

XPS Driver

For Windows 8, Windows Server 2012, Windows 7, or Windows Vista Service Pack 2 with the latest platform updates, you can use the XML Paper Specification (XPS). This Page description language provides an additional method for displaying, processing, and printing documents. As both a PDL and a document format, XPS requires compatible printing system hardware and software written for the Windows Presentation Foundation (WPF) architecture.

PCL and KPDL are not compatible with an XPS environment. Therefore, an XPS driver supports a single PDL setting. The XPS driver can be installed from the Product Library disc. In the Installation Method menu, click Custom Mode, and on the Custom Installation page, select KX XPS DRIVER.

Some driver features are unavailable when using the XPS driver.

Compatibility Settings

Compatibility Settings let you specify media source values, disable reverse

order printing for face-up output, override the application's Collate setting, and combine the Source and Media type lists in the Basic tab.

In a client/server environment, this feature is unavailable to a client logged in as a restricted user.

Media Source Enumeration

Media source enumeration supports compatibility for media source values

unique to the printer driver, such as those for cassettes or feeders. Your newly installed printer driver maintains identical media source support with the driver it replaces, whether for this driver or one from another manufacturer. If media

3-22 User Guide

Device Settings

source macros exist for the older driver, then the alignment of media source values maintains support without the need to change the macros.

Use the Driver Info utility (\Utility\Driver Info\DrvInfo.exe) to compare the source values for all installed drivers.

If the values for a given media source differ between printer drivers, you can reassign an enumerated value to create a match between the drivers.

Setting Media Sources

In Device Settings > Compatibility, from the Media source enumeration list

select the paper supply method. The current value is listed in the Enumerated value box.

Type an Enumerated value for the media source, and click Apply. To align

settings with a different driver, this value should align with those in the other driver.

Click OK in the Compatibility and Properties dialog boxes.

You can restore all the options in Compatibility to the default by clicking Reset.

Disable Face-Up Reverse Page Order

Disable face-up reverse page order produces the first page of a face-up job

on top and the last page on the bottom.

With the check box selected, face-up reverse page order is disabled.

With the check box cleared, the default reverse page order is enabled.

Setting Face-Up Reverse Page Order

You can reverse the order of face-up printing.

In Device Settings > Compatibility Settings, select Disable face-up reverse

page order.

Click OK in the Compatibility Settings and Properties dialog boxes.

You can restore all the options in Compatibility Settings to the default by clicking Reset.

Ignore Application Collation

This option bypasses the Collate setting in software applications, and gives priority to the printer driver setting.

With the check box selected, the printer driver Collate setting is used.

With the check box cleared, the application Collate setting is used.

Selecting Printer Driver Collation

In Device Settings > Compatibility, select Ignore application collation.

Click OK in the Compatibility Settings and Properties dialog boxes.

You can restore all the options in Compatibility Settings to the default by clicking Reset.

Printer Driver 3-23

Device Settings

Combine Source and Media Type Lists

You can change the driver's Basic tab so that Media type and Source are combined into one list, labeled Source. In the combined list, Media types are listed first, followed by cassettes and Manual Feed.

Creating a Combined Source List

In Device Settings > Compatibility, select Combine source and media type

lists.

Click OK in the Compatibility Settings and Properties dialog boxes.

You can restore all the options in Compatibility Settings to the default by clicking Reset.

Enable Manual Duplex on Network Port

For some models that do not have a duplex unit, this option lets you use manual duplex to print through a network port. Enable manual duplex on network

port is available when the printing system is connected through a network port.

Removing a Plug-in

You can remove an installed plug-in from the driver. If removed, the plug-in features do not appear in the driver interface.

Note: To remove the Output to PDF module, PDF must not be selected as the PDL.

In Device Settings, click Kyocera logo > Plug-in.

Select a plug-in module from the list and click Delete, then Yes.

Click OK in all dialog boxes.

3-24 User Guide

4 Quick Print

In the Quick Print tab, you can apply basic print settings to print jobs. You can select options quickly in a simple user interface.

Any Quick Print settings can be saved as a group, called a profile, and applied to any print job. Profiles support common printing tasks. Selections vary according to printing system model, optional devices, or driver version.

To return to the original settings, click Reset. The Reset button is available when accessing the printer driver from the application's Print dialog box.

An administrator can set the view of the Quick Print tab through the

Installation process, or in Device Settings > Administrator.

Quick Print Options

You can set one or more print options on the Quick Print tab. You can create your own customized view of print options with Edit Quick Print. And you can also select from profiles that have been set with predefined options for frequently run print jobs.

Orientation

Click the Orientation icon repeatedly to change between portrait, landscape, rotated portrait, and rotated landscape printing formats. The rotated options rotate the job orientation 180 degrees.

Color

Color lets you choose full-color printing or printing with black toner only. When

the selection appears in color, all color settings in the driver are enabled. Color cannot be chosen if Black & White mode is selected in Device Settings > Administrator > Lock Settings.

Click the Color icon to change between full color and black and white printing.

Collate

Collate specifies the order in which the pages of a multiple copy job are printed.

With Collate on, the first time the print job is sent to the printing system the data is rendered as page images in the printing system's memory. The remaining job copies are printed from the stored data. This avoids the extra processing involved in sending every copy from the computer to the printing system.

Click the Collate icon to change between On, On (reverse order), Off (reverse order), and Off.

With Collate on, the driver prints the complete job set by set (123, 123). With Collate off, it prints each page by set (111, 222). For example, with Collate on, three copies of a five-page document output as pages one through five in succession, three times.

The printer driver automatically overrides the application’s Collate setting and uses the printer driver setting. You can use the application's Collate setting by

Printer Driver 4-1

Quick Print

clearing the Ignore application collation check box in the Compatibility Settings dialog box accessed from Device Settings.

If On (reverse order) or Off (reverse order) is selected, the printed pages appear in reverse order. One or both of these options are available when Printer default is not selected under Destination in the Basic tab. For a faceup destination, Off (reverse order) can be disabled in Device Settings >

Compatibility Settings.

Duplex Printing

Duplex printing is printing on both sides of each page. Some models contain a standard or optional duplex unit that turns the paper over to allow printing on the reverse side. Flip on long edge or Flip on short edge must be selected to print on both sides of the cover and insert pages.

Flip on long edge

Turn the long edge of the page to view the content.

Flip on short edge

Turn the short edge of the page to view the content.

Manual Duplex

For some models, manual duplex lets you print on both sides of a sheet without a duplex unit. After the first half of the print job has been printed, the job can be flipped over and fed from the cassette for the second side printing. Click the Duplex icon repeatedly to change between flipping on long edge, flipping on short edge, and off.

To use manual duplex in the Quick Print tab, the Source selection in the Basic tab must be set to Cassette 1 or Cassette 2.

Flip on long edge

Turn the long edge of the page to view the content.

Flip on short edge

Turn the short edge of the page to view the content.

The manual duplex instruction sheet is printed by default. If you do not want to use this feature, clear the Print manual duplex instructions check box in the

Basic tab.

Pages per Sheet

Pages per sheet prints several pages on a single sheet of paper for the

purpose of reviewing the document and conserving paper. The size and readability of the multiple pages decrease as the number of pages per sheet is increased. Click the Pages per sheet icon repeatedly to change between 2 pages per sheet, 4 pages per sheet, and off. You can set the arrangement of the pages from the Layout tab as well as print borders around each of the pages.

When Pages per sheet is selected, Scaling, Full bleed, and Poster are unavailable in the Layout tab.

EcoPrint

EcoPrint changes the text and graphics to appear lighter in the print job. EcoPrint does not increase print speed. Click the EcoPrint icon to change

between on and off. For some models, you can select varying toner levels in the Imaging tab. For some models, EcoPrint is available only when KPDL is selected as the PDL.

4-2 User Guide

Staple

The Staple feature lets you create stapled document sets. Click the Staple icon to change between stapling (On) and not stapling (Off) the print job. Additional staple options can be selected in the Finishing tab.

Punch

The Punch feature places punches along the edge of the printed pages so that the pages can be bound together or placed in a binder. Click the Punch icon to change between punching (On) and not punching (Off) the print job. Additional punch options can be selected in the Finishing tab.

Edit Quick Print

The assortment of icons at the top of the Quick Print tab can be customized to include features that you use most often. Any number of icons from 0 to 5 can be displayed. All icons can be removed from view if you want to use only the Printer profiles options in the Quick Print tab.

The number of available features depends on the printing system model. If a feature, such as Staple, is added to the Quick Print tab but a finishing device is not installed, the icon appears as unavailable. Once the device is installed and selected in Device Settings, the icon becomes active.

Quick Print

Note: An administrator can hide the Edit Quick Print button by selecting Hide Edit Quick Print control in Device Settings > Administrator. The Edit Quick Print button is unavailable when the driver is accessed from an application’s Print dialog box.

Editing Quick Print Options

Depending on your operating system:

Windows 8 and Windows Server 2012: open the Control Panel, and then click View devices and printers.

Windows 7 and Windows Server 2008 R2: click Start, and then click Devices and Printers.

Windows Vista and Windows Server 2008: click Control Panel and then click or double-click Printers.

Windows XP and Windows Server 2003: click Start > Printers and Faxes.

Right-click your printing system model and click Printing Preferences.

Select the Quick Print tab.

Click Edit Quick Print.

In the Edit Quick Print dialog box:

To add a feature to the Quick Print tab, select the feature under Available controls, and click the right arrow to move the feature to Selected controls.

A maximum of 5 features can appear under Selected controls.

To remove a feature from the Quick Print tab, select the feature under

Selected controls, and click the left arrow to move the feature to Available controls. To use only the Printer profiles in the Quick Print tab, move all features to Available controls.

Printer Driver 4-3

Quick Print

Profiles

Click the up and down arrows to change the position of the features under

Selected controls. The feature at the top appears on the left in the Quick Print tab.

To restore the list to factory default options, click Reset.

Click OK to save your settings.

You can save printer driver settings as a profile. You can select multiple options in the Quick Print tab and the other Printing Preferences tabs, save them to a profile, and use all of them at once when you apply the profile. You can then use that profile to print the same type of print job again without having to reselect all the settings. In Printing Preferences, the Save as and Profiles buttons appear at the bottom of all tabs.

A maximum of 26 profiles can be established in one driver, including the Factory Default profile. In Device Settings > Administrator, you can choose to hide the Factory Default profile. Settings made in Device Settings tab cannot be saved to a profile.

Any profile except Factory Default can be edited, imported, and exported.

Selecting a Profile

Quick Print tab

In the Quick Print tab, select a profile. The settings list shows a summary of

settings for that profile.

Click Apply.

Click OK.

Profiles dialog box

In any of the Printing Preferences tabs, click Profiles.

In the Profiles dialog box, select a profile. The settings list shows a summary of

settings for that profile.

Click Apply.

Click OK.

Saving a Profile

The Save As Button

Set the printing options you want for your print job by opening Printing

Preferences and selecting all your driver settings.

In any tab, click Save as.

4-4 User Guide

To identify the profile, type a Name, select an Icon, and type a Description.

Click OK to save the profile.

The newly added profile appears in the Profiles dialog box and the Quick Print tab.

Note: To reset the printer driver to default settings, select the Factory Default profile, if available, and then click Apply. This clears the settings of a selected profile.

You can remove a profile by clicking Profiles to open the Profiles dialog box. Select the profile in the Select profile list and click Delete. You cannot delete the Factory Default profile.

The Profiles Button

Set the printing options you want for your print job by opening Printing

Preferences and selecting all your driver settings.

In any tab, click Profiles.

Quick Print

Click Save.

To identify the profile, type a Name, select an Icon, and type a Description.

Click OK to save the profile.

The newly added profile appears in the Profiles dialog box.

Click OK to close the dialog box.

Note: To reset the printer driver to default settings, select the Factory Default

profile, if available, and then click Apply. This clears the settings of a selected profile.

You can remove a profile by clicking Profiles to open the Profiles dialog box. Select the profile in the Select profile list and click Delete. You cannot delete the Factory Default profile.

Editing a Profile

In any tab, click Profiles.

In the Select profile section, select the profile to be edited, and then click Edit.

You can edit any of the three options: Name, Icon and Description.

Click OK to save the edited changes.

The newly edited profile appears in the Profiles dialog box and the Quick Print tab.

Printer Driver 4-5

Quick Print

Click Apply to use the selected profile to the current print job, or click OK to

close the dialog box.

Importing a Profile

In any tab, click Profiles > Import.

Browse for an existing profile (.KXP), select it, and then click Open.

A message appears if any of the profile settings in the imported file are unavailable in the existing driver. Select Yes to import the profile, or No to cancel the import.

If you selected Yes, the newly imported profile appears in the Profiles dialog box.

Click Apply to use the selected profile for the current print job, or click OK to

close the dialog box.

The newly added profile appears in the Quick Print tab.

Exporting a Profile

In any tab, click Profiles.

In the Select profile section, select the profile to be exported, and then click

Export.

In the Export Profile dialog box, name and save the profile.

Click OK to close the Profiles dialog box.

Application Based Printing

An administrator can associate a profile with an application so that all printing from the application uses the same profile settings. This makes profiles easier to use and ensures consistent printing from an application. For example, a duplex printing profile can be applied to all spreadsheet printing to save paper, or reports in Microsoft Word can be set to print with consistent stapling and print quality.

Associations between profiles and applications can be created at any time in the Application Based Printing dialog box, accessed from the Profiles dialog box. A maximum of 25 associations can be created. To use the associations in printing, you must select Associate Profile with application in Device

Settings > Administrator > General.

Note: Application Based Printing is only available for 32-bit operating

systems.

In a client/server environment, a user on a client computer can view details about server associations but cannot change settings or select another profile.

Adding an Association

In any tab, click Profiles.

4-6 User Guide

In the Profiles dialog box, click Application.

In the Application Based Printing dialog box, click Add.

In the Add Association dialog box, enter a name for the association, to a

maximum of 31 characters.

Under Select application, choose an application by one of the following

methods:

Select Application name, and select an installed application from the list.

Select Filename (*.exe), and enter a valid executable file name (.EXE) for an application that allows printing, or click Browse to find a file located on your computer.

Under Select profile, select a profile from the list.

Click OK in the Add Association and Application Based Printing dialog

boxes to create the association.

Quick Print

You can remove an association by selecting it and clicking Delete.

Editing an Association

In any tab, click Profiles.

In the Profiles dialog box, click Application.

In the Application Based Printing dialog box, select the association to be

edited and click Edit.

In the Edit Association dialog box, you can change desired settings under

Association name, Select application, or Select profile.

Click OK in the Edit Association and Application Based Printing dialog

boxes to save the revised association.

Printer Driver 4-7

5 Basic

In the Basic tab, you can specify the most commonly used printer driver settings. (Selections vary according to printing system model.)

To return to the original settings, click Reset. For some models, this also restores the Booklet selection in the Layout tab and the Staple, Punch, and Offset jobs selections in the Finishing tab, if selected. The Reset button is available when accessing the printer driver from the application's Print dialog box.

Print Size and Page Size

Print size controls the output page size of the document. To use this setting,

ensure that the Page Sizes setting matches the page size setting in your application. If the Print size is different from the page size in your application, then each page is enlarged or reduced to match the Print size. The percentage value shown in brackets indicates the size of the Print size setting relative to the Page Sizes setting. If the Page Sizes does not match the page size setting in the application (the size of the original) then, in most cases the Print size is ignored and the document is printed based on its original size.

You can create a page size with your chosen dimensions for printing on nonstandard size paper. You can then save the custom setting to the Page Sizes and Print size lists for later selection.

Custom page size displays the unit of measurement in inches or millimeters. You can change the Units setting in the User Settings dialog box, accessed from Device Settings.

Creating a Custom Page Size

In Basic > Print size, select Custom.

In the Page Sizes dialog box, click New.

A default custom name appears in the Name box. Type a name for your custom

page size.

Type or select values for the height and width. If the height or width value

exceeds the allowable limit, it automatically adjusts to the limit after Apply or OK is clicked.

When finished, click Apply.

Click OK to close the Page Sizes dialog box.

The custom page size appears in the Print size list, which is used for enlarging and reducing the sizes of prints.

5-1 User Guide

Source

To delete a custom page size from the Page Sizes dialog box, select the name of the custom page size and then click Delete.

Printing with Custom Size Pages

Load custom-sized paper into the MP tray.

In the Basic tab, select the name of your custom page size in the Print size list.

Click OK to return to the Print dialog box.

Click OK to start printing.

Source specifies the tray or cassette that supplies paper for a print job. The

default is Auto source selection, which instructs the printer to search for the media requested by the application or the printer driver. If the selected tray or cassette empties during a print job, then the printer searches for another source, and continues the job.

Some media types, such as transparencies, labels, envelopes, and tab divider sheets must be supplied from the MP tray. Ensure that the paper is properly loaded by following the instructions outlined in the printing system's Operation

Guide.

Basic

Copies

Carbon Copies

Note: Source and Media type are separate items in the dialog box, but can be combined using the Combine source and media type lists setting in Device Settings > Compatibility. If they are combined, Media type is

unavailable on the Basic tab, and media types can be selected in the Source list.

This setting specifies the number of copies to print. You can print up to 999 copies. For some models, the maximum is 9,999.

This feature lets you print additional copies on paper from different trays or cassettes. This is useful for printing copies of documents such as invoices on different colored paper or media type. The maximum number of copies can be printed for each carbon copy.

You can use the Prologue/Epilogue feature in the Advanced tab to add a logo or heading to each carbon copy.

When Carbon copies is selected, Booklet in the Layout tab, and all the features on the Publishing tab are unavailable.

Printing Carbon Copies

You can print additional copies on paper from different trays or cassettes.

In the Basic tab, select a source and number of copies for the original copy.

Printer Driver 5-2

Basic

Collate

For each carbon copy, load the desired media types or colored paper into

additional paper sources.

Click the Carbon copies icon.

Click Settings.

In the Carbon Copy Settings dialog box, select the number of copies for each

source.

Select a Source or Media type or both for each carbon copy.

Click OK to return to the Print dialog box.

Click OK to start printing.

Collate specifies the order in which the pages of a multiple copy job are printed.

Click the icons to change between on and off.

With On selected, the first time the print job is sent to the printing system the data is rendered as page images in the printing system's memory. The remaining job copies are printed from the stored data. This avoids the extra processing involved in sending every copy from the computer to the printing system.

With On selected, the driver prints the complete job set by set. With Off selected, it prints each page by set. For example, with On selected, three copies of a five-page document outputs as pages one through five in succession, three times.

The printer driver automatically overrides the application's Collate setting and uses the printer driver setting. You can use the application's Collate setting by clearing the Ignore application collation check box in the Compatibility Settings dialog box accessed from Device Settings.

Compatibility Settings.

Printing Collated Documents

In the Basic tab, click the Collate icons to change between on and off.

Type or select the number of complete sets of the print job in the Copies box.

The document page count must not exceed the printer tray capacity.

Click OK to return to the Print dialog box.

Click OK to start printing.

5-3 User Guide

Orientation

Media Type

Basic

This setting specifies the paper orientation of the print job. Click the Portrait, Landscape, Rotated portrait, or Rotated landscape icons. If a rotated option

is selected, the print job orientation is rotated 180 degrees.

Media type instructs the printer to search for the type of media that is requested by the application or the printer driver. The choices shown may change depending on the selection in Source. For some models, the default is Unspecified and if selected, the driver does not switch to another source tray if the selected tray is empty. If Auto media selection is selected, then the printer searches for another tray or cassette using the same paper size or media type. Automatic selection of media types can be disabled in the PCL XL Settings dialog box.

For some models, you can display the custom media type names from the printing system. If any names have been changed on the printing system, the new names appear in place of default names. To display the printing system names, use the Auto Configure feature in Device Settings.

Destination

Color

Note: Source and Media type are separate items in the dialog box, but can be combined using the Combine source and media type lists setting in Device Settings > Compatibility Settings. If they are combined, Media type is unavailable on the Basic tab, and media types can be selected in the Source list.

This setting specifies which output tray is used for the print job output. For some models with an optional mailbox installed, select a mailbox option, and then click Mailbox. In the Mailbox dialog box, select the desired mailbox, and then click OK.

For color models, the following options are available:

Full color

This mode prints full four-color text and graphics.

Black

This mode prints with black toner only, suppressing all color settings.

Click the icons to change between Full color and Black.

Full color and Black also appear in the Quick Print tab and in the Imaging tab. Changes in Quick Print, Basic, or Imaging tabs are reflected in the other tabs.

Printer Driver 5-4

Basic

EcoPrint

Duplex Printing

Printing in Duplex Mode

EcoPrint makes the entire image, text and graphics, appear lighter in the print

job. EcoPrint does not increase print speed. Click the icons to change between on and off. For some models, you can select varying toner levels.

EcoPrint also appears in the Quick Print tab and in the Imaging tab. Changes in Quick Print, Basic, or Imaging tabs are reflected in the other tabs.

Flip on long edge

Turn the long edge of the page to view the content.

Flip on short edge

Turn the short edge of the page to view the content.

Manual Duplex

In the Basic tab, click the Flip on long edge or Flip on short edge icon.

Click OK to return to the Print dialog box.

Click OK to start printing.

Duplex printing is printing on both sides of each page. Click the icons to change between Flip on long edge, Flip on short edge, and Off. For some models, manual duplex lets you print on both sides of a sheet without a duplex unit. After the first half of the print job has been printed, the job can be flipped over and fed from the cassette for the second side printing. Manual duplex is unavailable when any of the options in the Publishing tab are used.

In a client/server environment, this feature is unavailable to the client.

Flip on long edge

Turn the long edge of the page to view the content.

Flip on short edge

Turn the short edge of the page to view the content.

To use manual duplex:

The printer must be set to a local port. Or when using a network port, select Enable manual duplex on network port in the Compatibility Settings dialog box, accessed from Device Settings.

The Source selection must be Cassette 1 or Cassette 2.

Printing with Manual Duplex

For some models with no duplex unit, you can print on both sides using manual duplex.

5-5 User Guide

In Basic > Source, select Cassette 1 or Cassette 2.

Click the Flip on long edge or Flip on short edge icon.

Select the Print manual duplex instructions check box to print an instruction

sheet. Follow the printed instructions for placing the pages back into the cassette after the first side is printed.

Alternatively, to save a sheet of paper, clear the Print manual duplex instructions check box and follow steps 4-6.

Click OK in the Printing Preferences and Print dialog boxes.

The even-numbered pages are printed.

When printing stops, remove all printed sheets from the output tray.

With Flip on long edge selected, turn the stack over on the long edge and put the pages back into the cassette.

With Flip on short edge selected, turn the stack over on the short edge and put the pages back into the cassette.

Basic

Click OK in the Manual Duplex Instructions dialog box.

The odd-numbered pages are printed.

Printer Driver 5-6

6 Layout

In the Layout tab you can arrange document data on printed pages without affecting the original document. (Selections vary according to printing system model.)

To return to the original settings, click Reset. For some models, this also restores the Staple and Booklet (fold) selections in the Finishing tab, if selected. The Reset button is available when accessing the printer driver from the application's Print dialog box.

Multiple Pages per Sheet

Multiple pages per sheet prints several pages on a single sheet of paper for

the purpose of reviewing the document and conserving paper. The size and readability of the multiple pages decrease as the number of pages per sheet is increased. You can set the arrangement of the pages as well as print borders around each of the pages in the Layout tab.

When Multiple pages per sheet is selected, Scaling, Poster, and Full bleed are unavailable.

Printing Multiple Pages per Sheet

Scaling

In the Layout tab, click the Multiple pages per sheet icon.

In the Pages per sheet list, select the number of pages to print on each sheet of

paper.

In the Layout list, select the direction the pages should flow.

If you want to print a border around each page, select Print borders.

Click OK to return to the Print dialog box.

Click OK to start printing.

Scaling increases or decreases text and graphics on a page.

You can also select a gutter setting that enlarges the margins to accommodate manual stapling or manual hole punch.

If other Layout tab options are selected, Scaling is unavailable.

Setting Scaling on the Page

In the Layout tab, type or select a scaling percentage from 20 to 500.

6-1 User Guide

Gutter

Click OK to return to the Print dialog box.

Click OK to start printing.

Gutter increases the margins around your text and graphics on the left side and

at the top of the printed sheet. Gutter is often used for binding, hole punch or stapling to make a print job easier to read. This creates a larger margin space by shifting the printable area to the right, or down as much as one inch (25.4 mm).

Gutter width displays the unit of measurement in inches or millimeters. You can change the Units setting in the User Settings dialog box, accessed from

Device Settings.

Note: For models that support Finishing edge, Gutter is available in the Finishing tab.

Creating a Gutter

In the Layout tab, click Gutter.

Layout

Full Bleed

In the Gutter width options, type or select a value between 0.20 to 1.00 inches

(5.0 to 25.4 mm).

Short edge (top)

This selection modifies the outside margin on the top-edge of the page.

Long edge (left)

This selection modifies the outside margin on the left-side of the page.

Note: Availability of Gutter settings varies depending on Orientation and Duplex settings in the Basic tab.

If text extends too close to the edge of the page, select Reduce image to fit.

The text appears slightly reduced and away from the edge of the page. If text does not extend beyond the page when the gutter increases, clear Reduce image to fit.

Click OK to save gutter settings, then click OK again to return to the Print dialog

box.

Click OK to start printing.

Full bleed lets you produce full-page printing without any margins by printing to

a larger sized-paper than the original, and then letting you trim the edges. Trimming the document after printing ensures that the toner has completely covered the document to its edge. You can print booklets, posters, and other marketing documents. This feature helps you create a more professional look by allowing you to crop and zoom, improving the focus of the document.

Printer Driver 6-2

Layout

You can use crop marks to trim the edges of your document. The crop marks help guide you to accurately and evenly cut around your document. Click the icons to change between None, Corners, Border, and Off.

None

Does not print any crop marks.

Corners

Prints a set of crop marks in each corner of the page, to let you match the lines from side to side and cut the page precisely.

Border

Creates a thin black border around the entire page. You can follow this border to trim off any excess paper from your document.

If Full bleed is selected, the other features on the Layout tab and all the features on Finishing (except Separation), and Publishing tabs are unavailable.

With Full bleed selected, Scaling is fixed at 100% regardless of the print size and page size combination.

Ensure that the selection in Basic > Print size is larger than the page size. For example, with Full bleed selected, and in the Basic tab you select Print size > Letter and Page Sizes > Envelope #10, the document will contain white space for you to trim after printing.

Poster

Printing with Full Bleed

You can print to the edge of your paper.

In the Layout tab, under Full bleed, click the icons to select None, Corners, or

Border.

Click OK to return to the Print dialog box.

Click OK to start printing.

The Poster feature lets you create a document to a size that is larger than the paper your printing system can support. You can print a poster, or banner, up to 25 times larger than the original document. Segments of the poster document are printed on several sheets of paper and with the assistance of poster settings, you can reassemble the sheets easily to create a poster.

When Poster is selected, other Layout tab options are unavailable.

Use Pages per poster to select the poster size in relation to the original document size. Each option shows the number of sheets to be printed and the maximum poster size. For some models, the label “Sheets per page” appears instead of “Pages per poster.”

Pages per poster displays the unit of measurement in inches or millimeters. You can change the Units setting in the User Settings dialog box, accessed from Device Settings.

Use Print format to print a proof sheet, along with the poster, to guide you in assembling the printed poster sheets.

Poster pages

This selection prints all of the sheets to be assembled as a poster.

6-3 User Guide

Layout

Proof sheet

This selection prints all the poster pages on one sheet with markings that display the sheet assembly.

Poster pages and proof sheet

This selection prints all poster sheets and a one-page proof sheet.

Use Poster Settings to select options, in any combination to make it easier to create a poster. These options print visual cues on the poster sheets that provide help in cropping and assembling the pages.

Overlap edges

This selection duplicates the edges of document data on adjoining sheets. Poster appearance is improved when the edges overlap slightly. Select the check box, then type or select a value between 0.00 and 1.20 inches (0.0 and 30.4 mm). This option reduces the final poster size slightly.

Print crop marks

This selection prints a border at the edges of each poster sheet. You can crop each sheet on the border before assembling the sheets. This option ensures that data on adjoining sheets matches precisely.

Print assembly marks

This selection prints numbers at the edges of each sheet, matching numbers on adjoining sheets. Assemble each sheet edge to the same numbered edge on another sheet.

Booklet

Printing a Poster

You can print a poster.

In the Layout tab, click the Poster icon.

In Pages per poster, select the poster size. Each option describes the number

of sheets it takes to represent one finished poster page.

In Print format, select one of the options for a finished print format.

Click Poster Settings to select options in any combination. These options

ensure a precise assembly of the pages to create the poster.

Click OK to return to the Print dialog box.

Click OK to start printing.

Booklet prints a two-page layout on both sides of each sheet of paper. You can

fold and bind the booklet in the center. Folded booklets are half the size of the selected paper.

Additional booklet options are available in the Booklet Settings dialog box:

Layout lets you choose how to create booklet layout settings.

Create from driver settings

Printer Driver 6-4

Layout

Uses the driver settings for page sequence and pages per sheet. Select this option when the booklet layout is not created in the application.

Create from application settings

Uses the application settings for page sequence and pages per sheet. Select this option when the application creates the booklet layout.

For some models, Staple setting lets you choose whether to staple and fold the booklet. This option is available when a folding unit is installed.

None

Prints the booklet without stapling and folding.

Staple and fold

Prints, staples, and folds the booklet.

When Booklet is selected, other Layout tab options are unavailable.

A different paper source can be selected for the booklet cover. To include a cover on the booklet, select the Publishing tab, then select Cover mode.

Printing a Booklet

You can print a document as a booklet.

In the Layout tab, click the icon for one of the two binding options:

Left edge binding

This selection prints text that reads from left to right.

Right edge binding

This selection prints text that reads from right to left.

For additional booklet options, click Booklet Settings.

In the Booklet Settings dialog box, select from available Layout and Staple

setting options, and then click OK.

Click OK to return to the Print dialog box.

Click OK to start printing.

6-5 User Guide

Separation

7 Finishing

In the Finishing tab, you can specify document finishing features like punching holes and stapling. (Selections vary according to printing system model.)

To return to the original settings, click Reset. This also restores the Destination selection in the Basic tab and the Booklet selection in the Layout tab, if selected. The Reset button is available when accessing the printer driver from the application's Print dialog box.

The Separation feature stacks print jobs so that one print job can be distinguished from another. (Selections vary according to printing system model.)

Note: Separation features cannot be used with Finishing edge or with Staple.

Offset Jobs

The Offset jobs feature physically shifts each print job in the output tray.

To ensure consistent offset stacking, all users printing to the same printing system should select Offset jobs as the default setting.

The Offset jobs feature requires a finishing device to be selected under Device

options in the Device Settings tab. It does not work with the Staple or the Finishing edge features.

Offsetting Jobs

You can offset, or shift each print job in the output tray.

In Finishing > Separation, click the Offset jobs icon.

Click OK to return to the Print dialog box.

Click OK to start printing.

Rotate Copies

Rotate copies stacks each copy of a print job at a right angle in the output tray.

This feature requires the following:

Paper size selections are limited to Letter, A4, 16K, or B5 (JIS).

The selected paper size must be loaded into two paper sources, one horizontally and one vertically.

The print job must contain multiple pages and be specified to print multiple copies.

Printer Driver 7-1

Finishing

Tri-Fold

Note: For some models, a storage device must be installed.

Rotating Copies

You can stack each copy of a print job at right angles in the output tray.

In Basic > Destination, select an option that is not a finishing tray, for example:

Printer default.

Select a number of copies greater than 1.

In Finishing > Separation, click the Rotate copies icon.

Click OK to return to the Print dialog box.

Click OK to start printing.

The Tri-Fold feature lets you produce a document folded into thirds, like a brochure or a pamphlet. Paper sizes A4 and Letter can be used. You can choose to print on the inside or the outside of your document. You can select the direction of the folds. You can also select the number of pages produced as output.

This feature is available when a folding unit is installed.

Printing with Tri-Fold

In the Basic tab, under Destination, select Printer default or Folding tray.

In the Finishing tab, click the Tri-Fold icon.

In Print side, select one of the two options:

Inside

This selection prints on the inside of the folded document.

Outside

This selection prints on the outside of the folded document.

In Direction of fold, select from the options available.

Left to right/Top to bottom

By selecting this option for Portrait, the printer first folds the top third and then the bottom third of the page. For Landscape, the printer first folds the left third and then the right third of the page.

Right to left/Bottom to top

By selecting this option for Portrait, the printer first folds the bottom third and then the top third of the page. For Landscape, the printer first folds the right third and then the left third of the page.

7-2 User Guide

Bi-Fold

In Number of sheets, type or select the number of sheets that will be folded

into thirds, up to a maximum of 5.

Click OK to return to the Print dialog box.

Click OK to start printing.

The Bi-Fold feature lets you produce a document folded in half, like a brochure or a pamphlet. The paper sizes that can be used are Letter, Legal, Ledger, A3, A4, B4, Oficio II, and 8K. Printing occurs on the outside of your document. You can also select the number of pages produced as output.

This feature is available when a folding unit is installed.

Printing with Bi-Fold

In the Basic tab, under Destination, select Printer default or Folding tray.

In the Finishing tab, click the Bi-Fold icon.

Finishing

Finishing Edge

In Number of sheets, type or select the number of sheets that will be folded in

half, up to a maximum of 5.

Click OK to return to the Print dialog box.

Click OK to start printing.

Finishing edge aligns the matching sides of two different page sizes in a

document. For example, the long edge of an A4 page is aligned with the short edge of an A3 page; or the short edge of a letter size page is aligned with the short edge of a legal size page. Finishing edge can be used with or without the staple and punch features.

You can choose the position of staples in a document composed of mixed page sizes. In contrast, if you are printing a mixed page size document without using Finishing edge, staple positions depend on the paper size settings (portrait or landscape) in the paper cassettes.

Finishing edge should be selected before any other features in the Finishing tab. If set last, Finishing edge might change any settings that you previously made under Staple or Punch.

Selecting Finishing edge makes some other features unavailable, such as Separation and Tri-Fold. Finishing edge cannot be used with the Poster feature.

Finishing Edge Combinations

Finishing edge can be used with the following page size combinations:

A4 and A3 (210 x 297 mm and 297 x 420 mm)

B5 (JIS) and B4 (182 x 257 mm and 257 x 364 mm)

Printer Driver 7-3

Finishing

Letter and Legal (8.5 x 11 in. and 8.5 x 14 in.)

Letter and Ledger (8.5 x 11 in. and 11 x 17 in.)

16K and 8K (197 x 273 mm and 273 x 394 mm) [available on some models]

Positioning Options for Finishing Edge

You can select from available options to specify the page edges to be aligned and finished. For additional position settings, select Custom. Available options depend on Print size, Orientation, Booklet, and Multiple pages per sheet selections.

In the overview area at the bottom, the page image shows a blue highlighted strip to indicate the current selected Finishing edge with Staple and Punch positions, if selected. When the Staple option is used, the Finishing edge selection determines where staples are placed. Use this image to verify your selections for Finishing edge and Staple.

Custom Finishing Edge Settings

The illustrations in the Custom Finishing Edge Settings dialog box help you visualize the page alignments. Select the one setting that best illustrates the edge of the mixed pages you want to align.

In the Position list, you can select Custom to open the Custom Finishing Edge Settings dialog box.

The top two settings (A4/Letter) are for the smaller size paper in the mixed page document.

The next two settings (A3/Legal/Ledger) are for the larger size paper in the mixed page document.

Note that a change to one custom Finishing edge setting adjusts other selections to make them compatible with the change.

Setting the Finishing Edge

In the Basic tab, select the same size for Print size and Page Sizes.

In Basic > Source, select Auto source selection.

In the Finishing tab, click the Finishing edge icon.

In the Position list, select from available options, or select Custom. Positions

are based on the Print size selection in the Basic tab.

Click OK in all driver dialog boxes.

Load each paper size into different paper cassettes. For example, load A4 and

A3 paper so that both sizes feed the 297 mm edge or load letter and legal paper so that both sizes feed the 8.5 inch edge.

Click OK in the application’s Print dialog box.

If the printer driver determines that the specified paper size or direction (short or long edge) is unavailable in the printing system, the operation panel message requests that you load the correct paper size into the cassette with the correct orientation.

7-4 User Guide

Gutter

Gutter increases the margins around your text and graphics on the left side and

Gutter width displays the unit of measurement in inches or millimeters. You can change the Units setting in the User Settings dialog box, accessed from

Device Settings.

Note: For models that do not support Finishing edge, Gutter is available in the Layout tab.

Creating a Gutter

You can increase the margins on the left side and at the top of the printed sheet.

In the Finishing tab, click Gutter.

In the Gutter width options, type or select a value between 0.20 to 1.00 inches

(5.0 to 25.4 mm).

Short edge (top)

This selection modifies the outside margin on the top-edge of the page.

Long edge (left)

This selection modifies the outside margin on the left-side of the page.

Finishing

Staple

Note: Availability of Gutter settings varies depending on Finishing edge

settings, and Orientation and Duplex settings in the Basic tab.

If text extends too close to the edge of the page, select Reduce image to fit.

The text appears slightly reduced and away from the edge of the page. If text does not extend beyond the page when the gutter increases, clear Reduce image to fit.

Click OK to save gutter settings, and then click OK again to return to the Print

dialog box.

Click OK to start printing.

The Staple feature lets you create stapled document sets. You must first select a finisher under Device Settings > Device options. Selecting the Staple feature makes Separation and Transparency interleaving unavailable. The maximum number of sheets depends upon the finisher model and the selected Page size or Media type. The Gutter feature lets you increase the top and left margins to accommodate the location of the staples.

Staple and Separation features cannot be used together.

If Printer default is selected as the Destination in the Basic tab, the selection of an option in the Finishing tab results in the automatic selection of a destination compatible with that finishing option. The destination is

Printer Driver 7-5

Finishing

automatically updated to the first available output tray that supports the selected finishing option.

Staple selects the Destination automatically. If the Finishing options are changed, the Destination selection is not affected.

Finishing edge should be selected before any other features in the Finishing tab. If set last, Finishing edge might change any settings that you previously made under Staple.

Stapling a Print Job

With a finishing device installed, you can create stapled document sets.

In the Finishing tab, click the Staple icon.

Select the position from available options. For some models, the position

options vary based on settings in Finishing edge, which provides custom staple locations in the document.

If a folding unit is installed and Booklet is selected in the Layout tab, Booklet (fold) is automatically selected. The job is printed in booklet format and folded, with two staples placed in the binding.

Punch

Select the count for stapling:

For some models, under Count, select the number of sheets for each stapled set, or select All to staple all sheets.

For some models, select All sheets up to the limit displayed in the tab, or After every (2 to maximum number).

Click OK to return to the Print dialog box.

Click OK to start printing.

The Punch feature places punch holes along the edge of the printed pages so that the pages can be bound together or placed in a binder.

Punch is enabled when an optional finishing device supporting the Punch feature is selected under Device options in Device Settings. When you select the check box for a finishing device shown in blue in the Device options list, the Punch Unit Settings dialog box appears. If the device listing is already selected, double-click the option to open the Punch Unit Settings dialog box.

Punch cannot be used when Booklet is selected in the Layout tab.

Finishing edge should be selected before any other features in the Finishing

tab. If set last, Finishing edge might change any settings that you previously made for Punch.

Creating Punch Holes for a Print Job

The finishing device must support the Punch feature.

Available punch options are set in Device Settings and depend on the punch unit installed on the device and selected.

7-6 User Guide

In the Finishing tab, click the icons to select Off or to select the number of hole

punches:

2 hole

3 hole

4 hole

For some models, click Settings, and select the setting for punch position: Left,

Right, or Upper.

Click OK to return to the Print dialog box.

Click OK to start printing.

Finishing

Printer Driver 7-7

8 Imaging

In the Imaging tab, you can manage print quality, color settings, and grayscale settings. (Selections vary according to printing system model.)

To return to the original settings, click Reset. The Reset button is available when accessing the printer driver from the application's Print dialog box.

Print Quality and Custom Quality

Print quality lets you set the resolution for the print job. Resolution is a

measurement, in dots per linear inch (dpi), that describes the sharpness and clarity of printed text and images. Custom Quality lets you set a more refined resolution for the print job. (Selections vary according to printing system installed.)

The following Print quality options are available:

High quality

Uses the highest printing system resolution.

Proof

Uses the second highest printing system resolution. This option is unavailable for the PCL 5e/c Page description language.

Draft

Prints with EcoPrint mode.

Custom

Choose your own combination of settings for Resolution and Kyocera image refinement (KIR). Select Custom to open the Custom Quality Settings dialog box.

Custom Quality

The following Custom quality options are available:

Resolution

Resolution can be set to Fine 1200, Fast 1200 (unavailable for the PCL

5e/c Page description language), 600 dpi, and 300 dpi. (Selections vary according to printing system installed.)

Kyocera image refinement

Kyocera image refinement smoothes the edges of text and vector graphics and can be set to On or Off.

Selecting Print Quality

You can select the quality of your print job. (Selections vary according to printing system model.)

In Imaging > Print quality, select a print quality from the list.

Select Custom in the Print quality list and select from custom options.

8-1 User Guide

Trapping

Imaging

For color models, select EcoPrint or Gloss mode. EcoPrint and Gloss mode cannot be used together.

For black and white models, select Custom to open the Custom Quality Settings dialog box and select from available Resolution and Kyocera image refinement options.

In color printing, color inks or toners are applied separately to a page. A color image has its component colors applied in color separations of cyan, magenta, yellow and black. These color separations must be aligned (registered) precisely to produce a quality full color image. During printing, the paper or media type may shift slightly. While the shift might be very small, the gaps between the colors in the image can be noticeable. Color trapping corrects it by overlapping colors slightly so that minor alignment issues are corrected.

Note: Trapping is unavailable when PCL 5c is selected as the PDL.

Setting Trapping Values

You can overlap colors slightly to correct minor alignment issues.

Fonts

In Imaging > Trapping, select a value for the print overlap pixel width:

Light, 0.5 pixel trapping

Medium, 1.0 pixels trapping

Heavy, 1.5 pixels trapping

Very heavy, 2.0 pixels trapping

Click OK to return to the Print dialog box.

Click OK to start printing.

A computer font is a data file containing a set of glyphs (visual representations of textual elements), characters, or symbols. Common terms for fonts are:

Outline fonts, in contrast to bitmap fonts, are defined as a set of mathematical lines and curves. An outline font is more easily scalable (designed to display and print clearly at any point size) than a bitmap font.

Bitmap fonts define each character as a pattern of pixels (the smallest resolvable rectangular areas of an image). Such fonts are not easily scalable and distort when reduced or enlarged.

Native fonts are the basic or original fonts installed with the computer operating system. TrueType fonts are the native fonts used by Microsoft Windows.

TrueType fonts are a type of scalable outline fonts. TrueType has long been the most common format for fonts on Microsoft Windows.

System fonts are the primary fonts used by the operating system. They are typically accessed through an application interface or through a common font dialog box.

Device fonts are stored either permanently or temporarily in the printing system memory.

Printer Driver 8-2

Imaging

Font Settings

The Font Settings dialog box lets you specify how TrueType fonts are sent to the printing system. The chosen method affects the speed and quality of the print job:

Download as outlines

This method is best suited for large documents or print jobs using multiple fonts and font sizes. Print speeds are faster because of the optimization features in this setting. The repetition of similar font data sent to the printing system is reduced, thereby increasing the print speed. Print speed is not increased when using Asian fonts such as Japanese, Chinese, and Korean, because of the large amount of font information used for these particular fonts.

Allow native download

This method improves text quality and increases print speed by converting TrueType fonts to Adobe Type 42 font format. This feature is available when

KPDL is selected as the PDL.

Download as bitmaps

Downloading fonts as bitmaps provides more detail, however it creates large file sizes. This is best suited for print jobs with custom fonts, very small fonts (point size 1-4), or Asian fonts.

Substitute with device fonts

System fonts and device fonts are automatically matched based on typeface name. This function increases print speed and efficiency. It is useful for changing a font used throughout a large document, by replacing the old font with the desired font.

Note: GDI compatible mode does not support Substitute with device fonts.

Selecting Font Settings

You can specify how TrueType fonts are sent to the printing system.

In Imaging > Fonts, select one of the methods for sending TrueType fonts.

Click OK to return to the Print dialog box.

Click OK to start printing.

Font Substitution

Font substitution is the process of using one font in place of another when the intended font is unavailable to a printing system. Font substitution may be critical for output of documents to printing systems that are not well supported by a large font inventory. Standard PostScript fonts are available for substitution.

Setting Font Substitution

To set font substitution, you must open Printing Preferences outside of a

printing application. Depending on your operating system:

Windows 8 and Windows Server 2012: open the Control Panel, and then click View devices and printers.

8-3 User Guide

Windows 7 and Windows Server 2008 R2: click Start, and then click Devices and Printers.

Windows Vista and Windows Server 2008: click Control Panel and then click or double-click Printers.

Windows XP and Windows Server 2003: click Start > Printers and Faxes.

Right-click the desired printing system model and click Printing Preferences.

In Imaging > Fonts, select Substitute with device fonts, then click Fonts.

In the Fonts Substitution dialog box, the System fonts list shows the fonts installed on your computer. The Available device fonts list shows the printing system fonts.

Select the system font, and then the available device font to be substituted.

You can click Reset to restore the default values.

Click OK to save your settings.

If the device font does not have similar font characteristics to the system font, character spacing in the document may appear incorrect.

Imaging

Disable Device Fonts

Disabling Device Fonts

Half Speed Mode

In some cases, the printing system substitutes fonts even if you send the TrueType fonts as outline fonts or bitmap images. Select Disable device fonts to prevent substitution of device fonts for TrueType fonts.

This option also improves portability of printable data. (If cleared, device fonts may not match when sent to a different printing system.)

Some Adobe applications have device font limitations. To overcome these limitations, select Disable device fonts. Device fonts are normally visible in the application font lists as printer icons next to the font name, unless there are equivalent system fonts, in which case the “TT” TrueType icon remains.

You can prevent substitution of device fonts for TrueType fonts.

In Imaging > Fonts, select the Disable device fonts check box.

Click OK to save your settings.

Half speed mode reduces the print speed to half the rated speed. When selected, the toner adheres better when printing on small size, thick, or textured paper. This mode may result in quieter printing.

To enable this feature, in the Imaging tab, select the Half speed mode check box.

Note: Half speed mode applies to all media types except Transparency and Vellum.

Printer Driver 8-4

Imaging

Graphics

Graphics are pictorial representations of information. Graphics can be functional (charts, diagrams) or artistic (drawings, photographs). Graphics Settings let you control the visual results of your printed graphics with options determined by the selected Page Description Language. (Selections vary according to printing system model.)

Pattern Scaling

Pattern scaling is a feature that can help improve visual compatibility between

screen display and print output. Graphics objects, such as a shape or a path, often include patterns and fills that are composed of collections of printed dots. A pattern is a planned or random repetition of colors, shapes, lines, values, and textures to create a visual arrangement. A fill is the application of a color or grayscale to a graphics object. If printed patterns and fills do not match the appearance of that on the screen, use Pattern scaling to select a different density of printed dots.

In Imaging > Graphics, select Pattern scaling settings.

Auto (default setting)

This setting prints patterns and fills to match the on-screen appearance.

Coarse

This setting prints patterns and fills with the fewest number of lines, patterns, or dots. Coarse is the same as Auto when PCL XL or PCL 5e/c is selected as the PDL.

Medium

This setting prints patterns and fills with a greater number of lines, patterns or dots than the Coarse setting. Medium is the same as Auto when KPDL is selected as the PDL.

Fine

This setting prints patterns and fills with the greatest number of lines, patterns, or dots. Printed patterns and fills may appear more dense than the on-screen appearance.

Line Thinning

Line thinning reduces the pen width of lines used for barcodes and line

drawings. Drawing values controlled by an application are not changed.

In Imaging > Graphics, select Line thinning settings. Line thinning is available when PCL XL is selected in the PDL Settings dialog box. When GDI compatible mode is selected in the PDL Settings dialog box, Line thinning is not available.

Off (default setting)

Line thinning is not applied.

Barcodes

This setting reduces the pen width value for vertical and horizontal lines. It improves the readability of barcodes.

Fine lines

This setting reduces the pen width value for vertical, horizontal, and diagonal lines.

All

8-5 User Guide

This setting reduces the pen width by a value of 1 for vertical, horizontal, and diagonal line used in barcodes or line drawings.

Correct fine lines by device

Enables correction of pen width by the device rather than by the driver, to improve the quality of barcode printing. This feature is available only on supported models.

Halftone Screen

For some color models, Halftone screen appears near the top of the Graphics Settings dialog box. This feature improves the print quality of images, lines, and

characters. Halftone images simulate the look of a continuous tone image by placing a series of dots in a specific pattern. This feature is unavailable if PDF is selected in the PDL Settings dialog box.

For some black and white models, the Halftone Screen button appears at the bottom of the Graphics Settings dialog box. This feature lets an experienced user print different shades of gray as are found in photographs. Shades are produced by printing dots of various sizes and shapes, and by spacing them closer or farther apart. Shading can also be adjusted by the number of rows of data, the angle of the rows, and the shape of the data. This feature is available when KPDL is selected in the PDL Settings dialog box. It is unavailable when GDI compatible mode is selected in the PDL Settings dialog box.

Imaging

Setting the Halftone Screen

Halftone Screen is available in different versions for color models and for black

and white models.

Color models

In Imaging > Graphics, select from available options in the Halftone screen

list:

Normal

Select to print standard documents (recommended for most types of documents).

Gradation priority

Select to print documents with a smooth, continuous gradation of colors and grays.

Resolution priority

Select to print documents with sharp lines and characters.

High definition

Select to print documents with thin lines and small characters.

Click OK to return to the Print dialog box.

Click OK to start printing.

Black and white models

In Imaging > Graphics, click Halftone Screen.

Clear the Use printer's default screens check box.

Printer Driver 8-6

Imaging

Set the available options to the desired values:

Ink

Lists the halftone screens available. For black and white printers, this option appears unavailable and is permanently set to Black.

Frequency

Displays the number of rows of dots per inch or centimeter. Set the range from

2.0 to 999.9, and select lines/inch or lines/cm.

Angle

Sets the angle at which rows are aligned. Set the range from -180 to 180 degrees.

Shape

Select the shape of the halftone dot:

Ellipse

Resists optical jump. An optical jump occurs when an area of an image suddenly become darker. An ellipse shape provides a smooth gradation of tones. Select Ellipse for images with dark areas.

Round

Resists moiré formation and dot gain. Moiré formation is an unintended pattern that occurs when two or more colors are printed at the wrong angles. The correct angles depend on the number of colors being printed. Dot gain is when the halftone dots increase when printed, causing a moiré pattern. Select Round for images with light tints and highlighted areas.

Line

Used for special effect. Select Line to change the effect by selecting a different angle.

Select Increase accuracy of screens for better print quality, possibly

increasing print time.

Click OK to return to the Print dialog box.

Click OK to start printing.

Inversion Options

Inversion is the opposite of the normal order, arrangement, or position of an image or printed content.

In Imaging > Graphics, select Inversion options. The settings are available when KPDL is selected as the PDL.

Reverse image

This setting prints images like a photo negative, reversing black and white areas of the image.

Mirror print

This setting prints the page content backwards, as it would appear in a mirror image.

8-7 User Guide

Optimization

Optimization is a process or methodology of improving a printing system's

function or effectiveness.

In Imaging > Graphics, select Optimization. The settings are available when

KPDL is selected as the PDL.

Fast printing

This setting increases print speed and decreases spool size. It delivers images in binary format. It can be used for most everyday printing needs.

Document portability

This setting creates a PostScript file in ASCII text encoding. Unlike the binary format created in Fast printing, the ASCII text created with this selection can be edited.

CIE Option

CIE optimization bypasses the normal procedure of processing every aspect of

the CIE color space used in applications such as Adobe Acrobat and Photoshop. This feature increases print speed for documents printed from these applications by optimizing CIE data. It has no effect on print jobs that do not use CIE data. CIE optimization should be selected for speed not accuracy, so printed output may be different from appearance on the screen.

In Imaging > Graphics, select the CIE optimization check box. CIE optimization is available when KPDL is selected as the PDL.

Imaging

Gloss Mode

EcoPrint

Image Compression Mode

For color models, Image compression mode lets you select a method for compressing images depending on the desired quality in printed images. JPEG compression produces a lower quality image, while delta row compression produces a higher quality image but creates a larger file size. Image compression mode is available when KPDL or PCL XL is selected as the PDL.

In Imaging > Graphics, select from the following compression options:

Smaller file size

Uses JPEG compression

High quality

Uses delta row compression

Gloss mode simulates high-gloss copies by adding a glossy appearance to printed text and images.

Note: EcoPrint and Gloss mode cannot be used together.

EcoPrint changes toner saturation in the print job, making the entire print

image, including text and graphics, appear lighter. The amount of toner varies based upon your printing system model and the type of data printed (text, graphics, or both). EcoPrint and Gloss mode cannot be used together.

Printer Driver 8-8

Imaging

For some models, you can choose the amount of toner you want to save.

EcoPrint does not increase print speed.

EcoPrint is also available in the Quick Print and Basic tabs. If EcoPrint is

turned on in the Quick Print or Basic tab, the Imaging tab displays the previously-selected level. If no level is selected, the Imaging tab selection is

Medium.

Note: For some models, EcoPrint is available only when KPDL is selected as

the PDL.

Selecting EcoPrint

In the Imaging tab, click the EcoPrint icons to change between on and off.

In the list, select the amount of toner you want to save.

For some models click the EcoPrint button and select Low or High.

Click OK to return to the Print dialog box.

Click OK to start printing.

Color

Color lets you choose full-color printing or printing with black toner only.

In Imaging > Color, the following color modes are available:

Color Reproduction

Color reproduction lets you optimize the color rendering of photos and

graphics. This feature is available when Full color is selected under Color.

In Imaging > Color reproduction, the following printer profiles are available.

Full color

This mode prints full four-color text and graphics.

Black

This mode prints with black toner only, suppressing all color settings.

Printer settings

This option uses the printer settings only.

Text and graphics

This option is for printing documents that contain many graphs, charts or drawings.

Text and photos

This option is for printing documents with many photographic images.

Vivid colors

This option increases the color saturation of graphics and photos.

Publications

This option is for printing a mix of graphics and/or photos. Select this option to print close to the color shade of the screen.

8-9 User Guide

Imaging

Line art

This option is for printing figures or graphics drawn with lines. Select this option to print colored lines with pure simple color.

PANTONE

This option uses the PANTONE color profile installed in the application. PANTONE must be selected in the Optional Components Wizard when

installing the printer driver. Select this option when using the PANTONE color swatches that are provided with your printer software for some Adobe, Corel, and Quark applications. If selected, some Print quality and Color options, such as color adjustment, are unavailable. This option is available when KPDL is selected as the PDL.

Custom table

This option lets you select a custom color table that was previously downloaded to your printing system. All other Color reproduction options use the default color table.

Advanced

This option achieves greater consistency in color reproduction among various devices. It compensates for the different color spaces of color printing systems. Selecting and applying a set of profiles is called a color profile. Select to open the Color Correction dialog box for additional color printing options.

For some models, the following Color reproduction options are available:

Auto 1

For use in almost all cases, for printing generic documents.

Auto 2

Prints black text and graphs in black toner only.

Auto 3

Prints black text and graphs in four-color toner.

Auto 4

Prints images and graphs similar to colors shown on the monitor.

Picture image

Prints images, text, and graphs similar to colors shown on the monitor.

Text

Prints images, text, and graphs in vivid color (black prints with black toner only).

Chart (graphic)

Prints images, text, and graphs in vivid color (black prints with four-color toner).

Advanced

Select to open the Color Correction dialog box for additional color printing options.

Color Correction

The Color Correction feature alters the colors in an image in order to print it properly. It attempts to match the colors of the original image to the printer's colors. ICM is Microsoft's Image Color Management, the standard for Windows.

Printer Driver 8-10

Imaging

The following options are available in the Color Correction dialog box. (Selections vary according to printing system installed.)

None (application corrected)

With this option, color data processes without applying the adjustments contained in the printing system's internal color lookup tables. Ink simulation is not executed. This is useful if the application provides its own color correction.

ICM (system corrected)

This option specifies color rendering in the print job to make it as close to the original as possible. ICM technology relies upon associating an output device like a printing system with a Color Profile. An ICM Profile for a printing system contains information about rendering accurate color information for that device. The settings for ICM must be set in the Color Management tab in the printing system Properties.

Monitor simulation (RGB)

Corrects the sRGB monitor value according to HDTV standards.

Ink simulation (CMYK)

Provides output similar to the selected offset press ink set:

Euroscale Press Simulates European press standards by matching the equivalent Imation Matchprint proof.

SWOP Press Simulates U.S. press standards by matching the Specifications for Web Offset Publications.

Ink simulation (CMYK) is available when KPDL is selected as the PDL.

Selecting Color Correction

In Color reproduction, the Advanced option provides some methods for controlling how the printer processes color matching.

In Imaging > Color reproduction, select Advanced. In the Color Correction

dialog box:

If you select the None (application corrected) option, click OK to close the Color Correction dialog box.

If you select the ICM (system corrected) option, continue to step 2.

Select an option, then click OK to save the selection.

Optimize for exact color (colorimetric)

This option is for matching colors precisely in all print jobs, such as colors in a corporate logo.

Optimize for color contrast (best for images)

This option optimizes for color contrast by adjusting contrast to preserve detail throughout the tonal range. Select it for images or scanned photographs containing many colors or shades of color.

Optimize for color saturation (best for graphs)

This option optimizes for color saturation by adjusting hue to preserve the vividness of pure colors. Select for graphs or charts containing solid colors.

For some models, select Monitor simulation (RGB) and Ink simulation

(CMYK) options. Ink simulation (CMYK) is available when KPDL is selected

as the PDL.

8-11 User Guide

Click OK again to close the Color Correction dialog box.

Setting a Default Color Profile

When using the ICM (system corrected) feature in the Color Correction dialog box, you can set a color profile for your printing system.

Windows 8, Windows Server 2012, Windows 7, Windows Vista, Windows Server 2008, and Windows Server 2008 R2

Depending on your operating system:

Windows 8 and Windows Server 2012: open the Control Panel, and then click View devices and printers.

Windows 7 and Windows Server 2008 R2: click Start, and then click Devices and Printers.

Windows Vista and Windows Server 2008: click Start > Control Panel, and then click Printer.

Right-click your color model, then:

Windows 8, Windows Server 2012, Windows 7, and Windows Server 2008 R2: click Printer properties.

Windows Vista, Windows Server 2008, Windows XP, and Windows Server 2003: click Properties.

Imaging

Select the Color Management tab and click Color Management.

In the Devices tab > Device list, select the desired color printer.

Select the Use my settings for this device check box.

In the Profile selection list, select Manual, and click Add.

In the Associate Color Profile dialog box, select an ICC profile, or click

Browse to find a profile, and click OK. The profile is added to the Profiles associated with this device list.

Select the desired color profile and click Set as Default Profile.

Click Close.

Windows XP and Windows Server 2003

Click Start, and then click Printers and Faxes.

Right-click your color model, and select Properties.

Select the Color Management tab and click Add.

In the Add Profile Association dialog box, select a color profile from the list

and click Add.

Printer Driver 8-12

Imaging

Color Adjustment

Selecting Custom Color Adjustment

In the Color Management tab, select Manual.

Select the desired color profile from the list and click Set as Default.

Click Apply.

Color adjustment lets you customize the two color spaces in the driver and save up to three custom groups. Color space changes can be made to hue, saturation, and lightness (HSL) or to color balance levels.

Note: If different custom settings are selected for Adjustment and Color Optimizer (Advanced tab), the latest change takes precedence and is applied

to the print job.

In a client-server environment, settings a user makes in the client computer are saved for future use.

If a custom color setting has already been defined, you can select and apply it to a print job.

In Imaging > Color, click the Full color icon.

In the Adjustment list, select Custom 1, Custom 2, or Custom 3.

Click OK.

Adjusting HSL (Hue, Saturation, Lightness)

In Imaging > Color, click the Full color icon.

In the Adjustment list, select Edit.

In Adjustment Settings > Custom color adjustment, select Custom 1,

Custom 2, or Custom 3.

Select HSL (hue, saturation and lightness).

Under Select preview image, click the icon to select one of three different

images. Different colors are emphasized in each of the photographs to aid in the color adjustment process.

Adjust the distribution and balance of hues.

For coordinated hue adjustment, from the Modify list, select Master. Type or select the Hue value between -180 and +180.

For specific hue adjustment, from the Modify list, select Red, Yellow, Green, Cyan, Blue, or Magenta. Type or select the Hue value between -10 and +10.

8-13 User Guide

Type or select the Saturation, Lightness, and Contrast values between -10

and +10.

You can click Reset to restore the default values.

Click OK to save the new HSL settings.

Adjusting Color Balance

In Imaging > Color, click the Full color icon.

In the Adjustment list, select Edit.

In Adjustment Settings > Custom color adjustment, select Custom 1,

Custom 2, or Custom 3.

Select Color balance.

Under Select preview image, click the icon to select one of three different

images. Different colors are emphasized in each of the photographs to aid in the color adjustment process.

Imaging

Under each color bar, type or select the relative values of each color between

–10 and +10.

You can click Reset to restore the default values.

Click OK to save the new Color balance settings.

Black and White Adjustment

Black and white adjustment settings change the brightness and contrast of graphics. These settings are useful if graphic images are printing too light, too gray, or too dark. Text remains unaffected.

Adjusting Black and White Settings

For color models, in Imaging > Color, click the Black icon.

For color and black and white models, in the Adjustment list, select Custom.

A preview image in the Adjustment Settings dialog box illustrates any brightness and contrast changes.

Type or select the Brightness value to lighten or darken the graphic images of

the print job.

The brightest setting is +100; the darkest is -100. Zero is the default mid-level setting. Adjusting brightness allows for the customization of graphic images if images are printing too light or too dark.

Printer Driver 8-14

Imaging

Color Conversion

Type or select the Contrast value to increase or decrease the proportion of light to dark in the graphic images of the print job.

A high contrast setting decreases the grayscale spectrum, making light grays lighter and dark grays darker. A low contrast setting increases the grayscale spectrum, making light grays darker and dark grays lighter.

The highest contrast setting is +100; the lowest is -100. Zero is the default midlevel setting. Adjusting contrast is useful if graphic images are printing too gray, or too black and white. Text remains unaffected.

Click OK to save the new black and white settings.

Color conversion lets you choose how to apply color processing to your print job depending on how color data is received from the application. This feature is available if KPDL is selected as the PDL.

In Imaging > Color conversion, select from the following options:

Printer settings

Select this option to use the settings currently on the device.

Speed priority

Select this option if the driver receives RGB data from the application.

Quality priority

Select this option if the driver receives full-color data from the application. In the Job tab, in the Job Storage (e-MPS) > Type list, if saving to Custom Box, it is only possible to print. It is not possible to copy external memory or change or send internal data.

Text and Graphics Effects

Special settings are available for color or black and white printing. (Selections vary according to printing system model.)

Print text as black

This option prints all color text as black. It produces faster printing of color print jobs by reducing the amount of data sent to the printer. In black and white printing, it increases the detail for light-colored text printed. For color models, this feature is available with all of the Color options.

Print grays with black toner

This option prints grayscale with black toner only. Full color must be selected as the Color option.

Continuous tone

Images are represented by a series of evenly graduated tones, as in a photograph. This option is available for color models and is selected by default when Full color is selected as the Color option.

Print graphics as black

This option prints all color graphics with black, rather than grayscale. This feature is implemented for CAD applications. For color models, Black must be selected as the Color option.

Gray component replacement

This option replaces the gray component of CMY with black.

8-15 User Guide

Imaging

Composite overprint

This option blends overlapping images into a composite image. This feature is available when KPDL is selected as the PDL.

Printer Driver 8-16

Cover Mode

9 Publishing

In the Publishing tab, you can create covers and inserts for a print job, insert sheets between transparencies, and insert tab divider sheets. The features on this tab are available only when PCL XL or KPDL is selected as the PDL. (Selections vary according to printing system model.)

To return to the original settings, click Reset. The Reset button is available when accessing the printer driver from the application's Print dialog box.

Cover mode lets you add cover pages for the front and back of your document. You can print on cover pages of a different weight or color than the main document. The source of the cover paper is specified by adjusting the Media for cover settings in the Publishing tab.

Duplex printing must be selected in the Basic tab or Quick Print tab in order to print using the Front / Inside or Back / Outside options.

Although Cover mode, Page insert, and Index tab dividers can be used simultaneously, they cannot be used with Transparency interleaving.

Cover Mode Options

Check Box Selection Cover Insertion Type

Front Inserts a blank front cover.

Front Prints on the outside surface of the

Front Outside

front cover.

— continued

9-1 User Guide

Publishing

Check Box Selection Cover Insertion Type

Front Prints on the inside surface of the front

Front Inside

cover.

Front

Front Outside

Front Inside

Front and back

Front Outside

Prints on the outside and inside surfaces of the front cover.

Inserts blank front and back covers.

Prints on the outside surface of the front cover and inserts a blank back cover.

— continued

Printer Driver 9-2

Publishing

Check Box Selection Cover Insertion Type

Front and back

Prints on the inside surface of the front cover and inserts a blank back cover.

Front Inside

Front and back

Front Outside

Front Inside

Front and back

Back Inside

Prints on both sides of the front cover and inserts a blank back cover.

Prints on the inside surface of the back cover and inserts a blank front cover.

Front and back

Back Outside

Prints on the outside surface of the back cover and inserts a blank front cover.

— continued

9-3 User Guide

Check Box Selection Cover Insertion Type

Front and back

Back Inside

Back Outside

Prints on both sides of the back cover and inserts a blank front cover.

Publishing

Front and back

Front Outside

Front Inside

Back Inside

Back Outside

Prints on both sides of the front and back covers.

Printing Covers

In the Publishing tab, click the Cover mode icon.

Select Front or Front and back to specify the type of covers.

Select from Print onto options if you want to print on the covers.

In the Media for cover list, select the media type or source cassette for the front

and back covers. When you choose the media type, a source cassette matching that media type is automatically selected.

Click OK to return to the Print dialog box.

Click OK to start printing.

Transparency Interleaving

Transparency interleaving inserts a backing sheet between printed

transparencies. The backing sheet, also known as an interleaf, helps keep transparencies clean and prevents them from clinging together. This feature is only available when printing on transparencies supplied from the MP tray. You can print the same content on the backing pages as on the transparencies.

Transparency interleaving cannot be used together with Cover mode, Page insert, or Index tab dividers.

Printer Driver 9-4

Publishing

Inserting Backing Sheets Between Transparencies

In Basic > Media type, select Transparency. If the Source and Media type

lists have been combined (by a selection in Device Settings > Compatibility), Media type does not appear. Instead, in the Source list select Auto (Transparency).

In the Publishing tab, click the Transparency interleaving icon.

To print the transparency content on the inserted pages also, select the Print

onto backing check box.

In the Media for backing list, select the media type or source cassette. When

you choose the media type, a source cassette matching that media type is automatically selected.

Click OK to return to the Print dialog box.

Click OK to start printing.

The printing system's operation panel prompts you to load transparencies into the MP tray, and if necessary, load backing paper into the selected cassette.

Page Insert

A Page insert is a preprinted page or a page of a different paper type that is inserted at specified points in a print job. The inserted page can also be printed on during the print job. Both sides of the page insert can be printed on by using the duplex unit.

Duplex printing must be selected in the Basic tab or Quick Print tab in order to print using the Back option.

If this feature is used with Publishing > Index tab dividers, some options selected for Index tab dividers are automatically selected for Page insert. Similarly, Page insert selections appear in the Tab Settings dialog box.

Although Cover mode, Page insert, and Index tab dividers can be used simultaneously, they cannot be used with Transparency interleaving.

Page Insertion Options

Check Box Selection Page Insertion Type

Page insert Inserts a blank page.

— continued

9-5 User Guide

Publishing

Check Box Selection Page Insertion Type

Page insert Prints on the front side of the inserted

Front

Page insert Prints on the back side of the inserted

Back

page.

Page insert

Front

Back

Prints on both sides of the inserted page.

Printing Page Inserts

In the Publishing tab, click the Page insert icon.

To print on both the front and back of the inserted page, select the Front and

Back check boxes.

In Insert before pages, type the page number to insert. A page is inserted

between the page number you typed and the page before it.

From the Media for page list, select the media type or source cassette. When

you choose the media type, a source cassette matching that media type is automatically selected.

Click OK to return to the Print dialog box.

Printer Driver 9-6

Publishing

Click OK to start printing.

Index Tab Dividers

Index tab dividers inserts tab divider sheets at specified points in a print job to

divide sections of a printed document. You can also print on the tabs. You can use standard or custom tab divider sheets for A4 and Letter paper. Tab divider sheets must be supplied from the MP tray so that the tabs are on the edge opposite the feeding direction, and the printing surface is down. The first tab is on the left side relative to the feed direction. This feature is available for A3 models.

All tabs that are set up in the Tab Settings dialog box are applied to the current job.

Ensure that the paper is properly loaded by following the instructions outlined in the printing system's Operation Guide.

Some options selected for Index tab dividers are automatically selected for

Publishing > Page insert. Similarly, Page insert selections appear in the Tab Settings dialog box.

Tab text can be printed on only one side of the tabs, even if the document pages are printed on both sides.

We recommend that you print a test job on plain paper. Use a short test document, and cut plain paper to the size of the tab divider sheets. The test job will help you determine the correct driver settings and placement into the MP tray.

The Custom Media, Tab Settings, and Custom Tab dialog boxes display the unit of measurement in inches or millimeters. You can change the Units setting in the User Settings dialog box, accessed from Device Settings.

Index Tab Dividers Options

The following options are available for the Index tab dividers feature in the Publishing tab.

Media

From the list, select from available standard tab divider sheets for A4 or Letter. You can select Custom to open the Custom Media dialog box and create custom tab divider sheets.

Settings

Click to open the Tab Settings dialog box and select tab settings for the current print job.

Custom Media dialog box

You can create a custom size with your chosen dimensions for non-standard size tab divider sheets. Tab size is adjusted depending on the number of tabs and the selected distances before, between, and after the tabs. The total distance must not exceed the long edge width.

Number of tabs

Select how many tabs to include for the custom media, between 1 and 15.

Print size

Select A4 or Letter.

Before first tab

Type or select the distance between the edge of the paper and the first tab.

9-7 User Guide

Publishing

Between tabs

Type or select the distance between each of the tabs. For tabs that overlap each other, select a negative value.

After last tab

Type or select the distance between the edge of the paper and the last tab.

Extension

Type or select the distance the tab extends from the edge of the paper.

Tab Settings dialog box

Once the media is selected, you must select tab settings for the current print job. A maximum of 50 tab printing settings and a maximum of 50 page insert settings can be set. Selections apply to all tab divider sheets in the print job.

Tab patterns are repeated when the last tab position has been used. For example, with 20 tabs selected for 5-tab media, 5 tabs are inserted 4 times in a repeated pattern.

Note: If Use index tab dividers is selected, you cannot select the same Print onto setting in Page insert. If Use index tab dividers is not selected, because

the Print onto setting is the same as that in Page insert, a different setting from Page insert cannot be selected.

Current tab settings

Displays the tab settings for the current print job.

New

Click the button to add a new tab to the Current tab settings list. Then select settings for the new tab.

Delete

You can remove a tab by selecting it in the list and clicking Delete.

Customize

Click the button to open the Custom Tab dialog box and select custom tab settings such as font, color, and text alignment. The Customize button is available when Use index tab dividers is selected and Shift image is cleared.

Insert before page

Type the page number to insert. A tab divider sheet is inserted between the page number you typed and the page before it. If 1 is selected, the tab divider sheet is inserted before page 1. If Use index tab dividers is not selected, the Page insert feature is selected automatically with this page number in Insert before pages.

If a number is entered twice, an error occurs (red text box). Delete the duplicate entry under Current tab settings.

Print onto

Select options for printing document data on the inserted pages. Select Front to print the next page of document data on the tab divider sheet. Select None if you do not want to print document data on the tab divider sheets. With either selection, tab text is printed on the tabs, if selected.

Use index tab dividers

Select the check box to use the option selected in the Media list in the Publishing tab. When the check box is clear, Index tab dividers is the same as Publishing > Page insert.

Printer Driver 9-8

Publishing

Shift image

With Use index tab dividers selected, select Shift image for applications and templates that include tabs in the document. Page content and tab text are moved so that the tab text is printed on the tabs. Type or select the shift distance to a maximum of 30 mm (1.2 inches).

When using this feature, type the tab text in the application or template, not in the Tab Settings dialog box.

Position

Select the tab position for each tab. Auto sets the tab positions automatically, or you can select the position from the list. Available options depend on the selected standard media or the Number of tabs selection in the Custom Media dialog box. Tab divider sheets must be loaded to match the position settings.

Tab text (3 lines max)

Type a maximum of three lines of text for each tab, to a maximum of 260 characters on each line.

Custom Tab dialog box

You can select the font, style, color, size, orientation, tab alignment, text alignment, and line spacing for the tab text. Selections apply to all tab divider sheets in the print job.

Color options vary by model. For color models, select from default or custom colors. For black and white models, or with Black selected in the Quick Print,

Basic, or Imaging tabs, select Black or select shades of gray from the list.

Orientation options are different from the orientation options in the Quick Print and Basic tabs. For custom tabs, the following orientation options are available:

Normal

Viewing the sheets with tabs at the top, text is horizontal and right side up.

Flipped

Viewing the sheets with tabs at the top, text is horizontal and upside down.

Horizontal

Viewing the sheets with tabs on the right side, text is horizontal.

Vertical

Viewing the sheets with tabs on the right side, text is vertical.

Tab alignment options are similar to Microsoft Word vertical alignment:

Top

Tab text is aligned at the top edge of the tab extension.

Middle

Tab text is aligned at the center of the tab extension.

Bottom

Tab text is aligned at the bottom edge of the tab extension.

When selecting Text alignment and Line spacing options, view the paper with tabs on the right side, as in the dialog box illustration.

Inserting Index Tab Dividers

Load tab divider sheets into the MP tray with the long edge facing the direction

of the paper feed. The tabs will then be facing outward. Place the sheets with

9-9 User Guide

the printing surface down. The first tab is on the left side relative to the feed direction.

In the Publishing tab, click the Index tab dividers icon.

In the Media list, select a standard media option, or select Custom to create

custom media.

If Custom was selected in step 3, create the desired custom media in the

Custom Media dialog box, and click OK.

Click Settings.

In the Tab Settings dialog box, click New, and type the page number to insert.

A tab divider sheet is inserted between the page number you typed and the page before it.

Select your desired settings for Print onto and Position, and type the tab text.

Publishing

If Use index tab dividers is selected and Shift image is cleared, you can click

Customize and select custom settings for the tab text. Click OK.

For applications and templates that include tabs in the document, select Shift image, and select the shift distance.

Repeat steps 6-8 to include multiple tab divider sheets in the print job, and then

click OK.

If you want to use the current tab settings again, click Save as at the bottom of

the Printing Preferences dialog box and save the settings as a profile.

Click OK to return to the Print dialog box.

Click OK to start printing.

Printer Driver 9-10

10 Job

In the Job tab, you can store print jobs in the memory installed in the printing system. You can also select a Job name to use with Job storage features. You can use this tab to set or change the default settings that apply when you print a document from a Microsoft Windows application. (Selections vary according to printing system model.)

To return to the original settings, click Reset. The Reset button is available when accessing the printer driver from the application's Print dialog box.

Job Storage (e-MPS)

Job storage (e-MPS) offers a set of options for saving print jobs in printing

system memory, so that you can print or reprint them later. Print jobs can easily be reprinted later using the printing system’s operation panel, and printing of sensitive documents can be restricted to approved users. (Selections vary according to printing system model.)

For some models, a portion of the printing system's memory can be designated as a RAM disk for storing print job data temporarily, or you can install a storage device for larger capacity and permanent storage.

E-MPS is a multitier solution that provides advanced print management, directly from the desktop. By storing a job in the printing system, you can print it from the operation panel without sending it again from the computer.

To use the Job storage (e-MPS) features, you can set a User name in the

User Settings dialog box, available in Device Settings.

Temporary

Temporary lets you print jobs and save them on the hard disk. When the hard

disk becomes full, Temporary jobs are replaced beginning with the oldest jobs. If you do not want jobs to be removed, select the Permanent option.

Selecting Temporary as a storage option increases print speed on a multiple copy job. The first copy of the job is rendered once, then all subsequent copies are printed at the rated speed of the printing system.

Temporary jobs can be reprinted by installing and using the KYOCERA Net Viewer utility.

Storing a Temporary Print Job

You can print a job and store it temporarily on the hard disk.

In the Job tab, click the Job storage (e-MPS) icon.

In the Type list, select Temporary.

Click OK to return to the Print dialog box.

10-1 User Guide

Permanent

Click OK to start printing.

Permanent lets you print jobs and save them on the hard disk. Jobs are stored

on the hard disk until it becomes full, and then can only be removed manually.

Selecting Permanent as a storage option increases print speed on a multiple copy job. The first copy of the job is rendered once, then all subsequent copies are printed at the rated speed of the printing system.

A list of Permanent jobs can be printed at the printing system's operation panel. Set a Job name and User name to help you find the jobs in the Permanent

Code Job List.

Permanent jobs can be reprinted by installing and using the KYOCERA Net Viewer utility.

Storing a Permanent Print Job

You can print a job and store it on the hard disk until it is removed manually.

In the Job tab, click the Job storage (e-MPS) icon.

Job

In the Type list, select Permanent.

Click OK to return to the Print dialog box.

Click OK to start printing.

Placing a Barcode on a Print Job

For some models, barcode information can be added to a print job. You can then scan the print job or a job list with the optional Barcode reader to print a job. It requires that the Barcode reader be connected to the serial port on the printing system.

In the Job tab, click the Job storage (e-MPS) icon.

In the Type list, select Temporary or Permanent.

Click Options.

In the Barcode Options dialog box, select Barcode.

Select Print on first page only to print a barcode that appears only on the first

page of the print job. Select Print on all sheets to print a barcode on each page.

From the Position list, select the barcode position on the page.

In the Orientation menu, select whether you want the barcode to print in a

horizontal or vertical position. The default orientation is horizontal.

Printer Driver 10-2

Job

Virtual Mail Box

Storing a Job in a Virtual Mail Box

If you want to print the job ID as characters with the barcode, select Print barcode ID.

To finish, click OK.

Virtual mail box lets you send print jobs to electronic mail boxes rather than

physical mail boxes. Sending a job to a Virtual mail box also creates the mail box on the hard disk. After jobs are sent to a Virtual mail box, they can be printed from the printing system's operation panel. Jobs are saved until they are printed and then are removed from memory. You can create up to 255 mail boxes in the Hard Disk Settings dialog box in Device Settings. For some models, Virtual mail box is unavailable when KPDL is selected as the PDL.

The main difference between Virtual mail box and Synergy print box is that a job sent to a Virtual mail box is deleted as soon as it is printed, while a job sent to a Synergy print box is stored permanently in printing system memory.

You can store a print job in a Virtual mail box where it is held for printing.

Custom Box

In the Job tab, click the Job storage (e-MPS) icon.

In the Type list, select Virtual mail box (VMB), and then click Selection.

Select a method for choosing an output tray:

Select one or more trays in the Defined names list.

Select Prompt for Mailbox ID. When you click OK in the Print dialog box, select one or more trays from the Virtual Mailbox Selection dialog box that appears. If Virtual mail box is used repeatedly, this option lets you select trays easily without opening the Job tab for every print job.

Click OK to return to the Print dialog box.

Click OK to start printing.

Custom Box lets you store print jobs until they are printed from the printing

system's operation panel. You can print one or more jobs from the storage device.

Print jobs can be deleted after printing or saved on the storage device for 1-31 days.

Custom boxes must be set up for each user at the printing system's home page, and in the Hard Disk Settings or SSD Settings dialog box, accessed from

Device Settings. The maximum number of custom boxes is 1000.

Storing a Job in a Custom Box

After custom boxes are assigned, you can send print jobs to custom boxes, where print jobs are stored on the printing system’s storage device.

10-3 User Guide

In the Job tab, click the Job storage (e-MPS) icon.

In the Type list, select Custom box.

Click Settings.

Select a Custom Box Settings option:

Select Use specific box number, and type the box number and password.

Select Prompt for box number, and click OK. When the Custom Box dialog box appears, type a box number from the Defined custom boxes list. If a password was set, type the password.

Select Display box number list, and click OK. When the Custom Box dialog box appears, select a box from the list. If a password was set, type the password. This can be selected if Shared box is selected in the Hard Disk Settings or SSD Settings dialog box. (For some models, Shared box is selected by default.)

Select Verify box number for each login user, and click OK. When the Custom Box dialog box appears, type a box number. To include a password, select Require password and type the password. This can be selected when Shared box is selected in the Hard Disk Settings or SSD Settings dialog box. (For some models, Shared box is selected by default.)

Job

Quick Copy

Click OK to return to the Print dialog box.

Click OK to start printing.

With Verify box number for each login user selected, the driver searches for a login user name from the custom box list to serve as the custom box name:

If a match is found, the custom box is used for the print job.

If a match is not found, the driver checks for administrator or user permissions. With administrator permissions, you are prompted to type a box number and optional password for the print job. The driver searches for a Windows login user name and adds this name with the box number and password to the custom box list in the driver. With user permissions, the print job is canceled. You are then prompted to contact an administrator to establish printing permissions.

Quick copy is a Job storage (e-MPS) option that prints all copies of a print job and stores the job temporarily on the storage device for reprinting later. This feature is available when a storage device is installed and selected in Device

Settings.

Quick copy is useful for printing the job again later in the day when you need

additional copies at short notice. You can set the number of additional copies and print the job from the printing system’s operation panel without sending the job again from the computer.

The number of Quick copy or Proof and hold jobs that can be stored is set at the printing system’s operation panel, to a maximum of 50 jobs. When the designated number of jobs is reached, older jobs are replaced by new jobs. All Quick copy jobs are stored on the storage device after printing but are deleted

Printer Driver 10-4

Job

when the printing system is turned off. You can manually delete a job at the operation panel.

Warning: A print job replaces a job on the storage device having the same User name and Job name. To prevent this, select Use job name + date and time under Overwrite job name.

Printing a Quick Copy Job

With a storage device installed, Quick copy lets you print a document and save it in the printing system until the job is manually deleted or the printing system is turned off.

In the Job tab, click the Job storage (e-MPS) icon.

In the Type list, select Quick copy.

Click OK to return to the Print dialog box.

Click OK to start printing.

Proof and Hold

Proof and hold is a Job storage (e-MPS) option that prints one copy of a print

job so that you can proof it before printing the remaining copies. This feature is available when a storage device is installed, or for some models when a RAM disk is set up in the printing system and selected in Device Settings.

After the proof copy is printed and checked, remaining copies can be printed from the printing system’s operation panel without sending the job again from the computer. If desired, you can change the number of copies printed.

Note: Proof and hold is unavailable for some applications such as Microsoft Excel.

The number of Proof and hold or Quick copy jobs that can be stored is set at the printing system’s operation panel, to a maximum of 50 jobs. When the designated number of jobs is reached, older jobs are replaced by new jobs. All Proof and hold jobs are stored on the storage device after printing but are deleted when the printing system is turned off. You can manually delete a job at the operation panel.

Warning: A print job replaces a job on the storage device having the same User name and Job name. To prevent this, select Use job name + date and time under Overwrite job name.

Printing a Proof and Hold Job

Proof and hold lets you print one copy of a multicopy job to proof before

printing the remaining copies. The job is stored on the storage device or, for some models, in RAM disk memory, until the printing system is turned off or the job is manually deleted.

In the Basic tab, select the number of copies to be printed.

In the Job tab, click the Job storage (e-MPS) icon.

10-5 User Guide
