Kyocera PHANTOMK 450 User Guide

User Guide for Kyocera Phantom

This manual is based on the production version of the Kyocera K454L, K454N, and K454NC phones. Software changes may have occurred after this printing. Kyocera reserves the right to make changes in technical and product specifications without prior notice. The products and equipment described in this documentation are manufactured under license from QUALCOMM Incorporated under one or more of the following U.S. patents:

4,901,307 5,056,109 5,099,204 5,101,501 5,103,459 5,107,225 5,109,390 5,193,094 5,228,054 5,257,283 5,265,119 5,267,261 5,267,262 5,280,472 5,283,536 5,289,527 5,307,405 5,309,474 5,337,338 5,339,046 5,341,456 5,383,219 5,392,287 5,396,516 D356,560 5,408,697 5,414,728 5,414,796 5,416,797 5,426,392 5,437,055 D361,065 5,442,322 5,442,627 5,452,473 5,461,639 5,469,115 5,469,471 5,471,497 5,475,870 5,479,475 5,483,696 5,485,486 5,487,175 5,490,165 5,497,395 5,499,280 5,504,773 5,506,865 5,509,015 5,509,035 5,511,067 5,511,073 5,513,176 5,515,177 5,517,323 5,519,761 5,528,593 5,530,928 5,533,011 5,535,239 5,539,531 5,544,196 5,544,223 5,546,459 5,548,812 5,559,881 5,559,865 5,561,618 5,564,083 5,566,000 5,566,206 5,566,357 5,568,483 5,574,773 5,574,987 D375,740 5,576,662 5,577,022 5,577,265 D375,937 5,588,0 43 D376,804 5,589,756 5,590,069 5,590,406 5,590,408 5,592,548 5,594,718 5,596,570 5,600,754 5,602,834 5,602,833 5,603,096 5,604,459 5,604,730 5,608,722 5,614,806 5,617,060 5,621,752 5,621,784 5,621,853 5,625,876 5,627,857 5,629,955 5,629,975 5,638,412 5,640,414 5,642,398 5,644,591 5,644,596 5,646,991 5,652,814 5,654,979 5,655,220 5,657,420 5,659,569 5,663,807 5,666,122 5,673,259 5,675,581 5,675,644 5,680,395 5,687,229 D386,186 5,689,557 5,691,974 5,692,006 5,696,468 5,697,055 5,703,902 5,704,001 5,708,448 5,710,521 5,710,758 5,710,768 5,710,784 5,715,236 5,715,526 5,722,044 5,722,053 5,722,061 5,722,063 5,724,385 5,727,123 5,729,540 5,732,134 5,732,341 5,734,716 5,737,687 5,737,708 5,742,734 D393,856 5,748, 104 5,751,725 5,751,761 5,751,901 5,754,533 5,754,542 5,754,733 5,757,767 5,757,858 5,758,266 5,761,204 5,764,687 5,774,496 5,777,990 5,778,024 5,778,338 5,781,543 5,781,856 5,781,867 5,784,406 5,784,532 5,790,589 5,790,632 5,793,338 D397,110 5,799, 005 5,799,254 5,802,105 5,805,648 5,805,843 5,812,036 5,812,094 5,812,097 5,812,538 5,812,607 5,812,651 5,812,938 5,818,871 5,822,318 5,825,253 5,828,348 5,828,661 5,835,065 5,835,847 5,839,052 5,841,806 5,842,124 5,844,784 5,844,885 5,844,899 5,844,985 5,848,063 5,848,099 5,850,612 5,852,421 5,854,565 5,854,786 5,857,147 5,859,612 5,859,838 5,859,840 5,861,844

Phones

5,862,471 5,862,474 5,864,760 5,864,763 5,867,527 5,867,763 5,870,427 5,870,431 5,870,674 5,872,481 5,872,774 5,872,775 5,872,823 5,877,942 5,878,036 5,870,631 5,881,053 5,881,368 5,884,157 5,884,193 5,884,196 5,892,178 5,892,758 5,892,774 5,892,816 5,892,916 5,893,035 D407,701 5, 898,920 5,903,554 5,903,862 D409,561 5,907,167 5,909,434 5,910,752 5,911,128 5,912,882 D410,893 5, 914,950 5,915,235 5,917,708 5,917,811 5,917,812 5,917,837 5,920,284 D411,823 5,923 ,650 5,923,705 5,926,143 5,926,470 5,926,500 5,926,786 5,930,230 5,930,692 Other patents pending.

The Kyocera Wireless Corp. ("KWC") products described in this manual may include copyrighted KWC and third party software stored in semiconductor memories or other media. Laws in the United States and other countries preserve for KWC and third party software providers certain exclusive rights for copyrighted software, such as the exclusive rights to distribute or reproduce the copyrighted software. Accordingly, any copyrighted software contained in the KWC products may not be modified, reverse engineered, distributed or reproduced in any manner not permitted by law. Furthermore, the purchase of the KWC products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents or patent applications of KWC or any third party software provider, except for the normal, nonexclusive royalty-free license to use that arises by operation of law in the sale of a product. Kyocera is a registered trademark of Kyocera Corporation. Brick Attack, Doodler, Mask, and Phantom are trademarks of Kyocera Wireless Corp. QUALCOMM is a registered trademark of QUALCOMM, Inc. Tetris is a registered trademark of Elorg Company LLC. Openwave is a trademark of Openwave Systems Incorporated. eZiText is a registered trademark of Zi Corporation. All other trademarks are the property of their respective owners.

82-M8552-1EN, Rev. 002

FCC/IC Notice

This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. To maintain compliance with FCC RF exposure guidelines, if you wear a handset on your body, use the Kyocera Wireless Corp. (KWC) supplied and approved: Phone Case Model: TXLCC10042B Belt Clip Model: TXLCC10047B Sport Clip Model: TXLCC10045B Other accessories used with this device for body-worn operations must not contain any metallic components and must provide at least 22.5 mm separation distance including the antenna and the user’s body.

THIS MODEL PHONE MEETS THE GOVERNMENT’S REQUIREMENTS FOR EXPOSURE TO RADIO WAVES.

Your wireless phone is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the U.S. Government. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons, regardless of age and health. The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg.* Tests for SAR are conducted using standard operating positions specified by the FCC with the phone transmitting at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the phone while operating can be well below the maximum value.

This is because the phone is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base station antenna, the lower the power output. Before a phone model is available for sale to the public, it must be tested and certified to the FCC that it does not exceed the limit established by the government-adopted requirement for safe exposure. The tests are performed in positions and locations (e.g., at the ear and worn on the body) as required by the FCC for each model. The highest SAR values for these model phones are: AMPS/CDMA modes (Part 22) - Head: 1.37 W/kg; Body-worn: 0.66 W/kg PCS/CDMA mode (Part 24) - Head: 1.36 W/kg; Body-worn: 0.47 W/kg Body-worn measurements differ among phone models, depending upon availability of accessories and FCC requirements. The body-worn SAR values provided above were obtained by using Kyocera Wireless Corp. [KWC] supplied and approved: Phone Case Model: TXLCC10042B Belt Clip Model: TXLCC10047B Sport Clip Model: TXLCC10045B While there may be differences between the SAR levels of various phones and at various positions, they all meet the government requirement for safe exposure. The FCC has granted an Equipment Authorization for this model phone with all reported SAR levels evaluated as in compliance with the FCC RF emission guidelines. SAR information on this model phone is on file with the FCC and can be found under the Display Grant section after searching on the FCC ID: OVFKWC-K4X4 Additional information on SAR can be found on the Cellular Telecommunications and Internet Association (CTIA) web-site at

http://www.wow-com.com.

* In the United States and Canada, the SAR limit for mobile phones used by the public is 1.6 watts/kg (W/ kg) averaged over one gram of tissue. The standard incorporates a substantial margin of safety to give additional protection for the public and to account for any variations in measurements.

http://www.fcc.gov/oet/fccid

User Guide for Kyocera Phantom Phones iii

Caution

The user is cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the warranty and user’s authority to operate the equipment.

Optimize your phone’s performance

Use the guidelines on page 1 to learn how to optimize the performance and life of your phone and battery.

Air bags

If you have an air bag, DO NOT place installed or portable phone equipment or other objects over the air bag or in the air bag deployment area. If equipment is not properly installed, you and your passengers risk serious injury.

Medical devices

Pacemakers—Warning to pacemaker wearers: Wireless phones, when in the ‘on’ position, have been shown to interfere with pacemakers. The phone should be kept at least six (6) inches away from the pacemaker to reduce risk.

The Health Industry Manufacturers Association and the wireless technology research community recommend that you follow these guidelines to minimize the potential for interference.

• Always keep the phone at least six inches (15 centimeters) away from your pacemaker when the phone is turned on.

• Do not carry your phone near your heart.

• Use the ear opposite the pacemaker.

• If you have any reason to suspect that interference is taking place, turn off your phone immediately.

Hearing aids—Some digital wireless phones may interfere with hearing aids. In the event of such interference, you may want to consult your service provider or call the customer service line to discuss alternatives.

Other medical devices—If you use any other personal medical device, consult the manufacturer of the device to determine if it is adequately shielded from external RF energy. Your physician may be able to help you obtain this information. In health care facilities—Turn your phone off in health care facilities when instructed. Hospitals and health care facilities may be using equipment that is sensitive to external RF energy.

Potentially unsafe areas

Posted facilities—Turn your phone off in any facility when posted notices require you to do so.

Aircraft—FCC regulations prohibit using your phone on a plane that is in the air. Turn your phone off before boarding aircraft.

Vehicles—RF signals may affect improperly installed or inadequately shielded electronic systems in motor vehicles. Check with the manufacturer of the device to determine if it is adequately shielded from external RF energy. Your physician may be able to help you obtain this information.

Blasting areas—Turn off your phone where blasting is in progress. Observe restrictions, and follow any regulations or rules.

Potentially explosive atmospheres—Turn off your phone when you are in any area with a potentially explosive atmosphere. Obey all signs and instructions. Sparks in such areas could cause an explosion or fire, resulting in bodily injury or death.

Areas with a potentially explosive atmosphere are often, but not always, clearly marked. They include:

• fueling areas such as gas stations

• below deck on boats

• transfer or storage facilities for fuel or chemicals

• vehicles using liquefied petroleum gas, such as propane or butane

• areas where the air contains chemicals or particles such as grain, dust, or metal powders

• any other area where you would normally be advised to turn off your vehicle engine

Use with care

Use only in normal position (to ear). Avoid dropping, hitting, bending, or sitting on the phone.

Keep phone dry

If the phone gets wet, turn the power off immediately and contact your dealer. Water damage may not be covered under warranty.

Resetting the phone

If the screen seems frozen and the keypad does not respond to keypresses, reset the phone by completing the following steps:

1. Remove the battery door.

2. Remove and replace the battery.

If the problem persists, return the phone to the dealer for service.

Accessories

Use only Kyocera-approved accessories with Kyocera phones. Use of any unauthorized accessories may be dangerous and will invalidate the phone warranty if said accessories cause damage or a defect to the phone.

To shop online for a Hands-free Car Kit and other phone accessories, visit

store.

To order by phone, call (800) 349-4188 (U.S.A. only) or (858) 882-1410.

Radio Frequency (RF) energy

Your telephone is a radio transmitter and receiver. When it is on, it receives and sends out RF energy. Your service provider’s network controls the power of the RF signal. This power level can range from 0.006 to 0.6 watts.

In August 1996, the U.S. Federal Communications Commission (FCC) adopted RF exposure guidelines with safety levels for hand-held wireless phones. These guidelines are consistent with the safety standards previously set by both U.S. and international standards bodies in the following reports:

• ANSI C95.1 (American National Standards Institute, 1992)

www.kyocera-wireless.com/

• NCRP Report 86 (National Council on Radiation Protection and Measurements, 1986)

• ICNIRP (International Commission on NonIonizing Radiation Protection, 1996)

Your phone complies with the standards set by these reports and the FCC guidelines.

E911 Mandates

Where service is available, this handset complies with the Phase I and Phase II E911 Mandates issued by the FCC.

Battery and charger specifications

Charger Input Output

CV90-60858-01 100-240 VAC / 50/60 Hz4.5 V 1.5 A

CV90-60859-1 120 VAC / 60 Hz 5.2 V 400

Standard Battery: CV90-K3040 3.7V / 900mAh

Customer support

Your service provider’s customer support department may be accessible directly from your phone when you dial a number such as *611. They can answer questions about your phone, phone bill, call coverage area, and specific features available to you, such as call forwarding or voicemail. For questions about the phone features, refer to the materials provided with your phone, or visit

www.kyocera-wireless.com.

For additional questions, you may contact the Kyocera Wireless Corp. Customer Care Center in one of the following ways:

• Web site: www.kyocera-wireless.com

• Email: phone-help@kyocera-wireless.com

• Telephone: 1-800-349-4478 (U.S. and Canada) or 1-858-882-1401. Customer support phone numbers are also available in the following countries.

Argentina: 0-800-666-0052

User Guide for Kyocera Phantom Phones v

Australia: 800-507-000

Brazil: 0-800-55-2362

Chile: 800-43-1212

Colombia 01-800-700-1546

India: Toll free: 1-600-121214

Mexico: 001-866-650-5103

New Zealand: 0-800-990-100

Panama: 001-800-201-1984

Peru: 0-800-51-934

Puerto Rico: 1-866-664-6443

Venezuela: 0-800-100-2640

Before requesting support, please try to reproduce and isolate the problem. When you contact the Customer Care Center, be ready to provide the following information:

• The name of your service provider.

• The actual error message or problem you are experiencing.

• The steps you took to reproduce the problem.

• The phone’s electronic serial number (ESN). To find the ESN select

Toll: 0124-284-5000

Menu → Phone Info.

Qualified service

If the problem with your phone persists, return the phone with all accessories and packaging to the dealer for qualified service.

Become a product evaluator

To participate in the testing and evaluation of Kyocera Wireless Corp. products, including cellular or PCS phones, visit

093 453 037

beta.kyocera-wireless.com.

Kyocera Wireless Corp.

10300 Campus Point Drive, San Diego, CA 92121

Visit us at

To purchase accessories, visit

www.kyocera-wireless.com/store

U.S.A.

www.kyocera-wireless.com

CONTENTS

1 Getting Started. . . . . . . . . . . . . . . . . . . . . . 1

Charging the battery . . . . . . . . . . . . . . . . . . . . . . .1

Using menus . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

2 Making and Answering Calls . . . . . . . . . . 6

Making a call . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Calling emergency services. . . . . . . . . . . . . . . . . .7

Speed dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Setting up voicemail . . . . . . . . . . . . . . . . . . . . . . .9

Silencing an incoming call . . . . . . . . . . . . . . . . .10

Locking the keypad . . . . . . . . . . . . . . . . . . . . . .10

3 Entering Letters, Numbers,

and Symbols . . . . . . . . . . . . . . . . . . . . . . 13

4 Storing Contacts . . . . . . . . . . . . . . . . . . . 16

Saving a contact entry. . . . . . . . . . . . . . . . . . . . .16

Editing or erasing a contact . . . . . . . . . . . . . . . .17

Finding contact information . . . . . . . . . . . . . . . .18

5 Sending and Receiving

Text Messages . . . . . . . . . . . . . . . . . . . . .20

Sending text messages . . . . . . . . . . . . . . . . . . . .20

Retrieving text messages. . . . . . . . . . . . . . . . . . .23

Customizing message settings. . . . . . . . . . . . . . .25

6 Customizing Your Phone . . . . . . . . . . . . 27

Silencing all sounds . . . . . . . . . . . . . . . . . . . . . .28

Choosing a different ringer. . . . . . . . . . . . . . . . .28

Adjusting volume . . . . . . . . . . . . . . . . . . . . . . . .29

Using shortcuts . . . . . . . . . . . . . . . . . . . . . . . . .29

Personalizing the screen . . . . . . . . . . . . . . . . . .30

Creating a secure environment. . . . . . . . . . . . . .33

Setting message alerts . . . . . . . . . . . . . . . . . . . .34

Network settings. . . . . . . . . . . . . . . . . . . . . . . . .35

Data settings. . . . . . . . . . . . . . . . . . . . . . . . . . . .35

Setting position location. . . . . . . . . . . . . . . . . . .36

7 Using Voice Recognition . . . . . . . . . . . . 37

Setting up voice dialing . . . . . . . . . . . . . . . . . . .37

Calling using voice tags . . . . . . . . . . . . . . . . . . .37

Using voice features with

hands-free car kits. . . . . . . . . . . . . . . . . . . . . . . 38

Training voice recognition . . . . . . . . . . . . . . . . .39

8 Using Tools . . . . . . . . . . . . . . . . . . . . . . .40

Scheduler . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40

Alarm Clock. . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Tip Calculator . . . . . . . . . . . . . . . . . . . . . . . . . .41

Calculator . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41

World Clock. . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Timer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Stopwatch . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

9 Media Gallery / Fun & Games . . . . . . . . .43

Tetris . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43

Brick Attack. . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Doodler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44

My Sounds . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45

My Pictures . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

10 Connecting to the Internet . . . . . . . . . . . 47

Using the Web Browser . . . . . . . . . . . . . . . . . . . 47

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

User Guide for Kyocera Phantom Phones vii

1GETTING STARTED

Your phone comes with a removable lithium ion (LiIon) battery.

using the phone.

Fully charge the battery before

Installing the battery

1. Hold the phone facing

away from you.

2. Use your fingernail to

pull the circular latch toward the bottom of the phone and pull the battery door away.

3. Place the battery in

the phone casing with the metal contacts toward the top of the phone.

4. Place the battery door notches in the openings

near the bottom of the phone.

5. Press the circular latch

until it clicks.

Charging the battery

You must have at least a partial charge in the battery to make or receive calls.

To charge the battery, connect the AC adapter to the jack on the lower right side of the phone, then plug the adapter into a wall outlet.

The battery icon in the upper-right corner of the screen tells you whether the phone is:

• Charging (the icon is animated)

• Partially charged

• fully charged

Recharging the battery: You can safely recharge the

battery at any time, even if it has a partial charge.

Caring for the battery

General safety guidelines

• Do not take apart, puncture, or short-circuit the battery.

• If you have not used the battery for more than a month, recharge it before using your phone.

• Avoid exposing the battery to extreme temperatures, direct sunlight, or high humidity.

• Never dispose of any battery in or near a fire. It could explode.

User Guide for Kyocera Phantom Phones 1

Common causes of battery drain

• Playing games

• Using the Web

• Keeping backlighting on

• Operating in analog ( ) mode. Your phone switches between modes to find the best signal. To set your phone to operate in a single mode,

Menu → Settings → Network →

select

Digital or Analog.

• Operating in digital mode when far away from a base station or cell site.

• Using data cables or accessories, such as the Hands-free headset.

• Operating when no service is available, or service is available intermittently.

• High earpiece and ringer volume settings.

• Repeating sound, vibration or lighted alerts.

Performing basic functions

Turn the phone on: Press and wait until the

hourglass icon appears.

Turn the phone off: Press and hold until the

phone beeps or the screen goes blank.

Make a call: Enter the number and press . End a call: Press (the red key). Answer a call: Press (the green key). Access voicemail: Press and hold and follow

the system prompts. Contact your service provider for details about their voicemail system.

Verify your phone number:

Select Menu → Phone Info. Press down to

scroll through information.

Silence the ringer: Press , then to answer. Lock the keypad: Press and hold left. Access a contacts list: Press down. Silence all sounds: Press and hold right. Access your shortcuts: Press up.

2 Getting Started

Getting to know your phone

Jack for Hands-free Headset (sold separately) only.

Home screen. Press (item 3) to select Menu.

OK key selects a menu item or option.

Send/Talk key starts or answers a call.

Navigation key scrolls through lists and positions cursor.

Also accesses shortcuts from the home screen.

Keypad for entering numbers, letters, or symbols.

* Text key changes the text mode in text entry.

Antenna (does not extend)

Clear key erases the last character in text entry, or

returns to the previous menu.

End/Power key turns the phone on or off, ends a call, or

returns you to the home screen.

Jack for AC adapter (included).

Space # key enters a space during text entry.

0 Next key cycles through word choices during text entry.

Warning: Inserting an accessory into the incorrect jack

will damage the phone.

User Guide for Kyocera Phantom Phones 3

Using menus

The contents of the main menu are as follows:

Recent Calls

Incoming Calls Outgoing Calls Missed Calls Erase Lists

Contacts

View All Add New Find Name Add Voice Dial Speed Dial List Voice Dial List Business List Personal List Information

Messages

Voicemail Send New* InBox Net Alerts* OutBox* Saved Msgs Group Lists* Erase Msgs Msg Settings

* Not available on all phones. Check with your service provider.

Settings

Silent Mode Keyguard Sounds Display Voice Services Security Call Information Network Convenience Msg Settings Accessories

Fun & Games*



Tetris Brick Attack

Doodler My Sounds My Pictures

Tools

Scheduler Alarm Clock Tip Calculator Calculator World Clock* Time r Stopwatch

Phone Info

Your Phone Number

ESN Icon Key

(Scroll down to view information.)

Web Browser

Connects to Internet

• From the home screen, press to

Menu.

select

• Press left, right, up, or down to see menus.** Press to select a menu or menu item.

• Press up or down to view menu items.

• Press to back up a menu level.

** To change the way the menus appear, select

Menu → Settings → Display → Main Menu View,

then select either Graphic or List and press .

In this guide, an arrow → tells you to select an

option from a menu. For example, means select

Menu, then select the Settings option.

Menu → Settings

• Press to return to the home screen.

4 Getting Started

Understanding screen icons

These icons may appear on your phone’s screen.

The phone is operating in IS2000 (1X) digital mode.

The phone is operating in IS95 digital mode.

The phone is operating in Analog (FM) mode. The phone is receiving a signal. You can make and receive calls. Fewer bars indicate a weaker signal.

A call is in progress.

The phone is not receiving a signal. You cannot make or receive calls. The phone is roaming outside of its home service area. You have a text message, voicemail, or page. ( indicates an urgent text message, voicemail, or page.) The battery is fully charged. The more black bars, the greater the charge.

The alarm clock is set.

The phone is in privacy mode or is accessing a secure Web site. High-speed (3G) data service is available and active on your phone. Check with your service provider for availability.

The phone is sending or receiving highspeed data. The phone is sending or receiving mediumspeed data. The phone is sending or receiving standard-speed data. High-speed data service is available, but the phone is dormant.

The phone is at the home screen. To access the menus, press .

Keyguard is on. The keypad is locked.

The phone is set to light up instead of ring.

The phone is set to vibrate or to vibrate and then ring. Position location is set to your service provider and to emergency services. Position location is set to emergency services only.

User Guide for Kyocera Phantom Phones 5

2MAKING AND ANSWERING CALLS

Making a call

1. Make sure you are in an area where the signal

can be received. Look for the symbol on the home screen.

Note: The more bars you see in this symbol, the

clearer the reception will be. If there are no bars, try to move to where the reception is better. If your phone cannot locate a signal for 15 minutes, it changes to Power Save mode. If you see the text “Power Save Mode” and on the screen, press any key to return to normal operating mode.

2. Enter the phone number.

3. Press .

4. Press to end the call.

Redialing a number

To redial the last number called, press twice. If you see a message prompting you to speak a name, press again.

Calling a saved number

If you have already saved a phone number, you can use the contacts list to find it quickly.

1. Press down. This brings up a list of all

saved contacts.

2. Scroll down the list, find the contact you want,

and press to dial the number.

6 Making and Answering Calls

For more about finding contact information, seepage18.

Tip: To call a saved number using your phone’s

voice recognition feature, see “Calling using voice tags” on page 37.

Answering a call

When a call comes in, the phone rings, vibrates, or lights up (depending on your settings), and a dancing phone icon appears. The phone number of the caller also appears if it is not a restricted number. If the number is stored in your Contacts directory, the contact name appears.

• To answer the call, press .

• If you do not wish to answer the call, select

Silence or Ignore and press . Silence mutes

the ringer. Ignore mutes the ringer and returns you to the screen that was active at the time the call came in. Both actions will send the caller to voicemail if you do not pick up the call.

Silencing an incoming call

• To silence an incoming call quickly, press . Then press to answer the call.

This action silences the current call only. The next call will ring as normal.

Adjusting the volume during a call

To adjust the earpiece volume during a call, press

up or down.

Calling emergency services

Note: Regardless of your 3-digit emergency code

(911, 111, 000, 999, etc.), your phone will operate as described below.

• Dial your 3-digit emergency code and press .

You can call the code even if your phone is locked or your account is restricted. When you call, your phone enters emergency service exclusive access to your phone to call you back, if necessary. To make or receive regular calls after dialing the code, you must exit this mode.

To exit Emergency mode

When you have completed the emergency call:

1. Press to select Exit.

2. Press again to confirm your choice.

Note: To determine who has access to your

location, see “Setting position location” on page 36.

Emergency mode. This enables the

Dealing with missed calls

When you have missed a call, “Missed Call” appears on your screen unless the caller leaves a voicemail.

• Press or to clear the screen.

• To view the caller’s number or name, select

Calls. In the Recent Calls list, the missed call is

indicated with a flashing .

• If the caller left a voicemail message, select

Call.

Setting missed call alerts

You can set an alert to beep every five minutes after you have missed a call.

• Select

• To turn off the alert when it rings, press

• To cancel the alert, select

Menu → Settings → Sounds →

Missed Call → Enabled.

or.

Menu → Settings →

Sounds → Missed Call → Disabled.

Viewing recent call details

Details on the last 29 calls you made or received are stored in the Recent Calls list. You can get details on the caller’s name and phone number, along with the time and length of the call. Icons indicate the types of calls in the list.

Outgoing call Forwarded call

Incoming call Three-way call

Missed call (flashing)

User Guide for Kyocera Phantom Phones 7

Viewing recent calls

1. Select Menu → Recent Calls.

2. Select a list: Incoming Calls, Outgoing Calls,

Missed Calls.

3. Select a recent call item.

4. Select an option: Time—Show the time of the call.

–

Number—Show the caller’s number (for an

–

incoming call), or the number you called (for an outgoing call).

–

Prepend—Place the cursor at the beginning

of the phone number so you can add an area code, if you plan to save the number as a contact.

–

Save New or View Contact—Save the phone

number as a contact or view a contact that has been saved.

–

Add to—Add the phone number to a

saved contact.

View Contact—Show details on the contact

–

if the caller’s information is already in your Contacts directory.

Note: If the phone number has been classified as

“secret,” you must enter your four-digit lock code to view or edit it. For information on the lock code, see “Changing your lock code” on page 33. To classify a phone number as secret, see “Saving a contact entry” on page 16.

Erasing recent calls

1. Select Menu → Recent Calls → Erase Lists.

2. Select an option: Incoming Calls, Outgoing Calls, Missed Calls, or Erase All.

3. Press right and press to select Yes.

Speed dialing

Speed dialing allows you to quickly dial a stored phone number by entering a one- or two-digit speed dialing location number and pressing .

Note: Before you can use speed dialing, you must

save a phone number as a contact and assign a speed dial location to it.

• To save a phone number as a new contact and add a speed dial location, see “Saving a contact entry” on page 16.

• To add a speed dial location to a saved contact, see “Editing or erasing a contact” on page 17.

Using speed dialing

To call a contact that has a speed dial location:

• From the home screen, enter a one- or twodigit speed dialing location and press .

8 Making and Answering Calls

1-Touch Dialing

1-Touch Dialing is the fastest way to speed dial a contact that has a speed dial location.

Note: You must (1) enable 1-Touch dialing on your

phone and (2) have a speed dial location assigned to a contact. To assign a speed dial location to a contact see “Saving a contact entry” on page 16 or “Editing or erasing a contact” on page 17.

Enabling 1-Touch dialing

1. Select Menu → Settings → Convenience → 1-Touch Dialing → Enabled.

2. Press .

Using 1-Touch Dialing

To call a contact that has a speed dial location:

• From the home screen, press and hold a speed dialing location. If it is a two-digit location, press the first digit briefly, then press and hold the second digit. For example, if the speed dialing location is 15, press briefly, then press and hold .

Setting up voicemail

Before your phone can receive voicemail messages, you must set up a password and record a personal greeting with your service provider. When you have set up your voicemail, all unanswered calls to your phone are automatically transferred to voicemail, even if your phone is in use or turned off.

Note: Contact your service provider to set up your

password and personal greeting.

Checking voicemail messages

When a voice message is received, your screen will display a message: “New Message [x] Voicemail.” This text will remain for about five minutes. After that, look for the symbol at the top of your screen. The symbol flashes if the message is urgent.

If you see “New Message” on your screen

1. Press to select Call. This initiates a call to

your voicemail number.

2. Follow the prompts to retrieve the message.

For specific information on getting voicemail messages, contact your service provider.

If you see the symbol

1. Press to initiate a call to your voicemail

number.

2. Follow the prompts to retrieve the message.

Note: You can set the phone to beep, light up, or play

a tune every five minutes to remind you that you have voicemail. See “Setting message alerts” on page 34 and “Setting backlighting to flash” on page 32.

User Guide for Kyocera Phantom Phones 9

Silencing an incoming call

• To silence an incoming call quickly, press . Then press to answer the call.

This action silences the current call only. The next call will ring as normal.

Adjusting the volume during a call

• To adjust the earpiece volume during a call, press up or down.

Locking the keypad

The Keyguard locks your keypad to prevent accidental key presses when the phone is turned on and a call is not in progress. You can still answer or silence an incoming call.

• To lock the keypad from the home screen, press left and hold.

• To unlock the keypad, press in this order.

Changing the keyguard setting

1. Select Menu → Settings → Keyguard.

2. Highlight an option. You can set the phone to

lock the keypad immediately, or automatically if no key is pressed after 30 seconds, 1 minute, or 5 minutes.

3. Press to save.

Tracking calls

You can track the number and duration of calls made and received on your phone.

1. Select Menu → Settings → Call Information.

2. Select a timer: Recent Calls—Tracks all calls you have made

–

and received since you last reset this timer.

All Calls Timer—Tracks all calls you have

–

made and received. This timer cannot be reset.

3. To reset a timer, highlight Reset and press .

Timing your calls

You can set your phone to beep 10 seconds before each minute passes when you are on a call.

Menu → Settings → Sounds →

• Select

Minute Alert → Enabled.

Receiving data or faxes

Your phone may be able to receive certain data or faxes, depending on the system sending the information. You cannot receive voice calls while the phone is in data/fax mode. For more information, see “Data settings” on page 35.

10 Making and Answering Calls

Setting roaming alerts and ringers

Setting an alert for roaming

You can set your phone to alert you with beeps when you roam outside of your home service area.

1. Select Menu → Settings → Network →

Roam/Svc Alert.

2. Select an option and press . When no svc alerts you with three tones

–

decreasing in pitch when service is lost and three tones increasing in pitch when service is acquired again.

–

Roam Change alerts you with two

decreasing tones when roaming service is acquired and three increasing tones when home area service is acquired again.

–

Any Change alerts you with three

increasing tones if there is a change in roaming service or three decreasing tones if the phone loses service.

Setting the roam ringer

You can set a ringer to indicate when an incoming call will be subject to roaming charges.

1. Select Menu → Settings → Sounds →

Roam Ringer.

2. Highlight Enabled and press . You’ll hear a

sample of the ringer.

3. Press to set the ringer.

Setting Call Guard to avoid roaming calls

You can set your phone to warn you before you answer or place a call while roaming.

• Select

Menu → Settings → Convenience →

Call Guard → Call prompt.

The phone makes a distinctive ring to indicate an incoming call while you are roaming, and you must press to accept the call or to place a call while roaming.

Controlling network roaming

Specifying digital or analog mode

You may force the phone into either digital or analog mode. This is useful if you are in an area that borders on digital service and the automatic feature is causing the phone to keep switching between modes.

1. Select Menu → Settings → Network →

Digital/Analog.

2. Select an option and press .

–

Automatic automatically switches the phone

between digital and analog.

Analog only sets the phone to work in

–

analog mode only.

Analog call forces a call into analog mode

–

for the duration of the next call.

–

Digital only sets the phone to work in digital

mode only.

User Guide for Kyocera Phantom Phones 11

Turning roaming on or off

This setting allows you to control the phone’s roaming feature by specifying which signals the phone will accept.

1. Select Menu → Settings → Network →

Roam Option.

2. Select an option and press . Automatic (recommended setting) accepts

–

any system the phone service provides.

–

No Roaming prevents you from making

or receiving calls outside of your home service area.

Note: If your phone has more than one setting for

Automatic, contact your service provider to determine which one to use.

12 Making and Answering Calls

3ENTERING LETTERS, NUMBERS, AND SYMBOLS

You can enter letters, numbers, and symbols in contacts, text messages, and your banner.

Understanding text entry screens

The current text entry mode (and capitalization setting, when applicable) are indicated by icons.

text entry field

capitalization setting text entry mode

Text entry modes

There are four text entry modes:

Number mode Normal text mode Rapid text entry mode Symbol mode

Note: The mode you start in depends on the task

you are doing. For example, when entering a phone number, you’re in number mode. When entering a name for a contact, you’re in normal text mode.

Entering numbers

• To enter a number while in mode, press a number key once.

• To enter a number while in or mode, press and hold a number key until the number appears on the screen.

Entering words letter by letter

Use normal text mode to enter letters.

1. Press a key once for the first letter, twice for the

second letter, and so on. If your phone is set to Spanish, French, or Portuguese, accented letters are available.

2. Wait for the cursor to move right and enter the

next letter.

Entering words quickly

When you press a series of keys using mode,

checks its dictionary of common words and

guesses at the word you are trying to spell.

1. For each letter of the word you want, press the

key once. For example, to enter the word “any”

press: → → .

2. If the word doesn’t match what you want, press

to look at other word matches.

3. When you see the word you want, press .

User Guide for Kyocera Phantom Phones 13

Entering symbols

While entering text, you can enter symbols by pressing until you see the symbol you want. Using this method, you have access to the following symbols:

.@?!–,&:’

To access the full set of symbols:

1. Press right to highlight the current mode

and press to enter the menu.

2. Select Symbols.

3. Press down to view the list of symbols.

4. Press the number key corresponding to the

symbol you want.

Changing modes

Sometimes you need to change modes. For example, to enter numbers in an email address while in mode, you must change to

mode, enter the numbers, and then change

back to mode to complete the address.

To change text entry modes, you can either:

• Press and hold until icon for the mode you want appears.

-or-

• Press right to highlight the current text mode, press to enter the menu, then select a different mode.

Capitalization settings

Three capitalization settings are available in and modes:

Capitalize next letter

Lower case next letter Capitalize first letter of every word (in a

contact) or sentence (in a text message)

If no icon appears, all letters will be in lower case.

To change capitalization settings:

• Press until the icon for the setting you want appears.

14 Entering Letters, Numbers, and Symbols

Quick reference to text entry

This table gives general instructions for entering letters, numbers, and symbols.

To... Do this...

Enter a letter

Enter a number

Enter a symbol

Enter a space

Erase a character

Erase all characters

Move the cursor right or left

Change text entry modes

Capitalize the next letter

Lower case the next letter

Capitalize the first letter of each word

Highlight an option at the bottom of the screen

Use mode and press a key until you see the letter you want. For more information, see page 13.

Use mode and press a key once to enter its number. For more options, see page 13.

Use mode and press until you find the symbol you want. See page 14.

Press .

Press and hold .

Press up or down.

Press and hold .

In mode, press . Choose .

Press left or right.

User Guide for Kyocera Phantom Phones 15

4STORING CONTACTS

Use your phone’s Contacts directory to store information about a person or company. Your phone can hold, on average, about 200 phone numbers.

Saving a contact entry

To save a contact, take these steps.

1. From the home screen, enter the phone

number you want to save.

Tip: Enter the area code with the phone number

so that you can dial it from any service area.

Note: To save a contact without entering a

phone number, select

New, select an option, and skip to step 3.

2. Press to select Save New.

3. Enter a name for the contact. If you need to

learn how to enter letters, see page 13. Either save the contact now or assign options.

To save now, press to select

-orTo assign options, press right twice, then press to select down to highlight an option:

Assign Ringer or Unassign Ringer—Select

–

or remove a ringer to identify an incoming call from this contact.

Menu → Contacts → Add

Save.

Options. Press up or

–

Assign Picture or Unassign Picture—Select

or remove a picture to identify an incoming call from this contact.

–

Save—Save the information. Number Type—Select work, home, mobile,

–

pager, or fax. The number type will appear

as an icon next to the number in the Contacts list.

–

Add Voice Dial—Speak the name of the

contact person for this number so that you can dial it using voice recognition (VR). For more information, see page 37.

–

Speed Dialing—Select a speed dialing

location from the list.

Secret—Select Yes to lock the phone

–

number. If a phone number is locked, you must enter your four-digit lock code (see page 33) to view or edit the number.

–

Primary Number—Classify this number as

the primary number for the contact.

Classify Contact—Classify the contact as

–

Personal or Business. (See page 29 to set

the phone to ring differently for personal and business calls.)

4. Press to select Save. A check mark and the

word “Saved” appear.

16 Storing Contacts

–

Adding a code or extension

When you save the phone number of an automated service, you may include a pause where your phone would stop dialing; for example, where you would wait to dial an extension.

1. Enter the first portion of the phone number.

2. Press right to scroll through the options at

the bottom of the screen.

3. Press to select a type of pause.

Time Pause—Stops dialing for two

–

seconds, then continues to dial.

Hard Pause—Stops dialing until you

–

select

Release.

4. Enter the remaining numbers.

5. Select Save New.

Assign Picture or Unassign Picture to select

or remove a picture to identify an incoming call from this contact.

–

Erase Contact to erase the entire contact. Edit Name of the contact.

–

Classify Contact as personal or business.

–

6. Enter the new information.

7. Press to select Save.

Editing a phone number

1. Select Menu → Contacts.

2. Select View All or Find Name to find the contact

you want to edit.

3. Highlight the contact to edit and press .

4. Press down to highlight the phone number

you want to edit and press .

Editing or erasing a contact

To make changes to a contact, take these steps. (To erase all saved contacts, see page 34.)

1. Select Menu → Contacts.

2. Select View All or Find Name to find the contact

you want to edit.

3. Highlight the contact to edit and press .

4. Select Options.

5. Highlight an option and press to select it: Add New to add a number, address, or note.

– –

Assign Ringer or Unassign Ringer to select

or remove a ringer to identify an incoming

5. Highlight an option for the phone number and

press : –

Send Text Msg—Send a text message to the

phone number you selected.

View Number—See the phone number you

–

selected.

Add Voice Dial—Speak the name of the

–

contact person for this number so that you can dial it using voice recognition (VR). For more information, see page 37.

–

Speed Dialing—Assign or remove the

location you use to speed dial the number.

call from this contact.

User Guide for Kyocera Phantom Phones 17

– Edit Type—Assign a type: work, home,

mobile, pager, or fax. The type icon appears

next to the phone number in the Contacts list.

–

Erase Number—Erase the number from

the contact.

Erase Voice Dial—Erase the voice dial

–

name associated with the number.

Edit Number—Change the phone number.

– –

Edit Voice Dial—Record a new voice

dial name.

Secret—Make the number secret so that it

–

will not appear on the screen until the lock code is entered. Secret numbers can be called without a lock code. (For more information, see “Restricting calls” on page 34.)

–

Primary Number—Make this number the first

one that shows up when you open the contact.

Prepend—Move the cursor to the

–

beginning of the number so you can add the area code.

–

Exit—Exit without making changes.

6. Enter the new information and follow the prompts.

7. Press to select Save, if necessary.

Finding contact information

To find a phone number or contact, either (1) check the frequent contacts list, (2) search the Contacts directory, or (3) use Fast Find.

Checking the Frequent List or the All Contacts list

From the home screen, press down to see the last 15 of your most frequently called contacts (if you have enabled the Frequent List setting). You also see the All Contacts list if you scroll down past the double line.

To enable the Frequent List setting

• Select Menu → Settings → Convenience →

Frequent List → Enabled.

Searching the Contacts directory

1. Select Menu → Contacts.

2. Select a search method: View All—List all saved contacts.

–

Add New—Add new contacts.

– –

Find Name—Locate a specific name. Enter

part of the contact name, then select

Add Voice Dial—Speak the name of the

–

contact person for this number so that you can dial it using voice recognition (VR).

–

Speed Dial List, Voice Dial List, Business List, or Personal List—Select a contact

from a list.

3. Scroll down until you find the name you want,

then press

– To call the contact, highlight the number

and press .

– To display contact information, press .

Find.

18 Storing Contacts

Setting Fast Find

With Fast Find, you press one or two keys to view close matches of the number you are looking for.

• From the home screen, select

Menu → Settings → Convenience →

Fast Find → Enabled.

Using Fast Find

1. From the home screen, press the keys

corresponding to the letters of the name you want to find. A matching contact or speed dial entry appears. Press down to scroll through matching entries.

2. View the name you want, then press to call

the number or press to view contact details.

Viewing contacts

The following icons may appear next to information in your Contact entries.

work email address

home street address

mobile Web page URL

pager Note

fax

User Guide for Kyocera Phantom Phones 19

5SENDING AND RECEIVING TEXT MESSAGES

This chapter describes how to send, receive, and erase text messages from your phone. For information on voicemail messages, see page 9.

Important: The features and menus described in

this chapter may vary depending on services available in your area. In addition, usage charges may apply to each message. For details, check with your service provider.

Sending text messages

You can only send text messages to phones that are capable of receiving them, or to email addresses.

Writing a message

To send a text message to a single recipient:

1. Select Menu → Messages → Send New.

2. Choose a method to enter the recipient’s phone

number or email address: – Select a saved number from the

Contacts List, or select a Group List you

have created. For more about group lists, seepage25.

– Enter a

New Address manually.

(To learn how to enter text, see page 13.)

3. To add another recipient to this message,

choose a method: – Press right to select

select

Recent List, Contacts, or Group Lists.

Recent List

Options. Then

– Enter a space or comma after the first number.

Then enter another recipient manually.

Note: You can send a message to up to 10

contacts at once. The messages will be sent one at a time, once to each addressee.

4. When you are done entering addresses, press

right to highlight

5. Enter the message. To learn how to enter text,

Next and press .

see page 13. To add special features such as smiley faces, see “Including pictures, sounds, and prewritten text” on page 20.

Note: Depending on your service provider, you

may be charged for more than one message if your message exceeds a certain number of characters. For more information, see “Understanding appended messages” on page 22.

6. When you have completed the message, press

to select

Send.

Including pictures, sounds, and prewritten text

Depending on the services available from your carrier, you may include smiley faces, graphics, and sound in your text messages.

1. Create a text message and enter the addresses.

2. Select Next to advance to the message text

entry screen.

20 Sending and Receiving Text Messages

3. From the text entry screen, press right

twice, select

Options → Insert and select from

the options: –

My Sounds—Add a sound or melody.

Highlight one from the list and press to select

Insert.

My Pictures—Add a graphic you have

–

received in a text message, created using Doodler, or downloaded to your phone. Press right or left to scroll through graphics and press to select

Smileys—Select a smiley face icon. If the

–

Insert.

recipient’s phone does not support the same technology as your phone, the icons will appear to them in a more simplistic form.

Tip: Press and hold to cycle through

smileys while in the text entry screen. Highlight one and press to select

QuickText—Select a prewritten message.

–

Insert.

Highlight one from the list and press to select

Insert. (To edit or create new

prewritten messages, see page 26.)

–

Contacts—Add information about a saved

contact. Highlight the contact from the list and press to insert it.

4. When you have completed the message, you can

send it immediately or set sending options. To send it immediately, press to select

Send. To

set sending options, see the following procedure.

Setting sending options

When you are ready to send a message, you have several options for how and when you want the message to be received.

1. Once you have completed the message, press

right to highlight

Then choose from the list: –

Insert—Enhance your message with sounds,

graphics, smiley faces, prewritten text, or contact information (if available from your service provider). See options on page 20.

–

Add Address—Return to the “To” screen

to add another recipient without losing the message text. Enter the new address, then select entry screen.

Msg Receipt—Alerts you when the

–

recipient has received your message. (Service may not be available to you. Check with your service provider.)

–

Set Priority—Label the message as “Urgent.”

–

Callback Number—Include a callback

number with the message to let the recipient know at what number they can call you back. Select

Yes to include your own number, or

Edit to enter a different callback number. Send Later—Schedule when to send

–

the message.

Options and press .

Next to return to the message

User Guide for Kyocera Phantom Phones 21

– Save Message—Save the message in

your

Saved folder. This prevents the

message from being deleted if you have activated AutoErase, and enables you to send the message to others.

–

Save QuickText—Save the message you

have just entered as a prewritten message, then return to the message entry screen so you can send the message.

2. When you have finished setting options, press

to return to the message window.

3. Highlight Send and press .

Adding a signature

This setting allows you to create signature text. The signature does not display in the message creation screen; however, the signature is included at the end of all outgoing messages.

To create a signature

1. Select Menu → Settings → Msg Settings →

Signature.

2. Enter your signature in the text field.

3. Press to select OK and save the setting. Note: The signature text is tallied by the

character counter because the signature is included in the text field.

If you cannot send messages

You may not be able to send or receive messages if your phone’s memory is nearly full, or if digital service is not available at the time. To free up memory, erase old messages. See “Erasing messages” on page 25.

Understanding appended messages

Characters remaining

Text entry field

If you go over the character limit for a single message, the phone may automatically append an empty segment to your message to make space.

Important: Your service provider will charge you

for each message segment.

When you start a message, the maximum character limit (“200” in the example) appears above the text entry screen. This number counts down as you enter characters, until it reaches 0. If you continue to enter text after this counter reaches 0, a message segment may be appended. If a segment is appended, a message will appear on the phone screen.

22 Sending and Receiving Text Messages

Receiving incoming calls while creating messages

• If you don’t wish to answer the call, select

Ignore.

• To answer the call, press . The message you were working on will be saved in the Saved folder. To return to the message, select

Menu → Messages → Saved and select it.

Viewing the OutBox

You can check the status of messages you have sent as long as they have been saved to the OutBox.

Note: If messages you have sent were not saved to

the OutBox, select

Settings → Save to Outbox.

To view the OutBox:

1. Select Menu → Messages → OutBox.

2. Press up or down through the list of

messages. One of the following symbols appears next to each message:

Menu → Messages → Msg

The message is pending and will be sent when possible. You can cancel delivery of the message.

The scheduled message will be sent at the scheduled time. You cannot cancel delivery of the message.

The message cannot be sent because service is not available. An alert appears on your phone if the message cannot be sent.

The scheduled message has been sent and will be delivered as scheduled. You cannot cancel delivery of the message.

The message has been received by the recipient you specified.

The message has been received and opened by the recipient you specified. (This symbol may not be available. Check with your service provider.)

The message has been sent to more than one recipient.

The message has never been sent, or has not been sent since it was last modified. You can cancel delivery of the message.

Retrieving text messages

When a text message is received, your screen will display text similar to: “New message 1 Text Msg”. This text will remain for approximately five minutes. After that, look for the symbol at the top of your screen. The symbol flashes if the message is urgent.

User Guide for Kyocera Phantom Phones 23

If you see the “New Message” note

You can choose to:

•

View the message—Press . Ignore the message—Press right and

• press .

• Clear the screen

Note: If you receive a new message while you are

—Press .

reading a message, the one you are reading will be replaced by the new one. You can find the older message in the InBox: Select

Messages → InBox.

Menu →

If you see the symbol

If the symbol is flashing, the message is urgent.

1. Select Menu → Messages → InBox.

A list of all your received messages appears. New, unread messages appear in

bold.

indicates an “Urgent” message.

2. Press up or down to scroll through the list

of messages.

3. Press to read a message.

Reading the message

The options available to you may vary. Check with your service provider.

Note: Sounds embedded in text messages will not

play if the phone is set to Silence All mode.

1. If the text message is long, press down to

view the entire message.

2. When you are finished, you can Reply to the

sender,

Play the sound embedded in the

message,

Erase the message, Save the message

to your Saved folder, or set additional

Options

for the message: –View

Sender information.

Forward the message.

–

Reply with Copy to reply to the message

–

with a copy of the original attached.

–

Save Object(s), such as sound or pictures,

from the message. (This option is available if the incoming message includes a graphic or sound.)

–

Save Contact to save the sender’s phone

number or email address in your Contacts list. (This option is available if a vCard is included in the message.)

–

Save as QuickText to save the text from the

message as QuickText, which you can insert into other messages. Graphics and sound will not be saved as part of QuickText.(For more about QuickText, see page 26.)

3. Select Done. Note: The symbol indicates:

• A graphic did not come through. It may be too large or incorrectly formatted.

• An appended message is missing. (For more about appended messages, see page 22.)

24 Sending and Receiving Text Messages

Setting message alerts

You can set your phone to alert you of incoming text messages or pages. For more information, see “Setting message alerts” on page 34.

Erasing messages

It is a good idea to erase old messages, as messages take up memory in your phone.

You have the option of erasing text messages and pages as you send or read them, erasing them oneat-a-time from the list in the OutBox or InBox, or erasing them all at once.

Erasing all messages

1. Select Menu → Messages → Erase Msgs.

2. Press up or down and press to select

an option: –

InBox erases all messages in your InBox. OutBox erases all messages in your OutBox.

–

Saved Folder erases all messages in your

–

Saved folder.

–

All Messages erases all text messages in all

folders listed above.

3. A message appears: “Erase all messages?”

Select

Yes to erase messages or No to cancel.

Erasing single messages

1. Select Menu → Messages.

2. Press down and press to select the

type of text message you want to erase (

OutBox, or Saved).

3. Press to select the message to erase.

4. Select Erase to erase the message. A notification

InBox,

appears: “Erase this message?”

5. Select Yes to erase the message.

Note: You can erase a scheduled message from

the OutBox, but you cannot cancel delivery of the message.

User Guide for Kyocera Phantom Phones 25

Erasing messages automatically

Use this setting to have old messages automatically erased from the InBox when memory is low.

1. Select Menu → Messages → Msg Settings →

Auto-Erase.

2. Press to select Old InBox Msgs.

Customizing message settings

To make messaging easier, you can customize settings for sending and receiving messages.

Creating group lists

You can create and save a list of multiple recipients. Your Phantom phone will store five group lists with up to 10 recipients per list.

1. Select Menu → Messages → Group Lists →

Create New.

2. Enter a name for the list. For help entering text,

see page 13.

3. Press to select Next.

4. To enter the first phone number or email

address, select an option:

Recent List—Select numbers from your

–

Recent List.

–

New Address—Enter the phone number or

email address yourself. To learn how to enter text, see page 13.

–

Contacts List—Select contacts from your

phone book.

5. To enter the next address, enter a space or

comma after the first number or email address. (If you insert a saved contact or a number from the Recent List, the phone will insert the comma automatically.) Then press right twice, select

Options, and choose from the options.

6. When finished, press right and press

to select

Done.

7. To send a message to your new group, see

“Sending text messages” on page 20.

Creating and editing prewritten messages (QuickText)

Your phone comes with prewritten (QuickText) messages, such as “Please call me,” which you can insert into the body of a text message. You can edit these messages and create new ones. Your phone

will store up to 20 QuickText messages, with up to 100 characters per message.

1. Select Menu → Messages → Msg Settings →

Edit QuickText.

2. To create a new pre-written message, highlight New QuickText and press .

-orTo edit an existing pre-written message,

highlight the message and press .

3. Enter or edit the text and press to select Done. For help entering text, see page 13.

Note: You can also save an incoming message

as QuickText. For directions, see page 24.

Switching default text entry mode

You can set the default text entry mode to appear in message text entry screens.

1. Select Menu → Messages → Msg Settings →

Default Text.

2. Select Normal Alpha or Rapid Mode.

For more information on text entry modes, seepage13.

26 Sending and Receiving Text Messages

6CUSTOMIZING YOUR PHONE

The contents of the Settings menu are as follows.

Silent Mode Keyguard Sounds

Ringer Volume Ringer Type Business Ring Personal Ring Roam Ringer Earpiece Volume Key Volume Key Length Missed Call Smart Sound Minute Alert

Display

Backlighting My Banner Flashing Lights Main Menu View Screen Saver*

* Available on grayscale phones only ** Available on color phones only *** Not available on all phones. Check with your service provider.

Display (continued)

Wallpaper** Color Themes** Auto-Hyphen Language Time Format Contrast

Voice Services

Add Voice Dial Erase Voice Dial Voice Training Voice Wake-Up Voice Answer

Security

Lock Phone Limit Calls Lock Code Erase Contacts Emergency #’s

Call Information

Recent Calls All Calls Timer Data Timer

Network

Data/Fax Calls Privacy Alert Voice Privacy Data Setup User Name Set Phone Line Roam/Svc Alert*** Roam Option*** Digital/Analog*** Location***

Convenience

Shortcut Key Fast Find

Convenience (continued)

Frequent List 1-Touch Dialing Web Prompt Call Guard

Msg Settings

Voicemail Num. Alerts Signature Edit QuickText Callback Number Msg Receipt Save to Outbox Auto-Erase Default Text

Accessories

Pwr Backlight Headset Ring Auto-Answer TTY Device*** Com Speed***

User Guide for Kyocera Phantom Phones 27

Silencing all sounds

Your phone is set to make sounds when you receive calls, press keys, navigate through menus, and receive alerts (such as new messages).

You can silence all sounds and set the phone to vibrate

or light up when you receive calls and alerts.

Setting the phone to vibrate or light up

1. Select Menu → Settings → Silent Mode.

2. Choose an option and press : Vibrate Only—Causes the phone to vibrate

–

for the duration of the incoming call or other alert. appears.

–

Vibrate, Ring—Causes the phone to vibrate

for the first 10 seconds and then ring for the remainder of the incoming call alert.

appears.

–

Lights Only—Causes the phone to light up

for the duration of the incoming call or other alert. appears.

3. Press to return to the home screen.

Note: The phone will ring when it is attached to an

external power source (such as a charger), even if all sounds have been silenced.

Shortcut to Vibrate Only mode

• From the home screen, press right and hold. appears.

Turning sounds back on

To restore all sounds to the phone:

• From the home screen, press right and hold.

-or-

• Select

Menu → Settings → Silent Mode →

Norm. Sounds.

The or disappears. The phone will now ring for incoming calls and alerts.

Choosing a different ringer

Your Kyocera Phantom phone has 15 ringers you can from choose to use for incoming calls.

1. Select Menu → Settings → Sounds →

Ringer Type.

2. Scroll down the list to hear the different rings.

3. Press to select a ringer from the list.

28 Customizing Your Phone

Specifying ringers for different callers

You can assign ringers that identify calls from different phone numbers saved in your Contacts directory.

• To assign a ringer to an individual contact, see page 16.

• To assign a ringer to a class of contacts:

1. Select Menu → Settings → Sounds.

2. Ηighlight Business Ring or Personal Ring and

press

3. Select a ringer and press . Note: To classify a contact as Business or

Personal, see page 16.

Importing additional ringers

You can download additional ringers into your Kyocera Phantom phone using the Kyocera Phone Desktop software (sold separately). To purchase this software and other accessories, visit

www.kyocera-wireless.com/store.

You may be able to download ringers over-the-air. Check with your service provider for availability.

Adjusting volume

You can adjust the volume of the earpiece, the ringer, or the beeps you hear when the keys are pressed.

Adjusting the earpiece volume

To adjust the earpiece volume manually during a call, press up or down to find a comfortable level.

Adjusting the ringer volume

1. Select Menu → Settings → Sounds →

Ringer Volume.

2. Press right to increase the volume, or left to

decrease the volume.

Changing the key tones

You can change the volume and duration of the tones the phone makes when you press the keys. Select

Menu → Settings → Sounds and choose

Key Volume or Key Length.

Using shortcuts

From the home screen, you can access shortcuts by pressing the navigation key in different directions. Three shortcuts are automatically programmed into your phone:

Press left Left locks the keypad.

Press right

Press down

Press up

Right silences sounds and sets phone to vibrate.

Down lists the phone’s Contacts directory.

You can set a shortcut to one of the features of your phone.

User Guide for Kyocera Phantom Phones 29

Defining the feature shortcut (up)

1. Select Menu → Settings → Convenience →

Shortcut Key.

2. Highlight the feature you want a shortcut to, and

press to select it.

Using the feature shortcut

• From the home screen, press and hold up.

Choosing a different language

Your phone may display alternative languages.

1. Select Menu → Settings → Display →

Language.

2. Select a language, and press .

Personalizing the screen

Changing your banner

The banner is the personal label for your phone. It appears on the home screen above the time and date. The banner can be up to 14 characters long.

1. Select Menu → Settings → Display →

My Banner.

2. Select Edit.

3. Press to clear the screen.

4. Enter your new text.

5. Press to save.

Choosing a different menu view

You can change the appearance of the menus you see when you select

1. Select Menu → Settings → Display →

Main Menu View, then the option you want:

2. Press to return to the home screen. The

Menu from the home screen.

Graphic List

next time you press , you will see the menu view you selected.

Adjusting the backlighting

Your screen lights up while you are in a call or when you press a key on the keypad. However, you can change when and how backlighting lights up.

1. Select Menu → Settings → Display →

Backlighting.

2. Select an option from the list: 5 seconds, 10 seconds, 30 seconds, or 1

–

Minute —(Default) Turn backlighting on

for 5, 10, 30 seconds or 1 minute after your last keypress.

30 Customizing Your Phone

– 5 sec/in call , 10 sec/in call, 30 sec/in call, or

1 Min/in call—Turn backlighting on for the

duration of a call, and for 5, 10, 30 seconds or 1 minute after your last keypress. (

Note: These four settings drain the

battery more quickly and reduce talk and standby times.)

Setting power backlighting

You can set backlighting to remain on when an external power source, such as the AC adapter, is used with the phone.

Note: Power backlighting may not be available with

some accessories. Check with your service provider.

1. Select Menu → Settings → Accessories →

Pwr Backlight.

2. Select Always On to keep backlighting on.

(The battery charges more slowly when power backlighting is on.)

Setting backlighting to flash

You can set the backlighting on your phone to flash in a certain style when an incoming call is received. When this setting is activated, the lights will flash even if you silence the ringer.

1. Select Menu → Settings → Display →

Flashing Lights.

2. Select from Fast Flash, Slow Flash, or Heartbeat, or Rhythm. As you highlight the

options a sample of each flash is provided.

3. Press to select your option.

Caution: A small percentage of users may be photo

sensitive to flashing lights. In rare cases, exposure to flashing lights, under certain circumstances, may produce seizures. While such an event is not known to occur with mobile phone use, and the Phantom phone has been designed to minimize the possibility of any such occurrence, those who believe they may be photo sensitive should not enable the Flashing Lights feature.

Changing the display contrast

1. Select Menu → Settings → Display →

Contrast.

2. Select the level of contrast you want.

Setting numbers to auto-hyphenate

Auto-hyphenation is a setting that automatically inserts hyphens into your phone numbers to be consistent with the U.S. dialing plan. For example, 1-222-333-4444.

• Select

Menu → Settings → Display →

Auto-Hyphen → Enabled.

User Guide for Kyocera Phantom Phones 31

Selecting a screen saver

Note: Screen savers are not available on all

Phantom phones. They are included only on phones with a grayscale screen display and in some phones with a color screen display which also include an application such as BREW, Axcess Apps, or Download Shop. For availability, contact your service provider.

Screen savers work only from the home screen, and they are activated 10 seconds after the last keypress. Incoming calls and alerts override screen savers.

1. Select Menu → Settings → Display →

Screen Saver.

2. Highlight a screen saver and press .

3. Press to return to the home screen and wait

10 seconds to view the screen saver you chose.

Note: You can add graphics you have created or

saved to the Screen Savers list. Refer to “My Pictures” on page 46.

Selecting wallpaper

Wallpaper appears on the home screen, when the phone is not in use. This feature is available only on Phantom phones with a color screen display.

1. Select Menu → Settings → Display →

Wallpaper.

2. Highlight a wallpaper design and press .

3. Press to return to the home screen and

view the wallpaper you chose.

Selecting a color theme

You can select a color theme to display on your phone. This feature is available only on phones with a color screen display.

1. Select Menu → Settings → Display →

Color Themes.

2. Highlight a color theme from the list and

press .

3. Press to return to the home screen.

Choosing a different time/date format

1. Select Menu → Settings → Display →

Time Format.

2. Highlight the option you want.

Creating a secure environment

This section describes all the features involved in securing your phone and preventing access to personal information. All security features are shielded by a four-digit lock code.

32 Customizing Your Phone

Changing your lock code

The lock code is typically 0000 or the last 4 digits of your phone number.

1. Select Menu → Settings → Security.

2. Enter your four-digit lock code and select Lock Code. A message appears: “Change Code?”

3. Select Yes and enter a new four-digit code.

Enter your new lock code again.

Locking your phone

When your phone is locked, you can call only emergency numbers or your service provider number. You can still receive incoming calls.

1. Select Menu → Settings → Security.

2. Enter your four-digit lock code.

3. Select Lock Phone.

4. Highlight an option:

Never—Does not lock the phone.

–

On power up—Locks the phone every time

–

you turn it on.

–

Now—Locks the phone immediately.

5. Press .

Unlocking the phone

1. From the home screen, press to

select

Unlock.

2. Enter your four-digit lock code.

Designating emergency numbers

The emergency numbers feature allows you to specify three personal phone numbers that can be called when the phone is locked.

1. Select Menu → Settings → Security.

2. Enter your four-digit lock code.

3. Select Emergency #’s.

4. Select an Unassigned slot. Note: Enter the phone number, including the

area code. Do not enter 1 before the area code.

5. Press to select Done.

Notes:

• You can view these numbers only when they’re being entered for the first time.

• You cannot edit these numbers.

• To make a call to an emergency number from a locked phone, you must dial the number (including area code) exactly as it was stored in Emergency Numbers.

Restricting calls

You can restrict the calls that can be made from your phone to only those that have been saved in your Contacts Directory.

1. Select Menu → Settings → Security.

2. Enter your four-digit lock code.

3. Select Limit Calls.

4. Select Contacts Only.

User Guide for Kyocera Phantom Phones 33

Erasing all contacts

You can erase all contacts from the Contacts directory.

1. Select Menu → Settings → Security.

2. Enter your four-digit lock code.

3. Select Erase Contacts.

4. Select Yes to erase all contacts. A message

appears: “Erase ALL contacts?”

5. Select Yes to erase all contacts.

Setting message alerts

You can choose how you want be alerted of incoming voicemail, pages, or text messages.

1. Select Menu → Settings → Msg Settings → Alerts.

2. Select the type of alert: Message Alert, Net Alert, Page Alert, or Voicemail Alert.

3. Press to select an option:

– Vibrate, Beep, Hiya!, Rock!, or Happy—Set

the phone to vibrate, beep, or play a tune once when a new message is received.

– Options with

you once when a new message is received and then notify you again every five minutes. a reminder alert, press to select

–

Disabled—Turn off message alerts.

remind—Set the phone to notify

To stop

Ignore.

Setting alerts for your headset

When a headset (sold separately) is attached to the phone, you can set alert sounds to originate from the headset.

1. Select Menu → Settings → Accessories →

Headset Ring.

2. Select Out headset to have alerts originate from

the headset.

Network settings

Switching between phone lines

Your phone can have two service accounts, or phone lines, associated with it. Each phone line has its own phone number. When you are using one line, you cannot receive calls from the other. It would be as if the phone were “off” for that number. Your voicemail, however, will still take messages. All contacts and settings are shared for both lines.

1. Select Menu → Settings → Network →

Set Phone Line.

2. Select the other line and press .

Note: Before you can switch between phone lines,

you must first establish a second phone line with your service provider. Once it has been established, a second phone number becomes available in the menu for selection.

34 Customizing Your Phone

Data settings

Setting Com port speed

The Com Speed sets the data rate at which your phone connects to a laptop or PC, or at which it sends and receives over-the-air text messages.

1. Select Menu → Settings → Accessories →

Com Speed.

2. Select the speed. The options are: 19.2 kbps,

115.2 kbps (default), 230.4 kbps.

Note: There may be a higher charge for making

calls using high-speed data in areas where 1X service is available. Check with your service provider for details.

Setting the phone to receive data or faxes

Your phone may be able to receive certain data or faxes, depending on the system sending the information. To receive data or faxes, you must connect the phone to a laptop or PC and switch the phone from voice mode to data/fax mode.

Note: To purchase a cable, contact your service

provider, call (800) 349-4188 (U.S.A. only) or (858) 882-1410, or visit

www.kyocera-wireless.com/store.

1. Connect the phone to the laptop or PC.

2. Set the Com Speed.

3. Select Menu → Settings → Network →

Data/Fax Calls.

4. Press to select an option:

–

Voice only—Allow only voice calls. Fax next call or Data next call—Set the

–

phone to fax mode or data mode for the next incoming call or the next 10 minutes.

–

Fax until off or Data until off—Force the

phone into fax mode or data mode until the phone is turned off.

Note: You cannot receive voice calls while the

phone is in data/fax mode.

Connecting to a TTY/TDD device

TTY/TDD may not be available on your phone. Check with your service provider for availability.

You can connect the phone to a TTY device for the hearing impaired. using the phone with a TTY device.

1. Connect the TTY device to the phone.

2. Enter from

your keypad.

3. Press to select the TTY option.

Note: Enable TTY only when

User Guide for Kyocera Phantom Phones 35

Setting position location

This setting allows you to share your location information with network services other than emergency services (911, 111, 000, 999, etc.), in markets where service has been implemented.

Note: This feature works only when your phone is

in digital mode. You do not have the option of turning off the locator to emergency services.

1. Select Menu → Settings → Network →

Location.

2. If you see a message prompt, press

to continue.

3. Select 911 Only or Location On.

911 Only (default) shares your position

–

information only with emergency services when you call your 3-digit emergency code (911, 000, 111, 999, etc.).

–

Location On shares your position

information with your service provider’s network, in addition to emergency services.

For information on emergency calls, see “Calling emergency services” on page 7.

36 Customizing Your Phone

7USING VOICE RECOGNITION

Voice recognition allows you to make and answer calls by speaking commands into the phone’s microphone.

Note: You cannot use voice recognition to end a

call; you must press .

Setting up voice dialing

To make or receive calls using voice recognition (voice dialing), contacts must be saved and have associated voice tags.

Creating a voice tag for a contact

1. Select Menu → Contacts → Add Voice Dial.

2. Follow the voice prompts to record a name for

the contact.

3. Highlight an option:

–

Add new—Save a new contact to go with

the voice tag.

Add to existing—Add the voice tag to a

–

saved contact.

Viewing entries with voice tags

• Select Menu → Contacts → Voice Dial List.

A list of all contacts with assigned voice tags appears.

Editing a voice tag

1. Select Menu → Contacts → Voice Dial List.

2. Highlight the contact you want to edit, and press

to select it.

3. Highlight the phone number and press .

4. Select Add Voice Dial, Edit Voice Dial,

Erase Voice Dial.

5. Follow the prompts.

Calling using voice tags

1. If you haven’t already done so, record a voice

tag for the person you wish to call.

2. From the home screen, press . The phone

responds: “Say a name.”

3. Say the name of the person you want to call.

4. If the name you said matches a contact in the

Voice Dial List, the phone responds: “Calling (Name).” Remain silent to make the call, or say “

No” to cancel.

Note: If the phone finds multiple voice tags that

sound like the name you said, you will be asked to verify which name you want to call. Say “ when you hear the correct name. Say “ when you hear an incorrect name.

5. When you are finished, press . You cannot

end the call with a voice command.

Yes”

No”

User Guide for Kyocera Phantom Phones 37

Using voice features with hands-free car kits

You can use voice commands to make a phone call or to answer the phone only if your phone is connected to a professionally installed Kyocera hands-free car kit (sold separately).

Note: The following features apply only to

professionally installed hands-free car kits unless noted.

To shop for hands-free car kits, visit

www.kyocera-wireless.com/store, or call

800-349-4188 (U.S.A. only) or 858-882-1410.

Waking up the phone

If your phone is connected to a professionally installed Kyocera hands-free car kit, you can use a voice command to activate the phone to make a phone call.

Note: Voice Wake-up does not work with

Keyguard active.

To activate the Voice Wake-up setting:

1. Select Menu → Settings → Voice Services → Voice Wake-Up → With ext. pwr.

2. Select Menu → Settings → Keyguard →

Disabled, then press .

To wake up the phone:

1. Say “Wake Up” and listen for a tone.

2. Say “Wake Up” again until you hear two tones.

If the phone does not recognize your “Wake up” command, see “Training voice recognition” on page 39.

Answering the phone

You can set the hands-free car kit to either (1) answer automatically or (2) ring until you answer using a voice command.

Answering automatically

To set your phone to answer automatically:

•Select Menu → Settings → Accessories →

Auto-Answer → After 5 secs.

Note: This setting also works wih the portable

hands-free car kit.

Answering using voice commands

If Auto-Answer is turned off, you can use a voice command to answer an incoming call using the Kyocera hands-free car kit.

To turn off Auto-Answer:

•Select

Menu → Settings → Accessories →

Auto-Answer → Disabled.

38 Using Voice Recognition

To activate the Voice Answer setting:

1. Select Menu → Settings → Voice Services →

Voice Answer.

2. Highlight Enabled, then press .

3. Select Menu → Settings → Silent Mode →

Norm. Sounds then press .

To answer a call: When you receive an incoming call, the phone

responds: “Incoming call, answer?” or “Incoming roam call, answer?” If the caller is recognized as a saved contact entry, then the phone will say “Incoming call from (Name), answer?”

• Say “

Yes” or press any key except .

Ignoring an incoming call

To ignore an incoming call, do one of the following:

No” and press to silence the alert.

• Say “

• Remain silent. The voice alert repeats twice and the phone rings once, then returns to the home screen.

Training voice recognition

If your phone is having trouble recognizing your voice, you can train it with the commands “

No,” and “Wake up.”

1. Select Menu → Settings → Voice Services.

2. Select Voice Training.

3. Read the message and press .

4. Select Train All.

5. Follow the prompts for each word until training

is complete.

Note: The “Wake up” command can only be

used with a hands-free car kit or headset (both sold separately).

Yes,”

User Guide for Kyocera Phantom Phones 39

8USING TOOLS

Scheduler

The Scheduler allows you to schedule events and set reminder alerts.

Adding an event

1. Select Menu → Tools → Scheduler.

– For a day in this month, select View Day. Press

left and right to scroll through days.

– For a day in a different month, select

View Month. Press up or down to scroll

through months, and right or left to scroll through days.

2. Press to add an event to a selected date.

3. Enter a name for the event and press . For

help entering text, see page 13.

4. Set the event Start time, Duration, and Alarm

and press . – Press up or down to select hour,

minutes, and timing of alarm.

– Press left or right to move between fields.

5. Add a note to the event and press or press

twice

to finish.

Viewing, editing, or erasing an event

1. Select Menu → Tools → Scheduler.

2. Select View Day or View Month to find the event

you want to view, edit, or erase.

3. Press up, down, left, or right to highlight an

event and press to select it.

4. Press right and press to select Edit, Erase, or New. Follow the prompts.

5. Press to return to the home screen or

to return to scheduler options.

Alarm Clock

Use the Alarm Clock to set an alert for a specific time. The alert occurs only if the phone is on.

1. Select Menu → Tools → Alarm Clock → Set.

– Press up or down to select an hour

and minutes.

– Press left or right to switch between

hours, minutes, and a.m./p.m.

– Use the phone keypad to enter numbers.

2. Press to select Done and save the setting.

3. When the alarm rings, select Off to turn off the

alarm or

Snooze to silence the alarm for

10 minutes.

40 Using Tools

Tip Calculator

The Tip Calculator helps you calculate how much tip to include on a bill.

1. Select Menu → Tools → Tip Calculator.

2. Enter the amount of your bill and press .

3. Select the amount you want to include as a tip

(10%, 15%, 18%, 20%, Other) and press . Your total bill appears, including tip.

4. If you want to split the bill, press right and

press to select

5. Press to clear the default of 2 guests.

6. Enter the number of guests and press .

Split.

The amount each guest pays is calculated.

Calculator

Use the calculator for basic mathematical equations.

1. Select Menu → Tools → Calculator.

2. Use the keypad to enter numbers.

3. Press to select mathematical operations.

= equal + add x multiply ÷ divide - subtract . decimal point

C Clear all numbers entered and display a zero. MR Display the value currently stored in memory. M+ Add the displayed digit to the value stored

in memory. MC Clear the value currently stored in memory. ± Change the sign of the displayed number.

Clear one function or one digit from the screen. Hold down to clear all of the digits and operations and display a zero.

Exit the calculator and return to home screen.

World Clock

World Clock may not be available on your phone. Check with your service provider for availability.

The World Clock lets you check times in cities around the world in relation to local time.

1. Select Menu → Tools → World Clock.

The World Clock menu is displayed. Your local time and date is on the first line, followed by your selected world city and that city’s time and date.

When you first access World Clock, you are prompted to select a city.

2. Press to select Cities.

The Cities menu is displayed, showing 85 world cities in alphabetical order.

3. Press up or down to scroll through the

cities list. You can also use the number keys (2-9) to alphabetically tab through the list.

4. Press to select a city, like Athens.

The World Clock menu is displayed again, with Athens’ time and date.

User Guide for Kyocera Phantom Phones 41

From the World Clock menu, you can also select

Search to search by city or country.

1. Select Search from the World Clock menu.

The Search By menu is displayed.

2. Select your type of search.

– Press search by

City.

– Press down, then press to search

Country.

3. If you search by City, the Find City screen

is displayed.

a. Use your number keys (2-9) to enter the

letter(s) by which you want to search. For example, press

b. Press Search. c. Cities beginning with A are displayed, like

2 once to enter the letter A.

Anchorage, Athens, and Atlanta.

d. Use to move through the list, then press

to select a city.

4. If you search by Country, the Find Country

screen is displayed.

a. Use your number keys (2-9) to enter the

letter(s) by which you want to search. For example, press

b. Press Search. c. Countries beginning with A are displayed,

2 once to enter the letter A.

like Afghanistan, Algeria, and Australia.

d. Use to move through the list, then press

to select a country.

Timer

This timer counts down for a specified amount of time. It beeps when that amount of time has elapsed.

1. Select Menu → Tools → Timer.

2. Press to Set.

3. Press up or down to set the hours, minutes,

and seconds. To move the cursor, press left or right.

4. Select Start to begin the countdown. Stop to pause the countdown.

Select

5. When the alarm rings, press to silence it.

Stopwatch

1. Select Menu → Tools → Stopwatch.

2. Select Start to have the stopwatch begin counting.

3. Select Stop to stop counting.

4. Select Reset to set the counter back to zero and

begin counting again. Press when finished.

42 Using Tools

9MEDIA GALLERY / FUN & GAMES

The games described in this chapter may not be available on your phone. Check with your service provider for availability.

If you receive an

incoming call alert while you are

playing Tetris® or Brick Attack™, the game is paused and exited. You can return to play once the call alert ends. Games do not remain paused if the phone is turned off or loses power.

Tetris

The goal of this game is to guide the falling blocks down the screen to create a solid horizontal row at the bottom. The game ends when the new block cannot enter the play field because the area is occupied by another block or obstacle.

1. Select Menu → Fun & Games → Tetris.

2. Press to select Yes at the prompt, “Turn off

backlight to conserve battery?”

3. Select an option and press to select it.

–

New Game—Initiates game play. To pause

the game, press or . Pressing returns you to the menu where you can

Continue Game to resume or choose from

the other available options.

Resume Saved—Returns you to the game

–

you were last playing.

–

Scoreboards—Displays the top five scores

for the different game variations, including

No Time Limit (default), Timed 2 Min, Timed 3 Min, Timed 5 Min., and Garbage.

Settings—Choose a level of play, sounds,

–

and game type:

Starting level—Choose a level of play.

– –

Game Type—Choose type of game.

–

Sound—Choose when music will play

with this game:

Title, or No Sound (The No Sound

Sound Always, During

setting does not silence the sounds made when you press keys. To silence keys, see “Silencing all sounds” on page 28.)

Navigation: Use the following keys to guide the

blocks down the screen:

To: Use:

Rotate Counterclockwise

Hard drop

Move Left

Rotate Clockwise

Move Right

Soft drop the tile

Return to Tetris menu

Pause

or left

, , or up

or right

or down

User Guide for Kyocera Phantom Phones 43

Brick Attack

The goal of this game is to eliminate bricks arranged in levels. You send a moving ball upward using a paddle at the bottom of the screen.

1. Select Menu → Fun & Games → Brick Attack.

2. Press to select Yes at the prompt, “Turn off

backlight to conserve battery?”

3. Press to select New.

– To pause the game, press , then press

Resume.

– To move the paddle, press left or right.

4. To exit the game, highlight Exit and press .

Doodler

You can create and save graphics on your phone.

1. Select Menu → Media Gallery

(or Fun & Games)→ Doodler.

2. Wait 5 seconds for the intro screen to

disappear, or press to clear it.

3. Select New Doodle to open the drawing screen.

cursor

4. Use keys 1–9 to move the cursor

around the screen.

Note: Press to bring the cursor

back to center.

Note: For more drawing tips, refer to the

following sections.

Select a drawing color

1. Press left or right to highlight Color at the

bottom of the screen. Press .

2. Highlight a color from the palette and press .

Move cursor away from drawing

1. Press up or down to select .

(Shortcut: Press .)

2. Press a number key to move the cursor.

Note: To start drawing again, select a drawing

shade or color.

Clear screen

• Press .

44 Media Gallery / Fun & Games

Erase part of drawing

1. Press up or down to select .

2. Press a number key to move the eraser.

Add a shape

1. Press left or right to select Add Shape.

2. Press .

3. Select a shape and press .

4. To modify the shape, press right or left to

highlight an option and press

Options are Size, Rotate, and Move. (To move the shape, use keys 1–9.)

5. Select Done.

Saving the doodle

It is a good idea to save the doodle while you are working on it. If you receive a call while creating an unsaved doodle, it will be lost.

• Highlight

Save and press . The image will be

saved in the My Pictures folder. (See page 46.)

Note: If you make changes to an existing

doodle, you must save it with a different name.

Resuming a doodle

• To return to the last saved doodle you were working on, select

Fun & Games) → Doodler → Resume Doodle.

To return to another saved doodle, select

Media Gallery (or Fun & Games) → Doodler →

My Pictures.

Menu → Media Gallery (or

Menu →

My Sounds

Your phone contains preset sounds, which you can add to outgoing text messages. Check with your service provider for availability.

To access stored sounds:

1. Select Menu → Media Gallery (or Fun & Games) → My Sounds.

2. Press up or down to scroll through

the sounds.

3. Highlight an option and press to select it:

–

Play allows you to listen to the sound. Send opens a new message entry screen.

–

Assign allows you to use the sound as a

–

ringer on your phone.

–

Delete erases the sound from your My Sounds list.

User Guide for Kyocera Phantom Phones 45

My Pictures

The My Pictures menu stores 25 graphics you have created using the Doodler or received via text messaging. It also includes predefined graphics for your use. Check with your service provider for availability.

Note: All downloaded graphics are also stored in

the Screen Saver menu.

To view, edit, or erase graphics:

1. Select Menu → Media Gallery (or Fun & Games) → My Pictures.

2. Press up or down to scroll through

the graphics.

3. Highlight an option and press to select it:

–

Send opens a new message entry screen. Assign sets your graphic as a screen saver.

–

Edit takes you to the Doodler, where you

–

can modify the graphic. You cannot edit predefined graphics.

–

Delete erases the graphic from memory.

The graphic is also erased from the Screen Saver menu. (You cannot delete predefined graphics that came with the phone.)

–

Exit returns you to the home screen.

Saving memory

It is a good idea to erase old sounds and pictures, as they take up memory in your phone. To erase a sound or picture, select it and and then select

Delete. Refer to “My Sounds” and “My Pictures”.

46 Media Gallery / Fun & Games

10 CONNECTING TO THE INTERNET

Using the Web Browser

You can use your phone to browse the Internet if you have obtained phone Internet services from your service provider and if over-the-air Internet access is available in your area.

Note: You cannot receive incoming calls while you

are using the Web Browser.

Starting the Web Browser

1. Select Menu → Web Browser.

A message about airtime fees appears every time you start the browser.

To cancel the message, see “Changing the Web prompt” on page 48.

For more information about how airtime is charged, contact your service provider.

2. Press to continue.

If this is the first time you have connected to the Internet, a message informs you that security is not yet enabled for your Web Browser.

3. Press to select Yes to enable security.

When you are connected, a browser home page appears. It has a list of bookmarks and some Web menu options at the bottom of the screen.

– A appears in a secure session.

– An underline and an arrow indicate that

there is more text. Press down to view more text. Press to return to the previous screen.

4. When you have finished using the Internet,

press to exit the browser.

Using the Web menu options

The following options may appear on your screen:

•

Home returns you to the main Web Browser

window, or home page.

Mark Site saves the current location as a

• bookmark for easy access.

Bookmarks displays a list of your saved

• Web sites.

•

Setup gives you options for changing how

information is displayed.

Show URL displays the entire URL.

–

About Openwave displays information

–

about your Web Browser version.

–

Encryption should not be used unless you

are instructed to do so by your service provider.

–

UP.Link selects a different browser server.

You can use this option if you have more than one Web Browser account.

–

Restart restarts the Web Browser.

User Guide for Kyocera Phantom Phones 47

Searching for a Web site

How you search for a Web site depends on your service provider. For more information, contact your service provider.

Bookmarking a Web site

1. Go to the site you would like to bookmark.

2. Select Mark Site from the bottom of the screen.

Going to a bookmarked site

1. Select Menu → Web Browser.

2. If you see a message prompt, press

to continue.

3. From your Web home page, press

right to highlight

Bookmarks. A list of

bookmarks appears.

4. Enter the number corresponding to the

bookmark you want and press .

Checking Net alerts

Alerts received from a Web site are sent to your Net

Alerts inbox.

1. Select Menu → Messages → Net Alerts.

This action launches the browser inbox.

2. Press to accept browser fees.

3. Select an alert and follow the prompts.

Changing the Web prompt

1. Select Menu → Settings → Convenience →

Web Prompt.

2. Highlight an option and press to select it:

–

At Start confirms that airtime fees will be

applied when you use the browser.

At End verifies you want to exit the browser.

–

Both prompts you when you start the

–

browser and exit the browser.

–

No Prompts does not use any prompts.

48 Connecting to the Internet

INDEX

Numerics

1-Touch dialing, 9

Alarm Clock, 5, 40 alerts

for headsets

, 34

for messages, 34

for missed calls, 7 analog mode, 5 auto-hyphenation, 31

backlighting, 31 banner, 30 battery, 1 blocking outgoing calls, 33 bookmarks, 48 Brick Attack, 44

Calculator, 41 call counters, 10 callback number, 21 Contacts directory, 16 contrast, 31 countdown timer, 42

data/fax setup, 10, 35 digital mode, 5 display contrast, 31 Doodler, 44

emergency

position location

User Guide for Kyocera Phantom Phones 49

, 5, 36

erasing

contact entries

, 34

text messages, 25

Fast Find, 19 fax mode, 35 finding a saved phone number, 18 flashing lights, 31 frequent contacts, 18

games

Brick Attack

, 44

Doodler, 44 Tetris, 43

hands-free car kit

answering using voice

, 38

purchasing, v

hands-free headset

and phone ringer

, 34

jack, 3 purchasing, v

hard pause, 17

icons, 5 InBox, 24

keyguard, 5, 10 keypad, locking, 10

language, 30 lights, 31

lights-only mode, 5, 28

set to flashing, 31 limiting calls out, 33 lock code, 33 locking

, 10

keypad

phone, 33

memory, saving, 25 menu view, 30

number mode, 13 number type, 16

OutBox, 23

phone book (Contacts directory),

phone numbers

editing

, 17

finding, 19

saving, 16

verifying your own, 2 phone, unlocking, 33 portable hands-free car kit, 38 position location, 5, 36 prepend, 8, 18

QuickText, 21, 22, 26

redialing a number, 6 resetting the phone, v

ringers

choosing types

, 28

for different calls, 29 for roaming calls, 11 silencing, 2 volume, 29

roaming, 5

alerts, 11 controlling, 11 ringer, 11

saved phone numbers

editing

, 17

finding, 19 Scheduler, 40 screen contrast, 31 screen icons, 5, 7, 13, 23, 28 screen savers, 32 secret contacts, 8, 16 security, 32 shortcuts, 29 silent mode, 5, 28 smileys, 21 sound files, 45 speed dialing, 8 Stopwatch, 42 symbol mode, 14

Tetris, 43 text entry, 13

quick reference, 15 text messages, 20 time format, 32 Timer, 42 timing calls, 10 Tip Calculator, 41

TTY/TDD, 35

unlocking the phone, 33

vibrate, 5, 28 Voice Answer, 38 voice dialing, 37 voicemail, 2, 9 volume

, 7, 10, 29

earpiece key beep, 29 ringer, 29

Web Browser, 47 World Clock, 41

50 Index

Kyocera PHANTOMK 450 User Guide

Specifications and Main Features

Frequently Asked Questions

User Manual
